PICSTART

®

PLUS MECHATRONICS

GETTING STARTED GUIDE

Information contained in this publication regarding device applications and the like is intended by way of suggestion only. No representation or warranty is given and no liability is assumed by Microchip Technology Incorporated with respect to the accuracy or use of such information. Use of Microchip’s products as critical components in life support systems is not authorized except with express written approval by Microchip.

1999 Microchip Technology Incorporated. All rights reserved.

The Microchip logo, name, PIC, PICmicro, and PICSTART are registered trademarks of Microchip Technology

Incorporated in the U.S.A. and other countries.

IBM and PC/AT are registered trademarks of International Business Machines Corporation.

Windows and MS-DOS are registered trademarks of Microsoft Corporation.

All product/company trademarks mentioned herein are the property of their respective companies.

1999 Microchip Technology Inc.

DS00177C

PICSTART

®

Plus Mechatronics Getting Started Guide

DS00177C

1999 Microchip Technology Inc.

GETTING STARTED GUIDE

Table of Contents

Chapter 1. Getting Started with the PICSTART

®

Plus Mechatronics

Kit .......................................................................................5

1.1 Introduction .................................................................................. 5

Chapter 2. Installing MPLAB-v4.11 or Later ......................................7

2.1 CD-ROM Installation .................................................................... 7

2.2 Connecting the PICSTART Plus Programmer ........................... 12

Chapter 3. Your First Project for Version 4.11 or Later .................15

3.1 Entering Source Code ................................................................ 22

3.2 Building the Project Code .......................................................... 23

Chapter 4. About the Demonstration Program ...............................25

4.1 Instruction Definition .................................................................. 26

4.2 Flowchart of the Program Code ................................................. 28

Chapter 5. Demonstrating the Simulator .........................................29

5.1 Asynchronous Stimulus ............................................................. 29

5.2 Sleep Mode ................................................................................ 37

5.3 Animate ...................................................................................... 37

5.4 Watch Windows ......................................................................... 38

5.5 Break Points ............................................................................... 40

Chapter 6. Programming Your Code into the PIC12C509 ..............41

Appendix A. Programming a PIC12C509 MCU with the 8-pin Pong Game ...............................................45

Appendix B. How to Get Help and Recommended Reading ..............49

Appendix C. Correcting PICSTART

®

Plus

Communications Problems.............................................53

Appendix D. Glossary ............................................................................55

1999 Microchip Technology Inc.

DS00177C-page iii

Getting Started Guide

DS00177C-page iv

1999 Microchip Technology Inc.

GETTING STARTED GUIDE

Chapter 1. Getting Started with the PICSTART

®

Plus Mechatronics Kit

1.0 Introduction

Microchip strives to give engineers new tools and choices for implementing state-of-the-art control designs.Our minimal footprint microcontrollers are a case in point. There is a great deal of smarts packed into a tiny space in our 8bit microcontrollers. As your designs grow in complexity, the code you write

(later) can be easily transitioned to larger Microchip microcontrollers with more peripheral resources.

In order to help you get acquainted with the benefits gained by incorporating a microcontroller into your design, we will guide you through the steps in setting up your system, writing a short program, and programming your first

PICmicro

®

MCU.

To get started, you need to install Microchip’s MPLAB™ Integrated

Development Environment (IDE). PICSTART

®

Plus Mechatronics Kit, and

MPLAB IDE, which is supplied on CD-ROM.

1999 Microchip Technology Inc.

DS00177C-page 5

Getting Started Guide

NOTES:

DS00177C-page 6

1999 Microchip Technology Inc.

GETTING STARTED GUIDE

Chapter 2. Installing MPLAB-v4.11 or Later

2.1

CD-ROM Installation

1.

Insert the MPLAB CD-ROM into your CD-ROM drive.

If running Windows

®

95 with autoplay turned on, MPLAB™ should begin loading. If running Windows95 with autoplay turned off click the START button in the lower left-hand corner of your computer screen.

If running Windows 3.1x, select File from the tool bar.

2.

Select Run… from the menu to bring up the dialog box. Enter the drive letter for your CD-ROM (i.e., e:) Click OK.

Click the Browse button. To begin the installation program, double-click on

Mp41100.

1999 Microchip Technology Inc.

Note: Future versions of MPLAB will have higher revisions numbers (for example: Mp50000) and are available from Microchip’s web site at www.microchip.com under “Development Tools.”

DS00177C-page 7

Getting Started Guide

3.

The

Select Components

window enables you to select which components you want to install. A checkmark in the box will install the component. For this application using the PICSTART

®

Plus programmer, select the components as shown in the diagram. Click Next to proceed or Back to edit the previous selections.

Note: If you have a PICMASTER

®

emulator or a PRO MATE

® programmer, you will want to select the components for them as well.

4.

The

Select Language Components

window enables you to select the

Language Components for developing applications in MPLAB. For our purposes the default setting of all selected components is desired. Click

Next to proceed or Back to edit the previous selections.

DS00177C-page 8

1999 Microchip Technology Inc.

5.

Next, select the destination directory where you want to install the

MPLAB IDE files. The default setting is C:\Program Files\ MPLAB. Click

Next to proceed or Back to edit the previous selections.

6.

You can instruct the installation to save any files replaced by the installation process. Use this option if you want to create backups of the originals. The default setting is No. Click Next to proceed or Back to edit the previous selections.

1999 Microchip Technology Inc.

DS00177C-page 9

Getting Started Guide

7.

This window instructs the installation to add MPLAB to the Start Menu.

The default setting is Yes. Click Next to proceed or Back to edit the previous selections.

8.

You are ready to start the installation process, click Next to proceed or

Back to edit the previous selections.

DS00177C-page 10

1999 Microchip Technology Inc.

9.

Several Read Me files will be shown sequentially to give you the latest information about the development tools. You may want to read through these prior to clicking OK to proceed. They will look like this:

10. The installation is now complete. Click on Finish.

1999 Microchip Technology Inc.

DS00177C-page 11

Getting Started Guide

2.2

Connecting the PICSTART Plus Programmer

Turn off your computer. Connect the serial cable and PICSTART Plus

Development Programmer to an available COM Port on the back of your computer. Connect the power supply to the PICSTART Plus and plug it in.

The power light should be illuminated on the PICSTART Plus.

Turn on the computer.

1.

Start MPLAB by clicking on the MPLAB icon in the Microchip MPLAB program group. The MPLAB IDE is now running and you are ready to create a project.

2.

Since we will be using the PIC12C509 in our design, let’s set up the development mode. From the pull-down menu, select

Options>Development Mode.

DS00177C-page 12

1999 Microchip Technology Inc.

3.

Select MPLAB-SIM Simulator by highlighting the diamond shaped box, then click on the drop-down arrow and choose PIC12C509 as the processor. Then click the Reset button at the bottom of the screen.

4.

Next you will set up the PICSTART Plus programmer. From the pull-down menu, select

Options>ProgrammerOptions>Select Programmer>

PICSTART Plus

.

5.

Now setup the COM port. From the pull-down menu, select

Options>Programmer Options>Communications Port Setup

. Select the

COM port you have connected to the PICSTART programmer.

Note: If you experience any problems with PICSTART Plus

communications, please see Appendix C.

1999 Microchip Technology Inc.

DS00177C-page 13

Getting Started Guide

NOTES:

DS00177C-page 14

1999 Microchip Technology Inc.

GETTING STARTED GUIDE

Chapter 3. Your First Project for Version 4.11 or Later

To begin the process of developing your application, you must first create a project. Projects keep track of the windows you have open and the files associated with your design. This enables you to pick up where you left off each time you begin working.

1.

Using Windows Explorer, create a project directory for this tutorial called

“MECHA” under the MPLAB directory

2.

Select

Project>New Project…

from the pull-down menu.

3.

A

New Project

window appears. Type power1.pjt as your project name and click OK. Select “mecha” under the MPLAB directory, and click OK.

4.

The

Edit Project

window appears, click OK

1999 Microchip Technology Inc.

DS00177C-page 15

Getting Started Guide

5.

Next, select

File>New

from the pull-down menu.

6.

A new blank source page will open. The default file name will be similar to Untitled1.

DS00177C-page 16

1999 Microchip Technology Inc.

7.

Again, select

File>Save

As from the pull-down menu.

8.

The

Save File As

window appears. Make sure your are saving this file into your project directory. Type in power1.asm as the File Name and click OK.

1999 Microchip Technology Inc.

DS00177C-page 17

Getting Started Guide

9.

Next, you will add the source file to your project. Select

Project>Edit

Project

from the pull-down menu.

10. Click on the project filename power1.hex and press the Node

Properties button.

DS00177C-page 18

1999 Microchip Technology Inc.

11. The

Node Properties

window opens. Make sure the check boxes are selected as shown below and click OK.

• NODE should be set to POWER1.HEX

• Language Tool should be set to MPASM

• Hex Format should be set to INHX8M

• Error File and List File should be set to On

• Case sensitivity, Macro expansion, and Default radix can be set to the user’s preference. For this tutorial configure them as shown.

12. Next, click on the Add Node button to display the

Add Node

window.

1999 Microchip Technology Inc.

DS00177C-page 19

Getting Started Guide

13. Select your source file or type power1.asm as the File Name, and then click OK.

14. You should now see that both nodes are shown in the

Project

window, as shown below. Click the OK button to save your changes.

DS00177C-page 20

1999 Microchip Technology Inc.

15. Now we will set up the

Hardware

configurations. From the pull-down menu, select

Options>Processor Setup>Hardware

.

16. The

Processor Setup

window opens. make sure to select options shown below.

• Select Oscillator: Internal RC.

WatchDog Timer should be none.

Stack Overflow Break Enabled should be selected.

MCLR Enable is disabled.

1999 Microchip Technology Inc.

Your project has now been created. If at any time you wish to stop working on your project, you can close all windows by selecting

Project>Close

Project

and answer YES to save it. The next time you are ready to continue working, you can select

Project>Open Project

and pick up where you left off.

DS00177C-page 21

Getting Started Guide

3.1

Entering Source Code

You are now ready to edit the file power1.asm to create the code needed for

your application. (See Chapter 4 for a detailed line-by-line explanation of the

source code.)

1.

Type the following lines of text in the

power1.asm

window:

Note: This code is case sensitive, pay special attention to lower and upper case characters. In line 3, the text:

__CONFIG

has 2 underscore characters in it.

DS00177C-page 22

2.

After entering the source code, select

Project>Save Project

from the pull-down menu to save your project.

1999 Microchip Technology Inc.

3.2

Building the Project Code

1.

You are now ready to build the project. This will produce the hex file that will be used to program the PIC12C509 microcontroller part. A hex file is created from the source file you have written and has the same name as the source file except for the file extension which ends in .hex. The hex file contains the program as it would be written to the PICmicro MCU, in a numeric format. Select

Project>Build All

from the pull-down menu.

2.

If everything has been performed correctly, a

Build Results

window appears indicating “Build Completed Successfully.” Click close to continue. The close button is the “X” box in the upper right had corner of the window.

Note: If the

Build Results

window indicates errors, recheck your source code in the source file.

1999 Microchip Technology Inc.

3.

Click OK to continue.

DS00177C-page 23

Getting Started Guide

NOTES:

DS00177C-page 24

1999 Microchip Technology Inc.

GETTING STARTED GUIDE

Chapter 4. About the Demonstration Program

The program was designed to work with the “Pong Board.” The schematic is

located in Appendix A.2. There are two LEDs and two switches. Pressing a

switch (left or right) lights the corresponding left or right LED.

To better understand the source code program and how it works, below is a line-by-line evaluation of the program. The first three lines of the program

( list

,

#include

and

__config

) and the last line ( end

) are directives. That is, they are instructions to the assembler about how to create this program, but do not actually translate to program instructions.

list p=12c509

This tells the assembler that this program is for the processor PIC12C509.

#include <p12c509.inc.>

The

#include

directive tells the assembler to bring in another file at this point. The file named p12c509.inc is provided by Microchip to simplify the naming and assigning of special function registers, flag bits, and configuration word bits.

__CONFIG _CP_OFF & _WDT_OFF & _MCLRE_OFF & _IntRC_OSC

The

__CONFIG

directive tells the assembler how you want the configuration word programmed. (See the PIC12C5XX datasheet (DS40139) for details on the configuration word.) All Microchip PICmicro MCUs have a configuration word where certain features of the part are enabled or disabled. (there are two “underscore” characters preceding the word

CONFIG

, all other occurrences are single underscores) By ANDing the options you have chosen together (with the

&

character) you construct the desired configuration word.

In this case, we have chosen to turn code protect off, the Watchdog Timer off,

External Master Clear Pin off, and set the oscillator to internal RC.

end

The end

statement tells the assembler that it has reached the end of the assembly file. All program code is placed before the end statement.

count EQU 0x08

The equ

directive, called “equate” assigns a value to a label. Here, we are saying that we would like the number 8 to be used in place of the label count in our program. The label count

is used as a variable in our example, and is located at address

0x08

in data memory. Note that count

is a label, and as such should be placed at the left-most column of the page.

1999 Microchip Technology Inc.

DS00177C-page 25

Getting Started Guide

4.1

Instruction Definition

To help you better understand the program, we have defined the instructions used in it below. A program flow chart describing the program execution is

located on page 28. A more thorough explanation of these instructions, and

the many features of this part, can be found in the PIC12C5XX datasheet

(DS40139).

Note:

Many PICmicro instructions can access two registers at the same time. One register is W, the working register, the other register is the data address of your choice.

movwf GPIO

MOVe W to F. Copies the value currently stored in the W register to the register selected – in this example, the GPIO (General Purpose Input/Output) register.

movlw 0x0F

MOVe Literal to W. Moves a value into W. In this case, the hexadecimal value

F

is copied.

OPTION

Copies the current value of W into the

OPTION

register. For instance, “wake up on port change” and “weak pullups” are enabled in the option register for this part. (Port pullups cause the inputs to default to one if no other input is present on the pin).

TRIS GPIO

Copies the current value in W to the direction register (or TRIS register) of the port signified. In this case the port GPIO is being configured. A '1' configures a pin to an input for reading values in, and a '0' configures a pin as an output for writing values out.

decfsz count,f

DECrement F Skip if Zero. The decfsz

instruction decrements the value in the register designated (in this case count

). If the result is zero, the instruction immediately following this instruction is skipped (usually a goto instruction which branches back up and causes the value to be continuously decremented until it reaches zero). The result of the decrement can be placed back into the file register designated by ending the instruction with f

(as is done here) or it can be copied into the W register by putting a w

at the end of the instruction instead of f

. Note that if neither f

nor w

is written, the assembler defaults to f

.

goto main

This instruction causes the program to branch to the location indicated. You will notice that in this example program several 'labels' have been placed in the left column, such as main

. Labels make it easier to read a program and

DS00177C-page 26

1999 Microchip Technology Inc.

1999 Microchip Technology Inc.

see where it is branching. You should note that ONLY labels are placed in the left-most column. Anything else placed to the left edge will be mistakenly interpreted as a label, which could cause errors in your program.

clrf STATUS clrf GPIO

CLeaR F. The clrf

instruction simply clears, or zeros, the contents of the designated register. Here, the STATUS register is being initialized to zero. In this case, the register GPIO is cleared, which has the effect of making all I/O pins configured as outputs, to output a zero. See the PIC12C5XX datasheet

(DS40139) for details on the

STATUS

register.

btfsc GPIO,3

Bit Test F, Skip if Cleared. This instruction tests a bit and skips the next instruction if the bit is zero. In this case we are testing bit 3 (which corresponds to pin 4) of the GPIO port to see if a switch has been pressed.

The instruction immediately after the bit test is usually a

GOTO

that branches to another part of the program.

sleep

The sleep

instruction causes the clock oscillator to stop and all program execution to be halted. This puts the part into a low power mode. Several features can be enabled which will wake the processor from sleep. These include, a timed wake-up period, called the WDT, or WatchDog Timer; a reset, caused by a low input on the MCLR pin, if MCLRE is enabled; and finally a change on a port pin (like a key press) if wake-up on pin change is enabled. In this example only wake-up on pin change is enabled.

bcf GPIO,0 bsf GPIO,4

These instructions clear a bit ( bcf

) or set a bit ( bsf

). Clearing a bit on an output pin causes the output on the pin to go low, or 0V. Setting a bit causes it to go high, or to 5V in a 5V system. In our example, setting a bit turns on an

LED connected to the associated pin. In this example, we are clearing bit 0 and setting bit 4 of the GPIO.

DS00177C-page 27

Getting Started Guide

4.2

Flowchart of the Program Code

START reset movwf OSCCAL clrf STATUS movlw 0x0F

OPTION movlw 0x08

TRIS GPIO main decfsz count,f goto main clrf GPIO

Copy Factory

Calibration Value to

Internal Clock

Oscillator and

Initialize Status

Enable Wake up On

Pin Change and

Internal Pull-ups

Make All

Input/Output (I/O)

Pins Output Except

GPIO3 (an input)

Delay for 256 Loops with 8-bit Count

Down from Zero

Around to Zero Again

Set All Outputs to

Zero (and Thus, Turn

Off All LEDs) keytst btfsc GPIO,3

SLEEP bsf GPIO,0

GPIO3 = 0?

(Is a Switch

Pressed?)

No

Go into low power

SLEEP mode. Wake up on button press and reset to START.

Yes

Set Left Switch = 1

(Left LED is On)

Right Switch = 0

Note that setting the left switch to 1 also lights the left LED temporarily.

btfsc GPIO,3 goto rht_key lft_key bcf bsf

GPIO,0

GPIO,4 goto main rht_key got main

DS00177C-page 28

Input = 0 or 1?

(Left/Right

Pressed?)

Input = 0

Right Switch Pressed,

Light Right LED

Turn Off Left LED

Input = 1

Left Switch Pressed,

Left LED

Stays On

Note that if the right LED is lit, the left

LED is now turned off. It will not have been on long enough to be visible.

This is an example of how one pin can serve two functions if the part is fast enough.

1999 Microchip Technology Inc.

GETTING STARTED GUIDE

Chapter 5. Demonstrating the Simulator

5.1

Asynchronous Stimulus

The simulator is designed to step through your code to view registers, stimulate pins, etc., for debugging code. Asynchronous Stimulus controls the pin state to either be a high (1) or low (0).

1.

To demonstrate this, you must first modify your code. Add a semicolon

(;) to line 17 as shown. The semicolon comments out the goto main statement, which allows skipping the delay loop. We are going to step through the code manually for demonstration purposes and do not wish to waste time stepping through 256 cycles of delay loop.

Note:

After this demonstration, remove the semicolon and reassemble the file or the proper delay will not occur for a programmed part.

1999 Microchip Technology Inc.

DS00177C-page 29

Getting Started Guide

2.

Next, from the pull-down menu, select

Project>Build All

.

3.

If everything has been performed correctly, a

Build Results

window will appear indicating “Build Completed Successfully.” Click close to continue. The close button is the ‘X’ box in the upper right hand corner of the window.

Note:

If the

Build Results

window indicates errors, recheck your typing of the source code in the source file or, double-click on the error, and the cursor will be placed inside the source file near the location of the error.

DS00177C-page 30

1999 Microchip Technology Inc.

4.

Next, from the pull-down menu, select

Window>Special Function

Registers

. The

Special Function Register

window will now open. This window allows us to see the “GPIO” port.

5.

Select

Debug>Simulator Stimulus>Asynchronous Stimulus

to open the

Asynchronous Stimulus

window. This window enables you to assign a pin to a button.

1999 Microchip Technology Inc.

DS00177C-page 31

Getting Started Guide

6.

Move both of the

Special Function Registers

and

Asynchronous Stimulus Dialog

windows to allow you to view these along with your source file.

MPLAB™ should look like the figure shown.

7.

Next, move the mouse cursor to the

Asynchronous Stimulus Dialog

window. Right-mouse-click on the Stim 1 (P) button and select ‘Assign

Pin’.

DS00177C-page 32

1999 Microchip Technology Inc.

8.

The

Pin Section

window will appear, double-left-lick on GP3. You have just assigned a pin to the button.

9.

Now we want to assign an action to the botton. Move the mouse cursor over to the

Asynchronous Stimulus Dialog

window. Right-mouse-click on the GP3 (P) button and select ‘Toggle’.

1999 Microchip Technology Inc.

DS00177C-page 33

Getting Started Guide

10. Next, we will start stepping through your code. If you feel you need to start over at any time, press the F6 (Reset) key on your keyboard. Press

F6 (Reset) now or by

Debug>Run>Reset

.

You will notice the

Special Function Register

window has changed. The W register is highlighted in red indicating that the register has just been written to. Also in your “source file” a line is highlighted indicating that this is your next instruction to be operated. The highlighted text should be reset movwf OSCCAL

as shown in the figure below.

DS00177C-page 34

1999 Microchip Technology Inc.

1999 Microchip Technology Inc.

11. Take a look at the

Special Function Register

window, register gpio

. You will notice under the

Binary

column, there are a series of 1’s and 0’s, like this:

00001000

The first number 0 on the right is GP0. The second number 0 from the right is GP1, and so on. You will notice GP3 is a number 1. This indicates that your Asynchronous Stimulus button is toggled high. If it is low (0), then pressing the button you assigned to this pin will toggle it high (1), after the next instruction is executed.

Now press the GP3 button to toggle the pin to low. Click back on your

Source Code

window then press F7 (Step) or

Debug>Run>Step

. Take a look at your

Special Function Register

window. GP3 has changed from a

1 to a 0.

Note:

To advance the

Source Code

and

Special Function Register

window, click on your source code window first, before pressing

F7 (Step).

DS00177C-page 35

Getting Started Guide

12. Next, step through your code by pressing F7 (Step) until you reach keytst

. In your

Special Function Register

window, check your

GPIO register. If GP3 is 1, it will step to the next line sleep

. If GP3 is 0, it will skip sleep

and go to bsf

and keep running code.

DS00177C-page 36

13. Now, press the GP3 button. GP3 again will change from a low (0) to a high (1).

Note:

To advance the

Source Code

and

Special Function Register

windows, click on your source code window first, before pressing F7

(Step).

Now advance the code 10 times by pressing F7 (Step) ten times while viewing the

Source Code

. Notice how the code stops advancing, and the highlighted line stays at bsf

. You are in sleep

mode. See “Sleep Mode” and “Animate” on page 37 for more information.

Notice in the schematic, provided in Appendix A, that two different

switches are being read by one pin. The simulator only simulates the function of one switch here.

1999 Microchip Technology Inc.

5.2

Sleep Mode

Sleep Mode is a power-down mode for conserving battery life. In this program, sleep mode will only happen when GP3 is a 1 or when neither switch is pressed. When sleep mode occurs, it will stop running code and keep incrementing

T0PRE

. You can press F7 (Step) indefinitely and there will not be any change except to

T0PRE

. To wake it from sleep

, you have to toggle GP3 from a high (1) to a low (0). Once you do that, the code will return to the reset

routine, and continue to run code as normal.

5.3

Animate

Another useful feature of the MPLAB Simulator is Animate. It allows the simulator to step through the code automatically without user interaction. You can view movement in code, changes in registers, etc.

1.

From the pull-down menu, select

Debug>Run>Animate

. The code will start animating or stepping through the code automatically. Press F5

(Halt) to end Animate.

1999 Microchip Technology Inc.

DS00177C-page 37

Getting Started Guide

5.4

Watch Windows

Watch Windows are used to view registers that are declared at the beginning of the program, that are not already listed in the

Special Function Registe

r window. You may have noticed that there is one in the power1.asm code you wrote called “count.”

1.

To create a Watch Window for “count,” select

Window>New Watch

Window

.

2.

The

Add Watch Symbol

window will appear. Type in or select “count,” and then click on Properties button.

DS00177C-page 38

1999 Microchip Technology Inc.

1999 Microchip Technology Inc.

3.

The

Properties

window will appear. Select

Binary

under

Format

, then click OK.

4.

In the

Add Watch Symbol

window click on Add then Close.

5.

Your watch window should look like the figure below. Now stepping through your code using F7 (Step) will allow you to view that particular register without guessing what value is in it.

DS00177C-page 39

Getting Started Guide

5.5

Break Points

Break points allows the program to stop in “Run” or “Animate” mode at a specified location in your source code for debugging.

1.

To demonstrate, move your mouse cursor over to

OPTION

(line 12 in the source code). Right-mouse-click, and select Break Point(s).

2.

Next, press F6 (Reset), and then press F9 (Run). The code will run and stop at line 12 where option

is. Now you can view your registers at that moment of the program.

Other important areas not covered here include “Trace,” “Arm Counter,”

“Stimulus from a File,” and “Environment Setup.” These items are explained in the

MPLAB Users Guide

, the MPLAB Help Files or you can go to the web site www.microchip.com.

DS00177C-page 40

1999 Microchip Technology Inc.

MPLAB™ USER’S GUIDE

Chapter 6. Programming Your Code into the PIC12C509

1.

You are now ready to program your code into the PIC12C509 microcontroller. First, make sure you have removed the semicolon (;) in front of the goto main

statement, and then reassemble your code.

Otherwise, this delay will be “commented out” and you will not see the LED light correctly. Select

PICSTART Plus>Enable Programmer

from the pull-down menu.

2.

The

PICSTART Plus Device Programmer

window appears. Make sure that the PIC12C509 is selected. (If it is not, changing the processor may require you to close the project while the programmer resets. You can reopen the project after the correct device is selected.)

1999 Microchip Technology Inc.

DS00177C-page 41

MPLAB™ User’s Guide

3.

Select

Window>Program Memory Window

from the pull-down menu to bring the

Program Memory Window

to the front of your desktop. If the window is not open, select

Program>Memory

. Your screen should look like this:

4.

The

Program Memory Window

shows the actual opcodes and where they will go in the microcontroller’s program code space. You can change the display format by clicking on the “Document” icon in the upper lefthand corner of the program memory window and selecting Hex Code,

Machine Code or Disassembly Display.

DS00177C-page 42

1999 Microchip Technology Inc.

1999 Microchip Technology Inc.

5.

You are now ready to program the PIC12C509 microcontroller. At this time, you should familiarize yourself with the correct orientation of the

PIC12C509 part with respect to Pin 1 and the Zero Insertion Force (ZIF) socket on the PICSTART Plus Programmer. The chip has a notch at one end – designating pin one.

Once you have determined the correct orientation of the microcontroller, move the ZIF lever on the PICSTART Plus until the contacts open fully. The chip should be placed into the programmer ZIF socket at the top, with the notch oriented up.

Carefully place the PIC12C509 part into the programming socket of the

PICSTART Plus Programmer. Once the part is seated, move the lever to the closed position. This will firmly clamp the microcontroller pins and allow the part to be programmed.

Be sure pin 1 on the chip is oriented to pin 1 of the socket.

PICSTART

®

Plus

DEVELOPMENT PROGRAMMER

POWER

ACTIVE

18P

28P

8P

1

40P

Insert 8-pin PIC12C509 chip at the top of ZIF socket.

6.

To program the part, click on the Program button at the bottom of the

PICSTART Plus Device Programmer

window.

DS00177C-page 43

MPLAB™ User’s Guide

7.

The

Program/Verify

programming cycle.

window appears showing the status of the

8.

The programming cycle should take a few seconds. After completion, the

Program/Verify

window will indicate that a successful programming session has been completed.

DS00177C-page 44

9.

Once the microcontroller has been successfully programmed, remove it from the PICSTART Plus Programmer. You are now ready to insert the device into the “Pong Board.” The “Pong Board” schematic is located in

Appendix A.2.

Notice that the IC socket on the Pong Board also has a notch in it to help you locate Pin 1. When inserting the programmed chip into the socket, use care not to damage the pins as you push the chip into place.

The program you have just completed will cause the Pong Board to respond by lighting the right LED if the right key or both keys are pressed.

The left LED will light up if the left button is pressed. Otherwise, the board will go into a lower power

SLEEP

mode to conserve battery life.

1999 Microchip Technology Inc.

GETTING STARTED GUIDE

Appendix A. Programming a PIC12C509 MCU with the 8-pin Pong Game

You have successfully completed this tutorial, and would now like to do more with the Pong board

1

provided. A programming file, called 8pinpong.hex

2

has been provided on the floppy disk accompanying this tutorial. With this file, you can program another PIC12C509, put it in the board, and play the Pong game. It is assumed that you have successfully completed the tutorial provided. We will therefore provide an abbreviated explanation on how to program the part for the Pong game.

1.

Close the open project if you have not already done so. No project is necessary for programming a part when the hex file is already provided.

Enable the PICSTART Plus programmer, and select the PIC12C509.

Open the

Program Memory

window (

Window>Program Memory

). Your screen should look like this:

1999 Microchip Technology Inc.

1. If you are using this tutorial separately from the kit that the Pong board is

included in, you can create your own using the schematic in Section A.2.

2. The 8-pin Pong .hex file is also available for download from www.microchip.com.

DS00177C-page 45

Getting Started Guide

2.

To change the display mode of the Program Memory window, click on its upper left corner (at the document icon) and select Hex Code, Machine

Code, or Disassembly Display. We have selected Disassembly Display here.

3.

To load the programming file into memory, select

File>Import>Download to Memory

, as shown below. Locate the file 8pinpong.hex from the floppy disk provided (or on your hard drive if you have copied it over) and select

OK. You should see the program memory window change to reflect the loaded program.

4.

Make sure that the Configuration Word options (refer to “About the

Demonstration Program” section for more details) shown in the

PICSTART Plus

window under

Device Specifications

are set as shown:

DS00177C-page 46

5.

Click the Program button. If the programming process was successful, you can now place the programmed part into the Pong Board, and you are ready to play.

1999 Microchip Technology Inc.

A.1

HOW TO PLAY THE 8-PIN PONG GAME

8-pin Pong is a one dimensional version of the original video game played on the 8 LEDs across the top of the board. Each player takes a button at each end of the board. The object is to press the button when the “ball” is at the end of the board. Pressing the button when the ball is at the end returns the ball to the other player. Swing too early or too late and the ball is missed. Winner serves; one point per play; the first player to reach 15 points wins.

The game begins with one of the right-most LED flashing, awaiting the serve.

The ball is served when the corresponding button is pressed. The ball then moves down the board to the other end. The other player must hit the ball when it gets to the last LED in order to return the ball. Play continues until a player misses the ball. A miss occurs when the ball is not in the last LED.

When the ball is hit just right, the ball takes off with a high speed return and the game shifts into high gear.

The score is displayed in binary format between plays for a second or two.

The left player's score is displayed on the left side of the board and right player's score on the right side. The game is to 15 points, and the winning score is flashed on the screen.

The game resets when both players press their buttons simultaneously.

The Pong game shuts itself off after 30 seconds of inactivity. Wake-up occurs when either button is pressed.

1999 Microchip Technology Inc.

DS00177C-page 47

Getting Started Guide

A.2

8-PIN PONG BOARD SCHEMATIC

D1 D2

R3

100

+3

3

4

1

2

U1

V

DD

GP5/OSC1/CLKIN

GP4/OCS2

GP3/MCLR/V

PP

V

SS

GP0

GP1

GP2/T0CK1

6

5

8

7

PIC12C5XX

R1

100

Left Paddle

S1

R1

100

Right Paddle

S2

D3

R4

100

D4 D5 D6

R5

100

D7 D8

R6

100

+3

J1

BR1216

DS00177C-page 48

1999 Microchip Technology Inc.

GETTING STARTED GUIDE

Appendix B. How to Get Help and Recommended Reading

This tutorial is by no means exhaustive. Important subjects not covered here include writing relocatable programs to be assembled to object files, linking object files, device specifications, complete instruction definitions, applications specific information, and much more.

If you are interested in continuing your familiarization with Microchip’s products and development tools, there are a number of items available to you for this purpose. You will find the literature listed in this section on the

Microchip CD-ROM and on the web site at www.microchip.com. Hard copies of most literature can be obtained from your local Microchip distributor or representative.

If you are interested in obtaining pricing, delivery, samples, literature or any other information, please contact the distributor or factory representative nearest you. A complete listing of these sales offices can be found on the

CD-ROM, the web site, and in the back of any Microchip product literature.

1999 Microchip Technology Inc.

DS00177C-page 49

Getting Started Guide

B.1

OTHER USEFUL LITERATURE FROM

MICROCHIP

Datasheets for all Microchip PICmicro products are available.

The datasheets include device specifications, description of device operation, instruction definitions, product ordering guides and more. Product datasheets can be found on the CD-ROM and the web site.

The Embedded Control Handbook, Volume I

(DS00092)

and II

(DS00167)

.

These books contain a complete collection of the Application Notes provided by Microchip to help you design your product. There are many introductory as well as advanced topics covered. Program examples are provided. These application notes can also be found on the CD-ROM and the web site.

The Mid-Range PICmicro MCU Reference Manual

(DS33023)

.

A guide to using the Microchip Mid-Range family and its peripherals. This is an extensive how to guide and a “must have” for anyone developing for the PIC16CXXX

MCU family.

MPLAB Tutorial

MPLAB IDE, Simulator, and Editor User’s Guide (DS51025)

MPASM User’s Guide with MPLINK and MPLIB (DS33014)

PICSTART Plus User’s Guide (DS51028)

There are extensive Help files installed with MPLAB, and found in the MPLAB

Program Group in windows. Some of these files are actually complete electronic versions of the User's Guides. Subjects include MPLAB, MPASM,

MPLAB-SIM and PICSTART Plus.

Device Errata documents are available from the web site under Datasheets.

In these documents Microchip provides the latest device errata and workarounds.

The latest version of MPLAB and its components can always be found on the

Microchip web site at: www.microchip.com.

DS00177C-page 50

1999 Microchip Technology Inc.

B.1.1

Additional Resources - Beginning Level

Easy PIC’n

(English)

David Benson/Square 1 Electronics

Phone: 707-279-8881 (US)

ISBN: 0-9654162-0-8

A Beginners Guide to the Microchip PIC

(English)

Nigel Gardner/ Bluebird Technical Press Ltd.

Phone: 800 718 1997 (US), +44 1536 201 201 (UK)

ISBN: 1-899013-01-6, Stock No: 07WX4611

PIC Cookbook Volume 1

(English)

Nigel Gardner/Peter Birnie/Bluebird Technical Press Ltd.

Phone: 800 718 1997 (US), +113 2636311 (UK)

ISBN: 1-899013-02-4, Stock No: 07WX4610

PIC Cookbook Volume 2

(English)

Nigel Gardner/Peter Birnie/Bluebird Technical Press Ltd.

Phone: 800 718 1997 (US), +113 2636311 (UK)

ISBN: 1-901631-00-1, Stock No: 46WX3136

The Greatest Little PIC Book

(English)

Gordon Mcnee/Bluebird Technical Press Ltd.

Phone: 800 718 1997 (US), +113 2636311 (UK)

ISBN: 1-901631-01-X

Getting Started with PIC Microcontrollers

(English)

Al Stevens/Ziggurat Technologies

Phone: ++ 27 11 7922187 (South Africa) [email protected]

PIC16C5X Introductory Course

(English)

Farsoft Computers cc

Phone: ++ 27 11 8289255 (South Africa) [email protected]

1999 Microchip Technology Inc.

DS00177C-page 51

Getting Started Guide

B.1.2

Additional Resources - Intermediate Level

Programming and Customizing the PIC Microcontroller

(English)

Myke Predko/McGraw-Hill

ISBN: 0-07-913646-X

PIC’n Up The Pace

(English)

David Benson/Square 1 Electronics

Phone: 707-279-8881 (US)

ISBN: 0-9654162-1-6

PIC’s in Practice

(English)

Francesco Volpe/Safinaz Volpe/Elektor Electronics

ISBN: 0-905705-51-3

Les Microcontrolleurs PIC et mise en oeuvre

(French)

Christian Tavernier/Dunod

Fax: +33 1 46 347 846 (France)

ISBN: 2-10-002647-X

Micontrolleurs PIC a structure RISC

(French)

C.F. Urbain/Publitronic

Fax: +33 1 20 486 964 (France)

ISBN: 2-86661-058-X

Pratique des Microcontroleurs PIC

(French)

Francesco Volpe/Safinaz Volpe/Publitronic Elektor

ISBN: 2-86661-077-6

Mit dem PIC-Controller Erfolgreich Arbeiten

(German)

Dr Anne Koenig/Manfred Koenig/Markt & Technik Verlag

Phone: 89 460 030 (Germany)

ISBN: 3-8272-5168-0

Mikrokontroller mit RISC Struktur

(German)

C.F Urbain/ Elektor Compact

ISBN: 3-928051-83-0

PIC uC Praxis

(German)

Francesco Volpe/Safinaz Volpe/Elektor Verlag

ISBN: 3-89576-030-7

La Programmazione dei Microcontrollori PIC

(Italian)

Andrea Sbrana

Phone: +39 544 464070 (Italy)

New Possibilities with the Microchip PIC

(Russian)

RIGA

Phone: +371 935 0550 (Latvia)

MicroControladores PIC

(Spanish)

Christian Tavernier/Paraninfo

Phone: 446-3350 (Spain)

ISBN: 84-283-2373-9

DS00177C-page 52

1999 Microchip Technology Inc.

GETTING STARTED GUIDE

Appendix C. Correcting PICSTART

®

Plus Communications Problems

The large majority of the time everything goes well. If you are experiencing any problems getting PICSTART

®

Plus to communicate, there are a few things you can do.

1.

The current version of PICSTART Plus does not work under Windows

®

NT. NT requires a special hardware driver that is not currently available from Microchip, but is planned for a future release.

2.

Make sure that the programmer has power and that the serial cable is connected correctly.

3.

Ensure that there are no conflicts with other devices. This often happens when you have a modem or other serial device that is improperly configured. If you believe you are experiencing this problem, consult your Windows manual or other reference literature. You can try removing, reconfiguring or disabling the conflicting device, but do so only if you are familiar with these tasks.

4.

Try connecting the PICSTART Plus to a different serial port. If your PC has a 25-pin serial port, you will need a 25- to 9-pin serial port adapter.

5.

On some systems errors occur because of driver and hardware incompatibility. Try changing Flow Control to Hardware and/or turning off the

FIFO for the serial port. In Windows 95 this is done in the Control Panel.

Click the System icon. Next, select the Device Manager tab, and select

Ports. (Note, this is also where you would look for conflicts) If necessary, expand the Ports selection by clicking the “+” sign next to it. Now double click on the I/O port that PICSTART Plus is connected to. Select the Port

Settings tab. This is where flow control can be set to Hardware. To turn off the FIFO, click the Advanced button. Deselect the Use FIFO box and click OK to save.

6.

If you have a COM port but MPLAB will not let you select it (the option is grayed out) you may be able to assign the port manually by editing the mplab.ini file. Typically, this occurs if you have an “opening” in your COM port list. (i.e., you have a COM1, COM2, and a COM4, but no COM3). In this case you may be able to fix it by opening mplab.ini (use the

Microsoft

®

Windows

®

FIND command to locate this file) and editing the section called [programmers] so that the setting

CommPort=1

is set to the port you want selected. This is just a work-around to a deeper problem in which windows is incorrectly reporting port availability through the

16-bit driver.

1999 Microchip Technology Inc.

DS00177C-page 53

Getting Started Guide

NOTES:

DS00177C-page 54

1999 Microchip Technology Inc.

1999 Microchip Technology Inc.

GETTING STARTED GUIDE

Appendix D. Glossary

To provide a common frame of reference, this Glossary defines the terms that follow.

Application

A set of software and hardware developed by the user, usually designed to be a product controlled by a PICmicro microcontroller (MCU).

Assembler Source Code

A text file that is processed by an assembler to produce a one-to-one correspondence between assembler instructions and PICmicro machine code.

Asynchronous Stimulus

Data generated in real-time by the user to simulate external inputs to the simulator.

Breakpoint

An address where real-time execution of the firmware loaded in program memory will halt.

Build

A function that recompiles all the source files for an application.

C Code

A program written in the high level language called “C,” and which will be converted into PICmicro machine code.

Caution

An alert that is provided to warn you of a situation that would cause physical damage to a device, software file, or equipment.

Compile

To translate a user’s “C” source text code into machine code.

Configuration Bits

Unique bits programmed to set modes of operation. A configuration bit may or may not be preprogrammed.

Data RAM

General purpose file registers from RAM on the PICmicro device being emulated. The File Register window displays data RAM.

Dynamic Data Exchange (DDE)

DS00177C-page 55

Getting Started Guide

The message protocol in Microsoft Windows that transfers information in realtime between windows applications. MPLAB acts as a DDE client that can transmit data to requesting applications, but cannot receive data from other applications.

EEPROM

Electrically Erasable Programmable Read Only Memory.

Emulation

The process of executing software loaded in the PICMASTER program memory on the emulator probe as if the firmware resided on the microcontroller device under development.

Emulation Memory

Program memory contained within the emulator.

Emulator

Hardware that performs emulation.

See Emulation

.

Emulator System

The Microchip Emulator System includes the PICMASTER Pod, the PC

Interface Card, a Probe Kit, PRO MATE Device Programmer, Demonstration

Board, Socket Module and the MPLAB Software.

Export

Send data out of MPLAB in a standardized format.

Extended Microcontroller Mode (PIC17CXXX Devices Only)

In extended microcontroller mode, on-chip program memory as well as external memory is available. Execution automatically switches to external if the program memory address is greater than the internal memory space of the PIC17CXXX device. Inaccessible memory in extended microcontroller mode includes fuses, test memory, and boot memory.

External RAM

Off-chip Read/Write memory.

File Registers

On-chip general purpose and special function registers.

Halt

The command that stops the emulator. Executing Halt is the same as stopping at a breakpoint. The program counter stops, and the user can inspect and change register values, and single step through code.

Hex Code

A file of executable instructions assembled or compiled from source code into standard hex format code. Hex code can be directly converted to object code.

DS00177C-page 56

1999 Microchip Technology Inc.

1999 Microchip Technology Inc.

High Level Language

A language for writing programs that is of a higher level of abstraction from the processor than assembler code. High level languages employ a compiler to translate statements into machine instructions that the target processor can execute.

IDE

Integrated Development Environment. An application that has multiple functions for software development. The MPLAB IDE integrates a compiler, an assembler, a project manager, an editor, a debugger, simulator, and an assortment of other tools within one Windows 3.1 application. A user developing an application should be able to write code, compile, debug and test an application without leaving the MPLAB desktop.

Import

Bring data into the MPLAB Integrated Development Environment (IDE) from an outside source

Logic Probes

Up to fourteen logic probes connect to the Emulator. The logic probes provide external trace inputs, external trace halt signal, trigger output signal, external break input signal, trace buffer clock, +5V, and a common ground.

Make Project

A command that rebuilds an application, re-compiling only those source files that have changed since the last complete compilation.

Microcontroller Mode

One of the possible program memory configurations of the PIC17CXXX family of microcontrollers. In microcontroller mode, only internal execution is allowed. Thus, only the on-chip program memory is available in microcontroller mode. Accessible memory includes: program memory, fuses, test memory and boot memory (FE00h to FFFFh).

Microprocessor Mode

One of the possible program memory configurations of the PIC17CXXX family of microcontrollers. In microprocessor mode, the on-chip program memory is not used. The entire 64K program memory is mapped externally. Inaccessible memory in microprocessor mode includes fuses, test memory, and boot memory.

MPLAB Software

The name of the main executable program that supports the IDE with an

Editor, Project Manager, and Emulator/Simulator Debugger. The MPLAB

Software resides on the PC host. The executable file name is MPLAB.EXE.

MPLAB.EXE calls many other files.

MRU

Most Recently Used. Refers to files and windows available to be selected from MPLAB main pull down menus.

DS00177C-page 57

Getting Started Guide

Object Code

The machine code that is produced from the source code after it is processed by an assembler or compiler. This code will be-the memory-resident code that will run on the PICmicro MCU in the user’s application.

Off-Chip Memory

Off-chip memory refers to the memory selection option for the PIC17CXXX device where memory may reside on the target board, or where all program memory may be supplied by the Emulator.

Options>Processor

Setup>Hardware

provides the Off-Chip Memory selection dialog box.

Pass Counter

A counter that decrements each time an event (such as the execution of an instruction at a particular address) occurs. When the pass count value reaches zero, MPLAB halts the processor. You can assign the Pass Counter to either break logic or to trace logic.

PC

Any IBM or compatible Personal Computer. MPLAB needs a 386 or better machine.

PC Host

The computer running Windows 3.x.

PC Interface Card

A Microchip proprietary parallel interface card allowing the MPLAB software residing on the PC to communicate with the PICMASTER emulator.

PICMASTER

The hardware unit that provides tools for emulating and debugging firmware applications and is also referred to as the Emulator, and PICMASTER. This unit contains Emulation memory, breakpoint logic, counters, timers, and a trace analyzer among some of its tools.

PICmicro

PICmicro refers to the PIC12CXXX, PIC16CXXX, and PIC17CXXX Microchip microcontroller families.

Pod

The external emulator box that contains emulation memory, trace memory, event and cycle timers, and trace/breakpoint logic. Occasionally used as an abbreviated name for the PICMASTER Universal In-Circuit Emulator.

Power on Reset Emulation

A software randomization process that writes random values in data RAM areas to simulate uninitialized values in RAM upon initial power application.

DS00177C-page 58

1999 Microchip Technology Inc.

1999 Microchip Technology Inc.

Probe

A device specific interface between the simulator and the target application.

The probe connects to the emulator via a ribbon cable, and the target application board connects to the probe via a ribbon cable. The probe is sometimes called the header board.

Program Counter

A register that specifies the current execution address.

Program Memory

Memory in the emulator containing the downloaded target application firmware.

Project

A set of source files to build the object code for an application.

Prototype System

A term referring to a user’s target application, or target board.

Radix

The number base, hex, or decimal, used in selecting an address and for entering data in the

Window > Modify

command.

Run

The command that releases the emulator from halt, allowing it to run the application code and change or respond to I/O in real time.

SFR

Special Function Registers.

Simulator

A software program that models the operation of the PICmicro microprocessor.

Simulator Stimulus

Data generated to exercise the response of simulation to external signals.

Often the data is put into the form of a list of actions in a text file.

Single Step

This command steps though code, one instruction at a time. After each instruction, MPLAB updates register windows, watch variables, and status displays so you can analyze and debug instruction execution.

You can also single step C compiler source code, but instead of executing single instructions, MPLAB will execute all assembly level instructions generated by the line of the high level C statement.

Source

Source code, usually a text file of assembly instructions or C code.

DS00177C-page 59

Getting Started Guide

Special Function Registers

Registers that control I/O processor functions, I/O status, timers, or other modes or peripherals.

Stack

“Push-Down” list of calling routines. Each time a PICmicro microcontroller executes a call, the software pushes the return address to the stack. A RET or

RETLW command pops the address from the stack.

Static RAM, or SRAM

Static Random Access Memory. Program memory you can Read/Write on the target board that does not need refreshing frequently.

Step-Into

This command is the same as Single Step. Step-Into (as opposed to Step-

Over) follows a CALL instruction into a subroutine.

Step-Over

Step-Over allows you to debug code without stepping into subroutines. When stepping over a CALL instruction, the next breakpoint will be set at the instruction after the CALL. If for some reason, the subroutine gets into an endless loop or does not return properly, the next breakpoint will never be reached.

The Step-Over command is similar to Single Step except for its handling of

CALL instructions.

Stopwatch

A 48-bit counter for measuring execution cycles.

Symbol

An label usually produced by an assembler or compiler that refers to machine locations by function names, variable locations, constant declarations, source line-number, or other reference to user source code.

System Button

The System Button is located in the upper left corner of Windows and some dialogs. This button usually has “Minimize”, “Maximize”, and “Close.” In some

MPLAB windows, additional modes or functions can be found under the

System Button.

Target

Refers to a user application.

Target Application

Firmware residing on the target board.

Target Board

The circuitry and programmable device that makes up the target application.

DS00177C-page 60

1999 Microchip Technology Inc.

Target Processor

The microcontroller device on the target application board that is being emulated or simulated.

Template

Lines of text that you build for inserting into your files at a later time. The

MPLAB Editor stores templates in template files.

Tool Bar

A row or column of icons that you can click on to execute MPLAB functions.

Trace

An emulator or simulator function that logs program execution in real-time.

Trigger Output

Trigger output refers to an output signal that can be generated at any address or address range, and is independent of the trace, arm, and breakpoint settings. Any number of trigger output points can be set. The trigger output signal is available on logic probe pin 13 (white probe tip).

Watchdog Timer

A timer on a PICmicro microcontroller that resets the processor after a selectable length of time.

Watch Variable

A variable that you may monitor during a debugging session. Watch windows contain a list of watch variables that are updated at each breakpoint.

1999 Microchip Technology Inc.

DS00177C-page 61

Getting Started Guide

NOTES:

DS00177C-page 62

1999 Microchip Technology Inc.

NOTES:

1999 Microchip Technology Inc.

DS00177C-page 63

W

ORLDWIDE

S

ALES AND

S

ERVICE

AMERICAS

Corporate Office

Microchip Technology Inc.

2355 West Chandler Blvd.

Chandler, AZ 85224-6199

Tel: 480-786-7200 Fax: 480-786-7277

Technical Support: 480-786-7627

Web Address: http://www.microchip.com

Atlanta

Microchip Technology Inc.

500 Sugar Mill Road, Suite 200B

Atlanta, GA 30350

Tel: 770-640-0034 Fax: 770-640-0307

Boston

Microchip Technology Inc.

5 Mount Royal Avenue

Marlborough, MA 01752

Tel: 508-480-9990 Fax: 508-480-8575

Chicago

Microchip Technology Inc.

333 Pierce Road, Suite 180

Itasca, IL 60143

Tel: 630-285-0071 Fax: 630-285-0075

Dallas

Microchip Technology Inc.

4570 Westgrove Drive, Suite 160

Addison, TX 75248

Tel: 972-818-7423 Fax: 972-818-2924

Dayton

Microchip Technology Inc.

Two Prestige Place, Suite 150

Miamisburg, OH 45342

Tel: 937-291-1654 Fax: 937-291-9175

Detroit

Microchip Technology Inc.

Tri-Atria Office Building

32255 Northwestern Highway, Suite 190

Farmington Hills, MI 48334

Tel: 248-538-2250 Fax: 248-538-2260

Los Angeles

Microchip Technology Inc.

18201 Von Karman, Suite 1090

Irvine, CA 92612

Tel: 949-263-1888 Fax: 949-263-1338

New York

Microchip Technology Inc.

150 Motor Parkway, Suite 202

Hauppauge, NY 11788

Tel: 631-273-5305 Fax: 631-273-5335

San Jose

Microchip Technology Inc.

2107 North First Street, Suite 590

San Jose, CA 95131

Tel: 408-436-7950 Fax: 408-436-7955

AMERICAS

(continued)

Toronto

Microchip Technology Inc.

5925 Airport Road, Suite 200

Mississauga, Ontario L4V 1W1, Canada

Tel: 905-405-6279 Fax: 905-405-6253

ASIA/PACIFIC

Hong Kong

Microchip Asia Pacific

Unit 2101, Tower 2

Metroplaza

223 Hing Fong Road

Kwai Fong, N.T., Hong Kong

Tel: 852-2-401-1200 Fax: 852-2-401-3431

Beijing

Microchip Technology, Beijing

Unit 915, 6 Chaoyangmen Bei Dajie

Dong Erhuan Road, Dongcheng District

New China Hong Kong Manhattan Building

Beijing 100027 PRC

Tel: 86-10-85282100 Fax: 86-10-85282104

India

Microchip Technology Inc.

India Liaison Office

No. 6, Legacy, Convent Road

Bangalore 560 025, India

Tel: 91-80-229-0061 Fax: 91-80-229-0062

Japan

Microchip Technology Intl. Inc.

Benex S-1 6F

3-18-20, Shinyokohama

Kohoku-Ku, Yokohama-shi

Kanagawa 222-0033 Japan

Tel: 81-45-471- 6166 Fax: 81-45-471-6122

Korea

Microchip Technology Korea

168-1, Youngbo Bldg. 3 Floor

Samsung-Dong, Kangnam-Ku

Seoul, Korea

Tel: 82-2-554-7200 Fax: 82-2-558-5934

Shanghai

Microchip Technology

RM 406 Shanghai Golden Bridge Bldg.

2077 Yan’an Road West, Hong Qiao District

Shanghai, PRC 200335

Tel: 86-21-6275-5700 Fax: 86 21-6275-5060

ASIA/PACIFIC

(continued)

Singapore

Microchip Technology Singapore Pte Ltd.

200 Middle Road

#07-02 Prime Centre

Singapore 188980

Tel: 65-334-8870 Fax: 65-334-8850

Taiwan, R.O.C

Microchip Technology Taiwan

10F-1C 207

Tung Hua North Road

Taipei, Taiwan, ROC

Tel: 886-2-2717-7175 Fax: 886-2-2545-0139

EUROPE

United Kingdom

Arizona Microchip Technology Ltd.

505 Eskdale Road

Winnersh Triangle

Wokingham

Berkshire, England RG41 5TU

Tel: 44 118 921 5858 Fax: 44-118 921-5835

Denmark

Microchip Technology Denmark ApS

Regus Business Centre

Lautrup hoj 1-3

Ballerup DK-2750 Denmark

Tel: 45 4420 9895 Fax: 45 4420 9910

France

Arizona Microchip Technology SARL

Parc d’Activite du Moulin de Massy

43 Rue du Saule Trapu

Batiment A - ler Etage

91300 Massy, France

Tel: 33-1-69-53-63-20 Fax: 33-1-69-30-90-79

Germany

Arizona Microchip Technology GmbH

Gustav-Heinemann-Ring 125

D-81739 München, Germany

Tel: 49-89-627-144 0 Fax: 49-89-627-144-44

Italy

Arizona Microchip Technology SRL

Centro Direzionale Colleoni

Palazzo Taurus 1 V. Le Colleoni 1

20041 Agrate Brianza

Milan, Italy

Tel: 39-039-65791-1 Fax: 39-039-6899883

11/15/99

Microchip received QS-9000 quality system certification for its worldwide headquarters, design and wafer fabrication facilities in

Chandler and Tempe, Arizona in July 1999. The

Company’s quality system processes and procedures are QS-9000 compliant for its

PICmicro ® 8-bit MCUs, K

EE

L

OQ

® code hopping devices, Serial EEPROMs and microperipheral products. In addition, Microchip’s quality system for the design and manufacture of development systems is ISO 9001 certified.

All rights reserved. © 1999 Microchip Technology Incorporated. Printed in the USA. 11/99 Printed on recycled paper.

Information contained in this publication regarding device applications and the like is intended for suggestion only and may be superseded by updates. No representation or warranty is given and no liability is assumed by Microchip Technology Incorporated with respect to the accuracy or use of such information, or infringement of patents or other intellectual property rights arising from such use or otherwise. Use of Microchip’s products as critical components in life support systems is not authorized except with express written approval by Microchip. No licenses are conveyed, implicitly or otherwise, under any intellectual property rights. The Microchip logo and name are registered trademarks of Microchip Technology Inc. in the U.S.A. and other countries. All rights reserved. All other trademarks mentioned herein are the property of their respective companies.

 1999 Microchip Technology Inc.

M icrochip Technolog y Inc.

2355 W es t Cha ndler Blvd.

Cha ndler, AZ 85224-6199

Tel: 480 .786.720 0 Fa x: 480 .899.9210

© 1999 M icrochip Technolog y Inc., Printed in the U.S.A 6/99 DS0 0 177

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project
