PIXCI® D and PIXCI® D32
1 of 3
http://www.epixinc.com/legacy/pixci_d_d32.htm
About
Vision
Products
Support
Contact
PIXCI® D32 Compatible Cameras:
Dalsa: CA-D6, CT-E4, CT-P1
Thomson: TH78CA13, TH78CA14
PIXCI® D Compatible Cameras:
Basler: 113, L120, L130, L150, L160
Cohu: 4110, 6600
Dage-MTI: IFG-300
Dalsa: CA-D1, CA-D2, CA-D4, CA-D7, CA-D8,
CL-CB, CL-CC, CL-C3, CL-C4, CL-C5, CL-C6,
CL-C7, CL-C8, CL-C9, CL-E1, CL-E2, CL-F2,
CL-G1, CL-P1, CL-T3, CT-C5, CT-E1, CT-E2,
ML-C3
DVC: DVC-08, DVC-10, DVC-1300-BW,
DVC-1300-RGB
EG&G Reticon: LD-2010, LD-2020, LD-2040,
LD-2060, LD-2080, MD-4013
Hamamatsu: C4742-95
Hitachi: KP-F100, KP-F110
Inframetrics: 760
Redlake MASD: ES310, ES1.0, 1.4i, 1.6i, 4.2i,
6.3i, 16.8i
Pulnix: TM-1001, TM-1010, TM-1040, TM-1300,
TM-9701
Sensors Unlimited: SU320-1.7RT
Silicon Mountain Design: 1M15, 4M4
Takenaka System: FC1300
Thomson: TH78CA88A, TH78KC96M
Links to Camera Manufacturers
PIXCI® D & PIXCI® D32
Simplify Scientific Imaging!
The PIXCI® D and PIXCI® D32 imaging boards
are factory programmed to interface to your
particular model of digital output camera. Install
the board, attach the interface cable between
the board and camera, and run your imaging
software - that's all there is to it!
The digital interface is more resistant to noise
than a comparable analog interface. Use of the
camera's pixel clock eliminates jitter. The
PIXCI® D and PIXCI® D32 capture image
sequences, at the camera's video rate, to the
limit of your computer's memory. EPIX software
is available as C-Function Libraries (DLLs), or as
Innovations:
Line Scan or Area Scan
One, Two, Three or Four Data Inputs
8 to 32 Bit Camera Data
External Trigger In/Out
32 bit PCI Bus Master
132 MB/s Burst Transfers
Image Sequence Storage to
Motherboard Memory
Asynchronous Capture Control
Camera Integration and Reset Control
Call about Other Cameras
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
2/1/2016 8:21 AM
PIXCI® D and PIXCI® D32
2 of 3
http://www.epixinc.com/legacy/pixci_d_d32.htm
XCAP - a full-featured interactive image capture,
display, examination, processing, measurement,
printing, and archival program.
XCAP Image Processing Program for
Research and Industry
XCAP is a scientific and engineering program
providing hundreds of quantitative and
qualitative imaging operations. Quality control,
medical imaging, microscopy, machine vision,
research & development, and varied applications
requiring motion capture, image enhancement,
calibrated measurement, particle analysis, multicamera imaging, or image archival, are all easily
accomplished. XCAP empowers researchers and
developers to meet today's requirements, as well
as the evolving demands of future applications.
For Convenience and Confidence, Purchase the Complete
Computer System Directly From EPIX!
Contact EPIX Inc., or your EPIX distributor, for a quote on a complete imaging system
including camera, optics, power supply, cables, imaging board, computer, and software.
Imaging is one of the most demanding applications a computer system can be asked to
accomplish. Not all computer systems are capable of offering the required performance. As a
result, EPIX engineers continually evaluate the latest in computer technology. When you
purchase a complete imaging system with your PIXCI® D or PIXCI® D32 imaging board, EPIX
technicians consolidate all the necessary components and take the guesswork out of system
configuration. All hardware and software components are installed and tested as a system
before the system is shipped to you!
Imaging Board Pricing:
PIXCI® D
20 bit PCI imaging board for selected digital cameras:
$ 995.00
The PIXCI® D interfaces to a single output camera to a
maximum of 20 bits, or to a dual output camera to a maximum
of 10 bits. The PIXCI® D can also interface to 2 single output
cameras if the cameras can be pixel clock locked.
PIXCI® D32
32 bit PCI imaging board for selected digital cameras:
$ 1295.00
The PIXCI® D32 provides solutions for cameras or applications
which require 21-32 bits. Examples include interfacing to the
following: an 8-bit four output camera, a 10-bit three output
camera, a 12-bit two output camera, or a 24-bit RGB color
camera. The PIXCI® D32 can interface to multiple cameras for example, up to 4 single output 8-bit cameras, or 2 two
output 16-bit cameras if the cameras can be pixel clock
locked.
PIXCI® D & PIXCI® D32 Software Pricing:
Imaging program with graphical user interface - providing
XCAP
interactive image capture, display, examination, processing,
analysis, measurement, printing and archiving.
(For WIN 95/98/NT.)
Interactive imaging program for DOS.
XCIP
$ 1495.00
$ 1495.00
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
2/1/2016 8:21 AM
PIXCI® D and PIXCI® D32
3 of 3
http://www.epixinc.com/legacy/pixci_d_d32.htm
Library of board command and control functions.
(Available for DOS, WIN 95/98, and WIN NT.)
XCOBJ & PXIPL XCOBJ library of board command and control functions with
PXIPL library of image processing, analysis & measurement
functions.
(Available for DOS, WIN 95/98, and WIN NT.)
Interactive image capture, display, and archival program. A
XCAP-Lite
limited version of the XCAP program. Available from the
Software Download page.
(For WIN 95/98/NT.)
XCOBJ
PIXCI® D & PIXCI® D32 Cable Pricing:
Cable prices vary with the model of camera and the required
length. Some camera manufacturers offer cables directly
compatible to the PIXCI® D or PIXCI® D32. Contact EPIX,
Inc., Or your EPIX distributor, for cabling and pricing
information.
$ 495.00
$ 995.00
No Charge
With Board
Purchase
Cable
prices start
at $100.00
Back to EPIX Products
Back to the EPIX home page
Image Processing Products For Research and Industry
Prices and terms subject to change without notice.
All prices F.O.B. Buffalo Grove, Illinois.
USA Terms: Net 30 Days, subject to credit acceptance.
Contact EPIX, or your EPIX distributor, for volume
discounts and OEM pricing.
Specifications and prices subject to change without notice.
EPIX® imaging products are made in the USA.
Terms of Sale.
Trademark Notices.
Copyright © 2015 EPIX, Inc. All rights reserved.
Software price protection: Within 90 days of original
shipment, a discount equal to the original purchase
price of XCAP, XCIP, XCOBJ, or PXIPL, may be
applied to a new version of the same software.
Programming libraries license a single program
developer; the developed program which incorporates
object code libraries may be reproduced without
payment of additional royalties, as detailed in the
Software License Agreement.
Rev: 9 Dec 98, © EPIX 1998.
