User Guide
© UVI.net
> DO NOT USE THIS PRODUCT UNTIL YOU HAVE
READ THE FOLLOWING LICENSE AGREEMENT.
BY USING THIS PRODUCT (OR AUTHORIZING
ANY OTHER PERSON TO DO SO) YOU ACCEPT
THIS AGREEMENT.
Sounds & Software License Agreement
NOTE :
COPYRIGHT LAWS HAVE RECENTLY BEEN STRENGTHENED. IT IS IN
YOUR BEST INTEREST TO READ AND FOLLOW THIS AGREEMENT.
3. Ownership.
As between you and UVI, ownership of, and title to, the enclosed digitally
recorded sounds (including any copies) will be held by UVI. Copies are provided to you only to enable you to exercise your rights under the license.
Only this license is purchased by you.
4. Term.
This Agreement is effective from the date you open this package, and will
remain in full force until termination. This Agreement will terminate if you break
any of the terms or conditions of this Agreement. Upon termination you agree
to destroy and return to UVI all copies of this product and accompanying
documentation.
5. Restrictions.
This copy of the Sounds & Software (the Product) are licensed to you as the
end user. Please read this Agreement carefully.
Except as expressly authorized in this Agreement, you may not rent, sell, lease,
sublicense, distribute, transfer, copy, reproduce, display, modify or time share
the enclosed product or documentation.
You cannot transfer ownership of these Sounds and Software they contain.
You cannot re-sell or copy the Product.
THE SOUNDS IN THIS INSTRUMENT ARE GUARANTEED TO BE 100%
COPYRIGHT CLEAN
LICENSE AND PROTECTION
© UVI.net.
1. License Grant.
All rights reserved. All trademarks are the property of their respective holders.
UVI, brand (UVI) grants to you, subject to the following terms and conditions,
a non-exclusive, nontransferable right to use each authorized copy of the
enclosed Product.
The enclosed product is the property of UVI and is licensed to you only for
use as part of a musical performance, live or recorded. This license expressly
forbids resale or other distribution of the sounds and software included in
the Product or their derivatives, either as they exist on disc, reformatted for
use in another digital sampler, or mixed, combined, filtered, resynthesized
or otherwise edited, for use as sounds, multisounds, samples, multisamples,
wavetables, programs or patches in a sampler, microchip or any hardware or
software sample playback device.
You cannot sell the Product content or give it away for use by others in
their sampling or sample playback devices. In the event UVI terminates this
Agreement due to your breach, you agree to return the original and all other
copies of the software and documentation to UVI.
UVI reserves all rights not expressly granted to you.
2. Protection of Software.
You agree to take all reasonable steps to protect this product and any accompanying documentation from unauthorized copying or use. You agree not to
modify the enclosed product to circumvent any method or means adopted
or implemented by UVI to protect against or iscourage the unlicensed use of
copying of the enclosed Product.
UVI.net is registered trademarks of Univers Sons, SA
TABLE OF CONTENTS
Thanks for purchasing !
4
Installation
5
- Installation on Mac
- Installation on PC
String Machines > user interface
6
String Machines > presets list
8
String Machines > the beasts !
9
Credits 10
Thanks for Purchasing
11 Vintage Analog Beasts. Reborn.
Back in the 70’s leading keyboard designers around the world attempted to
reproduce orchestral string sounds through analog synthesis. The results were
far from their original intent but were in no way failures. Used on countless
cult records and engrained in our collective memory to this day; these ‘String
Machines’ bore an analog soul all their own. At UVI we are obsessed with this,
having spent countless hours working on ways to capture this analog soul and
present it as an accessible, expressive, fully editable digital tool. The result of
this obsession is String Machines; a hybrid instrument forged with the analog
imprint of 11 of the most musical string synthesizers ever built.
We’ve painstaking recorded thousands of samples with the very best analog
and digital gear available, applying everything we’ve learned in order to bring
you this comprehensive instrument at an unbelievable price.
UVI String Machines is your doorway to a grand collection of analog gems from
some of the most esteemed synth pioneers of our time.
• Authentic sound and character reproduces the analog grunge and
warmth of yesteryear
• Instant access to tons of presets and preset layers; find sounds you love
and get inspired quickly!
• Dual layers. Select the machine and the associated sounds.
• No loading time when switching machines and sounds.
• Shape your sounds using authentic analog-modeled filters, envelopes,
and LFOs
• Experiment with the step modulator and take your sound out of this world!
• Samples recorded in 24/96 khz with Prism convertors, mastered to
perfection and converted to 16/44.1 kHz.
This is the official free player to load and use the all the UVI sounds & instruments
available today. Stay tuned at www.uvi.net to get the last infos.
> Features in version 2
• New single mode for loading next generation of UVI sounds and instruments
• Compatible with the UVI scripted instruments
• Powerful Arpeggiator, extremely flexible and complete
• Easy to use Search Engine to find quickly what you’re looking for
• Universal compatibility Mac / PC
• Operate in full 64 bits on Mac / PC
• Manage instruments and loops in the same interface
• Smart integrated browser
• Convenient mixing environment with meters, mute, solo, volume, pan...
• Unlimited parts
• Up to 64 MIDI channels
• Disk streaming per part
• Multiple separate outputs
• MIDI learn
• Expert mode
• Cross-platform Multis & all host compatible
• Unlimited FX
• Complete professional effects arsenal, with easy editing
(delay, reverb, phaser, chorus, EQ, filter, drive, distortion, compressor...)
• Excellent sounding convolution reverb
• Direct sync to host : tempo & transport
• State-of-the-art real-time time-stretch algorithm
• Real-time sync to the beat: loops are always in time
• Latch mode
• Sample/Slice Start for loops and phrases
• Drag & Drop MIDI & Audio
• Import REX files, Apple Loops, AIFF, WAV and more...
• Expandable with all UVI sounds and instruments
• Direct connection to the UVI.net RSS feed
• Compatible with almost everything thanks to the free UVI Workstation 2.0.5
(stand-alone, Mac & PC, VST, AudioUnit, RTAS and MAS plug-in)
• Get unlimited control and editing features with MOTU MachFive 3
We wish you the best musical experience !
The UVI Team.
If you want to go deeper on the editing
and get access to the best time stretch,
granular and other synth engine, note
that the incredible MOTU MachFive 3
is the big brother of UVI Workstation.
> iLok key needed !
Check out www.motu.com
for more infos about MachFive 3
To be able to load sounds from this product, you’ll need an iLok key
as well as an iLok.com account.
And if you experience any
problem our support is here
to help : [email protected]
4
MachFive 3 by MOTU > Universal & Creative Sampler
INSTALLING THE UFS FILE
The UFS file is the actual sound-bank file, where every
data UVI String Machines needs is located: samples,
presets, scripts, FX, impulse responses, etc.
Once it’s installed following the procedure below,
you will be able to load the presets within the UVI
Workstation 2 or MachFive 3.
Stand Alone
Audio Units
RTAS
VST
MAS
> using UVI Workstation 2 or MOTU MachFive 3
Stand Alone
VST
RTAS
> using UVI Workstation 2 or MOTU MachFive 3
> Minimum System Requirements
> Minimum System Requirements
- MacIntel processors
- 2 GB of RAM
- 6 GB of hardisk space
- MAC OS X 10.5 or higher
- Hard Drive: when using Streaming, faster drive will allow more voices to play
- UVI Workstation 2.0.5 or MOTU MachFive 3.1 installed
> How to install the UFS file
Copy the UFS file in this location :
[your startup disk]/Library/Application Support/UVISoundBanks
You can also drop an alias of this file in this location, provided they have the
same name
(not My soundpack.ufs alias for instance)
- Core duo or faster
- 1 GB of RAM
- 6 GB of hardisk space
- Windows XP SP2 or higher version, Windows Vista
- Hard Drive: when using Streaming, faster drive will allow more voices to play
- UVI Workstation 2.0.5 or MOTU MachFive 3.1 installed
> How to install the UFS file
Copy the UFS file in this location :
C:\Program Files\UVISoundBanks.
You can also drop a shortcut to this file in this location, provided they have
the same
name (not Shortcut to My soundpack.ufs for instance)
5
STRING MACHINES USER INTERFACE
String Machines loads the sounds in two layers (A & B) and you can edit them
with the different shaping tools included in the user interface.
> MAIN
AMPLITUDE
• A / D / S / R
Typical volume envelope
• NO VEL
When on, all sounds will be played at maximum volume.
• VEL > ATK
Convert low velocities to long attacks and high velocities to short attacks.
FILTER
• Arrows / Preset
Select one of the global presets by using the arrows or the conventional preset list
• MASTER:
Global volume control
• EDIT/STEP
Switch from Edit page to Step page
• MUTE A/B Mute Layer A or B
• VOLUME/PAN
Control volume and pan for layer A or B
• OCTAVE
Octave transpose of the current layer
• Select Machine
The first slot allows you to change the machine
• Select Sounds
The second slot allows you to change the sound
•A/D/S/R
Typical filter envelope.
• ENV DEPTH
Depth of the ADSR applied to the filter.
• SHAPER
Select from LPF, BPF and HPF
• CUT OFF / Q
Low pass filter, cut off and resonance (Q)
• VELOCITY
Second LPF filter mapped to velocity
STEREO
> EDIT page
In the Edit page, you can choose to edit only the layer A, only the layer B, or
both layers at the same time.
6
• OFF : Standard playing mode using mono samples.
• ALT :
This emulates the multiple output from old samplers.
Each voice is panned sequencially from left to right.
(SPREAD parameter sets the depth of the stereo)
• UNI : • COLOR : Using sound layering manipulation, this feature allows a dramatic extension of the stereo image.
To be combined with COLOR and SPREAD settings.
Playing neighbouring samples, this parameter shifts the color of the sound in a unique way.
• SPREAD :
Works in ALT and UNI mode, setting the stereo spread.
• TUNE : Works only in UNI mode, detuning both layers.
STRING MACHINES USER INTERFACE
> STEP page
PITCH
String Machines proposes two easy step modulators that can be connected
independantly on both layers, volume and filters.
• COARSE Coarse tune the selected layer in semitones
• FINE
Fine tune the selected layer in cents
• GLIDE
Set the glide time
MODWHEEL
This section allows you to choose what will be assigned to the modwheel.
• VIBRATO : On/Off
• RATE : Speed of the vibrato (free)
• TREMOLO :
On/Off
• RATE : Speed of the tremolo (tempo dependent)
• FILTER : On/Off
• DEPTH : Depth setting from the low pass filter cut off frequency
MODULATOR
• RES
Speed resolution of the step
• STEP
Number of steps
• DELAY
Time to activate step
• RISE
Time to activate with a smooth transition
• SMOOTH
Smoothing the level value
EFFECTS
DESTINATION
• PHASER : On/Off
• MIX : To adjust the Dry/Wet weighting
• DELAY : On/Off
• MIX : To adjust the Dry/Wet weighting
• REVERB : On/Off
• MIX : To adjust the Dry/Wet weighting
• Knob
Set the level of the step modulator
• Button A/B
Set the destination of the step modulator
STEP EDIT
NOTE : you can add as many FX as you want in the UVI Workstation, and you
can even edit the sounds deeper within MOTU MachFive 3.1.
Simply draw your steps with the mouse.
A step with a value of «0» is like having no step.
7
STRING MACHINES PResets list
MASTER PRESETS
Korg
Poly Ensemble PE2000
Heavy synthesizer widely used by the
pioneers of 70’s electronic music
00 - Default Mono
00 - Default Stereo
01 - Melody Machine
02 - EKO Uni Strings
03 - VP330 Full
04 - Spectral Pad
05 - PTN VelociGate
06 - ChoirXygen
07 - PTN Ambitious
08 - Tibetan Mood
09 - So Brigitte
10 - PTN Technoid
11 - Milky Highway
12 - Para Tangerine
13 - Sweepness
14 - FX CatTalks
15 - Evolupad
16 - Strange Field
17 - Bass Perc Strings
18 - Wheeldorado
19 - Bubble Gum
20 - PTN Gate and Voices
21 - Analog Seventies
22 - PTN Pump me Up
23 - ExpressiVp
24 - PTN Simply Step
25 - Not that Cheezy
26 - PTN Phase B
27 - Morphe to PTN
28 - FX UFO’s
29 - Mix City
NOTE: String Machine allows you to
switch from all presets and layer with
no loading time.
>
Classic PE2K
Strings 1
Strings 2
Chorus 1
Chorus 2
Brass 1
Brass 2
Pipe 1
Pipe 2
Eko
Stradivarius
Also called «the Italian analog string
processor»
> EKO Stradi
Strings
Violin
Tutti
Excelsior
Strings Synthesizer K4
Rare string keyboard, introduced
in 1975 by Elettronica Excelsior of
Castelfidard
>
Excelsior
Cello
Strings
Cello Strings
Strings Ensemble
Logan
String Melody
MACHINE PRESETS
Pure string synthesizer with great
sound and basic presets.
> Logan Bass
Strings Bass
Percs
Perc + Bass
Layer A & B works exactly the same
way: the first line allows to select the
desired machine, the second line is
for the presets inside the machine.
8
>>>>
> Melody
Cello
Viola
Violin
Orchestra
Crumar Performer
Solid and fully polyphonic analog
Strings and Brass machine
> Performer
Strings 8
Strings 16
Strings 8+16
Elka Rhapsody
Violin, Cello and Strings with that
classic shimmering ensemble effect
> Rhapsody
Cello
Cello + Strings
Strings
Siel Orchestra
Orchestral synthesizer with
4 tweakable presets
> S-Orchestra
Cello
Violin
>
SS-Thirty Violin
Tutti Violin Mod 1
Tutti Violin Mod 2
Violin 1 Flat
Violin 2 Flat
Viola Flat
Viola + Violin Mod 1
Viola + Violin Mod 2
Roland RS-505
Famous machine combining strings,
a basic polysynth and a bass section
> US-505
Strings-I-4
Strings-I-8
Strings-I-4+8
Strings-II-4
Strings-II-8
Strings-II-4+8
Strings-III-4
Strings-III-8
Roland VP-330
Known as a vocoder, it contains excellent sounding strings and choirs.
> VP Stereo
Solina Performer
No doubt, this is THE String Machine
>
Solina
Full
Violin
Viola
Horn
Trumpet
>Solina Bass
ContraBasso
Cello
Yamaha SS30
Dual-oscillator classic string
synthesizer full of wood
> SS-Thirty Cello
Cello 1 Flat
Cello 1 Mod 1
Cello 1 Mod 2
Cello 1+2 Mod 1
Cello 1+2 Mod 2
Cello 2 Flat
Cello 2 Mod 1
Cello 2 Mod 2
All Choirs
Strings
Choirs 4
Choirs 8
Extra Attack
Add extra attack to string machines
with these two useful layers
Pizz
Stacc
STRING MACHINES THE BEASTS
Korg
Poly Ensemble PE2000
Elka Rhapsody
Siel Orchestra
Eko
Stradivarius
Solina
Performer
Excelsior
Strings Synthesizer K4
Yamaha
SS30
Logan
String Melody
Roland RS-505
Crumar
Performer
Roland VP-330
All rights reserved. All trademarks are the property of their respective holders.
9
CREDITS & THanks
Production
Univers Sons / UVI.net
Recording / Editing / Sound Design
Damien Vallet
Emmanuel Usai
Alain J Etchart
Scripting & Software
Olivier Tristan
Remy Muller
Graphic Design
Anthony Hak
Nathaniel Reeves
Thanks
Gert Prix @ eboardmuseum
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
