RETAIL SCALE PRINTER
Specifications and design are subject to change without notice.
44 SANNO-CHO, SHOGOIN, SAKYO-KU
KYOTO, 606-8392 JAPAN
PHONE: 81-75-771-4141
FACSIMILE: 81-75-751-1634
URL: http://www.ishida.com
Printed in Japan 211(SK) 05 No. 1777
Touch Panel
Customer display
The 7" touch panel makes scale operation as easy as playing.
The display consists of a neat format multi-window layout for tare,
weight, unit price and total price positioned vertically on the righthand side of the display, PLU name window and icons to easily
identify the scale connectivity status/printing mode/USB port. Up
to 3 sizes of preset keys may be programmable with the small size
capable of accommodating up to a maximum of 20 freely
programmable preset keys on a single page. The Uni-5 can store
up to 99 pages and each can be set as calegory/ group/ function/
operator/ PLU page. Further more, the operator display may be
utilised to view virtual receipts, open tickets, visualise totals
before printing and easy label fonmatting.
A sharp, bright, grayscale 7" LCD with backlight helps attract
customers' attention. Brightness is software adjustable and to
further reduce power consumption, standby mode may be set
to trigger automatically. The customer display can show
scrolling/ flashing advertising messages and up to 6 images
per A/D message with variable selectable speeds. A/D
messages may also be set to switch to full-screen in order to
ensure maximum visibility.
Membrane keyboard
Weighing Platter
Uni-5 is available in different capacity version: 3/6kg, 6/15kg and
15/30kg. All capacities come with a standard resolution of 3,000
divisions.
Interfaces
The Uni-5 comes with several interfaces as standard:
A) RS232 for self-sarvice 2 or 3 panel keyboards
connection or serial barcode scanner
B) Ethernet (100Mbps) for connection with PC and
connection with other scales (floating operator
system)
C) USB for memory expansion up to 2GB or barcode
scanner connection
D) RJ port for cash drawer connection
Wi-Fi is available as an option and may be ordered
either as a kit or as built-in factory option before
placing order.
Electronics/OS/Design
The hi-tech electronic multi-layer mainboard and stable
VxWorks operating system is what makes Ishida's
retail scale printer a truly reliable and long-lasting scale
for operation. From a design point-of-view, the tilting
platter allows the possibility to have a low-profile scale
base and also a small foot-print hence making sure the
Uni-5 will look attractive for the store, operator and more
importantly the customer!
For the last 15 years, Ishida has been using the flat surface
membrane keyboard type thus requiring less cleaning time
while achieving maximum cleanliness which are vital in everyday's store operation. The Uni-5 membrane keyboard consists
of a fixed numeric keyboard, fixed keys for zero setting of the
scale, tare key and label/ paper feed key. It also consists of 61
one-touch preset keys freely programmable for PLUs and/or
special preset function keys.
Printer
The direct thermal printer with side-loading system on the
Uni-5 has a variable speed which can be set via software
between 80, 100, 120 and 150mm/sec. The printer comes
standard with the backing rewinder thus ensuring you can
switch-over from labels to receipt or vice-versa. The peel
sensor which is standard too on all Ishida retail scale printers,
will make operation easier, faster and helps minimise label
waste. The Uni-5 printer is designed with the environment in
mind - Linerless printer is available and may be ordered as
standard or as a kit in order to be able to print receipt or labels
on linerless continuous rolls.
Multiple system configurations
wi-fi
Uni-5 P
Customer side
SLP-V: client
SLP-V: client
Uni-5 P
Master #1
Uni-5 P
Slave #2
Network #2
Meat Pre-Pack
Ethernet 100Mbps
Uni-5 P
Slave #3
WM-AI Series
Uni-5 E
Master #1
Uni-5 E
Slave #2
Uni-5 E
Slave #3
Network #4
multi-purpose
powerful CPU
Wi-Fi
Router
Hub
Delicatessen Pre-Pack
Elevated keyboard type retail scale
printer with tilting elevated keyboard
and tilting customer display
SLP-V: Sever
Network #6
Uni-5 E
Delicatessen Counter
Uni-5 SS
elegant
Meat Counter
Customer side
Network #3 - Floating Operator/ Receipt
Uni-5 E
Network #1 - Floating Operator/ Receipt
Back-0ffice
affordable
Pre-Pack Area
Model Variation...
Uni-5 B
Master #1
networkable
Uni-5 P
Customer side
reliable
Uni-5 B
Bench type retail scale printer with lower
keyboard
Pre-Pack Area
Uni-5 B
Network #5 - Label mode
Pole type retail scale printer with lower keyboard
Wi-Fi
Access Point
Uni-5 B
Uni-5 B
Uni-5 B
WM-NANO Series
Dimensions
Weight rages:
Max. Capacity
Division
Min.
Tare
6/ 15kg
2/ 5g
40g
5.998kg
Unit: mm
15/ 30kg
5/10g
100g
14.998kg
Uni-5 E (Elevated Keyboard Type)
Printer
8 dots/ mm
80/ 100/ 120/ 150 mm/sec
Max. 3 label format
EAN/UPC 8/12/13, ITF, GS1 Databar/Limited/Expanded, CODE128, EAN128
999
Die-cut labels and/or continuos paper
56mm
200mm
Forward and backward drive
Toothed belt
Ishida Quick Head Replacement (no tools required)
173
130
296
30°
90°
584
398
157
275
134
Resolution
Speed
Image printing
Barcodes
Customisable label formats
Label printing
Max. printing width
Max. printing height
Stepper motor
Driving mechanism
Thermal head replacement
417
Media
Min. width
Max. width
Min. height
Max. height
331
38mm
64mm (including backing paper)
38mm
200mm
Uni-5 SS (Self-Service Type)
498
Keyboard
Type
Numeric
189
189
7" colour touch panel
7" gray scale panel
4-wire resistive
99
Fully programmable category/ group/ function/ sub-total pages
601
Operator side
Customer side
Type
Max. pages
Keyboard
19 64
249
Display
Membrane
0-9 keys, 00 key programmable
SRAM
SDRAM
Flash memory
*USB
18
Memory
4MB
64MB
32MB
2GB
348
Uni-5 P (Pole Type)
PLU data settings
Weight/ fixed price/ 100g/ weight and fixed price
1 x Pack date, 2 x expiry dates
1 x Pack time, 2 x expiry times
Tare, VAT, department, group barcode format, traceability, fidelity points,deposit/link,
1st and 2nd label format, 3 images for printing, 1 display image, 1 safe handling image
190
130
Sales modes
Dates
Time
Other settings
I (manual input ) and II (scanner input)
468
Type
Barcode formats
398
275
173
34 formats
Indefinite
134
Pr-defined
Customisable
558
Traceability
60°
Reports
Daily/ weekly/ cumulative
Daily/ weekly/ cumulative
Interfaces
RS232C
RJ485
USB
Ethernet
*Wi-Fi
331
417
Uni-5 B (Bench Type)
1
1
1 (ver 1.0)
1 (100Mbps auto-duplex)
1
417
Serial or ethernet
464
*Barcode scanner
Operating voltage
Range
Permissible tolerance
275
398
Scanner
157
Receipt totals
Pre-pack totals
173
60°
100 - 240V 50/60Hz
+/- 10%
298
Operational environment
296
Min. +5˚C (41˚F), Max. +35˚C (95˚F), 20% - 85% R.H.
* Optional
