Product Catalogue

Product Catalogue
Product Catalogue
2017
www.tronixlighting.com
Intro
Product Catalogue
Order online? Ask for your
personal login account at
[email protected]
Orders placed before 12.00h (GMT +1)
will be shipped the same day
www.tronixlighting.com
WWW.TRONIXLIGHTING.COM
1
Intro
TRONIX LIGHTING
the quality brand in LED lighting
A-Z PRODUCTAANBOD – LEVERING UIT VOORRAAD
– SCHERPE PRIJSKWALITEITVERHOUDING
Tronix Lighting BV is een voorraadhoudende importeur en leverancier van
Led-verlichting gespecialiseerd in lichtoplossingen voor de professionele
markt. Al vanaf 1963 is er met veel aandacht voor productinnovatie en
ontwikkeling gebouwd aan duurzame relaties met prominente fabrikanten.
Ben van Dijk (i.m.),
Founder Tronix Lighting
Tronix Lighting onderscheidt zich met een breed verlichtingsassortiment,
een uitzonderlijke prijs-kwaliteitverhouding en gedegen vakkennis.
In samenwerking met en ondersteuning van groothandel en installateur
zoeken we continu naar nieuwe verlichtingsmogelijkheden in vrijwel
elk commercieel toepassingsbereik: van kantoren, winkels en horeca tot
aan magazijnen, fabriekshallen en buitentoepassingen. Deskundig en
eerlijk advies, meedenken in maatoplossingen en snelle levertijden staan
bij Tronix Lighting centraal voor duurzame relaties met onze klanten.
A-Z PRODUCT RANGE – DELIVERY FROM
STOCK – SHARP PRICE QUALITY RATIO
Tronix Lighting BV is a stockholding importer and supplier of Led
lighting, specializing in lighting solutions for the professional market.
As of 1963 we have been building sustainable relationships with
prominent manufacturers, putting high focus on product innovation
and development. Tronix Lighting stands out with a very wide product
range, an exceptional price-quality ratio and a high level of expertise.
In cooperation with and support of wholesalers and installers, we are
constantly looking for new lighting possibilities in virtually any field of
application: from offices, shops, hotels and restaurants to warehouses,
5000 m2 warehouse
production facilities and outdoor applications. Expertise and honest advice,
offering customized solutions and fast delivery times is what we believe
what it takes to keep sustainable relationships with our customers.
WE SPEAK YOUR LANGUAGE
2
Intro
A-Z-PRODUKTPALETTE – LIEFERUNG AB LAGER
– SHARFES PREIS/LEISTUNGSVERHÄLTNIS
Tronix Lighting BV ist ein lagerhaltenden Importeur und Lieferant
von Led-Beleuchtung, spezialisiert in Lichtlösungen für den
professionellen Markt. Schon seit 1963 haben wir dauerhafte
Beziehungen mit führenden Herstellern aufbauen können, mit dabei
viel Aufmerksamkeit für Produktentwicklung und Innovation. Tronix
Lighting zeichnet sich durch eine sehr breite Produktpalette, einem
sehr guten Preis Leistungs-Verhältnis und viel Fachkenntnis.
In Zusammenarbeit mit und Unterstützung der Großhändler
und Installateure, suchen wir kontinuierlich nach neuen
Beleuchtungsmöglichkeiten in praktisch jedem kommerziellen Bereich:
von Büros, Geschäfte, Hotels und Restaurants, bis zum Hallen, Werkstätten
und outdoor-Anwendungen. Wir glauben daß kompetente und
ehrliche Beratung, das zutragen Individueller Lösungen, und schnelle
Lieferzeiten schließlich dauerhafte Kundenbeziehungen garantieren.
TRONIX LIGHTING BV
OfficePostal
Tel:
+31 (0) 413 330380
Vluchtoord 41
Postbus 205
Fax:
+31 (0) 413 330385
5406 XP Uden
5400 AE Uden
E-mail:[email protected]
The Netherlands
The Netherlands
website:www.tronixlighting.com
WWW.TRONIXLIGHTING.COM
3
Content
Tronix uses different plug types:
Stripped wire
4
Schuko grounded
CEE 7/7
Schuko ungrounded
CEE 7/17
Euro plug
CEE 7/16
UK plug
BS 1363
Swiss plug
SEV 1011
Universal plug
Content
PANELS
6
DOWNLIGHTS
16
CEILING & WALL LIGHT
24
EMERGENCY LIGHT
36
TRACK LIGHT
40
LED MODULES CONSTANT CURRENT
50
TUBES & LAMPS
68
RECESSED MOUNTING PLATES
86
FLOOD LIGHT
92
WALL WASHERS
104
HIGH BAYS
108
INDUSTRIAL LINE LIGHTING
114
STREET & PARKING LIGHT
126
GARDEN LIGHTS & SPOTS
130
FLEX TAPE
142
NEON FLEX
162
COVE LIGHT
168
ROPE LIGHT
172
FLAT CABLE & BELT LIGHT
176
FIBER LIGHT
180
LIGHT BARS
184
ADVERTISING & SIGNING
188
DRIVERS & CONTROLLERS
194
The images and information provided in this catalogue may be subject
to alterations. Tronix accepts no liability for misprints or errors.
WWW.TRONIXLIGHTING.COM
5
Panels
Functional light for productive work spaces
6
Panels
LED PANEL 60*60 CM | HIGH EFFICIENCY
>100 LM/W | ALUMINIUM FRAME
INPUT
LM/W
240V
>100
CERTIFICATE
WARRANTY
CERTIFICATE
3
years
LED panels with high Lm/W performance in 6000K, 4000K or 3000K
Input: 240V
Power: 34 Watt
LED type: SMD 3014
Dimmable: Optional
Beam: 120°
IP rate: IP20
Length: 595 mm
Width: 595 mm
Depth: 11 mm
Wire length: 2 m
Connection type: Euro plug
Housing frame: Aluminium
PANEL 60*60 | ALU FRAME
COLD WHITE
6000K | 3673 LM
PANEL 60*60 | ALU FRAME
NATURAL WHITE
4000K | 3673 LM
ART. NR.
174-147
DIMMING METHOD
Non-dimmable
ART. NR.
174-146
DIMMING METHOD
Non-dimmable
ART. NR.
174-145
DIMMING METHOD
Non-dimmable
174-164
Triac
174-161
Triac
174-158
Triac
174-165
1-10V
174-162
1-10V
174-159
1-10V
174-166
Dali
174-163
Dali
174-160
Dali
LED PANEL 60*60 CM | HIGH EFFICIENCY
>100 LM/W | WHITE FRAME
Aluminium frame
PANEL 60*60 | ALU FRAME
WARM WHITE
3000K | 3615 LM
INPUT
LM/W
240V
>100
CERTIFICATE
WARRANTY
CERTIFICATE
3
years
LED panels with high Lm/W performance in 4000K or 3000K with white frame
Input: 240V
Power: 34 Watt
LED type: SMD 3014
Dimmable: Optional
Beam: 120°
IP rate: IP20
Length: 595 mm
Width: 595 mm
Depth: 11 mm
Wire length: 2 m
Connection type: Euro plug
Housing frame: Aluminium
(white painted)
PANEL 60*60 | WHITE FRAME
NATURAL WHITE
4000K | 3674 LM
PANEL 60*60 | WHITE FRAME
WARM WHITE
3000K | 3615 LM
ART. NR.
174-141
DIMMING METHOD
Non-dimmable
ART. NR.
174-140
DIMMING METHOD
Non-dimmable
174-182
Triac
174-176
Triac
174-183
1-10V
174-177
1-10V
174-184
Dali
174-178
Dali
White frame
WWW.TRONIXLIGHTING.COM
7
Panels
LED PANEL 60*60 CM | 40W | 4000K
INPUT
240V
LM/W
CERTIFICATE
With white painted aluminium frame
Input: 240V
Power: 40 Watt
LED type: SMD 3014
Dimmable: No
Beam: 120°
IP rate: IP20
Length: 595 mm
Width: 595 mm
Depth: 11 mm
Wire length: 2 m
Connection type: Euro plug
Housing frame: Auminium (white painted)
ART. NR.
COLOR TEMP. (CCT)
174-150
4000K
COLOR LED
 Natural White
LIGHT OUTPUT
3400 Lm
INPUT
CERTIFICATE
Input: 240V
Power: 40 Watt
LED type: SMD 3014
Dimmable: No
Beam: 120°
IP rate: IP20
Length: 595 mm
Width: 595 mm
Depth: 11 mm
Wire length: 2 m
Connection type: Euro plug
Housing frame: Aluminium
COLOR TEMP. (CCT)
4000K
CERTIFICATE
UGR<19
COLOR LED
 Natural White
LIGHT OUTPUT
3358 Lm
LED PANEL 60*60 CM | 25W | RGB
INPUT
240V
Controllable LED panel RGB
Input: 24V (RGB power supply not included)
Power: 25 Watt
LED type: SMD 3014
Dimmable: Yes
Beam: 120°
IP rate: IP20
Length: 595 mm
Width: 595 mm
Depth: 11 mm
Wire length: 2 m
Connection type: Stripped wire
Housing frame: Aluminium
ART. NR.
COLOR LED
COLOR TEMP. (CCT)
LIGHT OUTPUT
174-041
RGB
n/a
2000 Lm
ART. NR.
CONTROLLER*
214-114
RF Controller 12/24V, including RF remote control
* To be used with 12/24V power supply (not included)
8
WARRANTY
3
years
240V
Low UGR (anti-glare) value for visual comfort
ART. NR.
CERTIFICATE
White frame
LED PANEL 60*60 CM | 34W | UGR<19
174-151
WARRANTY
2
years
>85
DIMMABLE
-
+
RGB
CERTIFICATE
WARRANTY
3
years
CERTIFICATE
Panels
WWW.TRONIXLIGHTING.COM
9
Panels
LED PANEL 32*32 CM | 12W | WITH SPRINGS
INPUT
CERTIFICATE
Optional dimming: Triac, Dali
Input: 240V
Power: 12 Watt
LED type: SMD 3014
Dimmable: Optional
Beam: 120°
IP rate: IP20
Length: 320 mm
WARRANTY
CERTIFICATE
3
years
240V
Width: 320 mm
Depth: 9 mm (40 mm incl. springs)
Mounting hole: 297 x 297 mm
Wire length: 1,5 m
Connection type: Euro plug
Housing frame: Aluminium
ART. NR.
COLOR TEMP. (CCT)
174-034
4000K
 Natural White
COLOR LED
1050 Lm
LIGHT OUTPUT
174-033
3000K
 Warm White
970 Lm
ART. NR.
215-250
DRIVER
LED Driver | 700mA | 18 Watt | Triac Dimmable
215-262
LED Driver | 700mA | 20 Watt | Dali Dimmable
LED PANEL 30*120 CM | HIGH EFFICIENCY
>100 LM/W | ALUMINIUM FRAME
INPUT
LM/W
240V
>100
CERTIFICATE
WARRANTY
CERTIFICATE
3
years
LED panels with high Lm/W performance in 6000K, 4000K or 3000K
Input: 240V
Power: 34 Watt
LED type: SMD 3014
Dimmable: Optional
Beam: 120°
IP rate: IP20
Length: 1195 mm
Width: 295 mm
Depth: 11 mm
Wire length: 2 m
Connection type: Euro Plug
Housing frame: Aluminium
COLD WHITE
6000K | 3438 LM
NATURAL WHITE
4000K | 3438 LM
ART. NR.
174-142
DIMMING METHOD
Non-dimmable
ART. NR.
174-144
DIMMING METHOD
Non-dimmable
ART. NR.
174-143
DIMMING METHOD
Non-dimmable
174-173
Triac
174-170
Triac
174-167
Triac
174-174
1-10V
174-171
1-10V
174-168
1-10V
174-175
Dali
174-172
Dali
174-169
Dali
LED PANEL 60*120 CM | HIGH EFFICIENCY
>100 LM/W | ALUMINIUM FRAME
LED panels with high Lm/W performance in 4000K
Input: 240V
Power: 48 Watt
LED type: SMD 3014
Dimmable: Optional
Beam: 120°
IP rate: IP20
NATURAL WHITE 4000K | 5200 LM
10
WARM WHITE
3000K | 3343 LM
Length: 1195 mm
Width: 595 mm
Depth: 11 mm
Wire length: 2 m
Connection type: Euro Plug
Housing frame: Aluminium
ART. NR.
174-149
DIMMING METHOD
Non-dimmable
174-179
Triac
174-180
1-10V
174-181
Dali
INPUT
LM/W
240V
>100
CERTIFICATE
WARRANTY
3
years
CERTIFICATE
Panels
SURFACE MOUNTING KIT FOR 60*60 CM PANEL
ART. NR.
174-101
LENGTH
600 mm
WIDTH
600 mm
HEIGHT
70 mm
SURFACE MOUNTING KIT FOR 30*120 CM PANEL
ART. NR.
174-103
LENGTH
1200 mm
WIDTH
300 mm
CERTIFICATE
CERTIFICATE
HEIGHT
70 mm
SUSPENSION KIT FOR LED PANELS
MAX. 150 CM
CERTIFICATE
Suitable for any size LED Panels
ART. NR.
174-050
MAX. SUSPENDED HEIGHT
150 cm
UNIVERSAL CONNECTOR TO SCHUKO
ART. NR.
595-030
CONNECTION TYPE WIDTH
Schukot
300 mm
CERTIFICATE
HEIGHT
70 mm
WWW.TRONIXLIGHTING.COM
11
Panels
12
Panels
LED Panel Photo Ceilings
Experience natural daylight in any space. Ideal for office spaces, meeting rooms, waiting
areas, passage hallways, healthcare or any kind of treatment rooms.
Create natural environments in unexpected places or give any kind of space a complete different dimension with
photo printed LED panels. They make it possible to take the outside in and experience the effect of natural daylight.
The light effects are amazing.
HOW DOES IT WORK?
1.
Choose your panel size & color temperature:
60 x 60 cm | 30 x 120 cm | 60 x 120 cm in 3000K or 4000K
2.
Your panel gets de-assembled
3.
Choose an image of min. 1MB or make a choice from the ones we are offering.
4.
Your image is printed on a sticker that will then be sealed on the PS diffuser plate (see picture)
5.
The diffuser plate with the sealed image needs 1 day to dry
6.
Your panel is ready to be re-assembled
INFORMATION & PRICING
Our photo led panels include the regular panel price and in addition a basic charge for the sealing part and – if you do
not submit the image yourself – a small amount for a stock picture of your choice. Mounting is included.
For information about (photo) LED panels and pricing you can visit our website or contact us with any questions at
[email protected] For more information and pricing just visit our website or send a mail to [email protected]
AL frame
PS Diffuser
PMMA LGP
LED strip
AL Back plate
NO CURLING AROUND THE EDGES
Because the sticker image is sealed fully onto the PS diffuser plate – up into the corners – there will be no curling around the edges. The sticker will be sealed over the whole surface, making sure it is fully covered by the
aluminium frame. With regular sealing methods the diffuser plate is only just covered into the inside corners of
the frame, making the edges eventually curl up.
WWW.TRONIXLIGHTING.COM
13
Panels |
14
Round
Round
LED PANEL ROUND
| Panels
INPUT
CERTIFICATE
240V
In 5 diameters with choice in 3000K or 4000K
WARRANTY
CERTIFICATE
2
years
Input: 240V
LED type: SMD 3014
Dimmable: Optional (Triac)
Beam: 120°
IP rate: IP44*
Length panel to plug: 20 cm
Length driver to plug: 15 cm
Length power cable to driver: 100 cm
Connection type: Euro plug
Housing frame: Aluminium
* Panel front IP44
Panel driver IP20
ART. NR.
POWER SIZE Ø COLOR TEMP. (CCT)
174-014
5 Watt
124 mm 4000K
 Natural White
COLOR LED
380 Lm
LIGHT OUTPUT CABLE LENGTH*
140 cm
174-080
5 Watt
124 mm 3000K
 Warm White
380 Lm
140 cm
174-081
7 Watt
150 mm 3000K
 Warm White
480 Lm
140 cm
174-016
9 Watt
175 mm 4000K
 Natural White
620 Lm
140 cm
174-082
9 Watt
175 mm 3000K
 Warm White
620 Lm
140 cm
174-083
12 Watt 200 mm 3000K
 Warm White
760 Lm
140 cm
174-018
14 Watt 240 mm 4000K
 Natural White
880 Lm
140 cm
174-084
14 Watt 240 mm 3000K
 Warm White
880 Lm
140 cm
* Length from Europlug to panel
ART. NR.
215-349
DIMMABLE DRIVERS
LED Driver | 300mA | 9 Watt | Triac Dimmable
215-350
LED Driver | 300mA | 18 Watt | Triac Dimmable
215-261
LED Driver | 350mA | 20 Watt | Dali Dimmable
215-270
LED Driver | 350mA | 20 Watt | 1-10V Dimmable
Art. nr. 215-349
ART. NR.
174-014
DIAMETER Ø (A)
123 mm
MOUNTING Ø (B)
109 mm
DEPTH (C)
18 mm
174-080
123 mm
109 mm
18 mm
174-081
146 mm
135 mm
19 mm
174-016
174 mm
160 mm
21 mm
174-082
174 mm
160 mm
21 mm
174-083
199 mm
185 mm
21 mm
174-018
238 mm
225 mm
23 mm
174-084
238 mm
225 mm
23 mm
Art. nr. 215-261
Art. nr. 215-270
WWW.TRONIXLIGHTING.COM
15
Downlights
The right solution for a wide variety in applications
16
Downlights
LED REFLECTOR DOWNLIGHT COB | 15W
HIGH EFFICIENCY
Input: 220-240V
LED qty: 1
LED type: CREE-CXA1512
Driver: Class A driver LiFud included
(Non-dimmable)
Dimmable: Optional
ART. NR.
POWER COLOR TEMP. (CCT)
15 Watt
4000K
 Natural White
1586 Lm
104 Lm/W
136-070
15 Watt
3000K
 Warm White
1498 Lm
103 Lm/W
ART. NR.
DIMMING METHOD
Triac
215-270
1-10 V
215-216
Dali
LED COLOR
ART. NR.
POWER COLOR TEMP. (CCT)
30 Watt
4000K
 Natural White
3040 Lm
109 Lm/W
136-072
30 Watt
3000K
 Warm White
3015 Lm
108 Lm/W
ART. NR.
DIMMING METHOD
Triac
215-210
1-10 V
215-260
Dali
30˚
MOUNTING
HOLE
CERTIFICATE
WARRANTY
CERTIFICATE
3
years
Ø 155 MM
INPUT
POWER
240V
30W
BEAM
30˚
MOUNTING
HOLE
Ø 192 MM
CERTIFICATE
WARRANTY
CERTIFICATE
3
years
Beam: 30°
IP rate: IP20
Connection type: Euro plug
Wire length: 1,2 meter
Mounting: Recessed
Material: Aluminium/Glass
136-073
215-252
BEAM
LIGHT OUTPUT LM/W
LED REFLECTOR DOWNLIGHT COB | 30W
HIGH EFFICIENCY
Input: 220-240V
LED qty: 1
LED type: CREE-CXA2520
Driver: Class A driver LiFud included
(Non-dimmable)
Dimmable: Optional
POWER
15W
Beam: 30°
IP rate: IP20
Connection type: Euro plug
Wire length: 1,2 meter
Mounting: Recessed
Material: Aluminium/Glass
136-071
215-350
INPUT
240V
LED COLOR
LIGHT OUTPUT LM/W
SIZE
DIAMETER (A)
MOUNTING HOLE (B)
MOUNTING DEPTH (C)
15W Downlight
Ø 175 mm
Ø 155 mm
100 mm
30W Downlight
Ø 220 mm
Ø 192 mm
125 mm
Universal plug, Art. nr. 595-030
WWW.TRONIXLIGHTING.COM
17
Downlights
18
Downlights
WWW.TRONIXLIGHTING.COM
19
Downlights
LED REFLECTOR DOWNLIGHT
13W - 18W - 32W
Input: 220-240V
LED qty: 1
LED type: Citizen
Driver: Included (not dimmable)
Dimmable: Optional
Beam: 40°
INPUT
240V
ART. NR.
POWER COLOR TEMP. (CCT)
13 Watt
3000K
 Warm White
MOUNTING
HOLE
MOUNTING
HOLE
MOUNTING
HOLE
Ø 125 MM
Ø 175 MM
Ø 205 MM
CERTIFICATE
WARRANTY
CERTIFICATE
3
years
LED COLOR LIGHT OUTPUT
1100 Lm
136-064
18 Watt
3000K
 Warm White
1600 Lm
136-063
32 Watt
3000K
 Warm White
2800 Lm
ART. NR.
ACCESSORIES
136-167
Glass plate (frosted) for 13W Reflector Downlight - Art. Nr. 136-068
136-166
Glass plate (frosted) for 18W Reflector Downlight - Art. Nr. 136-064
136-165
Glass plate (frosted) for 32W Reflector Downlight - Art. Nr. 136-063
SIZE
DIAMETER (A) MOUNTING HOLE (B) MOUNTING DEPTH (C)
13W model
Ø 147 mm
Ø 125 mm
80 mm
18W model
Ø 204 mm
Ø 175 mm
97 mm
32W model
Ø 230 mm
Ø 205 mm
100 mm
DIMMABLE DRIVERS 13W MODEL
18W MODEL
32W MODEL
1-10V
Art. Nr. 215-270
n/a
Art. Nr. 215-210
Triac Dimmable
Art. Nr. 215-350
n/a
Art. Nr. 215-252
Dali
Art. Nr. 215-261
Art. Nr. 215-260
Art. Nr. 215-260
LED DOWNLIGHT | 18W - 21W - 31W
20
40˚
IP rate: IP20
Connection type: Euro plug
Wire length: 1,2 meter
Mounting: Recessed
Material: Aluminium/Glass
136-068
Input: 220-240V
LED qty: 1
LED type: Seoul LED
Driver: Included (non-dimmable)
Dimmable: Optional
Beam: 90°
BEAM
INPUT
240V
IP rate: IP20
Connection type: Euro plug
Wire length: 1,2 meter
Mounting: Recessed
Material: Aluminium/PC cover
ART. NR.
POWER COLOR TEMP. (CCT)
136-090
18 Watt
3000K
 Warm White
LED COLOR LIGHT OUTPUT
136-091
18 Watt
4000K
 Natural White 1330 Lm
136-092
21 Watt
3000K
 Warm White
136-093
21 Watt
4000K
 Natural White 1650 Lm
136-094
31 Watt
3000K
 Warm White
136-095
31 Watt
4000K
 Natural White 2300 Lm
1260 Lm
1500 Lm
2170 Lm
SIZE
DIAMETER (A) MOUNTING HOLE (B) MOUNTING DEPTH (C)
13W model
Ø 160 mm
Ø 135 mm
56 mm
18W model
Ø 200 mm
Ø 170 mm
85 mm
21W model
Ø 232 mm
Ø 198 mm
94 mm
DIMMABLE DRIVERS 18W MODEL
21W MODEL
31W MODEL
1-10V
Art. Nr. 215-210
Art. Nr. 215-210
n/a
Triac Dimmable
Art. Nr. 215-250
Art. Nr. 215-251
Art. Nr. 215-407
Dali
Art. Nr. 215-262
Art. Nr. 215-260
n/a
BEAM
90˚
MOUNTING
HOLE
MOUNTING
HOLE
MOUNTING
HOLE
Ø 135 MM
Ø 170 MM
Ø 198 MM
CERTIFICATE
WARRANTY
3
years
CERTIFICATE
Downlights
WWW.TRONIXLIGHTING.COM
21
Downlights
LED DOWNLIGHT
20W | ADJUSTABLE | ROUND
Input: 220-240V
LED qty: 1
LED type: Sharp COB
Driver: Included (non-dimmable)
Dimmable: Optional
Beam: 24°
IP rate: IP20
INPUT
POWER
240V
20W
BEAM
24˚
MOUNTING
HOLE
CERTIFICATE
CERTIFICATE
WARRANTY
CERTIFICATE
3
years
Ø 175 MM
Diameter: Ø 188 mm
Mounting hole: Ø 175 mm
Mounting depth: 145 mm
Connection type: Euro plug
Wire length: 1,2 meter
Mounting: Recessed
Material: Aluminium/Glass
Black
ART. NR.
HOUSING
136-010
White (RAL9003) 20 Watt
POWER COLOR TEMP. (CCT)
3000K
 Warm White
2088 Lm
136-013
Black
3000K
 Warm White
2088 Lm
20 Watt
ART. NR.
DIMMABLE DRIVER
215-260
LED Driver | 40W | Dali dimmable
LED COLOR LIGHT OUTPUT
LED DOWNLIGHT
30W | ADJUSTABLE | ROUND
Input: 220-240V
LED qty: 1
LED type: Sharp COB
Driver: Included (non-dimmable)
Dimmable: Optional
Beam: 24°
IP rate: IP20
22
ART. NR.
HOUSING
136-012
White (RAL9003) 30 Watt
INPUT
POWER
240V
30W
Diameter: Ø 188 mm
Mounting hole: Ø 175 mm
Mounting depth: 145 mm
Connection type: Euro plug
Wire length: 1,2 meter
Mounting: Recessed
Material: Aluminium/Glass
POWER COLOR TEMP. (CCT)
3000K
ART. NR.
DIMMABLE DRIVER
215-260
LED Driver | 700mA | 40W | Dali dimmable
215-210
LED Driver | 700mA | 40W | 1-10V dimmable
215-252
LED Driver | 700mA | 40W | Triac dimmable
LED COLOR LIGHT OUTPUT
 Warm White
3018 Lm
BEAM
24˚
MOUNTING
HOLE
Ø 175 MM
CERTIFICATE
CERTIFICATE
WARRANTY
3
years
CERTIFICATE
Downlights
LED DOWNLIGHT 45W | ADJUSTABLE
SQUARE
INPUT
POWER
240V
45W
BEAM
80˚
MOUNTING
HOLE
CERTIFICATE
CERTIFICATE
WARRANTY
CERTIFICATE
3
years
205 x 124
mm
Input: 220-240V
LED qty: 110
LED type: Sharp SMD
Driver: Included
Dimmable: No
Beam: 80°
IP rate: IP20
Mounting depth: 119 mm
Connection type: Euro plug
Wire length: 1,2 meter
Mounting: Recessed
Material: Aluminium/Glass
ART. NR.
COLOR TEMP. (CCT)
136-009
3000K
LED COLOR
 Warm White
LIGHT OUTPUT
4615 Lm
LED DOWNLIGHT 30W | SURFACE MOUNTED
INPUT
POWER
240V
30W
BEAM
36˚
CERTIFICATE
CERTIFICATE
WARRANTY
CERTIFICATE
3
years
Input: 220-240V
LED qty: 1
LED type: Sharp COB
Driver: Included
Dimmable: No
Beam: 36°
CRI: >80
Diameter: Ø 124 mm
Height: 130 mm
IP rate: IP20
Connection type: Euro plug
Wire length: 1,2 meter
Mounting: Recessed
Material: Aluminium/Glass
ART. NR.
COLOR TEMP. (CCT)
136-007
3000K
ART. NR.
ACCESSORIES
169-075
Reflector 38°
169-089
Reflector 60°
LED COLOR
 Warm White
LIGHT OUTPUT
3018 Lm
WWW.TRONIXLIGHTING.COM
23
Ceiling & Wall Lights
Large choice in lighting solutions for walls and ceilings
24
Ceiling & Wall Lights
WALL LAMP GYPSUM | WHITE HOUSING | G9
OUTPUT
Repaintable plaster wall lamp with G9 fitting (excluding lamp)
DOUBLE LIGHT
WARRANTY
CERTIFICATE
2
years
IP rate: IP20
Connection type: G9
Mounting: Surface mounted
Material: Gypsum/plaster
Light output: Up and down
Housing color: White (repaintable)
ART. NR.
MODEL
SIZE (LxWxD)
ART. NR.
MODEL
SIZE (Ø x D)
ART. NR.
MODEL
SIZE (LxWxD)
149-200
Square mini
120 x 120 x 50 mm
149-201
Round
Ø 150 x 75 mm
149-202
Square maxi
115 x 115 x 115 mm
ART. NR.
G9 LAMPS FOR GYPSUM HOUSINGS
175-510
G9 Lamp | 240V | 39 x 2835 LED | 2700K | Dimmable
175-511
G9 Lamp | 240V | 39 x 2835 LED | 4000K | Dimmable
SPOTLIGHT ADJUSTABLE 360°
Input: 220-240V
Power: 8 Watt / 15 Watt
Power Factor: >0.9
LED qty: 1
LED type: Epistar COB
Dimmable: Yes (Triac)
Beam: 24°
CRI: >90
ART. NR.
HOUSING COLOUR
INPUT
240V
BEAM
24˚
WARRANTY
CERTIFICATE
2
years
IP rate: IP20
Color Temp. (CCT): 3000K
Housing Color: White / Black
Driver: Included
Mounting: Surface mounted
Connection type: Screw terminal
Material: Aluminium
POWER
LIGHT OUTPUT
DIAMETER
HEIGHT
137-001
 White
8 Watt
650 Lm
50 mm
75 mm
137-005
 White
15 Watt
1200 Lm
70 mm
110 mm
137-002
 Black
8 Watt
650 Lm
50 mm
75 mm
137-004
 Black
15 Watt
1200 Lm
70 mm
110 mm
ART. NR.
ACCESSORIES
137-009
Ring for 8 Watt and 15 Watt Spotlight to connect and cover Central Box | White
137-010
Ring for 8 Watt and 15 Watt Spotlight to connect and cover Central Box | Black
Art nr. 137-009
Art nr. 137-010
White
Art nr. 137-001
Art nr. 137-005
Black
WWW.TRONIXLIGHTING.COM
25
Ceiling & Wall Lights
WALL LAMP BLACK | 1 X 10W
SINGLE OUTPUT
INPUT
POWER
COLOR TEMP.
IP RATE
240V
10W
3000K
IP44
OUTPUT
SINGLE LIGHT
WARRANTY
CERTIFICATE
2
years
Input: 220-240V
Power: 1 x 10 Watt
LED qty: 1
LED type: CREE CXA-1507
Beam: 115°
Color temperature: 3000K
Lumen: 700 Lm
IP rate: IP44
Connection type: Screw terminal
Mounting: Surface mount
Material: Aluminium
Housing color: Black
ART. NR.
HEIGHT
WIDTH
DEPTH
LIGHT OUTPUT
149-136
141 mm
144 mm
114 mm
Single (down), 1 x 700 Lm
WALL LAMP BLACK | 2 X 10W
DOUBLE OUTPUT
INPUT
POWER
COLOR TEMP.
IP RATE
240V
20W
3000K
IP44
OUTPUT
DOUBLE LIGHT
WARRANTY
CERTIFICATE
2
years
Input: 220-240V
Power: 2 x 10 Watt
LED qty: 2
LED type: CREE CXA-1507
Beam: 115°
Color temperature: 3000K
Lumen: 1400 Lm
IP rate: IP44
Connection type: Screw terminal
Mounting: Surface mount
Material: Aluminium
Housing color: Black
ART. NR.
HEIGHT
WIDTH
DEPTH
LIGHT OUTPUT
149-137
211 mm
144 mm
114 mm
Up and down, 2 x 700 Lm
WALL LAMP BLACK & WHITE | 10W
MOVING SENSOR
Input: 220-240V
Power: 10 Watt
LED qty: 1
LED type: CREE CXA-1507
Beam: 180°
Color temperature: 3000K
Lumen: 500 Lm
IP rate: IP44
Connection type: Screw terminal
Mounting: Surface mount
Material: Aluminium (Opal cover)
Housing color: Black with white cover
26
ART. NR.
HEIGHT
WIDTH
DEPTH
LIGHT OUTPUT
149-027
219 mm
144 mm
114 mm
500 Lm
INPUT
POWER
COLOR TEMP.
IP RATE
240V
10W
3000K
IP44
SENSOR
WARRANTY
2
years
CERTIFICATE
Ceiling & Wall Lights
WALL LIGHT | 2 X 1W | UP & DOWN
INPUT
POWER
COLOR TEMP.
240V
2W
6500K
OUTPUT
DOUBLE LIGHT
Input: 220-240V
Power: 2 Watt
LED qty: 2 (1 up, 1 down)
LED type: CREE
Beam: 40°
Color temperature: 6500K
WARRANTY
CERTIFICATE
2
years
Lumen: 2 x 74 Lm
IP rate: IP20
Connection type: Screw terminal
Mounting: Surface mount
Material: Aluminium
ART. NR.
HEIGHT
WIDTH
DEPTH
LIGHT OUTPUT
148-511
75 mm
76 mm
30 mm
Double, 1 led up & 1 led down
WALL LIGHT | 2 X 1W | UP OR DOWN
INPUT
POWER
COLOR TEMP.
240V
2W
6500K
OUTPUT
SINGLE LIGHT
Input: 220-240V
Power: 2 Watt
LED qty: 2 (on one side)
LED type: CREE
Beam: 40°
Color temperature: 6500K
WARRANTY
CERTIFICATE
2
years
Lumen: 2 x 74 Lm
IP rate: IP20
Connection type: Screw terminal
Mounting: Surface mount
Material: Aluminium
ART. NR.
HEIGHT
WIDTH
DEPTH
LIGHT OUTPUT
148-501
75 mm
140 mm
30 mm
Single 2 led’s, up or down
ALUMINIUM WALL LAMP | 12W
HIGH POWER
Input: 220-240V
Power: 12 Watt
LED qty: 12
LED type: CREE
Beam: 30°
Color temperature: 3000K
INPUT
POWER
COLOR TEMP.
IP RATE
240V
12W
3000K
IP44
OUTPUT
DOUBLE LIGHT
WARRANTY
CERTIFICATE
2
years
Lumen: 812 Lm
IP rate: IP44
Connection type: Screw terminal
Mounting: Surface mount
Material: Aluminium
ART. NR.
HEIGHT
WIDTH
DEPTH
LIGHT OUTPUT
149-135
210 mm
100 mm
130 mm
Double 2 x 406 Lm
ALUMINIUM WALL/BED LAMP | 2,5W
Input: 220-240V
Power: 2,5 Watt
LED qty: 1
LED type: CREE XP-E
Beam: 40°
Color temperature: 3000K
INPUT
POWER
COLOR TEMP.
WARRANTY
240V
2,5W
3000K
2
years
CERTIFICATE
Lumen: 182 Lm
IP rate: IP20
Connection type: Screw terminal
Mounting: Surface mount
Material: Aluminium/Steel
ART. NR.
SIZE MOUNTING BLOCK
LIGHT OUTPUT
149-110
81 x 51 x 32 mm
182 Lm
WWW.TRONIXLIGHTING.COM
27
Ceiling & Wall Lights
28
Ceiling & Wall Lights
WALL LIGHT RECESSED | 1W | 90 X 90 MM
INPUT
POWER
COLOR TEMP.
240V
1W
3000K
MOUNTING
HOLE
80x75 mm
IP RATE
WARRANTY
IP65
2
years
CERTIFICATE
Input: 220-240V
Power: 1 Watt
LED qty: 15
LED type: CREE SMD2835
Color temperature: 3000K
Lumen: 90 Lm
Mounting hole: 80 x 75 mm
IP rate: IP65
Connection type: Screw terminal
Mounting: Recessed
Material: Aluminium
ART. NR.
LENGTH
WIDTH
DEPTH
MOUNTING HOLE LIGHT OUTPUT
135-044
90 mm
90 mm
71 mm
80 x 75 mm
WALL LIGHT RECESSED | 3W | 140 X 70 MM
90 Lm
INPUT
POWER
COLOR TEMP.
240V
3W
3000K
MOUNTING
HOLE
128x58 mm
IP RATE
WARRANTY
IP65
2
years
IP RATE
WARRANTY
IP65
2
years
CERTIFICATE
Input: 220-240V
Power: 3 Watt
LED qty: 15
LED type: CREE SMD2835
Color temperature: 3000K
Lumen: 190 Lm
Mounting hole: 125 X 58 mm
IP rate: IP65
Connection type: Screw terminal
Mounting: Recessed
Material: Aluminium
ART. NR.
LENGTH
WIDTH
DEPTH
MOUNTING HOLE LIGHT OUTPUT
135-045
140 mm
70 mm
71 mm
125 x 58 mm
WALL LIGHT RECESSED | 3W | 140 X 140 MM
190 Lm
INPUT
POWER
COLOR TEMP.
240V
3W
3000K
MOUNTING
HOLE
128x112 mm
CERTIFICATE
Input: 220-240V
Power: 3 Watt
LED qty: 15
LED type: CREE SMD2835
Color temperature: 3000K
Lumen: 190 Lm
Mounting hole: 128 x 112 mm
IP rate: IP65
Connection type: Screw terminal
Mounting: Recessed
Material: Aluminium
ART. NR.
LENGTH
WIDTH
DEPTH
MOUNTING HOLE LIGHT OUTPUT
135-046
140 mm
140 mm
71 mm
128 x 112 mm
190 Lm
WWW.TRONIXLIGHTING.COM
29
Ceiling & Wall Lights
WALL LIGHT RECESSED | 700mA | 2,5W ROUND
Including recessed box
INPUT
POWER
COLOR TEMP.
700
mA
2,5W
3000K
MOUNTING
HOLE
Ø 50 MM
IP RATE
WARRANTY
IP65
2
years
CERTIFICATE
Input: 700mA
Power: 2,5 Watt
LED qty: 1
LED type: CREE XP
Beam: 120°
Color temperature: 3000K
IP rate: IP65
Connection type: Stripped wire
Mounting: Recessed
Material: Aluminium
ART. NR.
DIAMETER
MOUNTING HOLE LIGHT OUTPUT
135-140
78 mm
Ø 50 mm
111 Lm
WALL LIGHT RECESSED | 350mA | 1W | 50 X 83 MM
Including recessed box
INPUT
POWER
COLOR TEMP.
350
mA
1W
3000K
MOUNTING
HOLE
72x40 mm
WARRANTY
CERTIFICATE
2
years
Input: 350mA
Power: 1 Watt
LED qty: 1
LED type: MCOB
Beam: 120°
Color temperature: 3000K
IP rate: IP54
Connection type: Stripped wire
Wire length: 95 mm
Mounting: Recessed
Material: Aluminium
ART. NR.
LENGTH
WIDTH
DEPTH
MOUNTING HOLE LIGHT OUTPUT
135-142
82,5 mm
51 mm
34 mm
72 x 40 mm
WALL LIGHT RECESSED | 350mA | 3W
135 X 50 MM
100 Lm
INPUT
POWER
COLOR TEMP.
350
mA
3W
3000K
Including recessed box
Input: 350mA
Power: 3 Watt
LED qty: 1
LED type: MCOB
Beam: 120°
Color temperature: 3000K
IP rate: IP54
Connection type: Stripped wire
Wire length: 95 mm
Mounting: Recessed
Material: Aluminium
30
ART. NR.
LENGTH
WIDTH
DEPTH
MOUNTING HOLE LIGHT OUTPUT
135-143
133 mm
51 mm
34 mm
125 x 40 mm
300 Lm
MOUNTING
HOLE
125x40 mm
WARRANTY
2
years
CERTIFICATE
Ceiling & Wall Lights
WALL LIGHT RECESSED | 700mA | 2,5W | ROUND
INPUT
POWER
COLOR TEMP.
700
mA
2,5W
3000K
MOUNTING
HOLE
Ø 40 MM
WARRANTY
CERTIFICATE
2
years
Input: 700mA
Power: 2,5 Watt
LED qty: 1
LED type: CREE XP-E
Color temperature: 3000K
IP rate: IP20
Connection type: Modular plug
Mounting: Recessed
Material: Aluminium/PC
ART. NR.
DIAMETER
MOUNTING HOLE
MOUNTING DEPTH
LIGHT OUTPUT
148-528
42 mm
Ø 40 mm
53 mm
129 Lm
WALL LIGHT RECESSED | 700mA | 2,5W
SQUARE
INPUT
POWER
COLOR TEMP.
700
mA
2,5W
3000K
MOUNTING
HOLE
Ø 40 MM
WARRANTY
CERTIFICATE
2
years
Input: 700mA
Power: 2,5 Watt
LED qty: 1
LED type: CREE XP-E
Color temperature: 3000K
IP rate: IP20
Connection type: Modular plug
Mounting: Recessed
Material: Aluminium/PC
ART. NR.
DIAMETER
MOUNTING HOLE
MOUNTING DEPTH
LIGHT OUTPUT
148-529
42 mm
42 mm
53 mm
129 Lm
WALL LIGHT RECESSED | 0,5W | MINI
INPUT
POWER
COLOR TEMP.
12V
0.5W
5000K
MOUNTING
HOLE
Ø 30 MM
WARRANTY
CERTIFICATE
2
years
Input: 12V
Power: 0,5 Watt
LED qty: 6
LED type: CREE SMD3528
Beam: 120°
Color temperature: 5000K
IP rate: IP20
Connection type: Stripped wire
Mounting: Recessed
Material: Aluminium
ART. NR.
DIAMETER
MOUNTING HOLE
MOUNTING DEPTH
LIGHT OUTPUT
150-001
40 mm
Ø 30 mm
18 mm
30 Lm
WWW.TRONIXLIGHTING.COM
31
Vestibule lightning
32
Ceiling & Wall Lights
VESTIBULE BULKHEAD | 6,4W
RECTANGULAR | IP65
Input: 220-240V
Power: 6,4 Watt
LED qty: 1
Color temperature: 4000K
IP rate: IP65
INPUT
POWER
COLOR TEMP.
IP RATE
WARRANTY
240V
6,4W
4000K
IP65
2
years
CERTIFICATE
Connection type:
Screw connection
Mounting: Surface mount
Material: Polycarbonate
ART. NR.
LENGTH
WIDTH
DEPTH
LIGHT OUTPUT
136-024
345 mm
110 mm
65 mm
350 Lm
BULLS EYE LAMP | 5W-10W | IP54
INPUT
POWER
POWER
COLOR TEMP.
IP RATE
WARRANTY
240V
5W
10W
3500K
IP54
2
years
CERTIFICATE
In 5 or 10 Watt
Input: 220-240V
LED qty: 1
LED type: Cluster LED
Beam: 115°
Color temperature: 3500K
IP rate: IP54
Connection type:
Screw connection
Mounting: Surface mount
Material: Aluminium/Glass cover
ART. NR.
POWER
DIAMETER
DEPTH
LIGHT OUTPUT
136-055
5 Watt
Ø 154 mm
96 mm
275 Lm
136-056
10 Watt
Ø 154 mm
96 mm
550 Lm
VESTIBULE LAMP OVAL | 10W-12W | IP65
Input: 85-265V
LED type: SMD LED
Beam: 120°
Color temperature: 4000K
IP rate: IP65
INPUT
POWER
POWER
COLOR TEMP.
IP RATE
IK
WARRANTY
240V
10W
12W
4000K
IP65
IK09
2
years
Connection type:
Screw connection
Mounting: Surface mount
Material: Aluminium/PMMA cover
ART. NR.
POWER
LENGTH
WIDTH
DEPTH
LIGHT OUTPUT
136-022
10 Watt
220 mm
135 mm
96 mm
750 Lm
136-023
12 Watt
280 mm
180 mm
80 mm
950 Lm
VESTIBULE LAMP | 20W | ROUND
Input: 85-265V
LED type: SMD LED
Beam: 120°
Color temperature: 4000K
IP rate: IP65
CERTIFICATE
INPUT
POWER
COLOR TEMP.
IP RATE
IK
WARRANTY
240V
20W
4000K
IP65
IK09
2
years
CERTIFICATE
Connection type:
Screw connection
Mounting: Surface mount
Material: Aluminium/PMMA cover
ART. NR.
POWER
LENGTH
WIDTH
DEPTH
LIGHT OUTPUT
136-020
20 Watt
Ø 300 mm
135 mm
80 mm
1550 Lm
WWW.TRONIXLIGHTING.COM
33
Ceiling & Wall Lights
CEILING LIGHT | 12W-18W | IP44
INPUT
POWER
POWER
COLOR TEMP.
IP RATE
WARRANTY
240V
12W
18W
3000K
IP44
2
years
INPUT
POWER
COLOR TEMP.
SENSOR
WARRANTY
240V
9W
3000K
INPUT
POWER
COLOR TEMP.
IP RATE
WARRANTY
240V
22W
3000K
IP65
2
years
CERTIFICATE
Input: 220-240V
LED type: SMD 2835
Color temperature: 3000K
Beam: 115°
IP rate: IP44
Connection type: Screw connection
Mounting: Surface mount
Material: Polycarbonate
ART. NR.
POWER
DIAMETER
DEPTH
LIGHT OUTPUT
136-004
12 Watt
Ø 220 mm
53 mm
800 Lm
136-005
18 Watt
Ø 280 mm
53 mm
1200 Lm
CEILING LIGHT | 9W
CERTIFICATE
2
years
Input: 220-240V
LED qty: 156
LED type: SMD 2835
Color temperature: 3000K
Beam: 120°
IP rate: IP20
Connection type: Screw connection
Mounting: Surface mount
Material: Metal/Polycarbonate
ART. NR.
POWER
DIAMETER
DEPTH
LIGHT OUTPUT
MOVING SENSOR
136-002
9 Watt
Ø 258 mm
80 mm
827 Lm
No
136-003
9 Watt
Ø 258 mm
80 mm
827 Lm
Yes
CEILING LIGHT | 22W | IP65
Input: 220-240V
LED qty: 300
LED type: SMD 2835
Color temperature: 3000K
Beam: 120°
IP rate: IP65
Connection type: Screw connection
Mounting: Surface mount
Material: Polycarbonate
34
ART. NR.
POWER
DIAMETER
DEPTH
LIGHT OUTPUT
EMERGENCY
600-005
22 Watt
Ø 343 mm
106 mm
1100 Lm
No
600-004
24 Watt
Ø 343 mm
106 mm
1200 Lm
Yes
CERTIFICATE
Ceiling & Wall Lights
PENDANT LIGHT ALUMINIUM | 700mA | 2,5W
INPUT
POWER
COLOR TEMP.
WARRANTY
700
mA
2,5W
3000K
2
years
CERTIFICATE
Input: 700mA
Power: 2,5 Watt
LED qty: 1
LED type: CREE XP-E
Beam: 40°
Color temperature: 3000K
IP rate: IP20
Connection type: Modular plug
Mounting: Surface mount
Material: Aluminium
ART. NR.
DIAMETER
LENGTH
178-010
Ø 40 mm
118 mm
COLOR TEMP. (CCT)
 3000K
LIGHT OUTPUT
129 Lm
PENDANT LIGHT | 2 PCS | RGB & WARM WHITE
INCL. REMOTE CONTROL
INPUT
POWER
COLOR TEMP.
240V
18W
3000K
RGB
WARRANTY
CERTIFICATE
2
years
RGB and warm white can be controlled separately.
Including 1m mounting rail.
Input: 220-240V
Power: 2 x 9 Watt
Beam: 90°
Color temperature: 2*3000K & RGB
IP rate: IP20
Wire length: 1440 mm
Mounting rail: 1 meter
Mounting: Surface mount
Material: Aluminium/Polycarbonate/Glass
ART. NR.
DIAMETER
HEIGHT
178-002
Ø 100 mm
200 mm

COLOR TEMP. (CCT)
LIGHT OUTPUT
3000K + RGB
2 x 400 Lm
PENDANT LIGHTING FIXTURE | HIGHBAY SMALL
E27 + ACRYLATE HOOD
INPUT
IP RATE
WARRANTY
240V
IP54
2
years
CERTIFICATE
E27 lamp not included
Input: 220-240V
IP rate: IP54
Connection type: Screw connection
Fitting: E27
Wire Lenght: 690 mm
Mounting: Surface mount
Material: Acrylate
ART. NR.
DIAMETER
HEIGHT
950-010
Ø 325 mm
940 mm
WWW.TRONIXLIGHTING.COM
35
Emergency Light
Setting best standards for escape route illumination
36
Emergency Lights
LED EMERGENCY LIGHT | RECTANGULAR | IP65
INPUT
COLOR TEMP.
240V
4000K
SURFACE
SURFACE
IP RATE
CERTIFICATE
WARRANTY
CERTIFICATE
2
years
IP65
Excluding pictogram sticker art. nr. 600-006
Input: 240V
LED qty: 10
LED type: SMD5050
Color temp. (CCT): 4000K
Color LED: Natural White
Lumen: 95 Lm
IP rate: IP65
Operating time: min. 3 hrs
Connection type: Screw
Material: PC/Clear cover
ART. NR.
MOUNTING
POWER
SIZE
600-001
Surface
3,3 Watt
352 x 118 x 75 mm
ART. NR.
ACCESSORY
600-006
Pictogram sticker for emergency bulkheid art. nr. 600-001
LED EMERGENCY LIGHT | DOUBLE BLADE
INPUT
COLOR TEMP.
240V
6500K
SURFACE
RECESSED
CERTIFICATE
WARRANTY
CERTIFICATE
2
years
For recessed or surface mounting
Excluding pictogram sticker - 7 routing designs available
Input: 240V
LED qty: 10
LED type: DIP
Color temp. (CCT): 6500K
Color LED: Cold White
Lumen: 35 Lm
IP rate: IP20
Operating time: min. 3 hrs
Connection type: Screw
Material: Metal/steel housing with acrylic
double sided legend panel
Art. nr. 600-002
Art. nr. 600-007
ART. NR.
MOUNTING
POWER
COLOR TEMP. (CCT)
600-002
Surface
3,1 Watt
6500K
 Cold White
COLOR LED SIZE
305 x 225 x 45 mm
600-007
Recessed
3,4 Watt
6500K
 Cold White
410 x 260 x 135 mm
ART. NR.
PICTOGRAM STICKERS FOR ART. NR. 600-002 | 600-007
600-010
1. Direction Down
2. Direction Down
600-011
1. Direction Down
2. Neutral Green
600-012
1. Direction Up
2. Direction Up
600-013
1. Direction Up
2. Neutral Green
600-014
1. Direction Left
2. Direction Right
600-015
1. Direction Left
2. Neutral Green
600-016
1. Direction Right
2. Neutral Green
Art. nr. 600-010
Art. nr. 600-011
Art. nr. 600-012
Art. nr. 600-014
Art. nr. 600-015
Art. nr. 600-016
Art. nr. 600-013
WWW.TRONIXLIGHTING.COM
37
Emergency Lights
38
Emergency Lights
LED EMERGENCY SPOT
INPUT
COLOR TEMP.
240V
3000K
RECESSED
RECESSED
Ø 55MM
CERTIFICATE
WARRANTY
CERTIFICATE
2
years
Input: 240V
LED qty: 1
LED type: SMD
Color temp. (CCT): 3000K
Color LED: Warm White
Lumen: 160 Lm
IP rate: IP20
Operating time: min. 3 hrs
Connection type: Screw
Material: PC housing
ART. NR.
MOUNTING
POWER
DIAMETER
MOUNTING HOLE
MOUNTING DEPTH
600-003
Recessed
2 Watt
Ø 140 mm
Ø 55 mm
58 mm
LED CEILING EMERGENCY FIXTURE | IP65
INPUT
COLOR TEMP.
240V
3000K
SURFACE
SURFACE
IP RATE
CERTIFICATE
WARRANTY
CERTIFICATE
2
years
IP65
Also available in non-emergency version with continuous light (Art. nr. 600-005)
Input: 240V
LED qty: 300
LED type: SMD2835
Color temp. (CCT): 3000K
Color LED: Warm White
IP rate: IP65
Connection type: Screw
Material: PC housing
ART. NR.
LIGHT FUNCTION
MOUNTING
POWER
LUMEN
DIAMETER
OPERATING TIME
600-004
Emergency
Surface
24 Watt
1200 Lm
Ø 343 mm
Min. 3 hrs
600-005
Continuous
Surface
22 Watt
1100 Lm
Ø 343 mm
n/a
LED EMERGENCY PACK | FOR CONSTANT CURRENT DRIVER
INPUT
240V
CERTIFICATE
WARRANTY
CERTIFICATE
2
years
Input: 240V
Load: Max. 65W, with voltage ≤ 40V
Output: <40V DC
ART. NR.
POWER
SIZE
OPERATING TIME
600-008
Max. 65 Watt
204 x 111 x 44 mm
Min. 3 hrs
WWW.TRONIXLIGHTING.COM
39
Track Light
Powerful light sources for efficient
lighting and natural looking colors
in retail and hospitality
40
Track Light
3 PHASE TRACK SPOT | COB | 30W | 24°
INPUT
POWER
240V
30W
With 24° beam in 3000K, 4000K and Rose (meat)
BEAM
24˚
CRI
>80
CRI
>90
Input: AC 220-240V
Power: 30 Watt
Power factor: > 0,95
LED qty: 1 pc
LED type: Sharp COB
Dimmable: Triac (optional)
Beam: 24°
CRI: >80 / >90
IP rate: IP20
Length: 220 mm
Width: 155 mm
Diameter: 99 mm
Connection type: 3-phase adaptor
Housing: Aluminium
Finish: Black, Silver or White
ART. NR.
White
CRI >80
COLOR TEMP. (CCT)
>80
4000K
 Natural White
3120 Lm
169-064
 White
>80
3000K
 Warm White
3018 Lm
169-057
 Black
>80
4000K
 Natural White
3120 Lm
169-065
 Black
>80
3000K
 Warm White
3018 Lm
169-059
 Silver
>80
4000K
 Natural White
3120 Lm
169-058
 Silver
>80
3000K
 Warm White
3018 Lm
COLOR LED
CRI >90
COLOR TEMP. (CCT)
 White
>90
3000K
 Warm White
3018 Lm
169-111
 Black
>90
3000K
 Warm White
3018 Lm
169-091
 Black
>90
n/a
 Rose
n/a
ART. NR.
ACCESSORIES
169-075
Reflector 38° for 30 Watt Track Spot Series
169-089
Reflector 60° for 30 Watt Track Spot Series
215-251
Triac dimmable driver for 30 Watt Track Spot Series
With rose colored led for
enhanced presentation of meat
Art. nr. 169-091 (Black)
COLOR LED
LIGHT OUTPUT
169-110
TRACK SPOT 30W | MEAT LED
BLACK HOUSING
CERTIFICATE
3
years
Silver
 White
HOUSING
WARRANTY
Black
169-080
ART. NR.
HOUSING
CERTIFICATE
LIGHT OUTPUT
TRACK SPOT 30W | CRI >90
With high CRI for most natural
looking colors
Art. nr. 169-110 (White)
Art. nr. 169-111 (Black)
WWW.TRONIXLIGHTING.COM
41
Track Light
3 PHASE TRACK SPOT | COB | 40W | 38°
With 38° beam in 4000K, 3000K or 2700K
INPUT
POWER
240V
40W
BEAM
38˚
WARRANTY
Input: AC 220-240V
Power: 40 Watt
Power factor: > 0,95
LED qty: 1 pc
LED type: Sharp COB
Dimmable: No
Beam: 38°
CRI: >80
IP rate: IP20
Length: 235 mm
Width: 160 mm
Diameter: 109 mm
Connection type: 3-phase adaptor
Housing: Aluminium
Finish: Black, Silver or White
ART. NR.
42
CERTIFICATE
CERTIFICATE
CERTIFICATE
3
years
Black
Silver
White
HOUSING
COLOR TEMP. (CCT)
169-076

White
4000K
 Natural White
4220 Lm
169-066

White
3000K
 Warm White
4087 Lm
169-090

Black
2700K
 Warm White+
4027 Lm
169-077

Black
4000K
 Natural White
4220 Lm
169-067

Black
3000K
 Warm White
4087 Lm
169-079

Silver
4000K
 Natural White
4220 Lm
169-078

Silver
3000K
 Warm White
4087 Lm
ART. NR.
ACCESSORIES
169-086
Reflector 24° for 40 Watt Track Spot Series
COLOR LED
LIGHT OUTPUT
Track Light
3 PHASE TRACK SPOT | COB | 30W | 24° | DE LUXE
INPUT
POWER
240V
30W
With 24° beam in 3000K and optional anti-glare reflector
BEAM
24˚
WARRANTY
CERTIFICATE
CERTIFICATE
CERTIFICATE
3
years
No-screw feature
Input: AC 220-240V
Power: 30 Watt
Power factor: > 0,95
LED qty: 1 pc
LED type: Sharp COB
Dimmable: No
Beam: 24°
CRI: >80
IP rate: IP20
Length: 217 mm
Width: 142 mm
Diameter: 99 mm
Connection type: 3-phase adaptor
Housing: Aluminium
Finish: White and black
Modern screwles design
With optional anti-glare reflector
ART. NR.
169-099
HOUSING
 White
COLOR TEMP. (CCT)
3000K
ART. NR.
ACCESSORIES
169-100
Anti-glare sheet for art. nr. 169-099
169-075
Reflector 38° for 30 Watt Track Spot Series
169-089
Reflector 60° for 30 Watt Track Spot Series
COLOR LED
 Warm White
LIGHT OUTPUT
3018 Lm
WWW.TRONIXLIGHTING.COM
43
Track Light
3 PHASE TRACK SPOT | COB | 30W | 36°|
INTEGRATED DRIVER
INPUT
POWER
240V
30W
BEAM
36˚
WARRANTY
CERTIFICATE
CERTIFICATE
CERTIFICATE
3
years
With built-in driver and 36° beam in 3000K
Input: AC 220-240V
Power: 30 Watt
Power factor: > 0,95
LED qty: 1 pc
LED type: Sharp COB
Dimmable: No
Beam: 36°
CRI: >80
IP rate: IP20
Length: 295 mm
Width: 108 mm
Diameter: 99,5 mm
Connection type: 3-phase adaptor
Housing: Aluminium
Finish: Black, Silver or White
ART. NR.
HOUSING
Black
Silver
White
COLOR TEMP. (CCT)
COLOR LED
LIGHT OUTPUT
169-092
 White
3000K
 Warm White
3018 Lm
169-093
 Black
3000K
 Warm White
3018 Lm
169-094
 Silver
3000K
 Warm White
3018 Lm
ART. NR.
ACCESSORIES
169-098
Reflector ° for 30 Watt Track Spot Series
169-089
Reflector 60° for 30 Watt Track Spot Series
3 PHASE TRACK SPOT | COB | 40W |
ADJUSTABLE BEAM 20°~60°
INPUT
POWER
BEAM
WARRANTY
240V
40W
20˚~60˚
3
years
In 3000K and with adjustable beam for maximum light direction
Input: AC 220-240V
Power: 40 Watt
Power factor: > 0,95
LED qty: 1 pc
LED type: Sharp COB
Dimmable: No
Beam: 20°~60°
CRI: >80
IP rate: IP20
Length: 220 mm
Width: 200 mm
Diameter: 101 mm
Connection type: 3-phase adaptor
Housing: Aluminium
Finish: Black
ART. NR.
169-087
44
HOUSING
 Black
ADJ. BEAM
20°~60°
COLOR TEMP. (CCT)
3000K
COLOR LED
 Warm White
LIGHT OUTPUT
4087 Lm
CERTIFICATE
CERTIFICATE
CERTIFICATE
WWW.TRONIXLIGHTING.COM
45
Track Light
3 PHASE TRACK SPOT | COB | 2 x 30W | 36° |
DOUBLE HEAD
INPUT
POWER
240V
2X
30W
BEAM
36˚
WARRANTY
CERTIFICATE
CERTIFICATE
CERTIFICATE
3
years
In 3000K with double head for best beam direction
Input: AC 220-240V
Power: 60 Watt
Power factor: > 0,95
LED qty: 2 pcs
LED type: Sharp COB
Dimmable: Optional
Beam: 36°
CRI: >80
IP rate: IP20
Length: 225 mm
Width: 260 mm
Depth: 109 mm
Connection type: 3-phase adaptor
Housing: Aluminium
Finish: Black, Silver or White
ART. NR.
HOUSING
Black
Silver
White
COLOR TEMP. (CCT)
COLOR LED
LIGHT OUTPUT
169-095
 White
3000K
 Warm White
6036 Lm
169-096
 Black
3000K
 Warm White
6036 Lm
169-097
 Silver
3000K
 Warm White
6036 Lm
ART. NR.
ACCESSORIES
169-098
Reflector 24° for 30 Watt Track Spot Series
169-089
Reflector 60° for 30 Watt Track Spot Series
215-251 (2x)
Dimmable driver for 30 Watt Track Spot Series
3 PHASE TRACK SPOT | COB | 20W | 24°
3000K track spot with COB led
INPUT
POWER
240V
20W
BEAM
24˚
WARRANTY
3
years
Input: AC 220-240V
Power: 20 Watt
Power factor: > 0,95
LED qty: 1 pc
LED type: Sharp COB
Dimmable: No
Beam: 24°
CRI: >80
IP rate: IP20
Length: 200 mm
Width: 140 mm
Depth: 105 mm
Connection type: 3-phase adaptor
Housing: Aluminium
Finish: White
ART. NR.
169-069
46
HOUSING
 White
COLOR TEMP. (CCT)
3000K
COLOR LED
 Warm White
LIGHT OUTPUT
2088 Lm
CERTIFICATE
CERTIFICATE
CERTIFICATE
Track Light
3 PHASE TRACK SPOT FIXTURE | E27
WARRANTY
CERTIFICATE
CERTIFICATE
5
years
With E27 socket in black, silver or white.
Lamp not included
IP rate: IP20
Length: 75 mm
Width: 38 mm
Housing: Aluminium
Finish: Black, Silver or White
Black
Silver
White
ART. NR.
HOUSING
169-053
 White
169-054
 Black
169-050
 Silver
ART. NR.
COLOR TEMP. (CCT)
DIMMABLE
175-214
LED PAR38 Lamp E27 22W COB 3000K 25°
No
175-230
LED PAR20 Lamp E27 8W COB 3000K 25°
No
175-231
LED PAR30 Lamp E27 15W COB 2700K 25°
Yes
175-214
175-230
175-231
3 PHASE TRACK SPOT FIXTURE | GU10
WARRANTY
CERTIFICATE
CERTIFICATE
5
years
With GU10 socket in black, silver or white.
Lamp not included
IP rate: IP20
Length: 108 mm
Width: 55 mm
Housing: Aluminium
Finish: Black, Silver or White
Black
Silver
White
ART. NR.
HOUSING
169-055
 White
169-056
 Black
169-051
 Silver
ART. NR.
COLOR TEMP. (CCT)
DIMMABLE
175-118
LED GU10 Lamp 9W 3000K 40° Aluminium
Yes
175-131
LED GU10 Lamp 5W 2700K 40° White
Yes
175-135
LED GU10 Lamp 5W 2700K 40° Grey
Yes
175-139
LED GU10 Lamp 5W 4000K 40° Grey
Yes
175-118
175-131
175-135
175-139
WWW.TRONIXLIGHTING.COM
47
3-Fase
Phase Rail & Accessories
Track Light
POWER CONNECTOR
ENDCAP
ART. NR.
COLOR
ART. NR.
COLOR
COLOR
 Black
169-043
 Black
169-041
 Black
169-007
 Silver
169-015
 Silver
169-006
 Silver
169-025
 White
169-026
 White
169-024
 White
L-CONNECTOR
X-CONNECTOR
ART. NR.
COLOR
ART. NR.
COLOR
ART. NR.
COLOR
169-048
 Black
169-049
 Black
169-045
 Black
169-011
 Silver
169-017
 Silver
169-009
 Silver
169-031
 White
169-032
 White
169-028
 White
L-CONNECTOR ADJUSTABLE
INTERIOR CONNECTOR
ART. NR.
COLOR
ART. NR.
COLOR
169-070
 Black
169-040
 Black
169-012
 Silver
169-005
 Silver
169-033
 White
169-023
 White
FLEXIBLE CONNECTOR
I-CONNECTOR
ART. NR.
48
ART. NR.
169-042
COLOR
ART. NR.
COLOR
169-072
 Black
169-044
 Black
169-013
 Silver
169-008
 Silver
169-035
 White
169-027
 White
3-Fase Phase Rail & Accessories
Track Light
T-CONNECTOR
ART. NR.
COLOR
ART. NR.
COLOR
ART. NR.
COLOR
ART. NR.
COLOR
169-046
 Black
169-047
 Black
169-101
 Black
169-104
 Black
169-010
 Silver
169-016
 Silver
169-102
 Silver
169-105
 Silver
169-029
 White
169-030
 White
169-103
 White
169-106
 White
3 PHASE ADAPTER
PENDING
2m
ART. NR.
COLOR
ART. NR.
COLOR
169-074
 Black
169-073
 Black
169-020
 Silver
169-014
 Silver
169-037
 White
169-036
 White
3-PHASE TRACK RAIL
Rail 2 meter
ART. NR.
COLOR
Rail 3 meter
ART. NR.
COLOR
169-038
 Black
169-039
 Black
169-002
 Silver
169-003
 Silver
169-021
 White
169-022
 White
WWW.TRONIXLIGHTING.COM
49
LED Modules
Constant Current
Custom-made spot light solutions for
homes, shops & hospitality
50
LED Modules Constant Current
Tronix Universal Modules provide in a large range of application possibilties. Because of its design these Ø 50 mm LED
spots fit all common armatures currently used for 20W, 35W or 50W halogen spots.
UNIVERSAL MODULE | 2,5 WATT
Fits all regular 50 mm plates
Input: 700mA
Power: 2,5 Watt
LED qty: 1
LED type: CREE XP-E/G2
Dimmable: Yes
Beam: 40°
INPUT
POWER
700
mA
2,5W
BEAM
40˚
DIMMABLE
-
CERTIFICATE
WARRANTY
CERTIFICATE
3
years
+
IP rate: IP44
Diameter: Ø 50 mm
Depth: 24 mm
Connection type: Modular plug
Wire length: 100 cm
Housing: Aluminium
ART. NR.
VOLTAGE
COLOR TEMP. (CCT)
148-101
3,6 Volt
6500K
 Cold white
COLOR LED
> 141 Lm
148-137
3,6 Volt
3000K
 Warm white
> 182 Lm
148-139
3,6 Volt
2700K
 Warm white+
> 182 Lm
148-102
3,6 Volt
n/a
 Blue
n/a
148-103
3,6 Volt
n/a
 Green
n/a
148-104
2,4 Volt
n/a
 Red
n/a
148-105
2,4 Volt
n/a
 Amber
n/a
ART. NR.
ACCESSORY
148-101
Surface mounting box for Universal Module 2,5 Watt
UNIVERSAL MODULE COB | 3,3 WATT
Fits all regular 50 mm plates
Input: 350mA
Power: 3,3 Watt
LED qty: 1
LED type: CREE COB CXA-1304
Dimmable: Yes
Beam: 40°
LIGHT OUTPUT
INPUT
POWER
350
mA
3,3W
BEAM
40˚
DIMMABLE
-
CERTIFICATE
WARRANTY
CERTIFICATE
3
years
+
IP rate: IP44
Diameter: Ø 50 mm
Depth: 35 mm
Connection type: Modular plug
Wire length: 100 cm
Housing: Aluminium
35
24
ART. NR.
VOLTAGE
COLOR TEMP. (CCT)
148-146
9,4 Volt
3000K
 Warm white
COLOR LED
300 Lm
LIGHT OUTPUT
148-147
9,4 Volt
2700K
 Warm white+
300 Lm
Application possibilities with Universal LED Modules 50 mm:
Plate 80 serie
Plate 90 serie
Ground Spots
Surface mounting armatures
Renovation of
existing installations
WWW.TRONIXLIGHTING.COM
51
LED Modules Constant Current
UNIVERSAL MODULE COB | 6,5 WATT
Fits all regular 50 mm plates
Input: 700mA
Power: 6,5 Watt
LED qty: 1
LED type: CREE COB CXA-1304
Dimmable: Yes
Beam: 45°
INPUT
POWER
700
mA
6,5W
BEAM
45˚
DIMMABLE
-
CERTIFICATE
WARRANTY
IP rate: IP44
Diameter: Ø 50 mm
Depth: 61 mm
Connection type: Modular plug
Wire length: 100 cm
Housing: Aluminium
Art. nr. 148-140 / 148-141
ART. NR. MODEL VOLTAGE COLOR TEMP. (CCT)
COLOR LED
Regular
9,3 Volt
3000K
 Warm white
509 Lm
148-141
Regular
9,3 Volt
2700K
 Warm white+ 509 Lm
148-162
Flat
9,3 Volt
3000K
 Warm white
148-163
Flat
9,3 Volt
2700K
 Warm white+ 509 Lm
509 Lm
UNIVERSAL MODULE COB | 9 WATT
Fits all regular 50 mm plates
INPUT
POWER
BEAM
350
mA
9W
28˚
DIMMABLE
-
CERTIFICATE
WARRANTY
CERTIFICATE
3
years
+
IP rate: IP44
Diameter: Ø 50 mm
Depth: 62 mm
Connection type: Modular plug
Wire length: 100 cm
Housing: Aluminium
ART. NR.
VOLTAGE
COLOR TEMP. (CCT)
COLOR LED
LIGHT OUTPUT
148-164
28 Volt
3000K
 Warm white
1244 Lm
148-165
28 Volt
2700K
 Warm white+
1244 Lm
POWER MODULE | 7,5 WATT | ADJUSTABLE
Fits in the plate 90 series
Input: 700mA
Power: 7,5 Watt
LED qty: 3
LED type: CREE XP-E
Dimmable: Yes
Beam: 40°
52
Art. nr. 148-162 / 148-163
LIGHT OUTPUT
148-140
Input: 350mA
Power: 9 Watt
LED qty: 1
LED type: Epistar COB
Dimmable: Yes
Beam: 28°
CERTIFICATE
3
years
+
IP rate: IP20
Diameter: Ø 70 mm
Mounting depth: 47 mm
Connection type: Modular plug
Wire length: 100 cm
Housing: Aluminium
ART. NR.
VOLTAGE
COLOR TEMP. (CCT)
148-201
10,8 Volt
6500K
COLOR LED
 Cold white
LIGHT OUTPUT
423 Lm
INPUT
POWER
700
mA
7,5W
BEAM
40˚
DIMMABLE
-
+
CERTIFICATE
WARRANTY
3
years
CERTIFICATE
LED Modules Constant Current
WAYS OF DIMMING: PRIMARY, 0-10V AND WIRELESS DIMMING
The Tronix Architectural Modular Lighting System offers different dimming possibilities;
we here present the 3 most popular methods:
Primary dimming
This is the most popular way
of dimming, often used when
replacing traditional 50mm halogen
lamps or at small projects. This
way of dimming takes place at the
primary (230V) side and is based
on triac dimming. For this way of
dimming we recommend our Tronix
LED driver art. 215-131, but you
can also use most LED dimmers of
other brands like Gira, Berker, etc.
0-10V Dimming
This way of dimming is most
effective because it uses a separate
dimming signal. 1-10V dimming is
usually applied for new projects
where it is easy to offer an extra
signal cable for 1-10V (next to a 230V
system). For this way of dimming
we recommend our Tronix LED
driver art. 215-130, but you can
also use most LED dimmers of
other brands like Gira, Berker, etc.
Wireless Dimming
This way of dimming is quite
popular at smaller projects in
e.g. hotel rooms, porches, living
rooms etc. The dimmer works
with a memory function and a
soft touch on/off switch for a high
and luxurious user experience.
WWW.TRONIXLIGHTING.COM
53
LED Modules Constant Current
54
LED Modules Constant Current
WWW.TRONIXLIGHTING.COM
55
LED Modules Constant Current
The Downlight Module is designed for single mounting above sinks, in show cases, conservatories and floating ceilings.
In light technique comparable tot the Universal Module
DOWNLIGHT MODULE SMALL | 1 WATT
Input: 350mA
Power: 1 Watt
LED qty: 1
LED type: CREE XP-G2
Dimmable: Yes
Beam: 90°
IP rate: IP44
POWER
BEAM
1W
90˚
MOUNTING
HOLE
Ø 21 MM
DIMMABLE
-
CERTIFICATE
WARRANTY
CERTIFICATE
3
years
+
Diameter: Ø 25 mm
Mounting hole: Ø 21 mm
Mounting depth: 17,2 mm
Connection type: Modular plug
Wire length: 100 cm
Housing: Aluminium
ART. NR.
VOLTAGE
COLOR TEMP. (CCT)
148-155
3,6 Volt
3000K
COLOR LED
Input: 700mA
Power: 2,5 Watt
LED qty: 1
LED type: CREE XP-E/G2
Dimmable: Yes
Beam: 40°
IP rate: IP44
LIGHT OUTPUT
 Warm White
DOWNLIGHT MODULE | 2,5 WATT
56
INPUT
350
mA
90 Lm
INPUT
POWER
700
mA
2,5W
BEAM
40˚
MOUNTING
HOLE
Ø 43 MM
Diameter: Ø 50 mm
Mounting hole: Ø 43 mm
Mounting depth: 24 mm
Connection type: Modular plug
Wire length: 100 cm
Housing: Aluminium
ART. NR.
VOLTAGE
COLOR TEMP. (CCT)
148-111
3,6 Volt
6500K
 Cold white
COLOR LED
>141 Lm
LIGHT OUTPUT
148-119
3,6 Volt
3000K
 Warm white
>182 Lm
148-149
3,6 Volt
2700K
 Warm white+
>182 Lm
148-112
3,6 Volt
n/a
 Blue
n/a
148-113
3,6 Volt
n/a
 Green
n/a
148-114
2,4 Volt
n/a
 Red
n/a
148-115
2,4 Volt
n/a
 Amber
n/a
DIMMABLE
-
+
CERTIFICATE
WARRANTY
3
years
CERTIFICATE
LED Modules Constant Current
DOWNLIGHT MODULE COB | 3,3 WATT
Input: 350mA
Power: 3,3 Watt
LED qty: 1
LED type: CREE COB CXA-1304
Dimmable: Yes
Beam: 40°
IP rate: IP44
ART. NR.
VOLTAGE COLOR TEMP. (CCT)
9,4 Volt
3000K
 Warm white
300 Lm
148-151
9,4 Volt
2700K
 Warm white+
300 Lm
COLOR LED
BEAM
40˚
MOUNTING
HOLE
Ø 43 MM
DIMMABLE
-
CERTIFICATE
WARRANTY
CERTIFICATE
3
years
+
LIGHT OUTPUT
DOWNLIGHT MODULE | 3 X 2,5 WATT
ADJUSTABLE
INPUT
POWER
700
mA
7,5W
BEAM
40˚
MOUNTING
HOLE
Ø 78 MM
DIMMABLE
-
CERTIFICATE
WARRANTY
CERTIFICATE
3
years
+
Diameter: Ø 87 mm
Mounting hole: Ø 78 mm
Mounting depth: 70 mm
Connection type: Modular plug
Wire length: 50 cm
Housing: Aluminium
ART. NR.
MODEL
VOLTAGE
COLOR TEMP. (CCT)
148-508
Adjustable
10,8 Volt
3000K
COLOR LED
 Warm white
DOWNLIGHT MODULE | 3 X 2,5 WATT
FIXED
Input: 700mA
Power: 7,5 Watt
LED qty: 3
LED type: CREE XP-E
Dimmable: Yes
Beam: 40°
IP rate: IP20
POWER
3,3W
Diameter: Ø 50 mm
Mounting hole: Ø 43 mm
Mounting depth: 33 mm
Connection type: Modular plug
Wire length: 100 cm
Housing: Aluminium
148-150
Input: 700mA
Power: 7,5 Watt
LED qty: 3
LED type: CREE XP-E
Dimmable: Yes
Beam: 40°
IP rate: IP20
INPUT
350
mA
LIGHT OUTPUT
387 Lm
INPUT
POWER
700
mA
7,5W
BEAM
40˚
MOUNTING
HOLE
Ø 78 MM
DIMMABLE
-
+
CERTIFICATE
WARRANTY
CERTIFICATE
3
years
Diameter: Ø 87 mm
Mounting hole: Ø 78 mm
Mounting depth: 70 mm
Connection type: Modular plug
Wire length: 50 cm
Housing: Aluminium
ART. NR.
MODEL
VOLTAGE
COLOR TEMP. (CCT)
148-518
Non-adjustable
10,8 Volt
3000K
COLOR LED
 Warm white
LIGHT OUTPUT
387 Lm
WWW.TRONIXLIGHTING.COM
57
LED Modules Constant Current
58
LED Modules Constant Current
CABINET MODULE | 2,5 WATT
Suitable for mounting in/under closets and kitchen cabinets for best light
spread on kitchen areas
Input: 700mA
Power: 2,5 Watt
LED qty: 1
LED type: CREE XP-E
Dimmable: Yes
Beam: 90°
IP rate: IP44
Diameter: Ø 42 mm
INPUT
POWER
700
mA
2,5W
BEAM
90˚
MOUNTING
HOLE
Ø 34 MM
DIMMABLE
-
CERTIFICATE
WARRANTY
CERTIFICATE
3
years
+
Mounting hole: Ø 34 mm
Mounting depth: 17 mm
Connection type: Modular plug
Wire length: 75 cm
Housing: Aluminium
Wire length: 100 cm
Housing: Aluminium
Art. nr. 148-411
ART. NR.
VOLTAGE
COLOR TEMP. (CCT)
148-128
3,6 Volt
3000K
 Warm white
COLOR LED
129 Lm
148-129
3,6 Volt
2700K
 Warm white+
129 Lm
ART. NR.
ACCESSORY
148-411
Surface mounting box for Cabinet Module Art. Nr. 148-128/148-129
148-413
Triangle mounting box for Cabinet Module Art. Nr. 148-128/148-129
To avoid drilling holes, a surface mounting box is
available to use in combination
with the Cabinet module.
Art. nr. 148-413
Art. nr. 148-128
UNIVERSAL FURNITURE SPOT | 2,5 WATT
Fitting mounting holes of 44 tot 60 mm
Input: 700mA
Power: 2,5 Watt
LED qty: 1
LED type: CREE XP-E
Dimmable: Yes
Beam: 90°
IP rate: IP20
LIGHT OUTPUT
Art. nr.
148-128
+
148-411
Art. nr. 148-411
INPUT
POWER
700
mA
2,5W
BEAM
90˚
MOUNTING
HOLE
Ø 44-60 MM
DIMMABLE
-
+
CERTIFICATE
WARRANTY
CERTIFICATE
3
years
Diameter: Ø 64 mm
Mounting hole: Ø 44-60 mm
Mounting depth: 14 mm
Connection type: Modular plug
Wire length: 100 cm
Housing: Aluminium
ART. NR.
VOLTAGE
COLOR TEMP. (CCT)
148-530
3,6 Volt
4000K
 Natural White
COLOR LED
>129 Lm
LIGHT OUTPUT
148-535
3,6 Volt
3000K
 Warm White
>129 Lm
WWW.TRONIXLIGHTING.COM
59
LED Modules Constant Current
60
LED Modules Constant Current
SINGLE SPOT | 2,5 WATT
For lighting out objects in shop windows, display cases, books. The spot can
also be single mounted with a plug ready connection.
INPUT
POWER
700
mA
2,5W
BEAM
40˚
DIMMABLE
-
CERTIFICATE
WARRANTY
CERTIFICATE
3
years
+
Input: 700mA
Power: 2,5 Watt
LED qty: 1
LED type: CREE XP-E
Dimmable: Yes
Beam: 40°
IP rate: IP20
Diameter: Ø 45 mm
Connection type: Modular plug
Wire length: 100 cm
Housing: Aluminium
ART. NR.
VOLTAGE
COLOR TEMP. (CCT)
148-251
3,6 Volt
6500K
 Cold white
141 Lm
148-258
3,6 Volt
3000K
 Warm white
129 Lm
148-268
3,6 Volt
2700K
 Warm white+
129 Lm
ART. NR.
ACCESSORIES
148-423
Extension pole 10cm
148-426
Extension pole 60cm
148-127
Pole coupler
COLOR LED
SINGLE SPOT EXTENDED | 2,5 WATT
LIGHT OUTPUT
INPUT
POWER
700
mA
2,5W
BEAM
40˚
DIMMABLE
-
+
CERTIFICATE
WARRANTY
CERTIFICATE
3
years
Input: 700mA
Power: 2,5 Watt
LED qty: 1
LED type: CREE XP-E
Dimmable: Yes
Beam: 40°
IP rate: IP20
Diameter: Ø 45 mm
Connection type: Modular plug
Wire length: 100 cm
Housing: Aluminium
ART. NR.
HEIGHT
VOLTAGE
COLOR TEMP. (CCT)
148-259
246 mm
3,6 Volt
3000K
 Warm white
COLOR LED
129 Lm
LIGHT OUTPUT
148-260
346 mm
3,6 Volt
3000K
 Warm white
129 Lm
WWW.TRONIXLIGHTING.COM
61
LED Modules Constant Current
62
LED Modules Constant Current
PORCH MODULE | 700mA | 2,5 WATT
Suitable for outdoor terrace or porch lighting
INPUT
POWER
700
mA
2,5W
BEAM
40˚
MOUNTING
HOLE
Ø 34 MM
DIMMABLE
-
CERTIFICATE
WARRANTY
CERTIFICATE
3
years
+
Input: 700mA
Power: 2,5 Watt
LED qty: 1
LED type: CREE XP-E
Dimmable: Yes
Beam: 40°
IP rate: IP20
Diameter: Ø 42 mm
Mounting hole: Ø 33,5 mm
Mounting depth: 25 mm
Connection type: Modular plug
Housing: Aluminium
ART. NR.
VOLTAGE
COLOR TEMP. (CCT)
148-125
3,6 Volt
3000K
COLOR LED
LIGHT OUTPUT
 Warm white
PORCH MODULE | 350mA | 3,3 WATT
Suitable for outdoor terrace or porch lighting
129 Lm
INPUT
POWER
350
mA
3,3W
BEAM
40˚
MOUNTING
HOLE
Ø 34 MM
DIMMABLE
-
+
CERTIFICATE
WARRANTY
CERTIFICATE
3
years
Input: 350mA
Power: 3,3 Watt
LED qty: 1
LED type: CREE COB CXA-1304
Dimmable: Yes
Beam: 40°
IP rate: IP20
Diameter: Ø 42 mm
Mounting hole: Ø 33,6 mm
Mounting depth: 27 mm
Connection type: Modular plug
Housing: Aluminium
ART. NR.
VOLTAGE
COLOR TEMP. (CCT)
148-126
9,4 Volt
3000K
COLOR LED
 Warm white
LIGHT OUTPUT
300 Lm
WWW.TRONIXLIGHTING.COM
63
LED Modules Constant Current
64
LED Modules Constant Current
PROJECT MODULE | INDOOR
INPUT
POWER
700
mA
2,5W
BEAM
40˚
DIMMABLE
-
CERTIFICATE
WARRANTY
CERTIFICATE
3
years
+
Input: 700mA
Power: 2,5 Watt
LED qty: 1
LED type: CREE XP-E
Dimmable: Yes
Beam: 40°
IP rate: IP20
Diameter: Ø 32 mm
Depth: 23 mm
Connection type: Modular plug
Housing: Aluminium
ART. NR.
VOLTAGE
COLOR TEMP. (CCT)
148-278
3,6 Volt
2700K
COLOR LED
 Warm white+
LIGHT OUTPUT
129 Lm
PROJECT MODULE | OUTDOOR
INPUT
POWER
700
mA
2,5W
BEAM
IP RATE
40˚
IP44
DIMMABLE
-
+
CERTIFICATE
WARRANTY
CERTIFICATE
3
years
Input: 700mA
Power: 2,5 Watt
LED qty: 1
LED type: CREE XP-E
Dimmable: Yes
Beam: 40°
IP rate: IP44
Diameter: Ø 32 mm
Depth: 31 mm
Connection type: Modular plug
Housing: Aluminium
ART. NR.
VOLTAGE
COLOR TEMP. (CCT)
148-288
9,4 Volt
3000K
COLOR LED
 Warm white
LIGHT OUTPUT
129 Lm
WWW.TRONIXLIGHTING.COM
65
LED Drivers
For every application a plug-in ready driver
350mA
1W HP
9W COB
NON DIMMABLE SERIES
POWER
MIN.~MAX.LOAD:
MIN.~MAX.LOAD:
215-201
Indoor
6 Watt
min.1~max.4
min.1~max.1
215-303
Outdoor
4 Watt
min.1~max.3
min.1~max.1
215-412
Indoor
20 Watt
min.1~max.16
min.1~max.6
min.1~max.2
MIN.~MAX.LOAD:
TRIAC DIMMABLE SERIES
POWER
MIN.~MAX.LOAD:
MIN.~MAX.LOAD:
215-306
4 Watt
min.2~max.3
min.1~max.1
Outdoor
215-349
Indoor
9 Watt
min.2~max.7
min.1~max.2
215-350
Indoor
18 Watt
min.4~max.14
min.2~max.5
MIN.~MAX.LOAD:
min.1~max.1
1-10V DIMMABLE SERIES
POWER
MIN.~MAX.LOAD:
MIN.~MAX.LOAD:
MIN.~MAX.LOAD:
215-270
20 Watt
min.1~max.16
min.1~max.6
min.1~max.2
Indoor
DALI DIMMABLE SERIES
POWER
MIN.~MAX.LOAD:
MIN.~MAX.LOAD:
MIN.~MAX.LOAD:
215-261
Indoor
20 Watt
min.1~max.16
min.1~max.6
min.1~max.2
215-260
Indoor
30 Watt
min.3~max.22
min.1~max.8
min.1~max.2
700mA
66
3,3W
2,5W
NON DIMMABLE SERIES
POWER
MIN.~MAX.LOAD:
215-202
6 Watt
min.1~max.2
Indoor
6,5W COB
MIN.~MAX.LOAD:
215-305
Outdoor
4 Watt
min.1~max.1
215-211
Indoor
12 Watt
min.1~max.4
min.1~max.1
215-212
Indoor
20 Watt
min.1~max.8
min.1~max.2
MIN.~MAX.LOAD:
TRIAC DIMMABLE SERIES
POWER
MIN.~MAX.LOAD:
215-307
Outdoor
4 Watt
min.1~max.1
215-249
Indoor
9 Watt
min.2~max.3
min.1~max.1
215-250
Indoor
18 Watt
min.4~max.7
min.1~max.2
215-251
Indoor
25 Watt
min.5~max.10
min.2~max.3
215-252
Indoor
40 Watt
min.8~max.15
min.3~max.5
1-10V DIMMABLE SERIES
POWER
MIN.~MAX.LOAD:
MIN.~MAX.LOAD:
215-210
40 Watt
min.5~max.10
min.2~max.5
Indoor
DALI DIMMABLE SERIES
POWER
MIN.~MAX.LOAD:
MIN.~MAX.LOAD:
215-262
Indoor
20 Watt
min.1~max.7
min.1~max.3
215-260
Indoor
40 Watt
min.5~max.10
min.5~max.10
Plug & Play
Connectors
Work and Material saving
The Tronix modular system is ready to plug in which
saves a huge amount of time in assembly. The low
energy consumption of the wiring also results in major savings, as only very little current runs through
the wires. Thick wiring is therefore unnecessary.
IMPORTANT!
The modules must always be switched in series. When
these connectors are used, this is done automatically.
ORDER CODE
148-300
2-way connector with 2m wire
148-306
3-way connector with 2m wire
148-302
6-way connector with 2m wire
148-303
Extension cable 2 m
148-304
Extension cable 5 m
148-305
Extension cable 10 m
Example of Non-Dimmable system
LED Module
Tronix LED Driver
215-211
215-212
Top side view
LED Module
Tronix modules are standardly equipped with
a 40° lens. Unique feature of the Universal
module, Down Light module and Single
Spot is that the lens is replaceable with one
of your own choice.
Output
Lightbeam
3 way divider
100265V AC
LED Module
2 way divider
Example of Dimmable system (1 to 10V dimmer)
LED Module
148-400 lens 15°
148-401 lens 25°
148-403 lens 60°
Tronix LED Driver
215-110
215-210
Top side view
0-10V
DIM
350mA
3 way divider
Output
700mA
2 way divider
Example of Dimmable system (Halogen dimmer)
LED Module
LED Module
Tronix LED Driver
215-250
215-251
Top side view
Output
LED Module
3 way divider
100265V AC
Lenses
LED Module
100265V AC
DIMMER
LED Module
DIMMER
2 way divider
WWW.TRONIXLIGHTING.COM
67
Tubes & Lamps
A complete range to suit any purpose and get great savings
68
| Tubes & Lamps
T8
LED T8 TUBE 60 CM | 120 CM | 150 CM
RETROFIT
Retrofit installation, with SMD LED and matte cover
Power on one side - dummy starter included
Input: 220-240V AC, 50-60 Hz
Power factor: >90
LED type: SMD
Dimmable: No
Beam: 120°
BEAM
120˚
IP RATE
CERTIFICATE
ART. NR.
LENGTH
POWER
LED QTY COLOR TEMP. (CCT) COLOR CODE
60 cm
9 Watt
98 pcs
3000K
830
 Warm White
860 Lm
177-033
120 cm
18 Watt
196 pcs
3000K
830
 Warm White
1600 Lm
177-035
120 cm
18 Watt
196 pcs
4000K
840
 Natural White
1600 Lm
177-036
150 cm
24 Watt
240 pcs
4000K
840
 Natural White
2350 Lm
177-037
150 cm
24 Watt
240 pcs
3000K
830
 Warm White
2350 Lm
LED T8 TUBE 150 CM | 4000K | GLASS
RETROFIT
COLOR LED
BEAM
120˚
Retrofit installation, with glass housing and SMD LED
Power on one side - dummy starter included
LIGHT OUTPUT
LM/W
IP RATE
>130
IP20
CERTIFICATE
ART. NR.
LENGTH
POWER
LED QTY COLOR TEMP. (CCT) COLOR CODE
150 cm
24 Watt
240 pcs
4000K
840
LED T8 TUBE | 120 CM | SURFACE MOUNT
| CONNECTABLE
RETROFIT
BEAM
120˚
IP RATE
CERTIFICATE
CERTIFICATE
EASY
MOUNTING
WITH RVS
CLIPS
CRI: >80
IP rate: IP20
Max. to connect: 25 pcs
Diameter: Ø 28 mm
Connection type: T8
LENGTH
POWER
LED QTY COLOR TEMP. (CCT) COLOR CODE
120 cm
18 Watt
240 pcs
4000K
840
 Natural White
1600 Lm
177-054
120 cm
18 Watt
240 pcs
3000K
830
 Warm White
1600 Lm
ACCESSORY
WARRANTY
2
years
IP20
ART. NR.
5 meter power cable
GLASS
3120 Lm
177-053
ART. NR.
CERTIFICATE
1
year
LIGHT OUTPUT
 Natural White
Replacement for single halogen 36W surface mount tube
Suitable for stand alone or in-line surface mounting
177-058
WARRANTY
CRI: >80
IP rate: IP20
Diameter: Ø 28 mm
Connection type: T8
Housing: Glass
177-039
Input: 220-240V AC, 50-60 Hz
Power factor: >90
LED type: SMD
LED qty: 240
Dimmable: No
Beam: 120°
CERTIFICATE
CRI: >80
IP rate: IP20
Diameter: Ø 28 mm
Connection type: T8
Housing: Plastic + Aluminium
177-029
Input: 220-240V AC, 50-60 Hz
Power factor: >90
LED type: SMD
Dimmable: No
Beam: 120°
WARRANTY
3
years
IP20
COLOR LED
LIGHT OUTPUT
WWW.TRONIXLIGHTING.COM
69
Tubes & Lamps |
PL-PLC
Attention:
For correct installation and to avoid failure,
please make sure to
remove or disconnect
the existing ballast
LED PL/PL-C | 5 WATT | G23/24 | 2 PIN SOCKET
INPUT
POWER
240V
5W
BEAM
CERTIFICATE
WARRANTY
CERTIFICATE
2
years
125˚
270° rotatable
Input: 220V-240V AC - 50/60Hz
Power: 5 Watt
Power factor: >0,95
Dimmable: No
Color Temp. (CCT): 3000K
Beam: 125°
CRI: >80
IP rate: IP20
Diameter: Ø 35,4 mm
ART. NR.
TYPE
CONN. TYPE
SOCKET
176-001
LED PL
147 mm
LENGTH LIGHT OUTPUT
400 Lm
G23
2 pins
176-008
LED PL-C 147 mm
500 Lm
G24
2 pins
LED PL/PL-C | 7 WATT | G23/24 | 2 OR 4 PIN SOCKET
INPUT
POWER
240V
7W
INPUT
POWER
POWER
240V
5W
7W
BEAM
CERTIFICATE
WARRANTY
CERTIFICATE
2
years
125˚
270° rotatable
Input: 220V-240V AC - 50/60Hz
Power: 7 Watt
Power factor: >0,95
Dimmable: No
Color Temp. (CCT): 3000K
ART. NR.
TYPE
176-002
LED PL
Beam: 125°
CRI: >80
IP rate: IP20
Diameter: Ø 35,4 mm
LENGTH LIGHT OUTPUT
180 mm
560 Lm
CONN. TYPE
SOCKET
G23
2 pins
176-006
LED PL-C 165,5 mm
700 Lm
G24
2 pins
176-009
LED PL-C 165,5 mm
700 Lm
G24
4 pins
LED PL-C | 5 WATT | G24 | 2 PINS
BEAM
CERTIFICATE
WARRANTY
CERTIFICATE
2
years
140˚
270° rotatable
Input: 220V-240V AC - 50/60Hz
Power factor: >0,95
Dimmable: No
Color Temp. (CCT): 3000K
ART. NR. TYPE
Beam: 140°
CRI: >80
IP rate: IP20
Diameter: Ø 35 mm
POWER LENGTH LIGHT OUTP. CONN. TYPE SOCKET
176-016
LED PL-C 7 Watt
148 mm
700 Lm
G24
176-018
LED PL-C 5 Watt
148 mm
500 Lm
G24
2 pins
2 pins
LED PL | 5 WATT | E27 | 125°
INPUT
POWER
240V
5W
INPUT
POWER
240V
5W
BEAM
CERTIFICATE
WARRANTY
CERTIFICATE
2
years
125˚
270° rotatable
Input: 220V-240V AC - 50/60Hz
Power: 5 Watt
Power factor: >0,95
Dimmable: No
Color Temp. (CCT): 3000K
ART. NR.
TYPE
176-007
LED PL
Beam: 125°
CRI: >80
IP rate: IP20
Diameter: Ø 35,4 mm
E27
LENGTH LIGHT OUTPUT
153 mm
400 Lm
CONNECTION TYPE
E27
LED PL | 5 WATT | E27 | 140°
270° rotatable
Input: 220V-240V AC - 50/60Hz
Power factor: >0,95
Dimmable: No
Color Temp. (CCT): 3000K
Beam: 140°
CRI: >80
IP rate: IP20
Diameter: Ø 35 mm
E27
70
ART. NR.
TYPE
176-017
LED PL
POWER LENGTH
5 Watt
156 mm
LIGHT OUTPUT
SOCKET
500 Lm
E27
BEAM
140˚
CERTIFICATE
WARRANTY
2
years
CERTIFICATE
AR111
AR111 LED REFLECTOR LAMP | 240V
INPUT
POWER
POWER
240V
12W
15W
| Tubes & Lamps
External driver included
Input: 220-240V AC, 50-60 Hz
LED type: CREE SCOB
LED qty: 1
Beam: 24°
IP rate: IP20
Diameter: Ø111 mm
Depth: 68 mm
Connection type: Europlug
BEAM
24˚
DIMMABLE
-
CERTIFICATE
WARRANTY
CERTIFICATE
3
years
+
Anti-glare.
Stable Cree LED Chip. Very
low light attenuation.
Reflector design. Closer
traditional lighting effect
ART. NR.
POWER
COLOR TEMP. (CCT)
LIGHT OUTPUT
DIMMABLE
175-313
12 Watt
2700K
 Warm White+
COLOR LED
550 Lm
175-314
15 Watt
2700K
 Warm White+
840 Lm
No
Yes
AR111 LED REFLECTOR LAMP | GU10
INPUT
POWER
240V
15W
BEAM
24˚
DIMMABLE
-
CERTIFICATE
WARRANTY
CERTIFICATE
3
years
+
Input: 220-240V AC, 50-60 Hz
LED type: CREE SCOB
LED qty: 1
Beam: 24°
IP rate: IP20
Diameter: Ø111 mm
Depth: 94 mm
Connection type: GU10
ART. NR.
POWER
COLOR TEMP. (CCT)
175-320
15 Watt
2700K
COLOR LED
 Warm White+
LIGHT OUTPUT
DIMMABLE
840Lm
Yes
AR111 LED REFLECTOR LAMP | G53
INPUT
POWER
12V
15W
BEAM
24˚
CERTIFICATE
WARRANTY
CERTIFICATE
3
years
Direct replacement on 12V
Input: 12V
LED type: CREE SCOB
LED qty: 1
Beam: 24°
IP rate: IP20
Diameter: Ø111 mm
Depth: 68 mm
Connection type: G53
ART. NR.
POWER
COLOR TEMP. (CCT)
175-321
12 Watt
2700K
COLOR LED
 Warm White+
LIGHT OUTPUT
DIMMABLE
550 Lm
No
WWW.TRONIXLIGHTING.COM
71
Tubes & Lamps |
AR111
AR111 LED LAMP | FLAME DIMMING 2200K~2900K
INPUT
POWER
240V
12W
When dimming the lamp color will change from 2900K (100%) to 2200K (5%)
BEAM
36˚
FLAME DIMMING
2200K
CERTIFICATE
WARRANTY
CERTIFICATE
2
years
2900K
External driver included
Input: 220-240V AC, 50-60 Hz
LED type: Sharp COB
LED qty: 1
Beam: 36°
CRI rate: >82 Ra
IP rate: IP20
Diameter: Ø111 mm
Depth: 60 mm
Connection type: Screw terminal
ART. NR.
POWER
COLOR TEMP. (CCT)
175-316
12 Watt
2200K ~ 2900K
COLOR LED
LIGHT OUTPUT
 Warm White ~ Warm white ++ 600 Lm
AR111 LED LAMP | DIMMABLE DRIVER
DIMMABLE
Yes, flame dimming
INPUT
POWER
240V
15W
External driver included
BEAM
25˚
DIMMABLE
-
CERTIFICATE
WARRANTY
CERTIFICATE
2
years
+
Input: 220-240V AC
LED type: Sharp COB
Beam: 25°
IP rate: IP20
Diameter: Ø 111 mm
Depth: 70 mm
Connection type: Euro plug
ART. NR.
POWER
COLOR TEMP. (CCT)
175-270
15 Watt
2700K
COLOR LED
 Warm White
LIGHT OUTPUT
DIMMABLE
900 Lm
Yes
AR111 LED LAMP | 240V | GU10
INPUT
POWER
240V
14W
INPUT
POWER
BEAM
12V
7W
25˚
BEAM
40˚
DIMMABLE
-
CERTIFICATE
WARRANTY
CERTIFICATE
2
years
+
Input: 220-240V AC, 50-60 Hz
LED qty: 6
Dimmable: Yes
Beam: 40°
IP rate: IP20
Diameter: Ø111 mm
Depth: 81 mm
Connection type: GU10
ART. NR.
POWER
COLOR TEMP. (CCT)
175-311
14 Watt
3000K
COLOR LED
 Warm White
LIGHT OUTPUT
DIMMABLE
800 Lm
Yes
AR111 LED LAMP | RGB
Input: 12V RGB
LED qty: 6
Dimmable: Yes
Beam: 25°
IP rate: IP20
Diameter: Ø111 mm
Depth: 38 mm
Connection type: Stripped wire
72
ART. NR.
POWER
COLOR TEMP. (CCT)
COLOR LED
LIGHT OUTPUT
DIMMABLE
175-299
7 Watt
n/a
RGB
n/a
Yes
RGB
DIMMABLE
-
+
CERTIFICATE
WARRANTY
2
years
CERTIFICATE
| Tubes & Lamps
AR70
AR70 LED LAMP | 6 WATT | GU10
INPUT
POWER
BEAM
240V
6W
24˚
In 2700K or with Flame Dimming 2200~2700K
DIMMABLE
-
+
FLAME DIMMING
2000K
CERTIFICATE
WARRANTY
CERTIFICATE
2
years
2700K
Input: 220-240V AC, 50-60 Hz
LED type: Sharp COB
LED qty: 1
Beam: 24°
CRI rate: >82 Ra
IP rate: IP20
Diameter: Ø70 mm
Depth: 62 mm
Connection type: GU10
ART. NR.
POWER
COLOR TEMP. (CCT)
175-343
6 Watt
2700K
 Warm White
COLOR LED
LIGHT OUTPUT
DIMMABLE
300 Lm
Yes
175-344
6 Watt
2200K~2700K
 Warm White++ 300 Lm
AR70 LED LAMP | 7 WATT
DIMMABLE DRIVER | B15
Yes, flame dimming
INPUT
POWER
BEAM
240V
7W
36˚
DIMMABLE
-
+
CERTIFICATE
WARRANTY
CERTIFICATE
3
years
Including dimmable driver & B15 socket
Input: 220-240V AC, 50-60 Hz
LED type: CREE SCOB
LED qty: 1
Beam: 24°
CRI rate: >82 Ra
IP rate: IP20
Diameter: Ø70 mm
Depth: 48,5 mm
Connection type: B15
ART. NR.
POWER
COLOR TEMP. (CCT)
175-340
7 Watt
2700K
COLOR LED
 Warm White+
LIGHT OUTPUT
DIMMABLE
400 Lm
Yes
WWW.TRONIXLIGHTING.COM
73
Tubes & Lamps |
PAR Lamps
PAR20 LED LAMP | 8 WATT | 3000K
INPUT
POWER
BEAM
240V
8W
25˚
CERTIFICATE
WARRANTY
CERTIFICATE
2
years
Input: 220-240V AC, 50-60 Hz
LED type: Samsung
LED qty: 1
Beam: 25°
IP rate: IP20
Diameter: Ø 65 mm
Length: 103 mm
Connection type: E27
ART. NR.
POWER
COLOR TEMP. (CCT)
175-230
8 Watt
3000K
COLOR LED
 Warm White
LIGHT OUTPUT
DIMMABLE
510 Lm
No
PAR30 LED LAMP | 15 WATT | 2700K
INPUT
POWER
240V
15W
In dimmable or non-dimmable version
BEAM
25˚
DIMMABLE
-
CERTIFICATE
WARRANTY
CERTIFICATE
2
years
+
Input: 220-240V AC, 50-60 Hz
LED type: CREE SCOB
LED qty: 1
Beam: 25°
IP rate: IP20
Diameter: Ø 95 mm
Length: 104 mm
Connection type: E27
ART. NR.
POWER
COLOR TEMP. (CCT)
LIGHT OUTPUT
DIMMABLE
175-231
15 Watt
2700K
 Warm White
COLOR LED
840 Lm
Yes
175-232
15 Watt
2700K
 Warm White
840 Lm
No
PAR38 LED LAMP | 22 WATT | 3000K
INPUT
POWER
240V
22W
Input: 220-240V AC, 50-60 Hz
LED type: CREE COB
LED qty: 1
Beam: 25°
IP rate: IP20
Diameter: Ø 119 mm
Length: 140 mm
Connection type: E27
74
ART. NR.
POWER
COLOR TEMP. (CCT)
175-214
22 Watt
3000K
COLOR LED
 Warm White
LIGHT OUTPUT
DIMMABLE
1536 Lm
No
BEAM
25˚
CERTIFICATE
WARRANTY
2
years
CERTIFICATE
Corn Lamps
CORN LED LAMP | 20 WATT
| Tubes & Lamps
INPUT
POWER
240V
20W
In 3000K or 5000K
BEAM
CERTIFICATE
WARRANTY
CERTIFICATE
2
years
360˚
Input: 85-240V AC, 50-60 Hz
Power: 20 Watt
LED type: SMD
LED qty: 108
Dimmable: No
Beam: 360°
IP rate: IP20
Diameter: Ø 73 mm
Length: 165 mm
Connection type: E27
ART. NR.
COLOR TEMP. (CCT)
175-530
3000K
 Warm White
COLOR LED
1800 Lm
LIGHT OUTPUT
175-531
5000K
 Cold White
1900 Lm
CORN LED LAMP | 30 WATT
In 3000K or 5000K
INPUT
POWER
240V
30W
BEAM
360˚
CERTIFICATE
WARRANTY
CERTIFICATE
2
years
Input: 85-240V AC, 50-60 Hz
Power: 30 Watt
LED type: SMD
LED qty: 294
Dimmable: No
Beam: 360°
IP rate: IP20
Diameter: Ø 90 mm
Length: 165 mm
Connection type: E27
ART. NR.
COLOR TEMP. (CCT)
175-532
3000K
 Warm White
COLOR LED
2800 Lm
LIGHT OUTPUT
175-533
5000K
 Cold White
2880 Lm
Corn lamps E27 in 20W / 30W
in 3000K or 5000K
Effective outdoor lighting
WWW.TRONIXLIGHTING.COM
75
Tubes & Lamps |
GU10
GU10 LED LAMP | WHITE | 5 WATT COB | 2700K
INPUT
POWER
BEAM
240V
5W
40˚
Replacement for 30W halogen spot
Input: 220-240V AC
Power: 5 Watt
LED qty: 1 pc
LED type: Epistar COB
Dimmable: Yes (Triac)
Beam: 40°
ART. NR.
COLOR TEMP. (CCT)
175-131
2700K
COLOR LED
 Warm White+
LIGHT OUTPUT
DIMMABLE
300 Lm
Yes (Triac)
INPUT
POWER
BEAM
240V
5W
40˚
Replacement for 30W halogen spot
ART. NR.
COLOR TEMP. (CCT)
175-135
2700K
175-136
1800K~2700K
175-139
4000K
COLOR LED
 Warm White+
Flame Dimming
 Natural White
LIGHT OUTPUT
DIMMABLE
370 Lm
Yes (Triac)
Yes (Triac)
Yes (Triac)
370 Lm
400 Lm
INPUT
POWER
BEAM
240V
6W
40˚
Replacement for 35W halogen spot, featuring high quality lens
ART. NR.
COLOR TEMP. (CCT)
175-120
3000K
COLOR LED
 Warm White
LIGHT OUTPUT
DIMMABLE
415 Lm
Yes (Triac)
INPUT
POWER
BEAM
240V
9W
40˚
Replacement for 50W halogen spot, featuring high quality lens
76
CERTIFICATE
2
years
DIMMABLE
-
CERTIFICATE
WARRANTY
CERTIFICATE
2
years
+
DIMMABLE
-
CERTIFICATE
WARRANTY
CERTIFICATE
2
years
+
IP rate: IP20
Length: 80 mm
Diameter: Ø 50 mm
Connection type: GU-10
Housing: Aluminium (silver)
GU10 LED LAMP | ALUMINIUM | 9 WATT COB
Input: 220-240V AC
Power: 9 Watt
LED qty: 1 pc
LED type: Sharp COB
Beam: 40°
WARRANTY
IP rate: IP20
Length: 58 mm
Diameter: Ø 50 mm
Connection type: GU-10
Housing: Aluminium/Silver
GU10 LED LAMP | ALUMINIUM | 6 WATT COB
Input: 220-240V AC
Power: 6 Watt
LED qty: 1 pc
LED type: Sharp COB
Beam: 40°
CERTIFICATE
+
IP rate: IP20
Length: 58 mm
Diameter: Ø 50 mm
Connection type: GU-10
Housing: White Ceramic
GU10 LED LAMP | ALUMINIUM | 5 WATT COB
Input: 220-240V AC
Power: 5 Watt
LED qty: 1 pc
LED type: Epistar COB
Dimmable: Yes (Triac)
Beam: 40°
DIMMABLE
-
IP rate: IP20
Length: 92 mm
Diameter: Ø 50 mm
Connection type: GU-10
Housing: Aluminium (silver)
ART. NR.
COLOR TEMP. (CCT)
LIGHT OUTPUT
DIMMABLE
175-117
2700K
 Warm White+
COLOR LED
550 Lm
175-118
3000K
 Warm White
600 Lm
Yes (Triac)
Yes (Triac)
DIMMABLE
-
+
CERTIFICATE
WARRANTY
2
years
CERTIFICATE
| Tubes & Lamps
MR16-MR11
MR16 LED LAMP | 5 WATT COB | WHITE
Input: 12V
Power: 5 Watt
LED qty: 1 pc
LED type: COB
Beam: 40°
ART. NR. COLOR TEMP. (CCT)
175-132
2700K
COLOR LED
COLOR LED
No
175-134
3000K
 Warm White
No
400 Lm
MR16 LED LAMP | 3 WATT | ALUMINIUM
Input: 12V
Power: 3 Watt
LED qty: 1 pc
Beam: 30°
IP rate: IP20
COLOR LED
 Cold White
Input: 12V
Power: 1 Watt
LED qty: 1 pc
Beam: 38°
IP rate: IP20
INPUT
POWER
BEAM
12V
5W
40˚
CERTIFICATE
WARRANTY
CERTIFICATE
2
years
INPUT
POWER
BEAM
12V
3W
30˚
CERTIFICATE
WARRANTY
CERTIFICATE
2
years
LIGHT OUTP. DIMMABLE
90 Lm
No
INPUT
POWER
BEAM
12V
1W
38˚
INPUT
POWER
BEAM
12V
2W
35˚
CERTIFICATE
WARRANTY
CERTIFICATE
2
years
Length: 50 mm
Diameter: Ø 50 mm
Connection type: MR-16
Housing: Aluminium
COLOR LED
LIGHT OUTP. DIMMABLE
175-004
n/a
 Red
n/a
No
175-003
n/a
 Green
n/a
No
175-002
n/a
 Blue
n/a
No
175-006
n/a
 Amber
n/a
No
MR11 LED LAMP | 2 WATT | ALUMINIUM
ART. NR. COLOR TEMP. (CCT)
CERTIFICATE
2
years
Length: 50 mm
Diameter: Ø 50 mm
Connection type: MR-16
Housing: Aluminium
MR16 LED LAMP | 1 WATT | ALUMINIUM | IN 4 COLORS
Input: 12V
Power: 2 Watt
LED qty: 1 pc
Beam: 35°
IP rate: IP20
WARRANTY
LIGHT OUTP. DIMMABLE
 Warm White+ 400 Lm
ART. NR. COLOR TEMP. (CCT)
CERTIFICATE
IP rate: IP20
Length: 52 mm
Diameter: Ø 50 mm
Connection type: MR-16
Housing: Aluminium, Silver
2700K
6000K
40˚
No
175-133
ART. NR. COLOR TEMP. (CCT)
BEAM
5W
LIGHT OUTP. DIMMABLE
 Warm White+ 300 Lm
Input: 12V
Power: 5 Watt
LED qty: 1 pc
LED type: COB
Beam: 40°
175-001
POWER
IP rate: IP20
Length: 52 mm
Diameter: Ø 50 mm
Connection type: MR-16
Housing: White
MR16 LED LAMP | 5 WATT COB | ALUMINIUM
ART. NR. COLOR TEMP. (CCT)
INPUT
12V
CERTIFICATE
WARRANTY
CERTIFICATE
2
years
Length: 40 mm
Diameter: Ø 35 mm
Connection type: MR-11
Housing: Aluminium
COLOR LED
LIGHT OUTP. DIMMABLE
175-125
2800K
 Warm White
120 Lm
No
175-126
5000K
 Cold White
120 Lm
No
WWW.TRONIXLIGHTING.COM
77
Tubes & Lamps |
A60
A60 LED LAMP | 7 WATT | MILKY | DIMMABLE
Input: 220-240V AC
Power: 7 Watt
LED qty: 1 pc
Beam: 190°
IP rate: IP20
POWER
BEAM
7W
190˚
INPUT
POWER
BEAM
240V
7W
190˚
ART. NR.
COLOR TEMP. (CCT)
2700K
COLOR LED
 Warm White+
LIGHT OUTPUT
DIMMABLE
630 Lm
Yes (Triac)
A60 LED LAMP | 7 WATT | PIR
Input: 220-240V AC
Power: 7 Watt
LED qty: 1 pc
Beam: 190°
WARRANTY
CERTIFICATE
2
years
PIR
CERTIFICATE
WARRANTY
CERTIFICATE
2
years
COLOR LED
Art. nr.
175-733
E27 LED LAMP WITH DAY/NIGHT PIR
• PIR sensor lamp with day & night sensor
• Light switches on when darkness sets in, and switches off when daylight starts to come back.
ART. NR.
COLOR TEMP. (CCT)
LIGHT OUTPUT
PIR TYPE
DIMMABLE
175-732
2700K
 Warm White+
550 Lm
175-733
2700K
 Warm White+
550 Lm
Motion PIR
Day/Night PIR
No
No
A60 LED LAMP | FILAMENT | CLEAR
Input: 220-240V AC
Power: 3,5 Watt
LED type: Filament
LED qty: 1 pc
Beam: 360°
INPUT
POWER
BEAM
240V
3,5W
190˚
CERTIFICATE
WARRANTY
CERTIFICATE
2
years
IP rate: IP20
Length: 110 mm
Diameter: Ø 60 mm
Connection type: E27
Housing: Clear
ART. NR.
COLOR TEMP. (CCT)
175-760
2700K
COLOR LED
 Warm White+
LIGHT OUTPUT
DIMMABLE
180 Lm
No
A60 LED LAMP | FILAMENT | MILKY
78
CERTIFICATE
+
IP rate: IP20
Length: 102 mm
Diameter: Ø 50 mm
Connection type: E27
E27 LED Lamp with MOTION PIR - detection range 2-3M
• Light function starts to operate when the brightness in the room is less then 10 lux.
• Light automatically turns on when movement is detected within range 2-3 meters
• In case of no movement the light will stay on for 1 minute before it turns off.
Input: 220-240V AC
LED type: Filament
LED qty: 1 pc
Beam: 360°
IP rate: IP20
DIMMABLE
-
Length: 102 mm
Diameter: Ø 50 mm
Connection type: E27
Housing: Milky
175-730
Art. nr.
175-732
INPUT
240V
INPUT
POWER
POWER
BEAM
240V
3,5W
6,5W
190˚
Length: 110 mm
Diameter: Ø 60 mm
Connection type: E27
Housing: Milky
ART. NR.
POWER
COLOR TEMP. (CCT)
175-759
3,5 Watt
2700K
 Warm White+
COLOR LED
LIGHT OUTPUT
DIMMABLE
350 Lm
No
No
No
175-761
6,5 Watt
2200K
 Warm White++ 550 Lm
175-762
6,5 Watt
2700K
 Warm White+
600 Lm
CERTIFICATE
WARRANTY
2
years
CERTIFICATE
Vintage Lamps
| Tubes & Lamps
VINTAGE LED LAMP | 4 WATT | FILAMENT | A60
INPUT
POWER
240V
4W
In dimmable or non-dimmable version
Input: 220-240V AC
Power: 4 Watt
LED type: Filament
LED qty: 4 pc
Beam: 360°
ART. NR.
COLOR TEMP. (CCT)
2200K
 Warm White++ 400 Lm
175-880
2200K
 Warm White++ 400 Lm
COLOR LED
LIGHT OUTPUT
CERTIFICATE
WARRANTY
CERTIFICATE
2
years
+
DIMMABLE
Yes
No
VINTAGE LED LAMP | 4 WATT | FILAMENT | S64
INPUT
POWER
240V
4W
INPUT
POWER
240V
4W
In dimmable or non-dimmable version
BEAM
360˚
DIMMABLE
-
CERTIFICATE
WARRANTY
CERTIFICATE
2
years
+
IP rate: IP20
Length: 146 mm
Diameter: Ø 64 mm
Connection type: E27
Housing: Vintage glass
ART. NR.
COLOR TEMP. (CCT)
175-781
2200K
 Warm White++ 300 Lm
175-881
2200K
 Warm White++ 300 Lm
COLOR LED
LIGHT OUTPUT
DIMMABLE
Yes
No
VINTAGE LAMP | 4 WATT | FILAMENT | G95
In dimmable or non-dimmable version
Input: 220-240V AC
Power: 4 Watt
LED type: Filament
LED qty: 4 pc
Beam: 360°
DIMMABLE
-
IP rate: IP20
Length: 106 mm
Diameter: Ø 60 mm
Connection type: E27
Housing: Vintage glass
175-780
Input: 220-240V AC
Power: 4 Watt
LED type: Filament
LED qty: 4 pc
Beam: 360°
BEAM
360˚
BEAM
360˚
DIMMABLE
-
+
CERTIFICATE
WARRANTY
CERTIFICATE
2
years
IP rate: IP20
Length: 134 mm
Diameter: Ø 95 mm
Connection type: E27
Housing: Vintage glass
ART. NR.
COLOR TEMP. (CCT)
175-782
2200K
 Warm White++ 300 Lm
COLOR LED
LIGHT OUTPUT
175-882
2200K
 Warm White++ 300 Lm
DIMMABLE
Yes
No
WWW.TRONIXLIGHTING.COM
79
Tubes & Lamps |
Candle Lamp
CANDLE LED LAMP | 3 WATT | FILAMENT | E14
Input: 220-240V AC
Power: 3 Watt
LED type: Filament
LED qty: 4 pc
Beam: 360°
80
ART. NR.
COLOR TEMP. (CCT)
175-770
2200K
IP rate: IP20
Length: 99 mm
Diameter: Ø 35 mm
Connection type: E14
Housing: Clear
COLOR LED
LIGHT OUTPUT
 Warm White++ 300 Lm
DIMMABLE
No
INPUT
POWER
240V
3W
BEAM
360˚
CERTIFICATE
WARRANTY
2
years
CERTIFICATE
| Tubes & Lamps
P45 Lamps
P45 LED LAMP | 4 WATT | MILKY | E27
Input: 220-240V AC
Power: 4 Watt
LED type: SMD
Beam: 360°
IP rate: IP20
ART. NR.
COLOR TEMP. (CCT)
175-362
2700K
COLOR LED
 Warm White+
Input: 220-240V AC
Power: 4 Watt
LED type: SMD
Beam: 360°
IP rate: IP20
ART. NR.
COLOR TEMP. (CCT)
2700K
POWER
4W
INPUT
POWER
240V
4W
BEAM
360˚
WARRANTY
CERTIFICATE
CERTIFICATE
CERTIFICATE
CERTIFICATE
2
years
Length: 75 mm
Diameter: Ø 45 mm
Connection type: E27
Housing: Milky
LIGHT OUTPUT
DIMMABLE
250 Lm
No
P45 LED LAMP | 4 WATT | MILKY | E14
175-704
INPUT
240V
BEAM
360˚
WARRANTY
2
years
Length: 82 mm
Diameter: Ø 45 mm
Connection type: E14
Housing: Milky
COLOR LED
 Warm White+
LIGHT OUTPUT
DIMMABLE
250 Lm
No
TRONIX UNIVERSAL LED DIMMER
Compatible with well-known brands like Gira, Berker & Jung
LED Universal LED Dimmer
Trailing Edge Dimmer | 10W ~350W
Input: 220-240v 50Hz
Dimming method: Trailing edge
Compatible white plate: Available (art. 215-132)
ART. NR.
MIN.-MAX. LOAD
MOUNTING DEPTH
215-131
10W ~ 350W
24 mm
ART. NR. ACCESSORIES
215-132
Compatible white plate
595-021
P-Cable Black | 2*0.75mm | 2M with stripped wire
595-026
P-Cable Black | 2*0,75mm | 2M with Euro plug + GU10 socket
595-027
GU10 socket with stripped wire
595-029
MR16 socket with stripped
Art. nr. 215-131
WWW.TRONIXLIGHTING.COM
81
Tubes & Lamps |
Colored Lamps
G45 LED LAMP DECO | HIGH POWER
Input: 220-240V AC
Power: 1,7 Watt
Power factor: >0,8
LED type: SMD
LED qty: 30 pc
Dimmable: No
POWER
BEAM
WARRANTY
1,7W
190˚
2
years
INPUT
POWER
POWER
BEAM
WARRANTY
240V
1W
2W
190˚
1
year
INPUT
POWER
BEAM
WARRANTY
240V
2W
190˚
1
year
ART. NR.
COLOR TEMP. (CCT)
3000K
COLOR LED
 Warm White
LIGHT OUTPUT
DIMMABLE
155 Lm
No
G45 LED LAMP DECO
Input: 220-240V AC
LED type: DIP
Dimmable: No
Beam: 190°
Length: 69 mm
LED QTY
COLOR TEMP. (CCT)
COLOR LED
CERTIFICATE
CERTIFICATE
CERTIFICATE
CERTIFICATE
LIGHT OUTPUT
165-000
1 Watt
6 pc
2700K
 Warm White+
51 Lm
165-009
2 Watt
10 pc
2700K
 Warm White+
85 Lm
G45 LED BULB DECO | FILAMENT
Input: 220-240V AC
Power: 2 Watt
Dimmable: No
LED type: Filament
LED qty: 2
82
CERTIFICATE
Diameter: Ø 45 mm
Connection type: E27
Housing: Clear
POWER
ART. NR.
CERTIFICATE
Beam: 190°
Length: 69 mm
Diameter: Ø 45 mm
Connection type: E27
Housing: Clear
165-010
ART. NR.
INPUT
240V
COLOR LED
165-788
 White
165-783
 Blue
165-784
 Green
165-785
 Red
165-786
 Yellow
165-787
 Warm White
165-790
 Set of 10 lamps 5 colors excl. Warm
White
Beam: 190°
Length: 69 mm
Diameter: Ø 45 mm
Connection type: E27
Housing: Clear/colored
White
Blue
Green
Red
Yellow
Warm white
Colored Lamps
G45 LED BULB DECO | B22
Input: 220-240V AC
Power: 1 Watt
Dimmable: No
LED type: Filament (clear) / SMD
LED qty: 2
ART. NR.
COLOR LED
HOUSING
LED TYPE
 Warm White
Clear
Filament
165-021
 White
Milky
SMD
165-022
 Blue
Colored
SMD
165-023
 Green
Colored
SMD
165-024
 Red
Colored
SMD
165-025
 Yellow
Colored
SMD
165-028
 Warm White
Milky
SMD
P50 LED LAMP DECO | HEAVY DUTY
ART. NR.
POWER
BEAM
WARRANTY
1W
190˚
1
year
INPUT
POWER
BEAM
WARRANTY
240V
1W
190˚
1
year
CERTIFICATE
CERTIFICATE
CERTIFICATE
CERTIFICATE
CERTIFICATE
CERTIFICATE
Beam: 190°
Length: 83 mm
Diameter: Ø 50 mm
Connection type: E27
Housing: Clear/colored
COLOR LED
165-014
 Red
165-015
 Yellow
165-013
 Green
165-011
 White
165-018
 Warm White
165-012
 Blue
P45 LIGHT BULBS | INCANDESCENT | 10 PACK
Input: 220-240V AC
Power: 15 Watt
Dimmable: No
Beam: 190°
Length: 71 mm
ART. NR.
INPUT
240V
Beam: 190°
Length: 72 mm
Diameter: Ø 45 mm
Connection type: B22
Housing: Clear/colored
165-020
Input: 220-240V AC
Power: 1 Watt
Dimmable: No
LED type: SMD
LED qty: 10
| Tubes & Lamps
INPUT
POWER
BEAM
WARRANTY
240V
15W
190˚
1
year
Diameter: Ø 45 mm
Connection type: E27
Content: 10 pcs.
Housing: Clear/colored
HOUSING COLOR
165-074
 Red
165-075
 Yellow
165-073
 Green
165-071
 Clear
165-072
 Blue
WWW.TRONIXLIGHTING.COM
83
Tubes & Lamps |
G4-G9 Lamps
G4 LED LAMP | 12V | SIDE PIN | 3 X SMD LED
Input: 12V
Power: 0,5 Watt
LED type: SMD
Beam: 120°
INPUT
POWER
12V
0.5W
WARRANTY
CERTIFICATE
CERTIFICATE
CERTIFICATE
CERTIFICATE
CERTIFICATE
CERTIFICATE
CERTIFICATE
CERTIFICATE
2
years
IP rate: IP20
Length: 29 mm
Width: 11 mm
Connection type: G4
ART. NR.
LED QTY
COLOR TEMP. (CCT)
175-500
3 pcs
2700K
COLOR LED
 Warm White+
LIGHT OUTPUT
DIMMABLE
50 Lm
No
G4 LED LAMP | 12V | SIDE PIN | 6 X SMD LED
Input: 12V
Power: 1,1 Watt
LED type: SMD
Beam: 120°
INPUT
POWER
12V
1.1W
BEAM
120˚
WARRANTY
2
years
IP rate: IP20
Length: 32 mm
Diameter: Ø 23 mm
Connection type: G4
ART. NR.
LED QTY
COLOR TEMP. (CCT)
175-501
6 pcs
2700K
COLOR LED
 Warm White+
LIGHT OUTPUT
DIMMABLE
90 Lm
No
G4 LED LAMP | 12V | SIDE PIN | 12 X SMD LED
Input: 12V
Power: 2 Watt
LED type: SMD
Beam: 120°
INPUT
POWER
12V
2W
BEAM
120˚
IP rate: IP20
Length: 40 mm
Diameter: Ø 31 mm
Connection type: G4
ART. NR.
LED QTY
COLOR TEMP. (CCT)
175-502
12 pcs
2700K
COLOR LED
 Warm White+
LIGHT OUTPUT
DIMMABLE
160 Lm
No
G4 LED LAMP | 12V | DOWN PIN | 21 X SMD LED
Input: 12V
Power: 1,3 Watt
LED type: SMD
Beam: 120°
84
BEAM
120˚
IP rate: IP20
Length: 31 mm
Diameter: Ø 15 mm
Connection type: G4
ART. NR.
LED QTY
COLOR TEMP. (CCT)
175-503
21 pcs
2700K
COLOR LED
 Warm White+
LIGHT OUTPUT
DIMMABLE
110 Lm
No
INPUT
POWER
12V
1.3W
BEAM
120˚
WARRANTY
2
years
G4-G9 Lamps
| Tubes & Lamps
G4 LED LAMP | 12V | DOWN PIN | HP LED
Input: 12V
Power: 1 Watt
LED type: HP LED
Beam: 120°
INPUT
POWER
12V
1W
BEAM
WARRANTY
120˚
2
years
BEAM
WARRANTY
CERTIFICATE
CERTIFICATE
CERTIFICATE
CERTIFICATE
CERTIFICATE
CERTIFICATE
CERTIFICATE
CERTIFICATE
IP rate: IP20
Length: 20 mm
Diameter: Ø 10 mm
Connection type: G4
ART. NR.
LED QTY
COLOR TEMP. (CCT)
175-508
1 pc
3000K
COLOR LED
 Warm White+
LIGHT OUTPUT
DIMMABLE
50 Lm
No
G9 LED LAMP | 240V | 45 X SMD LED
Input: 220-240V AC
Power: 2,6 Watt
LED type: SMD
Beam: 120°
INPUT
POWER
240V
2.6W
INPUT
POWER
240V
3W
120˚
2
years
IP rate: IP20
Length: 58 mm
Diameter: Ø 22 mm
Connection type: G9
ART. NR.
LED QTY
COLOR TEMP. (CCT)
175-504
45 pcs
2700K
COLOR LED
 Warm White+
LIGHT OUTPUT
DIMMABLE
220 Lm
No
G9 LED LAMP | 240V | 60 X SMD LED
Input: 220-240V AC
Power: 3 Watt
LED type: SMD
Beam: 120°
BEAM
WARRANTY
120˚
2
years
IP rate: IP20
Length: 58 mm
Diameter: Ø 22 mm
Connection type: G9
ART. NR.
LED QTY
COLOR TEMP. (CCT)
175-505
60 pcs
2700K
COLOR LED
 Warm White+
LIGHT OUTPUT
DIMMABLE
260 Lm
No
G9 LED LAMP | 240V | 39 X SMD LED
Input: 220-240V AC
Power: 3 Watt
Power factor: >0,93
LED type: SMD
Beam: 120°
INPUT
POWER
240V
3W
BEAM
120˚
DIMMABLE
-
+
WARRANTY
2
years
IP rate: IP20
Length: 50 mm
Diameter: Ø 16 mm
Connection type: G9
ART. NR.
LED QTY
COLOR TEMP. (CCT)
LIGHT OUTPUT
DIMMABLE
175-510
39 pcs
2700K
 Warm White+
COLOR LED
280 Lm
Yes
175-511
39 pcs
4000K
 Natural White
280 Lm
Yes
WWW.TRONIXLIGHTING.COM
85
Plates
For elegant lighting results in any ceiling
86
Plates
RECESSED MOUNTING FIXTURE | AR111 | FULLY ADJUSTABLE
WARRANTY
CERTIFICATE
3
years
Delivered with fixed frame and trimless frame. To be used with AR111 lamp (not included)
Size: 192 x 192 mm
Housing: Black or White
Material: Iron, powder coated
Use in combination with: AR111 lamp
MOUNTING HOLE
MOUNTING DEPTH - Recessed
MOUNTING DEPTH - Trimless
148-043
ART. NR.
 Black
COLOR
152 x 152 mm
97 mm
100 mm
148-044
 White
152 x 152 mm
97 mm
100 mm
AR111 Lamp | Flame Dimmable
Art. nr. 175-316
ART. NR.
AR111 LAMP
175-316
AR111 Lamp | 12W | 2000K~2900K Flame Dimming | 36°
175-313
AR111 Lamp | 12W | 2700K | 24° | Non-Dimmable
175-314
AR111 Lamp | 15W | 2700K | 24° | Dimmable
FLAME DIMMING
2000K
2900K
RECESSED MOUNTING FIXTURE | AR70 | FULLY ADJUSTABLE
WARRANTY
CERTIFICATE
3
years
Delivered with fixed frame and trimless frame.
To be used with AR70 lamp (not included)
Size: 137 x 137 mm
Housing: Black or White
Material: Iron, powder coated
Use in combination with: AR70 lamp (with GU10 socket)
MOUNTING HOLE
MOUNTING DEPTH - Recessed
MOUNTING DEPTH - Trimless
148-050
ART. NR.
 Black
COLOR
108 x 108 mm
97,6 mm
100 mm
148-051
 White
108 x 108 mm
97,6 mm
100 mm
AR70 Lamp | Standard or
Flame dimmable
ART. NR.
AR70 LAMP
175-343
AR70 Lamp | 6W | 2700K | 24° | Dimmable | GU10
175-344
AR70 Lamp | 6W | 2000K~2700K Flame Dimmable | 24° | GU10
FLAME DIMMING
2000K
2700K
TRIMLESS RECESSED MOUNTING FIXTURES
Multifunctional fixtures with choice between fixed of trimless frame. Excl. AR111/AR70 lamp.
The new Tronix Trimless AR111/AR70 recessed mounting armatures are equipped with two different frames for
customized results: a visible ‘fixed’ frame (standard) and a separate ‘trimless’ frame that can be integrated in the
ceiling for elegant trimless results.
Black 
White 
Fixed frame
Trimless frame
AR111 | AR70 lamp
WWW.TRONIXLIGHTING.COM
87
Plates
High End Range Plates
Include fully adjustable versions
• Include fully adjustable plates that can be moved in
any possible direction
• High quality brushed and anodized aluminium (inner
and outer ring)
Economical Range Plates
Include partly adjustable versions
• Include partly adjustable plates that can only be moved
to one side.
• Brushed aluminum outer ring
• Also available in white
HIGH END RANGE High Class Brushed Aluminium (HCB)
Non Adjustable 80 mm models
ART.NR.
148-000
ART.NR.
148-001
MODEL
1 hole plate round
HCB Aluminium
MODEL
1 hole plate square
HCB Aluminium
DIMENSIONS
Ø 80 mm
DIMENSIONS
80 x 80 mm
MOUNTING
Ø 68 mm
MOUNTING
Ø 68 mm
ART.NR.
148-002
ART.NR.
148-003
MODEL
2 hole plate square
HCB Aluminium
MODEL
3 hole plate square
HCB Aluminium
DIMENSIONS
150 x 80 mm
DIMENSIONS
221 x 80 mm
MOUNTING
140 x 72 mm
MOUNTING
208 x 72 mm
ART.NR.
148-004
ART.NR.
148-005
MODEL
4 hole plate square
HCB Aluminium
MODEL
2x2 hole plate square
HCB Aluminum
DIMENSIONS
293 x 80 mm
DIMENSIONS
152 x 152 mm
MOUNTING
276 x 72 mm
MOUNTING
140 x 140 mm
Fully Adjustable 360° 90 mm models
88
ART.NR.
148-020
ART.NR.
148-021
MODEL
1 hole plate round
HCB Aluminium
MODEL
1 hole plate square
HCB Aluminium
DIMENSIONS
Ø 90 mm
DIMENSIONS
90 x 90 mm
MOUNTING
Ø 82 mm
MOUNTING
Ø 82 mm
ART.NR.
148-022
ART.NR.
148-023
MODEL
2 hole plate square
HCB Aluminium
MODEL
3 hole plate round
HCB Aluminium
DIMENSIONS
172 x 90 mm
DIMENSIONS
255 x 90 mm
MOUNTING
165 x 82 mm
MOUNTING
245 x 82 mm
ART.NR.
148-024
ART.NR.
148-025
MODEL
4 hole plate square
HCB Aluminium
MODEL
2x2 hole plate square
HCB Aluminum
DIMENSIONS
346 x 90 mm
DIMENSIONS
172 x 172 mm
MOUNTING
330 x 82 mm
MOUNTING
165 x 165 mm
Plates
ECONOMICAL RANGE Brushed Aluminium
Non Adjustable
ART.NR.
MODEL
DIMENSIONS
MOUNTING
148-551
1 hole plate round
Aluminium - ECO
Ø 79 mm
Ø 65 mm
148-552
1 hole plate square
Aluminium - ECO
79 x 79 mm
Ø 65 mm
148-555
1 hole plate round
Wit - ECO
Ø 79 mm
Ø 65 mm
148-556
1 hole plate square
Wit - ECO
79 x 79 mm
Ø 65 mm
148-550
1 hole plate round
Aluminium - ECO IP65
Ø 84 mm
Ø 60 mm
148-558
1 hole plate round
Wit - ECO IP65
Ø 84 mm
Ø 60 mm
148-561
1 hole plate round
Aluminium, Flush-mounted
Ø 71 mm
Ø 65 mm
148-562
1 hole plate round
White, Flush-mounted
Ø 71 mm
Ø 65 mm
Art. nr.
Art. nr.
148-551
148-552
Art. nr.
Art. nr.
148-555
148-556
Art. nr.
Art. nr.
148-550
148-558
Art. nr.
Art. nr.
148-561
148-562
Partly Adjustable
ART.NR.
MODEL
DIMENSIONS
MOUNTING
148-553
1 hole plate round
Aluminium - ECO
Ø 92 mm
Ø 80 mm
148-557
1 hole plate round
White - ECO
Ø 92 mm
Ø 80 mm
148-563
1 hole plate round
Black - ECO
Ø 92 mm
Ø 80 mm
148-559
1 hole plate square
Aluminium - ECO
92 x 92 mm
Ø 80 mm
148-560
1 hole plate square
White - ECO
92 x 92 mm
Ø 80 mm
148-507
1 hole plate round
Aluminium - ECO
Budget Price model
Ø 80 mm
Ø 74 mm
1 hole plate round
Aluminium
Flush-mounted
Fully adjustable
Ø 90 mm
1 hole plate round
Aluminium
Flush-mounted
Fully adjustable
Ø 90 mm
Ø 76 mm
ART.NR.
MODEL
DIMENSIONS
MOUNTING
148-030
1 hole plate round
AR111 - Aluminium
Ø 180 mm
Ø 150 mm
148-033
1 hole plate round
AR111 - White
Ø 180 mm
Ø 150 mm
148-031
1 hole plate square
AR111 - Aluminium
180 x 180 mm
Ø 150 mm
148-034
1 hole plate square
AR111 - White
180 x 180 mm
Ø 150 mm
148-032
2 hole plate square
AR111 - Aluminium
355 x 180 mm
325 x 150 mm
148-564
148-565
Art. nr.
Art. nr.
148-553
148-557
Art. nr.
Art. nr.
148-563
148-559
Art. nr.
Art. nr.
148-560
148-507
Ø 70 mm
Art. nr.
Art. nr.
148-564
148-565
AR111-Plates
148-035
2 hole plate square
AR111 - White
355 x 180 mm
325 x 150 mm
Art. nr.
Art. nr.
148-030
148-033
Art. nr.
Art. nr.
148-031
148-034
Art. nr.
Art. nr.
148-032
148-035
WWW.TRONIXLIGHTING.COM
89
Plates
90
Plates
WWW.TRONIXLIGHTING.COM
91
Flood Light
Powerfull illumination of areas, building facades or objects
92
Flood Light
Tronix LED Flood Lights:
Powerfull illumination of large areas
The Tronix range of LED Flood Lights is very diverse and answers to practically every demand when it comes to lighting
large outdoor spaces or objects: from lighting a car park up to highlighting a tree, billboard or historic building. Tronix offers
two IP65 rated model lines: the Floodlight Professional with CREE LED’s in gray or black aluminum, and the Floodlight Basic
models featuring COB and SMD LED’s. With a large choice in power, color and beam, the best result is always achieved.
FLOOD LIGHT PROFESSIONAL
For a focussed beam without stray-light effect
• With high quality CREE LED’S
• In low power models 6W – 18W
(grey aluminum) and high power models
25W – 120W (black aluminum)
• In various (white) colors and RGB
• High CRI
• Gray aluminum housing
• With symmetrical beam 45 ° for blasting
• With asymmetric beam 15 ° x45 ° (Flood 6)
for sideways falling “floodlight’
• With 2m rubber cable
• Different beams optionally available
• Black anodized aluminum housing
• Square tempered glass
(impact resistant)
• Symmetrical beam 33 ° (45° RGB)
• White 2m rubber cable
• Efficient heat dissipation by
optimizing airflow along heatsink
• Lamp 90° fixable in both directions
• Other beams optionally available
CREE LED
Double isolated
50W Construction
Flood Light Class 2
(NEN 1010)
FLOOD LIGHT BASIC
With a wide beam for general lighting purposes
• Equipped white COB/SMD LED’s
• High Lumen /
• In Warm White and Natural White
Watt ratio
10W - 20W - 50W - 100W
• Asymmetric beam
• With PIR sensor in
140° x 120°
Warm White 20W - 70W
• IP65
• In RGB 20W - 60W
With 1,5m
rubber cable
COB LED
With 5m
rubber cable
WWW.TRONIXLIGHTING.COM
93
Flood Light |
PRO
FLOODLIGHT PRO | 2 LED | 6 WATT
INPUT
INPUT
POWER
LED QTE
240V
24V
6W
2
BEAM
IP RATE
45˚
IP65
CERTIFICATE
WARRANTY
CERTIFICATE
2
years
With symmetrical beam 45°
Power: 6 Watt
LED qty: 2 pcs
LED type: CREE XR-E
Dimmable: No
CRI: >80
IP rate: IP65
Height: 127 mm
Width: 120,4 mm
Depth: 77 mm
Wire length: 2 meter
Housing: Aluminium
ART. NR.
INPUT
BEAM
COLOR TEMP. (CCT)
146-038
240 Volt
45°
3000K
 Warm White 214 Lm
COLOR LED LIGHT OUTPUT DIMMABLE CONNECTION
No
Schuko
146-058
24 Volt
45°
3000K
 Warm White 214 Lm
No
Stripped wire
ART. NR.
ACCESSOIRE
146-000
Floodlight Spike 35 cm for Flood Light model PRO 2/4/6
FLOODLIGHT PRO | 4 LED | 12 WATT
INPUT
INPUT
POWER
LED QTE
240V
24V
12W
4
BEAM
IP RATE
45˚
IP65
With symmetrical beam 45°
Power: 12 Watt
LED qty: 4 pcs
LED type: CREE XR-E
CRI: >80
IP rate: IP65
Height: 127 mm
Width: 142,4 mm
Depth: 77 mm
Wire length: 2 meter
Housing: Aluminium
94
ART. NR.
INPUT
BEAM
COLOR TEMP. (CCT)
146-071
240 Volt
45°
6500K
 Cold White
COLOR LED LIGHT OUTPUT DIMMABLE CONNECTION
560 Lm
No
Schuko
146-048
240 Volt
45°
3000K
 Warm White 429 Lm
No
Schuko
146-023
240 Volt
45°
n/a
 Green
No
Schuko
146-068
24 Volt
45°
3000K
 Warm White 429 Lm
No
Stripped wire
ART. NR.
ACCESSOIRE
146-000
Floodlight Spike 35 cm for Flood Light model PRO 2/4/6
n/a
CERTIFICATE
WARRANTY
2
years
CERTIFICATE
PRO
FLOODLIGHT PRO | 6 LED | 18 WATT
INPUT
INPUT
POWER
LED QTE
240V
24V
18W
6
BEAM
45˚
| Flood Light
BEAM
IP RATE
15˚x 45˚
IP65
With symmetrical beam 45° or asymmetrical beam 15° x 45°
CERTIFICATE
WARRANTY
CERTIFICATE
2
years
Power: 18 Watt
LED qty: 6 pcs
LED type: CREE XR-E
CRI: >80
IP rate: IP65
Height: 127 mm
Width: 161 mm
Depth: 77 mm
Wire length: 2 meter
Housing: Aluminium
Finish: Standard (non-painted)
ART. NR.
INPUT
BEAM
COLOR TEMP. (CCT)
146-021
240 Volt
45°
6500K
 Cold White
COLOR LED LIGHT OUTPUT DIMMABLE CONNECTION
840 Lm
No
Schuko
146-028
240 Volt
45°
3000K
 Warm White 643 Lm
No
Schuko
146-026
240 Volt
45°
n/a
 Amber
n/a
No
Schuko
146-011
240 Volt
15° x 45°
6500K
 Cold White
840 Lm
No
Schuko
146-018
240 Volt
15° x 45°
3000K
 Warm White 643 Lm
No
Schuko
146-012
240 Volt
15° x 45°
n/a
 Blue
No
Schuko
146-078
24 Volt
45°
3000K
 Warm White 643 Lm
No
Stripped wire
146-100
24 Volt
45°
n/a
Yes
Stripped wire
RGB
ART. NR.
ACCESSOIRE
146-000
Floodlight Spike 35 cm for Flood Light model PRO 2/4/6
n/a
n/a
WWW.TRONIXLIGHTING.COM
95
Flood Light |
PRO
FLOODLIGHT PRO | 12 LED | 25 WATT
INPUT
POWER
LED QTE
240V
25W
12
With symmetrical beam 33° or 45° in RGB
BEAM
BEAM
IP RATE
33˚
45˚
IP65
CERTIFICATE
WARRANTY
CERTIFICATE
2
years
Power: 25 Watt
LED qty: 12 pcs
LED type: CREE XP-E
CRI: >80
IP rate: IP65
Height: 286 mm
Width: 215 mm
Depth: 63 mm
Wire length: 2 meter
Housing: Aluminium
Finish: Black (powder paint)
ART. NR.
INPUT
BEAM
COLOR TEMP. (CCT)
146-009
240V
33°
4200K
 Natural White 1770 Lm
No
Schuko
146-088
240V
33°
3000K
 Warm White 1397 Lm
No
Schuko
146-101
240V + 24V RGB
45°
n/a
Yes
Schuko + RGB Plug
ART. NR.
ACCESSORY
146-200
RGB Signal Cable 5m for model PRO 12/27/48
COLOR LED LIGHT OUTPUT DIMMABLE CONNECTION
RGB
FLOODLIGHT PRO | 27 LED | 48 WATT
n/a
INPUT
POWER
LED QTE
240V
48W
27
With symmetrical beam 33° or 45° in RGB
BEAM
BEAM
IP RATE
33˚
45˚
IP65
Power: 48 Watt
LED qty: 27 pcs
LED type: CREE XP-E
CRI: >80
IP rate: IP65
Height: 344 mm
Width: 220 mm
Depth: 70 mm
Wire length: 2 meter
Housing: Aluminium
Finish: Black (powder paint)
96
ART. NR.
INPUT
BEAM
COLOR TEMP. (CCT)
146-041
240V
33°
6500K
 Cold White
3797 Lm
No
Schuko
146-019
240V
33°
4200K
 Natural White 3770 Lm
No
Schuko
146-098
240V
33°
3000K
 Warm White 2764 Lm
No
Schuko
146-102
240V + 24V RGB 45°
Yes
Schuko + RGB Plug
n/a
ART. NR.
ACCESSORY
146-200
RGB Signal Cable 5m for model PRO 12/27/48
COLOR LED LIGHT OUTPUT DIMMABLE CONNECTION
RGB
n/a
CERTIFICATE
WARRANTY
2
years
CERTIFICATE
| Flood Light
PRO
FLOODLIGHT PRO | 48 LED | 83 WATT
INPUT
POWER
LED QTE
240V
83W
48
With symmetrical beam 33° or 45° in RGB
BEAM
BEAM
33˚
45˚
RGB
IP RATE
CERTIFICATE
WARRANTY
CERTIFICATE
2
years
IP65
Power: 83 Watt
LED qty: 48 pcs
LED type: CREE XP-E
CRI: >80
IP rate: IP65
Height: 450 mm
Width: 300 mm
Depth: 80 mm
Wire length: 2 meter
Housing: Aluminium
Finish: Black (powder paint)
ART. NR. INPUT
BEAM
COLOR TEMP. (CCT)
146-029
240V
33°
4200K
 Natural White 6174 Lm
COLOR LED LIGHT OUTPUT DIMMABLE CONNECTION
No
Schuko
146-108
240V
33°
3000K
 Warm White 4813 Lm
No
Schuko
146-102
240V + 24V RGB 45°
Yes
Schuko + RGB Plug
n/a
ART. NR.
ACCESSORY
146-200
RGB Signal Cable 5m for model PRO 12/27/48
RGB
n/a
FLOODLIGHT PRO | 75 LED | 120 WATT
INPUT
POWER
LED QTE
240V
120W
75
With symmetrical beam 33°
Power: 120 Watt
LED qty: 75 pcs
LED type: CREE XP-E
CRI: >80
IP rate: IP65
Height: 550 mm
Width: 360 mm
Depth: 80 mm
Wire length: 2 meter
Housing: Aluminium
Finish: Black (powder paint)
ART. NR.
INPUT
BEAM
BEAM
IP RATE
33˚
IP65
CERTIFICATE
WARRANTY
CERTIFICATE
2
years
360
COLOR TEMP. (CCT)
COLOR LED LIGHT OUTPUT DIMMABLE CONNECTION
146-039
240V
33°
4200K
 Natural White 9946 Lm
No
Schuko
146-118
240V
33°
3000K
 Warm White 7778 Lm
No
Schuko
WWW.TRONIXLIGHTING.COM
97
Flood Light |
98
Basic
Basic
FLOODLIGHT BASIC SLIM | 10 ~50 WATT
POWER
POWER
POWER
BEAM
IP RATE
10W
20W
50W
140˚x120˚
IP65
| Flood Light
CERTIFICATE
CERTIFICATE
WARRANTY
CERTIFICATE
2
years
With a-symmetrical beam 140° x 120°
Input: 100-240 Volt
Dimmable: No
Beam: 120°
CRI: >80
IP rate: IP65
Connection type: Schuko
Wire length: 1,40 m
Housing: Aluminium
Finish: Black (powder paint)
ART. NR.
POWER
COLOR TEMP. (CCT)
LED TYPE
LIGHT OUTPUT
146-250
10 Watt
3000K
 Warm White
COLOR LED
SMD5730 -Epistar
800 Lm
146-251
20 Watt
3000K
 Warm White
SMD5730 -Epistar
1700 Lm
146-258
20 Watt
4000K
 Natural White
SMD5730 -Epistar
1700 Lm
146-255
50 Watt
3000K
 Warm White
SMD5730 -Epistar
4250 Lm
146-257
50 Watt
4000K
 Natural White
SMD5730 -Epistar
4250 Lm
146-157
50 Watt
2300K
 Extra Warm White
COB - Epistar
4000 Lm
146-266
50 Watt
n/a
 Green
COB - Epistar
n/a
SIZE A
SIZE B
SIZE C
SIZE D
112,2 mm
132,2 mm
188,2 mm
44,8 mm
149,9 mm
181,9 mm
233,7 mm
52,3 mm
235,5 mm
285,5 mm
361,5 mm
69,5 mm
235,5 mm
285,5 mm
361,5 mm
69,5 mm
235,5 mm
285,5 mm
361,5 mm
69,5 mm
FLOODLIGHT BASIC | 20~60 WATT | RGB
POWER
POWER
BEAM
IP RATE
20W
60W
140˚x120˚
IP65
RGB floodlight with asymmetrical beam 140° x 120°
RGB
CERTIFICATE
CERTIFICATE
WARRANTY
CERTIFICATE
2
years
Input: 100-240 Volt
LED qty: 1
LED type: COB - Epistar
Dimmable: Yes
Beam: 140° x 120°
CRI: >80
IP rate: IP65
Connection type: Schuko
Wire length: 1,4 m
Housing: Aluminium
Finish: Black (powder paint)
Remote Conrol: Included
ART. NR.
POWER
COLOR LED
SIZE A
SIZE B
SIZE C
146-159
20 Watt
RGB
180 mm
140 mm
109 mm
146-158
60 Watt
RGB
288 mm
150 mm
238 mm
WWW.TRONIXLIGHTING.COM
99
Flood Light |
Basic
FLOODLIGHT BASIC SLIM | 100 WATT
POWER
BEAM
IP RATE
100W
140˚x120˚
IP65
CERTIFICATE
CERTIFICATE
WARRANTY
CERTIFICATE
2
years
With asymmetrical beam 140° x 120°
Input: 100-240 Volt
Power: 100 Watt
LED type: SMD 5730 Epistar
Dimmable: No
Beam: 140° x 120°
CRI: >80
IP rate: IP65
Connection type: Schuko
Wire length: 1,4 m
Housing: Aluminium
Finish: Black (powder paint)
ART. NR.
POWER COLOR TEMP. (CCT)
146-256
100 Watt 3000K
COLOR LED LIGHT OUTPUT
 Warm White
8.000 Lm
FLOODLIGHT BASIC SLIM | 150 WATT
With asymmetrical beam 140° x 120°
Input: 100-240 Volt
Power: 150 Watt
LED qty: 3
LED type: COB - Epistar
Dimmable: No
Beam: 140° x 120°
CRI: >80
IP rate: IP65
Connection type: Schuko
Wire length: 1,4 m
Housing: Aluminium
Finish: Black (powder paint)
100
ART. NR.
POWER COLOR TEMP. (CCT)
146-263
150 Watt 3000K
COLOR LED LIGHT OUTPUT
 Warm White
12.000 Lm
POWER
BEAM
IP RATE
150W
140˚x120˚
IP65
CERTIFICATE
CERTIFICATE
WARRANTY
2
years
CERTIFICATE
Basic
FLOODLIGHT BASIC SLIM | 20 WATT | PIR
POWER
BEAM
20W
140˚x120˚
PIR
IP RATE
| Flood Light
CERTIFICATE
CERTIFICATE
WARRANTY
CERTIFICATE
2
years
IP65
With built-in motion PIR sensor and asymmetrical beam 140° x 120°
Input: 100-240 Volt
Power: 20 Watt
LED qty: 1
LED type: COB - Epistar
Dimmable: No
Beam: 140° x 120°
CRI: >80
IP rate: IP65
Connection type: Schuko
Wire length: 1,4 m
Housing: Aluminium
Finish: Black (powder paint)
ART. NR.
POWER COLOR TEMP. (CCT)
146-253
20 Watt
3000K
COLOR LED LIGHT OUTPUT
 Warm White
1575 Lm
FLOODLIGHT BASIC | 50 WATT | PIR
With mounted motion PIR sensor and asymmetrical beam 140° x 120°
POWER
BEAM
50W
140˚x120˚
PIR
IP RATE
IP54
CERTIFICATE
CERTIFICATE
WARRANTY
CERTIFICATE
2
years
Input: 100-240 Volt
Power: 50 Watt
LED qty: 1
LED type: SMD5730 - Epistar
Dimmable: No
Beam: 140° x 120°
CRI: >80
IP rate: IP54
Connection type: Schuko
Wire length: 1,4 m
Housing: Aluminium
Finish: Black (powder paint)
ART. NR.
POWER COLOR TEMP. (CCT)
146-162
50 Watt
3000K
COLOR LED LIGHT OUTPUT
 Warm White
4250 Lm
WWW.TRONIXLIGHTING.COM
101
Flood Light |
Basic
FLOODLIGHT BASIC | 50 WATT | CLASS 2 | NEN1010
POWER
BEAM
IP RATE
50W
140˚x120˚
IP65
CERTIFICATE
CERTIFICATE
WARRANTY
CERTIFICATE
2
years
With asymmetric beam 140° x 120° and 5 meter rubber cable
Input: 100-240 Volt
Power: 50 Watt
LED qty: 1
LED type: COB - Epistar
Dimmable: No
Beam: 140° x 120°
CRI: >80
IP rate: IP65
Connection type: Schuko ungrounded
Wire length: 5 m
Housing: Aluminium
Finish: Black (powder paint)
ART. NR.
POWER COLOR TEMP. (CCT)
146-161
50 Watt
3100K
COLOR LED
 Warm White
LIGHT OUTPUT
4000 Lm
POWER
BEAM
120˚
20W
FLOODLIGHT BASIC | 20 WATT | TABLET
IP RATE
CERTIFICATE
CERTIFICATE
WARRANTY
CERTIFICATE
2
years
IP65
Tablet model with symmetric beam 120°
Input: 240 Volt
Power: 20 Watt
LED qty: 1
LED type: COB - Epistar
Dimmable: No
Beam: 120°
CRI: >80
IP rate: IP65
Connection type: Schuko
Wire length: 1,4 m
Housing: Aluminium
Finish: White (powder paint)
ART. NR.
POWER COLOR TEMP. (CCT)
146-265
20 Watt
3000K
COLOR LED
 Warm White
LIGHT OUTPUT
HEIGHT
WIDTH
DEPTH
150 Lm
140 mm
130 mm
30 mm
FLOODLIGHT BASIC | 20 WATT | BATTERY
POWER
BEAM
IP RATE
20W
140˚x120˚
IP54
CERTIFICATE
Including 220V and 12V (car) charging cable
Input: 12/220 Volt
Power: 20 Watt
Power output: Max. 12 Watt
Battery: 7,4 Volt - 6600 mA
LED qty: 1
LED type: COB
Dimmable: No
Beam: 140° x 120°
CRI: >80
IP rate: IP54
Connection type: Schuko
Wire length: 1,4 m
Housing: Aluminium
Operating time: 5 hours
Charging time: 5 hours
Finish: Yellow (powder paint)
102
ART. NR.
POWER COLOR TEMP. (CCT)
146-160
20 Watt
3000K
COLOR LED
 Warm White
LIGHT OUTPUT
HEIGHT
WIDTH
DEPTH
1300 Lm
268 mm
215 mm
185 mm
CERTIFICATE
WARRANTY
2
years
CERTIFICATE
Basic
| Flood Light
FLOODLIGHT BASIC | WALL BRACKET
Housing: Aluminium
Finish: Black (powder paint)
ART. NR.
MODEL
LENGTH
146-176
For Floodlight Basic 10W - 20W - 50W - 60W
50 cm
146-177
For Floodlight Basic 10W - 20W - 50W - 60W
80 cm
146-178
For Floodlight Basic 100W - 150W
50 cm
146-179
For Floodlight Basic 100W - 150W
80 cm
FLOODLIGHT BASIC | STAND BRACKET DOUBLE
Housing: Aluminium
Finish: Yellow (powder paint)
ART. NR.
MODEL
146-174
For Floodlight 90 cm
Basic 2 x 20W
HEIGHT MAX. HEIGHT WIDTH
160 cm
80 cm
80 cm
DEPTH
146-175
For Floodlight 130 cm
Basic 2 x 50W
300 cm
90 cm
80 cm
FLOODLIGHT BASIC | FLOOR BRACKET
Housing: Aluminium
Finish: Yellow (powder paint)
ART. NR.
MODEL
HEIGHT WIDTH
146-172
For Floodlight Basic 20W
23 cm
19 cm
146-173
For Floodlight Basic 50W
36 cm
23 cm
WWW.TRONIXLIGHTING.COM
103
Wall Washer
Drawing attention to larges surfaces and buildings
104
Wall Washers
WALL WASHER | SLIM | 12W | WARM WHITE
INPUT
POWER
24V
12W
Suitable for light output up to 3 meter
BEAM
IP RATE
WARRANTY
60˚
IP65
3
years
CERTIFICATE
Input: 24V
Power: 12 Watt
LED qty: 24
LED type: CREE
Beam: 45°
IP rate: IP65
Connection type: Modular plug
Wire length: 1,2 meter
Mounting: Surface mount
Material: Aluminium, Black
Maximum light reach: >3 meters
ART. NR.
SIZE
190-079
1000 x 280 x 660 mm 3000K
COLOR TEMP. (CCT)
ART. NR.
ACCESSORIES
010-203
Extension Cable - 1M
010-205
Extension Cable - 2M
010-207
Extension Cable - 3M
010-209
Extension Cable - 5M
010-023
T-Connector
COLOR LED
 Warm White
LIGHT OUTPUT WIRE LENGTH
534 Lm
35 cm
Extension cable 1/2/3/5M
T-Connector
WALL WASHER | 28W | WARM WHITE OR RGB
INPUT
POWER
24V
28W
Suitable for light output up to 8 meter
BEAM
IP RATE
WARRANTY
60˚
IP65
2
years
CERTIFICATE
Input: 24V
Power: 28 Watt
LED qty: 24
LED type: CREE XR-C
Beam: 60°
IP rate: IP65
Connection type: Modular plug
Wire length: 1,2 meter
Mounting: Surface mount
Material: Aluminium
Maximum light reach: >8 meters
ART. NR.
SIZE
COLOR TEMP. (CCT)
190-078
1000 x 82 x 126 mm
3000K
190-077
1000 x 82 x 126 mm
n/a
ART. NR.
ACCESSORIES
010-203
Extension Cable for Single Color - 1M
010-205
Extension Cable for Single Color - 2M
010-207
Extension Cable for Single Color - 3M
010-209
Extension Cable for Single Color - 5M
146-201
Power / Extension cable for RGB - 5M
010-023
T-Connector for Single Color
COLOR LED
 Warm White
RGB
LIGHT OUTPUT WIRE LENGTH
1722 Lm
35 cm
n/a
25 cm
Extension Cable - Single Color 1/2/3/5M
Extension Cable - RGB 1/2/3/5M
T-Connector
WWW.TRONIXLIGHTING.COM
105
Wall Washers
106
Wall Washers
WWW.TRONIXLIGHTING.COM
107
High Bays
High savings with High Bay lighting
solutions for every warehouse
108
High Bays
HIGH BAY | BASE 50W | 3000K
POWER
COLOR TEMP.
IP RATE
50W
3000K
IP65
CERTIFICATE
Width: 270 mm
Depth: 180 mm
Connection type: Schuko
Wire length: 1 meter
Driver: Meanwell brand
ART. NR.
POWER
COLOR TEMP. (CCT)
LIGHT OUTPUT
950-034
50 Watt
3000K
6000 Lm
ART. NR.
ACCESSORIES - REFLECTOR HOODS
950-044
60° Acrylate Hood | Small
950-045
60° Acrylate Hood
950-040
60° Aluminium Hood
950-041
90° Aluminium Hood
950-042
120° Aluminium Hood
ACRYLATE HOOD 60°
SMALL
ACRYLATE HOOD 60°
Art. nr. 950-044
ALUMINIUM HOODS 60°/90°/120°
Art. nr. 950-045
Art. nr. 950-040
HIGH BAY | BASE 50W | 4200K
Input: 85-265V
Power: 50 Watt
Led type: Bridgelux COB
IP Rate: IP54
ART. NR.
POWER
COLOR TEMP. (CCT)
LIGHT OUTPUT
50 Watt
4200K
5000 Lm
ART. NR.
ACCESSORIES - REFLECTOR HOODS
950-043
60° Acrylate Hood
950-040
60° Aluminium Hood
950-041
90° Aluminium Hood
950-042
120° Aluminium Hood
Art. nr. 950-043
Art. nr. 950-041
Art. nr. 950-042
POWER
COLOR TEMP.
IP RATE
50W
4200K
IP54
CERTIFICATE
WARRANTY
CERTIFICATE
3
years
Length: 270 mm
Diameter: 220 mm
Connection type: Schuko
Wire length: 1,7 meter
950-030
ACRYLATE HOOD 60°
CERTIFICATE
3
years
Including Meanwell Driver
Input: 100-240V
Power: 50 Watt
Led type: Philips Lumileds
IP Rate: IP65
Length: 260 mm
WARRANTY
ALUMINIUM HOODS 60°/90°/120°
Art. nr. 950-040
Art. nr. 950-041
Art. nr. 950-042
WWW.TRONIXLIGHTING.COM
109
High Bays
110
High Bays
Art. nr. 950-035
High Bay Base 100W
Art. nr. 950-041
90° Aluminium
Hood
WWW.TRONIXLIGHTING.COM
111
High Bays
HIGH BAY | BASE 100W | 4000K
POWER
COLOR TEMP.
IP RATE
100W
4000K
IP65
CERTIFICATE
3
years
Meanwell Driver
Input: 100-240V
Power: 100 Watt
Led type: Philips Lumiled
IP Rate: IP65
Length: 307 mm
WARRANTY
Width: 271 mm
Depth: 300 mm
Connection type: Schuko
Wire length: 2 meter
Driver: Meanwell brand
ART. NR.
POWER
COLOR TEMP. (CCT)
LIGHT OUTPUT
950-035
100 Watt
4000K
12.000 Lm
ART. NR.
ACCESSORIES - REFLECTOR HOODS
950-044
60° Acrylate Hood | Small
950-045
60° Acrylate Hood
950-040
60° Aluminium Hood
950-041
90° Aluminium Hood
950-042
120° Aluminium Hood
Choose the best suitiable reflector hood for your lighting application:
ACRYLATE HOOD 60°
SMALL
ACRYLATE HOOD 60°
Art. nr. 950-044
ALUMINIUM HOODS 60°/90°/120°
Art. nr. 950-045
Art. nr. 950-040
HIGH BAY | BASE 150W | 4200K
Art. nr. 950-041
POWER
COLOR TEMP.
IP RATE
WARRANTY
150W
4200K
IP54
3
years
Meanwell Driver
Input: 85-265V
Power: 150 Watt
Led type: Bridgelux COB
IP Rate: IP54
Length: 340 mm
Width: 280 mm
Depth: 210 mm
Connection type: Schuko
Wire length: 1,7 meter
Driver: Meanwell brand
ART. NR.
POWER
COLOR TEMP. (CCT)
LIGHT OUTPUT
950-032
150 Watt
4200K
15.000 Lm
ART. NR.
ACCESSORIES - REFLECTOR HOODS
950-043
60° Acrylate Hood
950-040
60° Aluminium Hood
950-041
90° Aluminium Hood
950-042
120° Aluminium Hood
Choose the best suitiable reflector hood for your lighting application:
ACRYLATE HOOD 60°
Art. nr. 950-043
112
ALUMINIUM HOOD 60°/90°/120°
Art. nr. 950-040
Art. nr. 950-041
Art. nr. 950-042
Art. nr. 950-042
CERTIFICATE
CERTIFICATE
High Bays
UFO HIGH BAY | 200W
Meanwell Driver
Input: 100-240V
Power: 200 Watt
Led type: Philips Lumiled
Beam: 60° (optional 120°)
IP Rate: IP65
ART. NR.
POWER
COLOR TEMP. (CCT)
LIGHT OUTPUT
200 Watt
4000K
25.000 Lm
ART. NR.
ACCESSORY
120° tempered glass
COLOR TEMP.
IP RATE
4000K
IP65
CERTIFICATE
WARRANTY
CERTIFICATE
3
years
Diameter: 400 mm
Height incl. hook: 196.5mm
Connection type: Schuko
Wire length: 1 meter
Driver: Meanwell brand
950-037
950-038
POWER
200W
WWW.TRONIXLIGHTING.COM
113
Industrial
Line Lighting
Meeting high expectations in
industrial lighting solutions
114
Industrial Line Lighting
Toolless coupling
Minimum labor time
Connecting the Light bars is only a matter
of seconds and does not require any tools.
So you get double savings with an absolute
minimum amount of labor time.
Detail
VDE Terminal Block
Mechanical Connector
2,5 mm² Wires
WWW.TRONIXLIGHTING.COM
115
Industrial Line Lighting
Why choose for Tronix Industrial LED Line-Lighting?
1. Simplicity
Tronix light lines can easily be connected by means of a toolless click-coupling
system, enabling the realisation of light lines up to 100 meters long. Quick and easy
assembly are guaranteed.
2. Savings up to 60%
EIA
ENERGIE
INVESTERINGSAFTREK
With light performances up to 140 Lm per Watt, Tronix Industrial Light Lines realize
savings of up to 60% compared to conventional light lines. With this feature, they
qualify for the Energy Investment Tax Reduction settlement (EIA – Energie Investerings Aftrek for the Netherlands ), ensuring a short return on investment period.
INPUT
3. Control
1-10V
Maintain control over use, consumption and savings by applying a light management system such as Dali, 1-10V and presence detection.
4. Flexibility
Lens 30°
Lens 60°
Lens 90°
Double 25°
25° L/R
Offering a large choice in fixtures, both in performance and beam angle, Tronix
Industrial Light Lines are suitable for a wide variety of application areas, such as
warehouses, workshops, production facilities, shops, and sports centres.
5. Total Solution
In addition to just plain delivery, Tronix Lighting also supports and advises in
complete mounting and instalment, in close cooperation with our professional
partners. This also includes the possibility of making light plans. National coverage,
cost efficient and a single point of contact for the complete installation. In short, full
customer support from A-Z.
116
Industrial Line Lighting
Available LED modules with optical lens
Detail
Lens 30°
Lens 60°
Lens 90°
Double 25°
25° L/R
For all models below (the 1-10V as well
as the Dali dimmable versions), there is
an optional model available with emergency function.
1-10V DIMMABLE
POWER
BEAM ANGLE
LENGTH
LUMEN EFFICIENCY
DIMMABLE
CRI
COLOR TEMP. (CCT)
NETT WEIGHT
28W
30°/60°/90°/Double asymmetrical/LorR25°
1458 mm
140 Lm/W
Yes, 1-10V
>80Ra
3K/4K/5K/6.5K
1,6 Kg
36W
30°/60°/90°/Double asymmetrical/LorR25°
1458 mm
140 Lm/W
Yes, 1-10V
>80Ra
3K/4K/5K/6.5K
1,6 Kg
48W
30°/60°/90°/Double asymmetrical/LorR25°
1458 mm
140 Lm/W
Yes, 1-10V
>80Ra
3K/4K/5K/6.5K
1,6 Kg
75W
30°/60°/90°/Double asymmetrical/LorR25°
1458 mm
140 Lm/W
Yes, 1-10V
>80Ra
3K/4K/5K/6.5K
1,6 Kg
DALI DIMMABLE
POWER
BEAM ANGLE
LENGTH
LUMEN EFFICIENCY DIMMABLE
CRI
COLOR TEMP. (CCT)
NETT WEIGHT
28W-48W
30°/60°/90°/Double asymmetrical/LorR25°
1458 mm
140 Lm/W
Yes, Dali
>80Ra
3K/4K/5K/6.5K
1,6 Kg
36W-70W
30°/60°/90°/Double asymmetrical/LorR25°
1458 mm
140 Lm/W
Yes, Dali
>80Ra
3K/4K/5K/6.5K
1,6 Kg
48W-75W
30°/60°/90°/Double asymmetrical/LorR25°
1458 mm
140 Lm/W
Yes, Dali
>80Ra
3K/4K/5K/6.5K
1,6 Kg
WWW.TRONIXLIGHTING.COM
117
Industrial Line Lighting
Available LED modules with diffuse reflector
Detail
For all models below (the 1-10V as well
as the Dali dimmable versions), there
is an optional model available with
emergency function.
1-10V Dimmable
POWER
BEAM ANGLE
LENGTH
LUMEN EFFICIENCY
DIMMABLE
CRI
COLOR TEMP. (CCT)
NETT WEIGHT
32W
120° diffuse
1458 mm
140 Lm/W
1-10V
>80Ra
3K/4K/5K/6.5K
1,6 Kg
48W
120° diffuse
1458 mm
140 Lm/W
1-10V
>80Ra
3K/4K/5K/6.5K
1,6 Kg
Dali Dimmable
118
POWER
BEAM ANGLE
LENGTH
LUMEN EFFICIENCY
DIMMABLE
CRI
COLOR TEMP. (CCT)
NETT WEIGHT
32W - 48W
120° diffuse
1458 mm
140 Lm/W
Dali
>80Ra
3K/4K/5K/6.5K
1,6 Kg
Industrial Line Lighting
Mounting channels of 1,5M or 3M
Carrying profiles for Tronix industrial light lines are available in 1.5 meters and 3 meters, and are equipped with a
standard 7-wire cable 2.5 mm². They are suitable for 3-phase voltage in combination with dimming (1-10V or Dali)
or emergency power lighting. Or optionally available with an11-vein wiring for 3-phase voltage, in combination
with both dimming (1-10V or Dali) and emergency lighting.
L 1 = 1458 / 2916 mm
L 2 = 1578 / 3036 mm
L1
L2
DIMENSIONS LXWXH
DESCRIPTION
NETT WEIGHT
1458*69*66 mm
For 1 x LED module 1,5 meter / 7-veins with 2,5 mm2 cable
1,1 Kg
2916*69*66 mm
For 2 x LED module 1,5 meter / 7-veins with 2,5 mm2 cable
2,2 Kg
W
W
H
Size carrying profile including
Size carrying profile including
LED module with optical lens
LED module with optical lens
69 mm (W) x 66 mm (H)
H
69 mm (W) x 87 mm (H)
Carrying profile
Cover plate
LED Module
WWW.TRONIXLIGHTING.COM
119
Industrial Line Lighting
Cover- & Phase rail plates
Neutral cover plate
DIMENSIONS LXWXH DESCRIPTION
NETT WEIGHT
1458*69*24,2 mm
0,18 Kg
Neutral cover, polycarbonate material, white color
Neutral cover plate with rail for Track Light Spot
DIMENSIONS LXWXH DESCRIPTION
NETT WEIGHT
1458*69*24,2 mm
2,7 Kg
Aluminium cover with rail for Track Light
Accessories
End cap Set
Hang-up Wire Steel
End cap set (2 pcs) to
seal the lightline
Diameter:
Length:
1,5 mm
2 meter
2
Connector
male & female
For max. 320V/20A
AC Power Adaptor
with swivel (wartel) on
the top side
Dimensions Power Adaptor
(extra length on lightline):
L = 280 mm
120
Hang-up Clip
Size:
50*54,5*45 mm
Material thickness: 0,6 mm
Material:staal
Clip distance:
± 1,5 meter
Industrial Line Lighting
WWW.TRONIXLIGHTING.COM
121
Industrial Line Lighting
122
Industrial Line Lighting
WWW.TRONIXLIGHTING.COM
123
Industrial Line Lighting
INDUSTRIAL LIGHT BAR | LINEAIR For stand alone applications
BEAM
IP RATE
90˚
IP20
CERTIFICATE
CERTIFICATE
WARRANTY
CERTIFICATE
2
years
Input: 100-240V
Power: 52 Watt
Power Factor: >0,9
LED type: Epistar 2835
Beam: 90°
CRI: >80
IP Rate: IP20
Width: 70 mm
Height: 55 mm
Cover: Lenses (90°)
Steel Cable: Included (1 meter)
ART. NR.
LENGTH
COLOR TEMP. (CCT)
LIGHT OUTPUT
POWER
950-060
1436 mm
4000K
4500 Lm
52 Watt
IK
TRI-PROOF LIGHT BAR | EASY CONNECT
IK08
Including mounting clips 2 pcs
Input: 100-240V
Power: 54 Watt
Power Factor: >0,9
LED type: Epistar 2835
Beam: 120°
CRI: >80
IP Rate: IP65
Width: 63 mm
Height: 65 mm
Connection Type: Easy Connect System
Cover: PC Opal
Mounting Clips: Included (2pcs)
124
ART. NR.
LENGTH
COLOR TEMP. (CCT)
LIGHT OUTPUT
POWER
950-070
1500 mm
4000K
6480 Lm
54 Watt
ART. NR.
ACCESSORY
950-071
Power Cable - 1,5M
950-072
Extension Cable - 1,5M
BEAM
120˚
IP RATE
IP65
CERTIFICATE
WARRANTY
2
years
CERTIFICATE
Industrial Line Lighting
TRI-PROOF LIGHT BAR IK
IK08
Including mounting clips 2 pcs and cable gland 2 pc
BEAM
120˚
IP RATE
CERTIFICATE
WARRANTY
CERTIFICATE
3
years
IP65
Input: 100-240V
Power: 50 Watt
Power Factor: >0,9
LED type: Epistar 2835
Driver brand: XZ Power
Beam: 120°
CRI: >80
IP Rate: IP65
Width: 86 mm
Height: 80 mm
Connection Type: Screw Terminal inside
Cover: PC Opal
Operating Environment: -20°~35°
Accessories included: Mounting clip (2pcs) and cable gland (2pcs)
ART. NR. POWER
LENGTH
COLOR TEMP. (CCT)
LIGHT OUTPUT
950-065
50 Watt
1566 mm
4000K
5100 Lm
950-066
50 Watt with Emergency Pack
1566 mm
4000K
5100 Lm
ART. NR. ACCESSORY
950-067
Pendant Steel cable - 1 pc | 1,5M
T8 LIGHT BAR | EASY CONNECT BEAM
Including mounting clips 2 pcs, power cable 30 cm and splice connector
120˚
IP RATE
IP20
CERTIFICATE
WARRANTY
CERTIFICATE
2
years
Input: 100-240V
Power: 18 Watt
Power Factor: >0,9
LED type: Epistar SMD
Beam: 120°
CRI: >80
IP Rate: IP20
Width: 31 mm
Height: 38 mm
Connection Type: Easy Connect System
Cover: PC Opal
Operating Environment: -20°~35°
Accessories included: Mounting clip (2pcs), power cable (30 cm) & splice connector
ART. NR. POWER LENGTH
COLOR TEMP. (CCT)
177-053
18 Watt
1200 mm
4000 Kelvin
 Natural White
COLOR
LIGHT OUTPUT
1600 Lm
177-054
18 Watt
1200 mm
3000 Kelvin
 Warm White
1600 Lm
ART. NR. ACCESSORY
177-058
Power cable | 5M
WWW.TRONIXLIGHTING.COM
125
Street &
Parking Light
For bright and powerfull illuminations
of streets and parking areas
126
Street & Parking Light
PARKING LIGHT FIXTURE | E27 SOCKET
IP RATE
WARRANTY
IP54
5
years
Excluding lamp
CERTIFICATE
Input: E27 Light Bulb (not included)
IP Rate: IP54
IK Rate: IK09
Connection Diameter: Ø 60 mm
Material: PET + Aluminium
ART. NR. DIAMETER Ø
HEIGHT
220-040
459 mm
590 mm
ART. NR. ACCESSORIES - CORN LAMPS
175-530
LED Corn Lamp 20W | E27 | 3000K | 1800 Lm
175-531
LED Corn Lamp 20W | E27 | 5000K | 1900 Lm
175-532
LED Corn Lamp 30W | E27 | 3000K | 2800 Lm
175-533
LED Corn Lamp 30W | E27 | 5000K | 2880 Lm
LED PARKING LIGHT | 35W | 6500K
Including Philips Xitanium LED driver
POWER
IP RATE
WARRANTY
35W
IP65
2
years
CERTIFICATE
Input: 230V
Power: 35 Watt
LED type: CREE XP-E
Beam: 45°
IP Rate: IP65
Connection Diameter: Ø 48 mm
Connection Type: Stripped Wire
ART. NR. POWER
COLOR TEMP. (CCT)
LIGHT OUTPUT
LED QTY
LENGTH
WIDTH
DEPTH
220-021
6500K
2660 Lm
28
435 mm
245 mm
155 mm
35 Watt
ART. NR. ACCESSORY
220-022
Mounting converter for mounting on a vertical pole Ø60mm
WWW.TRONIXLIGHTING.COM
127
Street & Parking Light
LED STREET LIGHT | 60W - 90W - 120W | 4000K
BEAM
120˚
With Philips LED and Meanwell Driver
POWER
POWER
POWER
IP RATE
60W
90W
120W
IP65
CERTIFICATE
WARRANTY
CERTIFICATE
3
years
Input: 230V
Power: 60/90/120 Watt
LED type: Philips
Beam: 120°
IP Rate: IP65
Connection Diameter: Ø 60 mm
Connection Type: Screw Terminal inside
Housing: Aluminium, Grey
Adjustable
ART. NR. POWER
COLOR TEMP. (CCT)
LIGHT OUTPUT
LED QTY
LENGTH
WIDTH
DEPTH
220-030
4000K
7200 Lm
60
580 mm
315 mm
70 mm
60 Watt
220-031
90 Watt
4000K
10.800 Lm
90
680 mm
315 mm
70 mm
220-032
120 Watt
4000K
14.400 Lm
120
780 mm
315 mm
70 mm
Steel Mounting / Wall Support 60 mm
Suitable for all Street Light models
Art. nr. 220-060
ART. NR. ACCESSORY
220-060
LED Street Light | Mounting / Wall Support 60MM | Steel
LED STREET LIGHT | 106-140W | 4000K
BEAM
45˚
POWER
POWER
IP RATE
WARRANTY
106W
140W
IP65
3
years
Including Philips Xitanium LED driver
Input: 230V
Power: 106/140 Watt
LED type: CREE XPE HEW
Beam: 45°
IP Rate: IP65
Connection Diameter: Ø 60 mm
Connection Type: Screw Terminal
Housing: Aluminium, Grey
Ø 60 mm
CERTIFICATE
Straight mounting
Angled mounting
15°
ART. NR. POWER
COLOR TEMP. (CCT)
LIGHT OUTPUT
LED QTY
LENGTH
WIDTH
DEPTH
220-027
106 Watt
4000K
10.405 Lm
45
696 mm
376 mm
118 mm
220-028
140 Watt
4000K
13.698 Lm
60
763 mm
376 mm
118 mm
Steel Mounting / Wall Support 60 mm
Suitable for all Street Light models
Art. nr. 220-060
ART. NR. ACCESSORY
220-060
LED Street & Parking Light | Mounting / Wall Support 60MM | Steel
LED Streetlight 106 Watt
128
LED Streetlight 140 Watt
Street & Parking Light
WWW.TRONIXLIGHTING.COM
129
Garden Lights
& Spots
For attractive illumination of
gardens, patio’s or driveways
130
Garden Lights & Spots
GROUND SPOT | 16W | 24° | ADJUSTABLE
BEAM
24˚
POWER
INPUT
IP RATE
16W
240V
IP67
CERTIFICATE
WARRANTY
CERTIFICATE
2
years
With Eaglerise driver
Input: 100-240V
Power: 16 Watt
LED qty: 3
LED type: CREE CXA MHB
Beam: 24°
IP rate: IP67
Diameter: Ø 160 mm
Depth: 248 mm
Connection type: Stripped wire
Wire length: 2 meter
Material: Stainless steel 304 / Aluminium / Glass
ART. NR.
INPUT
COLOR TEMP. (CCT)
140-071
240 Volt
3000K
COLOR LED
 Warm White
LIGHT OUTPUT
MOUNTING HOLE
MOUNTING DEPTH
1300 Lm
155 mm
248 mm
GROUND SPOT | 38W | 24° | ADJUSTABLE
BEAM
24˚
POWER
INPUT
IP RATE
38W
240V
IP67
CERTIFICATE
WARRANTY
CERTIFICATE
2
years
With Moons driver
Input: 100-240V
Power: 38 Watt
LED qty: 7
LED type: CREE CXA MHB
Beam: 24°
IP rate: IP67
Diameter: Ø 250 mm
Depth: 267 mm
Connection type: Stripped wire
Wire length: 2 meter
Material: Stainless steel 304 / Aluminium / Glass
ART. NR.
INPUT
COLOR TEMP. (CCT)
140-073
240 Volt
3000K
COLOR LED
 Warm White
LIGHT OUTPUT
MOUNTING Ø
MOUNTING DEPTH
2800 Lm
245 mm
267 mm
WWW.TRONIXLIGHTING.COM
131
Garden Lights & Spots
GROUND SPOT | 8W | ASYMMETRICAL 25°
BEAM
POWER
INPUT
IP RATE
25˚
8W
240V
IP67
CERTIFICATE
WARRANTY
CERTIFICATE
3
years
Input: 100-240V
LED qty: 6
LED type: Osram
Beam: 25°
IP rate: IP67
Diameter: Ø 160 mm
Depth: 163,5 mm
Connection type: Stripped wire
Wire length: 1,5 meter
Material: Aluminium housing, tempered glass,
stainless steel 316 Akzo Nobel
ART. NR. INPUT POWER COLOR TEMP. (CCT)
140-070
240V
8 Watt
COLOR LED LIGHT OUTPUT MOUNTING HOLE
 Warm White
3000K
369 Lm
148 mm
MOUNTING DEPTH
160 mm
GROUND SPOT | WARM WHITE | 4 OUTPUTS
INPUT
IP RATE
240V
IP65
CERTIFICATE
Input: 100-240V
LED type: CREE XP
Color temp. (CCT): 3000K
Color LED: Warm white
IP rate: IP65
Connection type: Stripped wire
Wire length: 2 meter
Material: RVS / Glass / Aluminium / PC
COLOR LED LIGHT OUTPUT
140-051
240V
6,5 Watt
3
33°
3000K
 Warm White
350 Lm
140-055
240V
16 Watt
9
17°
3000K
 Warm White
1100 Lm
140-059
240V
26 Watt
15
33°
3000K
 Warm White
1750 Lm
140-063
240V
38 Watt
21
45°
3000K
 Warm White
2300 Lm
ART. NR. DIAMETER Ø
MOUNTING Ø (A)
MOUNTING DEPTH (B)
140-051
120 mm
118 mm
202 mm
140-055
160 mm
155 mm
244 mm
140-059
193 mm
190 mm
244 mm
140-063
250 mm
245 mm
263 mm
GROUND SPOT | RGB | 12V~24V
RGB
INPUT
INPUT
IP RATE
12V
24V
IP65
Including internal Meanwell driver
Input: 12V/24V
LED type: CREE XP
Color LED: RGB
IP rate: IP65
Connection type: Stripped wire
Wire length: 2 meter
Material: RVS / Glass / Aluminium / PC
132
CERTIFICATE
2
years
Including internal Meanwell driver
ART. NR. INPUT POWER LED QTY BEAM COLOR TEMP. (CCT)
WARRANTY
ART. NR. INPUT POWER LED QTY BEAM
COLOR LED DIAMETER Ø
MOUNTING Ø (A) MOUNTING DEPTH (B)
140-052
12V
6,5 Watt
3
17°
RGB
120 mm
118 mm
202 mm
140-060
24V
26 Watt
15
33°
RGB
193 mm
190 mm
244 mm
Art. nr. 140-051
Art. nr. 140-055
Art. nr. 140-059
Art. nr. 140-063
CERTIFICATE
WARRANTY
2
years
CERTIFICATE
Garden Lights & Spots
GROUND SPOT | 350mA | MINI
Excluding driver
INPUT
POWER
IP RATE
350
mA
1,5W
IP67
CERTIFICATE
WARRANTY
CERTIFICATE
3
years
Input: 350mA
Power: 1,5 Watt
LED qty: 1
LED type: CREE XP
IP rate: IP67
Diameter: 28 mm
Connection type: Stripped wire
Wire length: 3 meter
Material: Stainless steel 316, aluminium
ART. NR. INPUT BEAM
COLOR TEMP. (CCT)
140-001
3000K
350mA 45°
COLOR LED LIGHT OUTPUT MOUNTING Ø
 Warm White
80 Lm
25 mm
MOUNTING DEPTH
56 mm
ART. NR. ACCESSORY
215-303
LED Driver Mini | 350mA | 4 Watt | Outdoor
GROUND SPOT | 700mA | MEDI
Excluding driver
INPUT
POWER
IP RATE
700
mA
2,5W
IP67
CERTIFICATE
WARRANTY
CERTIFICATE
3
years
Input: 700mA
Power: 2,5 Watt
LED qty: 1
LED type: CREE XP
IP rate: IP67
Connection type: Stripped wire
Wire length: 3 meter
Material: Stainless steel 316, aluminium
ART. NR. INPUT BEAM
COLOR TEMP. (CCT)
140-002
700mA 45°
3000K
 Warm White
COLOR LED LIGHT OUTPUT DIAMETER Ø MOUNTING Ø MOUNTING DEPTH
111 Lm
40 mm
33 mm
90 mm
140-003
700mA 10°
3000K
 Warm White
111 Lm
40 mm
33 mm
90 mm
140-004
700mA 120° (Milky) 3000K
 Warm White
111 Lm
42 mm
39 mm
90 mm
ART. NR. ACCESSORY
215-305
LED Driver Mini | 700mA | 4 Watt | Outdoor
GROUND SPOT | 700mA | MEDI
SINGLE OR DOUBLE LIGHT OUTPUT
INPUT
POWER
IP RATE
700
mA
2,5W
IP67
CERTIFICATE
WARRANTY
CERTIFICATE
3
years
With 120° beam and single or double sided light output
Excluding driver
Input: 700mA
Power: 2,5 Watt
LED qty: 1
LED type: CREE XP
IP rate: IP67
IK rate: IK08
Connection type: Stripped wire
Wire length: 3 meter
Material: Aluminium
ART. NR. INPUT BEAM
COLOR TEMP. (CCT)
140-005
700mA 120°
3000K
 Warm White
COLOR LED LIGHT OUTPUT DIAMETER Ø MOUNTING Ø (A) MOUNTING DEPTH (B)
111 Lm
60 mm
39 mm
90 mm
140-006
700mA 2 x 120°
3000K
 Warm White
111 Lm
60 mm
39 mm
90 mm
ART. NR. ACCESSORY
215-305
LED Driver Mini | 700mA | 4 Watt | Outdoor
WWW.TRONIXLIGHTING.COM
133
Garden Lights & Spots
Ground Spot Housings
Empty ground spot housings are available in Ø 120 mm or Ø 150 mm to use in
combination with Tronix Universal Modules or 50 mm spots (GU10 & MR16)
Empty housing
Ground Spot
Ø 120 mm
Art. nr. 140-020
Empty housing
Ground Spot
Ø 150 mm
Art. nr. 140-030
SUITABLE LAMPS:
ADJUSTABLE
GROUND SPOT | EMPTY HOUSING | Ø 120 MM
GU-10 COB
5 Watt
Universal
Module COB
3,3 Watt
MR16 COB
5 Watt
Universal
Module COB
Flat - 6,5 Watt
Universal
Module
2,5 Watt
Universal
Module COB
Flat - 9,5 Watt
IP RATE
CERTIFICATE
WARRANTY
CERTIFICATE
2
years
IP65
Diameter: 120 mm
IP rate: IP65
Connection type: Stripped wire
Wire length: 2 meter
Material: RVS / Glass / Aluminium / PC
ART. NR. DIAMETER Ø
MOUNTING Ø
MOUNTING DEPTH
140-020
105 mm
165 mm
120 mm
GROUND SPOT | EMPTY HOUSING | Ø 150 MM | ADJUSTABLE
IP RATE
IP65
CERTIFICATE
WARRANTY
CERTIFICATE
2
years
Diameter: 150 mm
IP rate: IP65
Connection type: Stripped wire
Wire length: 2 meter
Material: RVS / Glass / Aluminium / PC
ART. NR. DIAMETER Ø
MOUNTING Ø
MOUNTING DEPTH
140-030
142 mm
205 mm
150 mm
ACCESSORIES | CONNECTION TUBE | 2 WAY OR 3 WAY
IP RATE
IP65
IP rate: IP65
Material: PC / RVS screws
ART. NR. NR. OF OUTPUTS
134
142-007
1
142-006
2
CERTIFICATE
Garden Lights & Spots
Art. nr. 140-052
WWW.TRONIXLIGHTING.COM
135
Garden Lights & Spots
GROUND SPOT MINI ~MIDI | 12V | 3 PCS
PLUG&
PLAY
Mini
3 pack
Input: 12V
LED type: DIP
IP rate: IP67
Connection type: Plug connection
Wire length: 1 meter
Material: RVS / PC
INPUT
IP RATE
12V
IP67
CERTIFICATE
WARRANTY
CERTIFICATE
2
years
Midi
ART. NR. MINI
INPUT
POWER
LED QTY
MOUNTING Ø DEPTH
WIRE
149-011
12V
0,3 Watt p/pc
1
 White
COLOR LED DIAMETER Ø
25 mm
19 mm
45 mm
1 meter
149-012
12V
0,3 Watt p/pc
1
 Blue
25 mm
19 mm
45 mm
1 meter
149-016
12V
0,3 Watt p/pc
1
 Amber
25 mm
19 mm
45 mm
1 meter
ART. NR. MIDI
INPUT
POWER
LED QTY
MOUNTING Ø DEPTH
WIRE
149-021
12V
0,5 Watt p/pc
6
 White
COLOR LED DIAMETER Ø
40 mm
30 mm
57 mm
2 meter
149-022
12V
0,5 Watt p/pc
6
 Blue
40 mm
30 mm
57 mm
2 meter
149-026
12V
0,5 Watt p/pc
6
 Amber
40 mm
30 mm
57 mm
2 meter
GROUND SPOT MAXI | 12V | 12 LED
PLUG&
PLAY
INPUT
IP RATE
12V
IP67
CERTIFICATE
WARRANTY
CERTIFICATE
2
years
Input: 12V
Power: 1 Watt
LED type: DIP
IP rate: IP67
Connection type: Plug connection
Wire length: 2 meter
Material: RVS / Glass / Aluminium / PC
ART. NR.
INPUT
LED QTY
149-032
12V
12
 Blue
COLOR LED DIAMETER Ø
110 mm
MOUNTING Ø DEPTH
95 mm
110 mm
149-036
12V
12
 Amber
110 mm
95 mm
110 mm
BRICK LIGHT | 12V | 16 LED
PLUG&
PLAY
Input: 12V
Power: 1,5 Watt
LED type: DIP
IP rate: IP67
Depth: 68 mm
Connection type: Plug connection
Wire length: 2 meter
Material: PC
136
ART. NR.
INPUT
LED QTY
WIDTH
MOUNTING DEPTH
149-041
12V
16
 White
COLOR LED LENGTH
100 mm
100 mm
60 mm
149-042
12V
16
 Blue
100 mm
100 mm
60 mm
149-046
12V
16
 Amber
100 mm
100 mm
60 mm
INPUT
IP RATE
12V
IP67
CERTIFICATE
WARRANTY
2
years
CERTIFICATE
Garden Lights & Spots
SPYKE CANDLE LIGHT | 12V
PLUG&
PLAY
INPUT
IP RATE
12V
IP67
CERTIFICATE
WARRANTY
CERTIFICATE
2
years
Input: 12V
Power: 0,2 Watt
LED qty: 1
LED type: DIP
IP rate: IP67
Connection type: Plug connection
Wire length: 2 meter
Material: Aluminium / Glass
ART. NR.
INPUT
149-088
12V
COLOR LED LENGTH
 Flame
470 mm
SPOT LIGHT | 12V | ALUMINIUM
PLUG&
PLAY
INPUT
POWER
IP RATE
12V
3W
IP54
INPUT
POWER
IP RATE
12V
3W
IP54
CERTIFICATE
WARRANTY
CERTIFICATE
2
years
Input: 12V
Power: 3 Watt
LED qty: 1
LED type: CREE
IP rate: IP54
Beam: 40°
Connection type: Plug connection
Wire length: 2 meter
Material: Aluminium / Glass
ART. NR.
INPUT
COLOR TEMP. (CCT)
149-089
12V
3000K
COLOR LED
 Warm White
LIGHT OUTPUT
LENGTH
68 Lm
420 mm
POLE LIGHT | 12V | ALUMINIUM
PLUG&
PLAY
CERTIFICATE
WARRANTY
CERTIFICATE
2
years
Input: 12V
Power: 3 Watt
LED qty: 1
LED type: CREE
IP rate: IP54
Connection type: Plug connection
Wire length: 2 meter
Material: Aluminium / Glass
ART. NR.
INPUT
COLOR TEMP. (CCT)
149-090
12V
3000K
COLOR LED
 Warm White
LIGHT OUTPUT
LENGTH
111 Lm
350 mm
POWER SUPPLY & ACCESSORIES | GARDEN LIGHT 12V
ART. NR.
INPUT
215-310
Power supply 12V | 30 Watt | Block type outdoor 102*50*27 mm | IP67
149-001
Main connector cable | 9 meter | 6 connections
149-002
Extension cable | 2 meter
149-003
Extension cable | 5 meter
149-004
Divider | 2-way | 1,5 meter wire length
149-005
Divider | 3-way | 1,5 meter wire length
PLUG&
CERTIFICATE
PLAY
WWW.TRONIXLIGHTING.COM
137
Garden Lights & Spots
&
G
U
PL
PLUG&
PLAY
Y
A
L
P
Thanks to the plug & play
system, Garden Lights is easy
to assemble for everyone.
LED
Garden
Easy assembling
Garden borders
Terraces
Driveways
Tilework
High safety due to low voltage 12V
138
LIGHTS
Garden Lights & Spots
GARDEN POLE | 240V | ALUMINIUM
INPUT
IP RATE
240V
IP54
CERTIFICATE
WARRANTY
CERTIFICATE
2
years
Input: 240V
Power: 4 x 1 Watt
LED qty: 4
LED type: CREE
IP rate: IP54
Connection type: Screw connection
Material: Aluminium
ART. NR.
INPUT
COLOR TEMP. (CCT)
149-301
240V
3000K
COLOR LED
 Warm White
DIAMETER Ø
LENGTH
15 cm
60 cm
GARDEN POLE OVAL | 240V | ALUMINIUM
INPUT
IP RATE
240V
IP54
CERTIFICATE
WARRANTY
CERTIFICATE
2
years
Input: 240V
Power: 1 x 3 Watt
LED qty: 1
LED type: CREE
IP rate: IP54
Connection type: Screw connection
Material: Aluminium
ART. NR.
INPUT
COLOR TEMP. (CCT)
149-303
240V
3000K
COLOR LED
 Warm White
DIAMETER Ø
LENGTH
9 cm
60 cm
SPOT LIGHT | 240V | ALUMINIUM
BEAM
40˚
INPUT
IP RATE
240V
IP54
CERTIFICATE
WARRANTY
CERTIFICATE
2
years
Input: 240V
Power: 1 x 3 Watt
LED qty: 1
LED type: CREE
Beam: 40°
IP rate: IP54
Lumen: 162
Connection type: Screw connection
Material: Aluminium
ART. NR.
INPUT
COLOR TEMP. (CCT)
149-304
240V
3000K
COLOR LED
 Warm White
LENGTH
DEPTH
35 cm
9 cm
SPOT LIGHT | 240V | ALUMINIUM | WITH 15CM SPIKE
BEAM
40˚
INPUT
IP RATE
240V
IP67
CERTIFICATE
WARRANTY
CERTIFICATE
2
years
Input: 240V
Power: 1 x 3 Watt
LED qty: 1
LED type: CREE
Beam: 40°
IP rate: IP67
Lumen: 162
Wire length: 2 meter
Connection type: Schuko plug
Material: Aluminium
ART. NR.
INPUT
COLOR TEMP. (CCT)
149-305
240V
3000K
COLOR LED
 Warm White
DIAMETER Ø
WIDTH
7 cm
11 cm
WWW.TRONIXLIGHTING.COM
139
Garden Lights & Spots
GARDEN POLE | 240V | ALUMINIUM | 1 LAMP DOWN | ROUND
INPUT
IP RATE
240V
IP54
CERTIFICATE
WARRANTY
CERTIFICATE
2
years
Input: 240V
Power: 5 x 1 Watt
LED qty: 5 (on one side)
LED type: CREE
IP rate: IP54
Connection type: Screw connection
Material: Aluminium
ART. NR.
INPUT
COLOR TEMP. (CCT)
149-306
240V
3000K
COLOR LED
 Warm White
LENGTH
WIDTH
DEPTH
60 cm
19 cm
19 cm
GARDEN POLE | 240V | ALUMINIUM | 2 LAMP DOWN | ROUND
INPUT
IP RATE
240V
IP54
CERTIFICATE
WARRANTY
CERTIFICATE
2
years
Input: 240V
Power: 6 x 1 Watt
LED qty: 6 (3 on each side)
LED type: CREE
IP rate: IP54
Connection type: Screw connection
Material: Aluminium
ART. NR.
INPUT
COLOR TEMP. (CCT)
149-307
240V
3000K
COLOR LED
 Warm White
LENGTH
WIDTH
DEPTH
60 cm
40 cm
19 cm
GARDEN POLE | 240V | ALUMINIUM | 2 LAMP DOWN | SQUARE
INPUT
IP RATE
240V
IP54
CERTIFICATE
WARRANTY
CERTIFICATE
2
years
Input: 240V
Power: 4 x 1 Watt
LED qty: 4 (2 on each side)
LED type: CREE
IP rate: IP54
Connection type: Screw connection
Material: Aluminium
ART. NR.
INPUT
COLOR TEMP. (CCT)
149-308
240V
3000K
COLOR LED
 Warm White
LENGTH
WIDTH
DEPTH
60 cm
13,5 cm
10 cm
GARDEN POLE | 240V | ALUMINIUM | 2 X MARKER LIGHT
Input: 240V
Power: 6 x 1 Watt
LED qty: 6 (3 on each side)
LED type: CREE
IP rate: IP54
Connection type: Screw connection
Material: Aluminium
140
ART. NR.
INPUT
COLOR TEMP. (CCT)
149-309
240V
3000K
COLOR LED
 Warm White
LENGTH
WIDTH
DEPTH
60 cm
4,5 cm
7,5 cm
INPUT
IP RATE
240V
IP54
CERTIFICATE
WARRANTY
2
years
CERTIFICATE
Garden Lights & Spots
UNDER WATER SPOTS | 12V | WARM WHITE OR RGB
Can only be used under water
BEAM
30˚
INPUT
12V
RGB
IP RATE
IP68
CERTIFICATE
WARRANTY
CERTIFICATE
2
years
Input: 12V
LED qty: 1
Beam: 30°
Diameter: 50 mm
IP rate: IP68
Length: 83,5
Connection type: Stripped wire
Material: Aluminium
ART. NR.
INPUT
POWER
COLOR TEMP. (CCT)
200-001
12V
5 Watt
3000K
 Warm White
COLOR LED
200-003
12V
15 Watt
3000K
 Warm White
200-004
12V
15 Watt
n/a
RGB
WWW.TRONIXLIGHTING.COM
141
Flex Tape
A wide range of flexible light strips and channels
to suit any decorative lighting application
142
Single color
FLEX TAPE 12V | 60 LED | SMD 3528 I IP20
INPUT
LED’S P/M
12V
60
Single color Flex Tape for indoor use - with 3M adhesive tape on the back
Input: 12 Volt
Power: 4,8 Watt p/m
LED qty: 60 p/m
LED type: SMD 3528
Dimmable: Yes
Beam: 120°
CRI: >90
IP rate: IP20
DIMMABLE
-
+
CUT. DIST.
IP RATE
CERTIFICATE
WARRANTY
CERTIFICATE
3
years
IP20
50MM
5M
LED distance: 16,7 mm
Cutting distance: 50 mm
Max. to connect: 5 m
Length: 5 m
Width: 8 mm
Height: 2 mm
PCB color: White
Conn. type: Stripped wire, 2 sides
ART. NR.
COLOR TEMP. (CCT)
LUMEN P/M
ART. NR.
ACCESSORIES
127-043
2700K
 Warm White
300
127-280
Power cable
127-008
3000K
 Warm White
300
127-281
Splice connector (corner)
127-044
4000K
 Natural White
360
127-204
Splice connector (in-line)
127-001
6500K
 Cold White
360
127-002
-
 Blue
n.a.
127-003
-
 Green
n.a.
127-004
-
 Red
n.a.
127-005
-
 Yellow
n.a.
COLOR LED
FLEX TAPE 24V | 120 LED| SMD 3528 | IP20
Single color Flex Tape for indoor use - with 3M adhesive tape on the back
Input: 24 Volt
Power: 9,6 Watt p/m
LED qty: 120 p/m
LED type: SMD 3528
Dimmable: Yes
Beam: 120°
CRI: >90
IP rate: IP20
| Flex tape
INPUT
LED’S P/M
24V
120
DIMMABLE
-
+
CUT. DIST.
IP RATE
IP20
50MM
5M
CERTIFICATE
WARRANTY
CERTIFICATE
3
years
LED distance: 8,3 mm
Cutting distance: 50 mm
Max. to connect: 10 m
Length: 5 m
Width: 8 mm
Height: 2 mm
PCB color: White
Conn. type: Stripped wire, 2 sides
ART. NR.
COLOR TEMP. (CCT)
127-049
2300K
 Warm White++
COLOR LED
600
LUMEN P/M
127-060
2700K
 Warm White+
600
127-065
3000K
 Warm White
600
127-066
4000K
 Natural White
720
127-067
7000K
 Cold White
720
127-042
-
 Blue
n.a.
WWW.TRONIXLIGHTING.COM
143
Flex tape |
Single color
FLEX TAPE 24V | 240 LED | SMD 3528 | IP20
INPUT
LED’S P/M
24V
240
Single color Flex Tape for indoor use in 3 white colors
DIMMABLE
-
+
CUT. DIST.
IP RATE
CERTIFICATE
WARRANTY
CERTIFICATE
3
years
IP20
25MM
5M
With 3M adhesive tape on the back
Input: 24V
Power: 19,2 Watt p/m
LED qty: 240 p/m
LED type: SMD 3528
Dimmable: Yes
Beam: 120°
CRI: >90
IP rate: IP20
LED distance: 4,2 mm
Cutting distance: 25 mm
Max. to connect: 5 m
Length: 5 m
Width: 10 mm
Height: 2 mm
PCB color: White
Conn. type: Stripped wire, 2 sides
ART. NR.
COLOR TEMP. (CCT)
127-069
2700K
 Warm White
COLOR LED
1200
LUMEN P/M
127-073
4000K
 Natural White
1440
127-074
7000K
 Cold White
1440
FLEX TAPE 24V | 240 LED | SMD 3528
DOUBLE ROW | IP20
INPUT
LED’S P/M
24V
240
DIMMABLE
-
+
CUT. DIST.
IP RATE
CERTIFICATE
50MM
WARRANTY
CERTIFICATE
3
years
IP20
5M
Single color indoor Flex Tape with double row of led’s
With 3M adhesive tape on the back
Input: 24 Volt
Power: 19,2 Watt p/m
LED qty: 2 x 120 p/m
LED type: SMD 3528
Dimmable: Yes
Beam: 120°
CRI: >90
IP rate: IP20
ART. NR.
COLOR TEMP. (CCT)
127-068
2700K
LED distance: 8,3 mm
Cutting distance: 50 mm
Max. to connect: 5 m
Length: 5 m
Width: 15 mm
Height: 2 mm
PCB color: White
Conn. type: Stripped wire, 2 sides
COLOR LED
 Warm White
LUMEN P/M
1200
FLEX TAPE 24V | 120 LED | SMD 5630 | IP20
Single color Flex Tape 2700K with double row of LED’s
With 3M adhesive tape on the back
Input: 24 Volt
Power: 33,6 Watt p/m
LED qty: 2 x 60 p/m
LED type: SMD 5630
Dimmable: Yes
Beam: 120°
CRI: >90
IP rate: IP20
144
ART. NR.
COLOR TEMP. (CCT)
127-090
2700K
LED distance: 16,7 mm
Cutting distance: 50 mm
Max. to connect: 5 m
Length: 5 m
Width: 15 mm
Height: 1,2 mm
PCB color: White
Conn. type: Stripped wire, 2 sides
COLOR LED
 Warm White
LUMEN P/M
3570
INPUT
LED’S P/M
24V
120
DIMMABLE
-
+
CUT. DIST.
IP RATE
IP20
50MM
5M
CERTIFICATE
WARRANTY
3
years
CERTIFICATE
Single color
FLEX TAPE 24V CONSTANT CURRENT | 60 LED
SMD 2835 | IP20
INPUT
LED’S P/M
24V
60
DIMMABLE
-
+
CUT. DIST.
| Flex tape
IP RATE
CERTIFICATE
100MM
WARRANTY
CERTIFICATE
3
years
IP20
20M
Single Color Flex Tape for indoor use - for lengths up to 20m
Power from 1 side | with 3M adhesive tape on the back
Input: 24 Volt
Power: 8,5 Watt p/m
LED qty: 60 p/m
LED type: SMD 2835
Dimmable: Yes
Beam: 120°
CRI: >90
IP rate: IP20
ARTICLE NR.
COLOR TEMP. (CCT)
127-111
3000K
LED distance: 16,7 mm
Cutting distance: 100 mm
Max. to connect: 20 m
Length: 20 m
Width: 12 mm
Height: 1,2 mm
PCB color: White
Connection type: Stripped wire
COLOR LED
 Warm White
LUMEN P/M
1020
FLEX TAPE 24V | 120 LED | SMD 335 | VERTICAL
LIGHT OUTPUT | IP20
INPUT
LED’S P/M
24V
120
DIMMABLE
-
+
IP RATE
CUT. DIST.
CERTIFICATE
50MM
WARRANTY
CERTIFICATE
3
years
IP20
5M
Single color Flex Tape 2700K for indoor use with vertical light output.
With 3M adhesive tape on the back
Input: 24 Volt
Power: 9,6 Watt p/m
LED qty: 120 p/m
LED type: SMD 335
Dimmable: Yes
Beam: 120°
CRI: >90
IP rate: IP20
ART. NR.
COLOR TEMP. (CCT)
127-062
2700K
LED distance: 8,3 mm
Cutting distance: 50 mm
Max. to connect: 5 m
Length: 5 m
Width: 8 mm
Height: 1,2 mm
PCB color: White
Conn. type: Stripped wire, 2 sides
COLOR LED
 Warm White
LUMEN P/M
600
FLEX TAPE 24V | 120 LED | SMD 3528 | IP65
Single color Flex Tape for outdoor use in 3 white colors
INPUT
LED’S P/M
24V
120
DIMMABLE
-
+
CUT. DIST.
IP RATE
IP65
50MM
5M
CERTIFICATE
WARRANTY
CERTIFICATE
3
years
With 3M adhesive tape on the back
Input: 24 Volt
Power: 9,6 Watt p/m
LED qty: 120 p/m
LED type: SMD 3528
Dimmable: Yes
Beam: 120°
CRI: >90
IP rate: IP65
ART. NR.
COLOR TEMP. (CCT)
LED distance: 8,3 mm
Cutting distance: 50 mm
Max. to connect: 10 m
Length: 5 m
Width: 8 mm
Height: 2,3 mm
PCB color: White
Conn. type: Stripped wire, 2 sides
COLOR LED
LUMEN P/M
127-059
2700K
 Warm White
600
127-058
3000K
 Warm White
600
127-041
6500K
 Cold White
720
WWW.TRONIXLIGHTING.COM
145
Flex tape |
Single color
FLEX TAPE 12V | 60 LED | SMD 3528 | IP67
INPUT
LED’S P/M
24V
60
DIMMABLE
-
Single color Flex Tape 3000K for outdoor use
+
CUT. DIST.
IP RATE
CERTIFICATE
WARRANTY
CERTIFICATE
3
years
IP67
50MM
5M
With 3M adhesive tape on the back
Input: 12 Volt
Power: 4,8 Watt p/m
LED qty: 60 p/m
LED type: SMD 3528
Dimmable: Yes
Beam: 120°
CRI: >90
IP rate: IP67
ART. NR.
COLOR TEMP. (CCT)
127-039
3000K
ART. NR.
ACCESSORIES
127-289
End cap
LED distance: 16,7 mm
Cutting distance: 50 mm
Max. to connect: 5 m
Length: 5 m
Width: 10 mm
Height: 4 mm
PCB color: White
Conn. type: Stripped wire, 2 sides
COLOR LED
 Warm White
LUMEN P/M
300
FLEX TAPE 24V | 60 LED | SMD 3528 | IP68
INPUT
LED’S P/M
24V
60
Single color Flex Tape 3500K for outdoor use
DIMMABLE
-
+
CUT. DIST.
IP RATE
CERTIFICATE
WARRANTY
CERTIFICATE
3
years
IP68
100MM
5M
With 3M adhesive tape on the back
Input: 24 Volt
Power: 4,8 Watt p/m
LED qty: 60 p/m
LED type: SMD 3528
Dimmable: Yes
Beam: 120°
CRI: >90
IP rate: IP68
ART. NR.
COLOR TEMP. (CCT)
127-078
3500K
ART. NR.
ACCESSORIES
127-289
End cap
LED distance: 16,7 mm
Cutting distance: 100 mm
Max. to connect: 5 m
Length: 5 m
Width: 10 mm
Height: 4 mm
PCB color: White
Conn. type: Stripped wire, 2 sides
COLOR LED
 Warm White
LUMEN P/M
300
FLEX TAPE 24V | 120 LED | SMD 3528 | IP68
Single color Flex Tape 3000K for outdoor use
With 3M adhesive tape on the back
Input: 24 Volt
Power: 9,6 Watt p/m
LED qty: 120 p/m
LED type: SMD 3528
Dimmable: Yes
Beam: 120°
CRI: >90
IP rate: IP68
146
ART. NR.
COLOR TEMP. (CCT)
127-088
3000K
ART. NR.
ACCESSORIES
127-289
End cap
LED distance: 8,3 mm
Cutting distance: 50 mm
Max. to connect: 5 m
Length: 5 m
Width: 10 mm
Height: 4 mm
PCB color: White
Conn. type: Stripped wire, 2 sides
COLOR LED
 Warm White
LUMEN P/M
600
INPUT
LED’S P/M
24V
120
DIMMABLE
-
+
CUT. DIST.
IP RATE
IP68
50MM
5M
CERTIFICATE
WARRANTY
3
years
CERTIFICATE
Single color
FLEX TAPE 24V | 36 LED | SMD 5050 | IP68
INPUT
LED’S P/M
24V
36
Single color Flex Tape 3500K for outdoor use
Input: 24 Volt
Power: 8,6 Watt p/m
LED qty: 36 p/m
LED type: SMD 5050
Dimmable: Yes
Beam: 120°
CRI: >90
IP rate: IP68
LED distance: 27,8 mm
ART. NR.
COLOR TEMP. (CCT)
127-098
3500K
ART. NR.
ACCESSORIES
127-288
End cap
COLOR LED
 Warm White
ART. NR.
COLOR TEMP. (CCT)
3000K
ART. NR.
ACCESSORIES
127-288
End cap
CUT. DIST.
IP RATE
CERTIFICATE
WARRANTY
CERTIFICATE
3
years
IP68
167MM
5M
LUMEN P/M
650
INPUT
LED’S P/M
24V
60
Single color Flex Tape 3000K for outdoor use
127-108
+
Cutting distance: 167 mm
Max. to connect: 5 m
Length: 5 m
Width: 12 mm
Height: 4 mm
PCB color: White
Conn. type: Stripped wire, 2 sides
FLEX TAPE 24V | 60 LED | SMD 5050 | IP68
Input: 24 Volt
Power: 14,4 Watt p/m
LED qty: 60 p/m
LED type: SMD 5050
Dimmable: Yes
Beam: 120°
CRI: >90
IP rate: IP68
DIMMABLE
-
| Flex tape
DIMMABLE
-
+
CUT. DIST.
IP RATE
CERTIFICATE
100MM
WARRANTY
CERTIFICATE
3
years
IP68
5M
LED distance: 16,7 mm
Cutting distance: 100 mm
Max. to connect: 5 m
Length: 5 m
Width: 14 mm
Height: 5 mm
PCB color: White
Conn. type: Stripped wire, 2 sides
COLOR LED
 Warm White
LUMEN P/M
1080
FLEX TAPE | 12V | 120 LED | SMD 3528
ADJUSTABLE 2500K~5000K | IP20
INPUT
LED’S P/M
12V
120
DIMMABLE
-
+
CUT. DIST.
IP RATE
IP20
50MM
5M
CERTIFICATE
CERTIFICATE
CERTIFICATE
WARRANTY
CERTIFICATE
3
years
Dual color Flex Tape with adjustable color temperature from 2500K~5000K
With 3M adhesive tape on the back
Input: 12 Volt
Power: 9,6 Watt p/m
LED qty: 120 p/m
LED type: SMD 3528
Dimmable: Yes
Beam: 120°
CRI: >90
IP rate: IP20
ART. NR.
COLOR TEMP. (CCT)
127-063
Adjustable 2500K ~ 5000K
LED distance: 8,3 mm
Cutting distance: 50 mm
Max. to connect: 5 m
Length: 5 m
Width: 10 mm
Height: 2 mm
PCB color: White
Conn. type: Stripped wire, 2 sides
COLOR LED
 Warm White ~
 Cold White
LUMEN P/M
600~700
CONTROLLER FOR ART. NR. 127-063
INPUT
INPUT
IP RATE
12V
24V
IP20
Matching controller for CCT-adjustable Flex Tape art. 127-063
Art. nr.: 214-110
Input: 12/24 Volt DC
Output power:
12V < 96W, 24V < 192W
Output current:
4 Ampère (each channel)
Current: 8 Ampère
IP rate: IP20
Length: 86 mm
Width: 86 mm
Depth: 37 mm
WWW.TRONIXLIGHTING.COM
147
Flex tape |
RGB
FLEX TAPE 12V | 30 LED | SMD 5050 | RGB | IP20
INPUT
LED’S P/M
12V
30
RGB Flex Tape for indoor use - with 3M adhesive tape on the back
Input: 12 Volt
Power: 7,2 Watt p/m
LED qty: 30 p/m
LED type: SMD 5050
Dimmable: Yes
Beam: 120°
CRI: >90
IP rate: IP20
LED distance: 33,4 mm
ART. NR.
COLOR TEMP. (CCT)
COLOR LED
LUMEN P/M
n/a
RGB
n/a
FLEX TAPE 12V | 60 LED | SMD 5050 | RGB | IP20
INPUT
LED’S P/M
12V
60
RGB Flex Tape for indoor use - with 3M adhesive tape on the back
ART. NR.
COLOR TEMP. (CCT)
COLOR LED
LUMEN P/M
n/a
RGB
n/a
FLEX TAPE 24V | 60 LED | SMD 5050 | RGB | IP20
RGB Flex Tape for indoor use - with 3M adhesive tape on the back
148
Cutting distance: 100 mm
Max. to connect: 10 m
Length: 5 m
Width: 10 mm
Height: 2 mm
PCB color: White
Conn. type: Stripped wire, 2 sides
ART. NR.
COLOR TEMP. (CCT)
COLOR LED
LUMEN P/M
127-101
n/a
RGB
n/a
ART. NR.
ACCESSORIES
127-282
Power cable RGB | IP20
127-203
Splice connector | IP20
CUT. DIST.
IP RATE
CERTIFICATE
WARRANTY
CERTIFICATE
3
years
IP20
100MM
5M
DIMMABLE
-
+
CUT. DIST.
IP RATE
CERTIFICATE
WARRANTY
CERTIFICATE
3
years
IP20
50MM
5M
Cutting distance: 50 mm
Max. to connect: 5 m
Length: 5 m
Width: 8 mm
Height: 2 mm
PCB color: White
Conn. type: Stripped wire, 2 sides
127-102
Input: 24 Volt
Power: 14,4 Watt p/m
LED qty: 60 p/m
LED type: SMD 5050
Dimmable: Yes
Beam: 120°
CRI: >90
IP rate: IP20
LED distance: 16,7 mm
+
Cutting distance: 100 mm
Max. to connect: 5 m
Length: 5 m
Width: 10 mm
Height: 2 mm
PCB color: White
Conn. type: Stripped wire, 2 sides
127-000
Input: 12 Volt
Power: 14,4 Watt p/m
LED qty: 60 p/m
LED type: SMD 5050
Dimmable: Yes
Beam: 120°
CRI: >90
IP rate: IP20
LED distance: 16,7 mm
DIMMABLE
-
INPUT
LED’S P/M
24V
60
DIMMABLE
-
+
CUT. DIST.
IP RATE
IP20
100MM
5M
CERTIFICATE
WARRANTY
3
years
CERTIFICATE
RGB
FLEX TAPE 24V | 60 LED | SMD 5050 | RGB +
2700K | IP20
INPUT
LED’S P/M
24V
60
DIMMABLE
-
+
CUT. DIST.
| Flex tape
IP RATE
CERTIFICATE
167MM
WARRANTY
CERTIFICATE
3
years
IP20
5M
RGB + Warm White Flex Tape for indoor use
With 3M adhesive tape on the back
Input: 24 Volt
Power: 14,4 Watt p/m
LED qty: 60 p/m
LED type: SMD 5050
Dimmable: Yes
Beam: 120°
CRI: >90
IP rate: IP20
ART. NR.
COLOR TEMP. (CCT)
127-064
2700K
LED distance: 16,7 mm
Cutting distance: 167 mm
Max. to connect: 5 m
Length: 5 m
Width: 10 mm
Height: 2 mm
PCB color: White
Conn. type: Stripped wire, 2 sides
COLOR LED
RGB + Warm
 White
LUMEN P/M
1200
FLEX TAPE 24V | 60 LED | SMD 5050
RGB + 2700K | 4 IN 1 | IP20
INPUT
LED’S P/M
24V
60
DIMMABLE
-
+
CUT. DIST.
IP RATE
CERTIFICATE
100MM
WARRANTY
CERTIFICATE
3
years
IP20
5M
RGB + Warm White (4 in 1 led) Flex Tape for indoor use
With 3M adhesive tape on the back
Input: 24 Volt
Power: 19,2 Watt p/m
LED qty: 60 p/m
LED type: SMD 5050
Dimmable: Yes
Beam: 120°
CRI: >90
IP rate: IP20
ART. NR.
COLOR TEMP. (CCT)
127-075
2700K
ART. NR.
ACCESSORIES
127-286
Power cable
127-287
Splice connector
LED distance: 16,7 mm
Cutting distance: 100 mm
Max. to connect: 10 m
Length: 5 m
Width: 12 mm
Height: 2 mm
PCB color: White
Conn. type: Stripped wire, 2 sides
COLOR LED
RGB + Warm
 White 4 in 1
LUMEN P/M
1600
FLEX TAPE 24V | 60 LED | SMD 5050 | RGB | IP65
RGB Flex Tape for outdoor use - with 3M adhesive tape on the back
Input: 24 Volt
Power: 14,4 Watt p/m
LED qty: 60 p/m
LED type: SMD 5050
Dimmable: Yes
Beam: 120°
CRI: >90
IP rate: IP65
LED distance: 16,7 mm
INPUT
LED’S P/M
24V
60
DIMMABLE
-
+
CUT. DIST.
IP RATE
IP65
100MM
5M
CERTIFICATE
WARRANTY
CERTIFICATE
3
years
Cutting distance: 100 mm
Max. to connect: 5 m
Length: 5 m
Width: 10 mm
Height: 2,3 mm
PCB color: White
Conn. type: Stripped wire, 2 sides
ART. NR.
COLOR TEMP. (CCT)
COLOR LED
LUMEN P/M
127-010
n/a
RGB
n/a
WWW.TRONIXLIGHTING.COM
149
Flex tape |
RGB
FLEX TAPE 24V | 36 LED | SMD 5050 | RGB | IP68
INPUT
LED’S P/M
24V
36
RGB Flex Tape for outdoor use - with 3M adhesive tape on the back
Input: 24 Volt
Power: 9 Watt p/m
LED qty: 36 p/m
LED type: SMD 5050
Dimmable: Yes
Beam: 120°
CRI: >90
IP rate: IP68
ART. NR.
COLOR TEMP. (CCT)
COLOR LED
LUMEN P/M
n/a
RGB
n/a
ART. NR.
ACCESSORIES
End cap
FLEX TAPE 24V | 60 LED | SMD 5050 | IP68
RGB Flex Tape for outdoor use - with 3M adhesive tape on the back
Input: 24 Volt
Power: 14,4 Watt p/m
LED qty: 60 p/m
LED type: SMD 5050
Dimmable: Yes
Beam: 120°
CRI: >90
IP rate: IP68
150
+
CUT. DIST.
IP RATE
CERTIFICATE
WARRANTY
CERTIFICATE
3
years
IP68
167MM
5M
LED distance: 27,8 mm
Cutting distance: 167 mm
Max. to connect: 10 m
Length: 5 m
Width: 12 mm
Height: 4 mm
PCB color: White
Conn. type: Stripped wire, 2 sides
127-072
127-288
DIMMABLE
-
LED distance: 16,7 mm
Cutting distance: 100 mm
Max. to connect: 5 m
Length: 5 m
Width: 12 mm
Height: 4 mm
PCB color: White
Conn. type: Stripped wire, 2 sides
ART. NR.
COLOR TEMP. (CCT)
COLOR LED
LUMEN P/M
127-070
n/a
RGB
n/a
ART. NR.
ACCESSORIES
127-288
End cap
INPUT
LED’S P/M
24V
60
DIMMABLE
-
+
CUT. DIST.
IP RATE
IP68
100MM
5M
CERTIFICATE
WARRANTY
3
years
CERTIFICATE
WWW.TRONIXLIGHTING.COM
151
152
U-Profiles
U-PROFILE | FLAT | 17 X 8 MM | 2M OR 3M
CERTIFICATE
ART. NR.
COVER
LENGTH
127-225
Matte
2 meter
127-525
Matte
3 meter
127-273
Semi-Clear
2 meter
127-229
Clear
2 meter
ART. NR.
ACCESSORIES
127-232
End cap set
127-233
Clip
MIN.ORDER
QTY.
10
Flat aluminium profile with standard finishing and matte, semi-clear or
clear cover
Material: Anodized Aluminium
Finishing: Standard (non-painted)
Cover: PMMA Matte, Semi-clear, Clear
| Flex tape
Width: 17,1 mm
Height: 8 mm
Max. flex tape width: 12,2 mm
Matte
Semiclear
Clear
U-PROFILE | FLAT | 20 X 20 MM | 2M OR 3M
CERTIFICATE
10
Flat aluminium profile with standard finishing and matte cover
Material: Anodized Aluminium
Finishing: Standard (non-painted)
Cover: PMMA Matte
MIN.ORDER
QTY.
Width: 19,7 mm
Height: 20 mm
Max. flex tape width: 16,9 mm
Matte
ART. NR.
COVER
LENGTH
127-228
Matte
2 meter
127-528
Matte
3 meter
ART. NR.
ACCESSORIES
127-230
End cap set
U-PROFILE | FLAT | 35 X 35 MM | 2M OR 3M
Flat aluminium profile with standard or white finishing and matte cover
Material: Anodized Aluminium
Finishing: Standard (non-painted)
Cover: PMMA Matte
MIN.ORDER
QTY.
10
Width: 35,2 mm
Height: 34,9 mm
Max. flex tape width: 32,2 mm
ART. NR.
COVER
LENGTH
127-243
Matte
2 meter
 Standard aluminium
127-543
Matte
3 meter
 Standard aluminium
127-244
Matte
2 meter
 White
127-544
Matte
3 meter
 White
ART. NR.
CERTIFICATE
FINISHING
Matte
ACCESSORIES
127-343
 End cap set - Aluminium
127-344
 End cap set - White
127-466
Hang-up Cable
WWW.TRONIXLIGHTING.COM
153
Flex tape |
U-Profiles
U-PROFILE | FLAT | 10 X 13 MM | 2M
CERTIFICATE
10
Flat aluminium profile with standard finishing and matte cover
Material: Anodized Aluminium
Finishing: Standard (non-painted)
Cover: PC Matte
MIN.ORDER
QTY.
Width: 10 mm
Height: 13 mm
Max. flex tape width: 8,4 mm
Matte
ART. NR.
COVER
LENGTH
127-249
Matte
2 meter
ART. NR.
ACCESSORIES
127-349
End cap set
127-449
Clip
U-PROFILE | FLAT | 43 X 35 MM | 2M
CERTIFICATE
10
Flat aluminium profile with standard finishing and matte cover
Material: Anodized Aluminium
Finishing: Standard (non-painted)
Cover: PMMA Matte
MIN.ORDER
QTY.
Width: 42,5 mm
Height: 34,9 mm
Max. flex tape width: 32,5 mm
Matte
ART. NR.
COVER
LENGTH
127-253
Matte
2 meter
ART. NR.
ACCESSORIES
127-353
End cap set
U-PROFILE | FLAT | 17 X 15 MM | 2M OR 3M
CERTIFICATE
10
Flat aluminium profile with standard finishing and matte cover
Material: Anodized Aluminium
Finishing: Standard (non-painted)
Cover: PMMA Matte
ART. NR.
COVER
LENGTH
127-261
Matte
2 meter
127-561
Matte
3 meter
ART. NR.
ACCESSORIES
127-361
End cap set
127-233
Clip
Width: 17,1 mm
Height: 15,3 mm
Max. flex tape width: 12,2 mm
Matte
U-PROFILE | FLAT | 24 X 15 MM | 2M OR 3M
Flat aluminium profile with standard finishing and matte cover.
Material: Anodized Aluminium
Finishing: Standard (non-painted)
Cover: PMMA Matte
154
ART. NR.
COVER
LENGTH
127-262
Matte
2 meter
127-562
Matte
3 meter
ART. NR.
ACCESSORIES
127-343
End cap set
127-462
Clip
MIN.ORDER
QTY.
CERTIFICATE
MIN.ORDER
QTY.
10
Width: 23,5 mm
Height: 15 mm
Max. flex tape width: 20,2 mm
Matte
U-Profiles
U-PROFILE | ROUND | 17 X 20 MM | 2M
CERTIFICATE
MIN.ORDER
QTY.
10
Aluminium profile with standard finishing and matte or clear curved cover
Material: Anodized Aluminium
Finishing: Standard (non-painted)
Cover: PMMA Matte or Clear
| Flex tape
Width: 17,1 mm
Height: 20 mm
Max. flex tape width: 12,2 mm
Matte
ART. NR.
COVER
LENGTH
BEAM
127-240
Matte
2 meter
120°
127-241
Clear
2 meter
30°
ART. NR.
ACCESSORIES
127-340
End cap set
Clear
U-PROFILE | ROUND | 20 X 20 MM | 2M
CERTIFICATE
10
Aluminium profile with standard finishing and matte curved cover
Material: Anodized Aluminium
Finishing: Standard (non-painted)
Cover: PMMA Matte
MIN.ORDER
QTY.
Width: 19,7 mm
Height: 20,2 mm
Max. flex tape width: 16,9 mm
Matte
ART. NR.
COVER
LENGTH
127-242
Matte
2 meter
ART. NR.
ACCESSORIES
127-342
End cap set
U-PROFILE | ROUND | 24 X 35 MM | 2M
CERTIFICATE
Aluminium profile with standard finishing and matte curved cover
Material: Anodized Aluminium
Finishing: Standard (non-painted)
Cover: PMMA Matte
MIN.ORDER
QTY.
10
Width: 23,5 mm
Height: 34,5 mm
Max. flex tape width: 20,4 mm
Matte
ART. NR.
COVER
LENGTH
127-248
Matte
2 meter
ART. NR.
ACCESSORIES
127-348
End cap set
Tronix Flex Tape
Flexible LED strips for indoor & outdoor applications.
WWW.TRONIXLIGHTING.COM
155
Flex tape |
L-Profiles
L-PROFILE | 19 X 19 MM | 45° | 2M OR 3M
CERTIFICATE
10
Aluminium 45° angle profile with standard finishing and matte or clear cover.
Material: Anodized Aluminium
Finishing: Standard (non-painted)
Cover: PMMA Matte, Clear
ART. NR.
COVER
LENGTH
127-226
Matte
2 meter
127-526
Matte
3 meter
127-227
Clear
2 meter
ART. NR.
ACCESSORIES
127-234
End cap set
127-235
Clip
Width: 18,5 mm
Height: 18,5 mm
Max. flex tape width: 12,2 mm
Matte
Clear
L-PROFILE | 16 X 16 MM | 45° | 2M
CERTIFICATE
MIN.ORDER
QTY.
10
Aluminium 45° angle profile with standard finishing and matte or semiclear cover.
Material: Anodized Aluminium
Finishing: Standard (non-painted)
Cover: PMMA Matte, Clear
MIN.ORDER
QTY.
Width: 16 mm
Height: 16 mm
Max. flex tape width: 10 mm
Matte
ART. NR.
COVER
LENGTH
127-269
Matte
2 meter
127-274
Semi-clear
2 meter
ART. NR.
ACCESSORIES
127-369
End cap set
127-469
Clip
Semiclear
L-PROFILE | 30 X 30 MM | 45° | 2M
Auminium 45° angle profile with standard finishing and matte or clear cover.
Material: Anodized Aluminium
Finishing: Standard (non-painted)
Cover: PMMA Matte, Clear
156
ART. NR.
COVER
LENGTH
127-267
Matte
2 meter
127-268
Clear
2 meter
ART. NR.
ACCESSORIES
127-367
End cap set
127-467
Clip
CERTIFICATE
MIN.ORDER
QTY.
10
Width: 30 mm
Height: 30 mm
Max. flex tape width: 20,2 mm
Matte
Clear
T-Profiles
T-PROFILE | 23 X 8 MM | RECESSED | 2M
CERTIFICATE
MIN.ORDER
QTY.
10
Recessed mounting profile with standard finishing and matte cover.
Material: Anodized Aluminium
Finishing: Standard (non-painted)
Cover: PMMA Matte
Width: 23,2 mm
| Flex tape
Height: 8 mm
Mounting width: 17,1 mm
Mounting depth: 6,2 mm
Max. flex tape width: 12,2 mm
Matte
ART. NR.
COVER
LENGTH
127-224
Matte
2 meter
ART. NR.
ACCESSORIES
127-231
End cap set
T-PROFILE | 36 X 28 MM | RECESSED | 2M
CERTIFICATE
10
Recessed mounting profile with standard finishing and matte cover.
Material: Anodized Aluminium
Finishing: Standard (non-painted)
Cover: PMMA Matte
Width: 36 mm
ART. NR.
COVER
LENGTH
127-246
Matte
2 meter
ART. NR.
ACCESSORIES
127-346
End cap set
127-446
Springs
Height: 28 mm
Mounting width: 23,1 mm
Mounting depth: 25,5 mm
Max. flex tape width: 18,6 mm
T-PROFILE | 23 X 15 MM | RECESSED | 2M
Matte
CERTIFICATE
ART. NR.
COVER
LENGTH
127-260
Matte
2 meter
ART. NR.
ACCESSORIES
127-360
End cap set
Height: 15,3 mm
Mounting width: 17,1 mm
Mounting depth: 12,8 mm
Max. flex tape width: 12,2 mm
T-PROFILE | 27 X 11 MM | RECESSED | 2M
Recessed mounting profile with standard finishing and matte extra
strong cover.
Material: Anodized Aluminium
Finishing: Standard (non-painted)
Cover: PMMA Matte
Width: 27,06 mm
ART. NR.
COVER
LENGTH
127-275
Matte
2 meter
ART. NR.
ACCESSORIES
127-375
End cap set
127-235
Clip
MIN.ORDER
QTY.
10
Recessed mounting profile with standard finishing and matte cover.
Material: Anodized Aluminium
Finishing: Standard (non-painted)
Cover: PMMA Matte
Width: 23,2 mm
MIN.ORDER
QTY.
Height: 11 mm
Mounting width: 21,4 mm
Mounting depth: 9,7 mm
Max. flex tape width: 12,2 mm
Matte
CERTIFICATE
MIN.ORDER
QTY.
10
Matte
WWW.TRONIXLIGHTING.COM
157
Flex tape |
Specials
STAIRS PROFILE | 48 X 27 MM | 2M
CERTIFICATE
10
Aluminium profile for stairs with standard finishing and matte cover.
Material: Anodized Aluminium
Finishing: Standard (non-painted)
Cover: PMMA Matte
MIN.ORDER
QTY.
Width: 48 mm
Height: 26,7 mm
Max. flex tape width: 12,3 mm
Matte
ART. NR.
COVER
LENGTH
127-245
Matte
2 meter
ART. NR.
ACCESSORIES
127-345
End cap set
STAIRS PROFILE | 80 X 50 MM | 2M
CERTIFICATE
10
Aluminium wall profile half round with standard finishing and matte cover.
Material: Anodized Aluminium
Finishing: Standard (non-painted)
Cover: PMMA Matte
MIN.ORDER
QTY.
Width: 80 mm
Height: 50 mm
Max. flex tape width: 14 mm
Matte
ART. NR.
COVER
LENGTH
127-264
Matte
2 meter
ART. NR.
ACCESSORIES
127-364
End cap set
CEILING PROFILE | 45 X 38 MM | 2M
CERTIFICATE
10
Aluminium profile for ceilings with standard finishing and matte cover.
Material: Anodized Aluminium
Finishing: Standard (non-painted)
Cover: PMMA Matte
MIN.ORDER
QTY.
Width: 37,7 mm
Height: 45 mm
Max. flex tape width: 20,4 mm
Matte
ART. NR.
COVER
LENGTH
127-255
Matte
2 meter
ART. NR.
ACCESSORIES
127-355
End cap set
THRESHOLD PROFILE | 57 X 10 MM | 2M
Aluminium profile for thresholds with standard finishing and matte cover.
Material: Anodized Aluminium
Finishing: Standard (non-painted)
Cover: PMMA Matte
CERTIFICATE
MIN.ORDER
QTY.
10
Width: 56,7 mm
Height: 9,8 mm
Max. flex tape width: 12,3 mm
Matte
158
ART. NR.
COVER
LENGTH
127-256
Matte
2 meter
ART. NR.
ACCESSORIES
127-356
End cap set
WALL PROFILE | 43 X 18 MM | 2M
CERTIFICATE
10
Aluminium wall profile half round with standard finishing and matte cover.
Material: Anodized Aluminium
Finishing: Standard (non-painted)
Cover: PMMA Matte
MIN.ORDER
QTY.
Width: 43,21 mm
Height: 17,73 mm
Max. flex tape width: 12
Matte
ART. NR.
COVER
LENGTH
127-263
Matte
2 meter
ART. NR.
ACCESSORIES
127-363
End cap set
WALL PROFILE | RECESSED | 78 X 26 MM | 2M
CERTIFICATE
10
Aluminium wall profile for recessed mounting with standard finishing and
matte cover.
Material: Anodized Aluminium
Finishing: Standard (non-painted)
Cover: PMMA Matte
ART. NR.
COVER
LENGTH
127-265
Matte
2 meter
ART. NR.
ACCESSORIES
127-365
End cap set
Width: 78 mm
Height: 26,2 mm
Max. flex tape width: 12,3 mm
HANG-UP PROFILE | ROUND | Ø 21 MM | 2M
Matte
CERTIFICATE
ART. NR.
COVER
LENGTH
127-266
Matte
2 meter
ART. NR.
ACCESSORIES
127-366
End cap set
127-466
Hang-up cable 2,5 meter
127-566
Mounting clip
Diameter: 20,8 mm
Max. flex tape width: 12,2 mm
Matte
WALL PROFILE | UP & DOWN | 49 X 18 MM | 2M
Aluminium profile for hang-up or wall mounting.
Material: Anodized Aluminium
Finishing: Standard (non-painted)
Cover: PMMA Matte
MIN.ORDER
QTY.
10
Aluminium profile for hang-up or wall mounting.
Material: Anodized Aluminium
Finishing: Standard (non-painted)
Cover: PMMA Matte
MIN.ORDER
QTY.
CERTIFICATE
MIN.ORDER
QTY.
10
Width: 48,5 mm
Height: 17,7 mm
Max. flex tape width: 12,2 mm
Matte
ART. NR.
COVER
LENGTH
127-276
Matte
2 meter
ART. NR.
ACCESSORIES
127-376
End cap set
127-476
Mounting clip
WWW.TRONIXLIGHTING.COM
159
Flex tape |
UV20/UV40
FLEX TAPE CHANNEL | UV20
ART. NR.
CHANNEL
WIDHT
DEPTH
076-100
UV20 | Aluminium channel | 2 meter | White
20 mm
50 mm
076-102
UV20 | Aluminium channel | 6 meter | Grey
20 mm
50 mm
076-103
UV20 | Aluminium channel | 6 meter | White
20 mm
50 mm
ART. NR.
ACCESSORIES
076-104
UV20 | 2pcs end cap | Grey
076-117
UV20 | 2pcs end cap | White
076-105
UV20 | Polycarbonate cover 2 meter
076-106
UV20 | Polycarbonate cover 3 meter
FLEX TAPE CHANNEL | UV40
160
ART. NR.
CHANNEL
WIDHT
DEPTH
076-110
UV40 | Aluminium channel | 2 meter | White
40 mm
50 mm
ART. NR.
ACCESSORIES
076-115
UV40 | Polycarbonate cover 2 meter
076-116
UV40 | Polycarbonate cover 3 meter
076-118
UV40 | 2pcs end cap | White
Accessoiries
FLEXTAPE WIRE | 2 CORE | PRO METER
FLEXTAPE WIRE | 3 CORE | PRO METER
ART. NR.
ART. NR.
127-250
127-251
FLEXTAPE WIRE | 4 CORE | PRO METER
FLEXTAPE WIRE | 5 CORE | PRO METER
ART. NR.
ART. NR.
127-252
127-272
3M TAPE RED | 33,33 METER ROLL
EXTENSION CABLE |75 CM | 2 PCS.
ART. NR.
ART. NR.
127-270
120-101
EXTENSION CABLE | 150 CM | 2 PCS
WIRE 20CM | DC MALE | 10-PACK
ART. NR.
ART. NR.
120-104
120-107
WIRE 20CM | DC FEMALE | 10PCS PACK
FLEX TAPE | CONNECTOR SET | IP20 | RGB
ART. NR.
ART. NR.
120-108
127-200
POWER CABLE
Art. nr. 127-286
| Flex tape
SPLICE CONNECTORS
Art. nr. 127-287
END CAPS
HANG-UP CABLES
Art. nr. 127-288
Art. nr. 127-289
Art. nr. 127-466
END CAP SETS
Art. nr. 127-230
Art. nr. 127-231
Art. nr. 127-232
Art. nr. 127-234
Art. nr. 127-340
Art. nr. 127-342
Art. nr. 127-343
Art. nr. 127-344
Art. nr. 127-345
Art. nr. 127-346
Art. nr. 127-348
Art. nr. 127-349
Art. nr. 127-353
Art. nr. 127-355
Art. nr. 127-356
Art. nr. 127-360
Art. nr. 127-361
Art. nr. 127-363
Art. nr. 127-364
Art. nr. 127-365
Art. nr. 127-366
Art. nr. 127-367
Art. nr. 127-369
Art. nr. 127-376
Art. nr. 127-235
Art. nr. 127-446
Art. nr. 127-449
Art. nr. 127-467
Art. nr. 127-469
CLIPS
Art. nr. 127-233
WWW.TRONIXLIGHTING.COM
161
Neon Flex
High quality Neon Rope Light for
spectacular outdoor lighting effects
162
Neon Flex
Neon Flex Pro
29mm
Available in White, Warm White, Blue, Green, Red, Amber, Yellow (color Jacket), RGB and Digital RGB
Neon Flex Flat
21mm
Available in White, Warm White and RGB
11.5mm
Neon Flex Mini Flat
18mm
Available in White and Warm White
9mm
Neon Flex Up & Down
Available in White and Warm White
WWW.TRONIXLIGHTING.COM
163
Neon Flex Flat |
PRO
IK 08
PROTECTION
Long lifetime with SMD LED 5050 and PCB structure
IP 68
PROTECTION
SALTWATER
RESISTANT
SOLVENTS
RESISTANT
UV RESISTANT
FLAME
RESISTANT
BENDING
DIAMETER
D:12CM
BEAM ANGLE
˚
160
DIMMABLE
-
CERTIFICATE
CERTIFICATE
WARRANTY
CERTIFICATE
3
years
+
Input: 24 Volt DC
LED type: SMD5050
Dimmable: Yes
IP rate: IP68
Length: 10/20/30 meter
Width: 11,5 mm
Height: 29 mm
Connection type: Stripped wire
Power Cable: Included (3 meter)
NEON FLEX PRO | SINGLE COLOR
10M ROLL - ART. NR.
20M ROLL- ART. NR.
MAX. TO CONNECT
POWER
 White | 5700K
NEON FLEX PRO | SINGLE COLOR
110-041
110-141
20 meter
12 Watt p/m
60
> 380 Lm p/m
10 cm
 Warm White | 3000K
110-048
110-148
20 meter
12 Watt p/m
60
> 380 Lm p/m
10 cm
 Blue
110-042
110-142
20 meter
12 Watt p/m
60
> 40 Lm p/m
10 cm
 Green
110-043
110-143
20 meter
12 Watt p/m
60
> 280 Lm p/m
10 cm
 Red
110-044
110-144
20 meter
6,5 Watt p/m
60
> 120 Lm p/m
16,7 cm
 Amber
110-045
110-145
20 meter
6,5 Watt p/m
60
> 90 Lm p/m
16,7 cm
 Yellow Color Jacket
n/a
110-245
20 meter
12 Watt p/m
60
> 210 Lm p/m
10 cm
ACCESSORIES - SINGLE COLOR
ART. NR.
Power Cable Front 3 Meter
115-050
Power Cable Back 3 Meter
115-052
End Cap
115-059
Splice Connector (IP20)
115-053
Aluminium Channel 1 Meter
115-051
Aluminium Channel 5 cm
115-054
PET Channel 1 Meter
115-064
LED P/M LIGHT OUTPUT CUTTING DISTANCE
NEON FLEX PRO | RGB
NEON FLEX PRO | RGB
10M ROLL - ART. NR. 20M ROLL- ART. NR. MAX. TO CONNECT POWER
RGB
110-040
110-140
20 meter
ACCESSORIES - RGB
ART. NR.
Power Cable Front
115-055
Power Cable Back
115-058
End Cap
115-056
Aluminium Channel 1 meter
115-051
Aluminium Channel 5 cm
115-054
PET Channel 1 meter
115-064
LED P/M LIGHT OUTPUT
12 Watt p/m 60
CUTTING DISTANCE
Red 22 Lm, Green 90 Lm, Blue 18 Lm,
White >130 Lm p/m
10 cm
NEON FLEX PRO | DIGITAL RGB
NEON FLEX PRO | DIGITAL RGB
30M ROLL
MAX. TO CONNECT
POWER
LED P/M
LIGHT OUTPUT
CUTTING DISTANCE
Digital RGB
110-146
30 meter
12 Watt p/m
56
n/a
12,5 cm
ACCESSORIES - DIGITAL RGB
ART. NR.
Power Cable Front
115-060
Power Cable Back
115-061
End Cap
115-062
Aluminium Channel 1 Meter
115-051
Aluminium Channel 5 cm
115-054
PET Channel 1 Meter
115-064
Digital Controller 1 Channel | Suitable for max. 100 Meter | 540 Effects
214-180
Aluminium Channel 1M / 5 cm
Art. nr. 115-051 / 115-054
164
Aluminium channel 1M / 5 cm
Digital controller for
Neon Flex - Digital RGB
Art. nr. 214-180
PET Channel 1 m
Art. nr. 115-064
PET Channel 1 m
Neon Flex
WWW.TRONIXLIGHTING.COM
165
Neon Flex Flat |
Flat
NEON FLEX FLAT | 24V
SINGLE COLOR
IK 08
PROTECTION
IP 68
PROTECTION
SALTWATER
RESISTANT
SOLVENTS
RESISTANT
UV RESISTANT
FLAME
RESISTANT
BENDING
DIAMETER
D:12CM
BEAM ANGLE
˚
160
DIMMABLE
-
CERTIFICATE
CERTIFICATE
WARRANTY
CERTIFICATE
3
years
+
Long lifetime with SMD LED 5050 and PCB structure
Input: 24 Volt DC
LED type: SMD5050
Dimmable: Yes
IP rate: IP68
Length: 10 meter
Width: 11,5 mm
Height: 21 mm
Connection type: Stripped wire
Power Cable: Included (3 meter)
ART. NR.
LENGTH
MAX. TO CONNECT
POWER
LED P/M LIGHT OUTPUT P/M
CUTTING DISTANCE
 White | 5700K
COLOR
075-051
10 meter
10 meter
12 Watt p/m
60
>320 Lm
10 cm
 Warm White | 3000k
075-058
10 meter
10 meter
12 Watt p/m
60
>320 Lm
10 cm
ACCESSORIES - NEON FLEX FLAT SC
ART. NR.
Power Cable Front 3 meter
075-030
End Cap
075-031
Aluminium Channel 1 meter
115-051
Aluminium Channel 5 cm
115-054
PET Channel 1 Meter
115-064
NEON FLEX FLAT | 24V | RGB
IK 08
PROTECTION
IP 68
PROTECTION
SALTWATER
RESISTANT
SOLVENTS
RESISTANT
UV RESISTANT
FLAME
RESISTANT
Long lifetime with SMD LED 5050 and PCB structure
BENDING
DIAMETER
BEAM ANGLE
D:12CM
160
˚
DIMMABLE
-
CERTIFICATE
CERTIFICATE
WARRANTY
3
years
+
Input: 24 Volt DC
LED type: SMD5050
Dimmable: Yes
IP rate: IP68
Length: 14 meter
Width: 11,5 mm
Height: 21 mm
Connection type: Stripped wire
Power Cable: Included (3 meter)
COLOR
ART. NR.
LENGTH
MAX. TO CONNECT
POWER
LED P/M LIGHT OUTPUT P/M
CUTTING DISTANCE
RGB
075-050
14 meter
14 meter
12 Watt p/m
60
10 cm
ACCESSORIES - NEON FLEX FLAT RGB
ART. NR.
Power Cable Front 3 meter
075-033
End Cap
075-031
Aluminium Channel 1 meter
115-051
Aluminium Channel 5 cm
115-054
PET Channel 1 Meter
115-064
Aluminium Channel 1M / 5 cm
Art. nr. 115-051 / 115-054
166
Aluminium channel 1M / 5 cm
Red 10 Lm, Green 75 Lm, Blue 15 Lm, White >110 Lm
PET Channel 1 m
Art. nr. 115-064
PET Channel 1 m
CERTIFICATE
| Neon Flex
Mini Flat and Up & Down
NEON FLEX MINI FLAT | 24V | 15M
IK 08
PROTECTION
IP 68
PROTECTION
SALTWATER
RESISTANT
SOLVENTS
RESISTANT
UV RESISTANT
FLAME
RESISTANT
Long lifetime with SMD LED and PCB structure
BENDING
DIAMETER
D:9CM
BEAM ANGLE
˚
160
DIMMABLE
-
CERTIFICATE
CERTIFICATE
WARRANTY
CERTIFICATE
3
years
+
Input: 24 Volt DC
LED type: SMD
Dimmable: Yes
IP rate: IP68
Length: 15 meter
Width: 9 mm
Height: 18 mm
Connection type: Stripped wire
Power cable: Included (3 meter)
ART. NR.
LENGTH
MAX. TO CONNECT
POWER
LED P/M LIGHT OUTPUT P/M CUTTING DISTANCE
 White | 5700K
COLOR
075-064
15 meter
15 meter
5 Watt p/m
72
> 120 Lm
8,33 cm
 Warm White | 3000K
075-060
15 meter
15 meter
5 Watt p/m
72
> 120 Lm
8,33 cm
ART. NR.
ACCESSORIES - NEON FLEX FLAT SC
075-061
Power Cable 3 meter & End Cap set
075-062
Aluminium Channel 1 meter
NEON FLEX UP & DOWN | 24V | 10M
IK 08
PROTECTION
IP 68
PROTECTION
SALTWATER
RESISTANT
SOLVENTS
RESISTANT
UV RESISTANT
FLAME
RESISTANT
Long lifetime with SMD LED 5050 and PCB structure
BENDING
DIAMETER
BEAM ANGLE
D:30CM
160
˚
DIMMABLE
-
CERTIFICATE
CERTIFICATE
WARRANTY
CERTIFICATE
3
years
+
Input: 24 Volt DC
LED type: SMD5050
Dimmable: Yes
IP rate: IP68
Length: 10 meter
Width: 16 mm
Height: 16 mm
Connection type: Stripped wire
Power cable: Included (3 meter)
ART. NR.
LENGTH
MAX. TO CONNECT
POWER
 White | 5700K
COLOR
077-051
10 meter
10 meter
10,5 Watt p/m 108
> 450 Lm
5,6 cm
 Warm White | 3000K
077-058
10 meter
10 meter
10,5 Watt p/m 108
> 450 Lm
5,6 cm
ART. NR.
ACCESSORIES | NEON FLEX UP&DOWN
077-060
Power Cable Front 3 meter
077-062
End Cap
077-066
Aluminium Channel 1 meter
077-069
Aluminium Channel 5 cm
LED P/M LIGHT OUTPUT P/M CUTTING DISTANCE
SHEARING TOOL
To make straight cuts with Neon Flex Rope Light
ART. NR.
ACCESSORIES - NEON FLEX
075-063
Shearing tool
WWW.TRONIXLIGHTING.COM
167
Cove Light
Perfect for indirect lighting and
angle-dependant outlining purposes
168
Cove Light
COVE LIGHT SILICON | 24V | 20M
DIMMABLE
-
Waterproof flexible LED Strips, silicon based for high endurance
Input: 24V
Power p/m: 14,4 Watt
LED qty: 60 LED/Meter
LED type: SMD5050
Dimmable: Yes
IP rate: IP65
+
CUT. DIST.
IP RATE
SALTWATER
RESISTANT
UV RESISTANT
CERTIFICATE
WARRANTY
CERTIFICATE
2
years
IP65
20M
50CM
Length: 20 meter
Width: 14,5 mm
Height: 7 mm
Connection type: Stripped wire
Power Cable: Included (0,3 meter)
Material: Silicon based
500mm
ART. NR. COLOR TEMP. (CCT)
COLOR
LENGTH
CUTTING DISTANCE
MAX. TO CONNECT
075-080
2700K
 Warm White
20 meter
50 cm
20 meter
075-081
4000K
 Natural White
20 meter
50 cm
20 meter
ART. NR.
ACCESSORIES | COVE LIGHT SILICON 24V
075-082
Power Cable 0,3 m & End Cap
075-225
Aluminium Channel - 2 m
14,5mm
16.7mm
Art. nr. 075-082
COVE LIGHT | 24V | 30M
DIMMABLE
-
Input: 24V
Power p/m: 3,6 Watt
LED qty: 50 LED/Meter
LED type: SMD3528
Dimmable: Yes
Art. nr. 075-225
+
CUT. DIST.
IP RATE
SALTWATER
RESISTANT
UV RESISTANT
30M
CERTIFICATE
WARRANTY
CERTIFICATE
2
years
IP65
20CM
IP rate: IP65
Length: 30 meter
Width: 12 mm
Height: 6 mm
Connection type: Stripped wire
200mm
ART. NR. COLOR TEMP. (CCT)
075-071
COLOR
 White
5000K
LENGTH
CUTTING DISTANCE
MAX. TO CONNECT
30 meter
20 cm
30 meter
12mm
20mm
ART. NR.
ACCESSORIES | COVE LIGHT 24V
076-006
End Cap
076-007
Mounting Clip
076-008
Splice connector
076-009
Corner connector - 15 cm
076-010
Power cable with DC plug - 1 m
076-017
Power cable with stripped wire -1 m
076-011
Aluminium channel - 2 m
076-016
PET channel with tape - 1 m
076-015
Converter cable 2 pin to dc plug
Art. nr. 076-006
Art. nr. 076-007
Art. nr. 076-008
Art. nr. 076-009
Art. nr. 076-010
Art. nr. 076-011
Art. nr. 076-015
Art. nr. 076-016
Art. nr. 076-015
WWW.TRONIXLIGHTING.COM
169
Cove Light
170
Cove Light
WWW.TRONIXLIGHTING.COM
171
Rope Light
Easy and cost-effective outlining tool
for decorative accent lighting
172
LED
LED ROPE LIGHT | 230V | 50/51M
INPUT
| Rope Light
LED’S P/M
230V
30/36
50/51M
DIMMABLE
-
+
IP RATE
CERTIFICATE
WARRANTY
CERTIFICATE
2
years
IP44
Input: 230V
LED type: DIP LED
LED structure: Vertical / horizontal
Dimmable: Yes
IP rate: IP44
Length: 50/51 meter
Diameter: 13 mm
Max. to connect: 50/51 meter
Power cable: Included
(Schuko Ungrounded EU Plug)
LENGTH
LED STRUCTURE POWER
055-001
ART. NR.
 White
COLOR LED
51 meter
Vertical
3,2 Watt/Meter
150 cm
36 LED p/m
055-101
 White
50 meter
Horizontal
2,7 Watt/Meter
100 cm
30 LED p/m
055-011
 White + Twinkle
51 meter
Vertical
3,2 Watt/Meter
150 cm
36 LED p/m (4 flashing)
055-008
 Warm White
51 meter
Vertical
3,2 Watt/Meter
150 cm
36 LED p/m
055-108
 Warm White
50 meter
Horizontal
2,7 Watt/Meter
100 cm
30 LED p/m
055-018
 Warm White + Twinkle
51 meter
Vertical
3,2 Watt/Meter
150 cm
36 LED p/m (4 flashing)
055-002
 Blue
51 meter
Vertical
3,2 Watt/Meter
150 cm
36 LED p/m
055-003
 Green
51 meter
Vertical
3,2 Watt/Meter
150 cm
36 LED p/m
055-004
 Red
50 meter
Vertical
2,4 Watt/Meter
200 cm
36 LED p/m
055-005
 Amber
50 meter
Vertical
2,4 Watt/Meter
200 cm
36 LED p/m
ART. NR.
ACCESSORIES - 230V ROPE LIGHT
065-005
Power Cable EU for 230V LED Ropelight & End Cap - IP44 | 1,5M
065-006
Power Cable UK for 230V LED Ropelight & End Cap - IP44 |1,5M
065-007
Power Cable Swiss for 230V LED Ropelight & End Cap - IP44 |1,5M
LED QTY
LED ROPE LIGHT | 230V | 6/9/15M
Horizontal structure
INPUT
LED’S P/M
230V
24/36
6/9/15M
Vertical structure
DIMMABLE
-
+
IP RATE
IP44
CERTIFICATE
WARRANTY
CERTIFICATE
2
years
Input: 230V
LED type: DIP LED
LED structure: Vertical
Dimmable: Yes
IP rate: IP44
Length: 6/9/15 meter
Diameter: 13 mm
Power cable: Included
(Schuko Ungrounded EU Plug)
LENGTH
LED STRUCTURE POWER
055-201
ART. NR.
 White
COLOR LED
6 Meter
Vertical
2,1 Watt/Meter
n/a
24 LED p/m
055-202
 Warm White
9 Meter
Vertical
3,2 Watt/Meter
150 cm
36 LED p/m
055-203
 Warm White
15 Meter
Vertical
3,2 Watt/Meter
150 cm
36 LED p/m
ART. NR.
ACCESSORIES - 230V ROPE LIGHT
065-005
Power Cable EU for 230V LED Ropelight & End Cap - 1,5M
065-006
Power Cable UK for 230V LED Ropelight & End Cap - 1,5M
065-007
Power Cable Swiss for 230V LED Ropelight & End Cap - 1,5M
LED QTY
WWW.TRONIXLIGHTING.COM
173
Rope Light |
LED
LED ROPE LIGHT | 24V | 30M
INPUT
LED’S P/M
24V
36
30M
24V Rope Light available in 6 colors - including power cable
DIMMABLE
-
+
IP RATE
CERTIFICATE
WARRANTY
CERTIFICATE
2
years
IP44
Input: 24V
LED qty: 36 LED p/m
LED type: DIP LED
LED structure: Vertical
Dimmable: Yes
IP rate: IP44
Length: 30 meter
Diameter: 13 mm
Max. to connect: 30 meter
Power cable: Included (Stripped wire)
ART. NR.
COLOR LED
POWER
LED QTY
050-001
 White
2,9 Watt/Meter
17 cm
36 LED p/m
050-008
 Warm White
2,9 Watt/Meter
17 cm
36 LED p/m
050-002
 Blue
2,9 Watt/Meter
17 cm
36 LED p/m
050-003
 Green
2,9 Watt/Meter
17 cm
36 LED p/m
050-004
 Red
1,7 Watt/Meter
28 cm
36 LED p/m
050-005
 Amber
1,7 Watt/Meter
28 cm
36 LED p/m
ART. NR.
ACCESSORIES - 24V LED ROPE LIGHT
065-010
Power Cable for 12/24V Ropelight & End Cap - IP44 | 1,5M | Stripped wire
LED ROPE LIGHT | 12V | 15M
INPUT
Input: 12V
LED qty: 36 LED p/m
LED type: DIP LED
LED structure: Vertical
Dimmable: Yes
IP rate: IP44
Length: 15 meter
Diameter: 13 mm
Max. to connect: 15 meter
Power cable: Included (Stripped wire)
174
COLOR LED
POWER
LED QTY
045-001
 White
2,9 Watt/Meter
8,3 cm
36 LED p/m
045-008
 Warm White
2,9 Watt/Meter
8,3 cm
36 LED p/m
045-002
 Blue
2,9 Watt/Meter
8,3 cm
36 LED p/m
045-003
 Green
2,9 Watt/Meter
8,3 cm
36 LED p/m
045-004
 Red
1,7 Watt/Meter
14 cm
36 LED p/m
045-005
 Amber
1,7 Watt/Meter
14 cm
36 LED p/m
ART. NR.
ACCESSORIES - 24V LED ROPE LIGHT
065-010
Power Cable for 12/24V Ropelight & End Cap - IP44 | 1,5M | Stripped wire
36
15M
12V Rope Light available in 6 colors - including power cable
ART. NR.
LED’S P/M
12V
DIMMABLE
-
+
IP RATE
IP44
CERTIFICATE
WARRANTY
2
years
CERTIFICATE
| Rope Light
Incandescent
ROPE LIGHT | INCANDESCENT | 45M
INPUT
DIMMABLE
230V
45M
Traditional Rope Light 230V
-
+
IP RATE
CERTIFICATE
WARRANTY
CERTIFICATE
1
year
IP44
Input: 230V
Bulb qty: 36 p/m
Bulb type: Incandescent
Bulb structure: Vertical
Dimmable: Yes
IP rate: IP44
Length: 45 meter
Diameter: 13 mm
Power cable: Included
(Schuko Ungrounded EU Plug)
LENGTH
POWER
480-030
ART. NR.
 Clear (Warm White Bulb)
COLOR
45 meter
16,5 Watt/Meter
100 cm
36 Bulbs p/m
BULB QTY
480-035
 Blue
45 meter
16,5 Watt/Meter
100 cm
36 Bulbs p/m
480-040
 Green
45 meter
16,5 Watt/Meter
100 cm
36 Bulbs p/m
480-045
 Red
45 meter
16,5 Watt/Meter
100 cm
36 Bulbs p/m
480-050
 Yellow
45 meter
16,5 Watt/Meter
100 cm
36 Bulbs p/m
480-075
 Milky White
45 meter
16,5 Watt/Meter
100 cm
36 Bulbs p/m
ART. NR.
ACCESSORIES - INCANDESCENT ROPE LIGHT
PACKAGING
LENGTH
IP RATE
PLUG TYPE
485-010
Power Cable EU & End Cap
Retail Pack (Topcard)
1,5 Meter
IP20
EU Plug Ungrounded
485-015
Power Cable EU & End Cap & Glue
Retail Pack (Topcard)
1,5 Meter
IP44
Schuko Ungrounded
485-020
Power Cable EU & End Cap
Bulb Packing (Plastic Bag)
1,5 Meter
IP44
Schuko Ungrounded
485-030
Power Cable UK & End Cap
Bulb Packing (Plastic Bag)
1,5 Meter
IP44
UK Ungrounded
485-031
Power Cable Swiss & End Cap
Bulb Packing (Plastic Bag)
1,5 Meter
IP44
Swiss Ungrounded
485-025
Power Cable EU & End Cap
Bulb Packing (Plastic Bag)
5 Meter
IP44
Schuko Ungrounded
GENERAL ACCESSORIES FOR 13MM ROPE LIGHT
Suitable for both LED and Traditional Rope Light 13 mm
ART. NR.
CHANNELS FOR 13MM ROPE LIGHT - BUNCH QTY 50 PCS
485-160
PVC Channel 2M
485-165
PET Channel 2M - UV/Chlorine/Salt Water-Resistant
485-170
Aluminium Channel 2M - UV resistant but sensitive to extension with heat
ART. NR.
MOUNTING CLIPS FOR 13MM ROPE LIGHT RETAIL QTY 50/100 X 25 PCS
485-060
Crocodile Clip 25 pcs in a bag
485-070
Mounting Clip 25 pcs in a bag
ART. NR.
CONNECTORS FOR 13MM ROPE LIGHT
485-050
2 pc Splice Connectors & Glue - Retail pack 50 x 2 pcs
485-085
Invisible Splice Connector - bag qty 100 pcs
485-090
Male Pin Connector - bag qty 100 pcs
485-105
T- Connector - bag qty 1 pc
485-110
X-Connector - bag qty 1 pc
485-100
End Cap - bag qty 100 pcs
485-055
Glue Bottle - Retail pack 1 pc
485-113
10 pcs heat schrinkable tube
Art. nr. 485-160
Art. nr. 485-165
Art. nr. 485-170
Art. nr. 485-070
Art. nr. 485-050
Art. nr. 485-085
Art. nr. 485-105
Art. nr. 485-110
Art. nr. 485-100
Art. nr. 485-060
Art. nr. 485-090
Art. nr. 485-055
Art. nr. 485-113
WWW.TRONIXLIGHTING.COM
175
Flat Cable
& Belt Light
For decorative and colorful lighting
176
Flat Cable & Belt Light
LED PARTY SET 230V | 12,5 METER
INCL. 20 COLORED LAMPS
INPUT
IP RATE
240V
IP44
CERTIFICATE
WARRANTY
CERTIFICATE
2
years
Mix of 5 colors, 4 lamps of each color. With 3 m lead wire.
Plug adaptor included.
Input: 240V (plug adapter incl.)
Power: 7,8 Watt
LED bulb qty: 20
LED qty per bulb: 5
IP rate: IP44
Bulb space: 50 cm
Bulb diameter: Ø 50 mm
Cable length: 15,5 m
Length from plug to first bulb: 3 m
Color: Blue, White, Yellow, Red & Green
ART. NR. BULB QTY COLOR TEMP. (CCT)
435-016
20
 Blue  White  Yellow  Red  Green (4 pcs each)
BELT LIGHT PROFI SET | 20 METER | 20 MOULDED SOCKETS
INPUT
IP RATE
230V
IP44
CERTIFICATE
WARRANTY
CERTIFICATE
2
years
Professional set with high quality moulded sockets. Excluding lamps.
Input: 230V
Socket qty: 20
Socket space: 100 cm
IP rate: IP44
Cable: 2 x1,5mm²
Cable length: 20m
Fitting: E27
Length from plug to first bulb: 50 cm
ART. NR. SOCKET QTY
SOCKET SPACE
585-035
100 cm
20
FLAT CABLE | PRE-MOUNTED SOCKETS
INPUT
IP RATE
230V
IP44
Flat cable with pre-mounted sockets.
CERTIFICATE
WARRANTY
CERTIFICATE
2
years
Input: 230V
Socket space: 100 cm
Cable: 2x1,5 mm²
Length from plug to first bulb: 50 cm
IP rate: IP44
ART. NR.
LENGTH
SOCKET QTY
SOCKET SPACE
585-036
10 meter
10
100 cm
585-037
20 meter
19
100 cm
585-023
100 meter 100
100 cm
ART. NR.
FLAT CABLE ACCESSORIES
585-020
Flat cable with ungrounded Schuko plug and end cap | without sockets | 25M
585-006
Flat cable with ungrounded Schuko plug and end cap | without sockets | 100M
585-025
Sockets | E27 - set of 20 pcs
585-026
Sockets | E27 - set of 100 pcs
585-029
End cap with hook
585-030
Flat cable connector
Art. nr. 585-020
Art. nr. 585-025
WWW.TRONIXLIGHTING.COM
177
Flat Cable & Belt Light
G45 LED LAMP DECO | HIGH POWER
Input: 220-240V AC
Power: 1,7 Watt
Power factor: >0,8
LED type: SMD
LED qty: 30 pc
Dimmable: No
INPUT
ART. NR.
COLOR TEMP. (CCT)
3000K
COLOR LED
 Warm White
Input: 220-240V AC
LED type: DIP
Dimmable: No
Beam: 190°
POWER
BEAM
WARRANTY
2W
190˚
1
year
INPUT
POWER
1W
DIMMABLE
No
CERTIFICATE
CERTIFICATE
CERTIFICATE
CERTIFICATE
Length: 69 mm
Diameter: Ø 45 mm
Connection type: E27
Housing: Clear
ART. NR.
POWER
LED QTY
COLOR TEMP. (CCT)
165-000
1 Watt
6 pc
2700K
 Warm White+
COLOR LED
51 Lm
LIGHT OUTPUT
165-009
2 Watt
10 pc
2700K
 Warm White+
85 Lm
G45 LED BULB DECO | FILAMENT
Input: 220-240V AC
Power: 2 Watt
Dimmable: No
LED type: Filament
LED qty: 2
INPUT
POWER
BEAM
WARRANTY
240V
2W
190˚
1
year
CERTIFICATE
CERTIFICATE
Beam: 190°
Length: 69 mm
Diameter: Ø 45 mm
Connection type: E27
Housing: Clear/colored
COLOR LED
165-788
 White
165-783
 Blue
165-784
 Green
165-785
 Red
165-786
 Yellow
165-787
 Warm White
165-790
 Set of 10 lamps 5 colors excl. Warm
White
P45 LIGHT BULBS | INCANDESCENT | 10 PACK
Input: 220-240V AC
Power: 15 Watt
Dimmable: No
Beam: 190°
Length: 71 mm
178
1
year
240V
LIGHT OUTPUT
155 Lm
G45 LED LAMP DECO
ART. NR.
WARRANTY
1,7W
Beam: 190°
Length: 69 mm
Diameter: Ø 45 mm
Connection type: E27
Housing: Clear
165-010
ART. NR.
BEAM
190˚
POWER
240V
COLOR LED
590-071
 Clear
590-072
 Blue
590-073
 Green
590-074
 Red
590-075
 Yellow
Diameter: Ø 45 mm
Connection type: E27
Content: 10 pcs.
Housing: Clear/colored
White
Blue
Green
Red
Yellow
Warm white
INPUT
POWER
240V
15W
DIMMABLE
-
+
BEAM
WARRANTY
190˚
1
year
CERTIFICATE
CERTIFICATE
Flat Cable & Belt Light
P50 LED LAMP DECO | HEAVY DUTY
Input: 220-240V AC
Power: 1 Watt
Dimmable: No
LED type: SMD
LED qty: 10
ART. NR.
INPUT
POWER
BEAM
WARRANTY
240V
1W
190˚
1
year
CERTIFICATE
CERTIFICATE
Beam: 190°
Length: 83 mm
Diameter: Ø 50 mm
Connection type: E27
Housing: Colored
COLOR LED
165-011
 White
165-012
 Blue
165-013
 Green
165-014
 Red
165-015
 Yellow
165-018
 Warm White
WWW.TRONIXLIGHTING.COM
179
Fiber Light
Fiber Light
Designed to make extraordinary ceilings or walls
180
Fiber Light
FIBER OPTIC KIT | 5W-20W | 100 STRINGS
INPUT
IP RATE
WARRANTY
240V
IP68
2
years
INPUT
IP RATE
WARRANTY
240V
IP68
2
years
INPUT
IP RATE
WARRANTY
240V
IP68
2
years
Including color wheel and 100 end pieces in retail packaging.
CERTIFICATE
Input: 240V
String qty: 100 (4 x 25)
Length: 200 mm
Width: 200 mm
Height: 110 mm
Fiber diameter: Ø 0,75 mm
IP rate: IP68 (fiber) | IP20 (engine)
Color wheel: 5 colors
Adaptor: Included
ART. NR.
LIGHT SOURCE
POWER
STRING QTY
833-001
Traditional / incandescent
20 Watt
25 x 2 meter
25 x 3 meter
25 x 4 meter
25 x 5 meter
833-009
LED
5 Watt
25 x 2 meter
25 x 3 meter
25 x 4 meter
25 x 5 meter
FIBER | LED RGB TUBE | 100 STRINGS
Fixed color changing program
CERTIFICATE
Input: 230V
Power: 6 Watt
String qty: 100 x 1,5 meter
Length: 130 mm
Diameter: 35 mm
Fiber diameter: Ø 0,75 mm
IP rate: IP68 (fiber) | IP20 (engine)
Adaptor: Included
ART. NR.
POWER
STRING QTY
833-006
3 x 2 Watt
100 x 1,5 meter
FIBER | LED RGB LIGHT ENGINE | 400 STRINGS
Including color wheel and remote control
CERTIFICATE
Input: 230V
String qty: 400 x 3 meter
Length: 125 mm
Width: 125 mm
Height: 80 mm
Fiber diameter: Ø 0,75 mm
IP rate: IP68 (fiber) | IP20 (engine)
Color wheel: 6 colors
Adaptor: Included
ART. NR.
POWER
STRING QTY
833-008
5 Watt
400 x 3 meter
ART. NR.
ACCESSORY
833-015
Twinkle wheel White/Black for Art. nr. 833-007& 833-008
Twinkle Wheel
Art. nr. 833-015
WWW.TRONIXLIGHTING.COM
181
Fiber Light
182
Fiber Light
WWW.TRONIXLIGHTING.COM
183
Light Bars
For efficient line-light on any work bench
184
Light Bars
LIGHT BAR 50CM | 45 SMD LED DIMMABLE
-
Including power cable, connection cable, connector & mounting clips
+
BEAM
INPUT
120˚
CERTIFICATE
WARRANTY
CERTIFICATE
2
years
24V
Input: 24V
Power: 4 Watt
LED qty: 45
Dimmable: Yes
Beam: 120°
IP rate: IP20
Lenght: 500 mm
Width: 19 mm
Heigth: 14 mm
Connection type: Stripped wire
Wire length: 10 cm
Housing: Aluminium + PC
Max. to connect: 10 pcs
ART. NR.
LENGTH
COLOR TEMP. (CCT)
128-041
50 cm
5000K
 White
COLOR LED LIGHT OUTPUT
270 Lm
128-028
50 cm
3000K
 Warm White
200 Lm
LIGHT BAR 30CM | 5 HIGH POWER LED
DIMMABLE
Including power cable, connection cable, connector & mounting clips
-
+
BEAM
120˚
INPUT
CERTIFICATE
WARRANTY
CERTIFICATE
2
years
24V
Input: 24V
Power: 5 Watt
LED qty: 5
Dimmable: Yes
Beam: 120°
IP rate: IP20
Lenght: 300mm
Width: 25mm
Height: 15,5mm
Connection type: Stripped wire
Wire length: 10 cm
Housing: Aluminium + PC
Max. to connect: 10 pcs
ART. NR.
LENGTH
COLOR TEMP. (CCT) LIGHT OUTPUT POWER
128-051
30 cm
5000K
400 Lm
5 Watt
128-038
30 cm
3000K
350 Lm
5 Watt
LIGHT TUBE | T5
BEAM
Incl. power cable 25 cm, connector, corner connector 5 cm and brackets
120˚
INPUT
230V
CERTIFICATE
WARRANTY
CERTIFICATE
2
years
Input: 90 - 230V
Dimmable: No
Color Temp.: 2700K
CRI: ≥80
Beam: 120°
IP rate: IP20
Width: 23 mm
Height: 31,50 mm
Connection type: Stripped wire
Wire length: 25 cm
Housing: Aluminium + PC
Max to connect: 10 meter
ART. NR.
LENGTH
COLOR TEMP. (CCT) LIGHT OUTPUT POWER
177-050
30 cm
2700K
340 Lm
5 Watt
177-051
60 cm
2700K
680 Lm
8 Watt
177-052
90 cm
2700K
1020 Lm
12 Watt
ART. NR.
ACCESSORIES
177-057
Power cable | 120 cm
WWW.TRONIXLIGHTING.COM
185
Light Bars
LIGHT BAR | NO GAP DIMMABLE
-
+
BEAM
120˚
INPUT
24V
CERTIFICATE
WARRANTY
CERTIFICATE
3
years
Input: 24V
Dimmable: Yes
Color Temp: 3000K
LED Type: SMD
CRI: ≥80
Beam: 120°
IP rate: IP20
Width: 30 mm
Height: 10 mm
Connection type: DC plug
Wire length: 100 cm
Housing: Aluminium + PC
Max to connect: 10 meter
ART. NR.
LENGTH
COLOR TEMP. (CCT)
LED QTY
LIGHT OUTPUT
POWER
128-100
100 cm
3000K
90
1200 Lm
15 Watt
128-101
60 cm
3000K
54
700 Lm
9 Watt
128-102
30 cm
3000K
24
350 Lm
5 Watt
128-103
15 cm
3000K
12
100 Lm
3 Watt
ACCESSORIES FOR NO-GAP LIGHT BAR 186
ART. NR.
POWER CABLES
128-107
Power Cable | 1M
128-108
Power Cable | 1M with touch dim
128-113
Extension cable | 15 cm
ART. NR.
CLIPS
128-104
Clips 180° 2 pcs
128-105
Clips 45° 2 pcs
128-106
Clips adjustable 2 pcs
ART. NR.
CONNECTORS
128-109
L-Connector Right
128-110
L-Connector Left
128-111
T-Connector
128-112
+ Connector
128-114
Splice/Middle connector
Power Cable - 1M
Art. nr. 128-107
Power Cable - 1M with touch dim
Art.nr. 128-108
Extension Cable - 15CM
Art. nr. 128-113
Clips 180º - 2pcs
Art. nr. 128-104
Clips 45º - 2pcs
Art. nr. 128-105
Clips Adjustable
Art. nr. 128-106
L-Connector right
Art. nr. 128-109
L-Connector Left
Art. nr. 128-110
T-Connector
Art. nr. 128-111
+ Connector
Art. nr. 128-112
Splice/Middle Connector
Art. nr. 128-114
Light Bars
WWW.TRONIXLIGHTING.COM
187
Advertising
& signing
Powerfull lighting tools for
advertising purposes
188
Advertising & Signing
OUTDOOR LED SCREENS
PIXEL PITCH
P5 MM
P6 MM
P8 MM
P10 MM
P16 MM
OPTIMAL VIEWING DISTANCE
>5 Meter
>6 Meter
>8 Meter
>10 Meter
>16 Meter
PIXEL
1R1G1B
1R1G1B
1R1G1B
1R1G1B
1R1G1B
LED TYPE
SMD2727
SMD3535
SMD3535
SMD3535
DIP
PIXEL PITCH (MM)
5 mm
6 mm
8 mm
10 mm
16 mm
PIXEL DENSITY
40.000
27.777
15.625
10.000
3.906
MODULE SIZE (MM)
160x160
192x96, 192x192
256x128
320x160
256x256
PIXELS P/MODULE
32x32
32x16 , 32x32
32x16
32x16
16x16
CABINET SIZE (MM)
960x960
960x960
1024x1024
960x960
1024x1024
PIXELS P/CABINET
192x192
160x160
128x128
96x96
64x64
BRIGHTNESS
>5500 cd/m2
>5500 cd/m2
>5500 cd/m2
>7000 cd/m2
>7000 cd/m2
VIEWING ANGLE
H120° V120°
H120° V120°
H120° V120°
H120° V120°
H110° V60°
AVERAGE CONSUMPTION (W/M2)
300
300
300
300
240
POWER SUPPLY
Meanwell
Meanwell
Meanwell
Meanwell
Meanwell
CABINET WEIGHT
36 KG
36 KG
42 KG
35 KG
45 KG
INDOOR LED SCREENS
PIXEL PITCH
P2.5MM
P3MM
P4MM
P5MM
P6MM
P10MM
OPTIMAL VIEWING DISTANCE
>2,5 Meter
>3 Meter
>4 Meter
>5 Meter
>6 Meter
>10 Meter
PIXEL
1R1G1B
1R1G1B
1R1G1B
1R1G1B
1R1G1B
1R1G1B
LED TYPE
SMD2020
SMD2020
SMD2020
SMD3528
SMD3528
SMD3528
PIXEL PITCH (MM)
2.5 mm
3 mm
4 mm
5 mm
6 mm
10 mm
PIXEL DENSITY
160.000
111.111
62.500
40.000
27.777
10.000
MODULE SIZE (MM)
160x160
PIXELS P/MODULE
64x64
192x192
64x64
256x128
160x160, 320x160
192x192, 384x192
320x160
64x32
32x32, 64x32
32x32, 64x32
32x16
CABINET SIZE (MM)
960x960
576x576
1024x1024
960x960
960x960
960x960
PIXELS P/CABINET
384x384
192x192
256x256
192x192
160x160
96x96
BRIGHTNESS
>1200 cd/m2
>1200 cd/m2
>1300 cd/m2
>1500 cd/m2
>1500 cd/m2
>1300 cd/m2
VIEWING ANGLE
H120° V120°
H120° V120°
H120° V120°
H120° V120°
H120° V120°
H120° V120°
AVERAGE CONSUMPTION (W/M2)
360
270
340
360
180
120
POWER SUPPLY
Meanwell
Meanwell
Meanwell
Meanwell
Meanwell
Meanwell
CABINET WEIGHT
37 KG
37 KG
42 KG
37 KG
37 KG
37 KG
ACCESSORY | VIDEO PROCESSOR
INPUT
VIDEO SYSTEM
DVI FORMAT
HDMI FORMAT
OUTPUT
WAY OF CONTROL
PIP/POP DISPLAY
MODES
NO. OF SCREEN TO
POWER SEPERATLY
2 x Video
1 x S-Video
1 x VGA
1 x HDMI
1 x DVI
2 x EXT
PAL/NTSC
PC (VESA):
<2304 x 1152_60Hz
PC (VESA):
<2304 x 1152_60Hz
HDMI 1.3:
<1920 x 1080p_60Hz
1 x VGA
2 x DVI
Panel Button
PC Software
3 pcs
2 pcs
ACCESSORY | BRIGHTNESS SENSOR
Sensor to control the brightness of each LED screen by LUX value
WWW.TRONIXLIGHTING.COM
189
Advertising & Signing
BACKGROUND MODULE | 2 X 3528 LED
Input: 12V
Power: 0,24 Watt
Module qty:
100 modules / 5 meter
LED qty per module: 2
LED type: Epistar 3528
Dimmable: Yes
ART. NR.
COLOR TEMP. (CCT)
125-021
6000K
LED COLOR
 Cold white
+
IP RATE
WARRANTY
IP65
3
years
CERTIFICATE
LIGHT OUTPUT
INPUT
MAX TO
CONNECT
12V
50 in
one line
DIMMABLE
-
+
IP RATE
WARRANTY
IP65
3
years
IP RATE
WARRANTY
IP65
3
years
CERTIFICATE
IP rate: IP65
Length: 62 mm
Width: 17 mm
Depth: 2,8 mm
Max. to connect: 50
Connection Type: Stripped Wire
ART. NR.
COLOR TEMP. (CCT):
6000K
 Cold White
COLOR LED
40 Lm
LIGHT OUTPUT
125-038
3000K
 Warm White
35 Lm
125-034
n/a
 Red
n/a
125-032
n/a
 Blue
n/a
125-000
n/a
RGB
n/a
BACKGROUND MODULE | HIGH POWER LED
190
DIMMABLE
-
8 Lm
125-031
Input: 12V
Power: 1 Watt
Module qty: 20 modules / 3 meter
LED qty per module: 1
LED type: High power
Dimmable: Yes
Beam: 120°
MAX TO
CONNECT
100 in
one line
Beam: 120°
IP rate: IP65
Length: 38 mm
Width: 15 mm
Depth: 5 mm
Max. to connect: 100
Connection Type: Stripped Wire
BACKGROUND MODULE | 3 X 5050 LED
Input: 12V
Power: 0,5 Watt
Module qty: 50 modules / 7 meter
LED qty per module: 3
LED type: Epistar 5050
Dimmable: Yes
Beam: 120°
INPUT
12V
IP rate: IP65
Length: 67 mm
Width: 37 mm
Depth: 7,5 mm
Max. to connect: 20
Connection Type: Stripped Wire
ART. NR.
COLOR TEMP. (CCT):
125-041
6000K
 Cold White
COLOR LED
70 Lm
LIGHT OUTPUT
125-048
3000K
 Warm White
60 Lm
INPUT
MAX TO
CONNECT
12V
20 in
one line
DIMMABLE
-
+
CERTIFICATE
Advertising & Signing
WWW.TRONIXLIGHTING.COM
191
Advertising & Signing
LED ADVERTISING BACKGROUND PANEL | 24V
Input: 24V
LED type: Epistar
Color Temp. (CCT): 6000K
Color LED: Cold white
Dimmable: Yes
ART. NR.
SIZE
POWER
LED QTY
LIGHT OUTPUT
MAX. TO CONNECT
304 x 304 mm
24 Watt
120
2400 Lm
10
128-071
60 x 304 mm
4,8 Watt
24
480 Lm
12
128-072
304 x 50 mm
4,2 Watt
20
400 Lm
12
128-073
60 x 50 mm
1,2 Watt
4
80 Lm
12
192
+
WARRANTY
CERTIFICATE
3
years
60 x 304 mm
EASY
CONNECTION
SYSTEM
ANY SIZE
POSSIBLE
60 x 50 mm
DIMMABLE
-
Beam: 120°
IP rate: IP20
Depth: 2 mm (15 mm at connector)
Connection Type: Screw
128-070
304 x 304 mm
INPUT
24V
304 x 50 mm
LED ADVERTISING BACKGROUND PANELS 24V
For maximum light output behind a
canvas or panel.
• In 4 sizes, connectable to create
any desired size.
• High light output: 100 Lm/Watt,
25.000 Lm/m²
• Power 250W p/m²
• 6000K, IP20, CRI > 85
• No hot spots: optimal distribution LED structure:
• Minimum mounting depth
38mm
Advertising & Signing
LED ADVERTISEMENT LIGT BAR | 24V | INDOOR
Input: 24V
Power: 15,6 Watt
LED type: CREE-XPE
Color Temp. (CCT): 6000K
Color LED: Cold white
BEAM
IP RATE
WARRANTY
140˚x120˚
IP20
3
years
CERTIFICATE
Beam: 30° x 65°
IP rate: IP20
Connection Type: Male/female
Material: Aluminium
ART. NR.
POWER
LIGHT OUTPUT
SIZE L*W*H
MAX. TO CONNECT
IP RATE
128-061
15,6 Watt
950 Lm
300 x 20 x 35 mm
5 pcs
IP20
LED ADVERTISEMENT LIGT BAR | 24V | OUTDOOR
Input: 24V
Power: 15,6 Watt
LED type: CREE-XPE
Color Temp. (CCT): 6000K
Color LED: Cold white
INPUT
24V
INPUT
BEAM
IP RATE
WARRANTY
24V
140˚x120˚
IP65
3
years
CERTIFICATE
Beam: 30° x 65°
IP rate: IP65
Connection Type: Male/female
Material: Aluminium
ART. NR.
POWER
LIGHT OUTPUT
SIZE L*W*H
128-063
15,6 Watt
950 Lm
320 x 21,2 x 15 mm 5 pcs
MAX. TO CONNECT
IP RATE
IP65
WWW.TRONIXLIGHTING.COM
193
Power Supplies
& Controllers
For the best possible dimming & lighting results
194
Power Supplies
LED DRIVER MINI | INDOOR
OUTPUT
OUTPUT
WARRANTY
350
mA
700
mA
3
years
CERTIFICATE
CERTIFICATE
CERTIFICATE
CERTIFICATE
CERTIFICATE
CERTIFICATE
CERTIFICATE
CERTIFICATE
Input: 100 - 240V
Output: 350 mA / 700 mA
Power: 6 Watt
Power factor: 0,4
Dimmable : No
IP Rate: IP20
Size (L x W x H): 50 x 32 x 18,5 mm
Connection type: Terminal block
Isolation : SELV
Ambient temperature: -20°C / +50°C
ART. NR.
OUTPUT
POWER
OUTPUT VOLTAGE
215-201
350 mA
6 Watt
3 ~ 17 Volt
215-202
700 mA
6 Watt
3 ~ 8 Volt
LED DRIVER MINI | OUTDOOR | (NON) DIMMABLE
OUTPUT
OUTPUT
IP RATE
350
mA
700
mA
IP65
DIMMABLE
-
+
WARRANTY
3
years
Input: 100 - 240V
Output: 350 mA / 700 mA
Power: 4 Watt
Power factor: 0.4
IP Rate: IP65
Size (L x W x H): 38 x 27 x 21 mm
Connection type: Stripped wire
Isolation: SELV
Ambient temperature: -20°C / +50°C
ART. NR.
OUTPUT
POWER
OUTPUT VOLTAGE
DIMMABLE
215-303
350 mA
4 Watt
2 ~ 12 Volt
No
215-306
350 mA
4 Watt
2 ~ 12 Volt
Yes
215-305
700 mA
4 Watt
2 ~ 6 Volt
No
215-307
700 mA
4 Watt
2 ~ 6 Volt
Yes
WWW.TRONIXLIGHTING.COM
195
Power Supplies
LED DRIVER | INDOOR
OUTPUT
OUTPUT
WARRANTY
350
mA
700
mA
3
years
CERTIFICATE
CERTIFICATE
CERTIFICATE
CERTIFICATE
CERTIFICATE
CERTIFICATE
CERTIFICATE
CERTIFICATE
CERTIFICATE
CERTIFICATE
CERTIFICATE
CERTIFICATE
Input: 100 - 240V
Output: 350 mA / 700 mA
Power factor: 0.8
Dimmable : No
IP Rate: IP20
Connection type: terminal block
Isolation : SELV
Ambient temperature: -20°C / +50°C
ART. NR.
OUTPUT
POWER
OUTPUT VOLTAGE
SIZE (L X W X H)
215-412
350 mA
20 Watt
2 ~ 58 Volt
98 x 39 x 22 mm
215-211
700 mA
12 Watt
2 ~ 12 Volt
99 x 39 x 22 mm
215-212
700 mA
20 Watt
2 ~ 29 Volt
113 x 44 x 33 mm
LED DRIVER | INDOOR | TRIAC DIMMABLE
OUTPUT
OUTPUT
350
mA
700
mA
DIMMABLE
-
DALI
+
WARRANTY
3
years
Input: 220 - 240V
Output: 350 mA / 700 mA
Power factor: 0.9
Dimmable : Triac Dimmable
IP Rate: IP20
Connection type: terminal block
Isolation : SELV
Ambient temperature: -20°C / +50°C
ART. NR.
OUTPUT
POWER
OUTPUT VOLTAGE
SIZE (L X W X H)
215-349
350 mA
9 Watt
6 ~ 26 Volt
113 x 44 x 28 mm
215-350
350 mA
18 Watt
15 ~ 52 Volt
113 x 44 x 28 mm
215-249
700 mA
9 Watt
3 ~ 13 Volt
99 x 39 x 22 mm
215-250
700 mA
18 Watt
6 ~ 26 Volt
113 x 44 x 33 mm
215-251
700 mA
25 Watt
18 ~ 36 Volt
113 x 44 x 33 mm
LED DRIVER | INDOOR | TRIAC DIMMABLE
Input: 220 - 240V
Output: 700 mA / 1050 mA
Power factor: >0.9
Dimmable : Triac Dimmable
IP Rate: IP20
Connection type: terminal block
Isolation : SELV
Ambient temperature: -20°C / +50°C
196
ART. NR.
OUTPUT
POWER
OUTPUT VOLTAGE
SIZE (L X W X H)
215-252
700 mA
40 Watt
29 ~ 58 Volt
166 x 52 x 24 mm
215-407
1050 mA
40 Watt
19 ~ 38 Volt
166 x 52 x 24 mm
OUTPUT
OUTPUT
700
mA
1050
mA
DIMMABLE
-
DALI
+
WARRANTY
3
years
Power Supplies
LED DRIVER | INDOOR | 1-10V DIMMABLE | 350 mA
DIMMABLE
-
1-10V
+
OUTPUT
WARRANTY
350
mA
3
years
OUTPUT
WARRANTY
700
mA
3
years
CERTIFICATE
CERTIFICATE
CERTIFICATE
CERTIFICATE
CERTIFICATE
CERTIFICATE
CERTIFICATE
CERTIFICATE
DIMMABLE
WARRANTY
CERTIFICATE
Input: 220 - 240V
Output: 350 mA
Power factor: >0.95
Dimmable : 1-10 Volt
IP Rate: IP20
Connection type: terminal block
Isolation : SELV
Ambient temperature: -20°C / +50°C
ART. NR.
OUTPUT
POWER
OUTPUT VOLTAGE
SIZE
215-270
350 mA
20 Watt
2 ~ 60 Volt
210 x 31 22 mm
LED DRIVER | INDOOR | 1-10V DIMMABLE | 700 mA
DIMMABLE
-
1-10V
+
Input: 220 - 240V
Output: 700 mA
Power factor: >0.95
Dimmable : 1-10 Volt
IP Rate: IP20
Connection type: terminal block
Isolation : SELV
Ambient temperature: -20°C / +50°C
ART. NR.
OUTPUT
POWER
OUTPUT VOLTAGE
SIZE (L X W X H)
215-210
700 mA
40 Watt
18 ~ 56 Volt
139 x 75 x 30 mm
LED DIMMER 0-10V | INDOOR | ROUND
-
Dimming method: 0 - 10 Volt
Diameter: 42 mm
Diameter button: 20 mm
IP Rate: IP20
ART. NR.
DIMMING
215-130
0-10 Volt
0-10V
+
3
years
Height: 37 mm
Wire length: 140 mm
Connection Type: Stripped Wire
Material : Aluminium (Brushed)
WWW.TRONIXLIGHTING.COM
197
Drivers
LED DRIVER | DALI DIMMABLE | 20 WATT
OUTPUT
OUTPUT
350
mA
700
mA
OUTPUT
OUTPUT
OUTPUT
350
mA
500
mA
700
mA
DIMMABLE
-
DALI
+
WARRANTY
CERTIFICATE
CERTIFICATE
CERTIFICATE
CERTIFICATE
CERTIFICATE
CERTIFICATE
CERTIFICATE
CERTIFICATE
3
years
Input: 220 - 240V
Output: 350 mA / 700 mA
Power factor: >0.95
Dimmable : Dali Dimmable
IP Rate: IP20
Size: 122 x 52 x 30 mm
Connection type: terminal block
Isolation : SELV
Ambient temperature: -20°C / +50°C
ART. NR.
OUTPUT
POWER
OUTPUT VOLTAGE
215-261
350 mA
20 Watt
2 ~ 60 Volt
215-262
700 mA
20 Watt
2 ~ 28 Volt
LED DRIVER | DALI DIMMABLE | 40 WATT
Driver with 3 different output possibilities
Input: 220 - 240V
Output: 350 mA / 500 mA / 700 mA
Power factor: >0.95
Dimmable : Dali Dimmable
IP Rate: IP20
Size: 139 x 75 x 30 mm
Connection type: terminal block
Isolation : SELV
Ambient temperature: -20°C / +50°C
198
ART. NR.
OUTPUT
POWER
OUTPUT VOLTAGE
215-260
350 mA
28 Watt
10 ~ 80 Volt
215-260
500 mA
40 Watt
10 ~ 80 Volt
215-260
700 mA
40 Watt
10 ~ 60 Volt
DIMMABLE
-
DALI
+
WARRANTY
3
years
Power Supplies
LED POWER SUPPLY | WALL TYPE | INDOOR
6-12-21 WATT
OUTPUT
OUTPUT
WARRANTY
12V
24V
2
years
CERTIFICATE
CERTIFICATE
OUTPUT
WARRANTY
CERTIFICATE
CERTIFICATE
CERTIFICATE
CERTIFICATE
12V
3
years
OUTPUT
OUTPUT
WARRANTY
CERTIFICATE
CERTIFICATE
12V
24V
2
years
Input: 100 - 240V
Output: 12/ 24V
Power factor: >0,9
Dimmable : No
IP Rate: IP20
Connection type: DC Plug
Wire Length: 150 cm
Isolation : SELV
Ambient temperature: -20°C / +50°C
ART. NR.
OUTPUT
POWER
PLUG TYPE
LENGTH
WIDTH
HEIGHT
215-020
12 Volt
6 Watt
EU
65 mm
30 mm
58 mm
215-025
12 Volt
6 Watt
UK
65 mm
30 mm
58 mm
215-030
12 Volt
12 Watt
EU
75 mm
43 mm
30 mm
215-040
12 Volt
24 Watt
EU
87 mm
52 mm
31 mm
215-042
24 Volt
24 Watt
EU
87 mm
52 mm
31 mm
LED POWER SUPPLY | BLOCK TYPE | INDOOR
18 WATT
Input: 100 - 240V
Output: 12V
Power factor: >0,9
Dimmable : No
IP Rate: IP20
Size: 115 x 45 x 21 mm
Isolation : SELV
Ambient temperature:
-20°C / +50°C
ART. NR.
OUTPUT
POWER
215-002
12 Volt
18 Watt
LED DRIVER | BLOCK TYPE | INDOOR | 50 WATT
Input: 100 - 240V
Output: 12/ 24V
Power factor: >0,9
Dimmable : No
IP Rate: IP20
Size: 120 x 79 x 32 mm
Connection Type: Screw
Isolation : SELV
Ambient temperature:
-20°C / +50°C
ART. NR.
OUTPUT
POWER
215-009
12 Volt
50 Watt
215-401
24 Volt
50 Watt
WWW.TRONIXLIGHTING.COM
199
Power Supplies
LED DRIVER | SLIM TYPE | INDOOR | 30 WATT
OUTPUT
WARRANTY
12V
3
years
CERTIFICATE
CERTIFICATE
CERTIFICATE
Input: 100 - 240V
Output: 12V
Power factor: >0,9
Dimmable : No
IP Rate: IP20
Size: 251 x 30 x 16 mm
Isolation : SELV
Ambient temperature: -20°C / +50°C
ART. NR.
OUTPUT
POWER
215-005
12 Volt
30 Watt
LED DRIVER | BLOCK TYPE | INDOOR | 75 WATT
OUTPUT
OUTPUT
WARRANTY
12V
24V
3
years
CERTIFICATE
CERTIFICATE
CERTIFICATE
CERTIFICATE
CERTIFICATE
CERTIFICATE
CERTIFICATE
CERTIFICATE
Input: 100 - 240V
Output: 12/ 24V
Power factor: >0,95
Dimmable : No
IP Rate: IP20
Size: 184 x 61 x 32 mm
Isolation : SELV
Ambient temperature: -20°C / +50°C
ART. NR.
OUTPUT
POWER
215-010
12 Volt
75 Watt
215-403
24 Volt
75 Watt
LED DRIVER | OPEN TYPE | INDOOR
60 WATT ~ 500 WATT
OUTPUT
OUTPUT
WARRANTY
12V
24V
2
years
Input: 100 - 240V
Output: 12/ 24V
Power factor: >0,9
Dimmable : No
IP Rate: IP20
Isolation : SELV
Ambient temperature: -20°C / +50°C
200
ART. NR.
OUTPUT
POWER
LENGTH
WIDTH
DEPTH
COOLING
215-052
12 Volt
60 Watt
130
100
42
Passive
215-070
12 Volt
120 Watt
160
97
38
Passive
215-054
12 Volt
200 Watt
199
110
50
Active
215-072
12 Volt
250 Watt
199
99
37
Active
215-074
12 Volt
350 Watt
215
114
49
Active
215-062
12 Volt
400 Watt
210
114
50
Active
215-073
12 Volt
250 Watt
199
99
37
Active
215-051
24 Volt
60 Watt
130
100
42
Passive
215-071
24 Volt
120 Watt
160
97
38
Passive
215-075
24 Volt
350 Watt
215
114
49
Active
215-077
24 Volt
500 Watt
241
124
65
Active
Power Supplies
LED DRIVER | 24V | INDOOR | 25 WATT
DIMMABLE
Input: 220 - 240V
Output: 24V
Power factor: >0,9
Dimmable : Yes (Triac)
IP Rate: IP20
OUTPUT
POWER
24V
25W
DIMMABLE
-
TRIAC
WARRANTY
CERTIFICATE
CERTIFICATE
CERTIFICATE
WARRANTY
CERTIFICATE
CERTIFICATE
CERTIFICATE
CERTIFICATE
CERTIFICATE
CERTIFICATE
CERTIFICATE
CERTIFICATE
3
years
+
Size: 122 x 52 x 30 mm
Isolation : SELV
Ambient temperature:
-20°C / +50°C
ART. NR.
OUTPUT
POWER
215-404
24 Volt
25 Watt
LED DRIVER | 24V | INDOOR | 40 WATT
DIMMABLE
Input: 220 - 240V
Output: 24V
Power factor: >0,9
Dimmable : Yes (Triac)
IP Rate: IP20
OUTPUT
POWER
24V
40W
DIMMABLE
-
TRIAC
+
2
years
Size: 120 x 79 x 32 mm
Isolation : SELV
Ambient temperature:
-20°C / +50°C
ART. NR.
OUTPUT
POWER
215-402
24 Volt
40 Watt
LED DRIVER | 24V | INDOOR | 100 WATT
DIMMABLE
Input: 220 - 240V
Output: 24V
Power factor: >0,95
Dimmable : Yes (Triac)
IP Rate: IP20
OUTPUT
POWER
24V
100W
DIMMABLE
-
TRIAC
+
WARRANTY
3
years
Size: 191 x 61 x 32 mm
Isolation : SELV
Ambient temperature:
-20°C / +50°C
ART. NR.
OUTPUT
POWER
215-003
24 Volt
100 Watt
LED DRIVER | 24V | OUTDOOR | 200 WATT
DIMMABLE
Input: 220 - 240V
Output: 24V
Power factor: >0,95
Dimmable : Yes (Triac)
IP Rate: IP67
OUTPUT
POWER
IP RATE
24V
200W
IP67
DIMMABLE
-
TRIAC
+
WARRANTY
CERTIFICATE
3
years
Size: 249 x 72 x 40 mm
Isolation : SELV
Ambient temperature:
-20°C / +50°C
ART. NR.
OUTPUT
POWER
215-004
24 Volt
200 Watt
WWW.TRONIXLIGHTING.COM
201
Power Supplies
LED DRIVER | OUTDOOR | 30-60 WATT
Input: 220 - 240V
Output: 12/24V
Power factor: >0,9
Dimmable : No
IP Rate: IP67
OUTPUT
POWER
POWER
IP RATE
WARRANTY
12V
24V
30W
60W
IP67
2
years
OUTPUT
OUTPUT
POWER
POWER
IP RATE
WARRANTY
12V
24V
60W
100W
IP67
3
years
CERTIFICATE
CERTIFICATE
CERTIFICATE
CERTIFICATE
CERTIFICATE
CERTIFICATE
Connection type: DC plug
Isolation : SELV
Ambient temperature:
-20°C / +40°C
ART. NR.
OUTPUT
POWER
LENGTH
WIDTH
HEIGHT
215-310
12 Volt
30 Watt
102 mm
50 mm
27 mm
215-300
24 Volt
30 Watt
102 mm
50 mm
27 mm
215-301
24 Volt
60 Watt
175 mm
66 mm
55 mm
LED DRIVER | OUTDOOR | 60-200 WATT
Input: 220 - 240V
Output: 12/24V
Power factor: >0,9
Dimmable : No
IP Rate: IP67
Connection type: DC plug
Isolation : SELV
Ambient temperature:
-20°C / +40°C
ART. NR.
OUTPUT
POWER
LENGTH
WIDTH
HEIGHT
215-092
12 Volt
60 Watt
216 mm
42 mm
30 mm
215-315
12 Volt
100 Watt
197 mm
68 mm
40 mm
215-317
12 Volt
200 Watt
221 mm
68 mm
40 mm
215-316
24 Volt
100 Watt
197 mm
68 mm
40 mm
215-318
24 Volt
200 Watt
221 mm
68 mm
40 mm
LED DRIVER | OUTDOOR | 60 WATT
Input: 90 - 295V
Output: 24V
Power factor: >0,9
Dimmable : No
IP Rate: IP64
OUTPUT
POWER
IP RATE
WARRANTY
24V
60W
IP64
3
years
Size: 181 x 61,5 x 35 mm
Connection type: Stripped Wire
Isolation : SELV
Ambient temperature:
-20°C / +40°C
ART. NR.
OUTPUT
POWER
215-501
24 Volt
60 Watt
LED DRIVER | OUTDOOR | 30 WATT
Input: 100- 240V
Output: 12V
Power factor: >0,9
Dimmable : No
IP Rate: IP67
202
OUTPUT
Size: 220 x 30 x 21 mm
Wire length in/out: 250 / 250 mm
Isolation : SELV
Ambient temperature:
-20°C / +40°C
ART. NR.
OUTPUT
POWER
215-090
12 Volt
30 Watt
OUTPUT
POWER
IP RATE
WARRANTY
12V
30W
IP67
2
years
CERTIFICATE
CERTIFICATE
CERTIFICATE
Power Supplies
WWW.TRONIXLIGHTING.COM
203
Controllers
Drivers
MAIN VOLTAGE:
Real glass
Real glass
Real glass
204
ART. NR.
214-130
DIMMING
Push and hold
SIZE
Ø32 mm x 10 mm
BATTERY
included
RANGE
<20 meter
ZONES
1
ART.NR
214-134
DIMMING
Push and hold
SIZE
Ø 32,2 mm x 12 mm
BATTERY
included
RANGE
<20 meter
ZONES
1
ART.NR
214-146
DIMMING
Touch Slide
SIZE
35 x 141 x 8,5 mm
BATTERY
included
RANGE
<20 meter
ZONES
1
ART.NR
214-131
DIMMING
Push and hold
SIZE
86 x 86 x 13 mm
BATTERY
included
RANGE
<20 meter
ZONES
5
ART.NR
214-144
DIMMING
Push and hold
SIZE
86 x 86 x 13 mm
BATTERY
included
RANGE
<20 meter
ZONES
1
ART.NR
214-145
DIMMING
Switch / Turn
SIZE
86 x 86 x 41 mm
BATTERY
included
RANGE
<20 meter
ZONES
1
ART.NR
214-152
DIMMING
RF wireless, push remote
SIZE
86 x 86 x 13,8 mm
BATTERY
includedv
RANGE
<20 meters
ZONES
2
MATERIAL
Real glass finishing
CONSTANT VOLTAGE:
CONSTANT CURRENT:
All above constant voltage
and constant current controllers require a 12V or 24V
power supply.
Controllers
Drivers
To control constant main voltage dimmable
LED application (for example LED GU10 lamps)
ART.NR
214-151
INPUT
240V AC
POWER
2 x 1,2 Ampere
MAX. LOAD
2 x 288 Watt
SIZE
170 x 59 x 30 mm
ART.NR
214-147
INPUT
12~36 Volt
POWER
1 Channel x 8 Ampere max.
MAX. LOAD
96 Watt (12 Volt) / 192 Watt (24 Volt)
SIZE
101 x 36 x 21 mm
ART.NR
214-132
INPUT
12~36 Volt
POWER
4 Channels x 5 Ampere max.
MAX. LOAD
240 Watt (12 Volt) / 480 Watt (24 Volt)
SIZE
178 x 45 x 19 mm
ART.NR
214-148
INPUT
12~36 Volt
POWER
1 Channel
MAX. LOAD
700mA x 12V~36V
SIZE
101 x 36 x 21 mm
ART.NR
214-150
INPUT
12~36 Volt
POWER
4 Channels
MAX. LOAD
4 x 350mA x 12V~36V
SIZE
178 x 45 x 19 mm
ART.NR
214-133
INPUT
12~36 Volt
POWER
4 Channels
MAX. LOAD
4 x 700mA x 12V~36V
SIZE
178 x 45 x 19 mm
Calculation example for constant voltage:
Power input depends on the input of the load. For a load of LED Strip 12V, a
12V power supply is required. Power depends on the needed power for load.
A 5 meter LED strip 12V with 10 Watt p/meter requires a power supply of 12V
with a minimum of 50 Watt.
To control constant voltage LED applications
(for example LED Flex Tape 12V24V)
To control constant current LED applications
(for example Universal or Downlight modules 700mA)
Calculation example for constant current:
To control 3 x universal module High Power 148-139 (pag. 52 | 2,5 Watt x
0,7 Ampere = 3,6 Volt) the voltage is 10,8 Volt and 7,5 Watt. A 12 Volt power
supply with a minimum power of 8 Watt is needed, for example 215-030.
To control 2 x universal module COB 148-146 (pag. 52 | 3,3 Watt x 0,35 Ampere = 9,4 Volt) the voltage is 18,8 Volt and 6,6 Watt. A 24 Volt power supply
with a minimum power of 7 Watt is needed, for example 215-042.
WWW.TRONIXLIGHTING.COM
205
Controllers
RECEIVER WITH REMOTE CONTROL
350 mA | 700 mA
INPUT
OUTPUT
OUTPUT
240V
350
mA
700
mA
INPUT
OUTPUT
OUTPUT
240V
350
mA
700
mA
DIMMABLE
-
+
WARRANTY
CERTIFICATE
2
years
Battery type: 3x AAA (not included)
Input: 220 - 240V
Dimmable: Yes
IP rate: IP20
Connection type: Screw
ART. NR.
OUTPUT
OUTPUT VOLTAGE
POWER
LENGTH
WIDTH
HEIGHT
214-160
350 mA
24~42 Volt
14,7 Watt
115 mm
45 mm
31 mm
214-161
700 mA
12~24 Volt
16,8 Watt
115 mm
45 mm
31 mm
RECEIVER WITHOUT REMOTE CONTROL
350 mA | 700 mA | 1050 mA
DIMMABLE
-
+
WARRANTY
CERTIFICATE
2
years
Input: 220 - 240V
Dimmable: Yes
IP rate: IP20
Connection type: Screw
ART. NR.
OUTPUT
OUTPUT VOLTAGE
POWER
LENGTH
WIDTH
HEIGHT
214-164
350 mA
24~42 Volt
14,7 Watt
115 mm
45 mm
31 mm
214-165
700 mA
12~24 Volt
16,8 Watt
115 mm
45 mm
31 mm
215-162
1050 mA
12~24 Volt
44,1 Watt
135 mm
45 mm
31 mm
REMOTE FUNCTION (RF) CONTROLLER
FOR 214-16X SERIE | TOUCH REMOTE
Battery type: 3x AAA (not included)
IP rate: IP20
206
ART. NR.
LENGTH
WIDTH
HEIGHT
214-163
114 mm
55 mm
23 mm
DIMMABLE
-
+
WARRANTY
2
years
CERTIFICATE
Controllers
LED DIMMER UNIVERSAL | TRAILING EDGE
10W ~350W
POWER
WARRANTY
10W
~
350W
3
years
CERTIFICATE
CERTIFICATE
Input: 220 - 240V
Dimming method: Trailing edge
Power: 10W ~ 350W
IP rate: IP20
ART. NR.
MIN.~MAX. LOAD LENGTH
WIDTH
MOUNTING DEPTH
215-131
10 Watt ~350 Watt
70 mm
24 mm
ART. NR.
DESCRIPTION
215-132
Plate for Universal Dimmer Art. nr. 215-131
70 mm
LED DIMMER 0-10V | INDOOR | ROUND
DIMMABLE
-
Dimming method: 0 - 10 Volt
Diameter: 42 mm
Diameter button: 20 mm
IP Rate: IP20
ART. NR.
DIMMING
215-130
0-10 Volt
0-10V
+
WARRANTY
CERTIFICATE
3
years
Height: 37 mm
Wire length: 140 mm
Connection Type: Stripped Wire
Material : Aluminium (Brushed)
LED DIMMER 12V/24V | POTENTIOMETER BASED
To use between power supply and LED fixture
INPUT
INPUT
WARRANTY
12V
24V
3
years
CERTIFICATE
CERTIFICATE
Input: 12/24V
IP rate: IP20
Connection type: Screw
ART. NR.
MAXIMUM POWER
LENGTH
WIDTH
DEPTH
214-118
96 Watt (12V)
192 Watt (24V)
90 mm
60 mm
60 mm
WWW.TRONIXLIGHTING.COM
207
Controllers
DIMMING MODULE | 12V/24V
DIMMABLE
To dim 12/24 constant voltage by 0-10 Volt
-
0-10V
+
WARRANTY
CERTIFICATE
CERTIFICATE
CERTIFICATE
CERTIFICATE
CERTIFICATE
CERTIFICATE
CERTIFICATE
CERTIFICATE
CERTIFICATE
CERTIFICATE
3
years
Input: 12- 36V
IP rate: IP20
Size: 101 x 36 x 21 mm
Connection type: Screw
ART. NR.
POWER OUTPUT
DIMMING
LENGTH
WIDTH
DEPTH
214-136
1*8 Ampère (96-288 Watt)
0-10V
115 mm
36 mm
21 mm
DIMMING MODULE | 700 mA
DIMMABLE
To dim constant current 700mA by 0-10 Volt
-
0-10V
+
WARRANTY
3
years
Input: 12- 36V
Output: 700mA
IP rate: IP20
Size: 101 x 36 x 21 mm
Connection type: Screw
ART. NR.
POWER OUTPUT
DIMMING
LENGTH
WIDTH
DEPTH
214-137
700 mA (8,4 - 25,2 Watt)
0-10V
115 mm
36 mm
21 mm
DIMMING MODULE | 12V/24V
DIMMABLE
To dim 12/24 constant voltage by Dali.
-
DALI
+
WARRANTY
3
years
Input: 12- 36V
IP rate: IP20
Size: 95 x 36 x 21 mm
Connection type: Screw
ART. NR.
POWER OUTPUT
DIMMING
LENGTH
WIDTH
DEPTH
214-156
1*8 Ampère (96-288 Watt)
Dali
95 mm
36 mm
21 mm
IR MOTION SENSOR | 360°
INPUT
WARRANTY
240V
2
years
INPUT
WARRANTY
240V
2
years
Input: 220V
Time delay: 10 sec. - 7 min. (adj.)
Detection motion speed: 0,6 - 1,5 m/sec
IP Rate: IP20
ART. NR.
DETECTION RADIUS
MAXIMUM LOAD
DETECTION DISTANCE
AMBIENT LIGHT
214-120
360°
800 Watt
Max. 8 meter
10-2000 Lux (adj.)
IR MOTION SENSOR | 180° | IP44
Input: 220V
Time delay: 10 sec. - 7 min. (adj.)
Detection motion speed: 0,6 - 1,5 m/sec
IP rate: IP44
Installation Height: 1,8 - 2,5m
208
ART. NR.
DETECTION RADIUS
MAXIMUM LOAD
DETECTION DISTANCE
AMBIENT LIGHT
214-119
180°
1200 Watt
Max. 12 meter
3-2000 Lux (adj.)
Controllers
REMOTE FUNCTION (RF) CONTROLLER 12/24V
INPUT
INPUT
WARRANTY
12V
24V
3
years
INPUT
INPUT
WARRANTY
12V
24V
3
years
CERTIFICATE
CERTIFICATE
CERTIFICATE
CERTIFICATE
Input: 12/24V
Current: 12A (3*4A)
Power: 144W-288W
Remote control: Yes, (Radio Frequent)
Battery type: 3x AAA (not included)
IP rate: IP20
ART. NR.
CONTROLER SIZE (LxWxD)
214-114
130 x 64 x 24 mm
REMOTE CONTROL WITH JOG WHEEL & 10 PRESET
Including internal rechargeable battery and USB charger cable.
Input: 12/24V
Maximum power: 72W-144W
Range: 20 meter
Nr. of programs: 10
Rechargeable: Yes (USB)
Dimmable: Yes
IP Rate: IP20
Art. nr. 214-121
ART. NR.
DESCRIPTION
LENGTH
WIDTH
DEPTH
214-121
Remote control with jog wheel & 10 presets
125 mm
55 mm
14 mm
214-122
RGB receptor 3x2A | 12/24V
150 mm
21 mm
18 mm
Art. nr. 214-122
WWW.TRONIXLIGHTING.COM
209
Controllers
RGB + WHITE REMOTE CONTROL RF | 2 OR 8 ZONES
WARRANTY
CERTIFICATE
CERTIFICATE
3
years
Battery type: 3x AAA (not included)
Range: 20 meter
Nr. of fixed programs: 10 different modes
IP Rate: IP20
Art. nr. 214-142
Art. nr. 214-155
Art. nr. 214-157
ART. NR.
REMOTE CONTROL
NR. OF ZONES
BUILT IN CHANGING PATTERNS
PATTERNS
LENGTH
WIDTH
DEPTH
214-142
RGB+W Remote Control
2
4 built-in changing patterns
4 scenes can be saved
131,6 mm
43,8 mm
24,5 mm
214-157
RGB+W Remote Control
4
3 built-in changing patterns
3 scenes can be saved
120 mm
55 mm
17 mm
214-155
RGB+W Remote Control
8
10 built-in changing patterns
4 colors can be saved
131,6 mm
43,8 mm
24,5 mm
ART. NR.
RGB CONTROLLER
214-143
RGB+W Controller 12V~36V
RGB controlling with DMX or Data repeaters
RGB RGB
RGB controlling with data repeaters or DMX
Power supply
Data Repeater
Advantages data repeater
•
Easy install
•
Intented for small projects
•
Cheaper to buy
RGB product
Power supply
Power supply
RGB Controller
Data Repeater
RGB product
Power supply
Data Repeater
RGB product
DMX DMX
Power supply
DMX receiver
Advantages DMX
•
More stable over long length
•
Suitable for large projects
•
More possibilities (RGB Product
separately to operate)
RGB product
Power supply
Power supply
DMX Master
DMX receiver
RGB product
Power supply
DMX receiver
210
RGB product
Controllers
DMX WAND CONTROLLER
To use in combination with Art. nr. 214-113 or 214-140
Input: 12/24V
Output: DMX512
Nr. of channels: 4 (DMX out)
IP Rate: IP20
ART. NR.
COLOR
214-135
Black
214-139
White
ART. NR.
ADVICED PRODUCTS
DMX Receiver 3*6A Constant Voltage
214-140
DMX Receiver 4*5A Constant Voltage
214-141
DMX Receiver 5*700mA Constant Current
215-020
Power Supply Wall Type Watt Indoor | 12V | 6W
DMX RECEIVER | 3 CHANNELS * 6 AMPERE
Works with each DMX-master or with DMX wall panel Art. 214-135 en 214-139
ART. NR.
LENGTH
WIDTH
DEPTH
128 mm
42 mm
33 mm
DMX RECEIVER | 4 CHANNELS * 8 AMPERE
Works with each DMX-master or with DMX wall panel Art. 214-135 en 214-139
3
years
CERTIFICATE
CERTIFICATE
INPUT
INPUT
12V
24V
DIMMABLE
-
+
WARRANTY
CERTIFICATE
CERTIFICATE
CERTIFICATE
CERTIFICATE
CERTIFICATE
CERTIFICATE
3
years
INPUT
INPUT
INPUT
12V
24V
36V
DIMMABLE
-
+
WARRANTY
3
years
Control method: DMX512
IP Rate: IP20
Connection type: Screw
Color: White
ART. NR.
LENGTH
WIDTH
DEPTH
214-140
128 mm
58 mm
29 mm
DMX RECEIVER | 5 CHANNELS * 700mA
Works with each DMX-master or with DMX wall panel Art. 214-135 en 214-139
Input: 12-36V
Output: 5 x 700mA
Power: 5 x 8,4-25,2W
Dimmable: Yes
Remote control: No
WARRANTY
Control method: DMX512
IP Rate: IP20
Connection type: Screw
Material: Aluminium
Color: Black
214-113
Input: 12-36V
Output: 4 x 8 Ampère
Power: 4 x 96-192W
Dimmable: Yes
Remote control: No
INPUT
24V
Operation: Color wheel
Connection type: Screw
Size: 86 x 86 x 35 mm
Mounting: Wall panel
214-113
Input: 12/24V
Output: 3 x 6 Ampère
Power: 3 x 72-144W
Dimmable: Yes
Remote control: No
INPUT
12V
INPUT
INPUT
INPUT
12V
24V
36V
DIMMABLE
-
+
WARRANTY
3
years
Control method: DMX512
IP Rate: IP20
Connection type: Screw
Color: White
ART. NR.
LENGTH
WIDTH
DEPTH
214-141
178 mm
46 mm
18 mm
WWW.TRONIXLIGHTING.COM
211
Controllers
DMX MASTER | MAX. 32 CHANNELS
Can be used in combination with remote controls Art. nrs. 214-142, 214-155 and 214-157
INPUT
WARRANTY
220V
3
years
CERTIFICATE
CERTIFICATE
CERTIFICATE
Input: 110-220V
Output: Up to 32 channels
IP rate: IP20
Connection type: Screw
Color: White
ART. NR.
DIMMING
LENGTH
WIDTH
DEPTH
214-153
178 mm
57 mm
21 mm
21 mm
ART. NR.
ACCESSORY
214-142
RGB+W Remote Control | 2 zones
214-157
RGB+W Remote Control | 4 zones
214-155
RGB+W Remote Control | 8 zones
See page 211
WIFI RECEIVER | 5 CHANNELS * 5 AMPERE | iOS/ANDROID
iOS/Android compatible.
Can also be used in combination with remote controls Art. nrs. 214-142, 214-155 and 214-157
Input: 12-36V
Output: 4 x 5 Ampère
Power: 4 x 60-180W
Control method: by iOS/Android or remote
ART. NR.
LENGTH
WIDTH
DEPTH
178 mm
55 mm
21 mm
ART. NR.
ACCESSORY
RGB+W Remote Control | 2 zones
214-157
RGB+W Remote Control | 4 zones
214-155
RGB+W Remote Control | 8 zones
Tip:
Use the free App Easy Color Pro!
212
INPUT
INPUT
WARRANTY
24V
36V
3
years
CERTIFICATE
CERTIFICATE
IP Rate: IP20
Connection type: Screw
Color: White
Ambient temperature: -20°C / +50°C
214-149
214-142
INPUT
12V
See page 211
Controllers
RGB DATA REPEATER | 3 CHANNELS | 12/24V
INPUT
INPUT
WARRANTY
12V
24V
3
years
INPUT
INPUT
WARRANTY
12V
24V
3
years
CERTIFICATE
CERTIFICATE
CERTIFICATE
CERTIFICATE
Input: 12/24V
Output: 3 * 8 Ampère
Power: 3 * 96-192W
IP Rate: IP20
Connection type: Screw
Material: Aluminium
Color: Black
ART. NR.
LENGTH
WIDTH
DEPTH
214-128
91 mm
90 mm
24 mm
RGB DATA REPEATER | 4 CHANNELS | 12/36V
Input: 12-36V
Output: 4 * 5 Ampère
Power: 4 * 60-180W
IP Rate: IP20
Connection type: Screw
Color: Black
ART. NR.
LENGTH
WIDTH
DEPTH
214-127
178 mm
45 mm
19 mm
WWW.TRONIXLIGHTING.COM
213
Drivers
Dimming LED modules
1. Primary
LED dimmer
LED Module:
for example 148-150
Primary dimmable LED driver
230V
230V
For example:
For example: 215-131
or other brand LED dimmer
215-250 (700mA)
215-350 (350mA)
2. 0-10V
0-10V LED Driver
215-110 (Adjustable 350/700mA, 10/20 Watt)
215-210 (700mA, 40 Watt)
230V
input
output
1-10V
215-130
or other brand 0-10V dimmer
LED Module
for example 148-140
3. Wireless
Remote:
LED Module
for example 148-149
214-130
214-134
214-131
214-146
214-144
214-145
Powersupply:
230V
700mA
For example 215-056
214-148
Input
12-36VDC
Receiver:
LED
12-24V
1
214-133
3
lin=20.5A
4
Learning Key
2
RF Easy Dimmer
700mA
700mA LED Module:
for example 148-140
214
230V
214-130
Remote:
3. Wireless
230V
214-146
215-051*
RF Easy Dimmer
Learning Key
214-132
lin=20.5A
214-147
Receiver:
214-118*
Dimmer 12/24V
215-400*
215-402*
Primary dimmable powersupply
12 - 24V
214-145
230V
12 - 24V
214-144
215-401*
Powersupply
215-131*
Powersupply
214-131
2. Secundary
230V
LED dimmer
Input
12-36VDC
1. Primary
LED
1
2
3
4
Voltage dimming 12 -24 Volt
12 - 24V
12 - 24V
12 - 24V
12 - 24V
127-041*
Flextape
127-069*
Flextape
127-065*
Flextape
Drivers
WWW.TRONIXLIGHTING.COM
215
Register
010-023
010-203
010-205
010-207
010-209
045-001
045-002
045-003
045-004
045-005
045-008
050-001
050-002
050-003
050-004
050-005
050-008
055-001
055-002
055-003
055-004
055-005
055-008
055-011
055-018
055-101
055-108
055-201
055-202
055-203
065-005
065-006
065-007
065-010
075-030
075-031
075-033
075-050
075-051
075-058
075-060
075-061
075-062
075-063
075-064
075-071
075-080
075-081
075-082
075-082
075-225
075-225
076-006
076-006
076-007
076-007
076-008
076-008
076-009
076-009
076-010
076-010
076-011
076-011
076-015
076-015
076-016
076-016
076-017
076-100
076-102
076-103
076-104
216
105
105
105
105
105
174
174
174
174
174
174
174
174
174
174
174
174
173
173
173
173
173
173
173
173
173
173
173
173
173
173
173
173
174
166
166
166
166
166
166
167
167
167
167
167
169
169
169
169
169
169
169
169
169
169
169
169
169
169
169
169
169
169
169
169
169
169
169
169
160
160
160
160
076-105
076-106
076-110
076-115
076-116
076-117
076-118
077-051
077-058
077-060
077-062
077-066
077-069
110-040
110-041
110-042
110-043
110-044
110-045
110-048
110-140
110-141
110-142
110-143
110-144
110-145
110-146
110-148
110-245
115-050
115-051
115-051
115-052
115-053
115-054
115-054
115-055
115-056
115-058
115-059
115-060
115-061
115-062
115-064
115-064
120-101
120-104
120-107
120-108
127-000
127-001
127-002
127-003
127-004
127-005
127-008
127-010
127-039
127-041
127-042
127-043
127-044
127-049
127-058
127-059
127-060
127-062
127-063
127-064
127-065
127-066
127-067
127-068
160
160
160
160
160
160
160
167
167
167
167
167
167
164
164
164
164
164
164
164
164
164
164
164
164
164
164
164
164
164
164
166
164
164
164
166
164
164
164
164
164
164
164
164
166
161
161
161
161
148
143
143
143
143
143
143
149
146
145
143
143
143
143
145
145
143
145
147
149
143
143
143
144
127-069
127-070
127-072
127-073
127-074
127-075
127-078
127-088
127-090
127-098
127-101
127-102
127-108
127-111
127-200
127-203
127-204
127-224
127-225
127-226
127-227
127-228
127-229
127-230
127-230
127-231
127-231
127-232
127-232
127-233
127-233
127-233
127-234
127-234
127-235
127-235
127-235
127-240
127-241
127-242
127-243
127-244
127-245
127-246
127-248
127-249
127-250
127-251
127-252
127-253
127-255
127-256
127-260
127-261
127-262
127-263
127-264
127-265
127-266
127-267
127-268
127-269
127-270
127-272
127-273
127-274
127-275
127-276
127-280
127-281
127-282
127-286
127-286
144
150
150
144
144
149
146
146
144
147
148
148
147
145
161
148
143
157
153
156
156
153
153
153
161
157
161
153
161
153
154
161
156
161
156
157
161
155
155
155
153
153
158
157
155
154
161
161
161
154
158
158
157
154
154
159
158
159
159
156
156
156
161
161
153
156
157
159
143
143
148
149
161
127-287
127-287
127-288
127-288
127-288
127-289
127-289
127-340
127-340
127-342
127-342
127-343
127-343
127-343
127-344
127-344
127-345
127-345
127-346
127-346
127-348
127-348
127-349
127-349
127-353
127-353
127-355
127-355
127-356
127-356
127-360
127-360
127-361
127-361
127-363
127-363
127-364
127-364
127-365
127-365
127-366
127-366
127-367
127-367
127-369
127-369
127-375
127-376
127-376
127-446
127-446
127-449
127-449
127-462
127-466
127-466
127-466
127-467
127-467
127-469
127-469
127-476
127-525
127-526
127-528
127-543
127-544
127-561
127-562
127-566
135-044
135-045
135-046
149
161
147
150
161
146
161
155
161
155
161
153
154
161
153
161
158
161
157
161
155
161
154
161
154
161
158
161
158
161
157
161
154
161
159
161
158
161
159
161
159
161
156
161
156
161
157
159
161
157
161
154
161
154
153
159
161
156
161
156
161
159
153
156
153
153
153
154
154
159
29
29
29
Register
135-140
135-142
135-143
136-002
136-003
136-004
136-005
136-007
136-009
136-010
136-012
136-013
136-020
136-022
136-023
136-024
136-055
136-056
136-063
136-063
136-064
136-064
136-068
136-068
136-070
136-071
136-072
136-073
136-090
136-091
136-092
136-093
136-094
136-095
136-165
136-166
136-167
137-001
137-002
137-004
137-005
137-009
137-010
140-001
140-002
140-003
140-004
140-005
140-006
140-020
140-030
140-051
140-051
140-052
140-055
140-055
140-059
140-059
140-060
140-063
140-063
140-070
140-071
140-073
142-006
142-007
146-000
146-000
146-009
146-011
146-012
146-018
146-019
30
30
30
34
34
34
34
23
23
22
22
22
33
33
33
33
33
33
20
20
20
20
20
20
17
17
17
17
20
20
20
20
20
20
20
20
20
25
25
25
25
25
25
133
133
133
133
133
133
134
134
132
132
132
132
132
132
132
132
132
132
132
131
131
134
134
94
95
96
95
95
95
96
146-021
146-023
146-026
146-028
146-029
146-038
146-039
146-041
146-048
146-058
146-068
146-071
146-078
146-088
146-098
146-100
146-101
146-102
146-102
146-108
146-118
146-157
146-158
146-159
146-160
146-161
146-162
146-172
146-173
146-174
146-175
146-176
146-177
146-178
146-179
146-200
146-200
146-201
146-250
146-251
146-253
146-255
146-256
146-257
146-258
146-263
146-265
146-266
148-000
148-001
148-002
148-003
148-004
148-005
148-020
148-021
148-022
148-023
148-024
148-025
148-030
148-031
148-032
148-033
148-034
148-035
148-043
148-044
148-050
148-051
148-101
148-102
148-103
95
94
95
95
97
94
97
96
94
94
94
94
95
96
96
95
96
96
97
97
97
99
99
99
102
102
101
103
103
103
103
103
103
103
103
96
97
105
99
99
101
99
100
99
99
100
102
99
88
88
88
88
88
88
88
88
88
88
88
88
89
89
89
89
89
89
87
87
87
87
51
51
51
148-104
148-105
148-111
148-112
148-113
148-114
148-115
148-119
148-125
148-126
148-127
148-128
148-128
148-129
148-137
148-139
148-140
148-141
148-146
148-147
148-149
148-150
148-151
148-155
148-162
148-163
148-164
148-165
148-201
148-251
148-258
148-259
148-260
148-268
148-278
148-300
148-302
148-303
148-304
148-305
148-306
148-411
148-411
148-411
148-413
148-413
148-423
148-426
148-501
148-507
148-508
148-511
148-518
148-528
148-529
148-530
148-535
148-550
148-551
148-552
148-553
148-555
148-556
148-557
148-558
148-559
148-560
148-561
148-562
148-563
148-564
148-565
149-001
51
51
56
56
56
56
56
56
63
63
61
59
59
59
51
51
52
52
51
51
56
57
57
56
52
52
52
52
52
61
61
61
61
61
65
67
67
67
67
67
67
59
59
59
59
59
61
61
27
89
57
27
57
31
31
59
59
89
89
89
89
89
89
89
89
89
89
89
89
89
89
89
137
149-002
149-003
149-004
149-005
149-011
149-012
149-016
149-021
149-022
149-026
149-027
149-032
149-036
149-041
149-042
149-046
149-088
149-089
149-090
149-110
149-135
149-136
149-137
149-200
149-201
149-202
149-301
149-303
149-304
149-305
149-306
149-307
149-308
149-309
150-001
165-000
165-009
165-010
165-011
165-012
165-013
165-014
165-015
165-018
165-020
165-021
165-022
165-023
165-024
165-025
165-028
165-071
165-072
165-073
165-074
165-075
165-783
165-784
165-785
165-786
165-787
165-788
165-790
169-002
169-003
169-005
169-006
169-007
169-008
169-009
169-010
169-011
169-012
137
137
137
137
136
136
136
136
136
136
26
136
136
136
136
136
137
137
137
27
27
26
26
25
25
25
139
139
139
139
140
140
140
140
31
82
82
82
83
83
83
83
83
83
83
83
83
83
83
83
83
83
83
83
83
83
82
82
82
82
82
82
82
49
49
48
48
48
48
48
49
48
48
WWW.TRONIXLIGHTING.COM
217
Register
169-013
169-014
169-015
169-016
169-017
169-020
169-021
169-022
169-023
169-024
169-025
169-026
169-027
169-028
169-029
169-030
169-031
169-032
169-033
169-035
169-036
169-037
169-038
169-039
169-040
169-041
169-042
169-043
169-044
169-045
169-046
169-047
169-048
169-049
169-050
169-051
169-053
169-054
169-055
169-056
169-057
169-058
169-059
169-064
169-065
169-066
169-067
169-069
169-070
169-072
169-073
169-074
169-075
169-075
169-075
169-076
169-077
169-078
169-079
169-080
169-086
169-087
169-089
169-089
169-089
169-089
169-089
169-090
169-091
169-092
169-093
169-094
169-095
218
48
49
48
49
48
49
49
49
48
48
48
48
48
48
49
49
48
48
48
48
49
49
49
49
48
48
48
48
48
48
49
49
48
48
47
47
47
47
47
47
41
41
41
41
41
42
42
46
48
48
49
49
23
41
43
42
42
42
42
41
42
44
23
41
43
44
46
42
41
44
44
44
46
169-096
169-097
169-098
169-098
169-099
169-099
169-100
169-101
169-102
169-103
169-104
169-105
169-106
169-110
169-111
174-014
174-016
174-018
174-033
174-034
174-041
174-050
174-080
174-081
174-082
174-083
174-084
174-101
174-103
174-140
174-141
174-142
174-143
174-144
174-145
174-146
174-147
174-149
174-150
174-151
174-158
174-159
174-160
174-161
174-162
174-163
174-164
174-165
174-166
174-167
174-168
174-169
174-170
174-171
174-172
174-173
174-174
174-175
174-176
174-177
174-178
174-179
174-180
174-181
174-182
174-183
174-184
175-001
175-002
175-003
175-004
175-006
175-117
46
46
44
46
43
43
43
49
49
49
49
49
49
41
41
15
15
15
10
10
8
11
15
15
15
15
15
11
11
7
7
10
10
10
7
7
7
10
8
8
7
7
7
7
7
7
7
7
7
10
10
10
10
10
10
10
10
10
7
7
7
10
10
10
7
7
7
77
77
77
77
77
76
175-118
175-118
175-118
175-120
175-125
175-126
175-131
175-131
175-131
175-132
175-133
175-134
175-135
175-135
175-135
175-136
175-139
175-139
175-139
175-214
175-214
175-230
175-230
175-230
175-231
175-231
175-231
175-232
175-270
175-299
175-311
175-313
175-313
175-314
175-314
175-316
175-316
175-320
175-321
175-340
175-343
175-343
175-344
175-344
175-362
175-500
175-501
175-502
175-503
175-504
175-505
175-508
175-510
175-510
175-511
175-511
175-530
175-530
175-531
175-531
175-532
175-532
175-533
175-533
175-704
175-730
175-732
175-733
175-759
175-760
175-761
175-762
175-770
47
47
76
76
77
77
47
47
76
77
77
77
47
47
76
76
47
47
76
47
74
47
47
74
47
47
74
74
72
72
72
71
87
71
87
72
87
71
71
73
73
87
73
87
81
84
84
84
84
85
85
85
25
85
25
85
127
75
127
75
127
75
127
75
81
78
78
78
78
78
78
78
80
175-780
175-781
175-782
175-880
175-881
175-882
176-001
176-002
176-006
176-007
176-008
176-009
176-016
176-017
176-018
177-029
177-033
177-035
177-036
177-037
177-039
177-053
177-053
177-054
177-054
177-058
177-058
178-002
178-010
190-077
190-078
190-079
200-001
200-003
200-004
214-114
214-180
215-131
215-201
215-202
215-210
215-210
215-210
215-210
215-211
215-212
215-216
215-249
215-250
215-250
215-250
215-251
215-251
215-251
215-251
215-252
215-252
215-252
215-252
215-260
215-260
215-260
215-260
215-261
215-261
215-261
215-262
215-262
215-262
215-270
215-270
215-270
215-270
79
79
79
79
79
79
70
70
70
70
70
70
70
70
70
69
69
69
69
69
69
125
69
125
69
125
69
35
35
105
105
105
141
141
141
8
164
81
66
66
17
22
66
20
66
66
17
66
10
66
20
46
41
66
20
17
22
66
20
17
22
66
20
15
66
20
10
66
20
15
17
66
20
Register
215-303
215-303
215-305
215-305
215-306
215-307
215-310
215-349
215-349
215-350
215-350
215-350
215-350
215-407
215-412
220-021
220-022
220-027
220-028
220-030
220-031
220-032
220-040
220-060
480-030
480-035
480-040
480-045
480-050
480-075
485-010
485-015
485-020
485-025
485-030
485-031
485-050
485-050
485-055
485-055
485-060
485-060
485-070
485-070
485-085
485-085
485-090
485-090
485-100
485-100
485-105
485-105
485-110
485-110
485-113
485-113
485-160
485-160
485-165
485-165
485-170
485-170
590-071
590-072
590-073
590-074
590-075
595-030
600-001
600-001
600-002
600-002
600-003
133
66
133
66
66
66
137
15
66
15
17
66
20
20
66
127
127
128
128
128
128
128
127
128
175
175
175
175
175
175
175
175
175
175
175
175
175
175
175
175
175
175
175
175
175
175
175
175
175
175
175
175
175
175
175
175
175
175
175
175
175
175
178
178
178
178
178
11
37
37
37
37
39
600-004
600-004
600-005
600-005
600-006
600-007
600-007
600-008
600-010
600-011
600-012
600-013
600-014
600-015
600-016
833-001
833-006
833-008
833-009
833-015
950-010
950-030
950-032
950-034
950-035
950-037
950-038
950-040
950-040
950-041
950-041
950-042
950-042
950-043
950-043
950-044
950-044
950-045
950-045
950-060
950-065
950-066
950-067
950-070
950-071
950-072
34
39
34
39
37
37
37
39
37
37
37
37
37
37
37
181
181
181
181
181
35
109
112
109
112
113
113
109
112
109
112
109
112
109
112
109
112
109
112
124
125
125
125
124
124
124
WWW.TRONIXLIGHTING.COM
219
Notes
220
Tronix Lighting BV
Vluchtoord 41, 5406 XP Uden
The Netherlands
Postbus 205, 5400 AE Uden
The Netherlands
Tel. 0031 (0) 413 330380
www.tronixlighting.com
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
