Software User Manual

Software User Manual

Version 1.5

EN 141027 REV B

End User License Agreement (EULA)

Do not use this product until the following license agreement is understood and accepted.

By using this product, or allowing anyone else to do so, you are accepting this agreement.

UltraMini (henceforth ‘the Product’) is licensed to you as the end user. Please read this Agreement carefully.

You cannot transfer ownership of these Sounds and Software they contain. You cannot re-sell or copy the Product.

LICENSE AND PROTECTION

1. License Grant

UVI grants to you, subject to the following terms and conditions, a non-exclusive, non-transferable right to use each authorized copy of the Product.

The product is the property of UVI and is licensed to you only for use as part of a musical performance, live or recorded. This license expressly forbids resale or other distribution of the sounds and software included in the Product or their derivatives, either as they exist on disc, reformatted for use in another digital sampler, or mixed, combined, filtered, resynthesized or otherwise edited, for use as sounds, multi-sounds, samples, multi-samples, wavetables, programs or patches in a sampler, microchip or any hardware or software sample playback device.

You cannot sell the Product content or give it away for use by others in their sampling or sample playback devices.

In the event UVI terminates this agreement due to your breach, you agree to return the original and all other copies of the software and documentation to UVI.

UVI reserves all rights not expressly granted to herein.

2. Protection of Software

You agree to take all reasonable steps to protect the product and any accompanying documentation from unauthorized copying or use. You agree not to modify the product to circumvent any method or means adopted or implemented by UVI to protect against or discourage the unlicensed use of copying of the Product.

3. Ownership

As between you and UVI, ownership of, and title to, the enclosed digitally recorded sounds (including any copies) are held by UVI. Copies are provided to you only to enable you to exercise your rights under the license.

4. Term

This agreement is effective from the date you open this package, and will remain in full force until termination. This agreement will terminate if you break any of the terms or conditions of this agreement. Upon termination you agree to destroy and return to

UVI all copies of this product and accompanying documentation.

5. Restrictions

Except as expressly authorized in this agreement, you may not rent, sell, lease, sub-license, distribute, transfer, copy, reproduce, display, modify or time share the enclosed product or documentation.

©2014 UVI, all rights reserved.

All trademarks are the property of their respective owners

Moog is not affiliated with UVI or any UVI products.

2

Table of Contents

Introduction

...............................................................................................................................................................................

4

What’s New

................................................................................................................................................................................

5

System Requirements

..........................................................................................................................................................

6

Installation

Step 1: Register Your Serial Number

.....................................................................................................................

7

Step 2: Activate Your License

...................................................................................................................................

8

Step 3: Install Your Instrument

.................................................................................................................................

9

Step 4: Load Your Instrument

...................................................................................................................................

10

Signal Flow and Functionality Overview

.....................................................................................................................

11

Classic and XL

...........................................................................................................................................................................

12

User Interface

Global and Oscillators

....................................................................................................................................................

13

Pitch, Color, Filters and Amps

...................................................................................................................................

14

Stereo and Effects

...........................................................................................................................................................

15

Phraser

..................................................................................................................................................................................

16

Arpeggiator

.........................................................................................................................................................................

17

Step Modulator

.................................................................................................................................................................

18

LFO Modulator and Modwheel Controls

.............................................................................................................

19

Low-CPU Mode (UltraMini LE)

.................................................................................................................................

20

Preset List

Preset List - Mono

..........................................................................................................................................................

21

Preset List - Poly

.............................................................................................................................................................

22

Preset List - Xtra 1.5

.......................................................................................................................................................

23

UVI Workstation: Tips and Tricks

....................................................................................................................................

24

Credits and Thanks

................................................................................................................................................................

25

3

Introduction

The Beauty of Firsts

There’s something evocative and mysterious about firsts. Normal people will recall their first pet, first crush or their first kiss. That’s not us. For us, that warm ethereal feeling comes from our first analog synth. There’s something timeless about it. Part of it is its place in history, being the first affordable and accessible analog synthesizer.

Part of it is a sonic fingerprint that resonates through over 40 years of live and recorded music. Regardless of the criteria we can only summarize by saying this instrument has made a permanent impression on us, and we’re not alone.

A Prolific Past

First made available to the public in 1971, this synth continued to be produced with very little change for over 10 years. Considered the most popular synth ever by some there’s no doubt the instrument has led a prolific life, leaving a massive wake in its path; changing perceptions and influencing synthesizer design to this day. With a striking balance of simplicity and sonic range it was one of the first real novice-friendly systems, a factor that surely contributed to its success and also made it a superb tool for teaching the basics of subtractive synthesis.

There’s No Quitting You

As firsts often do, this one taught us a great deal. It cultured in us a sensitivity to intuitive design and the importance of great sound regardless of form. In fact we’ve been speaking about it from a project perspective since we began. We knew that if we were going to do it, it would not only have to sound great but it would need to elicit that same balance of immediate simplicity and sonic reward - a deceptively complex task. As time progressed our vision crystallized; the design was ambitious but it was clear to all of us that this was a project we had to do.

Heart of a Hybrid Monster

One of our specialties is making hybrid instruments. With a hybrid instrument we get the best of both worlds. High fidelity sample-based waveforms produced by real circuits, in real machines give the instrument a pure sound from the start. Then accurately modeled filters and effects are used on the back-end to shape and control the sound, spending precious CPU cycles only where they’re needed. For this approach to work you need to build an amazing library of sounds and marry them to a truly advanced DSP engine. This is exactly what we’ve done for UltraMINI thanks to hundreds of man hours of tedious multi-sampling and the award-winning UVI Engine™.

Two Analog Souls

We started with a beautifully restored 1971 model, sampling every waveform of every oscillator across every key - and we did this for multiple overdrive settings. UltraMini seeps with a thick and immediate analog sound produced with the same 3-oscillator configuration. But we didn’t stop there. In 2002 the king of mono synths had a second coming; this version has its own wild character and we figured, what better way to make a Mini ultra than to give you two of them. Taking the new 2011 model, we performed the same comprehensive session creating an identical sample footprint.

Beyond Mini

Oscillators are only half the story—what about the filters? Don’t worry, we’ve got you covered. We’ve included not one, but two of our aggressive analog-modeled Xpander filters in UltraMINI, giving you unprecedented control and a sound so sweet you’ll swear it’s analog.

Additional features include amplitude and filter key follow, unrestricted polyphony, mono retrigger, per-oscillator amplitude, stereo, color and drive control, a built in bit crusher, phaser, delay, limiter and our advanced algorithmic reverb—SparkVerb, built-in phraser and arpeggiator assignable per-oscillator, step and LFO modulations and a huge library of expertly crafted presets to explore.

UltraMINI has been designed to give you a rich, authentic sound and an immediate experience. An elegant GUI presents controls in an easy-to-understand layout, grouped for efficient and intuitive operation eliciting the feel of a real Minimoog.

Now lets get started!

4

What’s New in v1.5

- 200+ New Factory Presets

- Computer-based Authorization (iLok dongle no longer required)

- Low-CPU Mode (UltraMini LE)

5

System Requirements

Compatibility

Audio Units, VST, MAS, AAX, RTAS or standalone

UVI Workstation 2.5.7 or higher

Minimum System Requirements

Intel CPU

4 GB of RAM (8 GB+ recommended)

2 GB of disk space

Mac OS X 10.7 or higher

iLok account (free, dongle not required)

Compatibility

VST, AAX, RTAS or standalone

UVI Workstation 2.5.7 or higher

Minimum System Requirements

Core Duo or faster

4 GB of RAM (8 GB+ recommended)

2 GB of disk space

Windows 7 or higher

iLok account (free, dongle not required)

Authorize the Way You Want

Your license allows 3 concurrent authorizations on any combination of computers and iLok dongles.

License management is a simple drag-and-drop process done through iLok License Manager.

Visi t ilok.com/ to download iLok License Manager and create your free account.

6

Step

1

Register Your Serial Number

1 2 3 4

You must have an account on uvi.net/ and ilok.com/ prior to registration

If you purchased a physical version of this product, your serial number is located on the inside of the box

If you purchased an electronic version of this product, your serial number will be included in a confirmation email

You can see a list of the products you’ve registered and their serial numbers anytime at uvi.net/my-products

1. Login to your account on uvi.net/

2. Navigate to the ‘Product Registration’ page

3. Enter your details and click ‘Register’

Upon completion a new license will be deposited in your iLok account

7

Step

2

Activate Your License

iLok License Manager is required for activation, download the newest version at ilok.com/ilm.html

Your license allows up to 3 concurrent activations on any combination of iLok dongles and computers

Activations can be moved between devices at anytime

1 2 3 4

1. Launch iLok License Manager

2. Login to your account

3. Click the ‘Available’ tab

4. Drag the license to your computer or an iLok dongle

5. Click ‘Ok’ to confirm the activation

The process is complete, your device is now authorized

»

To see how many authorizations you have left simply select the license and click ‘Show Details’

»

To deactivate your license, right-click it and select ‘Deactivate’ — doing so will return your license to the ‘Available’ tab

8

Step

3

Install Your Instrument

UVI Instruments can be stored anywhere on your system

Storing your instruments on a fast drive will improve performance

Your instruments can be downloaded at any time from uvi.net/my-products

1. Create a folder on your computer and place your UVI Instruments in it

Once this is done we need to tell UVI Workstation where to find your instruments.

We do this by creating a watch folder, follow the steps below to create your own:

2. Open UVI Workstation

3. Click the Settings page

4. Click the ‘Sound Banks’ tab

5. Click the ‘...’ button and select the folder where you’ve placed your instruments

6. Restart UVI Workstation and open the Browser

Your instruments will be available under the ‘Soundbanks’ tab

1 2 3 4

9

Step

4

Load Your Instrument

UVI Workstation is required to run UVI Instruments

The newest version of UVI Workstation can be downloaded free at uvi.net/downloads

UVI Workstation can be run as a standalone program or as a virtual instrument from within your DAW of choice

1 2 3 4

1. Open UVI Workstation

2. Click the Browser icon

3. Open the Sound Banks tab

4. Select a product, in this example we’ll choose Vector Pro, then select an instrument and patch

Double-click the patch to load it

5. The UI appears and you’re ready to jam!

10

Signal Flow and Functionality Overview

Step Mod LFO Mod

Arp/Phraser Oscillator 1

Pitch Color Volume

Filter 1

Arp/Phraser

Oscillator 2

+ Noise

Pitch Color Volume

Pitch Color Volume

Arp/Phraser Oscillator 3

Filter 1

Filter 1

Drive

Drive

Filter 2 Amp Env 2 Stereo 2

Drive

Filter 2 Amp Env 1 Stereo 1

Filter 2 Amp Env 3 Stereo 3

Crusher Phaser Delay Reverb Limiter Master

UltraMINI Signal Flow Diagram

Functionality Overview

UltraMINI is a 3+1 oscillator subtractive mono/poly switchable synthesizer built on the UVI Engine

and a comprehensive library of sample data from 2 hardware Minimoogs (1971 & 2011).

Each oscillator includes an octave switch, 6 base waveforms and has independent amplitude, drive, color, pan and overdrive controls.

Oscillators 2 and 3 have sweepable detune with a range of -7/+7 semitones. A noise oscillator offers pink or white tone. Its signal travels alongside oscillator two, feeding through its amplitude filter.

UltraMINI can run in mono portamento, mono portamento 2, mono retrigger or polyphonic modes. A global pitch control allows for glide effect with independent time and pitch depth settings.

3 amplitude filters provide standard ADSR envelope controls and can be edited individually or globally. A [NO VEL] switch overrides velocity data with a fixed 128 value. A [VEL > ATK] switch overrides the attack parameter with the incoming note velocity.

Xpander filters run in parallel offering low pass, band pass and high pass modes. Each filter is equipped with ADSR envelope controls as well as depth and velocity. Filters can be edited independently or globally and have independent bypass switches.

Linear Key Follow is available for both Filter and Amplitude envelopes.

A unique stereo control is available per oscillator. By default you can pan each oscillator signal to any position in the stereo spectrum. An [ALT] control is available, which when engaged will invert the stereo position with every key press. With [ALT] engaged the [Spread] control is enabled and sets the distance from center (0 being center, 10 being fully panned).

A variety of sound shaping effects are available including the proprietary SparkVerb. Effects run in serial in the following order: bit crusher, phaser, delay, reverb, limiter.

An arpeggiator and a phraser are available, each containing independent bypass per oscillator. The arpeggiator and phaser are exclusive, meaning only one can be engaged at a time. Activating one will deactivate the other if it happens to be engaged. Both offer editable resolution, groove, gate and step length controls for a maximum of 16 steps. The phraser offers live pattern input for fast programming.

Step and LFO modulators offer per oscillator parameter modulation of volume, pan, pitch and drive as well as filter cutoff for both Xpanders. In legato mode the Step modulator gains independent delay, rise and smooth controls and the

LFO modulator gains attack, decay and depth controls.

Patches can be saved as multis through UVI

Workstation or as programs in MachFive3. Additionally if you’re working in plug-in mode, patch settings will be automatically saved in your project via. your DAW.

11

Classic and XL

Old and New: A Brief Explanation

Within UltraMINI are two wholly separate instruments, the

Classic and XL (pictured here). The Classic sports a natural wood and black metal faceplate while the XL is dressed in a clean white. Each instrument has the same control set; your experience operating one will translate directly to the other. The difference between them lies at the core.

UltraMINI is based on a quite massive sample footprint taken from 2 vintage synths—one from 1971 and the other from 2011. Extreme care was taken to ensure these sets were as near as possible to allow for a consistent and seamless experience. These sample sets serve as the fundamental difference between the two versions of

UltraMINI; quite literally they are different instruments.

There are both subtle and distinct sonic differences between the two. To help illustrate this point we’ve made a generous preset bank available for both versions giving you a straight-forward way to AB a huge range of configurations if you’re so inclined.

We hope very much that you enjoy exploring these two synths and that you find ways to apply their particular strengths in your work.

UltraMINI - Classic (1971)

UltraMINI - XL (2011)

12

Global and Oscillators

Range

4

Waveform

5

Detune

6

Volume

7

Preset Navigator

2

Master Volume

1

8

Oscillator Bypass

9

Drive

10

Noise Bypass

11

Noise Volume

12

Noise Type

13

Overload Switch

3

Page Buttons

Global Controls

1 Master Volume

Set the master volume for the selected instance of UltraMINI (0-100)

2 Preset Navigator

Arrow buttons toggle through presets

Click preset name for a list view

3 Page Buttons

Navigate between the UI pages

Oscillator Controls

4 Range

Octave per-oscillator (-2/+2oct)

5 Waveform

Waveform per-oscillator

6 Detune

Detune per-oscillator (-7/+7 semitones)

7 Volume

Gain per-oscillator (0-100%)

8 Oscillator Bypass

Turn oscillators ON/OFF

9 Drive

Amount of Drive per-oscillator

10 Noise Bypass

Turn noise generator ON/OFF

11 Noise Volume

Noise gain (0-100%)

12 Noise Type

Choose Pink or White noise

13 Overload Switch

Select amount of overload per-oscillator

(none/soft/medium/hard)

13

Pitch, Color, Filters and Amps

Mode Switch

1

Color

2

Glide

3

No Vel

9

Vel > Atk

10

4

Filter Bypass

5

Filter Switch

6

Filter

7

Filter Envelope

8

Filter Mode

11

Amp Key Follow

12

Amp Switch

13

Amp Envelope

Polyphony

1 Mode Switch

Set global mode: (mono portamento, mono portamento 2, mono retrigger,

polyphonic)

Pitch Controls

2 Glide

» Depth

Set glide pitch depth

(-24/+24 semitones)

» Time

Set glide time (0/10)

Timbre Control

3 Color

Adjust timbre per-oscillator (-24/+24)

Filter Controls

4 Filter Bypass

5 Filter Switch

Edit filter parameters independently

(1/2) or all at once (All)

6 Filter

» Cutoff

Set filter cutoff (20Hz/20kHz)

» Resonance

Set filter resonance (0-100%)

» EG Depth

Set filter depth (-1/+1)

» Velocity

Set filter velocity (0-100%)

» Key Follow

Set linear key follow (0-200%)

(key position » resonance)

7 Filter Envelope

Attack/decay/sustain/release per filter

8 Mode

Set filter mode (LP/BP/HP)

Amplitude Controls

9 No Vel

Sets note velocity to a fixed value of 128

10 Vel > Atk

Overrides amp envelopes attack value with incoming note velocity

11 Key Follow

Set amp key follow amount (-1/+1)

(key position » volume)

12 Amp Switch

Edit amp parameters independently

(1/2/3) or all at once (All)

13 Amp Envelope

Attack/decay/sustain/release

per-oscillator

14

Stereo and Effects

Phaser

5

Bit Crusher

4

Pan

1

Alt

2

Spread

3

6

Delay

8

Limiter

7

SparkVerb

Stereo Controls

1 Pan

Set pan per-oscillator (L/C/R)

2 Alt

Engage Alt mode —inverts stereo position with each key press

3 Spread

Used in Alt mode—sets pan distance from center (0-100%)

Effects

4 Bit Crusher

» Bypass Switch

» Bits

Set bit depth (1-24bits)

» Frequency

Set sample rate (2-48kHz)

» Drive

Set drive amount (0-100%)

5 Phaser

» Bypass Switch

» Sync

Synchronize phaser to global tempo

» Speed

Set phaser rate (1/32 - 1/2)(0-10Hz)

» Depth

Set phaser depth (0-100%)

» Feedback

Set phaser feedback amount (0-100%)

6 Delay

» Bypass Switch

» Mix

Set mix of dry/wet signal (0-100%)

» Time

Set delay length (1/16tri - 1/2)

» Feedback

Set delay feedback amount (0-100%)

» Cutoff

Set cutoff amount (LP/Off/HP)

» Spread

Set spread amount (-100%/100%)

7 SparkVerb

» Bypass Switch

» Mix

Set mix of dry/wet signal (0-100%)

» Size

Set reverb size (4m/0.4s - 50m/5s)

» Decay

Set decay time (.5s/50s)

» Lo Decay

Set low decay multiplier (x0.1/x10)

» Lo Crossover

Set low crossover ƒ (10Hz/1kHz)

» Hi Decay

Set hi decay multiplier (x0.1/x10)

» Hi Crossover

Set hi crossover ƒ (12kHz/20kHz)

7 Limiter

» Bypass Switch

» Mix

Set limiter wet/dry mix (0-100%)

15

Phraser

Osc Bypass

2

Power

1

Step Length

3

Step Volume

8

Step Pitch

9

Step Tie

10

4

Groove Amount

7

Step Quantity

6

Record Note

5

Gate

11

Step Indicator

12

Phraser /Arp Switch

Phraser Controls

1 Power

ON/OFF switch for the phraser— enabling the phraser while the arpeggiator is on will disengage the arpeggiator

2 OSC Bypass

Per-oscillator bypass switch

3 Step Length

Set the step length (1/32 - 1/2)

4 Groove Amount

Set the groove amount (0-100%)

5 Gate Amount

Set the gate amount (0-100%)

6 Record Note

» Record

Enables phraser record mode—use to quickly program pitch sequences

» Skip Step

Use in record mode to skip a step

7 Step Quantity

Set the number of steps to be played

(1-16)

8 Step Volume

Set volume per-step

9 Step Pitch

Set pitch per-step (-48/+48 semitones)

10 Step Tie

Set tie per-step

11 Step Indicator

LED indicator displays current step

12 Phraser / Arp Switch

Switch between phraser and arpeggiator pages (does not change current mode)

16

Arpeggiator

Osc Bypass

2

Power

1

Step Length

3

Step Volume

9

4

Groove Amount

8

Step Quantity

7

Octave Range

6

Mode

5

Gate Amount

10

Step Indicator

11

Phraser /Arp Switch

Arpeggiator Controls

1 Power

ON/OFF switch for the arpeggiator— enabling the arpeggiator while the phraser is on will disengage the phraser

2 OSC Bypass

Per-oscillator bypass switch

3 Step Length

Set the step length (1/32 - 1/2)

4 Groove Amount

Set the groove amount (0-100%)

5 Gate Amount

Set the gate amount (0-100%)

6 Mode

Set the playback mode

(Up/Down-Up/Down)

7 Octave Range

Set the octave range to be played

(-6/+6oct)

8 Step Quantity

Set the number of steps to be played

(1-16)

9 Step Volume

Set volume per-step

10 Step Indicator

LED indicator displays current step

11 Phraser / Arp Switch

Switch between phraser and arpeggiator pages (does not change current mode)

17

Step Modulator

Step Level

1

Step Quantity

2

Step Length

3

Mode

4

Legato Controls

5

6

Filter 1

8

Volume

9

Pan

10

Pitch

11

Drive

7

Filter 2

Step Modulator Controls

1 Step Level

Set the parameter amount per-step

(-1/+1)

2 Step Quantity

Set the number of steps to be played

(1-16)

3 Step Length

Set the step length (1/32 - 1/2)

4 Mode

Set the playback mode

(Retrigger/No Retrigger/Legato)

5 Legato Controls

Enabled if mode is set to [Legato]

» Delay

Set the delay amount (0-10 sec)

» Rise

Set the rise amount (0-10 sec)

» Smooth

Set the step interpolation (0-100%)

6 Filter 1

» Step modulator » filter 1 cutoff (-1/+1)

» Bypass

7 Filter 2

» Step modulator » filter 2 cutoff (-1/+1)

» Bypass

8 Volume

» Step modulator » volume (0-100%)

» Bypass per-oscillator

9 Pan

» Step modulator » pan (0-100%)

» Bypass per-oscillator

10 Pitch

» Step modulator » pitch (-1/+1)

» Bypass per-oscillator

11 Drive

» Step modulator » drive (0-100%)

» Bypass per-oscillator

18

LFO Modulator and Modwheel Controls

Waveshape

1

Speed

2

Sync

3

Legato Controls

5

Mode

4

Filter 1

6

Filter 2

7

8

Volume

12

Filter

9

Pitch

10

Pan

13

Vibrato

11

Drive

14

Tremolo

Step Modulator Controls

1 Waveshape

Set the LFO waveshape

(sine, triangle, square, s&h)

2 Speed

Set the LFO speed

(Sync: 4x - 1/32)(Free: .18Hz - 15Hz)

3 Sync

Sync the LFO to the global tempo

4 Mode

Set the playback mode

(Retrigger/No Retrigger/Legato)

5 Legato Controls

Enabled if mode is set to [Legato]

» Attack

Set the delay amount (0-10 sec)

» Decay

Set the rise amount (0-30 sec)

5 Legato Controls (cont.)

» ED Depth

Set the smooth amount (-1/+1)

6 Filter 1

» LFO » filter 1 cutoff (-1/+1)

» Bypass

7 Filter 2

» LFO » filter 2 cutoff (-1/+1)

» Bypass

8 Volume

» LFO » volume (0-100%)

» Bypass per-oscillator

9 Pitch

» LFO » pitch (-1/+1)

» Bypass per-oscillator

10 Pan

» LFO » pan (0-100%)

» Bypass per-oscillator

11 Drive

» LFO » drive (0-100%)

» Bypass per-oscillator

Step Modulator Controls

12 Filter

» Modwheel » filter 1+2 cutoff (-1/+1)

» Bypass

13 Vibrato

» Modwheel » vibrato amount (0-100%)

» Bypass

14 Tremolo

» Modwheel » tremolo amount (01-00%)

» Bypass

19

Low CPU Mode (UltraMini LE)

Filtering CPU Cycles

UltraMini’s oscillators are powered by large multi-sampled libraries instead of realtime algorithms leaving the lions share of processing duty for two high quality multi-mode physically modeled filters. Under many circumstances, especially when running in poly mode, UltraMini can be quite resource hungry which is undesirable in larger sessions and on laptops.

In order to compensate for these environmental variables we’ve included a separate version of UltraMini with an optimized engine called UltraMini LE. The LE version functions near identically, with the only UI difference being in the filter section (see right-top). A significant amount of rework went into streamlining efficiency of the filter section, among others, allowing you to run more instances with less CPU overhead and for the most part very little difference in sound.

In order to get the best balance of sound quality to CPU efficiency the filters in UltraMini LE are single mode lowpass instead of switchable multi-mode. As lowpass is the most commonly used filter mode this should generally be a transparent change. However, in cases where presets have been designed with a bandpass or highpass filter mode the setting will be conformed to lowpass for

UltraMini LE likely resulting in a noticeable sound change.

Please make special note of this and pay close attention to the filter settings if moving between versions.

Additionally UltraMini LE utilizes a streamlined subset of the main sample library to improve loading speeds.

You can find the LE version of UltraMini along with the other modules in the UltraMini.ufs file (see right-bottom).

If the LE version does not appear in your UltraMini.ufs please download the latest version of UltraMini from the UVI website

(log in and click ‘Downloads’ under your user name).

Top: the filter section of UltraMini (standard)

Bottom: the filter section of UltraMini LE, with single-mode lowpass filters

UltraMini LE can be found with the other modules in the UltraMini library

20

Mono Presets

(Classic and XL)

00 - Init

Arpeggios

ARP - 101 Clean Decay MK

ARP - 101 Clean Short MK

ARP - Axial Tracer

ARP - Bass Reflector MK

ARP - Circuit Symp One

ARP - Count Down

ARP - Crystalizer

ARP - Engine Starter

ARP - Inversions

ARP - Melancolie

ARP - Popped Stitch

ARP - Rail Jumper

ARP - Slow Elepants

ARP - Speak n Spell CS

ARP - Spiral

ARP - Tangerine One

ARP - Telephony

ARP - Three Storms

ARP - Vintage Pincer

ARP - Warm Panner

ARP - Z Banana Factory

Bass

BS - 3 Oct Sub Click MK

BS - 3 Oct Sus MK

BS - Argentum

BS - Bloom Tender

BS - Broken Bass

BS - Droid Crooner Wheel MK

BS - Drone Step

BS - Hard Gristle

Preset List - Mono

BS - Hive Mind

BS - Hollow Sus MK

BS - I Am In Charge

BS - Light Hollow MK

BS - Mango Wheel

BS - Melodic MK

BS - Obee Boo

BS - Phassty

BS - Saw Tri MK

BS - Shinra Generator

BS - Short Bass CS

BS - Soft Funk MK

BS - This is D Mode

BS - Tracer Wheel

BS - Ultra Wet

BS - Very Low

BS - Video Game Sub

BS - Z Ball Dad

FX / Sound Design

FX - Broken Lead

FX - Daisy Grain

FX - Major Feeling

FX - Mini Arcade

FX - Minor Glitch

FX - OSC Kick CS

FX - Sonar Scan

FX - Steam CS

FX - Subsonic Devastator

FX - Sweep my Wheel

FX - Well Know One

Lead / Solo

LD - Big Short Lead

LD - Cliffs

LD - Cool Perfection CS

LD - Dark Choir

LD - Dragon Totem

LD - Endless Dawn

LD - Evolead

LD - Gryphic Solo

LD - HPF Lead CS

LD - Hybridation

LD - Lead Hollow MK

LD - Leading To Heaven

LD - Little Cake

LD - Love Me Funk

LD - Mini Saw Lead

LD - Multi Charger

LD - Nasty Tremowheel

LD - No Warning

LD - Phone Lead

LD - Raw Funk

LD - Robotik

LD - Smooth Solo

LD - So Funky

LD - Solo Axis

LD - Synth Hero

LD - Talking Fat

LD - The Last Whaal

LD - Turbo Charged

Monophonic

Phraser

PHR - Bass Magnetic

PHR - DG Havana

PHR - Electric Pirate

PHR - Fine AL

PHR - Finish Him

PHR - Gullfire

PHR - Hell Fusion

PHR - I Am Moustachu

PHR - Lydian

PHR - Noisy Bass Line

PHR - One Again

PHR - Phrase Min7 MK

PHR - Phraser Crew

PHR - Rubber Bandit

PHR - Substructure

PHR - The Earth Quake

PHR - WheeLocomotion

Short  Sequence

SEQ - Almost 8bit

SEQ - Cop Porn

SEQ - Little Mouse

SEQ - Short Soft

SEQ - VELectronica

SEQ - You Vee Hi

21

Poly Presets

(Classic and XL)

00 - Init

Analog Strings

STR - Big Triple

STR - Chunky Strings

STR - Full Phase Strings MK

STR - Mellow Strings

STR - Pure Old Analog

STR - Slow JMJ

STR - Strings Plain MK

STR - Strings Slow MK

Bass

BS - Bass The Dog MK

BS - Comp Attack MK

BS - Fusion MK

BS - Jazz in the Box MK

BS - Warm Attack

Poly Synths

PL - Analog Bells

PL - Band Pass Stepper MK

PL - Brabrass

PL - Brass 7th MK

PL - Brass 12 db MK

PL - Brass Oct MK

PL - Chord BP Stab MK

PL - Cosmic Forces

PL - Dawn Ascension

PL - Four Midable

PL - Future PPG CS

Preset List - Poly

PL - Gryphic Poly

PL - Old School Game

PL - Raise to 7th MK

PL - Relax

PL - Rendez Vous

PL - SanzAnalog

PL - Sequensations

PL - Simple Funky

PL - Soft Bright on Wheel

PL - Sun Titan

Arpeggios

ARP - Alternator

ARP - Jah Wheel

ARP - Man On Tropo

ARP - Nostalgia

ARP - Space Analog Piano

ARP - Space Dust MK

ARP - Sparkle Steps MK

ARP - Zodiac

Pads

PD - 2nd ENV Trigger MK

PD - 7th Random MK

PD - 70s Haunting MK

PD - Air Tin Teeter

PD - Arc Drops Move

PD - Baked Phalanges

PD - Bell and Dawn

PD - Dark Wheel Sweep

PD - Future Passed CS

PD - Lo Fox

PD - Male Choir MK

PD - Rocking Chair

PD - Silver Ramper

PD - Step eWHEELution

PD - Sweep Alien Zone

PD - Wheel Done

PD - Accumulator

Keyboards Sounds

KB - Analog Dub

KB - Cat Keys MK

KB - Church Analog

KB - Dream Analog Keys

KB - Lead Chords

KB - Medievaling

KB - Mini Wurli

KB - MKlavinet

KB - Organ Chapel MK

KB - Organ Dirty 5th MK

KB - Organ Perc MK

KB - Organ Soft 1 MK

KB - Organ Soft 2 MK

KB - Perc Keys MK

KB - Perfect Keys CS

KB - Pianolution

KB - Porta Sine

KB - Pure Beauty Keys

KB - Sine Keys MK

KB - Stellar Paradise

KB - Stepped Keys

KB - Synth Harpsychord

KB - Synth Keys

KB - The Lee Crew

FX / Sound Design

FX - Chrome Throat

FX - Crazy Melodic

FX - Destroy Strum

FX - Fire Mares

FX - Flutter

FX - Ghosted

FX - Inside UFOs

FX - Quino Polygon

FX - Soft Film Emitter

FX - Stack em High

Miscellaneous

MSC - Guitar Jazzy MK

MSC - Nate Bells

MSC - Space Marimba

MSC - Step Timelapse

MSC - The Voice and the

Whistle

MSC - Three Bells

MSC - Twelve Mellow

22

Preset List - Xtra 1.5

Bass

BS-Alive

BS-Antic

BS-Bodybass

BS-Dry Pass

BS-LoBit

BS-Mean Sus

BS-Portabit

BS-Raw Bass

BS-Triform

BS-Velocitize

Effects

FX-Chordmod

FX-Launch

FX-Mezmor

New Presets

(Classic and XL)

00 - Init

Arpeggios

ARP-Abcess

ARP-Autolog

ARP-Bevel Key

ARP-Chaotic

ARP-Chiff Grit

ARP-Chopper

ARP-Circles

ARP-Flicksyn

ARP-LoBit

ARP-Lock In

ARP-Meat Bass

ARP-One

ARP-Perk Chords

ARP-Pulse Wah

ARP-Square Glue

ARP-Two

Keyboard Sounds

KB-Aggro Organ

KB-Bandit

KB-Cab Chord

KB-Ting Vibe

Lead/Solo

LD-Bit Skit

LD-Biting Slider 1

LD-Biting Slider 2

LD-Crunch Keys

LD-Diver Glide

LD-Energy Waver

LD-Finglide

LD-Fri Jam

LD-Glass Grinder

LD-Mean Rise

LD-Noisy Open

LD-Open Stack

LD-Rez AM

LD-Ring Rez

LD-Rogue

LD-Stained

LD-Vibrofade

Pads

PD-Dampen

PD-Softback

PD-Twist Phase

Phraser

PHR-Agent Red

PHR-Blue Chordline 1

PHR-Blue Chordline 2

PHR-Blue Chordline 3

PHR-Can Opener

PHR-Chord Mover

PHR-Creep

PHR-Crunchy Chip

PHR-Diver Glide

PHR-Diver

PHR-Drive Cycles

PHR-Drive Max

PHR-Fastlane

PHR-Fri Mod

PHR-Gut Slide

PHR-Insecticide

PHR-Jam Slider

PHR-Joom

PHR-Little Beasty

PHR-Lo Aircrisp

PHR-Power Chord

PHR-Push

PHR-Ringer

PHR-Scream Bubble

PHR-Slide Pass LP

PHR-Slide Pass

PHR-Sub Crispy

PHR-TriOctane

PHR-Ups Bass

PHR-Whalk

PHR-Whip Squared

PHR-Wob Fly

Poly Synths

PL-Attacko

PL-Band Chord

PL-Bevel Key

PL-Blue Pluck

PL-Chord Me

PL-Fast Ambi

PL-Melodon

PL-Red Chord

Short Sequence

SEQ-Alive Auto

SEQ-Attacko

SEQ-Bodybass

SEQ-Gate Hollow

SEQ-Invert

SEQ-Rez Fry

SEQ-Softbit

STR-Stringmach

23

UVI Workstation: Tips + Tricks

MIDI Learn Arpeggiator

Most UVI Workstation parameters can be automated via. a convenient

MIDI Learn. MIDI Learn allows you to bind a physical MIDI controller to specific parameters within UVI Workstation.

Any FX tab parameter, Macro Knob or Slider in UVI instruments can use the MIDI Learn feature

The MIDI controller type and the MIDI Channel assignment will be saved with the multi or with your song in the host sequencer

Automation is assigned per-part

To use MIDI Learn:

1. Right-click the parameter in UVI Workstation that you want to automate

2. After the MIDI Learn dialog appears, Trigger the desired MIDI input controller (knob, fader etc.)

To remove a MIDI controller assignment:

Right-click the desired parameter and press “Delete”

Unlimited FX

UVI Workstation comes equipped with a robust arpeggiator. To insert an arpeggiator in a part, you need to display the Single view in the

UVI Workstation, then click on the note icon. The arpeggiator can be employed as a pattern gate, arpeggiator, or even an advanced rhythmic processor for your live MIDI performance or sequenced MIDI tracks. Arpeggiators can be inserted in an unlimited number of parts.

Preset Stacking

Thanks to the simplicity of the UVI Workstation you can stack as many preset as you want by simply assign multiple part on the same

MIDI channel.

Split, Velocity & Key Switch

UVI Workstation offers a wide variety of FX, or effect processors, to cover all your audio processing needs. The FX implementation is robust and includes the ability to insert unlimited FX slots in several stages of the signal flow.

Click the “FX” tab to open the FX page on the Single view

In Multi view the FX section is always displayed

The Keyswitch settings allow you to load multiple presets into two or more parts and dynamically play and mute them from your MIDI controller using key switching, note range, velocity range or any combination of the three parameters. This powerful feature gives you a great deal of real-time control.

Scroll Wheel

All knobs can be adjusted with the scroll wheel on your mouse.

When you double-click on any knob or slider, you can manually enter or type in the desired value.

24

Credits and Thanks

Produced by UVI

Recording / Editing / Sound Design

Damien Vallet

Kevin Guilhaumou

Alain J Etchart

Michael Kastrup

Nathaniel Reeves

Oliver Davis

Scripting & Software

Olivier Tristan

Remy Muller

GUI

Nathaniel Reeves

Special Thanks

Michael Kastrup

Manu @ master-wave.com

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project
