Table of Contents
SINGLE BOARD COMPUTER
PAGE
1-5
6
7
8
9-13
21 ROBO-8777VG2A
Table of Contents
About Portwell
About SBC (Single Board Computers)
About ESB
SBC Reference Table
FULL-SIZE SBC
Intel® CoreTM 2 Duo processor based PICMG
SBC with DDR2 SDRAM, VGA, Dual Gigabit
Ethernet, Audio and USB
ROBO-8777VG2A
22 ROBO-8773VG
Intel® CoreTM 2 Duo processor based PICMG SBC
with DDR SDRAM, VGA, Gigabit Ethernet and USB
ROBO-8773VG
14 ROBO-8921VG2R
23 ROBO-8719VG2AR
Dual/Quad Core™ Xeon® processor based
ROBO-8921VG2R
PICMG 1.3 SHB with DDR2 ECC SDRAM, VGA
& Dual Gigabit Ethernet
ROBO-8719VG2A
Intel® latest 45nm CoreTM 2 Duo or Celeron® M
processor based PICMG SBC with DDR2 SDRAM,
VGA, Dual Gigabit Ethernet and Audio
15 ROBO-8914VG2AR
ROBO-8914VG2AR
Intel® Core™ 2 Quad processor based
PICMG 1.3 SHB with DDR3 SDRAM, VGA,
Dual Gigabit Ethernet, Audio and USB
24 ROBO-8771VG2
Ultra Low Voltage Intel® Celeron M processor
based PICMG SBC with VGA and LAN
ROBO-8771VG
16 ROBO-8913VG2AR
Intel® Core™ 2 Quad processor based PICMG 1.3
SHB with DDR2 SDRAM, VGA, Dual Gigabit
Ethernet, Audio and USB
ROBO-8913VG2AR
25 ROBO-8718VG2A
Intel® Pentium® M or Celeron® M processor based
PICMG SBC with DDR2 533 SDRAM, VGA, Dual
Gigabit Ethernet and Audio
ROBO-8718VG2A
17 ROBO-8912VG2AR
ROBO-8912VG2AR
Intel® Core™ 2 Duo processor based PICMG 1.3
SHB with DDR2 SDRAM, VGA, Dual Gigabit
Ethernet, Audio and USB
26 ROBO-8713VGA
Intel® Pentium® 4 or Celeron® D processor based
PICMG SBC with DDR 400 SDRAM, AGP 8X VGA,
Gigabit Ethernet and Audio
ROBO-8713VGA
18 ROBO-8911VG2A
ROBO-8911VG2A
HALF-SIZE SBC
Intel® Pentium® M or Celeron® M processor based
PICMG 1.3 SHB with DDR2 SDRAM, VGA,
Dual Gigabit Ethernet, Audio and USB
19 ROBO-8910VG2A
27 ROBO-6711VGA
ROBO-6711VGA
Intel® Pentium® 4 or Celeron® D processor based
PICMG 1.3 SHB with DDR2 533 SDRAM, VGA,
Dual Gigabit Ethernet and Audio
28 ROBO-6730VLA
ROBO-8910VG2A
20 ROBO-8779VG2AR
ROBO-8779VG2AR
mPGA479M Pentium® M/Celeron® M processor
based half-sized PCI SBC with VGA, LCD,
GbE and Audio
ROBO-6730VLA
Ultra Low Voltage Intel® Celeron® M processor
based half-size PCI SBC with VGA, LCD, LAN
and Audio
Dual Intel® Core™ 2 Quad processor based PICMG 1.0
SBC with DDR3 SDRAM, VGA, DVI, Dual Gigabit
Ethernet, Audio and USB
INDUSTRIAL BACKPLANE
PAGE 29-30 PICMG 1.0 Backplane
31-32 PICMG 1.3 Backplane
33
PCI & ISA Backplane
INDUSTRIAL MAIN BOARD
PAGE 34-35 IMB Reference Table
36 RUBY-9911
RUBY-9911
Leading Intel® Core™ 2 Quad / Core™ 2 Duo
Processor based ATX motherboard with Dual Display,
Dual Gigabit Ethernet, Four SATA Ports, Four COM
Ports, and Eight USB Ports
39 RUBY-9717VGAR
RUBY-9717VGAR
40 RUBY-9716VG2AR
37 RUBY-9719VG2AR
®
RUBY-9719VG2AR
Intel Core™ 2 Duo/Core™ 2 Quad Processor based
ATX Motherboard with DDR2, VGA, Dual Gigabit
Ethernet, Audio and USB
RUBY-9716VG2AR
RUBY-9718VG2AR
01 Table of Contents
Intel® Core™ 2 Quad processor based ATX Industrial
Mainboard with DDR2 SDRAM, VGA, Dual Gigabit
Ethernet, Audio and USB
41 RUBY-9716VGAR
38 RUBY-9718VG2AR
Intel® Core™ 2 Quad processor based ATX Industrial
Mainboard with onboard DVI/VGA Dual-Display, DDR2
SDRAM, VGA, Dual Gigabit Ethernet, Audio and USB
Intel® Core™ 2 Quad processor based Micro-ATX
Industrial Mainboard with onboard DVI/VGA Dual-display,
DDR2 SDRAM, Gigabit Ethernet, Audio and USB
RUBY-9716VGAR
Intel® Core™ 2 Quad processor based ATX Industrial
Mainboard with DDR2 SDRAM, VGA, Gigabit Ethernet,
Audio and USB
Table of Contents
INDUSTRIAL MAIN BOARD
44 RUBY-7720VG2A
42 RUBY-9715VG2AR
RUBY-9715VG2AR
Intel® Core™ 2 Duo processor based ATX Industrial
Mainboard with DDR2 SDRAM, VGA, Dual Gigabit
Ethernet, Audio and USB
Intel® Pentium® M or Celeron® M processor based MicroATX Motherboard with DDR2 SDRAM, VGA, Dual Gigabit
Ethernet, Audio and USB
RUBY-7720VG2A
43 RUBY-9713VG2AR
RUBY-9713VG2AR
Intel® Core™ 2 Duo processor based Micro-ATX Industrial
Mainboard with DDR2 SO-DIMM, VGA, Dual Gigabit
Ethernet, Audio and USB
INDUSTRIAL CHASSIS
PAGE 45
About Chassis
46-47 Chassis Reference Table
48
63
RPC-500NC/L
19” 4U industrial rack-mount chassis
8-slot full-sized industrial node chassis
(Shoe-box)
RPC-500NC
50
AREMO-4196
AREMO-8164
65
The Best Cost-Performance 19” 4U
Height Pentium® 4 Processor Based
Rack-mount Computer
AREMO-4196
AREMO-8164
AREMO-4184
19" 4U Height rack-mount chassis with
dual AREMO-6182 node chassis
AREMO-4184
53
AREMO-2173P
67
19” 2U industrial rack-mount chassis for
PICMG backplane
AREMO-2173P
AREMO-6182
6-slot full-size industrial node chassis
(Shoe-box)
AREMO-6182
55
AREMO-2173MX
69
19” 2U industrial rack-mount chassis for
Micro-ATX or mini-ITX mother board
AREMO-2173MX
57
AREMO-3194
6-slot industrial node chassis for half-size
PCI cards
PNC-5063
70
19” 3U rack-mount chassis for ATX M/B
platform
AREMO-3194
PNC-5063
PRS-1174
19" 1U Height rack-mount micro-ATX based
server with four drives
PRS-1174
59
PRC-4207
71
19” 4U industrial rack-mount chassis for
server grade motherboard
PRC-4207
61
AREMO-6163
19" 1U Height industrial rack-mount P4
chassis
PRC-1194
72
6-slot full-sized industrial node chassis
(Shoe-box)
EZDRV-400
AREMO-6163
PRC-1194
EZDRV-400
5.25" compact drive set with slim type
DVD-ROM, SD/CF card reader, 2 USB ports
and space for 2.5" HDD
3.5” & ECX FORM FACTOR
PAGE 73
ESB Reference Table
74 PEB-2731VLA
PEB-2731VLA
3.5” Floppy-size, Ultra Low Voltage Intel® Celeron® M
processor based Embedded Board with VGA, LCD, LAN
and Audio
78 PEB-2738
PEB-2738
75 PEB-2130
PEB-2130
PEB-2131VGA
PEB-2780VG2A
3.5” Embedded size, based on Intel® AtomTM N270
Processor with DDR2 SDRAM, Dual Display by VGA/
LVDS, Gigabit Ethernet, Four Power COM Ports and
Audio
77 PEB-2737VLA
PEB-2737VLA
79 PEB-2780VG2A
3.5” Embedded size, Intel® Pentium® M or Celeron® M
processor based on Embedded Board with DVI, LVDS,
Dual Gigabit Ethernet, Audio and USB
76 PEB-2131VG2A
Intel® 45nm Ultra Low Power AtomTM processor based
ECX embedded board with VGA, LVDS, Gigabit
Ethernet, Audio, USB and SDIO
Intel® 45nm Ultra Low Power Menlow-XL processor
and chipset based ECX embedded board with dual
display, Audio, USB and SDIO
3.5” Embedded size, Based on Intel® 45nm Low
Power Pineview processor with DDR2 SODIMM,
dual display by VGA/LVDS, Dual GbE, Audio,
COM and USB
80 PEB-2770VG2A
PEB-2770VG2A
Compact In-Vehicle Application System
3.5” Embedded size, Based on Intel® 45nm Low
Power Pineview processor with DDR2 SODIMM,
dual display by VGA/LVDS, Dual GbE, Audio,
COM and USB
Table of Contents 02
Table of Contents
NANO-ITX FORM FACTOR
83 NANO-8045L
81 NANO-8044
Intel® Ultra Low Power AtomTM Processor
based NANO-ITX Board with dual display,
Gigabit Ethernet, Audio, USB and SDIO
NANO-8044
NANO-8045L
84 NANO-8050
82 NANO-8045
NANO-8045
Intel® Ultra Low Power AtomTM Processor
based NANO-ITX Board with dual display,
Gigabit Ethernet, Audio, USB and SATA
Intel® Ultra Low Power Atom Processor based
NANO-ITX Board with dual display, Gigabit
Ethernet, Audio, USB and SATA
NANO-8050
Leading Intel® latest ULV Mobile SFF 45nm
CoreTM 2 Duo or Celeron® M processor based
NANO-ITX with DDR2 SODIMM, Dual Displays,
Gigabit Ethernet, Audio, USB
MINI-ITX FORM FACTOR
PAGE 85
About Mini-ITX
86-89 Mini-ITX Reference Table
90 WADE-8067
WADE-8067
Leading Intel® 45nm CoreTM 2 Duo processor
or Celeron® M processor based Mini-ITX with
DDR3 SDRAM, HDMI, Dual Gigabit Ethernet,
Audio and USB
100 WADE-8047
WADE-8047
101 WADE-8180
91 WADE-8066
WADE-8066
On board Dual VGA Intel® Celeron® M/Pentium® M
processor Mini-ITX with DDR2 SDRAM, LVDS,
Four COM Ports and USB
Leading Intel® CoreTM 2 Duo processor based
Mini-ITX Board with DDR2 SDRAM, Dual Displays,
Two GbE LAN ports, Audio and USB
WADE-8180
Leading Intel® Core™ 2 Quad / Core™ 2 Duo
Processor based Mini-ITX embedded board with
Dual Display, WADE-8180 Dual Gigabit Ethernet,
SATA, COM and USB
92 WADE-8068
WADE-8068
Leading Mobile Intel® CoreTM 2 Duo processor
Mini-ITX with DDR2 SDRAM, Dual Displays, Two
GbE LAN ports, Four COM Ports, LPT and USB
102 WADE-8056
WADE-8056
93 WADE-8046
WADE-8046
Intel® CoreTM 2 Duo processor based Mini-ITX
Board with DDR2 SDRAM, VGA/ LVDS/ DVI,
Gigabit Ethernet, Audio and USB
103 WADE-8556
Leading Intel® CoreTM 2 Quad processor based
Mini-ITX Board with Dual Displays and One GbE
WADE-8556
104 WADE-8656
94 WADE-8065
Network Enriched Intel® CoreTM 2 Duo processor
based Mini-ITX Board with Dual Displays, Three
GbE LAN ports, Audio and USB
WADE-8065
Leading Intel® CoreTM 2 Quad processor based
Mini-ITX Board with PCI-E expansion and Two
GbE
WADE-8656
95 WADE-8071
WADE-8071
Intel® Low Power AtomTM N270 1.6GHz Processor
based Mini-ITX Board with DC12V input, dual display,
Gigabit Ethernet, Two SATA Ports, Two COM ports
and Six USB Ports support thin client application
105 WADE-8055
WADE-8055
Intel® Low Power AtomTM N270 1.6GHz
Processor based Mini-ITX Board with dual
display, Gigabit Ethernet, Two SATA Ports, Four
COM Ports and Six USB Ports
97 WADE-8072
®
WADE-8072
TM
Intel Low Power Atom N270 1.6GHz
Processor based Mini-ITX Board with dual
display, Gigabit Ethernet, Two SATA Ports, Four
COM Ports and Six USB Ports
98 WADE-8170
WADE-8170
Intell® AtomTM N270 Processor based Mini-ITX Board
with Dual Display, Dual Gigabit Ethernet, Two SATA
Ports, Two COM ports and Eight USB Ports
WADE-2221A
03 Table of Contents
Ultra Low Voltage Intel® Celeron® M processor
Mini-ITX with DDR2 SDRAM, Dual Display, Four
COM Ports and USB
Rugged and stylish Industrial Mini-ITX Bare Bone
System
107 WADE-1120A
WADE-1120A
The fan-less compact bare bone system with
Intel® Celeron® M Mini-ITX board
108 WADE-2231Q
WADE-2231Q
Rugged and stylish Industrial Mini-ITX Bare Bone
Chassis with 180W Active PFC PSU
109 ARTO-220-ITX
ARTO-220-ITX
99 WADE-8044
WADE-8044
Network Enriched Intel® CoreTM 2 Duo processor
based Mini-ITX Board with Dual Displays and Two
GbE
106 WADE-2221A
96 WADE-8070
WADE-8070
Leading Intel® CoreTM 2 Quad processor based
Mini-ITX Board with Dual Displays and One GbE
1.5U Advanced Mini-ITX based chassis for MiniITX M/B application
110 WADE-1042
WADE-1042
1U Height bare bone server with four drive bays
for RAID and two expansion slots
Table of Contents
MINI-ITX FORM FACTOR
113 WADE-2110
111 WADE-1181
Compact Low Profile Mini-ITX Bare Bone Chassis
with 1-slot PCI Expansion
WADE-1181
WADE-2110
112 WADE-1141
Cubic Mini-ITX Bare Bone Chassis with Front
Accessible Hard Drive Bay
114 Riser Card Selection Guide
Compact Low Profile Mini-ITX Bare Bone Chassis
WADE-1141
MODULAR COMPUTING PLATFORMS
PAGE 115 About Modular
116 PCOM-B211VG
Intel® CoreTM Duo & Solo processor based
Type II COM Express module with DDR2 SDRAM,
VGA, Gigabit Ethernet, SATA 300 and USB
PCOM-B211VG
124 PQ7-M102XL
PQ7-M102XL
117 PCOM-B212VG
Intel® CoreTM Duo or Celeron® M processor based
Type II COM Express module with DDR2 SDRAM,
VGA, Gigabit Ethernet and USB
PCOM-B212VG
125 PQ7-M103XL
PQ7-M103XL
118 PCOM-B213VG
Intel® GM45 platform based Type II COM Express
module with DDR3 SDRAM, VGA, Gigabit Ethernet,
SATA and USB
PCOM-B213VG
PCOM-B214VG
PQ7-M104G
PCOM-B215VG
PQ7-C100XL
PCOM-B216VG
Mini-ITX Form Factor Carrier Board for QSeven
Module with Dual Displays and Two GbE
PQ7-C200
PEM-E200VLA
PCOM-C210
129 PEM-E200VLA
Intel® AtomTM based Type ETX module with
DDR2 SDRAM, VGA, Fast Ethernet, SATA and
USB
130 PEM-C200
122 PCOM-C210
ATX Form Factor Evaluation Carrier Board for
COM Express Type II Module
3.5” ESB Form Factor Carrier Board For Qseven
Module
128 PQ7-C200
121 PCOM-B216VG
Intel® Arrandale processor based Type II COM
Express module with DDR3 SDRAM, VGA
Gigabit Ethernet 3. 0 GT/s SATA and USB
Qseven, based on Intel® AtomTM Processor
with DDR2 SDRAM, LVDS Display, Gigabit
Ethernet, SDVO and SATA
127 PQ7-C100XL
120 PCOM-B215VG
Intel® AtomTM based Type II micro-COM Express
module with DDR2 SDRAM, VGA, Gigabit
Ethernet, SATA, USB and NAND Flash
Qseven, Based on Intel® eMenlow XL Platform with
DDR2 SDRAM,SATA LVDS Display,
Gigabit Ethernet, SDVO and NANDrive
126 PQ7-M104G
119 PCOM-B214VG
Intel® AtomTM based Type II COM Express module
with DDR2 SDRAM, VGA, Gigabit Ethernet, SATA
and USB
QSeven, Intel® Embedded Menlow-XL Platform
with DDR2 SDRAM, LVDS Display, Gigabit
Ethernet, SDVO and SATA
Micro-ATX Form Factor Evaluation Carrier
Board for ETX Module
PEM-C200
123 PQ7-M101G
QSeven, based on Intel® AtomTM Processor with
DDR2 SDRAM, LVDS Display, Gigabit Ethernet,
SDVO and SATA
PQ7-M101G
EMBEDDED COMPUTING SYSTEM
PAGE 131
132
134
135
About WEBS
Quality Assurance
Brick concept
WEBS Reference Table
141 WEBS-3331
137 WEBS-3330
WEBS-3330
Embedded Fan-less system with Intel® AtomTM
N270 Processor in MINI-ITX form factor
WEBS-3331
142 WEBS-4330
138 WEBS-2120
WEBS-2120
Embedded compact fan-less system with Intel®
AtomTM Z510/Z530 based NANO-ITX board
WEBS-4330
WEBS-2121
WEBS-1310
WEBS-1320
Embedded rugged fan-less system with Intel®
Atom™ Z510PT/Z520PT based 3.5” ECX board
144 WEBS-1330
140 WEBS-1320
Embedded Fan-less system with Intel® AtomTM
Processor in 3.5" ECX form factor
Embedded rugged compact fan-less system with
Intel® AtomTM N270 based MINI-ITX board
143 WEBS-1310
139 WEBS-2121
Embedded compact fan-less system with Intel®
AtomTM Z510/Z530 based NANO-ITX board
Embedded slim fan-less system with Intel® AtomTM
N270 based MINI-ITX board
WEBS-1330
Embedded rugged fan-less system with Intel®
Atom™ N270 based 3.5” ECX board
Table of Contents 04
Table of Contents
EMBEDDED COMPUTING SYSTEM
145 WEBS-1340
WEBS-1340
147 WEBS Mounting Solution
Embedded rugged fan-less system with Intel®
Atom™ N450/D510 based 3.5” ECX board
146 WEBS-3332
WEBS-3332
Embedded rugged slim fan-less system with
Intel® Atom™ N270 based MINI-ITX board
INDUSTRIAL PSU
PAGE 148 PSU Reference Table
158 ORION-D3002DDP
149 GADIWA-P0901
GADIWA-P0901
120W DC/DC Converter (12V/input, ATX/
output), Board type
ORION-D3002DDP
159 ORION-D3502P
150 GADIWA-R9271
GADIWA-R9271
9V~27V/wide-input, 12V/output Regulator,
Board Type
ORION-D3502P
GADIWA-3160
ORION-D4602P
GADIWA-3161
MPM-842P
GADIWA-N2360
MPI-815P
ORION-A2501
MPI-810H
150W 1U ATX power supply with
active PFC
MPD-810H
150W Flex form factor power
supply with active PFC
155 ORION-A1801P
ORION-A1801P
180W Flex form factor power
supply with active PFC
120W universal input open-frame,
DC to DC power supply
162 MPE-008A-P
155 ORION-A1501P
ORION-A1501P
120W universal input open-frame
power supply
161 MPD-810H
154 ORION-A1501
ORION-A1501
150W 1U ATX power
supply with active PFC
161 MPI-810H
154 ORION-A2501
250W 1U ATX power supply with
active PFC
400W PS/2 ATX power supply
with active PFC
160 MPM-815H
153 GADIWA-N2360
360W Mini-Redundant PSU, 18~30VDC
Wide-Rang/input, ATX/output
460W+460W mini-redundant switching
power supply with active PFC
160 MPM-842P
152 GADIWA-3161
128W DC/DC 9V~29V/wide-input, ATX/
output, Board Type Converter
350W ATX mini-redundant with active
PFC power supply
159 ORION-D4602P
151 GADIWA-3160
128W DC/DC 12V~36V/wide-input, ATX/
output, Board Type Converter
300W -38VDC to -72VDC input DC/DC
mini-redundant ATX power supply
MPE-008A-P
80W universal input open-frame
power supply
162 MPI-806H
MPI-806H
60W universal input open-frame
power supply
163 Adapter
APH-3019-40W
156 ORION-B3501P
ORION-B3501P
163 Adapter
350W 2U ATX power supply
with active PFC
156 ORION-D3501P
ORION-D3501P
APH-3019-40W
APH-3020-60W
APH-3020-60W
350W ATX power supply with
active PFC
APH-3023-96W
APH-3023-96W
157 ORION-D4601P
ORION-D4601P
460W PS/2 ATX power supply
with active PFC
157 ORION-D5501P
ORION-D5501P
550W PS/2 ATX power supply
with active PFC
158 ORION-300DX/24/48
ORION-300DX/24/48
05 Table of Contents
300W -48V/24V DC input
DC/DC PS/2 ATX power supply
163 Adapter
163 Adapter
APH-3011-150W
APH-3011-150W
164 Configuration Matrix
165 Accessory
166 EZCool
About Portwell
Who is Portwell?
Portwell, Inc. was founded in Taiwan in 1993 and entered the Industrial PC market in 1995 by
developing single-board computers. Today, our continued development of leading-edge products has
resulted in strong growth in market share and revenue, a firm place on the Taipei stock exchange
(TAISDAQ), and has established Portwell as a major worldwide supplier of specialty computing
application platforms and services. Portwell, Inc. is not only a member of the select group of Intel®
Applied Computing Platform Providers (IACPP), but also an associate member of Intel® Embedded and
Communications Alliance (ECA), as well as Advanced Telecom Computing Architecture (ATCA) and an
executive member of PCI Industrial Computer Manufacturing group (PICMG).
Portwell, Inc. has worldwide offices in the U.S.A., Taiwan, Japan, China, Netherland, United Kingdom,
and India.
Why Partner with Portwell?
Whether you are working on a computer board or turnkey system, Portwell is the perfect partner to help
you deliver your products to market on time as well as maintain longevity of product life cycle. With 16
years experience in the design and manufacture of specialty computer boards and systems, Portwell not
only provides a one-stop resource for off-the-shelf products, but also supplies custom-built solutions and a
global logistics service to suit your needs.
Portwell OEM and ODM solutions satisfy a host of top-tier companies in the retail automation, medical equipment, industrial automation, Infotainment,
communication, and network security markets. Encouraged by our flexible business support, manufacturing excellence, and compliance with high
quality and environmental standards such as ISO 9001/14000 and RoHS, customers have taken advantage of our dedicated and sophisticated
engineering resource to satisfy their requirements for the design, manufacturing and logistics of application-specific computer boards, unique computer
chassis, and specific computer system configurations. Whether you're working on a Medical Single Board Computer or Internet Security Applicance,
Portwell is the perfect partner to help you deliver your products to market on time and stay one step ahead of the competition.
Why Portwell Platforms and Services?
Complete Product Portfolio
Select from our full range of both off-the-shelf and versatile custom solutions to scale your products. Portwell provides not only board-level
products, but also peripheral-level and complete system solutions.
Implement Latest Intel Technology
Partnering with Intel since 1999, and with streamline access to the latest Intel technologies and roadmap, Portwell delivers cutting-edge
solutions not only to meet and exceed the demand for the technologies, but also the needs of the long product life cycle.
Faster Time-to-Market
Portwell experienced engineers, complete product solutions, global operation and flexible business service help you meet the time-to-market
requirement and reduce your new product introduction cycle, as well as costs of conducting business.
Leading Edge Innovator
Portwell is committed to product and solution innovation, and not only has completed a variety of proof-of-concept designs with Intel, but is
also a leader in offering the latest technologies to the market.
Committed to Customer Satisfaction
Portwell operates a high standard process in determined pursuit of our commitment to continuously improve our products and services to
satisfy and exceed our customers' needs.
What is Portwell Value Proposition?
Design, Develop, and Deliver
Design, develop and deliver to meet customer requirements, such as production, reliability, stability, cost-effectiveness, and longevity of product.
Experienced and sophisticated engineering capability includes electronic, mechanical, firmware and system integration expertise.
Portwell Manufacturing Excellence
Supply chain and component inventory management with automation.
In-house SMT lines and PCB assembly and functional testing.
In-house system integration and testing.
ISO 14001 and ISO 9001 certified manufacturing facilities (89,000 sq. ft. in Taipei).
Flexible production capability.
Portwell Global Presence
One point of contact, global support.
Sales and technical support teams are available through Portwell worldwide offices in the U.S.A., Taiwan, Japan, China, Netherland,
United Kingdom, and India.
Customer-centric service and support.
About Portwell 06
About SBC
(Single Board Computers)
HIGH QUALITY
Portwell is a leading designer
and manufacturer of
PICMG slot boards.
Portwell, Inc. is a leading designer and manufacturer of PICMG slot boards. Featuring more expansion slots for add-in cards,
high integration with versatile backplanes, and ease of upgrading and maintenance, these boards are well suited to critical
applied computing applications.
As an Associate (Silver) Member of Intel® Embedded and Communications Alliance, Portwell is
guaranteed at least five-year availability of the Intel® components contained in the Embedded
Intel® Architecture. This helps equipment manufacturers to secure the longevity of products
that have gone through long periods of validation.
All the components used in the Portwell SBC are specifically selected to meet the environmental requirements from even the most
critical industrial applications. All the boards have to pass strict and complete reliability and compatibility tests in both design and
production phases.
In addition to our full-range PICMG 1.0 SBC, Portwell also provides a total solution of PICMG 1.2 system, integrating dual Xeon
®
processor based SHB, up to four independent PCI/PCI-X buses, single/redundant power supply and industrial chassis. The
new PICMG 1.2 standard is characterized by the replacement of the ISA bus with PCI-X bus. Because the PCI-X bandwidth
is eight times of a 32-bit / 33MHz PCI bus, many high throughput applications, such as image processing, data storage, and
communication appliance, have already adopted this bus architecture. Server board is the application that most utilizes the PCIX bus. Portwell also provides slot board features in response to growing needs, and to better fit these critical applications.
In pursuit of our commitment to excellence, Portwell operates an ISO 14001 and ISO 9001 qualified system (from initial
design, through manufacturing to delivery) to provide high performance industrial computing platforms with satisfying quality.
Furthermore, we consistently seek opportunities to collaborate with customers in every vertical market in order to develop the
right product in their domains. Through this cooperation, customers can get the core engine or system at the same pace as their
product planning.
Please note:
Specifications are subject to change without notice.
Other trademarks, logo, brands and company names are the property of their respective owners.
*
*
07 About SBC
About ESB
USE ESB IN YOUR NEXT PROJECT
Portwell ESB (Embedded System Board) product line targets the Interactive
client market with boards based on 5.25" and Embedded ATX/Micro ATX
form factors. Interactive client applications include ATM (Automated Teller
Machines), Kiosk, Digital Signage, POD, POS (Point-Of-Sale), Lottery, and
Vending and Gaming Machines.
HIGH SPEED PROCESSOR
All these interactive clients are even more powerful today in order to fulfill the current needs for
convenience and entertainment. Richer functions demand the higher speed and hyper-threading/dual
core processors we provide for running different applications concurrently.
ETHERNET
Highly personalized and customized service is gaining popularity and contributes to the huge customer
database growing behind the end nodes. To access this database, a secure and fast communication
channel is required. Nowadays, Ethernet is the most popular communication interface in the world. It
greatly minimizes construction cost and TTM (Time-To-Market) of the node terminals.
USB
USB (Universal Serial Bus) makes adding peripheral devices extremely easy without worrying about
add-in cards or IRQs. With the introduction of USB 2.0, the raw data transmission rate is increased
from 12 Mbps of USB 1.1 to 480 Mbps. Therefore, more and more peripherals adopt this interface.
Since more USB ports are either embedded in the chipset or can be added by the USB hub, the
system capability is expanded without any problems.
DUAL DISPLAY
Most of the Portwell ESB offers dual display support to display identical or different contents at the
same time. The secondary display provides additional information to users when they access or pass
information to the interactive clients. It also allows users to have a wider display by extending the
working space on dual displays.
About ESB 08
SBC Reference Table
FULL-SIZE SINGLE BOARD COMPUTER
MODEL
ROBO-8921VG2R
ROBO-8914VG2AR
ROBO-8913VG2AR
LGA771 Dual/Quad CoreTM Xeon®
LGA775 CoreTM 2 Quad/CoreTM 2
Duo/Celeron®
LGA775 CoreTM 2 Quad/CoreTM 2
Duo/Celeron®
System Bus
Frequency
1333/1066MHz
1333/1066/800MHz
1333/1066/800MHz
Max Memory
4 DIMM/32GB (DDR2)
4 DIMM/8GB (DDR3)
2 DIMM/4GB (DDR2)
ECC
YES
NO
NO
BIOS
AMI
AMI
AMI
Chipset
Intel ® 5100, ICH9R
Intel ® Q45, ICH10DO
Intel ® Q35, ICH9DO
SSD
N/A
N/A
N/A
VGA / Panel
XGI Z11
Intel ® Q45 GMCH
Intel ® Q35 GMCH
HDD Channel
6 SATA 300
6 SATA 300
6 SATA 300
FDD Drives
1
1
2
LAN
Intel 82575x1
Intel 82574Lx1, 82567LMx1
Intel® 82573Lx1, 82566DMx1
Expansion Interface
Two PCI-E x8, One PCI-E x4,
Four PCI
Four PCI-E x1, One PCI-E x16,
Four PCI
Four PCI-E x1, One PCI-E x16,
Four PCI
USB Port
10
12
12
ATX Control
YES
YES
YES
On-Board I/O
W83627DHG
W83627HG
W83627HG
Serial Port
2
2
2
Parallel Port
1
1
1
PS/2 K/B
Header
Header
Header
PS/2 Mouse
Header
Header
Header
WDT
YES
YES
YES
H/W Monitoring
YES
YES
YES
IrDA
N/A
N/A
YES
Audio
N/A
YES
YES
ISA
NO
NO
NO
Dimension (L) x (W)
338.5 mm x 126.39 mm
13.33" x 4.98"
338.5 mm x 126.39 mm
13.33” x 4.98”
338.5 mm x 126.39 mm
13.33" x 4.98"
Page
14
15
16
CPU
“ “ Over-clocking
*
09 SBC Reference Table
®
®
SBC Reference Table
FULL-SIZE SINGLE BOARD COMPUTER
MODEL
ROBO-8912VG2AR
ROBO-8911VG2A
ROBO-8910VG2A
CPU
LGA775 CoreTM 2 Duo/Pentium® D/
Pentium® 4/ Celeron® D
mPGA479M Pentium® M/Celeron® M
mPGA478 Pentium® 4/Celeron® D
System Bus
Frequency
1066/800/533MHz
533/400MHz
800/533MHz
Max Memory
2 DIMM/4GB (DDR2)
2 SODIMM/2GB (DDR2)
2 DIMM/2GB (DDR2)
ECC
NO
NO
NO
BIOS
Award
Award
Award
Chipset
Intel ® Q965, ICH8DO
Intel ® 915GME, ICH6
Intel ® 915GV, ICH6
SSD
N/A
CF Max. 1GB
CF Max. 1GB
VGA / Panel
Intel® Q965 GMCH
Intel® 915GM GMCH/YES
Intel® 915GV GMCH/NO
HDD Channel
6 SATA 300
1 EIDE Ultra DMA
100/66/33 & 4 SATA 150
1 EIDE Ultra DMA
100/66/33 & 4 SATA 150
FDD Drives
2
2
2
LAN
Intel® 82573Lx1, 82566DMx1
Marvell 88E8001x2
Marvell 88E8001x2
Expansion Interface
Four PCI-E x1, One PCI-E x16,
Four PCI
One PCI-E x16, Four PCI-E x1,
Four PCI
Four PCI Express x1, Four PCI
USB Port
10
8
8
ATX Control
YES
YES
YES
On-Board I/O
W83627EHG
W83627THF
W83627THF
Serial Port
2
2
2
Parallel Port
1
1
1
PS/2 K/B
Header
Header
Header
PS/2 Mouse
Header
Header
Header
WDT
YES
YES
YES
H/W Montioring
YES
YES
YES
IrDA
N/A
YES
YES
Audio
YES
YES
YES
ISA
NO
NO
NO
Dimension (L) x (W)
338.5 mm x 126.39 mm
13.33" x 4.98"
338.5 mm x 122 mm
13.33" x 4.8"
338.5 mm x 122 mm
13.33" x 4.8"
Page
17
18
19
“ “ Over-clocking
*
SBC Reference Table 10
SBC Reference Table
FULL-SIZE SINGLE BOARD COMPUTER
MODEL
ROBO-8779VG2AR
ROBO-8777VG2A
ROBO-8773VG
CPU
LGA775 CoreTM 2 Quad/CoreTM 2
Duo/Celeron®
LGA775 CoreTM 2 Duo/Pentium® D/
Pentium® 4/ Celeron® D
LGA775 CoreTM 2 Duo/Pentium® D/
Pentium® 4/ Celeron® D
System Bus
Frequency
1333/1066/800MHz
1066/800/533MHz
1066* (Optional)/800/533MHz
Max Memory
2 DIMM/4GB (DDR3)
2 DIMM/4GB (DDR2)
2 DIMM/2GB (DDR)
ECC
NO
NO
NO
BIOS
AMI
Award
Award
Chipset
Intel ® G41, ICH7R
Intel® Q965, ICH8
Intel® 865G, ICH5
SSD
Type II CF
N/A
N/A
VGA / Panel
Intel® G41 GMCH
Intel® Q965GMCH/NO
Intel® 865GMCH/NO
HDD Channel
4 SATA 300
4 SATA 300
4 EIDE Ultra DMA 100/66/33 &
2 SATA 150
FDD Drives
1
2
2
LAN
Intel® 82574Lx2
Realtek RTL 8111B x2
Realtek RTL 8110SC x1
Expansion Interface
N/A
N/A
N/A
USB Port
8
6
8
ATX Control
YES
YES
YES
On-Board I/O
W83627THG
W83627DHG
W83627THG
Serial Port
2
2
2
Parallel Port
1
1
1
PS/2 K/B
Header
Header
YES
PS/2 Mouse
Header
Header
YES
WDT
YES
YES
YES
H/W Montioring
YES
YES
YES
IrDA
NO
NO
YES
Audio
YES
YES
NO
ISA
YES
YES
YES
Dimension (L) x (W)
338.5 mm x 122 mm
13.33" x 4.8"
338.5 mm x 122 mm
13.33” x 4.8”
338.5 mm x 122 mm
13.33” x 4.8”
Page
20
21
22
“ “ Over-clocking
*
11 SBC Reference Table
SBC Reference Table
FULL-SIZE SINGLE BOARD COMPUTER
MODEL
ROBO-8719VG2AR
ROBO-8771VG2
ROBO-8718VG2A
CPU
45nm Mobile CoreTM 2 Quad/CoreTM 2
Duo/Celeron® M
ULV Celeron® M 600MHz
mFCPGA Pentium® M / Celeron® M
System Bus
Frequency
1066/800/667MHz
400MHz
533/400MHz
Max Memory
2 DIMM/4GB (DDR2)
1 DIMM/1GB (DDR)
2 DIMM/2GB (DDR2)
ECC
NO
NO
NO
BIOS
AMI
Award
Award
Chipset
Intel® GM45, ICH9ME
Intel® 852GM, ICH4
Intel® 915GME, ICH6
SSD
Type II CF
N/A
CF Max. 1GB
VGA / Panel
Intel GM45GMCH/YES
Intel 852GM GMCH/NO
Intel® 915GM/YES
HDD Channel
3 SATA 300
2 EIDE Ultra DMA
100/66/33
1 EIDE Ultra DMA 100/66/33 & 4
SATA 150
FDD Drives
1
2
2
LAN
Intel® 82567LM, 82574L
Realtek RTL8110SC x2
Marvell 88E8053x2
Expansion Interface
N/A
N/A
N/A
USB Port
6
12
4
ATX Control
YES
YES
YES
On-Board I/O
W83627DHG
W83627THG
W83627THF
Serial Port
2
2
2
Parallel Port
1
1
1
PS/2 K/B
Header
Header
Header
PS/2 Mouse
Header
Header
Header
WDT
YES
YES
YES
H/W Montioring
YES
YES
YES
IrDA
NO
YES
YES
Audio
YES
N/A
YES
ISA
YES
YES
YES
Dimension (L) x (W)
338.5 mm x 122 mm
13.33” x 4.8”
338.5 mm x 122 mm
13.33" x 4.8"
338.5 mm x 122 mm
13.33” x 4.8”
Page
23
24
25
®
®
“ “ Over-clocking
*
SBC Reference Table 12
SBC Reference Table
HALF-SIZE SINGLE BOARD COMPUTER
MODEL
ROBO-8713VGA
ROBO-6711VGA
ROBO-6730VLA
CPU
mPGA478 Pentium®4/
Celeron® D
mPGA478 Pentium® M/Celeron®M
ULV Celeron® M 600MHz
System Bus
Frequency
800/533/400MHz
533/400MHz
400MHz
Max Memory
2 DIMM/2GB (DDR)
1 SODIMM/1GB (DDR)
1 SODIMM/1GB (DDR)
ECC
NO
NO
NO
BIOS
Award
Award
Award
Chipset
Intel® 865G, ICH5
Intel® 852GME, ICH4
Intel® 852GM, ICH4
SSD
CF Max. 1GB
CF Max. 1GB
CF Max. 1GB
VGA / Panel
Intel® 865GV GMCH/NO
Intel® 852GM GMCH/YES
Intel® 852GM GMCH/YES
HDD Channel
2 EIDE Ultra DMA 100/66/33 & 2
SATA 150
2 EIDE Ultra DMA
100/66/33
2 EIDE Ultra DMA
100/66/33
FDD Drives
2
2
2
LAN
Intel® 82547x1
Intel® 82541x1
Intel® 82562x1
Expansion Interface
Proprietary PCI connector
NO
NO
USB Port
4
4
4
ATX Control
YES
YES
NO
On-Board I/O
W83627HF
W83627HF
W83627HF
Serial Port
2
2
2
Parallel Port
1
1
1
PS/2 K/B
YES
YES
YES
PS/2 Mouse
YES
YES
YES
WDT
YES
YES
YES
H/W Montioring
YES
YES
YES
IrDA
YES
YES
YES
Audio
YES
YES
YES
ISA
YES
YES
YES
Dimension (L) x (W)
338.5 mm x 122 mm
13.33" x 4.8"
185 x 122 mm
7.3" x 4.8"
185 x 122 mm
7.3" x 4.8"
Page
26
27
28
“ “ Over-clocking
*
13 SBC Reference Table
ROBO-8921VG2R
Four 240-pin DDR2 DIMM sockets
Dual/Quad CoreTM Xeon® processor based
PICMG 1.3 SHB with DDR2 ECC SDRAM,
VGA & Dual Gigabit Ethernet
Parallel port
Four USB ports
Dual COM ports
FDD port
Dual USB ports
Intel® Dual/Quad Core
XeonTM processor
Dual GbE ports
Intel® 82575 Gigabit Ethernet
XGI Z11
VGA port
Intel® 5100
FEATURES
ROBO-8921 offers flexible 1333/1066 MHz
selection of Intel® Dual/Quad CoreTM Xeon®
processors with LGA771 package
Flexible design of dual PCI Express x8 could
be aggregated as one PCI Express x16 for
Graphic card
Rich & powerful I/O expansion covers dual
PCI Express x8, one PCI Express x4 and
four PCI devices
Up to 32GB, ECC registered memory
assured the computer reliability and
benefited the data swapping process
Relative high performance graphic engine,
XGI Z11 provides solid 2D for server grade
market
Dual PCI Express x4 based Gigabit Ethernet
supports IPv4, IPv6 offloading, VLAN,
Wake-On-LAN functions
Intel® ICH9R
TMDS port
(optional) 2nd VGA port
(optional)
GENERAL
Processor
CPU & Package: Dual/Quad CoreTM Intel® Xeon® processor
(single or dual processor) in LGA-771 package
FSB: 1333/1066MHz
Chipset/Core Logic
Intel® 5100 and ICH9R
System Memory
- Up to 32GB DDR2 533/667 SDRAM on four 240-pin DIMM sockets
- Support ECC, registered
BIOS
AMI BIOS
Storage Devices
EIDE: N/A
SATA: Support Six SATA 300 drives (dual SATA ports via Backplane)
(RAID 0, 1, 5, 10)
Solid State Disk
N/A
Watchdog Timer
Programmable via software from 0.5 sec. to 254.5 sec.
Expansion Interface
- One PCI Express x8
- Three PCI Express x4
- Four PCI devices
Hardware Monitoring
System monitor (fan, temperature, voltage)
Power Requirement
Typical: [email protected]; [email protected]
Dimension
Dimension : 338.6(L) x 126.39(W) mm; 13.33"(L) x 4.98" (W)
PCB: 12-layer
Environment
Operating Temperature: 0 to 60oC (for 80W CPU limitation)
Storage Temperature: -20 to 80oC
Relative Humidity: 5% to 90%, non-condensing
MTBF
106,427 hrs
I/O
ORDERING GUIDE
Standard
Optional
ROBO-8921VG2R
Dual Xeon® LV processor based PICMG 1.3
SHB with VGA and Dual Gigabit Ethernet
(CPU Cooler included)
PS/2 Keyboard/Mouse with Bracket
PS/2 keyboard/mouse connectors on bracket
MIO
Two serial (RS232 x1, selectable RS232/485 x1), one parallel, one FDD
channel
IrDA
N/A
Ethernet
PCI Express x4 interface based Intel® 82575 dual Gigabit Ethernet controller
Audio
N/A
USB
Ten USB 2.0 ports (Four through backplane)
Keyboard & Mouse
Two USB 2.0 ports on bracket dedicated to keyboard & mouse
DISPLAY
Graphic Controller
XGI Z11
Graphic Memory
32MB DDR2 Memory
Display Interface
Support CRT and optional second CRT or DVI-D display interfaces
SBC-ROBO-8921VG2R 14
ROBO-8914VG2AR
Intel® Core™ 2 Quad processor based
PICMG 1.3 SHB with DDR3 SDRAM, VGA,
Dual Gigabit Ethernet, Audio and USB
COM2 (RS232/422/485 selectable)
Four 240 pin DDR3 DIMM sockets
+12V Power connector
Parallel port
Four SATA 300 ports
FDD port
COM1 (RS-232)
PS/2 keyboard & mouse
Dual USB ports
Dual GbE ports
VGA port
LGA775 socket
FEATURES
Intel® ICH10DO
Six USB Ports
GENERAL
Processor
CPU & Package: Intel® CoreTM 2 Quad, Core 2 Duo, Celeron processor in
LGA-775 package
FSB: 1333/1066/800MHz
Chipset/Core Logic
Intel® Q45 and ICH10DO
Delivers up to 8GB maximum DDR3 1066/800
on four long DIMM sockets
System Memory
Up to 8GB DDR3 1066/800 SDRAM on four 240-pin DIMM socket
BIOS
AMI BIOS
Support Intel® Q45 integrated GMA 4500
graphic engine delivers optimized 3D graphics
performance
Storage Devices
EIDE: N/A
SATA: Support six SATA 300 drives (dual SATA ports via backplane)
(RAID 0,1,5,10)
Solid State Disk
N/A
Support iAMT 5.0 and iTPM function
Watchdog Timer
Programmable via software from 0.5 sec. to 254.5 sec.
Expansion Interface
N/A
Hardware Monitoring
System monitor (fan, temperature, voltage)
Power Requirement
N/A
Dimension
Dimension: 338.5(L) x 126.39(W) mm / 13.33”(L) x 4.98” (W)
PCB: 8-layer
Environment
Operating Temperature: 0 to 55oC
Storage Temperature: -20 to 80oC
Relative Humidity: 5% to 90%, non-condensing
MTBF
N/A
Support Intel® CoreTM 2 Duo and Core 2 Quad
processors and offers flexible 1333/1066/800
MHz FSB selection
High speed dual Gigabit Ethernet based on
PCI Express x1, high bandwidth I/O interface
Rich I/O connections such as FDD, two
Gigabit Ethernet, serial ports, parallel port,
USB 2.0
Intel® Q45
Four on-board SATA ports support RAID
0,1,5,10
ORDERING GUIDE
Standard
ROBO-8914VG2AR
PICMG 1.3(PCI-E+PCI).LGA775.Core 2
Quad.SHB.w/VGA/Dual GbE/Audio
Optional
PA-M1AU
Multimedia kit with audio and USB ports
PS/2 Keyboard/Mouse Cable with Bracket
PS/2 keyboard/mouse connectors on bracket
USB cable with bracket
Two USB ports with bracket
Low profile LGA775 Cooler
High efficiency slim cooler increases reliability
of system
I/O
MIO
Two serial (RS-232x1, selectable RS-232/422/485 x1), one parallel and one
FDD channel
IrDA
N/A
Ethernet
- Dual 10BASE-T/100BASE-TX/1000BASE-T Ethernet
- PCI Express x1 interface based Gigabit Ethernet
- Dual RJ-45 connector with two LED indicators
Audio
HDA interface, 5.1-channel Audio (Realtek ALC 662)
USB
Twelve USB 2.0 ports (Four USB ports via backplane)
Keyboard & Mouse
Two USB 2.0 ports on bracket dedicated to keyboard & mouse
DISPLAY
Graphic Controller
- GMCH integrated Intel® Graphics Media Accelerator (GMA) 4500
- Provided improved 3D multimedia capabilities including Microsoft DirectX 10,
Shader Model 4.0, MPEG-2 and OpenGL 2.1
* Celeron®, Pentium® III, Pentium® 4 and XeonTM are registered
trademarks of Intel® Corporation
Graphic Memory
Intel® Dynamic Video Memory Technology (DVMT) 5.0 shares system memory
up to1GB
* Other trademarks, logo, brands and company names are the
property of their respective owners
Display Interface
Analog CRT: up to 2048 x 1536 @ 75Hz
* Specifications are subject to change without notice.
15 SBC-ROBO--8914VG2AR
ROBO-8913VG2AR
Intel® Core™ 2 Quad processor based
PICMG 1.3 SHB with DDR2 SDRAM, VGA,
Dual Gigabit Ethernet, Audio and USB
COM2 (RS232/422/485 selectable)
FDD port
Dual 240-pin DDR2 DIMM sockets
COM1
+12V power connector
Parallel port
PS/2 keyboard & mouse
Six USB ports
Dual USB ports
Dual GbE ports
VGA port
Intel® Q35
LGA 775 socket
FEATURES
Support Intel® CoreTM 2 Quad processor up to
FSB 1333MHz
Low profile processor improves stability and
reliability of whole system
Four SATA 300 ports
®
Intel ICH9DO
GENERAL
Processor
CPU & Package: Intel® CoreTM 2 Quad, CoreTM 2 Duo, Celeron ® processor
in the LGA-775 package
FSB: 1333/1066/800MHz
Chipset/Core Logic
Intel® Q35 & ICH9DO
System Memory
Up to 4GB DDR2 800/667 SDRAM on dual 240-pin DIMM sockets
BIOS
AMI BIOS
Storage Devices
EIDE: N/A
SATA: Support six SATA 300 drives (dual SATA ports via backplane)
(RAID 0, 1, 5, 10)
Support eSATA that can communicate with
multiple drives via port multiplier
Lockable cable-latched notches of SATA connector
secure connection in vibration condition
Solid State Disk
N/A
Embedded Intel® Active Management Technology
(AMT) remotely discovers, heals and protects
networked computing assets using third-party
management and security applications
Watchdog Timer
Programmable via software from 0.5 sec. to 254.5 sec.
Expansion Interface
Four PCI Express x1, one PCI Express x16 and four PCI
Hardware Monitoring
System monitor (fan, temperature, voltage)
System noise and heat are reduced through more
intelligent fan speed control algorithms by
integrated Intel® Quiet System Technology
Power Requirement
Typical: [email protected]; [email protected]
Dimension
Dimension : 338.5(L) x 126.39(W) mm; 13.33"(L) x 4.98" (W)
PCB: 8-layer
Flexiblie design of four external PCI Express x1
could aggregate as one PCI Express x4 for storage
device thru backplane
Environment
Operating Temperature: 0 to 60oC
Storage Temperature: -20 to 80oC
Relative Humidity: 5% to 90%, non-condensing
MTBF
115,592 hrs
I/O
MIO
Two serial (RS232 x1, selectable RS232/422/485 x1), one parallel and one
FDD channel
IrDA
IrDA 1.0
Ethernet
- Dual 10BAST-T/100BAST-TX/1000BAST-T Ethernet
- PCI Express x1 interface based Gigabit Ethernet
- Dual RJ-45 connector with two LED indicators
Audio
HDA interface, 2-channel Audio (Realtek ALC 262)
USB
Twelve USB 2.0 ports (Four USB ports via backplane)
Keyboard & Mouse
Two USB 2.0 ports on bracket dedicated to keyboard & mouse
ORDERING GUIDE
Standard
Optional
ROBO-8913VG2AR
LGA-775 Core 2 Quad processor based
PICMG 1.3 SHB with DDR2 SDRAM, VGA,
Dual Gigabit Ethernet, Audio and USB
PA-M1AU
Multimedia kit with audio and USB ports
PS/2 Keyboard/Mouse Cable with Bracket
PS/2 keyboard/mouse connectors on bracket
Low Profile LGA775 Cooler
High efficiency slim cooler that increases
reliability of system
DISPLAY
Graphic Controller
- GMCH integrated Intel® Graphics Media Accelerator 3100
- Provides improved 3D multimedia capabilities including DirectX 9, Shader
Model 2.0, OpenGL 1.4, MPEG-2 hardware acceleration
Graphic Memory
Intel® Dynamic Video Memory Technology (DVMT) 4.0 shares system memory
up to 256MB
Display Interface
Support CRT interface up to QXGA 75Hz (2048x1536)
SBC-ROBO-8913VG2AR 16
ROBO-8912VG2AR
Intel® Core™ 2 Duo processor based
PICMG 1.3 SHB with DDR2 SDRAM, VGA,
Dual Gigabit Ethernet, Audio and USB
COM2 (RS232/422/485 selectable)
Dual 240-pin DDR2 DIMM sockets
Four SATA 300 ports
COM1
Parallel port
FDD port
PS/2 keyboard & mouse
+12V power connector
Dual USB ports
Dual GbE ports
VGA port
Intel® Q965
LGA 775 socket
FEATURES
Support 45nm Intel® CoreTM 2 Duo processor
that generates a maximum 65W TDP. Lower
TDP than socket 775 Pentium® 4 processor
makes the vertical mount slot board more
reliable
Low profile processor improves stability and
reliability of whole system
More features, such as EM64T, EIST, XD & VT,
can be easily applied to system by changing
processor
Intel® ICH8DO
Four USB ports
GENERAL
Processor
CPU & Package: Intel ® CoreTM 2 Duo, Pentium ® D, Pentium® 4, Celeron® D
processor in the LGA-775 package
FSB: 1066/800/533MHz
Chipset/Core Logic
Intel® Q965 and ICH8DO
System Memory
Up to 4GB DDR2 800/667/533 SDRAM on dual 240-pin DIMM sockets
BIOS
Award BIOS
Storage Devices
EIDE: N/A
SATA: Support six SATA 300 drives (dual SATA ports via backplane)
(RAID 0, 1, 5, 10)
Solid State Disk
N/A
Watchdog Timer
Programmable via software from 0.5 sec. to 254.5 sec.
Integrated Intel® GMA 3000 graphics engine
built with high grade display capability
Expansion Interface
Four PCI Express x1, one PCI Express x16 and four PCI
Hardware Monitoring
System monitor (fan, temperature, voltage)
Lockable cable-latched notches of SATA connector
secure connection in vibration condition
Power Requirement
Typical: [email protected]; [email protected]
Dimension
Embedded Intel® Active Management Technology
(AMT) remotely discovers, heals and protects
networked computing assets using third-party
management and security applications
Dimension : 338.5(L) x 126.39(W) mm; 13.33"(L) x 4.98" (W)
PCB: 6-layer
Environment
Operating Temperature: 0 to 60oC
Storage Temperature: -20 to 80oC
Relative Humidity: 5% to 90%, non-condensing
MTBF
93,332 hrs
System noise and heat are reduced through more
intelligent fan speed control algorithms by
integrated Intel® Quiet System Technology
Flexiblie design of four external PCI Express x1
could aggregate as one PCI Express x4 for storage
device thru backplane
ORDERING GUIDE
Standard
ROBO-8912VG2AR
LGA-775 Core 2 Duo processor based PICMG
1.3 SHB with DDR2 SDRAM, VGA, Dual
Gigabit Ethernet, Audio and USB
Optional
PA-M1AU
Multimedia kit with audio and USB ports
PS/2 Keyboard/Mouse Cable with Bracket
PS/2 keyboard/mouse connectors on bracket
Low Profile LGA775 Cooler
High efficiency slim cooler increases reliability
of system
17 SBC-ROBO-8912VG2AR
I/O
MIO
Two serial (RS232 x1, selectable RS232/422/485 x1), one parallel and one
FDD channel
IrDA
N/A
Ethernet
- Dual 10BAST-T/100BAST-TX/1000BAST-T Ethernet
- PCI Express x1 interface based Gigabit Ethernet
- Dual RJ-45 connector with two LED indicators
Audio
HDA interface, 2-channel Audio (Realtek ALC 262)
USB
Ten USB 2.0 ports (four USB ports via backplane)
Keyboard & Mouse
Two USB 2.0 ports on bracket dedicated to keyboard & mouse
DISPLAY
Graphic Controller
- GMCH integrated Intel® Graphics Media Accelerator 3000
- Provides improved 3D multimedia capabilities including DirectX 9, Shader
Model 3.0, OpenGL 1.5, Advanced De-interlacing, MPEG-2 hardware
acceleration
Graphic Memory
Intel® Dynamic Video Memory Technology (DVMT) 4.0 shares system memory
up to 256MB
Display Interface
Support CRT interface up to QXGA 75Hz (2048x1536)
ROBO-8911VG2A
Dual COM ports CF socket
Intel® 915GME
Additional power source
TV-out connector
Intel® Pentium® M or Celeron® M processor
based PICMG 1.3 SHB with DDR2 SDRAM,
VGA, Dual Gigabit Ethernet, Audio and USB
Parallel port
FDD port
LVDS panel connector
IDE connector
Dual SATA port
Dual USB ports
Dual GbE port
+12V power connector
VGA port
Intel® ICH6
Dual USB ports
Two 200-pin DDR2 SODIMM sockets
FEATURES
ROBO-8911 offers flexible 400MHz and
533MHz FSB selection of Intel® Pentium® M /
Celeron® M that features high computing power
with low heat
Intel® new integrated engine GMA 900 provides
better display quality and effects thru faster
engine; SGI OpenGL 1.4 and Microsoft DirectX
9.0 supports latest external PCI Express x16
interface graphic’s card via backplane
Support dual view function via VGA, LVDS and
TV interfaces
Four SATA 150 ports for high speed storage
interface and easy cable routing
Support four PCI Express x1, one PCI Express
x16 and four PCI expansion via backplane
GENERAL
Processor
CPU & Package: Intel ® Pentium ® M or Celeron ® M processor in mFCPGA
package
FSB: 533/400MHz
Chipset/Core Logic
Intel® 915GME and ICH6
System Memory
Up to 2GB DDR2 533/400 SDRAM on two 200-pin SODIMM sockets
BIOS
Award BIOS
Storage Devices
EIDE: Support two EIDE devices with Ultra DMA 100/66/33
SATA: Support four SATA 150 devices (two through backplane)
Solid State Disk
One Type II CF socket; On Primary EIDE channel
Watchdog Timer
Programmable via software from 0.5 sec. to 254.5 sec.
Expansion Interface
- One PCI Express x16
- Four PCI Express x1
- Four PCI
Hardware Monitoring
System monitor (fan, temperature, voltage)
Power Requirement
Typical: [email protected]; [email protected]
Dimension
Dimension: 338.5(L) x 122(W) mm; 13.33"(L) x 4.8" (W)
PCB: 8-layer
Environment
Operating Temperature: 0 to 60oC
Storage Temperature: -20 to 80oC
Relative Humidity: 5% to 90%, non-condensing
MTBF
91,855 hrs
I/O
ORDERING GUIDE
Standard
Optional
ROBO-8911VG2A
Socket mPGA479M Pentium® M or Celeron®
M processor based PICMG 1.3 SHB with
DDR2 SDRAM, VGA, Dual Gigabit Ethernet
and Audio
PA-M1AU
Multimedia kit with audio and USB ports
PS/2 Keyboard/Mouse with Bracket
PS/2 keyboard/mouse connectors on bracket
MIO
Two serial (selectable RS232/422/485 x1), one parallel, one FDD channel
IrDA
IrDA 1.0
Ethernet
- Dual 10BASE-T/100BASE-TX/1000BASE-T Ethernet
- Dual RJ-45 connector with two LED indicators
Audio
AC'97 2.2 Audio (Realtek ALC 202A)
USB
Eight USB 2.0 ports (four through backplane)
Keyboard & Mouse
Two USB 2.0 ports on bracket for keyboard & mouse
DISPLAY
Graphic Controller
915GM integrated Graphics Media Accelerator 900 (GMA 900)
Graphic Memory
Dynamic system memory sharing up to 224MB (Intel® DVMT 3.0) or static
system memory sharing up to 128MB
Display Interface
CRT: Up to 2048 x1536 mode
LVDS: Single/Dual 18-bit LVDS channel support
TV: Up to 1024 x 768 resolution supported for NTSC/PAL
SBC-ROBO-8911VG2A 18
ROBO-8910VG2A
+12V power connector
Two 240-pin DDR2 DIMM sockets
Intel® Pentium® 4 or Celeron® D processor
based PICMG 1.3 SHB with DDR2 533 SDRAM,
VGA, Dual Gigabit Ethernet and Audio
CF socket
Additional power source
IDE connector
Parallel port
FDD port
Dual COM ports
Dual USB ports
Four SATA ports
Dual USB ports
Dual GbE ports
VGA port
Intel® 915GV
mPGA478 socket
FEATURES
Intel® ICH6
GENERAL
Processor
CPU & Package: Intel® Pentium® 4 or Celeron® D processor in mFCPGA package
FSB: 800/533MHz
Chipset/Core Logic
Intel® 915GV and ICH6
System Memory
Up to 2GB DDR2 533/400 SDRAM on two 240-pin DIMM sockets
Intel 915GV chipset with high performance
integrated graphics, backed up by Intel®
IPD’s long product life support
BIOS
Award BIOS
Storage Devices
EIDE: Support two EIDE devices with Ultra DMA 100/66/33
SATA: Support four SATA 150 drives
Intel® new GMA 900 integrated provides
better display quality and effects thru faster
engine; SGI OpenGL 1.4, Microsoft DirectX
9.0 supported
Solid State Disk
- One type II CF socket; On Primary EIDE channel
- Bootable for no drive on primary channel
Watchdog Timer
Programmable via software from 0.5 sec. to 254.5 sec.
Expansion Interface
- Four PCI Express x1
- Four PCI
Hardware Monitoring
System monitor (fan, temperature, voltage)
Power Requirement
Typical: [email protected]; [email protected]
Dimension
Dimension : 338.5(L) x 126.39(W) mm; 13.33"(L) x 4.98" (W)
PCB: 8-layer
Environment
Operating Temperature: 0 to 60oC
Storage Temperature: -20 to 80oC
Relative Humidity: 5% to 90%, non-condensing
MTBF
115,533 hrs
High quality and reliable design with wider
range Intel® Pentium® 4/ Celeron® D
processor to support mission critical
operation
®
Four SATA 150 ports for high speed storage
interface and easy cable routing
Support four PCI Express x1, and four PCI
expansion via backplane (additional one PCI
Express x16 per project spec.)
I/O
MIO
Two serial (selectable RS232/422/485 x1), one parallel, one FDD channel
IrDA
IrDA 1.0
ROBO-8910VG2A
Socket 478 Pentium ® 4 or Celeron® D
processor based PICMG 1.3 SHB with DDR2
SDRAM, VGA, Dual Gigabit Ethernet and
Audio
Ethernet
- Dual 10BASE-T/100BASE-TX/1000BASE-T Ethernet
- Dual RJ-45 connectors with two LED indicators
Audio
AC’97 2.2 Audio (Realtek ALC 202A)
USB
Eight USB 2.0 ports (four ports through backplane)
PA-M1AU
Multimedia kit with audio and dual USB port
Keyboard & Mouse
Two USB 2.0 ports on bracket for keyboard & Mouse
ORDERING GUIDE
Standard
Optional
PS/2 Keyboard/Mouse with Bracket
PS/2 keyboard/mouse connectors on bracket
19 SBC-ROBO-8910VG2A
DISPLAY
Graphic Controller
915GV integrated Graphics Media Accelerator 900 (GMA 900)
Graphic Memory
Dynamic system memory sharing up to 224MB (Intel® DVMT 3.0) or static
system memory sharing up to 128MB
Display Interface
Display resolution up to 2048 x 536 @ 85Hz refresh
ROBO-8779VG2AR
+12V power connector
Intel® CoreTM 2 Quad processor based
PICMG 1.0 SBC with DDR3 SDRAM, VGA,
DVI, Dual Gigabit Ethernet, Audio and USB
COM2 (RS232/422/485 selectable)
CF socket
Dual 240-pin DDR3 DIMM sockets
FDD port
COM1
Parallel port
PS/2 K/B & Mouse
Six USB ports
Dual USB ports
Dual GbE ports
VGA port
Intel® G41
LGA775 socket
Intel® ICH7R
SDVO connector
Four SATA ports
DVI-D connector
FEATURES
GENERAL
Processor
CPU & Package: Intel ® CoreTM 2 Quad, CoreTM 2 Duo, Celeron ® processor in
LGA-775 package
FSB: 1333/1066/800MHz
Chipset/Core Logic
Intel® G41 and ICH7R
Delivers up to 4GB maximum DDR3 1066/
800 on two long DIMM sockets
System Memory
Up to 4GB DDR3 1066/800 SDRAM on two 240-pin DIMM socket
BIOS
AMI BIOS
Support Intel® G41 integrated GMA X4500
graphic engine delivers optimized 3D graphics
performance
Storage Devices
EIDA: N/A
SATA: Support four SATA 300 drives (RAID 0, 1, 5, 10)
With RAID on ROBO-8779VG2AR, W/o RAID on ROBO-8779VG2A
Support dual display VGA and DVI-D interface,
and SDVO connector for other types display by
project
Solid State Disk
One Type II CF socket (up to UDMA5 mode)
Watchdog Timer
Programmable via software from 0.5 sec. to 254.5 sec.
Expansion Interface
N/A
High speed dual Gigabit Ethernet based on PCI
Express x1, high bandwidth I/O interface
Hardware Monitoring
System monitor (fan, temperature, voltage)
Power Requirement
N/A
Support one CF socket up to UDMA5 mode
Dimension
Dimension : 338.5(L) x 122(W) mm; 13.33"(L) x 4.8" (W)
PCB: 8-layer
Rich I/O connections such as FDD, two Gigabit
Ethernet, serial ports, parallel port, USB 2.0, and
SATA ports
Environment
Operating Temperature: 0 to 55oC
Storage Temperature: -20 to 80oC
Relative Humidity: 5% to 90%, non-condensing
MTBF
N/A
Support Intel® CoreTM 2 Duo and CoreTM 2 Quad
processors and offers flexible 1333/1066/
800Mhz FSB selection
ORDERING GUIDE
Standard
ROBO-8779VG2AR
Intel ® Core™ 2 Quad processor based PICMG
1.0 SBC with DDR3 SDRAM, VGA, DVI, Dual
Gigabit Ethernet, Audio and USB
ROBO-8779VG2A
Intel ® Core™ 2 Quad processor based PICMG
1.0 SBC with DDR3 SDRAM, VGA, DVI, Dual
Gigabit Ethernet, Audio and USB
Optional
PA-M1AU
Multimedia kit with audio and USB ports
PS/2 Keyboard/Mouse Cable with Bracket
PS/2 keyboard/mouse connectors on bracket
USB Cable with bracket
Two USB ports with bracket
PA-G1D
DVI output card via board to board SDVO
connector
Low Profile LGA775 Cooler
High efficiency slim cooler increases reliability
of system
I/O
MIO
Two serial (RS232 x1, selectable RS232/422/485 x1), one parallel and one
FDD channel
IrDA
N/A
Ethernet
- Dual 10 BASE-T/100 BASE-TX/1000 BASE-T Ethernet
- PCI Express x1 interface based Gigabit Ethernet
- Dual RJ-45 connectors with two LED indicators
Audio
HDA interface, 2-channel Audio (Realtek ALC 662)
USB
Eight USB 2.0 ports (Dual ports on bracket)
Keyboard & Mouse
Two USB 2.0 ports on bracket dedicated to keyboard & mouse
DISPLAY
Graphic Controller
- GMCH integrated Intel® Graphics Media Accelerator (GMA) x4500
- Provided improved 3D multimedia capabilities including Microsoft DirectX 10,
Shader Model 4.0 and OpenGL 2.0
Graphic Memory
Intel® Dynamic Video Memory Technology (DVMT) 5.0 shares system memory
up to 1GB
Display Interface
Analog CRT: up to 2048 x 1536
DVI-D: up to 2048 x 1536
SBC-ROBO-8779VG2AR
20
ROBO-8777VG2A
Intel® CoreTM 2 Duo processor based PICMG
SBC with DDR2 SDRAM, VGA, Dual
Gigabit Ethernet, Audio and USB
COM2 (RS232/422/485 selectable)
Dual 240-pin DDR2 DIMM sockets
Four SATA 300 ports
COM1
Parallel port
+12V power connector
FDD port
PS/2 keyboard & mouse
Dual USB ports
Dual GbE ports
VGA port
Intel® Q965
LGA 775 socket
Intel® ICH8
Four USB ports
ISA Bus
FEATURES
GENERAL
Processor
CPU & Package: Intel® CoreTM 2 Duo, Pentium® D, Pentium® 4, Celeron® D
processor in the LGA-775 package
FSB: 1066/800/533MHz
Chipset/Core Logic
Intel® Q965 and ICH8
System Memory
Up to 4GB DDR2 800/667/533 SDRAM on dual 240-pin DIMM socket
BIOS
Award BIOS
Storage Devices
More features, such as EM64T, EIST, XD &
VT, can be easily applied to system by
changing processor
EIDE: N/A
SATA: Support four SATA 300 drives
Solid State Disk
N/A
Watchdog Timer
Programmable via software from 0.5 sec. to 254.5 sec.
Integrated Intel® GMA 3000 graphics engine
built with high grade display capability
Expansion Interface
N/A
Hardware Monitoring
System monitor (fan, temperature, voltage)
Lockable cable-latched notches of SATA
connector secure connection in vibration
condition
Power Requirement
Typical: [email protected]; [email protected]
Dimension
Dimension : 338.5(L) x 122(W) mm; 13.33"(L) x 4.8" (W)
PCB: 6-layer
Support ISA expansion
Environment
Operating Temperature: 0 to 60oC
Storage Temperature: -20 to 80oC
Relative Humidity: 5% to 90%, non-condensing
MTBF
93,788 hrs
Support Intel® CoreTM 2 Duo processor that
generates a maximum 65W TDP. Lower TDP
than socket 478 Pentium® 4 processor makes
the vertical mount slot board more reliable
Low profile processor cooler improves
stability and reliability of whole system
I/O
ORDERING GUIDE
Standard
Optional
ROBO-8777VG2A
LGA-775 Core 2 Duo processor based PICMG
1.0 SBC with DDR2 SDRAM, VGA, Dual
Gigabit Ethernet, Audio and USB
PA-M1AU
Multimedia kit with audio and USB ports
PS/2 Keyborad/Mouse Cable with Bracket
PS/2 keyboard/mouse connectors on bracket
Low Profile LGA775 Cooler
High efficiency slim cooler increases reliability
of system
21 SBC-ROBO-8777VG2A
MIO
Two serial (RS-232x1, selectable RS232/422/485x1), one parallel and one
FDD channel
IrDA
N/A
Ethernet
- Dual 10BASE-T/100BASE-TX/1000BASE-T Ethernet
- PCI Express x1 interface based Gigabit Ethernet
- Dual RJ-45 connectors with two LED indicators
Audio
HDA interface, 2-channel Audio (Realtek ALC 262)
USB
Six USB 2.0 ports
Keyboard & Mouse
Two USB 2.0 ports on bracket dedicated to keyboard & mouse
DISPLAY
Graphic Controller
- GMCH integrated Intel Graphics Media Accelerator 3000 (Intel® GMA 3000)
- Provides improved 3D multimedia capabilities including DirectX 9, Shader
Model 3.0, OpenGL 1.5, Advanced De-interlacing, MPEG-2 hardware
acceleration
Graphic Memory
Intel® Dynamic Video Memory Technology (DVMT) 4.0 system memory sharing
up to 256MB
Display Interface
Support CRT interface up to QXGA 75Hz (2048 x 1536)
Intel® CoreTM 2 Duo processor based PICMG
SBC with DDR SDRAM, VGA, Gigabit
Ethernet and USB
ROBO-8773VG
COM2
Two SATA ports
Two 184-pin DIMM sockets
Two IDE connectors
COM1 (RS-232/422/485 selectable)
+12V power connector
Parallel port
FDD port
Two USB ports
GbE ports
6-pin mini-DIN connector
for KB/Mouse
VGA port
LGA 775 socket
Intel® 865G
Six USB ports
Intel® ICH5
Standalone Power Source
ISA Bus
FEATURES
Extreme cost / performance PICMG 1.0 single
board computer supports LGA 775 processor
with Gigabit Ethernet controller
Various I/O interface includes dual IDE channel,
dual SATA port, single FDD channel, dual serial
and single parallel port
Over-clocking extended the board supports 2nd
generation, lower power consumption / thermal
profile Core 2 Duo processor
Integrated Intel® Extreme Graphics 2 graphics
engine offers adequate display quality via VGA
interface
Single side design enhance reliability of
production and simplify its process at the
same time
Eight plug-and-play USB 2.0 ports allow
enriched expansion of the system built
upon the board
Support ISA expansion
GENERAL
Processor
CPU & Package: Intel® CoreTM 2 Duo, Pentium® D, Pentium® 4, Celeron® D
processor in LGA-775 package
FSB: 800/533MHz
Chipset/Core Logic
Intel® 865G and ICH5
System Memory
Up to 2GB DDR 400/333/266 SDRAM on dual 184-pin DIMM socket
BIOS
Award BIOS
Storage Devices
EIDE: Support four EIDE devices with Ultra DMA 100/66/33
SATA: Support dual SATA 150 drives
Solid State Disk
N/A
Watchdog Timer
Programmable via software from 0.5 sec. to 254.5 sec.
Expansion Interface
N/A
Hardware Monitoring
System monitor (fan, temperature, voltage)
Power Requirement
Typical: [email protected]; [email protected]
Dimension
Dimension : 338.5(L) x 122(W) mm; 13.33"(L) x 4.8" (W)
PCB: 6-layer
Environment
Operating Temperature: 0 to 55oC
Storage Temperature: -20 to 80oC
Relative Humidity: 5% to 90%, non-condensing
MTBF
105,743 hrs
I/O
ORDERING GUIDE
MIO
Two serial (RS232 x1, selectable RS232/422/485 x1), one parallel and one
FDD channel
IrDA
N/A
Standard
ROBO-8773VG
LGA-775 processor based PICMG 1.0 SBC
with DDR SDRAM, VGA, Gigabit Ethernet
and USB
Ethernet
- Single 10BASE-T/100BASE-TX/1000BASE-T Ethernet
- PCI interface based Gigabit Ethernet
- Single RJ-45 connector with two LED indicators
Audio
AC’97 interface reserved
Optional
USB Cable with bracket
Two USB ports with bracket
Low Profile LGA775 Cooler
High efficiency slim cooler increases reliability
of system
PA-M5A
Audio kit
USB
Eight USB 2.0 ports (Dual ports on bracket)
Keyboard & Mouse
One 6-pin mini-DIN connector for Keyboard & Mouse
DISPLAY
Graphic Controller
- GMCH integrated Intel® Extreme graphics 2 technology
- High performance 3D setup & render engine and hardware motion
compensation for MPEG2
Graphic Memory
Intel® Dynamic Video Memory Technology (DVMT) 2.0 system memory sharing
up to 64MB
Display Interface
Support CRT interface up to QXGA 75Hz (2048 x 1536)
SBC-ROBO-8773VG 22
ROBO-8719VG2AR
Intel® latest 45nm CoreTM 2 Duo or Celeron® M
processor based PICMG SBC with DDR2
SDRAM, VGA, Dual Gigabit Ethernet and Audio
Additional power source
COM2 (RS232/422/485 selectable)
Dual 240-pin DDR2 DIMM sockets
CF socket
FDD
+12V power connector
Intel® GM45
COM1
Parallel port
PS/2 K/B & Mouse
Four USB ports
Dual USB ports
Dual GbE ports
VGA port
Intel® ICH9ME
LVDS connector
SDVO connector
GENERAL
FEATURES
Three SATA ports
Processor
CPU & Package: Intel® 45nm Mobile CoreTM 2 Quad, CoreTM 2 Duo, Celeron® M
processor in mFCPGA package
FSB: 1066/800/667MHz
Chipset/Core Logic
Intel® GM45 and ICH9ME
System Memory
Up to 4GB DDR2 800/667 SDRAM on dual 240-pin DIMM socket
Integrated 5 generation graphic engine Mobile Intel
GMA 4500MHD built with max. graphics core speeds
up to 533MHz to improve graphics and 3D rendering
performance
BIOS
Award BIOS
Storage Devices
EIDE: N/A
SATA: Support three SATA 300 drives (RAID 0, 1)
Solid State Disk
One Type II CF socket (Up to UDMA5 mode)
Support two on-board display output options,
including VGA and 24-bit LVDS for flexible display
choice. An optional DVI-D output card support via
board to board SDVO connector by project
Watchdog Timer
Programmable via software from 0.5 sec. to 254.5 sec.
Expansion Interface
N/A
Hardware Monitoring
System monitor (fan, temperature, voltage)
Power Requirement
Typical: [email protected]; [email protected]
Dimension
Dimension : 338.5(L) x 122(W) mm; 13.33"(L) x 4.8" (W)
PCB: 8-layer
Environment
Operating Temperature: 0 to 60oC
Storage Temperature: -20 to 80oC
Relative Humidity: 5% to 95%, non-condensing
MTBF
111,404 hrs
ROBO-8719VG2A offers flexible FSB up to 1066MHz
selection of Intel® 45nm Mobile CoreTM 2 Quad,
CoreTM 2 Duo or Celeron® M processor that features
high computing power with low heat
th
®
®
Support integrated Intel Trusted Platform Module
(iTPM) for more secure plateforms
Support CF socket by SATA to IDE bridge for more
storage application
High speed dual Gigabit Ethernet support
Various I/O interface includes three high-speed
SATA 300 ports, six USB 2.0 ports, single Parallel
port, two COM ports and single FDD port
ORDERING GUIDE
Standard
Optional
ROBO-8719VG2AR
Intel ® latest 45nm CoreTM 2 Duo or Celeron® M
processor based PICMG SBC with DDR2 SDRAM,
VGA, Dual Gigabit Ethernet, and Audio
PA-M1AU
Multimedia kit with audio and USB ports
PS/2 Keyboard/Mouse Cable with Bracket
PS/2 keyboard/mouse connectors on bracket
PA-G1D
DVI output card via board to board SDVO connector
23 SBC-ROBO-8719VG2AR
I/O
MIO
Two serial (RS232 x1, selectable RS232/422/485 x1), one parallel and one
FDD channel
IrDA
N/A
Ethernet
- Dual 10BASE-T/100BASE-TX/1000BASE-T Ethernet
- PCI Express x1/GLCI/LCI interface based Gigabit Ethernet
- Dual RJ-45 connector with two LED indicators
Audio
HDA interface, 2-channel Audio (Realtek ALC 262)
USB
Six USB 2.0 ports
Keyboard & Mouse
Two USB 2.0 on bracket dedicated to keyboard & mouse
DISPLAY
Graphic Controller
- GMCH integrated Intel® Graphics Media Accelerator 4500MHD
- Provides improved 3D multimedia capabilities including DirectX 10, OpenGL
2.0, MPEG-2 hardware acceleration
Graphic Memory
Intel® Dynamic Video Memory Technology (DVMT) 5.0 shares system memory
to 256MB
Display Interface
CRT: Up to QXGA (2048x1536 mode)
LVDS: Dual channel 24-bit LVDS
SDVO: Optional DVI-D output card via SDVO channel
(Two display streams supported in above combination)
Ultra Low Voltage Intel® Celeron® M
processor based PICMG SBC with
VGA and LAN
ROBO-8771VG2
Standalone power connector
Parallel port
Two IDE connectors
One 200-pin SO-DIMM socket
FDD port
PS/2 KB/Mouse connector
Dual COM ports
Dual USB ports
Dual GbE ports
VGA port
Intel® ULV Celeron® M
600MHz processor
Intel® 852GM
FEATURES
Intel® ICH4
GENERAL
Processor
On-board Ultra Low Voltage Intel® Celeron® M
600MHz with L2 Cache processor with passive heat
sink for misson critical & fanless application
CPU & Package: Ultra Low Voltage Intel® Celeron® M 600MHz processor
FSB: 400MHz
Chipset/Core Logic
Intel® 852GM and ICH4
System Memory
Up to 1GB DDR 200/266 SDRAM on one 200-pin SODIMM socket
Ideal replacement in terms of cost, functionality and
performance
BIOS
Award BIOS 184-pin DIMM socket
Storage Devices
Support dual EIDE devices with Ultra DMA 100/66/33
Stand alone workable single board computer
Solid State Disk
N/A
Rich I/O connections such as IDE, Gigabit Ethernet,
serial port, parallel port, and USB ports
Watchdog Timer
Programmable via software from 0.5 sec. to 254.5 sec.
Expansion Interface
N/A
Hardware Monitoring
System monitor (fan, temperature, voltage)
Power Requirement
Typical: [email protected]; [email protected]
Dimension
Dimension : 338.5(L) x 122(W) mm; 13.33"(L) x 4.8" (W)
PCB: 6-layer
Environment
Operating Temperature: 0 to 60oC
Storage Temperature: -20 to 75oC
Relative Humidity: 5% to 95%, non-condensing
MTBF
130,741 hrs
ORDERING GUIDE
I/O
Standard
Optional
ROBO-8771VG2
Ultra Low Voltage Intel® Celeron® M processor
based PICMG SBC with VGA and LAN
USB Cable with bracket
Two USB ports with bracket
PS/2 Keyboard/Mouse Cable with Bracket
PS/2 keyboard/mouse connectors on bracket
PA-M5A
Audio kit
MIO
Two serial (one RS232/422/485 selectable), one parallel, one FDD channel
IrDA
N/A
Ethernet
- 10BASE-T/100BASE-TX/1000BASE-T Ethernet
- IEEE 802.3u auto-negotiation
- Dual RJ-45 connector with two LED indicators
Audio
AC'97 2.2 interface reserved
USB
Six USB 2.0 ports
Keyboard & Mouse
Two ports USB 2.0 on bracket dedicated to keyboard & mouse
DISPLAY
Graphic Controller
Intel® 852GM mobile optimized graphics controller
Graphic Memory
Dynamically allocates 32/64MB system memory for display
Display Interface
Support VGA (DB15 on bracket) interface
SBC-ROBO-8771VG2 24
ROBO-8718VG2A
Intel® Pentium® M or Celeron® M processor
based PICMG SBC with DDR2 533 SDRAM,
VGA, Dual Gigabit Ethernet and Audio
Dual COM port
Intel® 915GME
Four SATA ports
Parallel port
CF socket
TV-out connector LVDS panel connector
FDD port
IDE connector
Dual USB ports
Additional power source
Dual GbE ports
+12V power connector
VGA port
mPGA479M socket
Dual USB ports
Intel® ICH6
Two 200-pin SO-DIMM sockets
FEATURES
ROBO-8718 offers flexible 400MHz and
533MHz FSB selection of Intel® Pentium® M /
Celeron® M that features high computing power
with low heat
Scalable graphics support from Intel® 915GM
featuring GMA 900 to ATI M22 graphics
controller integrated 64MB display memory via
PCI Express x16
GENERAL
Processor
CPU & Package: Intel® Pentium® M or Celeron® M processor in mFCPGA
package
FSB: 533/400MHz
Chipset/Core Logic
Intel® 915GME and ICH6
System Memory
Up to 2GB DDR2 533/400 SDRAM on two 200-pin SODIMM sockets
BIOS
Award BIOS
Storage Devices
EIDE: Support two EIDE devices with Ultra DMA 100/66/33
SATA: Support four SATA 150 drives
Solid State Disk
- One Type II CF socket
- On Primary EIDE channel
- Bootable for no drives on primary channel
ATI M22 graphics support dual display
configuration of LCD/CRT, TV/ CRT, LCD/LCD,
LCD/TV displays
Watchdog Timer
Programmable via software from 0.5 sec. to 254.5 sec.
High speed dual Gigabit Ethernet based on PCI
Express x1, high bandwidth I/O interface
Expansion Interface
N/A
Hardware Monitoring
System monitor (fan, temperature, voltage)
Four SATA 150 ports for high speed storage
interface and easy cable routing
Power Requirement
Typical: [email protected]; [email protected]
Dimension
Dimension : 338.5(L) x 122(W) mm; 13.33"(L) x 4.8" (W)
PCB: 8-layer
Environment
Operating Temperature: 0 to 60oC
Storage Temperature: -20 to 80oC
Relative Humidity: 5% to 90%, non-condensing
MTBF
77,830 hrs
ORDERING GUIDE
Standard
Optional
ROBO-8718VG2A
Socket mPGA479M Pentium® M or Celeron ®
M processor based PICMG SBC with DDR2
533 SDRAM, VGA, Dual Gigabit Ethernet and
Audio
PA-M1AU
Multimedia kit for P4 SBC with audio and USB
ports
DVI-D Cable
TMDS adapter cable for DVI interface flat
panel
I/O
MIO
Two serial (selectable RS232/422/485 x1), one parallel, one FDD channel
IrDA
IrDA 1.0
Ethernet
- 10BASE-T/100BASE-TX/1000BASE-T Ethernet
- Dual PCI-Express x1 based
- Dual RJ-45 connectors with two LED indicators
Audio
AC’97 2.2 Audio (Realtek ALC 202A)
USB
Four USB 2.0 ports
Keyboard & Mouse
Two USB 2.0 ports on bracket dedicated to keyboard & mouse
DISPLAY
Graphic Controller
- ATI Mobility M22 graphics controller [ROBO-8718UG2A]
- Intel® 915GM integrated GMA 900 (Graphics Media Accerator) [ROBO-8718VG2A]
Graphic Memory
64MB display memory
Display Interface
- Support CRT, LVDS, TV-out & DVI-D (TMDS) display interfaces [ROBO8718UG2A]
- Support CRT, LVDS & TV-out display interfaces [ROBO-8718VG2A]
25 SBC-ROBO-8718VG2A
ROBO-8713VGA
+12V power connector
Two 184-pin DIMM sockets
Intel® Pentium® 4 or Celeron® D processor
based PICMG SBC with DDR 400 SDRAM,
AGP 8X VGA, Gigabit Ethernet and Audio
CF socket
Additional power source
Two IDE connectors
FDD port
Parallel port
Two Serial ATA ports
Two COM ports
GbE LAN port
Two USB 2.0 ports
PS/2 KB/Mouse connector
PCI extension conncector
VGA port
Intel® 865G
Intel® ICH5
mPGA478 socket
FEATURES
Intel ® Pentium® 4 processor with HyperThreading technology runs at 800MHz FSB
GENERAL
Processor
CPU & Package: Intel® Pentium® 4 or Celeron® (D) processor in mPGA478
package
FSB: 800/533/400MHz
Chipset/Core Logic
Intel® 865G and ICH5
System Memory
Up to 2GB dual channel DDR 400/333/266 SDRAM on two 184-pin DIMM
sockets
BIOS
Award BIOS
Storage Devices
EIDE: Support four EIDE devices with Ultra DMA 100/66/33
SATA: Support two SATA 150 devices
Solid State Disk
- One Type II CF socket
- On Secondary EIDE channel
Watchdog Timer
Programmable via software from 0.5 sec. to 254.5 sec.
Expansion Interface
Proprietary PCI connection interface
Hardware Monitoring
System monitor (fan, temperature, voltage)
Power Requirement
Typical: [email protected]; +12V(CPU)@5.7A; +12V (system)@0.8A
Dimension
Dimension : 338.5(L) x 122(W) mm; 13.33"(L) x 4.8" (W)
PCB: 8-layer
Environment
Operating Temperature: 0 to 50oC
Storage Temperature: -20 to 80oC
Relative Humidity: 5% to 90%, non-condensing
MTBF
98,733 hrs
Wire-speed Gigabit Ethernet based on
Communication Streaming Architecture
(CSA) with double throughput than PCI
based Ethernet
Rich expansion capability thru proprietary PCI
ORDERING GUIDE
Standard
ROBO-8713VGA
Socket 478 Pentium® 4 or Celeron® D processor
based PICMG SBC with DDR 400 SDRAM, integrated
graphic, Gigabit Ethernet and audio
Optional
ROBO-U160H
SCSI extension module with Portwell OmniPCITM
connection interface
ROBO-N100P
Single Fast Ethernet port extension module with
Portwell OmniPCITM connection interface
PA-M1AU
Multimedia kit for P4 SBC with audio and
USB ports
I/O
MIO
Two serial (selectable RS232/422/485 x1), one parallel, one FDD channel
IrDA
IrDA 1.0
Ethernet
- 10BASE-T/100BASE-TX/1000BASE-T Ethernet
- Gigabit Ethernet via CSA interface
- One RJ-45 connector with two LED indicators
Audio
AC’97 2.2 Audio (Realtek ALC 202A)
USB
Four USB 2.0 ports (two on bracket)
Keyboard & Mouse
- One 6-pin mini-DIN connector for keyboard and mouse
- One 5-pin header for external keyboard connection
DISPLAY
Graphic Controller
Intel® 865 integrated Extreme Graphics 2.0
Graphic Memory
64MB display memory
Display Interface
Support CRT display interface
SBC-ROBO-8713VGA 26
ROBO-6711VGA
FEATURES
Support Intel® low power consumption 533/
400MHz FSB Pentium® M/Celeron® M processor
for thermal/power limited applications
mPGA479M Pentium® M/Celeron® M
processor based half-size PCI SBC with
VGA, LCD, GbE and Audio
GENERAL
Processor
CPU & Package: Intel® Pentium® M/Celeron® M processor
FSB: 533/400MHz
Chipset/Core Logic
Intel® 852GME and ICH4
System Memory
Up to 1GB DDR 266/333 SDRAM with ECC on one 200-pin SODIMM socket
One SODIMM socket at the rear that supports up
to 1GB ECC system memory for critical
applications
BIOS
Award BIOS
Storage Devices
- Support dual EIDE channel with Ultra DMA 100/66/33
- One 44-pin and one 40-pin connector
Support dual display function via VGA and
LVDS output
Solid State Disk
- One Type II CF socket
- On secondary EIDE channel
- Bootable for no drives primary channel
Perfect engine for slim computers with LVDS
interface LCD panel
Watchdog Timer
Programmable via software from 0.5 sec. to 254.5 sec.
N/A
On-board Intel® 10BASE-T/100BASE-TX/
1000BASE-T Gigabit Ethernet
Expansion Interface
Hardware Monitoring
System monitor (fan, temperature, voltage)
Power Requirement
Typical: [email protected]; +12V(CPU)@1.5A
Dimension
Dimension : 185(L) x 122(W) mm; 7.3"(L) x 4.8" (W)
PCB: 8-layer
Environment
Operating Temperature: 0 to 55oC
Storage Temperature: -20 to 80oC
Relative Humidity: 5% to 90%, non-condensing
MTBF
116,027 hrs
One Type II Compact Flash at the rear supports
up to 1GB flash disk for installation OS without
hard drive
Audio Codec ’97 (AC’97) 2.2 for high quality
audio architecture
PCI bus interface for higher flexibility and
expandability
Optional support TV-out by project
ORDERING GUIDE
Standard
Optional
ROBO-6711VGA
mPGA479M Pentium® M/Celeron® M processor
based half-size PCI SBC with VGA, LCD, GbE and
Audio
PA-M1AU
Multimedia kit with audio and USB ports on bracket
27 SBC-ROBO-6711VGA
I/O
MIO
Two serial (one on bracket; one RS232/422/485 selectable), one parallel, one
FDD channel
IrDA
IrDA 1.0
Ethernet
- 10BASE-T/100BASE-TX/1000BASE-T Ethernet
- IEEE 802.3u auto-negotiation
- One RJ-45 connector with two LED indicators
Audio
AC’97 2.2 Audio (Realtek ALC 203)
USB
Four USB ports
Keyboard & Mouse
One 6-pin mini-DIN connector for keyboard/mouse
DISPLAY
Graphic Controller
Intel® 852GME mobile optimized graphics controller
Graphic Memory
Dynamical allocates 32/64MB system memory for display
Display Interface
Support VGA (DB15 on bracket) and LVDS interface
ROBO-6730VLA
FEATURES
GENERAL
Processor
CPU & Package: Ultra Low Voltage Intel® Celeron® M 600MHz processor
FSB: 400MHz
Chipset/Core Logic
Intel® 852GM and ICH4
System Memory
Up to 1GB DDR 200/266/333 SDRAM on one 200-pin SODIMM socket
BIOS
Award BIOS
Storage Devices
Support dual EIDE devices with Ultra DMA 100/66/33
Solid State Disk
- One Type II CF socket
- On secondary EIDE channel
- Bootable for no drives primary channel
Watchdog Timer
Programmable via software from 0.5 sec. to 254.5 sec.
Expansion Interface
N/A
Hardware Monitoring
System monitor (fan, temperature, voltage)
Power Requirement
Typical: [email protected]; [email protected]
Dimension
Codec '97 (AC'97) 2.2 for high quality
audio architecture
Dimension : 185(L) x 122(W) mm; 7.3"(L) x 4.8" (W)
PCB: 8-layer
Environment
PCI bus interface for higher flexibility and
expandability
Operating Temperature: 0 to 55oC
Storage Temperature: -20 to 75oC
Relative Humidity: 5% to 95%, non-condensing
MTBF
115,787 hrs
Fanless solution with on-board Ultra Low
Voltage Intel® Celeron® M 600MHz processor
Support dual display function via VGA and
LVDS output
Perfect engine for slim computers with LVDS
interface LCD panel
On-board Intel® 10BASE-T/100BASE-TX Fast
Ethernet
One SODIMM socket at the rear supports
up to 1GB system memory
One Type II Compact Flash at the rear supports
up to 1GB flash disk for installation OS wtihout
hard drive
Audio
Ultra Low Voltage Intel® Celeron® M
processor based half-size PCI SBC with
VGA, LCD, LAN and Audio
I/O
ORDERING GUIDE
Standard
Optional
ROBO-6730VLA
Ultra Low Voltage Intel ® Celeron® M processor based
half-size PCI SBC with VGA, LCD, LAN and Audio
PA-M1AU
Multimedia kit with audio and USB ports on bracket
MIO
Two serial (one on bracket; one RS232/422/485 selectable), one parallel, one
FDD channel
IrDA
IrDA 1.0
Ethernet
- 10BASE-T/100BASE-TX Ethernet
- IEEE 802.3u auto-negotiation support
- One RJ-45 connector
Audio
AC'97 2.2 Audio (Realtek ALC 202A)
USB
Four USB ports
Keyboard & Mouse
One 6-pin mini-DIN connector for keyboard/mouse
DISPLAY
Graphic Controller
Intel® 852 mobile optimized graphics controller
Graphic Memory
Dynamically allocates 32/64MB system memory for display
Display Interface
Support VGA (DB15 on bracket) and LVDS interface
SBC-ROBO-6730VLA 28
PICMG Backplane
PICMG GENERAL DESCRIPTION
PICMG Backplane in this section are SBC (Single Board Computer)/SHB (Single Host Board) companion that feature
expansion slots such as ISA, PCI, PCI-X or PCI Express interface. In addition, backplane also features several power
connectors that draw power from power supply to devices on it. Some LEDs are designed on board to indicate status of
each power rail.
PICMG 1.0 supports both ISA & PCI, PICMG 1.2 supports dual PCI or PCI-X, and PICMG 1.3 supports PCI Express and PCI
expansion. Some bridges or switches can be applied to backplane to support more devices or different kind of expansion
interfaces. However, PICMG 1.0, 1.2, and 1.3 are not compatible with each other.
PICMG 1.0 BACKPLANE
Passive Backplane: Backplane that only support up to four PCI master
32-bit PCI/16-bit ISA
18-slot Dual-system PICMG Backplane
155.35
155.35
19-slot (4xPCI) PICMG Backplane
71.25
79.5
71.25
79.5
- Fit for 20-slot chassis
- Designed for fault-tolerant computing
- ATX power connector support
265.2
265.2
- Fit for 20-slot chassis
- ATX power connector support
- Sufficient ISA slots for CTI application
PBP-18D4
10.16
10.16
PBP-19P4
18.6
52.11
140.49
99.61
40.6
101.6
27.14
72.47
140.49
40.6
101.6
415.4
415.4
159.44
18.6
69.14
212.96
69.94
317
PBP-13D4
10.16
155.35
34.9
212.96
13-slot Dual-system PICMG Backplane
257
71.25
71.25
53.6
- Fit for 14-slot chassis
- Special design for full-length PCI cards
- ATX power connector support
79.5
257
155.35
13-slot (4xPCI) PICMG Backplane
18.6
69.14
212.96
69.94
- Fit for 14-slot chassis
- Design for fault-tolerant computing
- ATX power connector support
79.5
10.16
PBP-13R4
69.94
317
317
PBP-08P3
18.6
96.61
18.6
96.61
PBP-08P4
8-slot (4xPCI) PICMG Backplane
71.25
10.16
79.5
8-slot (3xPCI) PICMG Backplane
- Fit for node chassis and
desktop case
212.96
217.96
212.96
217.96
- Fit for node chassis and
desktop case
- ATX power connector support
71.25
155.35
10.16
79.5
257
155.35
257
PBP-06P3
PBP-06P4
6-slot (3xPCI) PICMG Backplane
- Fit for node chassis
- ATX power connector support
15
55.5
- Fit for node chassis
- ATX power connector support
96
121.2
140.7
55.50
96.00
121.20
140.20
6-slot (4xPCI) PICMG Backplane
4.39
15.0
10.10
25.33
- 2.4 mm PCB thickness
- ATX power connector support
- Fit for 14-slot chassis
69.14
212.96
69.94
317
88.38
14-slot (4xPCI) Active PICMG Backplane
257
- Fit for 14-slot chassis
- ATX power connector support
- The most popular and reliable
PICMG backplane
67.16
257
155.35
14-slot (4xPCI) PICMG Backplane
79.5
71.25
18.6
ACTI-14P4
10.16
10.16
PBP-14P4
75.41
18.6
165.1
253.1
165.60
254.10
263.10
29 Backplane-PICMG
263.1
PICMG Backplane
PBP-02V1X
33.7
PBP-06V4
84
Vertical 6-slot (4xPCI) PICMG Backplane
Left View
Right View
Right View
Vertical 2-slot (1xPCI) PICMG Backplane
- Fit for 1U chassis
- ATX power connector support
33.7
- Fit for 2U chassis
- ATX and AT power connector support
331.9
Left View
327.9
327.9
84
331.9
39.5
PBP-03P2X
Vertical 3-slot (2xPCI) PICMG Backplane
337.11
Left View
Right View
39.5
- Fit for Portwell’s 1U chassis
- ATX power connector support
337.11
64-bit PCI/16-bit ISA
PBP-06P464
PBP-06V464
83.95
15
10.1
Vertical 6-slot (4x64-bit PCI)
PICMG Backplane
- Fit for node chassis
- ATX and AT power connector support
55.5
96.1
121.21
140.21
6-slot (4x64-bit PCI) PICMG Backplane
166.3
331.98
Left View
Right View
170.75
83.95
295.84
310.19
- Fit for 2U chassis
- ATX power connector
331.98
Active Backplane: Backplane that using bridge to support PCI master beyond four
PBP-19AC
265.2
265.2
19-slot (12xPCI) Active PICMG
Backplane
155.35
155.35
19-slot (18xPCI) Active PICMG
Backplane
10.16
10.16
PBP-19AI
71.25
79.5
89.69
71.25
79.5
89.69
18.6
18.6
27.17
52.11
88.38
88.38
40.6
101.57
72.47
52.11
27.17
72.47
101.57
40.6
415.4
ACTI-14AA
6.87
PBP-14AC-B
33.06
155.35
8
141.01
257.18
66.87
18.66
15.99
- 2.4 mm PCB thickness
- ATX power connector support
- Fit for 14-slot chassis
68.95
212.79
61
108
74.98
72.56
89.86
12.06
16.51
14-slot (10xPCI) Active PICMG Backplane
162.68
14-slot (12xPCI) Active PICMG
Backplane
260
10.16
415.4
68.15
316.87
317
PBP-14AC
10.16
10.16
PBP-14A7
18.6
155.35
257
71.25
18.6
69.14
212.96
14-slot (12xPCI) Active PICMG
Backplane
79.5
79.5
71.25
257
155.35
14-slot (7xPCI) Active PICMG
Backplane
96.61
69.94
45.37
70.98
34.9 35.04
317
317
71.25
8-slot (7xPCI) Active PICMG
Backplane
217.96
212.96
18.6
96.61
PBP-08A7
10.16
79.5
155.35
257
Backplane-PICMG 30
PICMG Backplane
PICMG 1.3 Selection Guide
Model
PBPE-19AG64
PCIEx16
PCIEx8
1 (x8 signal)
1 (x4 signal)
PBPE-14AD64
1
PBPE-06V464
Server
Grade
PBPE-08P41
2 (x8 signal)
PBPE-06A364
2 (x8 signal)
PBPE-06P2
2 (x8 signal)
PBPE-13A8
1
PBPE-12A9
1
PBPE-12AA64
1
PBPE-06V3
1
Non-Server
PBPE-06V
Grade
PCIEx4
PCIEx1
1
PBPE-05A364
1
1
8
ROBO8914VG2AR
ROBO8913VG2AR
ROBO8912VG2AR
1
4
3
1 (x4 signal)
4
2
1
1 (x4 signal)
2
3
8
1 (x4 signal)
9
8
2
1 (x4 signal)
3
4
1
4
2
PBPE-06P4
1
1 (x4 signal)
PBPE-06P3
ROBO8921VG2R
PCI
16
1
PBPE-07P4
PCI-X
1
4
1
3
PICMG 1.3 BACKPLANE
Server Grade Backplane
10.16
327
24.13
21.59
203.2
273
65.41
17.78
139.7
239.96
302.26
- Fit for 4U up chassis
- Four PCI-X buses support 16 PCI-X
expansion slots
232.49
14-slot [PCI-E x4 (1), PCI-E x8 (1), PCI-X (8),
PCI (3)]
196.93
PBPE-14AD64
19-slot [PCI-E x16 (1, x8 signal),
PCI-E x8 (1, x4 signal), PCI-X (16)]
160.10
154.94
PBPE-19AG64
- Fit for 4U chassis
- Four PCI-X buses support eight PCI-X
expansion slots
63.5
416.56
78.74
176.61
195.58
224.72
259.62
327
10.16
PBPE-06V464
8-slot [PCI-E x8 (1, x4 signal), PCI-E x16
(2, x8 signal), PCI (4)]
Vertical 6-slot [PCI-E x4 (1), PCI-X (4)]
84
160.10
PBPE-08P41
331.94
327
- Fit for Node chassis
- Four USB ports
Left View
Right View
- Fit for 2U chassis
- Dual PCI-X buses support four PCI-X slots
79.5
84
76.99
331.94
18.6
78.01
45.37
70.98
217
88.5
88.5
61.36
61.36
31 Backplane-PICMG
- Fit for Node chassis
- Four USB ports
327
327
10.13
40.5 25.2
55.5
140.20
6-slot [PCI-E x8 (1, x4 signal), PCI-E x16
(2, x8 signal), PCI (2)]
155
155
6-slot [PCI-E x16 (2, x8 signal), PCI-X (2),
PCI (1)]
- Fit for Node chassis
- Four USB ports
- Dual SATA ports
- Two PCI-X buses support two PCI-X
expansion slot
PBPE-06P2
10.10
10.10
PBPE-06A364
10.13
40.5 25.2
55.5
140.20
PICMG Backplane
Non-Server Grade Backplane
239.96
273
327
- Fit for 4U chassis
- Four USB ports
- Dual SATA ports
- 24-pin ESP12V power connector
196.93
12-slot [PCI-E x16 (1), PCI-E x8 (1,
x4 signal), PCI (9)]
160.10
PBPE-12A9
13-slot [PCI-E x1 (3), PCI-E x16
(1), PCI (8)]
317
234.80
327
311.84
267.84
191.77
154.94
PBPE-13A8
- Fit for 4U chassis
- Four USB ports
- Dual SATA ports
78.74
78.74
176.61
195.58
224.72
259.62
317
176.61
195.58
224.72
259.62
317
7-slot [PCI-E x4 (1), PCI-E x16 (1), PCI (4)]
155.35
- Fit for 4U chassis
- Four USB ports
- Dual SATA ports
- Two PCI-X buses support eight
PCI-X expansion slot
- Fit for Node chassis
- Four USB ports
- Dual SATA ports
327
327
317
273
239.96
196.93
160.10
12-slot [PCI-X (8), PCI-E x16
(1), PCI (2)]
79.5
156.49
78.74
PBPE-07P4
10.16
PBPE-12AA64
78.01
49.38
176.61
195.58
224.72
259.62
317
45.37
70.98
194.36
217.96
PBPE-06V3
Vertical 6-slot [PCI-E x1 (4),
PCI-E x16 (1)]
Vertical 6-slot [PCI-E x8 (1, x4
signal),
PCI-E x16 (1), PCI (3)]
84
84
PBPE-06V
331.94
331.94
Left View
Right View
Left View
Right View
84
84
- Fit for 2U chassis
- Four USB ports
- Dual SATA ports
- 24-pin ESP 12V power connector
- Fit for 2U chassis
- Four USB ports
- Dual SATA ports
331.94
331.94
149.86
88.5
149.86
88.5
- Fit for Node chassis
- Four USB ports
- Dual SATA ports
327
327
10.13
40.5 40.5 25.2
6-slot [PCI-E x8 (1, x4 signal),
PCI (4)]
155
155
6-slot [PCI-E x16 (1), PCI-E x4
(1), PCI (3)]
- Fit for Node chassis
- Four USB ports
- Dual SATA ports
PBPE-06P4
10.10
10.10
PBPE-06P3
10.13
40.5 40.5 25.2
140.2
140.2
10.10
PBPE-05A364
88.5
- Fit for Node chassis
- Four USB ports
- Dual SATA ports
- Two PCI-X buses support two
PCI-X expansion slot
327
155
5-slot [PCI-E x16 (1), PCI-X (2),
PCI (1)]
149.86
10.13
40.5 40.5 25.2
140.2
Backplane-PICMG 32
PCI & ISA Backplane
PCI GENERAL DESCRIPTION
Compact size backplane for half size PCI SBC
PICMG 1.0 Rev 2.1 Compliant (PCI golden finger only)
Support AT or ATX type power connector
4-layer PCB with power and ground planes to reduce
power noise and keep lower impedance
Frame rated PCB at 94-V0
User friendly design supports external K/B
connector, power for chassis fan and power indicator
PBP-05P
PBP-04P
5-slot Passive PCI Backplane
4-slot Passive PCI Backplane
36.11
10.6
22.43
59.31
104.08
66.2
140.00
85.85
33.76
46.91
124.35
83.35
85.85
44.35
44.35
170
37.01
160.00
170.00
ISA GENERAL DESCRIPTION
4-layer PCB with ground and power planes
for reducing noise and keeping lower impedance
Frame Rated PCB at 94-V0
LED power indicator for +5V, +12V, -5V and 12V
Easy cut for dual or multi systems(*)
Plug-in sockets of termination resistors for high-
170
165.1
14.4
15.24
6
6.35
43.18
Equipped with gold-plated socket for good contact
182
169
83.83
90
4-slot Passive ISA Backplane
44
72
Heavy duty terminal block connector for
industrial power supply wiring(*)
PBP-04I
3-slot Passive ISA Backplane
11
PBP-03I
speed signal.(*)
“*”means for most part of products
PBP-06I
PBP-08I
PBP-14I
6-slot Passive ISA Backplane
8-slot Passive ISA Backplane
14-slot Passive ISA Backplane
318.9
175.3
165
152.4
77.266
69.78
10.16
15.4
25.4
10.16
180.5
97.3
122.5
135
53.6
220.6
33 Backplane-PCI & ISA
70.98
155.35
174.6
16
55.5
69.78
46.114
70.98
57
5
IMB Reference Table
MODEL
RUBY-9911
RUBY9719VG2AR
RUBY9718VG2AR
RUBY9717VGAR
RUBY9716VG2AR
Form Factor
ATX
ATX
ATX
uATX
ATX
Chipset
Q45+ICH10DO
G41+ICH7R
Q965+ICH8DO
Q965+ICH8DO
Q965+ICH8DO
CPU
CoreTM 2 Quad/
CoreTM 2 Duo
CoreTM 2 Quad/
CoreTM 2 Duo
CoreTM 2 Quad/ CoreTM
2 Duo/ Pentium® D/
Pentium® 4/ Celeron® D
CoreTM 2 Quad/ CoreTM
2 Duo/ Pentium® D/
Pentium® 4/ Celeron® D
CoreTM 2 Quad/ CoreTM
2 Duo/ Pentium® D/
Pentium® 4/ Celeron® D
Display
VGA/DVI-D
VGA
VGA/DVI-D
VGA/DVI-D
VGA
Memory
DIMM x2 and up to 4G
DIMM x2 and up to 4GB
DIMM x4 and up to 8GB
DIMM x4 and up to 8GB
DIMM x4 and up to 8GB
Expansion
Four PCI slots, One
PCI-E x4 slot, One PCIEx16 slot
One PCI-E x16 slot, One
ISA slot and five PCI slot
Four PCI slots, Two PCI-E
x1 slot, One ADD2 slot
Two PCI slots, One PCI-E
x4 slot, One ADD2 slot
Four PCI slots, One
PCI-E x4 slot, One PCI-E
x16 slot
LAN
Gbe x2
GbE x2
GbE x2
GbE x1
GbE x2
Serial
RS232 x3,
RS232/422/485*1
RS232 x5,
RS232/422/485 x1
RS232 x3,
RS232/422/485 x1
RS232 x3,
RS232/422/485 x1
RS232 x3,
RS232/422/485 x1
USB
USB 2.0*8
USB 2.0 x8
USB 2.0 x10
USB 2.0 x10
USB 2.0 x8
SATA
SATA 4
SATA x4
SATA x6
SATA x6
SATA x5
IDE
IDE x1
IDE x1
N/A
N/A
IDE x1
RAID
RAID 0/1/5/10
RAID 0/1/5/10
RAID 0/1/5/10
RAID 0/1/5/10
RAID 0/1/5/10
SSD
N/A
CF x1
N/A
N/A
CF x1
Paralell
LPT x1
LPT x1
LPT x1
LPT x1
LPT x1
FDD
FDD x1
N/A
FDD x1
FDD x1
FDD x1
IrDA
--
N/A
N/A
N/A
IrDA 1.0
Audio
HDA 2 channel
HDA 2 channel
HDA 2 channel
HDA 2 channel
HDA 2 channel
Dimension
304.8 x 243.8mm
304.8 x 243.8mm
304.8 x 243.8mm
243.8 x 243.8mm
304.8 x 243.8mm
Page
36
37
38
39
40
IMB-Reference Table 34
IMB Reference Table
MODEL
RUBY9716VGAR
RUBY9715VG2AR
RUBY9713VG2AR
RUBY7720VG2A
Form Factor
ATX
ATX
uATX
uATX
Chipset
Q965+ICH8DO
945G+ICH7R
945GME+ICH7R
915GME+ICH6M
CPU
CoreTM 2 Quad/ CoreTM
2 Duo/ Pentium® D/
Pentium® 4/ Celeron® D
CoreTM 2 Duo/ Pentium®
D/ Pentium® 4/ Celeron®
D
CoreTM 2 Duo/ CoreTM
Duo/ CoreTM Solo
Pentium® M/ Celeron® M
Display
VGA
VGA
VGA/LVDS
VGA/LVDS
DIMM x4 and up to 8GB
DIMM x4 and up to 4GB
SO-DIMM x2 and up
to 4GB
DIMM x2 and up to 2GB
Expansion
Four PCI slots, One PCIE x4 slot, One PCI-E x1
slot, One PCI-E x16 slot
Six PCI slots, One PCI-E
x16 slot
One PCI slot (support up
to 4 PCI slots via riser
card), One PCI-E x4 slot,
one PCI-E x16 slot
Two PCI slots, One PCIE x16 slot, One PCI-E
x1 slot
LAN
GbE x1
GbE x2
GbE x2
GbE x2
Serial
RS232 x3, RS232/422/
485 x1
RS232 x1, RS232/422/
485 x1
RS232 x1, RS232/422/
485 x1
RS232 x3, RS232/422/
485 x1
USB
USB 2.0 x8
USB 2.0 x8
USB 2.0 x8
USB 2.0 x8
SATA
SATA x5
SATA x4
SATA x4
SATA x2
IDE
IDE x1
IDE x1
IDE x1
IDE x1
RAID
RAID 0/1/5/10
RAID 0/1/5/10
RAID 0/1/5/10
N/A
SSD
CF x1
N/A
N/A
CF x1
Paralell
LPT x1
LPT x1
LPT x1 (pin header)
LPT x1
FDD
FDD x1
FDD x1
FDD x1
FDD x1
IrDA
IrDA 1.0
IrDA 1.0
IrDA 1.0
IrDA 1.0
Audio
HDA 2 channel
AC’97 2.2
AC’97 2.2
HDA 2 channel
Dimension
304.8 x 243.8mm
312.8 x243.8mm
243.8 x 243.8mm
243.8 x 243.8mm
Page
41
42
43
44
Memory
35 IMB-Reference Table
Leading Intel® Core™ 2 Quad / Core™ 2 Duo
Processor based ATX motherboard with Dual
Display, Dual Gigabit Ethernet, Four SATA
Ports, Four COM Ports, and Eight USB Ports
RUBY-9911
Four PCI slots
Dual GbE ports & Four USB ports
Dual COM ports
Audio
VGA & DVI-D
PS/2 Keyboard & Mouse
Dual COM ports
PCI Express x4 slot
Parallel port
PCI Express x16 slot
LGA 775 socket
IEEE1394a port
(optional)
Four USB ports
Two 240-pin DDR3 DIMM
sockets
Intel® ICH10DO
Gigabit Ethernet
VGA
Intel® Q45
FDD port
IDE connector
ATX 24-pin power connector
Four SATA 300 ports
KB/MS DVI-D RS-232
USB Audio
Rear I/O
FEATURES
GENERAL
Processor
CPU & Package: Intel® Core™ 2 Quad / Core™ 2 Duo processor in LGA-775
package
FSB: 1333/1066/800 MHz
Chipset/Core Logic
Intel® Q45 Express and ICH10DO
System Memory
Up to 4GB DDR3 800/1066MHz SDRAM on Two 240-pin DIMM sockets
BIOS
AMI BIOS
Storage Devices
EIDE: Support one EIDE devices with Ultra DMA 100/66/33
SATA: Support four SATA 300 drivers
RAID: RAID 0/1/5/10
Solid State Disk
N/A
Watchdog Timer
Programmable via software from 1 sec. to 255 min.
One PCI-Express x16, One PCI-Express x 4 and
Four PCI slots
Expansion Interface
-One PCI-Express x16 slot
- One PCI-Express x4 slot
-Four 32-bit PCI expansion slots
TPM 1.2 and iAMT 5.0 supported
Hardware Monitoring
System monitor (fan, temperature, voltage)
Power Requirement
TBD
Dimension
Dimension : 308.4(L) x 243.8(W) mm ; 12’’(L) x 9.6’’(W)
Environment
Operating Temperature: 0 to 60°C
Storage Temperature: -20 to 80°C
Relative Humidity: 10% to 90%, non-condensing
MTBF
TBD
Intel® CoreTM 2 Quad / Core™ 2 Duo processor
Intel® Q45 Express and ICH10DO chipset
Two 240-pin DIMM sockets support dual channel
DDR3 SDRAM up to 4GB
Dual display: VGA / DVI-D, 3rd display via PCI or
PCI-Express expansion slot
Four SATA ports and One IDE connector
Support RAID 0, 1, 5, 10 function
I/O
ORDERING GUIDE
Standard
RUBY-9911
Intel® Core™ 2 Quad / Core™ 2 Duo processor ATX
Motherboard
* Specifications are subject to change without notice.
* Core™ 2 Quad and Core™ 2 Duo processor are registered
trademarks of Intel® Corporation.
* Other trademarks, logo, brands and company names are the
property of their respective owners.
MIO
- Four serial ports( RS232 x 3, selectable RS232/422/485 x 1)
- One D-SUB 15-pin and One D-SUB 24-pin at rear I/O panel
- One Parallel, One FDD channel, 8 GPIO
- One IEEE1394a (Optional)
IrDA
N/A
Ethernet
- Dual 10BASE-T/100BASE-TX/1000BASE-T Ethernet
- Dual RJ-45 connector with two LED indicators at rear I/O pannel
Audio
HD Audio interface, 2-channel Audio
USB
Eight USB ports (Four ports at rear I/O panel ; Four ports internal)
Keyboard & Mouse
PS/2 keyboard/mouse at rear I/O panel
DISPLAY
Chipset
Intel® Q45 Integrated Intel® Gen 5.0 GMA 4500 Graphics
Display Memory
Intel® Dynamic Video Memory Technology (Intel® DVMT 5.0)
Resolution
Up to 2048 x1536 @ 75 Hz (QXGA)
DVI
DVI-D interface
IMB-RUBY-9911 36
Intel® CoreTM 2 Duo/CoreTM 2 Quad Processor
based ATX Motherboard with DDR2, VGA,
Dual Gigabit Ethernet, Audio and USB
RUBY-9719VG2AR
Dual GbE & Four USB
Audio
PCI-E x16 slot
VGA
Powered COM (RS232/422/485)
Parallel port
PS/2 Keyboard & Mouse
ISA slot
Six PCI slots
LGA775 socket
Intel® G41
Intel® ICH7R
Header for TPM
Four power COM (RS232)
PS/2 Keyboard & Mouse
Dual GbE
Parallel
Two 240-pin DDR2
DIMM sockets
Eight GPIO
Power COM (RS232)
COM
Compact flash socket
Four SATA
IDE connector
ATX 24P power connector
Four USB
FEATURES
Intel® CoreTM 2 Quad / Core 2 Duo Processor and
Intel® G41 Chipset, FSB up to 1333MHz
Two 240-pin DIMMs support dual channel DDR2
SDRAM up to 4GB
Dual Gigabit Ethernet port
Six 32-bit PCI slots / Five PCI slots and One
ISA slot
Four SATA-300 ports support Intel Matrix Storage
Technology with RAID 0, 1, 5, 10
One 44pin IDE and one Compact flash share the
same channel
PCIE x16 slot can support x1, x4, x8 or x16 cards
Four USB
VGA
Audio
Rear I/O
GENERAL
Processor
CPU & Package: Intel® CoreTM 2 Quad, Intel® CoreTM 2 Duo processors in the
LGA-775 Land Grid Array package targeted for desktop platforms
Chipset/Core Logic
Intel® G41 and ICH7R
System Memory
Max. up to 4GB DDR2 667/800 SDRAM on two 240-pin DIMM sockets with dual
channel mode
BIOS
AMI BIOS
Storage Devices
- Four SATA 300 ports (RAID 0/1/5/10)
- One IDE 44-pin connector
- One Compact Flash connector (share with IDE channel)
Watchdog Timer
Programmable via software from 1 sec. to 255 min.
Expansion Interface
- One PCI-Express x16 slot
- One ISA slot and five 32-bit PCI slots
or
Six 32-bit PCI slots
Hardware Monitoring
System monitor (fan, temperature, voltage)
Dimension
Dimension : 305(L) x 244(W) mm; 12"(L) x 9.6" (W)
Environment
Operating Temperature: 0 to 60oC
Storage Temperature: -20 to 80oC
Relative Humidity: 5% to 95%, non-condensing
MTBF
TBD
I/O
ORDERING GUIDE
Standard
RUBY-9719VG2AR
45nm Intel® Core™ 2 Duo/Core™ 2 Quad Processor
based ATX Motherboard with DDR2, VGA, Dual Gigabit
Ethernet, Audio and USB
RUBY-9719VGAR (One LAN, w/o ISA &RAID)
45nm Intel® Core™ 2 Duo/Core™ 2 Quad Processor
based ATX Motherboard with DDR2, VGA, One Gigabit
Ethernet, Audio and USB, w/o ISA & RAID
MIO
- Six Powered serial ports: One RS232/422/485 (5V/12V) selectable at rear I/O
and Five RS232 (5V/12V) internal
- One Parallel port at rear I/O
- 8 GPIO internal
- LPC pin header for optional TPM module
Display
VGA
Ethernet
- Dual Gigabit Ethernet Controller (Intel® 82583V x2)
- Dual RJ-45 connector with two LED indicator at rear I/O panel
Audio
HD Audio interface (Mic-In, Line-In, Line-Out)
USB
Eight USB ports (Four ports at rear I/O panel; Four ports internal)
Keyboard & Mouse
PS/2 keyboard/mouse at rear I/O panel
DISPLAY
Graphic Controller
37 IMB-RUBY-9719VG2AR
- Intel® G41 integrated Intel® Gen. 5.0 GMA 4500 Graphics
- Intel® Dynamic Video Memory Technology 5.0
- Onboard display: VGA
RUBY-9718VG2AR
Intel® CoreTM 2 Quad processor based ATX
Industrial Mainboard with onboard DVI/VGA
Dual-Display, DDR2 SDRAM, VGA, Dual
Gigabit Ethernet, Audio and USB
Parallel port
GbE x2
Audio
DVI-D
PS/2 Keyboard & Mouse
VGA
USB x4
ADD2 slot
Two PCI Express x1 slots
Four PCI slots
LGA 775 socket
Intel® Q965
PS/2 Keyboard & Mouse
Parallel port
Intel ICH8DO
®
Four 240-pin DDR2
DIMM sockets
ATX 24-pin power connector
USB x4
Six SATA-300 ports
FEATURES
Industrial mainboard in ATX form factor that
supports all Intel® mainstream desktop processors
- CoreTM 2 Quad, CoreTM 2 Duo, Pentium® D,
Pentium® 4, Celeron® D processor in LGA-775
package
Benefits such as Hyper-Threading, EM64T, dualcore, EIST, XD & VT of processor can be easily
applied to system by changing processor
Onboard dual independent display: VGA and
DVI-D
One ADD2 graphics slot for ADD2 card
Two PCI Express x1 slots and four 32-bit PCI
expansion slots
GbE x2
Six SATA-300 ports, Intel® Matrix Storage
Technology with RAID 0, 1, 5, 10 support
VGA
DVI-D
Audio
Rear I/O
GENERAL
Processor
CPU & Package: Intel® CoreTM 2 Quad, CoreTM 2 Duo, Pentium® D, Pentium® 4,
Celeron® D processor in the LGA-775 package
FSB: 1066/800/533MHz
Chipset/Core Logic
Intel® Q965 and ICH8DO
System Memory
Up to 8GB DDR2 800/667/533 SDRAM on four 240-pin DIMM sockets
BIOS
Award BIOS
Storage Devices
Six SATA 300 ports with RAID 0/1/5/10 support by Intel® Matrix Storage
Technology
Solid State Disk
N/A
Watchdog Timer
Programmable via software from 1 sec. to 255 min.
Expansion Interface
- One ADD2 slot (single SDVO bus)
- Two PCI Express x1 slots
- Four 32-bit PCI expansion slots
Hardware Monitoring
System monitor (fan, temperature, voltage)
Power Requirement
+12V(CPU)@8.75A; 12V(System)@3.6A; 5Vsb(System)@0.13A;
5V(System)@5.6A; 3.3V(System)@2.81A
Dimension
Dimension : 304.8(L) x 243.8(W) mm; 12"(L) x 9.6" (W)
Environment
Operating Temperature: 0 to 55oC
Storage Temperature: -20 to 80oC
Relative Humidity: 5% to 90%, non-condensing
MTBF
TBD
I/O
MIO
Four serial ports(RS232/Powered selectable x2, selectable RS232/422/485 x1,
RS232 x1), one FDD, 12 GPIO
IrDA
N/A
Ethernet
- Dual 10BASE-T/100BASE-TX/1000BASE-T Ethernet (Intel® 82573L, Intel®
82566DM)
- PCI Express x1 interface based Gigabit Ethernet
- Dual RJ-45 connector with two LED indicators at rear I/O panel
Audio
HD Audio interface, 2-channel Audio
USB
Ten USB ports (Four ports at rear I/O panel; six ports internal)
Keyboard & Mouse
PS/2 keyboard/mouse at rear I/O panel
ORDERING GUIDE
Standard
RUBY-9718VG2AR
Intel® CoreTM 2 Quad processor based ATX Industrial
Mainboard with onboard DVI/VGA Dual-Display, DDR2
SDRAM, Dual Gigabit Ethernet, Audio and USB
DISPLAY
Graphic Controller
- GMCH integrated Intel® Graphics Media Accelerator 3000 (Intel® GMA 3000)
- ADD2 graphics slot (single SDVO bus) for ADD2 card
- Onboard dual independent display VGA and DVI-D
IMB-RUBY-9718VG2AR 38
Intel® CoreTM 2 Quad processor based
Micro-ATX Industrial Mainboard with
onboard DVI/VGA Dual-display, DDR2
SDRAM, Gigabit Ethernet, Audio and USB
RUBY-9717VGAR
Parallel port
PS/2 Keyboard & Mouse
VGA
GbE & USB x2
Audio
DVI-D
Powered RS-232 x2
ADD2 slot
One PCI Express x4 slot
Two PCI slots
RS-232/422/485
LGA 775 socket
RS-232
Intel® Q965
PS/2 Keyboard & Mouse
GbE
Parallel port
Intel® ICH8DO
Four 240-pin DDR2
DIMM sockets
FDD port
VGA
Powered RS232 x2
Eight USB ports GPIO ports
ATX 24-pin power connector
DVI-D
Audio
USB x2
Rear I/O
Six SATA-300 ports
FEATURES
Industrial mainboard in uATX form factor
that supports all Intel® mainstream desktop
processors - CoreTM 2 Quad, CoreTM 2 Duo,
Pentium® D, Pentium® 4, Celeron® D processor
in LGA-775 package
Onboard dual independent display: VGA and
DVI-D
GENERAL
Processor
CPU & Package: Intel® CoreTM 2 Quad, CoreTM 2 Duo, Pentium® D, Pentium® 4,
Celeron® D processor in LGA-775 package
FSB: 1066/800/533MHz
Chipset/Core Logic
Intel® Q965 & ICH8DO
System Memory
Up to 8GB DDR2 800/667/533 SDRAM on four 240-pin DIMM sockets
BIOS
Award BIOS
Storage Devices
Six SATA 300 ports with RAID 0/1/5/10 support by Intel® Matrix Storage
Technology
One ADD2 graphics slot for ADD2 card
Solid State Disk
N/A
One PCI Express x4 slot and two 32-bit PCI
expansion slots
Watchdog Timer
Programmable via software from 1 sec. to 255 min.
Expansion Interface
- One ADD2 slot (single SDVO bus)
- One PCI Express x4 slot
- Two 32-bit PCI expansion slots
Hardware Monitoring
System monitor (fan, temperature, voltage)
Power Requirement
+12V(CPU)@3.31A ; +12V(System)@5.82A ; +5V(System)@5.95A
Dimension
Dimension : 243.8(L) x 243.8(W) mm; 9.6"(L) x 9.6" (W)
Environment
Operating Temperature: 0 to 55oC
Storage Temperature: -20 to 80oC
Relative Humidity: 5% to 90%, non-condensing
MTBF
TBD
Six 32-bit PCI expansion slots for most
industrial I/O cards
Six SATA-300 ports support Intel® Matrix
Storage Technology with RAID 0, 1, 5, 10
I/O
ORDERING GUIDE
Standard
RUBY-9717VGAR
LGA-775 CoreTM 2 Quad processor based Micro-ATX
Industrial Mainboard with onboard DVI/VGA dual-display,
DDR2 SDRAM, Gigabit Ethernet, Audio and USB
MIO
Four serial ports(RS232/Powered selectable x2 on rear panel, Selectable
RS232/422/485 x1, RS-232 x1), one FDD, 12 GPIO
IrDA
N/A
Ethernet
- Single 10BASE-T/100BASE-TX/1000BASE-T Ethernet (Intel® 82566DM)
- PCI Express x1 interface based Gigabit Ethernet
- Single RJ-45 connector with two LED indicators at rear I/O panel
Audio
HD Audio interface, 2-channel Audio
USB
Ten USB ports (Two ports at rear I/O panel; eight ports internal)
Keyboard & Mouse
PS/2 keyboard/mouse at rear I/O panel
DISPLAY
Graphic Controller
39 IMB-RUBY-9717VGAR
- GMCH integrated Intel® Graphics Media Accelarator 3000 (Intel® GMA 950)
- ADD2 graphics slot (single SDVO bus) for ADD2 card
- Onboard dual independent display VGA and DVI-D
RUBY-9716VG2AR
Intel® CoreTM 2 Quad processor based ATX
Industrial Mainboard with DDR2 SDRAM,
VGA, Dual Gigabit Ethernet, Audio and USB
VGA Port
GbE port & Dual USB port
COM1 port (RS232/422/485 selectable)
Audio
Parallel port
PS/2 Keyboard & Mouse
GbE port & Dual USB port
PCI Express x16 expansion slot
PCI Express x4 expansion slot
LGA 775 socket
Intel® Q965
RS232 selectable COM port
Four PCI expansion slots
PS/2 Keyboard & Mouse
Intel® ICH8DO
Parallel port
Dual RS232/Powered selectable COM port
Five SATA 300 ports
Ten programmable GPIO ports
CompactFlash socket
Front panel I/O
Four 240-pin
DDR2 DIMM
sockets
COM1 port
ATX V2.2 24-pin power connector
Four USB ports
FEATURES
Industrial mainboard in ATX form factor supports
all Intel® mainstream desktop processors - CoreTM
2 Quad, CoreTM 2 Duo, Pentium® D, Pentium® 4,
Celeron® D processor in LGA-775 package
Benefits such as Hyper-Threading, EM64T, dualcore, EIST, XD & VT of processor can be easily
applied to system by changing processor
Embedded Intel 4th generation graphics engine
provides better user experience of display
performance
One PCI Express x16 slot features high-end
graphics card connection interface or dual
independent display with ADD2+ media card that
provides TV tuner, video capture in and DVI, TVout
One PCI Express x4 slot for storage add-in card
which provides reliable and safer data storage with
adequate I/O throughput
Five SATA 300 ports together with one IDE
channel and CF socket are perfect combination
to storage interface for all kinds of applications;
supports Intel® Matrix Storage Technology
IDE connector
RUBY-9716VG2AR
LGA-775 CoreTM 2 Quad processor based ATX Industrial
Mainboard with DDR2 SDRAM, VGA, Dual Gigabit
Ethernet, Audio and USB
USB x4
VGA port
FDD port
Audio
Rear I/O
GENERAL
Processor
CPU & Package: Intel® CoreTM 2 Quad, CoreTM 2 Duo, Pentium® D, Pentium® 4,
Celeron® D processor in LGA-775 package
FSB: 1066/800/533MHz
Chipset/Core Logic
Intel® Q965 and ICH8DO
System Memory
Up to 8GB DDR2 800/667/533 SDRAM on four 240-pin DIMM sockets
BIOS
Award BIOS
Storage Devices
EIDE: Support single EIDE device with Ultra DMA 100/66/33
SATA: Support five SATA 300 drives
Solid State Disk
One Type II CF socket (only available if no IDE device attached)
Watchdog Timer
Programmable via software from 1 sec. to 255 min.
Expansion Interface
- Four 32-bit PCI expansion slots
- One PCI Express x4 slot for x1 or x4 card
- One PCI Express x16 slot for PCIe x16 or PCIe x1 or ADD2/+ card
Hardware Monitoring
System monitor (fan, temperature, voltage)
Power Requirement
Typical: [email protected]; [email protected]; [email protected]
Dimension
Dimension : 304.8(L) x 243.8(W) mm; 12"(L) x 9.6" (W)
Environment
Operating Temperature: 0 to 55oC
Storage Temperature: -20 to 80oC
Relative Humidity: 5% to 90%, non-condensing
MTBF
73,803 hrs
I/O
MIO
Four serial (RS232/TTL selectable x1, RS232/Powered selectable x2,
RS232/422/485 selectable x1), one at rear I/O panel, one parallel, one FDD
channel
IrDA
IrDA 1.0
Ethernet
- Dual 10BASE-T/100BASE-TX/1000BASE-T Ethernet (Intel® 82573L, Intel®
82566DM)
- PCI Express x1 interface based Gigabit Ethernet
- Dual RJ-45 connector with two LED indicators at rear I/O panel
Audio
HDA interface, 2-channel Audio
USB
Eight USB 2.0 ports (Four ports at rear I/O panel; four ports internal)
Keyboard & Mouse
PS/2 keyboard/mouse at rear I/O panel
ORDERING GUIDE
Standard
GbE x2
DISPLAY
Graphic Controller
- GMCH integrated Intel® 4th generation Extreme Graphics controller
- Intel® GMA 3000 which provides improved 3D multimedia capabilities
including DirectX9, Shader Model 3.0, OpenGL 1.5, Advanced De-interlacing,
MPEG-2 hardware acceleration
- Support dual independent display with ADD2/+ card
IMB-RUBY-9716VG2AR 40
RUBY-9716VGAR
Intel® Core™ 2 Quad processor based ATX
Industrial Mainboard with DDR2 SDRAM, VGA,
Gigabit Ethernet, Audio and USB
VGA Port
Dual USB port
COM1 port (RS232/422/485 selectable)
Audio
Parallel port
PS/2 Keyboard & Mouse
GbE port & Dual USB port
PCI Express x16 expansion slot
PCI Express x1 expansion slot
PCI Express x4 expansion slot
LGA 775 socket
Intel® Q965
RS232 selectable COM port
Four PCI expansion slots
Parallel port
Dual RS232/Powered selectable COM port
Five SATA 300 ports
Ten programmable GPIO ports
CompactFlash socket
Front panel I/O
COM1 port
Four USB ports
FEATURES
Industrial mainboard in ATX form factor supports
all Intel® mainstream desktop processors - CoreTM
2 Quad, CoreTM 2 Duo, Pentium® D, Pentium® 4,
Celeron® D processor in LGA-775 package
Benefits such as Hyper-Threading, EM64T, dualcore, EIST, XD & VT of processor can be easily
applied to system by changing processor
Embedded Intel 4th generation graphics engine
provides better user experience of display
performance
One PCI Express x16 slot features high-end
graphics card connection interface or dual
independent display with ADD2+ media card that
provides TV tuner, video capture in and DVI, TVout
One PCI Express x4 slot for storage add-in card
which provides reliable and safer data storage with
adequate I/O throughput
One PCI Express x1 and four 32-bit PCI expansion
slots for most industrial I/O cards
Five SATA 300 ports together with one IDE
channel and CF socket are perfect combination
to storage interface for all kinds of applications;
supports Intel® Matrix Storage Technology
IDE connector
RUBY-9716VGAR
LGA-775 CoreTM 2 Quad processor based ATX Industrial
Mainboard with DDR2 SDRAM, VGA, Gigabit Ethernet,
Audio and USB
USB x2
VGA port
FDD port
Audio
Rear I/O
GENERAL
Processor
CPU & Package: Intel® CoreTM 2 Quad, CoreTM 2 Duo, Pentium® D, Pentium® 4,
Celeron® D processor in LGA-775 package
FSB: 1066/800/533MHz
Chipset/Core Logic
Intel® Q965 and ICH8DO
System Memory
Up to 8GB DDR2 800/667/533 SDRAM on four 240-pin DIMM sockets
BIOS
Award BIOS
Storage Devices
EIDE: Support single EIDE device with Ultra DMA 100/66/33
SATA: Support five SATA 300 drives
Solid State Disk
One Type II CF socket (only available if no IDE device attached)
Watchdog Timer
Programmable via software from 1 sec. to 255 min.
Expansion Interface
- Four 32-bit PCI expansion slots
- One PCI Express x4 slot for x1 or x4 card
- One PCI Express x1 slot
- One PCI Express x16 slot for PCIe x16 or PCIe x1 or ADD2/+ card
Hardware Monitoring
System monitor (fan, temperature, voltage)
Power Requirement
Typical: [email protected]; [email protected]; [email protected]
Dimension
Dimension : 304.8(L) x 243.8(W) mm; 12"(L) x 9.6" (W)
Environment
Operating Temperature: 0 to 55oC
Storage Temperature: -20 to 80oC
Relative Humidity: 5% to 90%, non-condensing
MTBF
73,803 hrs
I/O
MIO
Four serial (RS232/TTL selectable x1, RS232/Powered selectable x2, RS232/
422/485 selectable x1), one at rear I/O panel, one parallel, one FDD channel
IrDA
IrDA 1.0
Ethernet
- Single 10BASE-T/100BASE-TX/1000BASE-T Ethernet (Intel® 82566DM)
- PCI Express x1 interface based Gigabit Ethernet
- Single RJ-45 connector with two LED indicators at rear I/O panel
Audio
HDA interface, 2-channel Audio
USB
Eight USB 2.0 ports (Four ports at rear I/O panel; four ports internal)
Keyboard & Mouse
PS/2 keyboard/mouse at rear I/O panel
ORDERING GUIDE
Standard
GbE
Four 240-pin
DDR2 DIMM
sockets
ATX V2.2 24-pin power connector
Dual USB port
PS/2 Keyboard & Mouse
Intel® ICH8DO
DISPLAY
Graphic Controller
41 IMB-RUBY-9716VGAR
- GMCH integrated Intel® 4th generation Extreme Graphics controller
- Intel® GMA 3000 which provides improved 3D multimedia capabilities
including DirectX9, Shader Model 3.0, OpenGL 1.5, Advanced De-interlacing,
MPEG-2 hardware acceleration
- Support dual independent display with ADD2/+ card
RUBY-9715VG2AR
Intel® CoreTM 2 Duo processor based ATX
Industrial Mainboard with DDR2 SDRAM,
VGA, Dual Gigabit Ethernet, Audio and USB
Dual GbE port & four USB ports
PCI-E x16 expansion slot
Audio
Parallel port
VGA port COM1 port (RS-232/422/485 selectable)
PS/2 Keyboard & Mouse
COM2 port
Six PCI slots expansion
LGA 775 socket
Front panel header
Intel® 945G
PS/2 Keyboard & Mouse
Dual GbE port
Parallel port
Four USB ports
Four 240-pin
DDR2 DIMM
sockets
Four SATA 300 ports
8-port GPIO
Intel® ICH7R
FDD port
EPS12V 24-pin power connector
FEATURES
Industrial mainboard in ATX form factor
supports Intel® Pentium® 4 processor with
Hyper-Threading technology, CoreTM 2 Duo,
Pentium® D and Celeron® D processor in
LGA-775 package up to 1066MHz front side
bus
Support DDR2 667/533 SDRAM up to 4GB in
dual channel architecture
Intel® new GMCH integrated graphics engine
increases 9% ~ 25% performance of GMA
900 of Intel 915GV
One PCI Express x16 slot features high-end
graphics card connection interface or dual
independent displays with ADD2+ media card
that provides TV tuner, video capture in and
DVI, TV-out
Six 32-bit PCI expansion slots for most
industrial I/O cards
Dual Gigabit Ethernet ports based on PCI
Express x1 interface without sharing bandwidth
of PCI expansion bus
Four ports for SATA RAID controller providing
benefits of Intel Matrix Storage Technology
RAID 0, 1, 5, 10
ORDERING GUIDE
Standard
RUBY-9715VG2AR
Intel® CoreTM 2 Duo processor based ATX Industrial
Mainboard with DDR2 SDRAM, VGA, Dual Gigabit
Ethernet, Audio and USB
COM1 port
IDE connector
Four USB ports
VGA port
Audio
Rear I/O
GENERAL
Processor
CPU & Package: Intel® CoreTM 2 Duo, Pentium® D, Pentium® 4, Celeron® D
processor in LGA-775 package
FSB: 1066/800/533MHz
Chipset/Core Logic
Intel® 945G & ICH7R
System Memory
Up to 4GB DDR2 667/533 SDRAM on four 240-pin DIMM sockets
BIOS
Award BIOS
Storage Devices
EIDE: Support two EIDE devices with Ultra DMA 100/66/33
SATA: Support four SATA 300 drives
Solid State Disk
N/A
Watchdog Timer
Programmable via software from 1 sec. to 255 min.
Expansion Interface
- Six 32-bit PCI expansion slots
- One PCI Express x16 slot for graphics card, ADD2/+ card or PCI Express x1
(general purpose) card
- Up to four PCI Express x1 external interface per (project spec.)
Hardware Monitoring
System monitor (fan, temperature, voltage)
Power Requirement
Typical: [email protected] ; [email protected]
Dimension
Dimension : 312.8(L) x 243.8(W) mm; 12.3"(L) x 9.6" (W)
Environment
Operating Temperature: 0 to 55oC
Storage Temperature: -20 to 80oC
Relative Humidity: 5% to 90%, non-condensing
MTBF
105,889 hrs
I/O
MIO
Two serial (RS232 x1, selectable RS232/422/485 x1) ports, one at rear I/O
panel, one parallel, one FDD channel
IrDA
IrDA 1.0
Ethernet
- Dual 10BASE-T/100BASE-TX/1000BASE-T Ethernet (Intel® 82573L x2)
- PCI Express x1 interface based Gigabit Ethernet
- Dual RJ-45 connectors with two LED indicators at rear I/O panel
Audio
AC'97 2.2 Audio
USB
Eight USB 2.0 ports (Four ports at rear I/O panel; four ports internal)
Keyboard & Mouse
Dual 6-pin mini-DIN connectors at rear I/O panel for PS/2 keyboard/mouse
DISPLAY
Graphic Controller
GMCH integrated Intel® Graphics Media Accelarator 950 (Intel® GMA 950)
Graphic Memory
Dynamic system memory sharing up to 224MB (Intel® DVMT 3.0) or static
system memory sharing up to 128MB
Display Interface
Display resolution up to 2048 x 1536
IMB-RUBY-9715VG2AR 42
RUBY-9713VG2AR
Dual GbE & four USB ports
Intel® CoreTM 2 Duo processor based
Micro-ATX Industrial Mainboard with
DDR2 SO-DIMM, VGA, Dual Gigabit
Ethernet, Audio and USB
Dual COM port
PS/2 K/B & Mouse
Audio
VGA port
Two 200-pin DDR2 SO-DIMM sockets
PCI slot
PCI-Ex4 slot
PCI-Ex16 slot
FCPGA 478
Intel® 945GME
PS/2 K/B & Mouse
LVDS connector
Intel® ICH7R
Dual GbE port
VGA port
Parallel port
IDE connector
FDD port
Dual COM port
8-port GPIO
Four USB ports
Four SATA 300 ports
FEATURES
Four USB ports
Audio
Rear I/O
GENERAL
Processor
CPU & Package: Intel® CoreTM 2 Duo, CoreTM Duo, CoreTM Solo processor
FSB: 667/533MHz
Chipset/Core Logic
Intel® 945GME and ICH7R
System Memory
Up to 4GB DDR2 667/533 SDRAM on two 200pin SODIMM sockets
BIOS
Award BIOS
Storage Devices
One PCI-Express x4 slot or supports up to four
PCI Express x1 slot by riser card
EIDE: Support two EIDE devices with Ultra DMA 100/66/33
SATA: Support four SATA 300 drives
RAID: RAID 0/1/5/10
Solid State Disk
N/A
Support GPIO and LVDS on board
Watchdog Timer
Programmable via software from 1 sec. to 255 min.
Adopts Intel Matrix Storage Technology to support
RAID 0/1/5/10
Expansion Interface
- One 32-bit PCI expansion slot or support up to four PCI slots by riser card
- One PCI-Express x4 slot or support up to four PCI Express x1 slot by riser
card
- One PCI-Express x16 slot
Dual Gigabit Ethernet ports based on PCI Express
x1 interface without sharing bandwidth of PCI
expansion bus
Hardware Monitoring
System monitor (fan, temperature, voltage)
Power Requirement
Standby [email protected]; +12V(CPU)@3A, +12V(System)@1A,
+5V(System)@2.5A, +3.3V(System)@1.5A
Dimension
Dimension : 243.8(L) x 243.8(W) mm; 9.6"(L) x 9.6" (W)
Environment
Operating Temperature: 0 to 55oC
Storage Temperature: -20 to 80oC
Relative Humidity: 5% to 90%, non-condensing
MTBF
86,705 hrs
Industrial mainboard in uATX form factor supports
all Intel® CoreTM 2 Duo, CoreTM Duo, CoreTM Solo
processor for MoDT (Mobile on Desktop)
application
One 32-bit PCI expansion slot or supports up to
four PCI slots by riser card
ORDERING GUIDE
Standard
Optional
RUBY-9713VG2AR
Intel® CoreTM 2 Duo processor based Micro-ATX,
Industrial Mainboard with DDR2 SODIMM, VGA, Dual
Gigabit Ethernet, Audio and USB
PEP-541L
PCI-E x4 to PCI-E x4 riser card
PEP-544L
PCI-E x4 to four PCI-E x1 riser card
PEP-554L
PCI to four PCI slots riser card
PEP-553L
PCI to three PCI slots riser card
B9970540
Pentium® M 1U Active Heat Sink
I/O
MIO
Two serial (RS232 x1, selectable RS232/422/485 x1)
One parallel, one FDD channel, eight GPIO
IrDA
IrDA 1.0
Ethernet
- Dual 10BASE-T/100BASE-TX/1000BASE-T Ethernet (Intel® 82573L x2)
- PCI Express x1 interface based Gigabit Ethernet
- Dual RJ-45 connectors with two LED indicators at rear I/O panel
Audio
AC'97 2.2 Audio
USB
Eight USB 2.0 ports (Four ports at rear I/O panel; four ports internal)
Keyboard & Mouse
Dual 6-pin mini-DIN connector at rear I/O panel for PS/2 keyboard/mouse
DISPLAY
43 IMB-RUBY-9713VG2AR
Graphic Controller
GMCH integrated Intel® Graphics Media Accelerator 950 (Intel® GMA 950)
Graphic Memory
Dynamic share system memory up to 224MB (Intel DVMT 3.0) or static share
system memory up to 128MB
Display Interface
Display resolution up to 2048x1536; LVDS
RUBY-7720VG2A
Audio
Dual GbE & four USB ports
VGA port
Intel® Pentium® M or Celeron®
M processor based Micro-ATX
Motherboard with DDR2 SDRAM, VGA,
Dual Gigabit Ethernet, Audio and USB
Dual RS232 RI/5V/12V selectable
PS/2 Keyboard & Mouse
PCI Express x1 slot
Two PCI slots
LVDS
Intel® 915GME
PCI Express x16 slot
PS/2 K/B & Mouse
Four USB ports
Two 240-pin
DDR2 DIMM sockets
Eight GPIO ports
mPGA479M socket
One RS232 RI/5V/12V selectable
CF socket
RS232/422/485 RI/5V/12V selectable
FDD port
IDE port
Intel® ICH6M
USB
COM
Parallel port
Two SATA ports
FEATURES
Gigabit Ethernet
Industrial mainboard in Micro-ATX form factor
with 915GME chipset that supports Intel®
Pentium® M and Celeron® M processor up to
2.0GHz
ATX 20-pin power
connector
Audio
VGA port
Rear I/O
GENERAL
Processor
CPU & Package: Intel® mPGA479M socket support uFC-PGA Pentium® M or
Celeron® M up to 2.0GHz
FSB: 533/400MHz
Chipset/Core Logic
Intel® 915GME and ICH6M
System Memory
Up to 2GB DDR2-400/533 memory on two 240-pin DIMM sockets with dual
channel mode
BIOS
Award BIOS
Storage Devices
- Two SATA ports
- One IDE port
Maximum 2GB DDR2-533 system memory
Onboard dual display: VGA and LVDS, 3rd
display via PCI-E x16 Graphic card
One PCI-Express x16 slot for high-end graphics
card or ADD2 card
Solid State Disk
One Type I/II Compact Flash socket
Watchdog Timer
Programmable via software from 1 sec. to 255 min.
Dual Gigabit Ethernet ports based on PCIExpress x1 interface
Expansion Interface
Two 32-bit PCI expansion slots with riser card
supported
- Two 32-bit PCI expansion slots (supports one riser card)
- One PCI-Express x1 slot
- One PCI-Express x16 slot
Hardware Monitoring
System monitor (fan, temperature, voltage)
Fanless cooler for Intel® ULV processor
Power Requirement
TBD
Dimension
Dimension : 243.8(L) x 243.8(W) mm; 9.6"(L) x 9.6" (W)
Environment
Operating Temperature: 0 to 55oC
Storage Temperature: -20 to 80oC
Relative Humidity: 5% to 90%, non-condensing
MTBF
TBD
I/O
ORDERING GUIDE
Standard
RUBY-7720VG2A
Intel® Pentium M or Celeron M processor based MicroATX Motherboard with DDR2 SDRAM, VGA, Dual
Gigabit Ethernet, Audio and USB
MIO
Four serial ports (two RS232 (RI/5V/12V) selectable at Rear IO,
one RS232 & one RS232/422/485 (RI/5V/12V) selectable internally
IrDA
One IrDA
Ethernet
- Dual 10BASE-T/100BASE-TX/1000BASE-T Ethernet (Realtek 8111B-GR x2)
- PCI Express x1 interface based Gigabit Ethernet
- Two RJ-45 connector with two LED indicators at rear I/O panel
Audio
HD Audio interface, 2-channel Audio
USB
Eight USB 2.0 ports (Four ports at rear I/O panel; four ports internal)
Keyboard & Mouse
PS/2 keyboard/mouse at rear I/O panel
DISPLAY
Graphic Controller
- Intel® 915GME integrated GMA 900
- One VGA (rear panel) and one LVDS (onboard)
- Dual independent display by VGA and LVDS, 3rd display via PCIE x16
Graphic Card
IMB-RUBY-7720VG2A 44
About Chassis
FLEXIBLE AND UNIQUE
At Portwell, we take care of our customers’ needs. Portwell is pledged to remain customer centric -- even amid the relative
challenges of the rack-mount chassis market,. Unlike most chassis suppliers, whose focus is cost-down, our priority is
quality, and this is reflected in the concepts of our newly developed chassis designs.
1. NEW INDUSTRIAL DESIGN (ID)
Our new industrial design is definitely an eye-catcher, and the chassis has pleasing lines that make it easy to work with. We
have invested heavily in our industrial design. Consequently, our rack-mount chassis is not just attractive, but is also built
practically, so that it enhances the product outlook and strengthens the unity of our customers’ systems.
2. ADVANCED FUNCTIONALITY INSIDE
Since they first evolved from the PC, the growing new technologies have changed the applications of the rack-mount
chassis tremendously. New devices, such as USB and IEEE1394, have been completely adopted in the market. The
advanced functionality inside of a Portwell chassis is consistently updated in order to meet changing trends, and assures
Portwell of our continuing place as a market leader.
3. MODULIZED DESIGN TO ENABLE SYSTEM DIFFERENTIATION AND SUITABILITY FOR
FUTURE DEMANDS
The modularized, state-of-the-art design of our chassis enables Portwell to meet system differentiation and the suitability
for future demands. At Portwell, we understand that our rack-mount chassis are not for use by application controllers alone.
They could also be fault-tolerant systems. Therefore, some hot-swappable devices, such as Mirror or RAID disks, might be
integrated into the system. Portwell keeps an eye on future demands to build the capability inside the chassis to work with
your system now and in the future.
Contact your local Portwell office for more information on the state-of-the-art design of all
new Portwell chassis
-The First Priority for Customers
Advanced
Ruggedized
Enhanced
Modulized
Optimized
PORTWELL engineers custom-make products for customers quickly and efficiently.
Our Expertise:
Experienced and well-trained design team.
Integration of Industrial Design(ID), flexibility, and functionality.
Fast sample offering for customer classification and approval.
Collaborative design with customers.
Fast response to customers’ urgent demands:
Concept Design (3D): 2 working days
Mechanical Design: 5 working days
Samples Building: 14 working days
An outstanding chassis for all your needs.
45 About Chassis
Chassis Reference Table
AREMO-4196
TYPE
SLOT
AREMO-2173P
MODEL
ORDERING
INFO
4U
14-slot
RPC-500NC
RPC-500NC-14P4-3501P
4U
ATX M/B
RPC-500NC-MX
RPC-500NC-MX-D3501P
4U
14-slot
AREMO-4196
AREMO-4196-14P4-D3501P
BACKPLANE
Model Name
PBP-14P4
--
PBP-14P4
AREMO-4196-14P4-D3202P
2U
ATX M/B
AREMO-4196-MX
AREMO-4196-MX-D3501P
6-slot
AREMO-2173P
AREMO-2173P-06V4-D3501P
--
uATX M/B
AREMO-2173MX
ISA
PCI/PCI-X
PICMG
9
4
1
--
7
--
9
4
1
9
4
1
--
7
--
1
4
1
--
4
--
--
--
--
--
PBP-06V4
AREMO-2173P-06V4-D3502P
2U
PRC-4207
AREMO-3194
AREMO-2173MX-D3501P
AREMO-2173MX-3502P
3U
ATX M/B
AREMO-3194
AREMO-3194-MX-350X
--
--
7
--
4U
ATX M/B
PRC-4207
PRC-4207-MX
--
--
--
--
FS
6-slot
AREMO-6163
AREMO-6163-06P4-D3501P
PBP-06P4
1
4
1
FS
8-slot
AREMO-8164
AREMO-8164-08P4-D3501P
PBP-08P4
3
4
1
FS
12-slot
AREMO-4184
AREMO-4184-06P3-350X
PBP-06P3
4
6
2
AREMO-6182-06P3-350X
PBP-06P3
2
3
1
FS
6-slot
AREMO-6182
AREMO-6182-06P4-350X
PBP-06P4
1
4
1
--
1
--
--
2
1
1U
uATX
PRS-1174
PRS-1174-MX-270X
1U
3-slot
RPC-1194
RPC-1194
--
PBP-03P2X
Chassis Reference Table 46
Chassis Reference Table
AREMO-6163
TYPE
AREMO-8164
SLOT
AREMO-4184
PSU
MODEL
Model Name
4U
14-slot
RPC-500NC
AREMO-6182
ORION-D3501P
Power Range
ATX M/B
RPC-500NC-MX
14-slot
AREMO-4196
4U
ATX M/B
2U
AREMO-4196-MX
6-slot
420W ATX, PFC, P4
uATX M/B
Page
482(W) x 450(D) x 177(H) mm
19”(W) x 18”(D) x 7”(H)
48-49
ORION-D3502P
ORION-D3501P
350W ATX, PFC, P4
ORION-D3202P
320W ATX, PFC, redundant
ORION-D4201P
420W ATX, PFC, P4
ORION-D3501P
350W ATX, PFC, P4
ORION-D3502P
350W ATX, redundant
ORION-D3501P
350W ATX, PFC, P4
ORION-D3502P
350W ATX, PFC, redundant
AREMO-2173P
2U
Dimension
(W)x (D)x(H)
350W ATX, PFC, P4
ORION-D4201P
4U
PRS-1174
AREMO-2173MX
482(W) x 481(D) x 177(H) mm
19”(W) x 19”(D) x 7”(H)
50-52
482(W) x 441.6(D) x 88.4(H) mm
19”(W) x 17.4”(D) x 3.5”(H)
53-54
482(W) x 441.6(D) x 88.4(H) mm
19”(W) x 17.4”(D) x 3.5”(H)
55-56
3U
ATX M/B
AREMO-3194
ORION-B3501P
350W ATX, PFC, P4
482(W) x 456(D) x 132(H) mm
19”(W) x 18.0”(D) x 5.25”(H)
57-58
4U
ATX M/B
PRC-4207
ORION-D4601P
460W ATX, PFC, P4
482(W) x 519(D) x 177(H) mm
19”(W) x 20.4”(D) x 7”(H)
59-60
FS
6-slot
AREMO-6163
ORION-D3501P
350W ATX, PFC, P4
260(W) x 420.8(D) x 172(H) mm
10.24”(W) x 16.56”(D) x 6.77”(H)
61-62
FS
8-slot
AREMO-8164
ORION-D3501P
350W PFC, ATX, P4
330(W) x 420.8(D) x 17(H) mm
12.99”(W) x 16.56”(D) x 6.77”(H)
63-64
FS
12-slot
AREMO-4184
FSP350-601UA
350W PFC, ATX, P4
482(W) x 448(D) x 177(H) mm
19”(W) x 17.6”(D) x 7”(H)
65-66
FS
6-slot
AREMO-6182
FSP350-601UA
350W PFC, ATX, P4
219(W) x 448(D) x 160(H) mm
8.6”(W) x 17.6”(D) x 6.3”(H)
67-68
1U
uATX
PRS-1174
PRS-1174-MX-270X
270W ATX PFC, P4
482(W) x 510(D) x 44(H) mm
19”(W) x 20”(D) x 1.75”(H)
70
1U
3-slot
PRC-1194
PRC-1194-03P2X-A2501
250W ATX PFC, P4
482(W) x 474(D) x 44(H) mm
19”(W) x 18.7”(D) x 1.75”(H)
71
47 Chassis Reference Table
RPC-500NC/L
FEATURES
19” 4U industrial rack-mount chassis
GENERAL
Construction
Heavy-duty steel with aluminum front panel
Drive Bay
External: 5.25” x3, 3.5” FDD x1
Internal: 3.5” HDD x1
5.25” x3 + 3.5” x2 drive bays for RAID 0, 1, 5 &
CD-ROM
Two ball-bearing cooling fans for better
ventilation
Card Retainer
Two locations for one card retainer
Air Filter
One replaceable filter
Traditional rack-mount handles
Cooling Fan
One 12cm and one 8cm ball-bearing cooling fans
Two card retainer positions
Indicator
Power on/off x1, HDD x1
Two USB ports on the control panel
Switch
Power on/off x1, System reset x1, K/B lock x1
One PS/2 K/B connector cap included
Connector
One 5-pin K/B connector on the front panel with a cap
Standard Color
Beige, Black
Dimension
RPC-500N: 482(W) x 450(D) x 177(H) mm; 19”(W) x 17.7”(D) x 7”(H)
RPC-500L: 482(W) x 515(D) x 177(H) mm; 19”(W) x 20.3”(D) x 7”(H)
M/B applicable, especially for big-AT sized
M/B (RPC-500L)
Weight
RPC-500N: Net: 14 kg (30.9 lb); Gross: 15 kg (33.1 lb)
RPC-500L: Net: 17.5 kg (38.6 lb); Gross: 18.5 kg (40.8 lb)
PS/2 reduncant power supply installable
Backplane
PBP-14I: 14-slot ISA backplane
PBP-14AC: 14-slot (12xPCI) active PICMG backplane
PBP-14A7: 14-slot (7xPCI) active PICMG backplane
PBP-14P4: 14-slot (4xPCI) PICMG backplane
PBP-13D4: 13-slot dual-system PICMG backplane
One modularized function panel for single
(default) and dual (optional) systems
ATX
ORION-D3501P optional
POWER SUPPLY
RPC-500NC/L
Except the rack-mount handle, RPC-500N is
the same as RPC-500NC. It’s the best selling
4U rack-mount chassis for CTI, industrial, scientific, engineering and server applications.
ORDERING GUIDE
RPC-500NC
19” 4U rack-mount chassis for PICMG backplane
RPC-500L
Output Voltage & Current
[email protected]; [email protected]; [email protected]; [email protected], [email protected], [email protected]
Input Voltage
90V ~ 264V AC, full range
Input Frequency
47 ~ 63Hz
Input Current
[email protected], [email protected]
Efficiency
> 68%
MTBF
75,145 hrs
EMI & Safety Approval
UL, cUL, TUV, CE, FCC
Temperature/Humidity
Operating: 0 ~ 50oC, 20 ~ 85%RH
Storage: -40 ~ 70oC, 10 ~ 90%RH
Dimension (WxDxH)
150 x 140 x 86 mm; 5.9” x 5.5” x 3.4”
ENVIRONMENT
Operating Temperature Range
0 to +55°C
Storage Temperature Range
0 to +70°C
RPC-500L-MX
Relative Humidity
5% to 95%, non-condensing
19” 4U rack-mount chassis for server board
Vibration
5~7 Hz: 0.5” double amplitude displacement
7~2000 Hz: 1.5g acceleration
19” 4U rack-mount chassis for PICMG backplane
(Long size)
350W active PFC
RPC-500NC-MX
19” 4U rack-mount chassis for ATX M/B
Maximum output
Chassis-RPC-500NC/L 48
RPC-500NC/L
19” 4U industrial rack-mount chassis
FEATURE
BENEFITS
A lockable front door with thumb lock
Good for dust-proof & Running status visible
One power on/off switch with LED indicator, one reset and one K/B
lock switches inside the lockable door
Avoid accidental reset for better running security
Front replaceable air filter
For installing dual systems and redundant power supplies more easily
Two USB ports on the front panel
For easy access
One PS/2 K/B connector on the front panel
Convenient to connect to the keyboard
One K/B connector cap
Good for dust-proof for the front accessible K/B connector
Two ball-bearing cooling fans
Better ventilation to provide the system with higher reliability
Enhanced drive bracket to hold 3 x 5.25” + 1 x 3.5” (external) and
1 x 3.5” drives (internal)
For integrating varied systems with higher flexibility
Shock-resistant cushion for the drive bracket
Suitable for installing RAID and CD-ROM drive
Two adjustable positions for hold-down card retainers
For fixing all the cards more flexibly and tightly
Changeable modularized back panel for 14-slot ISA/PICMG
backplane or ATX M/B
Only one minutes to change the back panel
Easy to change to different backplanes and keep stock
Field replaceable power supply bracket for both normal PS/2 power
supply and PS/2 type redundant power supply
Only three minutes to change defective power supply
Only 30 seconds to change the defective PSU module
ENGINEERING DRAWING
Unit: mm
49 Chassis-RPC-500NC/L
The Best Cost-Performance 19” 4U
Height Pentium® 4 Processor Based
Rack-mount Computer
AREMO-4196
FEATURES
Three 5.25” and one external 3.5” HDD drive
bays for RAID 0, 1, 5 & CD-ROM
Two USB ports on the front panel
Dual 12cm ball-bearing cooling fans for better
ventilation
Two card retainer positions
PS/2 or redundant power supply installable
ATX
M/B applicable, especially for big-ATX
size M/B
Easily detached and washable air filter
Equipped with fan control card to detect fan
failure
ORDERING GUIDE
GENERAL
Construction
Heavy-duty steel with aluminum front panel
Drive Bay
External: 5.25” x3, 3.5” HDD x1
Card Retainer
Three locations for one card retainer
Air Filter
Two replaceable air filter
Cooling Fan
Two 12cm 8cm ball-bearing cooling fans
Indicator
Power on/off x1, HDD x1
Switch
Power on/off x1, System reset x1
Speaker
One 8 speaker
Connector
Two USB ports on the front panel
Standard Color
Silver, Black
Dimension
482(W) x 481(D) x 177(H) mm; 19”(W) x 18.1”(D) x 7”(H)
Weight
Net: 13.5 kg (29.8 lb); Gross: 14.5 kg (32 lb)
Backplane
PBP-14I: 14-slot ISA backplane
PBP-14AC: 14-slot (12xPCI) active PICMG backplane
PBP-14A7: 14-slot (7xPCI) active PICMG backplane
PBP-14P4: 14-slot (4xPCI) PICMG backplane
PBP-13D4: 13-slot dual-system PICMG backplane
ORION-D4201P optional
POWER SUPPLY
Input Voltage
90V ~ 264V AC, full range
Input Frequency
47 ~ 63 Hz
19” 4U rack-mount chassis for PICMG version
Input Current
[email protected]; [email protected]
AREMO-4196
AREMO-4196-MX
Efficiency
> 70%
19” 4U rack-mount chassis for M/B version
Holdup Time
17 ms. at full load @25oC
AREMO-4196-MX-4201P
Over Voltage Protection
[email protected]; [email protected]; [email protected]
19” 4U rack-mount chassis for ATX motherboard
with active 420W ATX, Active PFC power supply
Over Power/Load Protection
Output power over to 110%~140%
MTBF
100,000 hrs
EMI & Safety Approval
UL, TUV
Temperature/Humidity
Operating: 0 ~ 50oC, 20 ~ 85%RH
Storage: -40 ~ 70oC, 10 ~ 90%RH
Dimension (WxDxH)
150 x 140 x 86 mm; 5.9” x 5.5” x 3.4”
AREMO-4196-00-4201P
19” 4U rack-mount chassis for PICMG version and
420w ATX, Active PFC power supply (3-in-2 mobile
rack Drive is optional)
ENVIRONMENT
Operating Temperature Range
0 to +55°C
Storage Temperature Range
-20 to +80°C
Relative Humidity
5% to 95%, non-condensing
Vibration
5~7 Hz: 0.5” double amplitude displacement
7~2000 Hz: 1.5g acceleration
Chassis-AREMO-4196 50
AREMO-4196
The Best Cost-Performance 19” 4U
Height Pentium® 4 Processor Based
Rack-mount Computer
FEATURE
BENEFITS
A lockable front door with thumb lock
Good for dust-proof & security
One power on/off switch and one system reset botton on the
front panel behind the lockable door
Avoid accidental reset for better running security
Fan control board
Detect fan fail and Alarm
Front replaceable air filter
For easy cleaning and install
Equipped two USB ports
Efficient Access
Dual 12cm ball-bearing cooling fans
Better ventilation to provide the system with higher reliability
Enhanced drive bracket to hold three 5.25” and two 3.5” HDD
drives (internal)
For integrating varied systems with higher flexibility
Suitable for installing RAID and CD-ROM drive
Shock-resistant cushion for the drive bracket
Suitable for harsh industrial environment
Two adjustable positions for hold-down card retainers
For fixing all the cards more flexibly and tightly
Changeable modularized back panel for 14-slot ISA/PICMG
backplane or ATX motherboard
Only one minute to change the back panel
Easy to change to different backplanes and keep stock
Field replaceable power supply bracket for both normal PS/2 power
supply and PS/2 type redundant power supply
Only three minutes to change the defective power supply
Only thirty seconds to change the defective PSU module
WHAT’S NEW
PCI based RAID kits, supporting up to three SATA
HDDs with RAID 0, 1, 5 selections. The Disk bus is
E-IDE with Ultra DMA support. The RAID kits provide
a GUI manager for installation and maintenance. Hotswap and hot-spare capabilities are also supported.
Friendly design of handles, you can lift and
unstall AREMO-4196 comfortably and easily.
Power switch, RESET switch, HDD / Power
/ Fan-fail / LAN LEDs and two USB 2.0 ports
are on the front panel.
Flexible design to install power supply, the
bracket can be adapt to PS/2 type or miniredundant power supply.
AREMO-4196 enhances the drive bracket to
integrate up to three 5.25” and one 3.5” disk drives
within a limited space. (extra two 3.5” HDD drives
for AREMO-4196-MX)
Equipped with dual 12cm ball bearing fans,
AREMO-4196 provides the best ventilation up
to 208CFM to expire heat from the system.
AREMO-4196 adopts the newly designed
card retainer to hold both the PCI and ISA
type add-on-cards more tightly.
AREMO-4196 is equipped with two USB 2.0
connectors on the front panel to have a better
security control.
The washable fan filter can be easily taken
off to make an easier maintenance.
LED indicators include power, HDD, Fan-fail
and LAN functions.
The thumb lock offers easy operation. Users
can choose to lock it or not.
The washable fan filter can be easily taken
out for easier maintenance.
51 Chassis-AREMO-4196
AREMO-4196
AREMO-4196
The Best Cost-Performance 19” 4U
Height Pentium® 4 Processor Based
Rack-mount Computer
AREMO-4196-MX
ENGINEERING DRAWING
Unit: mm
Chassis-AREMO-4196 52
AREMO-2173P
FEATURES
19” 2U industrial rack-mount chassis
for PICMG backplane
GENERAL
One slim CD-ROM and two hot-swap 3.5”
HDD (SATA) Drive bays
Construction
Heavy-duty steel
Drive Bay
External: Slim type CD-ROM x1, Hot-swap 3.5” HDD x2
Two USB ports on the front panel
Air Filter
One external replaceable air filter
Two 7cm ball-bearing cooling fans for
better ventilation
Cooling Fan
Two 7cm ball-bearing fans
Indicator
HDD x1+ Power on/off x1
One power On/Off switch with protection cap
and one touch free reset for secure access
Switch
Power on/off (with a protection cap) x1, System reset x1
Speaker
One 8 speaker
Connector
Two USB ports equipped on the front panel
Standard Color
Silver, Black
Dimension
482(W) x 441.6(D) x 88.4(H) mm; 19”(W) x 17.4”(D) x 3.5”(H)
Weight
Net: 11.0 kg (23.1 lb); Gross: 12.0 kg (25.3 lb)
ORDERING GUIDE
AREMO-2173P-06V4-D3501P
Input Voltage
90V ~ 264V AC, full range
19” 2U rack-mount chassis with vertical 6-slot (4x
PCI) PICMG backplane and 350W ATX, active
PFC power supply
Input Frequency
47 ~ 63 Hz
Input Current
[email protected]
Efficiency
> 68%
Holdup Time
17 ms. at full [email protected]
Over Voltage Protection
[email protected]; [email protected]; [email protected]
Over Power/Load Protection
Output power over 110%~140%
MTBF
75,145 hrs
EMI & Safety Approval
UL, TUV, CE, FCC, CB, CSA, SEMKO, FIMKO, NEMCO, DIMCO
Temperature/Humidity
Operating: 0 ~ 50oC, 20 ~ 85%RH
Storage: -20 ~ 70oC, 10 ~ 90%RH
Dimension (WxDxH)
150x140x86 mm; 5.9”x5.5”x3.4”
AREMO-2173P-06V4
19” 2U rack-mount chassis with vertical 6-slot (4x
PCI) PICMG backplane
ORION-D3501P optional
POWER SUPPLY
AREMO-2173P-06V4-3502P
19” 2U rack-mount chassis with vertical 6-slot (4x
PCI) PICMG backplane and 350W active PFC
redundant power supply
ENVIRONMENT
53 Chassis-AREMO-2173P
Operating Temperature Range
0 to +55°C
Storage Temperature Range
-20 to +80°C
Relative Humidity
5% to 95%, non-condensing
Vibration
5~7 Hz: 0.5” double amplitude displacement
7~2000 Hz: 1.5g acceleration
AREMO-2173P
19” 2U industrial rack-mount chassis
for PICMG backplane
FEATURE
BENEFITS
350W Active PFC power supply
Sufficient power source for Intel® Pentium® 4 processor
Two 7cm high speed fans
Better ventilation to enhance system reliability
Two swappable SATA HDD drive bays
Easy to access HDD drives
Four Low profile PCI expansion slots
For system function expansion
Front replaceable air filters
Easy cleaning
WHAT’S NEW
Thumb Lock
Two Swappable SATA HDD Drives
Front Replaceable Air Filters/Fans
Convenient to operate or protect the system
Easy to access HDD drives
Convenient to change air filters or fans when
needed
Rear View
ENGINEERING DRAWING
Unit: mm
Chassis-AREMO-2173P 54
19” 2U industrial rack-mount
chassis for Micro-ATX or miniITX mother board
AREMO-2173MX
FEATURES
GENERAL
One slim CD-ROM and two hot-swap 3.5”
HDD (SATA) Drive bays
Construction
Heavy-duty steel
Drive Bay
External: Slim type CD-ROM x1, Hot-swap 3.5” HDD x2
Two USB ports on the front panel
Air Filter
One external replaceable air filter
Two 7cm ball-bearing cooling fans for
better ventilation
Cooling Fan
Two 7cm ball-bearing fans
Indicator
HDD x1+ Power on/off x1
One power On/Off switch with protection cap
and one touch free reset for secure access
Switch
Power on/off (with a protection cap) x1, System reset x1
Speaker
One 8 speaker
Connector
Two USB ports equipped on the front panel
Standard Color
Silver, Black
Dimension
482(W) x 441.6(D) x 88.4(H) mm; 19”(W) x 17.4”(D) x 3.5”(H)
Weight
Net: 11.0 kg (23.1 lb); Gross: 12.0 kg (25.3 lb)
ORDERING GUIDE
ORION-D3501P optional
POWER SUPPLY
AREMO-2173MX-D3501P
Input Voltage
90V ~ 264V AC, full range
19” 2U rack-mount chassis for micro-ATX or miniITX M/B with 350W ATX, active PFC power
supply
Input Frequency
47 ~ 63 Hz
Input Current
[email protected]
Efficiency
> 68%
Holdup Time
17 ms. at full [email protected]
Over Voltage Protection
[email protected]; [email protected]; [email protected]
Over Power/Load Protection
Output power over 110%~140%
MTBF
75,145 hrs
EMI & Safety Approval
UL, TUV
Temperature/Humidity
Operating: 0 ~ 50oC, 20 ~ 85%RH
Storage: -40 ~ 70oC, 10 ~ 90%RH
Dimension (WxDxH)
150x140x86 mm; 5.9”x5.5”x3.4”
AREMO-2173MX
19” 2U rack-mount chassis for micro-ATX or miniITX M/B
ENVIRONMENT
55 Chassis-AREMO-2173MX
Operating Temperature Range
0 to +55°C
Storage Temperature Range
-20 to +80°C
Relative Humidity
5% to 95%, non-condensing
Vibration
5~7 Hz: 0.5” double amplitude displacement
7~2000 Hz: 1.5g acceleration
AREMO-2173MX
FEATURE
BENEFITS
350W Active PFC power supply
Sufficient power source for Intel® Pentium® 4 processor
Two 7cm high speed fans
Better ventilation to enhance system reliability
Two swappable SATA HDD drive bays
Easy to access HDD drives
Four Low profile PCI expansion slots
For system function expansion
Front replaceable air filters
Easy cleaning
WHAT’S NEW
Thumb Lock
Two Swappable SATA HDD Drives
Front Replaceable Air Filters/Fans
Convenient to operate or protect the system
Easy to access HDD drives
Convenient to change air filters or fans when
needed
Rear View
ENGINEERING DRAWING
Unit: mm
Chassis-AREMO-2173MX 56
AREMO-3194
FEATURES
19” 3U rack-mount chassis for
ATX M/B platform
GENERAL
IEEE 1394 port and two USB ports on the
front panel
Construction
Heavy-duty steel
Drive Bay
External: 5.25”x2+3.5”x1; Internal: 3.5”x1
Dedicated cooling fans for expiring the heat
on the hot spots within the chassis
Air Filter
Two replaceable air filters at the front
Cooling Fan
Two 8 cm ball-bearing cooling fans
Dustproof front-access air filter for easy
cleaning and replacing
Indicator
Power on/off x1, HDD x1
Switch
Power on/off x1, System reset x1
Lockable front door provides greater security
Speaker
One 8 speaker
Thumb lock for greater security and to operate
system more easily
Connector
Two USB ports and 1 IEEE 1394 port on the front panel
Standard Color
Silver, Black
Dimension
481.6(W) x 487.8(D) x 132.7(H) mm ; 19”(W) x 19.2”(D) x 5.22”(H)
Weight
Net: 16 kg (35.3 lb) ; Gross: 18 kg (39.7 lb)
M/B
Micro-ATX, ATX
ORDERING GUIDE
AREMO-3194-MX-B3501P
19” 3U rack-mount chassis with 2U 350W ATX,
W/active PFC power supply for ATX M/B
ORION-B3501P optional
POWER SUPPLY
Input Voltage
90V ~ 264V AC, full range
Input Frequency
47 ~ 63 Hz
AREMO-3194E-MX-D3501P
Input Current
[email protected], [email protected]
19” 3U rack-mount chassis with PS/2 350W ATX,
Efficiency
> 65%
Holdup Time
16 ms. at full load
Over Voltage Protection
[email protected]~7.0V; [email protected]~4.5V; [email protected]~14.6V
Over Power/Load Protection
Output power over 110%~150%
MTBF
100,000 hrs
EMI & Safety Approval
UL, cUL, TUV, CE, FCC
Temperature/Humidity
Operating: 0 ~ 40oC, 20 ~ 90%RH
Storage: -20 ~ 60oC, 5 ~ 95%RH
Dimension (WxDxH)
100x200x70 mm; 3.94”x8.3”x2.8”
with active PFC power supply for ATX M/B
ENVIRONMENT
57 Chassis-AREMO-3194
Operating Temperature Range
0 to +55°C
Storage Temperature Range
-20 to +80°C
Relative Humidity
5% to 95%, non-condensing
Vibration
5~7 Hz: 0.5” double amplitude displacement
7~2000 Hz: 1.5g acceleration
AREMO-3194
19” 3U rack-mount chassis for
ATX M/B platform
FEATURE
BENEFITS
Two USB and one IEEE 1394 ports on the front panel
Sufficient power source for Intel® Pentium® 4 processor
Cooling tunnel design
Better ventilation to enhance system reliability
More expansion slots
Support up to six expansion and one AGP slots for higher expansibility
Thumb lock
Easy to operate the system
Lockable front door
Provide better security
Front replaceable air filters
For easy cleaning
WHAT’S NEW
Excellent In-System Cooling
PCI and AGP Expansion
Front Replaceable Air Filters
Two 8cm ball-bearing fans provide better
ventilation and keep smooth airflow
Six PCI and one AGP expansion slots for
adding more functions to the system
Convenient to change air filters
when needed
Lockable Front Door and
Thumb Lock
Protection Cap and Touch-Free
Reset Switch
Excellent Cooling System
Provide better security and operate the
system more easily
Avoid abnormal operation and increase
system reliability
New slot cover and air holes for
better ventilation
ENGINEERING DRAWING
Unit: mm
Chassis-AREMO-3194 58
PRC-4207
FEATURES
5.25” x3 + 3.5” x4 drive bays for RAID 0, 1, 5 &
CD-ROM
GENERAL
Construction
Heavy-duty steel
Drive Bay
External: 5.25” x3
Internal: 3.5” HDD x4
Two ball-bearing cooling fans for better
ventilation
Card Retainer
Two locations for one card retainer
Traditional rack-mount handles
Air Filter
One replaceable air filter
Cooling Fan
One 12cm and one 8cm ball-bearing cooling fans
Indicator
Power on/off x1, HDD x1
Switch
Power on/off x1, System reset x1, K/B lock x1
Connector
Two USB ports on the front panel
Standard Color
Beige, Black
Dimension
482(W) x 519(D) x 177(H) mm; 19”(W) x 20.4”(D) x 7”(H)
Weight
Net: 14 kg (30.9 lb); Gross: 15 kg (33.1 lb)
Backplane
PBP-14I: 14-slot ISA backplane
PBP-14AC: 14-slot (12xPCI) active PICMG backplane
PBP-14A7: 14-slot (7xPCI) active PICMG backplane
PBP-14P4: 14-slot (4xPCI) PICMG backplane
PBP-13D4: 13-slot dual-system PICMG backplane
Two card retainer positions
Two USB ports on front panel
ATX
M/B applicable, especially for server
grade M/B
PS/2 reduncant power supply installable
ORDERING GUIDE
PRC-4207
19” 4U rack-mount chassis for PICMG backplane
19” 4U industrial rack-mount chassis
for server grade mother board
PRC-4207-MX
19” 4U rack-mount chassis for ATX M/B
ORION-D4601P optional
POWER SUPPLY
Maximum output
460W
Output Voltage & Current
[email protected]; [email protected]; [email protected], [email protected], [email protected]
Input Voltage
90V ~ 264V AC selectable
Input Frequency
47 ~ 63Hz
Input Current
[email protected], [email protected]
Efficiency
> 70%
MTBF
100,000 hrs at 25oC
EMI & Safety Approval
UL, TUV, CE, FCC
Temperature/Humidity
Operating: 0 ~ 50oC, 20 ~ 85%RH
Storage: -40 ~ 60oC, 5 ~ 95%RH
Dimension (WxDxH)
150 x 140 x 86 mm; 5.9” x 5.5” x 3.4”
ENVIRONMENT
59 Chassis-PRC-4207
Operating Temperature Range
0 to +55°C
Storage Temperature Range
-20 to +70°C
Relative Humidity
5% to 95%, non-condensing
Vibration
5~7 Hz: 0.5” double amplitude displacement
7~2000 Hz: 1.5g acceleration
PRC-4207
19” 4U industrial rack-mount chassis
for server grade motherboard
FEATURE
BENEFITS
A lockable front door with acrylic windows
Good for dust-proof & Running status visible
One power on/off switch with LED indicator, one reset and one K/B
lock switches inside the lockable door
Avoid accidental reset for better running security
Front replaceable air filter
For installing dual systems and redundant power supplies more easily
Two USB ports on the front panel
For easy access
Two ball-bearing cooling fans
Better ventilation to provide the system with higher reliability
Enhanced drive bracket to hold 3 x 5.25” + 4 x 3.5” drives (internal)
For integrating varied systems with higher flexibility
Shock-resistant cushion for the drive bracket
Suitable for installing RAID and CD-ROM drive
Two adjustable positions for hold-down card retainers
For fixing all the cards more flexibly and tightly
Changeable modularized back panel for 14-slot ISA/PICMG
backplane or ATX M/B
Only one minutes to change the back panel
Easy to change to different backplanes and keep stock
Field replaceable power supply bracket for both normal PS/2 power
supply and PS/2 type redundant power supply
Only three minutes to change the defective power supply
Only 30 seconds to change the defective PSU module
ENGINEERING DRAWING
173.70
426.50
39.15
26.45
92
66.55
52.85
519.31
514.40
514.90
74.65
19.35
88
10.40
177
102.40
R
176.82
3.30
3.55
37.30
Unit: mm
465
482
Chassis-PRC-4207 60
AREMO-6163
FEATURES
One external 5.25” and two internal 3.5” HDD
drive bays
Two USB ports on the front panel
Can be vertically or horizontally mounted,
easy to fit into space limited environment
One 12cm ball-bearing cooling fan for
better ventilation
One replaceable air filter for easy cleaning
Two adjustable positions for hold-down card
retainers provide better protection from
vibration
6-slot full-size industrial node chassis
(Shoe-box)
GENERAL
Construction
Heavy-duty steel
Drive Bay
External: 5.25” x1
Internal: 3.5” HDD x2
Card Retainer
Two locations for one card retainer
Air Filter
One replaceable air filter at the front door
Cooling Fan
One 12cm ball-bearing fan
Indicator
Power on/off x1, HDD x1
Switch
Power on/off x1, System reset x1
Speaker
One 8 speaker
Connector
Two USB ports on the front panel
Standard Color
Silver, Black
Wall-mounting bracket equipped
Dimension
260(W) x 420.8(D) x 172(H) mm; 10.24”(W) x 16.56”(D) x 6.77”(H)
Both 6-slot ISA and PICMG 1.0 or 1.3
backplane applicable; easy to change
different backplanes
Weight
Net: 8.5 kg (18.7 lb); Gross: 9.5 kg (20.9 lb)
Backplane
PBP-06I: 6-slot PISA bus PICMG backplane
PBP-06P4: 6-slot (4xPCI) PICMG backplane
PBP-06P3: 6-slot (3xPCI) PICMG backplane
Field replaceable power supply bracket for
both normal PS/2 and PS/2 redundant
power supply, easy for changing defected
power supply
ORDERING GUIDE
AREMO-6163-06P3-D3501P
ORION-D3501P optional
POWER SUPPLY
Input Voltage
90V ~ 264V AC, full range
Input Frequency
47 ~ 63 Hz
Input Current
[email protected]
Efficiency
> 68%
Holdup Time
17 ms. at full load @25oC
Over Voltage Protection
[email protected] 7V; [email protected] 4.3V; [email protected] 15.6V
6-slot full-size industrial node chassis with
6-slot (3xPCI) PICMG backplane and 350W
active PFC ATX power supply
Over Power/Load Protection
Output power over to 110%~140%
MTBF
75,145 hrs
AREMO-6163-06P4-D3501P
EMI & Safety Approval
UL, TUV
6-slot full-size industrial node chassis with
6-slot (4xPCI) PICMG backplane and 350W
active PFC ATX power supply
Temperature/Humidity
Operating: 0 ~ 50oC, 20 ~ 85%RH
Storage: -40 ~ 70oC, 10 ~ 90%RH
Dimension (WxDxH)
150x140x86 mm; 5.9”x5.5”x3.4”
ENVIRONMENT
61 Chassis-AREMO-6163
Operating Temperature Range
0 to +55°C
Storage Temperature Range
-20 to +80°C
Relative Humidity
5% to 95%, non-condensing
Vibration
5~7 Hz: 0.5” double amplitude displacement
7~2000 Hz: 1.5g acceleration
AREMO-6163
6-slot full-size industrial node chassis
(Shoe-box)
FEATURE
BENEFITS
5.25” drive space for CD-ROM or mobile rack
Easy to install software
Two USB ports at the front
Easy to operate the system
One replaceable air filter
Easy cleaning
Two USB ports equipped
Can be vertically or horizontally mounted
Easy to fit into different space limited environments
Two adjustable positions for hold-down card retainer
For fixing all the cards more flexibly and tightly
Both 6-slot ISA and PICMG backplane applicable
Easy to change to different backplane and keep in stock
Field replaceable power supply bracket for both normal PS/2
power supply and PS/2 type redundant power supply
Easy maintenance
WHAT’S NEW
Two Adjustable Card Retainer Positions
Plastic Fan Filter
New HDD Drive Design
For fixing all the cards more flexibly and tightly
For easy cleaning and replace
Easy to install HDD drives
ENGINEERING DRAWING
Unit: mm
Chassis-AREMO-6163 62
AREMO-8164
FEATURES
8-slot full-size industrial node chassis
(Shoe-box)
GENERAL
Two 5.25” and two internal 3.5” HDD drive
bays for CD-ROM or mobile rack, easy to
install software and mirror disk (RAID1)
Construction
Heavy-duty steel
Drive Bay
External: 5.25” x2
Two USB ports on the front panel
Card Retainer
Two locations for one card retainer
Can be vertically or horizontally mounted,
easy to fit into space limited environment
Air Filter
One replaceable air filter at the front door
Cooling Fan
One 12cm ball-bearing fan
One 12cm ball-bearing cooling fan for
better ventilation
Indicator
Power on/off x1, HDD x1
Switch
Power on/off x1, System reset x1
One replaceable air filter for easy cleaning
Speaker
One 8 speaker
Two adjustable positions for hold-down
card retainers provide better protection
from vibration
Connector
2 USB ports on the front panel
Standard Color
Silver, Black
Dimension
330(W) x 420.8(D) x 172(H) mm; 12.99”(W) x 16.56”(D) x 6.77”(H)
Wall-mounting bracket equipped
Weight
Net: 10 kg (22.1 lb); Gross: 9.5 kg (20.9 lb)
Both 8-slot ISA and PICMG 1.0 or 1.3
backplane applicable; easy to change
different backplanes
Backplane
PBP-08I: 8-slot ISA backplane
PBP-08P4: 8-slot (4xPCI) PICMG backplane
PBP-08P3 : 8-slot (3xPCI) PICMG backplane
Field replaceable power supply bracket for
both normal PS/2 and PS/2 redundant
power supply, easy for changing defected
power supply
90V ~ 264V AC, full range
Input Frequency
47 ~ 63 Hz
Input Current
[email protected]
Efficiency
> 68%
Holdup Time
17 ms. at full load @25oC
Over Voltage Protection
[email protected] 7V; [email protected] 4.3V; [email protected] 15.6V
Over Power/Load Protection
Output power over 110%~140%
MTBF
75,145 hrs
AREMO-8164-08P4-00
EMI & Safety Approval
UL, TUV
8-slot full-size industrial node chassis with
8-slot (4xPCI) PICMG backplane
Temperature/Humidity
Operating: 0 ~ 50oC, 20 ~ 85%RH
Storage: -40 ~ 70oC, 10 ~ 90%RH
AREMO-8164-08P4-D3501P
Dimension (WxDxH)
150x140x86 mm; 5.9”x5.5”x3.4”
AREMO-8164
8-slot full-size industrial node chassis
ORION-D3501P optional
POWER SUPPLY
Input Voltage
ORDERING GUIDE
Internal: 3.5” HDD x2
8-slot full-size industrial node chassis with
8-slot (4xPCI) PICMG backplane and 350W
active PFC ATX power supply
63 Chassis-AREMO-8164
ENVIRONMENT
Operating Temperature Range
0 to +55°C
Storage Temperature Range
-20 to +80°C
Relative Humidity
5% to 95%, non-condensing
Vibration
5~7 Hz: 0.5” double amplitude displacement
7~2000 Hz: 1.5g acceleration
AREMO-8164
8-slot full-size industrial node chassis
(Shoe-box)
FEATURE
BENEFITS
5.25” drive bays for CD-ROM or mobile rack
Easy to install software and mirror disk (RAID 1)
Two USB ports on the front panel
Easy to operate the system
One replaceable air filter
Easy cleaning
Can be vertically or horizontally mounted
Easy to fit into different space limited environments
Two adjustable positions for hold-down card retainer
For fixing all the cards more flexibly and tightly
Both 8-slot ISA and PICMG backplane applicable
Easy to change to different backplane and keep in stock
Field replaceable power supply bracket for both normal PS/2
power supply and PS/2 type redundant power supply
Easy maintenance
WHAT’S NEW
Two Adjustable Card Retainer Positions
Plastic Fan Filter
Excellent Cooling System
For fixing all the cards more flexibly and tightly
For easy cleaning and replacing
New slot cover for better ventilation
ENGINEERING DRAWING
Unit: mm
Chassis-AREMO-8164 64
AREMO-4184
19" 4U Height rack-mount chassis with
dual AREMO-6182 node chassis
AREMO-4184
GENERAL
FEATURES
Construction
Heavy-duty steel
External: 5.25” x1 (each system)
Magic design for wall-mount, desk-top and
rack-mount application
Drive Bay
Ruggedized steel node chassis suitable for
harsh environment
Card Retainer
Two locations for one card retainer
Air Filter
One replaceable air filter at the front door
One built-in 12cm ball-bearing fan for better
ventilation
Cooling Fan
One 12cm ball-bearing fan
Indicator
Power on/off x1, HDD x1
Built-in 1U ATX type power supply
Switch
Power on/off (with a protection cap) x1, System reset x1
Support one external 5.25” and one internal
3.5” disk drive
Speaker
One 8 speaker
Optional one external 5.25” and one internal
3.5” disk drive
Connector
2 USB ports
Standard Color
Black, Silver
Dimension
AREMO-4184: 482(W) x 448(D) x 177(H) mm; 19”(W) x 17.6”(D) x 7”(H)
Weight
AREMO-6182: Net: 6.5 kg (14.3 lb); Gross: 8.0 kg (17.6 lb)
AREMO-4184: Net: 15.5 kg (34.2 lb); Gross: 17.5 kg (38.6 lb)
Backplane
PBP-06P3: 6-slot (3xPCI) PICMG backplane
PBP-06P4: 6-slot (4xPCI) PICMG backplane
PBP-06I: 6-slot (6xISA) PICMG backplane
Optional kit to combine two AREMO-6182 for
the rack-mount application, AREMO-4184
Internal: 3.5” x1 (each system)
FSP350-601UA optional
POWER SUPPLY
AREMO-6182
ORDERING GUIDE
AREMO-4184-06P4-350X/B
Two sets of AREMO-6182 with rack-mount kit,
6-slot (3xPCI) PICMG backplane and 350W
1U ATX, active PFC power supply
AREMO-6182-06P4-350X/B
6-slot node chassis with 6-slot (3xPCI) PICMG
backplane and 350W 1U ATX, active PFC power
supply
65 Chassis-AREMO-4184
Input Voltage
90V ~ 135V, 180V ~ 265V AC
Input Frequency
47 ~ 63 Hz
Input Current
[email protected], [email protected]
Efficiency
> 65%
Holdup Time
18m Sec
Over Voltage Protection
+3.3V: 4.5V; +5V: 6.5V; +12V: 15.6V
Over Power/Load Protection
+3.3V: 45A; +5V: 45A; +12V: 20A
MTBF
100,000 hrs
EMI & Safety Approval
UL, CSA, VDE, FCC, CE, NEMKO
Temperature/Humidity
Operating: 0 ~ 50°C, 20 ~ 80%RH
Storage: -40 ~ 70°C, 10 ~ 90%RH
Dimension (WxDxH)
150x140x86 mm; 5.9”x5.5”x3.4”
ENVIRONMENT
Operating Temperature Range
0 to +50°C
Storage Temperature Range
-20 to +80°C
Relative Humidity
5% to 95%, non-condensing
Vibration
5~7 Hz: 0.5” double amplitude displacement
7~2000 Hz: 1.5g acceleration
AREMO-4184
19" 4U Height rack-mount chassis with
dual AREMO-6182 node chassis
FEATURE
BENEFITS
One 5.25” drive bay for EZDRV
For both CD-ROM and FDD support or Hot-swappable HDD
Front replaceable air filter
Easy cleaning & replacing
Two adjustable positions for hold-down card retainer
For fixing all the cards more flexibly and tightly
Both 6-slot ISA and PICMG backplane applicable
Easy to change to different backplane and keep in stock
350W micro-ATX power supply
Save the space inside the chassis
Special kit to combine dual systems into 4U space
Can be integrated as a fault tolerant system
WHAT’S NEW
Special Configuration with EZDRV
Easy to Mount
Two become One
AREMO-6182 adopts EZDRV-300NCF or mobile rack
for 3.5” HDD
AREMO-6182 can be easily mounted on the
supporter
Combine two AREMO-6182 as a dual
system 4U chassis
ENGINEERING DRAWING
Unit: mm
Chassis-AREMO-4184 66
AREMO-6182
FEATURES
One external 5.25” and one internal HDD
drive bay
One replaceable air filter for easy cleaning
Can be vertically or horizontally mounted,
easy to fit into space limited environment
6-slot full-size industrial node chassis
(Shoe-box)
GENERAL
Construction
Heavy-duty steel
Drive Bay
External: 5.25” x1
Internal: 3.5” HDD x1
Card Retainer
Two locations for one card retainer
Air Filter
One replaceable air filter at the front door
Cooling Fan
One 12cm ball-bearing fan
Indicator
Power on/off x1, HDD x1
The fan filter panel can be installed in
different directions
Switch
Power on/off x1, System reset x1
Speaker
One 8 speaker
Two adjustable positions for hold-down
card retainers provide better protection
from vibration
Connector
2 USB ports
Standard Color
Black, Silver
Dimension
219(W) x 448(D) x 160(H) mm; 8.6”(W) x 17.6”(D) x 6.3”(H)
Wall-mounting bracket equipped
Weight
Net: 8.5 kg (18.7 lb); Gross: 9.5 kg (20.9 lb)
Both 6-slot ISA and PICMG 1.0 or 1.3
backplane applicable; easy to change
different backplanes
Backplane
6-slot PISA bus PICMG backplane
One 12cm ball-bearing cooling fan for
better ventilation
FSP350-601UA optional
POWER SUPPLY
Input Voltage
90V ~ 132V, 180V ~ 265V AC
Input Frequency
47 ~ 63 Hz
Input Current
[email protected], [email protected]
Efficiency
> 65%
Holdup Time
18m Sec
Over Voltage Protection
+3.3V: 4.5V; +5V: 6.5V; +12V: 15.6V
AREMO-6182-06P3-350X
Over Power/Load Protection
+3.3V: 45A; +5V: 45A; +12V: 20A
6-slot full-size industrial node chassis with
6-slot (3xPCI) PICMG backplane and 1U 350W ATX,
Active PFC power supply
MTBF
100,000 hrs
EMI & Safety Approval
UL, CSA, VDE, FCC, CE, NEMKO
AREMO-6182-06P4-350X
Temperature/Humidity
Operating: 0 ~ 50°C, 20 ~ 80%RH
Storage: -40 ~ 70°C, 10 ~ 90%RH
6-slot full-size industrial node chassis with
6-slot (4xPCI) PICMG backplane and 350W
active PFC ATX power supply
Dimension (WxDxH)
150x140x86 mm; 5.9”x5.5”x3.4”
ORDERING GUIDE
ENVIRONMENT
67 Chassis-AREMO-6182
Operating Temperature Range
0 to +50°C
Storage Temperature Range
-20 to +80°C
Relative Humidity
5% to 95%, non-condensing
Vibration
5~7 Hz: 0.5” double amplitude displacement
7~2000 Hz: 1.5g acceleration
AREMO-6182
6-slot full-size industrial node chassis
(Shoe-box)
FEATURE
BENEFITS
5.25” drive bay for CD-ROM or mobile rack
Easy to install software and mirror disk (RAID 1)
One replaceable air filter
Easy to operate the system
Can be vertically or horizontally mounted
For easy cleaning
Two adjustable positions for hold-down card retainer
Easy to fit into different space limited environment
Both 6-slot ISA and PICMG backplane applicable
For fixing all the cards more flexibly and tightly
Field replaceable power supply bracket for both normal PS/2
power supply and PS/2 type redundant power supply
Easy to change to different backplane and keep stock
Field replaceable bracket for both normal PS/2 and redundant power
supply
For ease of maintenance
Removable fan kit
Easy to replace the broken fan
WHAT’S NEW
Removable Fan Kit
Can be Mounted in Different Styles
Dual Card Retainers
Easy to replace the fan when broken
AREMO-6182 can be either vertically or
horizontally installed
It has two positions for card clamps to
hold both PCI and ISA cards tightly
ENGINEERING DRAWING
Unit: mm
Chassis-AREMO-6182 68
PNC-5063
FEATURES
One NB CD-ROM, one NB FDD and one 3.5”
HDD drive bays
GENERAL
Construction
Heavy-duty steel
Drive Bay
External: NB CD-ROM x1 + NB FDD x1 (devices built in)
Internal: 3.5” HDD x1
Can be vertically or horizontally mounted, easy
to fit into space limited environment
Air Filter
One replaceable air filter at the front door
Replaceable air filter for easy cleaning
Cooling Fan
One 12cm ball-bearing fan
Indicator
HDD x1
Switch
Power on/off (with a protection cap) x1, System reset x1
Speaker
One 8 speaker
Connector
Two USB ports on the front panel
Standard Color
Industrial dark gray
Dimension
196(W) x 262(D) x 196(H) mm; 7.7”(W) x 10.3”(D) x 7.2”(H)
Weight
Net: 6.5 kg (14.3 lb); Gross: 7 kg (15.4 lb)
Backplane
PBP-05P: 5-slot PCI backplane
One power on/off switch protection cap and
one touchfree reset for secure access
Two front accessible USB ports
Wall-mounting bracket equipped
One 12cm ball-bearing cooling fan provides
better ventilation to enhance the system
reliability
6-slot industrial node chassis for halfsize PCI cards
Built-in 150W ATX active PFC power supply
ORION-A1501
POWER SUPPLY
Input Voltage
90V ~ 264V AC, full range
Input Frequency
47 ~ 63 Hz
Input Current
[email protected], [email protected]
Efficiency
> 65%
Holdup Time
16 ms. at full load @25oC
PNC-5063-05P-150X
Over Voltage Protection
[email protected] 5.6~6.6V; [email protected] 3.6~4.2V; [email protected] 13.2~14.6V
6-slot node chassis with 5-slot PCI backplane,
150W ATX active PFC, power supply, 24X NB CDROM and NB FDD
Over Power/Load Protection
Output power over to 110%~160%
MTBF
84,228 hrs
EMI & Safety Approval
UL, CSA, TUV, FCC, CE
Temperature/Humidity
Operating: 0 ~ 50oC, 20 ~ 90%RH
Storage: -20 ~ 70oC, 5 ~ 95%RH
Dimension (WxDxH)
150x140x86 mm; 5.9”x5.5”x3.4”
ORDERING GUIDE
ENVIRONMENT
69 Chassis-PNC-5063
Operating Temperature Range
0 to +55°C
Storage Temperature Range
-20 to +80°C
Relative Humidity
5% to 95%, non-condensing
Vibration
5~7 Hz: 0.5” double amplitude displacement
7~2000 Hz: 1.5g acceleration
PRS-1174
FEATURES
Four external 3.5” HDD drive bays
19" 1U Height rack-mount micro-ATX
based server with four drives
GENERAL
Construction
Heavy-duty steel
Drive Bay
Internal: 3.5” HDD x4
One PCI expansion slot
Cooling Fan
One 4cm ball-bearing fan
Three 4cm ball-bearing cooling fans for
better ventilation
Indicator
Power on/off x1, HDD x1
Switch
Power on/off x1, System reset x1
Speaker
One 8 speaker
Connector
Two USB ports on the front panel
Standard Color
Silver
Dimension
432(W) x 510(D) x 44(H) mm; 10.24”(W) x 16.56”(D) x 6.77”(H)
Weight
Net: 8.5 kg (18.7 lb); Gross: 9.5 kg (20.9 lb)
Adopt
standard micro-ATX M/B
Support Hot-swappable mobile rack
Easy maintenance and installation
FSP270-50PLA optional
POWER SUPPLY
Input Voltage
90V ~ 264V AC, full range
Input Frequency
47 ~ 63 Hz
Input Current
[email protected]
Efficiency
> 68%
Holdup Time
17 ms. at full load @25oC
Over Voltage Protection
[email protected]~6.5V; [email protected]~4.5V; [email protected]~+5.6V
PRS-1174-MX-270X
Over Power/Load Protection
Output power over to 110%~140%
1U barebone RAID server with four drive bays,
270w active PFC power supply
MTBF
100,000 hrs
EMI & Safety Approval
UL, TUV, CE, FCC, CB, CSA, SEMKO, FIMKO,
NEMCO, DIMCO
Temperature/Humidity
Operating: 0 ~ 50oC, 20 ~ 85%RH
Storage: -40 ~ 70oC, 10 ~ 90%RH
Dimension (WxDxH)
150x81.6x40.6 mm; 5.9”x5.5”x3.4”
ORDERING GUIDE
ENVIRONMENT
Operating Temperature Range
0 to +55°C
Storage Temperature Range
-20 to +80°C
Relative Humidity
5% to 95%, non-condensing
Vibration
5~7 Hz: 0.5” double amplitude displacement
7~2000 Hz: 1.5g acceleration
Chassis-PRS-1174 70
PRC-1194
FEATURES
Single power supply with higher +12V output
for Pentium® 4 processor
Cooling tunnel design for expiring heat
generated by CPU
19" 1U Height industrial rack-mount P4
chassis
GENERAL
Construction
Heavy-duty steel
Drive Bay
External: NB CD-ROM x1 (or equivalent CD-RW / DVD-ROM) + NB FDD x1
Internal: 3.5” HDD x2
Air Filter
N/A
Power cable routed beneath the cooling tunnel
to avoid disturbance of air path
Cooling Fan
One 12cm ball-bearing fan
Indicator
Power on/off x1, HDD x1
Two PCI expansion slots for adding more
functions to system
Switch
Power on/off x1, System reset x1
Speaker
N/A
Connector
Two USB connectors on the front panel, reserved one COM port cutout
Standard Color
Black
Dimension
480.4(W) x 474(D) x 44(H) mm; 19”(W) x 18.7”(D) x 1.7”(H)
Weight
Net: 10 kg (22.05 lb); Gross: 13 kg (28.67 lb)
Backplane
PBP-03P2X: 3-slot (2xPCI) PICMG backplane
ORION-A2501 optional
POWER SUPPLY
Input Voltage
90V ~ 264V AC, full range
Input Frequency
47 ~ 63 Hz
Input Current
[email protected], [email protected]
Efficiency
> 65%
Holdup Time
16 ms. at full load @25oC
PRC-1194-03P2X-2501
Over Voltage Protection
[email protected]~6.5A; [email protected]~4.4V; [email protected]~15.6V
19” 1U rack-mount chassis with 3-slot (2xPCI)
PICMG backplane and 250W PFC power supply
Over Power/Load Protection
Output power over to 110%~160%
MTBF
105,405 hrs
EMI & Safety Approval
UL, cUL, TVU, CE, FCC
Temperature/Humidity
Operating: 0 ~ 50oC, 20 ~ 85%RH
Storage: -20 ~ 70oC, 10 ~ 90%RH
Dimension (WxDxH)
100x190x40.5 mm; 5.9”x5.5”x3.4”
ORDERING GUIDE
ENVIRONMENT
71 Chassis-PRC-1194
Operating Temperature Range
0 to +55°C
Storage Temperature Range
-20 to +80°C
Relative Humidity
5% to 95%, non-condensing
Vibration
5~7 Hz: 0.5” double amplitude displacement
7~2000 Hz: 1.5g acceleration
5.25" compact drive set with slim type
DVD-ROM, SD/CF card reader, 2 USB
ports and space for 2.5" HDD
EZDRV-400
External: 1xslim type DVD-ROM
SD Reader and 2 USB ports
Internal: 1xNB 2.5” HDD
CF Reader and LED for HDD
FEATURES
Construction
Heavy-duty steel with plastic front cover
Drive Bay
-External: Slim type DVD-ROM x1 + 2-in-1 reader + USB ports x2
One LED for internal HDD
ORDERING GUIDE
GENERAL
drive set can hold:
- one slim type DVD-ROM
- SD card reader
- CF card reader
- 2 USB ports
- 2.5” HDD (internal)
All-in-one
-Internal: NB 2.5” HDD x1
Indicator
HDD x1
Standard Color
Black
Dimension
149(W) x 185(D) x 43(H) mm; 5.9”(W) x 7.3”(D) x 1.7”(H)
Weight
Net: 0.9 kg (2 lb); Gross: 1.3 kg (2.9 lb)
ENVIRONMENT
EZDRV-400DR
Operating Temperature Range
0 to +55°C
5.25” compact drive bracket with slim type DVDROM, SD/CF reader, 2 USB ports and space for
2.5” HDD
Storage Temperature Range
0 to +70°C
Relative Humidity
5% to 95%, non-condensing
EZDRV-400DRW
5.25” compact drive bracket with slim type DVDRW, SD/CF reader, 2 USB ports and space for
2.5” HDD
Chassis-EZDRV-400 72
ESB Reference Table
MODEL
PEB-2731VLA
PEB-2130
PEB-2131VG2A
PEB-2737VLA
PEB-2738
PEB-2780
PEB-2770
Form Factor
3.5” Floppy-size
3.5" Embedded
3.5" Embedded
3.5" Embedded
3.5" Embedded
3.5" Embedded
3.5" Embedded
Ultra Low Voltage
Intel® Celeron® M
Intel® Celeron® M
Intel® ATOMTM N270
Intel® ATOMTM Z510
/ Z530
Intel® ATOMTM
Z510PT / Z520PT
Intel® ATOMTM
processor N450
852GM + ICH4
910GMLE + ICH6-M
945GSE + ICH7-M
US15W
US15WPT
Intel ICH8M
Intel ICH8M
400MHz
400MHz
533MHz / 667MHz
400MHz / 533MHz
400MHz / 533MHz
1.6GHz
1.6GHz
One SO-DIMM /
1GB
One SO-DIMM /
1GB
One SO-DIMM /
2GB
One SO-DIMM /
2GB
One SO-DIMM /
2GB
One SO-DIMM/2GB
One SO-DIMM/2GB
Memory Chip
Type
DDR
DDR2
DDR2
DDR2
DDR2
DDR2
DDR2
Display
VGA / LVDS / DVO
DVI-I / LVDS
VGA / LVDS
VGA / LVDS
SDVO / LVDS
VGA/18bit LVDS
VGA/18bit LVDS
Expansion
Interface
4 PCI master
expansion via riser
card / One Mini-PCI
socket
One Mini-PCI
Express socket
One Mini-PCI
Express socket
N/A
SDVO (with PCI-E
x1 + USB) connector
/ SDIO / TPM
header
Fast Ethernet x1
GbE x2
GbE x2
GbE x1
GbE x1
Gbe 2
Gbe 2
Serial
RS232 x2
RS232 x1, RS232 /
422 / 485 x1
RS232 x4
RS232 x1, RS232 /
422 / 485 x1
RS232 x1, RS232 /
422 / 485 x1
RS232 3 RS232 /
422 / 485
RS232 3 RS232 /
422 / 485
USB
USB 2.0 x6
USB 2.0 x6
USB 2.0 x7
USB 2.0 x8
USB 2.0 x6
USB 2.0 x6
USB 2.0 x6
N/A
SATA x2
SATA x2
SATA x2
N/A
SATA x2
SATA x2
One 44-pin IDE
connector
N/A
N/A
One 44-pin IDE
connector
One 44-pin IDE
connector
One 44-pin IDE
connector
One 44-pin IDE
connector
Compact Flash
socket x1
Compact Flash
socket x1
Compact Flash
socket x1
Compact Flash
socket x1
Compact Flash
socket x1
Compact Flash
socket x1
Compact Flash
socket x1
N/A
N/A
N/A
N/A
N/A
N/A
N/A
AC'97 2.3
High Definition Audio
2.1 channel
High Definition Audio
2.1 channel
High Definition Audio
2.1 channel
High Definition Audio
2.1 channel
High Definition Audio
2.1 channel
High Definition Audio
2.1 channel
154(W) x 104(L)
mm;
6.07”(W) x 4.13”(L)
146(W) x 102(L)
mm;
5.75”(W) x 4.02”(L)
146(W) x 102(L)
mm;
5.75”(W) x 4.02”(L)
146(W) x 102(L)
mm;
5.75”(W) x 4.02”(L)
146(W) x 102(L)
mm;
5.75”(W) x 4.02”(L)
146(W) x 102(L) mm;
5.75”(W) x 4.02”(L)
146(W) x 102(L) mm;
5.75”(W) x 4.02”(L)
74
75
76
77
78
79
80
CPU
Chipset
FSB
Max Memory
LAN
SATA
IDE
SSD
Parallel
Audio
Dimension
Page
73 ESB-PEB-2731VLA
®
Intel® ATOMTM
processor D510
®
PEB-2731VLA
3.5” Floppy-size, Ultra Low Voltage Intel®
Celeron® M processor based Embedded
Board with VGA, LCD, LAN and Audio
Four USB ports
CompactFlash
socket
PS/2 Keyboard/Mouse
VGA port
Line-out & MIC
Fast Ethernet
+12V single voltage
input
LVDS interface
Mini-PCI connector
Intel® ULV Celeron® M
600MHz / 1G Hz processor
VGA port
Line-out & Mic-in
Intel® ICH4
Support up to 4 PCI devices
via riser card
Four USB ports
DVO interface
Intel® 852GM
Rear I/O
SO-DIMM socket
FEATURES
3.5” compact computing engine equipped with
Ultra Low Voltage Intel® Celeron® M 600MHz/
1GHz processor for fanless requirement
application can be accomplished by
adding Mini-PCI form factor wireless adapter
Fast Ethernet
PS/2 Keyboard/Mouse
GENERAL
Processor
CPU & Package: Ultra Low Voltage Intel® Celeron® M processor
FSB: 400MHz
Chipset/Core Logic
Intel® 852GM and ICH4
System Memory
Up to 1GB DDR 266/200 SDRAM on one 200-pin SODIMM socket
BIOS
Award BIOS
SSD
- One Type II CF socket
- On secondary EIDE channel
Storage Devices
One 44-pin IDE connector
Watchdog Timer
Yes
Expansion Interface
- 4 PCI master expansion via riser card
- One Mini-PCI socket
Hardware Monitoring
Voltage, Fan, Temperature
Power Requirement
+12V only
Dimension
Dimension : 105.0(W) x 154.3(L) mm; 4.13"(W) x 6.07" (L)
Environment
Operating Temperature: 0 to 60oC
Storage Temperature: -20 to 80oC
Relative Humidity: 5% to 90%, non-condensing
Wireless
Display interface cover VGA, LVDS and DVO
to fulfill common graphic needs
Gold finger along short edge of board allows
up to four PCI devices expansion that increases
capability of the platform
+12V powered embedded board makes the
platform smaller and lighter with portable power
adapter
Equipped IrDA port enables wireless platform
remote control
I/O
ORDERING GUIDE
Standard
Optional
PEB-2731VLA
3.5” Floppy-size, Ultra Low Voltage Intel® Celeron® M
600MHz processor based Embedded Board with
VGA, LCD, LAN and Audio
PEB-2731VLA-1G-Z
3.5” Floppy-size, Ultra Low Voltage Intel® Celeron® M
1GHz processor based Embedded Board with
VGA, LCD, LAN and Audio
MIO
RS232 x2
IrDA
Yes (shared with one RS232)
Ethernet
10 BASE-T/100 BASE-TX Fast Ethernet (Intel® 82562EZ)
Audio
AC'97 2.3 Audio
USB
USB 2.0 x 6 (Four ports at rear I/O panel; dual ports internal)
Keyboard & Mouse
PS/2 Keyboard/Mouse
DISPLAY
Graphic Controller
Intel® 852GM mobile optimized graphics controller
Graphic Memory
Dynamically allocates 32/64MB system memory for display
Display Interface
Support VGA, LVDS and DVO ports
ESB-PEB-2731VLA 74
3.5” Embedded size, Intel® Pentium® M or Celeron®
M processor based on Embedded Board with DVI,
LVDS, Dual Gigabit Ethernet, Audio and USB
PEB-2130
Compact Flash socket
DVI-I port
Dual Gigabit Ethernet ports
Four USB ports
LVDS Connector
Intel® Pentium® M (Socket type)
or Celeron® M processor
Intel® ICH6M
Intel® 910 GMLE
Power Connector
Dual Gigabit Ethernet ports
Four USB ports
SO-DIMM Socket
Mini-PCI Express Socket
DVI-I port
SATA Connectors
Rear I/O
FEATURES
SYSTEM
CPU
Intel® Celeron® M or Pentium® M(socket type) processor
Chipset
Intel® 910GMLE and ICH6M
200-pin SO-DIMM supports DDR2 SDRAM
up to 1GB
System Memory
One 200-pin SO-DIMM supports DDR2 400 up to 1GB
BIOS
Award
One Type II Compact Flash and two SATA ports
SSD
Type II CompactFlash socket
Dual independent display: DVI and 18bit LVDS
Storage Devices
One CF socket and two SATA ports
On board dual Gigabit Ethernet
Watchdog Timer
Programmable via S/W from 1 sec. to 255 min.
Expansion Interface
One Mini-PCI Express socket
Hardware Monitoring
- FAN Speed (CPU and System)
- Temperature (CPU and System)
- Voltage (CPU Vcore, VBAT, 5VSB, 12V, 5V, 3.3V)
- Support case open function
Power Requirement
ATX compliant power
Dimension
146(W) x102(L) mm; 5.75”(W) x 4.0”(L)
Environment
Operation temperature: 0~55oC
Storage temperature: -20~80oC
Operation humidity: 5~95%, non-condension
®
®
®
Intel Pentium M or Celeron M in Micro-FCPGA/
FCBGA package
One
Wireless application can be accomplished by adding
Mini-PCI Express form factor wireless adapter
PACKING LIST
ATX
Power cable
heatsink
Utility CD
CPU
x1
x1
x1
ORDERING GUIDE
Standard
Optional
PEB-2130VGA-1000-Z
3.5” ESB based on Intel® Celeron® M 1GHz processor
with DVI / LVDS, LAN, COM, USB and Audio
PEB-2130VGA-600
3.5” ESB based on Intel® Celeron® M 600MHz processor with DVI / LVDS, LAN, COM, USB and Audio
PEB-2130VGA
3.5” ESB based on socket type with DVI / LVDS, LAN,
COM, USB and Audio
QTY
B2900260
1
75 ESB-PEB-2130
SATA x2, RS232 x1 and RS232/422/485(selectable) x1, 8-bit Digital I/O x1
Ethernet
Dual Gigabit Ethernet (Realtek RTL 8111B)
Audio
Mic in, Line out
USB
4 x USB 2.0 ports & 2 x USB 2.0 with header
Keyboard & Mouse
PS/2 Keyboard & Mouse (Header)
DISPLAY
OPTIONAL
Part No.
I/O
MIO
Description
SATA cable
Graphic Controller
Intel® 910GMLE GMA900
Graphic Memory
Intel® DVMT 3.0 supports up to 128MB video memory
Display Interface
DVI (Chrontel 7307C) / 18bit LVDS
PEB-2131VG2A
3.5” Embedded size, based on Intel® AtomTM
N270 Processor with DDR2 SDRAM, Dual
Display by VGA/LVDS, Gigabit Ethernet, Four
Power COM Ports and Audio
Dual Gigabit Ethernet ports
Compact Flash socket
Line-out, Line-in & Mic header
VGA port
Two USB ports
DC In
Line-out
DC 12V Input
24-bit LVDS port
Intel® AtomTM N270
Four COM ports
Dual Gigabit Ethernet ports
Intel® ICH7M
DC in
HDD Power
connector
KB/MS header
Two SATA Ports
®
Intel 945GSE
Two USB ports
Line-out
Mini-PCI Express socket
FEATURES
®
Intel Atom N270 and 945GSE platform that
provides cost effective solution= technology
CF interface provide best cost effective
storage for market
Support one SODIMM socket and up to 2GB
memory size
Mini-PCI Express and power COM ports bring flexible
usage model
Dual Gigabit Ethernet (10/100/1G) with RJ-45
connector
High Definition audio with 2-channel amplifi[email protected]
Low profile rear I/O supports thin client application
CPU
Intel® AtomTM N270 1.6GHz in FCBGA package
FSB: 533MHz
Chipset
Intel® 945GSE and ICH7-M
System Memory
Up to 2GB DDR2 533 SDRAM on one SODIMM socket
BIOS
Award
SSD
CF: Support one Compact Flash socket
Storage Devices
SATA: Support two SATA 150 drives
Watchdog Timer
Programmable via S/W from 1 sec. to 255 min.
Expansion Interface
One Mini-PCI Express socket
Hardware Monitoring
FAN Speed(System), Temerature (CPU and System)
Vcore, 12V, 5V, 3.3V, VBAT
Power Requirement
12V DC In
Dimension
146(L) x102(W) mm; 5.75”(L) x 4.0”(W)
Environment
Operation temperature: 0~60oC
Storage temperature: -20~80oC
Operation humidity: 5~95%, non-condension
PACKING LIST
3
in 1 Heatsink
x1
x1
SATA cable
SATA power
Utility
cable
x1
CD
x1
ORDERING GUIDE
Standard
Rear I/O
SYSTEM
TM
SATA and
VGA port
PEB-2131VG2A
(R). PEB-2131VG2A. ESB. N270. 945GSE. ICH7-M. w/
DDRII SDRAM/VGA/LVDS/Dual GbE/Audio
OPTIONAL
I/O
MIO
Two SATA ports and RS232 x4 with power as pin header type
Ethernet
Two Gigabit Ethernet with RJ45 connectors, IEEE802.3 10/100/1000 BASE-T
Compliant (Realtek RTL 8111D)
Audio
High Definition Audio with Audio Amplifier (one Line-out jack and Line-out/
Line-in/Mic-in header)
USB
USB 2.0 x 2 ports & USB 2.0 with header x5
Keyboard & Mouse
PS/2 Keyboard & Mouse with on board pin header
DISPLAY
Description
Graphic Controller
Intel® 945GSE integrated Graphics Media Accelerator (Intel® GMA 950)
Graphic Memory
Dynamic share system memory up to 224MB (Intel® DVMT 3.0) or static share
System memory up to 128MB
Display Interface
- Support CRT, 18bit/24bit LVDS (Chrontel 7308B-TF), display interfaces
- CRT display resolution up to 2048x1596 @ 85Hz refresh
Part No.
QTY
B6901970
1
USB cable
B7866130
1
COM port cable
ESB-PEB-2131VG2A 76
Intel® 45nm Ultra Low Power AtomTM processor
based ECX embedded board with VGA, LVDS,
Gigabit Ethernet, Audio, USB and SDIO
PEB-2737VLA
VGA port
COM port
GbE port & two USB ports
Audio
PS/2 KB/MS
Two USB ports
Power Connector
LVDS Interface
GPIO ports
Compact Flash Socket
Intel® AtomTM Z510/Z530
processor and System
Controller Hub US15W
GbE port
Two SATA ports
SDIO socket
IDE Connector
Four USB ports
SO-DIMM Socket
FEATURES
One
200-pin SO-DIMM supports DDR2 SDRAM
up to 2GB
One Type II CompactFlash, one IDE & two SATA
ports
Dual independent display: VGA and 24bit LVDS
One Gigabit Ethernet
PACKING LIST
Power cable
CPU heatsink
Utility CD
x1
x1
x1
ORDERING GUIDE
Standard
Optional
PEB-2737VLA-1100
3.5” ESB based on Intel® AtomTM 1.1G processor with
processor with VGA/LVDS, LAN, COM, USB and
Audio
PEB-2737VLA-1600
3.5” ESB based on Intel® AtomTM 1.6G processor with
VGA/LVDS, LAN, COM, USB and Audio
OPTIONAL
Part No.
QTY
B6900262
B690004S
Audio VGA port
Rear I/O
SYSTEM
Intel® AtomTM processor Z510 / Z530 and System
Controller Hub US15W (TDP<
=5W)
ATX
COM port
PS/2 KB/MS
CPU
Intel® Atom processor Z510 / Z530
FSB: 400/533 MHz
Chipset
Intel® System Controller Hub US15W
System Memory
One 200-pin SO-DIMM support DDR2 533/400 up to 2GB
BIOS
AMI
SSD
Type II CompactFlash socket
Storage Devices
One 44-pin IDE connector & two SATA ports
Watchdog Timer
Programmable via S/W from 1 sec. to 255 min
Expansion Interface
N/A
Hardware Monitoring
- Temerature (CPU and System)
- Voltage (CPU Vcore, VBAT, 5VSB, 12V, 5V, 3.3V)
Power Requirement
ATX compliant power
Dimension
102(W) x146(L) mm; 4.01”(W) x 5.74”(L)
Environment
Operation temperature: 0~60oC
Storage temperature: -20~80oC
Operation humidity: 5~95%, non-condension
I/O
MIO
IDE x1, SATA x2, RS232/422/485 x2: One DB9 & one pin header, SDIO x1,
K/B x1, Mouse x1, GbE x1
Ethernet
One Gigabit Ethernet (Realtek RTL 8111C)
Audio
Mic in, Line out
USB
USB 2.0 x 4 ports & USB 2.0 with header x4
DISPLAY
Description
Graphic Controller
Intel® System Control Hub US15W integrated graphics
1
SATA cable
Graphic Memory
Intel® GMA 500
1
IDE cable
Display Interface
VGA (Chrontel 7317A-TF) / 24bit LVDS
77 ESB-PEB-2737VLA
Intel® 45nm Ultra Low Power Menlow-XL processor and chipset based ECX embedded board with
dual display, Audio, USB and SDIO
PEB-2738
COM (RS232/422/485)
HDD Power connector
LVDS port
SDVO & PCIE x 1
connector
Intel® 45nm Ultra LOW
Power Menlow-XL
processor and Chipset
Line-out and Mic-in
Client USB port IDE port
SDIO port
KB/MS header
COM port
FEATURES
Four USB ports
GbE
Rear I/O
SYSTEM
CPU
Intel® AtomTM processor Z510P / Z520PT
Chipset
Intel® System Controller Hub US15WPT
One 200-pin SO-DIMM support DDR2 SDRAM
up to 2GB
System Memory
One 200-pin SO-DIMM support DDR2 533 up to 2GB
BIOS
AMI
SSD
Type II Compact Flash socket
Storage Devices
One 44-pin IDE connector
Watchdog Timer
Programmable via S/W from 1sec. to 255min.
Expansion Interface
- SDVO/PCI-E x1/USB signals on one connector for daughter board
- SDIO header
Dual independent display: SDVO(by VGA/DVI/LVDS
daughter card) and 24bit LVDS
One Gigabit Ethernet
TPM (Trusted Platform Module) could be added on
board (optional)
Customization (Extension card): BTB connector with
SDVO/USB/PCI-E x1 signal and SDIO pin header
Hardware Monitoring
- Temperature (CPU and System)
- Voltage (CPU Vcore, VBAT, 5VSB, 12V, 5V, 3.3V)
Storage: One PATA / One CompactFlash / One USB
Flash / One SDIO
Power Requirement
DC 12V input
Dimension
102(W) x146(L) mm; 4.01”(W) x 5.7”(L)
Environment
- PEB-2738I
Operation temperature: -40~80oC
Storage temperature: -40~80oC
Operation humidity: 5~95%, non-condensing
COM port
Z500PT series and System
Controller Hub US15WPT
Intel® AtomTM processor
DC in
12V DC input
PACKING LIST
CPU
heatsink
CD
x1
x1
Utility
ORDERING GUIDE
Standard
PEB-2738IVA-1100
3.5” ESB based on Intel® AtomTM wide temperature 1.1G
processor with LVDS/SDVO, COM, USB and Audio
Optional
PEB-2738IVA-1300
3.5” ESB based on Intel® AtomTM wide temperature 1.3G
processor with LVDS/SDVO, COM, USB and Audio
I/O
MIO
IDE x1, One RS232/422/485 selectable at rear IO and one RS232 internal,
SDIO pin header x1, SDVO connector x1, Client USB port x1
Ethernet
One RJ45 Gigabit Ethernet (Intel® 82574IT)
Audio
Line-out and Mic-in
USB
USB 2.0 x 4 & USB 2.0 with header x2
Keyboard & Mouse
One K/B & M/S pin header
DISPLAY
OPTIONAL
Part No.
QTY
B6900262
1
Description
IDE cable
AB9-3050Z
1
SDIO daughter board
AB9-3049Z
1
VGA daughter board
Graphic Controller
Intel® System Control Hub US15WPT integrated graphics
Graphic Memory
Intel® GMA 500
Display Interface
24bit LVDS / SDVO
ESB-PEB-2738 78
PEB-2780VG2A
3.5” Embedded size, Based on Intel® 45nm
Low Power Pineview processor with DDR2
SODIMM, dual display by VGA/LVDS, Dual
GbE, Audio, COM and USB
Dual Gigabit Ethernet
12V DC-in
USB x2
CF socket
RS232
VGA
RS232/422/485
GPIO
IDE
TWO RS232
USB x4
SO-DIMM socket
LVDS
Intel® ICH8M
Intel® AtomTM
N450
FEATURES
SYSTEM
CPU
Intel® AtomTM processor N450
200-pin SO-DIMM support DDR2 667 SDRAM
up to 2GB
Chipset
Intel® ICH8M
System Memory
One 200-pin SO-DIMM support DDR2 667 up to 2GB
MPEG2 Decode in HW; independent display: VGA/
18 bit LVDS
BIOS
AMI
SSD
Type II CompactFlash socket
Storage Devices
One 44-pin IDE connector and two SATA ports
Watchdog Timer
Programmable via S/W from 1sec. to 255min.
Expansion Interface
One connector with PCIE x1 signal for daughter board
Hardware Monitoring
- Temperature (CPU and System)
- Voltage (CPU Vcore, VBAT, 5VSB, 12V, 5V, 3.3V)
Power Requirement
12V DC Input
Dimension
146(L) x 105(W) mm; 5.75”(L) x 4.0”(W)
Environment
Operation temperature: 0~60oC
Storage temperature: -20~80oC
Operation humidity: 5~95%, non-condension
®
TM
Intel Atom processor N450 and ICH8M chipset
One
Two SATA
Dual independent display: VGA/18bit LVDS
Dual Gigabit Ethernet
Customization (Extension card): BTB connector
with PCIE x1 signal
Storage: One PATA/One Compact Flash/Two
SATA ports
12V DC input
REAR/IO
Dual Gigabit
CF socket
Ethernet
12V DC-in
VGA
RS232
I/O
USB x2
MIO
One IDE, two SATA ports, four serial ports: One DB9 & three box headers, one
CF socket and one PCIE x1 header
Ethernet
Dual RJ45 Gigabit Ethernet
Audio
High Definition Audio with one Line-out/Mic-in header
USB
2 x USB 2.0 ports and 4 x USB 2.0 with header
Keyboard & Mouse
One K/B & M/S pin header
PACKING LIST
CPU
heatsink
Utility CD
SATA cable
SATA power cable
x1
x1
x1
x1
ORDERING GUIDE
Standard
PEB-2780VG2A
3.5” Embedded size, Based on Intel 45nm Low Power
Pineview processor N450 with DDR2 SODIMM, Dual
display by VGA/LVDS, Dual GbE, Audio, COM and
USB
OPTIONAL
Part No.
QTY
B690004S
1
IDE Cable
B6901970
1
USB Cable
B7866130
1
COM Cable
79 ESB-PEB-2780VG2A
Description
DISPLAY
Graphic Controller
Intel® AtomTM processor (N450) Integrated Intel® DX9 graphics
Graphic Memory
Intel® Dynamic Video Memory Technology 4.0
Display Interface
18bit LVDS/VGA
PEB-2770VG2A
3.5” Embedded size, Based on Intel® 45nm
Low Power Pineview processor with DDR2
SODIMM, dual display by VGA/LVDS, Dual
GbE, Audio, COM and USB
Dual Gigabit Ethernet
12V DC-in
USB x2
CF socket
RS232
VGA
RS232/422/485
GPIO
IDE
TWO RS232
USB x4
SO-DIMM socket
LVDS
Intel® ICH8M
Intel® AtomTM
D510
FEATURES
SYSTEM
CPU
Intel® AtomTM processor D510
200-pin SO-DIMM support DDR2 667 SDRAM
up to 2GB
Chipset
Intel® ICH8M
System Memory
One 200-pin SO-DIMM support DDR2 667 up to 2GB
MPEG2 Decode in HW; independent display: VGA/
18 bit LVDS
BIOS
AMI
SSD
Type II CompactFlash socket
Storage Devices
One 44-pin IDE connector and two SATA ports
Watchdog Timer
Programmable via S/W from 1sec. to 255min.
Expansion Interface
One connector with PCIE x1 signal for daughter board
Hardware Monitoring
- Temperature (CPU and System)
- Voltage (CPU Vcore, VBAT, 5VSB, 12V, 5V, 3.3V)
Power Requirement
12V DC Input
Dimension
146(L) x 105(W) mm; 5.75”(L) x 4.0”(W)
Environment
Operation temperature: 0~60oC
Storage temperature: -20~80oC
Operation humidity: 5~95%, non-condension
®
TM
Intel Atom processor D510 and ICH8M chipset
One
Two SATA
Dual independent display: VGA/18bit LVDS
Dual Gigabit Ethernet
Customization (Extension card): BTB connector
with PCIE x1 signal
Storage: One PATA/One Compact Flash/Two
SATA ports
12V DC input
REAR/IO
Dual Gigabit
CF socket
Ethernet
12V DC-in
VGA
RS232
I/O
USB x2
MIO
One IDE, two SATA ports, four serial ports: One DB9 & three box headers, one
CF socket and one PCIE x1 header
Ethernet
Dual RJ45 Gigabit Ethernet
Audio
High Definition Audio with one Line-out/Mic-in header
USB
2 x USB 2.0 ports and 4 x USB 2.0 with header
Keyboard & Mouse
One K/B & M/S pin header
PACKING LIST
CPU
heatsink
Utility CD
SATA cable
SATA power cable
x1
x1
x1
x1
ORDERING GUIDE
Standard
PEB-2770VG2A
3.5” Embedded size, Based on Intel 45nm Low Power
Pineview processor D510 with DDR2 SODIMM, Dual
display by VGA/LVDS, Dual GbE, Audio, COM and
USB
DISPLAY
Graphic Controller
Intel® AtomTM processor (D510) Integrated Intel® DX9 graphics
Graphic Memory
Intel® Dynamic Video Memory Technology 4.0
Display Interface
18bit LVDS/VGA
OPTIONAL
Part No.
QTY
B690004S
1
Description
IDE Cable
B6901970
1
USB Cable
B7866130
1
COM Cable
ESB-PEB-2770VG2A 80
NANO-8044
Intel® Ultra Low Power AtomTM Processor based
NANO-ITX Board with dual display, Gigabit
Ethernet, Audio, USB and SDIO
FEATURES
Intel® AtomTM processor Z510 / Z530 and System Controller Hub
US15W
One 200-pin SO-DIMM supports DDR2 SDRAM up to 2GB
Dual independent display: VGA and 24bit LVDS
One Type II Compact Flash & one IDE connector
One Intel® Gigabit Ethernet
NANO-8044 takes advantage of the latest Intel® AtomTM
technologies. It supports DDR2 SDRAM, dual displays, one
Gigabit Ethernet and one expansion PCI-Express x1 slot.Base
on leading Intel® AtomTM solution, NANO-8044 is a compact and
ultra low power dissipation board for Medical, Mobile Gaming
and DSS applications.
MECHANICAL & ENVIRONMENTAL
SYSTEM
CPU
Intel® AtomTM processor Z510 / Z530
Operating Temperature
0~55°C
FSB
400/533 MHz
Storage Temperature
-20~80°C
BIOS
AMI BIOS
Operating Humidity
5%~95% non-condensing
System Chipset
Intel® System Controller Hub US15W
Dimension
4.72” x 4.72” (120 mm x 120 mm)
System Memory
One 200pin SO-DIMM support DDR2 400/533MHz up to 2GB
Storage
- 1x 44 pin IDE
- 1 x CF (up to UDMA5 mode)
- 1 x SD
Programmable via S/W from 1sec. to 255sec.
Watchdog Timer
H/W Monitor
GPIO
- Temperature (CPU and System)
- Voltage (CPU Vcore, VBAT, 5VSB, 12V, 5V, 3.3V)
On board programmable 8-bit Digital I/Os
Expansion
One PCI-Express x1 slot
REAR I/O
RS232/422/485
Gigabit Ethernet
On Board I/O
USB
Two USB 2.0 ports, Pitch 2.00mm
Others
One 24 bits LVDS, 8bit GPIO pin header, one SD
VGA
Audio
USB
Rear I/O
Serial Port
One RS232/422/485 port
Display
One VGA (by Chrontel CH 7317A)
Gigabit Ethernet
One RJ-45 LAN port
USB
Four USB 2.0 ports
Audio Interface
Line-out and Mic-in
ORDERING GUIDE
NANO-8044-1100
Intel® AtomTM processor Z510 Nano-ITX Board
NANO-8044-1600
Intel® AtomTM processor Z530 Nano-ITX Board
DISPLAY
Graphic Controller
Display Interface
Intel® System Controller Hub US15W integrated GMA 500
Graphics device
VGA / single channel 24-bit LVDS
81 NANO-ITX-NANO-8044
PER-4110R
One slot PCI-E x1 riser card
Intel® Ultra Low Power AtomTM Processor based
NANO-ITX Board with dual display, Gigabit
Ethernet, Audio, USB and SATA
NANO-8045
FEATURES
Intel® AtomTM processor Z510 / Z530 and System Controller Hub
US15W
One 200-pin SO-DIMM supports DDR2 SDRAM up to 2GB
Dual independent display: DVI-D and 24bit LVDS
One Type II Compact Flash & two SATA ports
One Realtek Gigabit Ethernet
Support DC 12V input
NANO-8045 takes advantage of the latest Intel® AtomTM
technologies. It supports DDR2 SDRAM, dual displays and
one Gigabit Ethernet. Base on leading Intel® AtomTM solution,
NANO-8045 is a compact and ultra low power dissipation board
for Medical, Mobile Gaming and DS applications.
MECHANICAL & ENVIRONMENTAL
SYSTEM
CPU
Intel® AtomTM processor Z510 / Z530
Operating Temperature
0~60°C
FSB
400/533 MHz
Storage Temperature
-20~80°C
BIOS
AMI BIOS
Operating Humidity
5%~95% non-condensing
System Chipset
Intel® System Controller Hub US15W
Dimension
4.72” x 4.72” (120 mm x 120 mm)
System Memory
One 200pin SO-DIMM support DDR2 400/533MHz up to 2GB
Storage
- 2 x SATA II
- 1 x CF (up to UDMA5 mode)
Programmable via S/W from 1sec. to 255sec.
Watchdog Timer
H/W Monitor
GPIO
- Temperature (CPU and System)
- Voltage (CPU Vcore, VBAT, 5VSB, 12V, 5V, 3.3V)
On board programmable 8-bit Digital I/Os
Expansion
N/A
REAR I/O
RS232
Audio
Gigabit Ethernet
On Board I/O
USB
Four USB 2.0 ports, Pitch 2.00mm, one can support client USB
Others
One 24 bits LVDS, 8 bit GPIO pin header, Line-out and Mic-in
pin header
DC 12V
USB
DVI-D
Rear I/O
Serial Port
One RS232 port
Display
One DVI-D (by Chrontel CH7307C)
Gigabit Ethernet
One RJ-45 LAN port
USB
Two USB 2.0 ports
Audio Interface
Line-out and Mic-in
ORDERING GUIDE
NANO-8045-1100
Intel® AtomTM processor Z510 Nano-ITX Board
NANO-8045-1600
Intel® AtomTM processor Z530 Nano-ITX Board
DISPLAY
Graphic Controller
Display Interface
Intel® System Controller Hub US15W integrated GMA 500
Graphics device
DVI-D / single channel 24-bit LVDS
NANO-ITX-NANO-8045 82
NANO-8045L
Intel® Ultra Low Power AtomTM Processor based
NANO-ITX Board with dual display, Gigabit
Ethernet, Audio, USB and SATA
FEATURES
Intel® AtomTM processor Z510 / Z530 and System Controller
Hub US15W
One 200-pin SO-DIMM supports DDR2 SDRAM up to 2GB
Dual independent display: DVI-D and 24bit LVDS
One Type II Compact Flash & two SATA ports
One Realtek Gigabit Ethernet
Support DC 12V input
Only 17mm height for rear I/O
NANO-8045L takes advantage of the latest Intel® AtomTM
technologies. It supports DDR2 SDRAM, dual displays, one
Gigabit Ethernet. Base on leading Intel® AtomTM solution,
NANO-8045L is a compact and ultra low power dissipation
board for Medical, Mobile Gaming and DS applications.
MECHANICAL & ENVIRONMENTAL
SYSTEM
CPU
Intel® AtomTM processor Z510 / Z530
Operating Temperature
0~60°C
FSB
400/533 MHz
Storage Temperature
-20~80°C
BIOS
AMI BIOS
Operating Humidity
5%~95% non-condensing
System Chipset
Intel® System Controller Hub US15W
Dimension
4.72” x 4.72” (120 mm x 120 mm)
System Memory
One 200pin SO-DIMM support DDR2 400/533MHz up to 2GB
Storage
- 2 x SATA II
- 1 x CF (up to UDMA5 mode)
Programmable via S/W from 1sec. to 255sec.
Watchdog Timer
H/W Monitor
GPIO
- Temperature (CPU and System)
- Voltage (CPU Vcore, VBAT, 5VSB, 12V, 5V, 3.3V)
On board programmable 8-bit Digital I/Os
Expansion
N/A
REAR I/O
USB
On Board I/O
USB
Four USB 2.0 ports, Pitch 2.00mm, one can support client USB
Others
One 24 bits LVDS, 8 bit GPIO pin header, Line-out and Mic-in
pin header
Audio
DVI-D
DC 12V
Gigabit Ethernet
Rear I/O
Display
One DVI-D (by Chrontel CH7307C)
Gigabit Ethernet
One RJ-45 LAN port
USB
Two USB 2.0 ports
Audio Interface
Line-out
ORDERING GUIDE
NANO-8045L-1100
Intel® AtomTM processor Z510 Nano-ITX Board
NANO-8045L-1600
Intel® AtomTM processor Z530 Nano-ITX Board
DISPLAY
Graphic Controller
Display Interface
Intel® System Controller Hub US15W integrated GMA 500
Graphics device
DVI-D / single channel 24-bit LVDS
83 NANO-ITX-NANO-8045L
NANO-8050
Leading Intel® latest ULV Mobile SFF 45nm CoreTM
2 Duo or Celeron® M Processor based NANOITX with DDR2 SODIMM, Dual Displays, Gigabit
Ethernet, Audio, USB
FEATURES
Intel® latest Ultra Low Voltage Mobile SFF 45nm CoreTM 2 Duo
or Celeron® M Processor
Intel® GS45 SFF and ICH9M SFF Chipset
One 200-pin SO-DIMM support DDR2 800/667MHz up to 2GB
Dual Display: VGA and 24-bit LVDS
One Intel® Gigabit Ethernet port
One PCI-Express x1 expansion slot
One Type II Compact Flash
Support iTPM function for more secure platforms
NANO-8050 adopts Intel® latest Small Form Factor(SFF) mobile
chipset and takes advantage of leading Intel® latest SFF CoreTM
2 Duo / Celeron® M technologies with high performance. It can
support one DDR2 SODIMM memory, one Intel® Gigabit Ethernet
port, one Type II Compact Flash, and one expansion PCI-Express
MECHANICAL & ENVIRONMENTAL
SYSTEM
FSB
Intel® latest ULV Mobile SFF 45nm CoreTM 2 Duo or Celeron®
M processor
800/1066 MHz
BIOS
AMI BIOS
System Chipset
Intel® GS45 SFF and ICH9M SFF Chipset
System Memory
One 200-pin SO-DIMM support DDR2 800/667MHz up to 2GB
SSD
One Type II Compact Flash (up to UDMA5 mode)
Watchdog Timer
Programmable via S/W from 1sec. to 255sec.
H/W Monitor
GPIO
- Temperature (CPU and System)
- Voltage (CPU Vcore, VBAT, 5VSB, 12V, 5V, 3.3V)
Onboard programmable 8-bit Digital I/Os
Expansion
One PCI-Express x1 slot
CPU
x1 slot. Built in graphic media accelerator (GMA) 4500MHD
graphic engine, NANO-8050 can support 3D performance and dual
display by VGA and LVDS. This is a compact size with low-heat
solution for versatile applications such as Medical and DS.
Operating Temperature
0~60°C
Storage Temperature
-20~80°C
Operating Humidity
5%~95% non-condensing
Dimension
4.72” x 4.72” (120 mm x 120 mm)
REAR I/O
Gigabit Ethernet
RS232/422/485
On Board I/O
USB
Two USB 2.0 ports
SATA
Two SATA 300 ports
Display
One 24 bit LVDS connector
Others
8bit GPIO pin header
VGA
Audio
USB
ORDERING GUIDE
Rear I/O
Serial Port
One selectable RS232/422/485 port
NANO-8050-2260
Display
One VGA
NANO-ITX Board with Intel® CoreTM 2 Duo SP9300 2.26GHz CPU
Ethernet
USB
One 10BASE-T/100BASE-TX/1000BASE-T Ethernet port with
RJ45 connector
Four USB 2.0 ports
Audio Interface
Line-out and Mic-in
NANO-8050-1200
NANO-ITX Board with Intel® CoreTM 2 Duo SU9300 1.2GHz CPU
NANO-8050-C1203
NANO-ITX Board with Intel® Celeron® ULV723 1.2GHz CPU
NANO-8050-C1202
DISPLAY
Graphic Controller
Display Interface
GMCH Integrated Intel® Graphics Media Accelerator (GMA)
4500MHD
- VGA : Up to 2048 x 1536 (QXGA)
- LVDS: Dual channel 24-bit LVDS support
NANO-ITX Board with Intel® Celeron® ULV722 1.2GHz CPU
PER-4110R
One slot PCIEx1 riser card
NANO-ITX-NANO-8050 84
About Mini-ITX
The Mini-ITX form factor, was defined by the chipset manufacturers in Taiwan,
is a highly integrated, all-in-one x86-based embedded computer board that
measures a mere 170mm x 170mm. Its compact size and all-in-one design
simplifies and accelerates the implementation of an embedded PC system.
Portwell's Mini-ITX computer boards and barebones systems offer a wide
selection of microprocessors, power consumption, peripheral I/Os, expansion
and mechanical form factors.
Whether you’re working on medical instruments, thin network devices or digital
media systems, Portwell’s Mini-ITX boards and barebones systems are the perfect solutions to help you to deliver your products on time and stay one step ahead of the competition.
With 15-year experience in the design and manufacture of single board computers, Portwell not only provides onestop shopping for the off-the-shelf products, but also custom-built solutions, tailor-made to suit your needs.
Form factor comparison of embedded computer boards
Form Factor
Board Size (inch/mm)
Expansion
Board Size
(inch2)
L (inch)
W (inch)
L (mm)
W (mm)
PC/104
3.55
3.78
90.17
95.89
Module
13.42
PC/104+
3.55
3.78
90.17
95.89
Module
13.42
STX
3.78
3.55
95.89
90.17
Carrier Board
13.42
ETX
4.49
3.74
114.00
95.00
Carrier Board
16.79
COM Express
4.92
3.74
125.00
95.00
Carrier Board
18.40
3.5” Embedded
5.75
4.02
146.00
102.00
Cables
23.12
3.5” ECX
5.75
4.13
146.00
105.00
Module
23.75
EPIC
6.50
4.53
165.00
115.00
Module
29.45
PICMG 1.3 Half-size
6.60
4.98
167.64
126.39
Backplane
32.87
PCI Half-size
7.28
4.80
185.00
122.00
Backplane
34.94
ISA Half-size
7.28
4.80
185.00
122.00
Backplane
34.94
PICMG 1.2 Half-size
7.52
4.80
191.03
121.92
Backplane
36.10
Mini-ITX
6.69
6.69
170.00
170.00
On Board
44.76
5.25” Embedded
5.75
8.00
146.05
203.20
Cables
46.00
EBX
5.75
8.00
146.05
203.20
Module
46.00
PICMG 1.0 Full-size
13.33
4.80
338.58
121.92
Backplane
63.98
PICMG 1.2 Full-size
13.33
4.80
338.58
121.92
Backplane
63.98
PICMG 1.3 Full-size
13.33
4.98
338.58
126.39
Backplane
66.38
Flex ATX
9.00
7.50
228.60
190.50
On Board
67.50
Micro-ATX
9.60
9.60
243.84
243.84
On Board
92.16
Embedded ATX
9.60
9.60
243.84
243.84
On Board
92.16
ATX
12.00
9.60
304.80
243.84
On Board
115.20
SSI
12.00
13.00
330.20
330.20
On Board
156.00
85 About Mini-ITX
Mini-ITX Reference Table
MODEL
WADE-8067
WADE-8066
WADE-8068
WADE-8046
Form Factor
MINI-ITX
MINI-ITX
MINI-ITX
MINI-ITX
CPU
CoreTM 2 Duo/ Celeron® M
CoreTM 2 Duo/ Celeron® M
CoreTM 2 Duo/ Celeron® M
CoreTM 2 Duo/ CoreTM Solo /
CoreTM Duo and Celeron® M
Chipset
GM45 + ICH9ME
GME965 + ICH8ME
GME965 + ICH8ME
945GME + ICH7-M
FSB
1066/800/667 MHz
800/533 MHz
800/533 MHz
667/ 533 MHz
Max Memory
Two SO-DIMMs / 8GB
Two SO-DIMMs / 4GB
Two SO-DIMMs / 4GB
Two SO-DIMMs / 4GB
Memory Chip
DDR3
DDR2
DDR2
DDR2
Display
VGA / DVI-D / LVDS / HDMI /
TV-OUT
DVI-I / TV-OUT
VGA / LVDS
VGA / LVDS / DVI
Expansion
One PCI-E x4 slot
One PCI slot, One PCI-E x1 slot
with PCI-E x4 interface
One PCI slot, One PCI-E x1 slot
with PCI-E x4 interface
One PCI-E x1 slot, One Mini
PCI socket
LAN
GbE x 2
GbE x 2
GbE x 2
GbE x 2
Serial
RS232 x 1, RS232/422/485 x1
RS232 x 1, RS232/422/485 x1
RS232 x 3, RS232/422/485 x1
RS232 x 3, RS232/422/485 x1
USB
USB 2.0 x 6
USB 2.0 x 8
USB 2.0 x 8
USB 2.0 x 6
SATA
SATA x 4
SATA x 2
SATA x 2
SATA x 2
IDE
N/A
N/A
N/A
One 44pin IDE connector
SSD
N/A
Compact Flash socket x1
Compact Flash socket x1
Compact Flash socket x1
Parallel
N/A
N/A
LPT header x 1
LPT header x 1
Audio
High Definition Audio 2.1 channel
High Definition Audio 5.1 channel
High Definition Audio 5.1 channel
High Definition Audio 5.1 channel
Dimension
6.69” x 6.69”
6.69” x 6.69”
6.69” x 6.69”
6.69” x 6.69”
Page
90
91
92
93
Mini-ITX Reference Table 86
Mini-ITX Reference Table
MODEL
WADE-8065
WADE-8071
WADE-8070
WADE-8072
Form Factor
MINI-ITX
MINI-ITX
MINI-ITX
MINI-ITX
CPU
Core™ 2 Duo/ CoreTM Solo /
Core™ Duo and Celeron® M
Intel® ATOM™ N270 1.6GHz
Intel® ATOM™ N270 1.6GHz
Intel® ATOMTM N270 1.6GHz
Chipset
945GME + ICH7-M
945GSE + ICH7-M
945GSE + ICH7-M
945GSE + ICH7-M
FSB
667/533 MHz
533/667 MHz
533 MHz
533 MHz
Max Memory
Two SO-DIMMs / 4GB
One SO-DIMM/ 2GB
One SO-DIMM / 2GB
One SO-DIMM / 2GB
Memory Chip
DDR2
DDR2
DDR2
DDR2
Display
VGA / LVDS / DVI
VGA/LVDS
VGA / LVDS / DVI
VGA / LVDS
Expansion
One PCI slot
One PCI-Express x1 slot
One PCI-E x1 slot, One Mini
PCI socket
One PCI slot, One PCI-E x1 slot
and One Mini-PCIE socket
LAN
GbE x 3
Gbe x 1
GbE x 2
GbE x 2
Serial
RS232 x 1, RS232/422/485 x1
RS232 x 2
RS232 x 3, RS232/422/485 x1
RS232 x 3, RS232/422/485 x1
USB
USB 2.0 x 6
USB 2.0 x 6
USB 2.0 x 6
USB 2.0 x 6
SATA
SATA x 2
SATA x 2
SATA x 2
SATA x 2
IDE
One 44pin IDE connector
One 44pin IDE Connector
One 44pin IDE connector
One 44pin IDE connector
SSD
Compact Flash socket x1
Compact Flash Socket*1
Compact Flash socket x1
Compact Flash socket x1
Parallel
N/A
N/A
LPT header x 1
LPT header x 1
Audio
High Definition Audio 5.1 channel
High Definition Audio 2.1 channel
High Definition Audio 5.1 channel
High Definition Audio 2.1 channel
Dimension
6.69” x 6.69”
6.69”x 6.69”(170mm x 170mm)
6.69” x 6.69”
6.69” x 6.69”
Page
94
95
96
97
87 Mini-ITX Reference Table
Mini-ITX Reference Table
MODEL
WADE-8170
WADE-8044
WADE-8047
WADE-8180
Form Factor
MINI-ITX
MINI-ITX
MINI-ITX
MINI-ITX
CPU
Intel® ATOMTM N270 1.6GHz
Celeron® M
Celeron® M
Core™ 2 Quad/ CoreT™ 2 Duo
Chipset
945GSE + ICH7-M
910GMLE+ICH6-M
910GMLE+ICH6-M
Q45+ICH10DO
FSB
533 MHz
400 MHz
400 MHz
1333/1066/800 MHz
Max Memory
One SO-DIMM/ 2GB
Two 240pin DIMMs / 2GB
Two 240pin DIMMs / 2GB
Two 240pin DIMMs / 2GB
Memory Chip
DDR2
DDR2
DDR2
DDR3
Display
VGA/DVI-D
VGA / LVDS / DVI (Optional)
Dual VGA / LVDS
VGA/DVI-D
Expansion
One PCI-Express x1 slot
One PCI x1 slot
One PCI x1 slot
One PCI-Express x16 slot
LAN
Gbe x 2
GbE x 2
Fast Ethernet x 2
Gbe x 2
Serial
RS232 x 2
RS232 x 3, RS232/422/485 x1
RS232 x 3, RS232/422/485 x1
RS232 x 2
USB
USB 2.0 x 8
USB 2.0 x 8
USB 2.0 x 8
USB 2.0 x 8
SATA
SATA x 2
SATA x 2
SATA x 2
SATA x 4
IDE
One 44pin IDE Connector
One 44pin IDE connector
One 44pin IDE connector
N/A
SSD
Compact Flash Socket*1
Compact Flash socket x1
Compact Flash socket x1
N/A
Parallel
N/A
LPT header x 1
LPT header x 1
N/A
Audio
High Definition Audio 5.1 channel
High Definition Audio 2.1 channel
High Definition Audio 2.1 channel
High Definition Audio 5.1 channel
Dimension
6.69”x 6.69”(170mm x 170mm)
6.69” x 6.69”
6.69” x 6.69”
6.69”x 6.69”
Page
98
99
100
101
Mini-ITX Reference Table 88
Mini-ITX Reference Table
MODEL
WADE-8056
WADE-8556
WADE-8656
WADE-8055
Form Factor
MINI-ITX
MINI-ITX
MINI-ITX
MINI-ITX
CPU
CoreTM 2 Uuad / CoreTM 2 Duo
/ Pentium® 4 and Celeron® D
CoreTM 2 Uuad / CoreTM 2 Duo
/ Pentium® 4 and Celeron® D
CoreTM 2 Uuad / CoreTM 2 Duo
/ Pentium® 4 and Celeron® D
CoreTM 2 Duo/ Pentium® 4 and
Celeron® D
Chipset
Q965+ICH8DO
Q965+ICH8DO
Q965+ICH8DO
945G + ICH7
FSB
1066 / 800 / 533 MHz
1066 / 800 / 533 MHz
1066 / 800 / 533 MHz
1066 / 800 / 533 MHz
Max Memory
Two 240pin DIMMs / 4GB
Two 240pin DIMMs / 4GB
Two 240pin DIMMs / 4GB
Two SO-DIMMs / 4GB
Memory Chip
DDR2
DDR2
DDR2
DDR2
Display
VGA
VGA / DVI-D
VGA
VGA
Expansion
One PCI x1 slot, One Mini PCI
socket
One PCI x1 slot, One Mini PCI
socket
One PCI x16 slot
One PCI x1 slot
LAN
GbE x 1
GbE x 1
GbE x 2
GbE x 2
Serial
RS232 x 4
RS232 x 4
RS232 x 1, RS232/422/485 x1
RS232 x 1, RS232/422/485 x1
USB
USB 2.0 x 6
USB 2.0 x 6
USB 2.0 x 8
USB 2.0 x 8
SATA
SATA x 4
SATA x 4
SATA x 6
SATA x 4
IDE
N/A
N/A
N/A
N/A
SSD
N/A
N/A
N/A
Compact Flash socket x1
Parallel
N/A
N/A
N/A
N/A
Audio
High Definition Audio 2.1 channel
High Definition Audio 2.1 channel
High Definition Audio 2.1 channel
High Definition Audio 5.1 channel
Dimension
6.69” x 6.69”
6.69” x 6.69”
6.69” x 6.69”
6.69” x 6.69”
Page
102
103
104
105
89 Mini-ITX Reference Table
WADE-8067
Leading Intel® 45nm CoreTM 2 Duo processor or
Celeron® M processor based Mini-ITX with DDR3
SDRAM, HDMI, Dual Gigabit Ethernet, Audio and USB
FEATURES
Intel® CoreTM 2 Duo / Celeron® M processors
Intel® GM45 and ICH9M-E Chipset
Two SO-DIMMs support dual channel DDR3 SDRAM up to
8GB
Dual Display: VGA / DVI / HDMI / LVDS / TV-out, 3rd Display
via PCI-Express graphic card
Support Intel® Active Management Technology 4.0
Integrated latest Trusted Platform Module (iTPM)
Built with latest mobile Intel® GM45 Express chipset, WADE-8067
takes advantage of Intel® CoreTM 2 Duo technologies which has
high performance and excellent power management features.
It not only supports dual display by VGA / DVI / HDMI / LVDS /
TV-out and the third display via PCI-Express expansion slot.
MECHANICAL & ENVIRONMENTAL
SYSTEM
CPU
Intel® CoreTM 2 Duo processor
FSB
667/800/1066MHz
BIOS
AMI BIOS
System Chipset
System Memory
In addition, with its display-enriched interface it can support
various multimedia devices, WADE-8067 is one industrial-grade
embedded Mini-ITX motherboard for POS, Lottery, Medical,
Gaming, DVR, Digital Signage and Kiosk.
®
Intel GM45 and ICH9M-E Chipset
Storage
Two 204pin SO-DIMMs support dual channel DDR3 SDRAM
up to 8GB
4 x SATA
Watchdog Timer
Programmable via S/W from 1sec. to 255min
H/W Monitor
GPIO
FAN Speed(CPU and System), Temperature(CPU and
System),Voltage, Case open function
On board programmable 8-bit Digital I/Os
Expansion
One PCI-E x 4 slot
Power Requirement
Operating Temperature
+12V(CPU) @ 0.53A; +12V(System) @ 0.2A; +5V @ 1.96A;
+3.3V @ 0.16A
0~60°C
Storage Temperature
-20~80°C
Operating Humidity
5~95% non-condensing
Dimension
6.69” x 6.69” (170 mm x 170 mm)
REAR I/O
VGA
RS232/422/485
Gigabit Ethernet
I/O
MIO
1 x RS232, 1 x RS232/422/485, 1 x TV-out header
USB
4 x USB 2.0 ports and 2 x USB 2.0 with header
Audio Interface
Mic-in, Line-in and Line-out, High Definition Audio 2.1 channel
Ethernet Interface
IEEE 802.3 10/100/1000BASE-T Gigabit Ethernet compliant
(Intel® 82567 and 82574L)
RS232
HDMI
DVI-D
USB
Audio
ORDERING GUIDE
WADE-8067PE
Intel® CoreTM 2 Duo and Intel® Celeron® M processor Based Mini-ITX Board with
VGA, DVI, HDMI, TV-out, Dual GbE LAN, Audio and USB
DISPLAY
Chipset
Display Memory
Multi Display
PEP-5A1X1
Intel® GM45 GMCH Integrated Intel® Graphics Media
Accelerator (GMA) 4500MHD
Intel® Dynamic Video Memory Technology (Intel® DVMT 5.0 )
LVDS / DVI-D (Chrontel CH7318B) / HDMI (Chrontel CH7318B)
/ VGA / TV-out
One PCI-E x4 riser card
B6931170
Active cooler
Mini-ITX-WADE-8067 90
WADE-8066
Leading Intel® CoreTM 2 Duo processor based MiniITX Board with DDR2 SDRAM, Dual Displays, Two
GbE LAN ports, Audio and USB
FEATURES
Intel® CoreTM 2 Duo and Celeron® M processor
Intel® GME965 and ICH8ME chipset
Two 200pin SO-DIMMs support dual channel DDR2
SDRAM up to 4GB
Dual Display :DVI-I / LVDS / TV-Out, 3rd Display via
expansion slot
One PCI slot and one PCI-E x 1 slot with PCI-E x 4
signal
Built with Intel® latest mobile chipset GME965, WADE-8066
takes advantage of Intel® CoreTM 2 Duo technologies. The
graphic media accelerator X3100 provides both fast video
response time and high quality images via the two-channel
MECHANICAL & ENVIRONMENTAL
SYSTEM
FSB
Intel® CoreTM 2 Duo and Intel® Celeron® M processor
(Socket P)
FSB 800/533 MHz
BIOS
Award BIOS
System Chipset
Intel® GME965 and ICH8ME Chipset
System Memory
SSD
Two 200pin SO-DIMMs support dual channel DDR2 SDRAM
up to 4GB
2 x Serial ATA connector high-speed data transfers at up to
3 Gb/s
1 x Compact Flash
Watchdog Timer
Reset; 1 sec.~255 min. and 1 sec. or 1 min./step
H/W Status Monitor
GPIO
Monitoring system temprature, voltage, and cooling fan
status. Auto throttling control when CPU overheats
On-board programmable 16 Digital I/O interface
Expansion
One PCI slot and One PCI-E x 1 slot (with PCI-E x 4 signal)
CPU
Storage
memory architecture. WADE-8066 supports dual display
by VGA, DVI, LVDS and TV-Out. With its display-enriched
interface, WADE-8066 can support various multimedia devices.
Power Requirement
+12V(System) @ 2.59A; +5V @ 2.96A; +3.3V @ 1.31A
Operating Temperature
0~55°C
Operating Humidity
0%~90% relative humidity, noncondensing
Size (L x W)
6.69” x 6.69” (170 mm x 170 mm)
Weight
0.94 lbs (0.43 Kg)
REAR I/O
Gigabit Ethernet
KB/MS
I/O
MIO
1 x RS232, 1 x RS232/422/485 selectable, 1 x K/B, 1 x Mouse
IrDA
IrDA 1.0
USB
4 x USB 2.0 ports and 4 x USB 2.0 with header
Audio Interface
Mic in, Line in, Line out, High Definition Audio 5.1 channel
Ethernet Interface
IEEE 802.3 10/100/1000BASE-T Gigabit Ethernet compliant
(Intel® 82566MM and Mavell88E8053)
RS232
DVI-I
WADE-8066
Intel® CoreTM 2 Duo and Celeron® M processors Main Board with
DVI, Audio, GbE LANs, 8 x USB 2.0
DISPLAY
Intel® GME965 Integrated GMA x3100 Graphics device
PEP-581R/582R
Display Memory
Intel®
One/Two slots PCI riser card
Resolution
Analog Display: Up to 2048 x 1536 (QXGA)
Digital DVI Display: Up to 1600 x 1200 (UXGA)
24-bit, dual Channel LVDS / TV-out / VGA / DVI (Silicon Image
SiI 1362)
DVMT 4.0 supports up to 384 MB video memory
PEP-592R
One PCI and one PCI-E x4 slot riser card
PER-4210R
One slot PCI-E x4 riser card
B9970540
1U active heatsink
91 Mini-ITX-WADE-8066
Audio
ORDERING GUIDE
Chipset
Multi Display
USB
WADE-8068
Leading Mobile Intel® CoreTM 2 Duo Processor Mini-ITX
with DDR2 SDRAM, Dual Displays, Two GbE LAN ports,
Four COM Ports, LPT and USB
FEATURES
Intel® CoreTM 2 Duo and Celeron® M processors
Intel® GME965 and ICH8M-E Chipset
Two 200-pin SO-DIMMs support dual channel DDR2 SDRAM
up to 4GB
Dual Display: VGA / 24bit LVDS, 3rd Display via expansion
slot Dual Gigabit Ethernet ports
Two SATA ports and One Type II Compact Flash
One PCI slot and one PCI-E x 1 slot with PCI-E x 4 signal
Three RS232 ports and one RS232/422/485 port
The WADE-8068 built with Intel® mobile GME965 chipset and
takes advantage of Intel® CoreTM 2 Duo technologies that can
support dual channel DDR2 memory, two Gigabit Ethernet
ports, one expansion PCI-Express x1 slot and one PCI slot.
Base on integrated graphic media accelerator (GMA) X3100
MECHANICAL & ENVIRONMENTAL
SYSTEM
FSB
Intel® CoreTM 2 Duo and Intel® Celeron® M processor
(Socket P)
800/533 MHz
BIOS
Award BIOS
System Chipset
Intel® GME965 & ICH8ME Chipset
System Memory
SSD
Two 200-pin SO-DIMM support dual channel DDR2 SDRAM up
to 4GB
2 xSerial ATA connector high-speed data transfers at up to
3Gb/s
1 x Compact Flash
Watchdog Timer
Programmable via S/W from 1sec. to 255min.
H/W Monitor
GPIO
FAN Speed(CPU and System), Temperature(CPU and System),
Voltage, Case open function
On board programmable 16-bit Digital I/Os
Expansion
One PCI slot and one PCI-E x 1 slot (with PCI-E x 4 signal)
CPU
Storage
graphic device, WADE-8068 can support high 3D performance
dual display by VGA and LVDS. With enriched serial ports make
WADE-8068 can be adopted for diversity applications such as
Panel PC, Lottery, Medical, Gaming and Digital Signage.
Power Requirement
+12V(System) @ 2.66A; +5V @ 3.74A; +3.3V @ 0.83A
Operating Temperature
0~55°C
Operating Humidity
5%~95% noncondensing
Size (L x W)
6.69” x 6.69” (170 mm x 170 mm)
Weight
0.94 lbs (0.43 Kg)
REAR I/O
KB/MS
Gigabit Ethernet
RS232/422/485
I/O
MIO
USB
1 x LPT, 3 x RS232 port, 1 x RS232/422/485 selectable, 1 x K/B,
1 x Mouse
4 x USB 2.0 ports and 4 x USB 2.0 ports with header
Audio Interface
Mic-in, Line-out, High Definition Audio 5.1 channel
Ethernet Interface
IEEE 802.3 10/100/1000BASE-T Gigabit Ethernet compliant
(Intel® 82566MM and Realtek 8111C)
RS232
VGA
USB
Audio
ORDERING GUIDE
WADE-8068
Intel® CoreTM 2 Duo and Intel® Celeron® M processor Based Mini-ITX Board with
VGA, 24-bit LVDS, Dual GbE LAN, Four COM Ports and Eight USB 2.0 Ports
DISPLAY
Chipset
Intel® GME965 GMCH Integreated Intel® GMA x3100
PEP-581R/582R
Display Memory
Intel® DVMT 4.0 supports up to 384MB video memory
One/Two slots PCI riser card
Resolution
Analog Display: Up to 2048 x 1536 (QXGA)
Digital LVDS: Up to 1600 x 1200 (UXGA)
24bit, dual channel LVDS / VGA
PEP-592R
Multi Display
One PCI and one PCI-E x4 slot riser card
PER-4210R
One slot PCI-E x4 riser card
B9970540
1U active heatsink
Mini-ITX-WADE-8068 92
WADE-8046
Intel® CoreTM 2 Duo processor based Mini-ITX Board
with DDR2 SDRAM, VGA/ LVDS / DVI, Gigabit Ethernet,
Audio and USB
FEATURES
Intel® CoreTM 2 Duo / CoreTM Duo / Celeron® M processor
Intel® 945GME and ICH7-M chipset
Two 200-pin SO-DIMMs support dual channel DDR2 SDRAM
up to 4GB
Dual display: VGA / LVDS / DVI, 3rd display via PCI-Express x
1graphic card
One PCI-Express x 1 expansion slot and one Mini PCI socket
One Compact Flash socket & high definition audio
WADE-8046 is a high performance Mini-ITX embedded board for
applications that need dual channel DDR2 memory, two Gigabit
Ethernet ports, one expansion PCI-Express x1 slot and one
Mini PCI socket. Built in Intel® 945GME and ICH7-M chipset, it
MECHANICAL & ENVIRONMENTAL
SYSTEM
CPU
Intel® CoreTM 2 Duo / CoreTM Duo / Celeron® M processor
FSB
533/667 MHz
BIOS
Award BIOS
System Chipset
Intel® 945GME GMCH and ICH7-M
System Memory
Storage
SSD
Watchdog Timer
H/W Status Monitor
takes advantage of Intel® CoreTM 2 Duo / CoreTM Duo / Celeron®
M processor. WADE-8046 can provide triple display for diversity
applications such as Lottery, Medical, Gaming and Digital
Signage.
Two 200pin SO-DIMM support dual channel DDR2 SDRAM up
to 4GB
- 2 x SATA
- 1 x 44 pin IDE connector
1 x Compact Flash share the same channel with IDE and
support UDMA
Programmable via S/W from 1sec. to 255min
GPIO
FAN Speed(CPU and System), Temperature(CPU and System),
Voltage, Case open function
Onboard programmable 8-bit Digital I/Os
Expansion
1 x PCI-Express x1 slot, 1 x Mini PCI socket
Power Requirement
Operating Temperature
+12V(CPU) @ 1.33A; +12V(System) @ 0.33A; +5V @ 1.74A;
+3.3V @ 0.72A
0~60°C
Storage Temperature
-20~80°C
Operating Humidity
5~95% non-condensing
Size (L x W)
6.69” x 6.69” (170 mm x 170 mm)
REAR I/O
RS232/422/485
VGA
Gigabit Ethernet
I/O
MIO
Two RS232 ports, one Parallel port
IrDA
N/A
USB
4 x USB 2.0 ports and 2 x USB 2.0 ports with header
Audio Interface
Line-out , Line-in and Mic-in
Ethernet Interface
IEEE 802.3 10/100/1000BASE-T Gigabit Ethernet compliant
(Realtek 8111C)
KB/MS
RS232
DVI-D
USB
Audio
ɈDVI-I connector support DVI-D signal only
ORDERING GUIDE
DISPLAY
Chipset
Display Memory
Resolution
Multi Display
93 Mini-ITX-WADE-8046
- Intel® 945GME GMCH Integrated
- Intel® GMA 950 graphics
Intel® DVMT 3.0 supports up to 224MB video memory
Analog Display: Up to 2048 x 1536 (QXGA)
Digital LVDS: Up to 1600 x 1200 (UXGA)
Digital DVI: Up to 1600 x 1200 (UXGA)
Dual Channel 18-bit LVDS / VGA / DVI (Chrontel CH7307)
WADE-8046
Intel® CoreTM 2 Duo / CoreTM Duo / Celeron® M processors Mini-ITX Board
PEP-5B1X1
One PCI-E x1 riser card
B9970542
Active cooler
WADE-8065
Network Enriched Intel® CoreTM 2 Duo Processor based
Mini-ITX Board with Dual Displays, Three GbE LAN
ports, Audio and USB
FEATURES
Intel® CoreTM 2 Duo / CoreTM solo / CoreTM Duo and Celeron® M
processors
Intel® 945GME and ICH7-M Chipset
Two 200-pin SO-DIMMs support dual channel DDR2 SDRAM
up to 4GB
Dual Display: VGA / DVI / LVDS, 3rd Display via expansion slot
Three Intel® Gigabit Ethernet
WADE-8065 is a network bandwidth-enriched solution. With a
low power consumption mobile processor, it not only provides
more than adequate computing power, but also eliminates any
heat issues. Dual video outputs are supported by two-channel
MECHANICAL & ENVIRONMENTAL
SYSTEM
CPU
Intel® CoreTM 2 Duo / CoreTM Duo / CoreTM Solo processor
FSB
667/533 MHz
BIOS
Award BIOS
System Chipset
Intel® 945GME and ICH7-M Chipset
System Memory
SSD
2 x 200-pin dual channel DDR2 SDRAM DIMM 667/533 MHz
support up to 4GB
- 1 x IDE
- 2 x SATA
1 x Compact Flash
Watchdog Timer
Reset:1 sec.~255 min. and 1 sec. or 1 min./step
H/W Status Monitor
GPIO
Monitoring system temperature, voltage, and cooling fan
status. Auto throttling control when CPU overheats
On-board programmable 8-bit Digital I/O interface
Expansion
1 x PCI slot
Storage
memory structure that enhances graphic performance. Three
GbE LAN ports provide the wide bandwidth necessory for
communication or network related applications. WADE-8065 is the
preferred choice where high price/performance ratio is a criterion.
Power Requirement
Operating Temperature
+12V(CPU) @ 1.16A; +12V(System) @ 0.32A; +5V @ 1.58A;
+3.3V @ 0.74A
0~55°C
Operating Humidity
0%~90% relative humidity, noncondensing
Size (L x W)
6.69” x 6.69” (170 mm x 170 mm)
Weight
0.94 lbs (0.43 Kg)
REAR I/O
RS232/422/485
Gigabit Ethernet
VGA
I/O
MIO
USB
1 x RS232, 1 x RS232/422/485 selectable, 1 x K/B, 1 x Mouse,
3 x GbE
2 x USB 2.0 ports and 4 x USB 2.0 with header
Audio Interface
Mic-in, Line-in, Line-out, High Definition Audio 5.1 channel
Ethernet Interface
IEEE 802.3 10/100/1000BASE-T Gigabit Ethernet compliant
(Intel® 82574L)
KB/MS
RS232
DVI-D
USB
Audio
ɈDVI-I connector support DVI-D signal only
ORDERING GUIDE
WADE-8065
Intel® CoreTM 2 Duo processor Mini-ITX Board with VGA, LCD, Audio,
three GbE LANs and 6 USB 2.0 ports
DISPLAY
Chipset
Intel® 945GME Integreated Intel® GMA 950 graphics
PEP-581R/582R
Display Memory
Integrated Intel® Graphics Media Accelerator GMA 950, and
share system memory to 224 MB
Analog Display Port: QXGA 2048 x 1536
Digital LVDS Port: UXGA 1600 x 1200
18-bit, dual Channel LVDS / VGA / DVI (Chrontel CH7307)
One/Two slots PCI riser card
Resolution
Multi Display
B9970540
1U active cooler
Mini-ITX-WADE-8065 94
WADE-8071
Intel® Low Power AtomTM N270 1.6GHz Processor based
Mini-ITX Board with DC12V input, dual display, Gigabit
Ethernet, Two SATA Ports, Two COM ports and Six USB
Ports support thin client application
FEATURES
Intel® ATOMTM N270 1.6GHz processor
Intel® 945GSE and ICH7-M chipset
One 200-pin SO-DIMM supports single channel DDR2
SDRAM up to 2GB
Dual display: VGA / LVDS, 3rd display via PCI-Express
x1 graphic card
One PCI-Express x1 expansion slot
12V DC Input
20mm height supports thin client application
Built with Intel® mobile 945GSE chipset, WADE-8071 takes
advantage of Intel® AtomTM N270 technologies. WADE-8071
features with its low power and also can provide dual displays
such as LVDS and VGA. In addition, WADE-8071 has one SODIMM
socket which supports DDR2 SDRAM, one Gigabit Ethernet, two
RS232 serial ports, two SATA, six USB ports and
one PCI-Express x1 expansion slot. WADE-8071 is not only a
suitable choice for fanless and low profile usage but also the best
solution for POS, Medical, Gaming and Digital Signage applications.
MECHANICAL & ENVIRONMENTAL
SYSTEM
CPU
Intel® AtomTM N270 1.6GHz processor
Power Requirement
DC Input
FSB
533/667 MHz
Operating Temperature
0~60°C
BIOS
Award BIOS
DC Input
10%~90% non-condensing
System Chipset
Intel® 945GSE GMCH and ICH7-M
Dimension
6.69’’ x 6.69’’ (170mm x 170mm)
System Memory
One 200-pin SO-DIMM supports single channel
DDR2 SDRAM up to 2GB
Storage
2 x SATA, 1 x IDE
SSD
1 x Compact Flash share the same channel with IDE
and support UDMA
Watchdog Timer
Programmable via S/W from 1sec. to 255min.
H/W Status Monitor
FAN Speed(CPU and System), Temperature
(CPU and System),Voltage, Case open function
GPIO
Onboard programmable 8-bit Digital I/Os
Expansion
1 x PCI-Express slot
REAR I/O
Gigabit Ethernet
I/O
MIO
1 x IDE, 2 x RS232 ports, 1x K/B, 1 x Mouse, 1 x CF
USB
4 x USB 2.0 ports and 2 x USB 2.0 with header
Audio Interface
Mic-in, Line-out
Ethernet Interface
IEEE 802.3 10/100/1000 BASE-T Gigabit Ethernet compliant
DC
RS232
VGA
USB
Audio
ORDERING GUIDE
DISPLAY
Chipset
Intel® 9945GSE GMCH Integrated Intel® GMA 950 graphics
Display Memory
Intel® DVMT 3.0 share system memory up to 128MB
WEDE-8071
Multi Display
- Analog Display: Up to 2048 x 1536 (QXGA)
- Digital LVDS: Up to 1600 x 1200(UXGA)
Dual Channel 18-bit and 24-bit output
Intel® Low Power AtomTM N270 1.6GHz Processor based MiniITX Board with DC12V input, dual display, Gigabit Ethernet, Two
SATA Ports, Two COM ports and Six USB Ports support thin client
application.
LVDS
95 Mini-ITX-WADE-8071
WADE-8070
Intel® Low Power AtomTM N270 1.6GHz Processor
based Mini-ITX Board with dual display, Gigabit
Ethernet, Two SATA Ports, Four COM ports and Six
USB Ports
FEATURES
Intel® AtomTM N270 1.6GHz processor
Intel® 945GSE and ICH7-M chipset
One 200-pin SO-DIMM supports single channel DDR2
SDRAM up to 2GB
Dual display: VGA / LVDS / DVI, 3rd display via PCI-Express x1
graphic card
One Mini-PCI and one PCI-Express x1 expansion slot
Two SATA, one Compact Flash socket & one IDE connector
Built with Intel® mobile 945GSE chipset, WADE-8070 takes advantage
of Intel® AtomTM N270 technologies. WADE-8070 features with its
low power and also can provide multiple displays such as LVDS,
VGA and DVI. In addition, WADE-8070 has one SO-DIMM socket
which supports DDR2 SDRAM, dual Gigabit Ethernet, two RS232
SYSTEM
MECHANICAL & ENVIRONMENTAL
CPU
Intel® AtomTM N270 1.6GHz processor
FSB
533 MHz
BIOS
Award BIOS
System Chipset
Intel®
System Memory
Storage
SSD
Watchdog Timer
H/W Status Monitor
serial ports, two SATA, one Mini PCI socket and one PCI-Express x1
expansion slot. WADE-8070 is not only a suitable choice for fanless
usage but also the best solution for POS, Medical, Gaming and Digital
Signage applications.
945GSE GMCH and ICH7-M Chipset
One 200-pin SO-DIMM supports single channel DDR2 SDRAM
up to 2GB
- 2 x SATA
- 1 x IDE
1 x Compact Flash share the same channel with IDE and support
UDMA
Programmable via S/W from 1sec. to 255min
GPIO
FAN Speed(CPU and System), Temperature(CPU and System),
Voltage, Case open function
Onboard programmable 8-bit Digital I/Os
Expansion
1 x Mini-PCI socket, 1 x PCI-Express x1 slot
Power Requirement
Operating Temperature
+12V(CPU) @ 0.17A; +12V(System) @ 0.24A; +5V @ 1.31A;
+3.3V @ 0.55A
0~60°C
Operating Humidity
10%~90% non-condensing
Size (L x W)
6.69” x 6.69” (170 mm x 170 mm)
REAR I/O
RS232/422/485
KB/MS
Gigabit Ethernet
Audio
VGA
I/O
MIO
USB
1 x EIDE, 3 x RS232 port, 1x K/B, 1 x Mouse,
1 x RS232/422/485 selectable
4 x USB 2.0 ports and 2 x USB 2.0 with header
Audio Interface
Mic in and Line-out, High Definition Audio 5.1 channel
Ethernet Interface
IEEE 802.3 10/100/1000BASE-T Gigabit Ethernet compliant
(Realtek 8111C)
RS232
DVI-D
USB
ɈDVI-I connector support DVI-D signal only
ORDERING GUIDE
WADE-8070
Intel® AtomTM N270 1.6GHz processor based Mini-ITX Board with VGA, 18bit LVDS, DVI,
Dual LAN, Four COM Ports and Six USB 2.0 Ports
DISPLAY
Chipset
Intel® 945GSE GMCH Integrated Intel® GMA 950 graphics
PEP-5B1X1
Display Memory
Intel® DVMT 3.0 share system memory up to 128MB
One PCI-E x1 riser card
Resolution
Analog Display: Up to 2048 x 1536 (QXGA)
Digital LVDS: Up to 1600 x 1200(UXGA)
18-bit, dual Channel LVDS / VGA / DVI-D (Chrontel CH7307)
Multi Display
Mini-ITX-WADE-8070 96
WADE-8072
Intel® Low Power AtomTM N270 1.6GHz Processor
based Mini-ITX Board with dual display, Gigabit
Ethernet, Two SATA Ports, Four COM ports and Six
USB Ports
FEATURES
Intel® AtomTM N270 1.6GHz processor
Intel® 945GSE and ICH7-M chipset
One 200-pin SO-DIMM supports single channel DDR2
SDRAM up to 2GB
Dual display: VGA / LVDS, 3rd display via expansion slot
Two SATA, one Compact Flash socket & one IDE connector
One PCI slot, one PCI-E x1 expansion slot and one Mini-
PCIE socket
Three RS232 ports and one RS232/422/485 port
Built with Intel® mobile 945GSE chipset, WADE-8072 takes advantage
of Intel® AtomTM N270 technologies. WADE-8072 features with its low
power and also can provide dual displays such as VGA and 24-bit
LVDS. In addition, WADE-8072 has one SO-DIMM socket which
supports DDR2 SDRAM, dual Gigabit Ethernet, four serial ports, two
SYSTEM
MECHANICAL & ENVIRONMENTAL
CPU
Intel® AtomTM N270 1.6GHz processor
FSB
533 MHz
BIOS
Award BIOS
System Chipset
Intel® 945GSE GMCH and ICH7-M Chipset
System Memory
One 200-pin SO-DIMM supports single channel DDR2 SDRAM
up to 2GB
- 2 x SATA
- 1 x IDE
1 x Compact Flash share the same channel with IDE and support
UDMA 5 (At bottom side board edge)
Programmable via S/W from 1sec. to 255min.
Storage
SSD
Watchdog Timer
H/W Status Monitor
GPIO
Expansion
SATA, one LPT, one PCI slot and one PCI-Express x1 expansion.
WADE-8072 is not only a suitable choice for fanless usage but also
the best solution for Mobile POS, Medical, Industrial Control and
Digital Signage applications.
Power Requirement
Operating Temperature
+12V(System) @ 0.35A; +5V(System) @ 2.44A; +3.3V(System)
@ 0.82A
0~60°C
Operating Humidity
5%~95% non-condensing
Size (L x W)
6.69” x 6.69” (170 mm x 170 mm)
REAR I/O
RS232/422/485
Gigabit Ethernet
KB/MS
FAN Speed(CPU and System), Temperature(CPU and System),
Voltage, Case open function
Onboard programmable 8-bit Digital I/Os
- 1 x PCI slot and one PCI-E x 1 slot
- 1 x TPM pin header
- 1 x Mini-PCIE socket
RS232
VGA
USB
Audio
I/O
MIO
USB
1 x IDE, 1 x LPT, 3 x RS232 ports, 1 x RS232/422/485 selectable,
1 x K/M, 1 x Mouse
4 x USB 2.0 ports and 2 x USB 2.0 with header
Audio Interface
Mic-in, Line-out
Ethernet Interface
IEEE 802.3 10/100/1000BASE-T Gigabit Ethernet compliant
(Realtek 8111D)
SOLDER SIDE
CF socket on board edge
DISPLAY
Chipset
Intel® 945GSE GMCH Integrated Intel® GMA 950 graphics
Display Memory
Intel® DVMT 3.0 share system memory up to 128MB
Resolution
Analog Display: Up to 2048 x 1536 (QXGA)
Digital LVDS: Up to 1600 x 1200(UXGA)
Dual Channel 24-bit output (Chrontel CH7308B) / VGA
Multi Display
Mini-PCIE socket
ORDERING GUIDE
WADE-8072
Intel® Low Power AtomTM N270 1.6GHz processor based Mini-ITX Board with dual display,
Gigabit Ethernet, Two SATA ports, Four COM ports and Six USB ports
97 Mini-ITX-WADE-8070
WADE-8170
Intel® AtomTM N270 Processor based Mini-ITX Board
with Dual Display, Dual Gigabit Ethernet, Two SATA
Ports, Two COM ports and Eight USB Ports
FEATURES
Intel® ATOMTM N270 1.6GHz processor
Intel® 945GSEand ICH7-M chipset
12V, 15V~24V DC Power Input
One 200-pin SO-DIMM supports single channel DDR2
SDRAM up to 2GB
Dual display: VGA / LVDS / DVI / TV-Out , 3rd display via
riser card
One PCI expansion slot (Two PCI & one PCI-Expansion x
1 slots via riser card)
Two SATA, one Compact Flash socket & one IDE
connector
Built with Intel® mobile 945GSE chipset, WADE-8170 takes
advantage of Intel® AtomTM N270 technologies. WADE-8170
features with its low power and also can provide multiple
displays such as LVDS, VGA, TV-out and DVI. In addition,
WADE-8170 has one SO-DIMM socket which supports DDR2
SYSTEM
SDRAM, dual Gigabit Ethernet, two RS232 serial ports, two
SATA, One PCI expansion slot (Two PCI & one PCI-Expansion
x 1 slots via riser card). Base on 12V & 15V~24V DC power
input design, WADE-8170 can be best solution for POS,
Medical, Gaming and Digital Signage applications.
MECHANICAL & ENVIRONMENTAL
CPU
Intel® AtomTM N270 1.6GHz processor
Power Requirement
DC Input
FSB
533 MHz
Operating Temperature
0~60°C
BIOS
Award BIOS
Operating Humidity
5%~95% non-condensing
System Chipset
Intel® 945GSE GMCH and ICH7-M
Size (L x W)
6.69’’ x 6.69’’ (170mm x 170mm)
System Memory
One 200-pin SO-DIMM supports single channel DDR2 SDRAM
up to 2GB
- 2 x SATA
- 1 x 40 pin IDE
1 x Compact Flash share the same channel with IDE and
support UDMA
Programmable via S/W from 1sec. to 255min.
Storage
SSD
Watchdog Timer
H/W Status Monitor
GPIO
FAN Speed(CPU and System), Temperature(CPU and System),
Voltage, Case open function
Onboard programmable 8-bit Digital I/Os
Expansion
1 x PCI slot, 1 x PCI-Ex1 slot through Riser card
REAR I/O
Gigabit Ethernet
VGA
RS232
DVI
RS232
I/O
MIO
IrDA
1 x EIDE, 2 x RS-232 ports, 1 x K/B, 1 x Mouse,
1 x S-Video header
N/A
USB
4 x USB 2.0 ports and 4 x USB 2.0 with header
Audio Interface
Mic-in, Line-out, Line-in
Ethernet Interface
IEEE 802.3 10/100/1000BASE-T Gigabit Ethernet compliant
KB/MS
USB
Audio
ORDERING GUIDE
WEDE-8170
Intel® AtomTM N270 1.6GHz processor Based Mini-ITX Board with VGA,
18bit LVDS, DVI, Dual LAN, Two COM Ports and Eight USB 2.0 Ports
DISPLAY
* Specifications are subject to change without notice.
Chipset
Intel® 945GSE GMCH Integrated Intel® GMA 950 graphics
Display Memory
Intel® DVMT 3.0 share system memory up to 128MB
Resolution
LVDS
-Analog Display: Up to 2048 x 1536 (QXGA)
-Digital LVDS: Up to 1600 x 1200(UXGA)
-Digital DVI: Up to 1600 x 1200(UXGA)
Dual Channel 18-bit
DVI
DVI-D interface
* Intel® ATOMTM processor is registered trademarks of Intel® Corporation.
* Other trademarks, logo, brands and company names are the property of
their respective owners.
Mini-ITX-WADE-8072 98
WADE-8044
Ultra Low Voltage Intel® Celeron® M Processor Mini-ITX
with DDR2 SDRAM, Dual Displays, Four COM Ports
and USB
FEATURES
Intel® Pentium® M / Celeron® M processor
Intel® 910GMLE and ICH6-M chipset
Two 240-pin DIMMs support dual channel DDR2 SDRAM
up to 2GB
Dual Display: VGA / 18bit LVDS
Dual Gigabit Ethernet ports and one PCI slot
One Type II Compact Flash, Four COM Ports and Eight
USB Ports
The WADE-8044 is cost effective Mini-ITX embedded board for
applications that need Dual channel DDR2 memory, Dual Gigabit
Ethernet ports and expansion PCI slot. With low power Intel®
Pentium® M / Celeron® M processor and Intel® 910GMLE and
ICH6-M chipset, WADE-8044 not only is a fanless solution but
also can provide dual displays for diversity applications such as
Lottery, Medical, Gaming and Digital Signage.
MECHANICAL & ENVIRONMENTAL
SYSTEM
CPU
Intel® Pentium® M / Celeron® M processor
Power Requirement
+12V(System) @ 0.48A; +5V @ 2.85A; +3.3V @ 0.63A
FSB
400 MHz
Operating Temperature
0~55°C
BIOS
Award BIOS
Operating Humidity
5%~95%, noncondensing
System Chipset
Intel® 910GMLE GMCH and ICH6-M
Size (L x W)
6.69” x 6.69” (170 mm x 170 mm)
System Memory
Two 240-pin DIMMs support dual channel DDR2 SDRAM up
to 2GB
- 2 x SATA
- 1 x IDE
1 x Compact Flash share the same channel with IDE and
support UDMA
Programmable via S/W from 1sec. to 255min.
Weight
0.94 lbs (0.43 Kg)
Storage
SSD
Watchdog Timer
H/W Status Monitor
GPIO
FAN Speed (CPU and System), Temperature (CPU and
System), Voltage, Case open function
On-board programmable 8-bit Digital I/O interface
Expansion
1 x PCI slot
REAR I/O
RS232
VGA
Gigabit Ethernet
I/O
MIO
1 x EIDE, 1 x LPT, 3 x RS232 port, 1 x RS232/422/485
selectable, 1 x K/B, 1 x Mouse
IrDA
N/A
USB
4 x USB 2.0 ports and 4 x USB 2.0 with header
Audio Interface
Mic in, Line out
IEEE 802.3 10/100/1000BASE-T Gigabit Ethernet compliant
(Realtek 8111B)
Ethernet Interface
KB/MS
RS232
DVI-D (optional)
USB
Audio
ORDERING GUIDE
WADE-8044
DISPLAY
Chipset
Intel®
Display Memory
Intel® DVMT 3.0 share system memory up to 128MB
Resolution
Analog Display: Up to 2048 x1536 (QXGA)
Digital LVDS: Up to 1400 x 1050 (SXGA+)
Digital DVI (Optional): Up to 1600 x 1200 (UXGA) (Chrontel
CH7307)
Dual Channel 18-bit
LVDS
99 Mini-ITX-WADE-8044
910GMLE GMCH Integrated
Intel®
GMA 900 graphics
Intel® Pentium® M / Celeron® M processors Based Mini-ITX Board with VGA,
18-bit LVDS, DVI, Dual GbE LAN, Four COM Ports and Eight USB 2.0 Ports
WADE-8044-600
Intel® Celeron® M 600MHz (512KB Cache) Based Mini-ITX Board with VGA, 18bit LVDS, Dual GbE LAN, Four COM Ports and Eight USB 2.0 Ports
WADE-8044-1G
Intel® Celeron® M 1.0GHz (Zero Cache) Based Mini-ITX Board with VGA, 18-bit
LVDS, Dual GbE LAN, Four COM Ports and Eight USB 2.0 Ports
WADE-8047
On board Dual VGA Intel® Celeron® M / Pentium® M
Processor Mini-ITX with DDR2 SDRAM, LVDS, Four
COM Ports and USB
FEATURES
Intel® Pentium® M / Celeron® M processor
Intel® 910GMLE and ICH6-M chipset
Two 240-pin DIMMs support dual channel DDR2 SDRAM
up to 2GB
Dual Display: Dual VGA / 18-bit LVDS
Two 10/100mbps LAN and one PCI slot
Two SATA ports, One IDE connector and One Type II
Compact Flash
Four COM Ports and Eight USB Ports
The WADE-8047 is a Mini-ITX embedded board featured its
onboard dual VGA ports that can deliver better cost effective
benefits when choosing display devices for operating. In
addition, it can also provide LVDS, Dual channel DDR2 memory,
two SATA ports, two 10/100 BASE-T Ethernet and expansion PCI
SYSTEM
slot. With low power Intel® Pentium® M / Celeron® M processor
and Intel® 910GMLE and ICH6-M chipset, WADE-8047 can meet
diversity applications such as Gaming, Lottery, Medical, and
Digital Signage.
MECHANICAL & ENVIRONMENTAL
CPU
Intel® Pentium® M / Celeron® M processor
Power Requirement
+12V(System) @ 2.40A; +5V @ 2.97A; +3.3V @ 0.45A
FSB
400 MHz
Operating Temperature
0~55°C
BIOS
Award BIOS
Operating Humidity
5%~95% non-condensing
System Chipset
Intel® 910GMLE GMCH and ICH6-M Chipset
Size (L x W)
6.69” x 6.69” (170 mm x 170 mm)
System Memory
Two 240-pin DIMMs support dual channel DDR2 SDRAM up
to 2GB
- 2 x SATA
- 1 x IDE
1 x Compact Flash share the same channel with IDE and
support UDMA
Programmable via S/W from 1sec. to 255min
Weight
0.95 lbs (0.43 Kg)
Storage
SSD
Watchdog Timer
H/W Status Monitor
GPIO
FAN Speed(CPU and System), Temperature(CPU and System),
Voltage, Case open function
On board programmable 8-bit Digital I/Os
Expansion
1 x PCI slot
REAR I/O
RS232
Fast Ethernet
KB/MS
Audio
I/O
MIO
IrDA
1 x EIDE, 1 x LPT, 3 x RS232 port, 1 x RS232/422/485
selectable, 1 x K/B, 1 x Mouse
N/A
USB
4 x USB 2.0 ports and 4 x USB 2.0 ports with header
Audio Interface
Mic-in, Line-in
Ethernet Interface
IEEE 802.3 10/100BASE-T Ethernet compliant
(Realtek 8111)
VGA
VGA
USB
ORDERING GUIDE
WADE-8047
Intel® Pentium® M / Celeron® M processors Based Mini-ITX Board with Dual VGA, 18-bit
LVDS, Dual LAN, Four COM Ports and Eight USB 2.0 Ports
DISPLAY
WADE-8047-600
Chipset
Intel® 910GMLE GMCH Integrated Intel® GMA 900 graphics
Display Memory
Intel® DVMT 3.0 share system memory up to 128MB
Intel® Celeron® M 600MHz (512KB Cache) Based Mini-ITX Board with Dual VGA, 18-bit
LVDS, Dual GbE LAN, Four COM Ports and Eight USB 2.0 Ports
Resolution
WADE-8047
Second VGA
Analog Display: Up to 2048 x 1536 (QXGA)
Digital LVDS: Up to 1400 x 1050 (SXGA+)
SDVO interface (CH7317)
LVDS
18-bit, dual Channel
Intel® Celeron® M 1.0GHz (Zero Cache) Based Mini-ITX Board with Dual VGA, 18-bit
LVDS, Dual GbE LAN, Four COM Ports and Eight USB 2.0 Ports
Mini-ITX-WADE-8047 100
WADE-8180
Leading Intel® Core™ 2 Quad / Core™ 2 Duo Processor
based Mini-ITX embedded board with Dual Display,
Dual Gigabit Ethernet, SATA, COM and USB
FEATURES
Intel® CoreTM 2 Quad / CoreTM 2 Duo processor Intel®
Q45 Express and ICH10DO chipset
Two 240-pin DIMM sockets support dual channel DDR3
SDRAM up to 4GB
Dual display: VGA / DVI-D, 3rd display via
PCI-Express x16 slot
Four SATA ports
Two GbE LAN ports and One PCI-E x16 slot
RAID 0 / 1 / 5 / 10
TPM 1.2 and iAMT 5.0 supported
Built with Intel® latest Q45 chipset, WADE-8180 takes advantage
of Intel® Core 2 Quad & Core 2 Duo technologies. With its PCI-E
x 16 slot, WADE-8180 offers the availability of extra graphic card
which can offer powerful graphic processing ability. In addition,
the VGA and DVI-D dual video outputs can drive two displays
simultaneously that suitable for gaming application. With dual
GbE LAN, four SATA, dual COM and eight USB I/O function,
WADE-8180 can be the best solution for multiple applications
such as automation, multi-media and KIOSK.
MECHANICAL & ENVIRONMENTAL
SYSTEM
CPU
Intel® CoreTM 2 Quad / CoreTM 2 Duo processor
Power Requirement
TBD
FSB
1333/1066/800 MHz
Operating Temperature
0~60°C
BIOS
AMI BIOS
Operating Humidity
10%~90%, noncondensing
System Chipset
Intel® Q45 Express and ICH10DO chipset
Dimension
6.69’’ x 6.69’’ (170mm x 170mm)
System Memory
Storage
Two 240-pin DIMM sockets support dual channel 800/1066MHz
DDR3 SDRAM up to 4GB
4 x SATA-300
Watchdog Timer
Reset; 1 sec.~255 min. and 1 sec. or 1 min./step
H/W Monitor
Monitoring CPU and system temperature, voltage and cooling
fan status
Onboard programmable 8-bit Digital I/O interface
(4 input / 4 output)
One PCI-Express x16 Slot
GPIO
Expansion
REAR I/O
VGA
Gigabit Ethernet
I/O
MIO
IrDA
1 x D-SUB 15-pin & 1 x D-SUB 24-pin connector, 2 x RS232
ports, 1 x K/B & Mouse
N/A
USB
4 x USB 2.0 ports and 4 x USB 2.0 ports with header
Audio Interface
Line out, Line-in and Mic-in
Ethernet Interface
IEEE 802.3 10/100/1000BASE-T Gigabit Ethernet compliant
KB/MS
DVI-D
RS232
USB
Audio
ORDERING GUIDE
WEDE-8180
Intel® CoreTM 2 Quad / CoreTM 2 Duo processor Mini-ITX Motherboard
DISPLAY
Chipset
Intel® Q45 Integrated Intel® Gen 5.0 GMA 4500 Graphics
Display Memory
Intel® Dynamic Video Memory Technology (Intel® DVMT 5.0)
Resolution
Up to 2048 x1536 @ 75 Hz (QXGA)
DVI
DVI-D interface
101 Mini-ITX-WADE-8044
* Specifications are subject to change without notice.
* CoreTM 2 Quad and CoreTM 2 Duo processor are registered trademarks
of Intel® Corporation.
* Other trademarks, logo, brands and company names are the property
of their respective owners.
WADE-8056
Leading Intel® CoreTM 2 Quad processor based
Mini-ITX Board with Dual Displays and One GbE
FEATURES
Intel® CoreTM 2 Quad processors
Intel® Q965 GMCH Chipset
Max. 4GB memory, DDR2 SDRAM
Dual Display by VGA/LVDS
One GbE LAN ports and one PCI slot
Max. four COM and six USB 2.0 ports
RAID 0/1/5/10
The WADE-8056 is an advanced mini-ITX embedded system board
(ESB) that takes advantage of Intel® CoreTM 2 Duo technologies. With
its GPIO, WADE-8056 offers robust computing power and reliability
for embedded applications that need a digital control interface. Dual
video outputs can drive two displays simultaneously at a high speed,
while maintaining superior image quality. The expansion slots, based
on PCI technologies and support up to two PCI slots, which provide
the highly flexibility necessary for functional expansion.
MECHANICAL & ENVIRONMENTAL
SYSTEM
Power Requirement
FSB
Intel® CoreTM 2 Quad / CoreTM 2 Duo and Pentium® 4 /
Celeron® D processor
FSB 1066/800/533 MHz
Operating Temperature
+5V @ 5.1A; +12V(CPU) @ 2.8A; +12V(system) @ 0.7A;
+3.3V @ 4.4A
0~55°C
BIOS
Award BIOS
Operating Humidity
0%~90% relative humidity, noncondensing
System Chipset
Intel® Q965 GMCH & 82801HB ICH8DO
Size (L x W)
6.69” x 6.69” (170 mm x 170 mm)
System Memory
Weight
0.94 lbs (0.43 Kg)
Storage
2 x 240-pin dual channel DDR2 SDRAM DIMM 533/667/800 MHz
supports up to 4 GB
4 x Serial ATA connector high-speed data transfers at up to 3 Gb/s
Watchdog Timer
Reset; 1 sec.~255 min. and 1 sec. or 1 min./step
H/W Status Monitor
GPIO
Monitoring system temperature, voltage, and cooling fan status.
Auto throttling control when CPU overheats
On-board programmable 8-bit Digital I/O interface
Expansion
1 x PCI slot; 1 x Mini-PCI
CPU
REAR I/O
Gigabit Ethernet
KB/MS
I/O
MIO
4 x RS232, 1 x K/B, 1 x Mouse, 1 x GbE
IrDA
N/A
USB
2 x USB 2.0 ports and 4 x USB 2.0 with header
Audio Interface
Mic in, Line in, Line out
Ethernet Interface
IEEE 802.3 10/100/1000BASE-T Gigabit Ethernet compliant
(Intel® 82566DM)
VGA
USB
Audio
ORDERING GUIDE
WADE-8056
Intel® CoreTM 2 Quad / CoreTM 2 Duo and Pentium® 4 / Celeron® D processors
Main Board with VGA, Audio, GbE LANs, 6 USB 2.0
EZCool
DISPLAY
Chipset
Intel® Q965 GMCH Integrated GMA 3000 Graphics device
Display Memory
Intel®
Resolution
Analog Display: Up to 2048 x 1536 (QXGA)
Digital LVDS Display: Up to 1920 x 1200
Dual Channel 24-bit
LVDS
RS232
DVMT 4.0 supports up to 384 MB video memory
Compact 1U active heatsink suitable for Intel® CoreTM 2 Duo processor
(blow 65W)
PEP-581R/582R
One/Two slots PCI riser card
PEP-582L
Two slots PCI riser card
Mini-ITX-WADE-8056 102
WADE-8556
Leading Intel® CoreTM 2 Quad processor based Mini-ITX
Board with Dual Displays and One GbE
FEATURES
Intel® CoreTM 2 Quad processors
Intel® Q965 GMCH Chipset
Dual Display by VGA/DVI
One GbE LAN ports, one PCI and one Mini-PCI slot
Max. four COM and six USB 2.0 ports
RAID 0/1/5/10
WADE-8556 is an advanced mini-ITX embedded system board
(ESB) that takes advantage of Intel® CoreTM 2 Quad technologies.
With its Mini-PCI slot, WADE-8556 offers the availability
of an extra wireless LAN card which is suitable for Kiosk
application. VGA & DVI dual video output can drive two displays
simultaneously, especially suitable for Digital Signage usage.
The expansion slots, based on PCI technologies and support up
to two PCI slots, which provide the highly flexibility necessary
for functional expansion.
MECHANICAL & ENVIRONMENTAL
SYSTEM
Power Requirement
FSB
Intel® CoreTM 2 Quad / CoreTM 2 Duo and Pentium® 4 /
Celeron® D processor
FSB 1066/800/533 MHz
Operating Temperature
+5V @ 5.1A; +12V(CPU) @ 2.8A; +12V(system) @ 0.7A;
+3.3V @ 4.4A
0~55°C
BIOS
Award BIOS
Operating Humidity
0%~90% relative humidity, noncondensing
System Chipset
Intel® Q965 GMCH & 82801HB ICH8DO
Size (L x W)
6.69” x 6.69” (170 mm x 170 mm)
System Memory
2 x 240-pin dual channel DDR2 SDRAM DIMM 533/667/800 MHz
support up to 4GB
4 x Serial ATA connector high-speed data transfers at up to
3 Gb/s
Reset:1 sec.~255 min. and 1 sec. or 1 min./step
Weight
0.94 lbs (0.43 Kg)
CPU
Storage
Watchdog Timer
GPIO
Monitoring system temperature, voltage, and cooling fan
status. Auto throttling control when CPU overheats
On-board programmable 8-bit Digital I/O interface
Expansion
1 x PCI slot; 1 x Mini-PCI
H/W Status Monitor
REAR I/O
KB/MS
RS232
Gigabit Ethernet
I/O
MIO
4 x RS232, 1 x K/B, 1 x Mouse, 1 x GbE
IrDA
N/A
USB
2 x USB 2.0 ports and 4 x USB 2.0 with header
Audio Interface
Mic in, Line in, Line out
Ethernet Interface
IEEE 802.3 10/100/1000BASE-T Gigabit Ethernet compliant
(Intel® 82566DM)
VGA
Audio
ORDERING GUIDE
WADE-8556
Intel® CoreTM 2 Quad / CoreTM 2 Duo and Pentium® 4 / Celeron® D processors
Main Board with VGA, Audio, GbE LANs, 6 USB 2.0
Compact 1U active heatsink suitable for Intel® CoreTM 2 Duo processor
(blow 65W)
Chipset
Intel®
Display Memory
Intel® DVMT 4.0 supports up to 384 MB video memory
PEP-581R/582R
Resolution
Analog Display: Up to 2048 x 1536 (QXGA)
Digital DVI Display: Up to 1920 x 1200
DVI-D interface
One/Two slots PCI riser card
103 Mini-ITX-WADE-8556
USB
EZCool
DISPLAY
DVI
DVI-D
Q965 GMCH Integreated GMA 3000 Graphics device
PEP-582L
Two slots PCI riser card
WADE-8656
Leading Intel® CoreTM 2 Quad processor based
Mini-ITX Board with PCI-E expansion and Two GbE
FEATURES
Intel® CoreTM 2 Quad processors
Intel® Q965 GMCH chipset
Six SATA ports support
Two GbE LAN ports, one PCI-E x16 slot
Max. two COM and eight USB 2.0 ports
RAID 0/1/5/10
WADE-8656 is an advanced mini-ITX embedded system board
(ESB) that takes advantage of Intel® CoreTM 2 Quad technologies.
With its PCI-E x16 slot, WADE-8656 gets the availability of extra
graphic card which can offer powerful graphic processing ability
SYSTEM
and suitable for gaming application. Six SATA Ports enrich the
system capacity, especially suitable for Storage usage. Two
Gigabit Ethernet ports provide high performance for networking
transmission.
MECHANICAL & ENVIRONMENTAL
Power Requirement
FSB
Intel® CoreTM 2 Quad / CoreTM 2 Duo and Pentium® 4 /
Celeron® D processor
FSB 1066/800/533 MHz
Operating Temperature
+5V @ 5.1A; +12V(CPU) @ 2.8A; +12V(system) @ 0.7A;
+3.3V @ 4.4A
0~55°C
BIOS
Award BIOS
Operating Humidity
0%~90% relative humidity, noncondensing
System Chipset
Intel® Q965 GMCH & 82801HB ICH8DO
Size (L x W)
6.69” x 6.69” (170 mm x 170 mm)
System Memory
2 x 240-pin dual channel DDR2 SDRAM DIMM 533/667/800 MHz
supports up to 4GB
6 x Serial ATA connector high-speed data transfers at up to
3 Gb/s
Reset; 1 sec.~255 min. and 1 sec. or 1 min./step
Weight
0.94 lbs (0.43 Kg)
CPU
Storage
Watchdog Timer
H/W Status Monitor
GPIO
Monitoring system temperature, voltage, and cooling fan
status. Auto throttling control when CPU overheats
On-board programmable 8-bit Digital I/O interface
Expansion
One PCI-E x16 slot
REAR I/O
Gigabit Ethernet
KB/MS
Audio
I/O
MIO
IrDA
1 x RS232, 1 x RS232/422/485 selectable, 1 x K/B, 1 x Mouse,
2 x GbE
N/A
USB
4 x USB 2.0 ports and 4 x USB 2.0 with header
Audio Interface
Mic in, Line in, Line out
Ethernet Interface
IEEE 802.3 10/100/1000BASE-T Gigabit Ethernet compliant
(Intel® 82566DM, Realtek 8111B)
RS232/422/485
VGA
USB
ORDERING GUIDE
WADE-8656
Intel® CoreTM 2 Quad / CoreTM 2 Duo and Pentium® 4 / Celeron® D
processors Main Board with VGA, Audio, GbE LANs, 8 USB 2.0
DISPLAY
Chipset
Intel® Q965 GMCH Integrated GMA 3000 Graphics device
EZCool
Display Memory
Intel® DVMT 4.0 supports up to 384 MB video memory
Compact 1U active heatsink suitable for Intel Core 2 Duo processor (blow 65W)
Resolution
Analog Display: Up to 2048 x 1536 (QXGA)
PER-4410R
LVDS
N/A
One slot PCI-E x16 riser card
Mini-ITX-WADE-8656 104
WADE-8055
Network Enriched Intel® CoreTM 2 Duo Processor based
Mini-ITX Board with Dual Displays and Two GbE
FEATURES
Intel® CoreTM 2 Duo / Pentium® 4 / Celeron® D Processor
Intel® 945G and ICH7 Chipset
Two 200pin SO-DIMMs support dual channel DDR2 SDRAM
up to 4GB
Four SATA ports support
Two GbE-LAN ports and one PCI slot
Max. two COM and eight USB 2.0 ports
All capacitors are solid type
WADE-8055 is an industrial–grade Mini-ITX board with best C/P
ratio. The LGA775 CPU socket enables WADE-8055 to support
wide range processors, such as Intel® CoreTM 2 Duo, Pentium® 4
or Celeron® CPUs. With special heatsink design, WADE-8055 can
run with Celeron® 440 35W processor without any fan.
Moreover, all solid type capacitors enhance the durability,
stability and reliability of the board as well.
MECHANICAL & ENVIRONMENTAL
SYSTEM
CPU
Intel® CoreTM 2 Duo / Pentium® 4 / Celeron® D processor
FSB
FSB 1066/800/533 MHz
BIOS
Award BIOS
System Chipset
Intel® 945G and ICH7 Chipset
System Memory
2 x 200-pin DDR2 SO-DIMM socket support up to 4GB
dual channel 667/533 MHz
Storage
Support 4 SATA 300 drives
SSD
1 x Compact Flash
Watchdog Timer
Reset:1 sec.~255 min. and 1 sec. or 1 min./step
H/W Status Monitor
Monitoring system temperature, voltage, and cooling fan
status. Auto throttling control when CPU overheats
GPIO
On-board programmable 8-bit Digital I/O interface
Expansion
1 x PCI slot
Operating Temperature
[email protected] ; [email protected] ; +12V(system)@0.48A ;
[email protected]
0~55°C
Operating Humidity
0%~90% relative humidity, noncondensing
Size (L x W)
6.69” x 6.69” (170 mm x 170 mm)
Weight
0.94 lbs (0.43 Kg)
Power Requirement
REAR I/O
Gigabit Ethernet
RS232
USB
I/O
MIO
1 x RS232, 1 x RS232/422/485 selectable
IrDA
N/A
USB
6 x USB 2.0 ports and 2 x USB 2.0 with header
Audio Interface
Mic in, Line in, CD Audio in, Line out
IEEE 802.3 10/100/1000BASE-T Gigabit Ethernet compliant
(Realtek 8111C x2)
Ethernet Interface
RS232/422/485
VGA
USB
Audio
ORDERING GUIDE
WADE-8055
Intel® CoreTM 2 Duo / Pentium® 4 / Celeron® D processors Mini-ITX Board
PEP-581R/582R
DISPLAY
Chipset
Intel® 945G GMCH
One/Two slots PCI riser card
Display Memory
Integrated Intel® Graphics Media Accelerator GMA 950, and
share system memory to 224 MB
PEP-582L
Resolution
Analog Display: Up to 2048 x 1536 (QXGA)
LVDS
N/A
105 Mini-ITX-WADE-8056
Two slots PCI riser card
EZCool
Compact 1U active heatsink suitable for Intel® CoreTM 2 Duo processor
(blow 65W)
WADE-2221A
The WADE-2221A is a rugged and stylish barebone system
suitable for embedded applications that stand alone or are
rackmounted. Its effective ventilation is achieved by the mesh
design of the front panel. No actual tool is needed to release the
top cover of chassis, simplifying integration and field service.
FEATURES
Rugged and Stylish Industrial Mini-ITX Bare
Bone System
This barebone system includes a WADE series board, 150-watt
or 180-watt power supply, 2.5" drive bay and one PCI expansion
slot. A 2U rackmount tray is specially designed to hold two units
side-by-side and converts them to the rackmount platform.
REAR I/O
Integrated with various Mini-ITX board
One PCI expansion slot
LAN
Audio Ports
Tool-free mechanism to open the top cover
Rugged and stylish design
Quick 2.5” HDD installation by releasing the
top cover
Built-in VGA/LAN/USB/COM ports
Two side-by-side units to form two systems
in 2U rackmount form factor
COM1
VGA
KB/MS
2 USB Ports
FSP150-50PLA optional
POWER SUPPLY
Input Voltage
90V ~ 264V AC, full range
Input Frequency
47 ~ 63 Hz
Input Current
[email protected], [email protected]
Efficiency
>68%
Holdup Time
20ms. at full [email protected]°C
WADE-2221A-150X
Over Voltage Protection
[email protected]~6.5V; [email protected]~4.5V; [email protected]~+5.6V
Over Power/Load
Protection
MTBF
Output power over to 110%~140%
Rugged and stylish industrail Mini-ITX Bare-bones Chassis with 150W
active PFC PSU
EMI & Safety Approval
UL, TUV, CE, FCC, CB, CSA, SEMKO, FIMKO, NEMCO, DIMCO
Temperature/Humidity
Operating: 0 ~ 50°C, 20 ~ 85%RH
Storage: -40 ~ 70°C, 10m ~ 90%RH
150x81.6x40.6 mm; 5.9”x3.2”x1.6”
Dimension (WxDxH)
ORDERING GUIDE
WADE-2221A-180X
100,000 hrs
Rugged and stylish industrail Mini-ITX Bare-bones Chassis with 180W
active PFC PSU
MECHANICAL & ENVIRONMENTAL
Operation Temperature
0~50°C
Storage Temperature
-20~80°C
Relative Humidity
5~95% non-condensing
Dimension
251 x 221.8 x 86.3 (mm)
Weight
3.5 Kg
Mini-ITX-WADE-2221A 106
WADE-1120A
The WADE-1120A is designed to efficiently dissipate any
internal heat, eliminating the need for a ventilation fan. It is
the perfect system solution for any embedded application
that operates in a harsh environment. WADE-1120A is
designed with either a built-in WADE-8041 board or similar
FEATURES
The fan-less compact bare bone system with
Intel® Celeron® M Mini-ITX board
Mini-ITX board as the barebone system. Its unique tool-free
design allows the integrator or field service professional
to release the top cover easily and quickly. Complete with
memory, DOM or Compact flash, WADE-1120A is ready to go
to work.
REAR I/O
Integrated with WADE-8041 or similar Mini-ITX board
Small form factor with fan-less ventilation mechanism
Rugged design for harsh environment
COM1
LAN
COM2, COM3
Unique tool-free design for quick top cover release
VGA
USB
KB/MS
Audio
COM4
FSP055-50LM optional
POWER SUPPLY
Maximum Output
55W ATX power supply
Input Voltage
90V ~ 265V AC, full range
Input Frequency
47 ~ 63 Hz
Input Current
2.0A(RMS)@115V, 1.0A(RMS)@230V
Efficiency
>74%
Holdup time
17ms. at 115V/60Hz or 230V/50Hz
Over Voltage Protection
[email protected]~4.5V; [email protected]~6.82V; [email protected]~16.5V
WADE-1120A-40X
MTBF
121,330 hrs
The Fan-free Designed Compact Node Chassis built with 40W ATX PSU
Certification
UL, cUL, TUV, CE, FCC
WADE-1120A-55X
Dimension (WxDxH)
183x50x37.6 mm; 7.2”x2”x1.5”
The Fan-free Designed Compact Node Chassis built with 55W ATX PSU
MECHANICAL & ENVIRONMENTAL
Operation Temperature
0~50°C
Storage Temperature
-20~80°C
Relative Humidity
5~95% non-condensing
Dimension
278 x 200 x 44 (mm)
Weight
2~2.5 Kg
107 Mini-ITX-WADE-1120A
ORDERING GUIDE
WADE-2231Q
The WADE-2231Q is a rugged and stylish barebones system
suitable for embedded applications that stand alone or are
rackmounted. Its effective ventilation is achieved by the mesh
design of the front panel. No actual tool is needed to release the
FEATURES
Rugged and Stylish Industrial Mini-ITX Bare
Bone Chassis with 180W Active PFC PSU
top cover of chassis, simplifying integration and field service.
This barebone system includes a WADE series board, 180-watt
power supply, 3.5" drive bay and one PCI expansion slot.
REAR I/O
Bare-bones Chassis for Mini-ITX board
Tool-free mechanism to open the top cover
COM
Rugged and stylish design
LAN
Quick 3.5” HDD installation by releasing the top cover
FSP180-50PLA optional
POWER SUPPLY
VGA
KB/MS
Audio
USB
Input Voltage
90V ~ 264V AC, full range
Input Frequency
47 ~ 63 Hz
Input Current
[email protected], [email protected]
Efficiency
>68%
Holdup Time
20ms. at full [email protected]°C
Over Voltage Protection
[email protected]~6.5V; [email protected]~4.5V; [email protected]~+5.6V
Over Power/Load
Protection
MTBF
Output power over to 110%~140%
WADE-2231Q-150X
100,000 hrs
Rugged and stylish industrail Mini-ITX Bare-bones Chassis with 150W
active PFC PSU
EMI & Safety Approval
UL, TUV, CE, FCC, CB, CSA, SEMKO, FIMKO, NEMCO, DIMCO
WADE-2231Q-180X
Temperature/Humidity
Operating: 0 ~ 50°C, 20 ~ 85%RH
Storage: -40 ~ 70°C, 10m ~ 90%RH
Rugged and stylish industrail Mini-ITX Bare-bones Chassis with 180W
active PFC PSU (CoreTM 2 Quad Solution)
Dimension (WxDxH)
150x81.6x40.6 mm; 5.9”x3.2”x1.6”
ORDERING GUIDE
MECHANICAL & ENVIRONMENTAL
Operation Temperature
0~50°C
Storage Temperature
-20~80°C
Relative Humidity
5~95% non-condensing
Dimension
310 x 252 x 86.3 (mm)
Weight
3.5 Kg
Mini-ITX-WADE-2231Q 108
ARTO-220-ITX
The compact and slim ARTO-220-ITX is design to fit Mini-ITX
MB applications operating where space is at a premium. It
also features a tool-free mechanical design to quickly release the top cover of the chassis for ease of integration and
FEATURES
1.5U Advanced Mini-ITX based chassis for MiniITX M/B application
field service. The barebone system includes a WADE series
board, 3.5” drive bay, one PCI expansion slot and a 250-watt
power supply.
REAR I/O
Bare-bones chassis for Mini-ITX board
Comptact, slim and stylish ID design
LAN
One 3.5” HDD bay and 250W PSU
Audio Ports
One PCI expansion slot
COM
KB/MS
Input Voltage
90V ~ 264V AC, full range
Input Frequency
47 ~ 63 Hz
Input Current
[email protected], [email protected]
Efficiency
>68%
Holdup Time
17ms. at full [email protected]°C
Over Voltage Protection
[email protected]~6.5V; [email protected]~4.5V; [email protected]~+5.6V
Over Power/Load
Protection
MTBF
Output power over to 110%~160%
EMI & Safety Approval
UL, cUL, TVU, CE, FCC
Temperature/Humidity
Operating: 0 ~ 50°C, 20 ~ 85%RH
Storage: -20 ~ 70°C, 10m ~ 90%RH
100x190x40.5 mm; 3.9”x7.5”x1.6”
105,405 hrs
MECHANICAL & ENVIRONMENTAL
Operation Temperature
0~50°C
Storage Temperature
-20~80°C
Relative Humidity
5~95% non-condensing
Dimension
374 x 241 x 74 (mm)
Weight
6.5 Kg
109 Mini-ITX-ARTO-220-ITX
2 USB Ports
FSP250-50PLB optional
POWER SUPPLY
Dimension (WxDxH)
VGA
ORDERING GUIDE
ARTO-220-ITX-250X
1.5U Advanced Mini-ITX based Chassis with 250W Active PFC PSU
WADE-1042
The WADE-1042 uses a 1U rack-mount form factor and is
designed for network or communication applications. Its four
drive bays support RAID configuration through the SATA inter-
FEATURES
1U Height bare bone server with four drive
bays for RAID and two expansion slots
faces on the board. Applications will benefit from WADE-1042’s
compact size, expansion capability, RAID configuration and
250-watt power supply.
REAR I/O
Bare-bones chassis for Mini-ITX board
LAN
Comptact, slim and stylish ID design
Four 3.5” HDD bays and 180W PSU
Parallel
Switch
Audio
Two PCI expansion slot
COM
VGA
USB
PCI
KB/MS
FSP220-60LE optional
POWER SUPPLY
Input Voltage
90V ~ 264V AC, full range
Input Frequency
47 ~ 63 Hz
Input Current
[email protected], [email protected]
Efficiency
>68%
Holdup Time
20ms. at full [email protected]°C
[email protected]~6.8V; [email protected]~4.8V; [email protected]~15.6V
Over Voltage Protection
Over Power/Load
Protection
MTBF
Output power over to 110%~140%
EMI & Safety Approval
UL, TUV, CE, FCC, CB, CSA, SEMKO, FIMKO, NEMCO, DIMCO
Temperature/Humidity
Operating: 0 ~ 50°C, 20 ~ 85%RH
Storage: -40 ~ 70°C, 10m ~ 90%RH
150x81.6x40.6 mm; 5.9”x3.2”x1.6”
Dimension (WxDxH)
ORDERING GUIDE
WADE-1042-220X
Advance Mini-ITX based Chassis for Rack-Mount with 180W Active PFC PSU
100,000 hrs
MECHANICAL & ENVIRONMENTAL
Operation Temperature
0~50°C
Storage Temperature
-20~80°C
Relative Humidity
5~95% non-condensing
Dimension
432 x 380 x 44 (mm)
Weight
8.5 Kg
Mini-ITX-WADE-1042 110
WADE-1181
Compact Low Profile Mini-ITX Bare Bone Chassis
with 1-slot PCI Expansion
A wider version Mini-ITX barebone chassis that provides
essential expansion capability for function that is not covered
by the embedded Mini-ITX board. The provided 1-slot PCI
FEATURES
expansion could be capture card for DSS application or serial
port card for data acquisition in factory.
REAR I/O
Support Mini-ITX embedded board
Hard drive bay for internal 2.5” hard drive (project based
to support 3.5” hard drive without PCI expansion)
Power Switch
Include 150W Active PFC power supply
Customized label of front panel and rear I/O bracket are
welcome
Dual USB ports and Power LED indication on front panel
150W Active PFC PSU
FSP150-50PLA optional
POWER SUPPLY
*Flexible rear I/O panel design
Input Voltage
90V ~ 264V AC, full range
Input Frequency
47 ~ 63 Hz
Input Current
[email protected], [email protected]
Efficiency
>68%
Holdup Time
20ms. at full [email protected]°C
WADE-1181-150X
Over Voltage Protection
[email protected]~6.5V; [email protected]~4.5V; [email protected]~+5.6V
Over Power/Load
Protection
MTBF
Output power over to 110%~140%
Advance Mini-ITX based Chassis with 1-slot PCI expansion for Desktop
(1U High) with 150W Active PFC PSU
EMI & Safety Approval
UL, TUV, CE, FCC, CB, CSA, SEMKO, FIMKO, NEMCO, DIMCO
Temperature/Humidity
Operating: 0 ~ 50°C, 20 ~ 85%RH
Storage: -40 ~ 70°C, 10m ~ 90%RH
150x81.6x40.6 mm; 5.9”x3.2”x1.6”
Dimension (WxDxH)
100,000 hrs
MECHANICAL & ENVIRONMENTAL
Operation Temperature
0~50°C
Storage Temperature
-20~80°C
Relative Humidity
5~95% non-condensing
Dimension
370 x 231 x 44.4 (mm)
Weight
3.2 Kg
111 Mini-ITX-WADE-1181
ORDERING GUIDE
WADE-1141
Mini-ITX adoption of embedded applications is non stop trend of
industries. A compact, easy installation and low price demanding
barebone chassis is urgently inquiry. WADE-1141, not fancy but
FEATURES
Compact Low Profile Mini-ITX Bare Bone Chassis
durable Mini-ITX barebone chassis meets the request perfectly.
Standard chassis yet customerized front panel label makes it
special for your project.
REAR I/O
Support Mini-ITX embedded board
Hard drive bay for internal 2.5” hard drive (3.5” drive
bay by project)
Power Switch
Include 150W Active PFC power supply
Customized label of front panel and rear I/O bracket
are welcome
Dual USB ports and Power LED indication on front
panel
Input Voltage
90V ~ 264V AC, full range
Input Frequency
47 ~ 63 Hz
Input Current
[email protected], [email protected]
Efficiency
>68%
Holdup Time
20ms. at full [email protected]°C
Over Voltage Protection
[email protected]~6.5V; [email protected]~4.5V; [email protected]~+5.6V
Over Power/Load
Protection
MTBF
Output power over to 110%~140%
EMI & Safety Approval
UL, TUV, CE, FCC, CB, CSA, SEMKO, FIMKO, NEMCO, DIMCO
Temperature/Humidity
Operating: 0 ~ 50°C, 20 ~ 85%RH
Storage: -40 ~ 70°C, 10m ~ 90%RH
150x81.6x40.6 mm; 5.9”x3.2”x1.6”
Dimension (WxDxH)
150W Active PFC PSU
FSP150-50PLA optional
POWER SUPPLY
100,000 hrs
*Flexible rear I/O panel design
ORDERING GUIDE
WADE-1141-150X
Advanced Mini-ITX based Chassis for Desktop (1U High) with 150W
Active PFC PSU
MECHANICAL & ENVIRONMENTAL
Operation Temperature
0~50°C
Storage Temperature
-20~80°C
Relative Humidity
Dimension
5~95% non-condensing
275 x 231 x 50(mm)
Weight
2.5 Kg
Mini-ITX-WADE-1141 112
WADE-2110
Install hard drive or maintance is terrible work for system
assembly or field maintance technicians. To easy their works
and minimumized down time of valueable running system, the
WADE-2110 provides one front accessable 3.5” hard drive bay to
FEATURES
Cubic Mini-ITX Bare Bone Chassis with
Front Accessable Hard Drive Bay
get away from the nightmare. The 2U height barebone chassis
can be fix in 19” cabinet with special carrier for having dual
systems in 2U space.
REAR I/O
Support Mini-ITX embedded board
Front accessable 3.5” SATA hard drive bay
Power Switch
Include 150W Active PFC power supply
Able to install dual systems in 19” rack with special
carrier
Dual USB ports and Power LED indication on front
panel
FSP150-50PLA optional
POWER SUPPLY
Input Voltage
90V ~ 264V AC, full range
Input Frequency
47 ~ 63 Hz
Input Current
[email protected], [email protected]
Efficiency
>68%
Holdup Time
20ms. at full [email protected]°C
Over Voltage Protection
[email protected]~6.5V; [email protected]~4.5V; [email protected]~+5.6V
Over Power/Load
Protection
MTBF
Output power over to 110%~140%
EMI & Safety Approval
UL, TUV, CE, FCC, CB, CSA, SEMKO, FIMKO, NEMCO, DIMCO
Temperature/Humidity
Operating: 0 ~ 50°C, 20 ~ 85%RH
Storage: -40 ~ 70°C, 10m ~ 90%RH
150x81.6x40.6 mm; 5.9”x3.2”x1.6”
Dimension (WxDxH)
100,000 hrs
MECHANICAL & ENVIRONMENTAL
Operation Temperature
0~50°C
Storage Temperature
-20~80°C
Relative Humidity
5~95% non-condensing
Dimension
215 x 231 x 88.5 (mm)
Weight
3.0 Kg
113 Mini-ITX-WADE-2110
150W Active PFC PSU
*Flexible rear I/O panel design
ORDERING GUIDE
WADE-2110-150X
Advance Mini-ITX based Chassis with front accessable hard drive bay and
150W Active PFC PSU
Riser Card Selection Guide
WADE ESB
Riser Card
WADE-2221A
ARTO-220-ITX
WADE-2232Q
PER-4210R
PEP-581R
WADE-8066
PEP-582R
PEP-5311R
PEP-581R
WADE-8056
PEP-582R
PEP-5311R
PEP-581R
WADE-8556
PEP-582R
PEP-5311R
WADE-8656
PER-4410R
PEP-581R
WADE-8065
PEP-582R
PEP-5311R
PEP-581R
WADE-8055
PEP-582R
PEP-5311R
PEP-581R
WADE-8044
PEP-582R
PEP-5311R
Mini-ITX-Riser Card Selection Guide 114
Modular Computing Solutions
Modular computing platforms
Compact size, computing power options, reliability, ease of use, and function
expansion are the key design considerations for every embedded application.
Modular computing boards have been defined and developed in order to satisfy these
design needs. The modular computing approach is to condense the fundamental
computer functions into a compact module that includes an interface for additional
function expansion.
The PC/104, PC/104+, and EBX (Embedded Board eXpandable) are some
traditional form factors of modular computing boards in the market place. The ETX
(Embedded Technology eXtended) form factor has been created in recent years with
greater computing power, smaller size, and extended expansion capability. In 2005, the ETX was imbued with latest interface
technologies such as PCI Express and SATA. Due to the simplicity of its circuit design, balanced computing power, and I/O
bandwidth, the ETX standard evolved into COM Express -- one of the PICMG (PCI Industrial Computer Manufacturer Group)
standards.
COM Express
The COM Express form factor includes a bootable host computer modular board that is connected with its carrier board through
the PCI Express interconnection. The PCI Express Technology enables the data transmission from parallel to serial. The
advantage of such architecture is higher I/O density and greater performance.
The module, bootable host computer "engine" is packaged as an off-the-shelf board and plugged into a "carrier board," which is
implemented with I/Os and also connects to the power supply. The application-specific system functions and peripheral expansion
are all built on the carrier board.
QSEVEN
The QSEVEN form factor measures a mere 70 x 70 mm, making it smaller than most of other modules in the market place. The
QSEVEN Consortium defined the mechanical and electrical interfaces so that hardware vendors and system integrators can build
and integrate compliant components, signal devices, and systems.
The high density, compact size and latest interfaces -- as well as the expandability to meet the latest serial transmission interface,
such as PCI Express, SATA, Gigabit Ethernet and SDVO interface - benefit many applications in the embedded market, including
industrial control and small form factor applications.
ETX
The ETX form factor is build from early 2000 for standardized module computing purpose. It includes the common PC functions
such as VGA, USB, Keyboard, Mouse, Serial/Parallel Port, IDE and Fast Ethernet. In addition, its PCI and ISA interfaces are
industrial standard that can support versatile applications and different kinds of peripheral devices. While it is an early modular
concept and has been adopted for a long time, the latest and powerful chipsets technology still brings this form factor higher
performance.
115 Modular Computing Solutions
PCOM-B211VG
Intel® CoreTM Duo & Solo processor based Type
II COM Express module with DDR2 SDRAM,
VGA, Gigabit Ethernet, SATA 300 and USB
Active Heat Sink
Passive Heat Sink
FEATURES
®
Intel 945GME based module supports Core
Solo or Core Duo processors
both Intel® socket type and BGA type
processors for intensive computing power or
fan-less applications
Accept
Plug-n-run with the carrier boards and
speeds up time-to market
SATA interface to support faster transfer rate
in storage devices
Maximum 2GB DDR2 memory
ORDERING GUIDE
Standard
Optional
GENERAL
Processor
CPU & Package: Intel® CoreTM Duo or Solo processor in mFCPGA package
FSB: 667/533MHz
Chipset/Core Logic
Intel® 945GME and ICH7MDH
System Memory
Up to 2GB DDR2 667/533/400 SDRAM on one 200-pin DIMM socket
BIOS
Award BIOS
Storage Devices
EIDE: Support one EIDE channel with Ultra DMA 100/66/33
SATA: Support Two SATA 150 drives
Solid State Disk
N/A
Watchdog Timer
N/A
Expansion Interface
- One PCI Express x16, multiplexed with SDVO interface
- Five PCI Express x1
- Four PCI devices
- LPC interface
- High definition audio interface
Hardware Monitoring
CPU temperature
Dimension
Dimension : 125(L) x 95(W) mm; 4.9"(L) x 3.7" (W)
Environment
Operating Temperature: 0 to 60oC
Storage Temperature: -20 to 80oC
Relative Humidity: 5% to 90%, non-condensing
I/O
MIO
N/A
PCOM-B211VG
Intel ® CoreTM Duo or Solo processor based
Type II COM Express module with DDR2
SDRAM, VGA, Gigabit Ethernet and USB
IrDA
N/A
Ethernet
One Gigabit Ethernet (Intel® PC82573L)
Audio
N/A
Active Heat Sink
Heat sink for both PCOM-210/211 with socket
type processor
USB
USB 2.0 x 8
Keyboard & Mouse
N/A
Passive Heat Sink
Heat sink for both PCOM-210/211 with low
power consumption on-board processor
DISPLAY
Graphic Controller
Intel® 945GME integrated Intel® Graphics Media Accelerator 950
(Intel® GMA 950)
Graphic Memory
Dynamic share system memory up to 224MB (Intel® DVMT 3.0) or static share
system memory up to 128MB
Display Interface
- Support CRT, LVDS and TV-out display interfaces
- CRT display resolution QXGA
Modular-PCOM-B211VG 116
Intel® CoreTM 2 Duo or Celeron® M processor
based Type II COM Express module with DDR2
SDRAM, VGA, Gigabit Ethernet and USB
PCOM-B212VG
200-pin DIMM sockets
Socket P
Active Heat Sink
Intel® ICH8M
Intel® GME965
Passive Heat Sink
FEATURES
®
TM
The Intel Core 2 Duo processor brings
dual-core technology and provides
significant performance improvement.
The Intel® GME965 integrated GMA X3100
graphic provides better performance and
variable display interfaces.
Design to comply with both socket type and
BGA type CoreTM 2 Duo & Celeron® M
processor for intensive computing
Architecture of module and carrier boards
speeds up time-to-market of tailor-made
equipment
Equipped with single PCI Express x1
interface based Gigabit Ethernet
GENERAL
Processor
CPU & Package: Intel® CoreTM 2 Duo or Celeron® M processor FCPGA package
FSB: 533/800MHz
Chipset/Core Logic
Intel® GME965 and ICH8M
System Memory
Up to 4GB DDR2 533/667 SDRAM on two 200-pin DIMM socket
BIOS
Award BIOS
Storage Devices
EIDE: Support one EIDE channel with Ultra DMA 100/66/33
SATA: Support three SATA 300 drives
Solid State Disk
N/A
Watchdog Timer
N/A
Expansion Interface
- One PCI Express x16, multiplexed with SDVO interface
- Five PCI Express x1
- Four PCI devices
- LPC interface
- High definition audio interface
Hardware Monitoring
CPU Voltage and Temperature
Dimension
Dimension : 125(L) x 95(W) mm; 4.9"(L) x 3.7" (W)
Environment
Operating Temperature: 0 to 60oC
Storage Temperature: -20 to 80oC
Relative Humidity: 5% to 90%, non-condensing
I/O
ORDERING GUIDE
Standard
PCOM-B212VG
Intel ® CoreTM 2 Duo or Celeron® M processor
based Type II COM Express module with
DDR2 SDRAM, VGA, Gigabit Ethernet and
USB
MIO
N/A
IrDA
N/A
Ethernet
One Gigabit Ethernet Controller (Intel® WG82574L)
Audio
N/A
USB
Eight USB ports
Keyboard & Mouse
N/A
DISPLAY
117 Modular-PCOM-B212VG
Graphic Controller
Intel® GME965 integrated Graphics Media Accelerator X3100
(Intel® GMA X3100)
Graphic Memory
Dynamic share system memory up to 384MB (Intel® DVMT 4.0)
Display Interface
- Support CRT, LVDS, TV-out, and SDVO display interfaces
- CRT display resolution up to 2048x1536 @ 85Hz refresh
Intel® GM45 platform based Type II COM Express
module with DDR3 SDRAM, VGA, Gigabit
Ethernet, SATA and USB
PCOM-B213VG
204-pin SODIMM sockets
Socket P
Intel® GM45
Active Heat Sink
®
Intel ICH9M-E
Passive Heat Sink
GENERAL
FEATURES
Processor
CPU & Package: Intel® 45nm CoreTM 2 Quad/Core 2 Duo FSPGA package
FSB: 667/800/1066MHz
Chipset/Core Logic
Intel® GM45 and ICH9M-E
System Memory
Up to 8GB DDR3 667/800/1066 SDRAM on two SODIMM socket
Intel GM45 integrated GMA 4500MHD
graphic provides extreme 3D performance
for media applications
BIOS
AMI BIOS
Storage Devices
EIDE: Support one EIDE channel with Ultra DMA 100/66/33
SATA: Support Four SATA 300 drives
Intel® GM45 platform brings latest iAMT 4.0
and ITPM for powerful management and
cryptal functions
Solid State Disk
N/A
Watchdog Timer
N/A
Expansion Interface
- One PCI Express x16, multiplexed with SDVO interface
- Five PCI Express x1
- Four PCI devices
- LPC interface
- High definition audio interface
Hardware Monitoring
CPU Voltage and Temperature
Power Requirement
TBA
Dimension
Dimension : 125(L) x 95(W) mm; 4.9"(L) x 3.7" (W)
Environment
Operating Temperature: 0 to 60oC
Storage Temperature: -20 to 80oC
Relative Humidity: 5% to 90%, non-condensing
®
TM
TM
The Intel 45nm Core 2 Quad/Core 2
Duo processor features dual core/quad core
technology that provides latest
semiconductor technology
®
Architecture of module and carrier boards
speeds up time-to-market of tailor-made
equipment
Support two SODIMM socket and up to 8GB
memory size
ORDERING GUIDE
Standard
PCOM-B213VG
Intel ® GM45 platform based Type II COM
Express module with DDR3 SDRAM, VGA,
Gigabit Ethernet and USB
I/O
MIO
N/A
IrDA
N/A
Ethernet
One Gigabit Ethernet Controller (Intel® WG82567LM)
Audio
N/A
USB
Eight USB ports
Keyboard & Mouse
N/A
DISPLAY
Graphic Controller
Intel® GM45 integrated Graphics Media Accelerator 4500MHD
(Intel® GMA 4500MHD)
Graphic Memory
Dynamic share system memory (Intel® DVMT 5.0)
Display Interface
- Support CRT, LVDS, TV-out and SDVO display interfaces
- CRT display resolution up to 2048x1536 @ 85Hz refresh
Modular-PCOM-B213VG 118
Intel® AtomTM based Type II COM Express
module with DDR2 SDRAM, VGA, Gigabit
Ethernet, SATA and USB
PCOM-B214VG
200-pin SO-DIMM socket
Intel® AtomTM N270
Active Heat Sink
Intel® ICH7M
Intel® 945GSE
Passive Heat Sink
FEATURES
®
TM
The Intel Atom N270 and 945GSE platform
that provides cost effective solution
technology
Intel® AtomTM N270 + 945GSE + ICH7M
platform brings under 10W TDP solution for
easy fan-less applications
SATA and IDE interface provide best cost
effective functions for market
Architecture of module and carrier boards
speeds up time-to-market of tailor-made
equipment
GENERAL
Processor
CPU & Package: Intel® AtomTM N270 1.6GHz in FCPGA package
FSB: 533MHz
Chipset/Core Logic
Intel® 945GSE and ICH7M
System Memory
Up to 2GB DDR2 533 SDRAM on one SO-DIMM socket
BIOS
Award BIOS
Storage Devices
EIDE: Support one EIDE channel with Ultra DMA 100/66/33
SATA: Support two SATA 150 drives
Solid State Disk
N/A
Watchdog Timer
N/A
Expansion Interface
- One SDVO port
- Three PCI Express x1
- Four PCI devices
- LPC interface
- AC'97/High definition audio interface
Hardware Monitoring
CPU temperature
Dimension
Dimension : 125(L) x 95(W) mm; 4.9"(L) x 3.7" (W)
Environment
Operating Temperature: 0 to 60oC
Storage Temperature: -20 to 80oC
Relative Humidity: 5% to 90%, non-condensing
Support one SODIMM socket and up to 2GB
memory size
I/O
ORDERING GUIDE
Standard
PCOM-B214VG
Intel ® AtomTM processor based Type II COM
Express module with DDR2 SDRAM, VGA,
Gigabit Ethernet and USB
MIO
N/A
IrDA
N/A
Ethernet
One Gigabit Ethernet Controller (Intel® WG82574L)
Audio
N/A
USB
Eight USB ports
Keyboard & Mouse
N/A
DISPLAY
119
Modular-PCOM-B214VG
Graphic Controller
Intel® 945GSE integrated Graphics Media Accelerator
(Intel® GMA 950)
Graphic Memory
Dynamic share system memory up to 224MB (Intel® DVMT 3.0) or static share
system memory up to 128MB
Display Interface
- Support CRT, LVDS, TV-out and SDVO display interfaces
- CRT display resolution up to [email protected] refresh
PCOM-B215VG
Intel® ATOM based Type II micro-COM Express
module with DDR2 SDRAM, VGA, Gigabit
Ethernet, SATA, USB and NAND Flash
SODIMM sockets
Intel® ATOMTM N450/D510
Intel® ICH8M
ATA 4GB Solid State Drive
FEATURES
GENERAL
Processor
The Intel® ATOM N450(Pineview-M) / D410
(Pineview-D, Single core) D510(Pineview-D,
Duo core) and ICH8M platform that provides
cost effective solution with low power and
duo core processor technology
CPU: Intel® ATOM N450/D510 in FCBGA package
- N450
- D510
Chipset/Core Logic
Intel® ICH8M
System Memory
Supports up to 4GB DDR2 667 SDRAM on one SODIMM
BIOS
AMI BIOS
Intel® Pineview-M / Pineview-D can be
supported on the same compact board
Storage Devices
IDE: Support one IDE channel with Ultra DMA 100/66/33
SATA: Support three SATA 300 drives
Support five PCI Express lanes, four x1
lanes can be configured to one x4 lane
Solid State Disk
On-board ATA 4GB Solid State Drive, up to 8G Byte
Watchdog Timer
N/A
On-board ATA 4GB Solid State Drive, up to
8G Byte
Expansion Interface
Support one DDR2 533/667MHz SDRAM,
up to 4GB memory size
- Five PCI Express x1 lanes of which four x1 lanes can be configured to one
x4 lane
- Four PCI devices
- LPC Interface
- AC97 / High definition audio interface
Hardware Monitoring
CPU Temperature
Support MPEG2 Decode in HW
Power Requirement
TBA
Dimension
Dimension : 70(L) x 70(W) mm; 2.75"(L) x 2.75" (W)
Environment
Operating Temperature: 0 to 60oC
Storage Temperature: -20 to 80oC
Relative Humidity: 5% to 90%
I/O
ORDERING GUIDE
Standard
PCOM-B215VG
Intel ® ATOM based Type II micro-COM Express
module with DDR2 SDRAM, VGA, Gigabit
Ethernet, SATA, USB and NAND Flash
* Specifications are subject to change without notice.
* Celeron M® and Pentium® M are registered trademarks of Intel
Corporation.
* Other trademarks, logo, brands and company are the property
of their respective owners.
MIO
N/A
IrDA
N/A
Ethernet
One Gigabit Ethernet Controller (Realtek RTL8111C-VC-GR)
Audio
N/A
USB
Eight USB ports
Keyboard & Mouse
N/A
DISPLAY
Graphic Controller
- N450 integrated Generation 2.5 graphics, supports DX9 Graphics up to
200MHz
- D510 integrated Generation 3.5 graphics, supports DX9 Graphics up
to 400MHz
Graphic Memory
Dynamic share system memory up to 256MB (Intel® DVMT 4.0)
Display Interface
- Support CRT, 1x 18bit LVDS display interfaces
- Resolution:
CRT display: Pineview-M: up to 1400 x 1050 @ 60Hz refresh
Pineview-D: up to 2048 x 1536 @ 60Hz refresh
LVDS display: Pineview-M: up to 1280 x 800
Pineview-D: up to 1366 x 768
Modular-PCOM-B215VG 120
Intel® Arrandale processor based Type II COM
Express module with DDR3 SDRAM, VGA
Gigabit Ethernet 3. 0 GT/s SATA and USB
PCOM-B216VG
204pin DDR3 SODIMM socket
Intel® QM57
FEATURES
®
The Intel Arrandale and QM57 platform with
turbo boost technology to maximize CPU &
Graphic performance
Intel® Arrandale platform support variously
powerful processor from ultra low power to
mainstream performance type
Supports Intel® intelligent power sharing
technology to reduce TDP (Thermal
Design Power)
Enhance Intel® vPro efficiency by Intel®
82577LM GbE PHY and AMT6.0
technology
Support two DDR3 800/1066 SDRAM on
two SODIMM sockets, up to 8GB memory
size
ORDERING GUIDE
Standard
PCOM-B216VG
Intel ® Arrandale processor based Type II COM
Express module with DDR3 SDRAM, VGA,
Gigabit Ethernet, 3.0GT/s SATA and USB
Intel ® Core i7-610E SV (4M Cache, 2.53 GHz)
CPU
Support List Intel® Core i7-620LE LV (4M Cache, 2.00 GHz)
Intel ® Core i7-620UE ULV (4M Cache, 1.06 GHz)
Intel ® Core i5-520E SV (3M Cache, 2.40 GHz)
Intel ® Core i3-330E SV (3M Cache, 2.13 GHz)
Intel ® Celeron P4505 SV (2M Cache, 1.86 GHz)
* Specifications are subject to change without notice.
* Arrandale Core i7 / i5 / i3 and Celeron are registered trademarks
of Intel Corporation.
* Other trademarks, logo, brands and company are the property
of their respective owners.
121 Modular-PCOM-B216VG
Intel® Arrandale processor
GENERAL
Processor
CPU & Package: Intel® 45nm Arrandale Core i7/i5/i3 or Celeron P4505
processor up to 2.53 GHz with 4MB Cache in FC-BGA package
DMI x4 Link: 4.8GT/s (Full-Duplex)
Chipset/Core Logic
Intel® QM57
System Memory
Up to 8GB DDR3 800/1066 SDRAM on two SODIMM sockets
BIOS
UEFI AMI BIOS
Storage Devices
SATA: Four SATA 300 drivers; IDE:one EIDE channel with Ultra DMA
100/66/33
Solid State Disk
N/A
Watchdog Timer
N/A
Expansion Interface
- One PCI Express x16
- Four PCI devices
- Six PCI Express x1
- LPC & SPI Interface
- High definition audio interface
Hardware Monitoring
CPU Voltage and Temperature
Power Requirement
TBA
Dimension
Dimension: 125(L) x 95(W) mm
Environment
Operation Temperature: 0~60 °C
Storage Temperature: -20~80 °C
Operation Humidity: 5~90%
I/O
MIO
N/A
IrDA
N/A
Ethernet
One Intel® 82577LM Gigabit Ethernet PHY
Audio
N/A
USB
Eight USB ports
Keyboard & Mouse
N/A
DISPLAY
Graphic Controller
Intel® Arrandale integrated Graphics Media Accelerator
(Gen 5.75 with 12 execution units)
Graphic Memory
Dynamic share system memory over 512MB (Intel® DVMT 5.0)
Display Interface
- Support CRT, LVDS, and PEG interfaces
- CRTdisplay resolution up to [email protected] refresh
PCOM-C210
ATX Form Factor Evaluation Carrier Board For COM
Express Type II Module
Gigabit Ethernet & Dual USB ports
Dual USB ports
Audio
COM port
VGA port
Parallel port
PS/2 Keyboard / Mouse
Four PCI Expansion
slots
LVDS port
Six PCI-E x1 slots
PCOM-C210 with PCOM module
PCI-E x16 slot
Four SATA ports
FEATURES
COM Express carrier board accepts Portwell
Type II COM Express modules
IDE channel
Rear I/O
GENERAL
Com Express Module
Portwell Type II COM Express Module
BIOS
Award BIOS (or BIOS on COM Express Module)
form factor to meet most standard
mounting space and provide more
expansions slots
Storage Devices
EIDE: Two EIDE devices with Ultra DMA 100/66/33
SATA: Four SATA ports
Solid State Disk
One Type II CF socket
On-board power and reset switches benefit
engineering testing or evaluation without a
chassis
Watchdog Timer
Programmable via software from 0.5 sec. to 254.5 min.
Expansion Interface
Four PCI, six PCI Express x1 and one PCI Express x16 expansion slots
(availability based on COM Express module)
2 EIDE, 4 SATA, 4 PCI, 6 PCI-E x1 and 1
PCI-E x16
Dimension
Dimension : 304.8(L) x 243.8(W) mm; 12"(L) x 9.6" (W)
Environment
Operating Temperature: 0 to 60oC
Storage Temperature: -20 to 80oC
Relative Humidity: 5% to 90%, non-condensing
ATX
CF Socket
FDD port
Allow user to select master BIOS on board
or from CPU module
I/O
ORDERING GUIDE
Standard
PCOM-C210
ATX Form Factor Evaluation Board For COM
Express Type II Module
MIO
RS232 x1, one FDD channel and one parallel port
IrDA
N/A
Ethernet
- Single 10BASE-T/100BASE-TX/1000BASE Ethernet
- Single RJ-45 connector with two LED indicators at rear I/O panel
Audio
High Definition Audio
USB
USB 2.0 x 6 (Dual ports at rear I/O panel; four ports internal)
Keyboard & Mouse
PS/2 keyboard & mouse
DISPLAY
Graphic Controller
Depends on selected PCOM Module
Graphic Memory
Depends on selected PCOM Module
Display Interface
Support VGA, LVDS interfaces with dual display capability
Modular-PCOM-C210 122
PQ7-M101G
Qseven, based on Intel® AtomTM Processor with
DDR2 SDRAM, LVDS Display, Gigabit Ethernet,
SDVO and SATA
Intel® US15W SCH
512MB or 1GB DDR2 Memory
2 SATA Ports
Intel® AtomTM Z510/530
Realtek 8111B GbE
* Actual Size
FEATURES
TM
Atom
Z510 (1.1GHz) or Z530 (1.6GHz)
Intel® US15W integrated GMA 500 Graphic,
full hardware acceleration of H.264, MPEG2,
VC1 and WMV9 is supported
GENERAL
Processor
Intel® AtomTM Processor Z510/Z530
Chipset/Core Logic
Intel® System Control Hub US15W
System Memory
Memory down, 512MB DDR2 400/533 SDRAM
BIOS
AMI
Support Two SATA Ports from Qseven
Golden Finger
Storage Devices
SDIO Interface, support boot from SD (SDIO 1.1); 2 x SATA
Solid State Disk
N/A
Ultra Low CPU and SCH TDP (Under 5W)
for fan-less application
Watchdog Timer
N/A
Expansion Interface
- One SDVO interface
- One PCI Express x1
- LPC Interface
- High definition audio interface
Full Hardware acceleration of H.264,
MPEG2, VC1 and WM V9 is supported
On board 512MB DDR2 supported
Hardware Monitoring
CPU Voltage and Temperature Sensing
4Mbit flash ROM for easy BIOS upgrade
and video BIOS for DFP
Dimension
Dimension : 70(L) x 70(W) mm; 2.75"(L) x 2.75" (W)
Environment
Operating Temperature: 0 to 60oC
Storage Temperature: -20 to 80oC
Relative Humidity: 5% to 90%, non-condensing
ORDERING GUIDE
Standard
PQ7-M101G-1100-0512
Intel ® AtomTM Z510 Processor based Qseven
module with 512MB DDR2 SDRAM, LVDS
Display, Gigabit Ethernet SDVO and SATA
PQ7-M101G-1600-0512
Intel ® AtomTM Z530 Processor based Qseven
module with 512MB DDR2 SDRAM, LVDS
Display, Gigabit Ethernet SDVO and SATA
PQ7-M101G-1600-1024
Intel ® AtomTM Z530 Processor based Qseven
module with 1024MB DDR2 SDRAM, LVDS
Display, Gigabit Ethernet SDVO and SATA
123 Modular-PQ7-M101G
I/O
MIO
N/A
IrDA
N/A
Ethernet
One Gigabit Ethernet Controller (Realtek RTL8111B-GR)
Audio
Intel® HDA
USB
USB 2.0 x 8
Keyboard & Mouse
N/A
DISPLAY
Graphic Controller
Intel® US15W SCH
Graphic Memory
Intel® GMA 500
Display Interface
LVDS / SDVO
Qseven, Intel® Embedded Menlow-XL Platform
with DDR2 SDRAM, LVDS Display, Gigabit
Ethernet, SDVO and SATA
PQ7-M102XL
512MB or 1GB DDR2 400/533 SDRAM
Intel® AtomTM Z510PT / Z520PT
Intel® US15WPT SCH
* Actual Size
FEATURES
TM
Atom Z510PT (1.1GHz) or Z520PT
(1.33GHz)
Intel® US15WPT integrated GMA 500
Graphic, full hardware acceleration of H.264,
MPEG2, VC1 and WMV9 is supported
Support Two SATA Ports from Qseven
Golden Finger
Ultra Low CPU and SCH TDP (Under 5W)
for fan-less application
Internal LVDS and SDVO interface for dual
independent display
On board 512MB DDR2 supported
4Mbit flash ROM for easy BIOS upgrade
and video BIOS for DFP
Intel® 82574 IT
GENERAL
Processor
Intel® AtomTM Processor Z510PT/Z520PT
Chipset/Core Logic
Intel® System Control Hub US15WPT
System Memory
Memory down, 512MB 400/533 SDRAM
BIOS
AMI
Storage Devices
SDIO Interface, support boot from SD (SDIO 1.1); 2 x SATA
Solid State Disk
N/A
Watchdog Timer
N/A
Expansion Interface
- One Port SDVO interface
- One PCI Express x1
- LPC Interface
- High definition audio interface
Hardware Monitoring
CPU Voltage and Temperature Sensing
Dimension
Dimension : 70(L) x 70(W) mm; 2.75"(L) x 2.75" (W)
Environment
Operating Temperature: -40 to 85oC
Storage Temperature: -40 to 85oC
Relative Humidity: 5% to 95%, non-condensing
I/O
ORDERING GUIDE
Standard
PQ7-M102XL-1100-0512
Intel ® AtomTM Z510PT Processor based
Qseven module with 512MB DDR2 SDRAM,
LVDS Display, Gigabit Ethernet SDVO and
SATA
PQ7-M1102XL-1330-0512
Intel ® AtomTM Z520PT Processor based
Qseven module with 512MB DDR2 SDRAM,
LVDS Display, Gigabit Ethernet SDVO and
SATA
MIO
N/A
IrDA
N/A
Ethernet
One Gigabit Ethernet Controller (Intel® 82574 IT)
Audio
Intel® HDA
USB
USB 2.0 x 8
Keyboard & Mouse
N/A
DISPLAY
Graphic Controller
Intel® US15WPT SCH
Graphic Memory
Intel® GMA 500
Display Interface
LVDS / SDVO
Modular-PQ7-M102XL 124
Qseven, Based on Intel® eMenlow XL
Platform with DDR2 SDRAM,SATA
LVDS Display, Gigabit Ethernet,
SDVO and NANDrive
PQ7-M103XL
512MB or 1GB DDR2 400/533 SDRAM
Intel® AtomTM Z510PT/Z520PT
PCI Express Switch
Intel® US15WPT SCH
Solid State Drive
Intel® 82574 IT
*Actual Size
FEATURES
GENERAL
Processor
Intel® Atom™ Processor Z510PT / Z520PT (with Hyper-Threading Technology)
Chipset/Core Logic
Intel® System Control Hub US15WPT
System Memory
Memory down, Up to 1 GB DDR2 400/533 SDRAM, single channel (64 bits
wide), 1 rank
BIOS
AMI
Storage Devices
SATA x2, SSD on module
LVDS and SDVO interface for dual
independent display
Solid State Disk
On-borad ATA 1GB Solid State Drive, up to 4G Byte support (optional)
Watchdog Timer
Customization
Full Hardware acceleration of H.264,
MPEG2, VC1 and WMV9 is supported
Expansion Interface
On board DDR2 supported up 1GB
- Two PCI Express x1 lanes (3rd lane is available if no GbE support)
- One SDVO interface
- LPC Interface
- High definition audio interface
4Mbit flash ROM for easy BIOS upgrade
and video BIOS for DFP
Hardware Monitoring
EMC 1402 for Voltage and Temperature Sensing
Dimension
Dimension : 70(W) x 70(L) mm; 2.75"(W) x 2.75" (L)
Environment
Operation Temperature:-40 to 85°C
Storage Temperature: -40 to 85°C
Operation Humidity: 5 to 90%
Atom™
Z510PT (1.1GHz) or Z520PT
(1.33GHz)
®
Intel US15WPT integrated GMA 500
Graphic
Ultra Low CPU and SCH TDP (Under 5W)
for fan-less application
ORDERING GUIDE
Standard
Optional
PQ7-M103XL-1100-0512-1G SSD
Intel ® Atom™ Z510PT Processor based
Qseven module with 512MB DDR2 SDRAM,
LVDS Display, Gigabit Ethernet, SDVO and
1GB SSD
PQ7-M103XL-1100-1024-1G SSD
Intel ® Atom™ Z510PT Processor based
Qseven module with 1GB DDR2 SDRAM,
LVDS Display, Gigabit Ethernet, SDVO and
1GB SSD
PQ7-M103XL-1330-0512-1G SSD
Intel ® Atom™ Z520PT Processor based
Qseven module with 512MB DDR2 SDRAM,
LVDS Display, Gigabit Ethernet, SDVO and
1GB SSD
PQ7-M103XL-1330-1024-1G SSD
Intel ® Atom™ Z520PT Processor based
Qseven module with 1GB DDR2 SDRAM,
LVDS Display, Gigabit Ethernet, SDVO and
1GB SSD
Heat Spreader
70x62x8mm for PQ7-M103XL with 512MB
DDR2 SDRAM
Heat Spreader
70x62x8mm for PQ7-M103XL with 1GB DDR2
SDRAM
125 Modular-PQ7-M103XL Series
I/O
MIO
N/A
IrDA
N/A
Ethernet
One Gigabit Ethernet Controller (Intel® 82574 IT)
Audio
Intel® High Definition Audio (Intel® HD Audio)
USB
USB 2.0 x 8
Keyboard & Mouse
N/A
DISPLAY
Graphic Controller
Intel® US15WPT SCH
Graphic Memory
Intel® GMA 500
Display Interface
- Single channel 112MHz LVDS transmitter, supports display with 1x18 and
and 1x24 bit data mapping up to resolutions of 1366x768 pixel
- Single channel SDVO interface, supports resolutions up to 1280x1024 pixel
- Dual independent display support
Qseven, based on Intel® AtomTM Processor
with DDR2 SDRAM, LVDS Display, Gigabit
Ethernet, SDVO and SATA
PQ7-M104G
Up to 2GB DDR2 Memory
Intel® US15W SCH
2 SATA Ports
Intel® AtomTM Z510/530
Realtek 8111D GbE
FEATURES
Atom™
Z510 (1.1GHz) or Z530 (1.6GHz)
Intel® US15W integrated GMA 500 Graphic,
full hardware acceleration of H.264, MPEG2,
VC1 and WMV9 is supported
GENERAL
Qseven Module
Intel® Atom™ Processor Z510/Z530
Chipset/Core Logic
Intel® System Control Hub US15W
System Memory
Memory down, up to 2GB DDR2 400/533 SDRAM
BIOS
AMI
Support two SATA and three PCI Express
lanes from Qseven Golden Finger
Storage Devices
SDIO Interface
Solid State Disk
On-board ATA 1GB Solid State Drive, up to 8G Byte support (optional)
Ultra Low CPU and SCH TDP (Under 5W)
for fan-less application
Watchdog Timer
N/A
Expansion Interface
- One Port SDVO Interface
- Three PCI Express x1 lanes (fourth lanes is available if no SATA support)
- Two Ports SATA Interface
- LPC Interface
- High Definition Audio Interface
Hardware Monitoring
CPU Voltage and Temperature Sensing
Dimension
Dimension : 70(W) x 70(L) mm; 2.75"(W) x 2.75" (L)
Environment
Operating Temperature: 0 to 60oC
Storage Temperature: -20 to 80oC
Relative Humidity: 5 to 90%
Internal LVDS and SDVO interface for dual
independent display
On board up to 2GB DDR2 supported
ORDERING GUIDE
Standard
PQ7-M104G-1100-0512
Intel ® Atom™ Z510 Processor based Qseven
module with 512MB DDR2 SDRAM, LVDS
Display, Gigabit Ethernet, SDVO and SATA
PQ7-M104G-1100-1024
Intel ® Atom™ Z510 Processor based Qseven
module with 1GB DDR2 SDRAM, LVDS
Display, Gigabit Ethernet, SDVO and SATA
PQ7-M104G-1100-2048
Intel ® Atom™ Z510 Processor based Qseven
module with 2GB DDR2 SDRAM, LVDS
Display, Gigabit Ethernet, SDVO and SATA
PQ7-M104G-1600-0512
Intel ® Atom™ Z530 Processor based Qseven
module with 512MB DDR2 SDRAM, LVDS
Display, Gigabit Ethernet, SDVO and SATA
PQ7-M104G-1600-1024
Intel ® Atom™ Z530 Processor based Qseven
module with 1GB DDR2 SDRAM, LVDS
Display, Gigabit Ethernet, SDVO and SATA
PQ7-M104G-1600-2048
Intel ® Atom™ Z530 Processor based Qseven
module with 2GB DDR2 SDRAM, LVDS
Display, Gigabit Ethernet, SDVO and SATA
I/O
MIO
N/A
IrDA
N/A
Ethernet
One Realtek Gigabit Ethernet Controller (RTL8111D)
Audio
Intel® HDA
USB
USB 2.0 x 8
Keyboard & Mouse
N/A
DISPLAY
Graphic Controller
Intel® US15W SCH
Graphic Memory
Intel® GMA 500
Display Interface
LVDS / SDVO
Modular-PQ7-M104G 126
PQ7-C100XL
3.5" ESB Form Factor Carrier Board For Qseven
Module
COM (RS232/422/485)
Four USB Ports
12V DC-IN
GbE port
VGA
SDIO
PQ7-M102XL with Qseven module
LVDS port
FEATURES
Rear I/O
GENERAL
Qseven module
Portwell Qseven module PQ7-M102XL Series
BIOS
AMI BIOS (or BIOS and Qseven Module)
Storage Devices
SATA x 2
Solid State Disk
One SD socket (Support boot from SD)
Watchdog Timer
Programmable via software from 0.5 sec. to 254.4 min.
On Board DC to DC circuit for DC in
application
Expansion Interface
One mini-PCIe connector
Dimension
Dimension : 146(L) x 105(W) mm; 5.75"(L) x 4.13" (W)
Mini-PCIe support
Environment
Support boot from SD (SDIO 1.1)
Operating Temperature: -40 to 85oC
Storage Temperature: -20 to 80oC
Relative Humidity: 5% to 90%, non-condensing
Qseven carrier board accept Portwell Qseven
modules
®
TM
Intel Atom
3.5” ESB form factor to embedded
applications
Z5XXPT and SCH US15WPT
I/O
ORDERING GUIDE
Standard
MIO
RS232 x1, Client USB x1, Mic-in/Line-out
IrDA
Yes
Ethernet
IEEE802.3 10/100/1000 BASE-T Gigabit Ethernet compliant
Audio
Mic-in, Line-out
USB
USB 2.0 x 7
Keyboard & Mouse
N/A
PQ7-C100XL
Qseven Module in 3.5" ESB Form Factor
Carrier Board with Wide range temperature
support
DISPLAY
127
Graphic Controller
Intel® US15WPT SCH
Graphic Memory
Intel® GMA 500
Display Interface
LVDS / VGA
PQ7-C200
Mini-ITX Form Factor Carrier Board For Qseven
Module with Dual Displays and Two GbE
Dual GbE + Four USB Ports
VGA
Audio
Parallel Port
COM1 (RS232)
PS2 Keyboard/Mouse
COM2 (RS232/422/485) selectable
PCI Expansion
slot
mini-PCI connector
PCIE x1 Expansion
slot
PQ7-C200 with Qseven module
Two SATA Ports
SDIO
FEATURES
Qseven carrier board accept Portwell Qseven
modules
®
TM
Z5XX and SCH US15W
One IDE channel
Rear I/O
LVDS
GENERAL
Qseven Module
Portwell Qseven module PQ7-M100 Series
BIOS
Award BIOS (or BIOS on Qseven Module)
Storage Devices
IDE x1, SATA x2
Intel Atom
Mini-ITX form factor for embedded
applications
Solid State Disk
One SD socket
Watchdog Timer
Programmable via software from 0.5 sec. to 254.5 min.
Dual PCI interface Gigabit Ethernet ports
Expansion Interface
One IDE channel and Two SATA 150 Ports
- One mini-PCI connector
- One PCI expansion connector
- One PCIE x1 expansion connector by riser card
One PCI and PCIE x1 expansion slot via riser
card
Hardware Monitoring
CPU temperature
Dimension
Dimension : 170(L) x 170(W) mm; 6.69"(L) x 6.69" (W)
Environment
Operating Temperature: 0 to 60oC
Storage Temperature: -20 to 80oC
Relative Humidity: 5% to 90%, non-condensing
I/O
MIO
RS232 x1, RS232/422/485 selectable x1, LPT x1, K/B x1, Mouse x1, GbE x2
IrDA
N/A
Ethernet
IEEE802.3 10/100/1000BASE-T Gigabit Ethernet compliant
Audio
Mic in, Line in, Line out
USB
USB 2.0 x 4 ports and USB 2.0 x2 with header
Keyboard & Mouse
PS/2 Keyboard & Mouse
ORDERING GUIDE
Standard
PQ7-C200
Qseven Module in Mini-ITX Form Factor
Carrier Board with Dual Displays and Two
GbE
DISPLAY
Graphic Controller
Intel® US15W SCH
Graphic Memory
Intel® GMA 500
Display Interface
LVDS / VGA
Modular-PQ7-C200 128
PEM-E200VLA
Intel® AtomTM based Type ETX module with DDR2
SDRAM, VGA, Fast Ethernet, SATA and USB
200-pin SODIMM socket
Two SATA Port
Intel® ICH7M
ATOMTM N270
Fast Ethernet
Intel® 945GSE
FEATURES
The Intel® AtomTM N270 and 945GSE
platform that provides cost effective solution
and technology
The Intel® platform brings under 10W TDP
solution for easy fan-less design
SATA and IDE interface provide best cost
effective functions for market
Architecture of module and carrier boards
speeds up time-to-market of tailor-made
equipment
GENERAL
Processor
CPU & Package: Intel® AtomTM N270 1.6GHz in FCBGA package
FSB: 533MHz
Chipset/Core Logic
Intel® 945GSE and ICH7M
System Memory
Up to 2GB DDR2 533 SDRAM on one 200-pin SODIMM socket
BIOS
Award BIOS
Storage Devices
EIDE: Support two EIDE channel with Ultra DMA 100/66/33
SATA: Support two SATA 150 drives
Solid State Disk
N/A
Watchdog Timer
Programmable via software from 1 sec. to 255 min.
Expansion Interface
- Two IDE channels
- Four PCI devices
- ISA Bus
- Two COM Ports
- One Printer Port
- PS/2 Keyboard and Mouse
- Line Out, Line In and MIC
Hardware Monitoring
CPU temperature
Dimension
Dimension : 114(L) x 95(W) mm; 4.5"(L) x 3.7" (W)
Environment
Operating Temperature: 0 to 60oC
Storage Temperature: -20 to 80oC
Relative Humidity: 5% to 90%, non-condensing
Support one SODIMM socket and up to 2GB
memory size
ORDERING GUIDE
Standard
PEM-E200VLA
Intel ® AtomTM N270, 945GSE platform based
ETX module with DDR2 SDRAM, VGA, Fast
Ethernet and USB
I/O
MIO
Two serial ports (TTL Level)
IrDA
Yes
Ethernet
One Fast Ethernet Controller (Realtek RTL8102EL)
Audio
One HDA Audio Codec
USB
Four USB ports
Keyboard & Mouse
PS/2 Keyboard and Mouse
DISPLAY
129 Modular-PEM-E200VLA
Graphic Controller
Intel® 945GSE integrated Graphics Media Accelerator (Intel® GMA 950)
Graphic Memory
Dynamic share system memory up to 224MB (Intel® DVMT 3.0) or static share
system memory up to 128MB
Display Interface
- Support dual VGA (2nd supported by Chrontel CH7317A), LVDS and TV-out
(optional)
- CRT display resolution up to [email protected] refresh
About-WEBS
WEBS: Portwell Intelligent Fan-less System
Compact, Flexible, Rugged Computing Systems
With the capability of leading embedded computing technology, Portwell developed the industrial grade
WEBS fan-less computing systems for harsh environment applications such as factory automation,
transportation, facility management, networking and public works.
To meet these harsh environmental parameters, each WEBS computing system was designed by precise
thermal simulation and verification to make the system stable and user friendly.
The all-aluminum chassis design provides effective heat dissipation and transfers the heat out of the system
quickly and easily.
Built with the latest Intel® chipsets, the WEBS systems feature not only superior performance but also low
power consumption. They are suitable for energy-critical applications and idea for environmental protection.
131 Portwell Intelligent Fan-less System
Quality Assurance
1 Design & Analysis
Portwell WEBS systems use quality assurance reviewing procedures in the critical early stages of development.
Designing a stable product makes it easy for quality checking and complies with Design for Quality (DFQ).
At the development stage the product design also involves the material and assembly important for production, with
the focus on Design for Manufacturability (DFM). This develops simple, consistent and efficient system structures
and endows the product with a stable quality.
With its experienced engineering team, plus the complete development facility with 3D, circuit and layout design
equipments, Portwell is able to supply more efficient system development to support its customers in “Design Win”.
Design & analysis is performed by 3D workstation. (WEBS-2120)
Circuit design & layout by advanced tools (NANO-8044)
2 Thermal Design
Since there is no fan and airflow inside the fan-less WEBS systems, handling the thermal output becomes one of
the most important concerns. System heat comes from ICs on the embedded board and this is pre-determined by
Intel®. Therefore, the key to developing a reliable fan-less system is determined by two major factors.
FLIR Systems
First is to balance the heat on the embedded board and make sure it does not accumulat. Determining the thermal
balance for the hot components is a prime concern. The picture below shows the heat situation of the NANO-8044,
NANO-ITX embedded board used in the WEBS-2120 system. The heat in this example is arranged and balanced
for superior dissipation in a fan-less system design.
60.5 °C
60
Ar1
50
Ar2
40
30
28.1
NANO-8044 M/B
Thermal image of NANO-8044 M/B
Second is to maximize the arrangement of heat dissipation by system design. WEBS Systems are designed with
an all-aluminum chassis that is ideal for heat dissipation. Heat sinks link the ICs on the embedded board and the
aluminum chassis for direct heat transference. The heat transfers from the bottom up so the lower temperature
is at the chassis top for greater ease of use and protection. The pictures below illustrate the heat flow of a WEBS
system. Balancing the heat of the product in this way makes the perfect fan-less system.
WEBS-2120 Heat-flow (Bottom)
WEBS-2120 Heat-flow (Top)
Intelligent Fan-less Embedded Solutions 132
Quality Assurance
3 Thermal Validation
After completing the thermal design, the WEBS system starts the thermal validation by following Intel’s thermal
guide and the system is tested inside the calibrated chamber with defined temperatures. The efficacy of the
WEBS system is further improved when the temperature of any component is over specification. Thermal tests are
conducted until all the major ICs are below thermal specification.
Holes are made on the heat sink and
thermal sensor cables are added for
measuring the temperature
Holes are made on the heat sink and thermal sensor cables
are added for measuring the temperature
4 Safety & Reliability Validation
In addition to the thermal validation, the WEBS systems undergo safety assessment and tests and achieve CE and
FCC certification. Testings include ESD, EMI and EMC.
To ensure product quality, complete quality assurance tests are performed during both the development and the
manufacturing phases for all system-level products. Portwell WEBS systems are tested and comply with safety
regulations, and are reliable to be used in the harsh environments.
-Based on customer’s requirements, Portwell can do additional tests with a NRE (non-recurring engineering) charge.
ESD Test
EMC Test
EMC Test
Vibration Test
Packing Vibration Test
Shock Test
Packing Drop Test
133 Intelligent Fan-less Embedded Solutions
Brick Concept
Brick Concept
As well as stable quality requirements, users are always looking for a unique product to differenciate them from
their competitors. To simplify system customization, Portwell created the Brick concept, an intelligent structure for
the WEBS systems that builds the WEBS chassis using three simple elements: wall, pillar and cover. This makes
the chassis flexible and easy for customization by following customer’s requirements. The illustation below shows
the segments for customization.
* May necessitate extra cost and MOQ for an individual customization.
Custom Color
Rugged Wall
Net Wall
Private Logo
Expand I/O (By model)
With its flexible structure, a Portwell WEBS system can adjust the size of its form-factor to supply a customized
chassis for customer. The three system sizes below illustrate the standard WEBS system form-factors. Customer
can adapt any model to suit their applications. (Size unit is mm)
150x150x51 (NANO-ITX)
200x150x51 (3.5” ECX)
200x200x51 (Mini-ITX)
Configuration
Full System: Chassis + (Power Module) + Adaptor + Cable + Embedded Board + Memory + HDD/CF
Bare System (By requuest only): Chassis + (Power Module) + Adaptor + Cable + Embedded Board
Intelligent Fan-less Embedded Solutions 134
WEBS Reference Table
Low Power
Low Power
Compact &
Low Power
Low Power
Slim & Cable-less
WEBS-3330
WEBS-2120
WEBS-2121
WEBS-1320
WEBS-3331
WADE-8070
NANO-8044
NANO-8045
PEB-2737
WADE-8071
MINI-ITX
NANO-ITX
NANO-ITX
3.5” ECX
MINI-ITX
Atom™ N270
1.6GHz
Atom™ Z510 1.1GHz
Atom™ Z530 1.6GHz
Atom™ Z510 1.1GHz
Atom™ Z530 1.6GHz
Atom™ Z510 1.1GHz
Atom™ Z530 1.6GHz
Atom™ N270 1.6GHz
945GSE+ICH7-M
US15W
US15W
US15W
945GSE+ICH7-M
FSB
533MHz
400MHz / 533MHz
400MHz / 533MHz
400MHz / 533MHz
533MHz
BIOS
Award BIOS
AMI BIOS
AMI BIOS
AMI BIOS
Award BIOS
200-pin SO-DIMM
200-pin SO-DIMM
200-pin SO-DIMM
200-pin SO-DIMM
200-pin SO-DIMM
Max. Memory
DDR2 2GB
DDR2 2GB
DDR2 2GB
DDR2 2GB
DDR2 2GB
Solid State
CF Socket
CF Socket
CF Socket
CF Socket
CF Socket
Model
Embedded
Board
Form Factor
Intel® Processor
Platform
Intel® Chipset
Socket
Memory
Storage
HDD
2.5” SATA HDD
2.5” PATA
2.5” SATA HDD
2.5” SATA HDD
N/A
Networking
Controller (interface)
RTL8111C-VB
(PCIE x1)
Intel® 82574L
(PCIE x1)
RTL8111C-VC
(PCIE x1)
RTL8111C-VC
(PCIE x1)
RTL8111C-VC
(PCIE x1)
Video
Controller
GMA 950
GMA 500
GMA 500
GMA 500
GMA 950
Audio
Codec
Realtek ALC662-GR
Realtek ALC262
Realtek ALC262
Realtek ALC262-VC2GR
Realtek ALC662-GR
Winbond W83627UHG
Winbond W83627DHG
Winbond W83627DHG
Winbond W83627DHG
Winbond W83627HGAW
Programable
(1sec. to 255min.)
Programable
(1sec. to 255min.)
Programable
(1sec. to 255min.)
Programable
(1sec. to 255min.)
Programable
(1sec. to 255min.)
COM Ports
1x RS232
1x RS232/422/485
1x RS232/422/485
1x RS232
1x RS232
1x RS232
Digital I/O
N/A
N/A
N/A
N/A
N/A
4
2
2
4
4
VGA
1 x VGA
1 x VGA
N/A
1 x VGA
1 x VGA
DVI
N/A
N/A
1 x DVI
N/A
N/A
LAN
1 x Gigabit Ethernet
1 x Gigabit Ethernet
1 x Gigabit Ethernet
1 x Gigabit Ethernet
1 x Gigabit Ethernet
PS/2
1 x KB; 1 x Mouse
N/A
N/A
1 x KB; 1 x Mouse
N/A
Audio
Line-out and Mic-in
Line-out and Mic-in
Line-out and Mic-in
Line-out and Mic-in
Line-out and Mic-in
1 x CF Socket
1 x CF Socket
1 x CF Socket
1 x CF Socket
1 x CF Socket
N/A
Controller
H/W Monitor
WDT
USB 2.0
I/O
Internal CF
1 x Mini-PCI socket
N/A
N/A
SDIO socket
(Internal onboard)
System
12V DC-in
12V DC-in
12V DC-in
12V DC-in
12V DC-in
Adaptor
100 ~ 240V
100 ~ 240V
100 ~ 240V
100 ~ 240V
100 ~ 240V
XP, Vista, CE, Linux
XP, XPe, CE, Linux
XP, XPe, CE, Linux
XP, Vista, CE, Linux
XP, Vista, CE, Linux
Temperature
-5 ~ 45°C
-5 ~ 45°C
-5 ~ 45°C
-5 ~ 45°C
-5 ~ 45°C
Hmidity (RH)
5 ~ 95%,
non-condensing
5 ~ 95%,
non-condensing
5 ~ 95%,
non-condensing
5 ~ 95%,
non-condensing
10 ~ 90%,
non-condensing
200 x 200 x 51
150 x 150 x 51
150 x 150 x 51
200 x 150 x 51
200 x 200 x 36
Expansion
Power
OS Supported
Environmental
Parameters
Size (mm)
135 WEBS Embedded Fan-less Systems
WEBS Reference Table
Wide Range Power
Input
Wide Temp.
Range
Rich Function
Rich Function
Slim & Cable-less
WEBS-4330
WEBS-1310
WEBS-1330
WEBS-1340
WEBS-3332
WADE-8170
PEB-2738
PEB-2131VG2A
PEB-2780
WADE-8071
MINI-ITX
3.5” ECX
3.5” ECX
3.5” ECX
MINI-ITX
Atom™ N270 1.6GHz
Atom™ Z510 1.1GHz
Atom™ Z520 1.3GHz
Atom™ N270 1.6GHz
Atom™ N450/D510
1.6GHz
Atom™ N270 1.6GHz
945GSE+ICH7-M
US15W PT
945GSE+ICH7-M
ICH8-M
945GSE+ICH7-M
FSB
533MHz
400MHz / 533MHz
533MHz / 667MHz
667MHz
533MHz
BIOS
Award BIOS
AMI BIOS
Award BIOS
Award BIOS
Award BIOS
200-pin SO-DIMM
200-pin SO-DIMM
200-pin SO-DIMM
200-pin SO-DIMM
200-pin SO-DIMM
Max. Memory
DDR2 2GB
DDR2 2GB
DDR2 2GB
DDR2 2GB
DDR2 2GB
Solid State
CF Socket
CF Socket
CF Socket
CF Socket
CF Socket
2.5” SATA HDD
2.5” SSD
2.5” SATA HDD
2.5” SATA HDD
N/A
RTL8111C-VC
(PCIE x1)
Model
Embedded
Board
Form Factor
Intel® Processor
Platform
Intel® Chipset
Socket
Memory
Storage
HDD
Networking
Controller (interface)
ALC8111C
(PCIE x1)
Intel® 82574IT
(PCIE x1)
RTL8111D-VB-GR
(PCIE x1)
1x Intel® 82657V
1x Intel® 82583V
(PCIE x1)
Video
Controller
GMA 950
GMA 500
GMA 950
GMA 950
GMA 950
Audio
Codec
Realtek ALC655
Realtek ALC662-GR
Realtek ALC662
Realtek ALC262
Realtek ALC662-GR
ITE IT8712
Winbond W83627DHG
Winbond W83627UHG
Winbond W83627UHG
Winbond W83627HG-AW
Programable
(1sec. to 255min.)
Programable
(1sec. to 255min.)
Programable
(1sec. to 255min.)
Programable
(1sec. to 255min.)
Programable
(1sec. to 255min.)
COM Ports
2x RS232
1x RS232
1x RS232/422/485
4x RS232
3x RS232
1x RS232/422/485
1x RS232
Digital I/O
8-bit Digital I/O
8-bit Digital I/O
N/A
N/A
N/A
4
4
2
4
4
VGA
1 x VGA
1 x VGA
1 x VGA
1 x VGA
1 x VGA
DVI
1 x DVI-D
N/A
N/A
N/A
N/A
LAN
2 x Gigabit Ethernet
1 x Gigabit Ethernet
2 x Gigabit Ethernet
2 x Gigabit Ethernet
1 x Gigabit Ethernet
PS/2
1 x KB; 1 x Mouse
N/A
N/A
N/A
N/A
Audio
Line in, Line-out and
Mic-in
Line-out and Mic-in
Line-out
N/A
Line-out and Mic-in
1 x CF Socket
1 x CF Socket
1 x CF Socket
1 x CF Socket
1 x CF Socket
Controller
H/W Monitor
WDT
USB 2.0
I/O
Internal CF
Expansion
N/A
1 x Mini-PCIExpress
1 x Mini-PCIExpress
N/A
N/A
System
12V DC-in or 9~27V
DC-in(optional)
12V DC-in
12V DC-in
12V DC-in
12V DC-in
Adaptor
100 ~ 240V
100 ~ 240V
100 ~ 240V
100 ~ 240V
100 ~ 240V
XP, Vista, CE, Linux
XP, Vista, CE, Linux
XP, Vista, CE, Linux
XP, Vista, CE, Linux
XP, Vista, CE, Linux
Temperature
-5 ~ 45°C
-25 ~ 70°C
-5 ~ 45°C
-5 ~ 45°C
-5 ~ 50°C
Hmidity (RH)
10 ~ 90%,
non-condensing
5 ~ 95%,
non-condensing
10 ~ 90%,
non-condensing
10 ~ 90%,
non-condensing
10 ~ 90%,
non-condensing
200 x 200 x 62
200 x 150 x 51
200 x 150 x 51
200 x 150 x 51
200 x 200 x 40
Power
OS Supported
Environmental
Parameters
Size (mm)
Intelligent Fan-less Embedded Solutions 136
WEBS-3330
Embedded compact fan-less system with Intel®
Atom™ N270 based MINI-ITX board
FEATURES
Intel® Atom™ N270 1.6GHz processor and
Intel® 945GSE + ICH7-M chipset
One 200-pin SO-DIMM supports DDR2 SDRAM
up to 2GB
51mm
Dual display (VGA / DVI), Dual Gigabit Ethernet
and Dual serial ports
Fan-less design is ideal for enviromnent-critical
application
200mm
200mm
Optional DVD module
Optional PCI/e x1 expansion slot for additional
peripheral card
Versatile mounting solutions such as Wall and
Panel mount (Optional)
Single DC 12V power input for easy system
intergation
REAR I/O
SYSTEM
CPU
Intel® AtomTM N270 1.6GHz processor
FSB
533 MHz
BIOS
Award BIOS
System Chipset
Intel® 945GSE GMCH and ICH7-M
System Memory
Watchdog Timer
One 200-pin SO-DIMM support DDR2 400/533 up to 2GB
- 1 x SATA 2.5” HDD
- 1 x CF
Programmable via S/W from 1sec. to 255min.
H/W Status Monitor
Temperature (CPU and System), Voltage, Case open function
Expansion
1 x Mini-PCI socket
Storage
REAR PANEL
Serial Port
1 x RS232; 1 x RS232/422/485 selectable
Display
1 x VGA; 1 x DVI
USB
4 x USB 2.0
KB/MS
1 x K/B; 1 x Mouse
Audio Interface
Line-out and Mic-in
Ethernet
2 x Gigabit Ethernet
RS232/422/485
KB/MS
VGA
RS232
DVI
Ethernet
USB
WEBS-3330-1602
Antenna Hole
Audio
DC In
WEBS-3330-1603
Power Supply Unit
Power Input
DC 12V
Adaptor
AC 100~240V
ORDERING GUIDE
WEBS-3330-1600
MECHANICAL & ENVIRONMENTAL
Operation Temperature
-5~45°C
Storage Temperature
-20~80°C
Relative Humidity
10~90% non-condensing
Dimension (WxDxH)
200x200x51 mm; 7.9”x7.9”x2”
200x200x83 mm; 7.9”x7.9”x3.3” (with optional module)
1.8 kg
Weight
137 System-WEBS-3330
System with WADE-8070 (Atom™ N270 1.6GHz) + 2GB DDR2 +
120GB HDD
WEBS-3330-1602
System with WADE-8070 (Atom™ N270 1.6GHz) + 2GB DDR2 +
120GB HDD + DVD Module
WEBS-3330-1603
System with WADE-8070 (Atom™ N270 1.6GHz) + 2GB DDR2 +
120GB HDD + PCI/e x 1 expansion
WEBS-2120
Embedded compact fan-less system with Intel®
AtomTM Z510/Z530 based NANO-ITX board
FEATURES
Intel® Atom™ processor Z510/Z530 and System
Controller Hub US15W
Ultra low power and fan-less design
One 200-pin SO-DIMM supports DDR2 SDRAM
51mm
up to 2GB
Versatile interfaces such as Compact Flash and
2.5” HDD
Compact and user-friendly design for easy instal-
lation and maintenance
150mm
150mm
Versatile mounting solutions such as Wall, Panel
and DIN mount (Optional)
Vibration test (5grms/5~500Hz/operation) - Com-
pact Flash
Shock test (50g peak acceleration - 11msec. dura-
tion) - Compact Flash
REAR I/O
SYSTEM
CPU
Intel® Atom™ processor Z510 / Z530
FSB
400/533 MHz
BIOS
AMI BIOS
System Chipset
Intel® System Controller Hub US15W integrated GMA 500
Graphics
One 200-pin SO-DIMM support DDR2 400/533 up to 2GB
- 1 x SATA 2.5” HDD
- 1 x CF
Programmable via S/W from 1sec. to 255min.
System Memory
Storage
Watchdog Timer
H/W Status Monitor
- Temperature (CPU and System)
- Voltage (CPU Vcore, VBAT, 5VSB, 12V, 5V, 3.3V)
RS232/422/485
VGA
USB
Audio
DC In
LAN
Brick Concept
REAR PANEL
Serial Port
1 x RS232/422/485
Display
1 x VGA
USB
4 x USB 2.0
Audio Interface
Line-out and Mic-in
Ethernet
Ethernet 1 x Gigabit Ethernet
Power Supply Unit
Power Input
DC 12V
Adaptor
AC 100~240V
ORDERING GUIDE
MECHANICAL & ENVIRONMENTAL
Operation Temperature
-5~45°C
WEBS-2120-1100
Storage Temperature
-20~80°C
Relative Humidity
5~95% non-condensing
System with NANO-8044 (Atom™Z510 1.1GHz) + 1GB DDR2 +
120GB HDD
Dimension (WxDxH)
150x150x51 mm; 5.9”x5.9”x2”
WEBS-2120-1600
Weight
1 kg
System with NANO-8044 (Atom™ Z530 1.6GHz) + 2GB DDR2 +
120GB HDD
System-WEBS-2120 138
WEBS-2121
Embedded compact fan-less system with Intel®
Atom™ Z510/Z530 based NANO-ITX board
FEATURES
Intel® Atom™ processor Z510/Z530 and System
Controller Hub US15W
Ultra low power and fan-less design
One 200-pin SO-DIMM supports DDR2 SDRAM
up to 2GB
51mm
Versatile interfaces such as Compact Flash and
SATA 2.5”HDD
Compact and user-friendly design for easy
installation and maintenance
150mm
150mm
Versatile mounting solutions such as Wall, Panel
and DIN mount (Optional)
Vibration test (5grms/5~500Hz/operation) -
Compact Flash
Shock test (50g peak acceleration - 11msec.
duration) Compact Flash
REAR I/O
SYSTEM
CPU
Intel® AtomTM
FSB
400/533 MHz
BIOS
AMI BIOS
Intel® System Controller Hub US15W integrated GMA 500
Graphics
System Chipset
System Memory
Storage
Watchdog Timer
H/W Status Monitor
processor Z510 / Z530
RS232
USB
One 200-pin SO-DIMM support DDR2 400/533 up to 2GB
- 1 x SATA 2.5” HDD
- 1 x CF
Programmable via S/W from 1sec. to 255min.
- Temperature (CPU and System)
- Voltage (CPU Vcore, VBAT, 5VSB, 12V, 5V, 3.3V)
DC In
DVI
Ethernet
Audio
Brick Concept
REAR PANEL
Serial Port
1 x RS232
Display
1 x DVI
USB
2 x USB 2.0
Audio Interface
Line-out and Mic-in
Ethernet
1 x Gigabit Ethernet
Power Supply Unit
Power Input
DC 12V
Adaptor
AC 100~240V
MECHANICAL & ENVIRONMENTAL
ORDERING GUIDE
Operation Temperature
-5~45°C
Storage Temperature
-20~80°C
Relative Humidity
5~95% non-condensing
System with NANO-8045 (Atom™ Z510 1.1GHz) +1GB DDR2 +
120GB HDD
Dimension (WxDxH)
150x150x51 mm; 5.9”x5.9”x2”
WEBS-2121-1600
Weight
1 kg
System with NANO-8045 (Atom™ Z530 1.6GHz) +2GB DDR2 +
120GB HDD
139 System-WEBS-2121
WEBS-2121-1100
WEBS-1320
Embedded compact fan-less system with Intel®
Atom™ Z510/Z530 based 3.5” ECX board
FEATURES
Intel® Atom™ processor Z510/Z530 and Sys-
tem Controller Hub US15W
Ultra low power and fan-less design
One 200-pin SO-DIMM supports DDR2 SDRAM
51mm
up to 2GB
Versatile interfaces such as Compact Flash and
SATA 2.5” HDD
Compact and user-friendly design for easy
150mm
200mm
installation and maintenance
Versatile mounting solutions such as Wall,
Panel and DIN mount (Optional)
Single DC 12V power input for easy system
intergation
REAR I/O
SYSTEM
CPU
Intel® AtomTM processor Z510 / Z530
FSB
400/533 MHz
BIOS
AMI BIOS
Intel® System Controller Hub US15W integrated GMA 500
Graphics
One 200-pin SO-DIMM support DDR2 400/533 up to 2GB
- 1 x SATA 2.5” HDD
- 1 x CF
Programmable via S/W from 1sec. to 255min.
- Temperature (CPU and System)
- Voltage (CPU Vcore, VBAT, 5VSB, 12V, 5V, 3.3V)
System Chipset
System Memory
Storage
Watchdog Timer
H/W Status Monitor
Ethernet
DC In
USB
RS232
KB/MS
USB
Audio
VGA
Brick Concept
REAR PANEL
Serial Port
1 x RS232
Display
1 x VGA
USB
4 x USB 2.0
KB/MS
1 x K/B; 1 x Mouse
Audio Interface
Line-out and Mic-in
Ethernet
1 x Gigabit Ethernet
Power Supply Unit
Power Input
DC 12V
Adaptor
AC 100~240V
ORDERING GUIDE
MECHANICAL & ENVIRONMENTAL
Operation Temperature
-5~45°C
WEBS-1320-1100
Storage Temperature
-20~80°C
Relative Humidity
5~95% non-condensing
System with PEB-2737 (Atom™ Z510 1.1GHz) +1GB DDR2
+ 120GB HDD
Dimension (WxDxH)
200x150x51 mm; 7.9”x5.9”x2”
Weight
1.2 kg
WEBS-1320-1600
System with PEB-2737 (Atom™ Z530 1.6GHz) +2GB DDR2
+ 120GB HDD
System-WEBS-1320 140
Embedded slim fan-less system with Intel® AtomTM
N270 based MINI-ITX board
WEBS-3331
FEATURES
Intel® AtomTM N270 1.6GHz processor and
Intel® 945GSE + ICH7-M chipset
One 200-pin SO-DIMM supports DDR2
SDRAM up to 2GB
36mm
Analog Display: Up to 2048 x 1536 (QXGA)
36mm height supports thin client and DS ap-
plication
200mm
200mm
Fan-less and optional cable-less design for
easy maintenance
Versatile mounting solutions such as Wall and
Panel mount (optional)
Single DC 12V power input for easy system
intergation
CF socket for storage
REAR I/O
SYSTEM
CPU
Intel® AtomTM N270 1.6GHz processor
FSB
533 MHz
BIOS
Award BIOS
System Chipset
Intel® 945GSE GMCH integrated GMA 950 Graphics and
ICH7-M
System Memory
One 200-pin SO-DIMM supports DDR2 400/533 up to 2GB
SSD
1 x CF
Watchdog Timer
Programmable via S/W from 1sec. to 255min.
H/W Status Monitor
VGA
DC In
Audio
USB
RS232
Ethernet
Temperature (CPU and System), Voltage, Case open function
Brick Concept
REAR PANEL
Serial Port
1 x RS232
Display
1 x VGA
USB
4 x USB 2.0
Audio Interface
Line-out and Mic-in
Ethernet
1 x Gigabit Ethernet
Power Supply Unit
Power Input
DC 12V
Adaptor
AC 100~240V
MECHANICAL & ENVIRONMENTAL
ORDERING GUIDE
Operation Temperature
-5~45°C
Storage Temperature
-20~80°C
WEBS-3331-1600
Relative Humidity
10~90% non-condensing
System with WADE-8071 (Atom™ N270 1.6GHz) +
2GB DDR2 + 4GB CF
Dimension (WxDxH)
200x200x36 mm; 7.9”x7.9”x1.4”
WEBS-3331-1601
Weight
1.1 kg
System with WADE-8071 (Atom™ N270 1.6GHz) +
1GB DDR2 + 512MB CF
141 System-WEBS-3331
Embedded rugged compact fan-less system with
Intel® Atom™ N270 based MINI-ITX board
WEBS-4330
FEATURES
Intel® Atom™ N270 1.6GHz processor and Intel®
945GSE+ICH7-M chipset
Dual display (VGA / DVI-D), Dual Gigabit
Ethernet and Dual RS232
62mm
Optional GADIWA-R9271 (9~27V) for IVI
application
Rugged and Fan-less design is ideal for
environment-critical application
External GPIO (4 in, 4 out) for digital control
200mm
Versatile mounting solutions such as Wall and
Panel mount (Optional)
200mm
Single DC 12V power input for easy system
intergation
Two interfaces of DC power input by adaptor plug
or wiring type
REAR I/O
SYSTEM
CPU
Intel® AtomTM
FSB
533 MHz
BIOS
AMI BIOS
Intel® 945GSE GMCH integrated GMA 950 Graphics and
ICH7-M
System Chipset
N270 1.6GHz processor
System Memory
One 200-pin SO-DIMM support DDR2 400/533 up to 2GB
Storage
1 x CF, 1x HDD
Watchdog Timer
Programmable via S/W from 1sec. to 255min.
H/W Status Monitor
Temperature (CPU and System), Voltage
WEBS-4330-1600
Audio
KB/MS
VGA
Power
Switch
DVI
RS232
Ethernet
RS232
USB
REAR PANEL
Serial Port
2 x RS232
Display
1 x VGA + 1 x DVI-D
USB
4 x USB 2.0
KB/MS
1 x K/B; 1 x Mouse
Audio Interface
Line-in, Line-out and Mic-in
Ethernet
2 x Gigabit Ethernet
PS/2
1 x Keyboard. 1 x Mouse
Digital IO
8-bit Digital IO
Power Supply Unit
Power Input
DC 12V
Adaptor
AC 100~240V
Optional wire type DC-IN
DC 9V~27V
DC In
WEBS-4330-1603
Audio
KB/MS
VGA
Power
Switch
DVI
RS232
Ethernet
RS232
USB
DC In (Wire type)
ORDERING GUIDE
MECHANICAL & ENVIRONMENTAL
Operation Temperature
-5~45°C
WEBS-4330-1600
Storage Temperature
-20~80°C
Relative Humidity
10~90% non-condensing
System with WADE-8170 (Atom™ N270 1.6GHz)
with DC Jack + Adaptor + 2GB DDR2 + 160GB HDD
Dimension (WxDxH)
200x200x62 mm; 7.9”x7.9”x2.4”
Weight
1.9 kg
WEBS-4330-1603
System with WADE-8170 (Atom™ N270 1.6GHz) +
GADIWA-R9271 with wire type power input interface
System-WEBS-4330 142
WEBS-1310
Embedded rugged fan-less system with Intel® Atom™
Z510PT/Z520PT based 3.5” ECX board
FEATURES
Intel® Atom™ processor Z510PT/Z520PT and
System Controller Hub US15WPT
Wide temperature range and fan-less design are
perfect for environment-critical applications
One Mini-PCIExpress expansion and Antenna
51mm
hole
GPIO and rich I/O and good for versatile
applications
Rugged and compact are good for using at harsh
150mm
environment
Versatile mounting solutions such as Wall and
200mm
Panel mount (Optional)
Single DC 12V power input for easy system
intergation
REAR I/O
SYSTEM
CPU
Intel® AtomTM
FSB
400/533 MHz
BIOS
AMI BIOS
System Chipset
Intel® US15WPT
System Memory
One 200-pin SO-DIMM support DDR2 400/533 up to 2GB
Storage
1 x CF, 1 x SSD
Watchdog Timer
Programmable via S/W from 1sec. to 255min.
H/W Status Monitor
Temperature (CPU and System), Voltage
Z510PT(1.1GHz)/Z520PT(1.3GHz)
GPIO
USB
REAR PANEL
Antenna
Hole
RS232
Audio
VGA
DC In
Ethernet
Serial Port
1 x RS232 + 1 x RS232/422/485
Display
1 x VGA
USB
4 x USB 2.0
Audio Interface
Line-out and Mic-in
Ethernet
1 x Gigabit Ethernet
Digital IO
8-bit Digital IO
Power
Switch
RS232/422/485
Power Supply Unit
Power Input
DC 12V
Adaptor
AC 100~240V
MECHANICAL & ENVIRONMENTAL
ORDERING GUIDE
Operation Temperature
-5~45°C
Storage Temperature
-20~80°C
Relative Humidity
5~95% non-condensing
System with PEB-2738 (Atom™ Z510PT 1.1GHz) +
1GB DDR2 + 512MB CF
Dimension (WxDxH)
200x150x51 mm; 7.9”x5.9”x2”
WEBS-1310-1300
Weight
1.6 kg
System with PEB-2738 (Atom™ Z520PT 1.3GHz) +
2GB DDR2 + 4GB CF
143 System-WEBS-1310
WEBS-1310-1100
Embedded rugged fan-less system with Intel®
Atom™ N270 based 3.5” ECX board
WEBS-1330
FEATURES
Intel® Atom™ N270 1.6GHz processor and Intel®
945GSE+ ICH7-M chipset
Analog Display: Up to 2048 x 1536 (QXGA)
One Mini-PCIExpress expansion with an Antenna
hole
51mm
Dual LAN and 4 COMs (5V/12V selectable)
are good for networking, POS and automation
applications
Rugged and compact design for harsh
150mm
200mm
environment
Versatile mounting solutions such as Wall and
Panel mount (Optional)
Single DC 12V power input for easy system
intergation
REAR I/O
SYSTEM
CPU
Intel® AtomTM
FSB
533 MHz
BIOS
AMI BIOS
Intel® 945GSE GMCH integrated GMA 950 Graphics and
ICH7-M
System Chipset
N270 1.6GHz processor
System Memory
One 200-pin SO-DIMM support DDR2 400/533 up to 2GB
Storage
1 x CF, 1x HDD
Watchdog Timer
Programmable via S/W from 1sec. to 255min.
H/W Status Monitor
Temperature (CPU and System), Voltage
Antenna
Hole
RS232 x 4
DC In
VGA
Ethernet
USB
Power
Line-out Switch
REAR PANEL
Serial Port
4 x Powered RS232 (5V/12V)
Display
1 x VGA
USB
2 x USB 2.0
Audio Interface
Line-out
Ethernet
2 x Gigabit Ethernet
Power Supply Unit
Power Input
DC 12V
Adaptor
AC 100~240V
ORDERING GUIDE
MECHANICAL & ENVIRONMENTAL
WEBS-1330-1600
Operation Temperature
-5~45°C
Storage Temperature
-20~80°C
System with PEB-2131 (AtomTM N270 1.6GHz) +
1GB DDR2 + 512MB CF
Relative Humidity
10~90% non-condensing
Dimension (WxDxH)
200x150x51 mm; 7.9”x5.9”x2”
Weight
1.6 kg
System-WEBS-1330 144
WEBS-1340
Embedded rugged fan-less system with Intel® Atom™
N450/D510 based 3.5” ECX board
FEATURES
Fan-less solution with Dual-Core CPU
Intel® Atom™ N450/D510 1.6GHz processor
and Intel® ICH8-M chipset
Dual Gigabit Ethernet
51mm
Rich I/O is good for versatile applications
Rugged and compact design for harsh
environment
150mm
Versatile mounting solutions such as Wall and
Panel mount (Optional)
200mm
Single DC 12V power input for easy system
intergation
Three RS232 and one RS232/422/485 serial
ports
REAR I/O
SYSTEM
CPU
Intel® AtomTM
FSB
667 MHz
BIOS
AMI BIOS
System Chipset
Intel® ICH8-M
System Memory
One 200-pin SO-DIMM support DDR2 up to 2GB
Storage
1 x CF, 1 x HDD
Watchdog Timer
Programmable via S/W from 1sec. to 255min.
H/W Status Monitor
Temperature (CPU and System), Voltage
N450/D510 1.6GHz processor
USB
RS232
RS232
Ethernet
VGA
Antenna
RS232/422/485 Hole
USB DC In
REAR PANEL
Serial Port
3 x RS232 + 1 x RS232/422/485
Display
1 x VGA
USB
4 x USB 2.0
Audio Interface
N/A (internal header only)
Ethernet
2 x Gigabit Ethernet
ORDERING GUIDE
Power Supply Unit
Power Input
DC 12V
Adaptor
AC 100~240V
MECHANICAL & ENVIRONMENTAL
Operation Temperature
-5~45°C
Storage Temperature
-20~80°C
Relative Humidity
10~90% non-condensing
Dimension (WxDxH)
200x150x51 mm; 7.9”x5.9”x2”
Weight
1.6 kg
145 System-WEBS-1340
WEBS-1340-1600
System with PEB-2780 (Atom™ N450 1.6GHz) +
1GB DDR2 + 512MB CF
Power
Switch
Embedded rugged slim fan-less system with Intel®
AtomTM N270 based MINI-ITX board
WEBS-3332
FEATURES
Intel® AtomTM N270 1.6GHz processor and
Intel?945GSE + ICH7-M chipset
One 200-Pin SO-DIMM supports DDR2 SDRAM
up to 2GB
40mm
Analog Display: Up to 2048 x 1536 (QXGA)
40mm height supports thin client and DS
application
200mm
Fan-less and optional cable-less design for easy
maintenance
200mm
Rugged and slim design is ideal for environment-
critical application
Versatile mounting solutions such as Wall and
Panel mount (Optional)
Vibration test (5grms/5~500Hz/operation)
Shock test (50g peak acceleration - 11msec.
duration)
REAR I/O
SYSTEM
CPU
Intel® AtomTM N270 1.6GHz processor
FSB
533 MHz
BIOS
Award BIOS
System Chipset
System Memory
Intel® 945GSE GMCH integrated GMA 950 Graphics and
ICH7-M
One 200-pin SO-DIMM support DDR2 400/533 up to 2GB
SSD
1 x CF
Watchdog Timer
Programmable via S/W from 1sec. to 255min.
H/W Status Monitor
Temperature (CPU and System), Voltage
Power Switch
VGA
DC In
Audio
USB
RS232
Ethernet
REAR PANEL
Serial Port
1 x RS232
Display
1 x VGA
USB
4 x USB 2.0
Audio Interface
Line-out and Mic-in
Ethernet
1 x Gigabit Ethernet
ORDERING GUIDE
Power Supply Unit
Power Input
DC 12V
Adaptor
AC 100~240V
WEBS-3332-1600
System with WADE-8071 (Atom™ N270 1.6GHz) +
2GB DDR2 + 4GB CF
MECHANICAL & ENVIRONMENTAL
WEBS-3332-1601
Operation Temperature
-5~50°C
System with WADE-8071 (Atom™ N270 1.6GHz) +
1GB DDR2 + 512MB CF
Storage Temperature
-20~80°C
Relative Humidity
10~90% non-condensing
Dimension (WxDxH)
200x200x40 mm; 7.9”x7.9”x1.6”
Weight
1.4 kg
System-WEBS-3332 146
WEBS Mounting Solution
Wall Mount Kit
Panel Mount Kit
WEBS-2120 / 2121 / 1320
WEBS-2120 / 2121
System Size
150/200(W) x 150(D) x 51(H)mm
System Size
150(W) x 150(D) x 51(H)mm
Ordering
WEBS-2120 Wall Mount Kit
Ordering
WEBS-2120 Panel Mount Kit
Remark
VESA 75/100
WEBS-3330 / 3331
System Size
200(W) x 200(D) x 51/36(H)mm
WEBS-1320
Ordering
WEBS-3330 Wall Mount Kit
System Size
200(W) x 150(D) x 51(H)mm
Ordering
WEBS-1320 Panel Mount Kit
Remark
VESA 75/100
WEBS-3330 / 3331
System Size
200(W) x 200(D) x 51/36(H)mm
Ordering
WEBS-3330 Panel Mount Kit
Remark
VESA 75/100
WEBS-3332 / 4330
System Size
200(W) x 200(D) x 40/62(H)mm
Ordering
WEBS-3332 Wall Mount Kit
WEBS-1310 / 1330 / 1340
System Size
200(W) x 150(D) x 51(H)mm
Ordering
WEBS-1310 Wall Mount Kit
DIN Mount Kit
WEBS-3332 / 4330
System Size
200(W) x 200(D) x 40/62(H)mm
Ordering
WEBS-3332 Panel Mount Kit
Remark
VESA 75/100
WEBS-1310 / 1330 / 1340
WEBS-2120 / 2121 / 1320
System Size
200(W) x 150(D) x 51(H)mm
System Size
150/200(W) x 150(D) x 51(H)mm
Ordering
WEBS-1310 Panel Mount Kit
Ordering
WEBS-2120 Wall Mount Kit
Remark
VESA 75/100
Remark
DIN Rail H=35mm (w/o Rail)
147 System-WEBS Mounting Solution
WEBS Mounting Solution
Wall Mount Kit
Panel Mount Kit
WEBS-2120 / 2121 / 1320
WEBS-2120 / 2121
System Size
150/200(W) x 150(D) x 51(H)mm
System Size
150(W) x 150(D) x 51(H)mm
Ordering
WEBS-2120 Wall Mount Kit
Ordering
WEBS-2120 Panel Mount Kit
Remark
VESA 75/100
WEBS-3330 / 3331
System Size
200(W) x 200(D) x 51/36(H)mm
WEBS-1320
Ordering
WEBS-3330 Wall Mount Kit
System Size
200(W) x 150(D) x 51(H)mm
Ordering
WEBS-1320 Panel Mount Kit
Remark
VESA 75/100
WEBS-3330 / 3331
System Size
200(W) x 200(D) x 51/36(H)mm
Ordering
WEBS-3330 Panel Mount Kit
Remark
VESA 75/100
WEBS-3332 / 4330
System Size
200(W) x 200(D) x 40/62(H)mm
Ordering
WEBS-3332 Wall Mount Kit
WEBS-1310 / 1330 / 1340
System Size
200(W) x 150(D) x 51(H)mm
Ordering
WEBS-1310 Wall Mount Kit
DIN Mount Kit
WEBS-3332 / 4330
System Size
200(W) x 200(D) x 40/62(H)mm
Ordering
WEBS-3332 Panel Mount Kit
Remark
VESA 75/100
WEBS-1310 / 1330 / 1340
WEBS-2120 / 2121 / 1320
System Size
200(W) x 150(D) x 51(H)mm
System Size
150/200(W) x 150(D) x 51(H)mm
Ordering
WEBS-1310 Panel Mount Kit
Ordering
WEBS-2120 Wall Mount Kit
Remark
VESA 75/100
Remark
DIN Rail H=35mm (w/o Rail)
147 System-WEBS Mounting Solution
PSU Reference Table
ORION-A2501
ORION-D5501P
ORION-D3202P
ORION-D4601P
ORION-D4602P
MPM-842P
MPI-815H
MPI-810H
MPI-806H
TYPE
MODEL
FORM
FACTOR
DIMENSON
Single
GADIWA-P0901
DC/DC
60 x 45 x 15 mm
120W / ATX Output
149
WideRange
GADIWA-P9271
Regulator
60 x 45 x 22 mm
9-27V DC /
Regulator
150
WideRange
GADIWA-3160
DC/DC
150 x 51 x 22.5 mm
128W / 12~36V DC
/ Input
151
WideRange
GADIWA-3161
DC/DC
100 x 45 x 22.5 mm
128W / 9-29V DC
/ Input
152
Redundant
GADIWA-N2360
mini-redundant
150 x 86 x 139.6 mm
360W / 18~30V DC
/ Input
153
Single
ORION-A2501
1U
100 x 190 x 40.5 mm
3.93” x 7.48” x 1.60”
250W / PFC / P4
154
Single
ORION-A1501
1U
100 x 190 x 40 mm
3.93” x 7.48” x 1.57”
150W / PFC / P4
154
Single
ORION-A1501P
Low-Noise
81.5 x 150 x 40.5 mm
3.2” x 5.9” x 1.6”
150W / ATX
155
Single
ORION-A1801P
Low-Noise
81.5 x 150 x 40.5 mm
3.2” x 5.9” x 1.6”
180W / ATX
155
Single
ORION-B3501P
2U
190 x100 x 70 mm
7.48” x 3.94” x 2.8”
350W / PFC / P4
156
Single
ORION-D3501P
PS/2
150 x 140 x 86 mm
5.9” x 5.5” x 3.4”
350W / PFC / P4
156
Single
ORION-D4601P
PS/2
150 x 140 x 86 mm
5.9” x 5.5” x 3.4”
460W / PFC / P4
157
Single
ORION-D5501P
PS/2
150 x 140 x 86 mm
5.9” x 5.5” x 3.4”
550W / PFC / P4
157
Redundant
ORION300DX/24/48
PS/2
150 x 140 x 86 mm
5.9” x 5.5” x 3.4”
330W / DC / ATX
158
Redundant
ORIOND3002DDP
mini-redundant
DC TO DC
150 x 183 x 86 mm
5.9” x 7.2” x 3.4”
300W / PFC / DC
/ P4
158
Redundant
ORION-D3502P
mini-redundant
150 x 190 x 84 mm
5.9” x 7.2” x 3.4”
320W / PFC / P4
159
Redundant
ORION-D4602P
mini-redundant
150 x 140 x 86 mm
5.9” x 5.5” x 3.4”
400W / PFC / P4
159
Single
MPM-842P
PS/2
150 x140 x 86 mm
5.9” x 5.5” x 3.4”
400W / Medical /
ATX
160
Single
MPI-815H
OPEN FRAME
198 x 93 x 40.5 mm
7.8” x 3.66” x 1.6”
150W / Fanless /
ATX
160
Single
MPI-810H
OPEN FRAME
83.9 x 152.4 x 38.1 mm
3.3” x 6” x 1.5”
120W / ATX
161
Single
MPD-810H
OPEN FRAME
DC TO DC
83.9 x 152.4 x 38.1 mm
3.3” x 6” x 1.5”
120W / DC / ATX
161
Single
MPE-008A-P
OPEN FRAME
50.8 x 127 x 40 mm
2” x 5” x 1.57”
80W / ATX
162
Single
MPI-806H
OPEN FRAME
128 x 81 x 40 mm
5.0” x 3.2” x 1.55”
60W / ATX
162
POWER RANGE PAGE
Adapter
163
Configuration Matrix
164
Industrial Power Supply 148
GADIWA-P0901
120W DC/DC Converter (12V/input,
ATX/output), Board Type
GADIWA-P0901 is a DC-DC converter for board type. It normally support 120Watts and maximum can reach to
150Watts. GADIWA-P0901 can save more space and cost, it’s not only capability for fan-less system but also
suitability for different application. Moreover, the converter is made and tested by automatic production line;
therefore, it can provide high quality and performance.
FEATURES
Installation Image
12V DC/input, plug into the ATX connector with board
output
Compact and user-friendly design for installation and
maintenance
Fan-less design for mission-critical application
Small size for 1U or higher system to save space
SPECIFICATION
Input Voltage
12V (+5%/-4%)
Line Regulation
11.52V / 12.6V
Output
120Watts/ 150Watts peak
Efficiency
>96% @ 12.3V
MTBF
836,407hrs @45°C, 592,361hrs @55°C
EMI & Safety Approval
CE, FCC
Input Connector
Mini-Fit 8 pin (P/N: B6902040)
Output Connector
Mini-Fit 20 pin (P/N: B6902071)
Dimension (WxDxH)
60 x 45 x 15 mm
CHARACTERISTICS
Output Voltage
Load Regulation
Cross Regulation
+12V
0~7A
6.5A
6A
+5V
0~6A
+3.3V
0~6A
6A
+5Vsb
0~2A
1A
-12V
0~0.1A
0.1A
ORDERING GUIDE
GADIWA-P0901
120W DC/DC Converter (12V/input, ATX/output), Board Type
149 Industrial Power Supply
GADIWA-R9271
9V~27V/wide-input, 12V/output
Regulator, Board Type
GADIWA- R9271 is a wide input regulator for board type. GADIWA-R9271 can collocate with GADIWA-P0901
and GADIWA-1120 which are DC-DC converters; it’s easily to deploy critical application. The converter is made
and tested by automatic production line; therefore, it can provide high quality and performance. GADIWA-R9271
has special design for socket type fuse protection.
FEATURES
Installation Image
Compact and user-friendly design for installation and
maintenance
Small size for 1U or higher system to save space
Suitable for Car PC, Steamer, Truck, Boat and Adapter
Special Design for Delay-Time
Socket Type Fuse Protection
SPECIFICATION
Input Voltage
9V~27V
Line Regulation
9V~27V continuous, 7~30V<10 [email protected] start
Efficiency
>95% @ 14V input
MTBF
577,768hrs @45°C, 409,990hrs @55°C
EMI & Safety Approval
CE, FCC
Input Connector
Mini-Fit 3 pin (P/N: B6902060)
Output Connector
Mini-Fit 8 pin (P/N: B6902042)
Dimension (WxDxH)
60 x 45 x 22 mm
GADIWA-R9271
CHARACTERISTICS
Output Voltage
Load Regulation
Cross Regulation
+12V
12.3V @ 0~8.5A
12.3V @ 0~8.5A
GADIWA-P0901
ORDERING GUIDE
GADIWA-R9271
9V to 27V/Wide-input, 12V/output Regulator, Board Type
Industrial Power Supply 150
GADIWA-3160
128W DC/DC 12V~36V/wide-input,
ATX/output, Board Type Converter
GADIWA- 3160 is a wide input converter for board type. It normally support 128Watts and maximum can reach
to 160Watts. GADIWA-3160 can save more space and cost, it’s not only capability for fan-less system but also
suitability for different application. Gadiwa-3610 also have UL certification and watch dog function design, it’ll be
easy to deploy any critical application.
FEATURES
Installation Image
12~36V/Wide-input, plug into the ATX connector with
board output
Compact and user-friendly design for installation and
maintenance
Fan-less design for mission-critical application
Small size for 1U or higher system to save space
12V output
Watchdog Timer function
20 pin output
SPECIFICATION
6 pin input
Input Voltage
12V~36V
Line Regulation
11.5V~36V/input
Output
128Watts / 160Watts Peak
Efficiency
>85% @ 12V
MTBF
245.000hrs @45°C, 192,000hrs @55°C
EMI & Safety Approval
UL, CE, FCC
Input Connector
Mini-Fit 6 pin (P/N: B6902400)
Output Connector
- Mini-Fit 20 pin (P/N: B6902410)
- 12V output (P/N: B6902420)
Dimension (WxDxH)
150 x 51 x 22.5 mm
CHARACTERISTICS
Output Voltage
Current Range
Current Range
+12V
0~8A
0~6A
+5V
0~8A
0~6A
+3.3V
0~7A
0~5.25A
+5Vsb
0~2A
0~1.5A
-12V
0~0.15A
0~0.12A
ORDERING GUIDE
GADIWA-3160
128W DC/DC 12V~36V/wide-input, ATX/output, Board Type Converter
151 Industrial Power Supply
GADIWA-3161
128W DC/DC 9V~29V/wide-input,
ATX/output, Board Type Converter
GADIWA- 3161 is a wide input board type converter. It normally support 128Watts and maximum can reach to
160Watts. GADIWA-3160 can save more space and cost, it’s not only capability for fan-less system but also
suitability for different application. Besides, the converter is made and tested by automatic production line;
therefore, it can provide high quality and performance.
FEATURES
Installation Image
9~29V/Wide-input, plug into the ATX connector with
board output
Compact and user-friendly design for installation and
maintenance
Fan-less design for mission-critical application
Small size for 1U or higher system to save space
12V output
Socket Type Fuse Protection
SPECIFICATION
Input Voltage
9V~29V, 6~9V workable with derating
Line Regulation
9V~29V/input
Output
128Watts / 160 Watts Peak
Efficiency
>85% @ 12V input @ 120W output
EMI & Safety Approval
CE, FCC
Input Connector
Mini-Fit 6 pin (P/N: B6902430)
Output Connector
- Mini-Fit 20 pin (P/N: B6902410)
- 12V output (P/N: B6902420)
Dimension (WxDxH)
100 x 45 x 22.5 mm
6 pin input
20 pin output
CHARACTERISTICS
Output Voltage
Load Regulation
Cross Regulation
+12V
0~6A
6A
+5V
0~6A
6A
+3.3V
0~6A
6A
+5Vsb
0~2A(Share with +5V)
2A(Share with +5V)
-12V
0~0.1A
0.1A
ORDERING GUIDE
GADIWA-3161
128W DC/DC 9V~29V/wide-input, ATX/output, Board Type Converter
Industrial Power Supply 152
GADIWA-N2360
360W Mini-Redundant PSU,
18~30VDC Wide-Rang/input,
ATX/output
GADIWA-N2360 360W DC-DC PS/2 mini redundant is an innovation stage to Portwell. It’s not only a design
of fan-less but also with 3+1 modules in PS/2 size. GADIWA-N2360 provides MCU and LED alarm design to
help you monitor system status and installation; it also provides connector customization to meet any critical
application. GADIWA-N2360 is made & tested by automatic production line; therefore, can provide high quality
and performance.
FEATURES
Installation Image
360W DC-DC PS/2 mini-redundant suitable for embedded
system
18V~30V wide-input, plug into ATX connector fit automotive
and boat
Compact and fan-less design fulfill mission-critical application
LED alarm is easy for installation and maintenance
MCU design help to monitor system status, temperature and
performance
SPECIFICATION
Input Voltage
18~30VDC
Input Current
17.6 A
Efficiency
85%
Holdup Time
16 ms. at full load
Over Voltage Protection
[email protected]; [email protected]; [email protected]
Temperature/Humidity
Operating: 0 ~ 45°C, 20 ~ 90%RH
Storage: -20 ~ 60°C, 5 ~ 95%RH
Dimension (WxDxH)
150 x 150.1 x 86 mm
86
150
Front View
DC OUTPUT
+5V
+3.3V
+12V
-5V
-12V
+5Vsb
Max. Load
21A
15A
18A
0.5A
0.1A
2A
Min. Load
0A
0A
0A
0A
0A
0A
Load Reg.
±5%
±5%
±5%
±10%
±10%
±5%
Line Reg.
±5%
±5%
±5%
±10%
±10%
±5%
Ripple
10mv
10mv
10mv
10mv
10mv
10mv
Noise
30mv
25mv
30mv
20mv
20mv
25mv
ORDERING GUIDE
GADIWA-N2360
360W Mini-Redundant PSU, 18~30VDC Wide-Rang/input, ATX/output
153 Industrial Power Supply
Rear View
10.50
139.60
ORION-A2501
250W 1U ATX power supply
with active PFC
FEATURES
Low profile power supply suitable for 1U and
node chassis
Active PFC, full-range input
®
®
Support for Intel Pentium 4 processor
Total output power of +5V, +3.3V and +12V
is 234W
ORDERING GUIDE
SPECIFICATION
Input Voltage
90V ~ 264V AC, full range
Input Frequency
47 ~ 63 Hz
Input Current
[email protected], [email protected]
Efficiency
> 65%
Holdup Time
16 ms at full load
Over Voltage Protection
+5V: 5.4 ~ 6.5V; +3.3V: 3.9 ~ 4.4V; +12V: 13.6 ~ 15.6V
Over Power/Load Protection
Output power over 110% ~ 160%
MTBF
ORION-A2501
250W 1U ATX power supply with active PFC
DC OUTPUT
+5V
+3.3V
+12V
-5V
-12V
+5Vsb
Max. Load
24A
20A
12A
0.5A
0.5A
1.5A
105,405 hrs
Min. Load
3A
1A
2A
0A
0A
0.1A
EMI & Safety Approval
UL, cUL, TUV, CE, FCC
Load Reg.
±5%
±5%
±8%
±10%
±10%
±5%
Temperature/Humidity
Operating: 5 ~ 40oC, 20 ~ 90%RH
Storage: -20 ~ 60oC, 5 ~ 95%RH
Line Reg.
±1%
±1%
±1%
±1%
±1%
±1%
80mv
80mv
120mv
150mv
150mv
80mv
Dimension (WxDxH)
Ripple &
Noise
100 x 190 x 40.5 mm; 3.93” x 7.48” x 1.59”
ORION-A1501
150W 1U ATX power supply with
active PFC
FEATURES
Low profile power supply suitable for 1U and
node chassis
Active PFC, full-range input
Higher +5V and +3.3 V output
Max. +5V standby output is 1.5A
ORDERING GUIDE
SPECIFICATION
ORION-A1501
150W 1U ATX power supply with active PFC
Input Voltage
90V ~ 264V AC, full range
Input Frequency
47 ~ 63 Hz
Input Current
[email protected], [email protected]
Efficiency
> 65%
+5V
+3.3V
+12V
-5V
-12V
+5Vsb
Holdup Time
16 ms. at full load
Max. Load
14A
10A
6A
0.5A
0.8A
1.5A
Over Voltage Protection
+5V: 5.6~6.6V; +3.3V: 3.6~4.2V; +12V: 13.2~14.6V
Min. Load
2A
1A
1A
0.1A
0.1A
0.1A
Over Power/Load Protection
Output power over 110% ~ 160%
Max. Watt.
135W
135W
135W
2.5W
9.6W
7.5W
MTBF
84,228 hrs
Load Reg.
±5%
±5%
±5%
±5%
±10%
±5%
EMI & Safety Approval
UL, cUL, TUV, CE, FCC
Cross Reg.
±5%
±5%
±5%
±5%
±10%
±5%
Operating: 0 ~ 40oC, 20 ~ 90%RH
Storage: -20 ~ 60oC, 5 ~ 95%RH
Line Reg.
±1%
±1.5%
±0.8%
±1%
±1%
±1%
Ripple
±1%
±1.8%
±1%
±2%
±1%
±1.2%
100 x 190 x 40 mm; 3.9” x 7.48” x 1.57”
Noise
±1.4%
±2.1%
±1%
±2%
±1%
±1.4%
Temperature/Humidity
Dimension (WxDxH)
DC OUTPUT
Industrial Power Supply 154
ORION-A1501P
150W Flex form factor power
supply with active PFC
FEATURES
1U Flex form factor power supply
Full-range input with active PFC
Max. 5V output is 13A
Low noise
ORDERING GUIDE
SPECIFICATION
ORION-A1501P
150W PSU. Active PFC. Low Noise
Input Voltage
90V ~ 264V AC, full range
Input Frequency
47 ~ 63 Hz
Input Current
[email protected], [email protected]
Efficiency
> 71%
Holdup Time
16 ms at full load
Over Voltage Protection
+5V: 4.75 ~ 5.25V; +3.3V: 3.14 ~ 3.47V; +12V: 11.4V ~ 12.6V
+5V
+3.3V
+12V
-12V
+5Vsb
Over Power/Load Protection
Output power over 110% ~ 150%
Max. Load
13A
10A
10A
0.5A
2A
MTBF
>160,000 hrs
Min. Load
0.3A
0.3A
1A
0A
0A
EMI & Safety Approval
TUV, UL/cUL
Load Reg.
±5%
±5%
±5%
±10%
±5%
Temperature/Humidity
Operating: 0 ~ 40oC, 20 ~ 90%RH
Storage: -20 ~ 60oC, 5 ~ 95%RH
Line Reg.
±1%
±1%
±1%
±1%
±1%
Ripple
50mv
50mv
120mv
120mv
50mv
81.5 x 150 x 40.5 mm; 3.2” x 5.9” x 1.6”
Noise
50mv
50mv
120mv
120mv
50mv
Dimension (WxDxH)
DC OUTPUT
ORION-A1801P
180W Flex form factor power
supply with active PFC
FEATURES
1U Flex form factor power supply
Full-range input with active PFC
Max. +5V output is 16A
Low noise
ORDERING GUIDE
SPECIFICATION
ORION-A1801P
180W PSU. Active PFC. Low Noise
Input Voltage
90V ~ 264V AC, full range
Input Frequency
47 ~ 63 Hz
Input Current
[email protected], [email protected]
Efficiency
> 75%
Holdup Time
16 ms at full load
Over Voltage Protection
+5V: 5.7 ~ 6.5V; +3.3V: 3.9 ~ 4.3V; +12V: 13.6 ~ 15V
+5V
+3.3V
+12V
-12V
+5Vsb
Over Power/Load Protection
Output power over 110% ~ 150%
Max. Load
16A
14A
14A
0.5A
2A
MTBF
>130,000 hrs
Min. Load
0.3A
0.3A
1.5A
0A
0A
EMI & Safety Approval
UL
Load Reg.
±5%
±5%
±5%
±10%
±5%
Temperature/Humidity
Operating: 0 ~ 40oC, 20 ~ 90%RH
Storage: -20 ~ 60oC, 5 ~ 95%RH
Line Reg.
±1%
±1%
±1%
±1%
±1%
Ripple
50mv
50mv
120mv
120mv
50mv
81.5 x 150 x 40.5 mm; 3.2” x 5.9” x 1.6”
Noise
50mv
50mv
120mv
120mv
50mv
Dimension (WxDxH)
155 Industrial Power Supply
DC OUTPUT
ORION-B3501P
350W 2U ATX power supply
with active PFC
FEATURES
2U ATX power supply suitable for 2U and larger
chassis
Active PFC, full-range input
Support Intel® Pentium® 4 processor
Max. +5V standby output is 2A
Max. +12V output is 18A
ORDERING GUIDE
SPECIFICATION
ORION-B3501P
350W 2U ATX power supply with active PFC
Input Voltage
90V ~ 264V AC, full range
Input Frequency
47 ~ 63 Hz
Input Current
[email protected], [email protected]
Efficiency
> 67%
Holdup Time
16 ms at full load
Over Voltage Protection
+5V: 6.5 ~ 7.0V; +3.3V: 4.5V; +12V: 14.5V
+5V
+3.3V
+12V
-12V
+5Vsb
Over Power/Load Protection
Output power over 110% ~ 150%
Max. Load
25A
17A
25A
0.5A
2A
MTBF
100,000 hrs
Min. Load
1.0A
1.0A
1.0A
0.25A
0A
EMI & Safety Approval
UL, CB, TUV, CE, FCC
Load Reg.
±5%
±5%
±5%
±10%
±5%
Temperature/Humidity
Operating: 0 ~ 40oC, 20 ~ 90%RH
Storage: -20 ~ 60oC, 5 ~ 95%RH
Line Reg.
±1%
±1.5%
±0.4%
±0.4%
±1%
Ripple
50mv
50mv
120mv
120mv
50mv
200 x 100 x 70 mm; 3.94” x 8.3” x 2.8”
Noise
100mv
100mv
150mv
200mv
100mv
Dimension (WxDxH)
DC OUTPUT
ORION-D3501P
350W ATX power supply with
active PFC
FEATURES
PS/2 ATX power supply, suitable for 2U, node
chassis, and larger chassis
Active PFC, full-range input
Total output power of +5V,+3.3V and +12V is 326W
Max. +12V standby output is 18A
Max. +5V load output is 40A
ORDERING GUIDE
SPECIFICATION
Input Voltage
90V ~ 264V AC, full range
Input Frequency
47 ~ 63 Hz
Input Current
[email protected]
Efficiency
> 68%
Holdup Time
17 ms. at full load @25oC
Over Voltage Protection
[email protected] 7V; [email protected] 4.3V; [email protected] 15.6V
Over Power/Load Protection
Output power over to 110%~140%
ORION-D3501P
350W PS/2 ATX power supply with active PFC
DC OUTPUT
+5V
+3.3V
+12V
-5V
-12V
+5Vsb
Max. Load
18A
20A
18A
0.3A
0.5A
2.5A
Min. Load
1A
1A
1A
0A
0A
0A
Load Reg.
±5%
±5%
±5%
±10%
±10%
±5%
MTBF
75,145 hrs
EMI & Safety Approval
UL, TUV, CE, FCC, CB, CSA, SEMKO, FIMKO,
NEMCO, DIMCO
Temperature/Humidity
Operating: 0 ~ 50oC, 20 ~ 85%RH
Storage: -40 ~ 70oC, 10 ~ 90%RH
Line Reg.
±1%
±1.5%
±1%
±2.4%
±1%
±1%
Ripple
±1%
±1.5%
±0.8%
±3%
±1.25%
±1%
150 x 140 x 86 mm; 5.9” x 5.5” x 3.4”
Noise
±1%
±1.5%
±0.8%
±3%
±1.25%
±1%
Dimension (WxDxH)
Industrial Power Supply 156
ORION-D4601P
460W PS/2 ATX power supply
with active PFC
FEATURES
PS/2 ATX power supply suitable for 2U
and larger chassis
Active PFC, full-range input
Support Intel® Pentium® 4 processor
Max. +12V standby output is 30A
ORDERING GUIDE
ORION-D4601P
SPECIFICATION
460W PS/2 ATX power supply with active PFC
Input Voltage
90V ~ 264V AC, full range
Input Frequency
47 ~ 63 Hz
Input Current
[email protected], [email protected]
Efficiency
> 60%
Holdup Time
16 ms at full load
Over Voltage Protection
+5V: 5.7 ~ 7.0V; +3.3V: 3.9 ~ 4.5V; +12V: 13.6 ~ 16.0V
+5V
+3.3V
+12V
-12V
+5Vsb
Over Power/Load Protection
Output power over 110% ~ 150%
Max. Load
20A
22A
16A
0.5A
2.5A
MTBF
100,000 hrs
Min. Load
0.5A
0.3A
1A
0A
0A
EMI & Safety Approval
UL, TUV
Reg.
±5%
±5%
±5%
±10%
±5%
Temperature/Humidity
Operating: 0 ~ 40oC, 20 ~ 90%RH
Storage: -20 ~ 60oC, 5 ~ 95%RH
Ripple
50mv
50mv
120mv
120mv
50mv
Noise
50mv
50mv
120mv
120mv
50mv
Dimension (WxDxH)
DC OUTPUT
150 x 140 x 86 mm; 5.9” x 5.5” x 3.4”
ORION-D5501P
550W PS/2 ATX power supply
with active PFC
FEATURES
PS/2 ATX power supply suitable for 2U and larger
chassis
Active PFC, full-range input
Support Intel® Pentium® 4 processor
Max. +12V output is 38A
ORDERING GUIDE
SPECIFICATION
ORION-D5501P
550W PS/2 ATX power supply with active PFC
Input Voltage
90V ~ 264V AC, full range
Input Frequency
47 ~ 63 Hz
Input Current
[email protected], [email protected]
Efficiency
> 60%
Holdup Time
16 ms at full load
Over Voltage Protection
+5V: 5.7 ~ 7.0V; +3.3V: 3.9 ~ 4.5V; +12V: 13.6 ~ 16
+5V
+3.3V
+12V
-5V
-12V
+5Vsb
Over Power/Load Protection
Output power over 110% ~ 150%
Max. Load
29A
27A
18A
0.3A
0.8A
2A
MTBF
100,000 hrs
Min. Load
3A
0.4A
1A
0A
0A
0A
EMI & Safety Approval
UL, cUL, TUV, CE, FCC
Reg.
+5% -4%
+5% -4%
+5% -4%
±10%
+9% -5%
+5% -4%
Temperature/Humidity
Operating: 0 ~ 40oC, 20 ~ 90%RH
Storage: -20 ~ 60oC, 5 ~ 95%RH
Ripple
50mv
50mv
120mv
120mv
120mv
50mv
Noise
50mv
50mv
120mv
120mv
120mv
50mv
Dimension (WxDxH)
157 Industrial Power Supply
150 x 165 x 86 mm; 5.9” x 6.5” x 3.4”
DC OUTPUT
ORION-300DX/24/48
300W -48V/24V DC input
DC/DC PS/2 ATX power supply
FEATURES
PS/2 ATX power supply suitable for 2U and
larger chassis
ORION-300DX/24 for +24V DC input, suitable
for vehicle applications
ORION-300DX/48 for -48V DC input, suitable for
telecommunication applications
Max. -12V output is 2A, suitable for CTI application
ORDERING GUIDE
ORION-300DX/48
300W -48V DC input DC/DC PS/2 ATX power supply
Input Voltage
-40V~-72V DC for ORION-300DX/48
19V~32V DC for ORION-300DX/24
Input Current
[email protected], [email protected] DC input
Efficiency
> 65%
Holdup Time
16 ms
Over Voltage Protection
+5V: 5.7 ~ 7.0V
MTBF
100,000 hrs
EMI & Safety Approval
UL, TUV, CSA
Temperature/Humidity
Operating: 0 ~ 40oC, 10 ~ 90%RH
Storage: -60 ~ 70oC, 5 ~ 95%RH
Dimension (WxDxH)
ORION-300DX/24
SPECIFICATION
150 x 140 x 86 mm; 5.9” x 5.5” x 3.4”
ORION-D3002DDP
300W 24V DC input DC/DC PS/2 ATX power supply
DC OUTPUT
+5V
+3.3V
+12V
-5V
-12V
+5Vsb
Max. Load
30A
15A
15A
2A
2A
1.2A
Min. Load
2A
0.3A
0.5A
0A
0A
0A
Load Reg.
±5%
±3%
±5%
±10%
±5%
±5%
Cross Reg.
±5%
±3%
±5%
±10%
±5%
±5%
Line Reg.
±1%
±1%
±1%
±1%
±1%
±1%
Ripple
±1%
±1.5%
±1%
±2%
±1%
±1%
Noise
±1%
±1.5%
±1%
±2%
±1%
±1%
300W -38VDC to -72VDC input DC/DC
mini-redundant ATX power supply
FEATURES
Mini-redundant DC to DC power supply suitable for
2U and larger chassis
Active PFC, full-range input
-38VDC to -72VDC input for telecommunication
applications
Test equipment for telecommunication applications
ORDERING GUIDE
ORION-D3002DDP
300W DC-DC W/Active PFC, redundant power supply
SPECIFICATION
DC OUTPUT
Input Voltage
-38~-72VDC
Input Current
11A
+5V
+3.3V
+12V
-5V
-12V
+5Vsb
Efficiency
> 58%
Max. Load
30A
22A
11A
1A
1A
1.5A
Holdup Time
16 ms. at full load
Min. Load
2A
0.3A
0.5A
0.05A
0.05A
0A
Over Voltage Protection
[email protected]; [email protected]; [email protected]
Load Reg.
±5%
±5%
±5%
±10%
±10%
±5%
Temperature/Humidity
Operating: 0 ~ 40oC, 20 ~ 90%RH
Storage: -20 ~ 60oC, 5 ~ 95%RH
Line Reg.
±5%
±5%
±5%
±10%
±10%
±5%
Ripple
50mv
50mv
120mv
130mv
100mv
50mv
150 x 183 x 86 mm; 5.9” x 7.2” x 3.4”
Noise
100mv
100mv
150mv
200mv
200mv
100mv
Dimension (WxDxH)
Industrial Power Supply 158
ORION-D3502P
350W ATX mini-redundant
with active PFC power supply
FEATURES
Mini-redundant ATX power supply suitable for 2U
and larger chassis
350W output
Active PFC, full-range input
ORDERING GUIDE
SPECIFICATION
ORION-D3502P
350W PS/2, w/active PFC, ATX power supply
Input Voltage
100V~240V AC
Input Frequency
47 ~ 63 Hz
Input Current
[email protected], [email protected]
Efficiency
> 80%
Holdup Time
16 ms. at full load
Over Voltage Protection
[email protected]; [email protected]; [email protected]
MTBF
> 100,000 hrs
EMI & Safety Approval
UL, cUL, TUV, CE, FCC
DC OUTPUT
Temperature/Humidity
Operating: 0 ~ 40oC, 20 ~ 90%RH
Storage: -20 ~ 60oC, 5 ~ 95%RH
Dimension (WxDxH)
150 x 190 x 84 mm; 5.9” x 7.2 x 3.4”
ORION-D4602P
+5V
+3.3V
+12V
-5V
-12V
+5Vsb
Max. Load
20A
20A
18A
0.5A
0.8A
2A
Min. Load
0.5A
0.5A
0.5A
0A
0A
0A
Load Reg.
±5%
±5%
±5%
±10%
±5%
±5%
Cross Reg.
±5%
±5%
±5%
±10%
±5%
±5%
Line Reg.
±1%
±1%
±1%
±1%
±1%
±1%
Ripple
50mv
50mv
120mv
200mv
200mv
50mv
Noise
50mv
50mv
120mv
200mv
200mv
50mv
460W+460W mini-redundant switching
power supply with active PFC
FEATURES
Mini-redundant power supply suitable for 2U/4U
and larger chassis
Active PFC, full-range input
Two independent AC inputs
ORDERING GUIDE
Input Voltage
90V ~ 264V AC, full range
Input Frequency
47 ~ 63 Hz
Input Current
[email protected], [email protected]
Efficiency
> 65%
Holdup Time
20 ms. at full load
Over Voltage Protection
+5V: 5.6 ~ 6.5V; +3.3V: 3.8 ~ 4.3V; +12V: 13.6 ~ 15.6V
Over Power/Load Protection
MTBF
EMI & Safety Approval
Temperature/Humidity
Dimension (WxDxH)
159 Industrial Power Supply
ORION-D4602P
460W+460W mini-redundant power supply
with active PFC
SPECIFICATION
DC OUTPUT
+5V
+3.3V
+12V
-12V
+5Vsb
Max. Load
25A
25A
30A
0.8A
2A
Min. Load
2A
2A
2.5A
0A
0A
Max. Watt.
370W
370W
370W
9.6W
10W
100,000 hrs
Load Reg.
±5%
±5/-3%
±5%
±5%
±10%
UL, TUV
Cross Reg.
±5%
±5/-3%
±5%
±5%
±5%
Operating: 0 ~ 40 C, 20 ~ 90%RH
Storage: -40 ~ 70oC, 5 ~ 95%RH
Line Reg.
±1%
±1%
±1%
±1%
±1%
Ripple
±1%
±1%
±1%
±1%
±1%
150 x 190 x 86 mm; 5.9” x 7.5” x 3.4”
Noise
±1%
±1%
±1%
±2%
±1%
Output power over 110% ~ 130% on +3.3V/+5V;
120% ~ 150% on +12V
o
MPM-842P
400W PS/2 ATX power supply
with active PFC
FEATURES
PS/2 ATX power supply suitable for 2U and larger
chassis
Active PFC, full-range input
Support Intel® Pentium® 4 processor
Max. 12V output is 22A
Medical level power supply
ORDERING GUIDE
SPECIFICATION
Input Voltage
90V ~ 264V AC, full range
Input Frequency
47 ~ 63 Hz
Input Current
[email protected], [email protected]
Efficiency
> 71%
Holdup Time
16 ms at full load
Over Voltage Protection
+5V: 4.75 ~ 5.25V; +3.3V: 3.14 ~ 3.47V; +12V: 11.4V ~ 12.6V
Over Power/Load Protection
Output power over 110% ~ 150%
MTBF
MPM-842P
400W PS/2 ATX power supply with active PFC
DC OUTPUT
+5V
+3.3V
+12V
-12V
Max. Load
21A
22A
22A
0.8A
1.5A
>160,000 hrs
Min. Load
0.3A
0.5A
1A
0A
0.1A
EMI & Safety Approval
TUV, UL/cUL
Load Reg.
±5%
±5%
±5%
±5%
±5%
Temperature/Humidity
Operating: 0 ~ 40oC, 20 ~ 90%RH
Storage: -20 ~ 60oC, 5 ~ 95%RH
Line Reg.
±1%
±1%
±1%
±1%
±1%
Ripple &
Noise
50mv
50mv
120mv
120mv
50mv
Dimension (WxDxH)
150 x 140 x 86 mm; 5.9” x 5.5” x 3.4”
MPI-815H
+5Vsb
150W 1U ATX power
supply with active PFC
FEATURES
1U ATX power supply
Full-range input
Max. +5V standby output is 14A
Thermal protection
+5V standby & remote On/Off
ORDERING GUIDE
SPECIFICATION
Input Voltage
90V ~ 264V AC, full range
Input Frequency
47 ~ 63 Hz
Input Current
[email protected], [email protected]
Efficiency
> 75%
Holdup Time
16 ms at full load
Over Voltage Protection
+5V: 5.7 ~ 6.5V; +3.3V: 3.9 ~ 4.3V; +12V: 13.6 ~ 15
Over Power/Load Protection
Output power over 110% ~ 150%
MTBF
MPI-815H
150W fanless, 1U, ATX power supply
DC OUTPUT
+5V
+3.3V
+12V
-12V
+5Vsb
Max. Load
14A
12A
10A
1A
1.5A
>130,000 hrs
Min. Load
1A
0A
0A
0A
0A
EMI & Safety Approval
UL
Load Reg.
±2%
±5%
±5%
±5%
±5%
Temperature/Humidity
Operating: 0 ~ 40oC, 20 ~ 90%RH
Storage: -20 ~ 60oC, 5 ~ 95%RH
Line Reg.
±1%
±1%
±1%
±1%
±1%
Ripple &
Noise
50mv
50mv
100mv
150mv
100mv
Dimension (WxDxH)
198 x 93 x 40.5 mm; 7.8” x 3.66” x 1.6”
Industrial Power Supply 160
MPI-810H
120W universal input open-frame
power supply
FEATURES
3.3” x 6” open-frame power supply suitable for
node chassis
Five rails outputs
(+5V, +12V, -12V, +3.3V & +5Vsb)
Universal AC input
Higher +5V output (14A)
ORDERING GUIDE
SPECIFICATION
MPI-810H
Input Voltage
90 ~ 260V AC
Input Frequency
47 ~ 63 Hz
Input Current
[email protected] or [email protected]
Efficiency
> 70%
Holdup Time
16 ms at full load
Over Voltage Protection
+5V: 5.6 ~ 6.6V; +3.3V: 3.6 ~ 4.2V; +12V: 13.2 ~ 14.6V
Over Power/Load Protection
Output power over 110% ~ 160%
+5V
+3.3
+12V
-12V
+5Vsb
MTBF
130,000 hrs
Max. Load
14A
12A
6A
1A
0.75A
EMI & Safety Approval
UL, VDE, CSA
Min. Load
1A
0A
0A
0A
0A
Temperature/Humidity
Operating: 0 ~ 50oC, 20 ~ 90%RH
Storage: -20 ~ 70oC, 5 ~ 95%RH
Load Reg.
±3%
±5%
±5%
±5%
±5%
Line Reg.
±1%
±1%
±1%
±1%
±1%
Dimension (WxDxH)
83.8 x 152.4 x 38.1 mm; 3.3” x 6” x 1.5”
Ripple
50mv
50mv
120mv
200mv
MPD-810H
120W universal input open-frame power supply
DC OUTPUT
120W universal input open-frame,
DC to DC power supply
FEATURES
Open-frame DC to DC power supply suitable for
node chassis
Five rails outputs (+5V, +12V, -12V, +3.3V & +5Vsb)
10~30 VDC input
Higher +5V output (10A)
ORDERING GUIDE
SPECIFICATION
MPD-810H
Input Voltage
10V ~ 30V DC
Input Frequency
47 ~ 63 Hz
Input Current
[email protected] DC
Efficiency
> 70%
Holdup Time
16 ms at full load
Over Voltage Protection
+5V: 5.6 ~ 6.6V; +3.3V: 3.6 ~ 4.2V; +12V: 13.2 ~ 14.6V
Over Power/Load Protection
Output power over 110% ~ 160%
+5V
+3.3
+12V
-12V
+5Vsb
MTBF
130,000 hrs
Max. Load
10A
8A
4A
1A
0.75A
EMI & Safety Approval
UL
Min. Load
1A
0A
0A
0A
0A
Temperature/Humidity
Operating: 0 ~ 50oC, 20 ~ 90%RH
Storage: -20 ~ 70oC, 5 ~ 95%RH
Load Reg.
±2%
±5%
±5%
±5%
Line Reg.
±2.5%
±2.5%
±2.2%
±2.5%
Dimension (WxDxH)
83.8 x 152.4 x 38.1 mm; 3.3” x 6” x 1.5”
Ripple
100mv
100mv
120mv
200mv
161 Industrial Power Supply
120W 10~30VDC input open-frame power supply
DC OUTPUT
±2.5%
MPE-008A-P
80W universal input open-frame
power supply
FEATURES
60W convection cooling and 80W forced
air-cooling
Conductive EMI Meets CISPR/FCC Class B
2” x 5” compact size dual output
A ray leakage current <100uA
ORDERING GUIDE
SPECIFICATION
MPE-008A-P
80W universal input open-frame power supply
Input Voltage
90V ~ 264V AC
Input Frequency
47 ~ 63 Hz
Input Current
[email protected]; [email protected]
Efficiency
> 80%
Holdup Time
16 ms at full load
Over Voltage Protection
Automatic recovery up on of over voltage condition. Trigger
point is at about 5.8V ~ 6.8V
DC OUTPUT
5V
+12V
Max. Load
5A
5A
Min. Load
0A
0A
±3%
±3%
MTBF
130,000 hrs
EMI & Safety Approval
UL, cUL, TUV, CE, CCC
Load Reg.
Temperature/Humidity
Operating: -20 ~ 50oC, 5 ~ 95%RH
Storage: -20 ~ 85oC, 5 ~ 95%RH
Line Reg.
±1%
±1%
Ripple
50mv
120mv
Noise
50mv
120mv
Dimension (WxDxH)
50.8 x 127 x 40 mm; 2.0” x 5” x 1.57”
MPI-806H
60W universal input open-frame
power supply
FEATURES
80W with 8.6CFM forced air-cooling
Compact size with ATX output
PG/PF signal
+5V standby & remote on/off
ORDERING GUIDE
SPECIFICATION
MPI-806H
60W ATX, open-frame power supply
Input Voltage
90V ~ 264V AC
Input Frequency
47 ~ 63 Hz
Input Current
[email protected], [email protected]
Efficiency
> 70%
Holdup Time
20 ms. at full load
Over Voltage Protection
+5V: 5.15 ~ 6.45V; +3.3V: 3.7 ~ 4.5V; +12V: 12.6 ~ 15.6V
+5V
+3.3V
+12V
-12V
+5Vsb
Over Power/Load Protection
Output power over 120%
Max. Load
8A
6A
3A
0.5A
0.75A
MTBF
130,000 hrs
Min. Load
1A
0A
0A
0A
0A
EMI & Safety Approval
UL, TUV
Load Reg.
±2%
±4%
±4%
±5%
±4%
Temperature/Humidity
Operating: 0 ~ 40oC, 20 ~ 90%RH
Storage: -20 ~ 60oC, 5 ~ 95%RH
Dimension (WxDxH)
128 x 81 x 40 mm; 5.0” x 3.2” x 1.55”
DC OUTPUT
Line Reg.
±1%
±1%
±1%
±1%
±1%
Ripple
50mv
50mv
120mv
120mv
120mv
Noise
±1%
±1%
±1%
±2%
±1%
Industrial Power Supply 162
Adapter
APH-3019-40W
SPECIFICATION
AC Input Voltage
90V ~ 264V
DC Output Voltage
12V
Output Load
3.33A
Output Regulation
11.4V~12.6V
Efficiency
>83.1%, [email protected], [email protected]
MTBF
100,000 [email protected]°C
EMI & Safety Approval
UL, cUL, TUV, CE, FCC, CB
Dimension
110(w) x 50(d) x 32(h) mm
APH-3020-60W
SPECIFICATION
AC Input Voltage
90V ~ 264V
DC Output Voltage
12V
Output Load
5A
Output Regulation
11.4V~12.6V
Efficiency
>87%, [email protected], [email protected]
MTBF
60,000 [email protected]°C
EMI & Safety Approval
UL, cUL, TUV, CE, FCC, CB
Dimension
110(w) x 62(d) x 32(h) mm
APH-3023-96W
SPECIFICATION
AC Input Voltage
90V ~ 264V
DC Output Voltage
12V
Output Load
8A
Output Regulation
11.4V~12.6V
Efficiency
>81%, [email protected], [email protected]
MTBF
100,000 [email protected]°C
EMI & Safety Approval
UL, cUL, TUV, CE, FCC, CB
Dimension
174(w) x 65(d) x 37(h) mm
APH-3011-150W
SPECIFICATION
163 Industrial Power Supply
AC Input Voltage
90V ~ 264V
DC Output Voltage
12V
Output Load
12.5A
Output Regulation
11.4V~12.6V
Efficiency
>86%, [email protected], [email protected]
MTBF
43,800 [email protected]°C
EMI & Safety Approval
UL, cUL, TUV, CE, FCC, CB
Dimension
171(w) x 72(d) x 40(h) mm
Configuration Matrix
Model
AREMO2173-MX
AREMO2173P
AREMO2173EB
ATX M/B
Micro ATX
V
AREMO3194
AREMO3194E
AREMO4196
RPC-500NC
PRC-4207
V
V
V
V
V
V
V
V
V
V
Server Board
PEB-7710
V
AREMO6163
AREMO8164
V
V
PBP-05V464/J
V
PBP-06P3
V
PBP-06P4
PBP-06P564
V
PBP-06V4
V
V
PBP-08A7
V
PBP-08P3
V
PBP-08P4
V
PBP-13D4
V
V
V
PBP-14A7
V
V
V
PBP-14AC
V
V
V
PBP-14AC-B
V
V
V
PBP-14P4
V
V
V
PBP-14PD64
V
PBP-14R4
V
V
V
V
PBP-18D4
PBP-19AC
PBP-19AI
PBP-19P4
PBPE-06V
V
PBPE-13A8
V
ORION-D4602P
ORION-300DX/24/48
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
ORION-D4201P
ORION-B3501P
V
ORION-B3502
V
ORION-D3502P
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
ORION-D4601P
V
V
V
V
V
V
V
V
ORION-D5501P
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
ORION-D3501P
FSP350-60GLC
V
V
Industrial Power Supply 164
Accessory
Embedded System Integration Service
In order to help improve our customer's product time to market, Portwell provides the following services
for the Embedded Computing Platform.
These services are provided for both board support and system integration, and are available to our valued
customers who work with our world-class ecosystem and alliance program for embedded computing.
The three main services include:
1. Panel Kit service
This service focuses on the Interactive Client segment -- defined by Intel IPD as users of display-oriented applications such as POS/
ATM/KIOSK/Medical/Gaming/E-payment -- and is supplemented by the 2001 Portwell Alliances with a first tier LCD maker in Taiwan
to provide three year longevity support, panel kit for most of Portwell embedded system boards, with customized video BIOS, and Intel
Embedded Graphic Driver (IEGD) by customer request.
2. Embedded OS board support package
Portwell joins the Microsoft Windows Embedded Partner (WEP) program and works with chipset and device silicon venders to provide
customers with this board support package (BSP). Customers can now focus their application software to shorten the system developing
cycle and still maintain a lower total cost of ownership (TCO).
3. Peripherals integration and system level thermal solution
Portwell can provide consulting service and deliverable solution for peripherals integration upon customer’s request. Our customer
service engineering team can even be your window to leverage the IT infrastructure of the greater China area.
Display Solution
Panel Kit service
Portwell focus on AUO Industrial Flat Panel Display featuring high brightness, 3-year longevity and great price competition. We
manage standard kits in stock to fulfill customers' time-critical orders. We also provide panel kit by different makers like Sharp,
Toshiba, NEC and LG to meet different requirements per specific applications. To order, customers may fill out a special panel
support request form and send it through to our account sales.
Standard Panel Kit for Power Embedded System Board for AUO LCD
Panel
AUO 8.4”
G084SN05 V0
AUO 10.4”
G104SN03 V0
AUO 12.1”
G121SN01 V0
AUO 15”
G150XG01 V0
AUO 17”
M170EG01 V0
AUO 19”
M190EN04 V1
AUO 20.1”
M201UN02 V2
PEB-3715
AL1-052
AL1-050
AL1-051
AL1-047
AL1-053
AL1-062
AL1-061
PEB-3730/32
AL1-056
AL1-054
AL1-055
AL1-048
AL1-057
AL1-069
AL1-060
PEB-3718
AL1-070
AL1-071
AL1-072
AL1-073
x
x
x
Model
Touch Screen service
Portwell works with worldwide touch screen makers like Elo/Tyco and 3M. For cost effective solution, Portwell
provides feasibility for
1 Required communication interface for Touch board, like RS232 or USB
2 Required size of Touch screen
3 Required actual application for suitable touch screen model, like resistive or capacitive
165 Industrial Power Supply
EZCool
A reliable thermal solution of processor is always highly appreciated for most
applications. The reliable solution is not only about whether the processor over its
thermal specification or keep its temperature under protection point but also noise
and weight related. EZCool is the reliable thermal solution for Intel® CoreTM 2 Duo
processor, Pentium® 4 651 and Celeron® D 352 and so on that Thermal Design
Power (TDP) does not over 65W because of it’s compact size, silent cooling fan
and fixing mechanism.
SPECIFICATION
Socket Type
Socket LGA 775 (CoreTM 2 Duo, Celeron® 440)
Heat Sink Dimension
90 x 90 x 18mm (L x W x H)
55.5x11.3 mm (compatible with 80mm fan)
Fan Dimension
ORDERING GUIDE
Part #
Model Name & Description
B9970620
EZCool
High efficiency and low profile cooler for
CoreTM 2 Duo processor
Heat Sink Material
Aluminum extrusion base and fins
Fan Speed
5.76 CFM (At zero pressure and 25oC, rated speed)
Fan Air Pressure
9.11 mmH2O (At zero static pressure and 25oC, rated speed)
Fan Life Expectancy
40,000 hours at 45oC
Bearing Type
Ball Bearing
Voltage Rating
12 VDC
Input Current
0.3 A Max. (At 25oC, in free air rated voltage)
Noise Level
39.3 dBA
Connector
3 pin
Heat Sink Weight
136.4 g (included fasteners)
Fan Weight
13.6 g
Thermal Interface Material
SC102
FEATURES
Along with Intel®’s CoreTM Mircoarchitecture and advanced manufacturing technologies, processor Thermal Design Power
(TDP) was lower from 85~130W to 65W only, and even lower for single core processor in Q3 this year. As a result, Portwell is
able to design a reliable cooler that can fits most applications demanding.
Compact Size
Bending Prevention
EZCool is just one of third height of boxed cooler that benefits applications
that need low profile cooler.
Larger preload of cooler causes the main board bending and it could
introduce permanent damage to the PCB (Print Circuit Board) and traces
on it. With back plate conjunction, EZCooler makes no defection of board.
61mm
20.24mm
Twist Avoidance
Semi-symmetric Design
Main board fixed vertically in chassis instead of horizontally such as PICMG
1.X SBC/SHB can be twisted because of the weight of cooler. It damages
SBC/SHB badly once the platform vibrates or shakes in the same direction.
The semi-symmetric heat sink design allows air flow thru dual directions
that can help ventilation of other key components nearby and fully leverage system air flow that draw from outside of the chassis.
Industrial Power Supply 166
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
