Cisco Cisco TelePresence MX800 Video Conferencing System Installation guide

MX800 Single
with single camera
MX800 Single
with dual camera
MX700
with single camera
MX800 Dual
MX700
with dual camera
Cisco TelePresence MX700 and MX800 Wall Mount
Room preparation guide
D15346.01 | 2016 MARCH
© 2016 Cisco Systems, Inc. All rights reserved.
Cisco TelePresence MX700 and MX800 Wall Mount - Room Preparation Guide
Contents
Requirements for the wall and mounting hardware..............................................3
Screw dimensions for the wall bracket.................................................................4
This document discusses how to
prepare the room before you start to
install the wall-mounted version of
Cisco TelePresence MX700 and MX800.
Planning the mounting height...............................................................................5
Planning the cable placement for MX700 with single or dual camera..................6
Planning the cable placement for MX800 Single with single or dual camera.......7
Planning the cable placement for MX800 Dual....................................................8
More resources....................................................................................................9
D15346.01 | 2016 MARCH
2
© 2016 Cisco Systems, Inc. All rights reserved.
Cisco TelePresence MX700 and MX800 Wall Mount - Room Preparation Guide
Requirements for the wall and mounting hardware
Follow local regulations
Requirements for the wall
Place mounting points at the studs in the wall
The wall-mounted system must be installed by qualified
personnel, in accordance with state and local regulations
for buildings and electrical installations.
Due to the size and weight of the MX700/MX800 systems,
it is important that the wall’s structure is able to support
the weight of the system, with a good margin.
The studs in the wall are normally spaced evenly, but
that is not necessarily the case in all buildings. Place the
mounting points at the studs.
The mounting points must hit a minimum number of studs:
Safety precaution
The lower wall bracket holds the total weight of the
system, and the focus is mainly on this bracket when
speaking about how much load the wall must support.
The systems power switch must be available at all times,
because it serves as the main disconnect device. The
power switch is located at the left side of the unit, behind
the side cover.
System weight
MX700
• Weight (single camera): 161 kg / 355 lb
• Weight (dual camera): 167 kg / 368 lb
Due to the size and mass of this product, we recommend
three people working together to mount the system.
MX800 Single
• Weight (single camera): 110 kg / 242 lb
• Weight (dual camera): 116 kg / 256 lb
Due to the size and mass of this product, we recommend
four people working together to mount the system.
Calculating the load per mounting point
In order to calculate the load per mounting point for the
lower wall bracket, you may want to use a safety factor.
This safety factor depends on the wall’s structure and the
state and local building regulations. As a general rule of
thumb, a safety factor of four (4) can be used.
Calculating the load per mounting point:
• Weight of the system [kg] × Safety factor / Number of
mounting points = Kilograms per mounting point
Convert to Newton per mounting point:
• Kilograms per mounting point × 9.81 m/s2 = Newton
per mounting point.
If you determine that the load per mounting point is
too high for the wall, you should consider adding more
mounting points or to reinforce the wall.
Requirements for the mounting hardware
MX800 Dual
• Weight: 224 kg / 494 lb
Due to the size and mass of this product, we recommend
four people working together to mount the system.
D15346.01 | 2016 MARCH
• For MX700, the mounting points must hit a minimum of
three studs
• For MX800 Single, the mounting points must hit a
minimum of two studs
• For MX800 Dual, the mounting points must hit a
minimum of four studs
Recommended number of mounting points
More mounting points than mentioned below can be used.
• The lower wall bracket holds the total weight of the
monitor. We recommend that you use a minimum of
four mounting points for each lower bracket. Locate
the studs in the wall and align the mounting points to
the studs.
• The top wall bracket secures that the top of the
monitor is held in place and prevents the monitor
from tipping forward. We recommend that you use a
minimum of two mounting points for each top bracket.
• The left spacer and right spacer ensures that the
space between the top and lower bracket is correct.
We recommend that you use two mounting points for
each spacer.
The mounting hardware (screws and bolts) used for wallmounting must be able to safely support the product.
The screw dimension supported by the wall bracket is
5 mm / 0.20 in. Mounting hardware is not provided.
3
© 2016 Cisco Systems, Inc. All rights reserved.
Cisco TelePresence MX700 and MX800 Wall Mount - Room Preparation Guide
Screw dimensions for the wall bracket
The screw dimension for the wall bracket is 5 mm / 0.20 in. The screw dimension is equal
for MX700 and MX800. The size of the wall brackets for MX700 and MX800 are not equal.
25 25
.98 .98
The illustration shows the wall brackets with an MX700.
25
.98
73
2.87
Top
bracket
5
.20
Spacer
Spacer
73 73
2.87 2.87
5
5
.20 .20
Top bracket dimensions
Lower
bracket
25
.98
15
.59
15 15
.59 .59
257325
.982.87
.98
5
.20
73 73
2.87 2.87
5
5
.20 .20
Lower bracket dimensions
D15346.01 | 2016 MARCH
4
© 2016 Cisco Systems, Inc. All rights reserved.
Cisco TelePresence MX700 and MX800 Wall Mount - Room Preparation Guide
Planning the mounting height
The recommended mounting height, measured from the floor to the horizontal slots in the
wall bracket (see illustration), is the same for MX700 and MX800. The illustration shows
the wall brackets with an MX700.
25
.98
The lower edge of
the screen image is
at the height of these
horizontal slots.
25
.98
15
.59
We recommend that the
distance from the floor
to the horizontal slots
in the wall bracket is
70 cm / 27.6 in.
If you mount the system higher than 70 cm / 27.6 in,
note the following consequences:
• You may need to increase the distance between
the video system and the table in order for the
closest participants to be captured by the camera.
• The camera gives an elevated view of the room,
and this is not optimal for video conferencing.
Floor
D15346.01 | 2016 MARCH
5
© 2016 Cisco Systems, Inc. All rights reserved.
73
2.87
5
.20
Cisco TelePresence MX700 and MX800 Wall Mount - Room Preparation Guide
C
148
5.82
Planning the cable placement for MX700 with single or dual camera
The illustration shows an MX700 with dual camera. The same dimensions apply to the
single camera version.
C
Safety precaution
The systems power
switch must be
available at all times,
because it serves as
the main disconnect
device. The power
switch is located at the
left side of the unit,
behind the side cover.
Left
side
27
1.06
C
The cables can be lead out (or in)
through these openings.
121
4.76
C
36
1.41
40
1.57
41
1.61
39
1.54
Section C-C: Detail from the lower part of the system.
The opening (36 mm / 1.41 in) at the back of the
monitor runs along the entire length, except where
the cable bridge is installed.
62
2.44
220
8.66
65
2.56
D15346.01 | 2016 MARCH
6
© 2016 Cisco Systems, Inc. All rights reserved.
Cisco TelePresence MX700 and MX800 Wall Mount - Room Preparation Guide
C
Planning the cable placement for MX800 Single with single or dual camera
148
5.82
The illustration shows an MX800 Single monitor with dual camera. The same dimensions
apply to the single camera version.
C
Safety precaution
The systems power
switch must be
available at all times,
because it serves as
the main disconnect
device. The power
switch is located at the
left side of the unit,
behind the side cover.
Left
side
C
27
The cables can beC lead out (or in)
through these openings.
1.06
121
4.76
39
1.54
41
1.61
62
2.44
D15346.01 | 2016 MARCH
30
1.18
36
1.41
40
1.57
Section C-C: Detail from the lower part of the system.
The opening (36 mm / 1.41 in) at the back of the
monitor runs along the entire length, except where
the cable bridge is installed.
400
15.75
225
8.86
7
© 2016 Cisco Systems, Inc. All rights reserved.
Cisco TelePresence MX700 and MX800 Wall Mount - Room Preparation Guide
C
Planning the cable placement for MX800 Dual
148
5.82
C
Safety
precaution
The systems power
switch must be
available at all times,
because it serves as
the main disconnect
device. The power
switch is located at
the left side of the
unit, behind the side
cover.
Left
side
27
1.06
The cables can be lead out (or in)C
through these openings.
121
4.76
C
36
1.41
40
1.57
39
1.54
41
1.61
Section C-C: Detail from the lower part
of the system. The opening (36 mm /
1.41 in) at the back of the monitor runs
along the entire length, except where
the cable bridge is installed.
400
15.75
39
1.54
62
2.44
225
8.86
D15346.01 | 2016 MARCH
8
© 2016 Cisco Systems, Inc. All rights reserved.
Cisco TelePresence MX700 and MX800 Wall Mount - Room Preparation Guide
More resources
User documentation for the MX series
User documentation for the MX series is found here:
http://www.cisco.com/go/mx-docs
2D CAD drawings with dimensions for MX700 and MX800
A set of 2D CAD drawings with dimensions for the MX series is found here:
http://www.cisco.com/c/en/us/support/collaboration-endpoints/telepresence-mx-series/products-technical-reference-list.html
Explore Project Workplace
Project Workplace can help you design and implement video enabled work spaces to improve collaboration:
http://projectworkplace.cisco.com/#/
Best Practices Guide
Download the Best Practices For Creating Effective Video-Enabled Rooms:
http://www.cisco.com/c/dam/assets/sol/tp/project-workplace/index.html#/page/download
Design Zone for Collaboration
Learn about the preferred architecture and system design for deploying Cisco Collaboration technology in the enterprise:
http://www.cisco.com/c/en/us/solutions/enterprise/design-zone-collaboration/index.html
D15346.01 | 2016 MARCH
9
© 2016 Cisco Systems, Inc. All rights reserved.
