OPERATING INSTRUCTIONS

OPERATING INSTRUCTIONS

OPERATING INSTRUCTIONS

Personal Computer

Model No.

UT-MA6

series

Contents

Read Me First

Safety Precautions .....................................................

Regulatory Information ...............................................

2

5

Getting Started

Introduction .................................................................

Description of Parts ....................................................

First-time Operation ..................................................

11

Turning On / Turning Off ...........................................

8

9

14

Useful Information

Handling and Maintenance .......................................

Installing Software ....................................................

15

19

Troubleshooting

Troubleshooting (Basic) ............................................

23

Appendix

LIMITED USE LICENSE AGREEMENT ...................

Specifications ...........................................................

LIMITED WARRANTY ..............................................

26

28

31

Please read these instructions carefully before using this product, and save this manual for future use.

UT-MA6_USEN.indb 1 24/02/2014 16:28:01

Safety Precautions

To reduce the risk of injury, loss of life, electric shock, fire, malfunction, and damage to equipment or property, always observe the following safety precautions.

Explanation of symbol word panels

The following symbol word panels are used to classify and describe the level of hazard, injury, and property damage caused when the denotation is disregarded and improper use is performed.

DANGER

Denotes a potential hazard that will result in serious injury or death.

WARNING

Denotes a potential hazard that could result in serious injury or death.

CAUTION

Denotes a hazard that could result in minor injury.

NOTICE

Denotes a hazard that could result in property damage.

The following symbols are used to classify and describe the type of instructions to be observed.

This symbol is used to alert users to a specific operating procedure that must not be performed.

This symbol is used to alert users to a specific operating procedure that must be followed in order to operate the unit safety.

DANGER

Precautions on the Built-in Battery

(for disposal)

When disposing the battery, generation of heat, ignition or rupture of the Built-in Battery may result.

Handling This Computer

„

Do Not Disassemble the Computer Except

When Disposing

Handling the Built-in Battery

„

Do Not Short the Positive (+) and Negative

(-) Contacts

„

Do Not Throw the Battery into a Fire or

Expose It to Excessive Heat

„

Do Not Apply Shocks to the Built-in Battery by Dropping It, Applying Strong Pressure to It, etc.

„

Do Not Charge

„

Do Not Use

„

Do Not Deform, Disassemble, or Modify the

Battery

„

Avoid Extreme Heat (Near the Fire, in Direct

Sunlight, for Example)

WARNING

Generation of heat, ignition or rupture of the Built-in

Battery may result.

„

Do Not Throw This Product Into a Fire or

Expose It to Excessive Heat

„

Do Not Deform, Disassemble, or Modify

This Product

„

Do Not Apply Shocks to the Product by

Dropping It, Applying Strong Pressure to

It, etc.

„

Do Not Charge the Battery Using Methods

Other Than Those Specified

„

Avoid Extreme Heat (Near the Fire, in Direct Sunlight, for Example)

„

When the Battery Has Deteriorated, Contact Your Technical Support Office to Replace the Battery

2

UT-MA6_USEN.indb 2 24/02/2014 16:28:01

WARNING

Fire or electric shock may result.

„

Do Not Do Anything That May Damage the

AC Cord, the AC Plug, or the AC Adaptor

Do not damage or modify the cord, place it near hot tools, bend, twist, or pull it forcefully, place heavy objects on it, or bundle it tightly.

Ö

Do not continue to use a damaged AC cord,

AC plug and AC adaptor.

• Contact your technical support office for repair.

„

Do Not Connect the AC Adaptor to a Power

Source Other Than a Standard Household

AC Outlet

Ö

Connecting to a DC/AC converter (inverter) may damage the AC adaptor. On an airplane, only connect the AC adaptor/charger to an AC outlet specifically approved for such use.

„

Do Not Pull or Insert the AC Plug If Your

Hands Are Wet

„

Do Not Disassemble This Product

„

Do Not Touch This Product In a Thunderstorm If Connected with the AC Cable or

Any Other Cables

„

Do Not Place Containers of Liquid or Metal

Objects on Top of This Product

Ö

If foreign matter has found its way inside, immediately turn the power off and unplug the AC plug and remove the battery pack.

Then contact your technical support office.

„

If a Malfunction or Trouble Occurs, Immediately Stop Use

If the Following Malfunction Occurs, Immediately Unplug the AC Plug

• This product is damaged

• Foreign object inside this product

• Smoke emitted

• Unusual smell emitted

• Unusually hot

Ö

After the above procedure, contact your technical support office for repair.

„

Clean Dust and Other Debris of the AC

Plug Regularly

• If dust or other debris accumulates on the plug, humidity, etc. may cause a defect in the insulation.

„

Insert the AC Plug Completely

Ö

Do not use a damaged plug or loose AC outlet.

Burns or low-temperature burns may result.

„

Do Not Use This Product in Close Contact

With Your Body For a Long Period of Time

• Do not use this product with its heat-emitting parts in close contact with your body for long periods of time.

• Low-temperature burns may result.

„

Do Not Touch The Surface of The AC Adaptor Continuously While Using/Charging

• Burns may result.

„

Do Not Expose Yourself or Other Persons to the Hot Wind from the Ventilation Hole

(Exhaust) For a Long Period of Time

• Depending on the direction of the computer or the way you hold the computer, your hands and body will be more exposed to the hot wind.

• Covering the ventilation hole (exhaust) with your hand or other object can cause heat to build up inside, possibly resulting in burns.

Detrimental health effects on your body may result.

„

Do Not Turn the Volume Up To Loud When

Using Headphones

• Listening at high volumes that overstimulate the ear for long periods of time may result in loss of hearing.

CAUTION

Fire or electric shock may result.

„

Do Not Move This Product While the AC

Plug Is Connected

Ö

If the AC cord is damaged, unplug the AC plug immediately.

„

Do Not Connect a Telephone Line, or a Network Cable Other Than the One Specified,

Into the LAN Port

Ö

Do not connect to a network such as the ones listed below.

• Networks other than 1000BASE-T,

100BASE-TX or 10BASE-T

• Phone lines (IP phone (Internet Protocol

Telephone), Telephone lines, internal phone lines (on-premise switches), digital public phones, etc.)

„

Do Not Subject the AC Adaptor To Any

Strong Impact

Ö

Do not continue to use the AC adaptor after a strong impact such as being dropped.

Ö

Contact your technical support office for repair.

„

Do Not Leave This Product in High Temperature Environment for a Long Period of

Time

• Leaving this product where it will be exposed to extremely high temperatures such as near fire or in direct sunlight may deform the cabinet and/or cause trouble in the internal parts.

„

Do Not Block the Ventilation Hole (Exhaust/

Intake)

Ö

Do not use this product wrapped in cloth or on top of bedding or a blanket.

„

Do Not Keep This Product Wherever There is a Lot of Water, Moisture, Steam, Dust,

Oily Vapors, etc.

3

24/02/2014 16:28:01 UT-MA6_USEN.indb 3

Safety Precautions

Fire or electric shock may result.

„

Hold the Plug When Unplugging the AC Plug

„

Use Only the Specified AC Adaptor With

This Product

Ö

Do not use an AC adaptor other than the one supplied (supplied with the unit or one sold separately as an accessory).

This product may fall over or drop, resulting in an injury.

„

Do Not Place This Product on Unstable

Surfaces

„

Avoid Stacking

Detrimental health effects on your body may result.

„

Take a Break Of 10-15 Minutes Every Hour

• Using this product for long periods of time may have detrimental health effects on the eyes or hands.

NOTICE

l

Do not place the computer near a television or radio receiver.

l

Keep the computer away from magnets. Data stored on the flash memory may be lost.

l

This computer is not intended for the display of images for use in medical diagnosis.

l

This computer is not intended for a use with connection of medical equipment for the purpose of medical diagnosis.

l

Panasonic shall not be liable for loss of data or other incidental or consequential damages resulting from the use of this product.

l

If this computer will not be used for a long period of time (a month or more), charge or discharge (use) the battery until the remaining battery level becomes 30% to 40% and store the product in a cool, dry place.

l

This computer prevents overcharging of the battery by recharging only when the remaining power is less than approx. 95% (when Economy Mode (ECO) is enabled:

75%) of capacity.

l

The battery is not charged when this computer is first purchased. Be sure to charge it before using it for the first time. When the AC adaptor is connected to this computer, charging begins automatically.

l

Should the battery leak and the fluid get into your eyes, do not rub your eyes. Immediately flush your eyes with clear water and see a doctor for medical treatment as soon as possible.

This computer is not intended for use in medical equipment including life-support systems, air traffic control systems, or other equipment, devices or systems that are involved with ensuring human life or safety. Panasonic cannot be held responsible in any way for any damages or loss resulting from the use of this unit in these types of equipment, devices or systems, etc.

This computer has been designed so as to minimize shock to the LCD, the leakage of liquid (e.g., water) on to the buttons, etc., but no warranty is provided against such trouble. Therefore, as a precision instrument, be extremely careful in the handling.

4

NOTE

l

The battery may become warm during recharging or normal use. This is completely normal.

l

Recharging will not commence if internal temperature of the battery is outside of the allowable temperature range (0 °C to 50 °C). (è Reference Manual “Battery Power”) Once the allowable range requirement is satisfied, charging begins automatically. Note that the recharging time varies based on the usage conditions.

(Recharging takes longer than usual when the temperature is 10 °C or below.) l

If the temperature is low, the operating time is shortened. Only use the computer within the allowable temperature range.

l

The battery is a consumable item. If the amount of time the computer can be run by using a particular battery becomes dramatically shorter and repeated recharging does not restore its performance, the battery should be replaced with a new one. Contact your technical support office.

l

Always power off the computer when it is not in use.

Leaving the computer on when the AC adaptor is not connected will exhaust the remaining battery capacity.

THIS PRODUCT IS NOT INTENDED FOR USE AS, OR

AS PART OF, NUCLEAR EQUIPMENT/SYSTEMS, AIR

TRAFFIC CONTROL EQUIPMENT/SYSTEMS, AIR-

CRAFT COCKPIT EQUIPMENT/SYSTEMS

*1

, MEDICAL

*2

, LIFE SUPPORT SYSDEVICES OR ACCESSORIES

TEMS OR OTHER EQUIPMENTS/DEVICES/SYSTEMS

THAT ARE INVOLVED WITH ENSURING HUMAN

LIFE OR SAFETY. PANASONIC WILL NOT BE RE-

SPONSIBLE FOR ANY LIABILITY RESULTING FROM

THE USE OF THIS PRODUCT ARISING OUT OF THE

FOREGOING USES.

*1

*2

AIRCRAFT COCKPIT EQUIPMENT/SYSTEMS include

Class2 Electronic Flight Bag (EFB) Systems and Class1 EFB

Systems when used during critical phases of flight (e.g., during take-off and landing) and/or mounted on to the aircraft.

Class1 EFB Systems and 2 EFB Systems are defined by

FAA: AC (Advisory Circular) 120-76A or JAA: JAA TGL (Temporary Guidance Leaflets) No.36.

As defined by the European Medical Device Directive (MDD)

93/42/EEC.

Panasonic cannot guarantee any specifications, technologies, reliability, safety (e.g. Flammability/Smoke/

Toxicity/Radio Frequency Emission, etc) requirements related to aviation standards that exceed the specifications of our COTS (Commercial-Off-The-Shelf) products.

UT-MA6_USEN.indb 4 24/02/2014 16:28:02

Regulatory Information

Information to the User / Informations destinées aux utilisateurs

<Only for model with wireless LAN/Bluetooth>

This product and your Health

This product, like other radio devices, emits radio frequency electromagnetic energy. The level of energy emitted by this product however is far much less than the electromagnetic energy emitted by wireless devices like for example mobile phones.

Because this product operates within the guidelines found in radio frequency safety standards and recommendations, we believe this product is safe for use by consumers. These standards and recommendations reflect the consensus of the scientific community and result from deliberations of panels and committees of scientists who continually review and interpret the extensive research literature.

In some situations or environments, the use of this product may be restricted by the proprietor of the building or responsible representatives of the organization. These situations may for example include: l

Using this product on board of airplanes, or l

In any other environment where the risk of interference to other devices or services is perceived or identified as harmful.

If you are uncertain of the policy that applies on the use of wireless devices in a specific organization or environment (e.g. airports), you are encouraged to ask for authorization to use this product prior to turning on the product.

Regulatory Information

We are not responsible for any radio or television interference caused by unauthorized modification of this product.

The correction of interference caused by such unauthorized modification will be the responsibility of the user. We and its authorized resellers or distributors are not liable for damage or violation of government regulations that may arise from failing to comply with these guidelines.

26-M-1

<Uniquement pour les modèles avec réseau local sans fil et/ou Bluetooth>

Ce produit et votre santé

Ce produit, comme tout autre appareil radio, émet de l’énergie radioélectrique. Toutefois, la quantité d’énergie

émise par ce produit est beaucoup moins importante que l’énergie radioélectrique émise par des appareils sans fil tels que les téléphones portables. L’utilisation de ce produit ne comporte aucun risque pour le consommateur du fait que cet appareil opère dans les limites des directives concernant les normes et les recommendations de sécurité sur les fréquences radio. Ces normes et recommandations reflètent le consensus de la communauté scientifique et résultent de délibérations de jurys et comités de scientifiques qui examinent et interprètent continuellement les nouveautés de la vaste littérature sur les recherches effectuées. Dans certaines situations ou environnements, l’utilisation de ce produit peut être restreinte par le propriétaire du bâtiment ou par les représentants responsables de l’organisation. Ces situations peuvent

être les suivantes par exemple : l

A bord d’un avion, ou l

Dans tout autre environnement où les risques d’interférence sur d’autres appareils ou services sont perçus ou identifiables comme dangereux.

Si vous n’êtes pas sûr de la réglementation applicable à l’utilisation d’appareils sans fil dans une organization ou un environnement spécifique, (par exemple dans un aéroport) nous vous invitons à demander l’autorisation d’utiliser ce produit avant sa mise en marche.

Informations concernant la réglementation

Nous déclinons toute responsabilité pour toute interférence radio ou télévision causée par des modifications non autorisées apportées à ce produit. La correction d’interférences causées par de telles modifications non autorisées sera la seule responsabilité de son utilisateur.

Nousmêmes, les revendeurs officiels et les distributeurs ne sommes pas responsable de tout dégât ou de toute violation des règlements de l’État pouvant découler du non-respect de ces directives.

26-F-1

Lithium Battery / Pile au lithium

Lithium Battery!

This computer contains a lithium battery to enable the date, time, and other data to be stored. The battery should only be exchanged by authorized service personnel.

Warning!

A risk of explosion from incorrect installation or misapplication may possibly occur.

15-E-1

Pile au lithium!

Le micro-ordinateur renferme une pile au lithium qui permet de sauvegarder certaines données, notamment la date et l’heure. La pile ne doit être remplacée que par un technicien qualifié.

Danger !

Risque d’explosion en cas de non respect de cette mise en garde!

15-F-1

Information for Users on Collection and Disposal of Old Equipment and used Batteries

These symbols are only valid in the European Union.

If you wish to discard this product, please contact your local authorities or dealer and ask for the correct method of disposal.

53-M-1

5

24/02/2014 16:28:02 UT-MA6_USEN.indb 5

Regulatory Information

CAUTION:

Risk of Explosion if Battery is replaced by an Incorrect Type. Dispose of Used Batteries According to the Instructions.

ATTENTION:

Il y a risque d’explosion si la batterie est remplacée par une batterie de type incorrect.

Mettre au rebut les batteries usagées conformément aux instructions.

58-E-1

58-F-1

For U.S.A.

Federal Communications Commission Radio Frequency Interference Statement

Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: l

Reorient or relocate the receiving antenna.

l

Increase the separation between the equipment and receiver.

l

Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

l

Consult the Panasonic Service Center or an experienced radio/TV technician for help.

Warning

To assure continued compliance, use only shielded interface cables when connecting to a computer or peripheral.

Also, any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment.

FCC RF Exposure Warning: l

This equipment is provided with PC Card slot that could be used with wireless transmitters, which will be specifically recommended when they become available.

Other third-party wireless transmitters have not been

RF exposure evaluated for use with this computer and may not comply with FCC RF exposure requirements.

<Only for model with wireless LAN/Bluetooth> l

This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.

l

This equipment may not be co-located or operated with any other antenna or transmitter.

l

This device meets the government’s requirements for exposure to radio waves.

This device is designed and manufactured not to exceed the emission limits for exposure to radio frequency (RF) energy set by the Federal Communications Commission of the U.S. Government.

l

The exposure standard for wireless device employs a unit of measurement known as the Specific Absorption

Rate, or SAR. The SAR limit set by the FCC is

1.6 W/kg.

* Tests for SAR are conducted using standard operating positions accepted by the FCC with the device transmitting at its highest certified power level in all tested frequency bands.

Although the SAR is determined at the highest certified power level, the actual SAR level of the device while operating can be well below the maximum value. This is because the device is designed to operate at multiple power levels so as to use only the poser required to reach the network. In general, the closer you are to a wireless base station antenna, the lower the power output.

<Only for model with wireless LAN>

This product is restricted to indoor use due to its operation in the 5.15 to 5.25

5.65 to 5.85

GHz

frequency range. FCC requires this product to be used indoors for the frequency range 5.15 to

5.25

GHz

to reduce the potential for harmful interference to co-channel Mobile Satellite systems. High power radars are allocated as primary users of the 5.25 to 5.35

GHz interference with and/or damage this product.

GHz

and

bands. These radar stations can cause

25-M-W-1

This device complies with Part 15 of the FCC Rules.

Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and

(2) This device must accept any interference received, including interference that may cause undesired operation.

Responsible Party: Panasonic Corporation of North America

Two Riverfront Plaza,

Newark NJ 07102

Support Contact: http://www.panasonic.com/contactinfo

6-M-1

6

UT-MA6_USEN.indb 6 24/02/2014 16:28:02

USA Only: Disposal may be regulated in your community due to environmental considerations. For disposal or recycling information, please visit Panasonic website: http:// www.panasonic.com/environmental or call 1-888-769-0149

65-M-2

<For USA-California Only>

This product contains a CR Coin Cell Lithium Battery which contains Perchlorate Material - special handling may apply.

See www.dtsc.ca.gov/hazardouswaste/perchlorate/

38-M-1

<For USA and Canada>

A lithium ion battery that is recyclable powers the product you have purchased.

Please call 1-800-8-BATTERY for information on how to recycle this battery.

L’appareil que vous vous êtes procuré est alimenté par une batterie au lithium-ion.

Pour des renseignements sur le recyclage de la batterie, veuillez composer le

1-800-8-BATTERY.

48-M-1

For Canada / Pour le Canada

Canadian ICES-003

CAN ICES-003(B) / NMB-003(B)

<Only for model with wireless LAN/Bluetooth>

Industry Canada

This product complies with RSS210 Industry Canada.

Operation is subject to the following two conditions;

7-M-3

(1) this device may not cause interference, and

(2) this device must accept any interference, including interference that may cause undesired operation of the device.

<Ne s’applique qu’aux modèles avec technologie Bluetooth/LAN sans fil>

Industrie Canada

Cet équipement est conforme à la norme CNR-210 d’Industrie Canada. Son fonctionnement est soumis aux deux conditions suivantes :

(1) ce dispositif ne peut produire de brouillage, et

(2) ce dispositif doit accepter le brouillage, y compris le brouillage pouvant entraîner le fonctionnement non désiré de l’appareil.

30-Ca-1-1

<Only for model with wireless LAN>

This product (local network devices) for the band 5150-

5250

5850

MHz harmful interference to co-channel Mobile Satellite systems.

High power radars are allocated as primary users (meaning they have priority) of 5250-5350

MHz

is only indoor usage to reduce potential for

MHz

and 5650-

and these radars could cause interference and/or damage to LELAN devices.

<Ne s’applique qu’aux modèles avec technologie LAN sans fil>

Cet appareil (pour réseaux locaux radioélectriques) dans les bandes de fréquences 5150-5250 une utilization à l’intérieur afin de réduire le risque d’interférence avec les systèmes satellites mobiles bicanaux.

Les radars forte puissance sont désignés comme étant les premiers utilisateurs (c’est-à-dire qu’ils ont la priorité) des bandes de fréquences 5250-5350

5850

MHz

MHz

MHz

est réservé à

et 5650-

. Ces stations radars peuvent provoquer des interférences et/ou des dommages à ce périphérique.

30-Ca-2-1

<Only for model with wireless LAN/Bluetooth> l

This computer complies with Industry Canada radiation exposure limits set forth for an uncontrolled environment.

l

This PC with WLAN and/or Bluetooth transmitters installed, has been approved for portable operation and does not require any minimum spacing be provided between antennas and all person’s body.

<Ne s’applique qu’aux modèles avec technologie Bluetooth/LAN sans fil> l

Cet équipement est conforme aux limites d’exposition aux rayonnements d’Industrie Canada établies pour un environnement non contrôlé.

l

Ce PC avec émetteurs WLAN et/ou Bluetooth a été approuvé à des fins d’opération mobile; aucun espace minimum entre les antennes et le corps de l’utilisateur n’est requis.

FOR USE WITH MODEL NO. : CF-AA5713A

POUR UTILISER AVEC MODÈLE : CF-AA5713A

20-Ca-1

For India

For the purpose of recycling to facilitate effective utilization of resources, please return this product to a nearby authorized collection center, registered dismantler or recycler, or Panasonic service center when disposing of this product.

Please see the Panasonic website for further information on collection centers, etc.

http://www.panasonic.co.in/wps/portal/home

68-M-1

UT-MA6_USEN.indb 7

7

24/02/2014 16:28:02

Introduction

Thank you for purchasing this Panasonic product. For optimum performance and safety, please read these instructions carefully.

n

Terms and illustrations in these instructions

CAUTION

NOTE

:

F8 :

Enter :

è

:

:

: Conditions that may result in minor or moderate injury.

Useful and helpful information.

Press [F8] key.

Press [Enter] key.

Page in these Operating Instructions or in the Reference Manual.

Reference to the on-screen manuals.

(Start) - [All Programs] : Touch (Start), and then touch [All Programs]. l

Some illustrations are simplified to help your understanding and may look different from the actual unit.

l

If you do not log on as an administrator, you cannot use some functions or cannot display some screens.

l

Refer for the latest information about optional products to the catalogs, etc.

l

In these instructions, the names and terms are referred as follows.

Ÿ

“Windows

®

7 Professional 64-bit Service Pack 1” as “Windows” or “Windows 7”

Ÿ

DVD MULTI drive as “DVD drive” n

Disclaimer

Computer specifications and manuals are subject to change without notice. Panasonic Corporation assumes no liability for damage incurred directly or indirectly from errors, omissions or discrepancies between the computer and the manuals.

n

Trademarks

Microsoft

®

, Windows

®

, and the Windows logo are registered trademarks of Microsoft Corporation of the United States and/or other countries.

Intel, Core, Centrino and PROSet are either registered trademarks or trademarks of Intel Corporation.

SDXC Logo is a trademark of SD-3C, LLC.

Bluetooth

®

is a registered trademark owned by Bluetooth SIG, Inc., U.S.A. and licensed to Panasonic Corporation.

NVIDIA, the NVIDIA logo and Quadro are trademarks and/or registered trademarks of NVIDIA Corporation in the U.S. and/or other countries.

DisplayPort is a trademark owned by the Video Electronics Standards Association in the United States and other countries.

Names of products, brands, etc., appearing in this manual are trademarks or registered trademarks of their respective own companies.

n

On-screen Manual

For further information about the computer, you can refer to the on-screen manual.

l

Reference Manual

The Reference Manual contains the practical information to help you fully enjoy the computer’s performance.

l

Important Battery Tips

The Important Battery Tips will provide you with the battery information so that you can use the built-in battery in the optimum condition to obtain longer operation time.

To access the on-screen manuals, follow the steps below.

Double-touch [Manual Selector] on the desktop screen, and select the on-screen manual.

8

UT-MA6_USEN.indb 8 24/02/2014 16:28:03

Description of Parts

Front side

㪘 㪙 㪚

Left side

Camera

è

Reference Manual “Camera”

A: Camera Indicator

B: Camera Lens

C: Ambient Light Sensor

The ambient light sensor is equipped with an automatic brightness adjustment function that adjusts the display screen.

(è page 16)

D: Wireless LAN Antenna / Bluetooth Antenna

<Only for model with wireless LAN>

<Only for model with Bluetooth>

è

Reference Manual “Wireless LAN” “Bluetooth”

E: Wireless LAN Antenna

<Only for model with wireless LAN>

è

Reference Manual “Wireless LAN”

F: Windows Button

è

Reference Manual “Hardware Buttons”

G: Power Switch

H: Hardware Buttons

è

Reference Manual “Hardware Buttons”

I: LED Indicator

: Power Indicator

Off: Power off/Hibernation, Green: Power on,

Blinking green: Sleep

: Drive status

: SD Memory Card status

(Blinking: During access or a password is requested)

è

Reference Manual “SD Memory Card”

: Battery status

è

page 15 “When the battery indicator does not light on”

è

Reference Manual “Battery Power”

J: Security Hook

Pull out the security hook when passing through a security cable. Store the security hook during normal use.

(The insulation coating has been applied to the metal part.)

For further information, read the manual that comes with the cable.

9

24/02/2014 16:28:04 UT-MA6_USEN.indb 9

Description of Parts

Rear side

㪚 㪛

Right side

㪠 㪟

A: Ventilation Hole (Exhaust)

B: Ventilation Hole (Intake)

Rear Camera

<Only for model with Rear Camera>

è

Reference Manual “Camera”

C: Camera Indicator

D: Camera Lens

E: Smart Card Slot

<Only for model with Smart Card Slot>

è

Reference Manual “Smart Card”

F: Microphone

G: Speaker

H: Expansion Bus Connector

è

Reference Manual “Cradle”

I: Ventilation Hole (Intake) / Speaker

J: Reset Button (For servicing by Panasonic)

K: Headphone Jack

A headphone can be connected.

L: SD Memory Card Slot

<Only for model with SD memory card slot>

è

Reference Manual “SD Memory Card”

M: USB3.0 Port

è

Reference Manual “USB Devices”

N: DC-IN jack

O: Mini DisplayPort

è

Reference Manual “External Display”

P: LAN port

è

Reference Manual “LAN”

This computer contains a magnet and magnetic products at the locations circled in the illustration at right.

Avoid leaving metallic object or magnetic media in contact with these areas.

10

UT-MA6_USEN.indb 10 24/02/2014 16:28:05

First-time Operation

n

Preparation

A

Check and identify the supplied accessories.

If you do not find the described accessories, contact Panasonic Technical Support.

• AC Adaptor . . .1

• AC Cord . . . . 1 • Soft Cloth . . . 1

Model No: CF-AA5713A è

Reference Manual

“Screen Input Operation”

• OPERATING INSTRUCTIONS (This book) . . . . . . . . . . . . . . . . . . . 1

B

Read the LIMITED USE LICENSE AGREEMENT before breaking the seal on the computer’s packaging

(è page 26).

1

1 Connect your computer to a power outlet.

The battery charging starts automatically.

CAUTION

l

Do not disconnect the AC adaptor until the first-time operation procedure is completed.

l

When using the computer for the first time, do not connect any peripheral device except AC adaptor.

l

Handling the AC adaptor

Ÿ

Problems such as sudden voltage drops may arise during periods of thunder and lightning. Since this could adversely affect your computer, an uninterruptible power source (UPS) is highly recommended unless running from the built-in battery alone.

2 Turn on the computer.

Press and hold the power switch (è page 9) until the power indicator (è page 9) lights.

CAUTION

l

Do not press the power switch repeatedly or do not hold the power switch for four seconds or longer.

11

24/02/2014 16:28:06 UT-MA6_USEN.indb 11

First-time Operation

3 Select language.

CAUTION

l

Carefully choose your language because you cannot change it later. If you set a wrong language, you need to reinstall Windows.

A

Select language and touch [OK].

The language setting will start by touching [OK] on the confirmation screen.

The language and OS setting will be completed in about 15 minutes.

B

When termination screen is displayed, touch [OK] to turn off the computer.

4 Setup Windows.

Follow the on-screen instructions.

l

The computer restarts several times. Wait until the drive indicator has turned off.

l

After the computer is turned on, the screen remains black or unchanged for a while, but this is not a malfunction. Wait for a moment until the

Windows setup screen appears.

l

Setup of Windows will take approximately 20 minutes.

Go to the next step, confirming each message on the display.

l

Follow the steps below.

A

When “Enable sensors” is displayed, touch [Enable this sensor].

B

When the [User Account Control] screen is displayed, touch [Yes].

C

At the [Display Rotation Tool] confirmation screen, touch [Yes].

The computer restarts automatically, and the setting is enabled.

l

You can set the Wireless Network after the setup of Windows is complete.

CAUTION

l

You can change the user name, password, image and security setting after setup of Windows.

l

Remember your password. If you forget the password, you cannot use

Windows. Creating a password reset disk beforehand is recommended.

l

Do not use the following words for user name: CON, PRN, AUX, CLOCK$,

NUL, COM1 to COM9, LPT1 to LPT9, @, &, space. In particular, if you create a user name (account name) that includes the “@” mark, a password will be requested at the log-on screen, even if no password has been set.

If you try to log on without entering a password, “The user name or password is incorrect.” may be displayed and you will not be able to log on to

Windows (è page 24).

5 Create the recovery disc.

A recovery disc allows you to install OS and restore its factory default condition, in case, for example, the recovery partition of the flash memory is damaged. We recommend creating a recovery disc before you begin using the computer.

Refer to è Reference Manual “Recovery Disc Creation Utility” about creating the disc.

NOTE

l

You can create the recovery disk of the OS which is pre-installed at the time of purchase.

NOTE

l

PC Information Viewer

This computer periodically records the management information of the flash memory, etc. The maximum data volume for each record is 1024 bytes.

This information is only used for estimating the cause when the flash memory goes down by any possibility. They are never sent to outside via network nor used for any other purpose except for the purpose described the above.

To disable the function, add the check mark for [Disable the automatic save function for management information history] in [Hard Disk Status] of PC Information Viewer, and touch [OK].

Reference Manual “Checking the Computer’s Usage Status”) l

If the recovery partition is deleted, you cannot create Recovery Disc(s).

12

UT-MA6_USEN.indb 12 24/02/2014 16:28:07

n

Battery duration

Note that the computer consumes electricity even when the computer power is off. If the built-in battery is fully charged, the battery will fully discharge in the following period of time:

Status

In sleep

Discharge period

Approx. 4 days

(Approx. 3 days with Wake Up from wired LAN function activated)

In hibernation Approx. 49 days

(Approx. 7 days with Wake Up from wired LAN function activated)

When power is off Approx. 49 days

(Approx. 7 days with Power On by

LAN function activated)

The above table shows the battery duration while the USB port continuous charging function is not used.

The battery duration will slightly be longer if a LAN cable is not connected to the computer, even when Wake Up from wired LAN function is activated.

n

Before using wireless function

A

Touch the Wireless Switch Utility icon to show the pop-up menu.

B

Select ON for the device you want to enable.

n

To change the partition structure

You can shrink a part of an existing partition to create unallocated disk space, from which you can create a new partition. In the default setting, you can use a single partition.

A

Touch (Start) and long touch [Computer], then touch [Manage].

l

A standard user needs to enter an administrator password.

B

Touch [Disk Management].

C

Long touch the partition for Windows (“c” drive in the default setting), and touch [Shrink Volume...].

l

The partition size depends on the computer specifications.

D

Input the size in [Enter the amount of space to shrink in MB] and touch [Shrink].

l

You cannot input a larger number than the displayed size.

l

To select [Reinstall to the OS related partitions.] in installing OS (è page 19), 70 GB or more is necessary for [Total size after shrink in MB].

E

Long touch [Unallocated] (the shrunk space in the step D) and touch [New Simple Volume...].

F

Follow the on-screen instructions to make the settings, and touch [Finish].

Wait until formatting is completed.

NOTE

l

You can create an additional partition using remaining unallocated space or newly creating unallocated space.

l

To delete a partition, long touch the partition and touch [Delete Volume...] in the step C.

UT-MA6_USEN.indb 13

13

24/02/2014 16:28:07

Turning On / Turning Off

Turning On

Press and hold the power switch (è page 9) until the power indicator (è page 9) lights.

NOTE

l

Do not press the power switch repeatedly.

l

The computer will forcibly be turned off if you press and hold the power switch for four seconds or longer.

l

Once you turn off the computer, wait for ten seconds or more before you turn on the computer again.

l

Do not perform the following operation until the drive indicator turns off.

Ÿ

Connecting or disconnecting the AC adaptor

Ÿ

Pressing the power switch

Ÿ

Touching the screen or external mouse/keyboard

Turning Off

A

Shut down the computer.

Touch (Start) - [Shut down].

Precaution against Starting Up/Shutting Down

l

Do not do the following

Ÿ

Connecting or disconnecting the AC adaptor

Ÿ

Pressing the power switch

Ÿ

Touching the screen or external mouse/keyboard

NOTE

l

To conserve power, the following power saving methods are set at the time of purchase.

Ÿ

The screen automatically turns off after:

10 minutes (when AC adaptor is connected) of inactivity

5 minutes (when operating on battery power) of inactivity

Ÿ

The computer automatically enters sleep

*1

after:

20 minutes (when AC adaptor is connected) of inactivity

15 minutes (when operating on battery power) of inactivity

*1

Refer to Reference Manual “Sleep or Hibernation Functions” about resuming from sleep.

14

UT-MA6_USEN.indb 14 24/02/2014 16:28:08

Handling and Maintenance

Operation environment

l

Place the computer on a flat stable surface not subject to shock, vibration, and danger of dropping. Do not place the computer upright or turn it over. If the computer is exposed to an extremely strong impact, it may become damaged.

l

Operating environment

Temperature: Operation : 5

Storage : -20

Humidity: Operation : 30

Storage : 30

%

°C

°C

%

to 35

to 60

to 80

to 90

%

°C

°C

%

{41

{-4

°F

°F

to 95

to 140

°F

°F

}

}

RH (No condensation)

RH (No condensation)

Even within the above temperature/humidity ranges, operation for a long time in extreme environments, smoking nearby, or operation in places where oil is used or where there is a lot of dust will result in the product deterioration and will shorten the product life.

l

Do not place the computer in the following areas, otherwise the computer may be damaged.

Ÿ

Near electronic equipment. Image distortion or noise may occur.

Ÿ

In extremely high or low temperature.

l

As the computer can become hot during operation, keep it away from items that are sensitive to heat.

Handling cautions

This computer is designed to minimize shock to parts such as the LCD and the flash memory drive, but no warranty is provided against any trouble caused by shock. Be extremely careful when handling the computer.

l

When carrying the computer:

Ÿ

Turn off the computer.

Ÿ

Remove all external devices, cables, Smart Cards and other protruding objects.

Ÿ

Do not drop or hit the computer against solid objects.

Ÿ

Do not grip the display part.

l

When you board an airplane, take the computer with you and never put it in your checked luggage. When using the computer on airplane, follow the airline’s instructions.

l

Avoid any harmful substances such as oil from getting into the touchscreen. The pointer may not work correctly.

l

Be careful not to get injured by dropping or getting hit when carrying the computer.

n

When the battery indicator does not light on

The battery indicator may not light on even if the AC adaptor is correctly connected to the computer, due to the following reasons.

l

The AC adaptor’s protection function may be working. In this case, pull out the AC cord and wait for more than

1 minute before reconnecting the AC cord.

n

When using peripheral devices

Follow these instructions and the Reference Manual to avoid any damage to the devices. Carefully read the instruction manuals of the peripheral devices.

l

Use the peripheral devices conforming to the computer’s specifications.

l

Connect to the connectors in the correct direction.

l

If it is hard to insert, do not try forcibly but check the connector’s shape, direction, alignment of pins, etc.

l

If screws are included, fasten them securely.

l

Remove the cables when you carry the computer. Do not pull the cables forcibly.

n

Preventing your computer from unauthorized use via wireless LAN/Bluetooth

<Only for model with wireless LAN/Bluetooth> l

Before using wireless LAN/Bluetooth, make the appropriate security settings such as data encryption.

15

24/02/2014 16:28:08 UT-MA6_USEN.indb 15

Handling and Maintenance

n

Battery Recalibration

l

The battery recalibration may take a long time due to the large battery capacity. This is not a malfunction.

<When performing “Battery Recalibration” after shutting down Windows>

Ÿ

Full charge: Approximately 2.5 hours

Ÿ

Complete discharge: Approximately 2 hours

When performing “Battery Recalibration” without shutting down Windows, it may take more time to charge / discharge.

n

Sensors

This computer is equipped with four sensors (acceleration sensor, gyro sensor, magnetic sensor, ambient light sensor), and you can use these sensors with any software that is compatible.

As the accuracy of each sensor output is dependent on the operating environment and other conditions, the results should only be used as a reference.

The acceleration sensor, gyro sensor, and magnetic sensor are located at the bottom left of the LCD. The detection results of each sensor may vary depending on how you are holding the computer, the application software you are using, and other factors.

l

Automatic brightness adjustment

The computer is equipped with an automatic brightness adjustment function that adjusts the display screen based on the ambient light sensor. You can configure the automatic adjustment function as follows.

A

Touch (Start) - [Control Panel] - [Hardware and Sound] - [Power Options].

B

Touch [Change plan settings] for the power plan currently used.

C

Touch [Change advanced power settings] and double-touch [Display].

D

Double-touch [Enable adaptive brightness], make necessary settings, and touch [OK].

Set each item to ON, and the brightness of the screen display will adjust automatically.

The ambient light sensor is located at the top of LCD.

The ambient light cannot be detected properly if this area is obstructed or dirty.

l

Magnetic sensor

The magnetic sensor on the computer operates by detecting geomagnetism. Therefore, the magnetic sensor may not function properly and it readings may be inaccurate, especially in the following environments.

Ÿ

Inside or near steel structures such as buildings or bridges

Ÿ

Inside or near automobiles, or near train power lines

Ÿ

Near metallic furniture or appliances

Ÿ

When the AC adaptor or other peripheral devices are brought closer to the computer

Ÿ

Near magnets, speakers, or other objects with strong magnetic fields

The magnetic directions indicated by the magnetic sensor may not be accurate immediately after purchase or in environments with poor magnetic fields.

In such cases, turn on the computer and move it as follows.

A

Hold the computer so that its screen side is facing upward and level.

B

While keeping the computer level, rotate it 90 degrees or more clockwise.

C

Return the computer to position A, and rotate it 90 degrees or more counterclockwise.

D

Return the computer to position A.

E

Tilt the computer 90 degrees or more to the left so that the left side of the computer tilts down.

F

Return the computer to position A, and tilt it 90 degrees or more to the right so that the right side of the computer tilts down.

CAUTION

● Hold the computer firmly when moving it. Strong shocks from dropping the computer may result in damage.

Maintenance

If drops of water or other stains get on the surface of the LCD panel, wipe them off immediately. Failure to do so may result in staining.

To clean the LCD panel

Use the soft cloth included with the computer. (For further information, refer to “Suggestions About Cleaning the LCD

Surface” è Reference Manual “Screen Input Operation”.)

To clean areas other than the LCD panel

Wipe with a soft dry cloth such as gauze. When using detergent, dip a soft cloth in water-diluted detergent and wring it thoroughly.

16

CAUTION

l

Do not use benzene, thinner, or rubbing alcohol since it may adversely affect the surface causing discoloration, etc.

Do not use commercially-available household cleaners and cosmetics, as they may contain components harmful to the surface.

l

Do not apply water or detergent directly to the computer, since liquid may enter inside of the computer and cause malfunction or damage.

UT-MA6_USEN.indb 16 24/02/2014 16:28:08

Dispose of Computer

<For Europe and U.S.A./Canada>

Attention Customers

Don't remove the battery by yourself. The battery must be removed by qualified professionals.

When disposing of this product, be sure to contact qualified professionals to remove the battery.

Attention Qualified professionals to remove the battery

Dispose of this product correctly in accordance with the local regulations after removing the battery as shown in the following procedure. n

Preparation

l

Remove all peripherals (SD memory card, etc.).

l

Erase the stored data. (è Reference Manual “Erasing Flash Memory Data”)

CAUTION

l

Never disassemble the computer except before disposal.

l

Refer to “Safety Precautions and Regulatory Information” for precautions when disposing of the computer.

1. Turn off the computer completely. (è page 14) l

Do not use sleep/hibernation.

2. While connecting the AC adaptor, press both volume buttons ( ten seconds. cover with a thin pointed tool.

and not start up.

3. Turn over the computer, and peel off the seal (A) on the side of Interface

) at the same time for more than

The built-in battery’s power output stops.

l

Disconnect the AC adaptor, and press the power button for 1 second or longer and confirm the computer does

A

4. Remove the screws (3), and lift up Interface cover to remove.

5. Remove the silver screw.

UT-MA6_USEN.indb 17

17

24/02/2014 16:28:10

Handling and Maintenance

6. Remove the screws (10).

7. Unhook the claws on the upper part of the cover (A), and open the cover from the right side (B).

l

The left side of the cover is connected to the computer with the cord. Do not pull the cord.

8. Disconnect the connector (B).

Insulate the connectors on the built-in battery by covering them with plastic tape, for example.

9. Remove the screws (7) that secures the built-in battery (C), and remove the built-in battery (C).

B

C

18

UT-MA6_USEN.indb 18 24/02/2014 16:28:11

Installing Software

Installing software will return the computer to the default condition. When you install the software, the flash memory data will be erased.

Back up important data to other media or an external hard disk before installation.

CAUTION

l

Do not delete the Recovery Partition on the flash memory. The Recovery Partition is not available to store data.

To check the Recovery Partition, perform the following methods.

A

Touch (Start) and long touch [Computer], then touch [Manage].

• A standard user needs to enter an administrator password.

B

Touch [Disk Management].

NOTE

l

You can use the following buttons instead of the keyboard.

: ↓ key

: ↑ key

: Enter key

: F2 key (Default setting) l

Connect the AC adaptor and do not remove it until installation is complete.

n

Flash memory Recovery

You can reinstall the OS that was pre-installed at the time of purchase.

Preparation

l

Remove all peripherals.

1 Turn on the computer, and touch the top left corner of the screen several times while

[Panasonic] boot screen is displayed.

The Setup Utility starts up.

l

If the [Panasonic] boot screen is not displayed, turn on the computer while touching the top left corner of the screen.

l

If the password is requested, enter the Supervisor Password.

2 Write down all of the contents of the Setup Utility and touch [Exit] and double-touch

[Load Default Values].

At the confirmation message, touch [Yes].

3 Touch [Exit] and double-touch [Save Values and Reboot].

At the confirmation message, touch [Yes].

Computer will restart.

4 Touch the top left corner of the screen several times while [Panasonic] boot screen is displayed.

The Setup Utility starts up.

l

If the password is requested, enter the Supervisor Password.

5 Select the [Exit] menu, then double-touch [Recovery Partition].

6 Touch [Next].

7 Touch [Reinstall Windows.] and touch [Next].

The License Agreement screen appears.

8 Touch [Yes, I agree to the provisions above and wish to continue!] and touch [Next].

9 Touch [Next].

If the option is displayed, select the setting and touch [Next].

l

[Reinstall Windows to the whole Disk to factory default.]

Select this option when you want to install Windows to the factory default. After installation, you can create a new partition. For how to create a new partition, refer to “To change the partition structure” (è page 13).

l

[Reinstall to the OS related partitions.]

*1

Select this option when the flash memory has already been divided into several partitions. For how to create a new partition, refer to “To change the partition structure” (è page 13).

You can keep the partition structure.

*1

This does not appear if Windows cannot be installed to the recovery partition and the area usable by Windows.

19

24/02/2014 16:28:11 UT-MA6_USEN.indb 19

Installing Software

10 At the confirmation message, touch [YES].

11 Select language and touch [OK].

To cancel the recovery procedure, touch [CANCEL], and touch the mark that appears at the top right corner of the screen.

12 At the confirmation message, touch [OK].

Installation starts according to the instructions on the screen. (It will take approximately 15 minutes.) l

Do not interrupt installation, for example by turning off the computer or other operation.

Otherwise installation may become unavailable as Windows may not start up or the data may be corrupted.

13 When Ending process screen is displayed, touch [OK] to turn off the computer.

14 Turn on the computer.

l

If the password is requested, enter the Supervisor Password.

15 Perform the “First-time Operation”, starting from step 4, “Setup Windows”

(è page 12).

16 Start the Setup Utility and change the settings as necessary.

17 Perform Windows Update.

20

UT-MA6_USEN.indb 20 24/02/2014 16:28:11

n

Using Recovery Disc

Use the Recovery Disc in the following conditions.

Ÿ

You have forgotten the administrator password.

Ÿ

Installation is not complete. The recovery partition in the flash memory may be broken.

Preparation

l

Prepare the following items:

• Recovery Disc (è Reference Manual “Recovery Disc Creation Utility”)

• USB DVD drive (optional) (refer to recent catalogs and other sources for information about the products available) l

Remove all peripherals (except for the USB DVD drive).

1 Connect the DVD drive to the USB port.

2 Start the Setup Utility.

Turn on the computer, and touch top left of the screen while [Panasonic] boot screen is displayed.

l

If the [Panasonic] boot screen is not displayed, turn on the computer while touching top left of the screen.

l

If the password is requested, enter the Supervisor Password.

3 Write down all of the contents of the Setup Utility and touch [Exit] and double-touch

[Load Default Values].

At the confirmation message, touch [Yes].

4 Check the [UEFI Boot] setting of the Setup Utility.

When the recovery disc for Windows 7 is used: [Disabled]

5 Set the Recovery Disc into the DVD drive.

6 Touch [Exit] and double-touch [Save Values and Reboot].

At the confirmation message, touch [Yes].

The computer will restart.

7 Press (Rotation lock) button while [Panasonic] boot screen is displayed.

The Setup Utility starts up.

l

If the password is requested, enter the Supervisor Password.

8 Touch [Exit], then double-touch your DVD drive in [Boot Override].

The computer will restart.

9 Touch [Next].

10 Touch [Reinstall Windows.] and touch [Next].

11 At the License Agreement screen, touch [Yes, I agree to the provisions above and wish to continue!] and touch [Next].

12 Select the setting and touch [Next].

l

[Reinstall with HDD recovery partition.]

Standard recovery method.

You can use recovery from Recovery Partition.

l

[Reinstall without HDD recovery partition.]

Increase usable HDD size.

You can NOT use recovery from Recovery Partition.

When this option is selected, you can no longer create Recovery Disc(s) after the recovery operation.

CAUTION

l

Carefully choose above item because you cannot change it later.

13 Touch [Next].

14 At the confirmation message, touch [YES].

15 Select language and touch [OK].

To cancel the recovery procedure, touch [CANCEL], and touch the mark that appears at the top right corner of the screen.

16 At the confirmation message, touch [OK].

Installation starts according to the instructions on the screen. (It will take approximately 60 minutes.) l

Do not interrupt installation, for example by turning off the computer.

Otherwise installation may become unavailable as Windows may not start up or the data may be corrupted.

UT-MA6_USEN.indb 21

21

24/02/2014 16:28:12

Installing Software

17 When Ending process screen is displayed, remove the Recovery Disc and DVD Drive.

18 Touch [OK] to turn off the computer.

19 Turn on the computer.

l

If the password is requested, enter the Supervisor Password.

20 Perform the “First-time Operation”, starting from step 4, “Setup Windows”

(è page 12).

21 Start the Setup Utility and change the settings as necessary.

22 Perform Windows Update.

22

UT-MA6_USEN.indb 22 24/02/2014 16:28:12

Troubleshooting (Basic)

Follow the instructions below when a problem has occurred. There is also an advanced troubleshooting guide in the

“Reference Manual”. For a software problem, refer to the software’s instruction manual. If the problem persists, contact

Panasonic Technical Support. You can also check the computer’s status in the PC Information Viewer

Reference Manual “Troubleshooting (Advanced)”).

n

Starting Up

Cannot start up.

The power indicator or battery indicator is not lit.

You have forgotten the password.

“Remove disks or other media. Press any key to restart” or a similar message appears.

Windows startup and operation is slow.

l

Connect the AC adaptor.

l

Remove the AC adaptor, and then connect it again.

l

If a device is connected to the USB port, disconnect the device, or set [USB Port] or [Legacy USB Support] to [Disabled] in the [Advanced] menu of the Setup Utility.

l

Check the [UEFI Boot] setting of the Setup Utility. [UEFI Boot] should be set to [Disabled].

l

Supervisor Password or User Password: Contact Panasonic Technical Support.

l

Administrator password:

Ÿ

If you have a password reset disk, you can reset the administrator password. Set the disk and enter any wrong password, then follow the on-screen instructions and set a new password.

Ÿ

If you do not have a password reset disk, install (è page 19) and set up Windows, and then set a new password.

l

If a device is connected to the USB port, disconnect the device, or set [USB Port] or [Legacy USB Support] to [Disabled] in the [Advanced] menu of the Setup Utility.

l

If the problem persists after removing the disk, it may be a flash memory failure.

Contact Panasonic Technical Support.

l

Start the Setup Utility (è Reference Manual “Setup Utility”) to return the Setup

Utility settings (excluding the passwords) to the default values. Start the Setup Utility and make the settings again. (Note that the processing speed depends on the application software, so this procedure may not make Windows faster.) l

If you installed a resident software after purchase, turn off the residence.

The date and time are incorrect.

[Executing Battery Recalibration] screen appears.

[Enter Password] does not appear when resuming from sleep/hibernation.

Cannot resume.

l

Make the correct settings.

A

Open the Control Panel.

B

Touch [Clock, Language, and Region] - [Date and Time].

C

Touch [Change time zone…].

D

Select the time zone, then touch [OK].

E

Touch [Change date and time…], then set the date and time.

l

If the problem persists, the internal clock battery may need to be replaced. Contact

Panasonic Technical Support.

l

When the computer is connected to LAN, check the date and time of the server.

l

The 2100 A.D. or later year will not be correctly recognized on this computer.

l

The Battery Recalibration was canceled before Windows was shut down last time.

To start up Windows, turn off the computer by the power switch, and then turn on.

l

Select [Enabled] in [Password On Resume] in the [Security] menu of the Setup

Utility (è Reference Manual “Setup Utility”).

l

The Windows password can be used instead of the password set in the Setup Utility.

A

Open the Control Panel.

Touch (Start) - [Control Panel].

B

Touch [System and Security] - [Power Option] - [Require a password on wakeup] and add a check mark for [Require a password].

l

One of the following operations may have been carried out. Press the power switch to turn on the computer. Data not saved will be lost.

Ÿ

In sleep mode, the AC adaptor was disconnected, or a peripheral was connected or disconnected.

Ÿ

The power switch was pressed for four seconds or longer to forcibly turn off the computer.

l

An error may occur when the computer automatically enters the sleep or hibernation mode while the screensaver is active. In this case, turn off the screensaver or change the pattern of the screensaver.

23

24/02/2014 16:28:12 UT-MA6_USEN.indb 23

Troubleshooting (Basic)

n

Starting Up

Other startup problems.

l

Start the Setup Utility (è Reference Manual “Setup Utility”) to return the Setup

Utility settings (excluding the passwords) to the default values. Start the Setup Utility and make the settings again.

l

Remove all peripheral devices.

l

Check to see if there was a disk error.

A

Remove all peripheral devices including an external display.

B

Open “Computer”.

Touch (Start) - [Computer].

C

Long touch [Windows (C:)], and touch [Properties].

D

Touch [Tools] - [Check now...].

Ÿ

A standard user needs to enter an administrator password.

E

Select the option in [Check disk options] and touch [Start].

F

Touch [Schedule disk check] and restart the computer.

l

Connect the external keyboard and start the computer in Safe Mode, then check the error details. When the [Panasonic] boot screen disappears

*1

at startup, press and hold F8 until the Windows Advanced Options Menu is displayed. Select the

*1

Safe Mode and press Enter.

When [Password On Boot] is set to [Enabled] in the [Security] menu of the Setup

Utility, [Enter Password] appears after the [Panasonic] boot screen disappears. As soon as you enter the password and press Enter, press and hold F8.

n

Entering Password

Even after entering the password, password input screen is displayed again.

Cannot log on to Windows.

(“The user name or password is incorrect.” is displayed.)

<Only if the external keyboard is connected> l

The computer may be in ten-key mode.

Disable the ten-key mode, and then input.

l

The computer may be in Caps Lock mode.

Disable the Caps Lock mode, and then input.

l

The user name (account name) includes an “@” mark.

- If another user account name exists:

Log on to Windows using another user account name, and delete the account name that includes “@”. Then create a new account name.

- If no other account name exists:

You need to reinstall Windows (è page 19).

n

Shutting down

Windows does not shut down. l Remove the USB devices.

l

Wait one or two minutes. It is not a malfunction.

n

Display

No display.

l

The external display may be selected. Operate on the external display by using the external keyboard/mouse.

A

Right-click the desktop, and then click [Screen resolution].

B

Select the operating mode in [Multiple displays].

C

Click [Apply].

D

Click [Keep changes].

E

Click [OK].

l

When using an external display,

Ÿ

Check the cable connection.

Ÿ

Turn on the display.

Ÿ

Check the settings of external display.

l

The display is turned off by the power-saving function.

To resume, touch the screen.

l

The computer entered sleep or hibernation by the power-saving function. To resume, press the power switch.

24

UT-MA6_USEN.indb 24 24/02/2014 16:28:13

n

Display

The screen is dark.

The screen is disordered.

The external display does not work normally.

Cannot rotate the display.

l

The screen is darker when the AC adaptor is not connected. Open the Dashboard for Panasonic PC and adjust the brightness. As you increase the brightness, battery consumption increases.

You can separately set the brightness for when the AC adaptor is connected and when not connected.

l

Under factory default settings, the brightness of the display screen will adjust automatically based on the ambient light detected by the ambient light sensor. You can adjust the settings for this sensor (è page 16).

l

Changing the number of display colors and resolution may affect the screen. Restart the computer.

l

Connecting/disconnecting an external display may affect the screen. Restart the computer. l

If the external display does not support the power saving function, it may not work normally when the computer enters the power saving mode. Turn off the external display.

l

The application program currently running may not support the image rotation. Quit the program, and then try to rotate the image. This can ameliorate the status.

l

When the automatic rotation is off, screen display does not rotate automatically.

l

When an external display is connected to the computer and the computer is rotated while in the [Extend] mode:

The screen display on the external display does not rotate.

The screen display on the internal LCD remains landscape, and does not rotate.

n

Screen

The pointer does not work.

l

When using the external mouse, connect it correctly.

l

Restart the computer using the external keyboard/mouse. l

If the computer does not respond to external keyboard/mouse commands, read “No response” (è see below).

The touchscreen does not work properly.

l l

Make sure that the grounding of the AC plug is connected properly.

If a device that emits strong radio waves near this product, should be kept away.

l

When the computer enters Safe Mode, please operate it with an external mouse.

l

The problem may be improved by adjusting the sensitivity using the following application software.

A

Touch (Start) - [All Programs] - [ELAN] - [Touch Screen Control Panel].

Follow the instructions on the screen.

Want to disable touch operation.

l

Using the following application software disables touchscreen operation.

A

Touch (Start) - [All Programs] - [Panasonic] - [Touch Screen Switch Utility].

Follow the instructions on the screen.

n

On-screen Manual

“This page cannot be displayed”or

“Script Error” displayed.

l

Touch other page in on-screen manual.

l

Quit and restart the on-screen manual.

n

Others

No response.

l

Open Task Manager and close the software application that is not responding.

l

An input screen (e.g., password input screen at startup) may be hidden behind another window. Touch the application icons at the bottom of the screen to check. l

Press the power switch for four seconds or longer to shut down the computer, and then press the power switch to turn it on. If the application program does not work normally, uninstall and reinstall the program. To uninstall,

A

Open the Control Panel.

1. Touch (Start) - [Control Panel].

B

Touch [Programs] - [Uninstall a program].

l

When connecting a peripheral device to use with this computer for the first time, updating the driver may take a few minutes. Please wait it is completed.

l

By a strong radio waves noise from the outside, touchscreen may not work properly.

Ÿ

If a device that emits strong radio waves near this product, should be kept away.

Ÿ

Make sure that the grounding of the AC plug is connected properly.

Ÿ

If source of the radio waves cannot be kept away, please operate it with an external mouse.

Cannot connect to a network. l Set the device ([Wireless LAN] / [Bluetooth] of [Wireless Configuration]) to [Enabled] in the [Advanced] menu of the Setup Utility (Wireless Configuration).

25

UT-MA6_USEN.indb 25 24/02/2014 16:28:13

LIMITED USE LICENSE AGREEMENT

THE SOFTWARE PROGRAM(S) (“PROGRAMS”) FURNISHED WITH THIS PANASONIC PRODUCT (“PRODUCT”)

ARE LICENSED ONLY TO THE END-USER (“YOU”), AND MAY BE USED BY YOU ONLY IN ACCORDANCE WITH

THE LICENSE TERMS DESCRIBED BELOW. YOUR USE OF THE PROGRAMS SHALL BE CONCLUSIVELY

DEEMED TO CONSTITUTE YOUR ACCEPTANCE OF THE TERMS OF THIS LICENSE.

Panasonic Corporation has developed or otherwise obtained the Programs and hereby licenses their use to you. You assume sole responsibility for the selection of the Product (including the associated Programs) to achieve your intended results, and for the installation, use and results obtained therefrom.

LICENSE

A. Panasonic Corporation hereby grants you a personal, non-transferable and non-exclusive right and license to use the Programs in accordance with the terms and conditions stated in this Agreement. You acknowledge that you are receiving only a LIMITED LICENSE TO USE the Programs and related documentation and that you shall obtain no title, ownership nor any other rights in or to the Programs and related documentation nor in or to the algorithms, concepts, designs and ideas represented by or incorporated in the Programs and related documentation, all of which title, ownership and rights shall remain with Panasonic Corporation or its suppliers.

B. You may use the Programs only on the single Product which was accompanied by the Programs.

C. You and your employees and agents are required to protect the confidentiality of the Programs. You may not distribute or otherwise make the Programs or related documentation available to any third party, by time-sharing or otherwise, without the prior written consent of Panasonic Corporation.

D. You may not copy or reproduce, or permit to be copied or reproduced, the Programs or related documentation for any purpose, except that you may make one (1) copy of the Programs for backup purposes only in support of your use of the Programs on the single Product which was accompanied by the Programs. You shall not modify, or attempt to modify, the Programs.

E. You may transfer the Programs and license them to another party only in connection with your transfer of the single

Product which was accompanied by the Programs to such other party. At the time of such a transfer, you must also transfer all copies, whether in printed or machine readable form, of every Program, and the related documentation, to the same party or destroy any such copies not so transferred.

F. You may not remove any copyright, trademark or other notice or product identification from the Programs and you must reproduce and include any such notice or product identification on any copy of any Program.

YOU MAY NOT REVERSE ASSEMBLE, REVERSE COMPILE, OR MECHANICALLY OR ELECTRONICALLY TRACE

THE PROGRAMS, OR ANY COPY THEREOF, IN WHOLE OR IN PART.

YOU MAY NOT USE, COPY, MODIFY, ALTER, OR TRANSFER THE PROGRAMS OR ANY COPY THEREOF, IN

WHOLE OR IN PART, EXCEPT AS EXPRESSLY PROVIDED IN THE LICENSE.

IF YOU TRANSFER POSSESSION OF ANY COPY OF ANY PROGRAM TO ANOTHER PARTY, EXCEPT AS PER-

MITTED IN PARAGRAPH E ABOVE, YOUR LICENSE IS AUTOMATICALLY TERMINATED.

TERM

This license is effective only for so long as you own or lease the Product, unless earlier terminated. You may terminate this license at any time by destroying, at your expense, the Programs and related documentation together with all copies thereof in any form. This license will also terminate effective immediately upon occurrence of the conditions thereof set forth elsewhere in this Agreement, or if you fail to comply with any term or condition contained herein. Upon any such termination, you agree to destroy, at your expense, the Programs and related documentation together with all copies thereof in any form.

YOU ACKNOWLEDGE THAT YOU HAVE READ THIS AGREEMENT, UNDERSTAND IT AND AGREE TO BE BOUND

BY ITS TERMS AND CONDITIONS. YOU FURTHER AGREE THAT IT IS THE COMPLETE AND EXCLUSIVE STATE-

MENT OF THE AGREEMENT BETWEEN US, WHICH SUPERSEDES ANY PROPOSAL OR PRIOR AGREEMENT,

ORAL OR WRITTEN, AND ANY OTHER COMMUNICATIONS BETWEEN US, RELATING TO THE SUBJECT MAT-

TER OF THIS AGREEMENT.

26

UT-MA6_USEN.indb 26 24/02/2014 16:28:13

Contrat de licence d’usage limité

Le(s) logiciel(s) (les “Logiciels”) fournis avec ce produit Panasonic (le “Produit”) sont exclusivement concédés en licence à l’utilisateur ultime (“vous”), et ils ne peuvent être utilisés que conformément aux clauses contractuelles cidessous. En utilisant les logiciels, vous vous engagez de manière définitive à respecter les termes, clauses et conditions des présentes.

Panasonic Corporation a mis au point ou obtenu les Logiciels et vous en concède l’utilisation par les présentes. Vous assumez l’entière responsabilité du choix de ce Produit (y compris des Logiciels associés) pour obtenir les résultats escomptés, ainsi que de l’installation, de l’utilisation et des résultats obtenus.

Licence

A. Panasonic Corporation vous octroie par les présentes le droit et la licence personnels, non cessibles et non exclusifs d’utiliser les Logiciels conformément aux termes, clauses et conditions de ce contrat. Vous reconnaissez ne recevoir qu’un droit limité d’utiliser les Logiciels et la documentation les accompagnant et vous vous engagez à n’obtenir aucun droit de titre, propriété ni aucun autre droit vis-à-vis des Logiciels et de la documentation les accompagnant ni vis-à-vis des algorithmes, concepts, dessins, configurations et idées représentés par ou incorporés dans les Logiciels et la documentation les accompagnant, dont les titres, propriété et droits resteront tous à

Panasonic Corporation ou à leurs propriétaires.

B. Vous ne pouvez utiliser les Logiciels que sur le Produit unique qui est accompagné par les Logiciels.

C. Vous et vos employés ou agents êtes requis de protéger la confidentialité des Logiciels. Vous ne pouvez ni distribuer ni mettre les Logiciels et la documentation les accompagnant à la disposition d’un tiers, par partage de temps ou de quelque autre manière que ce soit, sans l’autorisation écrite préalable de Panasonic Corporation.

D. Vous ne pouvez ni copier ni reproduire ni permettre la copie ni la reproduction des Logiciels ni de la documentation les accompagnant pour quelque fin que ce soit, à l’exception d’une (1) copie des Logiciels à des fins de sauvegarde uniquement pour soutenir votre utilisation des Logiciels sur le Produit unique qui est accompagné par les

Logiciels. Vous ne pouvez ni modifier ni tenter de modifier les Logiciels.

E. Vous ne pouvez céder les Logiciels et en octroyer la licence à une autre partie qu’en rapport avec votre cession du

Produit unique qui est accompagné par les Logiciels à cette autre partie. Au moment de cette cession, vous devez céder également toutes les copies, que ce soit sous forme imprimée ou lisible par la machine, de tous les Logiciels ainsi que de la documentation les accompagnant, à la même partie ou détruire les copies non cédées.

F. Vous ne pouvez retirer aucune marque de droits d’auteur, marque de commerce ou autre ni aucune identification de produit des Logiciels et vous devez reproduire et inclure toutes ces notices ou identifications de produit sur toutes les copies des Logiciels.

Vous ne pouvez assembler en sens inverse, compiler en sens inverse ni retracer les Logiciels ni aucune de leurs copies, de façon électronique ou mécanique, en tout ou en partie.

Vous ne pouvez utiliser, copier, modifier, altérer ni céder les Logiciels ni aucune de leurs copies, en tout ou en partie, à l’exception de ce qui est expressément stipulé dans ce contrat.

Si vous cédez la possession de toute copie ou de tout Logiciel à une autre partie, à l’exception de ce qui est autorisé au paragraphe E ci-dessus, votre licence est automatiquement résiliée.

Termes, clauses et conditions

Cette licence n’est effective que pour la durée de possession ou de crédit-bail du Produit, à moins d’une résiliation antérieure. Vous pouvez résilier cette licence à tout moment en détruisant, à vos frais, les Logiciels et la documentation les accompagnant avec toutes leurs copies, sous quelque forme que ce soit. Cette licence sera également résiliée, avec application immédiate, si les conditions de résiliation définies ailleurs dans ce contrat se sont réalisées ou si vous ne respectez pas les termes, clauses et conditions qui y sont contenues. Au moment de la résiliation, vous acceptez de détruire, à vos frais, les Logiciels et la documentation les accompagnant avec toutes leurs copies, sous quelque forme que ce soit.

Vous reconnaissez avoir lu ce contrat, en avoir compris toute la substance et avoir accepté de respecter ses termes, clauses et conditions. Vous reconnaissez en outre qu’ils sont la description complète et exclusive du contrat conclu entre nous, contrat qui remplace et annule toute proposition ou contrat précédent, écrit ou oral, et toute autre communication entre nous, relativement à l’objet du présent contrat.

27

24/02/2014 16:28:13 UT-MA6_USEN.indb 27

Specifications

This page provides the specifications for the basic model.

The model number is different according to the unit configuration.

l

To check the model number:

Check the bottom of the computer or the box the computer came in at the time of purchase.

l

To check CPU speed, memory size and the flash memory drive size:

Run the Setup Utility (è Reference Manual “Setup Utility”) and select [Information] menu.

[Processor Speed]: CPU speed, [Memory Size]: Memory size, [Hard Disk]: Flash Memory drive size n

Main Specifications

Model No.

CPU

Chipset

Video controller

Memory

*1

Video Memory

*1*2

Storage

*3

Display Method

Internal LCD

External Display

*4

Wireless LAN

LAN

Bluetooth

*7

Sound

Security Chip

Camera

Sensor

Card Slot

DisplayPort™

*5

HDMI

*6

Speaker

Microphone

Front

Rear

Ambient light sensor

Magnetic sensor

Gyro sensor

Acceleration sensor

Smart Card

*9

SD Memory

Card

*10

Equipped x 1 x 1

UT-MA6027HMM

Intel

®

Core™ i7-3687U vPro™ Processor (4 MB

*1

cache, up to 3.30 GHz) with Intel

®

Turbo

Boost Technology

Mobile Intel

®

QM77 Express Chip set

NVIDIA

®

Quadro

®

K1000M

16

GB

2

GB

dedicated VRAM

Flash memory drive: 256

GB

Approx. 25

GB this partition.)

Approx. 1

GB

is used as a partition with flash memory recovery tools. (Users cannot use

is used as a partition with system tools. (Users cannot use this partition.)

20” IPSα, 230ppi, Aspect ratio 15:10

16,777,216 colors (3840 × 2560 dots)

16,777,216 colors (3840 × 2160 dots Max.)

16,777,216 colors (1920 × 1200 dots Max.)

Intel

®

Centrino

®

Advanced-N 6235 (a/b/g/n) (è page 29)

IEEE 802.3 10Base-T/IEEE 802.3u 100Base-TX/IEEE 802.3ab 1000Base-T

è

page 29

WAVE and MIDI playback, Intel

®

High Definition Audio subsystem support, Stereo speaker

Internal mic for camera

TPM (TCG V1.2 compliant)

*8

1280 × 720 dots, 30 fps (Video)

1280 × 720 dots, 30 fps (Video) / 2592 × 1944 dots (Still)

Interface

Pointing Device

Power Supply

AC Adaptor *12

Internal Battery

Operating Time *13

Charging Time

*14

Power on

Power off

Power Consumption *15

USB port 3.0 x 1

*11

, LAN port (RJ-45), Mini DisplayPort™, Expansion Bus Connector,

Headphone (Miniature jack, 3.5 DIA / Impedance 32 Ω, Output Power 4 mW × 2, Stereo)

Capacitive Multi touch screen (up to 10 touch) / Electronic Touch Pen (optional)

AC adaptor or internal battery

Input: 100

V

to 240

V

AC, 50

Hz

/60

Hz

, Output: 15.6

V

DC, 7.05

A

Li-ion 11.1

V

, 4770 mAh

(typ.), 4590 mAh

(min.) (Not replaceable by user)

Approx. 2.5 hours

Approx. 4.0 hours

Approx. 2.5 hours

Approx. 65

W *16

/ Approx. 105

W

28

UT-MA6_USEN.indb 28 24/02/2014 16:28:14

n

Main Specifications

Model No.

Physical Dimensions (W × D × H)

Weight

UT-MA6027HMM

475 mm

× 334 mm

× 12.5 mm

{18.7 ” × 13.1 ” × 0.49 ”} (without protruding parts)

Approx. 2.54 kg

{5.60 lb.}

Operating Temperature

5

°C

to 35

°C

{41

°F to 95

°F

}

Environment

Storage

Humidity 30

%

to 80

%

RH (No condensation)

Temperature

-20

°C

to 60

°C

{-4

°F to 140

°F

}

Humidity 30

%

to 90

%

RH (No condensation) n

Software

Base OS

Installed OS

*18

Pre-installed Software

*18

Windows

Windows

®

®

8.1 Pro 64-bit

*17

7 Professional 64-bit Service Pack 1

*19

PC Information Viewer, Battery Recalibration Utility, Hand Writing Utility, Infineon

TPM Professional Package

*8 *20

, Dashboard for Panasonic PC, Recovery Disc

Creation Utility, Power Plan Extension Utility, Camera Utility, Manual Selector,

Wireless Switch Utility, Intel

®

PROSet/Wireless Software, Bluetooth Stack for

Windows by Toshiba, Touch Screen Control Panel, Touch Screen Switch Utility

Aptio Setup Utility

*21

, PC-Diagnostic Utility, Hard Disk Data Erase Utility

*22 n

Wireless LAN

Data Transfer Rates

Standards Supported

Transmission method

Wireless Channels Used

RF Frequency Band

IEEE802.11a: 54/48/36/24/18/12/9/6 Mbps (automatically switched)

*23

IEEE802.11b: 11/5.5/2/1 Mbps (automatically switched)

*23

IEEE802.11g: 54/48/36/24/18/12/9/6 Mbps (automatically switched)

*23

IEEE802.11n

*24

(HT20) GI

*25

:

= 400ns: 150/130/115/86/72/65/57/43/28/21/14/7 Mbps

(automatically switched)

*23

GI

*25

(HT40) GI

*25

= 800ns: 130/117/104/78/65/58/52/39/26/19/13/6 Mbps

(automatically switched)

*23

= 400ns: 300/270/240/180/150/135/120/90/60/45/30/15 Mbps (automatically switched)

*23

GI

*25

= 800ns: 270/243/216/162/135/121/108/81/54/40/27/13 Mbps (automatically switched)

*23

IEEE802.11a / IEEE802.11b / IEEE802.11g / IEEE802.11n

OFDM system, DSSS system

IEEE802.11a : Channels 36/40/44/48/52/56/60/64/100/104/108/112/116/120/

124/128/132/136/140/149/153/157/161/165

IEEE802.11b / IEEE802.11g : Channels 1 to 11

IEEE802.11n : Channels 1-11/36/40/44/48/52/56/60/64/100/104/108/112/116/

120/124/128/132/136/140/149/153/157/161/165

IEEE802.11a : 5.18 GHz - 5.32 GHz, 5.5 GHz - 5.7 GHz, 5.745 GHz - 5.825 GHz

IEEE802.11b / IEEE802.11g : 2.412 GHz - 2.462 GHz

IEEE802.11n : 2.412 GHz - 2.462 GHz, 5.18 GHz - 5.32 GHz, 5.5 GHz - 5.7 GHz,

5.745 GHz - 5.825 GHz n

Bluetooth

*7

Bluetooth Version

Transmission method

Wireless Channels Used

RF Frequency Band

4.0

Classic mode / Low Energy mode

FHSS system

Channels 1 to 79 / Channels 0 to 39

2.402 GHz - 2.480 GHz

UT-MA6_USEN.indb 29

29

24/02/2014 16:28:14

Specifications

*1

*3

*4

*10

1

MB

MB

= 1,048,576 bytes/1

= 1,000,000 bytes/1

GB

GB

= 1,073,741,824 bytes

*2

A segment of the main memory is allotted automatically depending on the computer’s operating status. The size of the Video

Memory cannot be set by the user.

= 1,000,000,000 bytes. Your operating system or some application software will report as fewer

The unit for North America (identified by the suffix ‘M’ on the model number) is supplied with a 125

2

*13

Measured at LCD brightness: 60

Varies depending on the usage conditions, or when an optional device is attached.

*14

*15

Varies depending on the usage conditions.

Approx. 0.5

Even when the AC adaptor is not connected to the computer, power is consumed (Max. 0.3

*16 plugged into an AC outlet.

Rated power consumption

23-E-1

*17

Contact Panasonic Technical Support about upgrading the OS.

GB

Selectable resolution depends on the specifications of the external display. Display may be impossible using some connected

*5 external displays.

Use the DisplayPort cable with a ferrite core.

*6

Only when connected to Cradle (optional).

The Duplicate mode is not available. DRM(Digital Rights Management) contents are not available through HDMI connector of

Cradle.

*7

Does not guarantee operation of all Bluetooth peripherals.

*8

Only for model with TPM.

For information on TPM, Double-touch [Manual Selector] on the desktop, and select “Installation Manual for Trusted Platform

Module (TPM)”.

*9

Only for model with Smart Card slot.

Operation has been tested and confirmed using Panasonic SD Memory Card with a capacity of up to 2

Memory Card with a capacity of up to 32

GB

, and Panasonic SDXC Memory Card with a capacity of up to 64

Operation on other SD equipment is not guaranteed.

*11

Does not guarantee operation of all USB-compatible peripherals.

*12

The AC adaptor is compatible with power sources up to 240

W cd/m

V

AC adaptor.

when the battery is fully charged (or not being charged) and the computer is OFF.

W

V

GB

, Panasonic SDHC

GB

.

AC compatible AC cord.

.

20-M-1-1

) simply by having the AC adaptor

*18

Operations of this computer are not guaranteed except for the pre-installed OS and the OS which is installed by using the flash

*19 memory recovery and the recovery disc.

This system is preinstalled with Windows 7 Professional software and also comes with a license for Windows 8.1 Pro software.

You may only use one version of the Windows software at a time. Switching between versions will require you to uninstall one version and install the other version.

*20

Must be installed before use.

*21

In this manual, the “Aptio Setup Utility” is referred to as “Setup Utility”.

*22

Perform on the recovery disc. Alternatively perform on the flash memory recovery.

*23

It does not correspond to IEEE802.11a+b+g+n standards.

*24

Actual speeds may differ.

Available when set to “WPA-PSK”, “WPA2-PSK” or “none”.

*25

Only available when HT40 enabled by the computer and access point which associated supports HT40.

30

UT-MA6_USEN.indb 30 24/02/2014 16:28:14

LIMITED WARRANTY

For U.S.A.

Panasonic System Communications Company of North America (PSCNA)

Computer Products - Worldwide Warranties

Section 1: Limited Warranty - Hardware

PSCNA, referred hereafter as “Panasonic” will repair the products listed below with new or rebuilt parts, free of charge in a Global

Panasonic designated service location for the period specified below from the date of original purchase in the event of a defect in materials or workmanship. These warranties are extended solely to the original purchaser. A purchase receipt or other proof of date of original purchase will be required before warranty performance is rendered.

• Laptop PC (CF-##) – 3 Years

• Tablet PC (FZ-##) – 3 Years

• Ultra-Mobile (CF-U#/CF-H# Series) – 3 Years

• PDRC - LCD & Keyboard Assembly – 3 Years

Battery Warranty

Batteries supplied with the product are covered under the warranty for one (1) year from date of purchase, except as excluded in Section 3. Batteries purchased separately are covered under the warranty for one (1) year from the date of purchase. A replacement battery furnished under the product warranty is covered for the remaining period of the one year warranty on the original or purchased battery.

Optional: Panasonic “Protection Plus” Warranty

Any unit for which the Panasonic “Protection Plus” warranty has been purchased will receive additional coverage for any failure that occurs due to accidental damage. All other terms and conditions of the standard warranty apply and this additional coverage will exist for the duration of the standard warranty period of the unit. If an extended Protection Plus warranty program is purchased, coverage is extended to the end of the last year of extended coverage purchased.

This warranty does not cover failures or defects that are caused by fire, intentional acts, loss, theft, improper maintenance, modification or service by anyone other than the Panasonic National Service Center or a Panasonic Authorized Service Provider, or damage that is attributable to acts of God. Cosmetic damage that does not affect functionality is not covered. Cosmetic damage on units with hardware failures will be repaired in accordance with the warranty terms. This warranty is extended solely to the original purchaser on the unit serial number for which it was purchased. Complete unit replacement fulfills the full obligation and is at the discretion of Panasonic and is limited to once during the coverage term. Maximum benefit is limited to one replacement per coverage year of the Motherboard, LCD, Storage Drive, and Keyboard.

Wireless Module Warranty

Panasonic approved wireless modems installed in Panasonic brand computers and integrated by Panasonic or an Authorized

Panasonic Wireless Integrator are covered under the warranty for the remaining warranty period of the device in which the modem is installed. For devices with less than three (3) months remaining on the unit warranty, the wireless modem will be covered for a period of three (3) months from the date of installation of the modem, covering only modem replacement or modem installation related issues.

All modems must be approved by the wireless carrier prior to use. Any use or attempted use of a wireless modem not approved and activated by the carrier for use on their network is strictly prohibited and is not sanctioned or warranted by Panasonic and may result in legal action. In addition, all modems must be approved by Panasonic as compatible with the device hardware before installation or use.

Panasonic’s sole responsibility for the warranty or technical support of the software required to install or operate the modem is defined in Section 2 (Limited Software Warranty). Any attempted software installation by anyone other than a Panasonic Authorized

Wireless Integrator is not covered under warranty and may result in service charges to re-image or replace the hard drive.

Installation or attempted installation by any party other than Panasonic or an Authorized Panasonic Wireless Integrator is strictly not covered under the warranty and may void the computer warranty if damage results.

Options and Accessories Warranties

The below listed Panasonic brand or supplied options and accessories are covered under this limited warranty for the period specified from the date of purchase or as specifically stated:

• AC Adaptor / Power Cord – 3 Years

• Memory Expansion Card (Panasonic Brand) – 3 Years

• Car Mount - Docking Station PCB or Vehicle Docking Station – 3 Years

• Desktop Port Replicator, I-O Box, Docking Cradle (like CF-U1) – 3 Years

• Antenna Pass-through Cable – 3 Years

• Backlit or Full-sized keyboard - 3 Years or assumes warranty of the unit in which it is installed

• Integrated Panasonic supplied options and kits including, but not limited to Wireless Modems, Media Bay Drives (Floppy,

CD, DVD, Combo), Camera, GPS, Bluetooth, Smartcard Reader, Magnetic Card Reader, Barcode Scanner, and Fingerprint

Reader - 3 Years or assumes warranty period of the unit in which it is installed provided the integration was performed by

Panasonic or an Authorized Integrator.

• Hard Drive / Solid State Drive (Internal) - 3 Years

• Separately purchased 2nd Hard Drive – 1 Year

• External USB Drives (CD / DVD / Floppy / Hard Drive) – 1 Year

• Optional Battery – 1 Year

• Battery Charger / Multi-Bay Battery Charger – 1 Year

• Stylus Pens, Digitizer & Standard - 90 Days (physical damage excluded)

UT-MA6_USEN.indb 31

31

24/02/2014 16:28:15

LIMITED WARRANTY

Section 2 - Limited Warranty - Software

Panasonic warrants to you only that the disk(s) or other media on which the Programs are furnished will be free from defects in material and workmanship under normal use for a period of sixty (60) days from the date of delivery thereof to you, as evidenced by your purchase receipt.

This is the only warranty Panasonic makes to you. Panasonic does not warrant that the functions contained in the Programs will meet your requirements or that the operation of the Programs will be uninterrupted or error free. Panasonic shall have no obligation for any defects in the disk(s) or other media on which the Programs are furnished resulting from your storage thereof, or for defects that have been caused by operation of the disk(s) or other media

Panasonic’s entire liability and your exclusive remedy under this warranty shall be limited to the replacement, in the United States or other Panasonic designated location, of any defective disk or other media which is returned to Panasonic’s Authorized Service

Center, together with a copy of the purchase receipt, within the aforesaid warranty period.

Section 3 - Limited Warranty Exclusions - Specifically excluded from the warranty are:

• All consumable items; such as screen protection films, logo badges, labels, cleaning cloths, carry cases, manuals, cables, straps, belts, holsters, tethers, and harnesses and any other options and accessories not listed above or covered under a separate warranty.

• Failures related to the product operating system, hard drive or solid state drive image, software setup, software program, virus, other program(s) or file(s) on any drive or in any computer memory location.

• Failures due to BIOS settings or changes, as well as any cosmetic or physical damage to the unit.

• Any unit or device with a missing or altered model number or serial number label

• Cosmetic damage or any damage which occurs in shipment

• Failures which are caused by products not supplied by Panasonic

• Failures which result from alteration, accident, misuse, introduction of liquid or other foreign matter into the unit, abuse, neglect, installation, maladjustment of consumer controls, improper maintenance or modification, use not in accordance with product use instructions

• Failures due to service by anyone other than a Panasonic Authorized Service Provider

• Failures caused by improper installation of options or accessories or due to integration by any company other than Panasonic or a Panasonic Authorized Integrator

• Damage, failure, or loss due to the unit being stolen, lost, misplaced, or used by anyone other than the original purchaser

• Damage that is attributable to acts of God

This limited warranty only covers failures due to defects in materials or workmanship which occur during normal use. If a unit is sent to a Panasonic Authorized Service Center and no hardware failure is found, the customer will be billed for labor to correct a software issue or reimage the hard drive plus shipping and applicable administrative fees at the current rates set by the service provider.

THIS PRODUCT IS NOT INTENDED FOR USE AS OR PART OF NUCLEAR EQUIPMENT/SYSTEMS, AIR TRAFFIC CONTROL

EQUIPMENT/SYSTEMS, OR AIRCRAFT COCKPIT EQUIPMENT/SYSTEMS

*

1

*1

. PANASONIC WILL NOT BE RESPONSIBLE FOR

ANY LIABILITY RESULTING FROM THE USE OF THIS PRODUCT ARISING OUT OF THE FOREGOING USES.

AIRCRAFT COCKPIT EQUIPMENT/SYSTEMS include class 2 Electronic Flight Bag (EFB) Systems and Class 1 EFB Systems when used during critical phases of flight (e.g., during take-off and landing) and/or mounted onto the aircraft. Class 1 EFB

Systems and 2 EFB Systems are defined by FAA: AC (Advisory Circular) 120-76A or JAA: JAA TGL (Temporary Guidance

Leaflets) No. 36.

Other Limits and Exclusions: There are no other express warranties except as listed above.

PANASONIC SHALL NOT BE LIABLE FOR LOSS OF DATA OR OTHER INCIDENTAL OR CONSEQUENTIAL DAMAGES

RESULTING FROM THE USE OF THIS PRODUCT, OR ARISING OUT OF ANY BREACH OF THIS WARRANTY. ALL EXPRESS

AND IMPLIED WARRANTIES, INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR

PURPOSE ARE LIMITED TO THE APPLICABLE WARRANTY PERIOD SET FORTH ABOVE. Some states do not allow the exclusion or limitation of incidental or consequential damages, or limitations on how long an implied warranty lasts, so the above limitations or exclusions may not apply to you.

This limited warranty gives you specific legal rights, and you may also have other rights which vary from state to state.

For technical support or to arrange for service on your Panasonic computer product, call our toll-free hotline at 1-855-PSC-TECH

(855-772-8324).

DIAL TOLL FREE: 1-855-PSC-TECH (855-772-8324)

Web Site : www.panasonic.com/toughbook

32

UT-MA6_USEN.indb 32 24/02/2014 16:28:15

LIMITED WARRANTY (GARANTIE LIMITÉE)

For Canada

PANASONIC COMPUTER AND PERIPHERALS LIMITED WARRANTY

Coverage – Panasonic Canada Inc. (“PCI”) warrants to you, the first end user customer, this computer product (excluding software media), when purchased from PCI or from a PCI authorized reseller, to be free from defects in materials and workmanship under normal use, subject to the terms set forth below, during the period of warranty coverage specified.

Scope of Coverage

Laptop Computers (except Battery) and AC Adaptor

• Factory/PCI installed options including Wireless WAN, GPS,

Bluetooth, Finger print reader, Backlit keyboard, Memory

Card and Media Bay Drives (Floppy, CD/DVD)

Mobile Wireless Display

• PDRC – LCD and Keyboard Assemblies

Port Replicator

Hand-held Computers

• Battery

Battery charger

• Auto Adaptor

External USB Drives

Digitizer pen or stylus

Period of Coverage

Three (3) Years from Date of

Original End User Customer

Purchase

One (1) Year from Date of

Original End User Customer

Purchase

All consumable items including protection film, cleaning cloth, carry case, tether and harness

Ninety (90) Days from Date of

Original End User Customer

Purchase

No Coverage

Type of Failure Coverage

Defective Materials or Workmanship

Defective Materials or Workmanship

Defective Materials or Workmanship nature of the defect claimed, at 1-800-668-8386 between 9:00 A.M. and 5:00 P.M., Eastern Time Zone, Mon. – Fri. (excluding holidays) for instructions on how to obtain service. A purchase receipt or other proof of date of original purchase is required before warranty service is performed. Defective parts covered by this Limited Warranty will be repaired or replaced with new or comparable rebuilt parts on an exchange basis. Warranty replacement or repair is subject to the terms of this Limited Warranty for the balance of the original period of warranty coverage.

No Coverage – This Limited Warranty does not cover products purchased outside Canada. Neither does it cover damage to, failure of, or defects in a product or accessory through mishandling, improper installation, abnormal use, misuse, neglect, accident, introduction of liquid or other foreign matter into the product, alteration or servicing by anyone not authorized by PCI, or act of God.

THIS PRODUCT IS NOT INTENDED FOR USE AS, OR AS PART OF, NUCLEAR EQUIPMENT/SYSTEMS, AIR TRAFFIC CON-

TROL EQUIPMENT/SYSTEMS, OR AIRCRAFT COCKPIT EQUIPMENT/SYSTEMS . PANASONIC WILL NOT BE RESPONSIBLE

FOR ANY LIABILITY RESULTING FROM THE USE OF THIS PRODUCT ARISING OUT OF THE FOREGOING USES.

*2

AIRCRAFT COCKPIT EQUIPMENT/SYSTEMS include Class2 Electrical Flight Bag (EFB) Systems and Class1 EFB Systems when used during critical phases of flight (e.g., during take-off and landing) and/or mounted on to the aircraft. Class1 EFB Systems and 2 EFB Systems are defined by FAA: AC (Advisory Circular) 120-76A or JAA: JAA TGL (Temporary Guidance Leaflets)

No.36

IF YOU SHIP THE PRODUCT FOR WARRANTY SERVICE

Carefully pack the product, preferably in the original carton. Include details of defect claimed and proof of date of original purchase. No liability is assumed for loss or damage to the product while in transit, if you chose your own transportation carrier.

SOFTWARE MEDIA LIMITED WARRANTY

supplied will be free from defects in materials and workmanship under normal use in Canada for a period of sixty (60) days from date of receipt as evidenced by your purchase receipt for your Panasonic Computer product.

THIS IS THE ONLY WARRANTY THAT PCI MAKES RESPECTING THE SOFTWARE MEDIA. PCI does not warrant the software.

Please refer to the software licensor’s written warranty (accompanying the copy of the software) for any software warranty claim.

Claim Procedure – In the event of a defect in material or workmanship in the media during the sixty (60) day warranty period, and you return it, transportation costs prepaid, to Panasonic Canada Inc., Computer Products Marketing, 5770 Ambler Drive, Mississauga, Ontario L4W 2T3, within the warranty period, together with a copy of your purchase receipt, and an explanation of the suspected defect, PCI will replace in Canada the defective disk(s) or other media.

Remedy – PCI’s entire liability, and your only remedy for any breach of this software media warranty is limited to replacement of the media only. It does not cover any other damages, including, but not limited to, loss of use or profit loss, or special, indirect or consequential damages, or other claims, whether or not of similar character.

No Coverage – This limited warranty does not apply if the disk(s) or other media has been used in other than a Panasonic product, or in environmental conditions other than those specified by PCI or the manufacturer, or if subjected to misuse, neglect, mishandling, modification or attempted modification of the program, or if damaged by accident or act of God. PCI is not responsible for damage to or loss of any program, data or removable storage media.

GENERAL

NO OTHER WARRANTIES – PCI DISCLAIMS ALL OTHER WARRANTIES, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT

NOT LIMITED TO, IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, WITH RE-

SPECT TO THE SOFTWARE, SOFTWARE MEDIA, COMPUTER PRODUCT, OPTIONS AND ACCESSORIES.

NO LIABILITY FOR CONSEQUENTIAL DAMAGES – IN NO EVENT SHALL PCI BE LIABLE FOR ANY SPECIAL, INDIRECT OR

CONSEQUENTIAL DAMAGES ARISING FROM ANY BREACH OF THE LIMITED WARRANTIES SET OUT IN THIS DOCUMENT,

OR FROM THE USE OF THE COMPUTER PRODUCT, INCLUDING, WITHOUT LIMITATION, LOSS OF DATA, BUSINESS, PROF-

IT OR GOODWILL.

IN ANY EVENT, PCI’S MAXIMUM LIABILITY FOR ANY BREACH SHALL NOT EXCEED THE AMOUNT ACTUALLY PAID BY YOU

FOR THE COMPUTER PRODUCT.

NO ACTION, REGARDLESS OF ITS BASIS, MAY BE BEGUN AGAINST PCI MORE THAN TWO (2) YEARS AFTER THE CAUSE

OF ACTION AROSE.

Statutory Warranties – Some jurisdictions do not allow these limitations or exclusions, so they may not apply to you.

33

UT-MA6_USEN.indb 33 24/02/2014 16:28:15

LIMITED WARRANTY (GARANTIE LIMITÉE)

Pour le Canada

GARANTIE LIMITÉE – ORDINATEURS ET PÉRIPHÉRIQUES PANASONIC

logiciels) est, au moment de sa vente par PCI ou d’un revendeur agréé par PCI, exempt de défauts de pièces et de fabrication dans les conditions normales d’utilisation, et ce, pendant la période de couverture de la garantie, sous réserve des modalités décrites ci-dessous.

Éléments couverts

• Ordinateurs blocs-notes (sauf batteries) et adaptateur secteur

Options installées en usine/par PCI incluant : WAN sans fil,

GPS, Bluetooth, lecteur d’empreintes digitales, clavier rétroéclairé, carte mémoire et lecteurs (disquettes, CD/DVD)

• Écran mobile sans fil

Ensembles PDRC – ACL et clavier

• Duplicateur de port

Durée de couverture

Trois (3) ans à partir de la date d’achat original.

Type de couverture

Défauts de pièces et de fabrication

• Ordinateurs de poche

Batterie

• Chargeur de batterie

Adaptateur pour voiture

• Périphériques USB

• Stylo pointeur standard ou pour numériseur graphique

Tous les articles consommables incluant les pellicules protectrices, chiffons de nettoyage, étuis de transport, longes et sangles

Un (1) an à partir de la date d’achat original.

Quatre-vingt-dix (90) jours à partir de la date d’achat original.

Aucune couverture

Défauts de pièces et de fabrication

Défauts de pièces et de fabrication nécessaire, communiquez par téléphone avec un représentant de PCI au 1-800-668-8386, entre 9h00 et 17h00 (heure de l’Est) du lundi au vendredi (sauf les jours fériés), avant l’échéance de la garantie applicable, en prenant soin d’identifier la nature de la défaillance.

Un reçu ou toute autre pièce justificative de la date d’achat original sera exigé avant toute réparation. Toute pièce défectueuse couverte par la présente garantie limitée sera réparée ou remplacée par une pièce neuve ou remise à neuf. Le remplacement ou la réparation sera fait conformément aux modalités de la présente garantie limitée pendant la durée restante de la période originale de la garantie.

Produits non couverts – La présente garantie limitée ne couvre pas les produits achetés à l’extérieur du Canada. Elle ne couvre pas non plus les dommages, la défaillance ou les défauts attribuables à une manutention inadéquate, une mauvaise installation, une utilisation anormale ou abusive, de la négligence, un accident, un déversement ou la pénétration d’un objet étranger, une modification, un cas fortuit ou une réparation effectuée par une personne non agréée par PCI.

CE PRODUIT N’EST PAS DESTINÉ À ÊTRE UTILISÉ, EN TOUT OU EN PARTIE, COMME SYSTÈME/ÉQUIPEMENT NUCLÉAIRE, SYSTÈME/

*3

. PANASONIC

DÉCLINE TOUTE RESPONSABILITÉ CONCERNANT L’UTILISATION DE CE PRODUIT DANS LES CAS SUSMENTIONNÉS.

Les SYSTÈMES/ÉQUIPEMENTS DE POSTE DE PILOTAGE D’AVION sont dotés de systèmes OEPP (organiseur électronique de poste de pilotage) de classe 2 et de classe 1 utilisés pendant des phases critiques de vol (par exemple, pendant le décollage et l’atterrissage) et(ou) montés sur l’avion. Les systèmes OEPP de classe 1 et de classe 2 sont définis par le circulaire d’information FAA: AC (Advisory Circular) 120-76A ou le feuilet n° 36 JAA: JAA TGL (Temporary Guidance Leaflets) No 36.

EXPÉDITION DU PRODUIT POUR SERVICE SOUS GARANTIE

Emballez soigneusement le produit, de préférence dans son emballage d’origine. Joignez une description de la défaillance de même qu’une pièce justificative de la date d’achat. Panasonic Canada Inc. ne peut être tenue responsable pour tout dommage ou perte subi pendant le transport si vous avez choisi le transporteur.

34

GARANTIE LIMITÉE – SUPPORTS DES LOGICIELS

Couverture – Panasonic Canada Inc. (« PCI ») garantit à l’acheteur original que la ou les disquettes ou tout autre support sur lequel le ou les programmes sont fournis sont exempts de défauts de pièces et de fabrication dans des conditions normales d’utilisation au Canada, et ce, pour une période de soixante (60) jours suivant la date de réception indiquée sur la preuve d’achat.

LA PRÉSENTE GARANTIE EST LA SEULE OFFERTE PAR PCI COUVRANT LES SUPPORTS DE LOGICIELS. PCI ne garantit pas les logiciels. Reportez-vous à la garantie écrite du concédant de licence d’utilisation du logiciel (qui accompagne la copie du logiciel) pour toute réclamation en vertu de la garantie.

Réclamation – marche à suivre – Panasonic Canada Inc. remplacera toute disquette ou support défectueux si l’article en question est retourné, port payé, à son service de Marketing – produits informatiques, 5770 Ambler Drive, Mississauga (Ontario) L4W 2T3, dans les soixante (60) jours suivant la date d’achat original. Joignez à votre envoi une pièce justificative de votre achat et une description du problème.

Recours – La responsabilité de PCI - et votre seul recours - dans le cas de toute défaillance couverte par la garantie sur ce support de logiciel est limitée au seul remplacement du support. Elle ne couvre aucun autre dommage, y compris, mais non exclusivement, la perte d’usage ou de profits, ni aucun dommage spécial, indirect ou consécutif, ni aucune autre réclamation de nature similaire ou autre.

Produits non couverts – La présente garantie limitée ne s’applique pas si la ou les disquettes ou autre support ont été utilisés dans un produit d’une marque autre que Panasonic ou dans des conditions environnementales autres que celles spécifiées par PCI ou le fabricant, ou soumis à une mauvaise utilisation, à la négligence, à une manutention inadéquate ou encore si le programme a été modifié ou subi une tentative de modification ou des dommages attribuables à un accident ou à un cas fortuit. De plus, PCI n’assume aucune responsabilité pour toute perte de, ou tout dommage à, un programme, des données ou un support de sauvegarde amovible.

GÉNÉRALITÉS

PCI NE RECONNAÎT AUCUNE AUTRE GARANTIE, EXPLICITE OU IMPLICITE, Y COMPRIS, MAIS NON EXCLUSIVEMENT, LES

GARANTIES IMPLICITES DE VALEUR COMMERCIALE ET D’UTILITÉ À UNE FIN QUELCONQUE, À L’ÉGARD DU LOGICIEL,

SUPPORTS DE LOGICIELS, PRODUITS INFORMATIQUES, PÉRIPHÉRIQUES ET ACCESSOIRES.

SOUS AUCUNE CIRCONSTANCE PCI NE POURRA ÊTRE TENUE RESPONSABLE DES DOMMAGES SPÉCIAUX, INDIRECTS

OU CONSÉCUTIFS ATTRIBUABLES À UN MANQUEMENT AUX GARANTIES LIMITÉES DÉCRITES DANS LE PRÉSENT DOCU-

MENT OU À L’UTILISATION DU PRODUIT INFORMATIQUE, Y COMPRIS, SANS RESTRICTION, LA PERTE DE DONNÉES,

D’AFFAIRES, D’ACHALANDAGE OU DE PROFIT.

DANS TOUS LES CAS, LA RESPONSABILITÉ MAXIMALE DE PCI POUR TOUT MANQUEMENT NE POURRA EXCÉDER LE

PRIX DE VENTE DU PRODUIT INFORMATIQUE.

AUCUNE RÉCLAMATION, SANS ÉGARD À SES MOTIFS, NE POURRA ÊTRE FAITE AUPRÈS DE PCI PLUS DE DEUX (2) ANS

APRÈS LES FAITS INVOQUÉS À LA BASE D’UNE TELLE RÉCLAMATION.

Garantie statutaires – Certaines juridictions interdisent de telles limitations ou exclusions; aussi, pourraient-elles ne pas s’appliquer.

UT-MA6_USEN.indb 34 24/02/2014 16:28:16

For Australia

Personal / Notebook Computers - 36 Month Warranty from Date of Purchase

Subject to the conditions of this warranty Panasonic or it’s Authorised Service Centre will perform necessary service on the product without charge for parts or labour, if in the opinion of Panasonic, the product is found to be faulty within the warranty period.

2. This warranty only applies to Panasonic products purchased in Australia and sold by Panasonic Australia or its Authorised

Distributors or Dealers and only where the products are used and serviced within Australia or it's territories. Warranty cover only applies to service carried out by a Panasonic Authorised Service Centre and only if valid proof of purchase is presented when warranty service is requested.

This warranty only applies if the product has been installed and used in accordance with the manufacturer’s recommendations

(as noted in the operating instructions) under normal use and reasonable care (in the opinion of Panasonic). The warranty covers normal domestic use only and does not cover damage, malfunction or failure resulting from use of incorrect voltages, incorrect installation, accident, misuse, neglect, build-up of dirt or dust, abuse, maladjustment of customer controls, mains supply problems, thunderstorm activity, infestation by insects or vermin, tampering or repair by unauthorised persons (including unauthorised alterations), exposure to abnormally corrosive conditions or any foreign object or matter having entered the product.

4. This warranty does not cover the following items unless the fault or defect existed at the time of purchase: Software

5. Warranty on Toughbook accessories (stylus, pens, AC charger, combo drive, etc) is 12 Months from the date of purchase &

3 months for batteries.

6. To claim warranty service, when required, you should:

Check the Panasonic web site for latest warranty contact http://www.panasonic.com.au/toughbook, use the Service Centre

Locator and call the National Service Centre number indicated.

Prepare purchase receipt as proof of purchase date and system serial number which will be required by the Authorised Service

Centre.

7. The Warranty excludes 3 or less faulty pixels on screen.

8. The Warranty includes the repair or exchange of faulty parts within the product with items that are functionally equivalent to that as originally supplied or better – including new or refurbished parts or units – solely at Panasonic’s discretion.

9. It is the customer’s responsibility to backup all data from the hard disk drive before sending equipment for repair. If a problem is related to the hard disk drive, or the hard disk drive has to be replaced, Panasonic will only reload the factory pre-installed software for the product onto the replacement drive.

10. Panasonic will arrange free pick up and return for approved warranty repairs within 50 km of capital city locations. Please ensure your unit is properly packed for return to the service location.

11. The warranties hereby conferred do not extend to, and exclude, any costs associated with the installation, de-installation or re-installation of a product, including costs related to the mounting, demounting or remounting of any screen, (and any other ancillary activities), delivery, handling, freighting, transportation or insurance of the product or any part thereof or replacement of and do not extend to, and exclude, any damage or loss occurring by reason of, during, associated with, or related to such installation, de-installation, re-installation or transit.

In addition to your rights under this warranty, Panasonic products come with consumer guarantees that cannot be excluded under the Australian Consumer Law. If there is a major failure with the product, you can reject the product and elect to have a refund or to have the product replaced or if you wish you may elect to keep the goods and be compensated for the drop in value of the goods.

You are also entitled to have the product repaired or replaced if the product fails to be of acceptable quality and the failure does not amount to a major failure.

If there is a major failure in regard to the product which cannot be remedied then you must notify us within a reasonable period by contacting the Panasonic Customer Care Centre. If the failure in the product is not a major failure then Panasonic may choose to repair or replace the product and will do so in a reasonable period of time from receiving notice from you.

THIS PRODUCT IS NOT INTENDED FOR USE AS OR AS PART OF NUCLEAR EQUIPMENT/SYSTEMS, AIR TRAFFIC CONTROL

EQUIPMENT/SYSTEMS, OR AIRCRAFT COCKPIT EQUIPMENT/SYSTEMS

*4

. PANASONIC WILL NOT BE RESPONSIBLE FOR

ANY LIABILITY RESULTING FROM THE USE OF THIS PRODUCT ARISING OUT OF THE FOREGOING USES.

*4

AIRCRAFT COCKPIT EQUIPMENT/SYSTEMS include Class 2 Electronic Flight Bag (EFB) Systems and Class 1 EFB Systems when used during critical phases of flight (e.g., during take-off and landing) and/or mounted onto the aircraft. Class 1 EFB Systems and 2 EFB Systems are defined by FAA: AC (Advisory Circular) 120-76A or JAA: JAA TGL (Temporary Guidance Leaflets) No.36.

THIS WARRANTY CARD AND THE PURCHASE DOCKET (OR SIMILAR PROOF OF PURCHASE)

SHOULD BE RETAINED BY THE CUSTOMER AT ALL TIMES

If you require assistance regarding warranty conditions or any other enquiries, please visit the

Panasonic Australia website www.panasonic.com.au/toughbook or contact by phone on 1300 132 463

PRO-031-F05 Issue: 4.0

Panasonic Australia Pty. Limited

ACN 001 592 187 ABN 83 001 592 187

1 Innovation Road, Macquarie Park NSW 2113 www.panasonic.com.au

11-11-2011

UT-MA6_USEN.indb 35

35

24/02/2014 16:28:16

Panasonic Corporation

Osaka, Japan

Panasonic System Communications Company of North America

Two Riverfront Plaza,

Newark NJ 07102

Panasonic Canada Inc.

5770 Ambler Drive, Mississauga,

Ontario L4W 2T3

Panasonic Australia Pty. Limited

ACN 001 592 187 ABN 83 001 592 187

1 Innovation Road, Macquarie Park NSW 2113

Importer’s name & address pursuant to the EU legislation

Panasonic System Communications Company Europe, Panasonic Marketing Europe GmbH

Hagenauer Straße 43

65203 Wiesbaden

Germany

Web Site : http://panasonic.net/

© Panasonic Corporation 2014

Printed in Japan

HS0214-0

DFQW5922ZA

UT-MA6_USEN.indb 36 24/02/2014 16:28:16

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement

Languages
