ProMedia
Fast Ethernet, Gigabit and
PoE Media Converters
Key Highlights
ProMedia Ethernet Media Conversion
10/100, 100 and 1000Mbps for
Multimode or Singlemode Fiber
Easy, economical upgrade to fiber
 Protects your networking electronics
investment
 Use with existing switches
 Auto-negotiation
selects best mode
of operation between devices
Choose between:




Single port
Fast Ethernet and Gigabit
Unmanaged and managed
Multimode or singlemode
PoE powered device features:


Link fault pass through
Dip switch settings
PoE power source features:







Link fault pass through
Internal power supply
Over-current protection
Under-current detection
Fault protection input
MDI power enable/disable
Dip switch settings
Managed models include:








Access via web, Telnet and SNMP
STP
RMON
SMTP support
DHCP support
Enterprise MIB
Alarm message support
Auto shutdown
 Warranty: 5 years, 1 year on power
supplies
WATERS NETWORK SYSTEMS
ww w. w a t e r s n e t . c o m Corporate Headquarters
7401 Metro Blvd., Suite 560
Edina, MN 55439
Toll Free: 800.862.3894
Phone: 952.831.5604
Fax: 952.831.5605
Manufacturing
945 37th Avenue, NW
Rochester, MN 55901
Toll Free: 800.328.2275
Phone: 507.285.1951
Fax: 507.285.1952
ProMedia 100Base
Media Converters
Waters Network Systems’ Media Converters enable the use of both fiber and
copper anywhere on your network. Waters offers a variety of models to choose from that
will provide an economical solution for extending distances in your network and also for
integrating new equipment in your existing network.
All ProMedia Converters transparently support both half and full duplex auto-sensing
operations. They are interoperable with any other standards-compliant Fast Ethernet and
Gigabit products.
Single-Port Media Converters are noted for their small, rugged metal cases, ease-
of-use features and energy-efficiency. These compact units can be mounted securely
on a wiring closet wall, office cabinet or desk with Velcro® or by using the metal clips
provided.
PoE Models provide power sourcing equipment (PSE) which combines data received
over a fiber link with 48VDC power, providing power to a IEEE802.3af powered device
over a copper cable. The converter includes a powered device (PD) signature and sensing and power monitoring features.
ProMedia-100 Models
 Unmanaged Fast Ethernet single port
 Multimode or singlemode ST or SC connectors (5 and 20 km)
ProMedia-100 PoE Models
 Unmanaged Fast Ethernet single port
 Multimode (ST or SC connectors)
 Link Fault Pass Through (LFP)
 Dip switch to set configurations
ProMedia-1000 Models
 Unmanaged Gigabit single port
 Multi or singlemode LC connector (10 km)
ProMedia-2000 Models
 Managed Gigabit single port
 Multi or singlemode LC connector (10 km)
WATERS NETWORK SYSTEMSTM
www.watersnet.com 1-800-441-5319
ProMedia Ethernet Media Converters
ORDERING INFORMATION
Model
Description
Dimensions
Weight
Unmanaged Single-Port
ProMedia-100SC-3
ProMedia-100ST-3
ProMedia-100SC-SM5
ProMedia-100ST-SM20
1-port
1-port
1-port
1-port
ProMedia-1000SX
ProMedia-1000LX-SM20
1-port 1000Base-TX (RJ45) to 1000Base-SX MM (SC)
1-port 1000Base-TX (RJ45) to 1000Base-LX SM (20km SC)
3.7 x 2.77 x 1.03 in (94 x 70.3 x 26.2mm)
3.7 x 2.77 x 1.03 in (94 x 70.3 x 26.2mm)
9.4 oz
9.4 oz
ProMedia-2000SX
ProMedia-2000LX-SM10
1-port 10/1000Base-TX (RJ45) to 1000Base-SX MM (SC)
5.55 x 3.78 x 1.73 in (141 x 96 x 44 mm)
1-port 10/1000Base-TX (RJ45) to 1000Base-LX SM (10km SC) 5.55 x 3.78 x 1.73 in (141 x 96 x 44 mm)
9.4 oz
9.4 oz
ProMedia-100POE-PDSC
ProMedia-100POE-PDST
ProMedia-100POE-PSESC
ProMedia-100POE-PSEST
1-port
1-port
1-port
1-port
9.4
9.4
9.4
9.4
Unmanaged Single-Port
Managed Single-Port
Unmanaged Single-Port
10/100Base-TX
10/100Base-TX
10/100Base-TX
10/100Base-TX
10/100Base-TX
10/100Base-TX
10/100Base-TX
10/100Base-TX
SPECIFICATIONS
NETWORK STANDARDS:
ProMedia 100s
IEEE 802.3
IEEE 802.3u
ProMedia 1000s
IEEE 802.3z
IEEE 802.3ab
ProMedia 2000s
IEEE 802.3
IEEE 802.3u
IEEE 802.3ab
IEEE 802.3z
IEEE 802.3x
IEEE 802.1d/w
IEEE 802.1s
ProMedia POEPD
IEEE 802.3u
IEEE 802.af
ProMedia POEPSE
IEEE 802.3u
PROMEDIA MANAGEMENT FUNCTIONS:
Access via web and Telnet
SNMP
STP
RMON
SMTP
DHCP
Enterprise MIB
Alarm message
Auto shutdown
(RJ45)
(RJ45)
(RJ45)
(RJ45)
(RJ45)
(RJ45)
(RJ45)
(RJ45)
to
to
to
to
to
to
to
to
100Base-FX
100Base-FX
100Base-FX
100Base-FX
MM (SC)
MM (ST)
SM (5km SC)
SM (20km ST)
100Base-FXPD MM (SC) 100Base-FX PD MM (ST)
100Base-FX PSE MM (SC)
100Base-FX PSE MM (ST)
3.7
3.7
3.7
3.7
x
x
x
x
2.77
2.77
2.77
2.77
x
x
x
x
1.03
1.03
1.03
1.03
in
in
in
in
(94
(94
(94
(94
x
x
x
x
70.3
70.3
70.3
70.3
x
x
x
x
26.2mm)
26.2mm)
26.2mm)
26.2mm)
3.7 x 2.77 x 1.03 in (94 x 70.3 x 26.2mm)
3.7 x 2.77 x 1.03 in (94 x 70.3 x 26.2mm)
5.24 x 6.22 x 1.57 in (133 x 158 x 40 mm)
5.24 x 6.22 x 1.57 in (133 x 158 x 40 mm)
LED INDICATORS:
ProMedia 100s
Power
FX TX Link, TX Tx, Link FDX
ProMedia 1000s
Power
FX Link, FX FDX, TP Link, TP ACT
ProMedia 2000s
Power-on
Loop back, FX: LNK/ACT; UTP, LNK1000,
ACT, FDX/COL
ProMedia PoE Models
Power-on
PoE, TP Link/ACT, 100, FX Link/ACT, FDX/
COL
RECOMMENDED CABLES: MM fiber:
50/125, 62.5/125 or 100/140
SM fiber:
8.3/125, 8.7/125, 9/125 or 10/125
UTP:
100 OHM Category 5, transmits up to 100m (328 feet)
oz
oz
oz
oz
oz
oz
oz
oz
NETWORK CABLE CONNECTORS:
RJ45 shielded female ports:
100Mbps: Category 5 UTP/STP
10Mbps: Category 3, 4, 5 UTP
Fiber MM port connectors:
SC/ST
Fiber SM port connectors:
SC/ST
POWER REQUIREMENT:
ProMedia 100s
[email protected]
ProMedia 1000s
[email protected]
ProMedia 2000s
[email protected]+5VDC
ProMedia PoE Models
100POEPD: [email protected] from PSE or
PoE injector
100POEPSE: 100~240 VAC, 50~60Hz
 Power Consumption: 24W
Note: SM (20, 40, 50, 60, 80, and 100km) is
available upon request.
OPERATING ENVIRONMENT:
Ambient:
32° to 122°F (0° to 50°C)
Ambient relative humidity:
5% to 90% (non-condensing)
EMI/SAFETY COMPLIANCE:
FCC Part 15, Class A, CE Mark & UL
WARRANTY:
5 years (1 year on power supplies)
Waters Network Systems reserves the right to change product specifications and/or model offerings without notice.
Copyright© 2011 Waters Network Systems. All rights reserved. 0211_ProMedia
9.4
9.4
9.4
9.4
