NEW MAGMAP 2000 FEATURES

25 Oct 2002

Manual Addendum

There are several exciting new features in the October 2002 release of MagMap 2000. We list them here as a manual addendum and as a PDF for website distribution.

I. The Problem:

In the contour map generation routine, the Legend was always visible and if you made the map with many contour interval colors, the legend became bigger than the map!

The Solution:

Now by right clicking on the map you can select “Plot Color Legend “ box or not. If you turn it off, then you can get a larger picture of the map on the screen for zooming and further analysis. Remember that when in PLOT DATA display (profile display) you can select anomalies for flagging by right clicking on the profile and selecting SET FLAG. When you do that, the flag appears on the profile (number 1 below), on the position map and also on the color contour map showing the position of the anomaly. Put the cursor on the anomaly and read the X, Y or Latitude Longitude of the cursor on the info bar at the bottom

3

4

II. The Problem:

Sometimes there may be spikes in the data that are hard to filter using the Despike feature of MagMap.

We have now added a much more powerful despike editor called the Range Despike editor.

The Solution:

With the profile plot on the screen, go to Filter then Range Despike. You will see an icon appear that will allow you to draw a box on the plot with your mouse. All data that exceeds the minimum or maximum boundaries of the box will be cut from the data set, but only with in the lateral boundaries of the box. This gives fine control as well and sweeping editing abilities to the user.

5

After Despike:

After the Range Despike editor has been applied the data is now modified and the results will be shown in the Contour Map and when the data is exported to Surfer, MagPick or Geosoft for additional processing. This is a quick and easy way to clean up the occasional spike or dropout.

III. The Problem:

Basestation data some times has noise that should be smoothed prior to applying diurnal correction.

MagMap2000 now offers a basestation smoothing routine which when combined with the Range Despike editor offers excellent noise reduction.

The Solution:

Bring in the basestation file and then go to Filter, Smooth Basestation Data. You can select a value from

1 to 10 for the smoothing, 10 being the highest filtering. Note that the filter curve is shown prior to your acceptance. If you go back to Filter and Smooth Basestation Data, you can choose Accept which will modify the data in memory. Then you can export it or plot it. Remember that your original data is never changed (*.bin files) but you can save a *.stn file over the original *.stn file.

6

Basestation data 4 hours

Basestation data, filter level 4 preview, zoomed in

7

Basestation filter 4 preview, further zoom

Basestation data, 0.05nT smoothed to 0.01 or better with filter level 4

Basestation data accepted

NOTE: This feature will be implemented on regular data by November 2002. Then you can apply smoothing to both basestation and field data!

8

IV. The Problem

Zooming in to see the data had a maximum limit using the circle with a + in it (or an X+ or Y+)

The Solution:

Our programmers have come up with a magnifying glass zoom tool like those found in graphics programs. The Icon is a circle with a small box in it. Simply select this icon and then draw a box around the portion of data that you want to zoom.

Menu bar for Zoom Tool

When you have finished zooming and wish to return to the original coordinate display, simply click on the green icon with the arrows pointing outward .

V. The Problem

Sometimes we may want to apply a “frequency filter” to our data that becomes a spatial frequency, i.e., we are looking for something specific, a source of a given size. Or we may want to eliminate a certain high or low frequency component in the data so that we can more clearly see the “targets” of interest.

The Solution:

For instance, let us say that we are interested in the geological signal because we are looking for magnetite concentrations associated with placer gold deposits. However, there are also magnetic materials right on the surface due to weathering of the host rock. We can raise the sensor to “look” deeper (essentially applying a low pass distance filter), but we can also filter out the high frequencies in the following manner.

9

Bring in data with low and high frequency components and contour

Now look at the data plot and apply a factor 7 spline to it, press review

If it looks sufficiently “low passed” then accept the data and generate a contour map. Compare with the raw data contour map above.

10

Or one can “look” even deep with higher spline factors.

What if we want to look at only the surface features, for instance if we are doing an archeological or UXO survey, we may want to accentuate the higher frequencies and remove the deeper geologic signal. In this case we apply a high order (high number) spline filter to the data and THEN CLICK THE DIFFERENCE button so that the data that is presented when we press review is the difference between the raw data and the splined data. Then in this fashion, only the higher data is saved into memory when we press the

Accept button.

Then when we contour the data we get high frequency (small target) data display.

11

VI. The Problem

Noise spikes due to operation of the sensor close to the dead zone (see dead zone sensor orientation discussion in technical report MTR-120) can be troublesome to remove. However with our new range despike and spline filter modules, the data clean up is simple and quick.

The Solution:

Here is a sample of data corrupted by poor sensor orientation:

12

First we use the Range Despike tool to eliminate the obvious spikes:

Now the data is rescaled:

Next we can do a quick spline fit for REVIEW using the Smooth Readings dialog box under Filter. If we wish we can do some additional despiking after applying the filter to see the results:

13

And now apply a factor 3 spline filter (Review) again from the Filter dialog and see results.

14

Now compare with and without despiking and filter

For more information, please refer to the manual and visit our website often for more updates.

15
