Robot vacuum cleaner
User manual
SR10J50✴✴✴ Series
• Before operating this unit, please read the instructions carefully.
• For indoor use only.
VR5000_EN_00734H-00_UK.indd 1
2015-04-22 오후 4:48:25
Contents
Preparation
Maintenance
Safety information
3
Cleaning and maintaining
27
Safety information
3
Cleaning the dustbin
27
Important safety instructions
4
Emptying the dustbin (Quick Empty)
28
Cleaning the driving wheel
28
Cleaning the sensors and the camera
28
Installation12
Cleaning the power brush
29
Accessories13
Cleaning the side brush
30
Charging14
Appendices
Installing the virtual guard (Optional) 16
Notes and cautions
31
Part name of the virtual guard
17
Charging
31
Inserting batteries
17
In use
31
Cleaning and maintenance
33
Installation
Operations
About the battery
33
Using the robot vacuum cleaner
18
About the IrDA sensor
34
Cleaning method for each mode
20
Information codes
35
Using the remote control
21
Troubleshooting36
Name of each part
25
Warnings about battery
38
Setting time/schedule
26
How to remove the battery
38
Setting the time
26
Specifications40
Setting the schedule
26
Open source announcement
41
2 English
VR5000_EN_00734H-00_UK.indd 2
2015-04-22 오후 4:48:26
Preparation
Safety information
Safety information
• Before operating the appliance, please read this manual thoroughly and
retain it for your reference.
Preparation
WARNING
WARNING
• Because these following operating instructions cover various models, the
characteristics of your vacuum cleaner may differ slightly from those
described in this manual.
Caution/Warning symbols used
WARNING
Indicates that a danger of death or serious injury exists.
caution
Indicates that a risk of personal injury or material damage exists.
Other symbols used
note
Indicates that the following text contains additional important information.
English 3
VR5000_EN_00734H-00_UK.indd 3
2015-04-22 오후 4:48:26
Important safety instructions
Preparation
When using an electrical appliance, basic precautions should be observed,
including the following:
Read all instrucrions before using your robot vacuum cleaner.
Unplug the charger (station) from outlet when not in use and before
conducting maintenance.
WARNING
To reduce the risk of fire, electric shock, or injury:
General
• Use only as described in this manual.
• Do not operate the robot vacuum cleaner or charger (station) if it has
been damaged in any way.
• If the robot vacuum cleaner is not working as it should, has been
dropped, damaged, left outdoors, or dropped in water, return it to a
customer care center.
• Do not handle the charger (station) or robot vacuum cleaner with wet
hands.
• Use only on dry, indoor surfaces.
• This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack
of experience and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way and understand
the hazards involved.
• Children shall not play with the appliance. Cleaning and user maintenance
shall not be made by children without supervision.
4 English
VR5000_EN_00734H-00_UK.indd 4
2015-04-22 오후 4:48:26
Preparation
BATTERY Charger (station)
• Do not modify the polarized plug to fit a non-polarized outlet or
extension cord.
• Do not use outdoors or on wet surfaces.
• Unplug the charger (station) from the outlet when not in use and before
servicing.
• Use only the charger (station) supplied by the manufacturer to recharge.
• Do not use with a damaged cord or plug or a loose power outlet.
• Do not pull or carry by the cord, use the cord as a handle, close the door
on the cord, or pull the cord around sharp edges or corners. Keep the
cord away from heated surfaces.
• Do not use extension cords or outlets with inadequate current carrying
capacity.
• Do not unplug by pulling on the cord. To unplug, grasp the plug, not the
cord.
• Do not mutilate or incinerate batteries as they will explode at high
temperatures.
• Do not attempt to open the charger (station). Repairs should only be
carried out by a qualified customer care center.
• Do not expose the charger (station) to high temperatures or allow
moisture or humidity of any kind to come into contact with the charger
(station).
English 5
VR5000_EN_00734H-00_UK.indd 5
2015-04-22 오후 4:48:26
Preparation
Robot vacuum cleaner
• Do not pick up hard or sharp objects such as glass, nails, screws, coins,
and etc.
• Do not use without a filter in place. When servicing the unit, never put
fingers or other objects into the fan chamber in case the unit accidentally
turns on.
• Do not put any objects into openings. Do not use with any openings
blocked; keep openings free of dust, lint, hair, and anything that may
reduce air flow.
• Do not use to pick up toxic materials (chlorine bleach, ammonia, drain
cleaner, etc.).
• Do not use to pick up anything that is burning or smoking, such as
cigarettes, matches, or hot ashes.
• Do not use to pick up flammable or combustible liquids such as gasoline,
nor use on areas where they may be present including:
––Locations with candles or desk lamps on the floor.
––Locations with unattended fires (fire or embers).
––Locations with distilled alcohol, thinner, ashtrays with burning
cigarettes, etc.
• Do not use the robot vacuum cleaner in an enclosed space filled with
vapours given off by oil based paint, paint thinner, moth proofing
substances, flammable dust, or other explosive or toxic vapours.
• Leaks from battery cells can occur under extreme usage or temperature
conditions.
• If the liquid gets on skin, wash quickly with water. If the liquid gets into
the eyes, flush them immediately with clean water for a minimum of 10
minutes. Seek medical attention.
6 English
VR5000_EN_00734H-00_UK.indd 6
2015-04-22 오후 4:48:26
Preparation
WARNING
Power related
• Please prevent any risk of electric shock or fire.
––Do not damage the power cord.
––Do not pull the power cord too hard or touch the power plug with wet
hands.
––Do not use a power source other than the national rated voltage and
also do not use a multi outlet to supply power to number of devices at
the same time.
––Do not leave the power cord carelessly on the floor.
––Do not use a damaged power plug, power cord or loose power outlet.
• Clean dust or any foreign matters on the pin and contact part of the
power plug.
––There is a risk of electric shock or malfunction.
Before use
• Do not use the robot vacuum cleaner near combustible materials.
––Places near candles, desktop lamps, fireplaces or near combustible
materials such as gasoline, alcohol, thinners etc.
• The robot vacuum cleaner is intended for household use therefore do
not use it in an attic, basement, storage, industrial building, out of indoor
space, in places with moisture (such as bathroom, laundry), or on the
table or shelves.
––The robot vacuum cleaner can be damaged or malfunction.
English 7
VR5000_EN_00734H-00_UK.indd 7
2015-04-22 오후 4:48:26
Preparation
• Install the Virtual guard (option) in front of dangerous areas (such as
stairs or railings) to prevent damaging the product or getting injured.
––For your safety, always keep the cliff sensor clean.
• Be sure the robot vacuum cleaner does not pass through or touch any
kind of liquids.
––The robot vacuum cleaner can be severely damaged and it may
contaminate other areas if the wheels pass through liquid.
• Do not spill any liquids on the charger.
––There is a risk of fire or electric shock.
• Do not use the charger for anything other than its intended purpose.
––There is a risk of fire or severe damage to the charger.
• Always keep the cliff sensor clean for your safety.
In use
• If any abnormal sounds, smells or smoke come from the robot vacuum
cleaner, immediately shut off the power switch at the bottom of the robot
vacuum cleaner and contact a service center.
Cleaning and maintenance
• When the power cord is damaged, contact a service center to get it
replaced by certified repairman.
––There is a risk of fire or electric shock.
• Please check with a Samsung Electronics service center when exchanging
batteries.
––Using batteries from other products can cause malfunction.
8 English
VR5000_EN_00734H-00_UK.indd 8
2015-04-22 오후 4:48:26
Preparation
caution
Before use
• Insert the dustbin before using the robot vacuum cleaner.
• Open room doors before cleaning in order to have all rooms cleaned
and install a Virtual guard (option) in front of entryways, balconies,
bathrooms, or other areas where the robot vacuum cleaner may fall.
• Be careful with the followings for proper automatic recharging.
––Always turn on the power of the charger.
––Install the charger where the robot vacuum cleaner can easily find.
––Do not leave any object in front of the charger.
• When installing the charger, do not leave the cord carelessly on the floor
since the robot vacuum cleaner may get tangled by it.
• Do not use the robot vacuum cleaner on black colored floors.
––The robot vacuum cleaner may not be able to operate normally.
• Do not pick up the robot vacuum cleaner by the dustbin holder.
• Do not place any objects within 0.5 m to both sides and 1 m to the front
of the charger.
• Make sure the charger’s charging contact is not damaged or have any
foreign matters on it.
• Do not install the charger in an area with a dark floor.
––If the floor around the charger is dark, recharging is hindered.
• Move any obstacles that may disturb the robot vacuum cleaner’s
movement (such as children’s indoor swing or slides) before cleaning.
English 9
VR5000_EN_00734H-00_UK.indd 9
2015-04-22 오후 4:48:26
Preparation
In use
• Using the robot vacuum cleaner on thick carpet may damage both the
robot vacuum cleaner and the carpet.
––The robot vacuum cleaner cannot pass over carpet that is thicker than
1 cm.
• Do not use the robot vacuum cleaner on tables or other high surfaces.
––There is a risk of damage if it falls.
• The robot vacuum cleaner may bump into chair, desk legs therefore move
them away for faster and efficient cleaning.
• When the robot vacuum cleaner is operating, do not lift it up or carry it
to another area.
• Do not hold the robot vacuum cleaner by its driving wheels when
carrying it to another area.
• Do not put any objects on top of the robot vacuum cleaner since it may
cause malfunction.
• Remove any large papers or plastic bags from the floor before using the
robot vacuum cleaner since they may block the intake.
• The robot vacuum cleaner may not be able to continue its operation if it
is stuck at entrances or veranda doorsills.
––The robot vacuum cleaner stops operating for safety reasons if it cannot
move for more than 5 minutes.
––To resume operating, turn the power switch off and then on again after
moving it to a location where it can continue cleaning.
• Do not aim the red pointer directly at people or animals (optional).
10 English
VR5000_EN_00734H-00_UK.indd 10
2015-04-22 오후 4:48:26
Preparation
Cleaning and maintenance
• Prevent any damage to the robot vacuum cleaner by complying the
followings.
––Do not clean the robot vacuum cleaner by spraying water directly onto
it or use benzene, thinner, acetone or alcohol to clean it.
• Do not disassemble or repair the robot vacuum cleaner yourself.
––This should only be done by a certified repairman.
• Always keep the obstacle sensor and cliff sensor clean.
––If foreign matter accumulates, sensors may malfunction.
English 11
VR5000_EN_00734H-00_UK.indd 11
2015-04-22 오후 4:48:26
Installation
Installation
Power of the charger must be on at all times.
Power lamp
(Red)
Install it in a place without
obstacles and danger of falling.
About 0.5 m
Installation
About 0.5 m
About 1 m
note
• Install the charger in a place where the floor and wall are level.
• Install the charger along the grain of wooden floors.
• If the power switch is off, the robot vacuum cleaner will not charge even if it is docked
on the charger.
• Always turn on the power of the charger.
––If power is not supplied to the charger, the robot vacuum cleaner cannot find it and
cannot automatically recharge.
––If the robot vacuum cleaner is left detached from the charger, the battery will drain
naturally.
• If the robot vacuum cleaner is in energy-saving mode, power will not come on even if
the power switch is turned off and then on. Press and hold the Start/Stop button on the
robot vacuum cleaner.
12 English
VR5000_EN_00734H-00_UK.indd 12
2015-04-22 오후 4:48:26
Accessories
Batteries
[AAA type (Option)]
User manual
Spare filter (Option)
Cleaning brush
Virtual guard (Option)
Installation
Remote control (Option)
English 13
VR5000_EN_00734H-00_UK.indd 13
2015-04-22 오후 4:48:27
Charging
It takes approximately 120 minutes to completely charge when charging for the first time
after purchase and can be used for approximately 90 minutes.
Charging lamp during charging (green)
Installation
WARNING
Rated input voltage of this
product is 220 - 240 V~.
1 Turn on the power switch on the
bottom.
You must turn on the power switch to turn
on the robot vacuum cleaner.
2 Manually charge the robot vacuum
cleaner by placing it on the charger.
Make sure the charge pins of the robot
vacuum cleaner and the charger is aligned.
3 Check the charging status.
“
” will turn on according to charging
progress and “FULL” will turn on when
charging is complete.
14 English
VR5000_EN_00734H-00_UK.indd 14
2015-04-22 오후 4:48:28
Automatic charging
When the battery indicator blinks during
cleaning, the robot vacuum cleaner will
return to the charger to charge itself
automatically.
You can command the robot vacuum
cleaner to recharge at the charger while it
is in cleaning process.
Installation
Recharge
Low battery (Lo)
Manually charge the robot vacuum cleaner
by placing it on the charger.
Steps to take if recharging is not being executed.
Check the installation status of the charger when:
• the charger is located in a place where the robot vacuum cleaner cannot easily access.
• distance between the charger and robot vacuum cleaner is over 5 m apart.
––It may take a long time for the robot vacuum cleaner to return to the charger for
recharging.
Manually charge the robot vacuum cleaner when:
• the charger is located in a corner.
• battery is fully exhausted.
• the robot vacuum cleaner is stuck by obstacles (furniture etc.).
• the robot vacuum cleaner can’t climb threshold near charge. (Height of the threshold
that the robot vacuum cleaner can climb: about 1.5 cm and below)
• when the battery indicator blinks and “Lo” is displayed.
• when the robot vacuum cleaner is set on Spot clean or Manual clean mode.
English 15
VR5000_EN_00734H-00_UK.indd 15
2015-04-22 오후 4:48:29
Installing the virtual guard (Optional)
Infrared ray from the Virtual guard will restrict the robot vacuum cleaner from
approaching certain areas.
Virtual guard
Installation
.5 m
m2
u
im
Min
The distance of virtual wall is 2.5 m at minimum and may differ depending on
surroundings and movement status of the robot vacuum cleaner.
Power lamp (Red) will blink.
1 Press the Power button to turn it on.
2 Install the Virtual guard where you
want to restrict the robot vacuum
cleaner’s entrance.
Make sure that the distance sensor is
facing in the desired direction you want
to create a invisible barrier (which will
restrict the robot vacuum cleaner’s
approach).
16 English
VR5000_EN_00734H-00_UK.indd 16
2015-04-22 오후 4:48:29
13
Part name of the virtual guard
Power button
Robot vacuum cleaner detection sensor
Power lamp
Power on: Red lamp blinks
Power off: Lamp is off
Battery cover
Installation
Distance detection sensor (Infrared ray
sensor)
Inserting batteries
Batteries for the Virtual guard must be purchased separately.
1 Open the battery cover of the Virtual
guard by pressing the locking tab
and lift it up.
2 Insert the batteries (D type) as
shown in the illustration (check the
+, - polarity).
3 Insert the tip of the cover into the
slot and push the other end to close
the battery cover.
English 17
VR5000_EN_00734H-00_UK.indd 17
2015-04-22 오후 4:48:30
Operations
Using the robot vacuum cleaner
You must turn on the power switch before using the robot vacuum cleaner.
Turning the power on/off
Turn on/off the power switch on
the bottom of the robot vacuum
cleaner.
WARNING
• When the robot vacuum
cleaner is not used for
10 minutes, power will turn
off automatically.
Operations
Using auto clean mode
The robot vacuum cleaner moves and
cleans automatically until it cleans an
entire space once.
❇❇ Stop cleaning: Press the
shortly
button
Using the cleaning modes
You can select the desired cleaning mode.
Recharge
You can command the robot vacuum
cleaner to recharge at the charger
automatically while it is in cleaning
process.
Setting schedule
You can set or cancel on-time or daily
schedule.
❇❇ Refer to “Setting the schedule”.
18 English
VR5000_EN_00734H-00_UK.indd 18
2015-04-22 오후 4:48:30
Selecting cleaning mode
Cleaning mode
How to select
Displayed icon
Press once
Auto clean
Press twice
Spot clean
Press 3 times
Max clean
Operations
Press 4 times
Manual clean
❇❇ Direction control can be done only by the
remote control.
Press 5 times
Edge clean
❇❇ When the robot vacuum cleaner is being charged, you can only select the Auto clean, Max clean or
Edge clean mode.
English 19
VR5000_EN_00734H-00_UK.indd 19
2015-04-22 오후 4:48:31
Cleaning method for each mode
Auto clean
About 1.5 m
Cleans automatically
until an entire space
is cleaned once.
About 1.5 m
Spot clean
Cleans a localized
area intensely. It
can be used to clean
bread or cookie
crumbs.
Max clean
Manual clean
Cleans until the
battery is depleted.
You can move the
robot vacuum cleaner
with the remote
control to clean the
desired spot.
Operations
Edge clean
Cleans the corners by
reaching to them as
close as possible.
20 English
VR5000_EN_00734H-00_UK.indd 20
2015-04-22 오후 4:48:32
Using the remote control
[A Type]
[B Type]
01
02
01
02
03
03
02
04
Operations
05
04
English 21
VR5000_EN_00734H-00_UK.indd 21
2015-04-22 오후 4:48:32
[A Type]
[B Type]
01 Power/Recharging
Power
Turn the robot vacuum cleaner’s power on/off
Recharging
Select to recharge the robot vacuum cleaner at the charger
while it is in cleaning process
02 Cleaning mode
Auto clean
Select to automatically clean an entire space once
Operations
Spot clean
Select to clean a localized area intensely
Max clean
Select to make the robot vacuum cleaner to clean until battery
indicator flashes after reaching down to one level
Manual clean
Select to manually control and clean by using the remote
control
Edge clean
Select to clean the corners by reaching to them as close as
possible
• When the obstacle sensor detects an obstacle during the
cleaning, the robot vacuum cleaner reduces its speed to
minimize the bumping impact and the bumper sensor also
helps it lower the buming impact.
Start/Stop
Select to start or stop cleaning process
22 English
VR5000_EN_00734H-00_UK.indd 22
2015-04-22 오후 4:48:34
[A Type]
[B Type]
03 Direction control
Select to move forward
Select to turn left
Select to turn right
❇❇ Moving backward is not available
04 Additional function
Silence mode
Select to clean with lower operation noise
• "
" displays on the display panel while the Silence mode
is operating.
Setting the time
Operations
Refer to page 26
Setting the schedule
Refer to page 26
English 23
VR5000_EN_00734H-00_UK.indd 23
2015-04-22 오후 4:48:35
05 Point cleaning
Only available with A type remote control
40 cm
You can use the remote control to point
and clean the desired spot while the
robot vacuum cleaner is in cleaning
process.
• Point the red light on the floor within
40 cm around the robot vacuum
cleaner’s location.
• Press and hold the Point cleaning button
to move the red light to the desired spot.
The the robot vacuum cleaner will follow
the light while cleaning.
Operating distance of the remote control
Operations
Height of the
remote control
Height of the
remote control
0.5 m
1m
1.5 m
Operating
distance
About
1.5 m
About
2m
About
2.5 m
Operating distance
Inserting batteries
Open the battery cover by lifting it up while pressing the locking tab and insert the
batteries as shown in the illustration. Then, close the cover until it clicks into place.
24 English
VR5000_EN_00734H-00_UK.indd 24
2015-04-22 오후 4:48:36
Name of each part
01
04
Top
05
01 Quick Empty cover (Option)
02 Dustbin button
03 Dustbin
04 Display panel
05 Remote control sensor
06 Obstacle sensor
07 Virtual guard sensor (Option)
08 Bumper sensor
02
03
05
06
06
07
08
01
04
02
02
01
01
03
06
09
07
08
01 Cliff sensor
02 Side brush
03 Charge pin
04 Roller
05 Driving wheel
06 Battery cover
07 Power brush
08 Power brush cover
09 Power switch
Operations
05
Bottom
Display panel
01
03
02
04
09
05 06 07 08
11
12
10
13
01 Start/Stop button
02 Number display
03 Daily schedule
04 One-time schedule
05 Auto clean
06 Spot clean
07 Max clean
08 Manual clean
09 Battery indicator
10 Recharging
11 Cleaning mode button
12 Schedule button
13 Recharge button
English 25
VR5000_EN_00734H-00_UK.indd 25
2015-04-22 오후 4:48:37
Setting time/schedule
B type remote control’s
control.
,
,
buttons works in same manner as A type remote
Setting the time
• You must set the current time before using the one-time/daily schedule.
• You can set the time only with the remote control.
Select "Hour"
Select "Minute"
or
or
Start setting
Setting complete
Setting the schedule
Operations
• Setting/cancelling the schedule can only be done while the robot vacuum cleaner is
docked on the charger.
• Press the Schedule button shortly to set one-time schedule.
• Press the Schedule button for 3 seconds to set daily schedule.
Select "One-time" or
"Daily" schedule
Select "Hour"
Select "Minute"
or
or
or
or
Start setting
Setting
complete
Cancelling during setup
Cancelling One-time/Daily schedule
To cancel the one-time schedule
Cancel complete
To cancel the daily schedule
Press for 3 sec.
Cancel complete
26 English
VR5000_EN_00734H-00_UK.indd 26
2015-04-22 오후 4:48:38
Maintenance
Cleaning and maintaining
You must turn off the power switch before cleaning the robot vacuum cleaner.
Cleaning the dustbin
Clean the dustbin if there’s too much dust in the dustbin.
2 Open the
dustbin cover
3 Remove the
filter from the
dustbin
4 Remove dust in
the dustbin and
the filter
5 Wash the
dustbin and the
filter
6 Reassemble the
filter into the
dustbin
7 Close the
dustbin cover
8 Reinsert the
dustbin into the
robot vacuum
cleaner
Maintenance
1 Remove the
dustbin
English 27
VR5000_EN_00734H-00_UK.indd 27
2015-04-22 오후 4:48:40
Emptying the dustbin (Quick Empty)
Use the Quick Empty cover for emptying the dustbin easily.
1 Open the Quick
Empty cover
2 Remove dust
in the dustbin
with a vacuum
cleaner
3 Close the Quick
Empty cover
Cleaning the driving wheel
L
I ON
L
F
L
R
OOF
R
OOF
R
L
I ON
L
F
L
2 Use a blunt rod
or tweezers
to remove the
foreign matters
R
R
L
R
Maintenance
L
1 Put a soft cloth
on the floor and
place the robot
vacuum cleaner
upside-down
Cleaning the sensors and the camera
Lightly wipe with soft cloth.
Camera
Front sensor
window
Cliff sensor window
Rear sensor
window
28 English
VR5000_EN_00734H-00_UK.indd 28
2015-04-22 오후 4:48:41
Cleaning the power brush
1 Remove the
dustbin
2 Remove the
power brush
cover
3 Remove the
power brush
4 Clean the power
brush
5 Reassemble the
power brush
6 Reassemble the
power brush
cover
Maintenance
English 29
VR5000_EN_00734H-00_UK.indd 29
2015-04-22 오후 4:48:43
Cleaning the side brush
Clean the side brush if there’s foreign matter on the brush.
1 Dip soft cloth
into warm water
R
R
R
2 Wrap the
side brushes
with the cloth
for about
10 seconds and
then wipe it
If hair or string is caught between the main unit and the side brush, follow the below
steps.
1 Remove the side
brushes
2 Clean the side
brushes
R
R
R
R
R
R
L
R
Maintenance
3 Reassemble the
side brushes
R
R
30 English
VR5000_EN_00734H-00_UK.indd 30
2015-04-22 오후 4:48:44
Appendices
Notes and cautions
Charging
note
• If the battery overheats during charging,
it may take longer to charge.
• When automatic charging is not working,
please check the followings.
––Turn the power switch (on the bottom
of the robot vacuum cleaner) off and
then on again.
––Unplug the charger’s power plug and
then plug it back on.
––Check whether there is any foreign
matter in the charge pins and clean the
robot vacuum cleaner and the charge
pins of the charger with a dry cloth or
rag.
––Check for any obstacles such as
reflective objects, chairs, etc. near the
charger.
• If the robot vacuum cleaner is left
detached from the charger, the battery
will drain naturally.
––Try to keep the robot vacuum cleaner
being charged on the charger. (Turn
off the power switch and leave the
charger unplugged when planning to
leave the house for long periods of
time by going on a business trip or
vacation, etc.)
In use
note
• To use the robot vacuum cleaner, the
power switch must be turned on. If the
power switch is turned off, all settings
will be reset.
• Do not lie down around the Robot
Vacuum that is running.
––Your hair may be caught between
the power brush and the side brush,
resulting in physical injury.
• The robot vacuum cleaner may get
caught on thresholds, etc. during
cleaning.
––To restart operation, shut off the
power switch, move the robot vacuum
cleaner to an area where it can move
easily and then turn on the power
again.
• The robot vacuum cleaner cannot
completely clean areas it cannot enter,
such as corners, between the wall and
sofa, etc.
––Please use another cleaning tool to
clean them regularly.
• The robot vacuum cleaner cannot
vacuum clumps of dirt, so some may
remain on the floor after cleaning.
Appendices
––Please use another cleaning tool to
clean them regularly.
English 31
VR5000_EN_00734H-00_UK.indd 31
2015-04-22 오후 4:48:44
• If the robot vacuum cleaner is turned
off, power cannot be turned on by the
Power button of the remote control.
Press and hold the Start/Stop button on
the robot vacuum cleaner.
• If the battery becomes low during Auto/
Max clean mode, the robot vacuum
cleaner will recharge and finish cleaning
the remaining area after recharging.
(Repeat cleaning frequency: 1 time)
• You cannot select and execute Max/
Manual clean mode while charging.
• Do not unnecessarily move the robot
vacuum cleaner or press buttons while
it is in Auto/Max clean mode. It assumes
that cleaning is complete and starts
cleaning again from the beginning.
• If the Point cleaning button is pressed
while the robot vacuum cleaner is
charging, it will move backward about
250 mm and rotate 180º.
• If the robot vacuum cleaner senses the
bumping impact or fall, it will move
backward automatically.
• If the Point cleaning button is not
pressed for more than 2 seconds, the
point cleaning function will be turned
off and the robot vacuum cleaner will
operate according to the previous
operation as the follows:
––When it was in the Stand-by mode, it
will stop on the spot.
––When it was in the Manual clean mode,
it will stand by on the spot for the
Manual mode.
––When it was in the Auto/Max/Edge
clean mode, it will operate in the
previous clean mode.
––When it was in the Spot clean mode,
it will operate in the Spot clean mode
from the spot.
––When it was returning to the charger
to charge itself, it will move to the
charger again.
• When the robot vacuum cleaner is
charging automatically since the battery
indicator blinks, the point cleaning
function will not operate.
Appendices
32 English
VR5000_EN_00734H-00_UK.indd 32
2015-04-22 오후 4:48:44
Cleaning and maintenance
note
• If you washed the dustbin and filter with
water,
––Dustbin: Completely wipe out the
water.
––Filter: Completely dry it in a shade
before using.
caution
• Watch your fingers when attaching or
detaching the filter, since they may get
stuck in the dustbin’s intake.
• To avoid blockages by foreign matter,
do not let toothpicks, cotton swabs etc.
from being vacuumed by the robot
vacuum cleaner.
• If it is difficult to remove foreign matters
from the power brush, contact a service
center.
• Since the power brush removes dirt
from the floor during cleaning, foreign
matters such as thread, long hair, etc.
may get caught in it. Therefore check
and clean it regularly.
About the battery
note
• Purchase batteries at service centers and
check the genuine part symbol (
)
and model name before purchasing.
• Charge batteries in a place with good
ventilation.
• The battery is exclusively for Samsung
Electronics robot vacuum cleaner; do not
use it for any other product.
• Do not disassemble or modify the
battery.
• Do not throw the battery out in fire or
heat it up.
• Do not connect any metallic object to
the charging contacts (+, -).
• Do not discard the batteries with your
household trash.
• Before you discard the robot vacuum
cleaner, dispose of the batteries in an
environmentally safe manner.
––Follow all local regulations when
disposing of batteries.
• Store it indoors (at 0 °C ~ 40 °C).
• If the battery malfunctions, do not
disassemble it yourself. Contact your
nearest service center.
Appendices
• The battery warranty period is 6 months
from the date of purchase.
English 33
VR5000_EN_00734H-00_UK.indd 33
2015-04-22 오후 4:48:44
• The robot vacuum cleaner is powered
by an environment-friendly Nickel Metal
Hydride (NiMH) rechargeable battery,
and an over-charge prevention function
guarantees an extended life time.
• An increased charging time and a
shorter battery life indicates the closer
end of the battery life. Please contact
an authorized customer care center to
replace your battery.
• Install the Virtual guard (option) away
from the charger as auto charging may
be interrupted if the Virtual guard is
near the charger.
• If more than one robot vacuum cleaners
is used simultaneously, they may
malfunction due to interference of the
infrared signals.
• The battery warranty period is 6 months
from the date of purchase.
About the IrDA sensor
caution
• Infrared signal transmission may not be
smooth in locations exposed to halogen
lamps or in outdoor locations.
• The robot vacuum cleaner uses 3 types
of infrared devices and a device may not
work in front of another device with a
higher priority.
––Infrared signal Priority: Remote control
> Virtual guard (option) > Charger
Appendices
• When controlling the robot vacuum
cleaner with the remote control, the
robot vacuum cleaner may cross the
invisible barrier set by the Virtual guard
(option) and enter the area you don’t
want it to enter, since remote control’s
signal has a higher priority.
• Different infrared signals may interfere
with one another and cause the devices
to malfunction if they are used together
in a small space or in a close distance.
34 English
VR5000_EN_00734H-00_UK.indd 34
2015-04-22 오후 4:48:45
Information codes
Information codes
Checklist
The robot vacuum cleaner is caught, stuck or trapped
while moving around.
• Turn off the power switch and move the robot vacuum
cleaner to another area.
Foreign matter caught in the Power brush.
• Turn off the power switch and remove the foreign matter
from the Power brush.
Foreign matter caught in the left Driving wheel.
• Turn off the power switch and remove the foreign matter
from the Driving wheel.
Foreign matter caught in the right Driving wheel.
• Turn off the power switch and remove the foreign matter
from the Driving wheel.
Bumper sensor needs to be checked.
• Turn off the power switch and turn it back on.
• Contact a service center if information code does not
disappear.
Foreign matter accumulated on the obstacle sensor.
• Turn off the power switch and clean the front and rear
sensor with a soft cloth.
Foreign matter accumulated on the cliff sensor.
• Turn off the power switch and clean the cliff sensor with a
soft cloth.
Foreign matter caught on the side brush.
If press Start/Stop button or turn off the power switch, the information code will be
cleared.
Appendices
• Turn off the power switch and remove the foreign matter
from the side brush.
English 35
VR5000_EN_00734H-00_UK.indd 35
2015-04-22 오후 4:48:45
Troubleshooting
Symptom
Checklist
• Check if the power switch is on.
• Check if all the icons are displayed on display panel.
The robot vacuum
cleaner is not working
at all.
• Check if the battery of the robot vacuum cleaner is
depleted.
––When “Lo” is displayed, carry the robot vacuum cleaner
to the charger to charge it.
• Replace the batteries (AAA type) when the remote
controller is not working.
• Check if the dustbin is assembled.
• When “Lo” is displayed on the display panel, carry the
robot vacuum cleaner to the charger to charge it.
The robot vacuum
cleaner is stopped during
cleaning process.
• When the robot vacuum cleaner is stuck by the obstacles
such as cord, threshold etc, pick it up to remove it from the
obstacle.
––If any fabric or string is caught in the drive wheel, turn
off the power switch and remove the fabric or string
before using it again.
• When the robot vacuum cleaner stuck to the floor where
there is a height difference, carry it to another area.
• If the filter is clogged, turn off the power switch and clean
the dustbin and filter.
Suction power is weak.
• When there’s too much dust in the dustbin, suction power
may get weakened. Turn off the power switch and empty
the dustbin.
• If the intake (on bottom of The robot vacuum cleaner) is
blocked by foreign matters, turn off the power switch and
remove foreign matter from the intake.
Appendices
• When noise suddenly increase, turn off the emergency
switch and empty the dustbin.
36 English
VR5000_EN_00734H-00_UK.indd 36
2015-04-22 오후 4:48:45
Symptom
Checklist
• Check if there’s power failure or whether the power plug is
unplugged.
The robot vacuum
cleaner cannot find the
charger.
• Remove any obstacles around the charger (about 1 m in
front and about 0.5 m to both sides of the charger) that
may disturb the robot vacuum cleaner from returning to
the charger.
• When there’s foreign matters on the charge pins that
affects charging, clean the foreign matter.
• Check if the Virtual guard (option) is installed near the
charger.
• Check if the charger is installed along the grain of wooden
floors or tiles.
The robot vacuum
cleaner suddenly cleans
diagonally.
• It may clean in diagonal direction for moving to another
area in shortest route, or it made contact with any
obstacles in that angle, or if it was charged at the charged
at an angle, or grain of the wooden/tile floor is in that
direction.
• If you point the red light directly at the robot vacuum
cleaner, it may not move to desired direction.
Point cleaning is not
working. (Option)
––Point the red light on the floor within 40 cm around the
robot vacuum cleaner.
• Do not use the point cleaning in direct sunlight, under
bright light or on dark floors.
The robot vacuum
cleaner passes through
the Virtual guard.
(Option)
• If the power lamp if the Virtual guard is off, check if the
Virtual guard is turned off and then turn it back on.
• Check if the distance sensor is facing in the desired
direction you want to create an invisible barrier.
• Make sure you are using batteries.
• Replace the batteries with new batteries. (2 type D (LR20)
batteries)
Appendices
The battery usage time
of the Virtual guard is
too short. (Option)
• If the batteries in the Virtual guard are depleted, replace
them. (2 type D (LR20) batteries)
English 37
VR5000_EN_00734H-00_UK.indd 37
2015-04-22 오후 4:48:45
Warnings about battery
❇❇ Only available in E.U.
WARNING
You must not remove (or attempt to remove) the battery incorporated in this product
on your own. To replace the battery, you must contact your service provider or an
independent qualified professional. These instructions have been prepared for the
exclusive use of your service provider or independent qualified professional.
FOR YOUR OWN SAFETY, DO NOT ATTEMPT TO REMOVE THE BATTERY ON YOUR OWN OR
DISPOSE OF IT IN FIRE. DO NOT DISASSEMBLE, CRUSH OR PUNCTURE THE BATTERY.
How to remove the battery
Remove the robot vacuum cleaner from the charger (station) for disassembling.
You must turn off the robot vacuum cleaner for safety before diassembling.
1 Lay down and invert the robot
vacuum cleaner, and then remove
2 screws.
2 Remove the battery cover.
Appendices
3 Remove the battery from the slot
and disconnect the connector.
38 English
VR5000_EN_00734H-00_UK.indd 38
2015-04-22 오후 4:48:46
Correct disposal of batteries in this product
(Applicable in countries with separate battery return systems.)
The marking on the battery, manual or packaging indicates that the battery in this
product should not be disposed of with other household waste. Where marked,
the chemical symbols Hg, Cd or Pb indicate that the battery contains mercury,
cadmium or lead above the reference levels in EC Directive 2006/66.
The battery incorporated in this product is not user replaceable. For information on its
replacement, please contact your service provider. Do not attempt to
remove the battery or dispose it in a fire. Do not disassemble, crush, or puncture the
battery. If you intend to discard the product, the waste collection site will take the
appropriate measures for the recycling and treatment of the product, including the
battery
Appendices
English 39
VR5000_EN_00734H-00_UK.indd 39
2015-04-22 오후 4:48:46
Specifications
Classification
Mechanical
specifications
Power
specifications
Cleaning
specifications
Item
Detail information
Diameter
355 mm
Height
93 mm
Weight
3.6 kg
Button type of the main unit
Touch type
Power voltage
220 - 240 V~, 50 - 60 Hz
Power consumption (Charger)
50 W
Power consumption (Main
unit)
40 W
Battery specifications
14.4 V / 2,000 mA
Charging type
Automatic charging/Manual charging
Cleaning mode
Auto, Spot, Max, Manual
Charging time
Approximately 120 minutes
Cleaning time
(On the basis of hard floor)
Approximately 90 minutes
Dust bin capacity
About 0.6 ℓ
Cleaning
method
Ceiling shape recognition
This Vacuum cleaner is approved the following. (Only available in E.U.)
Electromagnetic Compatibility Directive : 2004/108/EEC
Low Voltage Directive : 2006/95/EC
Appendices
40 English
VR5000_EN_00734H-00_UK.indd 40
2015-04-22 오후 4:48:46
Open source announcement
The software included in this product contains open
source software. You may obtain the complete
corresponding source code for a period of three years
after the last shipment of this product by sending an
email to mailto:[email protected]
It is also possible to obtain the complete corresponding
source code in a physical medium such as a CD-ROM; a
minimal charge will be required.
The following URL http://opensource.samsung.com/
opensource/VR5000J/seq/0 leads to the download page
of the source code made available and open source
license information as related to this product. This offer
is valid to anyone in receipt of this information.
Appendices
English 41
VR5000_EN_00734H-00_UK.indd 41
2015-04-22 오후 4:48:46
Note
42 English
VR5000_EN_00734H-00_UK.indd 42
2015-04-22 오후 4:48:46
Note
English 43
VR5000_EN_00734H-00_UK.indd 43
2015-04-22 오후 4:48:46
If you have any questions or comments relating to Samsung products,
please contact the SAMSUNG customer care center.
Country
Customer Care Center
Web Site
U.K
0330 SAMSUNG (7267864)
www.samsung.com
SOUTH AFRICA
0860 7267864 (SAMSUNG)
www.samsung.com
AUSTRALIA
1300 362 603
www.samsung.com
HONG KONG
(852) 3698-4698
www.samsung.com/hk
www.samsung.com/hk_en/
MALAYSIA
1800-88-9999
www.samsung.com
SINGAPORE
1800-SAMSUNG (7267864)
www.samsung.com/ch_fr/(French)
DJ68-00734H-00
DJ68-00734H
VR5000_EN_00734H-00_UK.indd 44
2015-04-22 오후 4:48:47
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
