Coolview®
The Brightest LED Examination Lights
Coolview® Accurate Illumination For All Your Examination Needs
“Brandon Medical is a UK manufacturer and
designer of world-leading technology for
operating theatres, critical care areas and
primary care institutions. For over 70 years,
Brandon Medical has provided healthcare
professionals with reliable, high-quality and
affordable medical equipment. Continuous
investment in our products allows us to meet
the ever-changing needs of our customers,
the healthcare industry and the patients it
serves.”
Coolview® CLED23
Coolview® CLED11FX
Lights to suit all of your clinical needs
Brandon Medical provides a comprehensive range of
LED medical lights to suit all of your clinical needs.
Brandon Medical’s LED medical lights use the latest
innovations in LED lighting technology to provide you
with better performance and lower lifetime costs.
The choice of medical lights we offer vary in light
intensity, light colour, mounting structures and price
so you can choose a light that meets all of your
clinical examination needs.
Coolview® CLED11SX
Premium Performance
Coolview® CLED23TM
Advanced best-in-class lighting intensity, anti-microbial
examination lamp.
Coolview® CLED10
Coolview® CLED23TM delivers the highest lighting
performance and colour corrected light, reducing eye
strain making the focus of the light vivid and tissues
easily identified.
General Examination
Coolview® CLED11TM SX & FX
Bright natural light, high intensity compact
examination lamp.
CLED11TM examination lamp is the perfect mid-range
lamp for a wide range of procedures. The CLED11TM
provides a high intensity, bright natural light, perfect for
medical consultation in primary care and medical clinics.
Coolview® CLED10TM
Compact, high intensity examination lamp with slimline
light head.
CLED10TM examination lamps use unique diamond optics
to reflect light at different angles. Ideal for primary
care areas.
Economical
Coolview® Eco
Coolview® EcoTM
Lighting performance to suit your healthcare speciality
and your budget.
Coolview® EcoTM emits an intense white bright light using
only 7 watts of power.
Coolview® CLED23TM Premium Performance
Coolview® CLED23TM provides uncompromising
lighting performance for the clinician. Its high
intensity performance and colour corrected light
make the focus of the examination vivid and
natural. The CLED23™ is a perfect light for
dermatology, ENT, Gynaecology and sensitive
areas such as neonatal and ICU departments.
CLED® 23T1C
Highest Light Quality
360°
CLED23TM emits 60,000 Lux of intense bright
light at 0.5m, providing a pool of clear light during
procedures. The light intensity can be altered
through 4 easily selectable settings providing a
suitable level of intensity for all procedures.
Large Illuminated Area
A large illuminated area of 190mm diameter
makes it easy to examine large areas of tissue and
makes it easier to target the light on the patient.
High Colour Rendition
Day Light
CLED23 reproduces all of the visible colours
naturally and accurately. The high Ra of ≥95
describes the exceptionally high quality of white
light whilst the high R9 of ≥90 measurement
describes how it accurately reproduces visible red.
TM
Colour Control Settings
CLED23TM allows the user to adjust the colour
temperature of the light source. This enhances
the clinician’s ability to recognise and distinguish
tissue conditions. The warm white (3,500°K)
setting is ideal for dermatological examinations
and the daylight white setting (4,500°K) is ideal
for the recognition of blood vessels.
Warm Light
Sanitized® for Lasting Protection
The CLED23TM uses an anti-microbial active substance
which is moulded into the lamp head, inhibiting the
growth of micro organisms including MRSA. This is
more than an external coating and allows the lamp to be
permanently resistant to contamination.
The Science Behind the Sanitizing
Bacteria
Moisture
CLED® 23TXMP
Material with Silver ions
The anti-microbial substance is integrated into the light
head during manufacturing. It inhibits the growth of and
proliferation of microbes and bacteria whilst the silver
ions destabilise the cell membrane. This prevents the
bacteria from multiplying. Tests have shown that 99% of
bacteria and germs are destroyed using the Sanitizied®
active substance.
To find out more visit:
www.sanitized.com/en.html
Environmentally Friendly
16 powerful and long lasting LEDs (30,000 hours)
provide a maintenance free light source whilst using
minimal power consumption. The LEDs do not contain
mercury, lead, cadmium, CFCs, POPs, VOCs or
halogens.
Coolview® CLED23TM Premium Performance
Full Rotation of Light Head
The Coolview® CLED23TM light head boasts
360° rotation. This allows the user to position
the light beam to suit any procedure, without
any restrictive stops or twisted cables. This also
means the examination light can be used to
provide ambient room lighting by reflecting light
from the ceiling. This is a feature often used in
neonatal care to provide night lighting.
Full Rotation at Ceiling Pole
Ceiling mounted models (CLED23T1C) also have
unrestricted 360° rotation at the ceiling pole
providing even more positioning flexibility.
Long Arm Reach & Large Angular
Movements
The exceptionally long, 1200mm arm reach
of the CLED23TM ensures the powerful beam
can be positioned all around the patient couch.
This allows for ‘head to toe’ examination of the
patient without the need for patient repositioning
during examination.
Spring-Balanced Positioning
Innovative spring-balanced arm system ensures
the light is positioned effortlessly, remains fixed
in place and is maintenance-free.
Fully Enclosed Light Head
The light head is sealed to prevent the ingress of
dust and moisture to IP43.
360°
Intuitive Control Panel
The easy to use and ergonomic control pod allows all
lighting features to be adjusted with a simple press of
the button.
Technical Data
CLED®
Light Intensity (at 0.5m)
60,000 Lux
Illuminance Field
210mm
LED Life
30,000 hours L70 B50
Colour Temperature
3,500°K - 4,500°K (2 Steps)
Colour Rendition Index (Ra)
≥95
Colour Rendition Index Red Colour (R9)
≥90
Power Consumption
True Power 14.9W
Apparent Power 20VA
IP Rating
20
Head Rotation
360°
Class of Protection
II
Safety Standards
EN 60601-1, EN 60601-2-41
Mounting Options
Ceiling, back-plate, desk,
mobile, wall & rail
23TXMP
Part Numbers
CLED23T1C
Ceiling mounted examination light
CLED23TXBP
Back-plate mounted examination light
CLED23TXDP
Desk mounted examination light
CLED23TXMP
Mobile mounted examination light
CLED23TXWP
Wall mounted examination light
CLED23TXRP
Rail mounted examination light
CAR14443
Coolview® rail mount accessory kit
All models are supplied as standard with a 1.8m cable terminating in a UK plug.
Additional Wiring Options
CC1MKL
1 metre Curly Cord UK Plug
CC3MSL
3 metre Schuko Plug
CC3MUL
3 metre US Plug
Coolview® CLED11TM LED Examination Lights
Coolview® CLED11TM examination lights are the perfect light source for a wide
range of procedures. Providing a high intensity, bright natural light, CLED11TM
is perfect for medical consultation in primary care and medical clinics.
Delivering High Illumination
CLED11TM emits 40,000 Lux of bright natural light at 0.5m providing an
intense, clear light source for use in general consultation areas.
Perfect Colour
Coolview® CLED11L1C
The colour corrected light source with a colour temperature of 4,400°K
allows for accurate representation of tissue during examination.
The CLED11TM has a high Ra of ≥93 which describes the
exceptionally high quality of white light whilst the high R9 of ≥90
measurement describes how accurately it reproduces visible red.
Comfortable, Cool Light Source
CLED11TM does not emit any infrared radiation, avoiding heat
exposure during examinations.
Large Illuminated Area
A large illuminated area of 180mm diameter makes it easy to
examine large areas of tissue and makes it easier to target the light
on the patient.
Spring-balanced and Multi-flex Technology
The FX arm ensures smooth, easy positioning and the arm will stay
fixed into position without drifting. The arm has a reach of 940mm
and includes an integrated transformer.
The SX arm also ensures smooth and easy positioning but has an
enhanced flexible arm for precise positioning.
Both have a turn restrictor to prevent the light from being pushed into the
wall and locking devices to prevent accidental removal from fixing brackets.
Unrestricted 360° Ceiling Pole Rotation
The Coolview® CLED11TM ceiling mounted examination light boasts
unrestricted 360° rotation. This allows the user to position the light beam
to suit any procedure, without restrictive stops and twisted cables.
Coolview® CLED11FXMP
Technical Data
Coolview® CLED11SXRP
CLED11FX
Light Intensity (at 0.5m)
CLED11SX
40,000 Lux
Illuminance Field
180mm at 0.5m
LED Life
30,000 hours L70 B50
Colour Temperature
4,400°K
Colour Rendition Index (Ra)
≥93
Colour Rendition Index
Red Colour (R9)
≥90
Power Consumption
Arm Reach
True Power 8-13W
Apparent Power 18.1 VA
940mm
Head Rotation
850mm
270°
Class of Protection
II
Safety Standards
Mountings
EN60601-1, EN60601-2-41
Ceiling, back-plate,
desk, mobile,
rail & wall
Back-plate,
desk, mobile,
rail & wall
CLED11FX Part Numbers
CLED11L1C
Ceiling mounted examination light
CLED11FXWP Wall mounted examination light
CLED11FXBP
Back-plate mounted examination light
CLED11FXDP
Desk mounted examination light
CLED11FXRP
Rail mounted examination light
CLED11FXMP
Mobile mounted examination light
CAR14443
Coolview® rail mount accessory kit
CLED11SX Part Numbers
CLED11SXWP Wall mounted examination light with multiflex arm
Coolview® CLED11SXMP
CLED11SXRP
Rail mounted examination light with multiflex arm
CLED11SXBP
Back-plate mounted examination light with multiflex arm
CLED11SXDP
Desk mounted examination light with multiflex arm
CLED11SXMP Mobile mounted examination light with multiflex arm
CAR14443
Coolview® rail mount accessory kit
All models are supplied as standard with a 1.8m cable terminating in a UK plug.
Additional Wiring Options
CC1MKL
1 metre Curly Cord UK Plug
CC3MSL
3 metre Schuko Plug
CC3MUL
3 metre US Plug
Coolview® CLED10TM LED Examination Lights
Coolview® CLED10TM examination lights provide
excellent lighting performance to suit your healthcare
speciality and budget.
Professional Light Quality
Thanks to its unique diamond optics, Coolview®
CLED10TM emits 50,000 Lux of intense bright light at
0.5m perfect for medical procedures.
Large Illuminated Area
A large illuminated area of 180mm makes it easy to
examine large areas of tissue.
Ergonomic
The CLED10TM offers a 280° lamp head rotation with
an ergonomic handle offering control of the light.
Coolview® CLED10STRP
Flexibility
The flexible arm ensures positional accuracy and
good durability. The sealed construction protects
against contamination.
Colour Corrected Light Source
The colour corrected light source with a colour
temperature of 4,400°K allows for accurate
representation of tissues during examination.
High Colour Rendition
CLED10TM reproduces all of the visible colours
naturally and accurately. The high Ra of ≥93 describes
the exceptionally high quality of white light whilst
the high R9 of ≥91 measurement describes how it
accurately reproduces visible red.
Coolview® CLED10STMP
Technical Data
Sturdy Handle
Light Intensity (at 0.5m)
50,000 Lux
Illuminance Field
180mm at 0.5m
LED Life
50,000 hours L70 B50
Colour Temperature
4,400°K
Colour Rendition Index (Ra)
≥93
Colour Rendition Index Red Colour (R9)
≥91
Power Consumption
13W
Head Rotation
280°
Class of Protection
II (double insulated)
Safety Standards
EN60601-1, EN60601-2-41
Mounting Options
Rail, desk, mobile & wall
Part Numbers
CLED10STBP
Back-plate mounted examination light
CLED10STDP
Desk mounted examination light
CLED10STMP
Mobile mounted examination light
CLED10STWP
Wall mounted examination light
CLED10STRP
Rail mounted examination light
CAR14443
Coolview® rail mount accessory kit
All models are supplied as standard with a 1.8m cable terminating in a UK plug.
Additional Wiring Options
On/Off Switch
CC1MKL
1 metre Curly Cord UK Plug
CC3MSL
3 metre Schuko Plug
CC3MUL
3 metre US Plug
Coolview® EcoTM Economical Examination Lights
Economical and Efficient
The Coolview® EcoTM LED examination light is
perfectly suited for consulting rooms and
GP treatment rooms. Coolview® EcoTM emits an
intense, white bright light equivalent to a 20W
halogen bulb but only using 7W.
Positioning and Long Reach
Articulated arm system ensures the light is easy
to move, easy to position and does not drift.
Long arm reach extends to 900mm to provide a
large working envelope
Cold Light
Coolview® EcoTM LED does not emit infrared
radiation, avoiding heat exposure during
examinations and increasing safety.
Environmentally Friendly
No mercury, lead, cadmium, CFCs, POPs, VOCs
or halogens. LED life is 30,000 hours, over
15 years of normal use, making Coolview®
EcoTM highly economical.
Coolview® Eco ELED7HXMT
Coolview® Eco ELED7HXWT
Technical Data
Light Intensity (at 0.5m)
15,000 Lux
Illuminance Field
300mm at 0.5m
LED Life
30,000 hours (L70)
Colour Temperature
4,000°K
Power Consumption
True Power 7-11 W
Apparent Power 19-27 VA
Head Rotation
270°
Class of Protection
II
Safety Standards
EN 60601-1, EN 60601-2-41
Mounting Options
Rail, desk, mobile & wall
Part Numbers
ELED7HXBT
Back-plate mounted examination light
ELED7HXDT
Desk mounted examination light
ELED7HXMT
Mobile mounted examination light
ELED7S3M
Mobile mounted examination light with
flexible arm*
ELED7HXWT
Wall mounted examination light
ELED7HXRT
Rail mounted examination light
CAR14443
Coolview® rail mount accessory kit
*Not suitable for gynaecological procedures
Coolview® Eco ELED7S3M
Coolview® LED Examination Lights – Mounting Options
Brandon Medical’s LED examination lamps are available in a variety of mountings to suit all clinical environments.
If you are unsure which mounting option is most suitable, please use the below as a guide to finding the most
appropriate configuration.
Ceiling
Mobile
n
n
n
Ideal for getting as close to the patient as possible
Easy to move and position
Use the light in multiple rooms
Wall
Lowest cost option
Can be hard wired into the wall, freeing up plugs
and floor space
n More secure than a mobile light
n
n
Wall
Back-plate
Back-plate
Should be used on non load-bearing walls for
example partition walls
n Can be hard wired into the wall, freeing up plugs
and floor space
n More secure than a mobile light
n
Desk
Rail
Added flexibility over a wall mounted light
Allows the light to be positioned nearer to the
point of examination
n Allows for easy movement along the couch length
n
n
Rail
Ceiling
n
n
n
n
Can be mounted anywhere in the room
Can be positioned out of the way
Ideal when space is limited
Longer arm reach
Mobile
Use our guide to find the perfect light for your application
Speciality
Rail Mounted
Wall Mounted
Mobile Base
Ceiling Mounted
Desk Clamp
A&E Consulting
All Applicable
All Applicable
All Applicable
X
X
A&E Minors
CLED23/CLED11
CLED23/CLED11
CLED23/CLED11
CLED23/CLED11
X
Anaesthetics
X
X
X
CLED23
X
Critical Care
CLED23/CLED11/CLED10 X
CLED23
X
X
Dermatology
All Applicable
All Applicable
X
X
X
Endoscopy
X
X
CLED23
X
X
General Practioner
All Applicable
All Applicable
All Applicable
All Applicable
All Applicable
General Ward
CLED11/ELED7/CLED10
All Applicable
X
X
X
Gynaecology
CLED23/CLED10
CLED23/CLED10
X
CLED23
X
Intensive Care Unit
CLED23/CLED10
X
CLED23/CLED10
X
X
Neonatal Care
CLED23/CLED10
X
CLED23/CLED10
X
X
Obstetrics
CLED23
CLED23
X
CLED23
X
Patient Room
CLED11/ELED7
CLED11/ELED7/CLED10
X
X
X
Exceeding Standards
Brandon Medical is certified as an
ISO 13485 and ISO 9000 manufacturer,
the global standard for medical device
manufacturers.
Brandon Medical Coolview® lights
conform to IEC 60601-1, IEC 606011-2
and IEC 60601-2-41
UK Customs
Approved Exporter
Status GB 16164/13
Coolview® lights are part of the Brandon Equipment Package.
Brandon Medical Co Ltd, Elmfield Road, Morley, Leeds, LS27 0EL
T: +44 (0)845 1243 666 F: +44 (0)845 1243 667
T: +44 (0)113 2777 393 F: +44 (0)113 2728 844
E: [email protected]
www.brandon-medical.com
In line with the Brandon policy of progressive improvement, the right is reserved to alter specifications and/or pieces without notice.
Brandon Medical and Coolview® are registered trademarks of Brandon Medical Co Ltd.
12/05/2017
A2 14307
Operating Theatre Lights and Battery Back Up
Minor Surgical Lights
Examination Lights
Theatre Control Panels
PACS Workstations
IPS Isolated Power Systems
UPS Uninterruptible Power Systems
Medical Gas Pendants and Accessories
Ultra Clean Ventilation Canopies
Operating Table and Accessories
Digital Audio Video Solutions
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
