Spot LXi Service Manual 704432

Spot LXi Service Manual 704432

Welch Allyn Spot Vital Signs

SYS kPa (mmHg)

DIA kPa (mmHg)

%

/ min

Service Manual

Spot Vital Signs

Welch Allyn Spot Vital Signs

Service Manual

ii

Welch Allyn Spot Vital Signs

Copyright 2007 Welch Allyn. All rights are reserved. No one is permitted to reproduce or duplicate, in any form, this manual or any part thereof without permission from Welch Allyn.

Welch Allyn assumes no responsibility for any injury to anyone, or for any illegal or improper use of the product, that may result from failure to use this product in accordance with the instructions, cautions, warnings, or statement of intended use published in this manual.

Welch Allyn

®

and Spot Vital Signs

®

are registered trademarks of Welch Allyn.

LNCS

is a trademark of, and SET

®

, LNOP

®

, and Masimo

®

are registered trademarks of, Masimo

Corporation. Possession or purchase of a Masimo SpO

2

-equipped device does not convey any express or implied license to use the device with unauthorized sensors or cables which would, alone or in combination with this device, fall within the scope of one or more of the patents relating to this device.

Nellcor

®

and Oxi-Max

®

are registered trademarks of Nellcor Puritan Bennett Inc.

Software in this product is Copyright 2007 Welch Allyn or its vendors. All rights are reserved. The software is protected by United States of America copyright laws and international treaty provisions applicable worldwide. Under such laws, the licensee is entitled to use the copy of the software incorporated with this instrument as intended in the operation of the product in which it is embedded. The software may not be copied, decompiled, reverse-engineered, disassembled, or otherwise reduced to human-perceivable form. This is not a sale of the software or any copy of the software; all right, title, and ownership of the software remain with Welch Allyn or its vendors.

For information about any Welch Allyn product, call Welch Allyn Technical Support:

USA +1 800 535 6663

+ 1 315 685 4560

Canada +1 800 561 8797

European Call Center +353 46 90 67790

Germany +49 7477 9271 70

Latin America +1 305 669 9003

Singapore +65 6419 8100

United Kingdom +44 207 365 6780

Australia +61 2 9638 3000

+800 074 793

China +86 21 6327 9631

France +33 1 55 69 58 49

Japan +81 3 3219 0071

Netherlands +31 157 505 000

South Africa +27 11 777 7555

Sweden +46 85 853 6551

Reorder No. 4200-89E

Manual Material No. 706317 Rev. K

Welch Allyn

4341 State Street Road

Skaneateles Falls, NY 13153 USA

Printed in USA

0297

Service Manual

Revision Information

Date

3/31/01

12/17/01

9/12/02

02/02/03

05/01/03

09/16/03

12/12/03

3/9/06

3/21/07

3/21/07

ECN # Revision Description

A Introduction of Service Manual

B

C

Originator Approval

JDB

Correction made to Section 1 regarding temperature accuracy,

Section 2 regarding part numbers, Section 3 regarding error codes, and updates to the drawings

JDB

Added New PCB layout and schematic for Spot Extensions.

Added tool SRC-MAX to tool list in Section 2.3. Removed old PCB and Old SpO

2

SpO

2

PCB and replaced with new Main PCB and New

PCB in section 2.4. Changed section 4.7 to cover both Spot and Spot Extensions SpO

2

PCB removal and replacement.

Changed section 5.8 to cover both Spot and Spot Extension SpO

2 testing. General Spelling and grammar clean up.

JDB

JDB

JDB

JDB

5-45656 D DLK

5-45893

5-46550

5-46989

E

F

G

Arden document release to SKF. Updated USA Service Center contact information.

Correction to tools required for service. Corrected General

Information phone numbers.

JDB

DLK

Updates repair BOM. Updated Accessories. Re-formated manual to meet Welch Allyn service manual work instructions.

DLK

Correction to page numbering and to voltage calibrations. Reformatted all systems of measurement to meet NIST Standards.

Reformatted Appendix E. Corrected grammar and punctuation.

Revised service and support details in Section 1. Removed schematics.

DLK

DLK

DLK

RJS

1007069 H

XXXXXX J

1010684 K

Removed references to Nellcor motion tolerance.

SAP new version glitch

AMJ

AMJ

Update section on Setting the Date and Time. Include testing and disassembly/assembly for the Masimo SpO

2 updated repair parts lists.

feature and

AMJ

JPK

FL

FL

iii

Drawings and/or illustrations and/or part numbers in this document are for reference only. For the most

current revision call the Welch Allyn Customer Service phone number (see page ii).

iv

Welch Allyn Spot Vital Signs

Contents

1 - Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Warnings and cautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

General warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Blood pressure warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

SpO

2

warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Temperature warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

IR communications port warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

General cautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Blood pressure cautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

SpO

2 cautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Temperature cautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Electrostatic discharge (ESD) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Safety symbols. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Agency symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

2 - Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Purpose and scope . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Other applicable documents. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Contents checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Possible attachments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Technical assistance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Field replacement units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Service loaners. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Service intervals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Spot Vital Signs configurations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

LCD (liquid crystal display) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Blood pressure hose and cuff connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Temperature probe connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

SpO

2

sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Quick reference card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

DCpower connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Charging the battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Standby mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

v

vi

Contents Welch Allyn Spot Vital Signs

3 - Functional overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Power on/off and system check procedure. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Internal configuration mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Functional verification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Temperature functional check. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

SpO2 functional check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

4 - Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Voltage calibration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Blood pressure calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Date/time set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

5 - Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Error codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Causes and corrective action . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Battery voltage check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Window display check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Blood pressure calibration check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Temperature functional check. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Masimo SpO

2

functional check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Nellcor SpO

2

functional check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Communication option check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Functional testing procedures. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Current test. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Noise levels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Button test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Interface test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Print quality . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Pneumatic tests . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Fail safe (over pressure) test. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Service work checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

6 - Disassembly and repair . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Battery disassembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Temperature disassembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Front housing and key pad disassembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

LCD disassembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Power and battery cable disassembly. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Main printed circuit board assembly. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

SpO

2

circuit board disassembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Masimo board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Nellcor board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Pump and valve disassembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

7 - Technical overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

System description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

Battery /charge system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

Service Manual Contents

vii

Main CPU power supply. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

Clock/calendar power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

Mod B NIBP power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

Thermometer power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

SpO

2

power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

LCD power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

Communications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

Interconnect diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

8 - Field replaceable units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

9 - Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Patient population . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Blood pressure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Pulse pximetry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

Masimo sensor accuracy guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

Masimo patents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

Nellcor® sensor accuracy guide. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Nellcor patents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

Mechanical . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

Electrical . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

Environmental. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

Guidance and manufacturer’s declaration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

Emissions and immunity information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

Patents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

Identification label and serial numbering system . . . . . . . . . . . . . . . . . . . . . . . . 67

Firmware identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

10 - Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

Spot Vital Signs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

Blood pressure cuff . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

Cables and pressure hose . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

Temperature probe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

SpO

2

sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

Battery removal and replacement. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

Masimo SpO

2

calibration check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

Nellcor SpO

2

functional check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

SpO

2

accessory disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

Temperature calibration check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

A - Repair test specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

General unit test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

A-D noise test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

Leak test. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

Inflation test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

Dump test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

viii

Contents Welch Allyn Spot Vital Signs

Pneumatic calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74

Pneumatic accuracy test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74

Valve control test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74

Voltage calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74

Blank mode current test. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74

Back light (Idle) current test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

Valve/pump mode current test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

Interface test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

Temperature option requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

Accuracy test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

Temperature probe test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

SpO

2

option requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

SpO

2 functional test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

SpO

2

mode current test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

Fail safe test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76

Over pressure test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76

Over 15 mmHg. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76

B - Supplies and Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77

Latex-free blood pressure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77

Pulse oximetry accessories and supplies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78

Masimo . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78

Nellcor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79

Temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

Extended warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

Miscellaneous. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81

C - Miscellaneous Mounting Accessories. . . . . . . . . . . . . . . . . . . . . . . 83

Wall mount kit (REF 4200-62) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83

Mobile stand kit (REF 4200-60) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84

IV pole mount accessory (REF 4200-64). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85

Anti-theft kit (REF 4200-70) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86

Transformer mounting plate accessory (REF 4200-75). . . . . . . . . . . . . . . . . . . . 87

IR dongle mounting accessory (REF 4200-170) . . . . . . . . . . . . . . . . . . . . . . . . . 88

Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89

Spot Vital Signs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89

Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89

1

Introduction

Welch Allyn has updated the Spot Vital Signs from its original configuration; offering a

Pressure Preset option (Version 2,

page 14 ) instead of a Print option (Version 1,

page 13 ).

In addition, some Version 2 configurations offer Masimo SpO

2

technology.

Table 1. Version comparison

Function/Appearance

Available option

Available SpO

2

capability

Bezel and switch array color

Version 1

(serial number less than

200705000)

Print

Nellcor

Black bezel/multi-colored switch array

Version 2

(serial number 200705000 and above)

Pressure Preset

Masimo or Nellcor

Blue

Warnings and cautions

Familiarize all operating personnel with the general safety information in this summary.

Specific warnings and cautions are also found throughout this manual. Such specific warnings and cautions may not appear here in this summary.

General warnings

A warning statement in this manual identifies a condition or practice, which if not corrected or discontinued immediately, could lead to patient injury, illness, or death.

WARNING The Welch Allyn Spot Vital Signs is designed for use by medical clinicians. Although this manual may illustrate medical spot check techniques, only a trained clinician who knows how to take and interpret a patient’s vital signs should use this system.

WARNING The information in this manual is a comprehensive guide to the operation of the Welch Allyn Spot Vital Signs. To achieve satisfactory results, you should read the manual thoroughly before attempting to use the device.

WARNING Spot Vital Signs is not intended to take measurements on neonatal patients. The AAMI SP10:1992 standard defines neonates as children 28 days or less of age if born at term (37 weeks gestation or more); otherwise up to 44 gestational weeks.

WARNING The Welch Allyn Spot Vital Signs is not defibrillator proof.

1

2

Introduction Welch Allyn Spot Vital Signs

WARNING The Welch Allyn Spot Vital Signs is not intended for continuous monitoring. Do not leave the device unattended while taking measurements on a patient.

WARNING To ensure patient safety, use only accessories and supplies (i.e., blood pressure cuffs, hoses, temperature probes, SpO

2

sensors, etc.) recommended for or supplied with Spot Vital Signs. Using unapproved accessories with Spot Vital Signs can affect patient and/or operator safety.

WARNING This device is not suitable for use in the presence of a flammable anesthetic mixture with air or oxygen or nitrous oxide. An explosion may result.

WARNING Avoid compression of the blood pressure cuff tubing or pressure hose of the Welch Allyn Spot Vital Signs. Compression of the cuff tubing or pressure hose may cause system errors to occur in the device.

WARNING Care should be taken to prevent water or other fluid from entering any connectors on the device. Should this occur, the connectors should be dried with warm air. All operating functions should then be checked for proper operation.

WARNING Any Spot Vital Signs which has been dropped or damaged should be checked by qualified service personnel to ensure proper operation prior to use. Do not use the Welch Allyn Spot Vital Signs if you notice any signs of damage.

Contact the Welch Allyn Customer Service Department for assistance.

WARNING Every three months, inspect the temperature probe, SpO

2 cord, and accessories for fraying or other damage. Replace as necessary.

WARNING There are no user-serviceable parts inside the device other than battery replacement. Refer Spot Vital Signs to the Authorized Service Center.

WARNING The Spot Vital Signs should not be used on patients who are linked to heart/lung machines.

WARNING The Spot Vital Signs does not operate effectively on patients who are experiencing convulsions or tremors.

WARNING This device complies with current required standards for electromagnetic interference and should not present problems to other equipment or be affected by other devices. As a precaution, avoid using this device in close proximity to other equipment.

WARNING This device is not intended for hand-held use during operation.

WARNING Welch Allyn recommends leaving the battery in the device, regardless if the device is not used for long periods of time, since there is no hazard of leaving the battery in the device.

WARNING Do not autoclave.

WARNING Welch Allyn is not responsible for the integrity of any mounting installation. Welch Allyn recommends that the customer contact their Biomedical

Engineering Department or maintenance service to ensure professional installation for safety and reliability of any mounting accessory.

Service Manual Introduction

3

Blood pressure warnings

WARNING To ensure pediatric blood pressure accuracy and safety, the Welch

Allyn Child Print Cuff (5200-03), the Welch Allyn Small Child Durable One-Piece

Cuff (5082-203-3), and the Welch Allyn Small Child Disposable One-Piece Cuff

(5082-93-3) are the smallest cuffs allowed for use with young children and infants.

The circumference of the child’s arm must fit within the range markings on the cuff.

WARNING You may experience inaccurate blood pressure measurements if blood pressure cuffs and/or hoses other than those provided by Welch Allyn for the Spot Vital Signs are used.

WARNING Patients who are experiencing moderate to severe arrhythmias may give inaccurate blood pressure measurements.

WARNING When several blood pressure measurements are taken on the same patient, it is recommended that the blood pressure cuff site and extremity are checked regularly for possible ischemia, purpura, and/or neuropathy.

WARNING Do not change the connector(s) on the blood pressure cuff tubing of this device to luer type. Luer type connectors are commonly used in intravenous infusion systems. Using the luer connectors on blood pressure cuff tubing creates the risk that the blood pressure tubing could be mistakenly connected to a patient's intravenous line, resulting in the introduction of air into the patient's circulatory system.

4

Introduction Welch Allyn Spot Vital Signs

SpO

2

warnings

WARNING Only use Spot Vital Signs with Masimo or Nellcor SpO

2

option with

Masimo or Nellcor brand sensors and accessories, respectively. Using the wrong or unapproved sensors or cables may cause improper performance.

WARNING The SpO

2

sensors and extension cables are intended for use only for pulse oximetry measurements. Do not attempt to connect these cables to a PC or any similar device.

WARNING Before use, carefully read the sensor’s directions for use, including all warnings, cautions, and instructions.

WARNING Do not use a damaged sensor or SpO

2

cable. Do not use a sensor with exposed optical components.

WARNING Tissue damage can be caused by incorrect application or duration of use of an SpO

2

sensor. Inspect the sensor site as directed in the sensor’s

Directions for Use.

WARNING Do not use the sensors during magnetic resonance imaging (MRI) scanning. Induced current could potentially cause burns. The pulse oximeter may affect the MRI image, and the MRI unit may affect the accuracy of the pulse oximetry measurements.

WARNING Certain ambient environmental conditions, sensor application errors, and certain patient conditions may affect SpO

2

readings and pulse signal.

WARNING Do not immerse the sensor or patient cables in water, solvents, or cleaning solutions (the sensors and connections are not waterproof). Do not use irradiation, steam, or ethylene oxide for sterilization.

WARNING Do not use the SpO

2

cable or power cord to lift the unit because the cable or cord could disconnect from the unit, causing the unit to drop on the patient.

WARNING The SpO

2

in the Welch Allyn Spot Vital signs is not intended for use as an apnea monitor.

WARNING Consider the SpO

2

an early warning device. As a trend toward patient deoxygenation is indicated, use laboratory instruments to analyze blood samples to completely understand the patient’s condition.

Service Manual Introduction

5

Temperature warnings

WARNING Single-use, disposable probe covers, available from Welch Allyn, limit patient cross-contamination. The use of any other probe cover or the failure to use a probe cover may produce temperature errors and is specifically not recommended.

WARNING Use only oral probes (blue cap) for taking oral and axillary temperatures. Use only rectal probes (red cap) for taking rectal temperatures. The use of the wrong probe may produce temperature errors.

WARNING Do not allow the tip of the temperature probe to come into contact with any heat source (e.g., hands or fingers) prior to taking a temperature measurement. If this occurs, discard the probe cover and start the temperature determination again.

WARNING Long-term continuous monitoring beyond three to five minutes is not recommended in any mode.

IR communications port warnings

WARNING The Welch Allyn Spot Vital Signs contains an infrared communications port for isolated communications with external devices. The port is located on the side of the device to preclude direct eye contact on a continual basis when viewing the display. As a precaution, do not look directly into the infrared port during operation.

General cautions

A caution statement in this manual identifies a condition or practice, which if not corrected or discontinued immediately, could lead to equipment failure, equipment damage, or data loss.

Caution If the accuracy of any measurement is in question, check the patient's vital sign(s) by an alternate method, then check to make sure the device is functioning properly.

Caution Ensure the device is placed on a secure surface or use one of the optional mounting accessories.

Caution Do not place fluids on the device.

6

Introduction Welch Allyn Spot Vital Signs

Blood pressure cautions

Caution Extremity and blood pressure cuff motion should be minimized during blood pressure determinations.

Caution If the blood pressure cuff is not at heart level, the difference in reading due to the hydrostatic effect should be noted. The value of 1.80 mmHg must be added to the displayed reading for every inch (2.5 cm) above heart level. The value of 1.80 mmHg must be subtracted from the displayed reading for every inch (2.5 cm) below heart level.

Caution Proper blood pressure cuff size and placement is essential to the accuracy of the blood pressure determination.

Caution When measuring blood pressure on children younger than 3 years of age, it is recommended that the Pressure Preset (initial inflation pressure) be set at 160 mmHg or lower.

SpO

2

cautions

Caution The pulse oximeter is calibrated to determine the percentage of arterial oxygen saturation of functional hemoglobin. Significant levels of dysfunctional hemoglobin such as carboxyhemoglobin or methemoglobin may affect the accuracy of the measurement.

Caution Physiological conditions, medical procedures, or external agents that may interfere with the pulse oximeter’s ability to detect and display measurements include dysfunctional hemoglobin, arterial dyes, low perfusion, dark pigment, and externally applied coloring agents such as nail polish, dye, or pigmented cream.

Caution Some sensors may not be appropriate for a particular patient. If at least

15 seconds of perfusion pulses cannot be observed for a given sensor, change sensor location or sensor type for perfusion to resume.

Caution When selecting a sensor, consider the patient’s weight and activity level, the adequacy of perfusion, the available sensor sites, the need for sterility, and the anticipated duration of monitoring.

Temperature cautions

Caution The Welch Allyn Spot Vital Signs is FDA cleared to measure the axillary temperature in Normal Mode for children under the age of 4. Normal Mode axillary temperatures may not be accurate on older children or adults. THE

WELCH ALLYN SPOT VITAL SIGNS IS NOT INTENDED TO BE USED ON

NEONATAL PATIENTS.

Service Manual

Electrostatic discharge (ESD)

Introduction

7

Electrostatic discharge is a sudden current flowing from a charged object to another object or to ground. Electrostatic charges can accomulate on common items such as foam drinking cups, cellophane tape, synthetic clothing, untreated foam packaging material, and untreated plastic bags and work folders, to name only a few.

Electronic components and assemblies, if not properly protected against ESD, can be permanently damaged or destroyed when near or in contact with electrostatically charged objects. When you handle components or assemblies that are not in protective bags and you are not sure whether they are static-sensitive, assume that they are static-sensitive and handle them accordingly.

• Perform all service procedures in a static-protected environment. Always use techniques and equipment designed to protect personnel and equipment from electrostatic discharge.

• Remove static-sensitive components and assemblies from their static-shielding bags only at static-safe workstations - a properly grounded table and grounded floor mat - and only when you are wearing a grounded wrist strap (with a resistor of at least 1 megohm in series) or other grounding device.

• Use only grounded tools when inserting, adjusting, or removing static-sensitive components and assemblies.

• Remove or insert static-sensitive components and assemblies only with monitor power turned off.

• Insert and seal static-sensitive components and assemblies into their original staticshielding bags before removing them from static-protected areas.

Always test your ground strap, bench mat, conductive work surface, and ground cord before removing components and assemblies from their protective bags and before beginning any disassembly or assembly procedures.

8

Introduction Welch Allyn Spot Vital Signs

Symbols

The following symbols are associated with the Spot Vital Signs.

Safety symbols

Agency symbols

s

Identifies information within the manual to avoid injury or equipment failure.

Type BF Equipment

Caution: consult accompanying documents

Handle with Care

Pb

Internally Powered, Lead Acid

Battery

Transport Temperature

Storage Humidity Recycle

Class II Equipment

IPXØ

Equipment is not protected against the ingress of liquid.

Do not dispose of this product as unsorted municipal waste. Prepare this product for reuse or separate collection as specified by Directive 2002/96/EC of the European Parliament and the

Council of the European Union on Waste Electronic and Electrical Equipment (WEEE). If this product is contaminated, this directive does not apply.

For more specific disposal information, see www.welchallyn.com/weee, or contact Welch Allyn Customer Service at +44 207 365 6780.

Mode of Operation: Continuous

C

166292

US

0297

EC REP

CERTIFIED TO:

CAN/CSA STD C22.2 NO. 601.1

CONFORMS TO:

UL STD 60601-1

IEC 60601-1

The CE mark on this product indicates that it has been tested to and conforms with the provisions noted within the 93/42/EEC Medical Device Directive.

European Regulatory Manager

Welch Allyn Ltd.

Navan Business Park • Dublin Road • Navan, County Meath, Republic of Ireland

Tel.: +353 46 90 67700 • Fax: +353 46 90 67756

2

Overview

Purpose and scope

The Spot Vital Signs Service Manual is intended as a reference for maintenance and repair to the field replaceable unit (FRU) level and are listed on

page 55

. This manual provides the technical qualified service person with troubleshooting information, repair procedures, and calibration and performance verification instructions. A technical overview of the Spot subsystems is provided as an introduction to the device’s circuitry and pneumatics.

This manual is intended for the technical qualified service person. Service training classes on Welch Allyn’s products are available. Contact Welch Allyn Technical Service for information.

Other applicable documents

The Spot Vital Signs Directions for Use manual is also available. Refer to this document for information other than maintenance and repair.

Welch Allyn 9600 Plus Calibration Tester Directions for Use - for all models.

Masimo Directions for Use - for models 42M0B and 42MTB

Nellcor Directions for Use - for models 42N0B and 42NTB

9

10

Overview Welch Allyn Spot Vital Signs

Contents checklist

Unpack the Welch Allyn Spot Vital Signs and applicable accessories, identify each item with the following checklist and inspect for missing items. Retain the shipping materials in the event of shipping damage or for return, if necessary, to Welch Allyn for repair or warranty service. All Spot Vital Signs include the following components:

Spot Vital Signs Device. This device automatically measures and displays blood pressure and pulse rate. Options include thermometry and pulse oximetry.

Directions for Use Manual. Read this manual thoroughly before using Spot Vital Signs.

Save this manual for reference.

Warranty Card. This card validates the Spot Vital Signs warranty. Fill out the warranty card and mail it today.

Blood Pressure Cuff. Latex free blood pressure cuff with connectors. Other size cuffs are available separately.

Blood Pressure Hose. Latex-free pressure hose with connectors to attach various sizes of blood pressure cuffs to the Spot Vital Signs.

AC Power Transformer and Cord Assembly. Provides power to the Spot Vital Signs and charges the internal battery.

Quick Reference/Error Code Card. Attach this quick operating and error code guide to the device handle, mobile stand, or wall mount.

Possible attachments

Spot Vital Signs may include the following items based on the model and accessories purchased:

SureTemp Temperature Probe and Covers. One oral temperature probe (blue cap) and one box of 25 single-use, disposable probe covers.

Pulse Oximetry (SpO

2

). The finger clip SpO

2

sensor and extension cable are for use with adult and pediatric patients. Other sensors are available separately.

Service Manual

Service

Overview

11

Caution Unauthorized repairs will void the warranty.

A Welch Allyn Service Center must perform all repairs on products under warranty.

Unauthorized repairs will void the warranty. Qualified electronics personnel or a Welch

Allyn Service Center should repair products out of warranty.

Technical assistance

If you have an equipment problem that you cannot resolve, call the Welch Allyn Service

Center nearest you for assistance. Technical service telephone support is available on normal business days.

If you are advised to return a product to Welch Allyn for repair or routine maintenance, schedule the repair with the service center nearest you.

Before returning a product for repair, you must obtain authorization from Welch Allyn.

Service personnel will give you a Service Notification number. Returns without a Service

Notification number will not be accepted for delivery.

If you need to return the Spot Vital Signs for service:

• Remove all hoses, cables, sensors, power cords, and any ancillary products not associated with the problem.

• Whenever possible, use the original shipping carton and packing materials.

• Include a packing list and the Welch Allyn Service Notification number.

• Note the Service Notification number on the outside of your shipping container.

It is recommended to insure all returned goods. The sender may initiate any claims for loss or damage to the product.

Field replacement units

Included with the Service Manual is a complete list of field replacement units. Order spare parts from your local Welch Allyn Service Center.

Service loaners

Service loaners are provided, on request, if a Welch Allyn Service Center provides repair service. Loaners for products repaired while under the original warranty, or while under service contract, are provided free of charge and are shipped within 48 hours of notification of need.

For service repairs outside of warranty or contract, loaners are available for a nominal charge and shipment is subject to availability. Loaners are shipped pre-paid; however, this charge is added to the service charges.

12

Overview Welch Allyn Spot Vital Signs

Service intervals

Verify Spot Vital Signs annually for blood pressure calibration, temperature, and SpO

2 accuracy.

Spot Vital Signs configurations

Table 2. Available Versions of Spot Vital Signs

REF

4200B

Description

Spot Vital Signs with blood pressure only

420TB Spot Vital Signs with blood pressure and SureTemp thermometer

42MOB

42NOB

Spot Vital Signs with blood pressure and Masimo SpO

2

*

Spot Vital Signs with blood pressure and Nellcor SpO

2

42MTB

42NTB

Spot Vital Signs with blood pressure, SureTemp thermometer, and Masimo SpO

2

*

Spot Vital Signs with blood pressure, SureTemp thermometer, and Nellcor SpO

2

* Version 2 configurations only.

Service Manual Overview

13

Controls

Figure 1. Spot Vital Signs with SureTemp Plus Thermometer (Version 1)

Thermometer Eject Button: push to remove used temperature probe cover.

Printer: press to print the measurements (Version 1 only).

Mode Button:

• holding for 2 seconds while the display is active turns off/on the backlight.

• in Standby Mode, recalls the last patient information.

• with the temperature probe removed from the probe holder, switches the temperature from

Oral to Axillary Mode.

MODE

SYS kPa (mmHg)

DIA kPa (mmHg)

SpO

2

%

/ min

M

P

C

Next Patient/Clear/Cancel Button:

• active display: clears the display.

• in Standby Mode: recalls the last patient information. Pressing a second time clears the screen.

• cancels an active blood pressure measurement and deflates the cuff.

Blood Pressure Start/Stop Button: initiates a new blood pressure cycle.

Pressing again cancels an active blood pressure measurement and deflates the cuff.

Pressure Hose Connector: port for blood pressure hose.

Power Button: controls power to the device.

14

Overview Welch Allyn Spot Vital Signs

Figure 2. Spot Vital Signs with SureTemp Plus Thermometer (Version 2)

Thermometer Eject Button: push to remove used temperature probe cover.

Pressure Preset Button: press to change the factory inflation default for one reading (Version 2 only).

Mode Button:

• holding for 2 seconds while the display is active turns off/on the backlight.

• in Standby Mode, recalls the last patient information.

• with the temperature probe removed from the probe holder, switches the temperature from

Oral to Axillary Mode.

SYS kPa

(mmHg)

DIA kPa

(mmHg)

SpO

2

%

/ min

Spot Vital Signs

Next Patient/Clear/Cancel Button:

• active display: clears the display.

• in Standby Mode: recalls the last patient information. Pressing a second time clears the screen.

• cancels an active blood pressure measurement and deflates the cuff.

Blood Pressure Start/Stop Button: initiates a new blood pressure cycle.

Pressing again cancels an active blood pressure measurement and deflates the cuff.

Pressure Hose Connector: port for blood pressure hose.

Power Button: controls power to the device.

Service Manual Overview

15

LCD (liquid crystal display)

The LCD may indicate any of the following: systolic blood pressure (mmHg or kPa), diastolic blood pressure (mmHg or kPa), temperature (

°F or °C), thermometer mode, pulse rate, pulse signal level, SpO

2

, MAP (mmHg or kPa), and battery charge level.

.

Option no longer available.

SYS mmHg

DIA mmHg

Systolic and Diastolic display: if MAP is turned on, the screen toggles between the systolic and diastolic values, and the word

“MAP” and the MAP value.

Date/Time: indicates that the user must set/re-set the current date and time.

Measurement Indicator: displays the blood pressure, SpO2, or temperature icon as Spot

Vital Signs is taking the respective measurement.

SpO

2

%

/ min

M

P

SpO

2

Display: shows the percent saturation of arterial hemoglobin (for devices with SpO

2

only).

Pulse Display: shows the pulse rate.

Temperature Display and Indicator: shows the temperature in Fahrenheit or Celsius (for devices with

SureTemp only).

Monitor Mode Temperature: indicates the thermometer is in Monitor Mode (for devices with SureTemp only).

Out-of-range indicator: shows the patient’s temperature reading above or below the measurement range limits (for devices with SureTemp only).

Icon not used.

Thermometer Mode icon: shows temperature mode (for devices with SureTemp only).

Temperature Probe Problem: indicates a temperature probe problem

(for devices with SureTemp only).

Battery Level indicator: displays the battery charge level.

Battery Charging: indicates the device is powered through the AC power transformer.

16

Overview Welch Allyn Spot Vital Signs

Connections

Use the following instructions to connect the blood pressure hose, thermometer probe, and optional attachments to the Spot Vital Signs.

Figure 3. Spot Side and Rear Panel Connections

Probe Cover Storage Compartment

: storage space for one box of probe covers.

SpO

2

Cable Connection Port

(for units with SpO

2

only)

Temperature Probe Holder: storage space for the temperature probe when not in use (for devices with SureTemp only).

Suretemp Thermometer

Connection Port (for devices with SureTemp only).

Battery Door

IR Data Interface:

Port for communicating with an external device.

DC Power

Connection Port

Threaded Insert: to mount the

Spot Vital Signs to a mobile stand.

Service Manual Overview

17

Blood pressure hose and cuff connections

Have available the Spot Vital Signs, blood pressure cuff, and blood pressure hose.

1.

Inspect the pressure hose; note that one end has a connector fitting and the other end does not. Attach the end without the connector fitting to the pressure hose connector (see page 14). Verify that the pressure hose is completely inserted over the connector and that the fit is snug.

2.

Join the other end of the pressure hose to the blood pressure cuff pneumatic tubing.

Twist the connectors together until finger-tight. DO NOT OVERTIGHTEN.

Temperature probe connection

The Welch Allyn Spot Vital Signs is available with two probes — one for oral/axillary temperatures (blue cap), and one for rectal temperatures (red cap). The rectal probe is an accessory item that is ordered separately.

Press down on the tab on top of the connector and insert the connector into the temperature probe connector port on the back of the Spot Vital Signs. The probe connector only fits into Spot Vital Signs one way. Verify the connector clicks into place.

Insert the temperature probe into the probe holder on the top of the Spot Vital Signs.

To remove the temperature probe, press down on the connector tab and lift out.

SpO

2

sensor

Spot Vital Signs is available with a wide variety of SpO

2

sensors and ships with a reusable finger sensor and extension cable. All other sensors are accessory items that are sold separately.

1.

Align the shape and pin configuration of the extension cable connector to the SpO

2 cable connection port on the top side of the Spot Vital Signs device.

2.

Push the connector firmly into the SpO

2

cable connection port.

3.

Align the opposite end of the extension cable to the sensor cable connector and firmly push them together.

Note

Use only Masimo or Nellcor SpO

2

sensors and accessories with the Spot Vital

Signs with Masimo or Nellcor configurations, respectively.

Quick reference card

Attach the Quick Reference Card to the Spot handle, mobile stand, or wall mount using the supplied plastic cable tie.

18

Overview Welch Allyn Spot Vital Signs

DCpower connection

Note

To assure proper electrical isolation, replace the AC power transformer/charger using only the Welch Allyn specified part (REF 5200-101A, 5200-103A, 5200-

103Z).

Use the Spot Vital Signs with battery power (after charging the battery) or battery and DC power supply.

1.

Insert the round transformer connector into the DC power connection port on the left of the Spot Vital Signs (see page 16).

2.

Insert the line cord into the line connector on the transformer then plug the power cord on the transformer into the AC main power source to charge the battery.

Charging the battery

CHARGE THE BATTERY FOR SIXTEEN (16) HOURS PRIOR TO INITIAL USE.

Attach the DC power transformer to the Spot Vital Signs then plug the transformer into the AC main power source.

While charging, the charger icon remains on and the battery icon segments continuously sequence. When the battery is fully charged, all battery icon segments display.

As the battery voltage level drops the segments turn off from left to right. If the Spot Vital

Signs is not plugged in to charge when the second last segment is turned off the Spot

Vital Signs issues a warning beep. As the voltage level drops to compromise measurements an error beep is heard and all other display fields turn off. Spot Vital Signs beeps at increasingly frequent intervals until it finally powers itself off.

If not used for extended periods of time then recharge the battery.

Standby mode

Standby Mode conserves battery power. When the device is powered up, but has not been used for 2 minutes, it goes into Standby Mode. “Z Z Z” shows across the top of the display with no backlight.

To bring the Spot Vital Signs out of Standby Mode, press the Mode or Pressure Preset button or begin a patient measurement.

3

Functional overview

This functional verification procedure helps to confirm the proper operation of the Spot

Vital Signs and options. This procedure supports the requirements of routine preventative maintenance. It is not necessary to disassemble the Spot Vital Signs to perform this procedure.

For the calibration procedures, see “Calibration” on page 25. If the Spot Vital Signs fails

certain functional tests or a circuit board is replaced, the device may require calibration. It is necessary to disassemble the Spot Vital Signs for calibration.

Always perform this functional verification procedure after performing any calibration. This procedure contains additional tests that are not included in calibration procedures.

Power on/off and system check procedure

Press the Power button to turn the device on or off. Upon each power up, all the LCD segments in each display turn on briefly and two beeps sound. If the internal self-check is

successful, the display shows its normal functions (see page 15) and the device is ready

for operation. If the self-check fails, an error code is shown in the on the display.

To turn the unit off, press the Power button.

Note

Turning the unit off erases measurement data.

19

20

Functional overview Welch Allyn Spot Vital Signs

Internal configuration mode

You can change several device operating parameters in the Internal Configuration Mode.

When changed, these settings become the default power-up settings. You will also see non-changeable device configurations for technical service purposes.

To enter the Configuration Mode:

1.

Turn the Spot Vital Signs off.

2.

Press and hold the Power - Blood Pressure Start/Stop buttons. The device enters the Internal Configuration Mode and displays the software version.

3.

Press the Mode button to cycle through the Internal Configuration menu until you see the menu option displayed on the screen.

4.

Use the Next Patient/Clear/Cancel or Blood Pressure Start/Stop button to change the default setting.

5.

Press the Mode button once to save the change and press the Power button to exit the Internal Configuration Mode.

Table 3. Configuration Menu Options

Setting

Blood Pressure Calibration

Displays “Cal”

Description

Prepares the Spot Vital Signs for calibration. Only qualified personnel should verify the

Spot Vital Signs blood pressure calibration. For more details, see “Blood pressure calibration” on page 27.

Inflation Pressure Preset Level

Displays “PrP”

120, 140, 160, 180, 200, 240, 280 mmHg. Factory default is 160 mmHg.

Pressure Preset Level

Displays “PrP“

On or off. Disables or enables the front panel Pressure Preset button.

On or off.

Backlight

Displays “BLT”

Mean Arterial Pressure

Displays “MAP”

Date/Time

Temperature Scale

Displays “TMP MOD”

On or off.

Changes or updates the actual date and time.

Fahrenheit (°F) or Celsius (°C) Normal Mode / Fahrenheit (°F) or Celsius (°C) Monitor

Mode mmHg or kPa. Blood Pressure Units

Displays “BP”

Battery Readings

Displays “BAT”

Battery Life

Displays “LFE”

Displays the total battery voltage.

Total number unit measurements. Displayed information only; operator cannot change.

Service Manual Functional overview

21

Functional verification

Complete all steps in this section before returning a Spot Vital Signs for service.

Verify that the pressure meter used (if not specified by this service manual) is calibrated and the calibration certificate of the meter is traceable to NIST. The pressure meter testing the Spot Vital Signs must have an accuracy of better than

"

3 mmHg.

Subtract the rated accuracy of the pressure measurement standard from the

"

3 mmHg rated accuracy of Spot Vital Signs. This is the pass/fail criteria to determine if the device is within calibration. If the differences between Spot Vital Signs and the pressure measurement standard are within the pass/fail criteria at all specified pressures, then the device is within calibration.

All test specifications are found in Appendix A.

1.

Use the pneumatic tubing to connect the Spot Vital Signs to the test station (page

26) . Disconnect the battery and connect the power supply. Verify the IR Data

Interface is free from obstacles.

2.

Open the Spot Vital Signs repair software and verify the computer is communicating with the Spot Vital Signs.

3.

Hold down the Blood Pressure Start/Stop button while powering on the Spot Vital

Signs. The Spot Vital Signs enters the configuration test mode. After the LCD displays the software versions press the Mode button to display CAL. Spot Vital Signs automatically performs an auto zero.

4.

Attach a pneumatic clamp to the 100 cc and the 250 cc cylinder and then remove the clamp from the 500 cc cylinder.

5.

Select Test/Calibration on the computer screen. The dialog box displays the Spot

Vital Signs manometer and battery readings and the valve and pump status.

To verify the blood pressure calibration:

1.

Push the Spot Vital Signs Blood Pressure Start/Stop button to close the valve.

2.

Pump the hand bulb to the set the pressures: 0 mmHg, 50

"5 mmHg, 150 "5 mmHg,

250

"5 mmHg. Verify each pressure is within "3 mmHg of the target pressure

(except for 0 mmHg which should be within

"1.0 mmHg).

3.

Press the Mode button until the LCD window reads “bat.”

To verify the voltage reading:

1.

Set the power supply to 5.6 (+0.3 / -0.0 Vdc).

2.

Verify that the voltage reading meets the test specification.

3.

Return the power supply to 6.5 Vdc (+0/- 0.25 Vdc) upon completion of this test.

4.

Select OK to exit the Test Calibration dialog box.

22

Functional overview Welch Allyn Spot Vital Signs

NOTE: The pass/fail criteria for the blood pressure calibration check depends upon the accuracy of the pressure measurement standard used.

• If the pressure measurement standard used is rated with an accuracy of ±0.1 mmHg, the pass/fail criteria is ±2.9 mmHg in order to guarantee that the instrument under test is within ±3 mmHg of NIST.

• If the pressure measurement standard used is rated with an accuracy of ±1.0 mmHg, the pass/fail criteria is ±2.0 mmHg in order to guarantee that the instrument under test is within ±3 mmHg of NIST

Temperature functional check

The 9600 Plus Calibration Tester takes approximately 20 minutes to heat to the lowest setting. When testing several thermometers at all three temperatures, it is recommended to test all probes at one Calibration Set Point Temperature before proceeding to the next Calibration Set Point Temperature.

To further expedite testing start at the lowest Calibration Set Point Temperature. The 9600

Plus Calibration Tester does not have an internal fan, this causes a longer cool down time than warm up time.

Refer to the 9600 Plus Calibration Tester Directions for Use manual for specific information regarding the LCD window or the control buttons.

1.

Choose the proper mains plug insert and slide it over the two prongs in the power converter.

Figure 4. Power Adapter and Mains Plug Inserts

Two prongs in the power adapter

US UK AUS EU

2.

Plug the power adapter into the 9600 Plus Calibration Tester

(Figure 4)

and the opposite end into a wall outlet.

3.

Place the 9600 Plus Calibration Tester on a level surface away from sunlight, drafts, and other sources of heat or cold.

4.

Observe the Set Point Mode in the upper left hand corner of the LCD display. If the unit displays a "D", it is in Default Mode and will heat to the lowest Set Point

Temperature. If you do not want to conduct testing at this Set Point Temperature, press and hold

the Temperature Selection button to select the desired setting. The temperature display will flash before staying on continuously to indicate the 9600 Plus

Calibration Tester has stabilized and is ready for use.

Service Manual Functional overview

23

To begin functional verification of the SureTemp thermometer:

Caution Store thermometers for testing in the same room as the 9600 Plus

Calibration Tester for approximately 30 minutes prior to testing to allow for thermal accommodation.

1.

Remove the probe from the probe well and clean it with either a 70% isopropyl alcohol solution, a 10% chlorine bleach solution, or a non-staining disinfectant. Let the probe air dry. Do not apply a probe cover.

2.

Place the thermometer in Monitor Mode, refer to the thermometer’s Operator's

Manual.

3.

Insert the probe into the Thermistor Device Port.

4.

Wait for approximately one minute or until temperature on the thermometer is stable for ten seconds. Compare the thermometer's temperature reading to the 9600 Plus

Calibration Set Point Temperature. If the temperatures are within ±0.1° C (±0.2° F), the thermometer is within calibration.

5.

Test all available thermometers for calibration verification at the current Calibration Set

Point Temperature. Proceed to the next Calibration Set Point Temperature, see

“Changing the calibration set point temperature” on page 23.

Changing the calibration set point temperature

To scroll from one set point to the next, press and hold the Temperature Selection button until a beep is heard. The newly selected set point appears in the upper left corner of the

LCD display. The device’s current temperature is displayed, starts to flash, and continues flashing until the cavity reaches the equilibrium at the new set point.

24

Functional overview Welch Allyn Spot Vital Signs

SpO2 functional check

There is no way to change the functionality of the SpO

2

module. If the SpO

2

is not functioning properly, contact Technical Service.

Masimo

This section applies to Version 2 only. Use the Masimo Tester to perform to functionally check the Masimo sensors.

1.

Orient the Masimo extension cable such that the DB-9 connector connects to the

SpO

2

connector on Spot Vital Signs. Connect the opposite end of the extension cord to the Masimo Tester (part number 11593).

2.

Power on Spot Vital Signs and confirm the SpO

2

reading in the Display Window is

81%± 3% and the pulse reading is 61 bpm ± 1 bpm.

If the reading is outside the range, contact Welch Allyn Technical Service.

3.

Place the thumb and index finger on the gray buttons on either side of the Masimo

Tester connector, press the buttons firmly, and gently pull to remove the tester.

Nellcor

Nellcor MP205 SpO

2

module

This section applies to Version 1 only. Use a Nellcor-approved SpO

2

simulator (SRC-2 ) to check the SpO

2

functionality.

1.

Confirm the settings of the simulator:

• Rate: 112

• Light: High 1

• Modulation: High

• RCAL Mode: RCAL63/local

2.

Connect the Nellcor SpO

2

simulator test cable to the Spot Vital Signs.

3.

Verify the Spot Vital Signs reading meets the requirements of the Repair Test

Specification in Appendix C.

4.

Reconnect the SpO

2

sensor. Place the sensor onto your finger and check Spot vital

Signs for a reading.

Nellcor MP506 and Nell-3 SpO

2

modules

Use a Nellcor-approved SpO

2

simulator (SRC-MAX ) to check the SpO

2

functionality.

1.

Confirm the settings of the simulator:

• HR: 60 and 200

• SpO

2

%: 75 and 90

2.

Connect the Nellcor SpO

2

simulator test cable to the Spot Vital Signs.

3.

Verify the Spot Vital Signs reading meets the requirements of the Repair Test

Specification in Appendix A.

4.

Reconnect the SpO

2

sensor. Place the sensor onto your finger and check Spot Vital

Signs for a reading.

4

Calibration

This chapter provides procedures to perform all adjustments required to calibrate the

Spot Vital Signs to conform to Welch Allyn specifications. Calibration requires qualified personnel to open the device housing.

WARNING Electric shock hazard. There are no user-serviceable parts inside Spot

Vital Signs other than battery replacement (see “Battery removal and replacement” on page 70). An operator may only perform maintenance

procedures specifically described in this manual. For service, refer the device to an Authorized Service Center.

Note

Always disconnect the sealed lead-acid battery in the Spot Vital Signs before performing any calibration function.

Gather the tools listed on

page 39 to have available during the procedures.

Connections

1.

Connect the blood pressure pneumatic tubing to the Spot Vital Signs and to the test station (part number 401028).

2.

Connect the IR Data Interface cable to the computer.

3.

Start the Spot Vital Signs repair software on the computer.

4.

Remove the battery and connect the power supply to the Spot Vital Signs.

5.

Confirm the IR Data Interface is not obstructed.

25

26

Calibration

Figure 5. Connect Diagram

Part Number

401028

250 ml Vol

100 ml Vol

500 ml Vol

200 ml Vol mmHg

MODE

MasimoSET.

Spot Vital Signs

C

Welch Allyn Spot Vital Signs

Service Manual Calibration

27

Voltage calibration

1.

Follow the steps in

“Connections” .

2.

Adjust the power supply to 5.6 Vdc ±0.1 Vdc (+0.3/-0.0 Vdc).

3.

Hold down the Blood Pressure Start/Stop button while powering up to enter the

"configuration test mode". After the software versions are displayed, press the Mode button until the Spot Vital Signs displays "BAT" in the LCD window.

4.

Select Calibrate > Voltage in the repair software. The Spot Vital Signs display window goes blank.

5.

Read the voltage on the digital multi-meter (DMM) connected to the power supply.

6.

Type the voltage reading in the Calibrated Voltage box and select Update.

7.

Enter your initials in the Calibration Signature field to complete the voltage calibration. and select OK. The voltage on the LCD display matches that of the DMM.

Blood pressure calibration

1.

Follow the steps in

“Connections” on page 25.

2.

Adjust the power supply to 6.5 Vdc (+0/- 0.25 Vdc).

3.

Hold down the Blood Pressure Start/Stop button while powering up to enter the

"configuration test mode". After the software versions are displayed, press the Mode button until the Spot Vital Signs displays "CAL" in the LCD window.

4.

Select the Calibrate > Manometer on the computer.

5.

Verify the valve is “open” and select Calibrate 0.

6.

Press the Blood Pressure Start/Stop button to close the valve and verify the 500 cc cylinder is the only volume in the system.

7.

Increase the pressure to 250 mmHg ±5 mmHg using the bulb and valve.

8.

Use the bulb and the calibrated digital pressure meter to manually inflate the device to 200 mmHg and enter the pressure meter reading from Spot Vital Signs in the

Calibration Gain text field.

9.

Place the cursor into the box below the Calibrate 0 button and type in the value of the pressure reading seen on the pressure meter. Select Calibrate 250.

28

Calibration Welch Allyn Spot Vital Signs

Date/time set

After recharging a dead battery or after disconnecting the battery for a few minutes, you must program the date and time screen.

To set the date/time after after a power loss (Version 1 only):

1.

Press and hold the Blood Pressure Start/Stop + Power buttons to enter the Internal

Configuration mode. The Spot Vital Signs displays an E38 error. Press the C button to cancel the error, and the revision level of the internal software displays.

2.

Press the Mode button to advance to the Date Set Screen. The day, month, and year show in the systolic, diastolic, and heart rate displays, respectively.

3.

Use the Mode button to select the date item for change. When a date option is selected, the respective display flashes.

4.

Use the Next Patient/Clear or Blood Pressure Start/Stop buttons (arrow up or arrow down) to change the selected date option. After making all the desired date changes, press the Mode button once to save the change and advance to the Time

Set Screen.

When in the Time Set Screen the hour (in 24-hour format) and minutes appear in the systolic and diastolic displays, respectively. Use the Mode button to select the time item for change. When selected, the time option flashes. Use the Next Patient/Clear or Blood Pressure Start/Stop buttons to set the time (in the same manner as described previously).

5.

Press the Mode button to save the time and advance to the next screen.

6.

Press the Power button to turn off the Spot Vital Signs.

To update the displayed date and time:

1.

Press and hold the Blood Pressure Start/Stop + Power buttons to enter the Internal

Configuration Menu. Spot Vital signs displays the revision level of the internal software.

2.

Press the Mode button to advance to the Date Set Screen. The day, month, and year appear in the systolic, diastolic, and heart rate displays, respectively.

3.

Use the Mode button to select the date option for change. When a date item is selected, the respective display flashes.

4.

Use the Next Patient/Clear or Blood Pressure Start/Stop buttons (arrow up or arrow down) to change the selected date option. After making all the desired date changes, press the Mode button once to save the change and advance to the Time

Set Screen.

When in the Time Set Screen the hour (in 24-hour format) and minutes appear in the systolic and diastolic displays, respectively. Use the Mode button to select the time item for change. When selected, the time option flashes. Use the Next Patient/Clear or Blood Pressure Start/Stop buttons to set the time (in the same manner as described previously).

5.

Press the Mode button to save the time and advance to the next screen.

6.

Press the Power button to turn off the Spot Vital Signs.

5

Troubleshooting

When the main printed circuit board (PCB) is replaced on a Spot Vital Signs version 1, the print function is no longer available. The new function, Pressure Preset, raises or lowers the blood pressure maximum inflation level for one measurement only. When replacing the main PCB, replace the switch array as well.

The following table of conditions and error codes provides a quick reference of the descriptions and probable causes of error codes.

To clear the error code:

Power the Spot Vital Signs off, wait five seconds, and power on. If the error code reappears then power the Spot Vital Signs off and disconnect the battery for five minutes.

Reconnect the battery and power on. If the error code continues to reappear, call Welch

Allyn for a Service Notification Number (see “Technical assistance” on page 11).

Press the Blood Pressure Start/Stop button to reset flashing patient alarm conditions.

Error codes

Table 4. General

Code

E11

C12

Description

Internal safety violation

Ambient temperature out of range

C13 Battery failure

E0.0 - E9.9

Temperature module malfunction

E42 Internal communications error

E20 - E50 General internal malfunction

Corrective Action

Check patient, contact Technical Service.

Adjust ambient temperature or device location.

Use wall transformer.

Contact Technical Service.

Disconnect the battery and wait 5 minutes.

Reconnect the battery and then set the date and time.

Contact Technical Service.

Table 5. Blood Pressure

Code

C02

C03

Description

Auto-zero failure

Inflation too rapid

C04

C05

Excessive inflation time

Excessive noise

Corrective Action

Check for air obstruction, limit patient movement.

Check for kinked blood pressure cuff tubing, pressure hose, or other air obstruction.

Check for air leaks.

Check patient condition, blood pressure cuff placement, limit patient movement.

29

30

Troubleshooting Welch Allyn Spot Vital Signs

Table 5. Blood Pressure

Code

C06

E10

Description

Measurement was outside of device’s measurement range

Blood pressure cuff overpressure condition

Table 6. Temperature

Code

C20

P

Description

Broken/missing probe

Loss of tissue contact

E0.2, E0.3

Ambient temperature out of range

C22 10-minute diagnostic time exceeded

Corrective Action

Check patient condition.

Check patient condition.

Corrective Action

Replace probe.

Ensure proper probe positioning.

Adjust ambient temperature or device location.

Remove probe, discard probe cover, retake temperature.

Code

E7

C6

C8

C9

Table 7. SpO

2

Description

Internal SpO

2

error.

SpO

2

pulse rate out of range

Faulty SpO

2

sensor.

SpO

2

time limit exceeded.

Corrective Action

Retake reading.

Check patient condition.

Replace sensor.

Remove sensor from patient. Reapply sensor and retake reading.

Causes and corrective action

Table 8. Inaccurate Blood Pressure Readings

Possible Cause

Incorrect blood pressure cuff size.

Use Welch Allyn approved blood pressure cuffs only.

Patient’s arm position

Arm movement during blood pressure cycle

Blood pressure taken over clothing

Arrhythmia

Explanation and Corrective Action

Determine correct blood pressure cuff size.

• Use reference markings on blood pressure cuff.

• Measure patient’s arm circumference midway between elbow and shoulder to select correct blood pressure cuff size).

Ensure patient’s arm is at heart level.

Keep arm still during blood pressure cycle.

• Movement may cause inaccuracies from artifact.

Take blood pressure on a bare arm.

Check for regularity of heart rate (palpate pulse or check device).

• Moderate to severe heart rate irregularities may make blood pressure difficult to measure.

Service Manual Troubleshooting

31

Table 8. Inaccurate Blood Pressure Readings

Possible Cause

Incorrect reference

Explanation and Corrective Action

Use the correct Korotkoff sound to determine diastolic blood pressure.

• Many listeners incorrectly equate diastolic blood pressure with the disappearance of sound only (phase 5). The Welch Allyn Spot Vital Signs was developed using the American Heart Association recommendations, which state that phase 5 be used unless sound continues to 0 mmHg, in which case the change in the quality of sound (phase 4) is to be used.

Deflate blood pressure cuff no faster than 3 mmHg per second.

• One of the major sources of error in auscultatory blood pressure measurement is deflating the blood pressure cuff too quickly. The American Heart Association recommends deflation no faster than 3 mmHg per second.

Only use a sphygmomanometer that is calibrated.

• An uncalibrated sphygmomanometer may take inaccurate blood pressure measurements.

Change in blood pressure between auscultatory reading and Welch Allyn Spot Vital

Signs reading

Poor auscultatory sound recognition by observer

Check blood pressure immediately prior to Welch Allyn Spot Vital Signs reading.

Use higher quality stethoscope. Have a different observer check patient’s blood pressure.

Note: Differences of up to 10 mmHg are considered normal and occur for a number of reasons including intra-patient blood pressure variability, observer hearing differences, and auscultatory deflation rate.

Table 9. Cuff Inflation and Deflation with No Blood Pressure Reading Displayed (or Error Code in

Display)

Possible Cause

Leak in pneumatic system

Arm movement during cycle

Blood pressure cuff tubing or pressure hose movement artifact

Explanation and Corrective Action

Ensure all blood pressure cuff attachments are tight. Carefully check for leaks in the blood pressure cuff, tubing, and pressure hose attached to the device.

Keep arm still during blood pressure cycle. Movement may cause inaccuracies from artifact.

Do not contact blood pressure cuff tubing or pressure hose during blood pressure cycle. Movement may cause inaccuracies from artifact.

Table 10. No Blood Pressure Cuff Inflation

Possible Cause

Connections between device and blood pressure cuff loose

Explanation and Corrective Action

Check all connections (do not overtighten).

Table 11. Temperature Malfunction

Possible Cause

Error code displayed

Explanation

Broken probe

Low temperature readings

Improper probe placement

Corrective Action

Replace probe. Consult Service Manual. Notify biomedical department or Welch Allyn Technical Support.

Place probe in most posterior sublingual pocket when in

Oral Mode. Verify patient has had nothing to eat or drink for 20 minutes.

32

Troubleshooting Welch Allyn Spot Vital Signs

Table 11. Temperature Malfunction

Possible Cause Explanation

No temperature displayed Probe not replaced

Corrective Action

Replace probe in holder prior to taking another temperature.

Table 12. SpO

2

Malfunction

Possible Cause Corrective Action

Sensor in place but no SpO

2 display

on Insert the patient’s finger completely into sensor.

Verify blood pressure and SpO

2

measurements are not taken on the same extremity.

Verify the sensor cable is correctly plugged into device.

Verify you are using the correct sensor. Use only Masimo or Nellcor SpO

2

sensors and accessories with the Welch Allyn Spot Vital Signs with Masimo or Nellcor configurations, respectively.

Table 13. Device Does Not Turn On

Possible Cause

Low battery

Device not powering up

Explanation and Corrective Action

Check connections between device and transformer, and transformer and wall receptacle.

Unplug unit from wall receptacle and check for breaks in cord. If connections are secure, check electrical outlet.

Charging indicator is on if connections are good and the device is plugged into a working outlet.

Notify biomedical department or Welch Allyn Technical Support.

Table 14. Blood Pressure Cuff Too Tight (Over Inflation)

Possible Cause

Pressure preset too high

Explanation and Corrective Action

Check default Pressure Preset setting in internal configuration mode. Unless patient has underlying systolic hypertension, set pressure preset at 160 mmHg. (If systolic blood pressure greater than pressure preset, the device automatically increases an additional 40 mmHg.)

Table 15. Blood Pressure Cuff Pops Off

Possible Cause

Inappropriate blood pressure cuff size

Blood pressure cuff applied inside out

Explanation and Corrective Action

Determine blood pressure cuff size with the blood pressure cuff markings. If blood pressure cuff continues to pop off, notify biomedical department or Welch Allyn

Technical Support.

Re-apply blood pressure cuff. Make sure Welch Allyn label is facing away from arm.

Table 16. Blood Pressure Cuff Deflating Too Slowly

Possible Cause

Normal operation

Pressure preset too high

Patient movement

Explanation and Corrective Action

Typical time to take a reading is 20 to 45 seconds; 165 seconds is the maximum.

Check default pressure preset setting in internal configuration mode.

Have patient sit still. Do not have arm tight against chest wall, as respiration may affect speed and accuracy of blood pressure measurement.

Service Manual Troubleshooting

33

Table 16. Blood Pressure Cuff Deflating Too Slowly

Possible Cause

Small leak in pneumatic system

Explanation and Corrective Action

Check blood pressure cuff tubing and pressure hose for leaks.

Battery voltage check

1.

Follow the steps in

“Connections” on page 25.

2.

Set the power supply to 6.5 Vdc (+0/-0.25 Vdc).

3.

Use a DMM to check the battery voltage. If the voltage is less than 6.0 Vdc, charge the battery.

If an E38 error is present on Version 1, the battery does not charge correctly. Clear the error and then proceed.

To charge the battery, place the battery back into the Spot Vital Signs and connect the charger for 8 hours. Let the device sit idle for one day and recheck the battery voltage.

If the voltage is below 6.0 Vdc, replace the battery (see “Battery removal and replacement” on page 70).

4.

Power on Spot Vital Signs. If the device does not power on: a.

Verify the power supply is connected to the device and turned on.

b.

Change the main PCB (see “Main printed circuit board assembly” on page 44).

c.

Change the display PCB (see “LCD disassembly” on page 42).

Window display check

1.

Press the Power button to start the Spot Vital Signs.

2.

Observe the Spot Vital Signs window display and verify the LED segments light up for one to two seconds before the device enters the normal operating mode.

If there any segments that do not light, change the window display (see “LCD disassembly” on page 42).

Blood pressure calibration check

Perform two or three blood pressure cycles to verify proper cuff inflation/deflation and the readings. If Spot Vital Signs does not inflate or deflate properly perform the following procedure.

1.

Open the Spot Vital Signs housing (see “Front housing and key pad disassembly” on page 42).

2.

Check Spot Vital Signs for pinched tubing and reroute if necessary. Re-run the blood pressure cycle to confirm the problem is fixed.

If there are no pinched tubes, change the valve (page 48) .

34

Troubleshooting Welch Allyn Spot Vital Signs

3.

Power off Spot Vital signs and enter the Configuration Mode (see “Internal configuration mode” on page 20).

4.

Press the Mode button until Cal displays in the LCD window.

5.

Press the Start button to close the valve and use the bulb to manually inflate the device to 250 mmHg and confirm Spot Vital Signs meets the leak test specification

(see “Leak test” on page 73).

Temperature functional check

Use the 9600 Plus Caligration Tester to check the thermometer accuracy (see

“Temperature functional check” on page 22).

Masimo SpO

2

functional check

Use the Masimo Tester to check the functionality of the SpO

2

module of Spot Vital Signs

(see “Masimo” on page 24).

Nellcor SpO

2

functional check

Use a Nellcor approved simulator to check the functionality of the SpO

2

module of Spot

Vital Signs (see “Nellcor” on page 24).

Communication option check

1.

Select Tools > Options and confirm that communication port and the cable are selected.

2.

Select Test and confirm that the Spot Vital Signs responds accordingly.

If an error is present then confirm that there are no obstacles in the way of the IR

Data Interface. Re-try the test.

If the error is still prsent then change the Main PCB

(page 44)

.

Functional testing procedures

Perform the functional testing procedures in this section before returning Spot Vital Signs into service.

Verify you are using a calibrated pressure meter with an accuracy of better than ±3 mmHg and that the calibration certificate is traceable to NIST.

Subtract the rated accuracy of the pressure measurement standard from the ±3 mmHg rated accuracy of Spot Vital Signs. This is the pass/fail criteria to determine if the device is within calibration. If the differences between Spot Vital Signs and the pressure measurement standard are within the pass/fail criteria at all specified pressures then the device is within calibration.

1.

Follow the steps in

“Connections” on page 25.

2.

Enter the

“Internal configuration mode” on page 20. Aftering viewing the software

versions, press the Mode button until CAL displays in the LCD window. Spot Vital

Signs automatically performs an auto zero once the LCD window displays CAL.

Service Manual Troubleshooting

35

3.

Connect to the 500 cc cylinder.

4.

Select Test > Calibration in the repair software. The dialog box displays the Spot Vital signs manometer reading, battery reading, and valve and pump status.

5.

Push the Blood Pressure Start/Stop button to close the valve.

6.

Use the hand bulb to verify Spot Vital Signs is within calibration specification at the target pressures of 250±5 mmHg, 150 ±5 mmHg, 50 ±5 mmHg, and 0 mmHg with each reading within ±3 mmHg of the target pressure except for the 0 mmHg reading which is within ±1.0 mmHg.

7.

Press the Mode button until the LCD window displays bat.

8.

Set the power supply to 5.6 Vdc (+0.3/-0.0 Vdc). Verify the voltage reading meets the

specification (see “Voltage calibration” on page 74).

After completing this test, return the power suppy to 6.5 Vdc (+0/-0.25 Vdc).

9.

Select OK in the Test Calibration dialog box.

Current test

1.

Follow the steps in

“Connections” on page 25.

2.

Power off Spot Vital signs and then power on in normal mode.

3.

Select Test > Current Levels in the Spot Vital Signs Repair Software. Use the reading from the current meter and check the following current levels: a.

Blank b.

Back Light (Idle) c.

Valve/Pump d.

SpO

2

Mode

The test result is a pass or fail result.

4.

Select Ok to exit the dialog box.

Noise levels

1.

Follow the steps in

“Connections” on page 25.

2.

Select Test > Noise Levels in the Spot Vital Signs Repair Software and press the Test button to retrieve Spot Vital Signs internal pressure channel noise level. The test

result is a pass or fail result (page 73)

.

3.

Select Ok to exit the dialog box.

Button test

1.

Follow the steps in

“Connections” on page 25.

36

Troubleshooting Welch Allyn Spot Vital Signs

2.

Select Test > Button Test in the Spot Vital Signs Repair Software and press each button on Spot Vital Signs while verifying that the computer acknowledges each button in the Button Pressed display.

3.

Select Ok to exit the dialog box.

Interface test

1.

Follow the steps in

“Connections” on page 25.

2.

Select Test > Display in the Spot Vital Signs Repair Software to confirm the Window

Display shows all of the segments.

3.

Select all on in the Spot Vital Signs Repair Software to confirm the Window Display shows all of the segments.

4.

Select all off in the Spot Vital Signs Repair Software to confirm the Window Display clears all of the segments.

5.

Select Normal in the Spot Vital Signs Repair Software to confirm the Window Display returns to the normal display.

6.

Select Segment in the Spot Vital Signs Repair Software to confirm the Window

Display shows each number is correct as the test progresses one cycle.

7.

Select on in the backlight Spot Vital Signs Repair Software to confirm the Window

Display backlight comes on.

8.

Select off in the backlight Spot Vital Signs Repair Software to confirm the Window

Display backlight goes out.

9.

Select buzzer test to confirm the buzzer of Spot Vital Signs is on. Select Ok to exit the test and turn the buzzer off.

10. Select Ok to exit the dialog box.

Print quality

This section affects Spot Vital Signs Version 1 only.

This test requires the use of the TTL service port. You cannot complete the test using IR for communication.

1.

Follow the steps in

“Connections” on page 25.

2.

Verify the printer is the HP IR printer that works with Spot Vital Signs.

3.

Select Test > Print Quality. Select test pattern 1. The printer prints out a pattern of large and small ASCII characters.

4.

Verify the quality of the printer output.

5.

Select test pattern 2. The printer prints out a solid gray field.

6.

Verify the quality of the printer output.

7.

Select Ok to exit the dialog box.

If the print quality is poor for either test then replace the printer batteries and re-test.

Service Manual Troubleshooting

37

Pneumatic tests

1.

Follow the steps in

“Connections” on page 25.

2.

Attach the test system to the 100 cc cylinder. Select Test > Pneumatic > Leak Test.

The software tests for leaks and provides a Pass or Fail indication.

3.

Attach the test system to the 500 cc cylinder. Select Dump Test . The software tests for the dump speed and provides a Pass or Fail indication.

4.

Attach the test system to the 250 cc cylinder. Select Inflation Test. The software tests for the inflation time and provides a Pass or Fail indication.

5.

Attach the test system to the 100 cc cylinder. Select Valve Control Test. The software tests for valve control and provides a Pass or Fail indication.

6.

Select Ok to exit the dialog box.

Fail safe (over pressure) test

1.

Follow the steps in

“Connections” on page 25.

2.

Enter the

“Internal configuration mode” on page 20. Aftering viewing the software

versions, press the Mode button until CAL displays in the LCD window. Spot Vital

Signs automatically performs an auto zero once the LCD window displays CAL.

3.

Connect the Spot Vital Signs to the 500 cc cylinder and press the Blood Pressure

Start/Stop button to close the valve.

4.

Pump the hand bulb until an E10 error occurs and record the highest pressure observed on the pressure meter.

5.

Press the Cancel button to return to CAL mode.

6.

Press the Blood Pressure Start/Stop button to close the valve.

7.

Apply 70 mmHg and start a timer. When an E11 error code is triggered, stop the timer and record the time.

38

Troubleshooting

Service work checklist

Spot Vital Signs

Model Number Serial Number BP Cycle Count Technician

Welch Allyn Spot Vital Signs

Date

Test

Unit SW Version

SPO2 SW Version

Thermometry SW Version

Unit Pressure @ 0 mmHg

Unit Pressure @ 50 mmHg

Unit Pressure @ 150 mmHg

Unit Pressure @ 250 mmHg

Test Voltage @ 5.5 V

Current Test – Sleep State

Current Test – Valve Pump

Noise Level

Button Test

Interface Test

Leak Test

Dump Test

Inflation Test

Valve Control Test

Over Pressure Test

SPO2 Sensor - Masimo

SPO2 Sensor - Nellcor

Temperature Calibration

Temperature Cal Key Suretemp

Test Data Pass/Fail Test Specification

+/- 1 mmHg

+/- 1 mmHg

+/- 1.5 mmHg

+/- 2.0 mmHg

+/- 0.1 VDC

< 0.5 A

< 2.0 A

< 0.05 mmHg

Pass/Fail

Pass/Fail

<= 6 mmhg in 15 seconds

< 10 Seconds

< 7 Seconds

Pass/Fail

296 to 329 mmHg

81% +/- 3% 61bpm +/- 1bpm

90% +/- 1% 60bpm +/- 1bpm

96.8 +/- 0.2F 105.8 +/- 0.2F

97.3 +/- 0.2 F

6

Disassembly and repair

This chapter provides the instructions for removing and replacing serviceable modules in the Spot Vital Signs.

Unless otherwise noted, re-assembly procedures are the reverse order of the disassembly procedures.

WARNING Electric shock hazard. There are no user-serviceable parts inside Spot

Vital Signs other than battery replacement (see “Battery removal and replacement” on page 70). An operator may only perform maintenance

procedures specifically described in this manual. For service, refer the device to an Authorized Service Center.

WARNING Follow the ESD procedures on see “Electrostatic discharge (ESD)” on page 7.

Note

Always disconnect the sealed lead-acid battery in the Spot Vital Signs before performing any repair function.

Have the following tools available during the procedures.

Description

Bulb and valve

Pneumatic tubing (3 ea.)

Test Cable (IR)

Test Cable (Service Cable Kit)

Repair Software

Welch Allyn 9600+ Calibrator

Welch Allyn Calibration Key

Spot Vital Signs Service Manual

Pneumatic clamps (3)

Pliers

Wire Cutter

Tweezers

Torque Bit (T8) phillips screw driver

T10 Torx Bit

3/8 Hex Socket

Part Number

5088-01

5089-12

66P824

130S60

130S57E

01800-210

06137-000

4200-145E

21730-001

Source

Welch Allyn

Welch Allyn

Welch Allyn

Welch Allyn

Welch Allyn

Welch Allyn

Welch Allyn

Welch Allyn

VWR Scientific 800-932-5000

Tool/Supply Store

Tool/Supply Store

Tool/Supply Store

Tool/Supply Store

Tool/Supply Store

Tool/Supply Store

Tool/Supply Store

39

40

Disassembly and repair Welch Allyn Spot Vital Signs

Description

Cable Tie Tool

Setra Pressure Meter (1-10 PSIG)

Netech Pressure Meter

Masimo SpO

2

Tester

Masimo Extension Cable - 4 ft

Part Number

2270-01

20-200IN

11593

PC-04-WA

Source

Tool/Supply Store

Setra +1 800 257 3872

Netech +1 800 547 6557

Masimo +1 800 326 4890

Masimo +1 800 326 4890

Nellcor Patient Simulator

Nellcor Patient Simulator

Nellcor Test Cable

Calibration Volumes

SRC-2 for MP205 Nellcor +1 800 6355267

SRC-MAX for

MP506/NELL-3

Nellcor +1 800 635 5267

8-Dec

401028

IBM compatible computer 486 133 MHz computer or better.

Digital Multi-Meter (qty 2) with 4.5 digit displays for accuracy.

Power Supply: 0-20 Vdc adjustable with 0-3A output.

Nellcor +1 800 635 5267

Welch Allyn

Battery disassembly

1.

Disconnect the power and all accessories from the Spot Vital Signs.

2.

Remove the four screws holding the battery door using a phillips-head screwdriver.

3.

Remove the battery door to expose the battery and lift it out. Disconnect the one-way connector.

Service Manual Disassembly and repair

41

Temperature disassembly

Follow the previous steps and then:

1.

Remove the three #10 Torx screws from the temperature housing.

2.

Roll the temperature housing toward the top of the Spot Vital Signs and carefully lay it on the bench.

Temperature Housing

Temperature PCB

3.

Unplug the flex cable from the connector on the temperature PCB.

4.

Remove the two #10 Torx screws from the temperature PCB from the temperature housing.

5.

Remove the two #10 Torx screws on the temperature probe holder and gently pull out.

Temperature probe holder screws

Temperature connector PCB screws

42

Disassembly and repair Welch Allyn Spot Vital Signs

Front housing and key pad disassembly

Follow all the previous steps and then:

1.

Remove the two screws inside the battery housing that are identified with arrows molded into the housing and the two screws underneath the temeprature housing.

2.

Hold the device together and lay the back housing on the bench.

3.

Carefully roll the front housing to the right.

4.

Disconnect the tubing from the front housing.

Pneumatic Tubing

Version 1

Pneumatic Tubing

Version 2

5.

Gently pull the button switch array out of the cover.

6.

Align and push the new button switch array into place.

LCD disassembly

Follow all the previous steps and then:

1.

Gently lift the LCD module from the posts.

2.

Roll the LCD to the left of the Spot Vital Signs and lay it on the bench.

LCD

Flex Cable

3.

Remove the flex cable from the LCD and set the LCD aside.

Service Manual Disassembly and repair

43

Power and battery cable disassembly

Follow all the previous steps and then:

1.

Push down on the tab that connects the power cable to the main PCB and pull it toward the bottom of the Spot Vital Signs.

Ferrite Bead

Power cable to main PCB connection

Wire tie

2.

Lift the ferrite from its holder.

3.

Use a 3/8” Hex socket to remove the nut from the outside of the transformer connector. Slide the cable through the rear housing opening.

4.

Cut the wire tie and slide the battery connector out of the rear housing to remove the cable assembly.

44

Disassembly and repair Welch Allyn Spot Vital Signs

Main printed circuit board assembly

Follow all the previous steps and then:

1.

Remove the pneumatic tubing from the transducer on the main PCB.

Torx Screws

Battery/Valve

Connector

Pneumatic Tubing

2.

Remove the battery/valve cable connector from the bottom of the PCB.

3.

Remove the 4 #10 Torx screws from the PCB.

4.

Lift Main PCB from housing.

If the Spot Vital Signs uses SpO

2

then remove the three screws on the underside of the Main PCB and lift the SpO

2

PCB off the main board (two main board connectors).

5.

Attach the existing SpO

2

board to the new main board reusing all hardware.

Service Manual Disassembly and repair

45

SpO

2

circuit board disassembly

Note

To assure proper SpO

2

operation, replace the SpO

2

board using only the Welch

Allyn specified part.

To assure patient electrical isolation, after the main board is nearly back in position, verify that the SpO

2

flex cable is freely floating and not pressed up against the main board.

Follow all the previous steps and then:

Masimo board

1.

Remove the copper tape and unfold the shielding. This exposes the two screws that hold the PCB to the standoffs.

Phillips screws

2.

Remove the two phillips head screws and lift the Masimo adapter board straight up.

There are four connectors on this board - two connect to the main PCB and the other two connect to the Masimo PCB.

Copper shield tape

3.

Unfold the paper to expose the SpO

2

board and remove the two screws holding the board.

46

Disassembly and repair Welch Allyn Spot Vital Signs

Masimo

4.

Remove the 2 screws and lift the board and shielding off the standoffs. This exposes insulating paper.

5.

Verify the paper is properly aligned before re-installing the shielding and the new PCB assembly.

Alignment Holes

When reassembling, lay the shielding on top of the insulating paper and then replace the board. Verify shielding lays over top of standoff after folding.

Service Manual Disassembly and repair

47

Nellcor board

Follow all the previous steps and then:

1.

Remove the three phillips head screws along with the nuts and spacers from the

SpO

2

PCB.

Phillips screws

Spacers (3 places)

2.

Remove the SpO

2

module (Nellcor MP205) from the main PCB.

Note

If a failure occurs in the MP205 PCB (obsolete), update to a Nell-3 PCB (704870) and update the Main PCB (403290). The new Main PCB (403290) correctly operates an MP205, an MP506, or a Nell-3 PCB. If the Nell-3 is used with the old main PCB, an E7 error occurs after connecting the power.

For MP205 PCB: Verify the following:

• There are two shunts at the top of the jumper row on the PCB before installing on the Main PCB.

• The two locking tabs on the connectors of the Nellcor MP205 PCB are broken off before installing onto the Main PCB.

• The nylon washers are located on the main PCB when reassembling the

SpO

2

PCB to the Main PCB.

For MP506 or Nell-3 PCB: Verify the following:

• The DIP switch positions are (1-on, 2-on, 3-off and 4-off) on the new PCB and the two locking tabs on the connectors of the Nellcor MP506 PCB are broken off before installing onto the Main PCB.

• Verify that the nylon washers are located on the main PCB when reassembling the SpO

2

PCB to the Main PCB.

48

Disassembly and repair Welch Allyn Spot Vital Signs

Pump and valve disassembly

Note

For proper blood pressure operation, replace the pump using only the Welch Allyn specifed part.

To assure patient electrical isolation, do not modify the length of the pump wires.

Follow all the previous steps and then:

1.

Disconnect the pneumatic tubing from the valve and pump.

Pneumatic

Tubing (valve)

Torx Screws

Wire Tie

Pneumatic Tubing

(pump)

2.

Cut the wire tie and remove the two Torx screws.

3.

Lift the valve and the pump from their respective locations on the rear housing.

Service Manual Disassembly and repair

49

To upgrade the pneumatic tubing:

1.

Verify you have two pieces of silicon tubing 1.5 inches in length (421051-11) and one elbow fitting (703843) available.

2.

Remove the 4.4 inch silicon tubing from the “T” fitting.

4.4 inch Silicon

Tubing

3.

Insert one of the 1.5 inch silicon tubing pieces onto the “T” fitting.

4.

Insert the elbow fitting into the 1.5 inch silicon tubing.

5.

Insert the second 1.5 inch tubing onto the elbow fitting.

6.

Connect the 1.5 inch tubing to the Spot Vital Signs.

To assemble the pump filter:

1.

Verify you have three pieces of silicon tubing .8 inches in length (421051-5), one elbow fitting (703843), one NIBP filter (600-0520-00), and one foam sleeve (706327) available.

2.

Connect one piece of the silicon tubing at each end of the elbow fitting, and then connect the NIBP filter to one of the open ends.

3.

Connect the last piece of silicon tubing to the opposite end of the NIBP filter.

50

Disassembly and repair

4.

Carefully slide and center the foam sleeve over the NIBP filter.

Welch Allyn Spot Vital Signs

5.

Remove the open-ended tubing from the pump and replace with the pump filter assembly. Confirm proper pump fitting.

7

Technical overview

System description

The Spot Vital Signs automatically measures systolic and diastolic blood pressure, pulse rate, pulse oximetry (SpO

2

), and temperature (oral, axillary under 4 years, and rectal) for adult and pediatric patients (excluding neonates).

The device is intended to be used by clinicians and medically qualified personnel. It is available for sale only upon the order of a physician or licensed health care provider.

Refer to the Spot Vital Signs Directions for Use manual for complete information.

Battery /charge system

Spot Vital Signs includes a 6 Volt, 4.5 amp-hour sealed lead-acid battery that supplies all power to the device. A polarized connector protects against reversing the battery connection. An external power supply charges the battery and can operate Spot Vital

Signs at the same time. The external power supply provides the Spot Vital Signs with up to 1000mA at 7.2VDC. As the battery charges, the energy required to charge it decreases and the external power supply voltage rises to 8 VDC while supplying 750mA. The voltage to the external power supply is approximately 12.5VDC with no load attached. The Spot

Vital Signs monitors the battery voltage to control the fast and trickle charge modes. The

CPU allows fast charge until the battery reaches approximately 7.0 VDC, and then the CPU switches the charger circuit to trickle charge mode. For a dead battery the external charger supplies sufficient power to allow the Spot Vital Signs to power on, but not enough energy for a blood pressure cycle. A 5 amp surface mount fuse is populated on the Spot

Vital Signs main board at location F301.

Main CPU power supply

A single +5VDC linear regualtor (U319) powers the CPU and provides power to other digital circuitry on the main printed circuit board.

Clock/calendar power

The battery directly powers the internal real time clock (U309) through a voltage divider.

The Spot Vital Signs always has power if a battery is connected. A 100uF capacitor (C308) delivers energy to the real time clock during a battery exchange. If the battery is disconnected for longer than 1 minute, reset the real time clock after restoring the battery power.

51

52

Technical overview Welch Allyn Spot Vital Signs

Mod B NIBP power

The main board contains the circuitry required for blood pressure measurement. The main

CPU controls the battery power to this module through a +5V linear regulator (U6). In the event of a critical blood pressure module error, the main CPU disconnects power from the

ModB module through the BPEN signal at Q11. A separate +5V linear regulator (U1) powers the ModB analog circuitry to keep digital signal noise separated from the analog components.

Thermometer power

A combination of the main CPU +5V and the ModB +5V supply the SureTemp thermometer circuitry. If the main CPU disconnects power from the ModB blood pressure circuitry then the SureTemp circuitry is also disabled.

SpO

2

power

The battery supplies power to the SpO

2

through a +5V linear regualtor (U322). If there is no SpO

2

module connected to the Spot Vital Signs main board the SpO2 power supply is disconnected.

LCD power

The main CPU supplies power to the LCD module through the J307 connector, and the

FET Q312 and comparator U324A control the backlight. This comparator and FET create a pulse width modulated signal that allows the backlight to maintain constant brightness during changing battery voltages. The white backlight LEDs are connected in series inside the LCD module. This configuration causes some LEDs to look brighter or dimmer than adjacent LEDs. This is normal and expected.

Communications

A Spot Vital Signs and computer can communicate through the IR or service communication ports. IR communication is the default mode and works as a standard serial port (9600 baud, 8 data bits, no parity, 1 stop bit, no flow control) when used with

Welch Allyn 130S57E communications kit. The hard-wired service port is positioned behind the battery. Connect the port as described in the interconnect diagram. The hardwired port is intended for service use only. Never use the hard-wire communications port while the device is connected to a patient because it has no patient isolation protection.

Service Manual

Interconnect diagram

32 RS-2

TTL

13

12

14

11

10

7

6

5

4

9

8

3

2

1

7

6

5

4

9

8

3

2

1

10

5

6

7

9

8

4

3

1

2

4

3

1

2

5

6

7

8

9

1

1

2 1

7

3

11

2

GND

GND

AGND

SHIELD

LEDA

VCC

10

1

E-

PUMP

LVE+

PUMP+

VALV

VA

3

2

1

5

4

VALVE

Technical overview

53

54

Technical overview Welch Allyn Spot Vital Signs

8

Field replaceable units

If a Version 1 (serial number less than 200705000) is sent in for updates or repair to the main printed circuit board, it is necessary to upgrade the keypad and front housing/bezel assembly. The Spot Vital Signs is then referred to and functions as a Version 2. See

Table 1 on page 1 for the specific version differences.

The following lists identify the available FRUs for Spot Vital Signs. To order an FRU, contact Welch Allyn Technical Support.

Table 17. Repair Replacement Table (Version 1 only)

Faulty Part

Main PCB assembly 421267-501

(Print option)

LCD 421020-501

Switch Array (Version 1)

Front Housing (Version 1) 421049-502

Replacement Part(s)

Main PCB assembly 403290 (Pressure Preset option)

Front Housing (Version 2) 403300

Switch Array (Version 2) 706213

Directions for Use (English) 706272

LCD 706062

Switch Array (Version 1) 703430

Front Housing (Version 1) 421049-502

Parts listed below are used in both Version 1 and Version 2 unless otherwise indicated.

Table 18. Spot Vital Signs Repair Parts List

Description

Probe Assembly, Lathg Conn. Oral - 9 Ft

Probe Assembly, Lathg Conn, Rectal - 9 Ft

M031 Probe Cover Clear - 1K

Cable Tie Mount

Cable Tie, 6 inch

Switch Array, Spot, Epoxy Coated, Version 1

Grommet, Ribbed, Shock Isolation

Assembly, Spot Pump Repair

Flex Cable, Main to Display

S/N Tracking Label, Version 1

S/N Tracking Label, Version 2

Screw, 4-20 x .31 Plastite PH Torx

Lockwasher, 5/16 Internal Tooth

Part Number

02678-100

02679-100

05031-101

113P463

113P464

703430

421019

421023-501

421030

402427

403430

421037

421039

Source

Welch Allyn

Welch Allyn

Welch Allyn

Welch Allyn

Welch Allyn

Welch Allyn

Welch Allyn

55

56

Field replaceable units

Table 18. Spot Vital Signs Repair Parts List

Description

Rear Housing

Door, Battery

Pod, Temperature

IR Window

Cover, SpO

2

Front Housing Assembly, Version 1

Assembly, Pneumatic Tubing Only

Assembly, Pneumatic Fittings and Tubing

Fitting “Y” 1/8 x 1/8 x 1/8

Fitting “T” 1/8 x 1/16 x 1/8

Fitting, Elbow 1/8” *Ref L230_2)

Tubing, Silicone, 1/8 x 1/4 x .80

Tubing, Silicone, 1/8 x 1/4 x 3.60

Tubing, Silicone, 1/8 x 1/4 x 9.0

Tubing, Silicone 1/8 x 1/4 x 1.50

Tubing, Silicone 1/16 x 3/16 x .50”

Filter, NIBP

Foam Sleeve

Flex Cable, Main to Temperature Pod

Cable Assembly - Pump/Pneutron Valve

PCB Assembly, Temperature Pod

Battery Label, Rear Housing

Cable Tie, 6” Releasable

Cable Assembly - Power Spot Ext

Label, Caution/Button

Packet, Desiccant, 2 Unit

Pump

Stepper Valve

Nellcor Label (carton)

“Nellcor Works Here” Label

Nellcor Nell3 Pulse Oximetry

Nellcor Nel-3 Patent Label

Washer, Flat, #4 Nylon

Standoff, #4 x .0400”

4-40 x .250 Hex Nut

Screw 4-40 .750 Pan Phillips w/Nyloc

Latch, SpO

2

Welch Allyn Spot Vital Signs

620377-1

704870

705224

22P1451

421018

790043

9P2486

421047

421219N

421220

421273

421278

618E50-1

620156

620157

620038

421051-8

421051-11

421052-1

600-0520-00

706327

421066

421099

421105-501

Part Number

421040-1

421042

421044

421045

421048

421049-502

421001-503

421001-504

620216

620217

703843

421051-5

421051-6

Source

Welch Allyn

Welch Allyn

Welch Allyn

Welch Allyn

Welch Allyn

Welch Allyn

Welch Allyn

Welch Allyn

Welch Allyn

Welch Allyn

Welch Allyn

Welch Allyn

Welch Allyn

Welch Allyn

Welch Allyn

Welch Allyn

Welch Allyn

Service Manual Field replaceable units

57

Table 18. Spot Vital Signs Repair Parts List

Description

Label, SureTemp Technology

Detachable Power Cord, Aust

Detachable Power Cord, Swiss

Detachable Power Cord, South America

Foam Strip

1vb Label Blank 1” x 4”

Screw 2-28 .750 Pan Tox SS

Flex cable, main to display

Pump sub-assembly

IR window

Battery, 6 volt

Cable assembly - power Spot Vital Signs ext.

Rear housing

Front housing assembly, Version 1 only - black

Temperature pod housing

SpO

2

cover

Battery door

Switch array, Version 1 only - 6/W/B

PCB assy, temperature pod

Cable assy - pump/pneutr ON valve

Stepper valve

Flex cable, main to temp pod

Assy, pneumatic tubing

Assy, Masimo front housing, Version 2 only - blue

MS-11 OEM PCB, Version 2 only

Standoff set, MS-11, left and right, Verions 2 only

Shield, MS-11, Version 2 only

Masimo adapter PCA, Version 2 only

Tape, copper, Masimo shield, Version 2 only

Assy, plain front housing, blue

Main PCA, Version 2 only

Display module

Switch array, blue/white

MS-11 Nomex, Version 2 only

Assy, pump filter

Power cord - domestic

Assembly, Spot pneumatic repair

421049-502

421044

421048

421042

703430

421105-501

421099

620157

421066

421001-504

403301

031-0160-00

706070

706053

403291

704681

Part Number

70999-0000

400627

761076-8

761076-9

78P567

900242-8

9P2847

421030

421023-501

421045

4200-84

421273

421040-1

403304

403290

706062

706213

706055

403370

76400

421001-503

Source

58

Field replaceable units

Table 18. Spot Vital Signs Repair Parts List

Description

Battery, sub-assembly

Transformer, 120VAC/60 Hz, 8 Vdc

Transformer, 220VAC/50 Hz, 8 Vdc

Calibration key, temperature probe calibration

Power cord (Europe)

Power cord (UK)

Patent label, Masimo, Version 2 only

Screw 4-20 .250 pan phillips, Version 2 only

DFU, English

Flex cable, main to display

Pump sub-assembly

IR window

Battery, 6 volt

Cable assembly - power Spot Vital Signs ext.

Rear housing

Front housing assembly, Version 1 only - black

Kits Available:

Spot Temperature Upgrade

Nellcor SpO

2

Upgrade

Masimo SpO

2

Upgrade

Pneumatic Assembly Upgrade:

Fitting, Elbow 1/8” (REF L230_2)

Tubing, Silicone, 1/8 x 1/4 x .80

Tubing, Silicone, 1/8 x 1/4 x 1.50

Filter, NIBP

Foam Sleeve

Welch Allyn Spot Vital Signs

130S61

130S62

130S64

703843

421051-5

421051-11

600-0520-00

706327

Part Number

421002-501

5200-101A

5200-103A

5200-25

76402

76404

704608

106124-4

706272

421030

421023-501

421045

4200-84

421273

421040-1

421049-502

Source

9

Specifications

Consider the accessories connected to the Spot Vital Signs as Type BF applied parts.

Patient population

The Welch Allyn Spot Vital Signs is designed for use with adult and pediatric patients.

Welch Allyn defines a pediatric patient as 29 days or more of age.

THE WELCH ALLYN SPOT VITAL SIGNS IS NOT INTENDED FOR USE ON NEONATES.

Welch Allyn defines neonates as children 28 days or less of age, born at term (37 weeks gestation or more), otherwise up to 44 gestational weeks.

Blood pressure

Cuff Pressure Range

Cuff Inflation Factory

Default

Systolic Range

Diastolic Range

Accuracy

Determination Time

Pulse Rate Range

Pulse Rate Accuracy

Overpressure Cutoff

0 mmHg to 300 mmHg

160 mmHg

60 mmHg to 250 mmHg

30 mmHg to 160 mmHg

Blood pressure accuracy meets or exceeds SP10-1992 AAMI standards for non-invasive blood pressure accuracy (AAMI standard: ± 5 mmHg mean error,

8 mmHg standard deviation). Blood pressure accuracy is validated for pressure measurement using the upper arm only.

Typical: 20 to 45 seconds

Maximum: 165 seconds

40 bpm to 200 bpm

±5.0%

305 mmHg -0/+15 mmHg

Temperature

Accuracy

Range

Determination Time

Calibration accuracy: + 0.2° F (+ 0.1° C).

Maximum: 109.4° F/43.0° C

Minimum:

86.0° F/30.0° C

Oral: approximately 4 seconds

Axillary: approximately 10 seconds

Rectal: approximately 15 seconds

59

60

Specifications Welch Allyn Spot Vital Signs

Pulse pximetry

Masimo sensor accuracy guide

Accuracy specified when used with Masimo SET pulse oximetry monitors or with licensed Masimo SET pulse oximetry modules using Masimo patient cables, during no motion. Numbers present ± 1 standard deviation. Plus or minus one standard deviation represents 68% of the population. SpO

2

accuracy from 70% to 100%. Pulse rate accuracy from 25 to 240 bpm. This accuracy guide only affects Version 2.

Performance Measurement Range

Perfusion

SpO

2

Accuracy

Pulse Rate Accuracy

SpO

2

: 70 to 100%

Pulse Rate: 25 - 240 beats per minute (BPM)

0.02% to 20%

Saturation: 70% to 100%

No Motion: Adults, Pediatrics ± 2 digits

Motion: Adults, Pediatrics ± 3 digits

Low Perfusion: Adults, Pediatrics ± 2 digits

Pulse Rate: 25 to 240 bpm

No Motion: Adults and Pediatrics ± 3 digits

Motion: Adults and Pediatrics ± 5 digits

Low Perfusion: Adults and Pediatrics ± 3 digits

Table 19. Masimo Sensor Accuracy Guide

Sensor

LNCS-DCI

LNCS-DCIP

LNCS-ADTX

LNCS-PDTX

LNCS INF-L

LNOP-DCI

LNOP-DCIP

LNOP-ADT

LNOP-PDT

LNOP INF-L

Weight Range

> 30 kg

10 to 50 kg

> 30 kg

10 to 50 kg

3 to 20 kg

> 30 kg

10 to 50 kg

> 30 kg

10 to 50 kg

3 to 20 kg

Saturation Accuracy

No Motion

± 2%

± 2%

± 2%

± 2%

± 2%

± 2%

± 2%

± 2%

± 2%

± 2%

Motion

± 3%

± 3%

± 3%

± 3%

± 3%

± 3%

± 3%

± 3%

± 3%

± 3%

Pulse Rate Accuracy

No Motion

± 3 bpm

± 3 bpm

± 3 bpm

± 3 bpm

± 3 bpm

± 3 bpm

± 3 bpm

± 3 bpm

± 3 bpm

± 3 bpm

Motion

± 5 bpm

± 5 bpm

± 5 bpm

± 5 bpm

± 5 bpm

± 5 bpm

± 5 bpm

± 5 bpm

± 5 bpm

± 5 bpm

Masimo patents

The Masimo sensors and cables are covered under one or more of the following U.S.A. patents: 5,758,644; 5,823,950; 6,011,986; 6,157,850; 6,263,222; 6,501,975; and other applicable patents listed at www.masimo.com/patents.htm.

Service Manual Specifications

61

Nellcor

®

sensor accuracy guide

Accuracy specifications are based on controlled hypoxia studies with healthy, non-smoking adult volunteers over the specified saturation SpO

2 range. Pulse oximeter

SpO

2

readings were compared to SaO

2 values of drawn blood samples measured by hemoximetry. All accuracies are expressed as + “X” digits. This variation equals plus one standard deviation (+ 1 SD), which encompasses 68% of the population.

SpO2 Accuracy (MP205 specification - 2002 and earlier)

Pulse Rate Range

Pulse Rate Range (using SpO

2

determination MP205 specification -2002 and earlier)

Pulse Rate Accuracy

Pulse Rate Accuracy (MP205 Spec - 2002 and earlier)

±3% in the range of 70-100%

Oxygen saturation (1 stand deviation).

<70% unspecified by the OEM.

25 to 240 bpm

25 to 245 bpm

±3 bpm

±3 bpm (low perfusion)

SpO

2

Module Heart Rate ±3 bpm

Table 20. OxiMax Sensor Models, Single Patient Use

Sensor Models

MAX-AI

MAX-PI

MAX-II

MAX-RI

1

1

The accuracy specification has been determined between saturations of 80% to 100%.

SpO

2

Range

70% to 100%

± 2

± 2

± 2

± 3.5

Table 21. OxiCliq Sensor Models, Single Patient Use

Sensor Models

OXICLIQ-PI

Table 22. Reusable Sensor Models

Sensor Models

D-YS (Infant to Adult)

D-YS and D-YSE

D-YS and D-YSPD

DS-100A

OXI-A/N (Adult)

OXI-P/I (Pediatric/infant)

SpO

2

Range

70% to 100%

± 2.5

SpO

2

Range

70% to 100%

± 3

± 3.5

± 3.5

± 3

Adult: ± 3

± 3

62

Specifications Welch Allyn Spot Vital Signs

Nellcor patents

Covered by one or more of the following US Patents: 4,802,486; 4,869,254; 4,928,692;

4,934,372; 5,078,136; 5,351,685; 5,485,847; 5,533,507; 5,577,500; 5,803,910; 5,853,364;

5,865,736; 6,083,172; 6,708,049; Re. 35,122 and foreign equivalents.

Mechanical

Dimensions

Weight

Mounting

Portability

Height: 9.7 inches (24.6 cm)

Length: 5.7 inches (14.5 cm)

Depth: 4.7 inches (12.0 cm)

Approximately 4.6 pounds (2.2 kg)

Self-supporting on rubber feet

Custom Mobile Stand

Custom Wall Mount

Custom IV Pole Mount

May be hand-carried when held by the rear handle.

Electrical

Power Requirements

Battery

Patient-rated isolation transformer is connected to AC mains:

North American Version:120VAC, 60Hz. 0.13A Input, 7.2VDC, 1.0A Output

International Version:240VAC, 50Hz 0.065A Input, 7.2VDC, 1.0A Output

Australian Version:240VAC, 50Hz, 13VA Input, 7.2VDC, 1.0A Output

Lead acid, with external charger.

A fully charged battery supports 130 typical blood pressure determinations taken at

7-minute intervals. The battery is 90-100% charged after 12 hours of charging. The battery automatically charges when the Spot Vital Signs is powered through the AC power transformer. The battery charges faster when the instrument is not in operation.

Environmental

Operating Temperature

Storage Temperature

Transport Temperature

Relative Humidity

Operating Altitude

+10

° to +40° C (Thermometer operating temperature 16° to 40° C)

+50

° to +104° F (Thermometer operating temperature 61° to 104° F)

-20

° to +50° C

-4

° to +122° F

-20

° to +49° C

-4

° to +122° F

15 to 90% (non-condensing)

-170 to +4877 m

-557 to +16,000 ft.

Service Manual Specifications

63

Guidance and manufacturer’s declaration

Emissions and immunity information

Electromagnetic Emissions

The Spot Vital Signs is intended for use in the electromagnetic environment specified below. The customer or user of the Spot Vital Signs should assure that it is used in such an environment.

Emissions Test

RF emissions

CISPR 11

RF emissions

CISPR 11

Harmonic emissions

IEC 61000-3-2

Voltage fluctuations/ flicker emissions

IEC 61000-3-3

Compliance

Group 1

Class B

Class A

Complies

Electromagnetic Environment - Guidance

The Spot Vital Signs uses RF energy only for its internal function. Therefore, its RF emissions are very low and are not likely to cause any interference in nearby electronic equipment.

The Spot Vital Signs is suitable for use in all establishments, including domestic establishments and those directly connected to the public low-voltage power supply network that supplies buildings used for domestic purposes.

64

Specifications Welch Allyn Spot Vital Signs

Electromagnetic Immunity

The Spot Vital Signs is intended for use in the electromagnetic environment specified below. The customer or user of the Spot Vital Signs should assure that it is used in such an environment.

Immunity Test IEC 60601

Test Level

± 6 kV contact Electrostatic discharge

(ESD)

± 8 kV air

IEC 61000-4-2

Electrical fast transient/ burst

±2 kV for power supply lines

Compliance Level

± 6 kV contact

± 8 kV air

±2 kV for power supply lines

Electromagnetic Environment - Guidance

Floors should be wood, concrete, or ceramic tile. If floors are covered with synthetic material, the relative humidity should be at least 30%.

Mains power quality should be that of a typical commercial or hospital environment.

IEC 61000-4-4

Surge

IEC 61000-4-5

Voltage dips, short interruptions, and voltage variations on power supply input lines.

IEC 61000-4-11

Power frequency

(50/60Hz) magnetic field

IEC 61000-4-8

±1 kV for input/output lines

±1 kV differential mode

±1 kV for input/output lines

±1 kV differential mode Mains power quality should be that of a typical commercial or hospital environment.

±2 kV common mode

>95% dip in 0.5 cycle

±2 kV common mode

>95% dip in 0.5 cycle

60% dip in 5 cycles

30% dip for 25 cycles

60% dip in 5 cycles

30% dip for 25 cycles

Mains power quality should be that of a typical commercial or hospital environment. If the user of the Spot Vital Signs requires continued operation during power mains interruptions, it is recommended that the Spot Vital Signs be powered from an uninterruptible power supply or battery.

>95% dip in 5 seconds

3 A/m

>95% dip in 5 seconds

3 A/m Power frequency magnetic fields should be at levels characteristic of a typical location in a typical commercial or hospital environment.

Service Manual Specifications

65

Electromagnetic Immunity

The Spot Vital Signs is intended for use in the electromagnetic environment specified below. The customer or user of the Spot Vital Signs should assure that it is used in such an environment.

Immunity Test IEC 60601

Test Level

Conducted RF

IEC 61000-4-6

Radiated RF

IEC 61000-4-3

3 Vrms

150 kHz to 80 MHz

3 V/m

80 MHz to 2.5 GHz

Compliance

Level

Electromagnetic Environment - Guidance

Portable and mobile RF communications equipment should be used no closer to any part of the Spot Vital Signs including cables, than the recommended separation distance calculated from the equation applicable to the frequency of the transmitter.

Recommended separation distance

V1 = 3 Vrms d = (1.17)

P

E1 = 3 V/m d = (1.17)

P

80 MHz to 800 MHz

d = (2.33)

P

800 MHz to 2.5 GHz where P is the maximum output power rating of the transmitter in watts (W) according to the transmitter manufacturer and d is the recommended separation distance in metres (m).

Field strengths from fixed RF transmitters, as determined by an electromagnetic site survey, a

should be less than the compliance level in each frequency range.

b

Interference may occur in the vicinity of equipment marked with the following symbol:

Note 1: At 80 MHz and 800 MHz, the higher frequency range applies.

Note 2: These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and reflection from structures, objects, and people.

a

Field strengths from fixed transmitters, such as base stations for radio (cellular/cordless) telephones and land mobile radios, amateur radio,

AM and FM radio broadcast and TV broadcast cannot be predicted theoretically with accuracy. To assess the electromagnetic environment due to fixed RF transmitters, an electromagnetic site survey should be considered. If the measured field strength in the location in which the Spot

Vital Signs is used exceeds the applicable RF compliance level above, the Spot Vital Signs should be observed to verify normal operation. If abnormal performance is observed, additional measures may be necessary, such as reorienting or relocating the Spot Vital Signs.

b

Over the frequency range 150 kHz to 80 MHz, field strengths should be less than 3 V/m.

66

Specifications Welch Allyn Spot Vital Signs

Recommended Separation Distances Between Portable and Mobile RF Communications Equipment and the Spot Vital Signs

The Spot Vital Signs is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer or user of the Spot Vital Signs can help prevent electromagnetic interference by maintaining a minimum distance between portable and mobile RF communications equipment (transmitters) and the Spot Vital Signs as recommended below, according to the maximum output power of the communications equipment.

Rated Max. Output

Power of Transmitter

(W)

0.01

0.1

1

10

100

Separation Distance According to Frequency of Transmitter (m)

150 kHz to 80 MHz 80 MHz to 800 MHz 800 MHz to 2.5 GHz

d = (1.17)

P

0.11667

0.36894

1.1667

3.6894

11.667

d = (1.17)

0.11667

0.36894

1.1667

3.6894

11.667

P

d = (2.33)

0.23333

0.73785

2.3333

7.3785

23.333

P

For transmitters rated at a maximum output power not listed above, the recommended separation distance d in meters (m) can be estimated using the equation applicable to the frequency of the transmitter, where P is the maximum output power rating of the transmitter in watts (W) according to the transmitter manufacturer.

Note 1: At 80 MHz and 800 MHz, the separation distance for the higher frequency range applies.

Note 2: These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and reflection from structures, objects, and people.

Patents

D392,043 and other patents pending.

Service Manual Specifications

67

Identification label and serial numbering system

The identification label for the Spot Vital Signs is located on the bottom of the device. The serial number format has 9-digits. The first 4 numbers state the year of manufacture and the last 5 numbers state the Spot Vital Signs manufacturing number. Therefore,

200608000 means the 8000th Spot Vital Signs manufactured in the year 2006.

For Spot Vital Signs, Version 1, the serial number is any year prior to 2007 and a manufacturing number 04999 or less. These serial number labels require the CE0050 mark.

4341 State Street Road

Skaneateles Falls,

NY 13153 USA

MADE IN THE U.S.A.

N344

WELCH ALLYN PTY LTD

5/38-46 SOUTH STREET

RYDALMERE

NSW 2116

AUSTRALIA

C

+

CERTIFIED TO

CAN/CSA STD

74 2 2 7

US

C22.2 NO. 601.1

CONFORMS TO

IEC 60601-1

UL STD 2601-1

PATENT NO.

D392,043

0050

420 SERIES

9-digit serial number location.

For Spot Vital Signs, Version 2, the year is 2007 and the manufacture number is 05000.

These serial number labels require the CE0297 mark.

4341 State Street Road

Skaneateles Falls,

NY 13153 USA

MADE IN THE U.S.A.

+

Pb

www.

welchallyn.

com

N344

0297

WELCH ALLYN PTY LTD

5/38-46 SOUTH STREET

RYDALMERE

NSW 2116

AUSTRALIA

CERTIFIED TO

CAN/CSA STD

C22.2 NO. 601.1

C

166292

US

CONFORMS TO

IEC 60601-1

UL 60601-1

SPOT VITAL SIGNS

Patent No. D392,043

9-digit model and serial number location.

Firmware identification

To confirm the software levels of the Spot vital signs, enter the Configuration Mode

(page

20) .

The main software versions display as follows:

In the SW1 screen the top two numbers are the software version of the Spot Module and the remaining numbers are for the SpO

2

module (if available). Press the Start or Clear button to cycle through the SpO

2

software number.

In the SW2 screen the two numbers represent the NIBP module software and the temperature algorithm version (if temperature is active).

Note

Review the Repair Test Specifications document located in Appendix C to verify the firmware levels.

68

Specifications Welch Allyn Spot Vital Signs

10

Maintenance

Cleaning

Spot Vital Signs

Caution Do not use ethyl alcohol to clean the Spot Vital Signs device.

Caution Do not sterilize or autoclave the Spot Vital Signs.

Occasionally wipe the Spot Vital Signs, as necessary, with a cloth slightly dampened with appropriately diluted, non-staining disinfectant solution. Use either 70% isopropyl alcohol,

10% chlorine bleach solution, or mild detergent in warm water. Never immerse the Spot

Vital Signs in any type of fluid.

Note

Prevent water or other fluids from entering any connectors. Should this occur, dry the connectors with warm air. Check all measurement functions for proper operation.

Blood pressure cuff

Caution Do not press with a hot iron.

Clean the blood pressure cuff with a damp cloth, or wash in water with soap or detergent.

Before washing the blood pressure cuff, remove the tube fitting(s), close off tubes with plugs (available as accessory 5082-163) and place the hook and loop fasteners in the closed position. After washing, allow the blood pressure cuff to air dry. Re-assemble the tube fitting(s).

Disinfection: You may use glutaraldehyde-type liquid disinfectants on the durable blood pressure cuff. Prolonged use of these disinfectants at full strength may cause discoloration of the white blood pressure cuff markings.

Sterilization: Do not use steam or heat to sterilize the blood pressure cuff or pressure hose. If necessary, use gas sterilization.

Cables and pressure hose

Wipe the cabling and pressure hose with a damp cloth moistened in a mild detergent solution. Do not immerse.

69

70

Maintenance Welch Allyn Spot Vital Signs

Temperature probe

Periodically wipe the temperature probe clean with an alcohol-dampened cloth, warm water, or properly diluted, non-staining disinfectant. Do not immerse the probe.

SpO

2

sensor

WARNING Do not immerse the sensor in water, solvents, or cleaning solutions

(the sensors and connections are not waterproof). Do not use irradiation, steam, or ethylene oxide for sterilization.

Clean the reusable SpO

2

sensor with a 70% isopropyl alcohol solution and allow to air dry.

Do not immerse the sensor or cable.

Every 3 months, inspect the temperature probe, SpO

2

cord, and accessories for fraying or other damage. Replace as necessary.

Battery removal and replacement

Caution Only use the Welch Allyn 4200-84 lead acid battery. Using the incorrect battery will cause damage to the Spot Vital Signs and void the warranty.

As necessary, replace the internal battery after heavy use or the battery no longer charges. Use a battery with the same part number.

1.

Turn the Spot Vital Signs off and disconnect the DC power transformer cord.

2.

Remove the 4 screws holding the battery door using a phillips-head screwdriver.

Remove the battery door to expose the battery.

3.

Tip the Spot Vital Signs to slide the battery out. Disconnect and discard the old battery per local regulations. Reconnect the new battery as shown as quickly as possible to prevent loss of power to the unit and subsequent loss of clock time.

Battery

Connector

Service Manual Maintenance

71

4.

Slide the new battery completely into the compartment. Lay the connector on the battery. The relief pocket in the battery door purposely provides sufficient clearance for the battery connector .

Relief Pocket

Battery Battery Connector

5.

Replace the battery door and tighten each of the 4 screws.

6.

Connect the AC power transformer to the Spot Vital Signs and charge the new battery for 16 hours. It is possible to use the Spot Vital Signs during this charging period.

The battery is a lead-acid battery. In the USA, call 1-800-SAV-LEAD for instructions on how to recycle. For users outside the US please contact your local authorities on recycling.

Masimo SpO

2

calibration check

Use a Masimo-approved SpO

2

simulator (Fluke Biotek Index 2 or Clinical Dynamics

SmartSat) to check the SpO

2

accuracy. There is no way to change the calibration of the

SpO

2

module. If the SpO

2

is out of calibration, contact Technical Service.

Nellcor SpO

2

functional check

Use a Nellcor SpO

2

simulator (SRC-MAX ) to check the SpO

2

functionality. There is no way to change the functionality of the SpO

2

module. If the SpO

2

is not functioning properly, contact Technical Service.

SpO

2

accessory disposal

Dispose of all finger sensors and cables in accordance with facility, local, and goverment regulations.

Temperature calibration check

Use the 9600 Plus Calibration Tester to check the SureTemp thermometer accuracy. If the thermometer is out of calibration, contact Technical Service.

72

Maintenance Welch Allyn Spot Vital Signs

A

Repair test specifications

This appendix refers to the Spot Vital Signs without pneumatics (tubing and cuff), temperature probe, SpO

2

probe, or main battery attached, unless otherwise noted.

Use the Repair Software for the performing the tests on the Spot Vital Signs. The standard test voltage, unless otherwise stated is 6.5 Vdc (+0/-0.25 Vdc). Unless otherwise stated, all calibrated volumes are ±10cc of the stated volume.

Unit software for the Spot Vital Signs is equal to or greater than "1.07" for "Spot" software

(SW 1) and equal to or greater than "1.01" for ModB software (SW2). If the Unit has Nellcor

SpO

2

(MP205 PCB), the SpO

2

software is equal to or greater than "1.2.0.0”. If the Unit has

Nellcor SpO

2

(MP506 PCB), the SpO

2

software is equal to or greater than “1.7.2.0”. If the

Unit has the temperature option, the temperature software is equal to or greater than

“2.1”.

General unit test

A-D noise test

The A-D Noise Test is defined as the amount of noise on the Spot Vital Signs A-D pressure channel; over a 1 second sample time while 0.0 mmHg is applied to the device pressure port. The maximum limit is 0.050 mmHg.

Leak test

The Leak Test is defined as the amount of pressure drop that is recorded over a 15-second interval with a 100cc cylinder attached to the Spot Vital Signs pressure port and that volume having a stabilized pressure of 250 mmHg. The limit is 5 mmHg maximum.

Inflation test

The Inflation Test is defined as the amount of time the Spot Vital Signs pump can inflate a

250 cc cylinder from 5 mmHg to 210 mHg. The limit is 7 seconds, maximum.

Dump test

The Dump Test is defined as the amount of time it takes Spot Vital Signs to deflate a 500 cc cylinder from 260 mmHg to less than 15 mmHg. The limit is 10 seconds.

73

74

Repair test specifications Welch Allyn Spot Vital Signs

Pneumatic calibration

Note

Do not calibrate the Spot Vital signs if the internal temperature is greater than

89.9° F (32° C).

Calibrate the Spot Vital Signs with 0 and 250 mmHg applied to the pressure port with the following algorithm:

Adjust the pressure calibration offset value with the following formula. ((Last auto zero pressure value + current Unit pressure)

(

16384) / (pressure offset correction value + pressure gain correction value). The pressure-offset value must be -15384 to 15384.

Verify that Spot Vital Signs successfully performs an auto zero.

Adjust the pressure gain value until the pressure deviation from the applied pressure is less than 0.1 mmHg. Continue to utilize the following formula until the pressure is less than 0.1 mmHg. (Applied pressure / Unit pressure)

(

pressure gain value. The pressure gain value must be 1000 to 31767.

When the pressure transducer calibration is performed (only when successful), a calibration signature (four printable characters) and the calibration date/time is stored in the Spot Vital Signs memory - any of four printable characters.

Pneumatic accuracy test

Enter the Internal Configuration Mode to perform this test (see “Internal configuration mode” on page 20).

Perform an Auto-zero before starting this test (

“To verify the blood pressure calibration:” ,

Step 1 on page 27 through Step 4 on page 27). The Pneumatic Accuracy test is defined as

the comparison of Spot Vital Signs pressure measurement and applied pressure at 0, 50,

150, and 250 mmHg. The specification for each reading is within ±3 mmHg of the target pressure except for the 0 mmHg reading which is within ±1.0 mmHg.

Valve control test

Connect a 100 cc cylinder to the Spot Vital Signs pressure port and pressurize to 160 mmHg. Give Spot Vital Signs the commands to open the valve for 10 mmHg/s, 15 mmHg/ s, and 25 mmHg/s. Record each pressure drop: 4 to 12 mmHg, 4 to 15 mmHg, and 4 to

25mmHg, respectively.

Voltage calibration

Calibrate the Spot Vital Signs battery voltage measurement circuit at 5.5 Vdc (+0.1/-0.0

Vdc). Verify the battery calibration factor is 14,384 to 18,384. (?)

After performing a successful battery measurement circuit calibration, Spot Vital Signs memory will store a calibration signature of up to four printable characters.

Blank mode current test

The Blank Mode Current Test is defined as the amount of current drawn through the battery terminals. All LCD segments, the back light, and the SpO

2

mode are all turned off.

The limit is 200 mA maximum.

Service Manual Repair test specifications

75

Back light (Idle) current test

The Back Light Current Test is defined as the amount of current drawn through the battery. All LCD segments and the back light are turned on while the SpO

2

mode is turned off. The limit is 400 mA maximum.

Valve/pump mode current test

The Valve/Pump Mode Current Test is defined as the amount of current that is drawn through the battery terminals; Spot Vital Signs is in the Blank Mode while the valve and pump are actuated to on. The limit is 700 mA maximum.

Interface test

When given the proper commands, the Display Window will turn on or off all segments and turn on or off the back light. When given the proper command, the buzzer sounds to verify operation. The user determines the pass/fail criteria.

Temperature option requirements

Accuracy test

Verify the accuracy of the temperature module is within ±0.2° F for readings with a nomal temperature of 97.3° F (36.3° C) using a Cal Key (5200-25). Verify Spot Vital Signs can read a temperature of 96.4° F (35.8° C) and 106° F (41.1° C) within ±0.3° F/±0.2° C using a

Welch Allyn 9600 Plus Calibrator.

If using a water bath to take temperatures, verify the bath themperature is between 84° F and 106°F/28.8°C and 41.1°C. The reading must agree within (±1.0° F/0.8° C) measuring against a temperature stated that is accurate to within (±1.0° F/0.8° C).

Temperature probe test

Spot Vital Signs displays “188.8” and then “ORL” after you remove the oral probe from the probe housing.

SpO

2

option requirements

These tests are only valid on Spot Vital Signs models with the Masimo or Nellcor SpO

2 option.

SpO

2

functional test

See

“Masimo” or “Nellcor” starting on page 24

for the functional test.

SpO

2

mode current test

The SpO

2

Mode Current Test is defined as the amount of current, less the Blank Mode

Current, that is drawn through the battery terminals, placing Spot Vital Signs in the Blank

76

Repair test specifications Welch Allyn Spot Vital Signs

Mode, actuating the SpO

2

mode and applying any SpO

2

signal to the device. The maximum limit is 120 mA maximum.

Fail safe test

Over pressure test

Verify that Spot Vital Signs can detect over pressure on the pneumatic system between

296.0 mmHg and 329 mmHg.

Over 15 mmHg

Verify that Spot Vital Signs can detect static pressure over 15 mmHg for 180 seconds.

B

Supplies and Accessories

Latex-free blood pressure

Table 1. Cuff and Bag Combination

Catalog #

5200-01

5200-02

Description

Cuff and bladder, adult, one tube

Cuff and bladder, large adult, one tube

Table 2. One-Piece Cuff

Durable Cuff

Catalog #

5082-203-3

5082-204-3

5082-205-3

5082-206-3

5082-207-3

5082-208-3

Description

One-piece cuff, small child, one tube

One-piece cuff, child, one tube

One-piece cuff, small adult, one tube

One-piece cuff, adult, one tube

One-piece cuff, large adult, one tube

One-piece cuff, thigh adult, one tube

Table 3. Replacement Cuffs and Bladders

Catalog #

5200-04

5200-05

5200-06

5200-11

Description

Adult Bladder, one tube

Large Adult Bladder, one tube

Child Bladder, one tube

Thigh Bladder, one tube

Table 4. Miscellaneous Blood Pressure Accessories

Catalog #

5200-12

5200-19

Description

Straight Pressure Hose (8ft./2.4M)

Straight Pressure Hose (5ft./1.5M)

Catalog #

5200-10

5200-03

Description

Cuff and bladder, thigh, one tube

Cuff and bladder, child, one tube

Disposable Cuff

Catalog #

5082-93-3

Description

One-piece cuff, small child, one tube (box of 5)

5082-94-3

5082-95-3

5082-96-3

5082-97-3

5082-98-3

One-piece cuff, child, one tube (box of 5)

One-piece cuff, small adult, one tube (box of 5)

One-piece cuff, adult, one tube (box of 5)

One-piece cuff, large adult, one tube (box of 5)

One-piece cuff, thigh, one tube (box of 5)

Catalog #

5082-01

5082-16

5082-18

5082-64

Description

Adult cuff (sleeve)

Large adult cuff (sleeve)

Child cuff (sleeve)

Thigh cuff (sleeve)

Catalog #

5200-08

Description

Calibration T-Connector

77

78

Supplies and Accessories

Pulse oximetry accessories and supplies

Masimo

Table 5. Adhesive Sensors: Single-Patient Use

Catalog # Description

LNCS-ADTX Adhesive Finger Sensor - Adult (20 per case)

LNCS-PDTX Adhesive Finger Sensor - Pediatric (20 per case)

LNCS INF-L Adhesive Finger Sensor - Infant (20 per case)

LNOP-ADT

LNOP-PDT

Adhesive Adult sensor (20 per case)

Adhesive Pediatric sensor (20 per case)

LNOP INF-L Adhesive Infant sensor (20 per case)

Weight Range

>30 kg

10 to 50 kg

3 to 20 kg

>66 lbs (30 kg)

22 to 110 lbs

(10 to 50 kg)

3 to 20 kg

Table 6. Reusable Sensor

Catalog # Description

LNCS-DCI Finger sensor - adult

LNCS-DCIP Finger sensor - pediatric

LNOP-DCI Finger sensor - adult

LNOP-DCIP Finger sensor - pediatric

Weight Range

>66 lbs (30 kg)

10 to 50 kg

>66 lbs (30 kg)

10 to 50 kg

Quantity

1

1

1

1

Table 7. Sensor Cables

Catalog #

LNC-4-WA

Description

4-foot cable with DB-9 connector for LNCS

LNC-10-WA 10-foot cable with DB-9 connector for LNCS

PC-04-WA 4-foot cable with DB-9 connector for LNOP

PC-08-WA 8-foot cable with DB-9 connector for LNOP

Weight Range

NA

NA

NA

NA

Quantity

1

1

1

1

Welch Allyn Spot Vital Signs

Service Manual

Nellcor

Table 8. OxiMax Adhesive Sensors: Single-patient use

Catalog #

MAX-AI

MAX-PI

MAX-II

MAX-RI

SRC-MAX

Description

Adult sensor

Pediatric sensor

Infant sensor

Adult nasal sensor

Portable oximetry tester

Weight Range

>30 kg

10 - 50 kg

3-20 kg

>50 kg

Quantity

24

24

24

24

Table 9. OxiMax OxiCliq® Sensors: Reusable cable

Catalog #

OC-3

OXICLIQ PI

Description

OxiCliq sensor cable (3 ft)

Pediatric oxygen transducer, user with OC-3 cable

Weight Range

10 - 50 kg

Quantity

1

Case of 24

Supplies and Accessories

79

Table 10. OxiMax Reusable Sensors

Catalog #

DS-100A

OXI-A/N

OXI-P/I

D-YS

D-YSE

D-YSPD

Description

Durasensor

®

adult oxygen transducer

Oxiband

®

OXI-A/N, adult/neonatal* transducer

Oxiband OXI-P/I, pediatric/infant transducer

Dura-Y

®

oxygen transducer

Ear clip (use with Dura-Y sensor)

PediCheck™ pediatric spot-check sensor (use with

Dura-Y sensor)

Weight Range Quantity

>40 kg 1

<3 kg or >40 kg 1 sensor/50 wraps

3 - 40 kg

>1 kg

>30 kg

3 - 40 kg

1 sensor/50 wraps

1 sensor/40 wraps

1

1

Table 11. OxiMax Sensor Cables

Catalog #

DEC-4

DEC-8

Description

SpO

2

extension cable, 4 ft.

SpO

2

extension cable, 8 ft.

Quantity

1

1

* The Welch Allyn Spot Vital Signs is not intended for use on neonatal patients.

80

Supplies and Accessories Welch Allyn Spot Vital Signs

Temperature

Table 12. Accessories and Supplies

Catalog #

02678-100

02679-100

05031-101

Description

Oral/axillary probe (9ft./2.7M)

Rectal probe (9ft./2.7M)

Disposable probe covers (1,000 covers, 25/box)

Mounting

Table 13. Accessories and Supplies

Catalog #

4200-60

4200-62

Description

Mobile Stand

Wall Mount

Extended warranty

Table 14. One-year extended warranty

Catalog #

4200-00B

4200-OTB

4200-N0B

Description

Model 4200B

Model 420TB

Model 42N0B

Catalog #

05031-110

06137-000

01802-110

Description

Disposable probe covers (10,000 covers, 25/box)

Temperature Calibration Key

Model 9600 Plus Calibration Tester

Catalog #

4200-64

4200-70

Description

IV Pole Mount

Anti-Theft Kit

Catalog #

4200-M0B

4200-NTB

4200-MTB

Description

Model 42M0B

Model 42NTB

Model 42MTB

Service Manual Supplies and Accessories

81

Miscellaneous

Table 15. Accessories and Supplies

Catalog #

4200-84

4200-87X*

4200-88X*

4200-155

4200-89E

4200-100

4200-170

53600

53600B

Description

Lead Acid Battery

Directions for Use

Quick Reference/Error Code Card

Inservice CD (English only)

Service Manual (English only)

Carrying Case

Connectivity Accessory Kit

Printer paper (24 rolls)

Printer paper (4 rolls)

Catalog #

5200-101A

5200-103A

5200-103Z

76400

76402

76404

76406

4200-250

4200-350

Description

AC Power Transformer (US/Canada/Japan)-120V,

60Hz

AC Power Transformer (Europe/UK) -240V, 50Hz

AC Power Transformer (Australia) - 240V, 50Hz

Line Cord (US/Canada/Japan)

Line Cord (Europe)

Line Cord (UK)

Line Cord (Australia)

Pediatric accessory kit (small child, child, small adult cuffs and Nellcor SpO

2

sensor)

Pediatric accessory kit (small child, child, small adult cuffs and Masimo SpO

2

sensor)

* Replace the “X” with the following letter abbreviation to order the appropriate language manual.

Table 16. Printed Material Language List

F

FI

C

DK

Language

Abbreviation

Language

E English

Chinese

Dansk

Français

Suomi

I

N

NL

Language

Abbreviation

Language

G Deutsch

Italiano

Norsk

Nederlands

Language

Abbreviation

Language

PO Polish

P

S

SW

Português

Español

Svensk

82

Supplies and Accessories Welch Allyn Spot Vital Signs

C

Miscellaneous Mounting

Accessories

Wall mount kit (REF 4200-62)

Caution Attach Bracket to wall before assembling basket. See Directions for

Use. Welch Allyn is NOT responsible for the integrity of any Wall or IV pole mounting interface. Welch Allyn recommends that the customer contact their

Biomedical Engineering department or maintenance service to ensure professional installation, safety, and reliability of any mounting accessory.

83

2.

5.

4.

1.

Attach bracket to wall before assembling basket.

See Directions for use.

3.

84

Miscellaneous Mounting Accessories

Mobile stand kit (REF 4200-60)

3.

Welch Allyn Spot Vital Signs

4.

LOAD

4.25 lbs

1.93 Kg

2.

1.

5.

Service Manual Miscellaneous Mounting Accessories

85

IV pole mount accessory (REF 4200-64)

Caution Welch Allyn is NOT responsible for the integrity of any Wall or IV pole mounting interface. Welch Allyn recommends that the customer contact their

Biomedical Engineering department or maintenance service to ensure professional installation, safety, and reliability of any mounting accessory

2.

1.

4.

3.

86

Miscellaneous Mounting Accessories

Anti-theft kit (REF 4200-70)

Welch Allyn Spot Vital Signs

(1) "A"

(1) "B"

(1) -

5/64"

"B"

"A"

Service Manual Miscellaneous Mounting Accessories

87

Transformer mounting plate accessory (REF 4200-75)

The Transformer Mounting Plate Kit

Plate

Wire Clamp

1. Align the bottom of the Spot

Vital Signs with the mounting plate.

2. Slide the Spot Vital Signs onto the mounting plate and start integral screw into brass nut located on the back of the Spot unit.

Brass Nut

3. Tighten the integral screw until snug. Do not overighten. Verify the Spot Vital is fastened securely to the transformer mounting plate.

4. Remove the wire clamp screw and save it for later use.

5. Place the transformer onto the mounting plate.

6. Place the wire clamp over the transformer and hook the two ends into the slots.

The ends must slip underneath the plate.

7. Replace the screw and firmly tighten it down so that the clamp is secure.

88

Miscellaneous Mounting Accessories

IR dongle mounting accessory (REF 4200-170)

INSTALLATION INSTRUCTIONS:

Step 1 - Remove rubber base from

IR dongle

Step 2 - Place IR dongle into bracket clamps

Step 3 - Tighten screws

Step 4 - Clean side of device housing using alcohol wipe

Step 5 - Remove adhesive protective paper from back of bracket

Step 6 - Place bracket flange (A) on device surface (B) and hole in bracket (C) over IR window (D) as shown. Press firmly to secure adhesive.

(Note: Max adhesive strength achieved in 24 hours.)

CAUTION: DO NOT Download any drivers during the installation process for this

IR Rs232 device. Drivers are not required and will interfere with communication between the device and the

Electronic Medical Record.

Welch Allyn Spot Vital Signs

Material #: 705633 Rev. B

Warranty

Spot Vital Signs

Welch Allyn warrants Spot Vital Signs, when new, to be free of defects in material and workmanship and to perform in accordance with manufacturer's specifications for a period of two years from the date of purchase from Welch Allyn or its authorized distributors or agents. The battery is covered by a one-year warranty against original defects in material or workmanship. Welch Allyn will either repair or replace any components found to be defective or at variance from manufacturer's specifications within this time at no cost to the customer. It shall be the purchaser's responsibility to return Spot Vital Signs to Welch Allyn or an authorized distributor, agent, or service representative. This warranty does not include breakage or failure due to tampering, misuse, neglect, accidents, modification, or shipping. This warranty is also void if the instrument is not used in accordance with manufacturer's recommendations or if repaired by other than Welch Allyn or an authorized agent. Purchase date determines warranty requirements. No other express warranty is given.

Remember to submit the instrument registration/warranty card for warranty validation.

Complete the information and mail the pre-addressed card to Welch Allyn.

Accessories

The Masimo finger sensor and cable are covered by a six-month warranty against original defects in material or workmanship.

The Nellcor DS-100A is covered by a one-year warranty and the Nellcor DEC-4 cable is covered by a three-month warranty against original defects in material or workmanship.

.

The Reusable Two-Piece Blood Pressure Cuff is covered by a two-year warranty against original defects in material or workmanship.

The SureTemp probe is covered by a one-year warranty against original defects in material and workmanship. Probe covers are intended for single-use only.

89

90

Warranty Welch Allyn Spot Vital Signs

Reorder No. 4200-89E

Material No.706317 Rev. K
