WV-ASC970 WV-ASC970

2011/Mar

Panasonic System Networks Co.,Ltd.

What are improved in ASC970 V4?

2

New i-PRO SmartHD camera support

Cameras: WV-SP105/SP102/SC385/SW395/SF346/SF342

HD716/616 integration enhancement

HD716/616 can be registered as i-PRO node so that GXD400/ASM970 can receive video image from HD616/716 through NW I/F on HD716/616

I/O-Ethernet Convertor support as alarm trigger source

ADVANTECH ADAM-6050/6060/6066

What are improved in ASC970 V4?

3

Fixed Camera stream Mode support on GXD400

In the case of that the customer requires precise full frame rate recording at any time, please select this mode to reduce camera’s workload for GXD400.

Specify Stream1 or Stream2 to display on both SXVGA and VGA area on GXD400 regardless of the area size.

*In this mode, the certain stream, VGA or QVGA, can be up-scaling according to area size as below chart.

Down-scaling is not available

SXVGA

Area

VGA Area

Fix Stream1 or Stream2

3M

(JPEG)

1.3M(SXVGA)

(JPEG, H.264)

VGA

(JPEG, H.264, MPEG-4)

QVGA

(JPEG, H.264, MPEG-4)

N/A

Yes

N/A

N/A

Yes

SXVGA SXVGA

VGA

VGA

VGA VGA VGA

VGA VGA VGA

Up-scaling is available

Multicast auto start support

In multicast system, the communicating way between ASM970 and cameras is improved to decrease the processing load on Cameras.

*GXD400 doesn’t support it.

What are improved in ASM970 V3?

16:9 Full HD screen view support

16

Full HD

9

4

Audio Support

-Audio reception (from camera/DVR to PC) is available for the Channel1 of ASM970/GXD400

-Audio transmission (from PC to camera) is up to 5 minutes per transmission

Downloaded File converter “ND Image Converter”

“n3r” file can be converted to “MP4” file by this tool

* This tool works only on the PC installed ASM970

What are improved in ASM970 V3?

5

Download operation improvement

Easy Download from search result

Download

Search Result

Selectable the step of Playback

Selectable x2/x3/x4/x5/x6/x7 fast-forward & Back-forward on the right click menu

What are improved in ASM970 V3?

6

Timeline display improvement

Timeline display is quickly updated correspond to Time&Date selection before the “Go-to-Date” button is clicked

Updated correspond to Time&Date selection

Change the title on the button to picture icon

(For example)

OFF ON

OFF

ON

Set

ON

Wiper

Reset

Brightness

Auto Start

OFF

Defroster

Focus

Key control on Menu

Auto Stop

OFF ON

OFF

ON

OFF

ON

HD716/616 integration enhancement (1/3)

7

Key Point of HD716/616 Integration enhancement

HD716/HD616 is Registered as SX650 node

Analog Cameras IP Cameras

Monitoring Display

･･･

Coax

Coax

Encoder

(GXE500)

･･･

Matrix Switcher

(SX650)

Ethernet

Ethernet

IP Network

HD Decoder

GXD400

Analog DVR (HD716/HD616) can be migrated into IP system with Matrix

Switcher and Encoder.

Coax

Coax

Monitoring PC

ASM970

Ethernet

DVR (HD716/HD616)

It is necessary to convert analog live/playback video to IP signal via encoder (GXE500).

System Controller

CU950

Management System

ASC970

HD716/HD616 is Registered as i-PRO node

i-PRO node

Analog Cameras

IP Cameras

･･･

Available after Ver.4

Monitoring Display

･･･

Coax

HD Decoder

GXD400(*)

IP Network

Ethernet

DVR (HD716/HD616)

Monitoring PC

ASM970

Analog DVR (HD716/HD616) can be migrated into IP system without

Matrix Switcher and Encoder.

(HD716/HD616 will be managed as an i-PRO device.)

*Required GXD400 ver2.20 or later

Management System

ASC970

System Controller

CU950

HD716/616 integration enhancement (2/3)

Difference of the functions

Registered as SX650 node

8

Available after Ver.4

Registered as i-Pro node

Live viewing on GXD400

Playback on GXD400

Live viewing on ASM970

Playback on ASM970

DVR control from CU950

Analog camera control from CU950

DVR control from ASM970

Analog camera control from ASM970

Local Monitor connected to HD716

/616 control from CU950/ASM970

OK (via GXE500)

*Resolution and frame rate depend on the setting of GXE500 (up to VGA/25fps).

*See next page

OK (via GXE500)

*Resolution and frame rate depend on the setting of GXE500 (up to D1/25fps).

*See next page

OK (directly)

*GUI menu control is possible

OK (via SX650)

*GUI menu control is possible

OK (directly)

*GUI menu control is possible

OK (via SX650)

*GUI menu control is possible

N/A

Live

HD716

HD616

Frame rate of HD616/716 on Live

Frame Field up to 12.5fps

up to 6.25fps

up to 12.5fps

up to 6.25fps

OK (directly), Rec resolution only

*Resolution and frame rate are limited and depend on the recording setting of HD716/616.

*See next page

OK (directly),

Rec resolution and QVGA

*Resolution and frame rate are

limited

and depend on the recording setting of HD716/616.

*See next page

OK (directly)

*GUI menu control is impossible

OK (directly)

*GUI menu control is impossible

OK (directly)

*GUI menu control is impossible

OK (directly)

*GUI menu control is impossible

N/A

Frame rate of HD616/716 in Rec resolution

Rec Resolution Frame Field

HD716

HD616 up to 12.5fps

up to 6.25fps

up to 25fps up to 12.5fps

HD716/616 integration enhancement (1/3)

Difference of the Playback

HD716/HD616 is Registered as SX650 node

Analog Cameras

encodes image from DVR as it is

･･･

Coax

Coax

Encoder

(GXE500)

Matrix Switcher

(SX650)

Ethernet

Ethernet

IP Network

9

Monitoring Display

HD Decoder

GXE400

•GXD400 or ASM970 displays DVR playback

the same as DVR analog output.

•Only One fixed pattern Image of a certain

DVR can be displayed at every GXD400 or

ASM970.

Coax

Ex:9-screen playback

Monitoring PC

ASM970

multiple screen with single monitor

DVR

(HD716/HD616)

Ethernet

single-screen/ multiscreen image

HD716/HD616 is Registered as i-PRO node

Available after Ver.4

Analog Cameras

･･･

Coax

IP Network

Ethernet

DVR

(HD716/HD616) single-screen

(multiple channel transmission is possible)

Monitoring Display

ch1 ch2 ch3 ch4 ch5 ch6

HD Decoder

GXE400

Monitoring PC

ASM970

impossible

ch1 ch1 ch3 ch4 ch5 ch6

Single screen with multiple monitors

•Multiple channel can be playback

synchronously or asynchronously on

ASM970, only asynchronously on GXD400.

•Displaying same channel of a DVR is

impossible on different monitors of one

GXD400 or ASM970.

What is WV-ASC970?

Discontinued

MPU955A is discontinued in September,2009.

WV-ASC970 is offered as software that runs by PC.

WV-ASC970 is a system management software which has the function of MPU955A and ASC960 and the control of the i-Pro device.

10

What is ASC970?

11

WV-ASC970 doesn’t touch any video stream. It just controls devices.

Therefore it can control large scale systems and keep high performance operation.

C1

Video Stream

C1 C2

Video Stream

Video S tream

C1

C1

IP Decoder

C2

IP Decoder

Control

Never

Touch

Control

C1

C2

M1

M2

Matrix Switcher

12

What are the benefits of WV-ASC970?

1. Panasonic Total System Quality

WV-ASC970 maximally brings out the picture quality and the functions from Panasonic devices that another partners can’t do.

In addition, as Panasonic devices are designed for high reliability, the server provides a fully controlled stable system.

13

2. Smooth migration from Analog system to IP system without wasting investment in the existing

Analog system

WV-ASC970 can control both Analog devices and IP ones so that we can smoothly migrate current Analog systems to IP systems with adding encoders only.

Encoder

Add

IP System

Analog Devices

No waste

Smooth

Migration

WV-ASC970

What are the benefits of WV-ASC970?

3. Seamless Easy Operation

Customers can seamlessly control IP and Analog devices with same and easy operation through WV-CU950 joystick controllers.

You don’t have to care IP or Analog.

14

WV-ASC970

Same

Operation

Analog Devices IP Devices

4. Reduces Operators’ Workload

WV-ASC970 supports various alarm sources and drives useful alarm actions such as Video

Switching, Preset, Sequence and so on. Also, it provides scheduled actions.

Thus operators can reduce their operation burden with the quite automatic operations.

Send an alarm Switch Video

WV-ASC970

What are the benefits of WV-ASC970?

5. Saves Initial Cost

WV-ASC970 doesn’t need any camera license fee.

Therefore Panasonic solutions with WV-ASC970 saves initial cost against PC-based management server solutions when customers install security systems first.

15

PC based solution

ASC970+ASM970

ASM100

8 16 32 64 96 128 160 192 224 256

Camera

What are the benefits of WV-ASC970?

6. Powerful User Management

WV-ASC970 provides powerful and flexible user management like privilege, priority or monitor/controller permission so that it can support operation for multi-site system or enterprise system.

16

Operator Operator Administrator

Flexible System Design

WV-ASC970 can provide powerful and flexible solutions for customers diverse requirements.

18

HD300A

HD300A

SX650

SX650 Node

Network

(LAN/WAN)

Plasma Display

IP Camera

HDMI

NWDR

i-Pro Node

GXD400

WV-ASC970

Surveillance System Management Server for IP, Analog or Hybrid solution

KEY FEATURES



Built for Large Scale System



e.g. 1535 x 1024 + 64 controllers : Hybrid system (SX650 + IP system)



Flexible System Design:



IP Solution



Analog Solution



Hybrid Solution

WV-ASC970

(Software)



Various Alarm Management(2048 alarm inputs)



Multi-Site System Capability (Up to 64 sites)



Redundant Capability for High Reliability



No Device License Fee

Linux Server for WV-ASC970

19

Supported Devices

20

Analog / IP

Analog

Category

Matrix Switcher

DVR (Digital Video Recorder)

Analog Camera

MPEG2 Encoder

MPEG2 Decoder

Model

SX650, SX850

(Discontinued)

HD300/HD300A series, RT416, HD616/716

Via Matrix Switcher or DVR

GXE900

(NTSC only)

GXD900

(NTSC only)

IP

(GX900 series)

IP

(i-Pro series)

IP Cameras All

i-PRO

cameras

PTZ NS202/202A, NS954, NW964, NS324,

SC385, SW395

Fixed Dome

Fixed Box

NF284, NW484S, NF302, NW502S,

SF33x,

SF346, SF342

NP244, NP1004, NP304, NP472,

NP502, SP30x,

SP105, SP102

ND200 (*2) , ND300/300A (*2) , ND400 (*2) NWDR (Network Disk

Recorder)

Encoder

Decoder

Controller

Video Management Software

(GUI)

NT304, NT314, GXE500

GXD400

CU950

WV-ASM970 (*1)

*1: Search functions are supported with ASM970 only. Setup function is not supported.

Large Scalability

WV-ASC970 has large scalability for enterprise surveillance systems.

Max System Size per ASC970: Input 1535 x Output 1024

(Hybrid system:SX650 + IP system)

21

Camera Monitor DVR/NWDR Controller

1535* 1024* 64*

Alarm

2048

C1

SEQ

C2

128 programs

128 steps/program

User

512

* Specifications for Analog, IP or Hybrid system

→

Refer to next page

64 *

Satellite

64

Large Scalability (NTSC)

22

WV-ASC970’s scalability for IP or Hybrid system are different from Analog.

Max System Size per WV-ASC970 server

System

Node Name SX650

Analog System

SX850

(discontinued)

SX850

(discontinued)

+

SX650

GX

SX650

Hybrid System

+ i-Pro

(discontinued)

+

GX

SX850 i-Pro

IP System i-Pro

Cameras

Monitors

(breakdown)

DVR/NWDR

Controllers

Alarms

Sequences

512

64ch

SX650 : 64

(Full matrix)

32

64

2048

128

*5

1024

256ch

SX850 : 256

(Full matrix)

64

64

2048

128

*5

1536

320ch

(total)

SX850 : 256

SX650 : 64

64

64

2048

128

*5

1536

320ch

(total)

SX650 : 64

GX : 256

*2

64

64

2048

128

1535

1024ch

(total) *1

SX650 : 64 i-Pro : 1024

*3

*1,*6

*5

*1

Steps per Sequence

Users

64

512

64

512

64

512

128

512

Satellites 64 64 64 64

*1: Total # of Cameras/DVR/NWDR/Decoders have to be 1023 or less

*2: e.g. GX(256) : 64 x GX900(4 screen)

*3: e.g. i-Pro(1024) : 32 x GXD400(6 screen) and 52 x ASM970(16 screen)

[note]

*4: It depends on system design. If you want to control more than 512 i-Pro devices from 1 WV-ASC970 server, contact Panasonic sales representatives.

*5: ASC970 can input up to 256 alarms simultaneously. *6: Max 32 for DVR.

*7: If you use encoder, analog camera needs to be counted up to 2048.

2048

512ch

(total)

SX850 : 256

GX : 256

*2

64

*1

64

2048

*5

128

128

512

64

2047

*1

1024ch

(total) *1

SX850 : 256 i-Pro : 1024

*3

Node Name

SX850

SX650

GX i-Pro

1023

*7

1024ch i-Pro : 1024

*3

64

64

2048

*5

128

128

512

64

Total max

1023 i-Pro devices

*4

Product

SX850

SX650

GXE900/GXD900

All i-Pro Cameras

Encoder

Decoder

NT304/314, GXE500

GXD400

NWDR ND200/300/400

Large Scalability (PAL)

23

WV-ASC970’s scalability for IP or Hybrid system are different from Analog.

Max System Size per WV-ASC970 server

System

Node Name SX650

Analog System

SX850

(discontinued)

SX850

(discontinued)

+

SX650

SX650

+

Hybrid System i-Pro

SX850

(discontinued)

+ i-Pro

IP System i-Pro

Cameras

Monitors

(breakdown)

512

64ch

SX650 : 64

(Full matrix)

1024

256ch

SX850 : 256

(Full matrix)

1536

320ch

(total)

SX850 : 256

SX650 : 64

1535

*1

(SX650:512 + i-Pro:1023)

1024ch

(total) *1

SX650 : 64 i-Pro : 1024

*2

2047

*1

(SX850:1024 + i-Pro:1023)

1024ch

(total) *1

SX850 : 256 i-Pro : 1024

*2

DVR/NWDR

Controllers

Alarms

Sequences

Steps per Sequence

32

64

2048

*4

128

64

64

64

2048

*4

128

64

64

64

2048

*4

128

64

64

*1,*5

64

128

128

2048

*4

64

64

*1

128

128

Users 512 512 512 512 512

Satellites 64 64 64 64 64

*1: Total # of Cameras/DVR/NWDR/Decoders have to be 1023 or less

*2: e.g. i-Pro(1024) : 32 x GXD400(6 screen) and 52 x ASM970(16 screen)

[note]

*3: It depends on system design. If you want to control more than 1023 i-Pro devices from 1 WV-ASC970 server, contact Panasonic sales representatives.

Node Name

SX850

SX650 i-Pro

*4: ASC970 can input up to 256 alarms simultaneously.

*5: Max 32 for DVR.

*6: If you use encoder, analog camera needs to be counted up to 2048.

1023

*6

1024ch i-Pro : 1024

*2

64

64

2048

*4

128

128

512

64

Total max

1023 i-Pro device s

*3

Product

SX850

SX650

All i-Pro Cameras

Encoder

Decoder

NT304/314, GXE500

GXD400

NWDR ND200/300/400

Counting i-Pro devices

Note that the number of I-Pro devices includes IP camera, NWDR, Encoder, and

Decoder.

24

In the example below, the number of “ i-Pro devices ” is “ 6 ”.

ASC970

1

1

2

2

4

Decoder (GXD400)

5

3

4

Encoder

(GXE500)

3

Analog Camera

Analog camera doesn’t need to be counted as i-Pro devices, but needs to be counted as the number of camera, can be counted up to 2048.

In the example, the number of “ Camera ” is “ 4 ”.

6

NWDR

ASM970

Counting i-Pro Monitors

Note that the number of I-Pro monitors includes each screen of GXD400.

In the example below, the number of “ i-Pro monitors ” is “ 10 ”.

25

ASC970

1

2

3

4

5

6

Decoder (GXD400)

Encoder

Analog Camera

(GXE500)

NWDR

7 8

ASM970

9

10

(Up to 16 monitors)

Monitors Selection

Note that it needs to set monitor number up to 6 each GXD400 in Admin Console, and select monitor number by CU950.

26

‘Admin Console’ Operation

1. Register GXD400 as the IPRO device

2. Set monitor number each GXD400

In case of GXD400, it is possible to set monitor number from 1 to 6 for multi-screen.

IPRO Device Registration Monitor Number Setting

Link monitor number to monitoring display

IP Camera

Transfer setting data

Management System

(ASC970)

Monitoring Display.1

Monitoring Display.2

MON1 MON2 MON3

MON4 MON5 MON6

MON7 MON8 MON9

MON10 MON11 MON12

Control Signal

Video Stream

System Controller

(CU950)

HD Decoder

(GXD400)

HD Decoder

(GXD400)

CU950 Operation

1. Select monitor number

2. Press MON (ESC) button

Even If you operate to change 6 sprit screen to 3 sprit screen in display 1, monitor number of display2 is not changed . (start from MON7)

High Reliability

Redundant function

We suggest WV-ASC970 redundant system which can consist of 2 servers.

It can switch over the operation to the standby one when any serious problem happens in the active one. (Automatic switching over)

27

Operation Operation

Switch Over

WV-ASC970 #1

RS232C cable & Ethernet

(Health Check)

WV-ASC970 #2

Linux base OS – Small Risk of virus attack

Various Alarm Management

WV-ASC970 supports various alarm sources and can implement up to 10 programmed actions according to the alarms.

28

ALARM

(Local/Global)

ALARM Action

(Local

/Global

)

Supported Alarm Sources

WV-ASC970

Up to 10 actions

Alarm Actions

Support “Global alarm”

Alarm in one domain can be

noticed

as alarm in another domain.

Satellite System Capability

WV-ASC970 is capable of up to 64 satellites system.

29

ASC970

#2

ASC970

#1

・

・

・

・

ASC970

#5

ASC970

#3

Network

(LAN/WAN)

ASC970

#4

Up to 64 satellites

ASC970

#64

Global Functions (Camera ID)

Consecutive camera ID can be used on Satellite System.

Either global ID or local ID is used with setting on ASC970 Admin.

Example of

global camera ID selection

(In the case of operator in Domain2 selecting cameras)

30

Camera selection with local camera ID

Camera selection with

global

camera ID

Domain Unit ID (1or2-digit) + Local Camera ID (5-digit) Global Camera ID (1to7-digit)

ASC970

SX650 Node

ASC970

Local

Global

Cam

1

Cam

2

Cam

100

Cam

1

Cam

2

Cam

1

Cam

2

Cam

100

Cam

101

Cam

102 i-Pro Node

Cam

100

Cam

200

･･･

ASC970

Cam

1

Cam

2

Cam

901

Cam

902 i-Pro Node

Cam

100

Cam

1000

Global Functions (Alarm Action)

31

When alarm is triggered, Alarm action is conducted beyond the domain

Alarm!

Only notification is possible

ASC970

Alarm

Action!

Alarm!

ASC970

Alarm!

ASC970

Alarm

Action!

Alarm action beyond domain becomes to be possible!

Alarm!

ASC970

Alarm

Action!

•Camera Preset Call

•Tour Sequence

•Group Sequence

•Group Display

•Video Switching

WV-ASC970 PC requirements

RedHat Enterprise Linux 5

Red Hat Enterprise Linux ES Ver.3 Update9

RedHat Enterprise Linux 5.3 server(x86) or later

* Current version is 5.5.

32

OS Installation - Service

It is necessary to install the following services in OS (RHEL5.5).

 Desktop Environments > GNOME Desktop Environment

* It is automatically installed, when [Customize now] is selected.

 Servers > FTP Server

* It is necessary to check xferstats in [Optional packages].

 Servers > Legacy Network Server --- telnet-server and tftp-server only

* It is necessary to check it in [Optional packages].

 Servers > PostgreSQL Database

 Servers > Server Configuration Tools

* It is automatically installed, when [Customize now] is selected.

 Servers > Web Server

 Base System > Administration Tools

* It is automatically installed, when [Customize now] is selected.

 Base System > Base

* It is automatically installed, when [Customize now] is selected.

33

 Base System > System Tools --- Wireshark and net-snmp-utils only

* It is necessary to check in [Optional packages].

 Base System > X Window System

* It is automatically installed, when [Customize now] is selected.

It is necessary to disable the following services in OS (RHEL5.5).

 Firewall

 SELinux (Kernel Access Control)

Functions / Specifications

Large Scalability

Analog Camera Operation

* Via DVR or MX-SW or GX i-Pro Camera Operation

Functions List

Cameras

Monitors

Controllers

DVR/NWDR

Alarms

Detail Information

1535

(*Hybrid system:SX650 + IP system)

1024

64

64

(*Max 32 for DVR )

2048

Sequences

Steps per Seq

Users

128

128

512

Domains 64

PTZ

Focus Adjustment

Iris Adjustment

Preset Program

Preset Call

Camera Menu (except DVR)

PTZ

Focus Adjustment

Iris Adjustment

Preset Program

Preset Call

34

Functions / Specifications

Recorder Operation

(NWDR)

Recorder Operation

(HD300/300A, RT416)

Monitor Operation

(DVR, MX-SW, GX)

Monitor Operation (GXD400)

Group Operation

Functions List

Detail Information

Playback control (Playback, R-Playback, T&D Playback, FF, REW,

Pause, Stop)

Search on WV-ASM970

Playback control (Playback, R-Playback, T&D Playback, FF, REW,

Pause, Stop)

REC control (REC start, REC stop)

Search on Monitor

Configuration on Monitor

OSD (except DVR)

Video Switching

Multi-screen (DVR only)

Tour Sequence

OSD

Video Switching

Multi-screen

Tour Sequence

Group Display

Group Preset

Group Sequence

35

Functions / Specifications

Alarm Operation

Alarm Action

Alarm Trigger source

Event Schedule

* Local only

Alarm Output of SX650/SX850

Functions List

Detail Information

Alarm Knowledge, Alarm Reset, Alarm Arm/Disarm

Alarm Output Control

Up to 10 programmable Alarm Actions per alarm

Camera Preset Call

Tour Sequence

Group Sequence

Group Display

Video Switching

Global alarm action

Motion Detect(Analog, i-Pro cameras)

Video Loss (except DVR)

RS-232C (Panasonic proprietary)

Panasonic Alarm Protocol

Global Alarm

Tour Sequence

Group Sequence

Group Preset

Video Switching

Alarm, Mode

Control Alarm Output On/Off by CU950

(SX850: Normally Open or Normally Closed selectable)

(SX650: Open collector output)

36

Functions / Specifications

User management

* Local User

Priority management

Functions List

Detail Information

Multiple Operator Levels

Device to Resource Privilege

Operator to Device Privilege

Operator to System Function Privilege

Multiple Device Priority Levels (65000)

Multiple Operator Priority Levels (65000)

Multiple Alarm Priority Levels (65000)

Multiple Event Priority Levels (65000)

2 WV-ASC970 servers redundant system Redundant

37

Approx.

2,000mm

Rack Configuration Example

38

The depth of rack mount server PC is longer than AV device.

So please note the depth of rack.

Encoder (GXE500)

Network Switch

WV-ASC970

Main & Backup Unit

(Redundant)

Approx.

1,700mm

Monitor w/ Keyboard for Rack Mount Type

Network Disk Recorder

UPS

The size of UPS depends on power consumption,

& it’d better install heavy items from bottom of rack.

39

Domain Concept

1 WV-ASC970 unit = 1 Domain unit

HD300A

HD300A

SX850

SX850 Node

GXE900 GXD900

GX Node

40

Domain unit 2

WV-ASC970 #2

HD300A

HD300A

SX650

SX650 Node

NW Switch

Network

(LAN/WAN)

WV-ASC970 #1

Domain unit 1

Domain unit 3

IP Camera

Plasma

HDMI

NWDR

i-Pro Node

GXD400

WV-ASC970 #3

Node Concept

WV-ASC970 categorize products as follows

Node Name Product

SX850

SX650

GX i-Pro

SX850

SX650

GXE900/GXD900

(NTSC only)

All i-Pro Cameras

Encoder NT304/314, GXE500

Decoder GXD400

NWDR ND200/ND300A/ND400

<Notes>

• The same type of node can not exist together in the same domain.

• Up to 2 different types of nodes can exist in one domain.

OK

2 types of nodes in one domain

PDP

IP Camera

<PAL case>

Acceptable configuration in a domain (6 types)

1. SX650 + SX850

2. SX650 + i-Pro

3. SX850 + i-Pro

4. Analogue Only : SX650

5. Analogue Only : SX850

6. i-Pro only

SX650

HD300A

ASC970

SX650 Node

HDMI

GXD400

NWDR

i-Pro Node

HD300A

HD300A

SX850

SX850 Node

HD300A

HD300A

SX650

SX650 Node

41

GXE900 GXD900

GX Node

PDP

IP Camera

HDMI

GXD400

NWDR

i-Pro Node

Node Concept

Case 1

NG

Same nodes in one domain

OK

Separate with two domain

42

ASC970

SX650

HD300A

SX650 Node

SX650

HD300A

SX650 Node

Case 2

NG

3 types of nodes in one domain

SX650

HD300A

ASC970

SX650 Node

ASC970

SX650

HD300A

SX650 Node

SX650

ASC970

Connect with network

HD300A

SX650 Node

PDP

IP Camera

SX850

HD300A

SX850 Node

OK

Up to 2 types of nodes in each domain

SX650

HD300A

ASC970

SX650 Node

SX850

HD300A

SX850 Node

Connect with network

HDMI

GXD400

NWDR

i-Pro Node

ASC970

IP Camera

PDP

HDMI

GXD400

NWDR

i-Pro Node

Local / Global Concept

WV-ASC970 regards its domain unit as Local and regards domains of another WV-ASC970s as Global.

43

HD300A

HD300A

SX850

SX850 Node

GXE900 GXD900

GX Node

NW Switch

Network

(LAN/WAN)

HD300A

HD300A

SX650

SX650 Node

GXE900 GXD900

GX Node

NW Switch

WV-ASC970 #1

Domain unit 1

LOCAL

WV-ASC970 #2

Domain unit 2

GLOBAL

Area Concept

“Controller”, “Monitor”, “Tour/Group SEQ” and “Group Preset” are belong to any area in a single domain.

Local Operator can control the devices only in the same area where he/she logins.

Local Super User can control the devices in the same area and in the different areas.

44

Camera (Analog/IP) Matrix-SW (SX650/850) DVR NWDR

Mon 1

(Area 1)

Operations

Mon 2

(Area 1)

Controller (Area 1)

Mon 3

(Area 1)

Login

T-SEQ

G-SEQ

G-PSET

Operations

(Area 1)

Mon 1

(Area 2)

Operations

Mon 2

(Area 2)

Mon 3

(Area 2)

Control

Can not control d ifferent a reas

Login

Local Operator

Area Change

(on the Controller)

Controller (Area 2)

T-SEQ

G-SEQ

G-PSET

Operations

(Area 2)

Local Super User

User Class Concept

Local User / Global User

Domain Unit

Domain Unit

Local Operator Local Super User

Super User

Permission

Global Super User

Domain Unit

Local Operator Local Super User Local Operator Local Super User

1

2

3

User Class

Local operator

Local super user

Global super user

Description

Local operator can operate its own domain unit

Local super user can operate & override its own domain unit

Global super user can operate & override all the domain units

45

User Class Concept

Local Operator / Local Super User

The difference between Operator and Super User is the granted privileges.

“Permission Override” and “Area Change” are for Super User only.

46

Local Super User

Super user should have all privileges.

Local Operator

Operator can be granted any privileges except for

“Permission Override” and

“Area Change” when operator is created.

Admin Console (Configuration Tool)

OSD Concept

Item

OSD information

Various information are displayed on screen display (OSD).

Operator understand operation status easily.

you can set display On/Off each line.

Alarm ID

Action ID

Alarm Message

Monitor ID

Area No.

Controller ID

Sequence info

Camera ID

Camera title

Clock

Play icon

Red frame

47

Format

Annnn

-n (n=0~9)

Max 6 character

MnnnnL (nnnn=0001~9999)

“L“ is Monitor Lock annn (nnn=1~999)

Knnn (nnn=1~999)

Tour Sequence: TnnnR

Group Sequence: GnnnR

R: Running, P: Pause

(nnn=1~999)

Cnnnnnn

(nnnnnn=100001~999999)

Max 11 character

Time & Date

Live: Time of camera

Playback: Playback time

Playback status

Play, Pause,Fast Play (x2~x7)

Rewind (x2~x7)

Alarm

48

1. Launch

2. Server

3. Device

4. Monitor

5. Operator

6. Sequence

7. Schedule

8. Alarm

9. Upload

10. Migration

11. Log

Set up Flow Chart

As well as admin console of MPU955A

49

Cooperation with i-PRO Config. Tool

Setup data downloaded from i-PRO Configuration Tool (V3.2 or later) can be used for setup of ASC970 system.

50

All devices and all items have to be registered manually.

The bigger system becomes, the harder work for registration becomes.

ASC970 i-Pro Node

Following items are registered automatically

•All i-PRO devices

•Camera model and IP address

•Encoder model and IP address

•Decoder model and IP address

•Monitor with decoder

•NVR model, IP address and camera relations

4.Setup remaining items

1.Configure the system with i-PRO configuration tool

i-PRO config. tool

2.Download the setup file to PC

3.Import i-PRO configuration to ASC970 Admin

ASC970 Admin

ASC970 Admin Console PC requirements

51

52

Management Software Comparison

WV-ASC970 Ver4

+ WV-ASM970 Ver3

WV-ASM100 Ver8

Functions/

Features

WV-ASM100L Ver8

53

User Priority Management

Monitor Wall

(GXD400 / ASM970)

Alarm Action Programming

Supported

Devices

Matrix Switcher

DVR

NW Cam/ Enc

NWDR

Internetmode (over HTTP) view

License for Client PC

Map Function

Controller (CU950) Connection

16:9 screen view

Multiscreen

Multiscreen pattern

Timeline Search

Number or windows

Audio

Snapshot

YES

YES

10 actions per one alarm

YES (*1)

HD316/316A

(*1)

, RT416

(*1)

,

HD616/716

All i-PRO cameras / encoders

ND200/ND300A/ND400

N/A

1x ASM970 supports

32x PC

YES

YES

YES

Total 16

1/4/

7

/9/

10/13

/16

YES

Up to 2 windows

(Operation&Map / Monitoring)

YES

N/A

N/A

N/A fixed action

N/A

HD316A, RT416, HD616/716

*HD316(nonA) is not supported.

All i-PRO cameras /encoders

NV200 /ND200/ND300A/ND400

YES

(i-PRO cam/HD716/616/NV200)

1x ASM100 supports 1x PC

YES

YES

N/A

Total 20 (16+4)

1/4/9/16

N/A

Up to 3 windows

(Operation / Map / Monitoring)

YES

YES

N/A

N/A fixed action

N/A

HD316A, RT416, HD616/716

*HD316(nonA) is not supported.

All i-PRO cameras /encoders

NV200 /ND200/ND300A/ND400

YES

(i-PRO cam/HD716/616/NV200)

1x ASM100L supports 1x PC

N/A

N/A

N/A

Total 16

1/4/9/16

N/A

1 monitor

(Operation)

YES

YES

(*1) To see images on ASM970 (not on the monitor connected to DVR or Matrix Switcher directly), encoder is required.

Combination of ASC970/ASM970

Software versions of ASC970 and ASM970 need to be combined as follows.

(If wrong combination, they would not work correctly.)

54

ASC970 (Server software)

ASM970 (Client software)

Version 1.0

Apr./2010-

Version 2.0

Version 1.0

Sep./2010-

Version 3.0

Version 2.0

Feb./2011-

Version 4.0

Version 3.0

GUI Sample

55

ASM970 PC Requirements

It is recommended to install this software on a PC that meets the following system requirements.

Items

OS

OS language

Computer

CPU

Memory

Requirements

Microsoft® Windows® XP Professional SP3 (32-bit)

Microsoft® Windows Vista® Business SP2 (32-bit)

Microsoft® Windows Vista® Business SP2 (64-bit)

Microsoft® Windows® 7 Professional (32-bit)

Microsoft® Windows® 7 Professional (64-bit)

English, Chinese (Simplified Chinese)

IBM PC/AT Compatible

Intel® Core 2 Duo 2.66 GHz or faster

Intel ® CoreTM 2 Quad Q9650 or faster (When operating H.264 images)

Intel ® CoreTM i7 -

920 or faster (When operating H.264 images)

1 GB or more

Video memory

CD-ROM drive

Monitor

Network Interface

Web browser

VRAM 128 MB or more (64 MB minimum), compatible with DirectX®9.0c

Necessary to install this software

1280 x 1024 pixels or higher

24-bit True color or better (Full color recommended)

100BASE-TX/1000BASE-T

Microsoft® Internet Explorer® 6.0 SP3

Microsoft® Internet Explorer® 7.0 SP1

Microsoft® Internet Explorer® 8.0

56

What are the benefits of WV-ASM970?

1. No License Fee (Dongle is unnecessary)

*Need to purchase one WJ-ASM970 per one WJ-ASC970

2. Easy management for device information

(Version number etc)

3. No need for Each PC’s configuration

4. Total system operation by software

57

58

Analog System (Single domain)

SX650/SX850 in Single domain

Max Node Capacity: 512 x 64 (SX650), 1024 x 256 (SX850)

59

Analog System (Multi domain)

SX650/SX850 in Multi domains

Max Node Capacity: 512 x 64 (SX650), 1024 x 256 (SX850)

60

HD300A

HD300A

SX850

BX850

HD300A

HD300A

RT416

SX650

SX650U

Video Link

HD300A

HD300A

RT416

SX650

SX650U

Video Link

WV-ASC970 #1

Domain A

WV-ASC970 #2

Domain B

WV-ASC970 #3

Domain C

Hybrid System (Single domain)

Hybrid with GXE500 in Single domain

Max System Capacity per Domain: 1535 x

1024

including 1023

i-PRO

devices

GXE500 GXE500

61

GXE500

Hybrid System (Multi domain)

Hybrid with GXE500 in Multi domains

Max System Capacity per ASC970: 1535 x 512 including 1023

i-PRO

devices

62

GXE500

GXE500

Hybrid System (Multi domain)

Hybrid with Analog DVR & GXE500 in Multi domains

Max System Capacity per ASC970: 1535 x 1024 including 1023 i-PRO devices

IP Camera

---

Matrix

Switch

Analogue Camera

---

Coaxial

It is necessary to convert analog playback video to IP signal via encoder (GXE500).

Ethernet

Monitoring Display

Coaxial

---

HD Decoder

(GXD400)

:

:

Encoder

(GXE500)

Ethernet

Core IP Network

Coaxial

Digital Disk

Recorder

---

Management System

ASC970

Ethernet

IP Network

---

System Controller

CU950

Ethernet

63

---

Monitoring PC

ASM970

It is possible to display analog playback video on decoder monitor (GXD400) and PC monitor (ASM970).

Hybrid System (Multi domain)

Complete Hybrid System

(with i-PRO Decoder)

64

GXE500

It is possible to display IP video and Analog video on Analog monitor as well as IP/PC one.

Full IP System (Single domain)

Full IP system with

i-PRO

products

65

66

Analog System

67

IP System

68

Hybrid System

GXE500

69

Satellite System

WJ-GXE500 WJ-GXE500

WJ-GXE500 WJ-GXE500

70
