Features of your new air conditioner
Cool Summer Offer
On those hot sweltering summer days and long restless nights, there is no better escape from the heat than the cool
comforts of home. Your new air conditioner brings an end to exhausting hot summer days and lets you rest.
This summer, beat the heat with your own air conditioner.
Cost Efficient System
Your new air conditioner not only provides maximum cooling power in the summer, but can also be an efficient heating
method in the winter with the advanced “Heat pump” system. This technology is up to 300% more efficient than electrical
heating, so you can further reduce its running cost. Now, meet year-round needs with one air conditioner.
Contents
Safety precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Checking before use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Viewing the parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Cleaning and maintaining the air conditioner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
This product has been determined to be in compliance with the Low Voltage Directive (2006/95/EC), the Electromagnetic
Compatibility Directive (2004/108/EC) and the Machinery Directive (2006/42/EC) of the European Union.
Correct Disposal of This Product
(Waste Electrical & Electronic Equipment)
(Applicable in the countries with separate collection systems)
This marking on the product, accessories or literature indicates that the product and its electronic accessories (e.g.
charger, headset, USB cable) should not be disposed of with other household waste at the end of their working life. To
prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate these
items from other types of waste and recycle them responsibly to promote the sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this product, or their local government
office, for details of where and how they can take these items for environmentally safe recycling.
Business users should contact their supplier and check the terms and conditions of the purchase contract. This product
and its electronic accessories should not be mixed with other commercial wastes for disposal.
2
Safety precautions
Before using your new air conditioner, please read this manual thoroughly to ensure that
you know how to safely and efficiently operate the extensive features and functions of
your new appliance.
Important safety symbols and precautions:
WARNING
Hazards or unsafe practices that may result in severe personal
injury or death.
CAUTION
Hazards or unsafe practices that may result in minor personal
injury or property damage.
Follow directions.
Do NOT attempt.
Make sure the machine is grounded to prevent electric shock.
Unplug the power plug from the wall socket.
Do NOT disassemble.
3
ENGLISH
Because the following operating instructions cover various models, the characteristics of
your air conditioner may differ slightly from those described in this manual. If you have any
questions, call your nearest contact center or find help and information online at www.
samsung.com.
Safety precautions
FOR INSTALLATION
WARNING
Use the power line with the power specifications of the product or higher and
use the power line for this appliance only. In addition, do not use an extension
line.
XXExtending the power line may result in electric shock or fire.
XXDo not use an electric transformer. It may result in electric shock or fire.
XXIf the voltage/frequency/rated current condition is different, it may cause fire.
The installation of this appliance must be performed by a qualified technician or
service company.
XXFailing to do so may result in electric shock, fire, explosion, problems with the
product, or injury.
Install a switch and circuit breaker dedicated to the air conditioner.
XXFailing to do so may result in electric shock or fire.
Fix the outdoor unit firmly so that the electric part of the outdoor unit is not
exposed.
XXFailing to do so may result in electric shock or fire.
FOR INSTALLATION
WARNING
Do not install this appliance near a heater, inflammable material. Do not install
this appliance in a humid, oily or dusty location, in a location exposed to direct
sunlight and water (rain drops). Do not install this appliance in a location where
gas may leak.
XXThis may result in electric shock or fire.
Never install the outdoor unit in a location such as on a high external wall where
it could fall.
XXIf the outdoor unit falls, it may result in injury, death or property damage.
This appliance must be properly grounded. Do not ground the appliance to a
gas pipe, plastic water pipe, or telephone line.
XXFailure to do so may result in electric shock, fire, an explosion, or other problems
with the product.
XXNever plug the power cord into a socket that is not grounded correctly and
make sure that it is in accordance with local and national codes.
4
FOR INSTALLATION
CAUTION
FOR POWER SUPPLY
ENGLISH
Install the draining hose properly so that water is drained correctly.
XXFailing to do so may result in water overflowing and property damage.
When installing the outdoor unit, make sure to connect the draining hose so
that draining is performed correctly.
XXThe water generated during the heating operation by the outdoor unit may
overflow and result in property damage.
In particular, in winter, if a block of ice falls, it may result in injury, death or
property damage.
WARNING
When the circuit breaker is damaged, contact your nearest service center.
Do not pull or excessively bend the power line. Do not twist or tie the power
line. Do not hook the power line over a metal object, place a heavy object on the
power line, insert the power line between objects, or push the power line into
the space behind the appliance.
XXThis may result in electric shock or fire.
FOR POWER SUPPLY
CAUTION
When not using the air conditioner for a long period of time or during a
thunder/lightning storm, cut the power at the circuit breaker.
XXFailing to do so may result in electric shock or fire.
5
Safety precautions
FOR USING
WARNING
If the appliance is flooded, please contact your nearest service center.
XXFailing to do so may result in electric shock or fire.
If the appliance generates a strange noise, a burning smell or smoke, unplug the
power plug immediately and contact your nearest service center.
XXFailing to do so may result in electric shock or fire.
In the event of a gas leak (such as propane gas, LP gas, etc.), ventilate
immediately without touching the power line.
Do not touch the appliance or power line.
XXDo not use a ventilating fan.
XXA spark may result in an explosion or fire.
To reinstall the air conditioner, please contact your nearest service center.
XXFailing to do so may result in problems with the product, water leakage, electric
shock, or fire.
XXA delivery service for the product is not provided. If you reinstall the product in
another location, additional construction expenses and an installation fee will
be charged.
XXEspecially, when you wish to install the product in an unusual location such as
in an industrial area or near the seaside where it is exposed to the salt in the air,
please contact your nearest service center.
FOR USING
WARNING
Do not touch the circuit breaker with wet hands.
XXThis may result in electric shock.
Do not strike or pull the air conditioner with excessive force.
XXThis may result in fire, injury, or problems with the product.
Do not place an object near the outdoor unit that allows children to climb onto
the machine.
XXThis may result in children seriously injuring themselves.
6
FOR USING
WARNING
If any foreign substance such as water has entered the appliance, cut the power
by unplugging the power plug and turning the circuit breaker off and then
contact your nearest service center.
XXFailing to do so may result in electric shock or fire.
Do not attempt to repair, disassemble, or modify the appliance yourself.
XXDo not use any fuse (such as cooper, steel wire, etc.)other than the standard
fuse.
XXFailing to do so may result in electric shock, fire, problems with the product, or
injury.
7
ENGLISH
Do not turn the air conditioner off with the circuit breaker while it is operating.
XXTurning the air conditioner off and then on again with the circuit breaker may
cause a spark and result in electric shock or fire.
After unpacking the air conditioner, keep all packaging materials well out of the
reach of children, as packaging materials can be dangerous to children.
XXIf a child places a bag over its head, it may result in suffocation.
Do not insert your fingers or foreign substances into the outlet when the air
conditioner is operating or the front panel is closing.
XXTake special care that children do not injure themselves by inserting their
fingers into the product.
Do not touch the front panel with your hands or fingers during the heating
operation.
XXThis may result in electric shock or burns.
Do not insert your fingers or foreign substances into the air inlet/outlet of the
air conditioner.
XXTake special care that children do not injure themselves by inserting their
fingers into the product.
Do not use this air conditioner for long periods of time in badly ventilated
locations or near infirm people.
XXSince this may be dangerous due to a lack of oxygen, open a window at least
once an hour.
Safety precautions
FOR USING
CAUTION
Do not place objects or devices under the indoor unit.
XXWater dripping from the indoor unit may result in fire or property damage.
Check that the installation frame of the outdoor unit is not broken at least once
a year.
XXFailing to do so may result in injury, death or property damage.
Max current is measured according to IEC standard for safety and current is
measured according to ISO standard for energy efficiency.
Do not stand on top of the appliance or place objects (such as laundry, lighted
candles, lighted cigarettes, dishes, chemicals, metal objects, etc.) on the
appliance.
XXThis may result in electric shock, fire, problems with the product, or injury.
Do not operate the appliance with wet hands.
XXThis may result in electric shock.
Do not spray volatile material such as insecticide onto the surface of the
appliance.
XXAs well as being harmful to humans, it may also result in electric shock, fire or
problems with the product.
Do not drink the water from the air conditioner.
XXThe water may be harmful to humans.
Do not apply a strong impact to the remote controller and do not disassemble
the remote controller.
Do not touch the pipes connected to the product.
XXThis may result in burns or injury.
FOR USING
CAUTION
Do not use this air conditioner to preserve precision equipment, food, animals,
plants or cosmetics, or for any other unusual purposes.
XXThis may result in property damage.
Avoid directly exposing humans, animals or plants to the air flow from the air
conditioner for long periods of time.
XXThis may result in harm to humans, animals or plants.
8
ENGLISH
This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety. Children should be
supervised to ensure that they do not play with the appliance.
For use in Europe : This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or mental capabilities
or lack of experience and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way and understand the
hazards involved. Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision.
FOR CLEANING
WARNING
Do not clean the appliance by spraying water directly onto it. Do not use
benzene, thinner or alcohol to clean the appliance.
XXThis may result in discoloration, deformation, damage, electric shock or fire.
Before cleaning or performing maintenance, unplug the air conditioner from
the wall socket and wait until the fan stops.
XXFailing to do so may result in electric shock or fire.
FOR CLEANING
CAUTION
Take care when cleaning the surface of the heat exchanger of the outdoor unit
since it has sharp edges.
XXTo avoid cutting your fingers, wear thick cotton gloves when cleaning it.
Do not clean the inside of the air conditioner by yourself.
XXFor cleaning inside the appliance, contact your nearest service center.
XXWhen cleaning the internal filter, refer to the descriptions in the ‘Cleaning and
maintaining the air conditioner’ section.
XXFailure to do may result in damage, electric shock or fire.
9
Checking before use
Operation ranges
The table below indicates the temperature and humidity ranges the air conditioner can be
operated within.
Refer to the table for efficient use.
MODE
OUTDOOR TEMPERATURE
INDOOR TEMPERATURE
COOLING
-15°C/5°F to 50°C/122°F
18°C/64°F to 32°C/90°F
HEATING
-20°C/-4°F to 24°C/75°F
27°C/81°F to less
DRYING
-15°C/5°F to 50°C/122°F
18°C/64°F to 32°C/90°F
NOTE
CAUTION
INDOOR HUMIDITY
80% or less
• The standardized temperature for heating is 7˚C/45˚F. If the outdoor temperature drops to 0˚C/32˚F or below,
the heating capacity can be reduced depeanding on the temperature condition.
If the cooling operation is used at over 32˚C/90˚F (indoor temperature), it does not cool at its full capacity.
• The use of the air conditioner at a relative humidity above the expected one
(80%) may cause the formation of condensate and the leakage of water drops on
the floor.
Maintaining your air conditioner
Internal protections via the unit control system
ffThis internal protection operates if an internal fault occurs in the air conditioner.
Type
Against cold air
The internal fan will be off to against cold air when the heat pump is heating.
De-ice cycle
(Defrost cycle)
The internal fan will be off to against cold air when the heat pump is heating.
Protect compressor
NOTE
10
Description
The air conditioner does not start operating immediately to protect the compressor of the
outdoor unit after it has been started.
• If the heat pump is operating in Heat mode, De-ice cycle is actuated to remove frost from an outdoor unit that
may have deposited at low temperatures.
The internal fan is switched off automatically and restarted only after the de-ice cycle is completed.
Tips on using air conditioner
Here are some tips that you would follow when using your air conditioner.
TOPIC
RECOMMENDATION
• If current outside temperatures are much higher than the
selected indoor temperature, it may take time to bring the inner
temperature to the desired coolness.
• Avoid drastically turning down the temperature. Energy is wasted
and the room does not cool faster.
Heating
• Since the air conditioner heats the room by taking heat energy
from outdoor air, the heating capacity may decrease when outdoor
temperatures are extremely low. If you feel the air conditioner
insufficiently heats, using an additional heating appliance in
combination with the air conditioner is recommended.
Frost & De-ice
• When the air conditioner runs in Heat mode, due to temperature
difference between the unit and the outside air, frost will form.
If this happens:
-- The air conditioner stops heating.
-- The air conditioner will operate automatically in De-ice mode for
10 minutes.
-- The steam produced on the outdoor unit in De-ice mode is safe.
No intervention is required; after about 10 minutes, the air
conditioner operates again normally.
❈The
❈ unit will not operate when it starts to de-ice.
ENGLISH
Cooling
Fan
• Fan may not operate for about 3~5 minutes at the beginning to
prevent any cold blasts while the air conditioner is warming up.
High indoor/
outdoor
temperatures
• If both indoor and outdoor temperatures are high and the air
conditioner is running in Heat mode, the outdoor unit’s fan and
compressor may stop at times. This is normal; wait until the air
conditioner turns on again.
Power failure
• If a power failure occurs during the operation of the air conditioner,
the operating immediately stops and unit will be off. When power
returns, the air conditioner will run automatically.
Protection
mechanism
• If the air conditioner has just been turned on after operation
stops or being plugged in, cool/warm air does not come out for
3 minutes to protect the compressor of the outdoor unit.
11
Checking before use
Selecting the best location
This air conditioner is designed to be installed under a ceiling.
Consider interior design, available space and the supply of cool air to select the best location.
❇❈ This product must be installed on the ceiling. (Do not make it stand up for use.)
Under the ceiling
Adjusting the air flow direction
Manually move each set of vertical blades left or right to provide the air-flow direction you prefer. The horizontal louvre is
motorized and can be adjusted at the controller.
CAUTION
12
• Be extremely careful with your fingers while adjusting the Horizontal air flow
direction. There is a potential risk of personal injury when the unit is mishandled.
Viewing the parts
Please read the user manual to get started and to make the best use of the air conditioner.
Please also refer to the local controller's user manual for operating guidelines.
ENGLISH
Main parts
Air flow blade(up/down)
Air flow blade(right/left)
Air filter(inside)
Front grille
Display
Blue : Operating indicator
Orange: Filter indicator
Green : Schedule indicator
Red : Error indicator
NOTE
• Your air conditioner and display may look slightly different from the illustration shown above depending on your
model.
13
Cleaning and maintaining the air conditioner
For the best performance from your air conditioner, clean it periodically. When cleaning, disconnect the electrical supply.
Cleaning the exterior
When cleaning, disconnect the electrical supply. No special tools are needed to clean it.
Wipe the surface of the unit with a slightly wet or dry cloth when needed.
Wipe off dirt of odd-shaped area by using a soft brush.
CAUTION
• Do not use Benzene or Thinner (Organic solvent).
They may damage the surface of the air
conditioner and can create a risk of fire.
Cleaning the filter
When cleaning, disconnect the electrical supply. Washable foam based Air filter captures large particles from the air. The filter
is cleaned with a vacuum or by hand washing.
Inspect the air filter once a month and clean it if necessary.
1. Open the front grille.
Slide the both hooks and unscrew two screws by screw driver from both of front grille.
2. Detach the front grille.
Open the grill and push it gently (over 100°) to detach the grille. Then, lift up the front grille.
14
3. Pull out the Air filter.
Slightly press the air filter and then pull the air filter out.
ENGLISH
4. Clean the Air filter with a vacuum cleaner or soft brush. If dust is too heavy, then rinse it with running water and dry it in a
ventilated area.
5. Insert the Air filter back in its original position.
6. Close the front grille.
NOTE
• The illustration shown above may differ from yours depending on your model.
• After cleaning the filter, press the Filter Reset button on the remote control for 2 seconds to reset the filter
schedule. Filter sign indicator will be on for cleaning time.
15
Cleaning and maintaining the air conditioner
If the air conditioner will not be used for an extended period of time, dry the air conditioner to maintain it in best condition.
XXDry the air conditioner thoroughly by operating in Fan mode for 3 to 4 hours and
disconnect the power plug. There may be internal damage if moisture is left in
components.
XXBefore using the air conditioner again, dry the inner components of the air conditioner
again by running in Fan mode for 3 to 4 hours. This helps remove odors which may
have generated from dampness.
Periodical checks
Refer to the following chart to maintain the air conditioner properly.
Type
Description
Clean the air filter
Indoor unit
Monthly
Every
2 months
Every
6 months
●
Clean the condensate drain pan
●
Thoroughly clean the heat exchanger
●
Clean the condensate drain pipe
Once a year
●
Replace the remote control batteries
Clean the heat exchanger on the outside of the unit
Outdoor unit
●
●
Clean the heat exchanger on the inside of the unit
●
Verify that all the electric components are firmly
tightened
●
Clean the fan
●
Verify that all the fan assembly is firmly tightened
●
Clean the condensate drain pan
●
● : This check mark requires checking the indoor/outdoor unit periodically, following to the description to maintain the air
conditioner properly.
NOTE
CAUTION
16
• The described operations should be performed more frequently if the area of installation is very dusty.
• These operations must always be performed by qualified personnel. For more
detailed information, see the installation part in the manual.
Appendix
Troubleshooting
PROBLEM
SOLUTION
The air conditioner
does not operate
immediately after it
has been restarted.
• Because of the protective mechanism, the appliance does not
start operating immediately to keep the unit from overloading.
The air conditioner will start in 3 minutes.
The air conditioner
does not work at
all.
• Check that the power plug is properly connected. Insert the
power plug into the wall socket correctly.
• Check if the circuit breaker is switched off.
• Check if there is a power failure.
• Check your fuse. Make sure it is not blown.
The temperature
does not change.
• Check if you selected Fan mode.
Press the Mode button on the remote control to select another
mode.
The cool (warm)
air does not come
out of the air
conditioner.
• Check if the set temperature is higher (lower) than the current
temperature. Press the Temperature buttons on the remote
controller to increase or decrease the set point temperature.
• Check if the air filter is blocked by dirt. Clean the air filter once
a month.
• Check if the air conditioner has just been turned on. If so,
wait 3 minutes. Cool air does not come out to protect the
compressor of the outdoor unit.
• Check if the air conditioner is installed in a place with a direct
exposure to sunlight. Hang curtains on windows to boost
cooling efficiency.
• Check if the air flow through either outdoor or indoor unit is
obstructed.
• Check if the refrigerant pipe is too long.
• Check if the air conditioner is only available in Cool mode.
• Check if the remote control is only available for cooling model.
17
ENGLISH
Refer to the following chart if the air conditioner operates abnormally. This may save time
and unnecessary expenses.
Appendix
PROBLEM
SOLUTION
The fan speed does
not change.
• Check if you selected Auto or Dry mode.
The air conditioner automatically adjusts the fan speed to Auto
in Auto/Dry mode.
Timer function
does not set.
• Check if you press the Power button on the remote control
after you have set the time.
Odors permeate in
the room during
operation.
• Check if the appliance is running in a smoky area or if there is a
smell entering from outside. Operate the air conditioner in Fan
mode or open the windows to air out the room.
The air conditioner
makes a bubbling
sound.
• A bubbling sound may be heard when the refrigerant is
circulating through the compressor. Let the air conditioner
operate in a selected mode.
• When you press the Power button on the remote control,
noise may be heard from the drain pump inside the air
conditioner.
Water is dripping
from the air flow
blades.
• Check if the air conditioner has been cooling for an extended
period of time with the air flow blades pointed downwards.
Condensation may generate due to the difference in
temperature.
Remote control is
not working.
•
•
•
•
The air conditioner
does not turn on or
off with the wired
remote control.
• Check if you set the wired remote control for group control.
The wired remote
control does not
operate.
• Check if TEST indicator is displayed on the wired remote
control. If so, turn off the unit and switch off the circuit breaker.
Call your nearest contact center.
18
Check if your batteries are depleted.
Make sure batteries are correctly installed.
Make sure nothing is blocking your remote control sensor.
Check that there are strong lighting apparatus near the air
conditioner. Strong light which comes from fluorescent bulbs
or neon signs may interrupt the electric waves.
PROBLEM
The indicators of
the digital display
flashes.
SOLUTION
• Press the Power button on the remote control to turn the unit
off and switch the circuit breaker off. Then, switch it on again.
ENGLISH
Model specification (Dimension and weight)
Dimension and weight
Type
Indoor Unit
Model
Net dimension (WxHxD) (mm)
Net weight(kg)
AC100JNCDEH
1650 x 235 x 675
42
AC120JNCDEH
1650 x 235 x 675
42
AC140JNCDEH
1650 x 235 x 675
42
AC100JNCDEH1
1350 x 235 x 675
33
AC160JNCDEH
1650 x 235 x 675
42
19
QUESTIONS OR COMMENTS?
COUNTRY
MEXICO
BRAZIL
COSTA RICA
DOMINICAN
REPUBLIC
ECUADOR
EL SALVADOR
GUATEMALA
HONDURAS
JAMAICA
CALL
01-800-SAMSUNG(726-7864)
0800-124-421 (Demais cidades e regiões)
4004-0000 (Capitais e grandes centros)
0-800-507-7267
00-800-1-SAMSUNG (726-7864)
1-800-751-2676
1-800-10-7267
1-800-SAMSUNG (72-6786)
800-6225
800-0726-7864
1-800-299-0013
1-800-299-0033
800-2791-9267
800-2791-9111
1-800-234-7267
1-800-SAMSUNG (726-7864)
NICARAGUA
001-800-5077267
PANAMA
800-7267
800-0101
PUERTO RICO
TRINIDAD
& TOBAGO
VENEZUELA
1-800-682-3180
1-800-SAMSUNG(726-7864)
CHILE
BOLIVIA
PERU
ARGENTINE
0-800-SAMSUNG (726-7864)
Bogotá 600 12 72
Gratis desde cualquier parte del país 01 8000 112
112 ó desde su celular #SAM(726)
800-SAMSUNG(726-7864)
800-10-7260
0800-777-08
0800-555-SAMSUNG (0800-555-7267)
URUGUAY
000-405-437-33
PARAGUAY
009-800-542-0001
COLOMBIA
UK
EIRE
0330 SAMSUNG (7267864)
0818 717100
0180 6 SAMSUNG bzw.
0180 6 7267864*
GERMANY
(*0,20 €/Anruf aus dem dt. Festnetz, aus dem
Mobilfunk max. 0,60 €/Anruf)
FRANCE
01 48 63 00 00
ITALIA
800-SAMSUNG (800.7267864)
SPAIN
34902172678
PORTUGAL
808 20 7267
LUXEMBURG 261 03 710
NETHERLANDS 0900-SAMSUNG (0900-7267864) (€ 0,10/Min)
BELGIUM
02-201-24-18
NORWAY
DENMARK
FINLAND
SWEDEN
815 56480
70 70 19 70
030-6227 515
0771 726 7864 (0771-SAMSUNG)
801-172-678* lub +48 22 607-93-33 *
* (koszt połączenia według taryfy operatora)
0680SAMSUNG (0680-726-786)
0680PREMIUM (0680-773-648)
0800 - SAMSUNG (0800-726 786)
0800-SAMSUNG (0800-7267864)
[Only for Premium HA] 0800-366661
[Only for Dealers] 0810-112233
POLAND
HUNGARY
SLOVAKIA
AUSTRIA
SWITZERLAND 0800 726 78 64 (0800-SAMSUNG)
CZECH
CROATIA
BOSNIA
MONTENEGRO
SLOVENIA
SERBIA
BULGARIA
ROMANIA
CYPRUS
GREECE
LITHUANIA
800 - SAMSUNG (800-726786)
072 726 786
055 233 999
020 405 888
080 697 267
090 726 786
011 321 6899
800 111 31 , Безплатна телефонна линия
08008 726 78 64 (08008 SAMSUNG )
Apel GRATUIT
8009 4000 only from landline, toll free
80111-SAMSUNG (80111 726 7864) only
from land line
(+30) 210 6897691 from mobile and land line
8-800-77777
OR VISIT US ONLINE AT
www.samsung.com/mx/support
www.samsung.com/br/support
www.samsung.com/latin/support (Spanish)
www.samsung.com/latin_en/support (English)
www.samsung.com/latin/support (Spanish)
www.samsung.com/latin_en/support (English)
www.samsung.com/latin/support (Spanish)
www.samsung.com/latin_en/support (English)
www.samsung.com/latin/support (Spanish)
www.samsung.com/latin_en/support (English)
www.samsung.com/latin/support (Spanish)
www.samsung.com/latin_en/support (English)
www.samsung.com/latin/support (Spanish)
www.samsung.com/latin_en/support (English)
www.samsung.com/latin_en/support (English)
www.samsung.com/latin/support (Spanish)
www.samsung.com/latin_en/support (English)
www.samsung.com/latin/support (Spanish)
www.samsung.com/latin_en/support (English)
www.samsung.com/latin/support (Spanish)
www.samsung.com/latin_en/support (English)
www.samsung.com/latin/support (Spanish)
www.samsung.com/latin_en/support (English)
www.samsung.com/ve/support
www.samsung.com/co/support
www.samsung.com/cl/support
www.samsung.com/cl/support
www.samsung.com/pe/support
www.samsung.com/ar/support
www.samsung.com/latin/support (Spanish)
www.samsung.com/latin_en/support (English)
www.samsung.com/latin/support (Spanish)
www.samsung.com/latin_en/support (English)
www.samsung.com/uk/support
www.samsung.com/ie/support
www.samsung.com/de/support
www.samsung.com/fr/support
www.samsung.com/it/support
www.samsung.com/es/support
www.samsung.com/pt/support
www.samsung.com/support
www.samsung.com/nl/support
www.samsung.com/be/support (Dutch)
www.samsung.com/be_fr/support (French)
www.samsung.com/no/support
www.samsung.com/dk/support
www.samsung.com/fi/support
www.samsung.com/se/support
www.samsung.com/pl/support
www.samsung.com/hu/support
www.samsung.com/sk/support
www.samsung.com/at/support
www.samsung.com/ch/support (German)
www.samsung.com/ch_fr/support (French)
www.samsung.com/cz/support
www.samsung.com/hr/support
www.samsung.com/support
www.samsung.com/support
www.samsung.com/si
www.samsung.com/rs/support
www.samsung.com/bg/support
www.samsung.com/ro/support
www.samsung.com/gr/support
www.samsung.com/lt/support
COUNTRY
LATVIA
ESTONIA
RUSSIA
BELARUS
GEORGIA
ARMENIA
AZERBAIJAN
KAZAKHSTAN
UZBEKISTAN
KYRGYZSTAN
TAJIKISTAN
MONGOLIA
CALL
8000-7267
800-7267
8-800-555-55-55 (VIP care 8-800-555-55-88)
810-800-500-55-500
0-800-555-555
0-800-05-555
0-88-555-55-55
8-10-800-500-55-500 (GSM: 7799, VIP care 7700)
8-10-800-500-55-500 (GSM: 7799)
00-800-500-55-500
8-10-800-500-55-500
+7-495-363-17-00
UKRAINE
0-800-502-000
MOLDOVA
CHINA
0-800-614-40
400-810-5858
HONG KONG
(852) 3698 4698
MACAU
SINGAPORE
AUSTRALIA
NEW ZEALAND
VIETNAM
0800 333
1800-SAMSUNG(726-7864)
1300 362 603
0800 726 786
1800 588 889
0-2689-3232,
THAILAND
1800-29-3232
MYANMAR
+95-01-2399-888
1800-88-9999
MALAYSIA
603-77137477 (Overseas contact)
021-56997777
INDONESIA
08001128888
1-800-10-7267864 [PLDT]
PHILIPPINES
1-800-8-7267864 [Globe landline and Mobile]
02-4222111 [Other landline]
TAIWAN
0800-329999
JAPAN
0120-363-905
1800 3000 8282 - Toll Free
INDIA
1800 266 8282 - Toll Free
BANGLADESH 09612300300
SRI LANKA
94117540540
08000-7267864
EGYPT
16580
ALGERIA
021 36 11 00
IRAN
021-8255 [CE]
SAUDI ARABIA 8002474357
PAKISTAN
TUNISIA
U.A.E
OMAN
KUWAIT
BAHRAIN
QATAR
TURKEY
0800-Samsung (72678) 80-1000-12 800-SAMSUNG (800 - 726 7864)
800-SAMSUNG (800 - 726 7864)
183-CALL (183-2255)
8000-GSAM (8000-4726)
800-CALL (800-2255)
444 77 11
0800-22273
JORDAN
06 5777444
SYRIA
18252273
MOROCCO
080 100 22 55
SOUTH AFRICA 0860 SAMSUNG (726 7864)
BOTSWANA
8007260000
NAMIBIA
08 197 267 864
ZAMBIA
0211 350370
MAURITIUS
23052574020
REUNION
262508869
MOZAMBIQUE 847267864 / 827267864
NIGERIA
0800-726-7864
0800-10077
Ghana
0302-200077
Cote D’Ivoire 8000 0077
SENEGAL
800-00-0077
CAMEROON
7095-0077
KENYA
0800 545 545
UGANDA
0800 300 300
TANZANIA
0800 755 755 / 0685 889 900
RWANDA
9999
BURUNDI
200
DRC
499999
SUDAN
1969
OR VISIT US ONLINE AT
www.samsung.com/lv/support
www.samsung.com/ee/support
www.samsung.com/ru/support
www.samsung.com/support
www.samsung.com/support
www.samsung.com/support
www.samsung.com/support
www.samsung.com/support
www.samsung.com/support
www.samsung.com/kz_ru/support
www.samsung.com/support
www.samsung.com/support
www.samsung.com/ua/support (Ukrainian)
www.samsung.com/ua_ru/support (Russian)
www.samsung.com/support
www.samsung.com/cn/support
www.samsung.com/hk/support (Chinese)
www.samsung.com/hk_en/support (English)
www.samsung.com/support
www.samsung.com/sg/support
www.samsung.com/au/support
www.samsung.com/nz/support
www.samsung.com/vn/support
www.samsung.com/th/support
www.samsung.com/support
www.samsung.com/my/support
www.samsung.com/id/support
www.samsung.com/ph/support
www.samsung.com/tw/support
www.samsung.com/jp/support
www.samsung.com/in/support
www.samsung.com/in/support
www.samsung.com/support
www.samsung.com/eg/support
www.samsung.com/n_africa/support
www.samsung.com/iran/support
www.samsung.com/sa/support
www.samsung.com/sa_en/support (English)
www.samsung.com/pk/support
www.samsung.com/n_africa/support
www.samsung.com/ae/support (English)
www.samsung.com/ae_ar/support (Arabic)
www.samsung.com/tr/support
www.samsung.com/Levant/support (English)
www.samsung.com/Levant/support (English)
www.samsung.com/n_africa/support
www.samsung.com/support
www.samsung.com/africa_en/support
www.samsung.com/africa_fr/support
www.samsung.com/support
Ceiling Type Series
AC✴✴✴JNCDEH✴
Air Conditioner
user manual
This manual is made with 100% recycled paper.
imagine the possibilities
Thank you for purchasing this Samsung product.
EN ES FR IT PT DE EL DB68-05134A-01
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
