User’s Guide

THANK YOU

Congratulations on your choice of the X5 VAC vacuum cleaner. Ergonomically designed, this attractive and highly effective X5 VAC cleaning appliance is the latest in home cleaning technology.

It is compact and always ready in an instant for quick pick-ups in and around the house.

Now you can keep your home spotlessly clean.

The economical X5 VAC cleaning appliance is well accessorized.

Its innovative and effective tools take care of almost every mess on both hard surfaces and carpet.

The X5 VAC cleaning appliance includes an easy-emptying bagless dust cup and washable / reusable filter.

Extension pipes and accessories allow for cleaning high, low and in hard to reach crevices while the liquid lifter is perfect for spot cleaning.

NOTES

Thane Direct and its affiliated companies assume no liability for personal injury or property damage resulting from the misuse of the X5 VAC vacuum cleaner including the failure to comply with the instructions contained in this User’s Guide or provided by the manufacturer or distributor of the treated surface.

IMPORTANT SAFETY INFORMATON

READ ALL INSTRUCTIONS BEFORE USING THIS CLEANING APPLIANCE

G. ADDITIONAL INFORMATION

SPECIFICATIONS

Battery

Charge Time (Approximate)

Use Time

Product Weight (Excluding Accessories)

Input

Lithium-ion

Initially: 7 hours; Re-charging: 7 hours

About 15 minutes

1.15 kg / 2.5 lbs

100 – 240V

BATTERY DISPOSAL

• Battery Pack must be disposed of or recycled in an environmentally friendly manner in accordance with any applicable laws.

• Remove the Battery Pack from the X5 VAC before disposal.

CONTENTS

A. Important Safety Instructions ..................................... 3 - 6

B. Key Features .................................................................. 7 - 8

C. Optional Accessories .................................................... 9

D. How to Use the X5 VAC ............................................... 10 - 18

Instructions for Use ............................................... 10

Charging Battery Pack ...............................................10

Disconnecting & Connecting Battery Pack ........... 11

Using the Standard Accessories ..........................12

Preparing for Use .......................................................13

Using the X5 VAC ......................................................13

Disposing of Dirt and Debris ................................ 15

Emptying the Dust Cup ...........................................15

Cleaning the Filters ....................................................16

Cleaning Accessories .................................................17

Storage ............................................................................17

Maintenance & Care ............................................... 18

E. How to Use Optional Accessories .................................19 - 25

Liquid Lifter ...............................................................19

Instructions for Use .................................................... 19

Using the Liquid Lifter with Suction Tool ............ 20

Using the Liquid Lifter with Window Cleaner ... 21 - 22

Maintenance & Care .................................................. 23

Using the Optional Accessories ............................ 24 - 25

F. Trouble Shooting ..............................................................26 - 28

G. Additional Information ....................................................29

1. Specifications ............................................................29

2. Battery Disposal .......................................................29

29

A. IMPORTANT SAFETY INSTRUCTIONS

When using an electric appliance, basic safety precautions should always be observed.

BEFORE USING THE X5 VAC, PLEASE READ ALL WARNINGS AND USE INSTRUCTIONS CAREFULLY.

!

WARNING

When Using the X5 VAC

• The X5 VAC is a re-chargeable, stick vacuum cleaner designed for indoor household use. Do not use for any purpose than described in this User’s Guide.

• The X5 VAC is to be used by adults and is designed for light, domestic indoor vacuuming and car use. Do not use it when driving

or while the car is in motion.

• Use the X5 VAC only with the attachments supplied.

• Before using the X5 VAC, ensure that it is fully assembled with the dust cup and filters, or Liquid Lifter attachment in place.

• Do not use the X5 VAC if it has been dropped, damaged, left outdoors or dropped in water; have it inspected or

repaired at an Authorized Service Centre.

• Do not use outdoors or on wet surfaces or pick up water or other liquids (unless you are using the Liquid Lifter with the X5 VAC)

• Do not use, store or charge the batteries of the X5 VAC outdoors.

• When using or moving the X5 VAC, hold by the handle. Do not lift by holding onto any of the accessories.

• The X5 VAC creates suction. Do not expose your hair, loose clothing, fingers or body parts to openings or moving parts.

• Do not use the X5 VAC to pick up:

o Hot, burning or smoking objects such as cigarettes, matches or hot ashes

o Hard or sharp objects such as glass, or metal objects, such as pins, nails and paper clips

o Large objects which can block airflow

o Liquids (unless you are using the Liquid Lifter)

o Poisonous, corrosive or toxic materials (such as chlorine bleach, ammonia and drain cleaner)

o Flammable or combustible materials or liquids (lighter fluid, gasoline, etc.) or use in the presence of explosive liquids or vapor

3

F. TROUBLE SHOOTING

Problem

Streaks when drying

Table 3. Trouble Shooting

- WINDOW CLEANER

Possible Cause

• Wiper Blade damaged

28

Solution

• Remove Wiper Blade and reverse.

If both sides of the Wiper Blade are damaged, replace

with a new Wiper Blade (available from the Customer

Service where you purchased your unit from).

To replace or reverse the Wiper Blade, gently pull the

Wiper Blade sideways out of its slot. Reverse the

Wiper Blade (or replace if damaged) before sliding

back into its slot.

F. TROUBLE SHOOTING - LIQUID LIFTER

Problem

No lifting or poor lifting of liquids

Liquid escapes from the

Storage Tank

Possible Cause

• Storage Tank is full

• Storage Tank is full

• Liquid Lifter is being tilted

upside down

• Release Pin is jammed

Solution

• Empty Storage Tank.

• Disconnect Liquid Lifter from Main Body and empty

Storage Tank.

• Disconnect Liquid Lifter from Main Body and empty

Storage Tank. Resume cleaning keeping the Liquid

Lifter in position A or B (see page 19).

• Disconnect Liquid Lifter from Main Body and

thoroughly rinse out entire Liquid Lifter, removing all

dirt and debris that may be stuck inside the unit.

Table 3. Trouble Shooting

27

A. IMPORTANT SAFETY INSTRUCTIONS

(continued)

• Do not obstruct the air flow openings or Air Vents of the X5 VAC or place it on a soft surface, such as a bed or couch, where the

air openings or Air Vents may be blocked.

• Keep air openings free of lint, hair, debris or anything that may obstruct air flow. Do not use the X5 VAC or any of the attachments

with any opening blocked.

• Do not handle the X5 VAC, charger, terminals or battery pack with wet hands.

• Do not place the X5 VAC on or near a hot gas or electric burner.

• Do not use the X5 VAC in an enclosed space filled with vapors given off by, for example, oil-based paint, paint thinner or other

explosive or toxic vapors.

• Use extra caution when vacuuming on stairs.

• Keep working area well lit.

• Vacuum fine dirt such as flour or plaster dust only in very small amounts to avoid clogging the unit.

• Before vacuuming highly polished floors, such as sealed hardwood or linoleum, make sure that the underside of the Vacuum Head

is free from foreign objects that could cause marking.

• Before using the X5 VAC or its accessories on flooring, rugs and carpet, consult the flooring manufacturer’s recommended

instructions.

Inspection and Repairs

• Before use, always check for any damage to the Main Unit, the Accessories and the Battery Charger.

• Do not lubricate any parts, or carry out any maintenance or repair work on the X5 VAC or its accessories other than as shown in

this User’s Guide.

After Use and Storing

• It is recommended to empty the Dust Cup and to clean the Mesh Filter and Fabric Filter after each use.

• Store your X5 VAC and accessories indoors in a dry place and away from children.

• When storing after use, ensure the Battery Charger is disconnected from the Battery Pack and unplug from the electrical outlet.

4

A. IMPORTANT SAFETY INSTRUCTIONS

(continued)

Battery Charger

• The Battery Charger has been designed for a specific voltage. Before charging the Batteries, always check that the voltage of the

electrical outlet corresponds to the voltage on the rating plate of the Charger Unit as follows: Input: 100 – 240V ~ 50/60Hz.

• Use only the Battery Charger supplied for charging batteries.

• Connect the plug on the Charger Unit to a standard, properly grounded electrical outlet.

• Do not modify the plug on the Charger Unit. Do not force the plug into an electrical outlet.

• Do not use an extension cord. Plug the Charger Unit directly into an electrical outlet.

• Always turn the power OFF before connecting the Battery Charger.

• Do not charge the batteries outdoors.

• Do not modify the Battery Charger or replace with any other type of Battery Charger.

• Do not damage the Charger Cord. Never pull or carry the Charger Unit by the cord, use cord as a handle, close door on cord, or

pull cord around sharp edges or corners. Do not run appliance over cord. Keep the cord away from heated surfaces.

• Do not unplug the Charger Unit by pulling the Charger Cord. To unplug the Charger Cord, grasp the Charger Unit and gently pull.

• Regularly check the Charger Cord for any damage. Do not use if damaged. To avoid a hazard, have damaged or worn Charger

Cord replaced by the manufacturer or a qualified repair facility.

• Do not open or probe the Battery Charger.

5

F. TROUBLE SHOOTING - MAIN UNIT

!

WARNING

possible solutions. Failure to do so could result in personal injury. Beware of sharp objects when checking for problems and possible causes.

Problem

Motor does not turn on

Possible Cause

• Battery is flat

Motor turns OFF while in use

• Battery Pack is not fitted

• Power Switch is OFF

• Battery is flat

Solution

• Charge Battery Pack or replace with fully charged

spare Battery Pack(if available).

• Connect battery pack.

• Turn Power Switch ON.

• Charge Battery Pack or replace with fully charged

spare Battery Pack (if available).

Does not pick up dirt

Dirt and debris drops out of

Dust Cup

Table 3. Trouble Shooting

Weak suction force caused by:

• Full Dust Cup

• Clogged Outer Filter

• Clogged Inner Filter

• Flat Battery

• Air Inlet (of the attached accessory)

is clogged or blocked

• Triangular Swivel Vacuum Head is

clogged or blocked

• Flap door is jammed and remains

open

• Flap Door is damaged and does not

seal properly

• Flap section in Flap Door is dislodged

26

• Empty Dust Cup.

• Clean Outer Filter.

• Clean, wash & dry Inner Filter.

• Charge Battery or replace with fully charged spare

Battery (if available).

• Remove accumulated dust & dirt from Air Inlet.

• Disconnect Triangular Swivel Vacuum Head from Dust

Cup Nozzle or Extension Pipe(s), turn over and remove

debris or obstruction.

• Disconnect Dust Cup Nozzle from Dust Cup, remove

Flap Door. Clear any blockage from Flap Door.

• Proceed as above and replace Flap Door.

• Proceed as above and re-fit the Flap section.

E. HOW TO USE OPTIONAL ACCESSORIES

(continued)

Accessory

Super Slim Flexible

Long Nozzle

2-in-1 Bristle Brush

Intended Use

Reaches way under refrigerators, behind radiators and for vacuuming lint out of your dryer and under your washer.

Can be used as a brush with bristles or as a standard suction tool without bristles.

Accessory Bag Store all your X5 VAC accessories.

Instructions for Use

Connect to the Flexible Hose for cleaning hard to reach area.

Connect directly to one of the Extension Pipes. Slide the bristles of the

2-in-1 Brush sideways to attach or detach from the suction head.

Easy to locate needed tool or accessory and reach for it.

Detailing Kit Cleans the tiniest of spaces, such as a computer keyboard or the dashboard in your car.

Insert the Connector directly to the Dust Cup (ensuring a firm, snug fit) and then attach the Adaptor to the Connector. Insert the Clear Hose to the Adaptor with one of the extension tubes and cleaning tools (see 1).

OR

1

Table 2. Use of Optional Accessories

25

A. IMPORTANT SAFETY INSTRUCTIONS

(continued)

Battery Pack

• To charge the Battery Pack, only use the Battery Charger supplied with the X5 VAC.

• Do not press the Battery Release Button during cleaning operation.

• Keep the terminal on the Battery Pack clear of objects. Do not probe or insert any objects other than the Charger Cord into the Charger Port.

• The Battery Pack is a sealed unit - do not attempt to open.

• Do not store the Battery Pack in locations where the temperature may exceed 40°C/104°F. Charge Battery Pack only at ambient

temperatures between 4°C/39.2°F and 40°C/104°F.

• Do not mutilate or incinerate the Battery Pack, or dispose of the Battery Pack in a fire or trash compactor as Battery Pack will

explode at high temperatures!

• Do not allow the Battery Pack to be immersed in water or become wet.

• Do not throw or cause impact.

• Under normal circumstances, the Battery Pack poses no safety concerns. In the unlikely event that liquid leaks from the battery, do

not touch the liquid and observe the following precautions:

o Skin contact – can cause irritation. Wash with soap and water.

o Inhalation – can cause respiratory irritation. Provide fresh air and seek medical advice.

o Eye contact – can cause irritation. Immediately flush eyes thoroughly with water for at least 15 minutes. Seek medical attention.

• Disposal – wear gloves to handle the Battery Pack and dispose of immediately in accordance with local ordinances or regulations.

Safety of Others

• The X5 VAC is not intended for use by children and persons with reduced physical, sensory or mental capabilities, or lack of

experience and knowledge, unless they have been given supervision or instructions concerning the use of the X5 VAC by a person

responsible for their safety.

• Do not allow the X5 VAC to be used as a toy. Close attention is necessary when used by or near children.

SAVE THESE INSTRUCTIONS

6

B. KEY FEATURES

STANDARD ASSEMBLY

Extension Pipe

Extension Pipe

Triangular Swivel

Vacuum Head

7

Main Unit

Filter Plate

Fabric Filter

Mesh Filter

Dust Cup

E. HOW TO USE OPTIONAL ACCESSORIES

(continued)

Accessory

Flexible Hose

Intended Use

Allows for flexibility when cleaning hard to reach areas.

Instructions for Use

Typically, it connects to the Brush Tool or Crevice Tool and is handy for cleaning the interior of cars.

Crevice Tool

Round Brush

Dome Duster

Use in tight and narrow spaces, corners and along edges in areas such as dresser drawers, upholstered furniture, stairs and baseboards.

Use for vacuuming shelves, curtains, lamps and furniture. The head of the brush can be swiveled to obtain the best angle for cleaning.

For general dusting as well as for dusting of delicate and fragile objects.

Can be used when connected to either one or both Extension Pipes,

Flexible Hose or directly to the Dust Cup Nozzle for close-up vacuuming.

Typically, it connects to one or both Extension Pipes, Flexible Hose or directly to the Dust Cup for close-up vacuuming.

Attach the Dome Duster to the Flexible Hose or to an Extension Pipe.

Use the brush to dust the cleaning surface.

3-in-1 Brush

Three interchangeable inserts to be used as follows:

Lint Brush:

Use for picking up fluff or hair on upholstery, carpets or clothing

Floor Brush:

Use on hard surfaces such as wooden floors, tiles or marble to remove dust and dirt

Carpet Brush:

Use on carpets to remove dust and dirt

Select an insert (Lint Brush, Floor Brush or Carpet Brush) for the task at hand and connect the insert to the 3-in-1 Brush. Then, connect the 3-in-1

Brush to the Extension Pipe, the Flexible Hose or to the Dust Cup Nozzle.

Table 2. Use of Optional Accessories

24

E. HOW TO USE OPTIONAL ACCESSORIES

(continued)

MAINTENANCE & CARE

On completion of the cleaning task:

• Slide the Power Switch OFF.

• Remove the Suction Tool or the Window Cleaner from the Liquid Lifter (see 1) to

dispose of dirt and debris.

• Carry the Liquid Lifter to a sink or drain.

• Drain the liquid from the Storage Tank by tilting the Storage Tank downwards (see 2).

• Disconnect the Liquid Lifter from the Main Body by pressing the Release Button (see 3).

• Thoroughly rinse both the Liquid Lifter and Window Cleaner with clean water (see 4).

• If the Flexible Extension Hose was used, rinse with clean water to remove any dirt and

debris that may be lodged in the hose.

• Clean the outer surface of the Liquid Lifter with a soft, damp cloth.

• Store the Liquid Lifter in a protected area, away from children, at room temperature.

• For the Window Cleaner to work effectively, it is important that the Wiper Blade is not

damaged as this will cause streaking.

• When storing the Window Cleaner, ensure it is stored so that it will not cause

deformation or damage to the Wiper Blade.

• Do not unscrew any assembled parts of the Liquid Lifter as this may cause leakage.

!

Always empty, rinse and clean the Storage Tank immediately after each use.

23

3 4

1

2

B. KEY FEATURES

(continued)

MAIN UNIT

Battery Charger

Dust Cup Clip

Dust Cup

Filter Plate

Fabric Filter (not shown)

Mesh Filter

Flap

Nozzle Clip

Nozzle Funnel

Dust Cup Nozzle

Note: Remove foam insert before use

8

Release Button

Power Switch

Handle

Battery Release Button

Charger Port

Charging Light

Support Feet

Support Ridge

Air Vents

Motor Unit (internal)

Dust Cup Hook

C. OPTIONAL ACCESSORIES

1. Flexible Extension Hose

2. Crevice Tool

3. Round Brush

4. Liquid Lifter

5. Suction Tool for Liquid Lifter

6. Window Cleaner for Liquid

Lifter

7. Dome Duster

8. 2-in-1 Bristle Brush

9. 3-in-1 Brush

10. Detailing Kit

11. Super Slim Flexible Long

Nozzle

12. Accessory Bag

2

1

3 4 5 6 7

8

9 10 11

12

Note: Configuration received and availability of accessories may vary by regions. To order accessories, please contact customer service where you purchased your unit from or your local distributor.

9

E. HOW TO USE OPTIONAL ACCESSORIES

(continued)

Using the Window Cleaner on vertical surfaces such as windows or mirrors

• Fill any suitable household container with clean water. Mix a few drops of liquid detergent with

the water.

• Dip a soft cloth or sponge in the water and wash the surface to be cleaned to loosen any dirt.

• Switch the Main Unit ON.

• Place the Wiper Blade horizontally against the window.

• Starting from the top of the window, move the Window Cleaner downwards using smooth, even

strokes, from one side of the window to the other (see 1).

• Each downward stroke should overlap slightly with the previous stroke.

• At the bottom of the window, turn the Window Cleaner so that the Wiper Blade is positioned

vertically. Move horizontally across the bottom of the window to remove any remaining liquid (see 2).

Overlap

Clean from left to right

(or from right to left)

Note: If the Window Cleaner is being used with the Flexible Extension Hose attached, windows can be dried by orientating the Window Cleaner vertically and drying windows starting at the top of the window pane and moving toward the bottom with a side-to-side motion (see 3).

Note: Should the amount of liquid being absorbed approach the MAX fill line as indicated on the Storage Tank, do not turn the Liquid Lifter on its side. First empty the Storage Tank and then proceed with drying of the surface.

22

Clean from left to right

(or from right to left)

Pull horizontally

2

3

1

E. HOW TO USE OPTIONAL ACCESSORIES

(continued)

Using the Liquid Lifter with Window Cleaner

The primary use of the Window Cleaner is for cleaning and drying of non-porous surfaces such as windows and mirrors. In addition, the Window Cleaner can also be used for cleaning and drying of glass tops.

There are 2 alternative ways of connecting the Window Cleaner:

Option 1: Connect the Window Cleaner directly to the Liquid Lifter inlet pipe. Hold the Main Unit in both hands while using it. It is recommended to connect the Window Cleaner this way when cleaning horizontal surfaces such as glass or granite tops.

Note: Ensure that the Window Cleaner is correctly aligned to the Liquid Lifter (see 1).

Option 2: Connect the Flexible Hose to the inlet pipe of the Liquid Lifter and connect the

Window Cleaner to the other end of the Flexible Hose (see 2).

Hold the Window Cleaner with one hand and the handle of the Main Unit with the other hand while using it.

1

2

21

D. HOW TO USE THE X5 VAC

INSTRUCTIONS FOR USE

CHARGING BATTERY PACK

!

WARNING the rating plate of the Battery Charger Unit.

• Your X5 VAC contains 3 Lithium Ion Batteries sealed inside the Battery Pack.

• To charge the Battery Pack, use the Battery Charger supplied. The Battery Pack can be connected

to the Main Unit (see 1). Alternatively, the Battery Pack may be disconnected from the Main Unit and

charged separately (see 2).

Note: If you have obtained a spare Battery Pack, this can be charged separately without being

connected to the Main Unit.

• Before charging the Battery Pack attached to the Main Unit, ensure the Power Switch is OFF.

• Initially, Battery Pack must be charged uninterrupted for 7 hours. When fully charged, the X5 VAC will

operate for up to 15 minutes. Recharging the Battery Pack will take about 7 hours.

• To charge the Battery Pack, connect the Charger Unit to the electrical outlet and plug the Charger

Cord into the Charger Socket located on the Battery Pack.

• The Charging Light on the Battery Pack will turn ON to indicate that the Battery Pack is charging. Once

fully charged, the Charging Light will turn off.

Note: While charging, the Battery Pack and the Charger Unit may become warm to the touch.

This is normal and is no cause for concern.

• Once the Battery Pack is charged, unplug the Charger Unit from both the Charger Port of the X5 VAC

and from the electrical outlet.

Tip: To prolong battery life, completely discharge and recharge the Battery Pack every 1 – 2 months.

!

CAUTION

Do not charge or store the Battery Pack at temperatures below 4º C/39.2°F & above 40º C/ 104°F.

Do not place the Battery Pack in direct sunlight.

1

2

10

D. HOW TO USE THE X5 VAC

(continued)

DISCONNECTING & CONNECTING BATTERY PACK

The Battery Pack connected to the Main Body may need to be removed and replaced with another Battery Pack if obtained

(available from the Customer Service where you purchased your unit from) for the following reasons:

• During use the batteries may become run down. If you would like to continue

cleaning, and have acquired a spare Battery Pack, you can swap Battery Packs .

• After prolonged use the Battery Pack may need replacement.

1 2

Disconnecting the Battery Pack

• With one hand, hold the Handle and press the Battery Release Button (see 1).

• With the other hand, grip the lower (curved part) of the Battery Pack and pull away from the Main Body in a straight line (see 2).

!

WARNING

The Battery Pack is clipped to the Main Unit and some force is required to separate it from the Main Unit.

Connecting the Battery Pack

• With one hand, hold the Handle. With the other hand, align the male

terminal on the Battery Pack with the female terminal on the Main Unit (see 1).

• Push the terminals together in a straight line until the Battery Pack is

positioned flush with the Main Body. Ensure that the Battery Release Button

engages fully with the Battery Pack (see 2).

1

2

11

E. HOW TO USE OPTIONAL ACCESSORIES

(continued)

Using the Liquid Lifter with Suction Tool

• The Liquid Lifter is designed to lift liquids and clean soiled areas from carpets, upholstery and hard surfaces.

!

WARNING

is safe to proceed.

• Hold the Handle and slide the Power Switch ON. Move the Suction Tool over wet spills by pressing it

down onto the cleaning surface and moving it gently back and forth over the area to be cleaned.

Do not shake or use jerky movements.

Continue until no more liquid can be removed (see 1).

• If the wet area is soiled: Apply a cleaning solution to the soiled area and use the brush on the

Suction Tool to gently scrub and loosen the dirt before sucking up the dirt and liquid.

• If there is a dry area that is soiled: Lightly spray or dampen the area with a soft cloth, apply a

cleaning solution to the soiled area, gently scrub the area with the brush to loosen the dirt,

followed by sucking up the dirt and liquid using the Suction Tool.

• When the Storage Tank has reached its maximum capacity (Max Fill Line) (see 2), stop and slide

the Power Switch OFF. Then empty the Storage Tank.

Note: Once the maximum capacity of the Storage Tank is reached, the Release Pin at the top of

the Liquid Lifter will start rising and the suction force will diminish or stop (even though the X5 VAC

Motor is still running). This is a built in safety measure and an indication that the Storage Tank is full

and must be emptied before continued use (see 3).

During the process of sucking up liquids, keep an eye on the level of liquid in the Storage Tank. Once the maximum fill line is reached, stop and empty the Storage Tank.

Tip: By taking immediate action after a spill, permanent staining can be prevented.

Tip: Ensure that the nozzle is angled at about 45 degrees to the cleaning surface to maximize

suction strength.

Table 2. Trouble Shooting: X5 VAC

20

MAX

2

3

1

E. HOW TO USE OPTIONAL ACCESSORIES

LIQUID LIFTER

INSTRUCTIONS FOR USE

• The Liquid Lifter is an attachment that connects to the Main Unit. It can be used with the

Suction Tool to activate and clean soiled areas and to lift wet spills. Alternatively, it can be

used with the Window Cleaner attachment to clean surfaces such as windows, mirrors and

glass tops. Liquids and debris are deposited into the Storage Tank of the Liquid Lifter.

!

WARNING

VAC is disconnected from the Charger before using the Liquid Lifter.

!

WARNING

position A, position B (depending on the cleaning surface). Once liquid has been absorbed into the Storage Tank, do not place the Liquid Lifter upright or tilt it backwards or lay it on its side (as shown as position C, D or E) as liquid may leak from the Storage Tank.

!

WARNING

the Storage Tank, immediately stop, turn OFF the Power Switch and investigate the cause of the problem (see Trouble Shooting).

Preparing for Use

Connect the Liquid Lifter to the Main Body as follows:

• Disconnect the Dust Cup, including the Filter Plate with Mesh and Fabric Filters from the

Main Unit.

• Connect the Liquid Lifter to the Main Body in the same way that the Dust Cup is connected to the Main Unit (see 1).

• Connect the Suction Tool or Window Cleaner to the inlet pipe of the Liquid Lifter (see 1)

IMPORTANT: Ensure the Liquid Lifter is empty before each use.

19

Position A Position C

Position B

Inlet Pipe

Position D

Position E

1

D. HOW TO USE THE X5 VAC

Table 1. Use of Accessories

(continued)

Accessory

Extension Pipe(s)

Triangular Swivel

Vacuum Head

Intended Use

Connect one or both Pipes to access hard to reach, or high areas. Use in conjunction with any of the other cleaning accessories.

Use on carpets, rugs, stairs as well as hard surfaces such as floors.

When cleaning carpets, switch the Floor Blade to the

UP

position.

When cleaning hard surfaces, switch the Floor Blade to the

DOWN

position. Typically, the Triangular

Swivel Vacuum Head is connected to one or both Extension Pipes. It can also be connected directly to the Dust Cup Nozzle for close-up vacuuming.

12

D. HOW TO USE THE X5 VAC

(continued)

PREPARING FOR USE

• Before using the X5 VAC for the first time, ensure the Battery Pack has been

charged for 7 hours without interruption.

• Check that the Mesh and Fabric Filters are fitted into the Dust Cup and that the

Dust Cup is securely clipped onto the Main Unit.

USING THE X5 VAC

• The X5 VAC can be used for vacuuming with or without the use of accessories.

• To facilitate a variety of cleaning jobs, connect one or more of the accessories

illustrated to the Dust Cup Nozzle (located on the Dust Cup):

Extension Pipe(s), Triangular Swivel Vacuum Head, – see Table 2 for more details

on the use of the optional accessories.

• To connect an accessory,

insert one end into the Dust

Cup Nozzle, ensuring a firm,

snug fit (see 1).

1

13

D. HOW TO USE THE X5 VAC

(continued)

MAINTENANCE & CARE

• Depending on the extent of use, the expected use time of the

Fabric Filter is about 3 – 6 months.

Replace the Fabric Filter if it becomes heavily soiled or torn (spare

Fabric Filters are available from the Customer Service where you purchased your unit from).

• Clean the outer surface of the X5 VAC and the

accessories with a soft, damp cloth. Do not use solvents like

thinners, benzene or any spray-type cleaners.

1

• Should the Trap Door become jammed, dislodged or damaged, proceed as follows:

o Unclip the Dust Cup from the Main Unit.

o Hold the Dust Cup with one hand with the Dust Cup Nozzle facing down.

o With the other hand, unscrew the screws below the Nozzle Funnel (see 1).

o Press the button on the Nozzle Clip and pull to disconnect the Dust Cup

Nozzle from the Dust Cup (see 2 - 4).

o Separate the Nozzle Funnel (with Trap Door) from the Dust Cup Nozzle (see 5).

o Inspect the Trap Door. If damaged, repair or replace (see 6).

o After repair or replacement, join the Nozzle Funnel and Flap Door to the Dust

Cup Nozzle (see 4).

o Insert the Dust Cup Nozzle into the

Dust Cup and connect to the Nozzle

Clip (see 7 - 8).

6 7

o Insert the screws below the Nozzle

Funnel and fasten (see 9).

Check that the Dust Cup Nozzle is securely connected to the Dust Cup.

18

8

2

4

9

3

5

D. HOW TO USE THE X5 VAC

(continued)

Re-installing the Mesh and Fabric Filters

• Ensure that both the Mesh Filter and Fabric Filter are completely clean

and dry before re-installing.

• Push the Fabric Filter back onto the Filter Plate (see 1).

• Place the Mesh Filter over the Fabric Filter and connect to the Filter Plate

by twisting the Filter Plate clockwise until it locks (see 2).

• Place the Filter Plate (with Mesh and Fabric Filters connected) into the

Dust Cup (see 3).

• Hook the Dust Cup onto the Dust Cup Hook (see 4).

• Connect the Dust Cup to the Dust Cup Clip (see 5).

Make sure that the Dust Cup is securely connected to the Main Body.

CLEANING ACCESSORIES

• After every use, disconnect the Accessories and inspect for any accumulation dust and dirt. If necessary, clear away any debris.

• Inspect the underside of the Triangular Swivel Vacuum Head, the Wheels and

the Axles for any debris that may be entangled and remove.

STORAGE

• Store the X5 VAC in a dry, cool area, away from children, at room

temperature.

• The X5 VAC can be stored upright or horizontally.

• Place and store the Accessories in the Accessory Bag (optional).

17

1

3

5

2

4

D. HOW TO USE THE X5 VAC

(continued)

• Use or connect the other end as suggested (see Table 1 and 2 in “How to Use Accessories/Optional

Accessories” sections).

• To turn the X5 VAC on, slide the Power Switch ON.

• Hold the Handle and proceed with vacuum cleaning by moving the Dust

Cup Nozzle (or the suction opening of any of the accessories) in close

proximity over the area or object to be vacuumed in an even and slow manner.

• After use, slide the Power Switch OFF.

• In between use, the X5 VAC can be placed upright (see 1) or

horizontally (see 2).

!

CAUTION

Do not press down on the Dust Cup or Dust Cup Nozzle with excessive force when connecting or using any of the accessories. This may cause damage to the Dust Cup.

1

2

14

D. HOW TO USE THE X5 VAC

(continued)

DISPOSING OF DIRT AND DEBRIS

• For best performance and to maintain suction power, it is important to empty

and clean the Dust Cup, Mesh Filter and Fabric Filter after use.

• The Dust Cup is transparent, allowing you to see how much dust and dirt has

accumulated inside the Dust Cup. Once the dust and dirt have reached a level

close to the Mesh Filter, this is an indication to stop and empty the Dust Cup.

!

WARNING

Cup that the Mesh Filter becomes covered or immersed. The Mesh Filter must

at all times be above the accumulated dirt and debris.

Tip: Regular cleaning of the Dust Cup, Mesh and Fabric Filters will ensure

efficient performance and increased lifespan of your X5 VAC.

EMPTYING THE DUST CUP

• Slide the Power Switch OFF.

• Disconnect any accessories from the Dust Cup Nozzle.

• Press the Release Button to disconnect the top of the Dust Cup from the Main

Body (see 1 & 2).

• Unclip the Dust Cup from the Dust Cup Hook (see 3).

• Pull the Filter Plate (with the Mesh and the Fabric Filters) out from the Dust Cup

(see 4 & 5).

• Empty dust and debris from the Dust Cup into a waste container.

Take care when disconnecting the Dust Cup from the Main Body to ensure that the Filter Plate does not fall out.

15

1

3

5

2

4

D. HOW TO USE THE X5 VAC

(continued)

CLEANING THE FILTERS

On a regular basis, clean the Mesh and Fabric Filters to dispose of dust and debris and to maintain the suction power of the X5 VAC.

Cleaning the Mesh Filter

• Disconnect the Mesh Filter from the Filter Plate by twisting the Filter Plate

counter-clockwise while pulling it away from the Mesh Filter (see 1 & 2).

• Shake out and dispose of dust and debris lodged in the Filter.

• To remove stubborn dirt, use a small brush.

• Rinsing the Filter under luke warm water may be necessary.

Cleaning the Fabric Filter

• Grip and gently pull the Fabric Filter out from the Filter Plate (see 3 & 4).

• Shake out and dispose of dust and debris lodged in the Filter.

• Use a small brush to remove dust and debris from the Fabric Filter.

• Should the Fabric Filter become soiled, it can be rinsed or gently hand

washed in luke warm water. Air dry and do not use hot air blowers such as

a hair dryer for drying.

Do not wash the filters in a washing machine.

16

1 2

3 4

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
