User Manual

Preface

Thank you for purchasing the Pro-face Graphic Logic Controller Factory Gateway

Series (hereby referred to as “Factory Gateway” or “Factory Gateway unit”).

This unit is designed to be connected to an External Device (PLC, etc.) that do not have their own Ethernet interface, via the Pro-Server system’s Ethernet connection. Pro-

Server allows the Factory Gateway unit to communicate with a host-level PC without specialized programming. This allows data collection and sharing of data with other PLC units.

Also, Pro-Server’s Add-on software, GP-Viewer and GP-Web, allow you to access factory floor data from a remote PC, and even perform maintenance.

In this manual’s examples, the Mitsubishi MELSEC-AnA Series PLC is used whenever possible, connected in a one-to-one relationship with a Factory Gateway

1. It is forbidden to copy the contents of this manual, in whole or in part, except for the user’s personal use, without the express permission of Digital Electronics

Corporation of Japan.

< Note >

2. The information provided in this manual is subject to change without notice.

3. This manual has been written with care and attention to detail; however, should you find any errors or omissions, contact Digital Electronics Corporation and inform them of your findings.

4. Please be aware that Digital Electronics Corporation shall not be held liable by the user for any damages, losses, or third party claims arising from any uses of this product.

All Company/Manufacturer names used in this manual are the registered trademarks of those companies.

© Copyright 2002 Digital Electronics Corporation

Factory Gateway Series User Manual

1

2

Preface

Table of Contents

Preface ........................................................................................................................ 1

Essential Safety Precautions ................................................................................... 4

General Safety Precautions ..................................................................................... 7

About Factory Gateway Models ............................................................................ 8

Package Contents ..................................................................................................... 8

UL/c-UL (CSA) Application Notes .......................................................................... 9

CE Marking Notes .................................................................................................. 9

Documentation Conventions .................................................................................. 10

CHAPTER 1 INTRODUCTION

1.1

Prior to Operating the Factory Gateway .................................................... 1-1

1.2

System Design ............................................................................................... 1-3

1.3

Accessories .................................................................................................... 1-4

CHAPTER 2 SPECIFICATIONS

2.1

General Specifications ................................................................................. 2-1

2.1.1

Electrical .............................................................................................. 2-1

2.1.2

Environmental ...................................................................................... 2-2

2.1.3

Structural ............................................................................................. 2-3

2.2

Functional Specifications ............................................................................. 2-3

2.2.1

Clock ................................................................................................... 2-3

2.2.2

Interfaces ............................................................................................. 2-3

2.3

Interface Specifications ................................................................................ 2-5

2.3.1

Serial Interface .................................................................................... 2-5

2.4

Part Names and Functions ........................................................................... 2-6

2.5

Dimensions .................................................................................................... 2-8

CHAPTER 3 INSTALLATION AND WIRING

3.1

Installation ..................................................................................................... 3-1

3.2

Wiring Cautions ............................................................................................. 3-2

3.2.1

Connecting the Power Cord ................................................................ 3-2

3.2.2

Connecting the Power Supply ............................................................. 3-4

3.2.3

Grounding ............................................................................................ 3-5

3.2.4

I/O Signal Line Cautions...................................................................... 3-6

3.3

Tool Connector .............................................................................................. 3-6

3.4

Ethernet Cable Connector ........................................................................... 3-7

Factory Gateway Series User Manual

Preface

3.5

IP Address Settings ...................................................................................... 3-7

3.6

Dip Switch Settings ....................................................................................... 3-8

3.6.1

Initializing Memory .............................................................................. 3-9

CHAPTER 4 TROUBLESHOOTING

4.1

Troubleshooting ............................................................................................. 4-1

4.1.1

LED Status Indicators ......................................................................... 4-2

4.1.2

Problem Solving................................................................................... 4-4

4.2

Periodic Check Points ................................................................................... 4-5

Factory Gateway Series User Manual

3

4

Preface

Essential Safety Precautions

This manual includes procedures that must be followed to operate the FACTORY

GATEWAY correctly and safely. Be sure to read this manual and any related materials thoroughly to understand the correct operation and functions of the FACTORY GATE-

WAY unit.

Safety Symbols

Please pay attention to the following safety symbols and their meanings:

WARNING

Indicates situations that may result in major machine damage, severe bodily injury, or death if the instructions are not followed.

CAUTION

Indicates situations that may result in damage to the machinery, or minor bodily injury if the instructions are not followed.

WARNINGS

System Design

• Please design your system so that equipment will not malfunction due to a communication fault between the Factory Gateway and its host controller This is to prevent any possibility of bodily injury or material damage.

• Do not use the Factory Gateway unit as a warning device for critical alarms that can cause serious operator injury, machine damage or production stoppage. Critical alarm indicators and their control/activator units must be designed using stand-alone hardware and/or mechanical interlocks.

• The Factory Gateway is not appropriate for use with aircraft control devices, aerospace equipment, central trunk data transmission (communication) devices, nuclear power control devices, or medical life support equipment, due to these devices’ inherent requirements of extremely high levels of safety and reliability.

Factory Gateway Series User Manual

Preface

WARNINGS

• When using the Factory Gateway with transportation vehicles (trains, cars and ships), disaster and crime prevention devices, various types of safety equipment, non life-support related medical devices, etc. redundant and/ or fail-safe system designs should be used to ensure the proper degree of reliability and safety.

Installation

• High voltage runs through the Factory Gateway. Never disassemble the Factory Gateway, otherwise an electric shock can occur.

• Do not modify the Factory Gateway unit. Doing so may cause a fire or an electric shock.

• Do not use the Factory Gateway in an environment where flammable gasses are present, since operating the Factory Gateway may cause an explosion.

Wiring

• To prevent an electric shock, be sure to confirm that the

Factory Gateway's power cord is not connected to the main power when connecting any cords, cables or lines to the Factory Gateway.

• Be sure to replace the Factory Gateway’s plastic terminal block cover after wiring is completed, since operating the

Factory Gateway without the cover may lead to an electric shock.

• Do not use power beyond the Factory Gateway's specified voltage range. Doing so may cause a fire or an electric shock.

Maintenance

• The Factory Gateway uses a lithium battery for backing up its internal clock data. If the battery is incorrectly replaced, the battery may explode. To prevent this, please do not replace the battery yourself. When the battery needs to be replaced, please contact your local Factory

Gateway distributor.

Factory Gateway Series User Manual

5

6

Preface

CAUTIONS

Installation

• Be sure to securely connect all cable connectors to the

Factory Gateway. A loose connection may cause incorrect input or output.

Wiring

• Ground the Factory Gateway's FG line separately from other units’ FG lines. Putting these FG lines too close may cause an electric shock or unit malfunction. Be sure to use a grounding resistance of 100

or less and a 2mm

2 or thicker wire, or your country’s applicable standard.

• When wiring the Factory Gateway, be sure that the rated voltage and terminal layout are within the designated range. If the voltage supplied differs from the rated voltage, or incorrect wiring or grounding is performed, it may cause a fire or unit malfunction.

• Use only the designated torque to tighten the Factory

Gateway's terminal block screws. If these screws are not tightened firmly, it may cause a short-circuit, fire, or Factory Gateway malfunction.

• Be careful that metal filings and wiring debris do not fall inside the Factory Gateway, since they can cause a fire,

Factory Gateway malfunction, or incorrect operation.

Unit Disposal

• When this unit is disposed of, it should be done so according to your country's regulations for similar types of industrial waste.

Factory Gateway Series User Manual

Preface

General Safety Precautions

• Do not install the Factory Gateway where the ambient temperature can exceed the allowed range. Doing so may cause the Factory Gateway to malfunction or shorten its operation life.

• Do not restrict or limit the Factory Gateway’s naturally occurring rear-face ventilation, or store or use the Factory Gateway in an environment that is too hot.

• Do not use this unit in areas where large, sudden temperature changes can occur. These changes can cause condensation to form inside the unit, possibly causing the unit to malfunction.

• Do not allow water, liquids, metal or charged particles to enter inside the Factory Gateway’s case, since they can cause either a Factory Gateway malfunction or an electrical shock.

• Do not use or store the Factory Gateway in direct sunlight, or in excessively dusty or dirty environments.

• Do not store or use the unit where strong jolting or excessive vibration can occur.

• Do not store or use the Factory Gateway where chemicals (such as organic solvents, etc.) and acids can evaporate, or where chemicals and acids are present in the air.

Corrosive chemicals: Acids, alkalies, liquids containing salt

Flammable chemicals: Organic Solvents

• Do not use paint thinner or organic solvents to clean the

Factory Gateway.

Factory Gateway Series User Manual

7

8

Preface

About Factory Gateway Models

The Factory Gateway Series in this manual refers to the following Factory Gateway model numbers:

Series Name

Model

Number

Comments

Factory Gateway FGW-SE41-24V

UL/c-UL Approved

CE Marked

GP Type with

Screen Creation

Software

Factory Gateway

FGW-SE

Package Contents

The following items are included in the Factory Gateway's package. Before using the

Factory Gateway, please confirm that all items listed here are present.

Factory Gateway Unit (1)

(FGW-SE41-24V)

Installation Guide (1)

Installation

Guide

This unit has been carefully packed, with special attention to quality. However, should you find anything damaged or missing, please contact your local Factory Gateway distributor immediately.

Factory Gateway Series User Manual

Preface

UL/c-UL (

CSA

) Application Notes

The FGW-SE41-24V is a UL/c-UL (CSA) recognized unit. (UL File

No. E220851)

The FGW-SE41-24V unit conforms to the following standards.

UL508 Electrical Control System for Industry

CAN/CSA-C22.2 No.1010-1

(Safety requirements for electrical equipment for measurement and laboratory use)

FGW-SE41-24V (UL Registration Model: 3080034-01)

<Notes>

The Factory Gateway must be installed in other equipment.

If the unit is installed in an area with no air conditioning system, be sure to attach the DIN rail to the rear of the unit. Also, be sure the unit is installed so it is at least 100 mm away from all of the unit’s directions except the rear side. If these requirements are not met, the heat generated by the unit’s internal components may cause the unit to fail to meet UL standards requirements.

The power supply unit connected to the I/O unit must be a UL/c-UL

(CSA) approved Class 2 power supply unit or Class 2 transformer

*1

. When the Factory Gateway or multiple I/O units under load are operated with a single power supply, the amount of current consumption and full-load current of the I/O units must be within the rated load of the Class 2 power supply unit or Class 2 power supply transformer. Be aware that the number of points which can be turned ON simultaneously may be limited, depending on the amount of load and load current value.

*1 A Class 2 power supply unit or Class 2 power supply transformer is defined by

NEC as being 30V and, at 8A or less output, less than 100VA.

CE Marking Notes

The FGW-SE41-24V is a CE Marked unit that conforms to EMC directives EN55011

Class A and EN61000-6-2.

<Caution>

While this unit is officially marked as conforming to the relevant EMC directives, it is the user’s final application of this unit in a larger system (i.e. the machinery, wiring, control panel, installation method, etc.) that will determine if this unit maintains or loses this conformance marking. Therefore, it is strongly advised that the user investigate and confirm whether their overall system (i.e. all related machinery and equipment) also conforms with these EMC directives.

Factory Gateway Series User Manual

9

Preface

Documentation Conventions

The list below describes the documentation conventions used in this manual.

Symbol Meaning

Indicates important information or procedures that must be followed for correct and risk-free software/device operation.

Data Collection

Software

Indicates the "Pro-Server with Pro-Studio for Windows" software. Pro-

Server is used as a server, and Pro-Studio is used as a data set up tool.

Factory Gateway

Configuration Tool

Used to set up and send protocol data to the Factory Gateway unit.

(sold as optional Add-on software)

Indicates the "GP-PRO/PBIII for Windows" software. GP-PRO/PBIII for

Screen Creation

Software

Windows is also included in the "GP-PRO/PBIII C-Package" software.

Intended primarily for the creation and maintenance of operator interface (GP unit) screens, it can also create screens for GP-Viewer and GP-Web.

GP Viewer

GP-Web

PLC

2-Way

Pro-Server uses this add-on software to display and sample screens created using the Screen Creation Sofware.

T his add-on software displays screens created using the Screen

Creation Sofware, using the Internet Explorer software.

Abbreviation for Programmable Logic Controller.

T his driver software is used as a protocol converter between external devices (PLCs, etc.) and PCs, Factory Gateway, GP and GLC series units.

*

Indicates additional important information.

Indicates an important hint or explanation.

10

Factory Gateway Series User Manual

Chapter

1 Introduction

1. Prior to Operating the

Factory Gateway

2. System Design

3. Accessories

1.1

Prior to Operating the Factory Gateway

Use the following steps to create projects for the Factory Gateway unit.

Factory Gateway Setup and Wiring

Setup

Wiring

IP Address Setup

Chapter 3 Setup and

Wiring GP-PRO/PBIII Device/PLC

Connection Manual

Software Installation

Pro-Server with Pro-Studio for Windows

Factory Gateway Configuration Tool

Pro-Server with Pro-

Studio for Windows Operation Manual

Factory Gateway Con-

figuration Tool Operation Manual

Create Network Project File

Search for Factory Gatewa

Register Factory Gateway as a node

Enter Factory Gateway Network Settings

Set up wiring

Send Network Project File

Pro-Server with Pro-

Studio for Windows Operation

Manual

Factory Gateway Serial Data Transfer

Start up Factory Gateway Configuration Tools

Search for Factory Gateway

Set up Serial Data Transfer Settings

Select and set up protocol

Send protocol and setting data

Factory Gateway

Configuration Tool Operation

Manual

When using GP-Web or GP-Viewer, screen creation software must first be installed, screens created and data sent to the

Factory Gateway unit.

Factory Gateway Configuration Tool Opera-

tion Manual

This manual explains the hardware settings used to set up the FActory Gateway unit.

For detailed information about operation of the Factory Gateway Configuration Tool, or

Pro-Server with Pro-Studio for Windows, please refer to the following manuals

Factory Gateway Configuration Tool Operation Manual

Pro-Server with Pro-Studio for Windows Operation Manual

1–1

Factory Gateway Series User Manual

Chapter 1 – Introduction

1.2

System Design

The following diagram represents the main selection of devices connectable to the

Factory Gateway unit.

Factory Gateway RUN Mode

Peripherals

RUN Mode

Edit Mode

GP-WEB

Client *1

ClientPC

Internet/

Intranet

Host PC - Pro-Server

- Pro-Studio

- GP-Viewer *2

- GP-Web Server *1

- IIS *1

Ethernet

Factory Gateway Unit

(2)

(1)

1–2

(3)

Data Transfer Cable

GPW-CB02

Mitsubishi GPP

Software* 3

Personal

Computer

(4)

RS-232C Cable

GP410-IS00-O* 4

RS-422 Cable

GP230-IS11-O*

4

GP230-IS12-O*

4

(for Multi-link cable)

(5)

RS-422 Connector

Terminal Adapter

GP070-CN10-O*

4

2-Port Adapter

II Cable

GP070-MDCB11

Mitsubishi PLC

A, Q, C, FX Series

(6)

2-Port

Adapter II

GP070-MD11

(6)

Mitsubishi PLC A-Series

Program Port I/F Cable

GP430-IP10-O

(6)

Mitsubishi PLC FX-Series

Program Port I/F Cable

GP430-IP11-O

Host

Controller

(PLCs, etc.)

Factory Gateway Series User Manual

Chapter 1 – Introduction

- Pro-Server

- Pro-Studio

- Factory Gateway Configuration Tool

- GP-PRO/PBIII for Windows

*1, *2

- GP-Viewer

*2

- GP-Web Screen Compiler *1

Factory Gateway Unit

(2)

(1)

*6

Factory Gateway

Interfaces

(1) Ethernet

(2) Tool Connector

(3) Serial Interface

Data Transfer Cable

GPW-CB02

Personal Computer

GP-PRO/PBIII for

Windows

PLC Interfaces

(4) RS-232C Port

(5) RS-422 Port

(6) Programming

Console Port

1. Required when using GP-Web.

2. Required when using GP-Viewer

3.

For information about compatible PLC types and software, refer to the GP-PRO/PB III for Windows Device/PLC Connection

Manual (included in the GP-PRO/PB III software).

4. Certain PLC types and models cannot be connected.

Refer to the GP-PRO/PB III for Windows Device/PLC Connec-

tion Manual (included in the GP-PRO/PB III software).

5. For the full range of compatible PCs, refer to the following manual.

Refer to the GP-PRO/PB III for Windows Operation Manual

(included in the GP-PRO/PB III software).

6. Normally, maintenance (data transfer) is possible using an Ethernet network.

However, depending on the data transfer cable used, a Factory Gateway System

Error may occur, preventing communication.

Factory Gateway Series User Manual

1–3

Chapter 1 – Introduction

1.3

Accessories

All optional equipment listed here is produced by Digital Electronics Corporation.

Available Software

Product Name Model No.

Pro-Server with Pro-Studio for Windows Ver. 4.0

Factory Gateway

Configuration Tool

*1

GP-PRO/PBIII for Windows

Ver. 6.0 or later

*2*3*4

GP-Viewer 1.0 or later

*3

GP-Web Ver. 1.5 or later

*4

PSW-ED01-V40

GPW-PB01W-V60

PSW-GV01-V10

GW-CJ01-V15

Description

This software is used to set up the Pro-

Server System. This software consists of 2 elements, a server (Pro-Server) and a setting entry program (Pro-Studio).

(Required)

Used to set up and send protocol data to the

Factory Gateway unit. Add-on software for

Pro-Server. (Required)

Used to create projects and screen data that can be sent to the Factory Gateway and then displayed using GP-Viewer or GP-

Web.Depending on the cable used, serial data transfer can also be used.

Installed in the Pro-Server PC and used to view or perform maintenance on data in a

PLC that is connected to the Factory

Gateway unit. (Add-on Software)

Used to create or maintain PLC device data that can be viewed with Internet Explorer software. This data is taken from a PLC

(device) that is connected to the Factory

Gateway unit. GP-Web system includes server, client and GP-PRO/PBIII software.

Tool Connector

Product Name Model No.

Data Transfer Cable GPW-CB02

Description

Connects the Factory Gateway to a personal computer. Transfers screen data and user programs.

1. Installed from Pro-Server with Pro-Studio for Windows CD-ROM. With Ver. 4.0*

CD-ROMs, this software may not be included. In this case, please download the software from the www.pro-face.com home page.

2. With Ver. 6.0*, add-on software is required. Please download this software from the www.pro-face.com home page.

3. Required when using GP-Viewer

4. Required when using GP-Web.

5. Normally, maintenance (data transfer) is possible using an Ethernet network.

However, depending on the data transfer cable used, a Factory Gateway System

Error may occur, preventing communication.

1–4

Factory Gateway Series User Manual

Chapter 1 – Introduction

Serial Interfaces

Product Name

RS-232C Cable

*1

RS-422 Cable

*1

RS-422 Terminal Block

Adapter

*1

2 Port Adapter II

Model No.

GP410-IS00-O

GP230-IS11-O

GP070-CN10-O

GP070-M D11

2 Port Adapter II Cable GP070-M DCB11

M itsubishi A Series

Programming Port I/F Cable

GP430-IP10-O

M itsubishi FX Series

Programming Port I/F Cable

GP430-IP11-O

Description

Interface cables between the host (PLC) and the

Factory Gateway.

Conversion adapter to convert serial data to

RS-422 format.

Interface unit that allows use of both Factory gateway and M itsubishi A, Q, C and FX series equipment in the same location.

Connects the Factory Gateway to the 2-Port

Adapter II.

Connects directly to M itsubishi's PLC I/F

Programming Console. Simultaneous use of program console, however, is not possible.

1. For details about the range of connectable PLCs:

Refer to the GP-PRO/PB III for Windows Device/PLC Connec-

tion Manual (included with the GP-PRO/PB III software).

Maintenance Items

Product Name

Connector Cover

Model No.

PS-BH00

Description

Side face connector cover.

Factory Gateway Series User Manual

1–5

Chapter 1 – Introduction

Memo

1–6

Factory Gateway Series User Manual

1. General Specifications

2. Functional Specifications

3. Interface Specifications

4. Part Names and Functions

5. Dimensions

Chapter

2 Specifications

2.1

General Specifications

2.1.1

Electrical

Rated Voltage

Rated Voltage Range

Allowable Voltage Drop

Power Consumption

In-Rush Current

Voltage Endurance

Insulation Resistance

DC 24V

DC 19.2V to DC 28.8V

10ms max.

10W max.

30A max.

AC 500V 20mA for 1 minute (between charging and FG terminals)

10M

or more at DC 500V (between charging and FG terminals)

Factory Gateway Series User Manual

2–1

Chapter 2 – Specifications

2.1.2

Environmental

Ambient Operating

Temperature

Storage Temperature

Ambient Humidity

Storage Humidity

Air Purity (Dust)

Atmosphere

Atmosheric Endurance

(GLC Operation

Altitude)

0 o

C to +55 o

C

-20 o

C to +60 o

C

10%RH to 90%RH

(non-condensing, wet bulb temperature: 39 o

C max.)

10%RH to 90%RH

(non-condensing, wet bulb temperature: 39 o

C max.)

0.1mg/m

3

max. (non-conductive levels)

Free of corrosive gasses

800hPa to 1,114hPa (2000 meters max.)

Shock Resistance

IEC61131-2 (JIS B 3501) compliant

(147m/s

2,

three times for each [X, Y, Z] direction)

Vibration Resistance

Noise Immunity

(via noise simulator)

Electrostatic Discharge

Immunity

IEC61131-2 (JIS B 3501) compliant

When Vibration is NOT Continuous

10Hz to 57Hz 0.075mm, 57Hz to 150Hz 9.8m/s

2

When Vibration is Continuous

10Hz to 57Hz 0.035mm, 57Hz to 150Hz 4.9m/s

2

(10 times [80 min.] for each [X, Y, Z] direction)

Noise Voltage: 1200Vp-p, Pulse Duration: 1

µ s

Rise Time: 1ns

Contact Discharge M ethod 6kV

(complies with IEC 61000-4-2 Level 3)

2.1.3

Structural

Grounding

External Dimensions

Weight

Cooling Method

100

max., or your country's applicable standard

W37mm x H131mm x D105mm [1.46 in.x 5.16 in. x 4.13

in.]

Approx. 0.6 kg [1.32 lb]

Natural air circulation

2–2

Factory Gateway Series User Manual

Chapter 2 – Specifications

2.2

Functional Specifications

2.2.1

Clock

Clock Accuracy

±65 seconds/month (at room temperature)

The FACTORY GATEWAY unit’s internal clock has a slight error. At normal operating temperatures and conditions, with the FACTORY GATEWAY operating from its lithium battery, the degree of error is 65 seconds per month. Variations in operating conditions and battery life can cause this error to vary from -380 to +90 seconds per month. For systems where this degree of error will be a problem, the user should be sure to monitor this error and make adjustments when required.

See Factory Gateway Configuration Tool Operation Manual.”

2.2.2

Interfaces

Serial Interface

Ethernet Interface

Tool Connector

Asynchronous Transmission:

RS232C/RS422

Data Length: 7 or 8 bits

Stop Bit: 1 or 2 bits

Parity: None, Odd or Even

Data Transmission Speed: 2,400 to 187,500bps

IEEE802.3, 10BASE-T

Asynchronous TTL level nonprocedural command I/F

<During screen file development>

Used for transferring data between the GLC application software and the GLC. Used for data transfer with the 2-Port feature.

Factory Gateway Series User Manual

2–3

Chapter 2 – Specifications

2.3

Interface Specifications

2.3.1

Serial Interface

This interface can be either RS-232C or RS-422. Connects FACTORY GATEWAY to

Host (PLC). This interface uses a socket-type connector.

1

Pin Assignments

13

SIO

14

25

12

13

14

8

9

10

11

Pin #

1

2

5

6

3

4

7

20

21

22

23

15

16

17

18

19

24

25

Signal Name

FG

SD

RD

RS

CS

DR

SG

CD

TRMX

RDA

SDA

NC

NC

VCC

SDB

RDB

RI

CSB

ERB

ER

CSA

ERA

NC

NC

NC

Condition

Frame ground

Send data (RS-232C)

Receive data (RS-232C)

Request send (RS-232C)

Clear send (RS-232C)

Data Set Ready (RS-232C)

Signal ground

Carrier detect (RS-232C)

Termination (RS-422)

Receive data A (RS-422)

Send data A (RS-422)

No connection (Reserved)

No connection (Reserved)

5V±5% output 0.25A

Send data B (RS-422)

Receive data B (RS-422)

Ring Indicate (RS-232C)

Clear send B (RS-422)

Enable receive B (RS-422)

Enable receive (RS-232C)

Clear send A (RS-422)

Enable receive A (RS-422)

No connection (Reserved)

No connection (Reserved)

No connection (Reserved)

Recommended Parts

Connector Dsub25pin plug XM2A-2501 (OMRON)

Cover Dsub25pin cover XM2S-2511

Dsub25pin cover XM2S-2521

(OMRON)

(OMRON)

Cable

Jack Screws XM2Z-0071

CO-MA-VV-SB5PX 28AWG

(OMRON)

(Hitachi Cable Ltd.)

Use rough metric type M2.6x0.45 p threads used to secure the cable’s set screws.

To confirm your PLC unit’s connection specifications, refer to the

GP-PRO/PB III for Windows Device/PLC Connection Manual (included in the GP-PRO/PB III C-Package01).

2–4

Factory Gateway Series User Manual

Chapter 2 – Specifications

Use the following instructions to create your own cable:

With an RS-422 cable:

• The following pins must be shorted as follows:

#18 (CSB) and #19 (ERB)

#21 (CSA) and #22 (ERA)

• Connecting the RS-422 cable’s #9 (TRMX) and #10 (RDA) pins inserts a termination resistance of 100

between

#10 (RDA) and #16 (RDB).

• When making a cable for a Memory Link system, use a

4-wire type cable.

With an RS-232C cable:

• Do NOT use the following pins:

#9 (TRMX), #10 (RDA), #11 (SDA), #15 (SDB), #16 (RDB),

#18 (CSB), #19 (ERB), #21 (CSA), #22 (ERA)

• Connect the #1 (FG) terminal only if it is required by a connected device.

• This FACTORY GATEWAY unit’s serial port is not isolated. When the host (PLC) unit is also not isolated, and to reduce the risk of damaging the RS-422 circuit, be sure to connect the #7 SG (Signal Ground) terminal.

• Pin #14 (VCC) DC 5V Output is not protected. To prevent damage or unit malfunction, use only the designated level of current.

Factory Gateway Series User Manual

2–5

Chapter 2 – Specifications

2.4

Part Names and Functions

A : Tool Connector

Connects the data transfer cable when transferring data for maintenance or when using 2-Port feature.

B : Ethernet I/F(10BASE-T)

Provides a 10BASE-T interface.

C : Network Status LED

These LEDs are positioned vertically and indicate the Ethernet data transfer status.

Location Color Indicates

Upper Green

Ready to transfer data

Not Lit Indicates

Not connected to network / Network trouble

Lower Yellow

T ransferring data

Not transferring data

A

B

C

D

E

Front

D : Serial I/F(Dsub 25pin)

Used for the Dsub25 pin’s RS-232C and RS-422 cables. Is connected to the Host (PLC.)

2.3 Interface Specifications

E : Power Input Terminal Block

Connects the power cord.

F : Power LED (PWR)

This LED indicates the Factory Gateway’s status.

LED

Green

Red

Orange

Not Lit

Factory Gateway Status

Normal operation

Data transfer (OFFLINE) mode

Initializing internal memory

System program error

G : Error Status LED (STA)

LED

Green

Red

Orange

Not Lit

Factory Gateway Status

Normal operation

System error / Screen memory data is damaged

2-Way feature error

System Program Error

For details, see 4.1.1 LED Status

Indicators

F

G

H

I

J

K

2–6

Factory Gateway Series User Manual

Chapter 2 – Specifications

H : Serial I/F (TxD)

When this indicator blinks, data is being sent.

I : Serial I/F (RxD)

When this indicator blinks, data is being received.

J : Reset Switch (RST)

Resets the Factory Gateway unit.

K :DIP Switches

Control various Factory Gateway features.

Factory settings are all “OFF”.

For details, see 3.6 Setting Dip

Switches

A

B

C

D

E

F

G

H

I

J

K

Front

L : DIN Rail Attachment Holder

L

M: Rotary Switches

These switches are used to set the unit’s IP

Address. The factory settings are “0”.

M

For details, see 3.5 Setting IP

Addresses

*1

Right Side

*1 This section is used only for maintenance by Pro-face. Do not open this cover.

Factory Gateway Series User Manual

2–7

Chapter 2 – Specifications

2.5

Dimensions

Unit:mm [in.]

37[1.46]

(9[0.35])

105[4.13] (8[0.31])

Front Right Side

2–8

Factory Gateway Series User Manual

Chapter

1. Installation

2. Wiring Cautions

3. Tool Connector

4. Ethernet Cable Connector

5. IP Address Settings

6. Dip Switch Settings

3 Installation and Wiring

3.1

Installation

The following information explains how to attach a 35mm DIN rail to the Factory

Gateway.

Attachment

Place the unit's curved, bottom lip over the bottom of the DIN rail, and tilt the unit up until the top face attachment clip clicks into place.

Factory

Gateway

DIN Rail

• Be sure that the top and bottom faces of the unit are correctly oriented and that the unit is vertical. Incorrect installation may prevent heat from dissipating correctly.

• When removing the unit from the attachment clips, hold the unit with your hand to prevent it from falling. To prevent the Factory Gateway unit from being dislodged from the DIN Rail due to being struck or bumped from the side, the following Stabilizer Clips are recommended.

BNL5P (IDEC Corporation)

HDV-1 (TOYO GIKEN Corporation)

Up

Removal

Use a standard screwdriver to force the unit's attachment clip up until the top of the unit is freed from the rail. Next, tilt the unit down and remove.

Standard

Screwdriver

DIN Rail

When removing the unit from the attachment clips, hold the unit with your hand to prevent it from falling.

Factory Gateway Series User Manual

3–1

Chapter 3 – Installation and Wiring

3.2

Wiring Cautions

3.2.1

Connecting the Power Cord

WARNINGS

To avoid an electric shock, be sure the power cord is unplugged from the power supply when connecting the power terminals to the Factory Gateway unit.

The Factory Gateway-SE41-24V uses a DC 24V power supply. If the power supply is outside of the rated voltage range, both the power supply and the Factory Gateway unit can be damaged.

The Factory Gateway unit is not equipped with a power switch. Therefore, be sure to connect a breaker-type power switch to the Factory Gateway unit’s power cord.

• Be sure to connect the FG terminal to earth. Otherwise, electrical shock may occur if the unit breaks down.

• To prevent the Ring Terminals from short-circuiting when the terminal block attachment screws are loosened, use sleeve-type Ring Terminals.

• When the FG terminal is connected, be sure that the wire is grounded.

Not grounding the Factory Gateway unit will result in excessive noise.

Use your country’s applicable standard for grounding.

• Whenever possible, use thick wires (2mm 2 max.) for power lines, and twist the exposed wire ends when connecting the Ring Terminals.

• Use the following crimp-on type Ring Terminals.

Over

φφφφφ

3.2 mm [0.13 in.]

Under 6.0 mm

[0.24 in.]

Ring Terminal

3–2

Factory Gateway Series User Manual

Chapter 3 – Installation and Wiring

Ring Terminals* 1

Power Input

Terminal Block

Front

+

FG

Positive electrode

Negative electrode

Grounding Terminal connected to the GLC chassis.

To connect the power supply lines:

1. Make sure the Factory Gateway unit’s power cord is not plugged in to the power supply.

2. Remove the Terminal Strip’s clear plastic cover.

3. Remove the terminal attachment screws from the three (3) middle terminals, position the Ring Terminals on the correct electrode, and reattach the screws.

See 3.2.2 – “Connecting the Power Supply.”

• Be sure that each Ring Terminal is connected to the correct terminal.

• Use a torque of only 0.5 to 0.6 N•m to tighten the terminal attachment screws.

4. Reattach the Terminal Strip’s clear plastic cover.

Factory Gateway Series User Manual

3–3

Chapter 3 – Installation and Wiring

3.2.2

Connecting the Power Supply

• When supplying power to the Factory

Gateway unit, separate the input/output and operation unit lines (see Diagram 1).

• To increase the noise resistance quality of the power cord, twist each power wire before attaching the Ring Terminal.

• The power supply cord must not be bundled or positioned close to main circuit lines (high voltage, high current), or input/output signal lines (see Diagram

2).

• Connect a lightning surge absorber (see

Diagram 3) to deal with power surges.

• To avoid excess noise, make the power cord as short as possible.

Dia. 1

Main power

Factory

Gateway power

Factory

Gateway

Input/

Output power

Input/

Output power

I/O device

Dia. 2

Main power

Factory

Gateway power

Factory

Gateway

I/O device

I/O device

Operation unit

Main circuit power

• Ground the surge absorber

(E1) separately from the Factory Gateway unit (E2).

• Select a surge absorber with a maximum circuit voltage that is greater than that of the power supply’s peak voltage.

Dia. 3

Factory

Gateway

Lightning surge absorber

3–4

Factory Gateway Series User Manual

Chapter 3 – Installation and Wiring

3.2.3

Grounding

CAUTION

Do NOT use common grounding, since it can lead to an accident or machine breakdown.

Connect the

FG

terminal found on the back of the

Factory Gateway

to an exclusive ground (diagram A).

(A) Exclusive Grounding (BEST)

• Make sure that the grounding resistance is less than 100

.

• The FG and SG lines are connected internally in the Factory Gateway.

• The grounding wire should have a cross-sectional area of at least

2 mm 2 . Create the grounding point as close to the Factory Gateway unit as possible, and keep the wire as short as possible. Replace thin wire with a thicker wire, and place it in a duct.

If exclusive grounding is not possible, use a common connection point (diagram B).

(B) Common Grounding (OK)

(C) Common Grounding (Not OK)

If the equipment does not function properly when grounded, disconnect the ground wire from the FG terminal.

Factory Gateway Series User Manual

3–5

Chapter 3 – Installation and Wiring

3.2.4

I/O Signal Line Cautions

• To help prevent noise and interference problems, separate all communication lines from power lines by placing them in a separate duct.

• If different wires must be placed in the same duct, separate them with an earthed/ grounded divider.

3.3

Tool Connector

A data transfer cable can be attached to the Factory Gateway unit’s tool connector.

The location of the Factory Gateway unit’s tool connector is shown in the following diagram.

WARNING

To prevent an electrical shock, be sure to unplug the

Factory Gateway unit’s power cord from the main power supply prior to attaching or detaching any connectors to or from the Factory Gateway.

Tool Connector

Front Face

3–6

Factory Gateway Series User Manual

Chapter 3 – Installation and Wiring

3.4

Ethernet Cable Connector

The Factory Gateway Ethernet interface is IEEE802.3 compliant, and transmits data at

10 Mbps. The Ethernet connector’s location is shown below.

Ethernet Interface

Pro-face strongly recommends that a trained engineer install your Ethernet network.

3.5

IP Address Settings

To set the Factory Gateway unit’s IP address, the 8 side face rotary switches are used.

To set these switches, you must first remove the right face Rotary Switch Cover. The factory settings are all “0”.

Also, the Factory Gateway unit’s IP address is set using HEX.

The example below uses an IP address (DEC) of 192.168.0.1.

Decimal

Hexadecimal

192

C0

168

IP Address

0

A8 00

1

01

Rotary Switch Settings

• Be sure to enter all IP address settings prior to connecting the Factory Gateway unit to the power supply. If power is connected to the Factory Gateway unit prior to setting these switches, a communication (2-Way feature) error will occur. In this case, please disconnect the Factory Gateway unit’s power supply, set these switches, and reconnect the power supply.

Factory Gateway Series User Manual

3–7

Chapter 3 – Installation and Wiring

• The “Subnet Mask” and “Default Gateway” settings are not set via these switches. They are set using the Pro-Server with Pro-

Studio for Windows software and then sent to the Factory Gateway unit.

See Pro-Server with Pro-Studio for Windows

Operation Manual.

• The IP Addresses should be set as follows:

00.00.00.01 -> 7F.FF.FF.FE (0.0.0.1 to 127.255.255.254)

80.00.00.01 -> BF.FF.FF.FE (128.0.0.1 to 191.255.255.254)

C0.00.00.01 -> DF.FF.FF.FE (192.0.0.1 to 223.255.255.254)

• After setting the IP Addresses, be sure to reattach the cover.

3.6

Dip Switch Settings

The Factory Gateway unit’s Dip Switches are used to set the following features:

- Startup Transfer Mode

- Initialize Internal Memory

- Enable System Data Overwrite

- Enable 2-Way Driver Overwrite

The switches are numbered from one to eight,

from bottom to top. Factory settings are OFF.

Switch

No.

1

2

Feature ON OFF Note

3

4

5

6

7

8

Reserved

Reserved

Startup transfer mode

*1

Initialize internal memory

*2

Enable System Data Overwrite

*3

Enable 2-Way Driver Overwrite

*3

Reserved

Reserved

Normally OFF

Normally OFF

Startup in transfer mode

Startup in on-line mode

Normally OFF

Initialize internal memory at start up

Do NOT initialize memory at start up

Normally OFF

Overwrite Enabled Overwrite Disabled Normally OFF

Overwrite Enabled Overwrite Disabled Normally OFF

Normally OFF

Normally OFF

*1 Normally, the Factory Gateway automatically changes to transfer mode. To disable this, use DIP switch No.1. Also, be sure to set the switch back to OFF after data transfer is completed. (If the PWR LED has changed to orange, the unit has changed to transfer mode.)

*2 Normally, the Factory Gateway reboots the system after data transfer. If Switch

No.4 is left ON, every time the Factory Gateway transfers data, internal memory’s data will be initialized (deleted). After you finish using Switch No.4, be sure to set the switch to OFF before transferring data again.

*3 The System and the 2-Way Driver data can only be overwritten using GP-PRO-

PBIII for Windows.

3–8

Factory Gateway Series User Manual

Chapter 3 – Installation and Wiring

• DIP switches are used to help the Factory Gateway recover from errors. Turning a switch ON forces that switch’s feature, such as initializing internal memory, ON. To ensure the integrity of your data, please keep these switches OFF when they are not being used.

• When changing the Dip Switches, be sure the tool/item you use is insulated, to prevent accidental damage to the unit.

3.6.1

Initializing Memory

Use the following steps to initialize the Factory Gateway unit’s memory.

1. Turn the Factory Gateway unit’s power supply OFF.

2. Set dipswitch 4 to ON.

3. Turn the Factory Gateway unit’s power supply ON.

4. The Factory Gateway unit’s power (PWR) LED will change from green to red.

(approximately 10 seconds is required for initialization.)

5. The Factory Gateway unit’s power (PWR) LED will change from red to green.

6. After checking that the Factory Gateway unit’s power (PWR) LED has changed to orange, turn the Factory Gateway unit’s power supply OFF.

7. Set dipswitch 4 to OFF.

8. Turn the Factory Gateway unit’s power supply ON.

Dip Switch 4’s initialization can be used for Ethernet-related information (Serial communication settings, Sub-net mask, distribution data, etc.), Network Project data, and screen data. System program, 2-Way Driver, and PLC communication protocol data cannot be initialized.

Factory Gateway Series User Manual

3–9

Chapter 3 – Installation and Wiring

Memo

3–10

Factory Gateway Series User Manual

1. Troubleshooting

2. Periodic Instection

Chapter

4 Troubleshooting

4.1

Troubleshooting

The following information explains how to troubleshoot the Factory Gateway unit.

The first steps should always be to check the following items.

• Is the Factory Gateway receiving the correct level of power?

• Is the Device/PLC receiving the correct level of power?

• Is the Factory Gateway correctly connected tot he Device/PLC?

• Is the Factory Gateway unit’s current protocol data correct for the type of

Device/PLC that is connected?

For details about the Factory Gateway Configuration Tool Error Messages, refer to the Factory Gateway Configuration Tool Operation Manual.

Factory Gateway Configuration Tool Operation Manual

Factory Gateway Series User Manual

4–1

Chapter 4 – Troubleshooting

4.1.1 LED Status Indicators

The Factory Gateway unit uses two LED indicators (PWR nad STA) to display the status of the Factory Gateway unit.The following table describes the problems indicated by these LEDs, and gives suggestions for how to solve each problem.

Lamp Name

PWR STA

OFF

Green

Red

Problem/Condition Possible Solution(s)

OFF

Green

Red

Orange

OFF

Green

Red

Orange

OFF

Green

Red

Orange

No power

Normally OFF

Normally OFF

Normally OFF

System Program Error

Power supply is not operating.

Power terminal are not connected.

Power cord is cut or damaged.

If lit, a hardware error has occurred.

If lit, a hardware error has occurred.

If lit, a hardware error has occurred.

Next, turn dipswitches 5 and 6 ON and perform forced setup using GP-PRO/PBIII for Windows. Be sure to also send 2-

Way Driver data.

(Normal status)

No problem

System Error/ Screen

Data Memory Error

(ONLINE)

T urn Dip Switch #4 ON and restart the unit. After memory is initialized, turn dip switch 4 OFF. Next, turn dipswitches 5 and 6 ON and perform forced setup using GP-PRO/PBIII for

Windows. Be sure to also send 2-Way Driver data.

Error (from external source)

Possibly interference or static from power line or input line noise. Either separate these lines, or ground the unit's FG

Factory Gateway Error terminal according to your country's regulations.

If lit, a hardware error has occurred.

Incorrect IP Address Correct the unit's current rotary switch IP Address settings.

Sub-net Mask Error

Check the unit's rotary switch IP Address settings and the

Network Project's Sub-net Mask settings.

Check is there is a problem with the Network Project's

2-Way Error

2-Way Driver Error

Provider information.

T urn Dip Switch #4 ON and restart the unit. After memory is initialized, turn dip switch 4 OFF. Next, turn dipswitches 5 and 6 ON and perform forced setup using GP-PRO/PBIII for

Normally OFF

Now initializing memory

(normal)

Windows. Be sure to also send 2-Way Driver data.

If lit, a hardware error has occurred.

After initialization is completed, PWR turns orange and ST A turns green. T urn Dip Switch 4 OFF when completed.

System Error/ Screen

Data Memory Error

(Now initializing memory)

T urn Dip Switch #4 ON and restart the unit. After memory is initialized, turn dip switch 4 OFF. Next, turn dipswitches 5 and 6 ON and perform forced setup using GP-PRO/PBIII for

Windows. Be sure to also send 2-Way Driver data.

After initialization is completed, PWR turns orange and ST A

2-Way Error

(Now initializing memory) turns green. T urn Dip Switch 4 OFF when completed. When unit restarts, PWR and ST A both turn green.

4–2

Factory Gateway Series User Manual

Chapter 4 – Troubleshooting

Lamp Name

PWR STA

Orange

Problem/Condition Possible Solution(s)

OFF

Green

Red

Orange

System Program Error

Next, turn dipswitches 5 and 6 ON and perform forced setup using GP-PRO/PBIII for Windows. Be sure to also send 2-

Way Driver data.

Factory Settings

(customer enters only

IP address)

Now transferring

Download Provider information and protocol data from Pro-

Studio.

Unit is operating normally and sending data.

Possibly interference or static from power line or input line

Error (from external source) noise. Either separate these lines, or ground the unit's FG terminal according to your country's regulations.

System Error/ Screen

Data Memory Error

(Data transfer error)

T urn Dip Switch #4 ON and restart the unit. After memory is initialized, turn dip switch 4 OFF. Next, turn dipswitches 5 and 6 ON and perform forced setup using GP-PRO/PBIII for

Windows. Be sure to also send 2-Way Driver data.

Factory Gateway Error

Factory Settings

(customer has not entered IP address)

Possible hardware error.

IP Address has not yet been entered. Set this data via the unit's side-face rotary switches. After unit is restarted, PWR turns orange and ST A turns green.

Incorrect IP Address Correct the unit's current rotary switch IP Address settings.

Check the unit's rotary switch IP Address settings and the

Sub-net Mask Error

Network Project's Sub-net Mask settings.

T urn Dip Switch #4 ON and restart the unit. After memory is

2-Way Driver Error initialized, turn dip switch 4 OFF. Next, turn dipswitches 5 and 6 ON and perform forced setup using GP-PRO/PBIII for

Windows. Be sure to also send 2-Way Driver data.

When a hardware error occurs, please contact your local Proface distributor for service and repair.

Factory Gateway Series User Manual

4–3

Chapter 4 – Troubleshooting

4.1.2 Problem Solving

The following data explains possible solutions for Factory Gateway unit related problems.

Connecting power causes the unit to initialize memory (PWR LED red -> orange)

CAUSE: Dip Switch #4 is turned ON.

SOLUTION: Turn Dip Switch #4 OFF and restart the Factory Gateway unit.

Unable to Transfer Data

CAUSE 1: Dip Switch #3 is turned ON, setting the unit in transfer mode.

SOLUTION: Turn Dip Switch #3 OFF and restart the Factory Gateway unit.

CAUSE 2: The protocol transferred to the Factory Gateway unit is incorrect.

SOLUTION: Check the Pro-Studio Status Monitor to confirm the type of PLC the Factory Gateway is connected to. Send new protocol if necessary.

CAUSE 3: The Ethernet type’s protocol has been sent.

SOLUTION: The Factory Gateway is not designed to work with the Ethernet protocol. Send the correct protocol to the Factory Gateway from the

GP-PRO/PBIII for Windows software, using the forced setup.

CAUSE 4: The Subnet Mask and the Default Gateway have been initialized.

SOLUTION: When Disp Switch #4 is used to initialize the unit, the Subnet Mask and the Default Gateway are also initialized. To use these items again, resend that data from Pro-Studio.

For information about the Sub-net Mask and the default Factory

Gateway settings,refer to

Factory Gateway Configuration Tool Operation Manual

Also, the port number will revert to 8000 after initialization. Thus, if the Factory Gateway unit tries to use a port other than 8000, data transfer cannot be performed.

(Use of Port No. 8000 is recommended.)

4–4

Factory Gateway Series User Manual

Chapter 4 – Troubleshooting

GP-Viewer Screens Cannot be Displayed

CAUSE: When data is sent from the Factory Gateway Configuration Tool, screen data is deleted.

SOLUTION: GP-Viewer screen data includes protocol data as well. However, if the Factory Gateway Configuration Tool software is used to change the Factory Gateway unit’s protocol, the new protocol in the Factory Gateway unit will be different from the previous protocol.

To prevent a possible data/protocol type conflict, however, the Factory Gateway Configuration Tool automatically deletes all existing Factory Gateway screen data prior to sending a new protocol. This, however, means that there is now no data for

GP-Viewer to read out and display.

To prevent this type of problem, when using Pro-Viewer to view

Factory Gateway data be sure to always use GP-PRO/PRIII to send both screen and protocol data to the Factory Gateway unit.

4.2

Periodic Check Points

To keep your Factory Gateway unit in its best condition, inspect the following points periodically.

Operation Environment

• Is the operating temperature within the allowable range (0

°

C to 55

°

C)?

• Is the operating humidity within the specified range (10%RH to 90%RH, wet bulb temperature of 39

°

C or less)?

• Is the operating atmosphere free of corrosive gasses?

Electrical Specifications

• Is the input voltage (DC 19.2V to DC 28.8V) appropriate?

Related Items

• Are all power cords and cables connected properly? Have any become loose?

• Is the DIN rail holding the unit securely?

Factory Gateway Series User Manual

4–5

Chapter 4 – Troubleshooting

Memo

4–6

Factory Gateway Series User Manual

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
