User Manual
www.samsung.com
About this manual
• This user manual describes procedures for using the touchpad
and mouse. Instructions for using the touch screen are for
models with the touch screen feature.
• This user manual is specially designed to detail the computer’s
functions and features.
• Images and screenshots are those of the representative model
of the series and may differ in appearance from the actual
product.
• The user manual supplied with the computer may vary
depending on the model.
• Content may differ from the final product and is subject to
change without prior notice. For the latest version of the
manual, refer to the Samsung website, www.samsung.com.
• Please read this manual before using the computer to ensure
safe and proper use.
• Optional items, some devices and software referred to in the
user manual may not be provided or subject to upgrades.
Note that the computer environment referred in the user
manual may not be the same as your environment.
• Descriptions are based on the computer’s default settings
and Windows 8.1 operating system. Available features and
additional services may vary by computer or operating
system.
2
About this manual
Instructional icons and
expressions
Copyright
© 2014 Samsung Electronics Co., Ltd.
This manual is protected under international copyright laws.
Warning: situations that could cause injury to yourself or
others
No part of this manual may be reproduced, distributed, translated,
or transmitted in any form or by any means, electronic or
mechanical, including photocopying, recording, or storing in any
information storage and retrieval system, without the prior written
permission of Samsung Electronics.
Caution: situations that could cause damage to the
computer or other equipment
Note: notes, usage tips, or additional information
Computer specifications or the contents of this manual may
be changed without prior notice due to an upgrade of the
computer’s functions.
The order of options or menus you must select to perform
a step. For example, select the Settings charm → Power
(represents select the Settings charm and then Power).
Select Click or touch. For example, when using a mouse or
touchpad, select Settings means click Settings. When
using a touch screen, it means touch Settings.
3
About this manual
Trademarks
HDMI, the HDMI logo, and the
term High Definition Multimedia
Interface are trademarks or
registered trademarks of HDMI
Licensing LLC.
• Samsung and the Samsung logo are trademarks or registered
trademarks of Samsung Electronics.
• Intel and Core are trademarks or registered trademarks of the
Intel Corporation.
As an ENERGY STAR® Partner,
Samsung has determined that this
product meets the ENERGY STAR®
guidelines for energy efficiency.
• Microsoft, MS-DOS, and Windows are trademarks or registered
trademarks of the Microsoft Corporation.
• Wi-Fi®, Wi-Fi Protected Setup™, Wi-Fi Direct™, Wi-Fi
CERTIFIED™, and the Wi-Fi logo are registered trademarks of
the Wi-Fi Alliance.
• The ENERGY STAR Program has reduced greenhouse gas
emissions and saved energy through voluntary labeling.
• All other trademarks and copyrights are the property of their
respective owners.
• Power management setting of this product have been
enabled by default, and have various timing settings from
1 minute to 5 hours.
• The product can wake with a button press on the chassis from
sleep mode.
4
About this manual
Caution for the data
Product capacity representation
Samsung Electronics shall not be liable for any data loss. Please
take care to avoid losing any important data and back up your
data to prevent any such data loss.
Storage capacity representation
The capacity of the storage device (HDD, SSD) of the manufacturer
is calculated assuming that 1KB=1,000 Bytes.
Operating system and software
support
However, the operating system (Windows) calculates the storage
device capacity assuming that 1KB=1,024 Bytes, and therefore the
capacity representation of the HDD in Windows is smaller than
the actual capacity due to the difference in capacity calculation.
For example, for an 80GB HDD, Windows represents the capacity
as 74.5GB, 80x1,000x1,000x1,000 byte/(1,024x1,024x1,024)byte =
74.505GB.
If you change the product’s factory OS (Operating System) to
another OS or if you install software which is not supported by the
product’s original factory OS, you will not receive any technical
support, product exchange or refund, and a fee will be charged
when requesting a service.
In addition, the capacity representation in Windows may be even
smaller because some programs such as Recovery may reside in a
hidden area of the HDD.
Please use your computer with the original factory OS. If you
install an OS other than the factory OS, data may be deleted or the
computer may not start.
Memory capacity representation
Recommended screen resolutions
The memory capacity reported in Windows is less than the actual
capacity of memory. This is because BIOS or a video adapter uses
a portion of memory or claims it for further use. For example,
for 1GB(=1,024MB) memory installed, Windows may report the
capacity as 1,022MB or less.
The recommended screen resolution for Windows is “FHD”
(1,920x1,080).
If you set the resolution higher than the recommended value, it
may result in problems with some applications, due to limitations
of the operating system.
5
Table of contents
Getting started
Basics
External devices
Appendix
7Layout
10 Charging the battery
13 Turning the computer on
and off
15 Unlocking the screen
30Keyboard
33Touchpad
37 LCD brightness
39Volume
40 Setup utility (BIOS)
52 External CD/DVD drive
54 Memory card
57 External display
70 Product specifications
71 Supported operating
systems
75Battery
77 Safety precautions
90 Important safety
information
93 Replacement parts and
accessories
95 Regulatory compliance
statements
113 WEEE symbol information
115 Samsung package TakeBack program
Windows
Network & Internet
16 About Windows
18Desktop
19Start screen
21 The Charms
23Applications
29 Microsoft account
29Store
46 Wireless LAN
Troubleshooting
59Recover/Backup
65 Windows recovery
function
65Q&A
Applications
48 Using applications
49Settings
50 Software Update
51 Samsung Link
6
Getting started
Number/Name
Camera indicator
light
• Indicates the camera status.
• Takes photos or videos.
Layout
Camera
• Features or options may differ depending on the model.
• Optional parts referred to in the manual may not be
provided or changed by the manufacturer.
Front view
1
Description
2
• Use the camera application on
the Start screen to take photos or
videos.
Microphone
• Use the built-in microphone.
LCD
• Displays the user interface.
Power button
• Press to turn the computer on.
Keyboard
• Press keys to enter data.
• Move the cursor and click options.
3
Touchpad
4
8
Power LED
5
• Works actions as those of a
mouse.
• Turns blue while the computer is
turned on.
• Shows the battery’s charging
status while the computer is
turned off.
– – Red: Battery charging is in
progress.
6
7
– – Green: Battery is fully
charged.
7
Getting started
Right view
Left view
1
Number/Name
2
1
Description
2
Number/Name
3
4
Description
• Connect the AC adapter to supply
the power to the computer.
Ear-set/Headset
jack
• Connect a headset or ear-set.
DC jack
USB 2.0 port
• Connect a USB device.
USB 3.0 port
• Connect a USB device.
HDMI port
• Connect external display devices
that support HDMI.
Micro SD Card
Slot
8
• This slot is for micro SD cards.
Getting started
Bottom view
Number/Name
Internal battery
• To remove or replace the internal
battery, take it to the Samsung
Service Center. You will be charged
for this service.
Speaker
• Emits sound from the computer.
1
2
2
9
Description
• Provides power to the computer
when not connected to an AC
adapter.
Getting started
3 Plug the power cable into an electric socket.
Charging the battery
► Type A
Charge the battery before using it for the first time. Use the AC
adapter to charge the battery.
• Use only Samsung-approved AC adapters, batteries,
and cables. Unapproved adapters or cables can cause
the battery to explode or damage the computer.
3
• Incorrectly connecting the charger may cause serious
damage to the computer.
2
1
To restore the battery power after cutting it, connect the
AC adapter.
► Type B
1 Connect the power cable to the AC adapter.
2 Connect the AC adapter to the DC jack of the computer.
2
10
1
Getting started
4 After charging, disconnect the AC adapter from the computer.
5 Unplug it from the electric socket.
The Power LED light turns on.
When charging is complete, the Power LED turns green.
• This computer is equipped with an internal battery.
The battery is not user-serviceable or user-replaceable.
• To have battery removed or replaced safely, take the
device to a Samsung Service Center. You will be charged
for this service.
• You can use the computer while it is charging, but
the battery charging time may increase. If the battery
temperature rises too much, the charging may stop as a
safety measure.
Power LED
Status
• Red: Charging
• Green: Fully charged
• Blue: Turned on
• No color: AC adapter not connected
11
Getting started
Battery status
Battery usage time
Move the cursor over the battery icon on the taskbar to view the
current battery charge when disconnecting the AC adapter from
the computer.
Batteries are replacement items and over time the battery’s
capacity to hold a charge and its power level is reduced. If a
battery can only hold its charge for half of the time that it could
when new, it is recommended to purchase a new, replacement
battery.
5 hr 21 min (64%) remaining
ENG
10:00 AM
When not using the battery for extended periods, charge the
battery to 30-40 % of full charge before storing it. This extends
battery life.
1/1/2014
Viewing the current battery charge when the
computer is turned off
Connect or disconnect the AC adapter from the computer to view
the current battery charge when the computer is turned off.
10:00
2013/7/1
12
Getting started
3 Press the Power button.
Turning the computer on and off
The Power LED turns on.
Turning on
1 Before turning on the computer, charge the battery.
2 Open the LCD panel.
4 Activate Windows by following the on-screen instructions.
• The Windows activation screen appears only when turning
on the computer for the first time.
• The computer’s date and time may be incorrect when you
turn it on for the first time. They may also be incorrect if the
battery has been fully discharged or removed. To set the
date and time, go to the desktop taskbar and right-click
the clock area. Then, click Adjust date/time and set the
current date and time.
• To adjust the brightness of the screen, see LCD
brightness.
• To adjust the sound, see Volume.
13
Getting started
Turning off
Turning off on the Start screen
Turning off on the desktop
1 Select Power (
) at the upper-right corner of the Start
screen.
1 To select the Start button, do one of the following:
• Mouse: Right-click the Start button ( ) at the lower-left
edge of the desktop.
2 Select Shut down or sign out→ Shut down.
Start
• Save all the data before turning off the computer.
• Since the procedures to turn the computer off may
differ depending on the installed operating system,
please turn the computer off according to the
procedures for the purchased operating system.
2 Select Shut down.
14
Getting started
Unlocking the screen
Turning off on the Charms
1 To open the Charms, do one of the following:
To unlock the lock screen, do one of the following:
• Mouse: Click the lock screen.
• Touchpad/Mouse: Move the cursor to the upper- or lowerright edge of the screen.
Start
• Keyboard: Press any key.
• Touchpad: Tap the touchpad.
Start
2 Select the Settings charm → Power → Shut down.
10:00
Wednesday, January 1
If the account has a password, enter the password to log in after
unlocking the screen.
15
Windows
Help
To access the help, do one of the following:
• Mouse: Move the cursor to the upper- or lower-right edge of
the screen to open the Charms and select the Settings charm
→ Help.
About Windows
• Keyboard: On the desktop, press the F1 key.
Microsoft Windows is an operating system that is used to control
a computer. For optimal use of the computer, learn how to use the
operating system properly. It is best to learn how to use Windows
by using Windows Help and Support, and Help+Tips.
• Images and available features may differ depending on
the model and operating system.
• This manual is designed for Windows 8.1 and content
may differ depending on the OS version.
• The image displayed on the desktop screen may differ
between models and OS versions.
16
Windows
Help+Tips
Screens in Windows 8.1
On the Start screen, select Help+Tips.
The following two screens are provided: the Start screen and the
desktop.
Start
Desktop
You can control Windows menus with the mouse or with gestures.
Start
Start screen
17
Windows
Desktop
Number/Name
The desktop provides a layout that is similar to earlier versions of
Windows.
Open the
Charms
On the Start screen, select Desktop from the tiles.
The Charms
Start button
18
Description
• Opens the Charms that are hidden at
the right of the screen.
• To open the Charms, do one of the
following:
– – Touchpad/Mouse: Move the
cursor to the upper- or lower-right
edge of the screen.
• Refers to the menu that allows you
to search, share, connect to devices,
configure settings or switch to the
Start screen.
• Move to the Start screen. Right-click or
touch and hold this button to access
Windows features, such as shutting
down the system or opening the
Control Panel.
Windows
Start screen
Using the Start button
To quickly and conveniently access various features of Windows,
do one of the following:
Launch applications on the Start screen.
On the desktop, click the Start button ( ) or open the Charms and
select the Start charm.
• Touchpad/Mouse: Right-click the Start button ( ).
Start
Number
Name
• Control Panel
• File Explorer
• Power menu
• Start button
19
Windows
Number/Name
User account
Power
Search
Open the
Charms
The Charms
Description
• Refers to the currently-used user
account.
• Turn off the computer or select Sleep
mode and Restart.
• Search for applications, files, or
websites by entering keywords.
• Opens the Charms that are hidden at
the right of the screen.
Number/Name
Start button
• To open the Charms, do one of the
following:
– – Touchpad/Mouse: Move the
cursor to the upper- or lower-right
edge of the screen.
• Refers to the menu that allows you
to search, share, connect to devices,
configure settings or switch to the
Start screen.
Desktop
Description
• The Start button can be accessed only
with the mouse. Move the cursor to
the lower-left edge of the screen to
view the Start button ( ). Click the
button to switch to the most recent
application screen or the desktop.
Right-click this button to access other
Windows features, such as shutting
down the system or opening the
Control Panel.
• The application screen appears where
the list of applications installed on the
computer is displayed. The application
screen can be accessed only with the
touchpad or mouse.
• Switches to the desktop.
• Refers to the tiles of installed
applications.
App tiles
20
• Samsung Apps supplied with the
original factory product are compatible
with the product’s supported OS.
Changing the OS may result in limited
use of the Apps.
Windows
The Charms
• Keyboard: Hold down the Windows key ( ) and press the C
key.
The Charms let you search, share links and photos, connect
devices, and change settings. The Charms functions available may
differ between the Start screen and the desktop or applications.
+
Opening the Charms
• Touchpad: Swipe inward from the right edge of the touchpad.
To open the Charms, do one of the following:
• Mouse: Move the cursor to the upper- or lower-right edge of
the screen.
Start
Start
Start
21
Windows
Learning about the Charms
Settings charm
Use the following Charms to control the computer:
To configure the computer, open the Charms and then select the
Settings charm → an option.
Charm
Search
Share
Start
Devices
Settings
Description
• Search for applications, files, or
websites by entering keywords.
• Share various files with others.
Option
Network
• Return to the Start screen or open the
most recent application.
• Connect devices, such as printers or
displays or sync files with a mobile
device.
• Configure the computer, set application
options, or add accounts. See Settings
charm.
Volume
Keyboard
• Set the brightness of the screen.
• Set the interval at which an
application sends notices.
• Turn off the computer or select
Sleep mode and Restart.
• Set a language to enter text.
Change PC
settings
• Change more settings and
personalize the computer.
Brightness
Notifications
Power
22
Description
• Connect the computer to a
network to use the Internet or
share files with other devices.
• Adjust the volume level.
Windows
Applications
Opening running applications
1 On the Start screen, place the cursor in the upper-left corner
Opening or closing applications
of the screen until a small application image appears.
Swipe from the left edge of the touchpad towards the middle
of the touchpad or screen to show running applications.
On the Start screen, select an application icon to open it.
• Touchpad/Mouse: Select at the lower-left edge of the
desktop to view all applications.
2 Move the cursor down to display a list of running applications.
3 Select an application to open it.
Closing an application
To close an application, do one of the following:
Right-click over an application in the list and click Close to exit
the application.
• Touchpad/Mouse: Move the cursor to the upper-right
edge of the application screen and select .
23
Windows
App tiles
Grouping tiles
Tile position
To group tiles, select and hold a tile and drag it to an open space.
Then, drag other tiles to the new group.
To change the position of an app tile on the Start screen, select
and hold the tile and then drag it to a new position.
Start
Start
24
Windows
Naming a group
Editing tiles
1 To open menu items, do one of the following:
1 To select a tile and then an option, do one of the following:
• Touchpad/Mouse: On the Start screen, right-click any
area.
• Touchpad/Mouse: Right-click on the tile to edit.
2 Select an option.
2 Select Customize.
3 Select Name group on each group.
4 Enter a name with the keyboard or the on-screen keyboard,
• Unpin from Start: Delete the tile from the Start screen.
• Resize: Change the size of the tile.
• Pin to taskbar/Unpin from taskbar: Add the tile to or
delete the tile from the taskbar.
and then press the Enter key.
25
Windows
4 Drag the Screen Split Bar to change the screen split ratio.
Using split screens
1 On the Start screen, select an application.
2 To enter the split mode, do one of the following:
Weather app
Screen Split Bar
Store app
• Touchpad/Mouse: Place the cursor at the top corner of the
screen. Drag the cursor to the left or right.
3 Arrange the position of each split screen as desired.
Example: If the Weather application and the Store application are
running at the same time
26
Windows
Adding or removing an application on the
Start screen
Using the camera application
Use the camera application provided by Windows to take photos
or videos or edit photos.
1 To move to the applications screen, do one of the following:
• Touchpad/Mouse: Select
Start screen.
1 On the Start screen, select Camera ( ).
2 Select to take photos or select to take videos.
at the lower-left edge of the
2 Touch and hold or right-click an application.
Menu items will appear at the bottom of the screen.
3 Select Pin to start (
) or Unpin from Start( ).
Example: When removing an application on the Start screen
27
Windows
Viewing photos or videos
Editing photos
To view photos or videos, do one of the following:
1 Select a photo.
2 Swipe upward from the bottom edge of the screen.
• Mouse: Click the arrow symbol on the left of the screen.
Or, on the Start screen, select Photos ( ) → Camera Roll.
Alternatively, right-click the photo.
3 Select Edit and edit the photo.
Camera etiquette
• Do not take photos or videos of other people without
their permission.
• Do not take photos or videos where prohibited.
• Do not take photos or videos in places where doing so
may violate other people’s privacy.
28
Windows
Microsoft account
Store
Some Microsoft services, such as the Store, require a Microsoft
account. Create a Microsoft account to get the most from the
computer.
Purchase and download applications for the computer. Create a
Microsoft account to use this feature. See Microsoft account.
On the Start screen, select Store.
Before creating an account, the internet must be
connected.
1
• This feature may not be available depending on the
operating system.
• Samsung cannot resolve problems with applications
installed from the Store. Contact customer support for
the application.
Open the Charms and select the Settings charm → Change
PC settings. Or select PC settings on the Start screen.
2 Select Accounts → Connect to a Microsoft account, and
then follow the on-screen instructions to complete the
account setup.
• If you already have an account, sign in with the Microsoft
account.
• The registered Microsoft account on the computer cannot
be removed.
• Select Switch to a Local account to sign in the computer
with a Windows account.
29
Basics
Keyboard
Enter text or access computer functions with the keyboard.
• Images and available features may differ depending on the model and operating system.
• The keyboard layout may differ depending on the country.
Using hot keys
• Press the Fn Lock key and then press a hot key.
To use keyboard hot keys, do one of the following:
• Hold down the Fn key and press a hot key.
→
+
30
Basics
Hot key functions
Key/Icon
Key/Icon
Description
F9
F1
• Settings: Launch the Settings application.
F10
F2
• Screen brightness control: Adjust the
brightness level.
F11
F3
F4
F5
F6
F7
F8
F12
• LCD/External monitor: Switch between the
LCD and an external display device when an
external display device is connected to the
computer.
• Touchpad: Turn on or off the touchpad
function.
• Mute: Mute or unmute the audio.
Fn +
Description
• View running applications: View running
applications on the left side of the screen.
• Desktop screen: Switch to the desktop.
• Close a running application.
• Wi-Fi: Open the Settings charm → Network
option. Turn a Wi-Fi network on or off.
• Right-click: Perform the right-click function.
• Open the app commands of the selected
application on the Start screen.
If the hot keys do not work properly, install the Settings
application.
• Volume Control: Adjust the volume level.
31
Basics
Windows hot keys
Use hot keys to access functions conveniently in Windows.
Press the Windows key ( ) or the Alt key, and a hot key
simultaneously.
Key
Windows key ( )+D
Description
• Switch to the Start screen or the
most recent application.
• Switch to the desktop.
Windows key ( )+C
• Open the Charms.
Windows key ( )+L
• Lock the screen.
Windows key ( )+U
• Open Ease of Access Center.
• Opens the project menu (external
display connection) in the Devices
charm.
• Open advanced management tools.
Windows key ( )
Windows key ( )+P
Windows key ( )+X
• Close a running application.
Alt+F4
• To use this function, the Fn Lock key
must be turned off.
32
Basics
Touchpad
Clicking function
Tap the touchpad or press the left touchpad button.
Use the touchpad to move the cursor or select an item. The left
and right buttons of the touchpad act the same as the left and
right buttons of a mouse.
Tap
• Use the touchpad only with fingers. The touchpad will
not recognize actions of other objects.
or
Click
• Images and the touchpad layout may differ depending
on the model.
Basic touchpad functions
Double-clicking function
Moving
Double-tap the touchpad or press the left touchpad button twice.
To move the cursor, move a finger on the touchpad.
Tap-tap
or
33
Click-click
Basics
Right-clicking function
Gesture functions
To right-click an item, tap the touchpad with two fingers or press
the right touchpad button.
Opening Charms
To open the Charms, swipe from the right edge of the touchpad to
the middle.
Tap
or
Click
Dragging function
To move an icon or an app tile to a desired location, press and hold
it and then drag it to the target position with the left touchpad
button pressed.
Viewing running applications
To open running applications, swipe from the left edge of the
touchpad to the middle.
34
Basics
Scrolling
Pinching
To scroll up, down, left or right, swipe with two fingers on the
touchpad.
To zoom in, spread two fingers apart on a website, map, or image.
Pinch to zoom out.
or
Gesture functions using three or more fingers on the
touchpad are not available.
35
Basics
Configuring touchpad gestures
Touchpad lock
Configure touchpad gestures to use the touchpad more efficiently.
Hold down the Fn key and press the F5 key. You can lock the
touchpad.
Open the Charms and then select the Settings charm → Change
PC settings → PC and devices → Mouse and touchpad →
desired options.
+
To cancel touchpad gestures, drag the switches for corresponding
options to the left.
Some options in the touchpad settings may not be
available depending on the model.
36
Basics
LCD brightness
Controlling with Charms
Open the Charms, select the Settings charm →
slider.
Adjust the LCD brightness to reduce eye strain and save power.
, and drag the
Controlling with keyboard
• To dim the LCD screen, hold down the Fn key and press the
F2 key.
+
• The LCD screen is set to the brightest level
automatically when the AC adapter is connected. The
LCD screen gets dimmer automatically when the AC
adapter is disconnected to preserve battery power.
• To brighten the LCD screen, hold down the Fn key and press
the F3 key.
• The computer has an automatic screen brightness
adjustment to extend the battery usage time. When
necessary, the screen brightness is gradually adjusted.
To turn off this function, right-click any area on the
desktop and set at Graphics Properties.
+
37
Basics
Changing display mode
Set the optimal conditions for the screen, based on the activity.
1 On the Start screen, select .
2 Select Settings.
3 Select Display → Display Color → an option.
• Dynamic: This will make the picture clear and sharp.
• Standard: Standard picture mode.
• Movie: Switch to this mode when the ambient lighting is
dark or when watching movies.
• Movie (Bright): This will make a darker scene brighter for
distinction.
• Read: Suitable for reading electronic books.
• No Effect: This is the default picture mode.
38
Basics
Volume
• To mute or unmute the volume, hold down the Fn key and
press the F6 key.
Adjust the system volume or sound volume when playing music
or video.
+
Controlling with keyboard
• To turn down the volume, hold down the Fn key and press the
F7 key.
Controlling with Charms
+
Open the Charms, select the Settings charm →
slider.
• To turn up the volume, hold down the Fn key and press the
F8 key.
+
39
, and drag the
Basics
Setup utility (BIOS)
Learning the BIOS screen
The BIOS setup screen appears as shown below.
Define a boot password, change the boot priority, or configure the
installed chipsets.
• Incorrect settings may cause the system to malfunction
or crash.
System Time >
System Date >
• The BIOS setup screens, menus, and items may appear
differently depending on the model and BIOS version.
• BIOS setup functions are subject to upgrades.
Entering the BIOS screen
SATA Port 1
XXXX
CPU
CPU
CPU
CPU
Intel(R)
XXXX
XXXX GHz
Supported
Vender
Type Core
Speed
VT (VT-x)
Total Memory
Solt1 Memory
Solt2 Memory
XXXX MB
XXXX MB
XXXX MB
BIOS Version
MICOM Version
XXXX
XXXX
3 American Megatrends, Inc.
Aptio Setup Utility - Copy (C) 2012
1 Turn on the computer.
2 Before the Samsung logo (Samsung ATIV) appears, press the
Number
Name
• Setup items
• Setup tools
F2 key several times.
– – Help: View the help for BIOS set up.
• If the computer is password-protected, press the F2 key
several times before the password screen appears.
– – Default: Return to default settings.
– – Restore: Cancel changes.
• If the password screen or the Windows start screen
appears, restart the computer and try again.
– – Save: Save settings.
– – Exit: Exit BIOS setup.
• Help
40
Basics
Number
BIOS setup keys
Name
• Setup menu
Key
– – SysInfo: View the basic specifications of
the computer.
Description
/
• Change values.
/
• Move to another menu.
– – Advanced: Configure the chipsets and
additional functions.
Enter
• Select an item or enter a sub-menu.
– – Security: Configure security functions.
Space
– – Boot: Configure peripherals and
boot-related settings.
Esc
F1
• Change the slide button.
• Return to a higher level menu or to the Exit
menu.
• View the setup help.
F3
• Load the previous settings.
F9
• Load the default settings.
F10
• Save changes and exit the BIOS setup.
• The BIOS setup screen appears only in English.
• When using a keyboard, only certain keys will control
the BIOS setup screen.
41
Basics
Boot password
Setting passwords
Setting a password with the BIOS enhances protection against
viruses and hacking attacks.
There are three password settings available; Supervisor Password,
User Password, and HDD Password.
• Supervisor Password (low security level): This password is
required when turning on the computer or attempt to enter
the BIOS setup.
• Do not forget your password or expose it to others.
• If you forget the Supervisor Password or HDD
Password, request assistance from the service center. In
this case, a service fee will be charged.
• User Password (low security level): This password is required
to enter the BIOS setup. This password will be deactivated
automatically if the Supervisor Password is disabled.
• When you forget the User Password, disable the
Supervisor Password, and the User Password is also
automatically disabled.
• HDD Password (high security level): This password is required
to access the hard disk drive (HDD) from another computer.
This password may not be supported, depending on the
model.
42
Basics
6 Enter the password again to confirm it and select Ok.
7 Select Save → Yes to save and restart.
Setting a boot password
1 Turn on the computer.
2 Before the Samsung logo (Samsung ATIV) appears, press the
• To enable the Password On Boot option, set a
Supervisor Password and enter the password when
starting up the computer.
F2 key several times.
3 Access the Security menu.
4 Select a password type (Supervisor Password, User
• To change the HDD Password after setting it, restart
the computer.
• For some models, when the password entered message
appears in the Setup Notice window, select Ok to
complete the setup.
Password, or HDD Password).
If you cannot select an item or the HDD Password Frozen
message appears, hold down the Power button to restart
the computer. Then, press the F2 key several times before
the Samsung logo (Samsung ATIV) appears to enter the BIOS
setup screen.
5 Enter a password and select Ok.
The password can be up to 20 characters.
43
Basics
Removing a password
Boot priority
1 Turn on the computer.
2 Before the Samsung logo (Samsung ATIV) appears, press the
Change the boot priority from the BIOS setup.
1 Turn on the computer.
2 Before the Samsung logo (Samsung ATIV) appears, press the
F2 key several times.
F2 key several times.
3 Access the Security menu.
4 Select a password type (Supervisor Password, User
3 Access the Boot menu.
4 Select Boot Device Priority.
5 Click an option menu to open the list.
6 Select an option.
7 Select Save → Yes to save and restart.
Password, or HDD Password).
5 Enter the current password and select Ok.
6 Without entering any characters, select Ok → Ok.
For some models, to cancel the password, select Cancel in
the Setup Notice window.
Select Exit → Yes to restart without saving the changes.
To boot to DOS when using a USB device, enter the BIOS
setup, select the Boot menu, and set the Fast BIOS Mode
item to Off.
44
Basics
3 Select Advanced → Smart Battery Calibration.
Using the Battery Calibration Function
When charging/discharging the battery repeatedly for a short
time only, the battery usage time may be reduced by the
difference between the actual battery charge and the remaining
charge display.
In this case, the actual battery charge and the remaining charge
display will be the same by discharging the battery completely
using the Battery Calibration function, and then recharging it
again.
CPU Power Saving Mode
On
Touch Pad Mouse
USB Charge In Sleep Mode
On
Off
USB S3 Wake-up
Off
Smart Battery Calibration >
The screen images and terms may differ from actual
product depending on the computer model and driver
version.
Aptio Setup Utility - Copy (C) 2012 American Megatrends, Inc.
4 The Battery Calibration function is activated and the battery
1 Disconnect the AC power adapter after turning off the
is forcefully discharged. To stop the operation, press the <Esc>
button.
computer.
2 Turn the computer back on, and press the F2 key to enter the
This operation requires 3~5 hours depending on the battery
capacity and the remaining battery charge.
Setup screen.
45
Network & Internet
Wi-Fi networks
1 Open the Charms and then select Settings charm →
Wireless LAN
Networks
View Connection Settings
Connect the computer to a wireless network to use the Internet.
Airplane mode
Off
The descriptions below are for computer models with
a Wireless LAN card or device. A Wireless LAN device is
optional. The pictures in this manual may differ from the
actual product depending on the wireless LAN device
model.
Wi-Fi
On
AP List
About Access Point (AP)
An Access Point (AP) is a network device that bridges wired
and wireless LANs and corresponds to a wireless hub in a wired
network. Multiple devices can be connected to an AP.
46
.
Network & Internet
2 Select a network from the list of detected wireless networks
Airplane mode
→ Connect automatically → Connect.
Airplane mode disables all wireless functions on the computer.
Only non-network services are available in Airplane mode.
Networks
• This computer uses a non-harmonized frequency and
is intended for use in all European countries. The WLAN
can be operated in the EU without restriction indoors,
but cannot be operated outdoors.
View Connection Settings
Airplane mode
Off
Wi-Fi
• Turn off the WLAN feature when not in use to save
battery power.
On
Connect automatically
Connect
3 Enter a password, if necessary, and select Next.
Once the computer has been connected to a wireless
network, it will attempt to connect to it automatically when
it is available. For the network key, please ask the network
administrator.
47
Applications
• Some applications are available only in Windows 8.1
desktop mode.
Using applications
• Third-party software related services
For descriptions about and service requests for
third-party applications, please contact the relevant
manufacturer. Some troubleshooting actions in
response to service requests may not work depending
on the application manufacturer.
• Images and features may differ depending on the
model and the application version.
Applications include the software that make up the
operating system. Windows provides basic applications for
frequently-performed tasks.
• Applications that are provided by Samsung can be
installed from SW Update.
• Some applications may not be supported depending
on the model.
48
Applications
Settings
Settings, a Samsung integrated settings application, offers various
settings functions.
Images and features may differ depending on the model
and the application version.
1 On the Start screen, click
at the lower-left edge, and select
Settings.
2 Select an option to configure the corresponding function.
Menu
Description
System
Optimization
• Set system optimization settings.
Power Management
• Set power related settings.
Network
• Set network functions and settings.
Display
• Set the screen brightness and color.
Audio
• Set sound functions and settings.
Input
• Set input functions and settings.
• Set security options to prevent cyber
attacks.
• Set Max performance mode.
Security
General
49
About Max performance mode
Max performance mode sets
the device to maintain the best
CPU performance. If the device
is used in Max performance
mode for extended periods, the
temperature of the device may
increase.
Applications
Software Update
2 Read and agree to the User Agreement.
Install and update Samsung applications and drivers on the
computer easily and conveniently. This application enables the
user to search for or download the BIOS, drivers, and applications
over the Internet. Keep the computer performing better and more
stably with SW Update.
3 Select Install & Update.
After installation, this step appears only once after the
application runs for the first time.
• To check for available updates, the computer must be
connected to the Internet.
• Only applications that have been installed with this
application can be updated.
• Images and features may differ depending on the
model and the application version.
1 On the Start screen, click
at the lower-left edge, and select
SW Update.
4 Select items to update → OK.
50
Applications
Samsung Link
Samsung Link enables the user to use the computer as cloud
storage and access it via a Samsung mobile device. Set folders
to share, and view and manage the shared folders anywhere
anytime.
On the Start screen, select Samsung Link.
Refer to the application help for more information.
51
External devices
Inserting and ejecting a CD or DVD
1 Press the Eject button to open the tray.
External CD/DVD drive
This computer supports external CD/DVD drives with USB
interfaces (optional). Check if the interface type of the external
CD-ROM drive is a USB type.
Connecting the drive
Number
Description
• Emergency aperture
Connect the drive to the USB port of the computer.
• Eject button
• Status indicator light
2 Insert a CD or DVD.
3 Push the tray inward until it clicks.
The status indicator turns on.
52
External devices
• Do not insert warped, cracked, or heavily scratched
disks. Doing so can damage the drive.
• Your external drive may differ from the images used in
this manual.
• Do not eject disks while the status indicator light is on.
• If the drive will not open when the power is off, insert
) into the emergency
the end of a paper clip (
aperture to open the tray manually.
• When cleaning a CD or DVD, wipe it with a soft cloth
from the inside edge towards the outside edge.
• Reading and writing speeds may differ depending on
the condition and type of media.
• A CD or DVD that is not in the shape of a circle is not
recommended.
53
External devices
• Some memory cards may not be fully compatible with
the computer. Using an incompatible card may damage
the computer or the memory card, or corrupt the data
stored in it.
Memory card
Use a memory card to transfer data to other digital devices, such
as digital cameras. Memory cards are sold separately. Purchase a
memory card with the necessary capacity for the requirement.
• Use caution to insert the memory card in the indicated
direction.
This computer supports the following types of memory cards.
Abbreviation
Description
mini SD
• mini Secure Digital
micro SD
• micro Secure Digital
mini SDHC
• mini Secure Digital High Capacity
micro SDHC
• micro Secure Digital High Capacity
micro SDXC
• micro Secure Digital eXtended Capacity
• Store the card separately to prevent losing the card
when moving the computer.
• Memory card speeds vary.
54
External devices
3 If a pop-up message appears, choose an action.
4 Select Open folder to view files.
5 Save, move, or delete data on the memory card.
Inserting a memory card
1 Remove the memory card slot cover.
2 Insert a memory card into the memory card slot in the
indicated direction.
The memory card folder opens only on the desktop.
Removing a memory card
Push the card gently until it disengages from the memory card
slot.
55
External devices
• To use a memory card to exchange data with a digital
device, such as a digital camera, formatting the data
with the digital device is recommended.
Formatting a memory card
Format the memory card to remove all data or before using it for
the first time.
• When trying to use a formatted memory card in
another digital device, format the memory card again in
the device.
Formatting a memory card deletes all data saved on
the card. If necessary, back up important data before
formatting the card.
• Inserting and removing a memory card repeatedly may
damage the memory card.
1 On the taskbar, select File Explorer ( ).
2 Right-click the memory card drive, and then select Format.
3 Select Start.
• Secure Digital Input Output (SDIO) is not supported.
• If the write-protect tab is in the locked position, you
cannot format, write, or delete data on the card.
56
External devices
External display
Connecting to a display
Connecting the computer to an external display device can be
useful for presentations or when watching a movie. The cables
required to connect an external display are sold separately. The
computer supports HDMI cables.
1 Connect the HDMI cable to the corresponding port of the
computer.
2 Connect the other end of the cable to the HDMI port of the
external display.
If the display has several HDMI ports, connect the cable to the
DVI IN port.
HDMI port
HDMI cable
• Check the available ports on the display device to
ensure that it is compatible with the computer.
• An external display is not supported when using DOS or
the Command Prompt window.
57
HDMI port
External devices
3 Connect the power cord to the external display.
4 Turn on the display and change its display mode to one that
You can also select a second screen mode in the control
panel. On the desktop, open the Charms and select the
Settings charm → Control Panel → Appearance and
Personalization → Display → Change display settings
→ Display → an option. For more information, refer to OS
help.
supports an external input.
5 On the computer, open the Charms and select the Devices
charm → Project → Second screen.
6 Select a mode.
• PC screen only: Show the interface on the computer
monitor only.
• Duplicate: Show the interface on both the computer
and the external display.
• Extend: Extend the screen to the external display.
• Second screen only: Show the interface only on the
external display.
58
Troubleshooting
• The Recovery application may not be supported on
models with less than 64 GB of disk space. For such
models, recover the computer to the factory default
settings by reinstalling Windows.
• Some functions may differ or may be unavailable,
depending on the version. Refer to the application’s
help for more information.
Recover/Backup
When a problem occurs with the computer, it is possible to easily
recover the computer back to the factory default settings by using
the Recovery application (Recover/Backup). It is also possible
to recover the computer to a previously backed up point. Back
up important data regularly before a problem occurs with the
computer.
• Run the Recovery application with administrator
privileges.
• CD/DVD drives are not supported by the Recovery
application.
• Recovering the computer erases the data or
applications saved after a backup point. Therefore, back
up important data regularly before a problem occurs
with the computer.
59
Troubleshooting
2 Select Backup Management → Factory image → Recover.
Recovering to factory default
Recover the computer to factory default settings. If necessary,
back up important data to an external storage device before
restoring the system. See Backing up the current system.
1 When the computer starts Windows: On the Start screen,
click
at the lower-left edge, and select Recovery.
When the computer does not start Windows: Turn on the
computer and press the F4 key several times before the
Samsung logo (Samsung ATIV) appears.
60
Troubleshooting
3 Select Recover.
Backing up the current system
Back up important data to an alternate internal drive or an
external storage device regularly to prevent data loss.
1 Select Backup Management → New backup.
4 Follow the on-screen instructions to complete the recovery.
61
Troubleshooting
3 Follow the on-screen instructions to complete the backup.
2 Select a drive from the drive list → Backup.
• When backing up to an external storage device, connect
the device to the computer and then select the external
drive.
Recovering after a backup
Select a backup point saved on an alternate internal drive or an
external storage device to recover the computer to the point.
1 When backing up to an external storage device, connect the
device to the computer.
2 On the Start screen, click
Recovery.
62
at the lower-left edge, and select
Troubleshooting
3 Select Backup Management → a backup image → Recover.
Copying the drive (making a disk image)
To replace the drive, move the data to the new drive by making a
disk image. The new drive must be large enough to hold the data
from the current drive.
Purchase an external hard drive connector separately to connect
the new drive to the computer.
1 Connect the new drive to the computer with an external hard
drive connector.
2 On the Start screen, click
Recovery.
4 Follow the on-screen instructions to complete data recovery.
3 Select Disk copy.
63
at the lower-left edge, and select
Troubleshooting
5 After the data is saved to another drive, open the cover at the
4 Select a recovery point → Disk copy.
bottom of the computer and replace the existing drive with
the new one.
The data on the disk is copied to the new disk.
If the cover is difficult to open, contact the Samsung Service
Center to request assistance. You will be charged for this
service.
64
Troubleshooting
Windows recovery function
Q&A
If the Recovery application is not supported by the computer,
recover system to factory default settings using the recovery
function of Windows.
When experiencing problems with the computer, try these
solutions.
Windows
Reinstalling Windows will erase all data saved on the
computer. Back up application and personal data to an
external storage device before reinstalling Windows.
Where is the Shut down button?
1 Open the Charms and select the Settings charm → Change
Mouse:
PC settings → Update and recovery → Recovery.
• At the upper-right corner of the Start screen, select Power
( ) → Shut down.
2 Select Get Started under Remove everything and reinstall
• Open the Charms and select the Settings charm → Power →
Shut down.
Windows.
Select Get Started under Refresh your PC without affecting
your files to recover the computer while keeping photos,
videos, music files, and documents.
• Right-click the Start button, and then click Shut down or sign
out → Shut down.
3 Follow the on-screen instructions to proceed with the
reinstallation.
After a recovery, on the Start screen, click at the lowerleft edge, and select SW Update to install the necessary
Samsung applications.
65
Troubleshooting
My application disappeared from the Start screen.
How can I correct this?
How can I uninstall an application?
1 On the desktop, open the Charms and select the Settings
Mouse:
1 On the Start screen, click
charm.
2 Select Control Panel → Programs → Uninstall a program →
at the lower-left edge to view
an application → Uninstall.
installed applications.
2
Alternatively, right-click the Start button, and the select
Programs and Features.
Right-click an application, and then select Pin to start.
Select an application to uninstall → uninstall.
66
Troubleshooting
How can I change the screen settings, environment
settings, color, and so on?
How can I start my computer in DOS?
Configure the lock screen, Start screen, and account picture by
opening the Charms and selecting the Settings charm → Change
PC settings → PC and devices. To configure any other features,
on the desktop, open the Charms and select the Settings charm
→ Control Panel.
1 Turn on the computer.
2 Before the Samsung logo (Samsung ATIV) appears, press the
To start the computer in DOS via a USB device:
F2 key several times.
3 Select the Boot menu.
4 Set Fast BIOS Mode to Off.
5 Set Secure Boot Control to Off.
6 Set OS Mode Selection to CSM OS and then restart the
Why am I unable to run Active X in Internet Explorer
when I launch it on the Start screen?
The version of Internet Explorer that appears on the Start screen
complies with HTML5 web standards, so it does not support Active
X. Launch Internet Explorer on the desktop to view websites that
require Active X.
computer.
Can I remove Windows 8 or Windows 8.1 and install a
different operating system?
To install a different operation system on the computer,
change the BIOS settings first. For more information,
visit http://www.samsung.com → Customer support →
Troubleshooting and search for Windows 8 or Windows 8.1.
67
Troubleshooting
Screen resolution
Why is the capacity representation of the hard disk
drive (HDD) in Windows different from the product
specifications?
Text on the screen overlaps or looks small.
The capacity of the storage device (HDD or SSD) of the
manufacturer is calculated assuming that 1KB=1,000 Bytes.
However, the operating system (Windows) calculates the storage
device capacity assuming that 1KB=1,024 Bytes, and therefore the
capacity representation of the HDD in Windows is smaller than
the actual capacity. The capacity representation in Windows may
be smaller than the actual capacity because some applications
occupy a certain area of the HDD outside of Windows.
If the font size is set too large or small, text may not fit or may not
be legible on the screen.
In this case, on the desktop, right-click any area and select
Personalize → Display → an option under Change the size of all
items → Apply → Sign out now.
Recovery
For models with the Recovery application, the HDD capacity
representation in Windows may be smaller than the actual
capacity because the Recovery application uses a hidden area of
5-20 GB of the HDD to save the recovery image, and that hidden
area is not counted towards the total size available to Windows.
The size of the Recovery application varies by model.
What is a Recovery Area?
The computer has an additional partition for restoring data
or saving backup files (only for models with the Recovery
application). This partition is called a Recovery Area and it
includes a recovery image comprised of the operating system and
applications.
68
Troubleshooting
What is a recovery image?
This refers to specifications about the operating system, drivers,
and software that are converted to a data image. It is required
to recover the computer and is embedded in the computer’s
HDD. However, this is not provided for storage devices where the
capacity is less than 64 GB, due to their small capacities.
How can I recover a computer that does not have the
Recovery application?
Recover the computer with the recovery function provided by
Windows. Refer to the Recover Functionality item in the help for
more details.
69
Appendix
• Optional components may not be provided or different
components may be provided depending on the
model.
• The system specifications are subject to change without
notice.
Product specifications
• The Storage device capacity of a computer in which
Recovery is installed, is represented as smaller than the
product specification.
The system specifications may differ depending on the derived
models. For detailed system specifications, refer to the product
catalogue.
Item
Operating
environment
AC/DC rating
PC rating
• Replacement, addition, or upgrade of memory is
unavailable for this computer hardware.
Specification
• The amount of memory that Windows can use may be
smaller than the actual amount of memory available.
• Temperature: -5–40 °C for storage,
10–35 °C when operating
• Humidity: 5–90 % for storage,
20–80 % when operating
• Input: 100–240 VAC, 50–60 Hz
• Output: 12VDC 3.33A, 12VDC 2.2A
• 12VDC 3.33A(40W), 12VDC 2.2A(26W)
70
Appendix
Supported operating systems
System
Windows 8.1
Windows 7
Windows XP
Ergonomic tips
Maintaining a proper posture during computer use is very
important to prevent physical injury. Improper or prolonged
keyboard use may result in repetitive strain injury. Viewing the
monitor screen for extended periods of time may result in eye
strain. Therefore, please follow these guidelines carefully when
setting up and using the computer.
Supported
64 bit
• Yes
32 bit
• No
64 bit
• Yes
32 bit
• No
64 bit
• No
32 bit
• No
Back and neck
71
Appendix
Arms and hands
• Use an adjustable chair with firm, comfortable support.
• Adjust the height of your chair so that thighs are horizontal to
the floor and feet are flat on the floor.
• The back of the chair should support the lower back. Adjust
the backrest to fit your body properly.
• Sit back fully in your chair and straighten the back and neck.
Avoid leaning forward or craning your neck toward the
computer screen.
• Avoid using the computer while lying down or on your lap.
If the computer’s temperature increases, there is a danger of
burn injury.
• The instructions in this manual have been prepared
so that they can be applied to the range of needs of
general users. If the user is not included in the range,
the recommendations should be applied according to
the user’s needs.
• Images may differ from actual products.
72
Appendix
Eye position and display illumination
• When using the keyboard and touchpad, the shoulders
should be relaxed. The upper arm and forearm should form an
angle that is slightly greater than a right angle, with the wrist
and hand in almost a straight line.
• Use a light touch when typing or using the touchpad and
keep the hands and fingers relaxed. Avoid rolling the thumbs
under your palms or supporting the wrists on the desk while
typing.
cm
50
• Use an external keyboard and mouse when using the
computer for long periods. When using an external keyboard
and mouse, position the devices at the same height as the
computer and within comfortable reach.
• Position the screen at least 50 cm away from your eyes.
• Adjust the height of the screen so that its top edge is equal to
or just below the level of your eyes.
• Avoid setting the screen’s brightness settings excessively high.
• Keep the screen clean.
• If wearing glasses, clean them before using the computer.
• When referring to printed content while typing, use a static
paper holder to hold the paper at about the same height as
the monitor.
73
Appendix
Hearing and volume control
Operating conditions
• Take at least a 10 minute break every hour.
• Avoid using the computer in dark locations. Use the computer
with as much ambient light as you would when reading a
book.
• Indirect illumination is recommended. Use a curtain to
prevent reflections and glare on the screen.
VOLUME
Check your volume!
• Ensure that volume is not too loud before using headphones.
• While operating a computer and talking on the phone, use a
headset. Using the computer while holding a phone on your
shoulder or with your neck may lead to muscle strain or injury.
• Avoid using headphones for long periods of time.
• Keep frequently used items within reach.
• Default audio settings can be changed by software and driver
updates without your knowledge. Always recheck equalizer
and volume settings before listening to audio.
• Use the computer only within the temperature and humidity
ranges specified in this manual.
• To prevent possible hearing damage, do not listen at high
volume levels for long periods.
74
Appendix
Battery
Power Indicator Light (LED)
Center Holes
Charging the battery on an airplane
Power outlets may vary by airplane. Choose the connection
method that fits your circumstances.
220V Power Plug
110V Power Plug
Good Example O
The power plug and auto adapter figures may differ from
the actual products.
Using an AC power plug
Insert the power plug pins into the center of the power outlet.
Wrong Example X
• If the pins are not inserted into the centers of the holes, they
will not be fully connected. In this case, reconnect the power
plug.
• You must insert the power plug when the power indicator
light (LED) is lit green. If the plug is connected properly, the
power indicator light remains green.
Otherwise, the power indicator light turns off. In this case,
disconnect the plug, verify that the power indicator light is
green and then reconnect the power plug.
75
Appendix
Using an auto adapter
Using an airplane charging converter
When a 12VDC power supply is available a cigarette lighter socket
will be provided. Use the optional auto adapter to use the 12VDC
power supply.
Depending on the type of airplane you are travelling on, use the
auto adapter and charging converter. Insert the airplane power
input jack into the airplane’s power outlet.
1 Insert the cigarette lighter plug of the auto adapter into the
1 Connect the auto adapter’s DC plug to the computer.
2 Connect the airplane charging converter (optional) to the
cigarette lighter socket.
2 Connect the DC plug of the auto adapter to the power input
auto adapter (optional).
port of the computer.
3 Insert the airplane power input jack into the power outlet.
Cigar socket of the airplane
Power outlet of the airplane
Auto adapter
1
Auto adapter
2
Charging converter
1
2
Cigar plug
DC plug
DC plug
76
Cigar plug
2
DC jack
Appendix
Safety precautions
Warning
This safety information relates to computer use. To prevent injury
or damage to your computer, read the safety information before
using it. Some of the content may not be applicable to your
computer.
Failure to follow instructions marked with this symbol may cause
personal injury and even fatality.
Installation related
• Since this is commonly applied to Samsung Computers,
some pictures may differ from actual products.
Keep the computer at least 15 cm away from
any object.
• The term “product,” as used in this manual, refers to
basic components, such as the computer, battery,
adapter and optional accessories provided by
Samsung.
15cm
Failure to do so may result in computer
malfunction or injury.
Do not place or use the computer on slanted or
vibrating places.
Failure to do so may result in computer
malfunction or damage.
To avoid danger of suffocation, keep the plastic
bag away from infants and children.
Putting a plastic bag over the head may result in
suffocation.
NP v3.7
77
Appendix
Connect the power cord to the AC adapter
firmly.
Power related
The power plug and wall outlet figures may differ
depending on the country specifications and the product
model.
Otherwise, there is a danger of fire due to an
incomplete contact.
Use only the AC adapter supplied with the
product.
Handle the power cord with care.
• Do not touch with wet hands.
Using another adapter may cause the screen to
flicker.
• Do not use a damaged or loose power
cord.
Use only properly earthed electric sockets or
extension cords.
• Use only specified voltage/capacity.
• Firmly insert the power cable into the AC
adapter.
Connecting to unearthed electric sockets or
extension cords does not protect users from
earth faults. Unearthed electric sockets or
extension cords may cause electric shock or fire.
• Do not unplug the power cord by pulling
the cable only.
• Unplug the wall-mount AC adapter
(adapter and plug integrated type) from
the wall outlet while holding the body and
pulling it.
If water or other conductive substances (e.g.
liquid, dust, metal powders, pencil leads, etc.)
enter the product, disconnect the power cord
and contact the Samsung service center. For
notebook computers that are provided with
an external removable battery, separate the
battery also.
Failure to do so may result in electric shock
or fire.
Damage to the device within the computer may
cause electric shock or fire.
78
Appendix
Take care not to allow metal objects such as a
key or clip to touch the battery terminal (metal
parts).
Keep the power cord or outlet clean with a dry
towel so that they are not covered with dust.
Failure to do so may result in electric shock or
fire.
This may cause excessive current and result in
fire, burns, or damage to the battery.
Do not bend or damage the power cable or
the AC adapter with a heavy or sharp-edged
object.
If the product leaks, emits strange odors, or
swells, immediately stop using the product and
contact the Samsung Service Center.
A damaged cable or cord may result in electric
shock or fire.
Failure to do so may result in an explosion or fire.
Battery usage related
To use the computer safely, replace a dead
battery with a new, authorized battery.
Keep the battery, AC adapter, and the power
cord away from infants and pets.
Failure to do so may result in electric shock or
computer malfunction.
When removing the real time clock (RTC)
battery, keep it away from infants and children.
Use only Samsung-approved battery and AC
adapter.
If a child swallows the battery, the child may
suffocate. If this happens, immediately contact a
doctor.
Batteries or AC adapters that are not approved
by Samsung may malfunction from a defective
safety device, resulting in an explosion or fire.
79
Appendix
Never heat the product or put the product
into a fire. Do not put or use the product in a
hot location such as a sauna, inside a vehicle
exposed to heat, and so on.
Usage related
Do not use the computer on heated floors or
electric pads, or on beds, blankets, or cushions
that block the ventilation of the computer.
There is a danger of explosion or fire.
In these environments, be careful not to block
the vent of the computer, which is normally at
the side or bottom of the computer. A blocked
vent causes the computer to overheat, resulting
in an explosion, fire, burns, or computer
malfunction.
Before cleaning the computer, disconnect all
the cables that are connected to the computer.
For notebook computers that are provided
with an external removable battery, separate
the battery also.
Failure to do so may result in electric shock or
fire.
Do not use the computer in very damp
locations such as a bathroom.
Keep the product away from water or liquid.
Failure to do so may result in computer
malfunction or electric shock. Use the computer
within the recommended temperature and
humidity range (10–35 °C, 20–80 % RH).
Water or liquid entering the computer may cause
a short circuit inside the product, resulting in
electric shock or fire.
80
Appendix
If the product is dropped or broken, disconnect
the power cord and contact the Samsung
Service Center. For notebook computers that
are provided with an external removable
battery, separate the battery also.
Follow all instructions as specified in the user
manual.
Do not disassemble any other parts by yourself.
Failure to do so may result in computer
malfunction, electric shock, or fire.
Using a broken computer may result in electric
shock or fire.
Do not disassemble the power supply unit,
the AC adapter, or the battery under any
circumstances.
Do not touch the computer vents or the
connected AC adapter for extended periods
while the computer is on.
Failure to do so may result in electric shock, fire,
or an explosion.
Contact with the vent or the connected AC
adapter for extended periods may result in lowtemperature burns, such as redness on the skin.
Shut down the computer and disconnect all
cables before disassembling the computer. If
the notebook is an external and removable
battery type, remove the external battery.
Upgrade related
Failure to do so, may cause electric shock.
Do not attempt to upgrade the computer,
unless you are qualified.
Contact the Samsung Service Center or an
electrician.
81
Appendix
When carrying the notebook computer with
other items, such as the adapter, mouse, books
etc, take care not to press anything against the
notebook computer.
Storage and movement related
Do not close the LCD panel and put the
computer into a bag to move it when it is still
turned on.
If a heavy object is pressed against the notebook
computer, a white spot or stain may appear on
the LCD. Therefore, take care not to apply any
pressure to the notebook.
The computer may overheat and there is a
danger of fire. Shut the computer down properly
before moving it.
In this case, place the notebook computer in
a separate compartment away from the other
objects.
When using wireless communication (LAN,
Bluetooth, etc) always follow applicable
instructions. For example, airlines and
hospitals have strict requirements.
Avoid exposing a drive to magnetic fields.
Security devices with magnetic fields include
airport walk-through devices and security
wands. The airport security devices that check
carry-on luggage, such as conveyor belts,
use x-rays instead of magnetism and will not
damage a drive.
82
Appendix
Do not place a heavy object over the product.
Caution
This may cause a problem with the computer. In addition, the
object may fall and cause injury, or damage the computer.
Failure to follow instructions marked with this symbol may cause
slight injury or damage to the product.
Connect the power cord to a nearer consent when installing the
computer.
Installation related
If a problem occurs to the computer and disconnection from the
consent is delayed, there is a danger of electric shock or fire.
Do not block the ports (holes), vents, etc. of the product and
do not insert water or other conductive substances (e.g.liquid,
dust, metal powders, pencil leads, etc.).
Dispose of worn-out batteries properly.
• There is a danger of fire or explosion.
Damage to a component within the computer may cause electric
shock or fire.
• The battery disposal method may differ depending on
your country and region. Dispose of the used battery in an
appropriate way.
When using the computer with it lying on its side, place it so
that the vents face upwards.
Do not throw or disassemble the battery and do not put it into
water.
Failure to do so, may cause the internal temperature of the
computer to rise and the computer to malfunction or halt.
This may cause an injury, fire or explosion.
83
Appendix
Use only a battery authorized by Samsung.
Usage related
Failure to do so may cause an explosion.
Use the pen for its intended purpose only.
Avoid contact with metal objects such as car keys or clips when
keeping or carrying a battery.
Using the pen improperly may cause physical injury.
Do not place a candle, light cigar, etc. over or on the product.
Contact with a metal may cause excessive current and a high
temperature and may damage the battery or cause a fire.
There is a danger of fire.
Make sure to have the product tested by a safety service
engineer after repairing the product.
Charge the battery according to the instructions in the manual.
Failure to do so, may cause an explosion or fire from damage to
the product.
Authorized Samsung Repair Centers will carry out safety checks
after a repair. Using a repaired product without testing it for safety
may cause an electric shock or fire.
Do not heat the product(or battery) or expose it to heat (e.g.
inside a vehicle during the summer).
There is a danger of explosion or fire.
84
Appendix
In case of lightning, immediately turn the system off, disconnect
the power cord from the wall outlet and phone line from
modem. Do not use a modem or phone.
Do not drop, hit, or apply excessive force to the computer.
There is a danger of electric shock or fire.
Do not touch the antenna with electricity facility such as the
power outlet.
Connect only permitted devices to the connectors or ports of
the computer.
There is a danger of electric shock.
Failure to do so, may cause electric shock and fire.
When handling computer parts, follow the instructions on the
manual supplied with the parts.
Close the LCD panel only after checking if the notebook
computer is turned off.
Failure to do so, may cause damage to the product.
The temperature may rise and it may cause deformation of the
product.
If the computer emits smoke, or there is a burning smell,
disconnect the power plug from the wall outlet and contact
the Samsung Service Center immediately. If the notebook is
external, and removable battery type, remove the external
battery.
Failure to do so may result in physical injury or data loss.
Do not press the Eject Button while the CD-ROM drive is in
operation.
There is a danger of fire.
You might lose data and the disk might be suddenly ejected and
could cause an injury.
Do not use a damaged or modified CD.
There is a danger of damaging the product or personal injury.
85
Appendix
Keep the product away from magnetic fields.
Do not insert the fingers into the PC Card Slot.
There is a danger of injury or electric shock.
• Magnetic materials may cause the product to malfunction or
cause the battery to discharge.
Use recommended computer cleansing solution when cleaning
the product and only use the computer when it is completely
dried.
• The magnetism in the computer may damage the information
in the magnetic stripe cards such as credit cards.
Failure to do so may cause electric shock or fire.
Upgrade Related
Emergency disk eject method using paperclip should not
be used while the disk is in motion. Make sure to use the
emergency disk eject method only when the Optical Disk Drive
has stopped.
Take care when touching the product or parts.
The device may be damaged or you may be injured.
Take care not to throw or drop a computer part or device.
There is a danger of injury.
This may cause injury or damage to the product.
Do not place your face close to the Optical Disk Drive tray when
it is operating.
There is a danger of injury due to an abrupt ejection.
86
Appendix
Make sure to close the computer cover before connecting the
power after a reassembly.
Storage and movement related
There is a danger of electric shock if your body touches an internal
part.
Properly shut down, disconnect and secure the computer
cables before moving it.
Use parts authorized by Samsung only.
Failure to do so may damage the computer or cause someone to
trip over a loose cable.
Failure to do so, may cause fire or damage the product.
For long periods of not using the notebook computer, discharge
the battery and preserve as it is detached. (For external and
removable battery type)
Never disassemble or repair the product by yourself.
If the computer serviced or repaired by an unqualified technician,
the warranty will not cover the repair fees. There is a danger of
accident. Use authorized Samsung Service Centers.
The battery will be preserved at its best condition.
Do not operate or watch the computer while driving a vehicle.
To connect a device that is not manufactured or authorized
by Samsung, enquire at the Samsung Service Center before
connecting the device.
There is a danger of a traffic accident. Please concentrate on
driving.
There is a danger of damaging the product.
Be careful when closing the LCD panel.
Closing the LCD panel with any object (such as a pen) placed on
the device’s keyboard may break the LCD panel.
87
Appendix
Cautions on preventing data loss (Hard disk
management)
Causes that may damage the data of a hard disk drive and the
hard disk drive itself.
Take care not to damage the data on a hard disk drive.
• The data may be lost when an external impact is applied to
the disk while disassembling or assembling the computer.
• A hard disk drive is so sensitive to external impact that an
external impact may cause loss of data on the surface of the
disk.
• The data may be lost when the computer is turned off or reset
by a power failure while the hard disk drive is operating.
• The data may be lost and irrecoverable due to a computer
virus infection.
• Take extra care, because moving the computer or an impact
on the computer when it is turned on may damage the data
of the hard disk drive.
• The data may be lost if the power is turned off while running
an application.
• Samsung is not liable for any loss of data on the hard disk
drive.
• Sudden impact or movement to the computer while the hard
disk drive is operating, may cause files to be corrupted or bad
sectors on the hard disk.
To prevent data loss due to damage to the hard disk drive,
please back up the data frequently.
88
Appendix
LCD bad pixels principle of the computer
Samsung observes strict specifications regarding the quality
and reliability of the LCD. However, there is a small chance that
a few pixels may be bad. A large number of bad pixels can cause
problems with the display, but a small number of bad pixels does
not generally affect computer performance.
Samsung’s quality standards for bad pixels are as follows:
• Bright dot: 2 or fewer
• Black dot: 4 or fewer
• Combination (bright and dark): 4 or fewer
Cleaning the LCD screen
Clean the LCD screen with a soft cloth dampened with computer
cleansing detergent. When cleaning the screen, move the cloth in
one direction. Do not use excessive force. Doing so may damage
the LCD screen.
89
Appendix
Important safety information
Setting up the system
• Read and follow all instructions marked on the product and
in the documentation before operating the system. Retain all
safety and operating instructions for future use.
Safety instructions
The system is designed and tested to meet the latest standards for
safety of information technology equipment. However, to ensure
safe use of this product, it is important that the safety instructions
marked on the product and in the documentation are followed.
• Do not use this product near water or a heat source such as a
radiator.
• Set up the system on a stable work surface.
• The product should be operated only with the type of power
source indicated on the rating label.
Always follow these instructions to help guard against
personal injury and damage to the system.
• Ensure that the electrical outlet to power the equipment is
easily accessible in case of fire or short circuit.
• If the computer has a voltage selector switch, make sure that
the switch is in the proper position for your area.
• Openings in the computer case are provided for ventilation.
Do not block or cover these openings. Make sure you provide
adequate space, at least 6 inches (15 cm), around the system
for ventilation when setting up your work area. Never insert
objects of any kind into the computer ventilation openings.
90
Appendix
• Ensure that the fan vents on the bottom of the casing are
clear at all times. Do not place the computer on a soft surface,
doing so will block the bottom vents.
Care during use
• Do not walk on the power cord or allow anything to rest on it.
• Do not spill anything on the system. The best way to avoid
spills is to not eat or drink near the system.
• When using an extension cord with this system, make sure
that the total power rating on the products plugged into the
extension cord does not exceed the extension cord power
rating.
• Some products have a replaceable CMOS battery on the
system board. There is a danger of explosion if the CMOS
battery is replaced incorrectly. Replace the battery with the
same or equivalent type recommended by the manufacturer.
• For Notebooks with glossy display bezels the user should
consider the placement of the Notebook as the bezel may
cause disturbing reflections from surrounding light and bright
surfaces.
Dispose of batteries according to the manufacturers
instructions. If the CMOS battery requires replacement insure
that a qualified technician performs the task.
• When the computer is turned off, a small amount of electrical
current still flows through the computer.
To avoid electrical shock, always unplug all power cables,
remove the battery and modem cables from the wall outlets
before cleaning the system.
91
Appendix
• Unplug the system from the wall outlet and refer servicing to
qualified personnel if:
The instruction on safety operation of the computer
1 When installing and operating devices please refer to safety
– – The power cord or plug is damaged.
requirements in the user manual.
– – Liquid has been spilled into the system.
– – The system does not operate properly when the operating
instructions are followed.
2 Devices can be used only with the equipment specified in the
– – The system was dropped or the casing is damaged.
3 If any smell of burning or smoke is detected from the
technical specifications of the devices.
– – The system performance changes.
computer the unit should be switched off and battery
removed. The unit should be checked by a qualified
technician before reuse.
4 Service and repair of devices should be carried out by
authorized service centers.
5 Do not allow the portable computer to operate with the base
resting directly on exposed skin for extended periods of time.
The surface temperature of the base will rise during normal
operation (particularly when AC Power is present). Allowing
sustained contact with exposed skin can cause discomfort or
eventually a burn.
92
Appendix
Replacement parts and
accessories
Battery disposal
Do not put rechargeable batteries or products powered by
non-removable rechargeable batteries in the garbage.
Use only replacement parts and accessories recommended by
manufacturer.
Contact the Samsung Service Center for information on how to
dispose of batteries that you cannot use or recharge any longer.
Follow all local regulations when disposing of old batteries.
To reduce the risk of fire, use only No. 26 AWG or larger
telecommunications line cord.
THERE IS RISK OF EXPLOSION IF BATTERY IS REPLACED BY
AN INCORRECT TYPE.
Do not use this product in areas classified as hazardous.
Such areas include patient care areas of medical and
dental facilities, oxygen rich environments, or industrial
areas.
DISPORE OF USED BATTERIES ACCORDING TO THE
INSTRUCTIONS.
93
Appendix
Laser safety
Connect and disconnect the AC adapter
All systems equipped with CD or DVD drives comply with the
appropriate safety standards, including IEC 60825-1. The laser
devices in these components are classified as “Class 1 Laser
Products” under a US Department of Health and Human Services
(DHHS) Radiation Performance Standard. Should the unit ever
need servicing, contact an authorized service location.
The socket-outlet shall be installed near the equipment and shall
be easily accessible.
Do not unplug the power cord by pulling the cable only.
Power cord requirements
The power cord set (all plug, cable and AC adapter plug) you
received with your computer meets the requirements for use in
the country where you purchased your equipment.
• Laser Safety Note: Use of controls or adjustments or
performance of procedures other than those specified
in this manual may result in hazardous radiation
exposure. To prevent exposure to laser beams, do not
try to open the enclosure of a CD or DVD drive.
Power cord sets for use in other countries must meet the
requirements of the country where you use the computer. For
more information on power cord set requirements, contact your
authorized dealer, reseller, or service provider.
• Class 1M laser radiation when operating part is open.
Do not view directly with optical instruments.
• Class 3B invisible laser radiation when open.
Avoid exposure to the beam.
94
Appendix
Regulatory compliance
statements
General requirements
The requirements listed below are applicable to all countries:
• All power cord sets must be approved by an acceptable
accredited agency responsible for evaluation in the country
where the power cord set will be used.
Wireless guidance
• The power cord set must have a minimum current capacity
of 7A and a nominal voltage rating of 125 or 250 volts AC, as
required by each country’s power system. (USA only)
(If fitted with 2.4G band or 5G band)
Low power, Radio LAN type devices (radio frequency (RF)
wireless communication devices), operating in the 2.4GHz/5GHz
Band, may be present (embedded) in the notebook system. The
following section is a general overview of considerations while
operating a wireless device.
• The appliance coupler must meet the mechanical
configuration of an EN 60 320/IEC 320 Standard Sheet C7
(or C5) connector, for mating with appliance inlet on the
computer.
Additional limitations, cautions, and concerns for specific
countries are listed in the specific country sections (or country
group sections). The wireless devices in the system are only
qualified for use in the countries identified by the Radio Approval
Marks on the system rating label. If the country you will be using
the wireless device in, is not listed, please contact your local Radio
Approval agency for requirements. Wireless devices are closely
regulated and use may not be allowed.
95
Appendix
• Radio frequency wireless communication can interfere
with equipment on commercial aircraft. Current
aviation regulations require wireless devices to be
turned off while traveling in an airplane.
802.11ABGN (also known as wireless Ethernet or Wi-Fi)
and Bluetooth communication devices are examples of
devices that provide wireless communication.
The RF field strength of the wireless device or devices that may
be embedded in the notebook are well below all international
RF exposure limits as known at this time. Because the wireless
devices (which may be embedded into the notebook) emit less
energy than is allowed in radio frequency safety standards and
recommendations, manufacturer believes these devices are safe
for use. Regardless of the power levels, care should be taken to
minimize human contact during normal operation.
• In environments where the risk of interference to other
devices or services is harmful or perceived as harmful,
the option to use a wireless device may be restricted
or eliminated. Airports, Hospitals, and Oxygen or
flammable gas laden atmospheres are limited examples
where use of wireless devices may be restricted or
eliminated. When in environments where you are
uncertain of the sanction to use wireless devices, ask
the applicable authority for authorization prior to use or
turning on the wireless device.
Some circumstances require restrictions on wireless devices.
Examples of common restrictions are listed on the next page:
• Every country has different restrictions on the use of
wireless devices. Since your system is equipped with
a wireless device, when traveling between countries
with your system, check with the local Radio Approval
authorities prior to any move or trip for any restrictions
on the use of a wireless device in the destination
country.
96
Appendix
• If the system came equipped with an internal
embedded wireless device, do not operate the wireless
device unless all covers and shields are in place and the
system is fully assembled.
United States of America
• Wireless devices are not user serviceable. Do not modify
them in any way. Modification to a wireless device will
void the authorization to use it. Please contact the
manufacturer for service.
Do not touch or move antenna while the unit is transmitting or
receiving.
USA and Canada Safety Requirements and Notices
Do not hold any component containing the radio such that the
antenna is very close to touching any exposed parts of the body,
especially the face or eyes, while transmitting.
• Only use drivers approved for country in which the
device will be used. See the manufacturer System
Restoration Kit, or contact the manufacturer’s technical
support for additional information.
Do not operate the radio or attempt to transmit data unless the
antenna is connected; if not, the radio may be damaged.
Use in specific environments:
The use of wireless devices in hazardous locations is limited by the
constraints posed by the safety directors of such environments.
The use of wireless devices on airplanes is governed by the Federal
Aviation Administration (FAA).
The use of wireless devices in hospitals is restricted to the limits
set forth by each hospital.
97
Appendix
Explosive Device Proximity Warning
The Part 15 radio device operates on a non-interference
basis with other devices operating at this frequency. Any
changes or modification to said product not expressly
approved by Intel could void the user’s authority to
operate this device.
Do not operate a portable transmitter (such as a wireless
network device) near unshielded blasting caps or in
an explosive environment unless the device has been
modified to be qualified for such use.
Use On Aircraft Caution
Unintentional emitter per FCC Part 15
Regulations of the FCC and FAA prohibit airborne
operation of radio-frequency wireless devices because
their signals could interfere with critical aircraft
instruments.
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation.
Other wireless devices
Safety notices for other devices in the wireless network:
Refer to the documentation supplied with wireless Ethernet
adapters or other devices in the wireless network.
98
Appendix
This equipment has been tested and found to comply
with the limits for a Class B digital device pursuant to Part
15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses,
and can radiate radio frequency energy. If not installed
and used in accordance with the instructions, it may
cause harmful interference. If this equipment does cause
harmful interference to radio or television reception,
which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
If necessary, the user should consult the dealer or an experienced
radio/television technician for additional suggestions. The user
may find the following booklet helpful: “Something About
Interference.”
This is available at FCC local regional offices. Our company is not
responsible for any radio or television interference caused by
unauthorized modifications of this equipment or the substitution
or attachment of connecting cables and equipment other than
those specified by our company. The correction will be the
responsibility of the user. Use only shielded data cables with this
system.
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV
technician for help.
99
Appendix
Intentional emitter per FCC Part 15
Operation of this device is subject to the following two conditions:
(If fitted with 2.4 G band or 5 G band)
(1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including
interference that may cause undesired operation of the device.
Low power, Radio LAN type devices (radio frequency (RF) wireless
communication devices), operating in the 2.4 GHz/5 GHz Band,
may be present (embedded) in the notebook system. This section
is only applicable if these devices are present. Refer to the system
label to verify the presence of wireless devices.
Wireless devices are not user serviceable. Do not modify
them in any way.
Modification to a wireless device will void the
authorization to use it. Contact manufacturer for service.
Wireless devices that may be in the system are only qualified for
use in the United States of America if an FCC ID number is on the
system label.
This device is restricted to indoor use due to its operation in the
5.15 to 5.25 GHz frequency range. FCC requires this product to be
used indoors for the frequency range 5.15 to 5.25 GHz to reduce
the potential for harmful interference to co-channel Mobile
Satellite systems. High power radars are allocated as primary users
of the 5.25 to 5.35 GHz and 5.65 to 5.85 GHz bands. These radar
stations can cause interference with and/or damage this device.
100
Appendix
Health and safety information
RF exposure or SAR information can viewed on-line at http://www.
fcc.gov/oet/ea/fccid/. This site uses this product FCC ID number
on the outside of the product. Sometimes it may be necessary to
remove the battery pack to find number. Once you have the FCC
ID number for a particular product, follow the instructions on the
website and it should provide RF exposure information or values
for typical or maximum SAR for particular product.
Exposure to Radio Frequency (RF) Signals
Certification Information
This product can contain an embedded radio transmitter and
receiver. It is designed and manufactured not to exceed the
exposure limits for radio frequency (RF) energy set by the Federal
Communications Commission (FCC) of the U.S. government. These
FCC exposure limits are derived from the recommendations of two
expert organizations, the National Council on Radiation Protection
and Measurement (NCRP) and the Institute of Electrical and
Electronics Engineers (IEEE). In both cases, the recommendations
were developed by scientific and engineering experts drawn from
industry, government, and academia after extensive reviews of the
scientific literature related to the biological effects of RF energy.
For corresponding model only
The Specific Absorption Rate (SAR) is a measure of the rate of
absorption of RF energy by the human body expressed in units
of watts per kilogram (W/kg). The FCC wireless devices to comply
with a safety limit of 1.6 watts per kilogram (1.6W/kg).
SAR level of this device while operating can be well below the
maximum value. This is because the device is designed to operate
at multiple power levels so as to use only the power required to
reach the network. In general, the closer you are to a wireless base
station antenna, the lower the power output.
Before a new model is available for sale to the public, it must be
certified to the FCC that it does not exceed the exposure limit
established by the FCC. Evaluation per each model is performed
in positions and locations (e.g. at the bottom on the body) as
required by the FCC.
For body worn operation, this model meets the FCC RF exposure
guidelines when used with Samsung accessory designated for this
product. Non-compliance with the above restrictions may result in
violation of FCC RF exposure guidelines.
101
Appendix
Canada
The term “IC” before the equipment certification number only
signifies that the Industry Canada technical specifications were
met. To reduce potential radio interference to other users, the
antenna type and its gain should be so chosen that the equivalent
isotropically radiated power (EIRP) is not more than that required
for successful communication. To prevent radio interference
to the licensed service, this device is intended to be operated
indoors and away from windows to provide maximum shielding.
Equipment (or its transmit antenna) that is installed outdoors is
subject to licensing.
Unintentional emitter per ICES-003
This digital apparatus does not exceed the Class B limits for radio
noise emissions from digital apparatus as set out in the radio
interference regulations of Industry Canada.
Intentional emitter per RSS 210
This device complies with RSS 210 of Industry Canada. Operation
is subject to the following two conditions: (1) this device may
not cause interference, and (2) this device must accept any
interference, including interference that may cause undesired
operation of this device.
102
Appendix
When using IEEE 802.11a wireless LAN, this product is restricted to
indoor use due to its operation in the 5.15 to 5.25 GHz frequency
range. Industry Canada requires this product to be used indoors
for the frequency range of 5.15 GHz to 5.25 GHz to reduce the
potential for harmful interference to co-channel mobile satellite
systems. High power radar is allocated as the primary user of the
5.25 to 5.35 GHz and 5.65 to 5.85 GHz bands. These radar stations
can cause interference with and/or damage to this device.
(If fitted with 2.4G band or 5G band)
Low power, Radio LAN type devices (radio frequency (RF) wireless
communication devices), operating in the 2.4GHz/5GHz Band,
may be present (embedded) in your notebook system. This
section is only applicable if these devices are present. Refer to the
system label to verify the presence of wireless devices.
Wireless devices that may be in your system are only qualified for
use in Canada if an Industry Canada ID number is on the system
label.
The maximum allowed antenna gain for use with this device
is 6dBi in order to comply with the E.I.R.P limit for the 5.25 to
5.35 and 5.725 to 5.85 GHz frequency range in point-to-point
operation.
103
Appendix
Brazil
The power output of the wireless device (or devices), which may
be embedded in your notebook, is well below the RF exposure
limits as set by Industry Canada.
Este produto esta homologado pela ANATEL, de acordo com
os procedimentos regulamentados pela Resolucao 242/2000, e
atende aos requisitos tecnicos aplicados.
Operation of this device is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including
interference that may cause undesired operation of the device.
Este equipamento opera em caráter secundário, isto é, não
tem direito a proteção contra interferência prejudicial, mesmo
de estações do mesmo tipo, e não pode causar interferência a
sistemas operando em caráter primário.
To prevent radio interference to licensed service, this
device is intended to be operated indoors and away from
windows to provide maximum shielding. Equipment (or
its transmit antenna) that is installed outdoors is subject to
licensing.
Wireless devices are not user serviceable. Do not modify
them in any way. Modification to a wireless device will
void the authorization to use it. Contact manufacturer for
service.
104
Appendix
European Union
European radio approval information (for products
fitted with EU-approved radio devices)
European Union CE marking and compliance notices
This Product is a Notebook computer; low power, Radio LAN type
devices (radio frequency (RF) wireless communication devices),
operating in the 2.4GHz/5GHz band, may be present (embedded)
in your notebook system which is intended for home or office use.
This section is only applicable if these devices are present. Refer to
the system label to verify the presence of wireless devices.
Products intended for sale within the European Union are
marked with the Conformité Européene (CE) Marking, which
indicates compliance with the applicable Directives and European
standards and amendments identified below. This equipment also
carries the Class 2 identifier.
The following information is only applicable to systems labeled
.
with the CE mark
European Directives
Wireless devices that may be in your system are only qualified for
use in the European Union or associated areas if a CE mark
with a Notified Body Registration Number and the Alert Symbol is
on the system label.
This Information Technology Equipment has been tested and
found to comply with the following European directives:
• EMC Directive 2004/108/EC
The power output of the wireless device or devices that may be
embedded in you notebook is well below the RF exposure limits
as set by the European Commission through the R&TTE directive.
• Low Voltage Directive 2006/95/EC
• R&TTE Directive 1999/5/EC
The low band 5.15 - 5.35 GHz is for indoor use only.
Samsung Electronics (UK) Ltd, Euro QA Lab.
See 802.11b and 802.11g restrictions for specific countries
or regions within countries under the heading “European
Economic Area Restrictions” below.
Blackbushe Business Park Saxony Way, Yateley, Hampshire GU46
6GG United Kingdom
105
Appendix
EU R&TTE compliance statements
Nation
Česky[Czech]
Dansk[Danish]
Deutsch[German]
Nation
Description
Samsung tímto prohlašuje,
že tento Notebook PC je ve
shodě se základními požadavky
a dalšími příslušnými
ustanoveními směrnice 1999/5/
ES.
Undertegnede Samsung
erklærer herved, at følgende
udstyr Notebook PC overholder
de væsentlige krav og øvrige
relevante krav i direktiv 1999/5/
EF.
Hiermit erklärt Samsung, dass
sich das Gerät Notebook PC
in Übereinstimmung mit den
grundlegenden Anforderungen
und den übrigen einschlägigen
Bestimmungen der Richtlinie
1999/5/EG befindet.
Eesti[Estonian]
English
Español[Spanish]
106
Description
Käesolevaga kinnitab
Samsung seadme Notebook
PC vastavust direktiivi 1999/5/
EÜ põhinõuetele ja nimetatud
direktiivist tulenevatele teistele
asjakohastele sätetele.
Hereby, Samsung, declares
that this Notebook PC is in
compliance with the essential
requirements and other
relevant provisions of Directive
1999/5/EC.
Por medio de la presente
Samsung declara que el
Notebook PC cumple con
los requisitos esenciales
y cualesquiera otras
disposiciones aplicables
o exigibles de la Directiva
1999/5/CE.
Appendix
Nation
Ελληνική[Greek]
Français[French]
Italiano[Italian]
Latviski[Latvian]
Description
Nation
ΜΕ ΤΗΝ ΠΑΡΟΥΣΑ Samsung
ΔΗΛΩΝΕΙ ΟΤΙ Notebook PC
ΣΥΜΜΟΡΦΩΝΕΤΑΙ ΠΡΟΣ ΤΙΣ
ΟΥΣΙΩΔΕΙΣ ΑΠΑΙΤΗΣΕΙΣ ΚΑΙ ΤΙΣ
ΛΟΙΠΕΣ ΣΧΕΤΙΚΕΣ ΔΙΑΤΑΞΕΙΣ
ΤΗΣ ΟΔΗΓΙΑΣ 1999/5/ΕΚ.
Par la présente Samsung
déclare que l’appareil
Notebook PC est conforme aux
exigences essentielles et aux
autres dispositions pertinentes
de la directive 1999/5/CE.
Con la presente Samsung
dichiara che questo Notebook
PC è conforme ai requisiti
essenziali ed alle altre
disposizioni pertinenti stabilite
dalla direttiva 1999/5/CE.
Ar šo Samsung deklarē, ka
Notebook PC atbilst Direktīvas
1999/5/EK būtiskajām prasībām
un citiem ar to saistītajiem
noteikumiem.
Lietuvių[Lithuanian]
Nederlands[Dutch]
Malti[Maltese]
107
Description
Šiuo Samsung deklaruoja,
kad šis Notebook PC atitinka
esminius reikalavimus ir
kitas 1999/5/EB Direktyvos
nuostatas.
Hierbij verklaart Samsung dat
het toestel Notebook PC in
overeenstemming is met de
essentiële eisen en de andere
relevante bepalingen van
richtlijn 1999/5/EG.
Hawnhekk, Samsung, jiddikjara
li dan Notebook PC jikkonforma
mal-ħtiāijiet essenzjali u ma
provvedimenti oħrajn relevanti
li hemm fid-Dirrettiva 1999/5/
EC.
Appendix
Nation
Magyar[Hungarian]
Polski[Polish]
Português[Portuguese]
Slovensko[Slovenian]
Description
Nation
Alulírott, Samsung nyilatkozom,
hogy a Notebook PC megfelel
a vonatkozó alapvetõ
követelményeknek és az
1999/5/EC irányelv egyéb
elõírásainak.
Niniejszym Samsung
oświadcza, Ŝe Notebook PC
jest zgodny z zasadniczymi
wymogami oraz pozostałymi
stosownymi postanowieniami
Dyrektywy 1999/5/EC.
Samsung declara que este
Notebook PC está conforme
com os requisitos essenciais e
outras disposições da Directiva
1999/5/CE.
Samsung izjavlja, da je ta
Notebook PC v skladu z
bistvenimi zahtevami in
ostalimi relevantnimi določili
direktive 1999/5/ES.
Slovensky[Slovak]
Suomi[Finnish]
Svenska[Swedish]
108
Description
Samsung týmto vyhlasuje, že
Notebook PC spĺňa základné
požiadavky a všetky príslušné
ustanovenia Smernice 1999/5/
ES.
Samsung vakuuttaa täten
että Notebook PC tyyppinen
laite on direktiivin 1999/5/EY
oleellisten vaatimusten ja sitä
koskevien direktiivin muiden
ehtojen mukainen.
Härmed intygar Samsung
att denna Notebook PC står
I överensstämmelse med de
väsentliga egenskapskrav och
övriga relevanta bestämmelser
som framgår av direktiv
1999/5/EG.
Appendix
Nation
Íslenska[Icelandic]
Norsk[Norwegian]
Türkiye[Türkçe]
To view the EU Declaration of Conformity for this product (in
English only), go to: http://www.samsung.com/uk/support/main/
supportMain.do or http://www.samsung.com/uk/support then
search the model number of the product.
Description
Hér með lýsir Samsung yfir því
að Notebook PC er í samræmi
við grunnkröfur og aðrar kröfur,
sem gerðar eru í tilskipun
1999/5/EC.
Samsung erklærer herved
at utstyret Notebook
PC er i samsvar med de
grunnleggende krav og øvrige
relevante krav i direktiv 1999/5/
EF.
Bu belge ile, Samsung bu
Notebook PC’nin 1999/5/
EC Yönetmeliğinin temel
gerekliliklerine ve ilgili
hükümlerine uygun olduğunu
beyan eder.
If the Declaration of Conformity for the model you are interested
in is not available on our web-site, please contact your distributor
or below address.
[email protected]
Manufacturer information
Samsung Electronics Co., Ltd.
129, Samsung-Ro, Yeongtong-Gu, Suwon-City, Gyeonggi-Do,
443-742, Korea
Samsung Electronics Suzhou Computer Co., Ltd.
No. 198, Fangzhou Road, Suzhou Industrial Park, Jiangsu Province,
215021, China
Tel: +86-0512-6253-8988
Samsung Electronics Vietnam Co., Ltd.
Yen Phong 1, I.P Yen Trung Commune, Yen Phong Dist., Bac Ninh
Province, Vietnam
For the web or the phone number of the Samsung Service Center,
see the Warranty or contact the retailer where you purchased your
product.
109
Appendix
European economic area restrictions
The European variant is intended for use throughout the European
Economic Area. However, authorization for use is further restricted
in particular countries or regions within countries, as follows:
Local restriction of 802.11b/802.11g radio usage
Note to integrator: The following statements on local restrictions
must be published in all end-user documentation provided with
the system or product incorporating the wireless product.
General
European standards dictate maximum radiated transmit power
of 100 mW effective isotropic radiated power (EIRP) and the
frequency range 2400 – 2483.5 MHz.
Due to the fact that the frequencies used by
802.11b/802.11g wireless LAN devices may not yet be
harmonized in all countries, 802.11b/802.11g products
are designed for use only in specific countries or regions,
and are not allowed to be operated in countries or regions
other than those of designated use.
The low band 5.15 - 5.35 GHz is for indoor use only.
Belgium
For private use outdoors in public spaces, no registration is
necessary for distances less than 300 m. For distances greater
than 300 m, you must register with the Belgian Institute for Postal
services and Telecommunications (BIPT). For commercial use
outdoors, you must obtain a license from the BIPT. For registration
or licensing, please contact the BIPT.
As a user of these products, you are responsible for
ensuring that the products are used only in the countries
or regions for which they were intended and for verifying
that they are configured with the correct selection of
frequency and channel for the country or region of use.
Any deviation from permissible settings and restrictions in
the country or region of use could be an infringement of
local law and may be punished as such.
For other languages, refer to the corresponding manuals.
France
The low band 5.15 - 5.35 GHz is for indoor use only.
110
Appendix
RF Exposure
As SAR is measured utilizing the devices highest transmitting
power the actual SAR of this device while operating is typically
below that indicated above. This is due to automatic changes to
the power level of the device to ensure it only uses the minimum
level required to reach the network.
General Statement on RF energy
Your Notebook or Tablet PC contains a transmitter and a receiver.
When it is ON, it receives and transmits RF energy. When you
communicate with your Notebook or Tablet PC, the system
handling your connection controls the power level at which your
Notebook or Tablet PC transmits.
The World Health Organization has stated that present scientific
information does not indicate the need for any special precautions
for the use of mobile devices. The note that if you want to reduce
your exposure then you can do so by limiting the length of calls to
keep the mobile devices away from the head and body.
Specific Absorption Rate (SAR) certification information
This Notebook or Tablet PC embedded with wireless WAN or
wireless LAN is included a radio transmitter and receiver. It is
designed not to exceed the limits for exposureto radio waves
recommended by international guidelines. These guidelines were
developed by the independent scientific organization ICNIRP and
include safety margins designed to assure the protection of all
persons, regardless of age and health.
The guidelines use a unit a measurement known as the Specific
Absorption Rate, or SAR. The SAR limit for mobile devices is
2.0 W/kg and the highest SAR value for this device when tested at
the body was 0.002 W/kg.
111
Appendix
RTC caution
Limiting exposure to radio frequency (RF) fields
For individuals concerned about limiting their exposure to
RF fields, the World Health Organisation (WHO) provides the
following advice:
CAUTION : Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type recommended
by the manufacturer. Discard used batteries according to the
Manufacturer’s instruction.
Precautionary measures: Present scientific information does not
indicate the need for any special precautions for the use of the
Notebook PC. If individuals are concerned, they might choose
to limit their own or their children’s RF exposure by limiting the
length of connections, or using ‘hands-free’ devices to keep your
Notebook PC away from the head and body.
Further information on this subject can be obtained from the
WHO home page http://www.who.int/peh-emf
WHO Fact sheet 193: June 2000.
112
Appendix
WEEE symbol information
India only
For more information on safe disposal and recycling visit our
website www.samsung.com/in or contact our Helpline numbers 18002668282, 180030008282.
Correct disposal of this product (Waste Electrical &
Electronic Equipment)
(Applicable in countries with separate collection
systems)
This product is RoHS compliant.
This marking on the product, accessories or literature
indicates that the product and its electronic accessories (for
example, charger, headset, USB cable) should not be disposed of
with other household waste at the end of their working life.
To prevent possible harm to the environment or human health
from uncontrolled waste disposal, please separate these items
from other types of waste and recycle them responsibly to
promote the sustainable reuse of material resources.
Household users should contact either the retailer where
they purchased this product, or their local government office,
for details of where and how they can take these items for
environmentally safe recycling.
Business users should contact their supplier and check the terms
and conditions of the purchase contract. This product and its
electronic accessories should not be mixed with other commercial
wastes for disposal.
113
Appendix
USA only
Correct disposal of batteries in this product
(Applicable in countries with separate collection
systems)
This marking on the battery, manual or packaging
indicates that the batteries in this product should not be disposed
of with other household waste at the end of their working life.
Where marked, the chemical symbols Hg, Cd or Pb indicate
that the battery contains mercury, cadmium or lead above the
reference levels in EC Directive 2006/66. If batteries are not
properly disposed of, these substances can cause harm to human
health or the environment.
This Perchlorate warning applies only to primary CR (Maganese
Dioxide) Lithium coin cells in the product sold or distributed ONLY
in California USA.
“Perchlorate Material- special handling may apply, see
www.dtsc.ca.gov/hazardouswaste/perchlorate.”
Dispose unwanted electronics through an approved recycler.
To find the nearest recycling location, go to our website:
www.samsung.com/recyclingdirect
Or call, (877) 278-0799.
To protect natural resources and to promote material re-use,
please separate batteries from other types of waste and recycle
them through your local, free battery return system.
For battery recycling go to call2recycle.org; or call 1-800-822-8837.
Warning : This product contains chemicals known to the state of
California to cause cancer and reproductive toxicity.
114
Appendix
Samsung package Take-Back
program
In partnering with select recyclers, Samsung offers packaging
take-back at no cost to you.
Simply call the following number for the locations nearest you.
CRT Processing, LLC
(877) 278-0799
Kathy Severson – Logistics contact
Dispose unwanted electronics through an approved recycler.
To find the nearest recycling location, go to our website:
www.samsung.com/recyclingdirect Or call, (877) 278-0799
115
Some content may differ from the computer depending on the region, service provider, software version, or computer model, and is
subject to change without prior notice.
www.samsung.com
English. 04/2015. Rev. 1.4
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
