STMTouch driver user manual

STMTouch driver user manual
UM1606
User manual
STMTouch driver user manual
Introduction
The document covers the following touch sensing library product codes:
•
STM8L-TOUCH-LIB
•
STM8TL-TOUCH-LIB
•
32L1-TOUCH-LIB
•
32F0-TOUCH-LIB
•
32F3-TOUCH-LIB
The STMTouch driver includes:
• A complete register address mapping with all bits, bitfields and registers declared in C.
This avoids a cumbersome task and more importantly, it brings the benefits of a bug free
reference mapping file, speeding up the early project phase.
• A collection of routines and data structures covering all functions to manage the touch
sensing technology.
The STMTouch driver source code is developed using the ANSI-C standard. It is fully
documented and is MISRA®-C 2004 compliant. Writing the whole library in 'Strict ANSI-C'
makes it independent from the development tools. Only the start-up files depend on the
development tools.
Run-time failure detection is also implemented by checking the input values for all library
functions. Such dynamic checking contributes towards enhancing the robustness of the
firmware. Run-time detection is suitable for user application development and debugging. It
adds an overhead which can be removed from the final application code to minimize code
size and execution speed. For more details refer to Section 1.4: Run-time checking.
Since the STMTouch driver is generic and covers many functionalities and devices, the size
and/or execution speed of the application code may not be optimized. For many
applications, the STMTouch driver may be used as is. However, for applications having
tough constraints in terms of code size and/or execution speed, the STMTouch driver may
need to be fine tuned.
Note:
April 2014
Additional information on the STMTouch driver functions, variables and parameters can be
found in the CHM user manual present in the STMTouch Library installation folder.
