SERIES 41800
VHF-TV
STEREO DIPLEXER
•
Ideal for Solid State Transmitters
•
Compatible with CCIR Dual Sound
•
Low Loss
•
Low VSWR
•
High Isolation
MCI’s VHF Compact Diplexers are constant impedance devices used to combine
visual and aural transmitters into a single
output. These units are constructed of
broadband coax hybrids and a cavity
section assembled in a unitized frame for
floor or ceiling mounting.
The aural cavities utilize a high Q design.
The cavity probe is constructed of low
coefficient-of-expansion Invar and is
silver-plated.
The diplexer is easily packaged in any
custom installation. It includes a mounted
reject load with RF sampling probe. Color
notch cavity is not included, but can be
supplied. Wattmeters and directional
couplers are additional.
Models are available for USA VHF channels 2-6 and 7-13 and European VHF
channels 2-4 and 5-12.
Models are available for Hi-V (Band III)
that can be tuned across the entire band.
Consult factory for specifications.
SERIES 41800
VHF-TV STEREO DIPLEXER
SPECIFICATIONS
Frequency:
Insertion Loss:
Visual:
+3.58 MHz:
Aural:
± 200 KHz:
Isolation:
VSWR:
Visual:
Aural:
Antenna Input:
Amplitude Response:
CHANNEL USA
(Frequency)
CHANNEL EUROPE (Frequency)
MODEL
POWER
(peak Vis)
SIZE
in
(cm)
WEIGHT
lbs
(kg)
CONNECTORS
EIA
MODEL
POWER
(peak Vis)
SIZE
in
(cm)
WEIGHT
lbs
(kg)
CONNECTORS
EIA
MODEL
POWER
(peak Vis)
SIZE
in
(cm)
WEIGHT
lbs
(kg)
CONNECTORS
EIA
MODEL
POWER
(peak Vis)
SIZE
in
(cm)
WEIGHT
lbs
(kg)
CONNECTORS
EIA
MODEL
POWER
(peak Vis)
SIZE
in
(cm)
WEIGHT
lbs
(kg)
CONNECTORS
EIA
Specify Channel
0.10 dB
0.50 dB
0.35 dB Maximum
<1.6 dB
35 dB (Visual to Aural)
40 dB (Aural to Visual)
1.05 Fv to Fv + 3.5 MHz
1.08 Fv +35 to Fv 4.18MHz
1.08 Aural ± 200 KHz
1.10 Over Band
2 dB at +4.18 MHz lo V
3 dB at +4.18 MHz Hi V
2-6 (54-88 MHz)
2-4 (47-68 MHz)
41835
100 kW
31x54x65
(79x137x165)
430
(195)
6 1/8-V, 3 1/8-A
41834
60 kW
31x48x65
(79x122x165)
390
(177)
4 1/16-V, 1 5/8-A
41833
40 kW
31x42x65
(79X107X165)
350
(159)
3 1/8-V, 1 5/8-A
41832
20 kW
31x42x62
(79x91.5x165)
330
(150)
1 5/8-V, 1 5/8-A
41831
10 kW
31x36x65
(79x91.5x165)
310
(140)
7/8-V, 7/8-A
7-13 (174-216 MHz)
5-12 (174-230 MHz)
41815
80 kW
31x54x40
(79x137x102)
380
(172)
6 1/8-V, 3 1/8-A
41814
60 kW
31x48x40
(79x122x102)
340
(154)
4 1/16-V, 1 5/8-A
41813
40 kW
31X42X40
(79x107x102)
300
(136)
3 1/8-V, 1 5/8-A
41812
10 kW
31x42x40
(79x915x102)
280
(127)
1 5/8-V, 1 5/8-A
41811
5 kW
31x36x40
(79x91.5x102)
260
(118)
7/8-V, 7/8-A
All specifications are subject to change without notice
Micro Communications, Inc. 15 Caron Street Merrimack, NH USA 03054
Tel: 603-429-0800 Toll-free: 800-545-0608 Fax: 603-429-1633 Web: www.mcibroadcast.com
Email:[email protected]
8/2006
