Saikano S.A.
Modelo: R8
Portatil
Oficina y Planta:
Av. San Martín 3442
Caseros | Buenos Aires | Argentina
CP: B1678GQX
Tel.
Portatil Gamer
Marca: Saikano
Modelo: R8
Importado por: Saikano S.A.
Hecho en China
(054-11) 4878-5222
[email protected]
Próximamente:
Nueva Planta Industrial
Gral. Rodríguez
Sector Industrial Planificado
Ruta Provincial Nro24 y calle Corrientes
Sección B - Fracción 3 Buenos Aires
ESPECIFICACIONES
DIMENSION387MMX274.5MMX30.9MM
WEIGHT
~2.4KG (TBD)
CPU
INTEL® HASWELL 47W BGA PROCESSOR (I7-4710HQ 2.5G)
CHIPSETHM87
MEMORY
2 SO-DIMM MEMORY SOCKETS
SUPPORT UP TO 16G DDR3L-1600
ODDN/A
HDD
2.5” 7MM SATA HDD
128G/256G MSATA SSD(OPTION)
DISPLAY
15.6” FULL HD LCD LED BACKLIGHT (IPS STYLE)
GRAPHICS CHIP
NVIDIA N15P-GX(GTX 860M) 4GB GDDR5 VRAM
AUDIO
HD AUDIO TWO SPEAKERS & SUBWOOFER X 1 AT BOTTOM
COMMUNICATION
LAN: 10/100,1000 GLAN WL_BT COMBO
KEYBOARD
86 (US)/ 87 (EU)/ 88 (BR)/ 91 (JP) KEYS KEYBOARD W/UNDER KEYBOARD BACKLIGHT
TOUCHPAD
NORMAL TOUCH PAD SUPPORT MULTI-FINGER FEATURE
MEDIA SLOT
4 IN 1 CARD READER (SD/SDHC/SDXC/MMC)
I/O PORTS
USB3.0 X 3
USB2.0 X 1 (USB CHARGER SUPPORT)
LAN PORT X 1
VGA PORT X 1
HDMI X 1
4-IN-1 CARD READER X 1
AUDIO COMBO JACK (HEADPHONE-OUT & MIC-IN) X 1
CAMERA
HD CAMERA WITH DUAL DIGITAL MIC
SYSTEM STATUS INDICATORS
1 LED FOR POWER
1 LED FOR HDD
1 LED FOR BATTERY STATUS
CONTROL BUTTONS
HOT KEY(ON KEYBOARD)
POWER BUTTON X 1
MAGNETIC LID SWITCH CONTROL FOR SYSTEM
STANDBY/WAKEUP/SUSPEND/RESUME
AC ADAPTER
150W (GTX 860M)
INPUT: 100~240V AC, 50/60HZ UNIVERSAL
BATTERY
8 CELL 6000MAH (GTX 860M)
OS
WINDOWS 8 64BIT
WINDOWS 8.1 64BIT
WINDOWS 7 DRIVERS READY
MINI CARD
ONE HALF SIZE SLOT FOR WLAN CARD
ONE FULL SIZE MSATA SLOT FOR MSATA SSD
SECURITY
KENSINGTON LOCK
Fotos
http://goo.gl/K8OBEv
SaikanoTechnology
SaikanoT
