LCD Digital Color TV

LCD Digital Color TV

Operating Instructions

KDL-22L4000

© 2008 Sony Corporation

4-115-438-12(1)

LCD Digital Color TV

Owner’s Record

The model and serial numbers are located at the rear of the TV. Record these numbers in the spaces provided below.

Refer to them whenever you call upon your Sony dealer regarding this TV.

Model Name

Serial No.

WARNING

To reduce the risk of fire or electric shock, do not expose this TV to rain or moisture.

s The TV must never be exposed to dripping, splashing, or spilling liquids of any kind.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

ATTENTION

RISQUE DE CHOC ELECTRIQUE,

NE PAS OUVRIR

PRECAUCION

RIESGO DE CHOQUE ELECTRICO

NO ABRIR

This symbol is intended to alert the user to the presence of uninsulated “dangerous voltage” within the TV’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

This symbol is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the TV.

The TV shall not be exposed to dripping or splashing and no objects filled with liquids, such as vases, shall be placed on the TV.

Antenna grounding according to the National Electrical Code,

ANSI/NFPA 70

Ground clamps

Electric service equipment

NEC: National Electrical Code

Antenna lead-in wire

Antenna discharge unit (NEC Section

810-20)

Grounding conductors

(NEC Section 810-21)

Ground clamps

Power service grounding electrode system

(NEC Art 250 Part H)

MOISTURE

s Do not place liquid filled objects such as a vase or potted plant on the TV.

s Do not use a power line operated TV set near water; for example, near a bathtub, washbowl, kitchen sink, laundry tub, wet basement or near a swimming pool, etc.

CAUTION

To prevent electric shock and blade exposure, do not use this polarized AC plug with an extension cord, receptacle or other outlet unless the blades can be fully inserted.

Declaration of Conformity

Trade Name: SONY

Model: KDL-22L4000

Responsible Party: Sony Electronics Inc.

Address: 16530 Via Esprillo,

San Diego, CA 92127 U.S.A.

Telephone Number: 858-942-2230

This equipment complies with part 15 of the

FCC rules. Operation is subject to the following two conditions: (1) This equipment may not cause harmful interference, and (2) this equipment must accept any interference received, including interference that may cause undesired operation.

NOTIFICATION

This equipment has been tested and found to comply with the limits for a Class B digital equipment, pursuant to Part 15 of the FCC

Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: s s s s

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

Consult the dealer or an experienced radio/TV technician for help.

Pursuant to FCC regulations, you are cautioned that any changes or modifications not expressly approved in this manual could void your authority to operate this equipment.

The shielded interface cable recommended in this manual must be used with this equipment in order to comply with the limits for a digital equipment pursuant to Subpart B of Part 15 of

FCC Rules.

For customer in Canada

This Class B digital apparatus complies with

Canadian ICES-003.

Safety

s s s s s

Operate the TV only on 110-240 V AC.

Use the AC power cord specified by Sony and suitable for the voltage where you use it.

The plug is designed, for safety purposes, to fit into the wall outlet only one way. If you are unable to insert the plug fully into the outlet, contact your dealer.

If you will not be using the TV for several days, disconnect the power by pulling the plug itself. Never pull on the cord.

For details concerning safety precautions,

see “Important Safety Instructions” on page 3.

Installing

s s s s s s

The TV should be installed near an easily accessible power outlet.

To prevent internal heat buildup, do not block the ventilation openings.

Do not install the TV in a hot or humid place, or in a place subject to excessive dust or mechanical vibration.

Avoid operating the TV at temperatures below 41°F (5°C).

If the TV is transported directly from a cold to a warm location, or if the room temperature changes suddenly, the picture may be blurred or show poor color due to moisture condensation. In this case, please wait a few hours to let the moisture evaporate before turning on the TV.

To obtain the best picture, do not expose the screen to direct illumination or direct sunlight. It is recommended to use spot lighting directed down from the ceiling or to cover the windows that face the screen with opaque drapery. It is desirable to install the TV in a room where the floor and walls are not of a reflective material.

2

CAUTION

Use the following Sony TVs only with the following WALL-MOUNT

BRACKET.

Sony Wall-Mount Bracket Model No.

Sony TV Model No.

KDL-22L4000

SU-WL100

Use with other WALL-MOUNT BRACKET may cause instability and possibly result in injury.

To Customers

Sufficient expertise is required for installing the specified TV. Be sure to subcontract the installation to Sony dealer or licensed contractors and pay adequate attention to safety during the installation.

Note

This television includes a QAM demodulator which should allow you to receive unscrambled digital cable television programming via subscription service to a cable service provider. Availability of digital cable television programming in your area depends on the type of programming and signal provided by your cable service provider.

Trademark Information

Macintosh is a trademark of Apple Inc., registered in the U.S. and other countries.

HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC.

Fergason Patent Properties, LLC:

U.S. Patent No. 5,717,422

U.S. Patent No. 6,816,141

Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories.

Blu-ray Disc is a trademark.

“BRAVIA”, and are trademarks or registered trademarks of

Sony Corporation.

“PLAYSTATION” is a registered trademark and “PS3” is a trademark of

Sony Computer Entertainment Inc.

Your BRAVIA TV is ENERGY STAR qualified.

It meets strict energy efficiency guidelines set by the U.S. Environmental Protection Agency and Department of Energy. ENERGY STAR is a joint program of these government agencies, designed to promote energy efficient products and practices.

Important

Safety

Instructions

1) Read these instructions.

2) Keep these instructions.

3) Heed all warnings.

4) Follow all instructions.

5) Do not use this apparatus near water.

6) Clean only with dry cloth.

7) Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.

8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.

9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety.

If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.

10) Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.

11) Only use attachments/accessories specified by the manufacturer.

12) Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.

13) Unplug this apparatus during lightning storms or when unused for long periods of time.

14) Refer all servicing to qualified service personnel.

Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

(Continued)

CLEANING

When cleaning, be sure to unplug the power cord to avoid any chance of electric shock. s Clean the cabinet of the TV with a dry soft cloth.

Allow adequate space around the TV set to ensure proper air circulation.

s Never place the TV in a confined space, such as a bookcase or built-in cabinet, unless proper ventilation is provided.

s Wipe the LCD screen gently with a soft cloth.

s Stubborn stains may be removed with a cloth slightly moistened with a solution of mild soap and warm water.

s If using a chemically pretreated cloth, please follow the instruction provided on the package.

s Never use strong solvents such as a thinner, alcohol or benzine for cleaning.

s Periodic vacuuming of the ventilation openings is recommended to ensure to proper ventilation.

VENTILATION

The ventilation openings in the TV are necessary to ensure reliable operation of the TV and to protect it from overheating. s Do not block or cover the ventilation openings with cloth or other materials.

s Never place the TV on a bed, sofa, rug or other similar surface where ventilation openings may be blocked.

Leave some space around the TV set as shown below.

Otherwise, air-circulation may be inadequate and cause overheating, which may cause a fire or damage to the TV set.

Installed on the wall

11

7 /

8 inches

(30 cm)

4 inches

(10 cm)

Installed with stand

4 inches (10 cm)

4 inches

(10 cm)

Leave at least this much space around the set.

11

7

/

8 inches

(30 cm)

4 inches

(10 cm)

/

8

(6 cm)

4 inches

(10 cm) s Unless proper ventilation is provided, the TV may accumulate dust and cause damage.

s Never allow liquid or solid objects to fall into the ventilation openings.

s If any liquid or solid object falls inside the TV unplug the TV immediately and have it checked by qualified service personnel before operating it further.

s Never push objects of any kind into the TV through the ventilation openings as they may come in contact with dangerous voltage points or short out parts that could result in a fire or an electric shock.

Leave at least this much space around the set.

Never install the TV set as follows:

Air circulation is blocked.

Air circulation is blocked.

Wall Wall

4 4

CARRYING THE TV

Carry the TV in the specified manner

To avoid dropping the TV and causing serious injury, be sure to follow these guidelines: s Before carrying the TV, disconnect all cables.

s When you carry the TV, place your hand as illustrated and hold it securely. Do not put stress on the LCD panel.

s When carrying the TV, do not subject it to shocks or vibration, or excessive force.

INSTALLATION

The TV should be installed near an easily accessible AC power outlet.

s Do not install the TV face up or down, upside down or on its side.

s Do not install the TV in hot, oily, humid, or excessively dusty places.

s Do not install the TV in places subject to extreme temperature, such as in direct sunlight, near a radiator or a heating vent. The TV may overheat in such conditions and can cause deformation of the enclosure and/or cause TV malfunction.

Medical institutions

Do not place this TV in a place where medical equipment is in use. It may cause a medical equipment malfunction.

Outdoor use

Do not install this TV outdoors. The TV should not be exposed to rain or direct sunlight in order to avoid damage and possible fire or electric shock.

Do not install this TV in a vehicle, ship or other vessel

s Excessive bumping motion of a moving vehicle or continuous swaying motion on a boat may cause the TV to fall down and cause injury.

s Exposing the TV to seawater may cause a fire, electric shock or damage to your TV.

s Do not install the TV in a place exposed to direct air conditioning; moisture may condense inside and may cause TV malfunction.

s Do not install the TV where it may be exposed to mechanical vibration.

s Do not install the TV where insects may enter.

s Do not install the TV in a location where it may protrude, such as on or behind a pillar, or any place you might bump your head or receive bodily injury.

s To prevent fire keep flammable objects or open flame (e.g. candles) away from the TV.

s Do not place optional equipment on top of the TV.

Prevent the TV from toppling over

Take measures to prevent the TV from toppling over and causing injury, damage to the TV and property.

Magnetic influence

s This TV contains a strong magnet in the speaker unit that generates a magnetic field. Keep any items susceptible to magnetic fields away from the speaker.

s Electro-magnetic radiation emitted from optional equipment installed too closed to the TV may cause picture distortion and/or noisy sound.

Wall-mount use

s Wall-mount installation requires the use of a Wall-Mount Bracket. When installing or removing the TV and the Wall-Mount

Bracket, be sure to use qualified contractors. If not properly secured during installation or removal from the

Wall-Mount Bracket, the TV may fall and cause serious injury.

s Be sure to follow the installation guide supplied with the Wall-Mount

Bracket when installing the TV.

s Be sure to attach the brackets with the specified parts supplied with the

Wall-Mount Bracket.

s Do not hang the TV from the ceiling. It may fall and cause serious injury.

s Do not hang anything on the TV. s Do not allow children to climb on the TV.

s Secure the TV to a wall and/or stand.

s Never install the TV on unstable and/or uneven surfaces.

s Do not allow children to climb on or play with furniture and TV sets.

s Do not install the TV on furniture that can easily be used as steps, such as a chest of drawers.

s Care should be taken to install the TV where it cannot be pushed, pulled over, or knocked down.

s Care should be taken to route all AC power cords and connecting cables so that they cannot be pulled or grabbed by curious children.

5

(Continued)

5

AC POWER CORD

s Do not touch the AC power cord and its plug with wet hand, it may cause electric shock.

Do not use a damaged or poorly fitting AC power outlet as your TV’s power source.

s Insert the plug fully into the outlet. If it is loose, it may cause arcing and result in a fire.

s When disconnecting the AC power cord, grasp the plug and disconnect from the wall outlet first. Do not pull by the cord.

s Do not overload the same AC power outlet.

s Keep the power cord away from heat sources.

s Do not convert or damage the AC power cord.

s Consult your electrician to have the outlet changed to suit your TV.

Subjecting the AC power cord to wear and/or abuse can damage the AC power cord and your TV.

s Do not place the TV where the power cord can be easily pinched, bent, twisted, or catch your feet.

Unplugging the AC power cord from the wall outlet will completely remove power from the TV. s During lightning storms or when the TV is left unattended and unused for extended periods of time, the AC power cord should be unplugged from the wall outlet. This will avoid possible damage to your TV. Also unplug the antenna to prevent damage to the TV. s Do not allow anything to rest on or roll over the cord.

s Before connecting cables, be sure to unplug the AC power cord for your safety.

s Do not move the TV with the AC power cord (or other cables such as audio and video) connected.

s Use only an original Sony AC power cord with your TV; no brand substitution is allowed.

s Do not use AC power cord supplied with the TV with any other equipment.

s Never use a damaged AC power cord. A damaged AC power cord can cause a short-circuit, which may result in a fire or electric shock.

s For energy conservation and safety reasons, practice unplugging the

AC power cord from the AC power outlet.

Clean the AC power plug

Unplug the AC power plug and clean it occasionally to avoid dust from accumulating.

While cleaning, look for signs of damage. A damaged AC power cord should never be used.

ACCESSORIES

Keep small accessories out of children’s reach.

Use only the specified accessories with this TV.

Volume Adjustment

s When using headphones, adjust the volume to avoid excessive audio levels from causing possible hearing loss.

BATTERIES

Your remote control batteries are consumables.

s To preserve our environment, dispose of used batteries according to your local laws or regulations.

s Do not dispose of batteries in a fire.

s Do not short-circuit, disassemble or overheat the batteries.

s Replace only with the same or equivalent type of batteries. Using incorrect replacement batteries can lead to an explosion.

6 6

LCD SCREEN

s Although the LCD screen is made with high-precision technology and has effective pixels of 99.99% or more, black dots or bright points of light (red, blue, or green) may appear constantly on the LCD screen.

This is a structural property of the LCD panel and is not a malfunction.

s The LCD screen is made with high-precision technology and to achieve a high level of performance and picture quality, this TV’s backlight setting is set to maximize the brightness of the TV. However, uneven brightness may be observed when the LCD TV is viewed in a dark ambient without an input source or blank screen. This condition is normal and not a malfunction of the TV. Changing the Picture mode,

Backlight setting, or turning on the Power Management will improve this condition.

s To avoid damaging the LCD panel, do not expose the LCD screen to direct sunlight.

s Do not push or scratch the LCD screen, or place objects on top of the

TV. The images may be uneven or the LCD panel may be damaged.

s If the TV is used in a cold place, smear may occur in the picture or the picture may become dark. This does not indicate a failure. These phenomena improve as the temperature rises.

s Ghosting may occur when still pictures are displayed continuously. It should disappear after a few moments.

s The LCD screen and enclosure get warm when the TV is in use. This is not a malfunction.

s Avoid spraying insect repellent with volatile material on the LCD screen.

s Avoid prolonged contact with rubber or plastic material to the LCD screen.

Broken screen panel

Do not throw anything at the TV as the impact can cause the LCD screen glass to crack, break or scatter.

Safety check

s Upon completion of any TV servicing or repair, ask the service technician to perform routine safety checks as specified by Sony and to certify that the TV is safe to operate.

Have a qualified service technician dispose of the TV if it is not safe to operate.

For customers in the United States

Lamp in this product contains mercury. Disposal of these materials may be regulated due to environmental considerations. For disposal or recycling information, please contact your local authorities or the Electronics Industries Alliance

(www.eiae.org).

s If damage occurs to the LCD panel, small traces of liquid crystal sandwiched between the glass may be found on scattered broken glass.

s Do not touch the broken glass with bare hands. As with any broken glass pieces, avoid skin contact and exposure to your eyes or mouth.

Avoid direct contact with liquid or damp surfaces of the glass as these may have an adverse effect on some people. The contacted area should be rinsed thoroughly with water. If conditions persist, see your doctor.

s If the surface of the TV cracks, do not touch the TV until you have unplugged the AC power cord. Otherwise electric shock may result.

SERVICING

Do not use the TV if you suspect the TV is damaged or if the TV is damaged.

s Do not attempt to service the TV yourself since opening the cabinet may expose you to dangerous voltage levels or other hazards. Refer all servicing to qualified service personnel.

s If replacement parts are required, acquire a written certification from the service technician which states that adequate replacement parts with the same or similar characteristics as the original parts have been used. Unauthorized substitutions may result in a fire, an electric shock or other hazards.

7 7

Contents

Getting Started

Welcome to the World of

® ..........................................................................10

Picture Quality and Aspect Ratio .................................................................................10

Assembling the Table-Top Stand .................................................................................11

Connecting the TV .........................................................................................................13

Cable System or VHF/UHF Antenna System............................................................13

Cable System and VHF/UHF Antenna System .........................................................13

HD Cable Box/HD Satellite Box ................................................................................14

PC .............................................................................................................................15

Other Equipment .......................................................................................................16

When Connecting to Optional Equipment ...................................................................17

Securing the TV..............................................................................................................19

Preventing the TV from Toppling...............................................................................19

Recommended Measures to Secure the TV .............................................................19

Bundling the Connecting Cables ...............................................................................21

Setting Up the Channel List - Initial Setup...................................................................22

Basic Operations

Remote Control ..............................................................................................................23

TV Controls.....................................................................................................................26

Using the Menus

Overview of MENU .........................................................................................................27

Using the Picture Settings ............................................................................................27

Using the Sound Settings .............................................................................................28

Using the Screen Settings.............................................................................................29

Using the PC Settings ...............................................................................................30

Using the Channel Settings ..........................................................................................31

Using the Parental Lock Settings .................................................................................32

Using the Setup Settings...............................................................................................35

Other Information

Troubleshooting.............................................................................................................37

Preparation for Wall Mounting......................................................................................39

PC Input Signal Reference Chart..................................................................................40

Specifications.................................................................................................................41

Index................................................................................................................................42

Customer Support

United States http://www.sony.com/tvsupport

Canada http://www.sony.ca/support

On-line Registration

United States http://productregistration.sony.com

Canada http://www.sonystyle.ca/registration

9

Getting Started

Welcome to the World of

®

Thank you for purchasing this Sony LCD Digital Color Television. This manual is for model KDL-22L4000. Be sure to check the supplied

accessories against the list on page 41.

Picture Quality and Aspect Ratio

You can enjoy crisp, clear images, smooth movement and high-impact visuals from 1080 HD signals. When you compare a high-definition signal to a standard analog signal, you will notice a big difference.

High-definition and standard-definition signals are transmitted with different aspect ratios (the width-to-height ratio of the image). HDTV uses a wider screen than conventional standarddefinition TV.

16:9 (high-definition) source

Most HDTV signals use a wide screen aspect ratio of 16:9. The 16:9 fills your BRAVIA screen, maintaining a crisp, clear, vivid picture.

4:3 (standard-definition) source

Most standard-definition signals use a boxy 4:3 aspect ratio. When a 4:3 image is displayed on an

HDTV, you will see black bars on the sides. The picture quality may not be as sharp as with HD sources.

You can use the Wide Mode function of the TV to adjust the 4:3 image to fit the entire screen (see pages

24, 29 and 30).

10

Getting Started

Assembling the Table-Top Stand

Follow the assembling steps required to attach the Table-Top Stand.

1

Take out the Table-Top Stand and screws from the carton. The screws are found in the accessory bag.

Screws

Accessory bag

Table-Top Stand

TV unit

Put your hands into the package, when taking out the TV from the carton.

2

Place the Table-Top Stand onto a level and stable surface.

(Continued)

11

Getting Started

3

Gently slide the TV unit onto the neck of the Table-Top Stand and align the screw holes.

Rear of TV

Do not put stress on the LCD panel or the frame around the screen.

Be careful not to pinch your hands or the AC power cord when you install the TV to the Table-Top Stand.

4

Use the supplied screws to attach the TV unit to the Table-Top Stand.

Screw

If an electric screwdriver is used, set the torque to tighten at approximately 1.5 N·m {15 kgf·cm}.

12

Getting Started

Connecting the TV

Cable System or

VHF/UHF Antenna

System

You can enjoy high-definition and standard-definition digital programming

(if available in your area) along with standard-definition analog programming.

This TV is capable of receiving unscrambled digital programming for both cable (QAM and 8VSB) and external VHF/UHF antenna (ATSC).

It is strongly recommended that you connect the CABLE/ANTENNA input using a 75-ohm coaxial cable to receive optimum picture quality. A

300-ohm twin lead cable can be easily affected by radio frequency interference, resulting in signal degradation.

Cable or VHF/UHF (or VHF only)

75-ohm coaxial cable Rear of TV

CABLE/ANTENNA

Cable System and

VHF/UHF Antenna

System

Use an optional A-B RF switch (not supplied) to switch between the cable and over-the-air antenna programming, as indicated below.

Cable

Antenna

A/B

RF Switch

A

B

Rear of TV

CABLE/ANTENNA

Be sure to set the Cable setting to On or Off in the Channel settings for

the type of input signal you choose (see page 31).

13

Getting Started

HD Cable Box/

HD Satellite Box

You can enjoy high-definition programming by subscribing to a highdefinition cable service or a high-definition satellite service. For the best possible picture, make sure you connect this equipment to your TV via the

HDMI or component video (with audio) input on the back of your TV.

Shown with HDMI Connection

Rear of TV

SERVICE

ONLY

IN

PC IN VIDEO

RGB IN

1

COMPONENT IN

(1080i/720p/480p/480i)

Y

HD cable box/

HD satellite box

CATV/Satellite antenna cable

L

AUDIO

R

AUDIO

VIDEO

L

(MONO)

P

P

B

R

L

L

DIGITAL

AUDIO

OUT

(OPTICAL)

AUDIO

OUT

AUDIO

R

AUDIO

R

AUDIO

R

HDMI cable

14

Shown with DVI Connection

Rear of TV

SERVICE

ONLY

IN

PC IN VIDEO

RGB IN

1

COMPONENT IN

(1080i/720p/480p/480i)

Y

AUDIO

R

L

AUDIO

VIDEO

L

(MONO)

P

P

B

R

L

L

DIGITAL

AUDIO

OUT

(OPTICAL)

AUDIO

OUT

AUDIO

R

AUDIO

R

AUDIO

R

AUDIO-R (red)

AUDIO-L (white)

DVI-to-HDMI cable

HD cable box/

HD satellite box

CATV/Satellite antenna cable

Audio cable

If the equipment has a DVI jack and not an HDMI jack, connect the DVI jack to the HDMI IN (with DVI-to-HDMI cable or adapter) jack and connect the audio jack to the L-AUDIO-R jacks of HDMI IN. For details,

see page 17.

Getting Started

Shown with Component Connection

Rear of TV

SERVICE

ONLY

IN

PC IN VIDEO

RGB IN

1

COMPONENT IN

(1080i/720p/480p/480i)

Y

HD cable box/

HD satellite box

L

AUDIO

R

AUDIO

VIDEO

L

(MONO)

P

P

B

R

L

L

DIGITAL

AUDIO

OUT

(OPTICAL)

AUDIO

OUT

AUDIO

R

AUDIO

R

AUDIO

R

AUDIO-R (red)

AUDIO-L (white)

P

R

(red)

P

B

(blue)

Y (green)

Component video cable

CATV/Satellite antenna cable

Audio cable

PC

Rear of TV

SERVICE

ONLY

IN

PC IN VIDEO

RGB IN

1

Use the TV as a monitor for your PC as shown below. Shown below is the

HD15 to HD15 connection.

COMPONENT IN

(1080i/720p/480p/480i)

Y

L

AUDIO

R

AUDIO

VIDEO

L

(MONO)

P

B

P

R

L

L

DIGITAL

AUDIO

OUT

(OPTICAL)

AUDIO

OUT

AUDIO

R

AUDIO

R

AUDIO

R

HD15-HD15 cable

(analog RGB)

Audio cable (stereo mini plugs)

Connect the PC IN jack to the PC using an HD15-HD15 cable with

ferrite core (analog RGB) and audio cable (see page 18).

If the PC is connected to the TV and no signal has been input from the

PC for more than 30 seconds, the TV enters the standby mode

automatically (see page 30).

Do not connect a PC to the TV’s HDMI input.

15

Getting Started

Other Equipment

Blu-ray

Disc Player/

“PS3”

DVD player

Digital satellite receiver

Digital cable box

Audio system

Digital recorder

Digital audio equipment

Camcorder

Rear of TV

SERVICE

ONLY

IN

PC IN VIDEO

RGB IN

1

COMPONENT IN

(1080i/720p/480p/480i)

Y

L

AUDIO

R

AUDIO

VIDEO

L

(MONO)

P

B

P

R

L

L

DIGITAL

AUDIO

OUT

(OPTICAL)

AUDIO

OUT

AUDIO

R

AUDIO

R

AUDIO

R

CABLE/ANTENNA

VIDEO2 IN

S-VIDEO

VIDEO

L

(MONO)

AUDIO

R

16

CABLE/ANTENNA

Personal computer

VCR Game system

Analog audio equipment

(A/V Receiver/Home Theater)

Headphones

Refer to the Quick Setup Guide (supplied) when connecting other equipment to your TV.

Getting Started

When Connecting to Optional Equipment

Left side Rear

VIDEO2 IN

S-VIDEO

For service use only

1

4 5 6 7

VIDEO

L

(MONO)

AUDIO

R

2

SERVICE

ONLY

IN

PC IN VIDEO

RGB IN

1

COMPONENT IN

(1080i/720p/480p/480i)

Y

0

3

L

AUDIO

R

AUDIO

VIDEO

L

(MONO)

P

P

B

R

L

L

DIGITAL

AUDIO

OUT

(OPTICAL)

AUDIO

OUT

AUDIO

R

AUDIO

R

AUDIO

R

8

9

CABLE/ANTENNA

qa

Item

1 VIDEO IN 2

S VIDEO

2 VIDEO IN 2

VIDEO/

L(MONO)-

AUDIO-R

Description

Connects to the S VIDEO output jack on your camcorder or other video equipment that has

S VIDEO. Provides better picture quality than composite video (2/6).

Connect to the composite video and audio output jacks on your A/V equipment such as a VCR or other video equipment.

3 Headphone jack Connects to your headphones. If your headphones do not match the jack, use a suitable plug adapter (not supplied).

While headphones are connected, the TV speakers are muted.

4 HDMI IN

HDMI/

L-AUDIO-R

HDMI (High-Definition Multimedia Interface) provides an uncompressed, all-digital audio/video interface between this TV and any HDMI-equipped audio/video equipment, such as a set-top box, DVD player, and A/V receiver. HDMI supports enhanced, or high-definition video, plus digital audio.

If the equipment has a DVI jack and not an HDMI jack, connect the DVI jack to the HDMI IN

(with DVI-to-HDMI cable or adapter) jack, and connect the audio jack to the L-AUDIO-R jacks of HDMI IN. (DVI connector is for video signals only.)

DVI-to-HDMI cable

Audio cable

HDMI adapter

Be sure to use only an HDMI cable that bears the HDMI logo.

When connecting a DVI-equipped PC to an HDMI jack, also connect an audio cable between the PC and L-AUDIO-R jacks.

(Continued)

17

Getting Started

Item

5 PC IN

(RGB/AUDIO)

Description

Connect to a personal computer’s video output connector using HD15-HD15 cable (analog

RGB, not supplied). Can also be connected to other analog RGB equipment.

See “PC Input Signal Reference Chart” on page 40 for the signals that can be displayed.

For some Apple Macintosh computers, it may be necessary to use an adapter

(not supplied). If this is the case, connect the adapter to the computer before connecting the HD15-HD15 cable.

6 VIDEO IN 1

VIDEO/

L(MONO)-AUDIO-

R

Connect to the composite video and audio output jacks on your camcorder or other video equipment such as video game equipment.

If you have mono equipment, connect its audio output jack to the TV’s L (MONO) audio input jack.

7 COMPONENT

IN (1080i/720p/

480p/480i)/

L-AUDIO-R

8

DIGITAL

AUDIO OUT

(OPTICAL)

If the picture is noisy, flickering or not clear, adjust the Phase and Pitch of the PC

Settings on page 30.

Connect to your DVD player’s or digital set-top box’s component video (YP

B

P

R

) and audio

(L/R) jacks. Component video provides better picture quality than the S VIDEO (1) and the composite video (2/6) connections.

Connects to the optical audio input of a digital audio equipment that is PCM/Dolby digital compatible.

9

0 qa

AUDIO OUT

L-AUDIO-R

AC IN

CABLE/

ANTENNA

Connect to the left and right audio input jacks of your audio or video equipment. You can use these outputs to listen to your TV’s audio through your stereo system.

Connects the supplied AC power cord.

RF input that connects to your Cable or VHF/UHF antenna.

* Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories.

VIDEO IN 2 is equipped with S VIDEO. S VIDEO will be selected when both composite video and S VIDEO are connected.

Component video (YP

B

P

R

) connection is necessary to view 480i, 480p, 720p, and 1080i formats. Note that this TV displays all picture format types in a resolution of 1,366 dots × 768 lines.

HDMI connection is necessary to view 480i, 480p, 720p, 1080i and 1080p formats. Note that this TV displays all picture format types in a resolution of 1,366 dots × 768 lines.

18

Getting Started

Securing the TV

Preventing the TV from Toppling

Sony strongly recommends taking measures to prevent the TV from toppling over; as unsecured TVs may topple and result in property damage, serious bodily injury or even death.

❑ Secure the TV to a wall and/or stand.

❑ Do not allow children to play or climb on furniture and TV sets.

❑ Avoid placing or hanging items on the TV.

❑ Never install the TV on:

• slippery, unstable and/or uneven surfaces.

• furniture that can easily be used as steps, such as a chest of drawers.

❑ Install the TV where it cannot be pulled, pushed, or knocked over.

❑ Route all AC power cords and connecting cables so that they are not accessible to curious children.

Recommended

Measures to Secure the TV

1

Secure the Stand for the TV.

Make sure the TV stand can adequately support the weight of the TV.

Use two angle braces (not supplied) to secure the stand.

For each angle brace use the appropriate hardware to:

• attach one side of the angle brace to the wall stud.

• attach the other side to the TV stand.

Angle brace

Stand

(Continued)

19

Getting Started

2

Secure the TV to the Stand.

Use the optional hardware listed below (not supplied):

• M6 × 12mm anchor bolt (screwed into the TV’s Table-Top Stand).

• A screw or similar (attach it to the TV stand).

• Rope or chain (strong enough to support the weight of the TV). Make sure that there is no excess slack in the rope or chain.

An alternative way to secure the TV is with an optional Sony Support Belt Kit.

Anchor bolt

Screw hole on the

Table-Top Stand

Screw

Contact Sony Customer Support to obtain the optional Support Belt Kit by providing your TV model name.

– For United States call: 1-800-488-7669 or visit: www.sony.com/accessories

– For Canada call: 1-877-899-7669

3

Anchor the TV to the Wall.

Use the hardware listed below (not supplied).

• Two M4 × 12-18mm anchor bolts (screw into the top-most wallmount holes located on the rear of the TV).

• Rope or chain (attach to one M4 anchor bolt).

• Wall-anchor (attach to the wall stud) strong enough to support the weight of the TV (pass the rope through the wall-anchor, then attach to the other M4 anchor bolt).

Wall-mount holes

Wall-anchor

Anchor bolts

Rope or chain

Measure 2 provides minimal protection against the TV toppling over.

For further protection, follow all three measures recommended above.

If an electric screwdriver is used, set the torque to tighten at approximately 2.0 N·m {20 kgf·cm}.

20

Getting Started

Bundling the

Connecting Cables

You can bundle the connecting cables with the supplied cable band as illustrated below.

Do not bundle the AC power cord with other connecting cables.

21

Getting Started

Setting Up the Channel List - Initial Setup

After you finish connecting your TV, you need to run Initial Setup, which automatically sets up available channels. The Initial Setup screen appears when you turn on your TV for the first time. If you do not want to set up the channels at this time, you can do it later by selecting the Auto Program

option in the Channel settings (see page 31).

POWER

1

Press to turn on the TV.

The Initial Setup screen appears.

2

Press V/v to highlight the desired language and to select.

3

The message “First please connect cable or antenna. Allow 50+ minutes for completion.” and “Start auto program now?” appear, make sure you already connected cable or antenna, then select OK to start Auto Program.

If you want to start Auto Program later, select Cancel.

Initial Setup

Please select your language:

English

Español

Français

Initial Setup

First please connect cable or antenna.

Allow 50+ minutes for completion.

Start auto program now?

OK Cancel

If you have cable and antenna available, please connect cable first.

4

The scanning of channels will start. If you want to stop and run Auto

Program later, press to cancel.

Initial Setup

Analog Channels Found: 0

Digital Channels Found: 0

5

When Auto Program is complete, press to continue.

Searching...

Please wait. Allow 50+ minutes for completion.

Press to cancel.

Cancel

6

If the Initial Setup programming found cable channels, you will be able

Initial Setup

to scan antenna channels as well.

Connect the antenna using an A-B RF switch (not supplied) and change the switch to antenna then start Auto

Program to search antenna channels.

If you want to use air signals, please connect antenna.

Allow 50+ minutes for completion.

OK Cancel

If the Initial Setup programming found antenna channels, the Auto

Program process will finish. If you want to scan cable channels, you can do it later using the Channel settings.

To run Auto Program again at a later time

Use the Auto Program feature as described on page 31.

To display the Picture in your Preferred Aspect Ratio

Select the proper Wide Mode as described on pages 24 and 29.

22

Basic Operations

Remote Control

1

2

3

4

5

6

7

8

9

0 z The 5 button and CH + have a tactile dot. Use them as a reference when operating the TV.

Button

1 DISPLAY

2 SLEEP

Description

Press once to display the current channel number, channel label, program remaining time and Wide Mode. The onscreen display (OSD) will turn off after a few seconds.

Press repeatedly until the TV displays the time in minutes

(Off, 15, 30, 45, 60, 90 or 120) that you want the TV to remain on before shutting off. To cancel Sleep Timer, press SLEEP repeatedly until Off appears.

3 FAVORITES Press once to display the stored Favorites list. You can store up to 8 channels and/or external inputs in your Favorites list.

4 PICTURE

5 RETURN

6 MENU

7 CC

8

9 VOL +/–

0 MUTING

How to Add to Favorites

While tuned to the channel you want to add to the list, press

FAVORITES and highlight “Add to Favorites”, then press

.

Your Favorites list will be cleared each time you run

Auto Program (see pages 22 and 31 for Auto

Program).

Press repeatedly to cycle through the available picture modes:

Vivid, Standard, Custom. The picture modes can also be

accessed in the Picture settings. For details, see “Using the

Picture Settings” on page 27.

Press to go back to the previous screen when displaying

MENU items and settings.

Press to display the MENU with TV functions and settings.

See “Overview of MENU” on page 27.

Press to turn on and off Closed Captions (CC). To change or

customize CC Display, see page 36.

Use with 0-9 and ENT buttons to select digital channels. For example, to enter 2.1, press

2

, ,

1

and ENT.

Press to adjust the volume.

Press to mute the sound. Press again or press VOL + to restore the sound.

(Continued)

23

Basic Operations

qa

Button

qa POWER qs WIDE qs

Description

Press to turn on and off the TV.

Press repeatedly to step through the Wide Mode settings: Wide

Zoom, Normal, and Full. The Wide Mode settings can also be

accessed in the Screen settings. (See page 29.)

Changing the Wide Screen Mode

(For PC timing, see below)

4:3 Original source

Standard definition source

16:9 Original source

High definition source m

Wide Zoom

Normal

Full

Wide Zoom

m

Normal

This mode is not available

Full

Normal is not available when you are watching a

720p, 1080i or 1080p source.

Changing the Wide Screen Mode for PC Timing

Incoming PC signal Incoming PC signal

800 × 600 1360 × 768 m

Normal

m

Normal

Full 1

Full 2

Full 1

Full 2

24

Button

qd INPUT qd qf qg qf V/v/B/b qg TOOLS qh JUMP qh qj qj 0 - 9 ENT qk CH +/–

Basic Operations

Description

Press to display the list of external inputs. Press repeatedly to toggle through the inputs.

Inputs can be changed by pressing

V/v and while the list of external inputs is displayed.

See page 35 for information about setting up the

external inputs labels, including the Skip feature.

Press

V/v/B/b to move the on-screen cursor. Press

to select/confirm an item.

Press to display the Tools Menu that is associated with your current input: analog TV, digital TV or external inputs. (See

pages 27, 28, 32, and 36.)

Press to jump back and forth between two channels. The TV alternates between the current channel and the last channel that was selected.

Press 0 - 9 to select a channel; the channel changes after two seconds. Press ENT to change channels immediately.

Press to scan through channels. To scan quickly through channels, press and hold down either +/–.

qk

Insert two size AA batteries (supplied) by matching the e and E on the batteries to the diagram inside the remote control’s battery compartment.

25

Basic Operations

TV Controls

1 2

MENU

INPUT

3

VOLUME

4 5

CHANNEL POWER

0

TIMER STANDBY POWER

6 7 8 9

Item

1 MENU

2

INPUT

Description

Press to display MENU with TV functions and settings (see “Overview of MENU” on page

27).

Press to display the list of external inputs. Press repeatedly to toggle through the inputs.

Inputs can be changed by pressing V/v and while the list of external inputs is displayed.

3

See page 35 for information about setting up the external inputs labels, including

the Skip feature.

In the MENU screen, this button serves as confirming the selection or setting.

Press to adjust the volume. In the MENU screen, these buttons serve as left/right buttons.

– VOLUME +

4

– CHANNEL +

5

POWER

Press to scan through channels. To scan quickly through channels, press and hold down either

–/+. In the MENU screen, these buttons serve as up/down buttons.

6 TIMER LED

Press to turn on and off the TV.

Lights up in orange when the sleep timer is set.

7 STANDBY LED Lights up in red when your TV is in PC power saving mode.

8 POWER LED

9

(IR) Infrared

Receiver

0 Speaker

Lights up in green when the TV is turned on.

Receives IR signals from the remote control.

Outputs audio signal.

The CHANNEL + button has a tactile dot. Use it as a reference when operating the TV.

Make sure that the TV is completely switched off before unplugging the power cord.

26

Using the Menus

Overview of MENU

MENU provides one button access for controlling your TV. It enables you to perform a variety of tasks intuitively with a control panel on the screen rather than a variety of remote control button presses.

Using the Picture Settings

TV Picture

Picture Mode

Reset

Backlight


Brightness

Color

Hue

Color Temp

Sharpness

Noise Reduction

Vivid

Max

Max

50

60

0

Cool

18

Off

Option

Picture Mode

Customized picture viewing

Reset

Backlight


Brightness

Color

Hue

Color Temp

White adjustment

Sharpness

Noise Reduction

Description

Vivid

Standard

Select for enhanced picture contrast and sharpness.

Select for standard picture settings. Recommended for home entertainment.

Allows you to store your preferred settings.

Custom

You can also access Picture Mode by using the TOOLS button or PICTURE button on the remote control.

Resets the current Picture Mode settings to the default values.

Adjust to brighten or darken the backlight.

Adjust to increase or decrease picture contrast.

Adjust to brighten or darken the picture.

Adjust to increase or decrease color intensity.

Adjust to increase or decrease the green tones.

Cool

Neutral

Warm

Select to give the white colors a bluish tint.

Select to give the white colors a neutral tint.

Select to give the white colors a reddish tint.

Adjust to sharpen or soften the picture.

Select to reduce the noise level. Select from High, Medium, Low and Off.

Noise Reduction is not available when you are watching a 1080i or 1080p source.

27

Using the Menus

Using the Sound Settings

Sound

Sound Mode

Reset

Treble

Bass

Balance

MTS

Alternate Audio

Speaker

Dynamic

+6

+6

0

Stereo

On

TV

Option

Sound Mode

Customized sound listening

Reset

Treble

Bass

Balance

MTS

Enjoy stereo, bilingual and mono programs

Alternate Audio

Digital channels only

Speaker

Description

Dynamic

Standard

Clear Voice

Enhances treble and bass.

Standard sound optimized for home use.

Suitable for spoken dialog.

Resets the current Sound Mode settings to the default values.

Adjust to increase or decrease higher-pitched sounds.

Adjust to increase or decrease lower-pitched sounds.

Adjust to emphasize left or right speaker balance.

Stereo

Auto SAP

Select for stereo reception when viewing a program broadcast in stereo.

Mono

Select to automatically switch the TV to second audio programs when a signal is received. If no SAP signal is present, the TV remains in

Stereo mode.

Select for mono reception. Use to reduce noise during weak stereo broadcasts.

MTS is only available for analog programs.

Select among the available options to switch among the alternate audio streams. The program you are tuned to may be broadcasted in a different language in the alternate audio streams.

On

Off

Alternate Audio is not available if the program is not broadcast with alternate audio streams.

Select to turn on the TV speakers.

Select to turn off the TV speakers and listen to the TV’s sound only through your external audio receiver and speakers.

You can also access Sound Mode, MTS and Alternate Audio by using the TOOLS button on the remote control.

28

Using the Screen Settings

Using the Menus

Screen

Wide Mode

Auto Wide

4:3 Default

Horizontal Center

Vertical Center

PC Settings

Wide Zoom

On

Wide Zoom

0

0

TV

Option

Wide Mode

Auto Wide

4:3 Default

Select the default Screen

Mode to use for 4:3 sources

Description

Wide Zoom Fills the screen with minimum distortion.

Normal

Full

Select to display 4:3 picture in original size when the original source is 4:3.

Select to enlarge the picture horizontally to fill the screen when the original source is 4:3 (Standard definition source). When the original source is 16:9 (High definition source), select this mode to display 16:9 picture in original size.

Normal is not available when you are watching a 720p, 1080i or 1080p source.

On

Off

Select to have the screen automatically change to the screen mode that is best for the current program. If frequent screen changes are disturbing to you, select Off.

Select to turn off the Auto Wide option. Choose a screen mode from the

Wide Mode option.

Auto Wide is not available when you are watching analog TV.

Wide Zoom Enlarges the 4:3 picture to fill the 16:9 screen, displaying as much of the original image as possible.

Normal

Full

Off

Select to display the 4:3 picture in its original size.

Select to enlarge the 4:3 picture horizontally only, to fill the display area.

Select to continue using the current Wide Mode setting when the channel or input is changed.

If 4:3 Default is set to anything but Off, the Wide Mode setting changes only for the current channel. When you change channels (or inputs), Wide Mode is automatically replaced with the 4:3 Default setting for 4:3 sources. To retain the current Wide Mode setting as channels and inputs are changed, set 4:3 Default to Off.

(Continued)

29

Using the Menus

Option

Horizontal Center

Vertical Center

Description

Allows you to move the position of the picture left and right (Available only in Wide

Zoom).

Horizontal Center feature is useful if TV is connected to game equipment.

Allows you to move the position of the picture up and down (Available only in Wide

Zoom).

Using the PC

Settings

When a PC is connected to the TV and the PC input is selected, the PC

Settings screen appears instead of the Screen settings.

Screen

PC Settings

Wide Mode

Auto Adjustment

Phase

Pitch

Horizontal Center

Vertical Center

Power Management

Normal

0

0

0

0

On

PC

Option

Wide Mode

Auto Adjustment

Phase

Pitch

Horizontal Center

Vertical Center

Power Management

Description

Normal

Full1

Full2

Select to display in the original image size.

Select to enlarge the picture to fill the display area, keeping its original aspect ratio.

Select to enlarge the picture to fill the display area.

Select to automatically adjust the display position and phase of the picture when the TV receives an input signal from the connected PC. Note that Auto Adjustment may not work well with certain input signals. In such cases, manually adjust the options below.

Adjust after Pitch to fine tune overall sharpness.

Adjust uneven sharpness on screen.

For the PC Input Signal Reference Chart, see page 40.

Allows you to move the position of the picture left and right.

Allows you to move the position of the picture up and down.

On Select to automatically switch to the power saving mode when there is no signal input for 30 seconds.

Off Select to turn off Power Management.

Power Management is not VESA-compliant.

30

Using the Channel Settings

Using the Menus

TV Channel

Favorites

Cable

Digital Channels

Auto Program

Show/Hide Channels

Label Channels

Diagnostics

On

Option

Favorites

Cable

Description

Select favorite channels and external inputs (see page 23).

On

Off

Select if you are receiving cable channels via Cable TV provider.

Select if you are using an antenna.

You should run Auto Program after changing the Cable setting.

Select to add digital channels.

Digital Channels

Auto Program Automatically sets up the channel list on the TV for all receivable channels.

1

Select Auto Program.

2

Select OK to start Auto Program.

Running Auto Program will clear Favorites list.

Show/Hide Channels Allows you to show or hide channels that appear when you use the CH +/– buttons.

1

Press V/v to scroll through the channels until you find the channel you want to show or hide. Then press to select it.

2

Press V/v to determine if the channel will be shown or hidden. Then press to select it.

Channels that you set to be hidden can be accessed only with the 0-9 buttons.

Label Channels

Diagnostics

You can set channels to be hidden that are automatically set in Auto Program.

Allows you to assign labels (such as station call letters) to channel numbers.

1

Press V/v to scroll through the channel numbers. Then press to select the channel number that you want to assign a label.

2

Press V/v to scroll through the label characters (A-Z, 0-9, etc.). Press b to move to the next character. Repeat to add up to 7 characters to the label. Press b to highlight OK and press to set.

Display diagnostics information about the TV. This can be useful in providing information to an authorized technician or repair person.

31

Using the Menus

Using the Parental Lock Settings

The Parental Lock settings allows you to set up the TV to block programs according to their content and rating levels. Use 0-9 on the remote control to enter a four-digit password. The first time you create a password, confirm the password by entering it again.

Parental Lock

Rating

Digital Rating

Unrated

Channel Block

External Input Block

Change Password

Select Country

Off

Off

Allow

U.S.A.

TV

Option

Rating

Digital Rating

(Available only in

U.S.A. where advanced ratings exist)

Unrated

(Available only when Country is set to U.S.A.)

Channel Block

External Input

Block

Description

Off

Child

Youth

Young Adult

Turn Parental Lock off. No programs are blocked from viewing.

Maximum ratings permitted are:

U.S.: TV-Y, TV-G, G

Canada: C, G, TV-Y

Maximum ratings permitted are:

U.S.: TV-PG, PG

Canada: C8+, PG, 8 ans +, TV-PG

Maximum ratings permitted are:

U.S.: TV-14, PG-13

Canada: 14+, 13 ans +, TV-14

Custom

Off

Select to set ratings manually.

U.S.: See page 33 for details.

Canada: See page 34 for details.

Turn Parental Lock off. No programs that contain downloadable ratings are blocked from viewing.

Select to block programs based on downloadable ratings.

Custom

Clear All Select to clear the entire downloadable rating system.

This action will delete the current Digital Rating menu and the menu will no longer be available until the TV is tuned to a channel that contains downloadable ratings.

You can also access Digital Rating by using the TOOLS button on the remote control.

Allow

Block

Allows programs and movies that are broadcasted without a rating.

Blocks all programs and movies that are broadcasted without a rating.

If you block unrated TV programs, be aware that the following types of programs may be blocked: programs broadcasted from another country, emergency broadcasts, political programs, sports, news, public service announcements, religious programs and weather.

Allows you to block channels regardless of program ratings.

To View a Blocked Channel

Press ENT when tuned to the blocked channel then enter the password.

Allows you to block external inputs regardless of program ratings.

To View a Blocked External Input

Press ENT when tuned to the blocked input then enter the password.

32

Using the Menus

Option

Change Password

Select Country

Description

Select to change your password.

You need your password for any future access into the Parental Lock settings. If

you lose your password, see “Lost password.” on page 38.

U.S.A.

Canada

Select to use U.S.A. ratings (see below).

Select to use Canadian ratings (see page 34).

US Models: Selecting Custom Parental Lock Rating Options

To select custom rating options for the U.S., select U.S.A. in the Select Country setting (see above).

Option

Movie Rating

TV Rating

Block programs by their rating, content or both

S

V

D

L

Description

G

PG

PG-13

R

All children and general audience.

Parental guidance suggested.

Parental guidance for children under 13.

Restricted viewing, parental guidance is suggested for children under

17.

No one 17 or under allowed.

NC-17 and X

Age-Based Ratings

TV-Y

TV-Y7

TV-G

TV-PG

TV-14

TV-MA

All children.

Directed to children age 7 and older.

General audience.

Parental guidance suggested.

Parents strongly cautioned.

Mature audience only.

Content-Based Ratings

FV Fantasy violence.

Suggestive dialogue.

Strong language.

Sexual situations.

Violence.

To ensure maximum blocking capability, set the Age-Based Ratings.

(Continued)

33

Using the Menus

Canadian Models: Selecting Custom Parental Lock Rating Options

To select custom rating options for Canada, select Canada in the Select Country setting (see page 33).

Option

English Rating

French Rating

U.S.A. Rating

Description

C

C8+

G

PG

14+

18+

G

8 ans +

13 ans +

16 ans +

18 ans +

All children.

Children 8 years and older.

General programming.

Parental guidance.

Viewers 14 and older.

Adult programming.

General programming.

Not recommended for young children.

Not recommended for ages under 13.

Not recommended for ages under 16.

Programming restricted to adults.

See “US Models” on page 33 for details.

Viewing Blocked Programs

You can view blocked programs by entering the password. Press ENT when tuned to a blocked program, then enter the password. This temporarily turns the parental control feature off. To reactivate the Parental

Lock settings, turn off the TV. When the TV is turned on again, your Parental Lock settings are reactivated.

34

Using the Setup Settings

Using the Menus

TV Setup

Closed Captions (CC)

Info Banner

Label Video Inputs

Language

Sleep Timer

Power Saving

Product Information

CineMotion

Off

On

English

Off

Off

Off

Option

Closed Captions

(CC)

Description

Allows you to select from several closed caption modes (for programs that are broadcast with closed captioning).

On

Off

Closed Captions (CC) is turned on.

Closed Captions (CC) is turned off.

Program Allows you to set basic and advanced Closed Captions (CC) options. See

“Programming Closed Captions (CC)” on page 36.

You can also access Closed Captions (CC) by using the CC button on the remote control.

Info Banner

Set to On or Off. When on, displays the program description and the remaining time (if the broadcaster offers this service). Displays for a few seconds when the channel is changed or the

DISPLAY button is pressed.

Label Video Inputs Allows you to identify A/V equipment you connected to the TV, such as a VCR, DVD, etc. For example, if you have a DVD player connected to the COMPONENT IN jack, you can select the label DVD for the Component input. Then when you press INPUT to change inputs, the video label you assigned to that input appears on screen.

1

Press V/v to highlight the video input (Video 1-2, Component, HDMI, PC) to which you want to assign a label. Then press to select the input.

2

Press V/v to highlight one of the displayed labels. Then press to select the label.

Language

Sleep Timer

You can select from the following labels for each input:

Video 1-2 –, DVD, VCR, Blu-ray, Cable Box, Satellite, DVR, Game, Camcorder, Skip

Component –, DVD, VCR, Blu-ray, Cable Box, Satellite, DVR, Game, Camcorder, Skip

HDMI

PC

–, DVD, VCR, Blu-ray, Cable Box, Satellite, DVR, Game, Camcorder, Skip

–, Skip

If you select Skip, your TV skips this input when you press the INPUT button.

The Skip label is useful for inputs to which no equipment is connected.

Select to display all on-screen settings in your language of choice: English, Español, Français.

Set the time in minutes (Off, 15, 30, 45, 60, 90, or 120) that you want the TV to remain on before shutting off automatically.

(Continued)

35

Using the Menus

Option

Power Saving

Description

Select to reduce the power consumption by adjusting the backlight brightness. This also enhances the black level. Select from Off, Low and High.

You can also access Power Saving by using the TOOLS button on the remote control.

Product Information Select to display the equipment information of your TV.

CineMotion

Select Auto to automatically detect film content and apply a reverse 3-2 pulldown process.

Moving pictures will appear cleaner and more natural looking. Select Off to disable the detection.

Programming Closed Captions (CC)

If you selected the

Program

option under Closed Captions (CC), you can change the following settings:

Option

Basic

Digital CC

Advanced

Advanced Settings

Description

Allows you to select basic analog (EIA-608) closed caption options.

CC1, CC2,

CC3, CC4

Displays a printed version of the dialogue or sound effects of a program. (Should be set to CC1 for most programs.)

Text1, Text2,

Text3, Text4

Displays network/station information presented using either half or the whole screen (if available).

Allows you to set digital closed captioning to Basic (digital EIA-608) or Advanced (digital

EIA-708).

Allows you to select advanced digital (EIA-708) closed caption options. Select from the available options.

Allows you to make additional settings for digital (EIA-708) closed caption options. Select

Text, and then select either As Broadcast or Custom.

Custom Allows you to customize the following settings:

Character Style Style 1-7

Character Color

Character Size

Character Opacity

Color 1-8

Small, Standard, Large

Solid, Translucent, Transparent,

Flashing

Edge Color

Edge Type

Background Color

Background Opacity

Window Color

Window Opacity

Color 1-8

None, Raised, Depressed, Uniform,

Left Shadow, Right Shadow

Color 1-8

Solid, Translucent, Transparent,

Flashing

Color 1-8

Solid, Translucent, Transparent,

Flashing

36

Other Information

Troubleshooting

If you have additional questions, service needs, or required technical assistance related to the use of your

Sony TV, please visit our website or call one of the following numbers: http://www.sony.com/tvsupport for US Support http://www.sony.ca/support for Canadian Support

1-800-222-SONY(7669) for US Support

1-877-899-SONY(7669) for Canadian Support

Problem Possible Remedies

No picture.

Cannot receive any channels.

TV is locked to one channel.

Cannot receive or select channels.

The TV turns off automatically.

No picture from some video sources.

Make sure the power cord is connected securely.

Turn on the power of the TV.

Check antenna/cable connections.

Perform Auto Program to add receivable channels that are not presently in the

TV’s memory (page 31).

Perform Auto Program to add receivable channels that are not presently in the

TV’s memory (page 31).

To receive or select cable channels, make sure that Cable in the Channel

settings is set to On (page 31). To receive or select UHF channels over an

antenna, make sure Cable is set to Off.

Check Power Management in the PC Settings (page 30).

Check the connection between the optional video equipment and the TV.

Press INPUT on the remote control (page 25).

Press MENU on the remote control. Select your desired input from the external inputs list.

Poor picture.

Double images or ghosts.

Only snow and noise appear on the screen.

Dotted lines or stripes.

No color/Dark picture/Color is not correct/The picture is too bright.

Noisy picture.

Check antenna/cable connections.

Check the antenna location and direction.

Check if the antenna is broken or bent.

Check if the antenna has reached the end of its serviceable life. (3-5 years in normal use, 1-2 years at the seaside.)

Keep the TV away from noise sources such as cars, motorcycles, or hair-dryers.

If using 300 ohm twin lead, move the excess lead away from the TV or try using

75 ohm coaxial cable instead.

Press PICTURE to select the desired picture mode (page 23).

Adjust the Picture Mode options in the Picture settings (page 27).

If you set the Power Saving mode to Low or High, it will enhance the black level.

Make sure that the antenna is connected using the 75-ohm coaxial cable (not supplied).

Keep the antenna cable away from other connecting cords.

To avoid TV interference, make sure to use an undamaged antenna cable.

(Continued)

37

Other Information

Problem

No sound/Noisy sound

Possible Remedies

Good picture, no sound.

Audio noise.

Wide Mode changes automatically.

“Black box” on screen.

Black bands appear at the top and bottom of the screen.

Certain programs on DVD or other digital sources display a loss of detail, especially during fast-motion or dark scenes.

Remote control does not operate.

Some digital cable channels are not being displayed.

Lost password.

How to reset the TV to factory settings.

Check the volume control.

Press MUTING or VOL + so that “Muting” disappears from the screen

(page 23).

Disconnect your headphones.

Set Speaker to On in the Sound settings (page 28). If it is set to Off, sound is

not output from the TV’s speakers regardless of the TV’s volume control.

Make sure that the antenna is connected using the 75-ohm coaxial cable (not supplied).

Keep the antenna cable away from other connecting cords.

To avoid TV interference, make sure to use an undamaged antenna cable.

The current Wide Mode setting is automatically replaced with the 4:3 Default setting when you change the channel or video input, if 4:3 Default in the Screen settings is set to anything but Off. If you want to lock in the Wide Mode selected

with the WIDE button, set 4:3 Default to Off in the Screen settings (page 29).

Check the Auto Wide option in the Screen settings (page 29).

You have selected a text option in the Setup setting and no text is available. (See

pages 35 and 36 to reset Setup selections.) To turn off this feature, set the

Closed Captions (CC) option to Off. If you were trying to select closed captioning, select CC1 instead of Text1-4.

Some wide screen programs are filmed in aspect ratios that are greater than 16:9

(this is especially common with theatrical releases). Your TV will show these programs with black bands at the top and bottom of the screen. For more details, check the documentation that came with your DVD (or contact your program provider).

The compression used by certain digital broadcasts and DVDs may cause your

TV’s screen to display less detail than usual, or cause artifacts (small blocks or dots, pixelations) to appear on your screen. This is due to your TV’s screen and ability to show very fine detail, and is normal for certain digitally recorded programs.

Check the polarity of the batteries or replace the batteries.

Point the remote control at the remote control sensor of the TV.

Fluorescent lamps can interfere with your remote control operation; try turning off the fluorescent lamps.

Keep the remote control sensor area clear from obstacles.

Certain cable companies have limitations on the broadcast of digital cable channels. Check with your cable company for more information.

The digital cable channel may be set to Hidden in the Show/Hide Channels

setting (see page 31).

Select the Parental Lock settings on the settings screen, then enter the following master password: 4357. The master password clears your previous password and

allows you to enter a new password (page 33).

Turn on the TV. While holding down the

V

button on the remote control, press the POWER button on the TV. (The TV will turn itself off, then back on again.)

Release the

V

button.

WARNING: The Reset will clear all of your customized settings including

Parental Lock setting.

38

Other Information

Preparation for Wall Mounting

This TV can be installed on a wall by using a Wall-Mount Bracket (sold separately). Before mounting the TV on a wall, the Table-Top Stand must be removed from the TV.

Do not remove the Table-Top Stand for any reason other than to wallmount the TV.

Sony Wall-Mount

Bracket Model

SU-WL100

Follow the simple steps below to remove the Table-Top Stand:

1

Disconnect all the cables from the TV.

2

Cover a level and stable surface with a thick and soft cloth.

3

Gently lay the TV, face down, onto the cloth. Make sure the Table-Top

Stand is hanging over the edge.

4

Remove the screws from the rear of the TV (see illustration below). Do not remove any other screws from the TV.

5

Detach the Table-Top Stand from the TV.

For bracket installation, refer to the instruction guide provided by the Wall-

Mount Bracket model for your TV. Sufficient expertise is required in installing this TV, especially to determine the strength of the wall for withstanding the TV’s weight. For product protection and safety reasons,

Sony strongly recommends that you use the Wall-Mount Bracket model designed for your TV and the wall-mounting of your TV should be performed by Sony dealers or licensed contractors.

Soft cloth

Table-Top

Stand

Be sure to store the removed screws and Table-Top Stand in a safe place until you are ready to reattach the Table-Top Stand. Keep the screws away from small children.

39

Other Information

PC Input Signal Reference Chart

Resolution

Signals

VGA

SVGA

XGA

WXGA

Horizontal

(Pixel)

640

640

720

800

800

1024

1024

1024

1280

1280

1360

×

×

×

×

×

×

×

×

×

×

×

×

Vertical

(Line)

480

480

400

600

600

768

768

768

768

768

768

Horizontal frequency

(kHz)

31.5

37.5

31.5

37.9

46.9

48.4

56.5

60.0

47.4

47.8

47.7

This TV’s PC input does not support Sync on Green or Composite Sync.

Vertical frequency

(Hz)

70

75

60

60

60

60

75

70

60

75

60

This TV’s PC VGA input does not support interlaced signals.

Standard

VGA

VESA

VGA-T

VESA Guidelines

VESA

VESA Guidelines

VESA

VESA

VESA

VESA

VESA

Your PC must support one of the above PC input signals to display on the television.

For the best picture quality, it is recommended to use the signals from the above chart with a 60 Hz vertical frequency from a personal computer. In plug and play, signals with a 60 Hz vertical frequency will be selected automatically. (PC reboot may be necessary.)

40

Specifications

Television system:

NTSC

ATSC (8VSB terrestrial)

QAM on cable

American TV standard

ATSC compliant 8VSB

ANSI/SCTE 07 2000

(Does not include CableCARD

Channel coverage:

Terrestrial

Cable functionality)

Analog

2-69

1-135

Antenna:

75-ohm external terminal for VHF/UHF

Digital

2-69

1-135

Panel System:

LCD (Liquid Crystal Display) Panel

Display resolution (horizontal

× vertical):

1,366 dots

× 768 lines

VIDEO IN 1/2:

S VIDEO (4-pin mini DIN) (VIDEO 2 only):

Y: 1.0 Vp-p, 75 ohms unbalanced, sync negative

VIDEO:

AUDIO:

C: 0.286 Vp-p (Burst signal), 75 ohms

1 Vp-p, 75 ohms unbalanced, sync negative

500 mVrms (100% modulation)

Impedance: 47 kilohms

COMPONENT IN:

YP

B

P

R

(Component Video):

Y: 1.0 Vp-p, 75 ohms unbalanced, sync negative

P

B

: 0.7 Vp-p, 75 ohms

AUDIO:

P

R

: 0.7 Vp-p, 75 ohms

Signal format: 480i, 480p, 720p, 1080i

500 mVrms (100% modulation)

Impedance: 47 kilohms

HDMI IN:

HDMI:

AUDIO:

Video: 480i, 480p, 720p, 1080i, 1080p

Audio: Two channel linear PCM 32, 44.1 and 48 kHz,

16, 20 and 24 bits

500 mVrms (100% modulation)

Impedance: 47 kilohms

AUDIO OUT:

500 mVrms (100% modulation)

DIGITAL AUDIO OUT (OPTICAL):

Optical Digital Audio Output (PCM/Dolby Digital)

PC IN:

Analog RGB (D-sub 15-pin):

0.7 Vp-p, 75 ohms, positive

See the PC Input Signal Reference Chart on page 40

AUDIO (Stereo mini jack):

500 mVrms (100% modulation)

Impedance: 47 kilohms

Headphones:

Stereo mini jack

Power Requirement:

110 V-240 V AC, 50/60 Hz

Screen size (in inches):

21.6 (22 class)

Speaker/Full range (2):

(in mm)

(in inches)

50 × 90

2 × 3

5

/

8

Speaker output:

5 W + 5 W

Other Information

Power consumption:

in use 55 W in standby less than 1.0 W

Dimensions:

with stand:

(in mm)

(in inches) without stand:

551 × 430 × 214

21

3

/

4

× 17 × 8

1

/

2

(in mm)

(in inches)

551 × 392 × 76

21

3

/

4

× 15 wall-mount hole pattern:

1

/

2

× 3

(in mm) 100 × 100 wall-mount screw size:

(in mm) M4 × 10-12

Mass:

with stand:

(in kg)

(in lb.) without stand:

(in kg)

(in lb.)

7.6

16 lb 12

1

/

8 oz

6.4

14 lb 1

3

/

4 oz

Supplied accessories:

Remote control RM-YD025 (1)

Size AA batteries (2)

AC power cord (1)

Table-Top Stand (1)

Screws (3)

Cable band (1)

Operating Instructions (1)

Quick Setup Guide (1)

Warranty Card (1)

Optional accessories:

Headphones plug adapter

Connecting cables

Support belt kit

Wall-Mount Bracket: SU-WL100

Optional accessories availability depends on its stock.

Design and specifications are subject to change without notice.

41

Index

0 - 9 buttons

4:3 Default

25

29

A

AC IN

18

Advanced

36

Advanced Settings

Alternate Audio

36

28

AUDIO OUT jack, described

Auto Adjustment

30

Auto Program

Auto Wide

29

22, 31

18

B

Backlight

Balance

27

28

Basic

36

Bass

28

Brightness

27

C

Cable

31

CABLE/ANTENNA input, described

18

CC button

23

CH+/– button

25, 26

Change Password

33

Channel Block

32

Channels

Creating labels

Setting up

22

CineMotion

36

Color Temp

31

Closed caption modes

35, 36

Closed Captions (CC)

35

Color

27

27

COMPONENT IN

(1080i/720p/480p/480i)

18

D

Diagnostics

31

DIGITAL AUDIO OUT (OPTICAL)

Digital CC

36

Digital Channels

31

Digital Rating

32

DISPLAY button

23

18

E

English Rating

34

ENT button

25

External Input Block

32

F

Favorites

31

FAVORITES button

23

French Rating

34

H

HDMI IN jack, described

Headphone jack, described

Horizontal Center

30

17

17

Hue

27

42

I

Info Banner

35

Infrared Receiver (IR)

26

INPUT button

25, 26

Installing the TV on a wall

39

J

JUMP button

25

L

Label Channels

31

Label Video Inputs

35

Language

35

M

MENU button

23, 26

Movie Rating

33

MTS

28

MUTING button

23

N

Noise Reduction

27

P

PC IN

18

Phase

30


27

PICTURE button

23

Picture Mode

27

Pitch

30

POWER button

24, 26

POWER LED

26

Power Management

30

Power Saving

36

Product Information

36

R

Rating

32

Reset

27, 28, 38

RETURN button

23

S

S VIDEO jack, described

17

Select Country

33

Settings

Channel

31

Parental Lock

32

PC Settings

30


27

Screen

29

Setup

35

Sound

28

Sharpness

27

Show/Hide Channels

31

SLEEP button

23

Sleep Timer

35

Sound Mode

28

Speaker

28

STANDBY LED

26

T

TIMER LED

26

TOOLS button

Treble

28

25

Troubleshooting

TV Rating

33

37, 38

U

U.S.A. Rating

34

Unrated

32

V

Vertical Center

30

VIDEO/AUDIO (L/R) jacks, described

17

, 18

Viewing Blocked Programs

VOL+/– button

23, 26

34

W

WIDE button

24

Wide Mode

29, 30

For Your Convenience

Please contact Sony Customer Support directly if you:

z

Have questions on the use of your television after reading your Operating Instructions Manual and Quick Setup Guide z

Experience difficulty operating your television

For United States http://www.sony.com/tvsupport

or to speak with a support representative: 1-800-222-SONY (7669)

For Canada http://www.sony.ca/support

or to speak with a support representative: 1-877-899-SONY (7669)

Sony will work to resolve your questions more quickly than your retailer or place of purchase.

Please Do Not Return the Product to the Store

On-line Registration Available:

Be sure to register your TV.

United States

http://productregistration.sony.com

Canada

http://www.sonystyle.ca/registration

Printed in Mexico
