[Specifications]
Type
Type
Recording Media
Digital, AF/AE single-lens reflex, camera with built-in flash
CF Card Type I and II, UDMA-compliant CF cards, via external
media (USB v.2.0 hard drive, via optional Wireless File Transmitter
WFT-E5A)
Image Format
Compatible Lenses
22.3 x 14.9 mm (APS-C size)
Canon EF lenses including EF-S lenses
(35mm-equivalent focal length is approx.1.6x the lens focal length)
Canon EF mount
Lens Mount
Image Sensor
Type
Pixels
Pixel Unit
Aspect Ratio
Color Filter System
Low-pass Filter
Dust Deletion Feature
Recording System
Recording Format
Image Format
File Size
High-sensitivity, high-resolution, large single-plate CMOS sensor
Effective pixels: Approx. 18.0 megapixels
Total pixels: Approx. 19.0 megapixels
4.3 μm square
3:2 (Horizontal: Vertical)
RGB primary color filters
Fixed position in front of the CMOS sensor
(1) Automatic Sensor Cleaning
• Removes dust adhering to the low-pass filter.
• Self-cleaning executed automatically (taking 2 sec.) when
power is turned on or off. Manual execution also possible
(taking 6 sec.).
• Low-pass filter has a fluorine coating.
(2) Dust Delete Data appended to the captured image
• The coordinates of the dust adhering to the low-pass filter
are detected by a test shot and appended to subsequent
images.
• The dust coordinate data appended to the image is used by
the provided software to automatically erase the dust spots.
(3) Manual cleaning of sensor
Design rule for Camera File System 2.0 and Exif 2.21
Still: JPEG, RAW (14-bit, Canon original), sRAW, mRAW,
RAW+JPEG
Video: MOV (Image data: H.264, Audio: Linear PCM)
(1) Large: Approx. 17.90 Megapixels (5,184 x 3,456)
(2) Medium: Approx. 8.00 Megapixels (3,456 x 2,304)
(3) Small: Approx. 4.50 Megapixels (2,592 x 1,728)
(4) RAW: Approx. 17.90 Megapixels (5,184 x 3,456)
(5) M-RAW: Approx. 10.10 Megapixels (3,888 x 2,592)
(6) S-RAW: Approx. 4.50 Megapixels (2,592 x 1,728)
Exact file sizes depend on the subject, ISO speed, Picture Style,
etc.
File Numbering
Color Space
Picture Style
Recording Functions
Backup Recording
White Balance
Settings
Auto White Balance
Color Temperature
Compensation
Color Temperature
Information
Transmission
Viewfinder
Type
Coverage
Magnification/Angle of
View
Eyepoint
Dioptric Adjustment
Correction
Focusing Screen
Mirror
Viewfinder Information
Consecutive numbering, auto reset, manual reset.
Possible to create new folders and select folders in the CF card.
Firmware Version 2.0.X allows manually setting the file name, the
first four alphanumeric characters, or the first three alphanumeric
characters + image size.
sRGB, Adobe RGB
Standard, Portrait, Landscape, Neutral, Faithful, Monochrome, User
Defined 1–3
Images record directly to the CF card. With the WFT-E5A attached,
image recording to the CF card and to the USB external media
connected to the WFT-E5A will be possible as follows:
(1) Standard
• No automatic switching of recording media.
(2) Automatic switching of recording media
• When the current recording media becomes full, it switches
to another recording media automatically and continues
recording.
(3) Separate recording
• Each recording media can be set to record a specific
image-recording quality for each shot.
(4) Recording of identical images
• Images can also be recorded at the same size to both
recording media. (RAW+JPEG, M RAW+JPEG or S
RAW+JPEG is possible).
(5) Backup to external recording media
• Selected images, all images, and quick backup are
possible.
Enabled with Wireless File Transmitter WFT-E5A attached
Auto, Daylight, Shade, Cloudy, Tungsten Light, White Fluorescent
Light, Flash, Custom, Color Temperature setting
Auto white balance with the image sensor
White Balance Correction: ± up to 9 levels, in 1-step increments
White Balance Bracketing: ± up to 3 levels, in 1-step increments
Provided
Eye-level pentaprism
Vertical/Horizontal approx. 100%
-1
Approx. 1.0x (-1m with 50mm lens at infinity) / 29.4° angle of view
Approx. 22mm (from eyepiece lens center)
-1
-3.0 to +1.0m (diopter)
Fixed
Quick-return half mirror (transmission: reflection ratio of 40:60) with
EF 600mm f/4L IS USM or shorter lenses)
AF information (AF points, focus confirmation light), Exposure
information (Shutter speed, aperture, ISO speed, AE lock, exposure
level, spot metering circle, exposure warning), Flash information
(Flash ready, flash exposure compensation, high-speed sync, FE
lock, red-eye reduction light), Image information (Highlight tone
Depth-of-Field Preview
Autofocus
Type
AF Points
AF Working Range
Focusing Modes
AF Point Selection
Selected AF Point
Display
AF-assist Beam
AF Function
Registration/Switching
Exposure Control
Metering Modes
Metering Range
Exposure Control
Systems
ISO Speed
(Recommended Exposure
Index)
priority, Monochrome shooting, maximum burst, white balance
correction, CF card information), Composition information (Grid,
electronic level), Battery check
Enabled with depth-of-field preview button
TTL-CT-SIR AF-dedicated CMOS sensor
19-point all cross-type AF (f/2.8 at center: Dual Cross Sensor)
EV -0.5 ~ 18 (at 73°F/23°C, ISO 100)
(1) Autofocus
- One-Shot AF
- Predictive AI Servo AF
* For automatic AF point selection, the AF point to start the AI
Servo AF operation can be selected.
* For automatic AF point selection, the active AF point can be
displayed.
- AI Focus AF (Switches between One-Shot AF and AI SERVO AF
automatically)
(2) Manual focus (MF)
(1) Manual selection: Single point AF
(2) Manual selection: Spot AF
(3) Manual selection: AF point expansion
(4) Manual selection: Zone AF
(5) Automatic selection: 19 point AF
Indicated by transmissive LCD display in the viewfinder and on the
LCD panel
When an external EOS-dedicated Speedlite is attached to the
camera, the AF-assist beam from the Speedlite will be emitted when
necessary.
With a Custom Function, four types of AF function settings can be
registered in a group: 1. AF area selection mode, 2. AI Servo
tracking sensitivity, 3. AI Servo AF tracking method, and 4. AI Servo
st nd
1 /2 img priority.
* This function can be assigned to the depth-of-field preview button
or lens A stop button by customizing camera controls/buttons
(Custom Controls).
63-zone SPC TTL metering with selectable modes
• Evaluative metering (uses all 63 zones; linked to active AF point)
• Partial metering (approx. 9.4% of viewfinder at center)
• Spot metering (approx. 2.3% of viewfinder at center)
• Center-weighted average metering
EV 1.0 ~ EV 20 (at 73°F/23°C with EF 50mm f/1.4 USM lens, ISO
100)
Program AE (Shiftable), Shutter-priority AE, Aperture-priority AE,
Creative Auto, Full auto, Manual exposure, E-TTL II autoflash
program AE
• Manually set by user, in P, Tv, Av, and M modes — ISO 100
thru 6400 (in 1/3 or full-stop increments)
• Automatic ISO setting in P, Tv, Av, and M modes — ISO 100–
6400; User-defined maximum ISO limit can be set from 400 thru
6400, in full-step increments (Firmware Version 2.0.X is
required)
• When Highlight Tone Priority is active: minimum possible ISO is
200
•
Automatic ISO setting in Basic Zone modes — ISO 100 thru
3200
Note: In Creative Zone modes (P, Tv, Av, M, and B modes) the
maximum settable ISO speed (400–6400) will vary within
the automatic automatic ISO speed range.*
Exposure Compensation
AE Lock
Shutter
Type
Shutter Speeds
Shutter Release
Self-Timer
Shutter Lag Time
Built-in Flash
Type
Flash Metering System
Guide Number
Recycle Time
Flash-ready Indicator
Flash Coverage
FE Lock
Flash Exposure
Compensation
External Speedlite
Zooming to Match Lens
Focal Length
Flash Metering
Flash Exposure
Compensation
FE Lock
External Flash Settings
PC Terminal
Drive System
Drive Modes
Continuous Shooting
Speed (Approx.)
Maximum Burst
*Firmware upgrade (Version 2.0.X) is required.
Up to ±5 stops in 1/3- or 1/2-stop increments (AEB ±3 stops)
* Indicated up to ±3 stops on the LCD panel and in the viewfinder.
Auto: Applied in One-Shot AF mode with evaluative metering when
focus is achieved
User-applied: By AE lock button
Vertical-travel, mechanical, Electronically-controlled, focal-plane
shutter
• 30 seconds to 1/8000th second; user-settable in 1/3 or full-step
increments (available shutter speeds vary by shooting mode); plus
Bulb
• X-sync at 1/250th second with EOS Speedlites
Soft-touch electromagnetic release
10-sec. or 2-sec. delay
Approx. 0.059 sec., according to Canon Inc. test methods and
criteria
Retractable, auto pop-up flash
E-TTL II auto flash; Manual flash and Multi flash also possible
12/39 (ISO 100, in meters/feet)
Approx. 3 sec.
Flash-ready icon lights in viewfinder
15mm lens angle of view (equivalent to approx. 24mm in 135
format)
Provided
±3 stops in 1/3- or 1/2-stop increments
Provided
E-TTL II autoflash
±3 stops in 1/3- or 1/2-stop increments
Provided
Flash function settings, Flash C.Fn settings
Provided
Single, High-speed continuous, Low-speed continuous, and Selftimer (10-sec. self-timer/remote control, or 2-sec. self-timer/remote
control)
High-speed: Max. 8.0 shots/sec
Low-speed: Max. 3.0 shots/sec
JPEG (Large/Fine): approx. 110* / approx. 130**
RAW: approx. 23*/approx. 25**
RAW+JPEG (Large/Fine): approx. 17* / approx. 17**
*Figures based on Firmware upgrade (Version 2.0.X), ISO 100,
Standard Picture Style and with 8GB CF memory card.
**Figures apply to 128GB UDMA 7 CF memory card.
Note: UDMA 7 CF memory card read/write speeds are not fully
supported with the EOS 7D Digital SLR camera, if using UDMA 7
memory cards, the read/write speeds will be equivalent to UDMA 6
Live View Functions
Shooting Modes
Focusing
Metering Modes
Metering Range
Grid Display
Exposure Simulation
Silent Shooting
Still photo shooting and video shooting
Quick mode (Phase-difference detection)
Live mode/Face detection Live mode (Contrast detection)
Face detection Live mode
Manual focusing (5x/10x magnification possible)
Evaluative metering with the image sensor (still photos)
Center-weighted average metering (video)
EV 1–20 (at 73°F/23°C with EF50mm f/1.4 USM lens, ISO 100)
Provided (Two-type grid displays)
Provided
Provided (Mode 1 and 2)
Video Shooting
File Format
File Size
Frame Rates
Continuous Shooting
Time
Focusing
Exposure Control
Exposure Compensation
LCD Monitor
Type
Monitor Size
Pixels
Coverage
Brightness Control
Coating
Interface Languages
Tilt Display
On LCD Monitor
In Viewfinder
Image Playback
Display Format
MOV (image data: H.264; audio: Linear PCM (monaural))
Recording Size: 1920 x 1080 (Full HD), 1280 x 720 (SD), 640 x 480
(SD)
1920 x 1080 (Full HD): 30p (29.97) / 24p (23.976) / 25p, 1280 x 720
(HD): 60p (59.94) / 50p, 640 x 480 (SD): 60p (59.94) / 50p
Approx. 12 min. (Full HD); 12 min. (HD); 24 min. (SD)
Based on Canon’s testing standards using a 4GB card
Autofocus: Quick mode, Live mode, Face Detection Live mode;
manual
Program AE, Manual exposure
±3 stops in 1/3- or 1/2-stop increments
TFT color, liquid-crystal monitor
3.0 in.
Approx. 920,000 (VGA)
Approx. 100%
Viewing angle: 170º
Auto: Brightness adjusted automatically by the light sensor, Manual:
7 levels provided
Anti-reflection, anti-dust coatings
25 (English, German, French, Dutch, Danish, Portuguese, Finnish,
Italian, Norwegian, Swedish, Spanish, Greek, Russian, Polish,
Czech, Hungarian, Romanian, Ukraine, Turkish, Arabic, Thai,
Simplified/Traditional Chinese, Korean, Japanese)
Electronic level indicates up to 360° roll and ±10° pitch in 1°
increments.
The AF point display is used to indicate up to ±6° roll and ±4° pitch
in 1° increments (during vertical shooting, up to ±4° roll and ±6°
pitch).
Single image, Single image + Image-recording quality/shooting
information, histogram, 4- or 9-image index, magnified view (approx.
Highlight Alert
1.5x-10x), rotated image (auto/manual), image jump (by 10/100
images, index screen, by shooting date, by folder), slide show (all
images/selected by date/folder)
Provided (Overexposed highlights blink)
Quick Control Function
Items
The following functions can be set (Press “Q “ button to access
Menu):
Shutter speed, aperture, ISO speed, exposure compensation, AEB,
flash exposure compensation, AF point selection (including AF area
selection modes), Picture Style, white balance, metering mode,
Auto Lighting Optimizer, image-recording quality, AF mode, drive
mode, and Custom Controls (camera controls/buttons
customization).
Image Protection & Erase
Protection
Erase
Direct Printing
Compatible Printers
Printable Images
Single images can be erase-protected or not
Single image, check-marked images or all images in the CF card
can be erased (except protected images)
PictBridge-compatible printers
JPEG images compliant to Design rule for Camera File System
(DPOF printing possible) and RAW/sRAW images captured with the
EOS 7D
Easy Print Feature
Provided
Digital Print Order Format
DPOF
Version 1.1 compatible
Direct Image Transfer
Compatible Images
JPEG and RAW/sRAW images
Only JPEG images can be transferred as wallpaper on the personal
computer screen
Customization
Custom Functions
Total 27
Custom Controls
The following camera controls can be customized by assigning the
desired function: Shutter button halfway pressing, AF-ON button,
AE lock button, depth-of-preview button, lens AF Stop button,
Multifunction button, SET button, Main Dial, Quick Control Dial, and
Multicontroller.
Camera User Settings
Register under Mode Dial's C1, C2 and C3 positions
My Menu Registration
Provided
Interface
USB Terminal
For personal computer communication and direct printing (USB 2.0
Hi-Speed), used for connecting the Canon GP-E2 GPS Receiver*
Video OUT Terminal
Extension System
Terminal
Power Source
Battery
*Firmware upgrade (Version 2.0.X) is required
(1) Video OUT terminal: NTSC/PAL selectable
(2) mini-HDMI OUT terminal
For connection to optional Wireless File Transmitter WFT-E5A
One Battery Pack LP-E6
AC power can be supplied via AC Adapter Kit ACK-E6
With Battery Grip BG-E7 attached.
Number of Shots
Number of shots (approx.)
Shooting Conditions
50% use of
AE 100%
built-in flash
Approx. 1000
Approx. 800
Approx. 900
Approx. 750
Temperature
Battery Life
Battery Check
Power Saving
Date/Time Battery
Startup Time
Dimensions & Weight
Dimensions (W x H x D)
Weight
Operation Environment
Working Temperature
Range
Working Humidity
At 73°F/23°C
At 32°F/0°C
Live View shooting at
Approx. 230
Approx. 220
73°F/23°C
Live View shooting at
Approx. 220
Approx. 210
32°F/0°C
The above figures apply with a fully-charged Battery Pack LP-E6
without a Battery Grip
The figures above are based on CIPA (Camera & Imaging Products
Association) testing standards
6-level display on top LCD panel.
"Battery Info" in Set-up Menu provides precise charge remaining
indication, in 1% increments.
Provided. Power turns off after 1, 2, 4, 8, 15 or 30 min.
One CR1616 lithium-ion battery
Approx. 0.1 sec. (Based on CIPA testing standards)
Approx. 5.8 x 4.4 x 2.9 in./148.2 x 110.7 x 73.5mm
Approx. 28.9 oz. / 820g (body only)
32–104°F/0–40°C
85% or less
All data are based on Canon's Standard Test Method. Subject to change without notice. If a problem occurs with a non-Canon lens attached to the camera, consult the lens maker.
Canon, DIGIC and EOS are registered trademarks of Canon Inc. in the United States and may
also be registered trademarks or trademarks in other countries. Microsoft, Windows and Windows
Vista are trademarks or registered trademarks of Microsoft Corporation in the United States
and/or other countries. Mac is a trademark of Apple, Inc., registered in the United States and
other countries. HDMI, the HDMI logo and High-Definition Multimedia Interface are registered
trademarks or trademarks of HDMI Licensing, LLC in the United States and/or other countries. All
other products and brand names are registered trademarks, trademarks or service marks of their
respective owners in the United States and/or other countries.
[What’s in the Box]
•
•
•
•
•
•
•
•
•
EOS 7D Body
EF 28–135mm f/3.5–5.6 IS USM*
Eyecup Eg (Not Shown)
Wide Neck Strap EW-EOS7D
Stereo AV Cable AVC-DC400ST
USB Interface Cable IFC-200U
Battery Pack LP-E6
Battery Charger LC-E6
“Great Photography is Easy”
Booklet and “Do More with Macro”
Booklet (Not shown)
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
