Si5356 I2C Programmable Any-Frequency 1-200 MHz

S i 5 3 5 6 B

*

I

2

C P

R O G R A M M A B L E

, A

N Y

- F

R E Q U E N C Y

1 – 2 0 0 M H

Z

,

Q

U A D

F

R E Q U E N C Y

8 - O

U T P U T

C

L O C K

G

E N E R A T O R

Features

Generates any frequency from 1 to

200 MHz on each of the 4 output banks

Eight CMOS clock outputs

Programmable frequency configuration

0 ppm frequency synthesis error for any combination of frequencies

19 to 30 MHz xtal or 5–200 MHz input clk

Easy to use programming software

Configurable “triple A” spread spectrum:

any

clock, any frequency, and with any spread amount

Programmable output phase adjustment with <20 ps error

Interrupt pin indicates LOS or LOL

OEB pin disables all outputs or per bank OEB control via I

2

C

Low jitter: 1.5 ps rms phase jitter

Excellent PSRR performance eliminates need for external power supply filtering

Low power: 45 mA (core)

Core VDD: 1.8, 2.5, or 3.3 V

Separate VDDO for each bank of outputs: 1.8, 2.5, or 3.3 V

Small size: 4x4 mm 24-QFN

Pb-free, RoHS-6 compliant

Industrial temperature range:

–40 to +85 °C

Applications

Printers

Audio/video

Networking

Communications

Storage

Switches/routers

Computing

Servers

OC-3/OC-12 line cards

Description

The Si5356B is a highly flexible, I

2

C programmable clock generator capable of synthesizing four completely non-integer related frequencies up to 200 MHz. The device has four banks of outputs with each bank supporting two CMOS outputs at the same frequency. Using Silicon Laboratories' patented MultiSynth fractional divider technology, all outputs have 0 ppm frequency synthesis error regardless of configuration, enabling the replacement of multiple clock ICs and crystal oscillators with a single device. Each output bank is independently configurable to support 1.8, 2.5, or 3.3 V. The device is programmable via an I

2

C/SMBuscompatible serial interface and supports operation from a 1.8, 2.5, or 3.3 V core supply.

Ordering Information:

See page 25.

Pin Assignments

XA XA

1 1

24 24 23 23 22 22

XB

XB

2 2

3 3

4 4

5 5

6 6

7 7 8 8 9 9 10 10

Functional Block Diagram

Si5356B

*Refer to Ordering Guide for custom part numbers.

Rev. 1.1 8/12 Copyright © 2012 by Silicon Laboratories Si5356B

S i 5 3 5 6 B

2 Rev. 1.1

Si5356B

T

A B L E O F

C

O N T E N TS

Section Page

1. Electrical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

2. Typical Application Circuits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

3. Functional Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

3.1. Input Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

3.2. MultiSynth Technology . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

3.3. Input and Output Frequency Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

3.4. Configuring the Si5356B . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

3.5. ClockBuilder

Desktop Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

3.6. Output Phase Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

3.7. CMOS Output Drivers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

3.8. Jitter Performance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

3.9. Status Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

3.10. Output Enable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

3.11. Spread Spectrum* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

3.12. Power Supply Considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

4. I

2

C Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

4.1. Custom Device Configurations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

5. Pin Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

6. Package Outline: 24-Lead QFN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

7. Recommended PCB Land Pattern . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

8. Ordering Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

8.1. Custom Part Numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

9. Top Marking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

9.1. Si5356B Top Marking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26

9.2. Top Marking Explanation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26

10. Errata . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

10.1. Description: Spread Modulation Rate and Nominal Frequency Error . . . . . . . . . . .27

10.2. Affected Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27

10.3. Impacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27

10.4. Workarounds . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27

10.5. Resolution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27

Document Change List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Contact Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Rev. 1.1
