IBM Rational DOORS for ClearCase

Interface

Using Rational DOORS for ClearCase

Interface

Release 2.1.1

Before using this information, be sure to read the general information under the

"Notices" chapter on page 27.

This edition applies to IBM Rational DOORS for ClearCase Interface,

VERSION 2.1.1, and to all subsequent releases and modifications until otherwise indicated in new editions.

© Copyright IBM Corporation 1993, 2011

US Government Users Restricted Rights—Use, duplication or disclosure restricted by GSA ADP Schedule Contract with IBM Corp.

Table of contents

Chapter 1: About this manual 1

Typographical conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Related documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Chapter 2: Concepts 5

About Rational DOORS for ClearCase Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

About Rational DOORS for ClearCase Interface functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Chapter 3: Importing from ClearCase 7

Importing from ClearCase into Rational DOORS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Importing structures for the first time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Re-importing structures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Imported attributes for structures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Viewing new information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Understanding imported information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Version structure. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Graphics colors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

ClearCase attributes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Labels. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Merge links . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Using Rational DOORS traceability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Managing links. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Applications of imported structures. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Import exceptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Chapter 4: Labelling Rational DOORS baselines 15

Importing ClearCase labels into Rational DOORS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Importing labels for the first time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Re-importing labels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Imported attributes for labels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Using Rational DOORS for ClearCase Interface iii

Table of contents

Creating Rational DOORS baselines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Understanding results . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Graphics colors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Viewing new information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Using Rational DOORS traceability. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Managing links . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Applications of imported labels. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Chapter 5: Troubleshooting 21

Poor performance when importing data to Rational DOORS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Chapter 6: Contacting support 23

Contacting IBM Rational Software Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Prerequisites . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Submitting problems. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Other information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Chapter 7: Notices 27

Trademarks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

iv Using Rational DOORS for ClearCase Interface

1

About this manual

Welcome to IBM

®

Rational

®

DOORS

®

for ClearCase Interface.

Rational DOORS for ClearCase Interface transfers data between Rational

DOORS and ClearCase

®

. It lets you synchronize configuration management regimes and establish traceability between information managed in Rational

DOORS and versions managed by ClearCase.

This manual describes how to use version 2.1.1 of Rational DOORS for

ClearCase Interface. It assumes that you know how to use both Rational

DOORS and ClearCase.

Typographical conventions

The following typographical conventions are used in this manual:

Typeface or

Symbol

Bold

Italics

Courier

>

Meaning

Important items, and items that you can select, including buttons and menus. For example: Click Yes to continue.

Book titles

Commands, files, and directories; computer output. For example: Edit your

.properties

file.

A menu choice. For example: Select File > Open. This means select the File menu, then select the Open command from it.

Related documentation

The following table describes where to find information in the documentation set:

For information on

How to use Rational DOORS

How to use ClearCase

See

The Rational DOORS Information

Center

The ClearCase documentation set

Using Rational DOORS for ClearCase Interface 1

About this manual

For information on

How to install Rational DOORS for

ClearCase Interface

See

The Rational DOORS Information

Center

2 Using Rational DOORS for ClearCase Interface

Related documentation

Using Rational DOORS for ClearCase Interface 3

About this manual

4 Using Rational DOORS for ClearCase Interface

2

Concepts

This chapter introduces Rational DOORS for ClearCase Interface and explains the concepts you need to understand before you use it:

About Rational DOORS for ClearCase Interface

About Rational DOORS for ClearCase Interface functions

About Rational DOORS for ClearCase Interface

Rational DOORS is the world’s leading tool for creating, structuring, and managing complex sets of requirements, such as those for a typical software development project. ClearCase from Rational Software Corporation is a source code control and configuration management system.

Rational DOORS for ClearCase Interface is a bridge between these two products, enabling complete lifecycle traceability from requirements through to configuration management.

Rational DOORS for ClearCase Interface allows software project teams to:

• Establish traceability from Rational DOORS information to specific elements, branches or versions in ClearCase.

• Import release information from ClearCase to Rational DOORS.

• Import merge information from ClearCase to Rational DOORS.

• Import ClearCase attributes to Rational DOORS.

• Create Rational DOORS baselines to match ClearCase labels.

• Navigate through all ClearCase elements, versions and branches in one window.

• Generate complete reports on combined ClearCase and Rational DOORS configuration status.

About Rational DOORS for ClearCase Interface functions

Rational DOORS for ClearCase Interface provides two functions that are fundamental to integrating configuration management with lifecycle traceability, as follows:

• The ability to represent the configuration item structure stored in ClearCase as a Rational DOORS module.

Using Rational DOORS for ClearCase Interface 5

Concepts

Each element, branch and version in a Versioned Object Base (VOB) is represented by a Rational DOORS object in a hierarchy that represents the complete version tree for the VOB. Merge hyperlinks are stored as Rational

DOORS links.

Once you have represented the ClearCase configuration item structure in a

Rational DOORS module, you can use regular Rational DOORS link functions to establish traceability from project information stored in

Rational DOORS to the configuration items. For example, a ClearCase version object that implements a specific requirement can be directly linked to the corresponding Rational DOORS requirement object. This allows you to demonstrate conformance to requirements at source-code level.

• The ability to baseline Rational DOORS modules using the same labels and comments as the ClearCase data.

This operation uses another Rational DOORS module to store a list of labels that exist in each VOB, and to create baselines automatically for groups of modules. Each baseline is recorded in the Rational DOORS module, providing a configuration-management record of which Rational

DOORS baselines relate to which ClearCase labels. This function also provides the important ability to create baselines for many Rational DOORS modules simultaneously.

These two functions create a unified approach to both traceability and information release control, resulting in full lifecycle traceability and rigorous configuration management.

6 Using Rational DOORS for ClearCase Interface

3

Importing from ClearCase

This chapter describes:

Importing from ClearCase into Rational DOORS

Viewing new information

Understanding imported information

Using Rational DOORS traceability

Import exceptions

Importing from ClearCase into Rational DOORS

This operation reads the complete structure of a VOB into a Rational DOORS module, creating a Rational DOORS object for each element, version and branch. Properties, attributes and labels are also imported.

Access to ClearCase elements is controlled by views that determine which elements, branches and versions are visible. ClearCase provides dynamic and snapshot views, depending on whether you want the views to be updated automatically or manually. Views also control access to derived objects and view-private files.

For these reasons it is vital that you choose the correct view for your import operation. Although Rational DOORS for ClearCase Interface imports all versions and branches, it cannot import view-private files from all views, so you must decide which view to use if you want these to be imported.

Rational DOORS for ClearCase Interface uses Windows

®

drive letters to select views. You can either choose to use the Dynamic-views drive, normally M:, or a view representing a specific dynamic or snapshot view. The dynamic views drive allows you to select any view of any VOB without needing to choose a drive letter, simplifying the import operation.

Importing structures for the first time

You can choose to import into an empty module or into a module that already contains objects. Each VOB is always imported under its own top-level object.

Normally, you want to maintain your configuration item structure in a special module. However, you might want to store information for several VOBs in the same module. If you choose to do this, the new VOB is imported under a new top-level object at the end of the module.

Using Rational DOORS for ClearCase Interface 7

Importing from ClearCase

To import from ClearCase:

1. Open the target Rational DOORS module.

2. From the DOORSConnect menu, select ClearCase >

Synchronize/import.

Note A command prompt window (DOS box) is displayed briefly before the Import Structure window displays.

This happens when Rational DOORS for ClearCase

Interface is communicating with ClearCase, and occurs several times during the import process. Each time, the command prompt window disappears automatically when the process is complete.

3. If you want to import from a dynamic view, make sure that the Drive field contains the correct drive. M: is the ClearCase default.

4. Select the view in the View field.

5. Select the VOB in the VOB field. The Path field shows the composite path that you have created.

Only mounted VOBs and views are shown. If you do not see the VOB or view you want to import, click Close to quit Rational DOORS for ClearCase

Interface, then use ClearCase to mount the required VOB and view.

6. If you want to import from a snapshot view or a dynamic view mounted on a specific drive, select Specific view drive from the Type drop-down list.

7. Select the correct drive and VOB. The Path field shows the composite path that you have created.

Only mounted VOBs are shown. If you do not see the VOB you want to import, click Close to quit Rational DOORS for ClearCase Interface and use ClearCase to mount the required VOB.

8. Clear the Create merge links in box if you do not want to create Rational

DOORS links representing ClearCase merge hyperlinks.

9. If you want to create links in the default link module, ClearCase Merges, and it does not exist, it is created automatically the first time you perform an import. In this case, go to step 11.

10. If you want to create links, but not in the default link module, click Select to display the Select Link Module window.

11. Select the link module you want to use, and click Select.

12. Click Import to start the import operation.

8 Using Rational DOORS for ClearCase Interface

Importing from ClearCase into Rational DOORS

Several command prompt windows appear briefly as the operation progresses.

When the import is complete, an import report is displayed.

The import report shows how many new items were created during the import, how many items were updated, how many were deleted and how many merge links were created.

For information on how to use the report window functions, see “Viewing new information,” on page 10.

Re-importing structures

It is likely that your ClearCase data will continue to evolve after you have imported it into Rational DOORS. Rational DOORS for ClearCase Interface can synchronize imported data with the state of the ClearCase VOB, adding new elements, versions and links and updating attributes and labels as required.

To synchronize your imported data, select the Rational DOORS object

representing the VOB to be re-imported and repeat the procedure in “Importing structures for the first time,” on page 7. This object appears at the top of the

structure, usually the first object in the module. An import report is displayed, showing the number of items that have been created or updated.

If an item is deleted from the VOB, the equivalent object in the Rational

DOORS surrogate module is flagged with the attribute CC Deleted set to True.

Items that are moved within the VOB, for example a source file moved from one directory to another are moved within the Rational DOORS surrogate module.

This allows traceability to be maintained.

Imported attributes for structures

ClearCase data is stored in Rational DOORS attributes when it is imported.

Attributes that store ClearCase data start with CC.

ClearCase properties are stored in the following attributes:

Attribute Contains

Object Heading The name of the ClearCase element. For a version this contains just the tail of the version name. For example, if the extended name of a version is: [email protected]@\main\windows\5 the Object Heading attribute contains 5.

Using Rational DOORS for ClearCase Interface 9

Importing from ClearCase

Attribute Contains

Object Text The ClearCase comment for the element, branch or version.

This typically contains the comment from a source file check-in.

CC Kind The type of the object. Possible values are VOB, Directory,

File, Version, Branch, Derived Object, or Private File.

CC Full Name The full version name of an item. In the example above this attribute would contain [email protected]@\main\windows\5

.

CC User The name of the person who created the element, version or branch.

CC Date The date on which the element, version or branch was created.

CC Merges

CC DBID

The full name of a version to which this version has been merged.

The ClearCase database identifier for the item.

Rational DOORS for ClearCase Interface also imports ClearCase labels and attributes. These are stored as Rational DOORS attributes and the values are kept with each Rational DOORS object.

If you have a ClearCase label Release_1, a Rational DOORS Boolean attribute called CC Label Release_1 is created. All versions that are marked with that label have the Rational DOORS attribute set to True. A simple Rational

DOORS filter immediately shows which items belong to each release.

If you have a ClearCase attribute QA_Status, a Rational DOORS string attribute called CC Attr QA_Status is created. When an element, branch or version has a value for this attribute it is copied into the Rational DOORS attribute.

Rational DOORS for ClearCase Interface also creates three attributes to store import metadata: CC Deleted, CC New, and CC Updated. These are set each time you import or synchronize, and are the basis for the import report filters.

You can create your own filters and views based on these attributes.

Viewing new information

Rational DOORS provides many useful ways of viewing imported ClearCase information. It has the advantage of being able to put all the relevant information into a single screen.

10 Using Rational DOORS for ClearCase Interface

Understanding imported information

Any updated information is clearly shown using the standard Rational DOORS change bars. After an import, new or updated items have their change bars set to red, but the rest of the objects remain unmodified.

In the case of a re-import, you can use the New items, Updated items and

Deleted items buttons in the Import Report window to show only the items that were new, updated or deleted.

ClearCase information can also be shown in graphics mode, where colors are used to distinguish the different kinds of object. Merge links are clearly shown if you click View, then Show, then Graphics Links. This option is automatically switched on by the Graphics button in the ClearCase Import Report window.

Understanding imported information

This section explains how to interpret the information and how to get the best from it.

Version structure

ClearCase version structures are represented as version hierarchies, written using an extended filename syntax, such as the following name: [email protected]@main\PERFORMANCE\5

This means that this is the fifth version of the file lookup.c

in the

PERFORMANCE branch. In ClearCase this structure can be seen graphically element by element when using the Version Tree utility.

Rational DOORS stores this information as a hierarchy of objects containing the names of the elements, branches and versions as headings, with check-in comments as the text.

The Rational DOORS graphics mode has the advantage over the ClearCase

Version Tree because it can show many version trees at once.

Graphics colors

When each item is imported it is assigned a color for use in graphics mode. This helps provide instant visual recognition of the structure of your data.

The color allocations are as follows:

Kind

VOB

Directory

Color

Red

Green

Using Rational DOORS for ClearCase Interface 11

Importing from ClearCase

Kind Color

File

Version

Blue

Light blue

Branch Yellow

Derived Object Pink

Private File Orange

ClearCase attributes

All user-defined ClearCase attributes are imported into Rational DOORS as string attributes with the same name, prefixed with CC Attr. For example, the

ClearCase attribute Test_Status is called CC Attr Test_Status in Rational

DOORS.

Attribute values are imported for all ClearCase elements, versions and branches.

If the values of attributes are subsequently changed in ClearCase, the values in

Rational DOORS are updated the next time the file is imported.

Labels

ClearCase labels are typically used to mark which files were included in a particular release. Labels have names, such as Patch_1.1. The import process creates a Boolean label for each imported label, prefixing the label name with CC

Label. For this example, the Boolean label would be CC Label Patch_1.1.

Each version that is labeled with a given name, has the Rational DOORS attribute set to True. This can be used in filters, and gives instant indications of what versions were used in a given release.

Merge links

ClearCase uses hyperlinks to indicate where files have been merged. These can be imported into Rational DOORS as regular Rational DOORS links. This import process is optional, and can be turned off using the Create merge links check box.

Links are created from the version to the one it is merged with, typically from a branch to the main stream. This is equivalent to the direction of the ClearCase hyperlinks.

12 Using Rational DOORS for ClearCase Interface

Using Rational DOORS traceability

The best way of viewing merge links is to turn on the display of graphics links by clicking View, then Show, then Graphics Links. Alternatively, all the normal

Rational DOORS link viewing and analysis mechanisms are available.

Using Rational DOORS traceability

Once imported into Rational DOORS, the ClearCase structure can be treated as normal in Rational DOORS. This means that the ClearCase structure can be included in your traceability schema. A typical application of this is to link source code modules to requirements in order to check which requirements have been met. This is only one case where traceability could be useful, as outlined below.

Managing links

You can use any of the standard methods for creating links between ClearCase configuration items and other Rational DOORS information:

• Drag and drop

Link > Create links

• Link module matrix

In each case you must take into account the correct direction for links to allow impact and traceability analyses to be performed as required. These analyses can be performed using the standard tools:

• Pop-up menus

Analysis > Impact or Analysis > Trace

• Layout DXL

Analysis > Wizard

The Analysis Wizard is particularly good for creating customized traceability reports. With this, you could create a report that shows the relationship between change requests and code check-ins, showing complete version names in the context of the change requests.

Links can be deleted using any of the standard techniques.

Applications of imported structures

Rational DOORS can be used to store any kind of structured information, so it is likely that you already have information that can be usefully linked to the configuration items. In addition to the classic application of requirements traceability, you can also build links from change requests, bug reports, design information, test plans and project plans to ClearCase versions.

Using Rational DOORS for ClearCase Interface 13

Importing from ClearCase

Once in place, you can demonstrate that specific changes have been implemented, or create reports that justify all checked in changes.

Another application is the creation of complete product manifests. Using the

Rational DOORS export functions, you can create documents in Word, HTML or any other supported format, that lists the document version included in a shipment.

Import exceptions

The Rational DOORS for ClearCase Interface import process is designed to import the information that you need most in your Rational DOORS-based lifecycle traceability scheme. To this end there are some items that are not imported. Two items that are deliberately not imported are listed below.

• Any version that is checked out is not imported until it is checked in. Any item that would be selected only with a \CHECKEDOUT configuration specification rule is specifically ignored. If a checked in item has been merged with an item that is still checked out the CC Merges attribute contains the reference; for example \main\CHECKEDOUT. However, no Rational DOORS link is created until the merge target is checked in.

• Versions of directory elements are not imported. Rational DOORS for

ClearCase Interface only imports from the directories that are selected by the configuration specification of the view from which you import.

Private files and derived objects from multiple views can be imported by repeating the import process from those different views. If there are several elements of the same name, Rational DOORS for ClearCase Interface has no way of distinguishing them; it then considers each private one an update of an earlier import.

14 Using Rational DOORS for ClearCase Interface

4

Labelling Rational DOORS baselines

This chapter describes:

Importing ClearCase labels into Rational DOORS

Creating Rational DOORS baselines

Understanding results

Using Rational DOORS traceability

Importing ClearCase labels into Rational DOORS

ClearCase labels are typically used to mark which files were included in a particular release. Labels have names, such as Release_3, which can be attached to versions of ClearCase elements. Labels can be attached to any version, and do not restrain in any way the numbering system.

Rational DOORS baselines create frozen versions of modules that are similar to checked-in versions of files: they can be referenced, but not changed. Baselines are numbered progressively using major and minor versions, plus a textual suffix.

ClearCase labels are ideal for use as Rational DOORS baseline suffixes, where they can be used for the same purpose as in ClearCase. This is the main function of the Rational DOORS for ClearCase Interface baseline labelling function.

Baseline labelling is a two-step process: importing labels and creating baselines.

The import process sets up a structure where a record of each created baseline is

kept. This section describes the import step while the section “Creating Rational

DOORS baselines,” on page 17 describes baseline creation.

Even though labels are directly related to a VOB, access to ClearCase is still controlled by views. For these reasons you must choose a view for your import operation.

Importing labels for the first time

You can choose to import into an empty module or into a module that already contains objects. The set of labels from each VOB is always imported under its own top-level object.

Normally, you would maintain your label and baseline structure in a special module, though you might choose to store label information for several VOBs in the same module. If you choose to do this, the new VOB will be imported under a new level one object at the end of the module.

Using Rational DOORS for ClearCase Interface 15

Labelling Rational DOORS baselines

It is advisable not to store label and baseline information in the same module as the imported ClearCase configuration structure.

To import labels from ClearCase:

1. Log in to Rational DOORS as the Administrator.

2. Open your target Rational DOORS module.

3. Select DOORSConnect > ClearCase > Label baselines.

A command prompt window (DOS box) is displayed briefly before the

Import ClearCase Labels window is displayed. This occurs when Rational

DOORS for ClearCase Interface is communicating with ClearCase.

If you want to import from a dynamic-view make sure that the Drive field contains the correct drive. M: is the ClearCase default.

4. Select the view in the View field.

5. Select the VOB in the VOB field. The Path field shows the composite path that you have created.

Note Only mounted VOBs and views are shown. If you do not see the VOB or view you want to import, click Close to quit Rational DOORS for ClearCase Interface, then use ClearCase to mount the required VOB and view.

6. If you want to import from a snapshot view or a dynamic view mounted on a specific drive, select Specific view drive from the Type drop-down list.

7. Select the correct drive and VOB. The Path field shows the composite path that you have created.

Note Only mounted VOBs are shown. If you do not see the

VOB you want to import, click Close to quit Rational

DOORS for ClearCase Interface, then use ClearCase to mount the required VOB.

8. Click Import to start the import operation.

A command prompt window appears briefly.

9. When the import is complete, the Rational DOORS module is updated and the Apply Label to Modules window is displayed. For further information,

see “Creating Rational DOORS baselines,” on page 17.

16 Using Rational DOORS for ClearCase Interface

Creating Rational DOORS baselines

Re-importing labels

It is likely that after you have completed this baseline labelling operation you will create more ClearCase labels. For this reason, Rational DOORS for ClearCase

Interface can synchronize existing imported labels with the state of the

ClearCase VOB, adding new labels as required.

To do this, select the VOB object at the top of the label and baseline structure,

then repeat the procedure in “Importing labels for the first time,” on page 15.

Imported attributes for labels

ClearCase data is stored in Rational DOORS attributes when it is imported.

Attributes that store ClearCase data start with CC.

ClearCase properties are stored in the following attributes:

Attribute

Object Heading

Object Text

CC Kind

Meaning

The name of the ClearCase label.

The ClearCase comment for the label, specified when the label was created.

The object type. Possible values are VOB, Label and

Baseline.

The name of the person who created the label.

The date on which the label was created.

CC User

CC Date

Creating Rational DOORS baselines

The second step of the import process is the creation of Rational DOORS baselines using an imported ClearCase label.

You create baselines using the ClearCase Apply Label to Modules dialog box.

To create labeled baselines:

1. Ensure all necessary Rational DOORS modules are closed and not in use by others.

2. Select the required label from the list in ClearCase labels.

3. Select the required module from the list in Rational DOORS modules.

You can select any number of modules in this list. Use Select all and Clear

all to simplify the selection process if you have a lot of modules.

Using Rational DOORS for ClearCase Interface 17

Labelling Rational DOORS baselines

4. Select the type of baseline required: Suffix only, Minor or Major version.

5. Select whether you want to include a suffix by clicking Use suffix. The default suffix is the selected ClearCase label. You can modify it before use if required.

6. Modify the label comment, if necessary. It is used as annotation for the baseline.

7. Click Baseline. You are asked to confirm the operation twice. To create the baseline, Rational DOORS needs to open all the selected modules in exclusive edit mode. This means you must make sure that no one else has any of the modules open in either exclusive or shareable edit modes.

Once a baseline has been created, it cannot be destroyed or recreated, so you must be absolutely certain that a group baselining operation is correct before proceeding.

Baselines are created for each of the specified modules, and the label module is updated to contain a baseline-creation object for each module.

The attribute CC Baseline is created and filled with the baseline name for each baseline creation object.

When the baseline creation is complete, a Baseline Labelling Report dialog box is displayed, showing how many labels and baselines were created.

For further information on how to use the Baseline Labelling Report window

functions, see “Understanding results,” on page 18.

Understanding results

All the normal Rational DOORS viewing mechanisms can be used on the label and baseline structure. The information can be displayed in either document or graphics mode. Each object type has been allocated a color to aid visual identification.

Graphics colors

When each item is imported it is assigned a color for use in graphics mode. This helps provide instant visual recognition of the structure of your data.

The color allocations are as follows:

Kind

VOB

Color

Red

18 Using Rational DOORS for ClearCase Interface

Using Rational DOORS traceability

Kind

Label

Baseline

Derived Object

Private File

Color

Green

Blue

Pink

Orange

Viewing new information

If you re-import labels or create new labels in the same module, you can use the

Apply filter button on the Baseline Labelling Report dialog box so that only the new items are displayed.

Using Rational DOORS traceability

By storing information on labels and baselines in a Rational DOORS module, they can be included in your traceability schema. In this way you can link details of released information directly to project plans and other applications, as outlined below.

Managing links

You can use any of the following standard methods for creating links between label and baseline objects and other Rational DOORS information:

• Drag and drop

Link > Create links

• Link module matrix

In each case you must take into account the correct direction for links to allow impact and traceability analyses to be performed as required. These analyses can be performed using the following standard tools:

• Pop-up menus

Analysis > Impact or Analysis > Trace

• Layout DXL

Analysis > Wizard

The last item, the analysis wizard, is particularly good for creating customized traceability reports. With this, you could create a report that shows the relationship between code check-ins and module baselines, showing complete

Using Rational DOORS for ClearCase Interface 19

Labelling Rational DOORS baselines

version names, baseline specifications, and dates in the context of planning information.

Links can be deleted by using any of the standard techniques.

Applications of imported labels

Rational DOORS can be used to store any kind of structured information, so it is highly likely that in your data you already have information that can be linked to baseline records. You might use it to associate particular module baselines with deliveries made to customers with specific requirements.

Another application is to create complete product manifests. Using the Rational

DOORS export functions, you can create documents in Word, HTML or any other supported format, that lists the document version included in a shipment.

20 Using Rational DOORS for ClearCase Interface

5

Troubleshooting

Poor performance when importing data to Rational DOORS

Poor performance when importing data to Rational DOORS

When importing data from ClearCase into Rational DOORS, the operation may take a long time and may appear to hang.

To resolve this problem, do the following before importing:

1. Open up Windows Task Manager.

2. Go to the Processes tab.

3. Right-click on the DOORS.exe process and for the Set priority menu option, click low.

4. Try the operation in the integration again.

5. Once the import operation has finished, set the priority of the process back to normal.

Using Rational DOORS for ClearCase Interface 21

Troubleshooting

22 Using Rational DOORS for ClearCase Interface

6

Contacting support

This chapter contains the following topics:

Contacting IBM Rational Software Support

Prerequisites

Submitting problems

Other information

Contacting IBM Rational Software Support

If the self-help resources have not provided a resolution to your problem, you can contact IBM Rational Software Support for assistance in resolving product issues.

Note If you are a heritage Telelogic customer, you can go to http://support.telelogic.com/toolbar and download the

IBM Rational Telelogic Software Support browser toolbar.

This toolbar helps simplify the transition to the IBM Rational

Telelogic product online resources. Also, a single reference site for all IBM Rational Telelogic support resources is located at http://www.ibm.com/software/rational/support/telelogic/

Prerequisites

To submit your problem to IBM Rational Software Support, you must have an active Passport Advantage® software maintenance agreement. Passport

Advantage is the IBM comprehensive software licensing and software maintenance (product upgrades and technical support) offering. You can enroll online in Passport Advantage from http://www.ibm.com/software/lotus/passportadvantage/howtoenroll.html

.

• To learn more about Passport Advantage, visit the Passport Advantage

FAQs at http://www.ibm.com/software/lotus/passportadvantage/brochures_faqs_ quickguides.html

.

• For further assistance, contact your IBM representative.

To submit your problem online (from the IBM website to IBM Rational

Software Support, you must additionally:

Using Rational DOORS for ClearCase Interface 23

Contacting support

• Be a registered user on the IBM Rational Software Support website. For details about registering, go to http://www-01.ibm.com/software/support/ .

• Be listed as an authorized caller in the service request tool.

Submitting problems

To submit your problem to IBM Rational Software Support:

1. Determine the business impact of your problem. When you report a problem to IBM, you are asked to supply a severity level. Therefore, you need to understand and assess the business impact of the problem that you are reporting.

Use the following table to determine the severity level.

Severity

1

2

3

4

Description

The problem has a critical business impact: You are unable to use the program, resulting in a critical impact on operations.

This condition requires an immediate solution.

This problem has a significant business impact: The program is usable, but it is severely limited.

The problem has some business impact: The program is usable, but less significant features (not critical to operations) are unavailable.

The problem has minimal business impact: The problem causes little impact on operations or a reasonable circumvention to the problem was implemented.

2. Describe your problem and gather background information. When describing a problem to IBM, be as specific as possible. Include all relevant background information so that IBM Rational Software Support specialists can help you solve the problem efficiently. To save time, know the answers to these questions:

• What software versions were you running when the problem occurred?

To determine the exact product name and version, use the option applicable to you:

24 Using Rational DOORS for ClearCase Interface

Submitting problems

• Start the IBM Installation Manager and click File > View Installed

Packages. Expand a package group and select a package to see the package name and version number.

• Start your product, and click Help > About to see the offering name and version number.

• What is your operating system and version number (including any service packs or patches)?

• Do you have logs, traces, and messages that are related to the problem symptoms?

• Can you recreate the problem? If so, what steps do you perform to recreate the problem?

• Did you make any changes to the system? For example, did you make changes to the hardware, operating system, networking software, or other system components?

• Are you currently using a workaround for the problem? If so, be prepared to describe the workaround when you report the problem.

3. Submit your problem to IBM Rational Software Support. You can submit your problem to IBM Rational Software Support in the following ways:

Online: Go to the IBM Rational Software Support website at https://www.ibm.com/software/rational/support/ and in the Rational support task navigator, click Open Service Request. Select the electronic problem reporting tool, and open a Problem Management

Record (PMR), describing the problem accurately in your own words.

For more information about opening a service request, go to http://www.ibm.com/software/support/help.html

.

You can also open an online service request using the IBM Support

Assistant. For more information, go to http://www-01.ibm.com/software/support/isa/faq.html

.

By phone: For the phone number to call in your country or region, go to the IBM directory of worldwide contacts at http://www.ibm.com/planetwide/ and click the name of your country or geographic region.

Through your IBM Representative: If you cannot access IBM

Rational Software Support online or by phone, contact your IBM

Representative. If necessary, your IBM Representative can open a service request for you. You can find complete contact information for each country at http://www.ibm.com/planetwide/ .

Using Rational DOORS for ClearCase Interface 25

Contacting support

If the problem you submit is for a software defect or for missing or inaccurate documentation, IBM Rational Software Support creates an Authorized Program

Analysis Report (APAR). The APAR describes the problem in detail. Whenever possible, IBM Rational Software Support provides a workaround that you can implement until the APAR is resolved and a fix is delivered. IBM publishes resolved APARs on the IBM Rational Software Support website daily, so that other users who experience the same problem can benefit from the same resolution.

Other information

For Rational software product news, events, and other information, visit the

IBM Rational Software website on http://www.ibm.com/software/rational/ .

26 Using Rational DOORS for ClearCase Interface

7

Notices

© Copyright IBM Corporation 1993, 2011

US Government Users Restricted Rights - Use, duplication, or disclosure restricted by GSA ADP Schedule Contract with IBM Corp.

This information was developed for products and services offered in the U.S.A.

IBM may not offer the products, services, or features discussed in this document in other countries. Consult your local IBM representative for information on the products and services currently available in your area. Any reference to an IBM product, program, or service is not intended to state or imply that only that IBM product, program, or service may be used. Any functionally equivalent product, program, or service that does not infringe any IBM intellectual property right may be used instead. However, it is the user’s responsibility to evaluate and verify the operation of any non-IBM product, program, or service.

IBM may have patents or pending patent applications covering subject matter described in this document. The furnishing of this document does not grant you any license to these patents. You can send written license inquiries to:

IBM Director of Licensing

IBM Corporation

North Castle Drive

Armonk, NY 10504-1785

U.S.A.

For license inquiries regarding double-byte character set (DBCS) information, contact the IBM Intellectual Property Department in your country or send written inquiries to:

Intellectual Property Licensing

Legal and Intellectual Property Law

IBM Japan Ltd.

1623-14, Shimotsuruma, Yamato-shi

Kanagawa 242-8502 Japan

The following paragraph does not apply to the United Kingdom or any

other country where such provisions are inconsistent with local law:

INTERNATIONAL BUSINESS MACHINES CORPORATION PROVIDES

THIS PUBLICATION “AS IS” WITHOUT WARRANTY OF ANY KIND,

Using Rational DOORS for ClearCase Interface 27

Notices

EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO,

THE IMPLIED WARRANTIES OF NON-INFRINGEMENT,

MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.

Some states do not allow disclaimer of express or implied warranties in certain transactions. Therefore, this statement may not apply to you.

This information could include technical inaccuracies or typographical errors.

Changes are periodically made to the information herein; these changes will be incorporated in new editions of the publication. IBM may make improvements and/or changes in the product(s) and/or the program(s) described in this publication at any time without notice.

Any references in this information to non-IBM websites are provided for convenience only and do not in any manner serve as an endorsement of those websites. The materials at those websites are not part of the materials for this

IBM product and use of those websites is at your own risk.

IBM may use or distribute any of the information you supply in any way it believes appropriate without incurring any obligation to you.

Licensees of this program who wish to have information about it for the purpose of enabling: (i) the exchange of information between independently created programs and other programs (including this one) and (ii) the mutual use of the information which has been exchanged, should contact:

Intellectual Property Dept. for Rational Software

IBM Corporation

1 Rogers Street

Cambridge, Massachusetts 02142

U.S.A.

Such information may be available, subject to appropriate terms and conditions, including in some cases, payment of a fee.

The licensed program described in this document and all licensed material available for it are provided by IBM under terms of the IBM Customer

Agreement, IBM International Program License Agreement or any equivalent agreement between us.

Any performance data contained herein was determined in a controlled environment. Therefore, the results obtained in other operating environments may vary significantly. Some measurements may have been made on development-level systems and there is no guarantee that these measurements will be the same on generally available systems. Furthermore, some measurements may have been estimated through extrapolation. Actual results

28 Using Rational DOORS for ClearCase Interface

Trademarks

may vary. Users of this document should verify the applicable data for their specific environment.

Information concerning non-IBM products was obtained from the suppliers of those products, their published announcements or other publicly available sources. IBM has not tested those products and cannot confirm the accuracy of performance, compatibility or any other claims related to non-IBM products.

Questions on the capabilities of non-IBM products should be addressed to the suppliers of those products.

This information contains examples of data and reports used in daily business operations. To illustrate them as completely as possible, the examples include the names of individuals, companies, brands, and products. All of these names are fictitious and any similarity to the names and addresses used by an actual business enterprise is entirely coincidental.

If you are viewing this information softcopy, the photographs and color illustrations may not appear.

Additional legal notices are described in the legal_information.html file that is included in your software installation.

Trademarks

IBM, the IBM logo, and ibm.com are trademarks or registered trademarks of

International Business Machines Corp., registered in many jurisdictions worldwide. Other product and service names might be trademarks of IBM or other companies. A current list of IBM trademarks is available on the web at www.ibm.com/legal/copytrade.html

.

Windows is a trademark of Microsoft Corporation in the United States, other countries, or both.

Other company, product or service names may be trademarks or service marks of others.

Using Rational DOORS for ClearCase Interface 29

Notices

30 Using Rational DOORS for ClearCase Interface

Index

A

attributes imported elements

, 12

imported labels

, 17

imported structures

, 9

B

baselines about displaying

, 18

creating

, 17

graphics mode

, 11, 18

E

exceptions

, 14

G

graphics mode

, 11, 18

I

IBM Customer Support

, 23

import exceptions

, 14

imported information about labels

, 12

attributes

, 12

color allocation

, 11, 18

displaying

, 10

filtering

, 19

understanding

, 11

version structures

, 11

imported labels about

, 12

about importing

, 15

attributes

, 17

importing for the first time

, 15

updating

, 17

imported structures attributes

, 9

importing for the first time

, 7

updating

, 9

importing about importing labels

, 15

about importing structures

, 7

attributes for imported labels

, 17

attributes for imported structures

, 9

displaying imported information

, 10

importing labels for the first time

, 15

importing structures for the first time

, 7

updating labels

, 17

updating structures

, 9

L

links

, 12, 13, 19

M

merge links

, 12

R

Rational DOORS for ClearCase Interface functions

, 5

introduction

, 5

T

traceability

, 13, 19

V

Versioned Object Bases (VOBs)

, 6

Using Rational DOORS for ClearCase Interface

31

Index

32

Using Rational DOORS for ClearCase Interface

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project
