Operating Instructions
7
8
1
2
9
3
10
11
12
4
5
6
SQ/SCAN
D·M
CLOCK
DO
N
MUTE
REP
RA
SRC
CQ-C1121W
PUSH SEL
APM
PWR
VO
L
TUNE/TRACK
BAND
M
DISP
(CQ-C1121W)
Specifications
Panasonic welcomes you to our constantly growing family of electronic products owners.
We endeavor to give you the advantages of precise electronic and mechanical engineering, manufactured with carefully selected components, and
assembled by people who are proud of the reputation their work has built for our company. We know this product will bring you many hours of
enjoyment, and after you discover the quality, value and reliability we have built into it, you too will be proud to be a member of our family.
General
Power supply
Current consumption
This operating instruction manual is for 3 models CQ-C1121W, CQ-C1101W and CQ-C1001W. All illustrations throughout this
manual represent model CQ-C1121W unless otherwise specified. The following table describes the differences among 3 models.
Differences between 3 models
CQ-C1121W/C1101W/C1001W
English
CD Player/Receiver
Before Reading These Instructions
Features
Volume control
Models
CQ-C1121W
CQ-C1101W
Tone adjustment range
CQ-C1001W
Rotary knob
Rotary knob
Button
Remote control function
Yes (Included)
No
No
Pre-amp. output connector
Rear/Front
Rear
Rear
Maximum power output
Speaker impedance
Pre-amp output voltage
Pre-amp output impedance
Dimensions (W x H x D)
Weight
FM Stereo Radio
: 12 V DC (11 – 16 V DC), negative
ground
: Less than 2.2 A (CD mode; 0.5 W 4
channels)
: 50 W x 4 (at 1 kHz), volume control
maximum (for CQ-C1121/C1101W)
: 45 W x 4 (at 1 kHz), volume control
maximum (for CQ-C1001W)
: Bass: ±12 dB at 100 Hz, Treble: ±12
dB at 10 kHz
:4 – 8 Ω
: 2.5 V (CD mode, 1 kHz, 0 dB)
: 200 Ω
: 178 x 50 x 160 mm
: 1.3 kg
Frequency range
Usable sensitivity
Frequency response
Alternate channel selectivity
Stereo separation
Image rejection ratio
IF rejection ratio
Signal to noise ratio
: 87.5 MHz – 108 MHz
: 6 dB/µV (75 Ω)
: 30 Hz – 15 kHz (±3 dB)
: 75 dB
: 35 dB (1 kHz)
: 75 dB
: 100 dB
: 62 dB
AM Radio
Frequency range
:531 kHz – 1 602 kHz
Usable sensitivity
: 28 dB/µV (S/N 20 dB)
CD Player
Sampling frequency
DA converter
Pick-up type
Light source
Wave length
Frequency response
Signal to noise ratio
Total harmonic distortion
Wow and flutter
Channel separation
: 8 times oversampling
: 1 bit DAC System
: Astigma 3–beam
: Semiconductor laser
: 790 nm
: 20 Hz – 20 kHz (±1 dB)
: 96 dB
: 0.01 % (1 kHz)
: Below measurable limits
: 75 dB
Note:
¡ Specifications and design are subject to modification without
notice due to improvements.
¡ Some figures and illustrations in this manual may be different
from your product.
Accessories
Operating Instructions
(English: YFM284C450ZA)
(êÛÒÒÍËÈ: YFM284C451ZA)
(
: YFM284C452ZA)
(YFM284C453ZA :
)
POWER
MUTE
PWR
VOL
MODE
TUNE
TRACK
BAND
CAR AUDIO
Q'ty: 1 set
Installation Instructions
(YFM284C449ZA)
Q'ty: 1
Mounting Collar *
Remote Control Unit
(include a battery, only
for CQ-C1121W)
(FX0214C384ZA)
(EUR7641020)
Trim Plate *
Q'ty: 1
Lock Cancel Plate
(FX0214C385ZA)
Q'ty: 2
Mounting Bolt
(YEJV014C002N)
Q'ty: 1
(YFC054C081ZA:
CQ-C1121/1101W)
(YFC054C079ZA: CQ-C1001W)
Q'ty: 1
Power Connector
(YEAJ02877)
Q'ty: 1
Rubber Bushing
Matsushita Electric Industrial Co., Ltd.
(YFS014C095ZA)
Q'ty: 1
Notes:
¡ The number in parentheses underneath each accessory part name is the part number for maintenance and service.
¡ Accessories and their part numbers are subject to modification without prior notice due to improvements.
¡ Mounting Collar and Trim Plate are mounted on the main unit at shipment. *
Web Site: http://www.panasonic.co.jp/global/
¡Please read these instructions carefully before using this product and keep this manual for future reference.
YFM284C450ZB TAMACO1104-1124
Printed in China
Note: Battery Information:
Battery Type: Panasonic lithium battery (CR2025) (Included
in the remote control)
Battery Life: Approximately 6 months under normal use (at
room temperature)
The 24-hour system is used for the clock.
1 Turn the ignition switch
2
until the accessory indicator lights.
Press [SRC] (PWR:
Power).
ACC
ON
3 Press [DISP] (CLOCK).
4
Hold down [DISP] (CLOCK) for more than
2 seconds.
Cleaning the
Unit
Maintenance
Safety Information
Your product is designed and manufactured to ensure the minimum of maintenance. Use a soft cloth for routine
exterior cleaning. Never use benzine, thinner, or other solvents.
■ Read the operating instructions for the unit and all other components of your car audio system carefully before using the system.
They contain instructions about how to use the system in a safe and
effective manner. Panasonic assumes no responsibility for any problems resulting from failure to observe the instructions given in this
manual.
If the replaced fuse fails, contact your nearest authorized Panasonic Service center.
Clock Display at Power Off
Warning
Fuse
Battery
Installation
Preparation
Pull the insulation film out from
the backside of the remote control gently.nly
Press [DISP] (Display) to change the display.
This pictograph intends to alert you to the presence of
important operating instructions and installation instructions. Failure to heed the instructions may result in
severe injury or death.
¡ Use fuses of the same specified rating (15 A). Using substitutes or fuses with higher ratings, or connecting the unit directly without a fuse could cause fire or damage to the unit. If the replaced fuse fails, contact your nearest authorized
Panasonic Service Center.
Display off
Clock display
Warning
❑ The driver should neither watch the display nor operate
the system while driving.
Anti-Theft System
Watching the display or operating the system will distract the driver from looking ahead of the vehicle and can cause accidents.
Always stop the vehicle in a safe location and use the parking
brake before watching the display or operating the system.
This unit is equipped with a removable face plate. Removing this face plate makes the unit totally inoperable.
¡ This face plate is not waterproof. Do not expose it to
water or excessive moisture.
¡ Do not remove the face plate while driving your car.
¡ Do not place the face plate on the dashboard or nearby
areas where the temperature rises high.
Notes:
¡ “AdJ” is displayed before adjusting the clock.
¡ Hold down []] or [[] to change numbers rapidly.
¡ Do not touch the contacts on the face plate and the main
unit, since this may result in poor electrical contact.
¡ If dirt or other foreign substances get on the contacts,
wipe them off with a clean and dry cloth.
This product is designed for operation with a negative grounded
12 V DC battery system. Never operate this product with other battery systems, especially a 24 V DC battery system.
❑ Keep batteries and insulation film out of reach of infants.
Batteries and insulation film can be ingested, so keep them out of
the reach of infants. If an infant ingests a battery or insulation film,
please seek immediate medical attention.
❑ Protect the Deck Mechanism.
Do not insert any foreign objects into the slot of this unit.
(Anti-Theft System)
8
Press [DISP] (CLOCK).
Face Plate Removing/Mounting
Clock Setting
Caution
[[]: sets the hour ahead.
[]]: sets the hour back.
[[]: sets the minute ahead.
[]]: sets the minute back.
safely and to alert you to potential dangers resulting from improper
connections and operations. The meanings of the pictographs are
explained below. It is important that you fully understand the meanings of the pictographs in order to use this manual and the system
properly.
Caution
This pictograph intends to alert you to the presence of
important operating instructions and installation instructions. Failure to heed the instructions may result in
injury or material damage.
❑ Do not disassemble or modify the unit.
Removing
Mounting
1 Turn off the power.
2 Press [ ]. The removable face plate will
1 Slide the left side of the removable face
open.
3 Pull it out toward you.
plate in place.
2 Press the right end of removable face plate
until a “click” is heard.
2
1
1
2
Caution
Observe the following cautions when using this
unit.
❑ Keep the sound volume at an appropriate level.
Keep the volume level low enough to be aware of road and traffic
conditions while driving.
❑ This unit is designed for use exclusively in automobiles.
❑ Do not operate the unit for a prolonged period with the
engine turned off.
Operating the audio system for a long period of time with the
engine turned off will drain the battery.
Observe the following warnings when using this
unit.
5 Adjust the hour.
7 Adjust the minute.
■ This manual uses pictographs to show you how to use the product
Warning
❑ Use the proper power supply.
6 Press [DISP] (CLOCK).
Q'ty: 1
Do not disassemble, modify the unit or attempt to repair the product yourself. If the product needs to be repaired, consult your
dealer or an authorized Panasonic Service Center.
❑ Do not use the unit when it is out of order.
If the unit is out of order (no power, no sound) or in an abnormal
state (has foreign objects in it, is exposed to water, is smoking, or
smells), turn it off immediately and consult your dealer.
❑ The remote control unit should not lie about in the car.
If the remote control unit lies about, it could fall on the floor while
driving, get wedged under the brake pedal, and lead to a traffic
accident.
❑ Refer fuse replacement to qualified service personnel.
When the fuse blows out, eliminate the cause and have it replaced
with the fuse prescribed for this unit by a qualified service engineer. Incorrect replacement of the fuse may lead to smoke, fire,
and damage to the product.
Observe the following warnings when installing.
❑ Disconnect the lead from the negative (–) battery terminal before installation.
Wiring and installation with the negative (–) battery terminal connected may cause electrical shock and injury due to a short circuit.
Some cars equipped with the electrical safety system have specific
procedures of battery terminal disconnection.
FAILURE TO FOLLOW THE PROCEDURE MAY LEAD TO THE
UNINTENDED ACTIVATION OF THE ELECTRICAL SAFETY SYSTEM
RESULTING IN DAMAGE TO THE VEHICLE AND PERSONAL
INJURY OR DEATH.
❑ Never use safety-related components for installation,
grounding, and other such functions.
Do not use safety-related vehicle components (fuel tank, brake,
suspension, steering wheel, pedals, airbag, etc.) for wiring or fixing the product or its accessories.
❑ Installing the product on the air bag cover or in a location
where it interferes with airbag operation is prohibited.
❑ Check for piping, gasoline tank, electric wiring, and other
items before installing the product.
If you need to open a hole in the vehicle chassis to attach or wire
the product, first check where the wire harness, gasoline tank, and
electric wiring are located. Then open the hole from outside if possible.
❑ Never install the product in a location where it interferes
with your field of vision.
❑ Never have the power cord branched to supply other
equipment with power.
❑ After installation and wiring, you should check the normal operation of other electrical equipment.
The continuation of their using in abnormal conditions may cause
fire, electrical shock or a traffic accident.
❑ In the case of installation to an airbag-equipping car,
confirm warnings and cautions of the vehicle manufacturer before installation.
❑ Make sure the leads do not interfere with driving or getting in and out of the vehicle.
❑ Insulate all exposed wires to prevent short circuiting.
❑ Do not expose the unit to direct sunlight or excessive
heat.
Otherwise these will raise the interior temperature of the unit,
and it may lead to smoke, fire, or other damage to the unit.
❑ Do not use the product where it is exposed to water,
moisture, or dust.
Exposure of the unit to water, moisture, or dust may lead to
smoke, fire, or other damage to the unit. Make especially sure
that the unit does not get wet in car washes or on rainy days.
Observe the following cautions when installing.
❑ Refer wiring and installation to qualified service personnel.
Installation of this unit requires special skills and experience. For
maximum safety, have it installed by your dealer. Panasonic is
not liable for any problems resulting from your own installation
of the unit.
❑ Follow the instructions to install and wire the product.
Not following the instructions to properly install and wire the
product could cause an accident or fire.
❑ Take care not to damage the leads.
When wiring, take care not to damage the leads. Prevent them
from getting caught in the vehicle chassis, screws, and moving
parts such as seat rails. Do not scratch, pull, bend or twist the
leads. Do not run them near heat sources or place heavy objects
on them. If leads must be run over sharp metal edges, protect
the leads by winding them with vinyl tape or similar protection.
❑ Do not install the product where it is exposed to strong
vibrations or is unstable.
Avoid slanted or strongly curved surfaces for installation. If the
installation is not stable, the unit may fall down while driving and
this can lead to an accident or injury.
❑ Installation Angle
The product should be installed in a horizontal position with the
front end up at a convenient angle, but not more than 30˚.
The user should bear in mind that in some areas there may be
restrictions on how and where this unit must be installed.
Consult your dealer for further details.
❑ Wear gloves for safety. Make sure that wiring is completed before installation.
❑ To prevent damage to the unit, do not connect the
power connector until the whole wiring is completed.
❑ Do not connect more than one speaker to one set of
speaker leads. (except for connecting to a tweeter)
Observe the following cautions when handling the
battery for the remote control unit.
● Use only specified battery (CR2025).
● Match the polarity of the battery with the (+) and (–) marks in
the battery case.
● Replace dead battery as soon as possible.
● Remove the battery from the remote control unit when not using
it for an extended period of time.
● Insulate the battery (by placing them in a plastic bag or covering
them with vinyl tape) before disposal or storage.
● Dispose of the battery according to the local regulations.
● Do not disassemble, recharge, heat or short the battery. Do not
throw a battery into a fire or water.
In case of battery leakage
● Thoroughly wipe the battery liquid off the battery case and insert
new battery.
● If any part of your body or clothing comes into contact with battery liquid, wash it with plenty of water.
● If battery liquid comes into contact with your eyes, wash them
with plenty of water and get immediate medical attention.
❑ Use the designated parts and tools for installation.
Use the supplied or designated parts and appropriate tools to
install the product. The use of parts other than those supplied or
designated may result in internal damage to the unit. Faulty
installation may lead to an accident, a malfunction or fire.
❑ Do not block the air vent or the cooling plate of the unit.
Blocking these parts will cause the interior of the unit to overheat and will result in fire or other damage.
Caution
THIS PRODUCT UTILIZES A CLASS I LASER.
USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT
IN HAZARDOUS RADIATION EXPOSURE.
DO NOT OPEN COVERS AND DO NOT REPAIR YOURSELF. REFER SERVICING TO QUALIFIED PERSONNEL.
Remote Control Sensor
(only for CQ-C1121W)
CQ-C1001W
TUNE/TRACK
3
10
11
12
4
5
6
SQ/SCAN
CLOCK
DO
REP
M
MUTE
SRC
7
1
DISP
8
2
9
3
10
11
12
4
5
6
SQ/SCAN
CLOCK
DO
REP
M
DISP
[DISP] (Display)
switches the information on
the display.
Preset Number
Press [DISP] to change the display.
Radio source display (Default)
Clock display
[▲] or [▼]
selects a value in the audio menu.
[SEL] (Select)
selects items in the audio menu.
1 Press [SRC] to select the radio source.
2 Press [BAND] to select a band.
3 Select a station.
Frequency adjustment
CQ-C1101W
CQ-C1001W
[TUNE]]: Lower
[TUNE[]: Higher
Press the corresponding preset button from [1] to [6] to
tune in a preset station.
Mute
Note: Settings of SQ, bass and treble are influenced
lights.)
one another. If such an influence causes distortion to
the audio signal, readjust bass/treble or volume.
Remote Control Unit (only for CQ-C1121W)
Note: This operating instruction manual explains operations for use with the buttons on the main unit. (Different operations excluded)
[MUTE]
toggles mute on/off.
POWER
VOL
[MODE]
selects a mode. (source)
MODE
Disc slot
takes a disc in with the label-side facing up.
Note: The power will be turned on automatically
when a disc is loaded.
[TRACK s] [TRACK d]
skip to the previous/next track in the player
mode.
Hold down either of them for fast reverse/fast
forward.
[u] (Eject)
ejects the disc.
(y / 5) (Pause/Play)
toggles pause/play in the player source.
VO
L
BAND
CQ-C1121W
PUSH SEL
APM
PWR
7
1
BAND
CAR AUDIO
[SRC] (Source)
selects a source.
8
2
9
3
10
11
12
4
5
6
SQ/SCAN
DO
[DISP] (Display)
switches the information on
the display.
[REP] (Repeat)
toggles on/off the repeat play.
REP
M
[1] to [6]
(7) to (12) (Hold down one of them for
more than 2 seconds.)
select a track directly.
(RANDOM)
toggles on/off the random play. (Hold it down
for more than 2 seconds.)
Caution
q
¡ Do not insert a disc when the
indicator lights.
¡ Refer to the section of “Notes on Discs”.
¡ This unit does not support 8 cm discs.
¡ If you insert an 8 cm disc and cannot eject it, turn ACC of your car off once and turn it on again, then press [u] (Eject).
¡ This unit does not support MP3 and WMA disc playback.
¡ This unit does not support CD text display.
¡ Do not insert foreign matter into the disc slot.
¡Keep batteries away from children to avoid the risk of
accidents. If an infant ingests a battery, please seek
immediate medical attention.
Caution
¡ Remove and dispose of the old battery immediately.
¡ Do not disassemble, heat or short a battery. Do not
throw a battery into a fire or water.
¡ Follow local regulations when disposing of a battery.
¡Improper use of batteries may cause overheating, an
explosion or ignition, resulting in injury or a fire.
w
1 Press [SRC] to select the Disc Player
source.
2 Select a desired portion.
Note: Battery Information:
Back side
w Put a battery in the case
with (+)-side facing up.
e Put the case back.
2
3
Battery Type: Panasonic lithium battery (CR2025) (Included
in the remote control)
Battery Life: Approximately 6 months under normal use (at
room temperature)
Operation Flow
Battery Notes
q Remove the battery holder
with the remote control unit
placed on a flat surface.
q Stick your thumbnail into
the groove, and push the
holder in the direction of
the arrow at the same
time.
w Pull it out in the direction
of the arrow using a
tough pointed object.
Warning
Tough pointed object
SEL
PWR
CLOCK
DO
REP
M
DISP
MUTE
SRC
Note: If no operation takes place for more than 5 seconds
in the audio menu (2 seconds in Main volume adjustment),
the display returns to the regular mode.
CQ-C1101W
CQ-C1101W
CQ-C1101W
[▲]
[▼]
CQ-C1001W
Press [SEL].
Press [▲] or [▼].
Volume
(Setting Range: 0 to 40, Default: 18)
(blinks once.)
seconds.
CQ-C1121W
Turn [VOL].
CQ-C1001W
[1] to [6] for more than 2 seconds.
1 Select a band.
2 Hold down [BAND] (APM) for more than 2
3 Adjust.
Press [VOL] (PUSH SEL).
With this operation, stations with good receiving conditions can
be automatically stored in the preset memory.
Note: New stations overwrite existing saved stations.
The preset stations under best receiving conditions are
received for 5 seconds each after presetting the stations
(SCAN). To stop scanning, press one of the preset buttons from [1] to [6].
[▲]: Up
[▼]: Down
Bass
(Setting Range: –12 dB to +12 dB by 2 dB,
Default: 0 dB)
[▲]: Increased
[▼]: Decreased
Treble
You can assign your favorite broadcasting station to the
[D•M] (Direct Memory) button. As the result of doing that,
your favorite broadcasting station can be received even if the
unit is turned off, or the CD mode is activated.
D•M station writing
[▲]: Increased
[▼]: Decreased
Balance
1 Select a station you would like to preset.
2 Hold down [D•M] for more than 2 seconds.
(Setting Range: 15 levels each and 0 (center),
Default 0)
[▲]: Right enhanced
[▼]: Left enhanced
Fader
D•M station calling
(Setting Range: 15 levels each and 0 (center),
Default 0)
1 Press [D•M].
[▲]: Front enhanced
[▼]: Rear enhanced
Note: If the fader is set to front, the pre-amp. output
(rear) is decreased.
Play time
If You Suspect Something Wrong
Display change
Track number
Check and take steps as described below.
If the described suggestions do not solve the problem, it is recommended to take the unit to your nearest authorized Panasonic Service
Center. The product should be serviced only by qualified personnel.
Please refer the checking and the repair to professionals. Panasonic
shall not be liable for any accidents arising out of neglect of checking
the unit or your own repair after your checking.
Press [DISP] to change the display.
Player source display (Default)
lights when a disc is in the player.
Warning
¡ Do not use the unit in an irregular condition, for example, without sound, or with smoke or a foul smell, which can cause
ignition or electric shock. Immediately stop using the unit and
consult your dealer.
¡ Never try to repair the unit by yourself because it is dangerous
to do so.
Repeat indicator
Clock display
Trouble
Check point
Common
Random play
Press [BAND] (y / 5).
Press again to cancel.
Direct track selection
Press [TRACK s] / [TRACK d].
Press a track number button from [1] to [6].
¡ The corresponding track (1–6) starts playing.
Hold down a track number button from [1]
to [6] ((7) to (12)) for more than 2 seconds.
¡ The corresponding track (7–12) starts playing.
All the available tracks are played in a random sequence.
Hold down [REP] (RANDOM) for more than
2 seconds.
Scan play
The first 10 seconds of each track is played in sequence.
Hold down [SQ] (SCAN) for more than 2
seconds.
No power
Hold down again to cancel.
Repeat play
The current track is repeated.
(blinks during scanning.)
Hold down again to cancel.
No sound
Press [REP].
Noise
Press again to cancel.
Notes on CD/CD Media
Pause
Track selection
Note: To perform fast forward/reverse, hold down either
of them.
Random indicator
DISP
(SCAN)
toggles on/off the scan play. (Hold it down for more than 2
seconds.)
Battery Replacement
SQ/SCAN
Trouble
Check point
CLOCK
N
MUTE
SRC
[TUNE]] [TUNE[]
down/up the frequency. (Hold it down for
more than 2 seconds for seek tuning.)
[TRACK s] [TRACK d]
skip to the previous/next track in the
player mode.
Hold it down for fast reverse/fast forward.
D·M
RA
[BAND]
selects a band in the radio source,
toggles pause/play in the player source,
and executes APM in the radio source.
(Hold it down for more than 2 seconds.)
6
Troubleshooting
[VOL}] [VOL{]
adjust the volume.
TUNE
TRACK
CQ-C1121W
1 Tune into a station.
2 Hold down one of the preset buttons from
Disc Player
MUTE
PWR
12
5
[DISP] (Display)
exits from the audio menu.
2 Select a mode to be adjusted.
Manual station preset
Press again to cancel.
TUNE/TRACK
[PWR] (POWER)
toggles power on/off.
11
4
(Setting Range: –12 dB to +12 dB by 2 dB,
Default: 0 dB)
Preset station selection
Press [VOLUME▲] or [VOLUME▼].
ON: Press [MUTE]. (
OFF: Press [MUTE] again.
10
BAND
APM
Note: New stations overwrite existing saved stations.
Note: Hold down either of them for more than 0.5
seconds and release it for station search.
Direct Memory
(VOCAL) clear sound:
emphasizes middle tone and slightly emphasizes treble.
Station Preset
Auto Preset Memory (APM)
Player Source Display
CQ-C1121W
3
Press [SEL].
Random, Repeat, Scan
Volume Adjustment
Turn [VOL].
9
2
CQ-C1001W
Notes on discs
(POP) wide-ranged and deep sound:
slightly emphasizes bass and treble.
(Setting Range: 0 to 40, Default: 18)
8
1 Display the audio menu.
Up to 6 stations can be preset in AM, FM1, FM2, and FM3
respectively.
Preset stations can be simply called up by pressing one of the
preset buttons from [1] to [6].
SQ is a function that can call up various sound types at
the touch of button in accordance with your listening
music type.
Press [SQ] to select the sound type as follows:
(ROCK) speedy and heavy sound:
exaggerates bass and treble.
Disc Player
7
lights while receiving the D•M station.
[TUNE ]] [TUNE []
down/up the frequency. (Hold it down for
more than 2 seconds for seek tuning.)
Preset buttons [1] to [6]
selects a preset station in the radio source,
and presets the current station. (Hold it down
for more than 2 seconds.)
Operation Flow
General Operations
Press [SRC] to change the source.
Radio
[SRC] (Source)
selects a source.
(FLAT) flat frequency response:
does not emphasize any part. (Default)
Source Selection
MUTE
D·M
CQ-C1001W
CQ-C1121W
SQ (Sound Quality)
Power on: Press [SRC] (PWR).
Power off: Hold down [SRC] (PWR) for
more than 1 second.
PWR
1
Audio menu
[SQ] (Sound Quality)
selects a sound type (SQ).
Turn your car's ignition switch to the ACC or ON position.
CQ-C1121W
APM
Press [VOL] (PUSH SEL).
[MUTE]
toggles mute on/off.
Power On/Off
L
SRC
lights when mute is on.
[SRC] (Source)
selects a source.
(PWR) (Power)
toggles power on/off.
VO
BAND
N
9
2
D·M
N
8
1
N
7
PWR
RA
MUTE
SRC
CQ-C1121W
APM
RA
PWR
MUTE
SRC
D·M
PUSH SEL
PWR
APM
L
BAND
CQ-C1121W
PUSH SEL
SEL
UME
VOL
APM
VO
L
Band
CQ-C1101W
[VOL]
selects a value in the audio menu.
(PUSH SEL) (Push to Select)
selects items in the audio menu.
UME
VOL
VO
BAND
BAND
Frequency
CQ-C1121W
Display change
RA
[VOLUME▲] [VOLUME▼] (Press)
adjusts the volume.
lights while receiving an FM stereo signal.
Radio Source Display
[VOL] (Volume) (Turn)
[D•M] (Direct Memory)
tunes into the station memorized in D•M.
(Hold it down for more than 2 seconds to
memorize the current station.)
[BAND]
selects a band in the radio source.
(APM) (Auto Preset Memory)
executes APM in the radio source. (Hold it
down for more than 2 seconds.)
PUSH SEL
[D•M] (Direct Memory)
tunes into the station memorized in D•M.
(Hold it down for more than 2 seconds to
memorize the current station.)
CQ-C1101W
Audio Settings
TUNE/TRACK
CQ-C1121W
Radio (FM/AM)
TUNE/TRACK
General
If you use commercial CDs, they must
have the label shown at right.
Some copy-protected music CDs are not
playable.
How to hold a disc
¡ Do not touch the underside of a disc.
¡ Do not scratch on a disc.
¡ Do not bend a disc.
¡ When not in use, keep a disc in a case.
Do not use irregularly shaped discs.
Do not leave discs in the following places:
¡ In direct sunlight
¡ Near car heaters
¡ Dirty, dusty and damp areas
¡ Seats and dashboards
Disc cleaning
Use a dry, soft cloth to wipe from the center outward.
Do not attach any seals or labels to your discs.
Do not write on the disc label with a ballpoint pen
or other hard-point pens.
Notes on CD-Rs/RWs
¡ You may have trouble playing back some CD-R/RW discs
recorded using CD recorders (CD-R/RW drives), either due
to their recording characteristics or dirt, fingerprints,
scratches, etc. on the disc surface.
¡ CD-R/RW discs are less resistant to high temperatures and
high humidity than ordinary music CDs. Leaving them
inside a car for extended periods may damage and make
playback impossible.
¡ Some CD-R/RWs cannot be played back successfully due
to incompatibility among writing software, a CD recorder
(CD-R/RW drive) and the discs.
¡ This player cannot play the CD-R/RW discs if the session is
not closed.
¡ This player cannot play the CD-R/RW discs which contain
other than CD-DA data (MP3/WMA, Video CD, etc.).
¡ Be sure to observe the instructions of the CD-R/RW disc
for handling it.
No sound from
left, right, front,
or rear speaker
Left and right
sounds are
reversed
CD Player
● Start the engine. (Or turn the ignition
switch to the ACC position.)
● Verify the wiring. (Ex. battery lead,
power lead, ground lead, etc.)
● Fuse blown (Contact the nearest
Panasonic Service Center.)
● Ask a professional for fuse replacement.
● Be sure to use the same rated fuse.
● Disable the mute function.
● Verify the wiring.
● Wait until the dew disappears before
turning on the unit.
● Make sure that grounding is established
properly.
● Adjust the balance and fader.
● Verify the wiring.
● Connect the speaker lead correctly.
No sound, or disc
is automatically
ejected
● Load the disc correctly.
● Clean the disc.
Sound skip,
poor sound
quality
● Clean the disc.
Sound skip
due to
vibration
● The maximum permissible tilt angle is
30°.
● Secure the unit.
Disc not
ejectable
● Press [u]. If the disc is still not ejected, contact the nearest Panasonic
Service Center.
Error Display Messages
(The disc is ejected automatically.)
The disc is dirty, or is upside down.
The disc has scratches.
● Check the disc.
Radio
Frequent
noise
● Tune in to another station of high-intensity waves.
● Make sure that the antenna mounted
point is grounded properly.
Preset data
deleted
● The preset memory is cleared to return
to the original factory setting when the
power connector or battery is disconnected.
No operation by some cause.
● If normal operation is not restored, call
the store where you purchased the unit
or the nearest Service Center to ask for
repairs.
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
