DESCRIPTION
The ELITE AC/DC 225 is the new generation of multi functional high quality
welding machine, designed and developed independently by our company.
The welder adopts a microcomputer system control, dual current loop PWM
control, full-bridge high frequency inverter system. It has convenient operation,
stable performance, small size and high duty cycle. The welder is mainly
applied to the welding of aluminum, aluminum alloy, copper, titanium, and
other non-ferrous metals and stainless steel, carbon steel and other metals,
Characteristics
☆ High successful rate of arc start
☆ Stable arc without breaking arc
☆ Safety, efficiency
☆ One model, seven functions:
◆ TIG/DC
◆ TIG/PULSE
◆ TIG/AC
◆ TIG/AC
/PULSE
◆ TIG/MIX
◆ TIG/SPOT
◆ MMA
SAFETY
Arc welding can be dangerous and can cause serious and even fatal
injuries
Protect yourself and others
Ensure the following safety precautions are taken:
Arc radiation
Protect yourself with a hamlet fitted with filters
Rain, steam, damp Use your welding unit in a clean/dry environment, on a flat surface.
Electric shock
Falls
This device must only be used with an earthed power supply. Do no
touch high voltage parts. Check that the power supply is suitable for
this unit
Ensure the unit is placed in a stable position to prevent the machine
from falling onto prople/objects
Burns
Wear protective (fire-proof) clothing (cotton, overalls or jeans).
Wear protective gloves and a fire-proof apron
Ensure other people keep a safe distance from the work area and do
not look directly at welding arc.
protect others by installing fire-proof protection walls.
Fire risks
Remove all flammable products from the work area. Do not work in
presence of flammable gases
Fumes
Do not inhale welding gases and fumes. Use the device in a well
ventilated environment, with artificial extraction if welding indoors
Additional
Precautions
Any welding operation undertaken in.....
- rooms where there is an increased risk of electric shocks,
- poorly ventilated rooms,
- in the presence of flammable or explosive material,
should always be approved by a "responsible expert”, and made in
presence of people trained to intervene in case of emergency.
Technical protection as described in the Technical Specification
CEI/IEC 62081 must be implemented. Welding in raised positions is
forbidden, except in case of safety platforms use.
SPECIFICATION
TIG
/DC
Rated input
voltage
Max
input
power factor
Rated open
voltage
Load voltage 10.2~18
V
Welding
5~200
current A
Arc current A
5~200
Base
/
current %
Crater current
5~200
Arc
force
/
current
Pulse
/
Frequency Hz
Pulse ratio %
/
TIG
TIG
TIG/AC
TIG
TIG
/PULSE
/AC
/PULSE
/MIX
/SPOT
AC230V±15% (195V~265V) 50/60Hz
MMA
8.1KW
10.5KW
70V
10.2~18
10.4~18
10.4~18
10.4~18
10.2~18
70V/12
V
20.2~28
5~200
10~200
10~200
10~200
5~200
5~200
5~200
10~90
10~200
/
10~200
10~90
10~200
/
/
/
/
/
5~200
/
10~200
/
10~200
/
10~200
/
/
/
/
5~200
0.1~800
/
0.1~800
/
/
/
10~90
/
10~90
/
/
/
AC
Frequency
Hz
AC
Balance %
Slop up time
S
Slop
down
time S
Pre Gas Time
S
Post
Gas
Time S
Spot time S
Duty Cycle at
25 OC
/
/
30~
200
30~
200
30~
200
/
/
/
/
10~50
10~50
10~50
/
/
0~10
0~10
0~10
0~10
0~10
/
/
0~10
0~10
0~10
0~10
0~10
/
/
0~10
/
0~30
/
/
/
/
/
/
0.01-5
/
60
60
50
50
50
60
60
Insulation
class
IP class
Dimension
mm
F
IP21S
443*200*238
FRONT PANEL LAYOUT
The front panel includes 6 button switches ( welding model switch, welding
function switch, arc start switch, 2T/4T switch, VRD switch, data loading and
recall switch), 1 encoder switch, 33 LED indicator and 1digital display.
Welding model switch:
MMA
DC TIG
AC TIG
SPOT
Welding function switch
DC ( Pulse)
Pulse( output current will change periodically based on the setted Pulse
frequency and base current )
MIX (AC square wave current will be inserted a DC current to stabilize arc)
Arc start switch
LIFT TIG: Contact start
HF TIG: High frequency start without contact
2T/4T switch
2T: short welding
4T: long welding
VRD switch
ON/OFF
Working ( Open voltage will be limited DC 12V safe voltage)
Data loading and recall switch
Loading( 20 of setting mode can be saved)
Recall
Encode switch(Setting)
The switch can be turned and pushed. Turning for choosing program and
adjust data. Pushing for confirming and exit of program and data.
Setting:
Start setting: Push the setting switch to start the setting, the default setting
LEDs are on
Program choosing: Turn the setting switch to choose program for setting,
the matched LED will be on.
Adjust parameters: Push the setting again, the chosen LED shinning, then
turn the setting for adjust the parameters.
Parameter confirmation: .Push the setting again for confirmation set
parameters, the LED keeps on.
Exit of setting: Push the setting again, the chosen LED off, then quit the
setting.
Digital display
Current
Time
Frequency
Balance %
TIG/DC operation
Data setting: Choose the TIG /DC model, DC welding function, LIFT/HF ,
2T/4T, adjust the pre gas time, arc current, slope up time, peak current, slop
down time, crater current, slope down time.
1. Pre gas time setting: In order to ensure that the workpiece and the
tungsten from contamination and burnout, set the pre gas time to let go
argon air to push out the rest air in the torch. The pre-gas provides
protection for the area where the welding pool will be formed. It also
improved stability when the welding arc is created.
2. Arc current Setting: Usually set the current less than the max current.
3. Slop up time Setting: Time needed to go from minimum current welding
current.
4. Max Current: It is the welding current. Set the current refer to the TIG
welding table.
5. Slop down time Setting: Time needed to shift from welding current to
minimum current. Avoid cracks and craters at the end of welding.
6. Crater current Setting: Usually set the current less than the max current.
7. Post gas time Setting: In order to ensure that the workpiece and the
tungsten from contamination and burnout, set the pre gas time to let go
argon air keep some time. It protects the weld poil and the electrode
against oxidization whilst the metal is cooling after welding.
TIG/DC WELDING TABLE
WORKPIECE
Flow rate
( ) (Argon
L/mn)
Φ Electrode
(MM)
Φ Rod (filler
metal) MM
CURRENT A
0.6
1.0,1.6
~1.6
20~40
4
1.0
1.0,1.6
~1.6
30~60
4
1.6
1.6,2.4
~1.6
60~90
4
2.4
1.6,2.4
1.6~2.4
80~120
4
3.2
2.4,3.2
2.4~3.2
110~150
5
4.0
2.4,3.2
2.4~3.2
130~180
5
4.8
2.4,3.2,4.0
2.4~4.0
150~220
5
6.4
3.2,4.0,4.8
3.2~4.8
180~250
5
DEOXIDIZE
1.0
1.6
~1.6
60~90
3~4
D COPPER
1.6
2.4
1.6~2.4
80~120
3~4
2.4
2.4,3.2
2.4~3.2
110~150
4
3.2
3.2,4.0
3.2~4.8
140~200
4~5
4.0
3.2,4.0,4.8
4.0~4.8
180~250
4~5
4.8
4.0,4.8
4.8~6.4
250~300
5~6
6.4
4.0,4.8,6.4
4.8~6.4
300~400
5~6
1.0
1.6
~1.6
50~60
5~6
1.6
1.6,2.4
~1.6
60~90
5~6
2.4
1.6,2.4
1.6~2.4
80~110
6~7
3.2
2.4,3.2
2.4~4.0
100~140
6~7
4.0
3.2,4.0
3.2~4.8
140~180
7~8
4.8
3.2,4.0,4.8
4.0~6.4
170~220
7~8
6.4
4.0,4.8
4.0~6.4
200~270
8~12
1.0
1.6
~1.6
30~40
3~4
1.6
1.6,2.4
1.6~2.4
40~70
4~5
2.4
1.6,2.4
1.6~2.4
60~90
4~5
3.2
1.6,2.4
2.4~3.2
75~110
5~6
4.0
2.4,3.2
3.2~4.0
90~120
5~6
4.8
3.0,4.0
3.2~4.8
110~150
5~6
6.4
3.2,4.0
4.0~4.8
130~170
6~7
MATERIAL
THICKNESS
STAINLESS
STEEL
(DC+)
(DC+)
ALUMIUM
(AC)
Magnesi
um(AC)
(MM)
( )
To optimize the welding process, it is recommend to gind the electrode prior to
welding as described in the diagram below
TIG welding process
1 Shielding gas
2 Arc
3 TIG filler rod
4 Weld pool
5 Collect
6 Tunsten Electrode
7 Workpiece
TIG welding techniques
The suggested electrode and welding rod angles for welding a bead on plate.
The same angles are used when marking a butt weld. The torch is held 60-75o
from the metal surface. This is the same as holding the torch 15-30o from the
vertical. Take special note that the rod is in the shielding gas during the
welding process
TIG/DC/PULSE Operation
Data setting: Choose the TIG /DC model, Pulse welding function, LIFT/HF ,
2T/4T, adjust the pre gas time, arc current, slope up time, peak current, base
current, slop down time, crater current, slope down time, pulse frequency,
pulse ratio..
1. Base current setting: Usually set in a small value as long as not break the
arc.
2. Pulse ratio setting: The ratio determines the hear input, the bigger ratio it
is, the weld seam is wider and deeper and vice versa. Usually set the ration
between 30%-70%.
3. Pulse frequency setting: The higher frequency it is, the weld seam
denser and vice versa.
TIG/DC/PULSE welding Table1
GAP
MM
MATERIAL
MILD
STEEL
JOINT SHAPE
PULSE CONDITION
PEAK
BASE
PULSE
PULSE
FEED
SPEED
SPEED
CM/MIN
CM/MIN
CURREN
()
CURRE
FREQU
T A
NT A
ENCY
0
200
50
2.5
50
60
60
1.2
150
20
1.5
45
30
60
1.6
130
20
1
50
15
40
()
RATIO%
WELDING
(HZ)
0
150
50
3
50
80
40
STAINLES
1.2
150
20
1
35
17
40
S STEEL
1.6
130
20
0.8
30
10
40
2.0
130
20
0.8
30
83
0
0
280
50
3
50
80
1.2
280
50
2
50
50
1.6
280
50
1.5
40
25
0
200
100
1
30
25
COPPER
TITANIUM
75
75
0
); ELECTRODE : Thoriated tungsten
electrode (3.2MM); FILL METAL:Φ1.2MM; LENGTH OF ARC:2MM
SHILDING GAS: ARGON (10L/MIN
TIG/DC/PULSE welding Table2
GAP
MARTE
RIAL
MM
JOINT SHAPE
PULSE CONDITION
MAXC
BASE
PULSE
WELDING
FEED
PULSE
SPEED
SPEED
RATIO%
CM/MIN
CM/MIN
URR
CURREN
ENT
()
FREQUE
T A
NCY HZ
1
250
50
0.8
20
10
60
1
170
60
2.5
50
50
60
1
120
50
2
50
20
30
1
160
50
1.5
45
8.5
60
(A)
( )
STEEL+
MILD
STEEL
STAINL
ESS
STEE+
MILD
STEEL
MILD
STEEL
STAINL
ESS
STEEL
); ELECTRODE : Thoriated tungsten
electrode (2.4MM); FILL METAL:Φ1.2MM; LENGTH OF ARC:2-3MM
SHILDING GAS: ARGON (10L/MIN
TIG/AC Operation
Data setting: Choose the TIG /AC model, , LIFT/HF , 2T/4T, adjust the pre
gas time, arc current, slope up time, peak current, slop down time, crater
current, slope down time, AC frequency, AC balance.
1. AC frequency setting: The higher frequency it is , the arc concreted more
intensive, weld seam smoother, but the sound of arc relatively shrill.
Usually suggest the low AC frequency.
2. AC Balance (EP ratio) setting: It is the percentage of AC negative wave
against AC period. The higher it is, the weld seam smoother, but the
penetration more shallow, tungsten worn easier. Usually suggest the low
EP ratio
TIG/AC/Pulse Operation
Data setting: Choose the TIG /AC model, Pulse welding function, LIFT/HF ,
2T/4T, adjust the pre gas time, arc current, slope up time, peak current, base
current, slop down time, crater current, slope down time, Pulse frequency ,
Pulse Ratio , AC frequency, AC balance.
TIG/DC/PULSE welding Table2
THIC
MATE
Filler metal
PULSE CONDITION
KNE
PEAK
BASE
PULSE
PULES
DIAMET
FEED
SS
CURRE
CURRE
FREQUENCY
RATIO %
ER MM
SPEED
MM
NT A
NT A
HZ
JOINT SHAPE
RIAL
CM/MIN
75
1.0
70
25
1
50
1.6
1.5
80
40
1
50
1.6
1.5
90
25
1
50
1.6
1.5
85
25
1
50
1.2
3.2
170
25
1
50
1.2
3.0
170
25
1
50
1.6
6.0
220
25
1
50
1.6
95
75
ALUM
95
290
IUM
170
250
250
FIRST L
180
25
1
50
1.6
180
25
1
50
1.6
250
6.0
220
25
1
50
1.6
270
3.0
120
25
1
50
1.6
60
6.0
SECOND
TIG/MIX Operation
MIX TIG: AC welding 0.3s+DC welding 0.2s.
Data setting: Choose the TIG /AC mode, MIX welding function, LIFT/HF ,
2T/4T, adjust the pre gas time, arc current, slope up time, peak current,, slop
down time, crater current, slope down time, AC frequency, AC balance.
Welding can refer to the TIG DC instruction.
TIG/SPOT Operation
Data setting: Choose the SPOT mode, adjust the pre gas time, slope up
time(spot time), peak current,, slop down time.
In this mode, the machine can works in HF and 2T only.
MMA Operation
Data setting: Choose the MMA mode, adjust slope up time( Arc force), peak
current.
Welding current setting table- Flat welding
MM
ELECTRODE
Ilmenite electrode
Titania
calcium
electrode
2.6
3.2
4.0
4.5
5.0
50~85
80~130
120~180
145~200
170~250
50~100
90~130
140~180
160~210
190~150
low
hydrogen
electrode
55~85
100~140
140~190
190~250
Welding current setting table- Vertical welding
MM
ELECTRODE
Ilmenite electrode
Titania
calcium
electrode
low
hydrogen
electrode
2.6
3.2
4.0
4.5
5.0
40~70
60~110
100~150
120~180
130~200
50~90
80~130
110~170
125~190
140~210
50~80
90~130
120~180
160~210
TROUBLE SHOOTING
Symptom
Causes
The device does not Thermal protection is on
deliver any current
and the yellow LED
in on
No arc exists
Torch switch is useless
Power switch is broken
The cable to switch is disconnected
The cable to workpiece is disconnected
The cable of torch is broken
Starting arc is not
Connecting tie-in is loose
good or jarless
Argon gas is not pure
The tungsten electrode is no good fixed or its quality is no good
Surface of welding
Dunghill or grease exists on the surface of workpiece
line is no good
Argon gas is not pure
Flux of argon gas is not enough
Dunghill exists on the surface of tungsten electrode
Tungsten electrode Current is too great or tungsten electrode is too thin
wastes hard
Argon gas is not pure
Polarity error
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement

Languages
