EMBEDDED MEMORY anD STORaGE SOLUTIOnS

aUTOMOTIVE COMMUnICaTIOnS InDUSTRIaL nETWORKInG SECURITY

2017

WHY CHOOSE SWISSBIT

Swissbit, the largest independent embedded memory and storage solutions manufacturer in

Europe, was created through a management buyout from Siemens Semiconductor in 2001. With over 20 years of experience in the memory & storage industry Swissbit has become a world class leader in technology, supplying high quality, high reliability memory & storage solutions with all established DRAM and flash interfaces.

Tier 1 customers in the industrial, networking / communication, and automotive segments continue to confirm the outstanding product features and quality and rely on Swissbit‘s excellent technical and logistics support.

Corporate Prof ile

Established

Financial Strength

CAGR 2009-2015

Headquarters

Subsidiaries

R & D sites

Production Site

1992 –2000 as SIEMENS AG

Swissbit AG was formed in 2001 through a management buyout

Privately held company, equity ratio > 60%

Double digit annual growth

Swissbit Group: Zug, Switzerland

Swissbit AG: Bronschhofen (St. Gallen, Lake Constance area)

Switzerland, Germany, USA, Japan, Taiwan

Switzerland, Germany and USA

Berlin, Germany

Overview of services provided by Swissbit:

PRODUCTS

- Complete line of NAND Flash Solid

State Drives with industry standard interfaces and form factors

- Both leading edge technology and legacy product offerings

- Extended and industrial temperature grade products

- Chip-On-Board (COB) and Systemin-Package technology

- Small form factor removable NAND

Flash cards

- Memory in-Package solutions

- Mobile Security Solutions, like

Secure microSD, SD and more

- Security firmware, drivers and SDK

SALES SERVICE AND

ENGINEERING SUPPORT

- Fast, effective, and competent sales staff on hand to serve your needs

- Our expert technical staff is avail- able for quick response

- Joint product qualification service

- In-house manufacturing in Germany

- Design-in support

CUSTOMIZATION

- Custom memory and storage solutions

- Security features

- Individual marking

- Conformal coating

OEM SERVICES

- Controlled bill of materials (BOM)

- Serialization and lot code tracking

- Support of long life cycles

- Stringent PCN and ECN process

TEST FOR RELIABILITY

- Final extended and industrial temperature testing with KTI and

Tanisys Technology equipment

- World class Swissbit application testing

- System Level Test During Burn-In

(TDBI)

- Environmental testing according to industrial and automotive standards

2

COMPLIANCE TO

- JEDEC, SDA, CFA, USB-IF, SATA-IO

- RoHS, REACH, and WEEE

- UL

- FCC, CE

QUALITY STANDARDS

- ISO 9001:2008

- TS 16949

- ISO 14001

ASSOCIATIONS

- JEDEC

- CompactFlash Association (CFA)

- SATA-IO

- USB Implementer Forum

- Secure Digital Association (SDA)

- Memory Implementers Forum

- Small Form Factor Special Interest

Group SFF-SIG

INTRODUCTION

Swissbit Target Applications ....... 4

Swissbit Product Features .......... 6

STORAGE SOLUTIONS

Flash Storage Solutions ............. 8

Flash Life Time Prediction .......... 9

SATA SSD‘s ............................. 10

SATA SSD 2.5“ ...........................

11

SATA SSD Modules SLC ................

12

SATA SSD Modules MLC ...............

13

CFast™ cards .......................... 14

CompactFlash™ cards ............... 16

MicroSD memory cards .............. 18

SD memory cards .................... 20

USB Flash Drives / Modules ......... 22

SECURITY SOLUTIONS

Security Products .................... 25

Security Editions ..................... 27

TECHNOLOGY

System-in-Package (SiP) ........... 28

Swissbit’s Unique 360°

Customer Service .................... 30

PART NUMBER DECODER

Storage and Security

Part Numbers ........................ 31

Global Presence ......................

32

3

SWISSBIT TARGET APPLICATIONS

INDUSTRY

Typical applications:

Industrial Automation

• Process- / motion control

• Industrial PC / embedded

• Industrial measurement

• Building technology

• Identification / access systems

• Surveillance

Energy

• Energy distribution

• Energy consumption

• Smart grid

Infotainment

• POS terminals

• Information terminals

• Ticket- / vending terminals

• Digital signage and advertising

• Casino gaming

• VLTs & lottery terminals

Healthcare

• Diagnostics

• Point of care testing

• Mobil systems

• Imaging

Transportation

• Train Control and Monitoring

Systems (TCMS)

• Multifunctional terminals

• Data recorders

Aerospace and defense

• In-flight Entertainment &

Communication (IFE&C)

• Communications, Command,

Control and Intelligence (C4ISR)

• Combat management systems

• Battlefield sensor systems

Memory and non-volatile storage solutions for embedded applications must provide reliable operation even in the most extreme conditions (e.g., temperature, shock, and vibration). As such, both the qualification cycle and the support life cycle needed for these products far exceed those of devices designed for typical consumer applications.

Swissbit‘s embedded memory and storage solutions are the perfect fit for such demanding applications. They offer the highest reliability and quality with long term availability and controlled BOM. To guarantee such high quality standards, each product undergoes thorough functional testing before being released for shipment.

AUTOMOTIVE

Typical applications:

• Entertainment systems

• Navigation systems

• Head unit / dashboard

• Black box / crash recorder

The increasing varieties of infotainment and dashboard applications in cars today require significantly higher storage capacities than before. All components used in automotive applications need to operate within a wide temperature range and withstand sudden power loss as well as shock and vibration.

Additionally, very low failure rates are essential, because replacements of malfunctioning parts can incur high costs.

Swissbit is the only independent embedded memory and storage manufacturer with TS16949. Our S-45 SD and microSD memory card lineup caters to the demands of an automotive application, offering the highest reliability and quality at competitive prices.

4

NETWORKING / COMMUNICATION

Typical applications:

• ATCA Blade

• Cable modem

• Content and video delivery

• Digital Subscriber Line access

multiplexer

• Enterprise Media Gateway

• Switches and routers

• Optical network

• Radar / Sonar

• Radio network controller

• Security

• Tetra Base Station

• Wireless Base Station

Telecommunication infrastructure is implemented globally in every possible climate zone; therefore the equipment has to operate under most severe weather conditions such as heat, cold, humidity, or dust. This results in a long, expensive qualification and testing process and the need for products that guarantee long-term availability to minimize the number of requalifications.

Our cards provide features that are particularly suitable for NetCom applications, where high reliability, longer duty cycles, and on-field firmware upgrade are key requirements.

Swissbit‘s product portfolio is very much focused on products and form factors that will dominate the NetCom sector in the near future, such as small form factors like our newest SATA III devices including M.2, mSATA, and slimSATA.

Among our solutions, we have customized products able to guarantee a high level of random performance meeting or exceeding most NetCom application requirements.

Swissbit‘s embedded memory and storage solutions are tested specifically for extreme environmental conditions and guarantee industry leading reliability standards. Long-term relationships with our suppliers allow us to maintain a fixed BOM along with the highest possible longevity.

SECURITY

Governments, enterprises, banks, and industry demand high-end security.

Swissbit‘s secure storage solutions offer smart modularization of algorithms and secure storage of encryption keys in one runtime environment. Thus solution providers can concentrate fully on system design while the computation of cryptographic operations is delegated to the trusted execution environment, e.g., a smart card chip in the flash memory device. The Swissbit Security

Interface supports all relevant mobile, portable, embedded, and PC platforms.

TARGET APPLICA-

5

SWISSBIT PRODUCT FEATURES

6

WIDE TEMPERATURE SUPPORT

Swissbit‘s embedded memory and storage solutions are designed and approved for reliable operation over a wide temperature range. The products are verified at temperature corners and pre-stressed with a burn-in operating functional test (Test During Burn In-TDBI).

ESD AND EMI SAFE

The product designs are in line with the latest regulations for electrostatic discharge and electromagnetic interference. Swissbit strives to exceed these limits with our own in-house technology and production capabilities, for example with

System-in-Package (SiP) competence.

SHOCK AND VIBRATION

Robustness is one of our key specification targets. The design, assembly, and use of selected materials guarantee an extremely solid design, which has been validated by extensive testing.

LIFE TIME MONITORING (LTM)

The Swissbit Life Time Monitoring feature enables users to access the memory device’s detailed Life Time Status and allows imminent failure prediction thereby avoiding unexpected data loss. This feature uses an extended

S.M.A.R.T. (Self-Monitoring, Analysis, and

Reporting Technology) interface or vendor specific commands to retrieve flash product information.

ZONE PROTECTION

The device allows the configuration of multiple zones with either no protection, write protection, or access protected settings. Each zone is secured with a separate password. A Windows tool and a programming library are available.

CONFORMAL COATING

Swissbit offers a special protective coating on selected products. This coating is a thin polyurethane film, which protects against aggressive environmental conditions such as dust, moisture, or corrosive gas.

SWISSBIT FEATURES

SECURE ERASE (SANITIZE / PURGE) /

FAST ERASE

This feature uses an uninterruptable sequence of data erase commands. Even a power-off can’t stop the process, which will continue upon restoration of power. The optional enhanced feature allows the customer to sanitize the data according to different standards like DoD, NSA,

IREC, etc. The purge algorithm can be started by

a software command or through a hardware pin.

TEMPERATURE SENSOR

The sensor allows the host hardware or software to monitor memory device temperature to improve data reliability in the target application environment.

HEAT SPREADER

Heat spreader for DRAM modules allow temperature hot spots to be dissipated over a larger surface area and improve the module’s reliability.

POWER FAIL PROTECTION AND

RECOVERY

Intelligent power fail protection and recovery protects data from unexpected power loss.

During an unintentional shutdown, firmware routines and an intelligent hardware architecture ensure that no corruption of user or system data will occur.

WEAR LEVELING

Sophisticated wear leveling and bad block management ensure that flash cells are sparingly and equally used to prolong the device‘s life.

READ-ONLY OPTIMIZED

In many industrial applications, content is written to the NAND flash once and is only read afterwards. For such cases, the firmware can be optimized to guarantee the highest possible data retention and less read disturb.

TRIM SUPPORT

The TRIM command allows the operating system to inform the SSD about which blocks of data are no longer considered in use and can be wiped internally, which increases system performance during subsequent write accesses.

With TRIM support, data scrap, which would otherwise slow down future write operations to the involved blocks, can be deleted in advance.

LOW POWER CONSUMPTION

Electronic devices with lower power consumption increase the value of the product, because they decrease energy cost, prolong battery life, and reduce heat generation in the device and hence require less cooling.

DATA CARE MANAGEMENT

Various effects like data retention, read disturb limits, or temperature can impact data reliability.

The latest generation of Swissbit products uses special methods to maintain and refresh the data for greater data integrity.

HIGH PERFORMANCE

Optimized for high sequential data rates and

IOPS by use of SLC technology.

SECURITY FEATURES

TRUE HARDWARE RNG

True random numbers are generated inside the secure element. True randomness is the key prerequisite for secure systems to prevent brute force attacks.

DIGITAL SIGNATURE AND

VERFICATION

Digital signatures are very popular and inevitable to protect against data or code manipulation.

HARDWARE BASED DATA

ENCRYPTION

Hardware based security is key when it comes to replaceability, simple workflows, and trusted runtime environments.

MOBILE BANKING AND EPURSE

Swissbit Security products for mobile banking and payment offer strong authentication and offline security.

K H

KNOW + HAVE

DEVICE PROTECTION BY DUAL

FACTOR AUTHENTICATION

The user needs to have the card and know the PIN.

IN FIELD FW UPDATE

The storage product can be upgraded with new

FW in the field. The upgrade process is protected against power loss.

LONGEVITY

The longevity product lines use special components with a long-term supply commitment of up to ten years. These products offer the lowest

TCO in demanding applications with high requalification cost.

WAF REDUCTION

The WAF (write amplification factor) for MLC based products is reduced by combining a paged based FW block management with a powerful card architecture and configuration settings.

SECURE VOICE

Secure Voice calls are a requirement for confidential communication. Swissbit Security products are optimal for fast, encrypted, and user friendly secure voice solutions.

ELLIPTIC CURVE CRYPTOGRAPHY

SUPPORT

Elliptic curves are faster and more efficient than

RSA cryptography.

SECURE CD-ROM

The flash memory can be partially or totally switched to read-only. This function ensures that e.g., important data can be modified only after PIN authentication.

DATA PROTECTION AND ENCRYPTION

Various data protection modes ensure privacy of stored data. The card offers a data safe function with strong AES encryption and PIN access protection.

SECURE LOGGING

In large, hidden storage, any system event log, tax data, consumption data, or audit trails can be stored securely in write-once mode, queue mode, or random access mode.

SWISSBIT FEATURES 7

SWISSBIT‘S EMBEDDED STORAGE SOLUTIONS

OEM‘s of various industries require a variety of memory and storage solutions. In contrast to typical consumer devices, Swissbit‘s embedded memory and storage solutions are designed for highest reliability under extreme environmental conditions. They come with a large feature set tailored to the demands of the industrial, automotive, and NetCom markets and with our commitment to long-term availability.

Swissbit‘s embedded memory and storage solutions portfolio covers all relevant interfaces and form factors including SD and microSD memory cards, CompactFlash

TM

and CFast

TM cards, 2.5“ SATA SSDs, SLIM SATA and mSATA SSDs, M.2, USB Flash Drives

(UFD) and modules.

Our sophisticated flash handling algorithms optimize performance and life of the Single Level Cell (SLC) and

Multi Level Cell (MLC) NAND flash used in our products.

combination with architectural and configuration improvements.

Product development according to stringent design rules and extensive product qualification procedures ensures the electrical and mechanical robustness of Swissbit‘s embedded storage solutions. All products are offered in commercial (0°C to +70°C) and industrial (-40°C to +85°C) temperature ranges. Available flash handling features include diagnostic information, built-in error correction, bad block management, static and dynamic wear leveling, and power fail protection. Our service team can offer product life time calculations for special use cases with specific workloads. The diagnostic features we provide enable our customers to access device state information and schedule replacements before the system stops working.

Swissbit has created a new product family named durabit that features highest endurance and unprecedented random write performance by using a page based FW translation layer in

8

Chip Capacity

Cost per Bit

Reliability & Endurance

Industrial Temperature

Write Performance

ECC Requirement

Data Retention

Longevity

SLC

•

••••

••••

••••

••••

•

••••

•••• pSLC

••

•••

••••

•••

••••

••

•••

••

durabit

The better MLC

•••

••

•••

•••

••••

••

•••

••

MLC

•••

••

•••

••

•••

••

••

•••

TLC

NAND FLASH TECHNOLOGY COMPARISON

••••

•

•

•

•

••••

•

•

•••• highest; ••• high; •• medium; • low

FLASH STORAGE SOLUTIONS

FLASH LIFE TIME PREDICTION

The endurance of flash based products is primarily defined by the maximum number of program / erase cycles of the flash components. SLC components normally allow 100,000 PE cycles per block while MLC is typically specified as 3,000 PE cycles and pSLC at 20,000.

This transparency of NAND component endurance is no longer provided for integrated flash cards with controllers and firmware. For each write that the host initiates, the flash controller has to perform internal management steps and may need to erase and write multiple blocks even at the smallest external write transfer size.

The ratio between internal write data volume and the external request size is called WAF (write amplification factor) and can vary between one (theoretical best case) and several hundred depending on card structure, flash components used, firmware architecture, and user- application write profile.

The WAF directly influences the IOPS rate but the endurance even more. With a WAF of 100, internal PE cycles are 100 times higher than expected from the external data rate, and the endurance limit is reached 100 times faster than anticipated.

Customer application use cases have a huge impact on the WAF. In most cases, how the software‘s access profile will translate into flash writes can hardly be predicted.

Swissbit supports a realistic forecast of the WAF and the endurance of their SSDs and storage cards with help of the Swissbit Life Time Monitoring Tool and statistical data stored into the flash by the firmware. This tool can read out the real usage data such as number of writes, number of erase cycles, the bad block statistic, the successful

ECC correction, and provides all the data necessary to extrapolate the life time of the device.

ENDURANCE OPTIMIZA-

The WAF can be significantly reduced from several hundreds to single digit values by using a page based firmware translation layer (FTL). Especially for MLC flash this means a significant improvement in endurance.

The Swissbit durabit

products use MLC flash and page based FTL and offer unprecedented endurance. durabit

SSDs even increase this benefit by a DRAM supported FTL and increased overprovisioning which enables the highest available endurance with MLC technology.

FLASH STORAGE SOLUTIONS 9

SATA 2.5“

SOLID STATE DRIVE

SATA SSD PRODUCTS

Swissbit’s 2.5” SSDs as well as the mSATA (MO-300), SLIM SATA (MO-297) and the M.2 SSD modules are ideal solutions for embedded applications requiring reliable and high performing storage in various form factors.

Our SATA SSDs offer a long service life combined with controlled BOM and a product change notification process. Each unit undergoes extensive testing over the full temperature range before being released for shipment.

The X-60 SATA 6Gb/s series is Swissbit’s solution for high performance, cost sensitive, high capacity markets. The SSD modules are available as mSATA (X-60m), SLIM SATA (X-60s), and M.2 (X-60m2). They were designed for all industrial, NetCom, and automotive applications requiring high data transfer rates up to 520 MB/s in sequential access and 75,000 IOPS in

4 KB random access. In addition, they offer a wide range of features such as Swissbit’s proven Power Fail Safety, ATA security feature set, Data Care

Management tools, a Windows or Linux tool and SDK for detailed

S.M.A.R.T.-based Life Time Monitoring, NCQ, TRIM, advanced wear leveling and bad block management and in-field firmware update functionality.

The 2.5” SSDs X-60 and X-60P combine the modules attributes with a rugged housing for best shock resistance. The X-60P product features additionally a Power Fail circuitry combined with a bank of high reliable capacitors. In case of a sudden power loss the stored energy allows complete hardening of the cached data into the flash.

The newly introduced SLC-based X-600 series are highly reliable storage solutions with outstanding endurance and are available with the same set of features as the X-60 products. They are built using the most reliable

SLC flash on the market and an industrial grade SATA III controller and operate from −40 °C to 85°C.

M.2 2280

M.2 2260

SLIM SATA SSD

MO-297 mSATA SSD

MO-300 full size

CFast

TM

card

69.85 mm

22.00 mm

PRODUCT SIZE COMPARISION

22.00 mm

X-600 series

X-60 series

X-60P

X-500

X-200 series

Industry Leading; default implemented; on request; not available

10 FLASH STORAGE SOLUTIONS

39 mm 29.85 mm 42.80 mm

2.5“ SATA lll

SSD

2.5“ SATA

SSD

2.5“ SATA

SSD

Series Name

Interface

Data Transfer Mode

Connector

Outline Dimensions

Flash Type

Density Range

X-60 / X-60P

SATA III - 6 Gbit/s

ATA8

15+7 pin Serial ATA

100.2 x 69.85 x 7.0 mm

MLC

30 GB – 960 GB

X-500 X-200

SATA II - 3 Gbit/s up to PIO4, MDMA2, UDMA6

15 + 7 pin Serial ATA with latch protection / special feature connector

15 + 7 pin Serial ATA

100.2 x 69.85 x 9.3 mm

16 GB - 512 GB

SLC

4 GB - 8 GB

Data Retention

10 years @ life begin

1 year @ life end

Endurance

Operating Temperature

485 TBW

(960GB, Enterprise workload)

-40°C to +85°C

2700 / 370 TBW

(64 GB, JESD219 Client /

Enterprise workload)

Commercial: 0°C to +70°C

Industrial: -40°C to +85°C

-55°C to +95°C Storage Temperature

Performance

Burst Rate (MB/s)

Sequential Read (MB/s)

Sequential Write (MB/s)

Random 4KB Read (IOPS)

Random 4KB Write (IOPS)

MTBF

Shock

Vibration

Humidity

Voltage

Power Consumption up to 600 up to 520 up to 450 up to 75,000 up to 75,000

5 V ± 10% / 3.3 V ± 5% typ 300 mA max 1200 mA

Idle 60 mA

DEVSLP <5 mA up to 300 up to 240 up to 220 up to 14,500 up to 5,300

≥ 2,000,000 hours

MIL-STD810; 2,000 G, 0.4 ms; 50 G, 11 ms

MIL-STD810; 20 G, 10-2,000 Hz random

85 % RH 85°C, 1,000 hrs

5 V ± 10 %

3.3 V optional

Slumber 140 mA max 700 mA

Idle 200 mA

100,000 P/E cycles

(Flash cell level)

-50°C to +100°C up to 300 up to 120 up to 95 up to 3,100 up to 25

≥ 2,500,000 hours

1,500 G

20 G

5 V ± 10 % max 320 mA

Idle 140 mA

Features & Tools

Part Number

X-60P: with Pfail Circuitry

Proven Power Fail Safety

NCQ, TRIM

Advanced Wear Leveling & Bad Block management

In-field firmware update

SBLTM Tool & SDK for S.M.A.R.T. based

Life Time Monitoring.

SFSAxxxxQvAAxss-t-dd-rrr-ccc

Proven Power Fail Safety

ATA security feature set

Enhanced Secure Erase, Purge and Sanitize features (MIL STD)

NCQ, TRIM

Advanced Wear Leveling & Bad Block management

In-field firmware update

SBLTM Tool & SDK for S.M.A.R.T. based Life

Time Monitoring

Proven Power Fail Safety

Security Features available

Wear Leveling & Bad Block management

SBLTM Tool & SDK for S.M.A.R.T. based Life

Time Monitoring

SFSAxxxxQvBJxss-t-dd-rrr-ccc SFSAxxxxQvBRxss-t-dd-rrr-ccc

FLASH STORAGE SOLUTIONS

11

SLC BASED MODULES

Part Number

MO-300 mSATA

MO-297

SLIM SATA

M.2

2242

M.2

2260 /

2280

MO-300 mSATA

MO-297

SLIM SATA

Series Name

Interface

Data Transfer Mode

Connector

Outline Dimensions

Thickness

Flash Type

Density Range

Data Retention

Endurance

X-600m X-600s X-600m2 X-200m X-200s

52 pos. Edge Connector

PCI Express (PCIe) mini

50.8 x 29.85 mm

3.3 mm

15 + 7 pin Serial ATA

Connector

4.0 mm

SATA III - 6 Gbit/s

ATA8

54 x 39 mm

75 pos. Edge Connector

B & M key

22 x 42 mm

3.6 mm

(PCIe) mini

SATA II - 3 Gbit/s up to PIO4, MDMA2, UDMA6

52 pos. PCI Express

22 x 60 / 80 mm 50.8 x 29.85 mm

DS: 3.6 mm

SS: 2.0 mm

3.3 mm

15 + 7 pin Serial ATA

Connector

54 x 39 mm

4.0 mm

8 GB – 128 GB 16 GB – 128 GB 8 GB – 64 GB

SLC

16 GB – 128 GB

10 years @ life begin

1 year @ life end max. 4.5 TBW per GB drive capacity

(JEDEC Enterprise WL)

2 GB - 64 GB

100,000 P/E cycles

(Flash cell level)

Operating Temperature

Commercial: 0°C to +70°C

Industrial: -40°C to +85°C

-40°C to +85°C Storage Temperature

Performance

Burst Rate (MB/s)

Sequential Read (MB/s)

Sequential Write (MB/s)

Random 4KB Read (IOPS)

Random 4KB Write (IOPS)

Voltage

Power Consumption

Features & Tools

3.3 V ± 5 % typ 450 mA max 750 mA

Idle 115 mA

DEVSLP 35 mA up to 600 up to 520 up to 405 up to 76,000 up to 73,000

5 V ± 10 % typ max

Idle

450 mA

750 mA

110 mA

DEVSLP 55 mA up to 600 up to 520 up to 245 up to 76,000 up to 54,000 typ

3.3 V ± 5 %

450 mA max 520 mA

Idle 115 mA

DEVSLP 35 mA up to 600 up to 520 up to 405 up to 76,000 up to 73,000 typ 450 mA max 750 mA

Idle 115 mA

DEVSLP 35 mA

Proven Power Fail Safety

NCQ, TRIM

Advanced Wear Leveling & Bad Block management

In-field firmware update

SBLTM Tool & SDK for S.M.A.R.T. based Life Time Monitoring

3.3 V ± 5 % typ 300 mA max 490 mA

Idle 180 mA up to 300 up to 120 up to 95 up to 3,100 up to 25

5 V ± 10 % typ 260 mA max 320 mA

Idle 140 mA

Proven Power Fail Safety

Advanced Wear Leveling & Bad Block management

SBLTM Tool & SDK for S.M.A.R.T. based Life

Time Monitoring

SFSAxxxxUvAAxss-tdd-rrr-ccc

SFSAxxxxVvAAxss-tdd-rrr-ccc

SFSAxxxxMvAAxss-tdd-rrr-ccc

SFSAxxxxUvBRxss-tdd-rrr-ccc

SFSAxxxxVvBRxss-tdd-rrr-ccc

12 FLASH STORAGE SOLUTIONS

MLC BASED MODULES

MO-300 mSATA

MO-297

SLIM SATA

M.2

2242

M.2

2260 / 2280

Series Name

Interface

Data Transfer Mode

X-60m X-60s

SATA III - 6 Gbit/s

ATA8

X-60m2

Connector

52 pos. Edge Connector

PCI Express (PCIe) mini

50.8 x 29.85 mm

15 + 7 pin Serial ATA Connector 75 pos. Edge Connector B & M key

Outline Dimensions

Thickness

Flash Type

Density Range

Data Retention

Endurance

3.3 mm

8 GB - 480 GB

54 x 39 mm

4.0 mm

22 x 42 mm

3.6 mm

22 x 60 / 80 mm

DS: 3.6 mm

SS: 2.0 mm

30 GB - 480 GB

MLC durabit

30 GB - 240 GB

10 years @ life begin

1 year @ life end max. 0.5 TBW per GB drive capacity ((JEDEC Enterprise WL) max 1.9 TBW per GB drive capacity (JEDEC Client WL)

30 GB - 960 GB

Operating Temperature

Storage Temperature

Performance

Burst Rate (MB/s)

Sequential Read (MB/s)

Sequential Write (MB/s)

Random 4KB Read (IOPS)

Random 4KB Write (IOPS)

Voltage

Power Consumption

Features & Tools

Part Number

3.3 V ± 5 % typ 500 mA max 960 mA

Idle 115 mA

DEVSLP 35 mA

Commercial: 0°C to +70°C

Industrial: -40°C to +85°C

-40°C to +85°C up to 600 up to 520 up to 450 up to 75,000 up to 75,000

5 V ± 10 % up to 600 up to 520 up to 340 up to 72,000 up to 78,000 typ 450 mA max 750 mA

Idle 110 mA

DEVSLP 55 mA typ 420 mA max 480 mA

Idle 110 mA

DEVSLP 35 mA

Proven Power Fail Safety

NCQ, TRIM

Advanced Wear Leveling & Bad Block management

In-field firmware update

SBLTM Tool & SDK for S.M.A.R.T. based Life Time Monitoring up to 600 up to 520 up to 450 up to 72,000 up to 75,000

3.3 V ± 5 % typ 500 mA max 960 mA

Idle 115 mA

DEVSLP 35 mA

SFSAxxxxUvAAxss-t-dd-rrr-ccc SFSAxxxxVvAAxss-t-dd-rrr-ccc SFSAxxxxMvAAxss-t-dd-rrr-ccc

FLASH STORAGE SOLUTIONS 13

CFast™ CARDS

CFast™ cards combine two existing industry standards into a single product: the CompactFlash™

(CF) card form factor and the Serial ATA (SATA) interface commonly used in hard disks. CFast™ cards can replace both HDDs and CompactFlash™ cards in applications requiring small form factors, high endurance and the ability to withstand shock, vibration, extreme temperatures (-40°C to +85°C), high altitude and rough environmental conditions. Swissbit’s CFast™ cards provide rugged storage for embedded and industrial systems where performance, data and system reliability, power fail protection and flexibility are important design considerations.

Swissbit CFast™ cards operate with a 3.3 Volt low power source and support three SATA power management states: Active, Partial, and Slumber. This standard is a perfect choice for both boot devices and as removable media for applications requiring low to medium storage densities with a small footprint. Additionally, the Swissbit CFast™ cards come with full engineering and customization support, S.M.A.R.T. based Life Time Monitoring features, our intelligent flash Management algorithms and Error Correction, guaranteeing the highest level of reliability even in rough application environments.

Swissbit’s latest innovations are the F-60 / F-600 SATA III CFast™ card series. Using state of the art controllers and MLC / SLC flash technology, the F-60 / F-600 achieve data transfer rates up to 520 MB/s in sequential access and 76,000 IOPS in 4 KB random access. In addition, the F-60 / F-600 series feature Swissbit’s proven Power Fail Safety, ATA security feature set, enhanced Secure Erase tools, a

Windows or Linux tool and SDK for detailed S.M.A.R.T.-based Life Time Monitoring, NCQ, TRIM, advanced wear leveling and bad block management or in-field firmware update functionality.

F-600

F-60

F-50

F-240

Industry Leading; default implemented; on request; not available

14 FLASH STORAGE SOLUTIONS

CFAST

TM

CARD

CFAST

TM

CARD CFAST

TM

CARD CFAST

TM

CARD

Series Name

Interface

Data Transfer Mode

Connector

Outline Dimensions

Flash Type

Density Range

Data Retention

F-600

SLC

8 GB - 64 GB

F-60 F-50

CFast™ 2.0 - SATA III - 6 Gbit/s

ATA8

MLC durabit

8 GB - 240 GB

CFast™ Type I

36.4 x 42.8 x 3.6 mm

MLC

8 GB - 256 GB

10 years @ life begin

1 year @ life end

F-240

CFast™ 1.0 - SATA II - 3 Gbit/s

ATA7

SLC

2 GB - 64 GB

Endurance

Operating Temperature

Features & Tools

Part Number

7.6 TBW per GB drive capacity 0.5 TBW per GB drive capacity 0.05 TBW per GB drive capacity

100,000 P/E cycles

(Flash cell level)

Commercial: 0°C to +70°C

Industrial: -40°C to +85°C

-40°C to +85°C Storage Temperature

Performance

Burst Rate (MB/s)

Sequential Read (MB/s)

Sequential Write (MB/s)

Random 4KB Read (IOPS)

Random 4KB Write (IOPS) up to 600 up to 520 up to 245 up to 76,000 up to 54,000

MTBF

Shock

Vibration

Humidity

Voltage

Power Consumption typ 450 mA max 715 mA

Idle 105 mA

DEVSLP 35 mA up to 600 up to 520 up to 180 up to 72,000 up to 43,000

≥ 2,000,000 hours

MIL-STD810; 2,000 G, 0.4 ms; 50 G, 11 ms

MIL-STD810; 20 G, 10-2,000 Hz random typ 400 mA max 495 mA

Idle 110 mA

DEVSLP 35 mA up to 600 up to 500 up to 330 up to 53,000 up to 74,000

85 % RH 85°C, 1,000 hrs

3.3 V ± 5 % typ 290 mA max 420 mA

Idle 75 mA

DEVSLP 35 mA

Proven Power Fail Safety

NCQ, TRIM

Advanced Wear Leveling & Bad Block management

In-field firmware update

SBLTM Tool & SDK for S.M.A.R.T. based Life Time Monitoring

SFCAxxxxHvAAxss-t-dd-rrr-ccc up to 300 up to 120 up to 120 up to 3,200 up to 75

≥ 2,500,000 hours

1,500 G

20 G typ 140 mA max 250 mA

Idle 55 mA

PHYSLP <20 mA

Proven Power Fail Safety

Sophisticated Wear Leveling &

Bad Block management

Read Disturb Management

TRIM

Low Power Consumption

Security & SBZoneProtection features available

SBLTM Tool & SDK for S.M.A.R.T. based Life Time Monitoring

Evaluation kit with 2.5” SATA adapter board available

SFCAxxxxHvBVxss-t-dd-rrr-ccc

FLASH STORAGE SOLUTIONS 15

CompactFlash™ CARDS

To this day, CompactFlash™ (CF) cards remain the most popular flash-based storage solution used in the embedded and industrial markets and the

CompactFlash™ card form factor and connector are well established. Swissbit‘s

CF cards were developed with strong focus on quality, reliability, robustness, and longevity. We select only high-quality components and apply design rules fitting the stringent requirements of our customers. Hardware and firmware were tested and qualified by our experienced technical team and features and functionality have been proven in many challenging customer applications.

Swissbit‘s CF Series C-3x0 and C-4x0 are offered in both commercial (0°C to

+70°C) and industrial (-40°C to +85°C) temperature ranges, providing rugged, reliable memory for a wide range of demanding use cases. They are designed to address a broad range of concerns from compatibility, booting, and power fail safety to long-term supply, controlled BOM, and outstanding flash protocolhandling techniques to ensure highest possible data integrity. In contrast to commonly promoted sequential performance values, Swissbit is especially focused on optimized random-access speed, one of the key requirements in legacy embedded CompactFlash applications.

Swissbit’s most recent CF card product family is the C-300 Longevity series, which offers maximum long-term availability (until at least 2021). In addition, the C-300 Longevity CF card ensures optimized backward compatibility with legacy systems, high random access speed, and a wide range of capacities from

32 MB to 8 GB using highly reliable SLC flash with 100,000 program / erase cycles.

C-300

C-300

LONGEVITY

C-320

C-440

Industry Leading; default implemented; on request; not available

16 FLASH STORAGE SOLUTIONS

LONGEVITY UDMA6 CF

COMPACTFLASH™

CARD

COMPACTFLASH™

CARD

COMPACTFLASH™

CARD

COMPACTFLASH™

CARD

Series Name

Interface

Data Transfer Mode

C-300 C-300 Longevity

CFA4.1

C-320

True IDE / PC card - Up to UDMA4, MDMA4 & PIO6

C-440

CFA5.0

True IDE / PC card - Up to

UDMA6, MDMA4 & PIO6

Connector

Outline Dimensions

Flash Type

Density Range

Data Retention

Endurance

128 MB - 8 GB 32 MB - 8 GB

CFC Type I

36.4 x 42.8 x 3.3 mm

SLC

2 GB - 32 GB

10 years @ life begin

1 year @ life end

100,000 P/E Cycles

(Flash Cell Level)

2 GB - 64 GB

Operating Temperature

Commercial: 0°C to +70°C

Industrial: -40°C to +85°C

Storage Temperature

Performance

Burst Rate (MB/s)

Sequential Read (MB/s)

Sequential Write (MB/s)

Random 4KB Read (IOPS)

Random 4KB Write (IOPS) up to 66 up to 37 up to 20 up to 3,300 up to 40

MTBF

Shock

Vibration

Humidity

Voltage

Power Consumption

Features & Tools

Part Number up to 66 up to 37 up to 20 up to 3,300 up to 50

-50°C to +100°C

1,500 G

20 G up to 66 up to 45 up to 35 up to 2,800 up to 44

≥ 3,000,000 hours up to 133 up to 65 up to 40 up to 2,400 up to 300 (with TRIM)

PIO typ 50 mA @ 3.3 V

DMA typ 70 mA @ 3.3 V

DMA typ 110 mA @ 5 V

Proven Power Fail Safety

Sophisticated Wear Leveling & Bad Block management

Security & SBZoneProtection features available

SBLTM Tool & SDK for S.M.A.R.T. based Life Time Monitoring

SFCFxxxxHxBKxss-t-xx-rrr-ccc

85 % RH 85°C, 1,000 hrs

3.3 V ± 5 %

5 V ± 10 %

SFCFxxxxHxBKxss-t-xx-rrr-ccc

PIO typ 60 mA @ 3.3 V

DMA typ 90 mA @ 3.3 V

DMA typ 130 mA @ 5 V

PIO typ 60 mA @ 3.3 V

DMA typ 80 mA @ 3.3 V

DMA typ 90 mA @ 5 V

Proven Power Fail Safety

Sophisticated Wear Leveling &

Bad Block management

Read Disturb Management

TRIM

Security & SBZoneProtection features available

SBLTM Tool & SDK for S.M.A.R.T. based Life Time Monitoring

SFCFxxxxHxBOxss-t-dd-rrr-ccc SFCFxxxxHvBUxss-t-dd-rrr-ccc

FLASH STORAGE SOLUTIONS 17

FLASH MANAGEMENT

MECHANISM

- Optimized error correction code

- Efficient algorithms for bad block management

- Real life time monitoring

- Sophisticated wear leveling and bad block management

- Power fail protection

microSD MEMORY CARDS

Swissbit‘s Industrial microSD Memory Cards are designed, manufactured and tested to withstand extreme environmental conditions. Each of our product series is designed for a broad, embedded use case with its unique requirements for longevity, service life, endurance, temperature, data retention, and cost.

The durabit S-45u series combines latest MLC technology with an innovative controller and a sub-page based firmware that enables unprecedented random write performance and an up to 100 times higher endurance compared to standard microSD card solutions. The special firmware features in the S-45u include powerful built-in error correction, read retry, autonomous data care management, randomizer, wear leveling and bad block management algorithms, and intelligent power fail protection. The Swissbit microSD memory cards are supported by the

Swissbit life time monitoring for real time status information. Applications that demand highest endurance and performance benefit from the equally featured but SLC flash technology based

S-450u. This series supports data transfer rates of up to 80 MB/s. Both S-450u and S-45u fulfill

UHS-I, class 10 speed grade.

By only using the strong bit of an MLC cell the S-46u pSLC version increases the endurance by a factor of 6.7 against MLC and offers all the features of the S-45u.

All Swissbit microSD Cards can withstand extreme environmental conditions. They provide the highest level of mechanical stability and enhanced ESD protection. Furthermore, the hard gold

SD connectors endure a minimum of 20,000 insertion cycles.

S-300u

S-200u

S-45u

S-46u

S-450u

18

Industry Leading; default implemented; not available

FLASH STORAGE SOLUTIONS

microSD

MEMORY

CARD

(SD / SDHC) microSD

MEMORY

CARD

(SD) microSD

MEMORY

CARD

(SD / SDHC) microSD

MEMORY

CARD

(SDHC / SDXC) microSD

MEMORY

CARD

(SD / SDHC)

Series Name

Interface

Data Transfer Mode

Connector

Outline Dimensions

Flash Type

Density Range

Data Retention

Endurance

Operating Temperature

S-300u

SD 2.0, Class 6 / 10

1 GB - 2 GB (SD)

4 GB - 8 GB (SDHC)

S-200u

SD 2.0, Class 6

Storage Temperature

Performance

Burst Rate (MB/s)

Sequential Read (MB/s)

Sequential Write (MB/s)

Random 4KB Read (IOPS)

Random 4KB Write (IOPS)

-40°C to +85°C up to 25 up to 24 up to 22

MTBF

Shock

Vibration

Humidity

Voltage

93 % RH 40°C, 500 hrs

Power Consumption

Read typ

Write typ

50 mA

50 mA

Proven Power Fail Safety

Advanced Wear Leveling

& Bad Block management

Features & Tools

Part Number

SFSDxxxxNxBWxss-t-ddrrr-ccc up to 25 up to 21 up to 18

Read typ

Write typ

30 mA

40 mA

Proven Power Fail Safety

Sophisticated Wear

Leveling & Bad Block

Management

Diagnostic features

Life Time Monitoring

SFSDxxxxNxBNxss-t-ddrrr-ccc

S-450u up to 104 up to 80 up to 75 up to 1200 up to 30

≥ 3,000,000 hours

1,500 G

50 G

85 % RH 85°C, 1,000 hrs

2.7 - 3.6 V

S-45u

SD 3.0, Class 10, UHS-I microSD

15 x 11 x 0.7 / 1 mm

SLC

512 MB - 2 GB (SD) 512 MB - 2 GB (SD)

4 GB - 8 GB (SDHC)

10 years @ life begin

1 year @ life end

MLC durabit

4 GB - 32 GB (SDHC)

64 GB (SDXC)

100,000 P/E Cycles

(Flash Cell Level)

3,000 P/E Cycles

(Flash Cell Level)

Extended: -25°C to +85°C

Industrial: -40°C to +85°C

-40°C to +100°C up to 50 up to 40 up to 12 up to 750 up to 650

Read typ 100 mA

Write typ 100 mA

Proven Power Fail Safety

S-46u pSLC

2 GB (SD)

4 GB – 16 GB (SDHC)

20,000 P/E Cycles

(Flash Cell Level) up to 104 up to 48 up to 48 up to 1350 up to 1400

Sophisticated Wear Leveling & Bad Block management

Autonomous Data Care Management

SBLTM Tool & SDK for detailed Life Time Monitoring

SFSDxxxxNxBMxss-t-dd-rrr-ccc

FLASH STORAGE SOLUTIONS 19

FLASH MANAGEMENT

MECHANISM

- Optimized error correction code

- Efficient algorithms for bad block management

- Diagnostic with real life time monitoring

- Sophisticated wear leveling and bad block management resistance

- Power fail protection

SD MEMORY CARDS

Secure Digital (SD) memory cards have a wide spread use in industrial and automotive application, ranging from read only applications as in navigation systems to utilization as boot media, for video recording or data logging. Swissbit’s Industrial Secure Digital (SD) card series are designed for high sustained performance and endurance over the entire lifetime and are manufactured and tested to withstand extreme environmental conditions. They provide the highest level of mechanical stability and enhanced ESD protection.

Each of our product series meets the stringent industry requirements for longevity, service life, endurance, temperature, data retention, and overall cost.

The durabit

S-45 / S-46 series combine latest MLC technology with an innovative controller and a sub-page based firmware that enables unprecedented random write performance and an up to 100 times higher endurance compared to standard SD card solutions. The S-45/S-46 firmware features include powerful built-in error correction, read retry, autonomous data care management, randomizer, wear leveling and bad block management algorithms, and intelligent power fail protection. The Swissbit SD memory cards are supported by the Swissbit life time monitoring for real time status information.

Applications that demand highest endurance and performance benefit from the SLC based

S-450. This series supports data transfer rates of up to 80 MB/s and offers the same data care features as the S-45. Both S-450 and S-45 fulfill UHS-I, class 10 speed grade. By only using the strong bit of an MLC cell the S-46 pSLC version increases the endurance by a factor of 6.7 against

MLC and offers all the features of the S-45.

S-200 / 220

S-45

S-46

S-450

Industry Leading; default implemented; not available

20 FLASH STORAGE SOLUTIONS

SD MEMORY

CARD

(SD / SDHC)

SD MEMORY

CARD

(SD / SDHC)

SD MEMORY

CARD

(SDHC / SDXC)

SD MEMORY

CARD

(SD / SDHC /

SDXC)

S-46 Series Name

Interface

Data Transfer Mode

Connector

Outline Dimensions

Flash Type

Density Range

Data Retention

S-200 / 220

SD 2.0, Class 6 / 10

512 MB - 2 GB (SD)

4 GB - 8 GB (SDHC)

S-450

Endurance

100,000 P/E Cycles

(Flash Cell Level)

Operating Temperature

Storage Temperature

Performance

Burst Rate (MB/s)

Sequential Read (MB/s)

Sequential Write (MB/s)

Random 4KB Read (IOPS)

Random 4KB Write (IOPS) up to 25 up to 24 up to 19 up to 1400 up to 90

MTBF

Shock

Vibration

Humidity

Voltage

1,000 G

15 G

Power Consumption

Features & Tools

Part Number

Read typ 40 mA

Write typ 65 mA

Proven Power Fail Safety

Sophisticated Wear Leveling

& Bad Block management

Diagnostic features & Life Time

Monitoring through SD / SPI command set

SFSDxxxxLvBNxss-t-dd-rrr-ccc up to 104 up to 90 up to 75 up to 1200 up to 30

S-45

SD 3.0, Class 10, UHS-I

SLC

512 MB - 2 GB (SD)

4 GB - 32 GB (SDHC)

SD

32 x 24 x 2.1 mm

MLC durabit

4 GB - 32 GB (SDHC)

64 GB - 128 GB (SDXC)

10 years @ life begin

1 year @ life end

3,000 P/E Cycles

(Flash Cell Level)

Extended: -25°C to +85°C

Industrial: -40°C to +85°C

-40°C to +100°C up to 104 up to 40 up to 12 up to 750 up to 650

≥ 3,000,000 hours

85 % RH 85°C, 1,000 hrs

2.7 -3.6 V Normal

1,500 G

50 G

Read typ 75 mA

Write typ 75 mA

Proven Power Fail Safety pSLC

2 GB (SD)

4 GB – 32 GB (SDHC)

64 GB (SDXC)

20,000 P/E Cycles

(Flash Cell Level) up to 104 up to 50 up to 55 up to 1350 up to 1400

Sophisticated Wear Leveling & Bad Block management

Autonomous Data Care Management

SBLTM Tool & SDK for detailed Life Time Monitoring

SFSDxxxxLxBMxss-t-dd-rrr-ccc

FLASH STORAGE SOLUTIONS 21

USB FLASH DRIVES / MODULES

The Universal Serial Bus (USB) interface is very well established and has almost entirely replaced any other forms of serial or parallel interfaces for computer peripherals and memory storage devices. Advantages of USB are its flexibility, fast sequential data transfer rate, and the ability to obtain power through the connector. Most computer and embedded systems support these devices either via the standard USB connector or internal, on-board terminal headers.

Swissbit offers both options in different form factors and in commercial and industrial operating temperature ranges. State of the art NAND flash handling algorithms, stringent component selection, product change control, and a

100% in-process final system test at full temperature range (-40°C to +85°C) qualify Swissbit’s USB Flash Drive (UFDs) for embedded and industrial markets.

Swissbit’s U-110 and U-4x Series (USB Flash Module) offers a no compromise flash based storage solution for:

• embedded PCs that need a rugged reliable storage solution,

• servers with backup or recovery functionality, and

• general industrial computers needing easy-to-use boot media.

All Swissbit USB solutions combine security features and Life Time Monitoring tools for product life control.

U-45 / U-46

U-400

U-110 unitedCONTRAST II

default implemented; on request; not available

22 FLASH STORAGE SOLUTIONS

eUSB FLASH

MODULE eUSB FLASH

MODULE eUSB FLASH

MODULE

USB FLASH DRIVE

Series Name

Interface

Data Transfer Mode

Connector

Outline Dimensions

Flash Type

Density Range

Data Retention

U-400

SLC

1 GB - 16 GB (32 GB opt.)

U-45 / U-46 U-110

USB 2.0

High / Full Speed

Standard:

Low Profile:

2.54 mm - 10 Pin (key option)

2.00 mm - 10 Pin (key option)

Standard: 36.8 mm x 26.65 mm x 9.6 mm

Low Profile: 36.8 mm x 26.65 mm x 5.7 mm

MLC durabit / pSLC

4 GB - 32 GB / 2GB - 16GB

SLC

1 GB - 16 GB

10 years @ life begin

1 year @ life end

3,000 / 20,000 P/E Cycles

(Flash Cell Level)

Commercial: 0°C to +70°C

Industrial: -40°C to +85°C unitedCONTRAST II

USB A-Plug

68.0 mm x 18.0 mm x 8.0 mm

SLC

512 MB - 16 GB

Endurance

Operating Temperature

100,000 P/E Cycles

(Flash Cell Level)

Storage Temperature

Performance

Burst Rate (MB/s)

Sequential Read (MB/s)

Sequential Write (MB/s)

Random 4KB Read (IOPS)

Random 4KB Write (IOPS up to 60 up to 37 up to 26 up to 1,600 up to 30

MTBF

Shock

Vibration

Humidity

Voltage

Power Consumption

Features & Tools

Part Number

-50°C to +100°C

100,000 P/E Cycles

(Flash Cell Level) up to 60 up to 32 up to 23 up to 650 up to 650

2.54 mm:

SFUIxxxxJvABxss-t-dd-rrr-ccc

2.00 mm:

SFUIxxxxKvABxss-t-dd-rrr-ccc up to 60 up to 32 up to 23 up to 1,600 up to 30

≥ 3,000,000 hours

50 G up to 60 up to 32 up to 23 up to 1,600 up to 30

3.3 V ± 5 % / 5 V ± 10 %

Full Speed typ 70 mA

High Speed typ 80 mA

15 G

85 % RH 85°C, 500 hrs

Proven Power Fail Safety

Windows / Linux – Spare block read out

Bootable USB Drive

Supports latest OS as Fixed Drive

Connector pitch & key variations available

Shock & vibration resistant

5 V ± 10 %

(3.3 V ± 5 % optional)

5 V ± 10 %

Full Speed typ 80 mA

High Speed typ 100 mA

Proven Power Fail Safety

Windows / Linux – Spare block read out

Hot Pluggable / Plug & Play

Optimized Wear Leveling

Security features

Password manager available

2.54 mm:

SFUIxxxxJvBPxss-t-dd-rrr-ccc

2.00 mm:

SFUIxxxxKvBPxss-t-dd-rrr-ccc

SFU2xxxxEvBPxss-t-dd-rrr-ccc

FLASH STORAGE SOLUTIONS 23

SECURITY SOLUTIONS

Security is becoming mandatory in diverse markets. Data breaches and compromised IT environments are becoming a reality. In the meantime legal requirements force solution providers to use state of the art security concepts.

If critical systems fail or sensitive data leak, severe fines and penalties are imminent. Customers and solution providers are rightly concerned about risks, creating a necessity to improve security in a reliable and flexible fashion.

That GSM calls can easily be tapped has been widely publicized in the telecommunications market. Reports about the mass interception of Internet data on a global scale compromise trust in the privacy of communications.

Sophisticated attacks on industrial facilities raise questions about liability and reliability. A new class of threats and risks needs consideration. Consumers, governments, enterprises, and industry are affected by security breaches directly or indirectly, visible or invisible.

Swissbit is the partner to support customers in industrial, medical, government, telecommunications, and the banking sector in delivering secure systems.

Each and every system requires storage to operate. While globally recognized as a leader in highly reliable flash memory solutions, Swissbit also designs, develops, and manufactures security products that provide additional security functions and features. Swissbit demonstrates a continuous, uninterrupted migration path towards secure systems while maintaining the reliability and flexibility of existing memory form factors.

Swissbit offers product related services:

• Security firmware and drivers

• Logo printing

• Optical and electronic personalization

• Design-in of consigned smart card chips

As well as extended services:

• Security consulting

• Security training

• Customer support

• Design-in support

• Connection with eco-system partner network for turn

key solutions and quick time to market

24 SECURITY SOLUTIONS

SECURITY PRODUCTS

The security product series in the microSD and SD form factor addresses the growing demand for mobile, portable and industrial security. The products offer tangible hardware security in the same manner as the plug and play approach.

For various markets, Swissbit offers a broad set of security use cases.

The flash memory can be used by any host to store data on the cards at high speed.

Additional security functions of the card can be activated to protect any data.

Valuable data such as sensitive files, emails, photos, OS images, FW updates, log files and audit trails can be protected by encryption, access protection, or made resistant to tampering by digital signature. Voice and video calls as well as data streams for M2M communication can be protected by the card in high speed. The best fitting product can be chosen depending on the use case.

Our security product series provides a smart card chip or a security extension to the Swissbit durabit™ firmware or a combination of both.

The block diagram below illustrates the architecture of the Swissbit

Security Interface, the flash controller, and the Encrypted flash chips.

The Swissbit Security Interface empowers solution providers to build applications on various platforms. An

SDK is available to develop applications on Windows™ and Linux™ PC platforms and on mobile phones and tablets like Android™ and BlackBerry™.

PKCS#11

Middleware

Partner and Customer solutions (like

applications, services, middleware, license control)

Swissbit

Security

Interface durabit™ firmware

AES

APP with Swissbit

Security Extension

(optional)

Secure

Element

Java

Applet

(Encrypted)

Flash

Memory

K H

KNOW + HAVE

SE

VE

FE

PE

DP

Industry Leading; default implemented; on request; not available

SECURITY SOLUTIONS 25

AVAILABLE SMART CARDS CHIPS

SE / VE / PE

FE

Infineon SLE 78 smart card chip

CC EAL 5+ HW and OS

Java card 3.0.4

Global Platform 2.2.1

Smart card OS jTop ID

Infineon SLE 78 smart card chip

FIPS 140-2 level 3

Java card V2.2.x (ext. of V3.0)

Global Platform 2.2.1

Gemalto ID Core 30

Security

Drivers / API

RSA up to 2048 bit optional ECC up to 512 / 521 bit

AES up to 256 bit

SHA2 up to 512 bit

RNG AIS31, FIPS-140

RSA up to 2048 bit

ECC up to 512 / 521 bit

AES up to 256 bit

SHA2 up to 512 bit

Compatible Middleware:

•

AET SafeSign

•

•

Charismathics

Cryptovision

Compatible Middleware:

• Gemalto

80 k EEPROM secure storage 160 k EEPROM secure storage

Windows, Mac, Linux,

BlackBerry, Android

SDK available

PKCS#11 Middleware

Windows, Mac, Linux,

BlackBerry, Android

SDK available

PS-100u PS-45

Compliance

Data transfer /

Compatible to

Temperature /

Compatible to

Flash Type

SE / VE / FE / PE

SPI mode supported

Speed class 10

S-45

-25°C to 85°C

S-45

(E-grade only)

MLC

8 GB - 16 GB

8 GB – 32 GB

8 GB – 16 GB

4 GB – 64 GB

PS-45u PS-450 PS-450u

SD 3.0 SD, ASSD V1.1

S-45u

S-45u

(E-grade only)

S-450

S-450

(E-grade only)

8 GB – 16 GB

4 GB – 32 GB

4 GB – 32 GB

4 GB – 32 GB

S-450u

SLC

S-450u

(E-grade only)

512 MB – 2 GB

512 MB – 8 GB

26 SECURITY SOLUTIONS

SECURITY EDITIONS

The Standard Edition SE fits best into authentication and PKI (Public Key

Infrastructure) use cases.

The card is supported by leading middleware vendors in mobile, desktop, and tablet use cases to ensure a seamless design-in into existing security infrastructures.

The

Voice Edition VE provides in addition to the SE card Elliptic Curve Cryptography. The enormous advantage of computation and security combined with small certificate sizes makes a VE card ideal for online key and certificate exchange.

The Premium Edition PE offers asymmetric and symmetric cryptography like the VE cards by the embedded smart card chip, whereas the

Data Protection

Edition DP offers symmetric encryption without smart card chip by the durabit™ FW.

PKCS#11

Middleware

The newly available Swissbit PKCS#11 Middleware is available as option for the SE,VE and PE product on industrial systems. A standardized interface enables smart integration into PKI use cases during personalization and in the field for digital signature and high secure encryption.

FE cards provide a secure element according FIPS 140-2 certification. US governmental organizations and enterprises that need to follow the FIPS

140-2 security standard benefit from smart integration into a storage form factor.

SECURITY PRODUCT

Mobile / PC

MATRIX

SE

Standard

Edition

PS-100u microSD 8 GB – 16 GB

VE

Voice

Edition

8 GB – 16 GB

FE

FIPS

Edition

8 GB – 16 GB

Medical

Automotive

Industrial

PS-45 SD 8 GB – 16 GB

PS-45u microSD 8 GB – 16 GB

PS-450 SD 4 GB – 32 GB

PS-450u microSD 0.5 GB - 2 GB

8 GB – 16 GB

8 GB – 16 GB

4 GB – 32 GB

0.5 GB - 2 GB

8 GB – 16 GB

8 GB – 16 GB

4 GB – 32 GB

0.5 GB - 2 GB

PE

Premium

Edition

8 GB – 16 GB

8 GB – 16 GB

4 GB – 32 GB

0.5 GB - 2 GB

DP

Data

Protection

8 GB – 32 GB

8 GB – 64 GB

8 GB – 32 GB

4 GB – 32 GB

0.5 GB - 2 GB

SECURITY SOLUTIONS 27

28

SYSTEM-IN-PACKAGE (SIP)

System-in-Package (SiP) is the processing of sensitive bare dies or chips into robust finished modules or components. With 20 years of experience, Swissbit successfully uses advanced packaging technologies to achieve the smallest form factors and to build multi-chip-packages. With this electronic integration approach, our products provide more functionality or highest memory densities inside one package, various functional blocks (RF, digital, sensors, security, and memory) as well as passive components are combined.

Beginning with the wafer and bare die handling, Swissbit utilizes a flexible chip-on-board (COB) assembly and packaging line. Processes like SMT assembly, die bonding, Au and Al wire bonding, dam&fill, transfer molding, precise separation with laser technology and sawing, housing, labeling, laser marking, etc. are very well established.

Die stacking, especially for flash and DRAM, is one of our expertises besides the integration of additional hardware features and an experienced team of testing and quality engineers. Our own Memory-In-Package line qualifies

(but does not limit) Swissbit as the development and production partner for any dedicated or customized memory-related product with challenging integration or reliability requirements. If you cannot satisfy the special demands regarding space and performance using traditional components and processes,

Swissbit offers feasibility studies, manages or supports your development project, and produces prototypes and small and mid-size volumes (up to 50,000 pieces / month). We will aid you beginning at your project's conception: from the design phase, prototyping, determining the circuit layout, and material selection to preparing the appropriate packaging for transport.

Swissbit produces and develops according to ISO 9001:2008, TS 16949, and

ISO 14001 approved processes and is an experienced partner in global industrial and automotive accounts.

Swissbit´s technology portfolio combined with its strong engineering knowhow and experience enables new, innovative MCP (Multi Chip Packages)/SiP/

COB configurations like stacked dies, side-by-side, sensors integration, etc.

System-in-Package solutions could be smaller, cheaper, and having tighter security.

System-in-Package benefits:

• Reduced process complexity

• Lower TCO (total cost of ownership)

• Reduced system board space due to smaller sized solutions than

individually packaged ICs

• Layer count reduction in System PCB

• Reduced board mounted height

• Mixed analog / digital design

• Reduced system board test complexity

SWISSBIT SIP AND COB COMPETENCY

CONCEPTION DEVELOPMENT

VERIFICATION &

QUALIFICATION

PRODUCTION LOGISTICS

• Product definition

• Feasibility studies

• Verification plan

• Qualification plan

• Design for test

• Design for

production

• Design to cost

• Package

development

• Process

development

• Substrate layout

• Test engineering

and development

• Failure analysis

consulting

• Product verification

• Debugging

• Optimization

• Reliability testing

• Life time

• Compliance to CE /

FCC / VCCI, UL, RoHS,

and REACH

• Fast prototyping

• Ramp up

• Yield management

• Series production of:

• SMT

• SiP

• COB

• MCP

• BGA

• Stock management

• Supply chain

management

• One-stop sourcing

SWISSBIT IS OFFERING THE FOLLOWING PRODUCTION TECHNOLOGIES

SMD

SEPARATION /

SINGULATION

DIE ATTACH / CHIP BONDING /

DIE STACKING

WIRE BONDING

ENCAPSULATION

MARKING

ADHESIVE APPLY

CONFORMAL

COATING

SYSTEM IN PACKAGE (SIP) 29

SWISSBIT’S UNIQUE 360° CUSTOMER SERVICE

PRE-SALES

YOUR FUTURE WITH OUR SOLUTION

Swissbit’s experienced BDM and FAE teams in Europe, North America, and Asia support you in the selection and qualification of the most suitable memory and storage solution for your applications.

Our services include

• TCO support

• consulting (design / concept / technology)

• qualification cycle support & joint qualification

• evaluation units

• hardware customization

• firmware customization

• midware customization for security products

• consulting for your future product generations

PRE-

SALES

AFTER-

SALES

CUSTOMER

SALES

AFTERSALES

LOCAL SUPPORT — GLOBALLY

Our engagement stretches far beyond the delivery of our products. Through sophisticated lifecycle management, we can ensure maximum longevity and smooth transitions in the event of product changes. And while we are proud of our best-in-class quality, we are still prepared to provide fast and solution-oriented RMA support at any time, including 4D and 8D reports whenever required.

Our services include

• local high level engineering support

• longevity of product lines - up to ten years

• field support (including firmware upgrades)

• full product and service life support

SALES

LOCAL SUPPORT — GLOBALLY

We understand the importance of providing local support in your language and time zone. For that reason,

Swissbit has established sales offices in all major regions plus a strong network of partners that reaches even farther. Our experienced sales teams manage forecasting and order fulfillment, if desired also through third-party logistics or distribution networks.

Our services include

• Global Account and Key Account Management

• highly sophisticated channel partners who can

support sampling within 24 hours

• fast, reliable response time

• highly reliable inventory management using an

integrated CRM/ERP/BI system for smart data

analysis and forecasting

30 CUSTOMER SERVICE

• hardware customization

• firmware customization

• midware customization for security products

• consulting for your future product generations

SWISSBIT PART NUMBER – THE DNA OF YOUR SPECIFIC PRODUCT

Flash and Security Part Number Decoder

S F CF 2048 H 4 B O 2 TO

1 2 3 4 5 6 7 8 9 10

-

I

11

-

M

12

S

13

*

14

*

15

Swissbit

Memory (1)

Memory Type (2)

F: Flash Products

Product Type (3)

U2: USB 2.0 Flash Drive

UI: UFD internal / Module

CA: CFast™

CF: CompactFlash™

SD: SD memory card

MM: Multimedia card

PA: PATA / IDE

SA: SATA

PC: PCIe

Density (4)

0016: 16 MB 4096: 4 GB

0032: 32 MB 8192: 8 GB

030G: 30 GB

060G: 60 GB

0064: 64 MB 016G: 16 GB 120G: 120 GB

0128: 128 MB 032G: 32 GB 240G: 240 GB

0256: 256 MB 064G: 64 GB 480G: 480 GB

0512: 512 MB 128G: 128 GB 960G: 960 GB

1024: 1 GB

2048: 2 GB

256G: 256 GB 001T: 1TB

512G: 512 GB 002T: 2TB

Product Dimension (5)

H: CompactFlash

TM

/ CFast

TM

J: UFD Module 2.54 mm terminal header

K: UFD Module 2.00 mm terminal header

L: SD memory card

M:M.2 SSD

N: microSD memory card

O: Multimedia card

Q: SSD 2.5”

U: mSATA (MO-300)

V: SLIM SATA (MO-297)

Product Generation (6)

Memory Organization (7)

Technology (8)

Design Option (15)

Configuration (14)

PIN Mode (13)

0: 1 nCE & R/nB

1: 2 nCE & R/nB

2: 4 nCE & R/nB

A: LGA 1 nCE & R/nB

B: LGA 2 nCE & R/nB

C: LGA 4 nCE & R/nB

E: COB 1 nCE

F: COB 2 nCE

G: COB 4 nCE & R/nB

H: COB 8 nCE & R/nB

O: 2 TSOP, single channel, 1 nCE & R/nB

P: 2 TSOP, single channel, 2 nCE & R/nB

Q: 2 TSOP, single channel, 4 nCE & R/nB

S: TSOP 1 nCE & R/nB

T: TSOP 2 nCE & R/nB

U: TSOP 4 nCE & R/nB

Flash Package Classification (12)

M: SLC SDP (single die package)

D: SLC DDP (dual die package)

Q: SLC QDP (quad die package)

N: SLC ODP (octal die package)

G: MLC SDP (single die package)

L: MLC DDP (dual die package)

H: MLC QDP (quad die package)

Temperature Rating (11)

I: Industrial Temp. (-40°C to +85°C)

E: Extended Temp. (-25°C to +85 / 90°C)

C: Commercial Temp. (0°C to +70°C)

Flash Supplier (10)

SA: Samsung

MT:Micron Technology

TO: Toshiba

MA:Macronix

HY: SK Hynix

Chips / Channels (9)

PART NUMBERS 31

11

12

32

Swissbit AG

Headquarters, R&D,

FAE support, Sales

Industriestrasse 4,

9552 Bronschhofen, Switzerland [email protected]

Swissbit Germany

R&D + Production

Wolfener Straße 36,

12681 Berlin, Germany [email protected]

Swissbit Security

R&D, FAE support, Sales

Kirchenstraße 62,

81675 Munich, Germany [email protected]

Swissbit Germany

Design Center

Dresden, Germany [email protected]

Swissbit NA Port Chester, NY

HQ SBNA + Sales

18 Willett Ave #202,

Port Chester, NY 10573, USA [email protected]

Swissbit NA Westford, MA

R&D + FAE support

238 Littleton Rd #202b,

Westford, MA 01886, USA [email protected]

Swissbit NA Houston, TX

Sales

4621 Pecan Grove

Sugar Land, TX 77479, USA [email protected]

Swissbit NA Silicon Valley, CA

Sales

2333 Maximilian Drive

Campbell, CA 95008, USA [email protected]

Swissbit NA Eagle, ID

Sales

1117 E Plaza DriveEagle,

ID 83616, USA [email protected]

Swissbit Japan

FAE support + Sales

2-1-24 Koenji-Kita,

Suginami-Ku Tokyo 166-0002,

Japan [email protected]

11

Swissbit China

FAE support

R 1701, Bd8, ZhonghaiKangcheng,

No. 149 QinghuiRd,

LonggangDist., Shenzhen, China [email protected]

12

Swissbit Taiwan

R&D, FAE support, Sales

2F., No. 125, Shengli 2nd Rd, Zhubel City,

Hsinchu County 302, Taiwan (R.O.C.) [email protected]

Mouser Electronics

Authorized Distributor

Click to View Pricing, Inventory, Delivery & Lifecycle Information:

Swissbit

:

SFSA16GBU1BR4TO-I-QT-226-STD SFSA256GQ1BJATO-I-NU-216-STD SFSA32GBU1BR4TO-I-NC-226-STD

SFSA064GQ1BJATO-I-QT-216-STD SFSA032GQ1BJATO-I-DT-216-STD SFSA016GQ1BJ8TO-I-DT-216-STD

SFSA128GQ1BJ8TO-I-NU-216-STD SFSA8192U1BR4TO-I-DT-226-STD SFSA256GQ1BJATO-C-NU-216-STD

SFSA032GQ1BJATO-C-DT-216-STD SFSA128GQ1BJ8TO-C-NU-216-STD SFSA016GQ1BJ8TO-C-DT-216-STD

SFSA064GQ1BJATO-C-QT-216-STD SFCF16GBH2BU4TO-C-QT-527-STD SFCF2048H2BU2TO-C-MS-527-STD

SFCF64GBH2BU4TO-C-NU-527-STD SFCF8192H2BU2TO-C-QT-527-STD SFCF4096H2BU4TO-C-MS-527-STD

SFCF32GBH2BU4TO-C-QT-527-STD SFPA2048Q1BO2TO-I-MS-243-STD SFPA2048Q1BO2TO-C-MS-243-STD

SFPA32GBQ1BO8TO-I-QT-243-STD SFPA8192Q1BO2TO-C-QT-243-STD SFPA32GBQ1BO8TO-C-QT-243-STD

SFPA4096Q1BO2TO-I-DT-243-STD SFPA8192Q1BO2TO-I-QT-243-STD SFPA16GBQ1BO4TO-I-QT-243-STD

SFPA4096Q1BO2TO-C-DT-243-STD SFPA16GBQ1BO4TO-C-QT-243-STD SFSA8192U1BR4TO-C-DT-226-STD

SFSA2048U1BR2TO-I-MS-226-STD SFSA16GBU1BR4TO-C-QT-226-STD SFSA4096U1BR4TO-I-MS-226-STD

SFSA1024U1BR2TO-C-MS-226-STD SFSA32GBU1BR4TO-C-NC-226-STD SFSA2048U1BR2TO-C-MS-226-STD

SFSA4096U1BR4TO-C-MS-226-STD SFCA32GBH2BV4TO-C-QT-226-STD SFCA8192H2BV4TO-C-DT-226-STD

SFCA4096H2BV4TO-C-MS-226-STD SFCA64GBH2BV4TO-C-NU-226-STD SFCA16GBH2BV4TO-C-QT-226-STD

SFCF0256H1BK1TO-C-MS-553-SMA SFCF0128H1BK1TO-C-MS-553-SMA SFCF0512H1BK2TO-C-MS-553-SMA

SFCF1024H1BK2TO-C-MS-553-SMA SGN02G72F1BD1SA-CCWRT SEN06464H2CH1MT-25WR

SGN04G64E1BD2SA-DCWRT SGN02G64D2BD1SA-DCWRT SGN01G64D2BG1SA-CCWRT SGN01G72F1BG1MT-

CCWRT SGN08G72G1BB2SA-DCWRT SGN08G64B3BB2SA-DCWRT SFSA480GQ1BJ8TO-I-OC-216-STD

SLN04G72G2BK2MT-DCRT SLN04G64E1BK2MT-DCRT SEN01G64D1BF1SA-30WR SFU28192E1BP2TO-C-QT-

111-STD SFCF8192H1BO2TO-C-Q1-543-SMA SFSA032GQ1BJATO-I-DT-226-STD SFSA256GQ1BJATO-I-NU-226-

STD SFCF16GBH1BO4TO-C-Q1-543-SMA SFU22048E1BP2TO-C-MS-111-STD SFSA016GQ1BJ8TO-I-DT-226-STD

SFCF32GBH1BO4TO-C-NC-543-SMA SFSA128GQ1BJ8TO-I-NU-226-STD SFU24096E1BP2TO-C-DT-111-STD

SFCF4096H1BO2TO-C-D1-543-SMA SFSA064GQ1BJATO-I-QT-226-STD SFU216GBE1BP2MT-I-QT-121-STD

SEN01G64D1BF1SA-25R SFU216GBE1BP2MT-C-QT-121-STD SFU24096E1BP2TO-I-DT-111-STD

SFCF2048H1BO2TO-C-M0-543-SMA SFCF0512H1BK1MT-C-MS-553-SMA SFCF0128H1BK1MT-C-MS-553-SMA

SFCF4096H1BK2MT-C-QP-553-SMA SFCF1024H1BK2MT-C-MO-553-SMA SFCF0256H1BK1MT-C-MS-553-SMA

SFCF8192H1BK4MT-C-QT-553-SMA SFCF2048H1BK1MT-C-QT-553-SMA SFSD4096L1BM1TO-I-GE-111-STD

SFSD016GL1BM1TO-I-LF-111-STD SFSD8192L1BM1TO-I-GE-111-STD SFSA512GQ1BJATO-I-NC-226-STD

SFSD032GL1BM1TO-I-HG-111-STD SFSD8192L1BM1TO-E-GE-111-STD SFSA060GQ1BJ4TO-C-LB-216-STD

SFSA480GQ1BJ8TO-C-OC-216-STD SFSA120GQ1BJ8TO-C-LB-216-STD SFSD2048N1BN1TO-E-QF-161-STD

SFSA030GQ1BJ2TO-C-LB-216-STD SLN08G64B3BB2SA-DCRT SLN02G72F1BK1MT-DCRT SFSA240GQ1BJ4TO-

C-OC-216-STD SFSD4096L1BM1TO-E-GE-111-STD SFSA064GQ1BJATO-I-QT-226-STC SFSA064GQ1BJATO-C-

QT-226-STD SFSA4096U1BR4TO-I-MS-236-STD
