IJM258(C) PhotoGloss 170 g/m2 FSC

IJM258(C) PhotoGloss 170 g/m2 FSC
Photo Papers
Crystalpoint ™
Water
(eco) Solvent
UV Curable
Latex
Product
Description
Physical
Properties
IJM258(C) PhotoGloss
170 g/m2 FSC®
Instant dry, glossy, FSC environmentally certified, photo paper with a microporous ceramic coating for
rapid ink absorption and excellent image sharpness.
Weight
170 ± 7 g/m2
CIE Whiteness (D65/10°)
Thickness
170 ± 7 µm
L, a*,b* delta b
91,4 ± 0,5; - 0,5 ± 0,3;
Opacity
>85
Gloss (BYK)60º
50 ± 5 %
Applications/
features
Excellent surface
High opacity
Outstanding stiffness
Brilliant gloss level
Most excellent whiteness
Universal compatibility
Instant dry
FSC environmentally certified
Very consistent layflat
5760 dpi resolution possible
Best results at 1440 dpi
Photography
Portrait Posters
Graphic art reproduction
Available
Widths (mm)
2”core
610
3” core
914
145
914
Storage
Conditions
Shelf life: 2 years
Temperature 23ºC, Relative Humidity 50%. Repack opened rolls when not in use
Print
Conditions
Best results are obtained at 23ºC and 50% RH.
Higher humidity will increase drying time, low humidity may cause curling.
Environment,
Health & Safety
No Material Safety Data Sheet required. Paper waste is suitable for recycling in most countries.
Please refer to local paper recycle station.
Printer
compatibility
Refer to www.mediaguide.oce.com
Lamination
Compatibility
Cold
Warm
Hot
yes
yes
no
Outdoor
Use
- 2,4 ± 0,5; 11,2 ± 0.8
Cold: pressure sensitive
Warm: heat activated: 85°C - 95°C
Hot: heat activated: 105°C -130°C
Not suitable for outdoor use. Short time outdoor use possible only when laminated.
Colour
Profiles
Canon develops high-quality colour profiles for media / ink / printer / RIP combinations.
Check availability of profiles for your printer on mediaguide.oce.com
Environmental
Certification
Processing
Guidelines
Printing guidelines
Finishing guidelines
Always use gloves when handling rolls. Always print
on the outside of roll.
To insure best print performance
of this or any media, check the print cartridges
daily.
While loading the HP 5x00 printer only feed 6
inches of paper
beyond printer heads. This will prevent alignment
errors when machine loads paper.
This media is designed to accept
400% ink loads but ink loads > 240% will increase
dry time.
The coating of this photo paper is optimized to
obtain good lamination results.
Allow adequate dry times before over laminating.
We recommend the use of the Océ warm or cold
laminates for the best results.
Allow the print to dry properly before to lamination.
That is at least 24 hours.
Generally lamination will only slightly improve UV
resistance (outdoor inks should be used when UV
resistance is required)
One sided lamination may cause curling.
Standard disclaimer:
All specifications subject to change without notice. All
company and/or product names are trademarks and/or
registered trademarks of their respective manufacturers in
their markets and/or countries.
Canon Inc.
canon.com
Canon Europe
canon-europe.com
English edition 0615
© Canon Europa N.V., 2016
