USER'S MANUAL
PHC-16
GUIDE TO OPERATIONS
Copyright 1985, KOHJINSHA Corporation. All rights reserved. No
part of this publication may be reproduced or translated into any
language without prior written permission of KOHJINSHA Corporation.
MS is a trademark of Microsoft Corporation.
IBM is a trademark of International Business Machines
Corporation.
1-2-3 is a trademark of Lotus Development Corporation.
WordStar is a registered trademark of Micropro International
Corporation.
"WARNING: THIS EQUIPMENT HAS BEEN CERTIFIED TO COMPLY WITH THE
LIMITS FOR A CLASS B COMPUTING DEVICE. PURSUANT TO SUBPART J OF
PART 15 OF FCC RULES, ONLY PERIPHERALS (COMPUTER INPUT/OUTPUT
DEVICES) CERTIFIED TO COMPLY WITH THE CLASS B LIMITS MAY BE
ATTACHED TO THIS COMPUTER. OPERATION WITH NON CERTIFIED
PERIPHERALS IS LIKELY TO RESULT IN INTERFERENCE TO RADIO AND TV
RECEPTION."
"This equipment generates and uses radio frequency and if not
installed and used properly, that is, in strict accordance with
the manufacturer s instruction, may cause interference to radio
and television reception. It has been tested and found to comply
with the limits for a Class B computing device in accordance with
the specification in Subpart J of Part 15 of FCC Rules, which are
designed to provide reasonable protection against such
interference in a residential installation. However, there is no
guarantee that interference will not occur In a particular
installation. If this equipment does cause interference to
radio and/or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following
measures:
* Reorient the receiving antenna
* Relocate the computer with respect to the receiver
* Move the computer away from the receiver
* Plug the computer into a different outlet so that the
computer and receiver are on different branch circuits.
If necessary the user should consult the dealer or an experienced
radio/television technician for additional suggestions. The user
may find the following booklet prepared by the Federal
Communications Commission helpful:
"How to Identify and Resolve Radio-TV Interference Problems"
Printers should be attached with approved FCC shielded cable to
maintain FCC compliance.
1-2
Welcome to PHC-16, the world's first truly personal computer.
PHC-16 is a full-featured IBM-compatible business computer.
It comes with:
* 256K of memory, expandable to 1280K.
* 5-1/4 inch physical (diskette) drive and 3.5
inch physical (diskette) drive plus a unique
internal electronic RAM drive with up to 360K memory.
* Optional add-on physical (diskette) drive.
* Full 80 column, 25 line LCD screen.
* RS-232 serial and parallel printer connections.
RGB and composite ports for optional monitors.
* Optional built-in modem.
Optional add-on expansion unit.
* Reads from and writes to a 3.5 inch floppy disk.
With all these features, you might expect a desktop full of
equipment. Instead, PHC-16 is as portable as a briefcase. It's
compact design, low weight, (only 12 pounds), and optional
battery pack, make it an ideal companion for the business person
on the go. Use it on a plane, train, boat, taxi, bus, or in your
hotel room. Take it home for the evening, or take it around the
world. It's always ready.
Best of all, PHC-16 is easy to use. It uses Microsoft DOS and
runs most programs written for the IBM PC. Add your favorite
application software, and you re off and running.
This manual, the PHC-16 Guide to Operations, gives you
instructions for setting up and operating your PHC-16. If you
have never operated a computer before, a section for the first
time user introduces you to a few helpful basics.
It is beyond the scope of this manual to tell you everything you
may need to know about computers, MS-DOS, BASIC, and application
programs. Since there are many books available for the IBM PC,
we have tried to give you a quick primer on PC operations while
concentrating only on those items that differ from IBM PC
operations.
This section is only for those who have already opened their
PHC-16, are experienced using IBM PC or compatible computers and
PC or MS-DOS, and hate to read manuals. Follow these few steps
to get off to a fast start:
1. Press the keyboard release latch to detach the keyboard.
2. Install batteries in the keyboard. Press any key and make
sure the light in the upper right corner comes on. The
keyboard is wireless, but needs a clear path between the
keyboard and computer.
3. Insert the AC adapter into the computer. Turn the AC
adapter switch on.
4. Press the screen release latch and adjust the screen angle.
5. Insert the DOS diskette from the DOS manual, or any bootable
diskette, into the PHC-16's physical (diskette) drive.
MAKE SURE THE LABEL ON THE DISKETTE FACES TOWARD THE REAR OF
THE COMPUTER AND THE NOTCH IS UP. Push the diskette into
the slot until 1t clicks. Press in the button labeled
"PUSH" at the top of the drive until it clicks.
6. Turn ON the PHC-16 power switch at the back and lower right of
the computer. Press in the left side of the switch so the
red line on the right side of the switch is showing.
7. Depending on the internal switch settings, the PHC-16
elther:
* Automatically sets up a RAM drive as Drive B, and
installs DOS, or
* Displays a screen that lets you set up a RAM drive.
Follow the instructions on the screen.
You are now up and running!
USING THE RAM DRIVE FOR A TWO DRIVE SYSTEM
The RAM drive enables the PHC-16 to work like a two-drive
system. Since the RAM drive is much faster than the physical
diskette drive, we recommend that you load your application
software program diskette onto the RAM drive and use the physical
drive for your data. Since the default drive is A, you can
toggle the drive designations of A and B between the physical and
RAM drives by pressing the CTRL, Left Shift, and D keys
simultaneously and continue to use A as the default drive. Or,
you can change the default drive to B. Here are some examples:
l. Your word processor programs are on one diskette and your
data is on another. Insert your word processor program
diskette in the physical drive and copy the files to the RAM
drive like this:
COPY *.* B:
Remove the word processor diskette and insert the data
diskette in the physical drive. Swap drive designations by
pressing CTRL, ALT, and D at the same time. The RAM drive
(your word processor) is now A and the physical drive (your
data) is now B. Load your word processor (for Wordstar, for
example, type WS and press ENTER) and operate as you would
on any two-drive system.
2. Your spreadsheet is copy protected and won t copy to the RAM
drive. Instead, copy your data (or only the files you need)
to the RAM drive, and use the spreadsheet program diskette
in the physical drive. REMEMBER TO COPY YOUR DATA BACK TO
YOUR DATA DISKETTE WHEN YOU RE THROUGH, BEFORE TURNING OFF
THE PHC-16!
3. Your filer system is on one diskette and your data 1s on
another. But once the filer programs load, that diskette is
never read. Insert the filer system diskette in the physical
drive and load it as you would normally. Swap drive
designations, remove the program diskette, and insert your
data diskette in the physical drive.
To display the help screen showing switch settings and keyboard
options press the CTRL, Left Shift, and T (for Teach) keys at the
same time.
CAUTION: BE SURE TO ALLOCATE ALL 360K TO THE RAM DRIVE BEFORE
USING THE DISKCOPY COMMAND! Although it appears that DOS has
copied the entire 360K disk, it has not and may result in missing
data or produce unpredictable results!
Fast Start
