RTM8030 User's Guide
RTM8030 User's Guide
Document Revision 1.2
May 2009
Revision History
Rev. Index
Brief Description of Changes
Date of Issue
1.0
first release
December 2007
1.1
Sensor name modifications, added Jumper JP4, MTBF value
changed
July 2008
1.2
third release
May 2009
Customer Service
Contact Information:
Kontron Canada, Inc.
4555, Ambroise-Lafortune
Boisbriand, Québec, Canada
J7H 0A4
Tel: (450) 437-5682
(800) 354-4223
Fax: (450) 437-8053
E-mail: [email protected]
Kontron Modular Computer GMBH
Sudetenstrasse 7
87600 Kaufbeuren
Germany
+49 (0) 8341 803 333
+49 (0) 8341 803 339
[email protected]
Visit our site at:www.kontron.com
© 2009 Kontron, an International Corporation. All rights reserved.
The information in this user's guide is provided for reference only. Kontron does not assume any liability
arising out of the application or use of the information or products described herein. This user's guide may
contain or reference information and products protected by copyrights or patents and does not convey any
license under the patent rights of Kontron, nor the rights of others.
Kontron is a registered trademark of Kontron. All trademarks, registered trademarks, and trade names used
in this user's guide are the property of their respective owners. All rights reserved. Printed in Canada. This
user's guide contains information proprietary to Kontron. Customers may reprint and use this user's guide in
other publications. Customers may alter this user's guide and publish it only after they remove the Kontron
name, cover, and logo.
Kontron reserves the right to make changes without notice in product or component design as warranted by
evolution in user needs or progress in engineering or manufacturing technology. Changes that affect the
operation of the unit will be documented in the next revision of this user's guide.
i
RTM8030 User's Guide
Table of Contents
Table of Contents
Safety instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vi
Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vi
When Working Inside a Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .vii
Preventing Electrostatic Discharge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . viii
Preface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ix
How to Use This Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ix
Customer Comments. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .x
Advisory Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .x
Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xi
Powering Up the System. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xi
Adapter Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xi
Storing Boards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xi
Regulatory Compliance Statements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xii
Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xiii
1.
Product Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1.1
Product Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1.2
What’s Included. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1.3
Board Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
1.4
Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.5
Hot-Swap Capability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.6
Interfacing with the Environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.6.1
2.
RTM (rear transition module) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Board Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2.1
Block Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2.2
Rotary Binary Selector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2.3
USB 2.0 Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.4
SAS Link . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2.5
SAS Hard Drive Option . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2.6
Serial Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2.7
Ethernet 100Base-TX Interface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2.8
SFP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2.9
Redundant MMC Flash Boot Block . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
ii
RTM8030 User's Guide
Table of Contents
2.10 Hardware Management Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2.10.1
Sensor Data Record (SDR). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
2.10.2
Hardware Sensors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
2.10.3
Field Replaceable Unit (FRU) Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
2.10.4
E-Keying . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
2.10.5
MMC Firmware Code . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
2.10.6
MMC Firmware Upgrade Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
2.10.7
Boot Block Upgrade Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
2.11 Debugging Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
3.
2.11.1
Hot Swap LED (LED0) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
2.11.2
Out Of Service (LED1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
2.11.3
Healthy LED (LED2). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Installing the Board. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
3.1
3.1.1
Jumper Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
3.1.2
Setting Jumper & Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
3.2
A.
B.
D.
Board Hot Swap and Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
3.2.1
Installing the RTM in the chassis. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
3.2.2
Removing the RTM from the chassis . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Connector Pinouts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .A-1
A.1
Connectors and Headers Summary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .A-1
A.2
AdvancedTCA I/O RTM Connector (P30) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .A-2
A.3
SAS Faceplate Connector (J2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .A-3
A.4
USB Port (J3). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .A-3
A.5
SERIAL PORT(J6B & J6C) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .A-3
A.6
Ethernet(J6D) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .A-4
A.7
SFP Channel (J7) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .A-4
A.8
SAS Hard Drive Connector (J10) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .A-5
Software Update . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .B-1
B.1
C.
Setting Jumper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
MMC Firmware Update Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .B-1
Getting Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-1
C.1
Returning Defective Merchandise. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-2
C.2
When Returning a Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-3
Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . D-1
iii
RTM8030 User's Guide
List of Figures
List of Figures
Figure 2-1: Block Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Figure 2-2: Connector Block Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Figure 2-3: Reset Switch / RS-232 Port Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Figure 2-4: SAS Block diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Figure 3-1: Setting Jumper & Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
iv
RTM8030 User's Guide
List of Tables
List of Tables
Table 1-1 Board Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Table 2-1 USB Connector Pinout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Table 2-2 Serial Port Connector Pinout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Table 2-3 IPMI Hardware Sensors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Table 2-4 Board Information Area. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Table 2-5 Product Information Area . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Table 2-6 Type 16 Module Current Requirements Records . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Table 2-7 Type 19h - AMC Point-To-Point Connectivity Record . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Table 2-8 Type 19h - AMC Point-To-Point Connectivity Record . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Table 2-9 Type 19h - AMC Point-To-Point Connectivity Record . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Table 2-10 Type 19h - AMC Point-To-Point Connectivity Record . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Table 2-11 Type 19h - AMC Point-To-Point Connectivity Record . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Table 2-12 Type 19h - AMC Point-To-Point Connectivity Record . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Table 2-13 Type 19h - AMC Point-To-Point Connectivity Record . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Table 2-14 Hot-Swap LED Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Table 3-1 Jumper Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
v
RTM8030 User's Guide
Safety instructions
Safety instructions
Before You Begin
Before handling the board, read the instructions and safety guidelines on the following pages to prevent
damage to the product and to ensure your own personal safety. Refer to the "Advisories" section in the
Preface for advisory conventions used in this user's guide, including the distinction between Warnings,
Cautions and Notes.
• Always use caution when handling/operating the computer. Only qualified, experienced,
authorized electronics service personnel should access the interior of the computer. The power
supplies produce high voltages and energy hazards, which can cause bodily harm.
• Use extreme caution when installing or removing components. Refer to the installation
instructions in this user's guide for precautions and procedures. If you have any questions, please
contact Kontron Technical Support
WARNING
High voltages are present inside the chassis when the unit's power cord is plugged
into an electrical outlet. Turn off system power, turn off the power supply, and then
disconnect the power cord from its source before removing the chassis cover. Turning
off the system power switch does not remove power to components.
vi
RTM8030 User's Guide
Safety instructions
When Working Inside a Computer
Before taking covers off a computer, perform the following steps:
• Turn off the computer and any peripherals.
• Disconnect the computer and peripherals from power sources or subsystems to prevent electric
shock or system board damage. This does not apply to when hot-swapping parts.
• Follow the guidelines provided in "Preventing Electrostatic Discharge" on the following page.
• Disconnect telephone or telecommunications lines from the computer.
In addition, take note of these safety guidelines when appropriate:
• To help avoid possible damage to system boards, wait five seconds after turning off the computer
before removing a component, removing a system board, or disconnecting a peripheral device from
the computer.
• When you disconnect a cable, pull on its connector or on its strain-relief loop, not on the cable
itself. Some cables have a connector with locking tabs. If you are disconnecting this type of cable,
press in on the locking tabs before disconnecting the cable. As you pull connectors apart, keep
them evenly aligned to avoid bending any connector pins. Also, before connecting a cable, make
sure both connectors are correctly oriented and aligned.
CAUTION
Do not attempt to service the system yourself, except as explained in this user’s
guide. Follow installation and troubleshooting instructions closely.
vii
RTM8030 User's Guide
Safety instructions
Preventing Electrostatic Discharge
Static electricity can harm system boards. Perform service at an ESD workstation and follow proper ESD
procedure to reduce the risk of damage to components. Kontron strongly encourages you to follow proper
ESD procedures, which can include wrist straps and smocks, when servicing equipment.
Take the following steps to prevent damage from electrostatic discharge (ESD):
• When unpacking a static-sensitive component from its shipping carton, do not remove the
component's antistatic packing material until you are ready to install the component in a
computer. Just before unwrapping the antistatic packaging, be sure you are at an ESD workstation
or grounded. This will discharge any static electricity that may have built up in your body.
• When transporting a sensitive component, first place it in an antistatic container or packaging.
• Handle all sensitive components at an ESD workstation. If possible, use antistatic floor pads and
workbench pads.
• Handle components and boards with care. Don't touch the components or contacts on a board.
Hold a board by its edges or by its metal mounting bracket.
• Do not handle or store system boards near strong electrostatic, electromagnetic, magnetic, or
radioactive fields.
viii
RTM8030 User's Guide
Preface
Preface
How to Use This Guide
This user's guide is designed to be used as step-by-step instructions for installation and as a reference for
operation, troubleshooting, and upgrades.
You can find the latest release of this User's Guide at:
http://www.kontron.com or at: ftp://ftp.kontron.ca/support/
For the circuits, descriptions and tables indicated, Kontron assumes no responsibility as far as patents or
other rights of third parties are concerned.
The following is a summary of chapter contents:
• Chapter 1, Product Description
• Chapter 2, Board Features
• Chapter 3, Installing the board
• Appendix A, Connector Pinout
• Appendix B, Software Update
• Appendix C, Getting Help
ix
RTM8030 User's Guide
Preface
Customer Comments
If you have any difficulties using this user's guide, discover an error, or just want to provide some feedback,
please send a message to: [email protected] Detail any errors you find. We will correct the errors
or problems as soon as possible and post the revised user's guide on our Web site. Thank you.
Advisory Conventions
Seven types of advisories are used throughout the user guides to provide helpful information or to alert you
to the potential for hardware damage or personal injury. They are Note, Signal Paths, Jumpers Settings, BIOS
Settings, Software Usage, Cautions, and Warnings. The following is an example of each type of advisory. Use
caution when servicing electrical components.
Note:
Indicate information that is important for you to know.
Signal Path:
Indicate the places where you can fin the signal on the board.
Jumper Settings:
Indicate the jumpers that are related to this sections.
BIOS Settings:
Indicate where you can set this option in the BIOS.
Software Usage:
Indicates how you can access this feature through software.
CAUTION
Indicate potential damage to hardware and tells you how to avoid the problem.
WARNING
Indicates potential for bodily harm and tells you how to avoid the problem.
Disclaimer: We have tried to identify all situations that may pose a warning or a caution condition in this
user's guide. However, Kontron does not claim to have covered all situations that might require the use of a
Caution or a Warning.
x
RTM8030 User's Guide
Preface
Unpacking
Follow these recommendations while unpacking:
• Remove all items from the box. If any items listed on the purchase order are missing, notify
Kontron customer service immediately.
• Inspect the product for damage. If there is damage, notify Kontron customer service immediately.
• Save the box and packing material for possible future shipment.
Powering Up the System
Before any installation or setup, ensure that the board is unplugged from power sources or subsystems.
If you encounter a problem, verify the following items:
• Make sure that all connectors are properly connected.
• Verify your boot devices.
• If the system does not start properly, try booting without any other I/O peripherals attached,
including AMC adapters.
Make sure your system provides the minimum DC voltages required at the board's slot, especially if DC power
is carried by cables.
If you are still not able to get your board running, contact our Technical Support for assistance.
Adapter Cables
Because adapter cables come from various manufacturers, pinouts can differ. The direct crimp design offered
by Kontron allows the simplest cable assembly. All cables are available from Kontron Sales Department.
Storing Boards
Electronic boards are sensitive devices. Do not handle or store device near strong electrostatic,
electromagnetic, magnetic or radioactive fields.
xi
RTM8030 User's Guide
Preface
Regulatory Compliance Statements
FCC Compliance Statement for Class A Devices
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generated, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experience radio/TV technician for help.
WARNING
This is a Class A product. If not installed in a properly shielded enclosure and used in
accordance with this User's Guide, this product may cause radio interference in
which case users may need to take additional measures at their own expense.
Safety Certification
All Kontron equipment meets or exceeds safety requirements based on the IEC/EN/UL/CSA 609501 family of standards entitled, "Safety of information technology equipment." All components are
chosen to reduce fire hazards and provide insulation and protection where necessary. Testing and
reports when required are performed under the international IECEE CB Scheme. Please consult the
"Kontron Safety Conformity Policy Guide" for more information.
CE Certification
The product described in this user's guide was tested in a representative system and is found to be
compliant with the CE marking requirements. For computer systems to remain CE compliant, only
CE-compliant parts may be used. Maintaining CE compliance also requires proper cable and cabling
techniques. Although Kontron offers accessories, the customer must ensure that these products
are installed with proper shielding to maintain CE compliance. Kontron does not offer engineering
services for designing cabling systems. In addition, Kontron will not retest or recertify systems or
components that have been reconfigured by customers.
xii
RTM8030 User's Guide
Preface
Limited Warranty
Kontron grants the original purchaser of Kontron's products a TWO YEAR LIMITED HARDWARE WARRANTY as
described in the following. However, no other warranties that may be granted or implied by anyone on behalf
of Kontron are valid unless the consumer has the express written consent of Kontron.
Kontron warrants their own products, excluding software, to be free from manufacturing and material
defects for a period of 24 consecutive months from the date of purchase. This warranty is not transferable nor
extendible to cover any other users or long- term storage of the product. It does not cover products which
have been modified, altered or repaired by any other party than Kontron or their authorized agents.
Furthermore, any product which has been, or is suspected of being damaged as a result of negligence,
improper use, incorrect handling, servicing or maintenance, or which has been damaged as a result of
excessive current/voltage or temperature, or which has had its serial number(s), any other markings or parts
thereof altered, defaced or removed will also be excluded from this warranty.
If the customer's eligibility for warranty has not been voided, in the event of any claim, he may return the
product at the earliest possible convenience to the original place of purchase, together with a copy of the
original document of purchase, a full description of the application the product is used on and a description
of the defect. Pack the product in such a way as to ensure safe transportation (see our safety instructions).
Kontron provides for repair or replacement of any part, assembly or sub-assembly at their own discretion, or
to refund the original cost of purchase, if appropriate. In the event of repair, refunding or replacement of
any part, the ownership of the removed or replaced parts reverts to Kontron, and the remaining part of the
original guarantee, or any new guarantee to cover the repaired or replaced items, will be transferred to cover
the new or repaired items. Any extensions to the original guarantee are considered gestures of goodwill, and
will be defined in the "Repair Report" issued by Kontron with the repaired or replaced item.
Kontron will not accept liability for any further claims resulting directly or indirectly from any warranty
claim, other than the above specified repair, replacement or refunding. In particular, all claims for damage
to any system or process in which the product was employed, or any loss incurred as a result of the product
not functioning at any given time, are excluded. The extent of Kontron liability to the customer shall not
exceed the original purchase price of the item for which the claim exists.
Kontron issues no warranty or representation, either explicit or implicit, with respect to its products
reliability, fitness, quality, marketability or ability to fulfil any particular application or purpose. As a result,
the products are sold "as is," and the responsibility to ensure their suitability for any given task remains that
of the purchaser. In no event will Kontron be liable for direct, indirect or consequential damages resulting
from the use of our hardware or software products, or documentation, even if Kontron were advised of the
possibility of such claims prior to the purchase of the product or during any period since the date of its
purchase.
Please remember that no Kontron employee, dealer or agent is authorized to make any modification or
addition to the above specified terms, either verbally or in any other form, written or electronically
transmitted, without the company's consent.
xiii
RTM8030 User's Guide
Product Description
1. Product Description
1.1
Product Overview
The RTM8030 is a single slot (6HP) AdvancedTCA Rear Transition Module. This RTM provides additional
connectivity to the AT8030 CPU front blade.
1.2
What’s Included
This board is shipped with the following items:
• One RTM8030 board
• One CD-ROM containing documentations and drivers.
• Cables that have been ordered
If any item is missing or damaged, contact the supplier.
1
RTM8030 User's Guide
Product Description
1.3
Board Specifications
Table 1-1:Board Specifications
Features
Description
Compatible Products
•
AT8030
Compliancy
•
•
•
•
•
•
PICMG3.0 R2.0 ECN002
SAS1R10
SFF-8470
IEEE 802.3z (fiber interface)
IEEE 802.3 (copper interface)
PICMG HPM.1
•
•
•
Management Controller compliant to PICMG 3.0 and IPMI v1.5 rev 1.1.
Management Controller is run time field reprogrammable without payload impact.
Robust fail safe reprogramming implementation (which includes two firmware
images) that could perform automatic or manual rollback if a problem occurs during
critical reprogramming phase.
Remote upgrade capability (via IPMB).
Management Controller self test which can detect failure under its code integrity and
trig an automatic rollback.
IPMI Features
•
•
•
Hardware system monitor through IPMI (voltages, currents, temperature),
temperature monitor / alarm; board temperature sensor, power failure.
Mechanical
•
322.25 x 93.74 x 29 mm
Power Requirements
•
•
10W Typical without hard drive.
20 W Typical with hard drive.
Environmental
Temperature*
Operating: 0-55°C/32-131°F with 30CFM airflow
Storage and Transit: -40 to +70°C/-40 to 158°F
Environmental
Humidity*
Operating: 15% to 90% @55°C/131°F non-condensing
Storage and Transit: 5% to 95% @ 40°C/104°F non-condensing
Environmental Altitude*
Operating: 4,000 m / 13,123 ft
Storage and Transit: 15,000 m / 49,212 ft
Environmental Shock*
Operating: 3G, half-sine 11ms, each axis
Storage and Transit: 18G, half-sine 11ms, each axis
Environmental
Vibration*
Operating: 5-200Hz. 0.2G, each axis
Storage and Transit: 5 Hz to 20 Hz @ 1 m2/s3 (0.01 g2 /Hz) (flat) 20 Hz to 200 Hz @ -3 dB/
oct (slop down)
Reliability
•
•
•
MTBF: > 500 000 hours @ 40 C / 104 F (Telcordia SR-332, Issue 1)
Whole board protected by active breaker
USB voltage protected by an active breakers
•
Safety: CE Mark to EN 60950-1:2001. Meets or exceeds UL 60950-1/CSA C22.2 No
60950-1-07.
Designed to meet GR-1089-CORE
EMI/EMC: FCC 47 CFR Part 15, Class A; CE Mark to EN55022/EN55024/EN300386
Supervisory
Safety / EMC
Warranty
•
•
Two years limited warranty
* Designed to meet or exceed
2
RTM8030 User's Guide
Product Description
1.4
Compliance
This product conforms to the following specifications:
• PICMG3.0 R2.0 ECN002 - Advanced Telecommunication Computing Architecture
• PICMG HPM.1
• SAS1R10 - Serial Attached SCSI - 1.1 Revision 10. (SAS-1.1)
• SFF-8470 (T10 Technical Committee and SCSI Trade Association)
• IEEE 802.3z (fiber interface)
• IEEE 802.3 (copper interface)
1.5
Hot-Swap Capability
The RTM8030 supports Full Hot Swap capability as per PICMG3.0R2.0. It can be removed from or installed in
the system while it is on (without powering-down the system). Please refer to the PICMG3.0R2.0
specification for additional details. However, all managements the infrastructure is present for hot-swap,
but the user must take the proper action to protect its data under the OS of the Front Board (such as
unmount a SAS drive)
3
RTM8030 User's Guide
Product Description
1.6
Interfacing with the Environment
1.6.1
RTM (rear transition module)
The RTM8030 is a single slot (6HP) AdvancedTCA Rear Transition Module. This module provides additional
connectivity for AT8030 CPU front blade.
1.6.1.1
Standard Compliance
• PICMG3.0 R2.0 ECN002 - Advanced Telecommunication Computing Architecture
• PICMG HPM.1
• SAS1R10 - Serial Attached SCSI - 1.1 Revision 10. (SAS-1.1)
• SFF-8470 (T10 Technical Committee and SCSI Trade Association)
1.6.1.2
SAS Feature
• Compliant to SAS-1.1 Revision 10 / SFF-8470
• SAS signal integrity guarantee over a four meters cable
1.6.1.3
Serial Port Feature
• One (1) serial port available on the RTM face plate through one (1) RJ-45 connector dedicated for Port 0.
• One (1) serial port available on the RTM face plate through one (1) RJ-45 connector shared between Port
1 to Port 7.
• RS-232 signals level at RTM face plate connector.
• Serial port speed capability is: 9.6kbits/s to 115.2kbits/s.
1.6.1.4
FRU Data EEPROM
• FRU Data EEPROM size is 512Kbit and it includes board identification and serial number.
1.6.1.5
Hot Swap
The RTM8030 supports hot swapping by using the switch connected to the face plate lower ejector. This
switch indicates the coming hot swap action. The insertion of the RTM to a slot is always done over a non
powered connector. During the extraction procedure, the management power is disabled only when the
RTM8030 is removed. This procedure is identical to the AdvancedTCA AMC behavior.
1.6.1.5.1
Inserting the RTM8030 into the slot
The presence of the RTM is indicated by one signal. The front blade IPMC recognizes the RTM insertion when
this signal is low. As soon as inserted, the MMC on the RTM turns the blue LED ON and enables the 3.3V_SUS
to the RTM. Once the I2C link is working, the IPMC of the front blade accesses the serial EEPROM to retrieve
4
RTM8030 User's Guide
Product Description
FRU data. After knowing the type of RTM inserted, the IPMC negotiates with System Manager in order to
activate the +12V payload power. After RTM local voltages have been ramped up, the IPMC from the front
blade enables the RTM Link.
After this the IPMC informs the CPU SW there is a functional RTM blade present via standard hot swap sensor.
1.6.1.5.2
Removing the RTM8030 from the slot
The RTM_EJECT signal goes HIGH by opening the RTM lower ejector handle. This indicates to the front blade
IPMC that a hot swap action is going to take place. The IPMC then negotiates the removal with the System
manager and if it is granted, it proceeds with the removal process.
The IPMC first notifies the CPU SW of coming hot removal. After the CPU SW has disabled SAS links, it notifies
the MMC that the RTM blade can be removed. The MMC then activates reset to the RTM blade (via the
Expander), disables the RTM Link and turns OFF the payload +12V power. When it is safe to remove the RTM
blade from the slot, the MMC turns the Blue / Hot Swap LED ON. Front Blade IPMC turns OFF the management
power only when their is no RTM detected. (RTM8030 removed from the slot)
5
RTM8030 User's Guide
Board Features
2. Board Features
2.1
Block Diagram
Figure 2-1:Block Diagram
3
,-.
/01
#0
B<
%&"'
()#*(&
+
%&-2
,-.
0"
$;[email protected]
*A&0<#
!
8>@
&
*#
4
8>@
&
*#
< ,&
: &
"&-2
!
:,-.
"11
4
"#$
$; &
.=;8>
!!
3$5/06478
(9
6
RTM8030 User's Guide
Board Features
Figure 2-2:Connector Block Diagram
BA#
C;??
"&A
;@.%C;
[email protected],
"
"##$
A
#
!
;@.%C;
"
%#$
[email protected]%(
<BA#
C;=
>;@.%C;
%
C;??
"&A
[email protected]%$(
@
>;@.%C;
A
#
!
"
4
46"
"#$
BA#
A
#
!
"
,-.
7
RTM8030 User's Guide
Board Features
2.2
Rotary Binary Selector
The RTM8030 has a rotary binary selector which is composed of a binary coded rotary switch and a
debouncing circuit. This binary selector controls the connection from the face plate Reset and RS232 Rx/Tx
signals to the CPU blade through the zone 3 connector. The binary selector has 8 positions, from 0 to 7.
Position 0 doesn't select any group signals. Positions 1 to 7 selects corresponding group signals. When the
shaft has not reach a definite position, the position output is positon 7.
When the rotary switch is at position 1, then:
Z3_RESET1# is connected to the faceplate “reset” switch (SW5).
Z3_RS232_RX1/TX1 are connected to the faceplate selectable RS232 connector (J6-C).
When the rotary switch is at position 2, then the Z3_RESET2# and Z3_RS232_RX/TX2 are connected to the
switches SW4-SW5 and connector J6-C.
This connectivity pattern is the same up to position 7.
When the rotary switch is at position 0, then the switches SW4-SW5 and connector J6-C are not connected to
any front blade signals.
The signal Z3_RESET0# is connected to the faceplate switch SW3.
The signals Z3_RS232_RX0/TX0 are connected to the faceplate RS232 connector (J6-B).
Figure 2-3:Reset Switch / RS-232 Port Selection
Reset Switch / RS-232 Port Selection
Rotary Switch Reset Switch RS-232 Port
Activated
(SW1) Position Activated
0
SW5 Not Used J6C Not Used
1
SW5 CPU1
J6C CPU1 COM1
2
SW5 CPU2
J6C CPU2 COM1
3
SW5 ES
J6C ES UART0
4
SW5 Not Used J6C AMC Bay
5
SW5 Not Used J6C CPU0 COM2
6
SW5 Not Used J6C CPU1 COM2
7
SW5 Not Used J6C CPU2 COM2
ANY
SW3 CPU0
J6B CPU0 COM1
8
RTM8030 User's Guide
Board Features
2.3
USB 2.0 Interface
USB features include:
• Capability to daisy chain as many as 127 devices per interface
• Fast bi-directional
• Isochronous/asynchronous interface
• 480 MBPS transfer rate
• Standardization of peripheral interfaces into a single format
• Backward compatible with USB 1.1 devices
USB supports Plug and Play and hot-swapping operations (OS level). These features allow USB devices to be
automatically attached, configured and detached, without reboot or running setup.
Table 2-1:USB Connector Pinout
Pin
Signal
1
VCC
2
DATA-
3
DATA+
4
GND
Signal Path:
The USB Port is available through the RTM front plate (J3).
The USB Port is connected to the CPU engine 0 of the AT8030.
9
RTM8030 User's Guide
Board Features
2.4
SAS Link
The RTM8030 has one (1) 3Gbits/s SAS link available on the face plate through the SAS Hard Disk Connector
or through the external SAS connector. This link is coming from the front blade through the zone 3
connector. A SAS signal conditioner (repeater) and multiplexer is needed to guarantee SAS signal integrity
over the cable between two RTM blades. The maximum SAS cable length between two RTM blades is 4m. SAS
links work after both RTM units have been powered up. SAS port mapping is drawn below:
Figure 2-4:SAS Block diagram
Jumper Settings:
JP4 must be installed to enable the SAS External Connector otherwise; the Onboard SAS HDD is
enabled.
2.5
SAS Hard Drive Option
Kontron offers the option of adding a SAS hard drive on the RTM8030. This hard drive is located on the
component side of the PCB, in the lower part of the RTM8030.
Note:
The SAS Hard Drive Option is connected to the CPU engine 0 of the AT8030.
10
RTM8030 User's Guide
Board Features
2.6
Serial Port
The RTM8030 has two serial ports available on the RTM face plate. One serial port is permanent (always
connected to the CPU engine 0) and the other one is selected between RS232 port1 to port7 by using the
rotary binary selector. Serial ports are coming from the front blade through zone 3 connector. RS232
buffers are used on the RTM to convert LVTTL level from zone 3 to RS232 level at the face plate connector.
Both RS232 buffers are connected to the management power. Serial port works from 9 to 115 kbits/s. Both
transceivers can detect a valid RS232 level signal on the face plate RxD input signal. Those RS232 detect
signals are connected to the RTM-Link slave CPLD and the MMC.
Table 2-2:Serial Port Connector Pinout
Pin
Signal
1
N.C.
1
N.C.
3
TX#
4
GND
5
GND
6
RX#
7
N.C.
8
N.C.
Note:
Standard product uses a RJ-45 8 pins connector. RI (ring indicator) and DCD (data carrier detect)
signals are not available.
The pinout is a custom one, not the same as RS-232D TIA/EIA-561.
Signal Path:
RS232 port 0 is available on the RTM face plate through J6B. This port is always connected the CPU
engine 0.
RS232 port 1-7 is available on the RTM face plate through J6C. Depending the the rotary switch
position, the port will be connected to either CPU engine 1 or 2 or to the Unit computer.
2.7
Ethernet 100Base-TX Interface
The RTM8030 has one ethernet 100Base-TX interface accessible on the RTM face plate through a RJ45
connector. This port is the management port of the unit computer on the AT8030.
11
RTM8030 User's Guide
Board Features
2.8
SFP
The RTM8030 has one SFP module connector available on the RTM face plate. The SFP module signals are
coming from the front blade 1000Base-X interface through zone 3 connector.
2.9
Redundant MMC Flash Boot Block
The MMC microcontroller runs a firmware from its internal 256KB flash. It is programmed by an additional 8K
boot block. It keeps the last two copies of the MMC firmware in dedicated flash memories. The boot block
activates the MMC image and can rollback a firmware update in the MMC in case of problems.
The Boot Block itself uses code. Functions of the boot block are kept to a minimum and field updatable with
payload impact.
2.10 Hardware Management Overview
The RTM communicates with the Module Management Controller (MMC) using the IPMB_L channel.
The memory subsystem of the MMC consists of an integrated flash memory to hold the MMC operation code
and integrated RAM for data. The field replacement unit (FRU) inventory information is stored in the
nonvolatile memory on an EEPROM connected via a local I2C interface to the MMC microcontroller. It is
possible to store up to 4 KBytes within the FRU inventory information. Event generation over IPMB-L bus to
reach the front board that forward it to the ShMc ensure that 'post-mortem' logging information is available
even if the power of the RTM is disabled.
The onboard DC voltages and temperature are monitored by the MMC microcontroller device. The MMC will
send an event to the front board if any of the thresholds are exceeded.
To increase the reliability of the RTM8030 management subsystem, an external watchdog supervisor only for
the MMC is implemented. The MMC must strobe the external watchdog at 500 μsec. intervals to ensure
continuity of operation of the board's management subsystem. If the MMC ceases to strobe the watchdog
supervisor, the watchdog resets the MMC. The watchdog timeout expires after one second if strobes are not
generated. The external watchdog supervisor is not configurable and must not be confused with the IPMI
v1.5 watchdog timer commands. This external watchdog of the MMC is implemented in a separate chip.
2.10.1
Sensor Data Record (SDR)
Every sensor on the RTM is associated with a Sensor Data Record (SDR). Sensor Data Records contain
information about the sensors identification such as sensor type, sensor name, sensor unit. SDR also
contain the configuration of a specific sensor such as threshold/hystheresis, event generation capabilities
that specifies sensor behaviour. Some fields of the sensor SDR are configurable through IPMI v1.5 command
and are set to built-in initial value. Finally one field wich is the sensor owner must reflect the module
addresses that allow a system management software to identify the owner of the SDR when it is scanned from
the front board IPMC and merged within the IPMC Device SDR repository.
From IPMI prespective, the RTM8030 management controller is set up as a satellite management controller
(SMC). It does support sensor devices, and use the IPMI static sensor population feature of IPMI v1.5 to
12
RTM8030 User's Guide
Board Features
merge the hot swaped RTM sensor with the front board sensors population. The usual way the SHMC is
informed about an RTM insertion is through the RTM Module Hot Swap sensor and a radial presence line on
the RTM connector. All SDRs can be queried using Device SDR commands to the firmware. Module sensors
that have been implemented are listed below.
2.10.2
Hardware Sensors
Table 2-3:IPMI Hardware Sensors
Sensor Name
Voltage/Signals Monitored
Scanning Enabled Health LED
under Power
(Green to Amber)
State
IPMI Info-1
Internal IPMC firmware diagnostic
*
N
IPMI Info-2
Internal IPMC firmware diagnostic
*
N
FRU Agent
Board FRU Data agent that verify FRU Data validity
*
N
Module HS
RTM HS State
*
N
IPMBL State
Operational state of IPMB-L
*
N
MMC Stor Err
Management sub-system health: non volatile memory
error.
*
N
TempSensor1
Board Temperature Sensor
-
X
TempSensor2
Board Temperature Sensor
*
X
Vcc +3.3V
3.3 V
-
X
Vcc +3.3VSUS
3.3 V Suspend
*
X
Vcc +5V
5.0V
-
X
Vcc +12.0v
12.0 V
-
X
Vcc BlueLED
Voltage on blue LED board input power supply
*
X
Vcc +12VDisk
12.0V on HDD
-
X
Health Error
Board health sensors (aggregation of other sensors)
*
Asserted /
Desserted
MMC Reboot
MMC reboot detection
*
N
Ver change
MMC firmware upgrade detection
*
N
Power Good
Actual power status
*
N
Pres SFP-A
SFP presence status
*
N
Overlcc SFPA
SFP Over Current Status
-
N
OverlccRS232
RS-232 Over Surrent status
-
N
Overlcc USB0
USB Over Current status
-
N
X
Exceed critical threshold
*
Power On/Off
-
Power On
N
No change
13
RTM8030 User's Guide
Board Features
P30
J7
J10
SW3
SW1
J6B
J6C
J3
J6D
Temperature Sensor Locations
J2
2.10.2.1
Sensor 1
Sensor 2
2.10.2.2
IPMB-L Link Sensor
The RTM8030 has an IPMB-L links to communicate with the processor board and other devices in the chassis
chassis IPMB-0 bus. MMC monitors the bus for any link failure and sends the bus failure event to the front
board upon the recovery occurs.
2.10.2.3
Module Hot Swap
Similar to an AMC, a Hot Swap module is implemented. The hot-swap event message conveys the current
state of the module, the previous state and a cause of the state change as can be determined by the MMC.
Refer to AMC.0 R2.0 specifications for further details on the module hot-swap state.
2.10.3
Field Replaceable Unit (FRU) Information
The FRU Information provides inventory data about the boards where the FRU Information Device is located.
The part number or version number can be read through software.
FRU information in the RTM8030 includes data describing the RTM8030 board similar to AMC.0 R2.0
specification requirements. This information is retrieved by the RTM, enabling reporting of board-specific
information through a standardized mechanism.
Table 2-4:Board Information Area
Board Information Area
Field Description
Value (hex)
Format Version
0x01
Board Area Length
*Calculated
Language code
0x00
Manufacturing Date / Time
*Based on mfg. date
Board Manufacturer type/length
*Calculated
Board Manufacturer
“Kontron”
Board Product Name type/length
*Calculated
Board Product Name
“RTM8030”
14
RTM8030 User's Guide
Board Features
Board Information Area
Board Serial Number type/length
*Calculated
Board Serial Number
Manufacturer S/N
Board Part Number type/length
*Calculated
Board Customer Part Number
"T5704_XX"*
FRU File ID type/length
*Calculated
FRU File ID
"FRU5704_YY"**
No more fields
0xC1
Padding
0x00
Board Area Checksum
*Calculated
Table 2-5:Product Information Area
Product Information Area
Field Description
Value (hex)
Format Version
0x01
Product Area Length
*Calculated
Language Code
0x00
Manufacturer Name type/length
*Calculated
Manufacturer Name
“Kontron”
Product Name type/length
*Calculated
Product Name
“RTM8030”
Product Part/Model Number type/length
*Calculated
Product Part/Model Number
"T5704_XX"*
Product Version type/length
*Calculated
Product Version
“XX” *
Product Serial Number type/length
*Calculated
Product Serial Number
Manufacturer S/N
Asset Tag type/length
0xC0
Asset Tag
FRU File ID type/length
*Calculated
FRU File ID bytes
"FRU5704-YY"**
No more fields
0xC1
Padding
0x00
Product Info Area Checksum
*Calculated
15
RTM8030 User's Guide
Board Features
Table 2-6:Type 16 Module Current Requirements Records
Type 16 – Module Current Requirements Record
Record Type ID
C0h
Record format version
02h
Manufacturer ID
00315Ah (PICMG Record ID)
PICMG Record ID
16h (Module Power Descriptor table)
Record Format Version
00h
Current Draw
09h (0.9 Amps at 12 V => 10.8 Watts)
2.10.4
E-Keying
E-Keying has been defined in the AMC.0 R2.0 Specification to prevent module damage and prevent
misoperation and also to verify port connection compatibility. The FRU data contains the RTM point-to-point
connectivity record as described in Section 3.9.2 of the AMC.0 R2.0 specification. The records are formatted
as per AMC.0 R2.0 but the I/O ports assignation are OEM since AMC.0 does not specify RTM.
The Set/Get AMC Port State IPMI commands defined by the AMC.0 specification are used for either granting
or rejecting the E-keys.
Table 2-7:Type 19h - AMC Point-To-Point Connectivity Record
Type 19h - AMC Point-To-Point Connectivity Record
Record Type ID
C0h
Record format version
02h
Record Length
N/A
Record Checksum
N/A
Header Checksum
N/A
Manufacturer ID
00315Ah à PICMG Record ID
PICMG Record ID
19h à AMC Point-To-Point Connectivity Record
Record Format Version
00h
OEM GUID Count
04h
OEM GUID List
OEM GUID [F0]
Update Channel
OEM GUID [F1]
Serial
OEM GUID [F2]
100 BaseT
OEM GUID [F3]
USB
Record Type/Connected-device ID
89hà RTM
AMC Channel Descriptor Count
0Eh
16
RTM8030 User's Guide
Board Features
Table 2-8:Type 19h - AMC Point-To-Point Connectivity Record
Type 19h - AMC Point-To-Point Connectivity Record
AMC Channel Descriptor
0FFFFE0h (Ethernet Port)
Reserved (Bits 23-20)
0Fh
Lane 3 Port Number (Bits 19-15)
1Fh
Lane 2 Port Number (Bits 14-10)
1Fh
Lane 1 Port Number (Bits 9-5)
1Fh
Lane 0 Port Number (Bits 4-0)
00h
AMC Channel Descriptor
0FFFFE1h (Ethernet Port)
Reserved (Bits 23-20)
0Fh
Lane 3 Port Number (Bits 19-15)
1Fh
Lane 2 Port Number (Bits 14-10)
1Fh
Lane 1 Port Number (Bits 9-5)
1Fh
Lane 0 Port Number (Bits 4-0)
01h
AMC Channel Descriptor
0FFFFE2h (SAS)
Reserved (Bits 23-20)
0Fh
Lane 3 Port Number (Bits 19-15)
1Fh
Lane 2 Port Number (Bits 14-10)
1Fh
Lane 1 Port Number (Bits 9-5)
1Fh
Lane 0 Port Number (Bits 4-0)
02h
AMC Channel Descriptor
0FFFFE3h (SAS)
Reserved (Bits 23-20)
0Fh
Lane 3 Port Number (Bits 19-15)
1Fh
Lane 2 Port Number (Bits 14-10)
1Fh
Lane 1 Port Number (Bits 9-5)
1Fh
Lane 0 Port Number (Bits 4-0)
03h
AMC Channel Descriptor
0FFFFE4h (Ethernet Port 100BaseT)
Reserved (Bits 23-20)
0Fh
Lane 3 Port Number (Bits 19-15)
1Fh
Lane 2 Port Number (Bits 14-10)
1Fh
Lane 1 Port Number (Bits 9-5)
1Fh
Lane 0 Port Number (Bits 4-0)
04h
AMC Channel Descriptor
0FFFFEBh (Update Channel)
Reserved (Bits 23-20)
0Fh
Lane 3 Port Number (Bits 19-15)
1Fh
Lane 2 Port Number (Bits 14-10)
1Fh
Lane 1 Port Number (Bits 9-5)
1Fh
Lane 0 Port Number (Bits 4-0)
0Bh
17
RTM8030 User's Guide
Board Features
Table 2-9:Type 19h - AMC Point-To-Point Connectivity Record
Type 19h - AMC Point-To-Point Connectivity Record
AMC Channel Descriptor
0FFFFECh (Serial)
Reserved (Bits 23-20)
0Fh
Lane 3 Port Number (Bits 19-15)
1Fh
Lane 2 Port Number (Bits 14-10)
1Fh
Lane 1 Port Number (Bits 9-5)
1Fh
Lane 0 Port Number (Bits 4-0)
0Ch
AMC Channel Descriptor
0FFFFEDh (Serial)
Reserved (Bits 23-20)
0Fh
Lane 3 Port Number (Bits 19-15)
1Fh
Lane 2 Port Number (Bits 14-10)
1Fh
Lane 1 Port Number (Bits 9-5)
1Fh
Lane 0 Port Number (Bits 4-0)
0Dh
AMC Channel Descriptor
0FFFFEEh (Serial)
Reserved (Bits 23-20)
0Fh
Lane 3 Port Number (Bits 19-15)
1Fh
Lane 2 Port Number (Bits 14-10)
1Fh
Lane 1 Port Number (Bits 9-5)
1Fh
Lane 0 Port Number (Bits 4-0)
0Eh
AMC Channel Descriptor
0FFFFEFh (Serial)
Reserved (Bits 23-20)
0Fh
Lane 3 Port Number (Bits 19-15)
1Fh
Lane 2 Port Number (Bits 14-10)
1Fh
Lane 1 Port Number (Bits 9-5)
1Fh
Lane 0 Port Number (Bits 4-0)
0Fh
AMC Channel Descriptor
0FFFFF0h (Serial)
Reserved (Bits 23-20)
0Fh
Lane 3 Port Number (Bits 19-15)
1Fh
Lane 2 Port Number (Bits 14-10)
1Fh
Lane 1 Port Number (Bits 9-5)
1Fh
Lane 0 Port Number (Bits 4-0)
10h
AMC Channel Descriptor
0FFFFF1h (Serial)
Reserved (Bits 23-20)
0Fh
Lane 3 Port Number (Bits 19-15)
1Fh
Lane 2 Port Number (Bits 14-10)
1Fh
Lane 1 Port Number (Bits 9-5)
1Fh
Lane 0 Port Number (Bits 4-0)
11h
18
RTM8030 User's Guide
Board Features
Table 2-10:Type 19h - AMC Point-To-Point Connectivity Record
Type 19h - AMC Point-To-Point Connectivity Record
AMC Channel Descriptor
0FFFFF2h (Serial)
Reserved (Bits 23-20)
0Fh
Lane 3 Port Number (Bits 19-15)
1Fh
Lane 2 Port Number (Bits 14-10)
1Fh
Lane 1 Port Number (Bits 9-5)
1Fh
Lane 0 Port Number (Bits 4-0)
12h
AMC Channel Descriptor
0FFFFF3h (Serial)
Reserved (Bits 23-20)
0Fh
Lane 3 Port Number (Bits 19-15)
1Fh
Lane 2 Port Number (Bits 14-10)
1Fh
Lane 1 Port Number (Bits 9-5)
1Fh
Lane 0 Port Number (Bits 4-0)
13h
AMC Channel Descriptor
0FFFFF4h (USB)
Reserved (Bits 23-20)
0Fh
Lane 3 Port Number (Bits 19-15)
1Fh
Lane 2 Port Number (Bits 14-10)
1Fh
Lane 1 Port Number (Bits 9-5)
1Fh
Lane 0 Port Number (Bits 4-0)
14h
Table 2-11:Type 19h - AMC Point-To-Point Connectivity Record
Type 19h - AMC Point-To-Point Connectivity Record
AMC Link Descriptor
FC00005100h
Reserved (Bits 39-34)
03Fh
AMC Asymmetric Match (Bits 33-32)
00b à Exact match
Link Grouping ID (Bits 31-24)
00h à Single Channel Link
AMC Link Type Extension (Bits 23-20)
00h à 1000 Base BX
AMC Link Type (Bits 19-12)
005h à AMC.2 Ethernet
AMC Link Designator (Bits 11-0)
0100h à AMC Channel 0, lane 0
AMC Link Descriptor
FC00005101h
Reserved (Bits 39-34)
03Fh
AMC Asymmetric Match (Bits 33-32)
00b à Exact match
Link Grouping ID (Bits 31-24)
00h à Single Channel Link
AMC Link Type Extension (Bits 23-20)
00h à 1000 Base BX
AMC Link Type (Bits 19-12)
005h à AMC.2 Ethernet
AMC Link Designator (Bits 11-0)
0101h à AMC Channel 1, lane 0
AMC Link Descriptor
FC00207102h
Reserved (Bits 39-34)
03Fh
AMC Asymmetric Match (Bits 33-32)
00b à Exact match
Link Grouping ID (Bits 31-24)
00h à Single Channel Link
19
RTM8030 User's Guide
Board Features
Type 19h - AMC Point-To-Point Connectivity Record
AMC Link Type Extension (Bits 23-20)
02h à Serially Attached SCSI/SATA
AMC Link Type (Bits 19-12)
007h à AMC.3 Storage
AMC Link Designator (Bits 11-0)
0102h à AMC Channel 2, lane 0
AMC Link Descriptor
FD00107102h
Reserved (Bits 39-34)
03Fh
AMC Asymmetric Match (Bits 33-32)
01h -> Implements SATA Server
Interface
Link Grouping ID (Bits 31-24)
00h à Single Channel Link
AMC Link Type Extension (Bits 23-20)
01h à Serial ATA
AMC Link Type (Bits 19-12)
007h à AMC.3 Storage
AMC Link Designator (Bits 11-0)
0102h à AMC Channel 2, lane 0
AMC Link Descriptor
FC00207103h
Reserved (Bits 39-34)
03Fh
AMC Asymmetric Match (Bits 33-32)
00b à Exact match
Link Grouping ID (Bits 31-24)
00h à Single Channel Link
AMC Link Type Extension (Bits 23-20)
03h à Serially Attached SCSI/SATA
AMC Link Type (Bits 19-12)
007h à AMC.3 Storage
AMC Link Designator (Bits 11-0)
0103h à AMC Channel 3, lane 0
AMC Link Descriptor
FD00107103h
Reserved (Bits 39-34)
03Fh
AMC Asymmetric Match (Bits 33-32)
01h -> Implements SATA Server
Interface
Link Grouping ID (Bits 31-24)
00h à Single Channel Link
AMC Link Type Extension (Bits 23-20)
01h --> Serial ATA
AMC Link Type (Bits 19-12)
007h à AMC.3 Storage
AMC Link Designator (Bits 11-0)
0103h à AMC Channel 3, lane 0
Table 2-12:Type 19h - AMC Point-To-Point Connectivity Record
Type 19h - AMC Point-To-Point Connectivity Record
AMC Link Descriptor
FC000F2104h
Reserved (Bits 39-34)
03Fh
AMC Asymmetric Match (Bits 33-32)
00h ->Exact match
Link Grouping ID (Bits 31-24)
00h à Single Channel Link
AMC Link Type Extension (Bits 23-20)
00h -> None
AMC Link Type (Bits 19-12)
F2h: OEM GUID Definition (100 BaseT)
AMC Link Designator (Bits 11-0)
0104h à AMC Channel 4, lane 0
AMC Link Descriptor
FC000F0105h
Reserved (Bits 39-34)
03Fh
AMC Asymmetric Match (Bits 33-32)
00h ->Exact match
Link Grouping ID (Bits 31-24)
00h -> Single Channel Link
AMC Link Type Extension (Bits 23-20)
00h -> None
20
RTM8030 User's Guide
Board Features
Type 19h - AMC Point-To-Point Connectivity Record
F0h : OEM GUID Definition (Update
Channel)
AMC Link Type (Bits 19-12)
AMC Link Designator (Bits 11-0)
0105h --> AMC Channel 5, lane 0
AMC Link Descriptor
FC000F1106h
Reserved (Bits 39-34)
03Fh
AMC Asymmetric Match (Bits 33-32)
00b à Exact match
Link Grouping ID (Bits 31-24)
00h à Single Channel Link
AMC Link Type Extension (Bits 23-20)
00h à None
AMC Link Type (Bits 19-12)
F1h : OEM GUID Definition (Serial)
AMC Link Designator (Bits 11-0)
0106h à AMC Channel 6, lane 0
AMC Link Descriptor
FC000F1107h
Reserved (Bits 39-34)
03Fh
AMC Asymmetric Match (Bits 33-32)
00b à Exact match
Link Grouping ID (Bits 31-24)
00h à Single Channel Link
AMC Link Type Extension (Bits 23-20)
00h à None
AMC Link Type (Bits 19-12)
F1h : OEM GUID Definition (Serial)
AMC Link Designator (Bits 11-0)
0107h --> AMC Channel 7, lane 0
AMC Link Descriptor
FC000F1108h
Reserved (Bits 39-34)
03Fh
AMC Asymmetric Match (Bits 33-32)
00b à Exact match
Link Grouping ID (Bits 31-24)
00h à Single Channel Link
AMC Link Type Extension (Bits 23-20)
00h à None
AMC Link Type (Bits 19-12)
F1h : OEM GUID Definition (Serial)
AMC Link Designator (Bits 11-0)
0108h à AMC Channel 8, lane 0
AMC Link Descriptor
FC000F1109h
Reserved (Bits 39-34)
03Fh
AMC Asymmetric Match (Bits 33-32)
00b à Exact match
Link Grouping ID (Bits 31-24)
00h à Single Channel Link
AMC Link Type Extension (Bits 23-20)
00h à None
AMC Link Type (Bits 19-12)
F1h : OEM GUID Definition (Serial)
AMC Link Designator (Bits 11-0)
0109h --> AMC Channel 9, lane 0
Table 2-13:Type 19h - AMC Point-To-Point Connectivity Record
Type 19h - AMC Point-To-Point Connectivity Record
AMC Link Descriptor
FC000F110Ah
Reserved (Bits 39-34)
03Fh
AMC Asymmetric Match (Bits 33-32)
00b à Exact match
Link Grouping ID (Bits 31-24)
00h à Single Channel Link
AMC Link Type Extension (Bits 23-20)
00h à None
AMC Link Type (Bits 19-12)
F1h : OEM GUID Definition (Serial)
21
RTM8030 User's Guide
Board Features
Type 19h - AMC Point-To-Point Connectivity Record
AMC Link Designator (Bits 11-0)
010Ah à AMC Channel 10, lane 0
AMC Link Descriptor
FC000F110Bh
Reserved (Bits 39-34)
03Fh
AMC Asymmetric Match (Bits 33-32)
00b à Exact match
Link Grouping ID (Bits 31-24)
00h à Single Channel Link
AMC Link Type Extension (Bits 23-20)
00h à None
AMC Link Type (Bits 19-12)
F1h : OEM GUID Definition (Serial)
AMC Link Designator (Bits 11-0)
010Bh à AMC Channel 11, lane 0
AMC Link Descriptor
FC000F110Ch
Reserved (Bits 39-34)
03Fh
AMC Asymmetric Match (Bits 33-32)
00b à Exact match
Link Grouping ID (Bits 31-24)
00h à Single Channel Link
AMC Link Type Extension (Bits 23-20)
00h à None
AMC Link Type (Bits 19-12)
F1h : OEM GUID Definition (Serial)
AMC Link Designator (Bits 11-0)
010Ch à AMC Channel 12, lane 0
AMC Link Descriptor
FC000F110Dh
Reserved (Bits 39-34)
03Fh
AMC Asymmetric Match (Bits 33-32)
00b à Exact match
Link Grouping ID (Bits 31-24)
00h à Single Channel Link
AMC Link Type Extension (Bits 23-20)
00h à None
AMC Link Type (Bits 19-12)
F1h : OEM GUID Definition (Serial)
AMC Link Designator (Bits 11-0)
010D à AMC Channel 13, lane 0
AMC Link Descriptor
FC000F310Eh
Reserved (Bits 39-34)
03Fh
AMC Asymmetric Match (Bits 33-32)
00b à Exact match
Link Grouping ID (Bits 31-24)
00h à Single Channel Link
AMC Link Type Extension (Bits 23-20)
00h à None
AMC Link Type (Bits 19-12)
F3h : OEM GUID Definition (USB)
AMC Link Designator (Bits 11-0)
010E à AMC Channel 14, lane 0
2.10.5
MMC Firmware Code
MMC firmware code is organized into boot code and operational code, both of which are stored in a flash
module. Upon an MMC reset, the MMC executes the boot code and performs the following:
1 Self test to verify the status of its hardware and memory.
2 Performs a checksum of the operational code.
3 Set operational state that tells the boot block the firmware operate correctly.
Upon successful verification of the operational code checksum, the firmware will jump to the operational
code.
22
RTM8030 User's Guide
Board Features
2.10.6
MMC Firmware Upgrade Procedure
The upgrade procedure is compliant to PICMG HPM.1. MMC Firmware upgrades can be done by using
IPMITOOL from sourceforge from the front blade or remotely on the chassis. It has been designed to upgrade
through any IPMI interface without payload impact.
23
RTM8030 User's Guide
Board Features
2.10.7
Boot Block Upgrade Procedure
Type the following to perform MMC firmware upgrade
ipmifwu -fb <file> -P /dev/ttyS0 -M rtm -p <ENTER>
Note:
During boot block firmware upgrade the MMC is held in reset
2.10.7.1
Hot-Swap Process
The RTM8030 has the ability to be hot-swapped in and out of the front board. The onboard MMC manages the
RTM's power-up and power-down transitions. The list below illustrates this process for power down request.
1 Ejector latch is opened. HOT_SWAP_PB# assertion. MMC firmware detects the assertion of this signal.
2 MMC sends "Module Handle Open" event message to the front board. The corresponding M state of the
front board moves from M4-> M5.
3 The front board moves from M5 -> M6 if the SHMC grants the request. The front board IPMC sends the FRU
control requesting quiesced state to the RTM.
4 The firmware deasserts payload power and sends "Module Quiesced" event message to the front board
where it transitions from M6 to M1 state.
2.10.7.2
Hot-Swap LED
The RTM8030 supports a blue Hot Swap LED mounted on the front panel. This LED indicates when it is safe to
remove the RTM from the front board. The on-board MMC drives this LED to indicate the hot-swap state. The
following states are possible:
Table 2-14:Hot-Swap LED Description
LED state
Description
OFF
M4 state; normal state when board is in operation.
ON
M1 state; ready for hot swap.
Short blink
M5 state; deactivation request
Long blink
M2 state; activation request.
When the RTM latch is disengaged from the faceplate, the hot swap switch embedded in the PCB will assert a
"HOT_SWAP_PB#" signal to the MMC, and the MMC will send “Module Handle Open” event message to the
front board which moves from the M4 state to the M5 state. At the M5 state, the front board will ask the SHMC
(or Shelf Manager) for permission to move the RTM to the M6 state. Then the IPMC of the front board,
through IPMB-L, will set the RTM Hot Swap LED to indicate this state with a short blink. Once permission is
received from the SHMC or higher-level software, the front board will move to the M6 state.
The SHMC or higher level software can reject the request to move to the M6 state. If this occurs, the RTM will
returns the Hot Swap LED to a solid off condition, indicating that the RTM has returned to M4 state.
If the RTM reaches the M6 state through an extraction request through the RTM handle latch, the MMC
communicates to the front board that the module must discontinue operation in preparation for removal.
24
RTM8030 User's Guide
Board Features
The Hot Swap LED continues to flash during this preparation time, just like it does at the M5 state. When
main RTM payload power is successfully removed from the RTM slot, the Hot Swap LED remains lit, indicating
it is safe to remove the RTM from the chassis.
2.11 Debugging Features
All LEDs are “user” overritable by using standard PICMG LED api.
2.11.1
Hot Swap LED (LED0)
The Blue / Hot Swap LED indicates the hot swap status of the RTM. The LED is ON when it is safe to remove the
RTM from the slot. During normal operation, this LED is OFF.
2.11.2
Out Of Service (LED1)
The AdvancedTCA LED1 is red or amber and indicates an Out-of-Service (OOS) condition. During normal
operation, the OOS LED is OFF. This LED is ON during firmware upgrade and is user configurable if needed by a
customer application.
2.11.3
Healthy LED (LED2)
The AdvancedTCA LED2 is green or amber and indicates a healthy condition. The healthy LED indicates if the
blade is powered up and all voltages and temperatures are within specifications. During normal operation,
this LED is ON (green). This LED is also ON (amber) when one of the RTM8030 voltage or temperature fails.
25
RTM8030 User's Guide
Installing the Board
3. Installing the Board
3.1
Setting Jumper
3.1.1
Jumper Description
Table 3-1:Jumper Description
Name
Description
Jumper
SAS Output
When JP4 is IN, the SAS External Connector is Enabled.
When JP4 is OUT, the onboard SAS Hard Disk is Enabled.
JP4
3.1.2
Setting Jumper & Location
JP4
Figure 3-1:Setting Jumper & Location
P30
JUMPER SETTINGS
( Default Setting)
J2
J3
SAS Connector
USB
J6D
Ethernet
J6C
Serial Port
1-7
J6B
Serial Port
0
M
JP4 - SAS Output
SAS External Connector
Onboard SAS HDD
in
out
SW1
Rotary Switch
Channel
1-7
0
1-7
Reset
26
RTM8030 User's Guide
Installing the Board
3.2
Board Hot Swap and Installation
Because of the high-density pinout of the hard-metric connector, some precautions must be taken when
connecting or disconnecting a board to/from a backplane:
1 Rail guides must be installed on the enclosure to slide the board to the backplane.
2 Do not force the board if there is mechanical resistance while inserting the board.
3 Screw the frontplate to the enclosure to firmly attach the board to its enclosure.
4 Use extractor handles to disconnect and extract the board from its enclosure.
WARNING
Always use a grounding wrist wrap before installing or removing the board from a
chassis.
3.2.1
Installing the RTM in the chassis
To install the RTM:
1 Remove the filler panel of the slot.
2 Ensure the board is configured properly.
3 Carefully align the PCB edges in the bottom and top card guide.
4 Insert the board in the system until it makes contact with the CPU board.
5 Using both ejector handles, engage the board in the CPU board connectors until both ejectors are locked.
6 Fasten screws at the top and bottom of the faceplate.
3.2.2
Removing the RTM from the chassis
To remove the RTM:
1 Unscrew the top and the bottom screw of the faceplate.
2 Unlock the lower handle latch.
3 Wait until the blue LED is fully ON, this mean that the hot swap sequence is ready for board removal.
4 Use both ejectors to disengage the board from the CPU board.
5 Pull the board out of the chassis.
27
RTM8030 User's Guide
A. Connector Pinouts
A.1
Connector
Connectors and Headers Summary
Description
P30
RTM Connector
J2
SAS Faceplate Connector
J3
USB 2.0 Connector
J6B
Serial Port
J6C
Serial Port
J6D
Ethernet
J7
SFP (Ethernet)
J10
SAS Hard Disk Connector
A-1
RTM8030 User's Guide
A.2
AdvancedTCA I/O RTM Connector (P30)
Pin
ROW A
ROW B
ROW C
ROW D
ROW E
ROW F
1
V_12V_1
V_12V_5
V_12V_2
V_3V2_SUS
RTM_EJECT
RTM_PRSNT#
2
V_12V_3
V_12V_6
V_12V_4
IPMC_INT#
IPMC_SCL
IPMC_SDA
3
RS232_0_TX
RS232_0_RX
JTAG_TDI
JTAG_TDO
JTAG_TMS
JTAG_TCK
4
SOCA
SOCB
INT_0
INT_1
RTML_TX
RTML_RX
5
RS232_1_TX
RS232_1_RX
RS232_2_TX
RS232_2_RX
RS232_3_TX
RS232_3_RX
6
RS232_5_TX
RS232_5_RX
RS232_6_TX
RS232_6_RX
RS232_7_TX
RS232_7_RX
7
N.U.
N.U.
N.U.
N.U.
RESET_0#
RESET_1#
8
100BASE_TX+
100BASE_TX-
100BASE_RX+
100BASE_RX-
100BASE_CT
N.C.
9
SAS_0_TX+
SAS_0_TX-
SAS_0_RX+
SAS_0_RX-
SAS_1_TX+
SAS_1_TX-
10
1000BX_TX_1+
1000BX_TX1-
1000BX_RX1+
1000BX_RX1-
1000BX_TX2+
1000BX_TX2-
Pin
ROW G
ROW H
ROW AB
ROW CD
ROW EF
ROW GH
1
N.C.
RTM_EN#
GND
GND
GND
GND
2
USB_D+
USB_D-
GND
GND
GND
GND
3
JTAG_TRST
N.C.
GND
GND
GND
GND
4
RTML_CLK
RESET
GND
GND
GND
GND
5
RS232_4_TX
RS232_4_RX
GND
GND
GND
GND
6
UC_SCL
UC_SDA
GND
GND
GND
GND
7
RESET_2#
RESET_3#
GND
GND
GND
GND
8
N.C.
N.C.
GND
GND
GND
GND
9
SAS_1_RX+
SAS_1_RX-
GND
GND
GND
GND
10
1000BX_RX2+
1000BX_RX2-
GND
GND
GND
GND
A-2
RTM8030 User's Guide
A.3
SAS Faceplate Connector (J2)
Pin
Signal
Pin
Signal
S1
RX_0+
G1
GND
S2
RX_0-
G2
GND
S3
RX_1+
G3
GND
S4
RX_1-
G4
GND
S5
N.C.
G5
GND
S6
N.C.
G6
GND
S7
N.C.
G7
GND
S8
N.C.
G8
GND
S9
N.C.
G9
GND
S10
N.C.
S11
N.C.
MTG1
CGND_1
S12
N.C.
MTG2
CGND_2
S13
TX_1-
S14
TX_1+
S15
TX_0-
S16
TX_0+
A.4
USB Port (J3)
Pin
Signal
1
VCC
2
DATA-
3
DATA+
4
GND
A.5
SERIAL PORT(J6B & J6C)
Pin
Signal
1
N.C.
2
N.C.
3
TX#
4
GND
5
GND
6
RX#
7
N.C.
8
N.C.
A-3
RTM8030 User's Guide
A.6
Pin
Ethernet(J6D)
Signal
1
TX+
2
TX-
3
RX+
4
N.C.
5
N.C.
6
RX-
7
N.C.
8
N.C.
A.7
SFP Channel (J7)
Pin
Signal
Pin
Signal
Pin
Signal
1
VEET_1
11
VEER_3
21
cGND_1
2
TX_FAULT
12
RD-
22
cGND_2
3
TX_DIS
13
RD+
23
cGND_3
4
MODDEF2
14
VEER_4
24
cGND_4
5
MODDEF1
15
VCCR
25
cGND_5
6
MODEFF0
16
VCCT
26
cGND_6
7
R_SEL
17
VEET_2
27
cGND_7
8
LOS
18
TD+
28
cGND_8
9
VEER1
19
TD-
29
cGND_9
10
VEER2
20
VEET_3
30
cGND_10
31
cGND_11
A-4
RTM8030 User's Guide
A.8
SAS Hard Drive Connector (J10)
Pin
Signal
Pin
Signal
S1
S2
GND
P1
3.3V
PortA_TX+
P2
3.3V
S3
PortA_TX-
P3
3.3V
S4
GND
P4
GND
S5
PortA_RX-
P5
GND
S6
PortA_RX+
P6
GND
S7
GND
P7
5V
S8
GND
P8
5V
S9
PortB_TX+
P9
5V
S10
PortB_TX-
P10
GND
S11
GND
P11
Ready LED
S12
PortB_RX-
P12
GND
S13
PortB_RX+
P13
12V
S14
GND
P14
12V
P15
12V
A-5
RTM8030 User's Guide
B. Software Update
B.1
MMC Firmware Update Procedure
The MMC Firmware update procedure is detailed in a ReadMe file included with the MMC Firmware package as
well as the update utility. This package can be downloaded from our website http://www.kontron.com or
from our FTP site ftp://ftp.kontron.ca/Support. The firmware update procedure is also compliant to PICMG
HPM.1 wich define a standard way for update process.
B-1
RTM8030 User's Guide
C. Getting Help
If, at any time, you encounter difficulties with your application or with any of our products, or if you simply
need guidance on system setups and capabilities, contact our Technical Support at:
North America
EMEA
Tel.: (450) 437-5682
Tel.: +49 (0) 8341 803 333
Fax: (450) 437-8053
Fax: +49 (0) 8341 803 339
If you have any questions about Kontron, our products, or services, visit our Web site at: www.kontron.com
You also can contact us by E-mail at:
North America: [email protected]
EMEA: [email protected]
Or at the following address:
North America
Kontron Canada, Inc.
EMEA
Kontron Modular Computers GmbH
4555, Ambroise-Lafortune
Sudetenstrasse 7
Boisbriand, Québec
87600 Kaufbeuren
J7H 0A4 Canada
Germany
C-1
RTM8030 User's Guide
C.1
Returning Defective Merchandise
Before returning any merchandise please do one of the following:
• Call
1Call our Technical Support department in North America at (450) 437-5682 and in EMEA at +49 (0)
8341 803 333. Make sure you have the following on hand: our Invoice #, your Purchase Order #,
and the Serial Number of the defective unit.
2Provide the serial number found on the back of the unit and explain the nature of your problem to
a service technician.
3The technician will instruct you on the return procedure if the problem cannot be solved over the
telephone.
4Make sure you receive an RMA # from our Technical Support before returning any merchandise.
• Fax
1Make a copy of the request form on the following page.
2Fill it out.
3Fax it to us at: North America (450) 437-0304, EMEA +49 (0) 8341 803 339
• E-mail
1Send us an e-mail at: [email protected] in North America and at: [email protected] in EMEA. In the e-mail, you must include your name, your company name, your
address, your city, your postal/zip code, your phone number, and your e-mail. You must also
include the serial number of the defective product and a description of the problem.
C-2
RTM8030 User's Guide
C.2
When Returning a Unit
•In the box, you must include the name and telephone number of a contact person, in case further
explanations are required. Where applicable, always include all duty papers and invoice(s)
associated with the item(s) in question.
•Ensure that the unit is properly packed. Pack it in a rigid cardboard box.
•Clearly write or mark the RMA number on the outside of the package you are returning.
•Ship prepaid. We take care of insuring incoming units.
North America
Kontron Canada, Inc.
EMEA
Kontron Modular Computers GmbH
4555, Ambroise-Lafortune
Sudetenstrasse 7
Boisbriand, Québec
87600 Kaufbeuren
J7H 0A4 Canada
Germany
C-3
RTM8030 User's Guide
Return to
Manufacturer
Authorization Request
Contact Name:
______________________________________________________________
Company Name:
______________________________________________________________
Street Address:
______________________________________________________________
City:
__________________________
Province/State:
_________________________
Country:
__________________________
Postal/Zip Code:
_________________________
Phone Number:
__________________________
Extension:
_________________________
Fax Number:
__________________________
E-Mail:
_________________________
Serial Number
Failure or Problem Description
P.O. #
(if not under warranty)
Fax this form to Kontron’s Technical Support department
in North America at (450) 437-0304
in EMEA at +49 (0) 8341 803 339
C-4
RTM8030 User's Guide
D. Glossary
Acronyms
Descriptions
6U
CompactPCI board size (3U = 100 mm by 160 mm, 6U = 233.35 mm by 160 mm). Refers to height.
8HP
Horizontal Pitch (1 HP = .2 inches, a CompactPCI board is 4HP, Dual width CompactPCI board is 8HP).
Refers to width.
ACL
Access Control List. IP Access Control List.
ACPI
Advanced Configuration & Power Interface
ADC
Analog to Digital Converter
AdvancedMC
(Same as AMC). Advanced Mezzanine Card.
AER
Advanced Error Reporting. PCI Express device capability for more robust error reporting and is
implemented with a specific PCI Express capability structure. See the PCI Express Base Specification.
AMC
(Same as AdvancedMC). Advanced Mezzanine Card.
AMC.0
Advanced Mezzanine Card Base Specification.
AMC.1
PCI Express and Advanced Switching on AdvancedMC. A subsidiary specification to the Advanced
Mezzanine Card Base Specification (AMC.0).
AMC.2
Ethernet Advanced Mezzanine Card Specification. A subsidiary specification to the Advanced
Mezzanine Card Base Specification (AMC.0).
AMC.3
Advanced Mezzanine Card Specification for Storage. A subsidiary specification to the Advanced
Mezzanine Card Base Specification (AMC.0).
ANSI
American National Standards Institute
API
Application Programming Interface
APIC
Advanced Programmable Interrupt Controller
APM
Advanced Power Management
ARMD
ATAPI Removable Media Device
ARP
Address Resolution Protocol
ASCII
American Standard Code for Information Interchange. ASCII codes represent text in computers,
communications equipment, and other devices that work with text.
ASF
Alert Standard Format. A standard for how alerting and remote-control capabilities on network
controllers work.
ATA
Advanced Technology Attachment
ATAPI
Advanced Technology Attachment Packet Interface
ATCA
Advanced Telecommunications Computing Architecture
ATX
Advanced Technology Extended. Form factor for computer case.
BBS
BIOS Boot Specification
BCD
Binary-Coded Decimal
BDA
BIOS Data Area
BER
Bit Error Ratio
BEV
Bootstrap Entry Vector
BI
Base Interface. Backplane connectivity defined by the ATCA.
BIOS
Basic Input/Output System
BIST
Built-in Self Test
BMC
Base Management Controller
BOM
Bill Of Material
D-1
RTM8030 User's Guide
Acronyms
Descriptions
BT
Block Transfer. An optional IPMI system management interface.
CAD
Computer-Aided Design
CB
Certification Body
CCB
Core Complex Bus (Inside PowerQuicc III CPU)
CD
Compact Disk
CDROM
(Same as CD-ROM). Compact Disk Read-Only Memory.
CD-ROM
(Same as CDROM). Compact Disk Read-Only Memory.
CFM
Cubic Foot per Minute
CISPR22
Comité International Spécial des Perturbations Radioélectriques publication 22. Special
International Committee on Radio Interference publication 22.
CLI
Command-Line Interface
CLK1
AdvancedTCA bused resource Synch clock group 1
CLK1A
AdvancedTCA bused resource Synch clock group 1, bus A
CLK1B
AdvancedTCA bused resource Synch clock group 1, bus A
CLK2
AdvancedTCA bused resource Synch clock group 2
CLK2A
AdvancedTCA bused resource Synch clock group 2, bus A
CLK2B
AdvancedTCA bused resource Synch clock group 2, bus B
CLK3
AdvancedTCA bused resource Synch clock group 3
CLK3A
AdvancedTCA bused resource Synch clock group 3 , bus A
CLK3B
AdvancedTCA bused resource Synch clock group 3 , bus B
CMIC
CPU Management Interface Controller
CMOS
Complementary Metal Oxide Semiconductor. Also refers to the small amount of battery (or capacitor)
powered CMOS memory to hold the date, time, and system setup parameters.
CMP
Core Multi-Processing
COP
Common On-chip Processor. Common on-chip processor function.
COTS
Commercial-Off-The-Shelf
CPCI
Compact PCI
CPLD
Complex Programmable Logic Device
CP-TA
Communications Platforms Trade Association
CPU
Central Processing Unit. This sometimes refers to a whole blade, not just a processor component.
CPUID
CPU IDentification. Code that uniquely identify a processor type.
CRC
Cyclic Redundancy Check
CS1
Components Side 1 as describes in PICMG3.0.
CS2
Components Side 1 as describes in PICMG3.0.
CTCA
Compact Telecom Computing Architecture
CTS
Clear To Send
DC
Direct Current
DCM
Daughter Card Mezzanine
DDR
DDR SDRAM or Double-Data-Rate
DDR2
(Same as DDR-II). DDR2 SDRAM or Double-Data-Rate two (2) Synchronous Dynamic Random Access
Memory.
DDR-II
(Same as DDR2). DDR2 SDRAM or Double-Data-Rate two (2) Synchronous Dynamic Random Access
Memory.
D-2
RTM8030 User's Guide
Acronyms
Descriptions
DED
Double-bit Error Detect or Double-symbol Error Detect.
DFTG
Design For Testability Guidelines
DHCP
Dynamic Host Configuration Protocol
DIMM
Dual In-line Memory Module
DIN
Deutsches Institut für Normung. German Institute for Standardization.
DMA
Direct Memory Access
DMI
Desktop Management Interface
DOS
Disk Operating System
DPLL
Digital Phase-Locked Loop
DRAM
Dynamic Random Access Memory
DSP
Digital Signal Processing
DTC
Data Transfer Controller
DTR
Data Terminal Ready
DTS
Digital Thermal Sensor in IA32 processors.
DUART
Dual Universal Asynchronous Receiver/Transmitter
DVD
Digital Video Disk
ECC
Error Checking and Correction
EDMA
Enhanced Direct Memory Access
EEPROM
Electrically Erasable Programmable Read-Only Memory
ECM
E500 Coherency Module.
EFI
Extensible Firmware Interface
EFT
Electric Fast Transient
EHCI
Enhanced Host Controller Interface. Specification for Universal Serial Bus specification, revision 2.0.
EIA
Electronic Industries Alliance
EISA
Extended Industry Standard Architecture. Superset of ISA, 32-bit bus architecture.
EIST
(Same as SpeedStep). Enhanced Intel SpeedStep Technology
EM64T
Extended Memory 64 Technology. Intel 64 is Intel's implementation of x86-64 used by 64-bit
operating systems.
EMC
ElectroMagnetic Compatibility
EMI
ElectroMagnetic Interference
EMTTM
Turbo mode and enhanced Multi Threaded Thermal Management
EOL
End Of Life
EPS
Engineering Product Specification
ERM
Electromagnetic compatibility and Radio spectrum Matters
ES
Ethernet Switch
ESD
ElectroStatic Discharge
ESI
Enterprise South bridge Interface. Interface to the I/O legacy bridge component of the Intel ICHx.
ETH
Same as Ethernet.
ETSI
European Telecommunications Standards Institute
FADT
Fixed ACPI Description Table
FAT
File Allocation Table. Usually followed by a number, ex.: FAT32, which defines the number of bits used
to address clusters on a disk.
D-3
RTM8030 User's Guide
Acronyms
Descriptions
FC
Fibre Channel
FCC
Federal Communications Commission
FCPGA
Flip-Chip Pin Grid Array
FCS
First Customer Shipment. Refers to Kontron scheduling for boards.
FC-AL
Fibre Channel-Arbitrated Loop
FDD
Floppy Disk Drive
FI
Fabric Interface. Backplane connectivity defined by the ATCA.
FIFO
First In First Out
FML
Fast Management Link
FPGA
Field-Programmable Gate Array
FPL
FPGA-to-PLD Link. FPL is a 20 MHz serial link that exchange 32-bit of data in each direction between
the FPGA and a companion PLD. Comes from Kontron Canada.
FRBx
Fault-Resilient Booting level [1-3]. A term used to describe system features and algorithms that
improve the likelihood of the detection of, and recovery from, processor failures in a multiprocessor
system.
FRB2
Fault-Resilient Booting, Level 2.
FRT
Free-Running Timer
FRU
Field Replaceable Unit. Any entity that can be replaced by a user in the field. Not all FRUs are hot
swappable.
FSB
Front Side Bus
FTP
File Transfer Protocol
FW
FirmWare
FWH
FirmWare Hub. Boot flash connected to the LPC bus containing BIOS FW.
GA
Geographic Address
GARP
Generic Attribute Registration Protocol
Gb
Gigabit
GB
(Same as GByte) GigaByte.
GByte
(Same as GB) GigaByte.
GbE
Gigabit Ethernet
GHz
GigaHertz
GMRP
GARP Multicast Registration Protocol
GND
GrouND
GPCM
General-Purpose Chip select Machine
GPI
General Purpose Input
GPIO
General Purpose Input Output
GPO
General Purpose Output
GRUB
GRand Unified Bootloader
GUID
Globally Unique Identifier
GVRP
GARP VLAN Registration Protocol
HDD
Hard Disc Drive
HFM
High Frequency Mode. The highest operating speed for the processor.
HMS
Hardware Management System
HPM
PICMG Hardware Platform Management specification family
D-4
RTM8030 User's Guide
Acronyms
Descriptions
HPM.1
Hardware Platform Management IPM Controller Firmware Upgrade Specification
HW
HardWare
HWS
HardWare Specification
I2C
Inter Integrated Circuit bus
IA-32
(Same as IA32). Intel Architecture 32 bits
IA32
(Same as IA-32). Intel Architecture 32 bits
IBA
Intel Boot Agent
IC
Integrated Circuit
ICE
In-Circuit Emulator
ICH
I/O Controller Hub
ICT
In-Circuit Test
ID
IDentification
IDE
Integrated Drive Electronics
IEC
International Electrotechnical Commission
IICH
Integrated I/O Controller Hub
IMCH
Integrated Memory Controller Hub
IEEE
Institute of Electrical and Electronics Engineers
IERR
Internal ERRor. A signal from the Intel Architecture processors indicating an internal error condition.
IICH
Integrated I/O Controller Hub. Sub-part of the MICH chipset.
INT
INTerrupt
IMCH
Integrated Memory Controller Hub. Sub-part of the MICH chipset.
iMPACT
Xilinx iMPACT, a tool featuring batch and GUI operations, allows you to perform two basic functions:
Device Configuration and File Generation.
IMVP-6
Intel Mobile Voltage Positioning. The Intel Mobile Voltage Positioning specification for the Intel®
Core™ Duo Processor. It is a DC-DC converter module that supplies the required voltage and current
to a single processor.
IO
(Same as I/O). Input Output
IOAPIC
(Same as IO-APIC). IO Advanced Programmable Interrupt Controller
IOH
I/O Hub
IO-APIC
(Same as IOAPIC). IO Advanced Programmable Interrupt Controller
IOL
IPMI-Over-LAN
IP
Internet Protocol
IPM
Intelligent Platform Management
IPMB
Intelligent Platform Management Bus
IPMB-0
Intelligent Platform Management Bus Channel 0, the logical aggregation of IPMB-A and IPMB-B.
IPMB-A
Intelligent Platform Management Bus A
IPMB-B
Intelligent Platform Management Bus B
IPMB-L
Intelligent Platform Management Bus Local
IPMC
Intelligent Platform Management Controller
IPMI
Intelligent Platform Management Interface
IPMIFWU
Intelligent Platform Management Interface FirmWare Update
IPv6
Internet Protocol version 6
IRQ
Interrupt ReQuest
D-5
RTM8030 User's Guide
Acronyms
Descriptions
ISA
Industry Standard Architecture. 16-bit (XT) bus architecture.
ISE
Xilinx electronic design automation (EDA) tools for use with its devices.
ISO
International Organization for Standardization
ITU
International Telecommunication Union
ITU-T
ITU Telecommunication standardization sector. ITU is International Telecommunication Union.
JEDEC
Joint Electron Device Engineering Council
JTAG
Joint Test Action Group
KB
KiloByte
KCS
Keyboard Controller Style. An IPMI system interface.
KCS-SMM
Keyboard Controller Style. BIOS private IPMI system interface.
KCS-SMS
Keyboard Controller Style. Application IPMI system interface.
KHz
KiloHertz
LAN
Local Area Network
LBA
Logical Block Addressing
LBC
Local Bus Controller (On PowerQuicc III CPU)
LED
Light-Emitting Diode
LFCS
Limited First Customer Shipment. Refers to Kontron scheduling for boards.
LFM
Low Frequency Mode. The lowest operating speed for the processor.
LIP
Loop Initialization Primitive. Related to FC arbitrated loop topology (an initial message needed for
learning the loop addresses and acquiring one).
LPC
Low Pin Count port
LPT1
Line Print Terminal 1
LSB
Least Significant Byte
LUN
Logical Unit Number
LV
Low Voltage
LVCMOS
Low-Voltage Complementary Metal Oxide Semiconductor
LVDS
Low-Voltage Differential Signaling
MAC
Media Access Controller address of a computer networking device.
MB
MegaByte
MBE
Multiple Bit Error
MBIST
(same as MemBIST). Memory Built-In Selft-Test. Chipset feature for out-of-band memory testing and
intialization.
MBR
Master Boot Record
MC
Management Controller
MCH
Memory Controller Hub
MemBIST
(same as MBIST). Memory Built-In Selft-Test. Chipset feature for out-of-band memory testing and
intialization.
MDn
Message Digest algorithm (n=2, 5)
MDI
Medium Dependent Interface. MDI port or uplink port.
MHz
MegaHertz
MICH
Memory controller Hub and I/O Controller Hub. Chipset that integrates IMCH and IICH in a single chip
solution.
Microcode
Intel-supplied data block used to correct specific errata in the processor.
D-6
RTM8030 User's Guide
Acronyms
Descriptions
MII
Media Independent Interface
MIIM
Media Independent Interface Management
MLVDS
Multipoint Low-Voltage Differential Signaling
MMC
Module Management Controller. MMCs are linked to the IPMC.
MMIO
Memory-Mapped IO
MOSFET
Metal-Oxide-Semiconductor Field-Effect Transistor
MP
MultiProcessor
MPS
MultiProcessor Specification
MRC
Memory Reference Code. Chipset specific code provided by the manufacturer and integrated into the
BIOS to test and intialize the system memory.
MSB
Most Significant Byte
MSI
Message Signaled Interrupts
MSR
Model Specific Register inside IA32 processors.
MTBF
Mean Time Between Failures
MTRR
Memory Type Range Register. CPU cache control registers.
MUX
MUltipleXer
NAND
Type of Flash Memory, used for mass storage.
NC
Not Connected
NDA
Non-Disclosure Agreement
NEBS
Network Equipment-Building System
NEDS
Network Equipment Development Standard
NMI
Non-Maskable Interrupt
NSI
North South Interface. Internal physical interface between the IMCH and IICH.
NV
Non-Volative. Refers to persistent storage.
NVRAM
Non-Volatile Random Access Memory
NVS
Non-Volatile Storage
O&M
(Same as OAM/OA&M). Operations and Maintenance
OAM
(Same as OA&M/O&M). Operations, Administration and Maintenance
OA&M
(Same as OAM/O&M). Operations, Administration and Maintenance
OEM
Original Equipment Manufacturer
OMU
Operations and maintenance Unit
OOS
Out Of Service
OS
Operating System
OSI
Open Source Initiative
PAE
Physical Address Extension. Feature of x86 processors that allows for up to 64 gigabytes of physical
memory to be used in 32-bit systems, given appropriate operating system support.
PAM
Programmable Attribute Map. Chipset registers that controls the steering of read and write cycles
that address the BIOS area.
PCB
Printed Circuit Board
PCI
Peripheral Component Interconnect
PCI-32
Peripheral Component Interconnect 32 bits
PCI®
Peripheral Component Interconnect
PCIe
(Same as PCI-E). PCI-Express. Next generation I/O standard
D-7
RTM8030 User's Guide
Acronyms
Descriptions
PCI-E
(Same as PCIe). PCI-Express. Next generation I/O standard.
PCI-X
PCI + minor changes to the protocol and faster data rate.
PDP
Project Development Process
PDU
Power Distribution Unit
PECI
Platform Environment Control Interface
PECL
Positive Emitter-Coupled Logic
PEF
Platform Event Filtering. An IPMI subfunction.
PET
Platform Event Trap. An IPMI message type.
PEM
Power Entry Module
PERR
Parity ERRor. A signal on the PCI bus that indicates a parity error on the bus.
PHY
PHYsical layer. Generic electronics term referring to a special electronic integrated circuit or
functional block of a circuit that takes care of encoding and decoding between a pure digital domain
(on-off) and a modulation in the analog domain.
PIC
Programmable Interrupt Controller
PICMG
PCI Industrial Computer Manufacturers Group
PICMG®
PCI Industrial Computer Manufacturers Group
PIR
Product Issue Report
PIU
Plug-In Unit
PLCC
Plastic Leaded Chip Carrier
PLD
Programmable Logic Device
PLL
Phase Lock Loop
PMC
PCI Mezzanine Card
PMM
POST Memory Manager
PNE
Platform for Network Equipment. A Carrier Grade Linux (4.0) platform.
POH
System Operating Power-On Hours.
POR
Power-On Reset
POST
Power-On Self-Test
PPP
Point-to-Point Protocol
PROM
Programmable Read-Only Memory
PTS
Prepare To Sleep. An ACPI method called before the OS makes a change to system power state level.
PWB
(Same as PCB). Printed Wiring Board
PWM
Pulse-Width Modulation
PXE
Preboot eXecution Environment
QPI
QuickPath Interconnect. Point-to-point interconnect between Intel processors and IOH.
RAID
Redundant Array of Independent Disks / Redundant Array of Inexpensive Disks.
RAKP
RMCP+ Authenticated Key-Exchange Protocol
RAM
Random Access Memory
RAS
Row Address Strobe, used in DRAM. May also refers to Reliability, Availability, Serviceability features
of the chipset.
RASUM
Reliability, Availability, Serviceability, Usability and Manageability features of the chipset (AER and
ECC are RASUM features).
RCRB
Root Complex Register Block registers. Chipset memory-mapped space for configuration registers.
RGMII
Reduced Gigabit Media Independent Interface
D-8
RTM8030 User's Guide
Acronyms
Descriptions
RHEL
Red Hat Enterprise Linux
RIMM
Rambus Inline Memory Module
RMCP
Remote Management Control Protocol
RMII
Reduced Media Independent Interface
RMON
Remote network MONitoring
RMS
Root Mean Square
RoHS
Restriction of the Use of Certain Hazardous Substances
ROM
Read Only Memory. Also refers to option ROM or expansion ROM code used during POST to provide
services for specific controllers, such as boot capabilities.
RPP
Reliability Prediction Procedure
RS-232
(Same as RS232). Recommended Standard 232.
RS232
(Same as RS-232). Recommended Standard 232.
RSS
Receive Side Scaling
RTC
Real Time Clock
RTM
Rear Transition Module
RTM-Link
Rear Transition Module Link. Kontron 3-wire protocol.
RTS
Request To Send
S.M.A.R.T.
Self-Monitoring, Analysis, and Reporting Technology for IDE.
S0
ACPI OS System State 0. Indicates fully on operating state.
S5
ACPI OS System State 5. Indicates Soft Off operating state.
SAS
Serial Attached SCSI
SATA
Serial ATA
SBC
Single Board Computer
SBE
Single Bit Error
SCI
System Control Interrupt
SCL
Serial CLock
SCSI
Small Computer System Interface
SDH
Synchronous Digital Hierarchy
SDR
Sensor Data Record
SDRAM
Synchronous Dynamic Random Access Memory
SEC
Single-bit Error Correct
SEEPROM
Serial EEPROM
SEL
System Event Log
SERDES
SERializer/DESerializer. Pair of functional blocks commonly used in high speed communications.
These blocks convert data between serial data and parallel interfaces in each direction.
SERIRQ
Serial IRQ
SERR
System ERRor. A signal on the PCI bus that indicates a ‘fatal’ error on the bus.
SFP
Small Form-factor Pluggable
SGMII
Serial Gigabit Media Independent Interface. Standard interface used to connect a Gigabit Ethernet
MAC-block to a PHY.
ShMC
Shelf Management Controller
SIMD
Single Instruction, Multiple Data
SIMM
Single In-line Memory Module
D-9
RTM8030 User's Guide
Acronyms
Descriptions
SIRQ
Serial Interrupt ReQuest
SLC
Single-Level Cell
SMART
Self-Monitoring, Analysis, and Reporting Technology, or S.M.A.R.T. A monitoring system for
computer hard disks to detect and report on various indicators of reliability, in the hope of
anticipating failures.
SMB
(Same as SMBus/SMBUS). System Management Bus.
SMBIOS
System Management BIOS
SMBUS
(Same as SMB/SMBus). System Management Bus.
SMBus
(Same as SMB/SMBUS). System Management Bus.
SMI
System Management Interrupt
SMM
System Management Mode
SMP
Symmetric MultiProcessing. SMP systems allow any processor to work on any task no matter where
the data for that task are located in memory; with proper operating system support, SMP systems can
easily move tasks between processors to balance the workload efficiently.
SMR
Special Modification Request. Indicates a customer specific change.
SMS
System Management Software
SMT
Surface MounT.
SMTP
Simple Mail Transfer Protocol
SNMP
Simple Network Management Protocol
SNTP
Simple Network Time Protocol
SO-CDIMM
Small Outline Clocked 72-bit Dual In-line Memory Module
SO-DIMM
Small Outline Dual In-line Memory Module
SOL
Serial Over LAN
SONET
Synchronous Optical NETworking
SPD
Serial Presence Detect. A standardized way to automatically access information about a computer
memory module.
SPI
Serial Peripheral Interface
SpeedStep
(Same as EIST). Enhanced Intel SpeedStep Technology.
SRAM
Static Random Access Memory
SSE2
Streaming SIMD Extension 2. SIMD is "Single Instruction, Multiple Data".
SSE3
Streaming SIMD Extension 3. SIMD is "Single Instruction, Multiple Data".
SSH
Secure SHell. A network protocol that allows data to be exchanged over a secure channel between
two computers.
SSP
Serial SCSI Protocol
STM-1
Synchronous Transport Module 1
STP
Spanning Tree Protocol
SW
SoftWare
SWS
SoftWare Specification
TA
Ambient Temperature
TAP
Telocator Access Protocol. An IPMI Serial/Modem interface component.
TCC
Thermal Control Circuit
TCLKA
Telecom CLocK A. AMC Clock Interface.
TCLKB
Telecom CLocK B. AMC Clock Interface.
TCLKC
Telecom CLocK C. AMC Clock Interface.
D-10
RTM8030 User's Guide
Acronyms
Descriptions
TCLKD
Telecom CLocK D. AMC Clock Interface.
TCO
Total Cost of Ownership. Refers to a logic block in the Intel ICH products family. The watchdog timer
(WDT) is one of the functions of that logic block.
TCP
Transmission Control Protocol
TDP
Thermal Design Power
TM
(Same as TM1). Thermal monitor. CPU Thermal based on clock throttling.
TM1
Thermal monitor 1. CPU Thermal based on clock throttling.
TM2
Thermal monitor 2. CPU Thermal based on Enhanced Intel SpeedStep Technology transitions.
TOLM
Top Of Low Memory. Highest DRAM available to system, below 4GB.
TPM
Trusted Platform Module
TX
Transmit
TXD
Transmit
UA
Upgrade Agent
UART
Universal Asynchronous Receiver Transmitter
UC
Unit Computer
UDP
User Datagram Protocol. An Internet Protocol.
UHCI
Universal Host Controller Interface. Specification for Universal Serial Bus specification, revision 1.0.
UL
Underwriters Laboratories inc
UPM
User Programmable Machine
USB
Universal Serial Bus
UUID
Universal Unique ID number.
VA
Volt-Amperes. Unit used for apparent power.
VAC
Volt Alternating Current. Volt unit used when alternating current.
VCC
Power supply
VCORE
Processor CORE power supply
VID
Voltage IDentification. The CPU uses VID pins to support automatic selection of power supply
voltages.
VGA
Video Graphics Array
VLAN
Virtual Local Area Network
VLSI
Very-large-scale integration
VSUS
Power supply in suspend power
VT
Video Terminal
VTT
Power supply
WD
WatchDog
WDT
WatchDog Timer
WfM
Wired for Management
WWN
World Wide Name
WWPN
World Wide Port Name
XAUI
X (meaning ten) Attachement Unit Interface. A standard for connecting 10 Gigabit Ethernet (10GbE)
ports.
XDP
eXtended Debug Port
XMC
Switched Mezzanine Card
D-11
RTM8030 User's Guide
D-12
RTM8030 User's Guide
Was this manual useful for you? yes no
