Table of Contents
Operation Chart
Model No.
FP-D355/D355DC
FP-D455/D605
Options
Options
FA-A355/A888/F320/F350/F355/F365/FK35/FK36/TR350/TR355/RU350/RU355
FA-DS725/DS825/MA301/MADM8
Making Copies
Operating Instructions (For Copier)
Before operating
Digital Copier
FP-D350
Before operating this copier, please read
these instructions completely and keep these
operating instructions for future reference.
The digital copier with options
(See P.56)
English
Troubleshooting
Specifications
J
?
I
Energy Star
The FP-D355/D355DC/D455/D605 series copiers comply with Tier 2 of the Environmental
Protection Agency’s Energy Star Program. This voluntary program specifies certain energy
consumption and usage standards for copiers. These copiers will automatically “power down”
after a specified period of non-use. The use of these Energy Star compliant copiers will reduce
energy consumption and ultimately benefit the environment.
The default functions can be adjusted depending on your office requirements. Please see your
authorised Panasonic copier dealer for more details.
2
Table of Contents
Table of Contents
Before Operation
Operation Chart
■ Common features and usage ............................................................... 4
■ Function Categories ............................................................................ 5
Precautions .................................................................................................................................... 6
Control Panel
■ Control Panel ........................................................................................ 9
■ Touch Panel Display .......................................................................... 10
Making Copies
Basic Menu
Duplex/Original
H Copy
■ Full Size Copying ................................................................................ 12
■ Reduction or Enlargement Copying .................................................... 13
■ Using the Sheet Bypass ..................................................................... 14
■ 1 \ 2 Copy / 2 \ 1 Copy / 2 \ 2 Copy ............................................ 16
■ Book \ 2 Copy .................................................................................. 17
■ 2 Page Copy ...................................................................................... 18
■ N in 1 Copy ......................................................................................... 19
■ 1 to N Copy ........................................................................................ 25
■ SADF Mode ........................................................................................ 26
Zoom/Effects
■ Zoom Copying .................................................................................... 28
■ Centering/Mirror/Inverse copy ............................................................. 29
■ Edge/Margin/Book Mode .................................................................... 30
■ Page numbering ................................................................................. 31
Insertion Job
■ Cover/Page Insertion .......................................................................... 33
■ OHP Interleaving/Presentation ........................................................... 34
■ Job Memory ...................................................................................... 35
■ Sky Shot Modes ................................................................................. 36
■ Energy Saver/Interrupt ........................................................................ 38
■ Combining Function Table .................................................................. 39
Other Features
User Preset ................................................................................................................................... 40
■ General Functions .............................................................................. 41
■ Copier Settings ................................................................................... 42
■ General Functions for Key Operator ................................................... 44
■ Copier Settings for Key Operator ........................................................ 49
Options
Options
■ Options .............................................................................................. 56
■ ADF (FA-A355)/i-ADF (FA-A888) ........................................................ 57
■ 3 Bin Finisher, Exit Guide Unit (FA-F350/F355/FK35/FK36) .............. 59
■ 2 Bin Finisher, Exit Guide Unit (FA-F365/FK36/SP30) ....................... 62
■ 2 Bin Finisher, Exit Guide Unit (FA-F320/FK35/FK36) ....................... 67
■ Inverting Shift Tray (FA-TR350/TR355) ............................................... 72
Maintenance
Handling
Checking
■ Adding Paper ...................................................................................... 73
■ Adding Toner ....................................................................................... 75
■ Replacing the Waste Toner Bottle ...................................................... 76
■ Removing the Punch Dust ................................................................. 77
■ Removing a Paper Misfeed ................................................................. 78
■ Troubleshooting .................................................................................. 93
Specifications .............................................................................................................................. 95
System Information ..................................................................................................................... 99
3
Operation Chart
Common features and usage
■ Basic Operation
MULTI-SIZE
FEED
FP-D455
FP-D605
SORT/
FINISH
USER
PRESET
ENERGY
SAVER
MANUAL INTERRUPT
RESET
A3
1
2
A4
4
5
A4
7
8
9
0
#
FLS•B4
A5
FP-D355
FP-D355DC
2
Place paper
Turn the Power
Switch on
(FP-D355/D355DC)
Turn Operation
Position original
Switch On
(FP-D455/D605)
3
6
3
Copy size
Number of copies
(reduction/
(Up to 999)
enlargement only)
1
4
Press Start*
■ Position of the original
C Place face down on platen and in ADF (FA-A355).
Face Up in i-ADF (FA-A888).
A3
A4
B4
A4R
A3
FLS•B4
A4R
A5
A4
A5
C If the original is incorrectly placed on the platen glass,
part of the copy image may be missing.
C For originals smaller than A5 size, align with center of
left original guide and select A5.
A5
A4R
B4
A3
A4
Original Guide See [
]
■ Memory capacity:
When the memory becomes full during the original scanning, the message of “Function not
available for lack of memory” will be displayed in the message display. In this case, follow the
operating instruction in the message display.
When the additional memory is required, consult with authorised dealer.
■ Note on making multiple copies (For FP-D455/D605)
If the fusing temperature drops excessively during a multi-copy cycle, there is a possibility that
the copying speed will be reduced. The copying speed will automatically return to normal when
the fusing temperature rises enough to ensure good fusing performance.
NOTE
4
∗
While the copier is warming up, you may position your original on the copier, enter
your copy job selections and press the Print key. The wait indicator will flash until the
warm up cycle is completed and the copy job automatically start.
C When making 100 copies continuously or intermittently within 20 minutes, the fan
motor will start rotation. This is not irregular operation but just to cool off the machine.
C For FP-D455/D605, at following condition Touch Panel Display may light but it will turn
off within 40 seconds.
1. After turning off the Power switch.
2. After connecting the power code to the plug.
Operation Chart
Touch Panel Display
Operation Chart
Touch Panel Display
■ Function Categories
A
BASIC
MENU
Basic Menu
DUPLEX/
ZOOM/
INSERTION
ZOOM/EFFECTS
INSERTION
JOB
ORIG. --> COPY
EFFECTS
JOB
100%
LIGHT
BASIC
MENU
Basic Menu
1
\
2
2
D
1
\
2
N in 1
DUPLEX/
BASIC
MENU ORIG. --> COPY
Basic Menu
\
2
JOB
Job
memory
MEMORY
Book \ 2
1 to N
ZOOM/
ZOOM/EFFECTS
EFFECTS
JOB
Job
memory
MEMORY
INSERTION
INSERTION
JOB
JOB
Zoom
Centering
Page
Numbering
Edge
Margin
Book
Mirror
Inverse
DUPLEX/
BASIC
Basic MENU
Menu ORIG. --> COPY
ZOOM/
ZOOM/EFFECTS
EFFECTS
Basic Menu (See page 12)
# Text, Text/Photo, Photo Mode Key
$ Exposure Control Keys
% Auto Exposure Key
& Cassette Indication
( Cassette Selection Key
) Job Status Key
PAPER TRAY
TEXT/PHOTO PHOTO
ZOOM/
INSERTION
DUPLEX/
ZOOM/EFFECTS
INSERTION
JOB
EFFECTS
JOB
ORIG. --> COPY
2 page
C
DARK
AUTO
TEXT
JOB STATUS
B
JOB
Job
memory
Job
memory
MEMORY
INSERTION
INSERTION
JOB
JOB
JOB
Job
memory
MEMORY
Presentation
OHP interleaving
Page insertion
Duplex/Original H Copy (See page 15)
# 1 \ 2 Copy Key
$ 2 \ 1 Copy Key
% 2 \ 2 Copy key
& Book \ 2 Copy Key
( 2 Page Copy Key
) N in 1 Copy Key
* 1 to N Copy Key
+ SADF Key (See NOTE on page 15)
Zoom/Effects (See page 27)
# Zoom Key
$ Centring Mode Key
% Page Numbering Mode Key
& Edge Mode Key
( Margin Mode Key
) Book Mode Key
* Mirror Mode Key
+ Inverse Mode Key
Insertion Job (See page 32)
# Cover Mode Key
$ Page Insertion Mode Key
% OHP Interleaving Mode Key
& Presentation Mode Key
Cover
E
Job memory
Select Mem. in or Mem. #
= more settings
Basic Menu
DUPLEX
ZOOM/EFFECTS INSERTION JOB
ORIG. --> COPY
DUPLEX/
BASIC
MENU ORIG. --> COPY
Basic Menu
1
2
2
2
BOOK
2
2 PAGE
Memory
in
ZOOM/
EFFECTS
INSERTION
JOB
ZOOM/EFFECTS INSERTION JOB
ZOOM
COVER
CENTERING
INSERTION
PAGE
NUMBERING
Job memory
JOB
Job
memory
MEMORY
Job Memory (See page 35)
# M1, M2, M3, M4, M5 Key
$ Memory In Key
■ Basic Menu Selection
C Displays all functions when touching
Basic Menu Key.
C Touch Basic Menu Key again to return to
the basic screen.
INTERLEAV.
ERASE
N in 1
1 to N
MIRROR
PRESEN.
INVERSE
5
Precautions
For your safety
■ Laser Safety
LASER SAFETY
This unit employs a laser. Only qualified service personnel should
attempt to service this device due to possible eye injury.
Caution
This product utilizes a laser.
Use of controls or adjustments or performance of procedures other than
those specified herein may result in hazardous radiation exposure.
■ Caution Labels
DANGER
CAUTION
ATTENTION
VORSICHT
Invisible laser radiation when open.
Avoid direct exposure to beam.
Invisible laser radiation when open.
Avoid direct exposure to beam.
Rayonnement laser invisible si ouvert.
Dangereux de regarder a l'interieur.
Unsichtbare laserstrahlen wenn geöffnet.
Nicht hinensehen.
PRECAUTION
Peligro-Cuando la cubierta esté abierta se
podrá escapar radiación de rayo láser.
Evite la exposición directa al rayo láser.
LASER KLASSE 1
LASER CLASSE 1
RANGO LASER 1
CLASS
1 LASER PRODUCT
(
)
TO IEC 825
CAUTION:
Invisible laser radiation when open
and interlocks defeated.
AVOID EXPOSURE TO BEAM.
VARNING:
OSYNLIG LASERSTRALNING NÄR DENNA
DEL ÄR ÖPPNAD OCH
SPÄRRAR ÄR
URKOPPLADE.
STRALEN ÄR FARLIG.
6
VORSICHT:
Unsichtbare Laserstrahlung, wenn
Abdeckung geöffnet und
Sicherheitsverriegelung überbrückt.
NICHT DEM STRAHL AUSSETZEN.
VARO!:
NÄKYMÄTÖN AVATTAESSA
JA SUOJALUKITUS
OHITETTAESSA OLET
ALTTIINA LASERSÄTEIL
YLLE.
ÄLÄ KATSO SÄTEESEN.
ATTENTION:
Rayonnement laser invisible
dangereux en cas d'ouverture et
lorsque la sécurité est neutralisée.
EXPOSITION DANGEREUSE AU
FAISCEAU.
VARNING:
OSYNLIG LASERSTRALNING NÄR DENNA
DEL ÄR ÖPPNAD OCH
SPÄRREN ÄR
URKOPPLAD.
BETRAKTA EJ STRALEN.
PELIGRO:
Cuando se abre y se invalida el
bloqueo, se producen radiaciones
invisibles de láser.
EVÍTESE LA EXPOSICIÓN
DIRECTA A TALES RAYOS.
ADVARSEL:
USYNLIG LASERSTRALING
VED ABNING NAR
SIKKERHEDSAFBRYDERE ER
UDE AF FUNKTION.
UNDGA UDSÆTTELSE
FOR STRALING.
ADVARSEL:
USYNLIG LASERSTRALING
NAR DEKSEL APNES OG
SIKKERHEDSLAS BRYTES.
UNNGA EKSPONERING
FOR STRALEN.
FFPTE2412
FFPTE1539
Precautions
Handling
Before operating
■ Do not look directly at exposure lamp when copying.
■ Do not turn the power switch off or open the front
panel during copying.
C Do not drop paper clips or other metal objects into
the copier.
Toner and Paper
■ Store toner, developer and paper in cool areas with
low humidity.
C High quality paper of 60 – 90 g/m2 (55 – 130 g/m2
via sheet bypass) may be used.
C For optimum copy quality, it is essential that
Panasonic Brand Toner is used in the copier.
Ventilation
■ The copier should be installed in a well-ventilated
area to minimize the ozone density in the air.
7
Precautions
Installation
■ The copier should not be installed in areas with the
following conditions:
C Extremely high or low temperature and humidity.
Ambient Conditions Temperature: 10°C – 30°C
Relative humidity: 30% – 80%
C Where temperature and humidity can change
rapidly, causing condensation.
C Direct exposure to sunlight.
C Directly in air conditioning flow.
C In areas of high dust concentration.
C In areas of poor ventilation.
C In areas with chemical fume concentration.
C In areas with extreme vibration.
C Unstable or uneven floors.
FOR YOUR SAFETY
The mains plug on this equipment must be used to disconnect mains power. Please ensure that the
socket outlet is installed near the equipment and shall be easily accessible.
For U.K.
This appliance is supplied with a moulded three pin mains plug for your safety and convenience.
A 13 amp fuse is fitted in this plug.
Should the fuse need to be replaced please ensure that the replacement fuse has a rating of 13
amps and that it is approved by ASTA or BSI to BS1362
Check for the ASTA mark 7 or the BSI mark 6 on the body of the fuse.
If the plug contains a removable fuse cover you must ensure that it is refitted when the fuse is
replaced.
If you lose the fuse cover the plug must not be used until a replacement cover is obtained.
A replacement fuse cover can be purchased from your local Panasonic Dealer.
IF THE FITTED MOULDED PLUG IS UNSUITABLE FOR THE SOCKET OUTLET IN YOUR OFFICE
THEN THE FUSE SHOULD BE REMOVED AND THE PLUG CUT OFF AND DISPOSED OF SAFELY.
THERE IS A DANGER OF SEVERE ELECTRICAL SHOCK IF THE CUT OFF PLUG IS INSERTED
INTO ANY 13 AMP SOCKET.
If a new plug is to be fitted please observe the wiring code as shown below.
If in any doubt please consult a qualified electrician.
WARNING: THIS APPLIANCE MUST BE EARTHED.
IMPORTANT: The wires in this mains lead are coloured in accordance with the following code:
Green and Yellow: Earth
Blue
: Neutral
Brown
: Live
As the colours of the wires in the main lead of this appliance may not correspond with the coloured
markings identifying the terminals in your plug, proceed as follows:
The wire which is coloured GREEN-AND-YELLOW must be connected to the terminal in the plug which
is marked by letter E or by the safety Earth symbol “L” or coloured GREEN or GREEN-AND-YELLOW.
The wire which is coloured BLUE must be connected to the terminal in the plug which is marked
with the letter N or coloured BLACK.
The wire which is coloured BROWN must be connected to the terminal in
the plug which is marked with the letter L or coloured RED.
How to replace the fuse.
Open the fuse compartment with a screwdriver and replace the fuse.
N
Caution Note: Disconnect from the mains supply before removing covers.
8
Control Panel
Control Panel
# $ %
MULTI-SIZE
FEED
SORT/
FINISH
& ( ) *
USER
PRESET
ENERGY
SAVER
MANUAL INTERRUPT
+
-
RESET
Precautions
Control Panel
.
A3
1
2
3
A4
4
5
6
A4
7
8
9
0
#
FLS•B4
A5
Original Size
Keys
No
#
$
%
&
(
)
*
+
.
Copy Size
Keys
Touch Panel Display
Quantity
Keys
Contents
Multi-Size Feed Key
C When Multi-sized originals are copied using i-ADF/ADF (Option).
Sort/Finish Key
C When sorting and stapling with Finisher (Option).
User Preset Key
C Changes default modes.
Energy Saver Key
C Can save power while the copier is not in use.
Manual Key
C After pressing this key, the original size can be selected manually.
Interrupt Key
C Interrupts other copy or print jobs while making copies.
Reset Key
C Resets all features to the initial power-on state.
Clear Key
C Clears the copy count in the display.
Stop Key
C Stops the copy run.
Operation Switch (FP-D455/D605 only)
C For turning the power On/Off.
NOTE
Start Key
Ready
Indicator
Refer to
P.58
P.59 – 72
P.40 – 55
P.38
P.12
P.38
———
———
———
———
C The Control Panel displayed above shows only copier functions. Please refer to the
proper operating instructions for Facsimile/Internet/Printer control panel functions.
9
Control Panel
Touch Panel Display
MULTI-SIZE
FEED
SORT/
FINISH
USER
PRESET
ENERGY
SAVER
MANUAL INTERRUPT
RESET
A3
1
2
3
A4
4
5
6
A4
7
8
9
0
#
FLS•B4
A5
#$
%& (
)
*
Ready to Copy
BASIC
MENU
Basic Menu
7
6
5
4
DUPLEX/
ZOOM/
INSERTION
ZOOM/EFFECTS
INSERTION
JOB
ORIG. --> COPY
EFFECTS
JOB
JOB
Job
memory
Job
memory
MEMORY
+
-
100%
LIGHT
JOB STATUS
3
TEXT
AUTO
DARK
TEXT/PHOTO PHOTO
2
.
/
0
2
PAPER TRAY
1
C Adjusting the touch panel display contrast
Adjust brightness of the display by repeatedly pressing A3 or A5 original size key while
pressing and holding the Clear key.
To make the display brighter : A3 size key
To make the display darker : A5 size key
ATTENTION
10
C Use soft finger pressure only to activate touch Screen panel. DO NOT USE SHARP
OBJECTS such as pens, fingernails etc., as this may damage the panel.
Control Panel
■ Touch Panel Display Indications
No
Contents
#
Warning indications
?: Add Toner J: Add Paper
$
SADF/Multi-size Feed Mode indication
P.26, 58
%
Original Image indication
———
&
Rotate Mode indication*
———
(
Copy paper indication
———
)
Number of copies
———
*
Machine/User Error Code indication (E1-01, U13, etc.,)
+
Function Categories
-
Copy Paper Size indication
.
Finisher Functions indication
/
Selected Paper Tray and Paper status indication
2: Tray position G : Normal H : Low paper J: Add Paper
Sheet Bypass
: Normal
: Add Paper
0
Cassette Selection Key
P.13
1
Manual Exposure Select keys (Light and Dark)
P.12
2
Original Mode Select key (Text/Text/Photo/Photo)
P.12
3
Job Status Key
P.12
4
Auto Exposure Key
———
5
Exposure Indicator (7 steps)
———
6
Copy Ratio indication
———
7
Original Size indication
———
NOTE
Refer to
∗
P.73 – 77
P.93
Control Panel
B: Replace waste toner bottle. 2: Call service
P.93
P.15 – 39
———
P.59, 62, 67, 72
———
When making copies in A4 (B) if the cassette runs out paper, the copier will
automatically select the A4R (C) cassette and rotate the image to said.
However, the function is not available if any problem occurs by the image rotation
function in the middle of copy operation. (Duplex/Original → copy, Insertion job,
Sort/Finish mode, etc.)
11
Basic Menu
Full Size Copying
■ When copying the same size as the original (1:1)
Copy size and copy density are automatically selected.
MULTI-SIZE
FEED
SORT/
FINISH
USER
PRESET
ENERGY
SAVER
MANUAL INTERRUPT
RESET
A3
1
2
3
A4
4
5
6
A4
7
8
9
FLS•B4
A5
1
0
Original Size
Keys
Touch Panel Display
Position original
2
Number of copies
(Up to 999)
■ Initial Screen
3
Press Start
When placing A4 size originals
Ready to Copy
BASIC
MENU
Basic Menu
1
DUPLEX/
ZOOM/
INSERTION
ZOOM/EFFECTS
INSERTION
JOB
ORIG. --> COPY
EFFECTS
JOB
LIGHT
TEXT
JOB STATUS
AUTO
DARK
TEXT/PHOTO PHOTO
JOB
Job
memory
Job
memory
MEMORY
Input the code number, if x appears.
# Select the original(s)
C Text:
Originals are mainly composed of text.
C Photo:
Originals are mainly composed of photo.
C Text/Photo: Combined originals with text and photo.
2
PAPER TRAY
$ Job Status Key
C Each setting jobs will be indicated on the display.
■ When manually selecting exposure control or original size:
Select exposure control
LIGHT
JOB STATUS
TEXT
AUTO
DARK
TEXT/PHOTO PHOTO
Manual Key
ENERGY
SAVER
MANUAL INTERRUPT
RESET
2
PAPER TRAY
C Press the Light or Dark key.
The centre setting is the normal position.
C Touch the Auto key to change the Auto mode.*
Select original size.
# Select original size with Original Size key.
Lights up (Manual mode)
CLEAR
1
2
3
$ To cancel Manual mode
Press
Key
Light turns off
NOTE
12
C Benefits of QUARC (QUAlitative Reasoning based adaptive Controller).
The FP-D355/D355DC/D455/D605 series features exclusive new Panasonic imaging
technology which utilises an advanced form of artificial intelligence to ensure optimal
copy quality and performance under varying environmental conditions, from a wide
range of originals.
∗ The Auto mode cannot be selected in following condition.
(1) The Photo mode is selected.
(2) The Photo mode or Text/Photo mode is selected when FA-A355 is used.
Basic Menu
Reduction or Enlargement Copying
■ When copying with preset ratios
There are 5 preset reduction and 5 preset enlargement modes.
MULTI-SIZE
FEED
SORT/
FINISH
USER
PRESET
ENERGY
SAVER
MANUAL INTERRUPT
RESET
1
2
3
A4
4
5
6
A4
7
8
9
0
#
A5
1 2
3
4
Position
original
Number of
copies
(Up to 999)
Press Start
Select the copy size
(Landscape for A4/A5 size)
Example: Reduction
Original size
A3
Full Size Copying
Reduction or Enlargement
A3
FLS•B4
Copy size
FLS•B4
A3
A4
A4
A4
The correct ratio is automatically selected.
A5
Reduction and enlargement ratios. (%)
Ready to Copy
BASIC
Basic MENU
Menu
DUPLEX/
ZOOM/
INSERTION
ZOOM/EFFECTS INSERTION JOB
ORIG. --> COPY
EFFECTS
JOB
NOTE
A3
B4
A4
141
122
100
71
A5
200
173
141
100
B4
A4
A5
100
87
71
50
115
100
82
58
C When changing the paper size, touch
Paper Tray key.
LIGHT
ATTENTION
A3
JOB
Job
memory
Job
memory
MEMORY
65%
65%
JOB STATUS
Copy size
Original
size
TEXT
AUTO
DARK
TEXT/PHOTO PHOTO
2
PAPER TRAY
Paper Tray (CASSETTE) Key
C Part of the image may be deleted if the direction of the original and copy
paper do not correspond.
C If the copy size is different from the paper size you can use the sheet bypass.
This will save you having to change the setting of the paper trays.
13
Basic Menu
Using the Sheet Bypass
■ To copy on letterhead, mailing labels, transparencies and odd-size paper,
etc., or to use the bypass as an additional paper source.
1
2
Position original.
Open the Sheet Bypass.
Sheet Bypass
3
Pull out the Sheet Bypass tray
until it stops.
4
# Place approximately 50 sheets of
paper.
1
Side Guides
5
NOTE
Do not fill above
2
Insert the paper until it stops.
$ Adjust the side guides.
Incorrect adjustment may cause paper
to wrinkle, misfeed or skew.
Press Start.
C The bypass has priority over the paper trays. The copier automatically selects the
Sheet Bypass when paper is placed in the empty bypass tray.
C Some types of mailing labels and transparency film may damage your machine.
Please contact your service provider for advice regarding non-standard paper types.
C Do not feed curled paper through the bypass to avoid misfeed.
14
Duplex/Original H Copy
■ Initial Screen
Select function
EFFECTS
ORIG. --> COPY
1
\
2
2 page
2
\
1
N in 1
2
INSERTION
INSERTION
JOB
JOB
\
2
JOB
Job
memory
MEMORY
Book \ 2
1 to N
Using the Sheet Bypass
Duplex/Original H Copy
ZOOM/
ZOOM/EFFECTS
BASIC
MENU DUPLEX/
Basic Menu
∗
C Touch the desired key to select the function.
1\2
From single sided originals to double
sided copies.
⇒ See P.16
2\1
From double sided originals to single
sided copies.
⇒ See P.16
2\2
From double sided originals to double
sided copies.
⇒ See P.16
From book originals to double sided
copies
⇒ See P.17
Book \ 2
2 Page
NOTE
Copying two facing pages of an A3 size
⇒ See P.18
original on two separate A4 size sheets.
N in 1
From two (or four or eight) single sided
originals onto side by side single sided
copies.
⇒ See P.19
1 to N
From one single sided original to two
(or four) single sided copies.
⇒ See P.25
SADF
A special original (like thin paper etc.,)
can be fed from the ADF/i-ADF original
tray.
⇒ See P.26
∗
Displays when selecting “Yes” with the SADF function. (See P.49)
C To copy double sided originals you can use the i-ADF (FA-A888) or place
double sided originals directly onto the original glass.
C ADU (Automatic Duplex Unit) is required when making a double sided copy.
The ADU FP-D355DC/D455/D605 is standard.
C To reset Duplex/Original H Copy mode, press Reset key.
15
Duplex/Original H Copy
1 \ 2 Copy / 2 \ 1 Copy / 2 \ 2 Copy
■ 1 \ 2 Copy
■ 2 \ 1 Copy
From single sided originals to double sided copies.
From Copier Platen & i-ADF/ADF
From double sided originals to single sided copies.
Using i-ADF
■ 2 \ 2 Copy (FA-A888 is required)
From double sided originals to double sided copies.
Using i-ADF
■ Procedure
ADF FA-A355
i-ADF FA-A888
MULTI-SIZE
FEED
SORT/
FINISH
USER
PRESET
ENERGY
SAVER
MANUAL INTERRUPT
RESET
A3
1
2
3
A4
4
5
6
A4
7
8
9
FLS•B4
A5
Face-Down
0
Face-Up
2
3 (4) 1
Place
originals
Count
originals
(1 \ 2 only)
Even number
original
Touch 1 \ 2,
2 \ 1 or
2\2
Number of
copies
(Up to 999)
Press
Start
# For odd or even originals, touch the Odd or Even
key.
Set number of originals
Press OK
Odd number
original
Select original
size
5 6
Original
count
$ If number of originals is unknown, touch Original
Count key.
% Touch OK key.
CANCEL
& Return Originals to the ADF/i-ADF.
NOTE
C To reset a mode selected using the menu, touch Cancel key on the touch panel.
C FA-A355 is only available for the model FP-D355/D355DC.
16
Duplex/Original H Copy
Book \ 2 Copy
■ Book \ 2 Copy
From book originals to double sided copies
A3 size originals only.
(Book Format)
SORT/
FINISH
USER
PRESET
ENERGY
SAVER
MANUAL INTERRUPT
RESET
Duplex/Original
H Copy
MULTI-SIZE
FEED
(Facing Pages)
A3
1
2
3
A4
4
5
6
A4
7
8
9
FLS•B4
A5
1
Position original
on the Platen
0
2
Select the
copy size
3
Select Book \ 2
mode and Copy
format
4
Number of
copies
(Up to 999)
5
Press Start
A3 size original
Centre book
by length
and width
according to
centre
marks.
Centre
Centre (Book) mark
C Copy last page first in Facing pages and
Book Format mode.
NOTE
Select facing page or book format
Press OK
2 side
Facing
pages
2 page
Book
format
Cancel
CANCEL
C Touch OK key.
C To reset a mode selected using the menu, touch Cancel key on the touch
panel.
17
Duplex/Original H Copy
2 Page Copy
■ 2-Page Copy
Copying two facing pages of an A3 size
original on two separate A4 size sheets.
A3 size originals only.
■ Procedure
MULTI-SIZE
FEED
SORT/
FINISH
USER
PRESET
ENERGY
SAVER
MANUAL INTERRUPT
RESET
A3
1
2
3
A4
4
5
6
A4
7
8
9
FLS•B4
A5
2
0
(3) 1
Place
originals
Select copy
size*
Touch 2 Page
mode
4 5
Number of
copies
(Up to 999)
Press
Start
Book on the platen
A3 size original
Centre book
by length and
width
according to
centre marks.
Centre
Centre (Book) mark
NOTE
∗
For reduction or enlargement copy only.
C To reset a mode selected using the menu, touch Cancel key on the touch panel.
18
Duplex/Original H Copy
N in 1 copy
■ N in 1 copy
■ Booklet
From two/four/eight single sided originals, side
by side, to single sided copies. (See page 21-24)
From four single sided originals, side by
side, to double sided copies. (See page 24)
Using FA-F365
1
1
2
Others
2
3
2
3
3
4
4
1
4
■ Procedure
ADF
i-ADF
MULTI-SIZE
FEED
SORT/
FINISH
USER
PRESET
ENERGY
SAVER
MANUAL INTERRUPT
RESET
1
2
3
A4
4
5
6
A4
7
8
9
A5
Face-Down
0
Face-Up
2
3
Place originals
Copy size*
Count originals
(except Booklet)
1
Touch N in 1 mode
and make selection
4 5
Number of
copies
Press Start
Set number of originals
press OK
Number of
originals
Number of Original
Cancel
CANCEL
# Touch ADF key or input the number of originals with Key Pad.
$ After originals are counted, touch the OK key.
% When the ADF key is touched in the step #, re-position originals in document
feeder.
NOTE
∗
Copy is automatically reduced.
(ex. A4 to A4 size)
C A4 B size originals only for Booklet.
C The ADF/i-ADF is required for N in 1 copy.
C When using booklet, the maximum number of images that can be stored is
60. If the original capacity you are copying exceeds 50 (ADF capacity), a
user intervention screen will appear that will enable you to process more
originals. If this screen does not appear, see page 43.
19
Duplex/Original
H Copy
A3
FLS•B4
Duplex/Original H Copy
N in 1 copy
■ N in 1 copy
Combination for N in 1 copy operation.
Originals
Layout
2
2
1 2
1
1
Mode
1
2
3
4
2
3
4
2
1 2
1
1
2
2
8
8
1 2
3 4
4
3
1
2
8
8
2
2
1
1
1 3
2 4
3 1
4 2
See page 22
12 13 21 31
34 24 43 42
1
3
5
7
2
4
6
8
1
2
3
4
5
6
7
8
2
4
6
8
1
3
5
7
5
6
7
8
1
2
3
4
See page 23
1234 1357 4321 7531
5678 2468 8765 8642
2 4
8
Booklet
1 3
1
3
2
4
8
2
1
5
7
20
2 1
4 3
1234 1357 4321 7531
5678 2468 8765 8642
8 in 1
1
2 1
4
2
2
3
1
1
2
See page 21
12 13 21 31
34 24 43 42
4 in 1
1
2 1
1
2
2 in 1
1
Operation
6
8
5
6
7
8
See page 24
Note:
Center edge will
be lacked.
Duplex/Original H Copy
N in 1 copy
■ 2 in 1 Copy
From two single sided originals, side by side, to single sided pages.
■ Procedure
ADF
i-ADF
MULTI-SIZE
FEED
SORT/
FINISH
USER
PRESET
ENERGY
SAVER
MANUAL INTERRUPT
RESET
A3
1
2
3
A4
4
5
6
A4
7
8
9
FLS•B4
A5
Face-Up
2
Copy size
3
Place originals*
Count originals
# Touch Odd or Even number original
key, then touch ADF key.
$ When the number of originals are
unknown, touch ADF key.
% After originals are counted, touch the
OK key.
& When the ADF key is touched in the
step $, re-position originals in
document feeder.
NOTE
∗
1
Touch N in 1 mode
and make selection
4 5
Number of
copies
Press Start
%
# Select original direction
$ Select the copy layout
(See page 20)
Original direction should be placed as follows:
Original Guide (Rear)
(For ADF)
C The ADF/i-ADF is required for N in 1 copy.
or
Original Guide (Rear)
a
a
or
a
or
a
or
(For i-ADF)
21
Duplex/Original
H Copy
Face-Down
0
Duplex/Original H Copy
N in 1 copy
■ 4 in 1 Copy
From four single sided originals, side by side, to single sided pages.
■ Procedure
ADF
i-ADF
MULTI-SIZE
FEED
SORT/
FINISH
USER
PRESET
ENERGY
SAVER
MANUAL INTERRUPT
RESET
A3
1
2
3
A4
4
5
6
A4
7
8
9
FLS•B4
A5
Face-Down
0
Face-Up
2
3
Place originals*
Copy size
1
Touch N in 1 mode
and make selection
Count originals
# Touch ADF key or input the number of
originals with Key Pad.
$ After originals are counted, touch the OK key.
% When the ADF key is touched in the step #,
re-position originals in document feeder.
∗
Press Start
# Touch 4 in 1 key
% Select the copy layout (See page 20)
Original direction should be placed as follows:
Original Guide (Rear)
(For ADF)
C The ADF/i-ADF is required for N in 1 copy.
or
a
a
or
a
or
(For i-ADF) Original Guide (Rear)
a
or
22
Number of
copies
(Up to 999)
&
$ Select original direction
NOTE
4 5
Duplex/Original H Copy
N in 1 copy
■ 8 in 1 Copy
From eight single sided originals, side by side, to single sided pages.
■ Procedure
ADF
i-ADF
MULTI-SIZE
FEED
SORT/
FINISH
USER
PRESET
ENERGY
SAVER
MANUAL INTERRUPT
RESET
A3
1
2
3
A4
4
5
6
A4
7
8
9
FLS•B4
A5
Face-Up
2
Copy size
3
Place originals*
Count originals
1
Touch N in 1 mode
and make selection
# Touch ADF key or input the number of originals
with Key Pad.
$ After originals are counted, touch the OK key.
% When the ADF key is touched in the step #,
re-position originals in document feeder.
∗
Number of
copies
(Up to 999)
Press Start
&
# Touch 8 in 1 key
$ Select original direction
NOTE
4 5
% Select the copy layout (See page 20)
Original direction should be placed as follows:
Original Guide (Rear)
(For ADF)
C The ADF/i-ADF is required for N in 1 copy.
or
a
a
or
a
or
a
or
(For i-ADF) Original Guide (Rear)
23
Duplex/Original
H Copy
Face-Down
0
Duplex/Original H Copy
N in 1 copy
■ Booklet Copy
From plural single sided originals, side by side, to single sided pages.
■ Procedure
ADF
i-ADF
MULTI-SIZE
FEED
SORT/
FINISH
USER
PRESET
ENERGY
SAVER
MANUAL INTERRUPT
RESET
A3
1
2
3
A4
4
5
6
A4
7
8
9
FLS•B4
A5
Face-Down
Face-Up
Copy size
1
2
Touch N in 1 mode
and make selection
Place originals
(A4 size only)
ADF
0
3 4
Number of
copies
(Up to 999)
4
3
2
Press Start
# Touch Booklet
key
1
i-ADF
1
2
3
a
When using the FA-F365:
Copies are
sorted,
stitched and
stapled.
4
$ Touch OK key
C The OK key
cannot be
operated
when
originals are
placed onto
ADF/i-ADF.
Stapled
When using booklet, the maximum number
of images that can be stored is 60. If the
original capacity you are copying exceeds
50 (ADF capacity), a user intervention
screen will appear that will enable you to
process more originals. If this screen does
not appear, see page 43.
NOTE
C The ADF/i-ADF is required for N in 1 copy.
C When copying landscape direction, center edge of copied image will be
lacked.
C For FA-F365: when the paper is misfed in the saddle stitcher unit or the inlet
cover/upper cover is opened, re-start copying from the first page.
24
Duplex/Original H Copy
1 to N Copy
■ 1 to 2 Copy
■ 1 to 4 Copy
From one single sided original to two
single sided copies.
From one single sided original to four
single sided copies.
1
2
1
3
2
4
3
4
■ Procedure
i-ADF
MULTI-SIZE
FEED
SORT/
FINISH
USER
PRESET
ENERGY
SAVER
MANUAL INTERRUPT
RESET
Duplex/Original
H Copy
ADF
A3
1
2
3
A4
4
5
6
A4
7
8
9
FLS•B4
A5
Face-Down
0
Face-Up
Copy size*
2
Place originals
Platen
i-ADF
A B
A B
A
B
A
B
3 4
Number of Press Start
Touch 1 to N
copies
mode and
(Up to 999)
make selection
When 1 to 2 copying, set the original as follows:
Original
1
ADF
Select function
press OK
to
to
CANCEL
Cancel
NOTE
C To reset a mode selected using the menu, touch Cancel key on the touch panel.
∗
(
Copy is automatically enlarged.
ex. A4 to A4 size
1 to 2: 141%, 1 to 4: 200%
)
25
Duplex/Original H Copy
SADF MODE
■ SADF (Single Automatic Document Feeder) Function
A special original (like thin paper etc.,) can be fed from the i-ADF original tray and copied
continuously with manual operation.
Select SADF setting “Yes” in the user preset mode before using this function. (See page 49)
■ Procedure
ADF
i-ADF
MULTI-SIZE
FEED
SORT/
FINISH
USER
PRESET
ENERGY
SAVER
MANUAL INTERRUPT
RESET
A3
1
2
3
A4
4
5
6
A4
7
8
9
FLS•B4
A5
Face-Down
Face-Up
1A7
(3) 2
Position original
one at a time




7
Copy size
(reduction/
Timing for next original enlargement only)
C In 5 sec. from last 
copy exit.

#
DUPLEX/
ORIG. --> COPY
4 5 6
Select [
function
Number of
copies
(Up to 999)
$
Ready to Copy
BASIC
Basic MENU
Menu
0
ZOOM/
ZOOM/EFFECTS
EFFECTS
INSERTION
INSERTION
JOB
JOB
JOB
Job
memory
Job
memory
MEMORY
LIGHT
NOTE
AUTO
TEXT/PHOTO
DARK
ZOOM/
ZOOM/EFFECTS
BASIC
MENU DUPLEX/
Basic Menu
EFFECTS
ORIG. --> COPY
\
2
2 page
TEXT
Copy
Select function
1
JOB STATUS
Press
Start.
2
\
1
N in 1
2
INSERTION
INSERTION
JOB
JOB
\
2
JOB
Job
memory
MEMORY
Book \ 2
1 to N
2
PAPER TRAY
C SADF function cannot be combined with 2 \ 1, 2 \ 2, N in 1 and Finishing
function (except Non-sort).
C Set the original from the last page in 1 \ 2 copy mode.
C To reset a mode selected using the menu, touch Cancel key on the touch panel.
26
Zoom/Effects
■ Initial Screen
Select function
ZOOM/
ZOOM/EFFECTS
EFFECTS
JOB
Job
memory
MEMORY
INSERTION
INSERTION
JOB
JOB
Zoom
Centering
Page
Numbering
Edge
Margin
Book
Mirror
Inverse
Duplex/Original
H Copy
DUPLEX/
DUPLEX
BASIC
MENU ORIG.
Basic Menu
PRIG -->
--> COPY
COPY
C Touch the desired key to select the function.
Zoom
Centring
Page Numbering
Edge
Margin
Book
Copies with variable zoom ratios from
25% to 400% in 1% increments.
⇒ See P.28
Shifts image to centre.
⇒ See P.29
Prints a page number on the copies.
⇒ See P.31
Creates a blank edge.
⇒ See P.30
Shifts image to right or left.
⇒ See P.30
Eliminates dark inner binding shadows. ⇒ See P.30
Mirror
Copies a mirror image.
⇒ See P.29
Inverse
Copies a inverse image.
C Negative to Positive
C Positive to Negative
⇒ See P.29
NOTE
C To reset Zoom/Effects mode, press Reset key.
C For combining Zoom/Edit functions and other functions, see page 39.
C Press the Clear key and re-enter the correct number if you make a mistake.
27
Zoom/Effects
Zoom Copying
■ Zoom
■ Auto Zoom
Copies with variable zoom ratios from 25%
to 400% in 1% increments.
MULTI-SIZE
FEED
SORT/
FINISH
Copy ratio can be selected automatically by
selecting the paper size.
USER
PRESET
ENERGY
SAVER
MANUAL INTERRUPT
RESET
A3
1
2
3
A4
4
5
6
A4
7
8
9
0
#
FLS•B4
A5
1 2
3
Position
original
Select Zoom
or Auto Zoom
Select Zoom/
Effect mode
4 5
Select
paper
 On the platen

 when Auto Zoom 
3
Number of
Press
copies
Start.
(Up to 999)
Auto Zoom mode, make
 In
copies with ADF/i-ADF or
 platen cover open.


Select copy ratio by using F·G keys and
touch OK.
Select Zoom or Auto Zoom and
touch OK.
Select function
press OK
Zoom
6
Set zoom %
press OK
Auto zoom
Zoom
X·Y key
4
Select paper size and touch OK.
Select paper tray
Press OK
Auto Zoom
Cancel
CANCEL
CANCEL
When setting X, Y zoom ratio individually,
press X, Y key first, then set the zoom ratio
by F·G key.
Select mode and touch OK.
Setting X, Y zoom to same ratio along
with the height or width (whichever
shorter) of the copy paper.
Setting X, Y zoom ratio individually along
with the height and width of the copy paper.
ATTENTION
NOTE
C When changing paper size after setting zoom ratio, please use cassette key.
If you use copy size key, zoom ratio will be changed.
C Remove the originals from the ADF/i-ADF before selecting the auto zoom mode.
C Incorrect original position detection may occur if any strong light shines onto the platen
glass during the auto zoom mode.
28
C To reset a mode selected using the menu, touch Cancel key on the touch panel.
Zoom/Effects
Centering/Mirror/Inverse copy
■ Mirror
■ Centring
Copy image can be centred
automatically on selected paper.
A mirror image can automatically
be made.
■ Inverse
Negative/Positive image can be
made for interesting effects.
MULTI-SIZE
FEED
SORT/
FINISH
USER
PRESET
ENERGY
SAVER
MANUAL INTERRUPT
Zoom/Effects
■ Procedure
RESET
A3
1
2
3
A4
4
5
6
A4
7
8
9
0
#
FLS•B4
A5
1 2
Position
original
3
Select Zoom/
Effect mode
4 5
Select Centring,
Mirror or Inverse
(On the platen
when centering*)
Select
paper
Number of
copies
(Up to 999)
Centring only
6
Press Start
Select function
DUPLEX/
BASIC
MENU ORIG. --> COPY
Basic Menu
NOTE
ZOOM/
ZOOM/EFFECTS
EFFECTS
INSERTION
INSERTION
JOB
JOB
JOB
Job
memory
MEMORY
Zoom
Centering
Page
Numbering
Edge
Margin
Book
Mirror
Inverse
∗
In centring mode, make copies with ADF/i-ADF or platen cover open.
Remove the originals from the ADF/i-ADF before selecting the centring
mode.
C Incorrect original position detection may occur if any strong light shines onto
the platen glass during the centring mode.
C To reset a mode selected using the menu, touch Cancel key on the touch
panel.
29
Zoom/Effects
Edge/Margin/Book Mode
Reset Key: To reset each mode menu.
■ Procedure
MULTI-SIZE
FEED
SORT/
FINISH
USER
PRESET
ENERGY
SAVER
MANUAL INTERRUPT
RESET
A3
1
2
3
A4
4
5
6
A4
7
8
9
FLS•B4
A5
1 2
Position
original
Select Zoom/
Effect mode
0
3 (4) 5
Select Edge
Margin or Book
Select
paper
Number of
copies
(Up to 999)
6
Press
Start
Edge
# Select vertical or horizontal edge
$ Adjust each void width by using the F·G keys.
% Touch OK key.
& When the void areas are both the same for vertical and
horizontal, adjust the void width by using the F·G keys,
then touch OK key.
Set width of edge
Press OK
CANCEL
∗
Margin
Set width of margin
press OK
-
Initial setting (Factory setting): 5 mm
# Select margin area
$ Adjust each void width by using the F·G keys.
% Touch OK key.
∗
Initial setting (Factory setting): 10 mm
CANCEL
Cancel
Book
# Adjust each void width by using the F·G keys.
$ Touch OK key.
Set width of void
press OK
-
∗
∗
CANCEL
Cancel
NOTE
Initial setting (Factory setting) can be changed by the
User Mode function.
(Please refer to page 42)
C How to place the original when margin mode:
Platen
i-ADF
A
B
C
30
Initial setting (Factory setting): 20 mm
A
B
C
ADF
Zoom/Effects
Page Numbering
■ Feature
The page number can be automatically printed on each page.
MULTI-SIZE
FEED
SORT/
FINISH
USER
PRESET
ENERGY
SAVER
MANUAL INTERRUPT
RESET
A3
2
3
4
5
6
A4
7
8
9
0
#
A5
1 2
Position
Select Zoom/
original
Effect mode
(ADF/i-ADF
only)
3
4 5 6
Select Page
Numbering
Select
paper
Number of
copies
(Up to 999)
Press Start
Zoom/Effects
1
A4
FLS•B4
# Select print position for page numbering.
Select position and
start page; press OK
$ Select the first page to begin page numbering
using 10-key on the control panel. Page 1, 2 or
3 can be selected.
3
% Touch OK key.
& Touch ADF key or input the number of originals
with Key Pad.
( After originals are counted, touch the OK key.
) When the ADF key is touched in the step #,
re-position originals in document feeder.
Set number of originals
Press OK
C Page number is indicated with -n- or n/m form.
(Example)
Number of
originals
Number of Original
Cancel
CANCEL
NOTE
–1–
1/8
C The page numbering format can be changed in user preset mode. (See P.41)
C To reset a mode selected using the menu, touch Cancel key on the touch panel.
C Print position
1
1 1
Portrait
1
1
1
Landscape
31
Insertion Job
■ Initial Screen
Select function
DUPLEX/
BASIC
Basic MENU
Menu ORIG. --> COPY
ZOOM/
ZOOM/EFFECTS
EFFECTS
INSERTION
INSERTION
JOB
JOB
JOB
Job
memory
MEMORY
Presentation
OHP interleaving
Page insertion
Cover
C Touch the desired key to select the function.
Cover
Adds cover page(s) to the copies.
⇒ See P.33
Page insertion
Inserts paper between the copies.
⇒ See P.33
OHP interleaving
Inserts paper between OHP film.
⇒ See P.34
Inserts paper between OHP film and
makes copied sets for hand-outs.
⇒ See P.34
Presentation
NOTE
C The i-ADF/ADF is required for Insertion Job.
C To reset Insertion job, press reset key.
32
Insertion Job
Cover/Page insertion
■ Cover
■ Page insertion
Adds cover page(s) to the copies.
Inserts paper between the copies.
Blank Paper
Cover
Cover
Blank Paper Copied Paper
Copied Paper
Cover
Cover
Insertion
Cover
Cover
Back
Back
■ Procedure
ADF
i-ADF
MULTI-SIZE
FEED
SORT/
FINISH
USER
PRESET
ENERGY
SAVER
MANUAL INTERRUPT
RESET
A3
1
2
3
A4
4
5
6
A4
7
8
9
FLS•B4
A5
Face-Up
1
2 3 4 5
Position original
(Up to 50)
Select Cover or Select
Page Insertion cassette
Cover
# Select Cover mode (Front or Front/Back)
$ Select Blank or Copy
% Touch OK key.
2
Select mode
Press OK
Cover (Front)
Blank
Copy
3
Press
Start
# Touch ADF key (Count originals)
$ Select cassette and touch OK key.
Input number of originals
select paper tray
Press OK
Number of
originals
Cover (Front+Back)
Blank
Number of
copies
Copy
Cover
Copy
CANCEL
Cancel
CANCEL
Page insertion
# Select Blank/Copy mode
$ Touch OK key.
2
Select mode
press OK
3
# Touch ADF key (Count originals) % Input insert position
$ Select cassette and touch
(Up to 20)
OK key.
& Touch OK key.
Input number of originals
select paper tray
Press OK
Number of
originals
Page
insertion
Insertion
Blank
Input position of insert
press OK
Sheet placement
Copy
Page
insert
Copy
Cancel
CANCEL
NOTE
CANCEL
CANCEL
C The number of the originals can be input using the ten key instead of the
ADF originals count.
C To reset a mode selected using the menu, touch Cancel key on the touch
panel.
33
Insertion Job
Face-Down
0
Insertion Job
OHP Interleaving/Presentation
■ OHP interleaving
■ Presentation
Inserts paper between OHP
film.
Blank Paper
Copied Paper
1
1
(1)
2
2
OHP
OHP
(2)
OHP
Inserts paper between OHP film and makes copied sets
for hand-outs.
Copied Paper + Copies
Blank Paper + Copies
1
1
(1)
2
2
OHP
OHP
(1)
(1)
(2)
OHP
OHP
OHP
(2)
(2)
■ Procedure
ADF
i-ADF
MULTI-SIZE
FEED
SORT/
FINISH
USER
PRESET
ENERGY
SAVER
MANUAL INTERRUPT
RESET
A3
1
2
3
A4
4
5
6
A4
7
8
9
0
#
FLS•B4
A5
Face-Down
Face-Up
1 2
Place OHP
Place
(Sheet Bypass) originals
4
OHP interleaving
Select blank/copy and touch OK key
3 4 5 6 7
Select
Insertion
Job mode
Select
Select
blank/copy cassette
paper
Select mode
Press OK
Presentation
Presentation
OHP
interleaving
Blank insert
Copy
Cancel
CANCEL
5
OHP interleaving
Select cassette
Confirm selection
Press OK
Copy insert
CANCEL
Presentation
Select cassette
Confirm number of copies,
paper tray
Press OK
Page
insert
Page
insert
Copy
CANCEL
NOTE
34
Press
Start
Presentation
Select blank/copy insertion and touch OK
key
Select mode
Press OK
Blank
Number of
copies
CANCEL
C To reset a mode selected using the menu, touch Cancel key on the touch
panel.
Other Features
Job Memory
■ Five copy jobs can be programmed in memory (M1 to M5) for recall at a
later time.
MULTI-SIZE
FEED
SORT/
FINISH
USER
PRESET
ENERGY
SAVER
MANUAL INTERRUPT
RESET
A3
2
3
4
5
6
A4
7
8
9
0
#
A5
#
Job memory
Select Mem. in or Mem. #
= more settings
B4
70
160
95
220
A4
A4
A3
50 %
A5
Job memory
Select Mem. in or Mem. #
= more settings
100
To store a job into a memory
# Set up the copy job to be stored in memory.
$ Press Job Memory key
% Touch Memory In key. (f)
& Touch M1, M2, M3, M4 or M5 key.
B4
100
90
95
B4
*
Insertion Job
Job Memory
1
A4
FLS•B4
70
160
95
220
To recall a job from memory mode.
( Press Job Memory key
) Touch M1, M2, M3, M4 or M5 key.
* Press Start
B4
g: Means there are more settings other
than what is indicated on the display.
NOTE
C Job memory mode will not be deleted even if the Power Switch is turned off.
C When storing a new job, the previously stored job will automatically be
deleted and the current job stored in its place.
C To reset Programming job, press reset key.
35
Other Features
Digital Skyshot Modes
■ To copy from the platen with the platen cover or ADF open.
Two types of skyshot modes can be selected.
Manual Skyshot Mode: Making copies from small originals without dark areas around the
image.
Digital Skyshot Mode: Copies can be automatically adjusted although they are not placed in
parallel to the original guide. (except A3 and A4 B)
■ Setting the skyshot mode
MULTI-SIZE
FEED
SORT/
FINISH
USER
PRESET
ENERGY
SAVER
MANUAL INTERRUPT
RESET
A3
1
2
3
A4
4
5
6
A4
7
8
9
FLS•B4
A5
0
1A3 2
Press User Preset
Set the Skyshot Mode
(1) Touch the COPIER SETTINGS key.
User preset mode
Select function
GENERAL FUNCTIONS
COPIER SETTINGS
(2) Touch the H key to open the 2/3 of Copier settings
menu.
(3) Touch the Digital skyshot mode or Manual skyshot
setting key.
(4) Select the desired function and touch OK key.
User preset mode; copier
select item
OK
05 Reduce N in 1 for space
06 Digital skyshot setting
07 Manual skyshot setting
08 Paper size priority
(3)
Digital Skyshot Mode
None
Free shape: Copy is made with slant.
Parallel: Copy is made to parallel. (within 5 degree)
Manual Skyshot Mode:
OFF, M1 ON, M2 ON, M1&M2 ON
09
2/3
NOTE
C When changing the M1 or M2 size, please consult the key operator.
C Incorrect erasure may occur if there is a black line at the edge of the original or an
image which the copier is detected as a black pattern in the skyshot mode.
C Incorrect original position detection may occur if any strong light shines onto the platen
glass during skyshot mode.
36
Other Features
Digital Skyshot Modes
■ Operation
For Manual Skyshot Mode:
i-ADF
Platen
MULTI-SIZE
FEED
SORT/
FINISH
USER
PRESET
ENERGY
SAVER
MANUAL INTERRUPT
RESET
1
2
3
A4
4
5
6
A4
7
8
9
0
#
A5
1
2
Install the
check feeder
(1) Position original
(2) Adjust the guides
(i-ADF)
(Option)
3
4 5
Select M1 or M2
Press Start*
Number of
copies
Example M1: i-ADF
M2: Platen
Touch Job Memory key.
Touch M1 or M2 key.
JOB memory
select Mem. in or Mem. #
= more settings
Ready to Copy
JOB
Job
memory
Job
memory
MEMORY
DUPLEX/
ZOOM/
INSERTION
ZOOM/EFFECTS
INSERTION
JOB
BASIC
MENU
Basic Menu
ORIG. --> COPY
EFFECTS
JOB
Align
edges to
the arrow.
LIGHT
JOB STATUS
Check Feeder
TEXT
DARK
AUTO
DUPLEX
Basic Menu ORIG. --> COPY
ZOOM/EFFECTS
INSERTION JOB
SIZE 1
160mm 70mm
SIZE 2
95mm 220mm
Memory
in
Job memory
2
PAPER TRAY
TEXT/PHOTO PHOTO
For Digital Skyshot Mode:
Free shape
MULTI-SIZE
FEED
Original
SORT/
FINISH
USER
PRESET
MANUAL INTERRUPT
RESET
Copy
A3
1
2
3
A4
4
5
6
A4
7
8
9
0
#
FLS•B4
A5
1
Position original
on the Platen
 Make copies with ADF/i-ADF 
 or platen cover open.

NOTE
ENERGY
SAVER
Parallel
23
Number of
copies
Copy
Press Start
∗
In the manual skyshot mode, A4 size paper is selected automatically.
C When using the manual skyshot mode (M1 and M2 are turned ON), the
other job memory cannot be used.
C To reset the manual skyshot mode, press Reset key.
C To reset the digital skyshot mode, close the ADF/i-ADF or platen.
Automatically turns On or Off by opening/closing.
37
Digital Skyshot Modes
A3
FLS•B4
Other Features
Energy Saver/Interrupt
Energy Saver Key
MULTI-SIZE
FEED
SORT/
FINISH
USER
PRESET
ENERGY
SAVER
Interrupt Key
MANUAL INTERRUPT
RESET
A3
1
2
3
A4
4
5
6
A4
7
8
9
0
#
FLS•B4
A5
Start Key
■ This mode can save power while the copier is not
in use.
Energy Saver Mode
ENERGY
SAVER
# To enter this mode
Press Energy Saver key, the indicator will flash.
$ To cancel this mode and make copies
Press Energy Saver key again.
Sleep Mode
# Automatically enters after 60 minutes from the last
copy. Copier power will drop and the indicator will
light.
$ To make copies, press Energy Saver key.
INTERRUPT
Interrupt Mode
C This mode can interrupt other copy jobs while making copies.
Interrupt Tray
3rd bin
NOTE
(FA-F350/F355)
# Press Interrupt key, then indicator will light.
When pressing Interrupt key twice, interrupt mode
is cancelled.
$ When in interrupt mode, only the platen glass can
be used.
For FA-F350/F355
Copies are exited to the interrupt tray
% Touch Interrupt key again to continue original job.
(
)
While making staple sort copy with FA-F365, the
Interrupt mode will be started after completing the
staple sort copies.
C Energy saver time (15 minutes) and Auto off time (60 minutes) can be changed by key
operator. (See P.44)
Power Consumption
Warm Up Time
FP-D355/D355DC FP-D455/D605 FP-D355/D355DC FP-D455/D605
Normal Operation Approx. 200 Wh Approx. 230 Wh
None
None
Power Saving Mode Approx. 135 Wh Approx. 190 Wh
30 sec.
30 sec.
Approx.
9
Wh
Approx.
15
Wh
75
sec.
180 sec.
Sleep Mode
Modes
38
Other Features
Combining Function Table
INSERTION
JOB
INSERTION
Other Functions
JOB
1\2
2\1
2\2
Book \ 2
2 Page
N in 1
Booklet∗∗
1 to N
Zoom
Auto Zoom
Centring
Page Numbering
Edge
Margin
Book
Mirror
Inverse
Presentation
OHP interleaving
Page insertion
Cover
Interrupt
Nonsort
Sort
Group
Staple sort
Punch∗
Manual skyshot
Digital skyshot
– – – – O – – OOOOOOO – – – – OOOOOOOO
–
– – – – – – O – – OOO – – – – – OOOOOOOO
– –
– – – – – O – – OOO – – – – – OOOOOOOO
– – –
– – – – – – – – OOO – – – – – – – OOOe –
– – – –
– – – – – – – O – O – – – – – – – OOOe –
O – – – –
– – – – – – – – – – – – – – – – OOOOO
– – – – – –
– – – – – – – – – – – – – – – – O – – –
– – – – – – –
– – – – – – – – – – – – – – OOOe –
OOO – – – – –
– OOOOOOOOOOOOOOOOO
O – – – – – – – –
O – OOO – – – – – – – OOOOO
O – – – – – – – OO
– OOOOO – – – – – O – – – O
OOO – – – – – O – –
OO – – – – – OO – OO – OO
OOOOO – – – OOOO OO – – OOOOOOOOOO
OOOOO – – – OOOOO O – – – – OOOOOOOO
O – – OO – – – OOO – OO
– – – – – – OOOOOO
– – – – – – – – O – O – – – –
O – – – – OO – – – O
– – – – – – – – O – O – – – –O
– – – – OO – – – O
– – – – – – – – O – – – O – – – –
– – – – – O – OO
– – – – – – – – O – – – O – – – – –
– – – O – – – –
OOO – – – – – O – – OOO – – – – –
O – – O – OO
OOO – – – – – O – – OOO – – – – – –
– – O – OO
– – – – – – – – O – – – OOOOO – – – –
O – – – –
OOOOOO – OOOOOOOOOO – O – – O
– – – O
OOOOOOOOOOOOOOO – – O – OOO –
– – O
OOOOOO – OOOO – OOO – – – – – – O – –
– O
OOOeeO – eOOOOOOO – – – – OO – – – –
O
OOO – – O – – OOOOOOOOOO – OO – OOOO
– – – – – – – – – – – – – – – – – – – – – – – – – – –
O – – – – – – – O – – – OOOOO – – – – – O – – – O
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
O
–
–
–
–
–
–
–
O
–
–
–
O
O
O
O
O
–
–
–
–
–
O
–
–
–
O
–
–
O: Combination use is possible. However it may not accepted when further
multiple combinations are selected.
e: Combination use is not accepted on the FA-F320.
–: Combination use is not accepted, or not recommended.
NOTE
∗
Punch mode is available on the FA-F320 only.
∗∗ When making the Booklet copy with FA-F365, the Sort/Finish key cannot be
operated.
39
Energy Saver/Interrupt
Combining Function Table
ZOOM/EFFECTS
DUPLEX/ORIG.
H COPY
First
Selections
Other Functions
ZOOM/EFFECTS
1\2
2\1
2\2
Book \ 2
2 Page
N in 1
Booklet∗∗
1 to N
Zoom
Auto Zoom
Centring
Page Numbering
Edge
Margin
Book
Mirror
Inverse
Presentation
OHP interleaving
Page insertion
Cover
Interrupt
Nonsort
Sort
Group
Staple sort
Punch∗
Manual skyshot
Digital skyshot
Later
Selections
DUPLEX/ORIG.
H COPY
User Preset
■ User Preset modes allow you to change the initial copy mode, if
necessary.
Options
General
Functions
Copier
Settings
Printer
Settings
File Settings
Input Identification Code
General
Functions for
Key Operator
Copier
Settings for
Key Operator
File Settings
for Key
Operator
Printer
Settings for
Key Operator
■ Procedure
User Preset Key
MULTI-SIZE
FEED
SORT/
FINISH
USER
PRESET
Reset Key
ENERGY
SAVER
MANUAL INTERRUPT
RESET
A3
1
2
3
A4
4
5
6
A4
7
8
9
0
#
FLS•B4
A5
# Press User Preset Key.
C Setting menu will appear on the display.
User preset mode
Select function
GENERAL FUNCTIONS
COPIER SETTINGS
$ Select one of four functions.
C File and Printer settings are optional.
% Select mode
C Input ID code for key operator settings.
& Follow the on screen instructions.
( After setting, touch OK key in Display Panel.
) Press User Preset key or Reset key, then exit
User preset mode.
NOTE
40
C Please refer to each operation guide for file settings and printer settings.
User Preset
General Functions
■ User Preset modes allow you to change the initial copy mode, if
necessary.
00 Finisher mode default
OK
Nonsort
User preset mode; general
select item
05 Hard disk status
01 Staple position
Front
06 Departmental counter
02 Power on default mode
Copy
07 Page numbering style
03 Manual add toner
OFF
08 Hole punch default
04 User information change
2/2
OFF
2/2
Modes
Function
Initial setting
00 Finisher mode default
Selects finisher mode.
C Non-sort, Sort, Sort/Staple, Group
Non-sort
01 Staple position setting
Selects staple position.
C Front, Rear, Booklet
Front
02 Power on default mode
1/2
-n-
09 Key operator mode
1/2
Screen
No.
OK
∗
Selects mode.
C Copy or Filing
Copy
Allows the addition of toner as determined by
operator. Toner is rapidly added after selecting
ON and touching OK.
C OFF, ON
04 User information change ∗ Allows changing user information as determined
by operator. After user ID is entered or card is
inserted, the following items can be changed.
C User ID, Password.
05 Hard disk status
∗ Hard disk condition will indicate on the
screen for 3 seconds.
OFF
03 Manual add toner
06 Departmental counter
Copy usage and copy limit of selected
department and total copy usage will appear
on the screen for 3 seconds.
07 Page numbering style
Selects numbering style
C -n- or n/m (ex: -1- or 1/10)
-n-
08 Hole punch default
Selects hole punch mode
C OFF, ON
OFF
09 Key operator mode
Input key operator ID code.
NOTE
∗
User Preset
User preset mode; general
select item
Not needed in copying mode, but needed when installing options for
advanced functions (see page 99).
41
User Preset
Copier Settings
■ User Preset modes allow you to change the initial copy mode, if
necessary.
User preset mode; copier
select item
00 Margin value default
OK
10mm
5mm
06 Digital skyshot setting
02 Book value default
20mm
07 Manual skyshot setting
03 Margin reduction def.
100%
08 Paper size priority
04 Duplex mode default
No
Screen
No.
2/3
05 Reduce N in 1 for space
01 Edge value default
1/3
1/3
User preset mode; copier
select item
Modes
OK
No
Freeshp
OFF
A4
09
2/3
Function
Initial setting
00 Margin value default
Selects the margin shift value.
C 5mm, 10mm, 15mm or 20mm
10mm
01 Edge value default
Selects the edge width.
C 5mm, 10mm, 15mm or 20mm
5mm
02 Book value default
Selects the book void width.
C 15mm, 20mm, 25mm or 30mm
20mm
03 Margin reduction default
Selects the reduction ratio in margin mode.
C 100%, 95%, 93% or 91%
100%
04 Duplex mode default
Determines most frequent usage mode
C No, 1 to 2, 2 to 2 or Book to 2
No
05 Reduce N in 1 for space
Selects whether or not to disable edge deletion No
C No, Yes
06 Digital skyshot setting
Selects whether or not to disable edge
deletion*
C None, Freeshap, Parallel
Free shape
07 Manual skyshot setting
Enables or disables the use of Manual
Skyshot.
C OFF, M1 ON, M2 ON, M1&M2 ON
OFF
08 Paper size priority
Specifies the paper size in manual paper size
setting mode.
C A4, A4-R, B4⋅FLS, A3, A5
A4
09 (Reserved)
NOTE
42
∗
To copy from the platen with the original
cover or i-ADF open. Normally, this makes
Copy
Copy
a copy with a solid (black) area around the
original if the original is smaller than the
copy paper. This mode eliminates the solid
Digital Skyshot Digital Skyshot
area automatically.
Mode (OFF)
Mode (ON)
User Preset
■ User Preset modes allow you to change the initial copy mode, if
necessary.
User preset mode; copier
select item
OK
10 Skyshot paper selection
11 Booklet scanning
1 time
12
13
14 Key operator mode
3/3
Modes
Function
Initial setting
10 Skyshot paper selection
Select skyshot operation.
When the Parallel function is selected in the
06 Digital skyshot setting (See page 42).
C Matching, Auto
Matching
11 Booklet scanning
Select booklet scanning operation.
(For FA-F365)
C 1 time (less than 50 originals), Open (more
than 51 originals)*
1 time
3/3
User Preset
Screen
No.
12 (Reserved)
13 (Reserved)
14 Key operator mode
Input key operator ID code.
∗
For Example: 60 originals
1st step: Position originals of page 11 to 60.
2nd step: Position originals of page 1 to 10.
43
User Preset
General Functions for Key Operator
■ Input key operator ID code to change settings.
User preset mode; general
select item
OK
00 Paper size
None
1 min.
06 Special paper tray 2
None
15 min.
07 Finisher bin function
C/F/P
03 Auto off time
60 min.
08 Auto paper out rotate
OFF
04 Language default
English
09
02 Energy saver time
1/9
Screen
No.
2/9
Modes
Function
Initial setting
00 Paper Size
Sets the paper size of each paper drawer.
C A3, B4, A4, A4-R, B5, B5-R, A5, FLS1,
FLS2, Ledger, Legal, Letter, Letter-R,
Invoice
Contact
your
service
provider.
01 Auto reset time
Selects the reset time.
C None, 45 seconds, 1 minute, 2 minutes
Selects the energy saver time.
C 5/15/30/60 minutes, 1.5/3/4 hours
Selects the Auto off time.
C No, 15/30/60 minutes, 1.5/3/4 hours
Selects the message language of the display.
C Japanese, English, French, Spanish
Sets the paper drawer for special paper (eg:
coloured).
C None, Copier upper, Copier lower, System
Console Upper, Middle Lower, LCC, Bypass
1 minute
06 Special paper tray 2
Sets another paper drawer for special paper.
C Same as above
None
07 Finisher bin function
C1: Copy, Filing
(1st priority)
C2: Copy, Filing
(2nd priority)
P : Printer
∗
C1/C2/P
02 Energy saver time
03 Auto off time
04 Language default
05 Special paper tray 1
2/9
OK
05 Special paper tray 1
01 Auto reset time
1/9
User preset mode; general
select item
08 Auto paper out rotate
Selects stack position for 3 bin finisher
(For FA-F350/F355: Top/Middle/Lower,
For FA-F365: Top/Lower/Invalid)
C C1/C2/P
C2/P/C1
C1/P/C2
P/C1/C2
C2/C1/P
P/C2/C1
Copier will automatically rotate image and
print when selected paper drawer is empty.
C OFF, ON
15
minutes
60
minutes
English
None
OFF
09 (Reserved)
NOTE
∗
Not needed in copying mode, but needed when installing options for advanced
functions (see page 99).
C It is necessary to input operator ID code before changing items on this page.
44
User Preset
■ Input key operator ID code to change settings.
User preset mode; general
select item
OK
User preset mode; general
select item
10 Original set beep sound
15 No ID operation
11 Orig. set sound ADF
16 User registration
12 Unknown file access def
Group
18 User information change
14 Dept. counter mode
19 ID card change
3/9
4/9
Modes
10 Original set beep sound
11 Original set beep sound
in ADF
12 Unknown file access
default
13 (Reserved)
Function
Initial setting
——
——
——
——
∗
Selects the unknown access rights
C Group, Public
Group
Contact
your
service
provider.
17 User delete
Monitors copy usage of each department
(1) Copy usage of each department
(2) Copy limit of each department
(3) Copy number of each department
∗ Operation for user without access rights
C No save (prohibit filing functions)
Free (permit filing functions)
∗ Registers user to the copier
C User name, department, Tel No., user ID
number, password
∗ Deletes user registration
18 User information change
∗
Changes user information registered
19 ID card change
∗
Changes ID card information registered
14 Departmental counter
mode
15 No ID operation
16 User registration
NOTE
∗
User Preset
Screen
No.
4/9
Free
17 User delete
13
3/9
OK
Free
Not needed in copying mode, but needed when installing options for advanced
functions (see page 99).
C It is necessary to input operator ID code before changing items on this page.
45
User Preset
General Functions for Key Operator
■ Input key operator ID code to change settings.
User preset mode; general
select item
OK
User preset mode; general
select item
20 Date time setting
25
21
26
22 TCP/IP address
27
23 TCP/IP subnet mask
28
24 TCP/IP default gateway
29 DD file server IP add.
5/9
Screen
No.
6/9
Modes
20 Date time setting
OK
Function
Initial setting
Sets date time registered
C Day, Month, Year, Time
21 (Reserved)
5/9
22 TCP/IP address
∗
23 TCP/IP subnet mask
∗
24 TCP/IP default gateway
∗
Sets user IP address
C 3 digit × 4
Sets the subnet mask
C 3 digit × 4
Sets the gateway address
C 3 digit × 4
25 (Reserved)
26 (Reserved)
6/9
27 (Reserved)
28 (Reserved)
29 DD file server IP add.
NOTE
∗
∗
Sets DD file server IP address
C 3 digit × 4
Not needed in copying mode, but needed when installing options for advanced
functions (see page 99).
C DD file server: It is a Network server which is able to connect with the Hyper
Document System (HDS). DD server software is required when the HDS server
function is used.
46
C It is necessary to input key operator ID code before changing items on this page.
User Preset
■ Input key operator ID code to change settings.
OK
User preset mode; general
select item
OK
30 Hard disk backup select Manual
35 Hard disk backup
Stop
31 Hard disk backup time
36 System version update
Stop
32 Hard disk backup day
37 User ID input
Sunday
33 Backup to RMV media
Stop
38 User info. list print
34 Restore from RMV media Stop
Stop
39
8/9
7/9
Screen
No.
Yes
Modes
Function
Initial setting
30 Hard disk backup select
∗
31 Hard disk backup time
∗
32 Hard disk backup day
∗
Sunday
33 Backup to RMV media
∗
Stop
34 Restore from RMV media
∗
Stop
35 Hard disk backup
∗
Stop
36 System version update
∗
Stop
37 User ID input
∗
Yes
38 User info. list print
∗
Stop
7/9
8/9
Selects the Hard disk backup method
C Auto, Manual
Manual
User Preset
User preset mode; general
select item
Sets the Hard disk backup time
C Hour: minute
Selects the Hard disk backup day
C Sunday, Monday, Tuesday, Wenes.,
Thursday, Friday, Saturday, Everyday
Selects the backup to removable media
C Stop, Start
Selects the restore from removable media
C Stop, Start
Selects the hard disk backup manually
C Stop, Start
Selects the system version update
C Stop, Start
Selects the user ID input to use without ID
card
C No, Yes
Allows printing user information
(User name, department, Tel No., user ID
number, password)
C Stop, Start
39 (Reserved)
NOTE
∗
Not needed in copying mode, but needed when installing options for
advanced functions (see page 99).
C It is necessary to input key operator ID code before changing items on this
page.
C RMV is 100MB Zip Disk
47
User Preset
General Functions for Key Operator
■ Input key operator ID code to change settings.
User preset mode; general
select item
OK
40 Fold position (A3/Ledger)
41 Fold position (B4)
42 Fold position (A4/Letter-R)
43 Fnisher bin def. timer
44 (Reserved)
9/9
Screen
No.
9/9
Modes
Function
Initial setting
40 Fold position (A3/Ledger)
C –4 ~ +4 mm
0mm
41 Fold position (B4)
C –4 ~ +4 mm
0mm
42 Fold position (A4/Letter-R) C –4 ~ +4 mm
0mm
43 Finisher bin def. timer
C None, 3 sec., 10 sec., 30 sec.
3 sec.
44 (Reserved)
NOTE
48
C It is necessary to input key operator ID code before changing items on this page.
User Preset
Copier Settings for Key Operator
■ Input key operator ID code to change settings.
00 Auto exposure default
OK
Manual
P/T
02 Photo mode contrast
Medium
07 Page insertion default
03 T/P mode contrast
Medium
08 Cover mode default
1/4
Screen
No.
Modes
00 Auto exposure default
01 Original mode default
02 Photo mode contrast
03 T/P mode contrast
(Text/Photo mode)
04 Photo mode sharpness
05 T/P mode sharpness
(Text/Photo mode)
06 Interleaving default
07 Page insertion default
2/4
05 T/P mode sharpness
01 Original mode default
04 Photo mode sharpness Medium
1/4
User preset mode; copier
select item
08 Cover mode default
09 SADF default
NOTE
06 Interleaving default
09 SADF default
OK
Medium
Blank
Blank
F,Blank
No
2/4
Function
Initial setting
Determines whether to use Auto Exposure mode
C No, Auto, Manual
Selects original setting
C Text, T/P (Text/Photo), Photo
Selects contrast for Photo mode
C lightest, light, normal, dark, darkest
Selects contrast for Text/Photo mode
C light, normal, dark
Selects Sharpness for Photo mode
C light, normal, dark
Selects Sharpness for Text/Photo mode
C light, normal, dark
Selects OHP interleaving paper
C Blank, Copy
Selects Page Insertion
C Blank, Copy
Selects Cover paper
C F, Blank (Front cover blank),
F, Copy (Front cover copied),
FB, Blank (Front & back cover blank),
FB, Copy (Front & back cover copied)
Manual
Enables or disables the use of SADF function.
C No, Yes
No
User Preset
User preset mode; copier
select item
T/P
Medium
Medium
Medium
Medium
Blank
Blank
F, Blank
C It is necessary to input key operator ID code before changing items on this
page.
49
User Preset
Copier Settings for Key Operator
■ Input key operator ID code to change settings.
User preset mode; copier
select item
OK
OFF
10 Maximum copy setting
11 Multisize rotation
No
OK
15
16 Memory overflow warning Print
12 M1, size
70 × 160
17 Document save default
13 M2, size
95 × 220
18 Image data memory time 20min.
14 Text mode sharpness
Medium
19
3/4
Screen
No.
Modes
10 Maximum copy setting
11 Multisize rotation
3/4
User preset mode; copier
select item
12 M1, size
13 M2, size
14 Text mode sharpness
No
4/4
Function
Determines whether to limit number of copies
(1-99) or not
When using the same size paper in Multi-size
feeding mode, select the paper direction by
rotating or not.
C No, Yes
Input a size in memory 1 for frequent usage
size. (X: width, Y: Length)
Input a size in memory 2 for frequent usage
size. (X: width, Y: Length)
Selects sharpness for Text mode
C light, normal, dark
Initial setting
OFF
(No limit)
No
rotation
70 × 160 mm
(X) (Y)
95 × 220 mm
(X) (Y)
Medium
15 (Reserved)
4/4
16 Memory overflow
warning
17 Document save default
Selects the memory overflow warning
C Print, Cancel
∗ Selects the document save default
C No, Yes
18 Image data memory time C Keep, 3min., 5min., 10min., 20min., 30min.
Print
No
20min.
19 (Reserved)
NOTE
∗
Not needed in copying mode, but needed when installing options for advanced
functions (see page 99).
C It is necessary to input key operator ID code before changing items on this page.
50
User Preset
User Setting
■ Paper size priority
Specifies the paper size in manual paper size setting mode.
MULTI-SIZE
FEED
SORT/
FINISH
USER
PRESET
ENERGY
SAVER
1
2
3
A4
4
5
6
A4
7
8
9
FLS•B4
A5
2
MANUAL INTERRUPT
RESET
A3
0
Proceed according to screen order
# Touch copier setting.
GENERAL FUNCTIONS
COPIER SETTINGS
User preset mode; copier
select item
00 Margin value default
OK
User Preset
1
Press user preset key
$ Proceed to next page..
10mm
01 Edge value default
5mm
02 Book value default
20mm
03 Margin reduction def.
100%
04 Duplex mode default
No
1/2
User preset mode; copier
select item
05 Reduce N in 1 for space
06 Digital skyshot setting
07 Manual skyshot setting
08 Paper size priority
OK
% Touch 08 (Paper size priority).
No
Freeshp
OFF
A4
09 Set key operator code
2/2
& Touch paper size you require and touch OK key.
( Press Reset key then exit Function preset.
51
User Preset
User setting for key operator
■ Check paper size
The paper trays are designed to accommodate A5, A4, A4R, B4·FLS and A3 size paper. To
change the paper size, perform following steps as shown below.
1
Press user preset key
MULTI-SIZE
FEED
SORT/
FINISH
USER
PRESET
ENERGY
SAVER
1
2
3
A4
4
5
6
A4
7
8
9
FLS•B4
A5
2
MANUAL INTERRUPT
RESET
A3
0
Proceed according to screen order
# Touch general functions
User preset mode
Select function
( Select 00 (Paper size)
User preset mode; general
select item
OK
00 Paper size
GENERAL FUNCTIONS
COPIER SETTINGS
01 Auto reset time
1 min.
02 Energy saver time
15 min.
03 Auto off time
60 min.
04 Language default
English
1/9
$ Proceed to next page.
User preset mode; general
select item
00 Finisher mode default
OK
Nonsort
01 Staple position
Front
02 Power on default mode
Copy
03 Manual add toner
) Touch paper drawer you require and
select paper size∗
Select paper trey
press OK
OFF
04 User information change
1/2
% Select key operator key
User preset mode; general
select item
OK
Paper size is changing as follows.
05 Hard disk status
A3
06 Departmental counter
07 Page numbering style
08 Hole punch default
A4
OFF
09 Key operator mode
2/2
& Input ID code (3 digit) and touch OK key
User preset mode
input identification code
B4⋅FLS
-n-
A5
A4R
* Touch OK key.
+ Press Reset key then exit Function
preset
CANCEL
NOTE
52
∗
If the paper tray is not installed or is not inserted completely, the paper size indication
will not appear.
User Preset
# Pull out paper drawer and remove
paper.
$ Move paper guide a to the paper
length required.
Paper Guide a
2
% Move paper guide b to the paper
width required.
User Preset
3
Change paper guide inside of paper drawer and paper size indicator
3
Squeeze the stopper to move the paper
guide b to the desired paper size.
Stopper
Paper
Guide b
& Change the paper size indicator.
Take out and re-insert the indicator so
the correct paper size is shown.
(A5 size is on the rear)
Size Indicator
( Place new paper into drawer.
) Close paper drawer.
53
User Preset
User Preset modes for Key operator.
■ Departmental counter
Key operator can manage, limit copies, counters and code numbers for each department.
(Maximum department number: 100)
1
Press user preset key
MULTI-SIZE
FEED
SORT/
FINISH
USER
PRESET
ENERGY
SAVER
RESET
A3
1
2
3
A4
4
5
6
A4
7
8
9
FLS•B4
A5
2
MANUAL INTERRUPT
0
Proceed according to screen order
# Select General function
User preset mode
Select function
& Proceed to screen 3/9 and select 14
Departmental counter mode.
User preset mode; general
select item
GENERAL FUNCTIONS
COPIER SETTINGS
OK
10 Original set beep sound
11 Orig. set sound ADF
12 Unknown file access def
Group
13
14 Dept. counter mode
3/9
$ Proceed to next page and select 09 key
operator key.
User preset mode; general
select item
OK
05 Hard disk status
( Select menu of total counter, count
number, limited number or password,
and touch OK key.
06 Departmental counter
07 Page numbering style
08 Hole punch default
Departmental counter data
-nOFF
TOTAL COUNTER DEPT. COUNTER
Print list
MAX. COPIES
I.D CODE
09 Key operator mode
2/2
Input
% Input ID code (3 digit) and touch OK key
User preset mode
input identification code
CInput 0 means total counters
will be cleared.
CANCEL
NOTE
54
C To reset the user preset mode, press Reset key.
User Preset
3
Change Number of Department counter, limit copy and code number.
% OK
Departmental counter data
TOTAL
DEPT.
COUNTER
COUNTER MAX. COPIES
I.D CODE
001 012346 002 000000 003 000000 004 000000
005 000000 006 000000 007 000000 008 000000
Number of Department counter
# Select required department using the scroll key.
$ Input “0” means clear all counts.
% Touch OK key.
009 000000 010 000000 011 000000 012 000000
013 000000 014 000000 015 000000 016 000000
017 000000 018 000000 019 000000 020 000000
Counts (6 digit)
Input
#
001 012346
$
#
% OK
Departmental counter data
TOTAL
DEPT.
COUNTER
COUNTER MAX. COPIES
I.D CODE
001 015000 002 000000 003 000000 004 000000
005 000000 006 000000 007 000000 008 000000
Department No. (3 digit)
Limit copy for each Department
# Select required department using the scroll key.
$ Input limit copy number.
% Touch OK key.
009 000000 010 000000 011 000000 012 000000
017 000000 018 000000 019 000000 020 000000
Limit copy number (6 digit)
Input
#
001 015000
User Preset
013 000000 014 000000 015 000000 016 000000
$
#
% OK
Departmental counter data
TOTAL
DEPT.
COUNTER
COUNTER MAX. COPIES
I.D CODE
001 112233 002 000000 003 000000 004 000000
005 000000 006 000000 007 000000 008 000000
Department No.
Code number for each department
# Select required department using the scroll key.
$ Input code number.
% Touch OK key.
009 000000 010 000000 011 000000 012 000000
013 000000 014 000000 015 000000 016 000000
017 000000 018 000000 019 000000 020 000000
Code number (1~6 digit)
Input
#
4
$
001 112233
#
Department No.
Exit user preset mode
User preset mode; general
select item
# OK
# Touch OK key.
$ Press user preset key on control panel.
10 Original set beep sound
11 Orig. set sound ADF
12 Unknown file access def
Group
13
14 Dept. counter mode
3/9
NOTE
C To reset the user preset mode, press Reset key.
55
Options
Options
2 Bin Finisher
(FA-F320 for FP-D355/D355DC)
C When hole punching copies.
(Lower bin functions)
C A4 size only. (Except A4 C)
C Single position stapling.
C Offset sets automatically
ADF, Automatic Document Feeder
(FA-A355 for FP-D355/D355DC)
i-ADF, Inverting Automatic Document
Feeder
(FA-A888)
C To feed originals automatically.
C Multi-size feeding.
C For N in 1 copying.
C For duplex copying. (FA-A888 only)
Inverting Shift Tray
(FA-TR350)
2 Bin Inverting Shift Tray
(FA-TR355)
C Offset sets automatically
C 250 sheets capacity.
Inverting Unit
(FA-RU350 for FA-F350/F355)
(FA-RU355 for FA-F350/F355/F365)
C Face down
C Used only with the 2/3 Bin Finisher.
2 Bin Finisher
(FA-F365 for FP-D455/D605)
C Multi-position stapling.
(50 sheets)
C All 2 bins shift.
C Saddle Stitch.
Options for 2 Bin
Finisher
Punch Unit
(FA-SP30)
C When hole punching
copies.
3 Bin Finisher
(FA-F350 for FP-D355/D355DC
FA-F355 for FP-D455/D605)
C Large capacity
(Max. 1,550 copies)
C Multi-position stapling.
(50 sheets)
C All 3 bins shift.
ADU, Automatic Duplex Unit∗
(FA-MADM8)
C For duplex copying.
Options for 2/3 Bin Finisher
Exit Guide Unit (FA-FK35/FK36)
C When 2/3 Bin Finisher is
installed.
C FA-FK35 cannot be used
with FA-F365.
System Console
(FA-DS725/DS825)
C To increase paper feed sources and
capacity.
(Storage Drawer × 1)
■ Other Options
Hard Disk for electronic sort
(FA-HD13 for FP-D355/D355DC)
(FA-HD14 for FP-D455/D605)
Platen Cover (FA-UC20)
Platen Cover Mounting Kit
(FA-GK35)
Exit Tray (FA-X350)
NOTE
56
3000 Sheet Large Capacity Cassette
(FA-MA301)
C 3000 sheets
Options for System Console
Paper Drawer
(FA-MA0556)
C 550 sheets
∗: On the FP-D355DC/D455/D605 type, the ADU (Automatic Duplex Unit/FA-MADM8) is
standardly equipped.
Options
ADF (FA-A355)/i-ADF (FA-A888)
1. Features
# Automatic original feeding
C The ADF/i-ADF tray can hold up to 50 originals of 80 g/m2 paper. (30 originals/B4·FLS, A3)
It can accommodate originals from A5 to A3 size (50 to 110 g/m2).
C Automatic original size detection.
$ Duplex Copying (FA-A888)
CThe i-ADF allows you to perform two different types of duplexing automatically. (See P.15-26)
% Multi-size feeding
C Different size originals to be copied full size (1:1) or same size. (See P.58)
& 2:1 Copy (FA-A888)
C Double sided original to single sided copies. (See P.16)
( N in 1 copy (FA-A888)
C To make a single sided copy (full size or reduction), from two (or four or eight) single sided
originals side-by-side. (See P.19-24)
) SADF (Single Automatic Document Feeder) Function
C A special original (like thin paper etc.,) can be fed from the ADF/i-ADF original tray and copied
continuously with manual operation. (See P.26)
2. Components
FA-A888
Face-Down
Options
Automatic Document
Feeder
FA-A355
Face-Up
Original Feed
Tray
Original Guides
Adjust to width of original.
Original Feed
Original Size Indicator
Tray
Original Guides
Adjust to width of original.
57
Options
3. Operation
■ Operation Procedure
ADF
i-ADF
MULTI-SIZE
FEED
SORT/
FINISH
USER
PRESET
ENERGY
SAVER
MANUAL INTERRUPT
RESET
A3
1
2
3
A4
4
5
6
A4
7
8
9
FLS•B4
A5
Face-Down
Face-Up
1
(2) (3) 4 5
Select Multisize feeding
Position
original
For Duplex copy Number of
(FA-A888)
copies
Inappropriate originals
C Paper with a smooth surface such as glossy
and coated papers
C Transparencies
C Originals with a lead edge that is creased,
folded, punched or glued
(2)
A3
A4
Press Start
C Paste-ups
C Pressure sensitive paper or paper with
carbon backing
C Paper with excessive curl
C Stapled originals
C Paper with fresh oil on them
Combination of Multi-size feeding
Originals
58
0
Copies
Full Size
Reduction
A3
A4
A4R
A4
Options
3 Bin Finisher, Exit Guide Unit (FA-F350/F355/FK35/FK36)
1. Features
FA-F350/F355 (3 Bin Finisher)
Shift-group
Shift-sort
1
2
3
Staple-sort
1
1
1
C Shift electronic sort copy
C Staple electronic sort copy
C Up to 50 originals (A4)/30
originals (A3, B4, A4 C)
C Paper Weight: 64 – 80 g/m2
FA-FK35/FK36 (Exit guide unit)
C Feeds paper to 3 bin finisher
2. How to use
ADF
i-ADF
MULTI-SIZE
FEED
SORT/
FINISH
USER
PRESET
ENERGY
SAVER
MANUAL INTERRUPT
RESET
1
2
3
A4
4
5
6
A4
7
8
9
A5
Face-Down
Automatic Document
Feeder
3 Bin Finisher, Exit Guide Unit
A3
FLS•B4
0
Face-Up
1 2 3 4 5
Platen
Staple Position
(ex. %-1)
Position
original
Select Sort/
Finish key
Number
Select
sort mode of copies
Press
Start
Face-Down
Select finisher mode(s)
Press OK
1
∗
OK
2
3
The Shift-sort is not available in the
first set when the memory is full.
Select the type of copy group mode into inverting unit
# Non-sort
Copy is stored on the tray
$ Shift-sort*
Multiple copies are sorted automatically and
stacked with shift.
% Staple-sort
Following functions can be selected by
pressing staple-sort key.
%-1: Top left corner (1 position)
%-2: Left (2 positions) (except A4 C)
%-3: Bottom left corner (1 position)
& Shift-group
Multiple copies are stored by shifting
59
Options
3 Bin Finisher, Exit Guide Unit (FA-F350/F355/FK35/FK36)
3. Operation
Interrupt Tray
When using interrupt copy mode.
1 Bin
2 Bin
3 Bin
(1) Bin Capacity (sheets)
Modes
Paper Size
Staple-sort
A4
Non-sort
Shift-sort
Shift-group
Interrupt
Tray
None
A4 R, B4⋅FLS, A3
None
A4, A5
A4 R, B4⋅FLS, A3
50∗
30∗
∗
1 Bin
2 Bin
300
750
or (30 sets)
150
500
or (30 sets)
300
1000
150
500
3 Bin
200
(20 sets)
100
(20 sets)
200
100
Non-sort only
(2) Interrupt Copying
From the platen glass only.
MULTI-SIZE
FEED
SORT/
FINISH
1
Press Interrupt key
USER
PRESET
ENERGY
SAVER
MANUAL INTERRUPT
RESET
A3
1
2
3
A4
4
5
6
A4
7
8
9
FLS•B4
A5
0













2
Select copy modes
(Max. 50 copies)
60
3 4
Press Start
key
Copies are
stacked on the
Interrupt Tray
Options
3 Bin Finisher
(3) When replacing the staple cartridge
Add staple
OK
1
The message shown on the left appears
when the staples are out.
Open the stapler cover.
Stapler
cover
2
$ Pull out the staple unit until it stops.
Lock Knob
3
# Remove the empty staple cartridge.
NOTE: Leave any remaining staples in
the stapler unit.
$ Install the new cartridge.
% Push the staple unit back to original
position, then turn the lock knob in
clockwise direction.
4
NOTE
Check the operation
Select the staple-sort mode with control
panel and print the desired data.
C If the unit fails to staple after replacing the staple
cartridge follow the instructions below.
# Remove the staple cartridge.
$ Pull down the stapler towards you.
% Press the release knob and swing the staple jam
lever back and forth.
If the unit still fails to work, contact your service
provider.
61
3 Bin Finisher, Exit Guide
Unit
3 Bin Finisher
# Turn the lock knob in counter clockwise
direction.
Options
2 Bin Finisher, Exit Guide Unit (FA-F365/FK36/SP30)
1. Features
FA-F365 (2 Bin Finisher)
Shift-group
Shift-sort
Staple-sort
Punch
2
4
6
1
1
1
3
1
5
C Shift electronic sort copy
C Staple electronic sort C Stack by punch
copy
C Up to 50 originals
(A4)/30 originals (A3,
B4, A4 C)
C Paper Weight: 64 – 80
g/m2
FA-FK36 (Exit guide unit)
C Feeds paper to 2 bin finisher
2. How to use
i-ADF
MULTI-SIZE
FEED
SORT/
FINISH
USER
PRESET
ENERGY
SAVER
MANUAL INTERRUPT
RESET
A3
1
2
3
A4
4
5
6
A4
7
8
9
FLS•B4
A5
0
Face-Up
1 2 3 4 5
Platen
Staple Position
(ex. %-1)
Position
original
Select Sort/
Finish key
Number
Select
sort mode of copies
Press
Start
Face-Down
Select finisher mode(s)
Press OK
∗
62
OK
The Shift-sort is not available in the
first set when the memory is full.
Select the type of copy group mode into inverting unit
# Non-sort
Copy is stored on the tray
$ Shift-sort*
Multiple copies are sorted automatically and
stacked with shift.
% Staple-sort
Following functions can be selected by
pressing staple-sort key.
%-1: Top left corner (1 position)
%-2: Left (2 positions) (except A4 C)
%-3: Bottom left corner (1 position)
& Shift-group
Multiple copies are stored by shifting
( Punch
Copies are punched and exited onto bin/tray.
Options
3. Operation
Punch Unit (Option/FA-SP30)
When punching the copies (2 or 3 holes)
1 Bin
2 Bin
Saddle Sticher Tray
When using the Booklet copy mode (See page 24)
(1) Bin Capacity (sheets)
Paper Size
1 Bin
Staple-sort
A4
750
750
or (30 sets)
500
500
or (30 sets)
1000
1000
500
500
A4 R, B4⋅FLS, A3
Non-sort
Shift-sort
Shift-group
A4, A5
A4 R, B4⋅FLS, A3
2 Bin
2 Bin Finisher, Exit
Guide Unit
Modes
(2) Saddle Stitcher Tray Capacity
Item
Paper Size
Capacity
Description
A3, A4R
W/out binding: 1 sheets
(including single cover page)
W/binding
: 2 to 15 sheets
Paper Capacity 10 sets (stack of 11 to 15 sheets), 15 sets (stack of 6 to 10 sheets),
25 sets (stack of 5 sheets or less)
NOTE
C An FA-FK36 is required when installing the optional FA-F365.
63
Options
(3) When replacing the staple cartridge
Add staple
OK
1
The message shown on the left appears
when the staples are out.
Open the stapler cover.
Stapler
cover
2
# Turn the lock knob in counter clockwise
direction.
$ Pull out the staple unit until it stops.
Lock Knob
3
# Remove the empty staple cartridge.
NOTE: Leave any remaining staples in
the stapler unit.
$ Install the new cartridge.
% Push the staple unit back to original
position, then turn the lock knob in
clockwise direction.
4
NOTE
64
Check the operation
Select the staple-sort mode with control
panel and print the desired data.
C If the unit fails to staple after replacing the staple cartridge
follow the instructions below.
# Remove the staple cartridge.
$ Pull down the stapler towards you.
% Press the release knob and swing the staple jam lever
back and forth.
C If the unit still fails to work, contact your service provider.
C After installing finisher and changing staple cartridge, it might
be stapled without the staple for max. 8 times.
Options
(4) When supplying the saddle stitcher unit with staples
Supplying the Saddle Stitcher Unit with Staples
1
Open the lower front cover.
2
Slide out the stitcher unit.
3
Pull the stitcher unit to the front
once, and then shift it up.
4
Hold the empty cartridge on its
sides, and remove it.
2 Bin Finisher
To install a new staple cartridge perform the following steps.
65
Options
66
5
Fit the new cartridge.
6
Pull the stitcher to the front once,
and then return it to its original
position.
7
Push in the stitcher unit, and close
the lower front cover.
Options
2 Bin Finisher, Exit Guide Unit (FA-F320/FK35/FK36)
1. Components
Upper Bin
C Stack face up
C Hole Punch
Lower Bin
C A4 size only. (Except A4 C)
C Stapling (Up to 30 originals)
C Shift electronic sort
C Stack face down
FA-F320
2. Features
■Upper Bin
Rotate
Punch
3
2
C Sort by rotating sets
2 Bin Finisher
2 Bin Finisher, Exit Guide
Unit
1
C Stack by punch
■Lower Bin
Shift
Punch
Punch and Shift
C Offset using
electronic sorting
Staple Sort
Punch and Staple
C Offset using
C Sort by punching
punching and
and stapling sets
electronic sorting
C Sort by stapling sets
■FA-FK35/FK36 (Exit Guide Unit )
C Feeds paper to 2 bin finisher.
FA-FK35/FK36 should be installed when installing FA-F320.
67
2 Bin Finisher, Exit Guide Unit
3. How to use
ADF
i-ADF
MULTI-SIZE
FEED
SORT/
FINISH
USER
PRESET
ENERGY
SAVER
MANUAL INTERRUPT
RESET
A3
1
2
3
A4
4
5
6
A4
7
8
9
FLS•B4
A5
Face-Down
0
Face-Up
Platen
Staple Position
1 2 3 4 5
Position
original
Select Sort/
Finish key
Number
Select
sort mode of copies
Press
Start
Face-Down
Select finisher mode(s)
Press OK
Non-sort
Sort
Sort/rotate
Group/rotate
Punch
Shift-sort
Shift-group
Staple-sort
A4
A4
A4
∗
In the punch mode, A3 size and A4 B
size are available. With other sizes,
punch is not enough or lack of the
hole(s).
In the 2 hole punch mode, B4⋅FLS
size and A4 size are available.
NOTE
68
Select the type of copy group mode into 2 bin
finisher and press OK.
# Non-sort
Copy is stored on the tray
$ Sort
Multiple copies are sorted automatically and
stacked with shift.
% Sort-rotate (Upper bin only)
Copied sets are separated by rotation and
exited onto tray.
& Group-rotate (Upper bin only)
Grouped copies are rotated and exited onto
tray.
( Punch*
Sorted copies are punched and exited onto tray.
(Except Sort-rotate and Group-rotate modes)
) Shift-sort (Lower bin only)
Copied sets are offset and exited onto tray.
* Shift-group (Lower bin only)
Grouped copies are offset and exited onto tray.
+ Staple-sort (Lower bin only)
Sorted copies are stapled and exited onto tray.
C The above sort modes may not work if you are using gray originals, as this may cause
a memory overflow.
In such a case, it is recommended either make copies by separate lots (except staplesort) or install optional hard disk (FA-HD13/HD14).
Options
4. When replacing the staple cartridge
Non-sort
Sort
Sort/rotate
Group/rotate
Punch
Shift-sort
Shift-group
Staple-sort
1
Pull out the finisher.
2
Open the stapler cover.
3
# Lift up the lock lever.
2 Bin Finisher, Exit Guide
Unit
2 Bin Finisher
The message shown on the left appears
when the staples are out.
Add staples
$ Raise up the stapler unit.
1
2
4
Remove the staple cartridge.
69
Options
5
# Remove the empty staple case.
$ Install the new staple case.
2
1
70
6
Pull out the tape.
7
Insert the staple cartridge.
8
Return the stapler unit to the
original position.
9
10
# Close the stapler cover.
$ Return the finisher to the original
position.
Check the operation
Select the staple-sort mode with control
panel and print the desired data.
Options
5. If the unit fails to staple after replacing the staple follow the instruction below.
1
2
Remove the staple cartridge
according to staple replacing
procedures steps 1 to 4.
3
1
2
Reinstall the staple cartridge
according to staple replacing
procedures steps 7 to 10 and
check operation. (See P.70)
3
# Lift up the finisher entry
guide.
4
Return the finisher to original
position.
(See P.69)
# Open the staple cover.
$ Remove the jammed staple.
% Close the staple cover.
6. Punch disposal
2 Bin Finisher
Pull out the finisher.
# Pull out the trash box.
$ Dispose the punch trash.
$ Return the trash box.
71
Options
Inverting Shift Tray (FA-TR350/TR355)
1. Feature
Copies are stacked on the upper bin. (Lower bin is for printer function)
Original
Shift
Rotate
3
3
2
1
2
3
1
1
2
Offset using electronic
sorting
2. Operation
ADF
Sort by rotating sets
i-ADF
MULTI-SIZE
FEED
SORT/
FINISH
USER
PRESET
ENERGY
SAVER
MANUAL INTERRUPT
RESET
A3
1
2
3
A4
4
5
6
A4
7
8
9
FLS•B4
A5
Face-Down
Face-Up
2 3
1
Press
Sort/Finish
key
Position
original
Non-sort
Shift-sort
∗
Shift-group
Sort/rotate
Group/rotate
Following modes are available using
the exit tray.
Non-sort
NOTE
0
Sort
∗
Sort/rotate
Group/rotate
Select sort
mode
4 5
Number of
copies
Press Start
Select copy output method
# Non-sort*
Copies are exited onto tray.
$ Shift-sort**
Copied sets are offset and exited onto tray.
% Shift-group
Grouped copies are offset and exited onto tray.
& Sort-rotate*
Copied sets are separated by rotation and
exited onto tray.
( Group-rotate*
Grouped copies are rotated and exited onto
tray.
) Sort (Using Exit Tray)*
Copies are exited onto exit tray.
Non-sort, Sort/rotate and Group/rotate are available without the FA-TR350/TR355.
Shift-sort and Shift-group require the FA-TR350/TR355.
∗∗ The Shift-sort is not available in the first set when the memory is full.
C The ADF/i-ADF is required for Sort/rotate and Group/rotate modes.
C Sort/rotate and Group/rotate functions are not available in the double sided copy, 2
page copy and 1 in N modes.
72
Handling
Adding Paper
■ 550 Sheet Paper Tray
1
Pull paper tray out of copier.
2
Place paper into paper tray.
3
Make sure paper is not loaded
above overfill indicator located in
the paper tray.
Do not load ADU with paper. (Option)
Overfill Indicator
1
Single sided copy
2
4
ATTENTION
Double sided copy*
Push paper tray back into copier.
Inverting Shift Tray
Special papers, like glossy paper, mailing
labels and transparencies cannot be used
in the paper tray. Use bypass for special
paper.
J
∗
When making double sided copies without an automatic duplex unit, place
the copies face-up in the paper tray to the double sided overfill indicator.
C When the staple sorter is used:
Some papers may not be suitable for stapling. Please check with your
service department if you are unsure about the type of paper you are using.
73
Handling
Adding Paper
■ 3000 Sheet Large Capacity Cassette (LCC)
1
# Open the door.
$ The paper feed tray will go down.
Do not touch the tray while it is
moving.
2
Paper Feed Tray
1
2
3
4
74
ADD PAPER
After tray stops, place paper neatly on to
tray.
A4 size only (portrait).
Overfill Indicator
Do not fill above red line.
Up to 3000 sheets, 80 g/m2
Close the door.
Handling
Adding Toner
■ When U13 appears
1
Open front panel.
Turn toner hopper assembly.
Toner Hopper
2
Remove toner bottle
# Turn empty toner bottle until it stops.
$ Slide empty toner bottle towards you
and remove.
3
Cap
Shake well before using.
Shutter
10 – 15 times until the toner inside is
evenly distributed.
Remove the cap from the bottle.
Plug
New Toner
Bottle
4
Do not turn the shutter, or remove the
plug.
# Insert new toner bottle to the hopper
assembly.
$ Turn the bottle until it stops, and arrows
are aligned.
1
2
J
5
ATTENTION
Return the toner hopper assembly
to original position.
Close front panel.
C For optimum copy quality use the recommended Panasonic toner. Store
toner in a cool dark place. Do not unseal toner before use. Use it as fast as
possible after unsealing.
75
?
Handling
Replacing the Waste Toner Bottle
■ When U14 appears
1
Open the front cover.
2
Slowly pull the waste toner box
straight out.
3
Close the box with the enclosed
cap.
4
5
ATTENTION
NOTE
76
Do not squeeze the bottle.
Cap
Install a new waste toner box.
3
2
Do not insert the bottle from the top.
1
Close the front cover.
C Do not reuse the toner from the waste toner box.
C If you have no replacement waste toner bottle, please contact your service provider.
Handling
Removing the Punch Dust
■ When the punch dust is full (For FA-F365)
Punch Trash box is full.
Empty Punch trash box.
OK
The message shown on the left appears
when the punch dust is full.
To empty the punch scrap tray, perform the following steps.
1
Open the front cover of the
puncher unit.
2
Draw out the punched scrap
container.
3
Discard the punched scrap.
4
Return the punched scrap
container to its original position.
77
Handling
Removing a paper misfeed
■ If a paper misfeed should occur, the misfeed indicator and misfeed
position(s) will be shown on the touch panel display.
MULTI-SIZE
FEED
SORT/
FINISH
USER
PRESET
ENERGY
SAVER
MANUAL INTERRUPT
RESET
A3
1
2
3
A4
4
5
6
A4
7
8
9
FLS•B4
A5
0
F
H G A
B
C
D
I
E
Paper Misfeed Positions
I
Copier
or
System Console
A: The paper exit area: (See P.79)
B: Paper transport area (See P.80)
C: Paper entry area (See P.80)
LCC, Large Capacity Cassette (See P.81)
D: Automatic Duplex Unit (ADU) (See P.83)
E: System console (See P.81)
F
ADF
i-ADF
F: ADF/i-ADF (See P.82, 84)
Finisher
G:FA-TR350/TR355 (See P.85 – 86)
FA-F320 (See P.92)
H: FA-F350/F355/F365 (See P.87 – 89)
I : FA-F365 (See P.90 – 91)
c
ATTENTION
78
C Make sure that the misfeed indicator goes off after removing a paper misfeed.
The misfeed indicator will not go off if the paper is still jammed in the copier.
Check again and remove all misfed paper.
Handling
■ Paper exit area
A
1
# Open front panel.
$ Open exit cover.
1
2
2
Note: If Finisher or Inverting shift tray is
installed, move from the machine
before above operation.
# Turn the left paper clearing knob.
$ Remove the misfed paper.
2
1
Left Paper Clearing Knob
3
Caution
heated
surface
Fusing Area
Caution: This fuser area will be hot.
# Open the fuser guide.
$ Check that no misfed paper is
remaining.
% Close the fuser guide.
Fuser Guide
4
ATTENTION
# Close exit cover.
$ Close front panel.
I
C The fusing area may be hot, so use caution when removing misfed paper.
C The front panel must be opened prior to opening the exit cover.
C Make sure that the misfeed indicator goes off after removing all misfed paper.
C After removing misfed paper, close front panel as soon as possible.
79
Handling
■ Paper transport and paper entry areas
B
C
1
Open front panel.
Front Panel
2
1
3
# Lower lever a.
$ If copy paper is fed far into the copier,
turn the right paper clearing knob.
% Remove the misfed paper.
& Raise lever a to original position.
2
Right Paper
Lever a Clearing Knob
3
2
1
# Open the paper feed cover.
$ Remove misfed paper.
% Close entry cover.
Entry Cover
4
ATTENTION
Close front panel.
C Do not touch or scratch the surface of the drum.
C Make sure that the misfeed indicator goes off after removing all misfed paper.
80
Handling
■ System console/Large Capacity Cassette
C
E
1
System console
2
# Open the paper feed cover.
$ Remove the misfed paper.
% Close the paper feed cover.
1
Paper Feed Cover
2
Large Capacity Cassette
2
1
# Hold the latch and slide the large
capacity cassette to the right.
$ Remove the misfed paper.
Release Latch
# Open the door.
$ Remove the misfed paper.
% Close the door.
& Return the large capacity cassette to
original position.
2
1
I
ATTENTION
C Make sure that the misfeed indicator goes off after removing all misfed paper.
81
Handling
■ i-ADF
F
1
Entry Area
2
# Open entry cover.
$ Remove the misfed paper.
% Close entry cover.
1
Entry Cover
# Open the i-ADF.
$ Open entry cover.
% Remove the misfed paper.
& Close entry cover and the i-ADF.
Entry Cover
2
3
1
2
Exit Area
# Open the i-ADF.
$ Remove the misfed paper.
If paper is remaining on the platen
glass, remove it.
2
1
If paper can not be removed:
4
ATTENTION
82
% Close the i-ADF.
& Remove the misfed paper.
C Make sure that the misfeed indicator goes off after removing all misfed paper.
Handling
■ Automatic Duplex Unit (ADU)
C
A
D
1
2
Pull out automatic duplex unit.
Paper Guide Plate a.
Paper Guide Plate b.
3
# Open paper guide plate a.
$ Open paper guide plate b.
% Remove misfed paper.
& Close paper guide plate b.
( Close paper guide plate a.
Push back automatic duplex unit.
F
I
ATTENTION
C When the misfeed indicators light at A, C and D, remove misfed paper from A
and C first then remove it in the ADU (D).
C Make sure that the misfeed indicator goes off after removing all misfed paper.
C Open Paper Guide Plate a completely or fingers might be wedged.
83
Handling
■ ADF
F
1
Paper feed unit
# Close exit tray.
$ Open the paper feed cover.
% Remove the misfed paper.
& Close the paper feed cover.
( Put exit tray back.
Paper Feed Cover
2
Paper exit
# Open the paper feed cover.
$ Remove the misfed paper.
% Open exit cover.
& Make sure no paper remains.
( Close exit cover.
ATTENTION
84
C Check that the paper misfeed indicator disappears.
Handling
■ Inverting Shift Tray (FA-TR350), Inverting Unit (FA-RU350/RU355)
G
1
# Hold release lever.
For FA-RU350/RU355:
Open the Finisher to the left.
$ Open inverting shift tray until it stops.
Release Lever
2
# Open transfer guide.
$ Remove the misfed paper.
% Close transfer guide.
3
Close inverse shift tray.
For FA-RU350/RU355:
Close the Finisher.
F
I
ATTENTION
C Make sure that the misfeed indicator goes off after removing all misfed paper.
85
Handling
■ 2 Bin Inverting Shift Tray (FA-TR355)
G
1
Release Lever
# Hold release lever.
$ Open the 2 bin inverting shift tray to the
left until it stops.
Pull out gently.
2
# Open transfer guide.
3
Return the 2 bin inverting shift tray
to the original position.
ATTENTION
86
$ Remove the misfed paper.
% Close transfer guide.
C Make sure that the misfeed indicator goes off after removing all misfed
paper.
Removing a paper misfeed
■ 3 Bin Finisher (FA-F350/F355)
H
1
Press the lock release button and
open the finisher to the left.
Pull out gently.
Lock release button
2
Open the interrupt tray
Interrupt Tray
3
# Open the top cover.
$ Open the buffer roller cover.
% Remove the misfed paper.
& Close the buffer roller cover and top
cover.
4
ATTENTION
Return the finisher to the original
position.
I
c
C Make sure that the misfeed indicator goes off after removing all misfed paper.
87
Handling
■ 2 Bin Finisher (FA-F365)
H
Removing misfed paper(s) from the Finisher Unit
To clear a jam from the finisher, perform the following steps.
Note: If the paper jammed in the finishers Infeed Guide, it can be removed by opening the front door
of the copier.
88
1
Holding the finisher unit as shown,
move it to detach it from the copier.
2
Remove any misfed paper(s)
visible from the outside.
3
Open the upper cover, and check
the inside of the finisher.
Handling
4
Lift the buffer roller cover, and
remove misfed paper.
5
Lift the buffer roller, and remove
misfed paper.
6
Return the buffer roller and the
buffer roller cover to their original
positions, and close the upper
cover.
7
Return the finisher to its original
position.
c
ATTENTION
C Make sure that the misfeed indicator goes off after removing all misfed paper.
89
Handling
■ 2 Bin Finisher/Saddle Stitch Unit (FA-F365)
I
Removing misfed paper(s) from the Saddle Stitcher Unit
To remove a jam from the Saddle Stitch Unit, perform the following steps.
90
1
Holding the finisher as shown,
move it to detach it from the
copier.
2
Open the lower front cover.
3
Turn the knob on the right cw.
Handling
4
Turn the knob on the left ccw while
pushing it in.
5
# Open the saddle exit cover.
$ Remove misfed paper.
% Close the saddle exit cover.
6
Open the Infeed Cover, and
remove misfed paper.
7
Close the lower front cover.
8
Return the finisher to its original
position.
ATTENTION
c
C Make sure that the misfeed indicator goes off after removing all misfed paper.
91
Handling
2 Bin Finisher (FA-F320)
C Make sure that the misfeed indicator
goes off after removing all misfed
paper.
G
1
#
# Lift up the upper cover.
$ Remove misfed paper.
$
2
# Pull out the finisher.
$ Pull out the trash box.
(See P.71)
% Open the stapler cover.
(See P.69)
3
# Turn the paper transport knob A.
#
$ Remove misfed paper.
$
When paper cannot be removed:
Lift up the finisher guide and remove
misfed paper.
When the misfed paper is not found:
#
$
92
4
# Turn the paper transport knob B.
$ Remove misfed paper.
# Close the staple cover and install the
trash box.
$ Return the finisher to original position.
Checking
Troubleshooting
■ Before you call service
Check
Action
Unit does not operate
Does the display light?
(See P.9)
Check if the Power Switch is turned on and
if the power plug is inserted into the outlet.
Does the Energy saver key flash (or light)
and displays are turned OFF?
(See P.38)
Press Energy saver key on control panel.
Do any of the U## codes and messages
appear on display?
(U0, U4, U10, U12, U13....etc.,)
Perform actions in accordance with each
message.
Does the add staples indicator and
message appear on display? (0)
(See P.61, 64 or 69)
Add staples.
(See P.61, 64 or 69)
Does the add paper indicator and message
appear on display? (J/ )
(See P.11)
Add paper.
(See P.14, 73 or 74)
Does paper misfeed indicator and
message appear on display? (I)
(See P.78)
Remove the misfed paper.
(See P.79 – 92)
Does any of the E#-## indicator and
message appear on display?
Turn copier power switch off, then back on.
If error code comes back again, call
service.
Does the remove punch dust indicator and
message appear on display? ( )
(See P.77)
Remove the punch dust.
(See P.77)
I
Call service.
93
Troubleshooting
Does the call service indicator and
message appear on display? (2)
(See P.11)
Checking
Troubleshooting
Check
Action
Copies are light
Does the exposure indicator say “light”?
Touch the “dark” key or touch the “Auto”
key to choose the auto mode. (See P.12)
Does the add toner indicator and message
appear on displays?
Add toner. (See P.75)
Copies are marked
Is the copier platen glass or platen cover
dirty?
Clean the platen or platen cover.
(See below)
■ If the measures outlined above do not solve the problem, call your Service provider.
■ Cleaning
As a rule, clean once a week.
Platen Cover
(Option)
Platen/Platen Cover
# Gently wipe marks off with cloth and neutral
detergent.
$ Gently wipe again with a dry cloth.
Platen
94
Specifications
■ FP-D355/D355DC/D455/D605
Type:
Desk Top
Copy/Print Process:
Laser/Electrostatic photographic method
Process:
Dry, New Magnefine High Definition Toner
Resolution:
(Copy mode)
Max. 600 dpi (FP-D355/D355DC])
Max. 400 dpi (FP-D455/D605)
Resolution:
(Print mode)
Max. 600 × 600 dpi
Max. 1,200 × 600 dpi (with smoothing)
Image Memory:
24 MB
Multi-Copy Speed:
35 A4 size copies per minute (FP-D355/D355DC)
45 A4 size copies per minute (FP-D455)
60 A4 size copies per minute (FP-D605)
Maximum Copy Size:
A3 (297 × 420 mm)
Void Area: max. 5.0 mm
Copy Size:
A3 – A5 via paper drawer/tray
A6R - A3 via sheet bypass
Reduction Ratios:
Preset: 87%, 82%, 71%, 58%, 50%
Variable: from 99% to 25% in 1% increments
Enlargement Ratios:
Preset: 115%, 122%, 141%, 173%, 200%
Variable: from 101% to 400% in 1% increments
Paper Feed:
550 sheet paper drawer × 2 (× 1: FP-D355DC/D455/D605) plus 50 sheet
Bypass Automatic Switching
Paper Selection:
Automatic
Paper Weight:
Paper drawer/tray: 60 – 90 g/m2
Bypass: 55 – 130 g/m2
Automatic Duplex Unit: 80 – 90 g/m2
Quantity Selector:
1 - 999, Automatic Repeat, Automatic Reset to 1
Exposure Control:
Automatic, Text/Photo, Text and Photo Mode
Toner Supply:
Automatic
Dimensions:
606 (W) × 770 (D) × 624 (H) mm
Weight:
76 kg (FP-D355)
80 kg (FP-D355DC)
84 kg (FP-D455/D605)
Electrical Requirements:
AC 220-240V, 50Hz, 6.5A
95
Troubleshooting
Specifications
Specifications are subject to change without notice.
Specifications
■ i-ADF (FA-A888), ADF (FA-A355)
Original Capacity:
50 sheets/A5, A4 30 sheets/B4⋅FLS, A3
Paper Size:
A5, A4, A4 R, B4⋅FLS, A3
Paper Weight:
50 – 110 g/m2
Electrical Requirements:
Supplied from copier
Dimensions:
622 (W) × 546 (D) × 117 (H) mm without Tray (FA-A355)
600 (W) × 519 (D) × 120 (H) mm without Tray (FA-A888)
Weight:
11 kg (FA-A355)
12 kg (FA-A888)
■ Inverting Shift Tray (FA-TR350)
Paper Size:
A5, A4, A4 R, B4⋅FLS, A3
Paper Weight:
60 – 90 g/m2
Bin Capacity:
Non-sort, Sort/rotate, Group/rotate: 250 sheets
Shift-sort, Shift-group:
200 sheets (A4, A5)
150 sheets (A3, B4⋅FLS)
Electrical Requirements:
Supplied from copier
Dimensions:
79 (W) × 582 (D) × 419 (H) mm
Weight:
9 kg
■ 2 Bin Inverting Shift Tray (FA-TR355)
Paper Size:
A5, A4, A4 R, B4⋅FLS, A3
Paper Weight:
60 – 130 g/m2 (Face Down: 60 – 90 g/m2)
Number of Bins:
2
Bin Capacity:
Upper
Non-sort, Sort/rotate, Group/rotate: 300 sheets (A4, A5)
200 sheets: (A3, B4⋅FLS)
Shift-sort, Shift-group:
200 sheets (A4, A5)
150 sheets: (A3, B4⋅FLS)
Lower
300 sheets (For printer function only)
Electrical Requirements:
Supplied from copier
Dimensions:
259 (W) × 582 (D) × 522 (H) mm
Weight:
16.2 kg
Specifications are subject to change without notice.
96
Specifications
■ 3 Bin Finisher (FA-F350/F355)
Paper Size:
A5, A4, A4 R, B4⋅FLS, A3
Paper Weight:
50 – 128 g/m2
Number of Bins:
3 + Interrupt Tray
Bin Capacity:
Interrupt Tray
50 sheets
1 Bin
300 sheets
2 Bin
1,000 sheets
3 Bin
200 sheets
(See page 60 for detailed information)
Electrical Requirements:
Supplied from copier
Dimensions:
669 (W) × 582 (D) × 1,039 (H) mm (FA-F350)
669 (W) × 603 (D) × 1,039 (H) mm (FA-F355)
Weight:
34.5 kg (FA-F350)
36.0 kg (FA-F355)
■ 2 Bin Finisher (FA-F365)
Paper Size:
A5, A4, A4 R, B4⋅FLS, A3
Paper Weight:
60 – 128 g/m2
Number of Bins:
2 + Interrupt Tray
Bin Capacity:
1 Bin
1,000 sheets
2 Bin
1,000 sheets
25 sets
Electrical Requirements:
Supplied from copier
Dimensions:
669 (W) × 661 (D) × 438 (H) mm
Weight:
52.0 kg
97
Specifications
Stitch Tray
(See page 63 for detailed information)
Specifications
■ 2 Bin Finisher (FA-F320)
Paper Size:
Upper Bin: A5, A4, A4 R, B4⋅FLS, A3
Lower Bin: A4
Paper Weight:
60 – 105 g/m2 (Upper Bin, without punch: 60 - 130 g/m2)
Number of Bins:
2
Bin Capacity:
Upper
100 sheets
Lower
1,000 sheets (When sorting mode: maximum 30 sets and/or 1,000 sheets)
Electrical Requirements:
Supplied from copier
Dimensions:
405 (W) × 520 (D) × 438 (H) mm
Weight:
16.2 kg
Specifications are subject to change without notice.
■ System Console (FA-DS725/DS825)
FA-DS725
FA-DS825
Combination:
Storage Drawer × 1
550 Sheet Paper Drawer × 1
Storage Drawer × 1
Paper Size:
A5, A4, A4 R, B4⋅FLS, A3
A5, A4, A4 R, B4⋅FLS, A3
Paper Weight:
60 – 90 g/m2
60 – 90 g/m2
Electrical Requirements:
Supplied from copier
Supplied from copier
Dimensions:
606 (W) × 661 (D) × 416 (H) mm
606 (W) × 661 (D) × 416 (H) mm
Weight:
22 kg
27 kg
Applicable models:
FA-D355/D355DC
FA-D455/D605
■ Large Capacity Cassette (FA-MA301)/Automatic Document Unit (FA-MADM8)
FA-MA301
FA-MADM8
(FP-D355DC/D455/D605 is
standard.)
Paper Size:
A4
A5R – A3
Paper Weight:
60 – 90 g/m2
60 – 90 g/m2
Paper Capacity:
Maximum 3000 sheets, 20 g/m2
Stack-less
Electrical Requirements:
Supplied from system console
Supplied from copier
Dimensions:
290 (W) × 445 (D) × 517 (H) mm
Weight:
15 kg
Specifications are subject to change without notice.
98
——
9 kg
System Information
■ The FP-D355/D355DC/D455/D605 series is a powerful multi-function digital copier which can
combine copying, printing, electronic filing and network functions all in one unit! Superior output
quality is ensured with 600 dpi resolution in both copying and printing modes.
(Note: 400 dpi for FP-D455/D605 in copying mode.)
We hope you find that the wide ranging capabilities of the FP-D355/D355DC/D455/D605 will
make your office-place more productive and efficient.
■ Procedure for system upgrades
FP-D355
FP-D355DC
FP-D455
FP-D605
Filing
Plus
Further
more
and/or
Network
Printer
C Before system upgrades
Part name
Printer Controller/HDD
Mounting Kit
Part No.
FA-PK30
Remarks
Control panel for mounting the printer and
filing
Part No.
FA-WA11
FA-WB10
FA-HD12
Remarks
Set up unit for Filing
B Hard Disk (2GB)
B Card reader
B Removable media B Battery
B Personal cards (10)
For FA-WA11/WA12
For FA-WA11/WA12
FA-PC360
FA-MC360
Printer controller for PCL6*
Printer controller for PS printer and PCL5e
FA-HD01
For FA-PC360 or FA-MC360
FA-NE35
Network PCB (Ethernet) for printer and filing
For Filing
Part name
1. DD Filing Unit
(For FP-D355/D355DC)
2. DD Filing Unit
(For FP-D455/D605)
3. DD Browser Software
4. Hard Disk Drive for Backup
FA-WA12
For Printer
Printer Unit
Multi Page Description
Language Controller
Hard Disk Drive for Printer
For Network
Network Adapter Unit
∗
PCL6 is the Page Description Language of the H.P. Company.
C Information regarding the options for Filing, Printer, Network can be found in
each of the options respective operating guides.
99
Specifications
System Information
NOTE
CCOLOR “Black”>
For Service Call:
Matsushita Electric Industrial Co., Ltd.
Osaka 542-8588, Japan
FFPTD1077 S1000-0
October 2000
Printed in Japan
English
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
