User Manual

1

Contents

Introduction

Getting Started

Pager Features

1

Battery Information

3

6

Battery Installation and Removal 7

Button Definition

Pager

Pager

Backlight

Main Menu Screen

Function Menu

Time and Date

Private Time

Alarm(One Time/Daily)

Pager Control

8

9

9

9

Mode

Quick Access to Vibrate Mode

10

11

12

13

Scroll

Reminder Alert

19

20

21

Messages

Button Definition for Inbox and

Saved Folders 22

Button Definition for Info Folder 23

Inbox Folder

Inbox Folder Function Menu

Receiving Messages

Error & Priority Messages

Info Folder Function Menu

Saved Folder

Saved Folder Function Menu

24

25

27

28

Message Full Indication &

Duplicate Messages 29

Info Folder (Information Service) 30

14

15

16

17

18

31

33

34

Feature Name Change

Other Features

35

36

Low Battery Alert

Out of Range

Power Up Message

Auto Backlight 37

Depleted Battery Shutdown

Over the Air Programming

Maintenanace

Care for your pager

37

37

38

2

3

Pager Features

The Br 802 POCSAG offers a wide range of useful features

- 4 Lines, 20 English character screen

- Up to 40 Inbox messages

- Up to 24 Info slots with 5 history per slot

- 20 Saved slots for messages transferred from Inbox or Info folder

- 8 user selectable pleasing alerts

- Vibrate alert and vibra call

- Quick access to vibrate mode

- 3 speed auto scrolling option

- Private time

- Backlight display for ease of reading

- Message zoom

- Unread message indication

- Alarm (One Time/Daily)

- Changeable naming for Group message, Info slot, Info folder,

Saved folder and Inbox folder

- Error message indication*

- Message preview

- Message full indication

- Continous message indication

- Unread message indication

- Duplicate message indication*

- Priority message alert

- Group message alert

- Info message alert

- Unread message reminder alert

- Low battery alert*

- Real time clock and date display

- Adjustable LCD contrast

- Battery life gauge

- Out of range indication*

4

- Power up message*

- Auto Backlight on upon reception of message*

- Over the air programming*

5

*optional features are set by the service provider

Battery Information

This pager is designed to operate on one 'AA' size alkaline battery( Do not use any other battery type than AA alkaline). If the display shows the battery level is low. Replace the battery as described on page 7. The correct time and any stored Messages will remain intact for up to one minute after removing the battery.

WARNING

- Use of a battery other than an Energizer E91 OR a Duracell

MN 1500 1.5V AA Alkaline Battery may impair Intrinsic Safety. To prevent ignition of flammable or combustible atmospheres, remove battery before servicing.

Intrinsic Safety Markings

RAD DEV FOR HAZ LOC INT SAFE

CI.I,Div1,Gr.CD, Cl.I,Div2,Gr.ABCD, Exia, T4

0539 II 1 G EEx ia IIA T4 DEMKO 05 ATEX 0511276

6

7

Battery Installation and

Removal

- Place the pager face down on the palm of your hand

- Unlock the door and slide it out as shown

- Insert new battery into battery compartment

- Ensure that the battery polarity is corrct as indicated on the housing.

- To close, slide the battery door back into position and lock it

Button Definition

Up

Button

Backward

Button

Forward

button

Down

Button

Read/On

Button

Function

Button

- Backward Button : navigate back

- Forward Button : navigate forward

- Function Button : access the function menu

- Read/On button : read messages/hold to turn pager on

- Down button : navigate down/hold to quick access to

vibrate mode

- Up button : navigate up

8

Pager ON

Press and hold for 2 seconds to turn on the pager.

Pager OFF

Press button once from the Main Menu screen to go to the Function

Menu screen, then press button five times to select TURN OFF function.

Press button, "TURN OFF" is displayed.

Press button again to confirm turning your pager off, or button to cancel.

Backlight

Press and hold for 2 seconds to turn ON the backlight manually

Press and hold for 2 seconds to turn OFF the backlight manually

Main Menu Screen

Time and Date

Display

Private Time

Indicator

Alarm

Out Of Range

Battery Level

Alert Status

Saved

Folder

Inbox

Folder

Unread Message/s

Indicator

Info Folder

Unread Info

Slot Counter

The pager returns to the Standby screen after the time out period. Time, date,battery level and private time indicators are displayed in the

Standby screen.

Press any button to return to the Main Menu screen

10

Function Menu

11

Current Function

Prompt

Set Alert

Set Time

Private Time

Turn Pager Off

Pager Control

Set Alarm

- Press to enter the function Menu screen from the Main menu screen.

- Press to move to the desired menu icon

- Press to select

- Press to cancel and return to the Main Menu

Pager Tips

Without any key press, the pager automatically returns to the Standby screen without saving changes after 16 sec.

Alert Mode

Alert Icons

Dummy Alert

8 Pleasing

Alerts

- Press to enter the Function Menu screen from the Main Menu screen

- Press to enter alert mode sub function. The dummy alert will blink

- Press to move to different alert modes and hear a sample from vibrate,sleep,vibra-call,chirp,continous alert and pleasing alerts 1-8

- Press to confirm your selection,or to cancel.

The alert status is updated in the status icon display as described below:

Audio :

Pleasing alert,chirp continous alert

Sleep:

Receives messages but no alert

Vibrate: vibration

Vibra-call:

Vibration followed by audio alert

12

Quick Access to Vibrate mode

You can use to quickly access vibrate mode if your pager is currently in audio alert mode. (Your pager must be on the Main Menu page in order to use this function).

Alert mode active

Silent mode active

12:00 01 01 12:00 01 01

00 00 00 00

13

- Press and hold for 2 seconds to access vibrate mode.

- Repeat the process to return to previously active alert mode.

- When the pager is in Private Time, quick access to vibrate mode is not available.

Time and Date

To access and set the time and date of your pager;

12:00 01 01

12 hr

12:00

AM

01 JAN 03

- Press once from the Main Menu screen to enter the Function Menu screen and SET ALERT will appear.

- Press button once to select "SET TIME", then press the button and a 12 hour clock appears.

-To select the 12hr or 24hr clock press / then press to advance and set the hour of your pager.

-After presing to highlight the hour field, use the / button to choose the value.

- Repeat the above steps for setting minutes, AM/PM, day, month and year.

- Press to confirm your settings, or to cancel.

14

15

Private Time

Activating Private Time sets a daily period of time in which your pager will not alert. Private Time overrides any current alert mode status.

However, the pager will still receive messages, the alarm and Priority Alerts will still alert when the pager is in Private Time.

12:00 01 01

Private time active

START END

12:00

AM

12:00

PM

-Press the button once from Main Menu screen to go to the Function

Menu screen, "SET ALERT" will appear. Press twice to select

"PRIVATE TIME", then press to enter. A flashing clock appears.

- Press / to activate or deactivate the Private Time function.*

- Press to go to the "START" field , press / to set the starting time. Then Press to go to the "END" field, press / to set the ending time.

- Press to confirm your settings, or to cancel.

* A dot at the left of the Status Icon Display indicates that the function is active.

Alarm ( One Time/Daily )

To use your pager as an Alarm;

12:00 01 01

#

-Press once from Main Menu screen to go to the Function Menu screen, "SET ALERT" will appear. Press three times to select "SET

ALARM", then press to enter and a flashing appears.

- Press / to turn the alarm ON or OFF . Press to move to the time field.

- Press / to change the hour then press to move to the next field.

Repeat this step for setting minutes, AM/PM, day, month and year.

- Press to confirm your settings, or to cancel.

- When the Alarm is active an Alarm icon is displayed in the Status Bar.

Pager Tips

By setting no date for your alarm the alarm will sound every day at the

specified time; - example: " 9 : 00 AM -- --- -- "

16

Set Contrast

To change the display contrast of your pager's screen;

12:00 01 01

#

- Press once from the Main Menu screen to go to the Function Menu screen, "SET ALERT" will appear. Press four times to select "PAGER

CONTROL", then press and "SET CONTRAST" appears. Press to select Set Contrast.

- Press to select and change the display contrast of your pagers screen.

/

- Press to confirm your settings, or to cancel.

18

Auto Scroll

Activating Auto Scroll will cause the display to scroll through a message automatically. The display will scroll faster or slower depending on the set speed.

12:00 01 01

#

MEDIUM

19

- Press from the Main Menu screen to go to the Function Menu screen,

"SET ALERT" will appear. Press the button four times to select

"PAGER CONTROL", then press . Press once and "AUTO

SCROLL " appears. Press to select Auto Scroll.

- Press / to make auto scroll active or inactive .

- Press to highlight auto scroll level and use / to select "SLOW",

"MEDIUM" or "FAST" as the scroll speed.

- Press to confirm your settings, or to cancel.

Reminder Alert

By turning Reminder on, the pager will alert at 2 minute intervals when there are unread messages.

12:00 01 01

REMINDER

OFF

#

- Press once from Main Menu screen to go to the Function Menu screen, "SET ALERT" will appear. Press four times to select "PAGER

CONTROL", then press the button once and press the button twice and "REMINDER " appears. Press to enter the Reminder menu.

- Press / Button to switch ON or OFF.

- Press to confirm your settings, or to cancel.

20

Set Zoom

You can double the font size of your message display for easy reading.

12:00 01 01

SET ZOOM

OFF

#

21

- Press once from Main Menu screen to enter the Function Menu screen and "SET ALERT" will appear. Press the button four times to select

"PAGER CONTROL", then press the button and scroll the button three times and "ZOOM " appears. Press to enter the Set Zoom menu.

- Press / to switch ZOOM ON or OFF.

- Press to confirm your settings, or to cancel.

Button Definition for Inbox and Saved Folders

In the Inbox or Saved Folder Screen;

: display content of current message

: move to the next message

: move to the previous message

: move to the previous line of message icons

: move to the next line of message icons

: enter Inbox/Saved Folder Function screen

When reading an Inbox or Saved message;

: scroll down through the message. When it reaches the bottom it returns to the Inbox/Saved Folder Screen

: move to the next message

: move to the previous message

: jump to the top of the message. When at the top of the message it returns to the Inbox/Saved Folder Screen

: scroll down through the message. When it reaches the bottom it returns to the Inbox/Saved Folder Screen

: enter Inbox/Saved Message Function screen

22

23

Button Definition for Info Folder

In the Info Folder Screen;

: display the content of current message in the slot

: move to the next slot

: move to the previous slot

: preview the previous message in the current slot

: preview the next message in the current slot

: enter Info Folder Function screen

When reading an Info Folder Message;

: scroll down through the message. When it reaches the bottom it jumps to the next message. When it reaches the last message in the slot the pager returns to the first message of the slot

: move to the next message

: move to the previous message

: jump to the top of the message. When at the top it returns to the Info Folder Screen

: scroll down through the message. When it reaches the bottom it jumps to the next message. When it reaches the last message in the slot the pager returns to the first message of the slot

: enter Info Message Function screen

Inbox Folder

- Press to enter Inbox Folder Screen from the Main Menu screen when the cursor is on the Inbox Folder icon.

Current message number

Total messages

Current cursor position

Read group message

Unread message

Read message

Unread group message

Locked message

MESSAGE TEXT PREVIEW

24

25

Inbox Folder Function Menu

16 24

ESCAPE

ESCAPE

LOCK/UNLOCK

MESSAGE

DELETE

MESSAGE

DELETE ALL

SAVE MESSAGE

- Press to open the Inbox Folder Function Menu screen.

- Press to move to the next Inbox Folder Function prompt.

- Press to activate the selected function.

- A confirmation prompt "?" comes with "DELETE ALL" and "DELETE

MESSAGE".

- Press again to confirm, or to cancel.

- A message is defined as read once the first page of the message has been read. Previewing a message is not considered as reading a message.

- Locking a message prevents it from being accidentally deleted or overwritten by new messages. You can lock up to 20 messages.

- You can enter Inbox Message Function menu by pressing when you are reading the message. The operation is the same as the Inbox Folder

Function Menu except there is no "DELETE ALL".

- Please note. Locked messages cannot be deleted. Likewise, unread messages cannot be deleted by using "DELETE ALL".

26

27

Receiving Messages

When a message is received, your pager alerts you according to your set alert mode. The time and date stamp at the end of each message indicates when the message was received.

(Normal,group and Priority messages have different pleasing alerts)

Time and Date stamp

05 07

MESSAGE TEXT MESSAGE

TEXT MESSAGE TEXT

MESSAGE TEXT MESSAGE

TEXT MESSAGE TEXT

05 07

CAP-1

12:01AM 0 1FEB2003

4-line x 20 Alpha characters Continuous Message Indicator shows that the message continues on the next screen

- Press to read the message

Error and Priority Messages

- When an error message is received and read, the incorrect characters blink. Error messages are a result of poor reception from the paging station.

05 07

MESSA EXT

Blinking incorrect characters icon

- When a Priority message is received, your pager will alert you with a unique alert no matter what mode the pager is currently in (eg; sleep, vibrate, private time etc.)

28

29

Info Folder (Information Service)

Your pager can receive information such as world news or financial report

(the extent of the information received depends on your service provider)

When an info message is received, your pager alerts you if you turn on the info alert via info folder function menu

- Press any button to enter the Main Menu Screen from the Standby screen

- Press to enter the Info Folder Screen from the Main Menu screen when the cursor is on the Info Folder icon.

Unread mail, alert active

No mail, alert inactive

Read mail, alert inactive

Unread mail, alert inactive 07 07

Current slot number

Total slots

Read mail, alert active

No mail, alert active

Current cursor position

*Maximum of 5 Info messages from the same source stored in one slot.

*After a slot is full (5 messages) the next incoming info message will

delete the oldest info message.

30

31

Info Folder Function Menu

Press to enter the Info Folder Function Screen from the Info Folder

Screen

05 10

ESCAPE

ESCAPE

ALERT

ON/OFF

DELETE ALL SLOTS

DELETE SLOT

/

- Press to activate the selected function.

A confirmation message "?" comes with "DELETE SLOT" and "DELETE

ALL SLOTS".

- Press again to confirm your settings, or to cancel.

- You can enter Info Message Function menu by pressing when you are reading mail.

The operation is the same as the Info Folder Function menu except there is no "DELETE ALL SLOTS" and there is an additional function of "SAVE

MESSAGE", which allows you to move individual Info messages to the

Saved Folder.

32

33

Saved Folder

You can store up to 20 important Inbox or Info messages in your Saved

Folder. When the Saved Folder is full, "MEMORY FULL" appears if you attempt to store Inbox or Info messages to the Folder.

Current cursor position

03 05

Saved message

MESSAGE TEXT PREVIEW

- Press the Button to enter the Saved Folder screen from the Status screen when the cursor is on the Saved Folder icon.

Saved Folder Function Menu

- Press to enter the Saved Folder Function Screen from the Saved

Folder Screen

05 05

ESCAPE

ESCAPE

DELETE

MESSAGE

DELETE ALL

-You can enter Saved Message Function menu by pressing when you are reading the message. The operation is the same as the Saved Folder

Function menu except that there is no "DELETE ALL".

34

35

The Br802 POCSAG is designed to allow the service provider to customize naming fields for personalization or interface

The following naming components can be changed

Naming components Maximum character limit

Group name 11

Info name 14

Inbox folder name 10

Info folder name 10

Saved Folder name 10

Low Battery Alert

When the battery is low on power, the pager will emit an alert every hour during the day ( 8 am to 8pm )

Out of Range

The

Out of range indicates non reception of signal by the pager.When this happens a

icon appears in the status icon display

Power Up Message

The customised message will show only when this feature is enabled by the service provider during power up or at the stand by screen.

If this feature is not enabled,

ABC Provider

you will only see a blank screen with a row of icons at the top of the standby screen.

36

37

Autobacklight on Upon Reception of Message

This feature alerts user by sight.

Upon reception of message, the pager backlight will automatically be switched on and remains on for the default duration.

Over The Air Programming

(OTA) Over-the-air programming is another service provider function. This allows changing of pager settings without requiring it to be physically connected to a PC.

Maintenance

Care of your pager

To maintain the fine quality of your pager's display screen please do not attempt the following:

1) Subject the pager to extreme temperatures or moisture

2) Immerse the pager in water

3) Use any cleaning solution

Always clean the pager with a non-abrasive cloth

38

DAVISCOMMS (S) PTE LTD

Block 70 Ubi Crescent, #01-07

Ubi TechPark

Singapore 408570

500048R04

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
