VWD: General Information
Specifications
Specifications
Table 1
Specifications of 79853C VWD
Detection Type
Double beam photometer.
Noise
< 1.5 x 10-5 AU peak-to-peak at 254 nm, flowing
water at 1 ml/min, 1 second response time (10-90%),
standard flow cell.
Drift
< 5 x 10-4 AU/hour at 254 nm after warm-up.
Wavelength Range
190 - 600 nm, settable in 1 nm increments.
Wavelength Accuracy
±2 nm.
Wavelength Reproducibility
±0.3 nm.
Bandwidth
6.5 nm.
Linear Absorbance Range
Better than 1% up to 1.2 AU using acetone at 265 nm.
Response Time
0.25, 1 or 4 seconds (10-90%); user-selectable.
Spectra
Storage of 1 spectrum during run; scan rate
10 nm/sec; range from 190 to 600 nm, selectable.
Post-run plotting speed from 1 to 50 nm/sec
selectable; plotting of background-corrected
spectrum.
Light Source
Deuterium lamp from 1090/40/50 DAD.
Flow Cells
Standard 14 µl volume, 8 mm pathlength cell with
40 bar (588 psi) pressure maximum. Optional micro,
preparative, high-pressure cells are available.
Display
Single line, 16 character fluorescent display with real
time display of operating parameters and/or
absorbance.
Control
Integrated keyboard with function keys; parameter
editing during run possible; keyboard lock; optional
control by computer or 3396 Series II integrator.
Service Handbook for 1050 Series of HPLC Modules - 11/2001
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
563
VWD: General Information
Specifications
Table 1
Specifications of 79853C VWD
Parameters
Wavelength, output range, response time, zero,
offset, balance, spectrum acquisition.
Diagnostic Aids
Wavelength calibration check with Holmium oxide
filter.
Time-programs
Time-programmable wavelength and output range;
storage of up to 5 time-programs.
Analog Output
One output user-configurable as recorder or
integrator. For recorder: 100 mV or 1 V output range
from 0.001 to 4 AU, user-selectable; for integrator:
100 mV/2 AU full scale or 1 V/2 AU full scale,
user-selectable.
Communications
START (input/output), STOP (input/output), READY
(output), SHUTDOWN (output) for synchronization
with other LC modules.
Safety Aids
Extensive diagnostics, error detection and display via
front-panel LED’s. Leak detection, safe leak handling,
leak output signal for shutdown pumping system. Low
voltages in major maintenance areas.
Environment
Temperature range: 5 to 55°C
Humidity: < 95% (non-condensing)
Power Requirements
Line voltage: 100-120 or 220-240 VAC ±10%
Line frequency: 48-66 Hz
Power consumption: 150 VA max.
Dimensions
Height: 133 mm ( 5.2 inch)
Width: 325 mm (12.8 inch)
Depth: 545 mm (21.5 inch)
Weight: 14 kg ( 31 lb)
564
Service Handbook for 1050 Series of HPLC Modules - 11/2001
