System Configuration Example
VIDEO INTERCOM SYSTEM
LINE-UP CATALOGUE
System Units
Wireless Video Intercom System
VL-SWD501
Main Monitor Station
VL-MWD501
Wireless Monitor Station
VL-WD613
Up to
6
Door Station
Bedroom
Room 1
DECT Repeater
VL-V554
Room 2
VL-FKD2
Up to
Up to
2
Living Room
< 2 Wire >
Kitchen
Den
2
Garage
Wireless Sensor Camera
VL-PS240
VL-WD812
Up to
4
Electric lock
Electric lock
System Units
Video Intercom System
VL-SVN511
Main Monitor Station
VL-MVN511
Door Station
VL-V555
Up to
2
Bedroom
Room 1
Room 2
Mobile Devices
Up to
4
Router
Living Room
< 2 Wire >
Kitchen
Den
VL-PS240
VL-RLY1
Electric lock
Electric lock
