28НТ5404
28НТ5404
0416115
System SmartCord™ 3v3 range
Especially designed for in-room Interactive applications within Hotels
• Monitor Look
• Programmable Channel Blanking
• SmortCord™ 3v3 Expansion Slot For
• Auto Power On
Application Cards (prepared for Digital)
• Volume Control Locking Features
• SmartPlug™ Two-Ways Addressable Port
• Switch On Channel Programming
• Stereo
• Audio/Video Muting
• Multi Language Teletext Reception
• ESP™ (Energy Savings Programmability)
• Wireless Smart-Loader™ Fast Reliable Clone
• Built-in Extra Power Supply (12V, 5V, 3V3)
Programming Capability
• Security Menu Access
• Front Control Lockout
• Low Battery Detect/on For Remote Control
• Welcome Message Selection
• Consumer Television Convertible
• Sleep Timer
• Head Phone Connection
• Fast IR Loop Through Connection
• External Speaker Connection
• Electronic Program Guide
28НТ5404
The System SmartCard™ 3v3 is a full featured
commercial television designed and manufactured
exclusively for applications utilising interactive services
and entertainment systems.
Product Information
Product Highlights
Audio/Video Muting
Smart Plug™ Port
Automatically detects a loss of television signal and
optionally mutes both audio and video.
Compatible with all major premium entertainment
services, the Philips "SmartPlug" eliminates
confusing set-top boxes and makes it easy for
guests to use interactive guest services.
Co/our
SmartCard™ 3v3 Expansion Slot
Metallic Anthracite
Chassis
Type: ILOI
Tube Category:
28" Black Line FX / 70 cm
Visual Screen:
28": 67 cm
Smart picture
Sound
Sound Power:
Loudspeaker:
2 x 5 W RMS Stereo
2 On Board Speakers
Wireless Smart-Loader™
Provides the ability to copy all programming
settings from one set into additional sets.This
feature ensures uniformity between sets and
significantly reduces installation time.
PLL digital tuning
UVSH tuner
127 presets
Dynamic Program Differentiation
WST I PageTXT
Connections
Headphone out (3.5 mm jack)
Smartcard Slot
TV aerial Input (75 Q coax)
Ext loudspeakers (3.5 mm jack)
RJI I connector (SmartLoader)
Euro A/V connector
Provides guest with onscreen directory listing
number and network affiliation. Channel guide is
accessed via the touch of a single button on the
remote control.
ESP™ (Energy Saving Programmability)
Energy Saving system that powers television off
after a specified period of use. A simple countdown
clock can be selectively set to operate from
0-99 hours with automatic clock reset at each
power up.
Low Battery detection Remote
Contra/
This feature informs hotelier the need to replace
RC batteries to pre-empt guest complain.
External Speaker connection
Hotel-Mode features
Reception
- Front:
- Rear:
Permits OEM or third-party decoders and
controllers to be installed inside television for
custom designed component integration. Eliminates
need for external set-top decoders, controllers, or
data terminals. Integrates systems for superior
control applications. Allows expandability for future
upgrades. Prepared for Digital applications.
Electronic Program Guide
- Front Control locking: this feature locks all front
controls, preventing guests from adjusting any
television setting.
- Programmable Channel Blanking: provides a means
to force the picture to be blanked without
affecting the audio. Perfect for audio-only services
(e.g. FM radio).
- Volume Control Locking Feoture:this feature forces
the TV set to operate within a user defined
volume range preventing volume adjustments.
- Switch On Channel: it forces the television to a
specified channel when turned on. Perfect for inhouse advertising or information channels.
Easy installation of speaker to bathroom via rear
connector.
We/come Message
A welcome greeting (max. 2 line with 20 characters
each) is displayed on the screen each time the set
is switched on.
Consumer Television Convertible
Easily converts to true consumer television for
after-market sales.
Muhi Language Teletext reception
Miscellaneous
28" Smart Card TV:'ON' Power consumption: 66 W;
Stand-by consumption: 4 W;'OFF' consumption: 2,5 W.
Mains: AC 220-240 ± 10%
Frequency: 50/60 Hz
Net Weight:
37 kg.
TV set Dimension:
(W x H x D mm)
694 x 579 x 470
Ambient temperature: + 5° to 45°
Guests can be served in their own language. Per
each channel western and eastern European
languages, Greek,Turkish, Arabic or Cyrillic
characters are available.
Auto Power On
Forces the default power setting to the ON
position after a power interruption or preventing
sets from being turned off while in use.
RC86702 not by-packed
Type
Version
Transmission System
Destination
28HT5404
/OIZ
PAL BG, SECAM L/L', PAL-I
Continental W. Europe
BG/DK
Eastern Europe + UAE
PAL-I, SECAM L/L' PAL BG
United Kindom + Ireland
28HT5404
/05Z
Specifications subject to change without notice.
