CA-MIC4-SH-NC
4-Pin Micro / Unterminated Shielded Cable, Page 1 of 1
Description
4-pin micro mating connector on one end of a 4 conductor round twisted pair 26 AWG cable.
Pin-out
Pin
Description
Color
1
+5VDC power
Orange or Red
2
A CHannel
Blue or Green
3
Ground
Brown or Black
4
B Channel
Yellow
Pin
Description
Color
1
+5VDC power
Orange or Red
2
A channel
Blue or Green
3
Ground
Brown or Black
4
B channel
Yellow
Pin-out
Ordering Information
CA-MIC4-SH-NC Notes
Length
1 - 500FT (Increments of 1FT)
US Digital warrants its products against defects
in materials and workmanship for two years.
See complete warranty for details.
Base Pricing
Quantity
Price
10
$6.80
For volume discounts, please contact us at [email protected] or 800.736.0194.
