Samsung ML-1450 User's manual

Samsung ML-1450 User's manual
This manual is provided for information purposes only. All information included herein is
subject to change without notice. Samsung Electronics is not responsible for any damages,
direct or indirect, arising from or related to use of this manual.
© 2001 Samsung Electronics Co., Ltd. All rights reserved.
•
•
•
•
•
ML-1450, ML-1451N and Samsung logo are trademarks of Samsung Electronics Co., Ltd.
Centronics is a trademark of Centronics Data Computer Corporation.
PCL and PCL 6 are trademarks of Hewlett-Packard Company.
IBM and IBM PC are trademarks of International Business Machines Corporation.
Apple, AppleTalk, TrueType, Laser Writer and Macintosh are trademarks of Apple Computer,
Inc.
• Microsoft, Windows, Windows 9x, Windows Me, Windows 2000, Windows NT, Windows XP
and MS-DOS are registered trademarks of Microsoft Corporation.
• PostScript 3 is a trademark of Adobe Systems Inc.
• All other brand or product names are trademarks of their respective companies or
organizations.
1
Contents
1 Introduction
Special Features –––––––––––––––––––––––––––––––––––––––––––– 1.1
Printer Components ––––––––––––––––––––––––––––––––––––––––– 1.4
2 Setting Up Your Printer
STEP 1:
STEP 2:
STEP 3:
STEP 4:
STEP 5:
STEP 6:
STEP 7:
Unpack Your Printer –––––––––––––––––––––––––––––––––– 2.1
Install the Toner Cartridge ––––––––––––––––––––––––––– 2.3
Load Paper –––––––––––––––––––––––––––––––––––––––––– 2.5
Connect to the Computer with a Parallel Cable ––––––– 2.8
Turn on the Printer ––––––––––––––––––––––––––––––––––– 2.9
Print a Demo Page! –––––––––––––––––––––––––––––––––– 2.9
Install the Printer Software ––––––––––––––––––––––––– 2.10
Installing USB Driver ––––––––––––––––––––––––––––––– 2.17
3 Using the Control Panel
Control Panel Buttons ––––––––––––––––––––––––––––––––––––––– 3.1
Control Panel Lights ––––––––––––––––––––––––––––––––––––––––– 3.3
4 Print Media
Choosing Paper and Other Media –––––––––––––––––––––––––––– 4.1
Selecting the Output Tray ––––––––––––––––––––––––––––––––––– 4.4
Loading Paper ––––––––––––––––––––––––––––––––––––––––––––––– 4.6
Printing on Envelopes –––––––––––––––––––––––––––––––––––––– 4.12
Printing on Labels –––––––––––––––––––––––––––––––––––––––––– 4.14
Printing on Transparencies –––––––––––––––––––––––––––––––––– 4.15
Printing on Preprinted Paper –––––––––––––––––––––––––––––––– 4.16
Printing on Card Stock or Custom-sized Media –––––––––––––– 4.17
2
5 Printing Tasks
Printing a Document ––––––––––––––––––––––––––––––––––––––– 5.1
Using Toner Save Mode –––––––––––––––––––––––––––––––––––– 5.6
Printing on Both Sides of the Paper (Manual Duplexing) –––––––––– 5.7
Printing Multiple Pages on One Sheet of Paper (N-Up Printing) – 5.10
Scaling Your Document ––––––––––––––––––––––––––––––––––– 5.11
Fitting Your Document To a Selected Paper Size –––––––––– 5.12
Printing Booklets ––––––––––––––––––––––––––––––––––––––––– 5.13
Printing Posters –––––––––––––––––––––––––––––––––––––––––– 5.16
Setting Graphic Properties ––––––––––––––––––––––––––––––– 5.18
Printing Watermarks ––––––––––––––––––––––––––––––––––––– 5.21
Using Page Overlay –––––––––––––––––––––––––––––––––––––– 5.24
Printing on Different Paper for the First Page ––––––––––––– 5.28
Reprinting the Last Page ––––––––––––––––––––––––––––––––– 5.29
6 Maintaining Your Printer
Maintaining Toner Cartridge ––––––––––––––––––––––––––––––– 6.1
Cleaning the Printer ––––––––––––––––––––––––––––––––––––––– 6.4
7 Problem Solving
Troubleshooting Checklist –––––––––––––––––––––––––––––––––– 7.1
Solving General Printing Problems ––––––––––––––––––––––––– 7.2
Printing Special Pages ––––––––––––––––––––––––––––––––––––– 7.6
Clearing Paper Jams ––––––––––––––––––––––––––––––––––––––– 7.7
Solving Print Quality Problems –––––––––––––––––––––––––––– 7.16
Troubleshooting Error Messages ––––––––––––––––––––––––––– 7.22
Common Windows Problems –––––––––––––––––––––––––––––– 7.25
Common Macintosh Problems ––––––––––––––––––––––––––––– 7.26
Troubleshooting PS Errors –––––––––––––––––––––––––––––––– 7.28
3
Contents
(continued)
A Specifications
Printer Specifications –––––––––––––––––––––––––––––––– A.1
Paper Specifications ––––––––––––––––––––––––––––––––– A.2
B Using Your Printer with a Macintosh
Macintosh Installation ––––––––––––––––––––––––––––––– B.1
Using QPDL Driver ––––––––––––––––––––––––––––––––––– B.5
Using PS Driver –––––––––––––––––––––––––––––––––––– B.11
C Printing from DOS Applications
About Remote Control Panel for DOS –––––––––––––––– C.1
Installing the Remote Control Panel
for DOS Users ––––––––––––––––––––––––––––––––––––––– C.2
Selecting Print Settings –––––––––––––––––––––––––––––– C.5
D Using Windows PostScript Driver
Setting Your Printer with the PS Option –––––––––––––– D.1
Installing PPD Files –––––––––––––––––––––––––––––––––– D.1
Accessing the PS Printer Driver Features ––––––––––––– D.9
4
E Using Your Printer on a Network
About Sharing the Printer on a Network –––––––––––––– E.1
Setting Up a Locally Shared Printer –––––––––––––––––– E.2
Setting Up a Network-Connected Printer ––––––––––––– E.5
F Printer Options
Precautions –––––––––––––––––––––––––––––––––––––––––– F.1
Memory and PostScript SIMMs ––––––––––––––––––––––– F.2
Network Interface Card –––––––––––––––––––––––––––––– F.5
Paper Tray 2 ––––––––––––––––––––––––––––––––––––––––– F.7
G Using Your Printer in Linux
Linux Driver Installation ––––––––––––––––––––––––––––– G.1
INDEX
5
Environmental and Safety Consideration
Laser Safety Statement
The printer is certified in the U.S. to conform to the requirements of DHHS 21 CFR, chapter 1
Subchapter J for Class I(1) laser products, and elsewhere, is certified as a Class I laser
product conforming to the requirements of IEC 825.
Class I laser products are not considered to be hazardous. The laser system and printer are
designed so there is never any human access to laser radiation above a Class I level during
normal operation, user maintenance, or prescribed service condition.
WARNING
Never operate or service the printer with the protective cover removed from Laser/Scanner assembly.
The reflected beam, although invisible, can damage your eyes.
CAUTION
VORSICHT
ATTENTION
ATTENZIONE
- INVISIBLE LASER RADIATION WHEN THIS COVER OPEN. DO
NOT OPEN THIS COVER.
- UNSICHTBARE LASERSTRAHLUNG, WENN ABDECKUNG
GEÖFFNET. NICHT DEM STRAHL AUSSETZEN.
- RAYONNEMENT LASER INVISIBLE EN CAS D’OUVERTURE.EXPOSITION DAN
GEREUSE AU FAISCEAU.
-RADIAZIONE LASER INVISIBILE IN CASO DI APERTURA.
EVITARE L’ESPOSIZIONE AL FASCIO.
PRECAUCION -RADIACION LASER IVISIBLE CUANDO SE ABRE. EVITAR EXPONERSE AL
RAYO.
ADVARSEL.
- USYNLIG LASERSTRÅLNING VED ÅBNING NÅR SIKKERHEDSBRYDERE ER
UDE AF FUNKTION. UNDGÅ UDSAETTELSE FOR STRÅLNING.
ADVARSEL.
- USYNLIG LASERSTRÅLNING NÅR DEKSEL ÅPNES. STIRR IKKE INN I
STRÅLEN. UNNGÅ EKSPONERING FOR STRÅLEN.
VARNING
- OSYNLIG LASERSTRÅLNING NÄR DENNA DEL ÄR ÖPPAND OCH SPÄRREN ÄR
URKOPPLAD. BETRAKTA EJ STRÅLEN. STRÅLEN ÄR FARLIG.
VARO!
6
- AVATTAESSA JA SUOJALUKITUS OHITETTAESSA OLET ALTTIINA
NÄKYMÄTTÖMÄLLE LASERSÄTEILYLLE ÄLÄ KATSO SÄTEESEEN.
Environmental and Safety Consideration
Ozone Safety
OZONE
During normal operation, the ML-1450 Series printer produces
ozone. The ozone produced does not present a hazard to the
operator. However, it is advisable that the machine be operated in
a well ventilated area.
If you need additional information about ozone, please contact
your nearest Samsung dealer.
Power Saver
This printer contains advanced energy conservation technology
that reduces power consumption when it is not in active use.
When the printer does not receive data for an extended period of
time, power consumption is automatically lowered.
The energy star emblem does not represent EPA endorsement of
any product or service.
7
Environmental and Safety Consideration
Radio Frequency Emissions
FCC regulations
This device has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
(1) Reorient or relocate the receiving antenna.
(2) Increase the separation between the equipment and receiver.
(3) Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
(4) Consult the dealer or an experienced radio/TV technician for help.
CAUTION: Changes or modifications not expressly approved by the manufacturer responsible for
compliance could void the user’s authority to operate the equipment.
Canadian Radio Interference Regulations
This digital apparatus does not exceed the Class B limits for radio noise emissions from digital
apparatus as set out in the interference-causing equipment standard entitled “Digital
Apparatus”, ICES-003 of the Industry and Science Canada.
Cet appareil numérique respecte les limites de bruits radioélectriques applicables aux appareils
numériques de Classe B prescrites dans la norme sur le matériel brouilleur: “Appareils
Numériques”, ICES-003 édictée par l’Industrie et Sciences Canada.
8
Environmental and Safety Consideration
Declaration of Conformity (European Countries)
Approvals and Certifications
The CE marking applied to this product symbolises Samsung Electronics Co., Ltd. Declaration of
Conformity with the following applicable 93/68/EEC Directives of the European Union as of the dates
indicated:
January 1, 1995: Council Directive 73/23/EEC Approximation of the laws of the member states
related to low voltage equipment.
January 1, 1996: Council Directive 89/336/EEC (92/31/EEC), approximation of the laws of the
Member States related to electromagnetic compatibility.
March 9, 1999: Council Directive 1999/5/EC on radio equipment and telecommunications terminal
equipment and the mutual recognition of their conformity.
A full declaration, defining the relevant Directives and referenced standards can be obtained from
your Samsung Electronics Co., Ltd. representative.
EC Certification
Certification to 1999/5/EC Radio Equipment & Telecommunications Terminal
Equipment Directive (FAX)
This Samsung product has been self-certified by Samsung for pan-European single terminal
connection to the analogue public switched telephone network (PSTN) in accordance with Directive
1999/5/EC. The product has been designed to work with the national PSTNs and compatible PBXs of
the European countries:
In the event of problems, you should contact the Euro QA Lab of Samsung Electronics Co., Ltd. in
the first instance.
The product has been tested against TBR21 and/or TBR 38. To assist in the use and application of
terminal equipment which complies with this standard, the European Telecommunication Standards
Institute (ETSI) has issued an advisory document (EG 201 121) which contains notes and additional
requirements to ensure network compatibility of TBR21 terminals. The product has been designed
against, and is fully compliant with, all of the relevant advisory notes contained in this document.
9
Environmental and Safety Consideration
10
Environmental and Safety Consideration
Memo
11
1
CHAPTER
Introduction
Congratulations on the purchase of your ML-1450 series
printer! This chapter provides information on the following
topics:
◆ Special Features
◆ Printer Components
Special Features
Your new Samsung ML-1450 series printer is equipped with
special features that improve print quality, giving you a
competitive edge. You can:
Print with excellent quality and high speed
• Prints at 1200 dots per inch (dpi). See page 5.18.
• Prints 14 pages-per-minute(A4 size), 15 pages-perminute(Letter size).
Flexible paper handling
• A 100-sheet Multi-Purpose Tray supports letterheads,
envelopes, labels, transparencies, custom-sized media,
postcards, and heavy paper.
• Standard 550-sheet input tray (Tray 1) and optional 550sheet input tray (Tray 2) supports all standard sizes of
paper.
• Two output tray: Select either the top face-down output or
the rear face-up output tray for the most convenient
access.
• Straight-through paper path capability from the
Multi-Purpose Tray to the rear output tray.
Create professional documents
• Customizes your documents by using Watermarks such as
“Confidential.”
8
9
• Prints Booklets. This feature enables you to easily print the
pages required to create books. Once printed, all you have to
do is fold and staple the pages.
• Prints Posters. The text and pictures of each page of your
document are magnified and printed across the selected
sheet of paper. After the document has printed, trim off the
white edges of each sheet. Tape the sheets together to form
a poster.
INTRODUCTION 1.1
Special Features
Save time and money
• Allows you to use the Toner Save mode to save toner. See
page 5.6.
• Allows you to print on both sides of the paper to save paper
(Manual Duplexing). See page 5.7.
• Allows you to print multiple pages on one single sheet of
paper to save paper (N-Up printing). See page 5.10.
• Preprinted forms and letterheads can be printed on plain
paper. See ‘Using Page Overlay’ on page 5.24.
• One-touch last page printing is available when the printer
is in ready mode.
• This printer automatically conserves electricity by
substantially reducing power consumption when not printing.
• This printer meets Energy Star guidelines for energy
efficiency.
Expand the printer capacity
• The ML-1450 printer has 4 MB of memory (16 MB on ML-1451N)
which can be expanded to 68 MB (80 MB on ML-1451N).
• PostScript 3 Emulation* (PS) SIMM adds PS printing.
• Optional network interface enables network printing.
(ML-1451N comes with a built-in network interface.)
*PostScript 3 Emulation
IPS-PRINT_Printer language Emulation© Copyright 1995-2002,
Oak Technology, Inc., All rights reserved
1.2 INTRODUCTION
Special Features
Print in various environments
• Prints in Windows, DOS, and Macintosh.
• Supports Linux.
• ML-1450 series printer comes with Parallel and USB. You
can install an optional network interface (ML-1451N have a
built-in network interface).
Printer Features
Table below lists a general overview of features supported by
the ML-1450 series printer.
Network Card
PostScript SIMM
ML-1450
N
N
ML-1451N
Y
N
INTRODUCTION 1.3
Printer Components
Front View
Control panel
Top output tray
Control board cover
(needed to access the
control board to install
printer options)
(Face down output )
Multi-Purpose Tray
Top cover
(Inside)
Toner cartridge
Tray 1
(550-sheet paper feeder)
Tray 2
(Optional 550-sheet paper feeder)
1.4 INTRODUCTION
Paper level
indicators
Printer Components
Rear View
Rear output tray door
Network port
(ML-1450: Option
ML-1451N: Standard)
(Face up output)
USB port
Power switch
Parallel port
Power receptacle
INTRODUCTION 1.5
2
CHAPTER
Setting Up
Your Printer
This chapter provides step by step information on setting
up your printer. Topics included in this chapter are:
◆ step 1: Unpack Your Printer
◆ step 2: Install the Toner Cartridge
◆ step 3: Load Paper
◆ step 4: Connect to the Computer with a Parallel Cable
◆ step 5: Turn on the Printer
◆ step 6: Print a Demo Page!
◆ step 7: Install the Printer Software
Installing USB Driver
Unpack Your Printer
1
Remove the printer and all accessories
from the packing carton. Make sure that
your printer has been packed with the
following items:
Toner cartridge
Power cord
CD-ROM
Quick Guide
Notes:
• If any items are missing or damaged, notify
your dealer immediately.
• Components may differ from one country
to another.
• The CD-ROM contains the printer driver, the
User’s Guide, the Adobe Acrobat Reader
program.
2
Carefully remove all packing tapes from
the printer.
SETTING UP YOUR PRINTER 2.1
Unpack Your Printer
Selecting a Location
Select a level, stable place with adequate space for air circulation. Allow extra space for
opening covers and trays. The area should be well-ventilated and away from direct
sunlight or sources of heat, cold, and humidity. See the image below for clearance space.
Do not set the printer close to the edge of your desk or table!
Clearance Space
100 mm
(3.9 in.)
(3.9 in.)
482.6 mm(19 in.)
100 mm
561 mm(22 in.)
2.2 SETTING UP YOUR PRINTER
1211.6 mm(47.7 in.)
320 mm(12.6 in.)
Front: 482.6 mm(enough space so that
trays can be removed)
Back: 320 mm(enough space to allow
opening of the Back Cover)
Right: 100 mm
Left: 100 mm(enough space for
ventilation)
Install the Toner Cartridge
1
Open the top cover lid. Pull up on the
handle to open the lid.
Handle
2
Carefully tear one end of the plastic bag.
Don’t use a knife or other sharp objects
as they might scratch the drum of the
cartridge.
3
Locate the sealing tape at the end of the
toner cartridge. Carefully pull the tape
completely out of the cartridge. Discard
the tape.
4
Gently shake the cartridge from side to
side to distribute the toner evenly inside
the cartridge.
CAUTION:
To prevent damage, do not expose the toner
cartridge to light for more than a few minutes.
Cover it with a piece of paper if left exposed
for more than a few minutes.
If toner gets on your clothing, wipe it off with
a dry cloth and wash clothing in cold water.
Hot water sets toner into fabric.
SETTING UP YOUR PRINTER 2.3
Install the Toner Cartridge
5
Locate the cartridge slots inside the
printer, one on each side.
6
Grasp the handle and insert the
cartridge in the printer until it drops into
place.
7
Close the top cover. Make sure that the
cover is securely closed.
Note: When printing text at 5% coverage, you can expect a toner cartridge life of approximately
6,000 pages (3,000 pages for the toner cartridge that is shipped with the printer).
2.4 SETTING UP YOUR PRINTER
Load Paper
1
Pull the paper tray out of the printer.
2
Push down on the metal paper lift plate to
lock it in place.
3
Load paper with the print side facing
down.
Make sure that all four corners are flat
in the tray.
SETTING UP YOUR PRINTER 2.5
Load Paper
4
Make sure that the stack goes under the
metal retaining clip A and the plastic
tabs on the end guides.
Pay attention to the paper limit mark on
the left inside wall of the tray.
Paper overloading may cause paper
jams.
Note: If you want to change the paper size
in the tray, refer to: “To Change Paper Size
in Tray”
5
Slide the tray back into the printer.
To Change Paper Size in Tray
1
Squeeze the metal tab on the rear
paper guide to adjust for the paper
length.
2.6 SETTING UP YOUR PRINTER
A
Load Paper
2
Adjust the paper length guide so the
pointer matches the desired paper size.
LGL
FOLIO
Pointer
A4
LTR
EXEC
JIS B5
3
After loading paper, squeeze the side
guide as shown and slide it to the left
flush against the paper.
4
If necessary, use the rear width guide.
Squeeze the rear width guide as shown
and slide it to the left.
Notes:
• Do not push the width guide far enough to cause the media to warp.
• If you do not adjust the width guide, it may cause a paper jam.
SETTING UP YOUR PRINTER 2.7
Connect to the Computer
with a Parallel Cable
1
Make sure that both the printer and
the computer are turned off.
2
Plug the parallel printer cable into the
connector on the back of the printer.
Push the metal clips down to fit inside
the notches on the cable plug.
3
Connect the other end of the cable to
the parallel interface port on your
computer, and tighten the screws.
See your computer documentation if
you need help.
➞ To the parallel
port on PC
Note: To connect the printer to the parallel port of the computer requires a certified parallel cable.
You will need to buy the IEEE1284 compliant cable.
If you are using a USB interface
Go to page 2.17, “Installing USB Driver.”
Note: USB cable shorter than 3m is recommended.
If you are using a network interface
Go to page F.5, “Network Interface Card.”
Notes:
• ML-1451N comes with a built-in network interface.
• Shielded cables must be used with this equipment
to maintain compliance with the EMC Directive (89/336/EEC).
2.8 SETTING UP YOUR PRINTER
Turn on the Printer
1
Plug the power cord into the power
receptacle on the back of the printer.
2
Plug the other end into a properly
grounded AC outlet.
3
Turn on the power.
➞ To AC outlet
Print a Demo Page!
As the printer powers up, all the printer
control panel lights turn on briefly. When
only the Data light remains on, press and
hold the Demo button.
Hold the Demo button down until all the
lights blink (for about 2 seconds) and
then release. The demo page will print.
The demo page provides a sample of the
print quality to help you verify that the
printer is printing correctly.
ML-1450 Series
Laser Beam Printer
Excellent Performance, High quality
Robust Network connectivity
SETTING UP YOUR PRINTER 2.9
Install the Printer Software
Included with your printer is a CD-ROM containing the printer
drivers for some of the most popular Windows software
applications. To operate your printer, you must install a printer
driver, which translates data from your application into data
that the printer understands.
The CD-ROM shipped with your printer contains the following:
• SPL printer driver for Windows. Use this driver to take full
advantage of your printer’s features.
• PostScript Printer Description (PPD) file for Windows and
Macintosh to allow installation of the PostScript driver.
If you are printing from a computer with a parallel cable
Go to page 2.12 for information on installing the printing
software on a computer that is attached directly to the printer
with a parallel cable.
If you are printing with a USB
Go to page 2.17, “Installing USB Driver”, for information on
installing the print software on a USB-enabled computer.
If you are printing from a Macintosh
Go to Appendix B, “Using Your Printer with Macintosh”, for
information on installing the PostScript option for Macintosh.
If you are printing from DOS
Go to Appendix C, “Printing from DOS Applications”, for
information on installing the DOS print software and printing
from DOS application.
2.10 SETTING UP YOUR PRINTER
Install the Printer Software
If you are printing with PostScript driver
Go to Appendix D, “Using Windows PostScript Driver”, for
information on installing the PPD file.
If you are using Linux
Go to Appendix G, “Using Your Printer in Linux”, for information
on installing the Linux driver.
Before Installing the Printer Software
Verify the following:
• At least 32 MB or more of RAM is installed on your PC.
• There is at least 200 MB of free disk space on your PC.
• All applications are closed on your PC before beginning
installation.
• Windows 95, Windows 98, Windows Me, Windows NT 4.0,
Windows 2000 or Windows XP.
SETTING UP YOUR PRINTER 2.11
Install the Printer Software
ng ML-1450 Ser
msu
ies
Sa
Installing the Printer Software from the CD-ROM
1 Place the CD-ROM in the CD-ROM drive. Installation will start
automatically.
If the CD-ROM drive does not automatically run:
Select Run from the Start menu, and type x:\cdsetup.exe
in the Open box (where x is the drive letter for the CD-ROM
drive), then click OK.
Note: If the New Hardware
Found box appears during the
installation procedure, click
the x in the upper right
corner of the box, or click
Cancel.
2 When the opening screen appears, select the appropriate
language.
2.12 SETTING UP YOUR PRINTER
Install the Printer Software
3 Click Install the Samsung Software on your PC.
4 The Welcome window opens. Click Next.
SETTING UP YOUR PRINTER 2.13
Install the Printer Software
5 The files are copied into the appropriate directory.
6 Click Finish.
2.14 SETTING UP YOUR PRINTER
Install the Printer Software
Printer Driver Features
ML-1450 series printer drivers will support the following
standard features:
• Input tray selection
• paper size, orientation and media type
• number of copies
Table below lists a general overview of features supported by
the ML-1450 series printer drivers.
SPL
Driver
Features
PostScript
Win2000/XP Win9x NT4.0 Macintosh Win2000/XP Win9x NT4.0 Macintosh
Toner save
Y
Y
Y
N
Y
Y
Y
N
Print quality option
Y
Y
Y
Y
Y
Y
Y
Y
Halftoning
Y
Y
Y
N
N
Y
Y
N
Manual duplex
Y
Y
Y
N
N
N
N
N
Booklet printing
Y
Y
Y
N
N
N
N
N
Poster printing
Y
Y
Y
N
N
N
N
N
Multiple pages per sheet (N-up)
Y
Y
Y
Y
Y
Y
N
Y
Fit to page printing
Y
Y
Y
Y
N
N
N
N
Different source for first page
Y
Y
Y
N
N
N
N
N
Watermark
Y
Y
Y
Y
N
N
N
N
Overlay
Y
Y
Y
N
N
N
N
N
TrueType fonts option
N
N
N
N
Y
Y
Y
Y
Error reporting
N
N
N
N
Y
Y
Y
Y
SETTING UP YOUR PRINTER 2.15
Install the Printer Software
Software Installation Tips
How do I remove the
printing software ?
In Windows, after installation, the Uninstall icon in the
ML-1450 series program group allows you to select and remove
any or all of the Windows ML-1450 printing system
components.
1. From the Start menu, select Programs.
2. Select Samsung ML-1450 Series, and then
Samsung ML-1450 Series driver Maintenance.
3. The Samsung ML-1450 Series Maintenance dialog box
appears. Check Remove and then click Next.
4. When you are asked to confirm your selection, click OK.
5. The Samsung ML-1450 Series printer driver and all of its
components are removed from your computer.
6. Click Finish.
If you have installing
problems
• Exit your software programs. Then turn off the computer and
the printer. Turn on the printer, then turn on the computer.
• Close any virus protection programs that are running on your
computer.
• If you fail the installation, you will have to reinstall.
1. From the Start menu, select Programs.
2. Select Samsung ML-1450 Series, and then
Samsung ML-1450 Series driver Maintenance.
3. The Samsung ML-1450 Series Maintenance dialog box
appears. Check Repair and then click Next.
4. When you finish reinstallation, click Finish.
How do I access
printer features ?
Some printer features, such as paper size and page
orientation, may be available through your application settings.
Use application settings, if available, because they override
printer driver settings.
Access advanced printer features through your printer driver.
See Chapter 5, “Printing Tasks” for instructions on using your
printer driver features.
2.16 SETTING UP YOUR PRINTER
Installing USB Driver
If you have a USB (Universal Serial Bus) port enabled on your computer, and if
your computer is running Windows 98/Me/2000/XP, you can connect your
ML-1450 series printer to the USB chain of devices.
Note: Connecting the printer to the USB port of the computer requires a certified
USB cable. You will need to buy the USB 1.0 or 1.1 compliant cable.
Installing USB driver in Windows 98/Me
1. Connect printer with
USB cable and
install USB driver
1 Make sure that both the printer and computer are turned ON.
2 Plug one end of the USB cable into the USB port on the printer.
➝ To PC
3 Plug the other end into the USB port on the computer.
4 The Add New Hardware Wizard dialog box appears. Click
Next.
SETTING UP YOUR PRINTER 2.17
Installing USB Driver
5 Check Search for the best driver for your device and click
Next.
6 Check CD-ROM drive and click Browse, then choose x:\USB
(where x is the drive letter for the CD-ROM drive). Click Next.
7 Click Next. The USB driver will be installed.
2.18 SETTING UP YOUR PRINTER
Installing USB Driver
8 Click Finish.
9 When the opening screen appears, select the appropriate
language.
Note: If you already installed
the printer driver, the
International Setup Version
screen doesn’t appear.
SETTING UP YOUR PRINTER 2.19
Installing USB Driver
10 Click Install the Samsung Software on your PC.
11 Follow the instructions on the screen to complete the
installation. For more details, see page 2.12.
2.20 SETTING UP YOUR PRINTER
Installing USB Driver
2. Check your PC
printer port
1 From the Start menu, select Settings, then select Printers.
2 Select the Samsung ML-1450 Series printer icon in the
Printers folder.
3 Select Properties from the File menu.
4 Click the Details tab. Check SSUSB: (ML-1450) in the
Print to the following port box. Click OK.
Notes:
• If you want to use your printer with the Parallel cable, remove the USB
cable and connect the Parallel cable. Then reinstall the printer driver.
• If your printer doesn’t work properly, reinstall the printer driver.
SETTING UP YOUR PRINTER 2.21
Installing USB Driver
Installing USB driver in Windows 2000/XP
1. Connect printer 1
with USB cable
Make sure that both the printer and computer are turned ON.
2 Plug one end of the USB cable into the USB port on the printer.
➝ To PC
3 Plug the other end into the USB port on the computer.
2.22 SETTING UP YOUR PRINTER
Installing USB Driver
ng ML-1450 Ser
msu
1 Place the CD-ROM in the CD-ROM drive. Installation will
start automatically.
If the CD-ROM drive does not automatically run:
ies
Sa
2. Install USB driver
Select Run from the Start menu, and type
x:\cdsetup.exe in the Open box (where x is the drive
letter for the CD-ROM drive), then click OK.
Note: If the New Hardware
Found box appears during the
installation procedure, click
the x in the upper right
corner of the box, or click
Cancel.
2 When the opening screen appears, select the appropriate
language.
SETTING UP YOUR PRINTER 2.23
Installing USB Driver
3 Click Install the Samsung Software on your PC.
4 Follow the instructions on the screen to complete the
installation. For more details, see page 2.12.
2.24 SETTING UP YOUR PRINTER
Installing USB Driver
3. Check your PC 1
printer port
From the Start menu, select Settings, then Printers.
(Windows 2000)
From the Start menu, select Printers and Faxes.
(Windows XP)
2 Select the Samsung ML-1450 Series printer icon in the
Printers folder.
3 Select Properties from the File menu.
4 Click the Port tab. Check the port and the printer.
Click OK.
• Samsung ML-1450 Series is connected to the USB Port.
• The printer prints using the USB cable.
Note: If your printer stop the
connecting with USB cable,
the printer driver icon is
faded.
Notes:
• If you want to use your printer with the Parallel cable, remove the USB
cable and connect the Parallel cable. Then reinstall the printer driver.
• If your printer doesn’t work properly, reinstall the printer driver.
SETTING UP YOUR PRINTER 2.25
Installing USB Driver
Frequently Asked Questions About USB
Q
What is USB?
A
Universal Serial Bus (USB) makes it easy to connect devices to
your computer without having to open your PC. USB uses a
standard port and plug combination for connecting devices like
printers, modems, scanners, and digital cameras. It also offers
the benefit of being able to easily add, remove, and move
devices.
Because USB is a relatively new technology, we recommended
using a parallel printing connection. However, USB is an option
to customers who want to print from Windows 98/Me/2000/XP,
Macintosh using a USB cable. If your computer’s USB port is
enabled and properly setup, you can connect your printer to it
or to a chain of USB devices via a USB cable.
Q
How can I determine if my computer’s USB port is enabled?
A
1 In Windows 98/Me, select Start ➝ Settings ➝ Control Panel.
2 Double-click the System icon.
3 Click the Device Manager tab.
4 Click the plus (+) icon before the Universal Serial Bus
Controller item.
If you see a USB host controller and a USB root hub listed, USB is
properly enabled. If you have multiple hubs on the USB chain, try
connecting your printer to a different hub or to another USB
device. Also, make sure the cable connections are firm. (USB hubs
are hardware devices into which you can plug multiple USB
cables.)
If you do not see these devices listed, refer to your computer’s
documentation or contact the manufacturer for more information
on enabling and setting up USB. Remember, you can always use a
parallel cable to connect your printer’s parallel port to your
computer. (If you decide to switch to a parallel cable connection,
you may need to remove and reinstall the printer software. )
2.26 SETTING UP YOUR PRINTER
Installing USB Driver
Q
Can other users on my USB chain print to my ML-1450 printer?
A
Yes. Windows 98/Me/2000/XP allows you to “share” your
printer using software settings on your computer. After others
on the USB chain have installed the printer software for your
specific printer, they can print to your shared printer.
Q
After I install my printer, why isn’t my ML-1450 printer assigned to
an LPT printer port in the Print dialog box of my software
application?
A
USB uses a different naming convention for USB devices. After
the printer has been installed, you see SSUSB:(your printer
name) instead of LPT.
Q
How can I increase printing speed and quality?
A
When operated on a USB chain, your printer may become
slower if other USB devices are being used while you’re
printing. For optimal print performance, avoid using other
devices in the USB chain while printing.
SETTING UP YOUR PRINTER 2.27
3
CHAPTER
Using the
Control Panel
This chapter describes how to use the printer’s control
panel. It provides information on the following topics:
◆ Control Panel Buttons
◆ Control Panel Lights
Control Panel Buttons
The printer has three buttons: Cancel/Reprint, Demo and Toner Save.
Cancel job
Press Cancel/Reprint and hold until the control panel
lights blink to cancel a job the printer is currently
printing. The Error light will blink while the print job is
cleared from both the printer and the computer, and the
printer will then return to the ready mode. This may
take some time, depending on the size of the print job.
Note: If the Cancel/Reprint button is accidentally pushed, the
job must be reprinted. There is no undo function.
Reprint last page of the job
If you press Cancel/Reprint in the ready mode, the
printer prints the last page of the last print job. For
further information, see page 5.29.
USING THE CONTROL PANEL 3.1
Control Panel Buttons
Print demo page and configuration sheet
Press and hold Demo for about 2 seconds until the
control panel lights blink slowly to print a demo page.
The printer must be in the ready mode.
Press and hold Demo for about 6 seconds until the
control panel lights blink rapidly to print a configuration
sheet. The printer must be in the ready mode. For
further information, see page 7.6.
Start manual feeding
When you select Manual Feed for Paper Source from
your software application, you should press Demo each
time you feed a sheet of paper manually. For further
information, see page 4.10.
Cleaning the inside of the printer
Press and hold Demo for about 10 seconds until the
control panel lights remain illuminated to automatically
clean the inside of the printer. After cleaning the printer,
one cleaning sheet prints. For further information,
see page 7.6.
Toner Save
(on)
(off)
3.2 USING THE CONTROL PANEL
Press Toner Save to turn the toner save mode on or off.
The printer must be in the ready mode.
• If the button backlight is on, toner save mode
activates and the printer uses less toner to print a
document.
• If the button backlight is off, toner save mode is
disabled and you will print in normal quality. For
further information on Toner Save mode, see page 5.6.
Control Panel Lights
The control panel lights indicate the status of your printer. If the Error light is
on, the printer is experiencing an error. See “Troubleshooting Error Messages”
on page 7.22.
Light status legend
symbol for “light off”
symbol for “light on”
symbol for “light blinking”
Control Panel Light Message
Ready Mode
The Data light is on and the printer is ready to print.
No action is needed. If you press and hold the Demo
button for about 2 seconds, a demo page will print. If
you press and hold the button for about 6 seconds, a
configuration sheet will print.
USING THE CONTROL PANEL 3.3
Control Panel Lights
Processing
The printer is receiving or processing data. Wait for the
job to print.
Pressing the Cancel/Reprint button cancels the current
job. One or two pages may print as the printer clears
the print job. The printer will return to the ready mode
after the job has been canceled.
Data
The Data light blinks rapidly. Data is in the printer
memory waiting to be printed.
Pressing the Cancel/Reprint button cancels the current
job and the printer returns to the ready mode.
Paper out
The printer is out of paper. The Paper light blinks until
paper is added.
Load paper into the printer. There is no need to press
any button to reset.
Manual feed mode
The printer is set to Manual Feed mode. You have to
feed paper manually through the Multi-Purpose Tray. If
you do not want to be in the Manual Feed mode, change
the setting from your printer properties. For details on
the Manual Feed mode, see page 4.10.
3.4 USING THE CONTROL PANEL
Control Panel Lights
Paper out in the manual feed mode
In the Manual Feed mode, the printer picks up paper
from the Multi-Purpose Tray, one sheet at a time.
Feed the correct paper in the Multi-Purpose Tray, and
press the Demo button to start printing.
Printing in the manual feed mode
The printer is processing data in the Manual Feed mode.
Wait for the job to print.
USING THE CONTROL PANEL 3.5
4 Print Media
CHAPTER
This chapter will help you understand what kind of paper
you can use with the ML-1450 series printer and how to
properly load paper in the different paper trays for the
best print quality.
Topics included in this chapter are:
◆ Choosing Paper and Other Media
◆ Selecting the Output Tray
◆ Loading Paper
◆ Printing on Envelopes
◆ Printing on Labels
◆ Printing on Transparencies
◆ Printing on Preprinted Paper
◆ Printing on Card Stock or Custom-sized Media
Choosing Paper and Other Media
You can print on a variety of print media, such as plain paper,
envelopes, labels, transparencies, card stocks and so on. See
“Paper Specifications” on page A.2. To get the best possible
print quality, use only high-quality copier-grade paper.
When you choose print media, consider the following:
• Desired outcome: The paper you choose should be
appropriate for the project.
• Size: You can use any size paper that fits easily within the
paper adjusters of the paper tray.
• Weight : Your printer supports paper weight as follows:
• 16~28 lbs bond for Tray 1 or optional Tray 2
• 16~43 lbs bond for Multi-Purpose Tray
• Brightness: Some papers are whiter than others and
produce sharper, more vibrant images.
• Surface smoothness: The smoothness of the paper affects
how crisp the printing looks on the paper.
• Opacity: Opacity refers to the degree to which printing on
one side of the paper shows through the other side. Use
paper high in opacity (or thicker paper) for two-sided
(duplex) printing.
Always test a sample of paper before purchasing large
quantities.
CAUTION: Using media that does not confirm to the specification
listed in the paper specification can cause problems that may
require service. This service is not covered by the warranty or
service agreements.
PRINT MEDIA 4.1
Choosing Paper and Other Media
Media Sizes and Capacities
Media Size
Input Source/Capacity*1
Tray 1 or Optional Tray 2
Multi-Purpose Tray
Manual Feed
550
550
550
550
550
550
–
100
100
100
100
100
100
100
1
1
1
1
1
1
1
10
10
10
10
10
1
1
1
1
1
Plain Paper
Letter (8.5 x 11 in.)
Legal (8.5 x 14 in.)
Executive (7.25 x 10.5 in.)
Folio (8.5 x 13 in.)
A4 (210 x 297 mm)
B5 (182 x 257 mm)
A5 (148 x 210 mm)
Envelopes
No. 10 (4.12 x 9.5 in.)
Monarch (3.87 x 7.5 in.)
C5 (162 x 229 mm)
DL (110 x 220 mm)
B5 (176 x 250 mm)
40
40
40
40
40
(Tray
(Tray
(Tray
(Tray
(Tray
2
2
2
2
2
only)
only)
only)
only)
only)
Labels*2
Letter (8.5 x 11 in.)
A4 (210 x 297 mm)
–
–
25
25
1
1
Transparency films*2
Letter (8.5 x 11 in.)
A4 (210 x 297 mm)
–
–
20
20
1
1
Card stocks*2
–
10
1
Bond*2
1
*1 Depending on paper thickness, maximum capacity may be reduced.
*2 If you are experiencing excessive jamming, feed one sheet at a time
through the Multi-Purpose Tray.
4.2 PRINT MEDIA
Choosing Paper and Other Media
Paper Guidelines
When selecting or loading paper, envelopes, or other special
media, keep these guidelines in mind:
• Attempting to print on damp, curled, wrinkled, or torn paper
can cause paper jams and poor print quality.
• Use cut-sheet paper only. You cannot use multi-part paper.
• Use only high-quality, copier grade paper.
• Do not use paper that has been already printed on or that
has been fed through a photocopier.
• Do not use paper with irregularities, such as tabs or
staples.
• Do not attempt to load any tray during printing and never
overfill the tray. This could cause a paper jam.
• Avoid paper with embossed lettering, perforations, or
texture that is too smooth or too rough.
• Colored paper should be of the same high quality as white
photocopy paper. The pigments must withstand the printer’s
fusing temperature of 400°F (205°C) for 0.1 second without
deterioration. Do not use paper with a colored coating that
was added after the paper was produced.
• Preprinted forms must be printed with nonflammable, heatresistant ink that will not melt, vaporize, or release
hazardous emissions when subjected to the printer’s
approximately 400°F (205°C) fusing temperature for 0.1
second.
• Store paper in its ream wrapper until it is ready to use.
Place cartons on pallets or shelves, not on the floor.
• Do not place heavy objects on top of the paper, whether it
is packaged or unpackaged.
• Keep paper away from moisture, direct sunlight or other
conditions that can cause it to wrinkle or curl.
PRINT MEDIA 4.3
Selecting the Output Tray
The printer has two output locations: the rear output tray and the top output tray.
To use the top output tray, be sure the rear output tray is closed. To use the rear output tray,
open it.
• If paper coming out of the top output tray has problems, such as excessive curl, try
printing to the rear output tray.
• To avoid paper jams, do not open or close the rear output tray while the printer is
printing.
Printing to the Top Output Tray (Face down)
The top output tray collects paper face-down, in
correct order. The top output tray should be used
for most print jobs and is recommended for printing
the following:
• over 250 sheets of paper, continuously
œ Top output tray
Printing to the Rear Output Tray (Face up)
un
ma sr
Sinte
Pr
œ Rear output tray
4.4 PRINT MEDIA
L
ML-1A6SER PR
INTER
50
g
The printer always prints to the rear output tray if it
is open. Paper comes out of the printer face-up,
with the last page on top.
Printing from the Multi-Purpose Tray to the rear
output tray provides the straight paper path.
Opening the rear output tray might improve output
quality with the following:
•
•
•
•
•
•
over 100 sheets of paper, continuously
envelopes
labels
small custom-size paper
postcards
paper lighter than 16 lb (60 g/m2) or
heavier than 28 lb (105 g/m2)
• transparencies:
Note: Some special transparencies may have stacking
problem by curl. In that case, please use the face down tray.
Selecting the Output Tray
To open the rear output tray:
1
Open the rear door by pulling it down.
The cover functions as the output tray.
2
Pull the extender to extend the output
tray to its full-length position.
This will allow the tray to hold longer
paper.
3
If you do not want to stack the printed
pages on the rear output tray, slide the
extender back into place and close the
tray. The pages will then stack on the
top output tray.
Note: The capacity of the rear output tray is
the same as that of the Multi-Purpose Tray. If
the tray is overloaded with printed pages, it
may fall from the printer. Remove the pages
so that the tray is not overloaded.
PRINT MEDIA 4.5
Loading Paper
Proper paper loading helps to prevent paper jams and ensure
trouble-free printing. Do not remove paper tray(s) while a job
is printing. Doing so may cause a paper jam.
The paper level indicator on the front of the paper tray(s)
shows the amount of paper currently left in the tray. When the
tray is empty, the indicator turns red.
Paper full œ
œ Paper empty
Using Tray 1 or the Optional Tray 2
Tray 1 holds 550 sheets of paper. See “Media Sizes and
Capacities” on page 4.2 for acceptable paper size and
capacities of each trays.
Load a stack of paper into the Tray 1 or optional Tray 2 and
print. For details on loading paper in the Tray 1 or optional
Tray 2, see “Load Paper” on page 2.5.
Tray 1
Optional Tray 2
4.6 PRINT MEDIA
Loading Paper
Using the Multi-Purpose Tray
The Multi-Purpose Tray is located in the front of your printer.
It can be closed when you are not using it, making the printer
more compact. The Multi-Purpose Tray can hold several sizes
and types of paper, such as transparencies, cards, and
envelopes. You may also want to use the Multi-Purpose Tray
for single page print jobs on letterheads, colored paper for use
as separator sheets, or other special paper that you do not
normally keep in the paper tray.
You can load approximately 100 sheets of paper, 10 envelopes,
20 transparencies, 10 card stocks or 25 labels at a time.
When you print from the Multi-Purpose Tray, you must select
Multi-Purpose Tray for Paper Source from your software
application, and then select the paper size and type from the
software application for the paper you have loaded.
See page 5.3.
• Load only one size of print media at a time in the MultiPurpose Tray.
• To prevent paper jams, do not add paper when there is still
paper in the Multi-Purpose Tray. This also applies to other
types of print materials.
• Print media should be loaded face up with the top of the
print media going into the Multi-Purpose Tray first and be
placed against the left edge of the tray.
• Do not place objects on the Multi-Purpose Tray. Also avoid
pressing down or applying excessive force on it.
œ Multi-Purpose Tray
PRINT MEDIA 4.7
Loading Paper
To load paper in the Multi-Purpose Tray:
1
Pull the Multi-Purpose Tray down towards
you.
2
Slide the extender to extend the tray to
its full-length position to hold longer
paper.
3
Prepare a stack of paper for loading by
flexing or fanning them back and forth.
Straighten the edges on a level surface.
4.8 PRINT MEDIA
Loading Paper
4
Place paper with the print side face
up, and against the left edge of the
tray.
Note: Make sure that you have not
loaded too much print media. The stack
should be under the stack height limit
mark. The print media buckles if you load
a stack that is too deep, or push it in too
far.
Stack height limit mark
5
Slide the paper width guide to the left
flush against the stack of print material
without bending.
6
After printing, push the extender back
to its place and close the Multi-Purpose
Tray.
PRINT MEDIA 4.9
Loading Paper
Using the Manual Feed
When you change the print settings, if you select Manual Feed in the Paper Source option,
you can manually load paper in the Multi-Purpose Tray. Manually loading paper can be helpful
when you want to check the print quality after each page is printed.
This loading procedure is almost the same as the procedure for loading in the Multi-Purpose
Tray except you load paper sheet-by-sheet in the Multi-Purpose Tray, send print data to print
the first page, and press the Demo button to print each following page.
1
Load the paper in the Multi-Purpose Tray
with the print side up.
2
Slide the paper width guide to the left
flush against the stack of print media
without bending.
4.10 PRINT MEDIA
Loading Paper
3
When you print a document, you must
select Manual Feed for Paper Source
from the software application, and then
select the correct paper size and type.
For details, see page 5.3.
4
Print the document.
5
The Manual light on the control panel
blinks. Press the Demo button on the
control panel.
The sheet of paper is loaded and
printed.
6
After one page is printed, the Manual
light on the control panel blinks again.
Feed the next sheet into the MultiPurpose Tray and press Demo.
Repeat this step for every page to be
printed.
PRINT MEDIA 4.11
Printing on Envelopes
Guidelines
• Only use envelopes recommended for laser printers. Before you load envelopes in the
Multi-Purpose Tray, make sure that they are undamaged and are not stuck together.
• Do not load more than 10 envelopes into the Multi-Purpose Tray.
• Do not feed stamped envelopes.
• Never use envelopes with clasps, snaps, windows, coated lining, or self-stick adhesives.
These envelopes may severely damage the printer.
1
Open the Multi-Purpose Tray and slide
the extender to its full-length position.
2
Open the rear output tray and pull the
extender.
4.12 PRINT MEDIA
Printing on Envelopes
3
Flex or fan the envelopes to supply air
through them for loading.
4
Load the envelopes with the flap side
down, and against the left edge of the tray.
The stamp area is on the left side and the
end of the envelope with the stamp area
enters the Multi-Purpose Tray first.
5
Adjust the guide to the left edge of the
envelope stack.
6
When you print on envelopes, configure
the paper source, type and size properly
in the software application. For details,
see page 5.3.
7
After printing, close the Multi-Purpose
Tray and the rear output tray.
PRINT MEDIA 4.13
Printing on Labels
Guidelines
• Only use labels recommended for laser printers.
• Do not load more than 25 labels into the Multi-Purpose Tray at a time.
• Verify that the labels’ adhesive material can tolerate fusing temperature of 200°C
(392°F) for 0.1 second.
• Make sure that there is no exposed adhesive material between the labels. Exposed areas
can cause labels to peel off during printing, which can cause paper jams. Exposed
adhesive can also cause damage to printer components.
• Do not feed a sheet of labels through the printer more than once. The adhesive backing
is designed for one pass through the printer.
• Do not use labels that are wrinkled, bubbled, separated from the backing sheet, or
damaged in any way.
1
Open the Multi-Purpose Tray and the
rear output tray.
2
Load labels with print side up, and
against the left edge of the tray. Adjust
the guide to fit the width of the labels.
3
When you print on labels, configure the
paper source, type and size in the
software application. For details, see
page 5.3.
Note: To prevent them from sticking
together, remove label sheet from the
output tray as they are printed out.
4.14 PRINT MEDIA
Printing on Transparencies
Guidelines
• Only use transparencies recommended for use in laser printers.
• Do not load more than 20 transparencies into the Multi-Purpose Tray at a time.
• Make sure that the transparencies are not wrinkled or curled, and that they do not have
any torn edge.
• Hold the transparencies by the edges and avoid touching the print side. Oils from your
fingers that are deposited on the transparency can cause print quality problems.
• Be careful not to scratch or leave fingerprints on the print side.
1
Open the Multi-Purpose Tray and pull
the extender out of its full-length
position.
2
Load transparencies with print side
up, and the top with the adhesive
strip entering the printer first.
Adjust the guide to fit the width of the
transparencies.
3
When you print on transparencies,
configure the paper source, type and
size in the software application. For
details, see page 5.3.
Notes:
• To prevent transparencies from sticking
together, remove them from the output
tray as they are printed.
• Place transparencies on a flat surface
after removing them from the printer.
PRINT MEDIA 4.15
Printing on Preprinted Paper
Preprinted paper is paper that has some type of printing placed on it before it is sent through
the printer (paper that has a preprinted logo at the top of the page, for example).
Guidelines
• Letterheads must be printed with heat-resistant ink that will not melt, vaporize, or
release hazardous emissions when subjected to the printer’s fusing temperature of 400°F
(205°C) for 0.1 second.
• Ink on letterheads must be non-flammable and should not adversely affect any printer
rollers.
• Forms and letterheads should be sealed in a moisture-proof wrapping to prevent changes
during storage.
• Before you load preprinted paper as forms and letterheads, verify that the ink on the
paper is dry. During the fusing process, wet ink can come off preprinted paper.
1
Load letterheads into the tray you want
to use as shown in the figures. Adjust
the guide to fit the width of the paper
stack.
XXXX
XXXX
Load with the
design face down,
bottom edge
toward the printer.
2
When you print a document on the
paper, configure the paper source, type
and size in the software application. For
details, see page 5.3.
Load with the design face up,
top edge toward the printer.
4.16 PRINT MEDIA
XX
Printing on Card Stock or Custom-sized Media
Postcards, 3.5 by 5.83 in.(index) cards and other custom-sized media can be printed with the
ML-1450 series printer. The minimum size is 90 by 148 mm (3.5 by 5.83 in.) and the
maximum size is 216 by 356 mm (8.5 by 14 in.).
Guidelines
• Always insert the short-edge into the Multi-Purpose Tray first. If you want to print in
landscape mode, make this selection through your software. Inserting paper long-edge
first may cause a paper jam.
• Do not load more than 10 cards into the Multi-Purpose Tray at a time.
• Do not print on media smaller than 90 mm (3.5 in.) wide or 148 mm(5.83 in.) long.
• Set margins at least 6.4 mm (0.25 in.) away from the edges of the media in the software
application.
1
Open the Multi-Purpose Tray and the
rear output tray and pull the extender
out to its full-length position.
2
Load print media with print side up,
short edge first and against the left
edge of the tray.
Adjust the guide to fit the width of the
media.
3
Configure the paper source, type and
size in the printer driver’s properties
(see page 5.3) and print.
Note: If the size of your print media is
not listed in the Paper Size box in the
Paper tab of the printer driver
properties, select Custom Paper and
set the paper size manually.
PRINT MEDIA 4.17
5 Printing Tasks
CHAPTER
This chapter explains your printing options and covers
common printing tasks.
Topics included in this chapter are:
◆ Printing a Document
◆ Using Toner Save Mode
◆ Printing on Both Sides of the Paper (Manual Duplexing)
◆ Printing Multiple Pages on One Sheet of Paper (N-Up
Printing)
◆ Scaling Your Document
◆ Fitting Your Document To a Selected Paper Size
◆ Printing Booklets
◆ Printing Posters
◆ Setting Graphic Properties
◆ Printing Watermarks
◆ Using Page Overlay
◆ Printing on Different Paper for the First Page
◆ Reprinting the Last Page
Printing a Document
The following procedure describes the general steps required
for printing from various Windows applications. The exact
steps for printing a document may vary depending on the
application program you are using. Refer to your software
application’s documentation for the exact printing procedure.
1 Open the document you want to print.
2 Select Print from the File menu. The Print dialog box for
your application will be displayed (the Print dialog box for
your application may look slightly different).
The basic print settings you will need are usually selected
within this Print dialog box. These settings include the
number of copies, paper size, and page orientation.
If you see
a Properties button, click it.
If you see Setup, Printer, or
Options, click that button instead;
then click Properties
in the next screen.
Make sure your
printer is selected
here.
PRINTING TASKS 5.1
Printing a Document
3 To take full advantage of the printer features provided by
your ML-1450 series printer, click Properties in the
application’s Print dialog box and go to step 4.
If you see Setup, Printer, or Options, click that button
instead. Then click Properties in the next screen.
4 Now you see the Samsung ML-1450 series printer’s
Properties dialog box. The Properties dialog box allows you
to access all the information you will need when using your
printer.
If necessary, click the Paper tab to display the settings
shown below. The Paper tab contains the options for
setting the basic paper handling.
5.2 PRINTING TASKS
Printing a Document
Make sure the Paper Source is set to Tray1. If you use
paper in the Multi-Purpose Tray or optional Tray2, select the
corresponding paper source.
Manual Feed source is used when printing to special
media. You have to feed one sheet at a time into the printer.
See page 4.10.
If the paper source is set to Auto Select, the printer
automatically selects the print media according to the
following order: Multi-Purpose Tray, Tray1, Tray2 (option).
Make sure the Paper Type is set to Use Printer Default.
If you load a different type of print media, select the
corresponding paper type. For further information on print
media, refer to chapter 4 ‘Print Media’.
Also, select the paper size you have loaded in your printer.
The Paper Orientation option allows you to select the
direction in which information is printed on a page. Portrait
prints across the width of the page, letter style. Landscape
prints across the length of the page, spreadsheet style.
œ
œ
Landscape
Portrait
You can also see the printable area.
PRINTING TASKS 5.3
Printing a Document
5 Click other tabs on the top of the Properties dialog box to
access other features, if needed.
6 When you complete the print settings, click OK until the
Print dialog box is displayed.
7 Click OK to start printing.
Notes:
• Most Windows applications will override settings you specify in the
printer driver. Change all print settings available in the software
application first, and change any remaining settings using the printer
driver.
• The settings you change remain in effect only while you are using the
current program. To make your changes permanent, make them in
the Printers folder. Follows this procedure:
1. Click the Windows Start button.
2. Select Settings, then Printers to open the Printers window.
3. Select the Samsung ML-1450 Series.
4. Click the right mouse button and select Properties to open the
properties window.
5.4 PRINTING TASKS
Printing a Document
Canceling a Print Job
There are two ways to stop a print job.
To stop a print job from the ML-1450 series printer
Press the Cancel/Reprint button on the control panel.
The printer will finish printing the page that is moving through
the printer and delete the rest of the print job. Pressing
Cancel/Reprint cancels only the current job in the printer. If
more than one print job is in printer memory, Cancel/Reprint
must be pressed once for each job.
To stop a print job from the Printers folder
1. From the Start menu, select Settings.
2. Select Printers to open the Printers window, then doubleclick the Samsung ML-1450 Series.
3. From the Document menu, select Cancel Printing
(Windows 9x/Me) or Cancel (Windows 2000/XP/NT 4.0).
Printing Help
The Samsung ML-1450 series printer has a help screen that can
be activated by the Help button in the printer Properties dialog
box. These help screens give detailed information about the
printer features provided by the ML-1450 series printer driver.
From the upper right hand corner, click ? then click on a
setting for more information.
If you want to restore the default printer properties settings
when you change the print settings, click Defaults in the
Properties dialog box.
PRINTING TASKS 5.5
Using Toner Save Mode
Toner Save mode allows the printer to use less toner on each
page. Selecting this option will extend the life of your toner
cartridge and reduce your cost per page, but will reduce print
quality. This setting is not available with 1200 dpi settings.
There are two ways to enable the Toner Save mode.
To enable this feature from the ML-1450 series
printer
Press the Toner Save button on the control panel. The printer
must be in the ready mode (Data light is on).
• If the button backlight is on, toner save mode activates and
the printer uses less toner to print a page.
• If the button backlight is off, toner save mode is disabled
and the printer prints in the normal mode.
To enable this feature from the software application
1. When you change the print settings from your software
application, access the printer properties. See page 5.2 to
access the printer properties.
2. Click the Graphic tab, and select the Toner Save Mode
option. You can select from:
• Printer Setting: If you select this option, this feature is
determined by the setting you’ve made on the control
panel of the printer.
• Standard: If you don’t need to save toner to print a
document, select this option.
• Save: Select this option to allow the printer to use less
toner on each page.
3. Click OK.
5.6 PRINTING TASKS
Printing on Both Sides of the Paper (Manual Duplexing)
To print on both sides of the paper (manual duplexing), you
must run the paper through the printer twice. You can print
using the top output tray (face down tray) or the rear output
tray (face up tray). Samsung recommends using the top
output tray for light-weight paper. Use the rear output tray for
any heavy media or media that tends to curl when printed,
such as envelopes and card stock.
Note: To print on both sides of the paper, you must use the
Multi-Purpose Tray for the paper input source. Load paper in the
Multi-Purpose Tray.
1 When you change the print settings from your software
application, access the printer properties. See page 5.2 to
access the printer properties.
From the Paper tab, select the paper orientation, source,
size and type.
2 Click the Output tab, then choose Flip on Long Edge or
Flip on Short Edge from the Type drop-down list in the
Manual Duplex Printing section.
Note: If you can not see Flip
on Long Edge in the Type
drop-down list, set the Type
box in the Output Mode
section to Multiple Pages per
Side, Scaling Printing or Fit to
Page.
PRINTING TASKS 5.7
Printing on Both Sides of the Paper (Manual Duplexing)
Choosing Flip on Long Edge lets you place the binding
orientation along the long edge of the paper, as in a
magazine.
Choosing Flip on Short Edge lets you place the binding
orientation along the short edge of the paper, as in a
calendar.
2
3
2
3
5
5
œ
œ
Flip on Long Edge in the
Portrait orientation
Flip on Long Edge in the
Landscape orientation
2
➛ Flip on Short
Edge in the
Portrait
orientation
3
3
5
2
œ
Flip on Short Edge in the
Landscape orientation
5
3 Select Face Down Tray (top output tray) or Face Up Tray
(rear output tray) in which the printed media is to be
stacked. According to this option, the printer will determine
the print page order when the second sides are printed.
If you select Face Up Tray, open the face up tray.
4 If you want to print the instruction page which tells you
how to load the paper, click Print Instruction sheet. If
the box is checked, the printer prints the instruction page
before the duplexing job is printed. If the box is empty, this
feature is disabled.
5 Start printing. The printer automatically prints only the oddnumbered pages.
5.8 PRINTING TASKS
Printing on Both Sides of the Paper (Manual Duplexing)
6 After the first side has been printed, remove the remaining
paper from the Multi-Purpose Tray and set it aside until
after you finish your manual duplexing job.
7 Gather up the printed pages, flip the stack, and then
straighten the stack before placing it back in the MultiPurpose Tray.
Note: If you have selected the Face Up Tray option in Step 3,
the last page is placed on the top of the stack. Do not
rearrange the pages before reloading them to print the second
side. Your printer knows the stacked page order and will print
the corresponding second side for each page.
Remove the printed
pages, and reload them
into the Multi-Purpose
Tray with the printed
side face down.
The following illustrations show you how to put the printed
pages back into the printer.
(left edge toward
the printer)
Flip on Long Edge in the
Landscape orientation
(right edge toward
the printer)
Flip on Short Edge in the
Landscape orientation
Note: Manual duplexing can
cause the printer to become
dirty more quickly and can
therefore reduce print quality.
See “Cleaning the Printer” on
page 6.4 if the printer
becomes dirty.
(top edge toward
the printer)
Flip on Long Edge in the
Portrait orientation
(bottom edge
toward the printer)
Flip on Short Edge in the
Portrait orientation
8 You are prompted to reinsert the paper into the MultiPurpose Tray. Click OK on the screen to start printing the
second side. The printer automatically prints only the evennumbered pages.
PRINTING TASKS 5.9
Printing Multiple Pages on
One Sheet of Paper
1
2
3
4
(N-Up Printing)
You can select the number of pages that you want to print on
a single sheet of paper. If you choose to print more than one
page per sheet, the pages will appear decreased in size and
arranged on the sheet. You can specify up to 16 pages.
1 When you change the print settings from your software
application, access the printer properties. See page 5.2 to
access the printer properties.
œ 4 pages per sheet
From the Paper tab, select the paper orientation, source,
size and type.
2 Click the Output tab, and choose Multiple Pages per
Side in the Type drop-down list. Then select the number of
pages you want to print per sheet (1, 2, 4, 9 or 16) in the
Pages per Sheet drop-down list.
3 Click Print Page Borders if you want to print a border
around each page on the sheet. Print Page Borders is
enabled only if Pages per Sheet is 2, 4, 9, or 16.
4 Click OK, then start printing.
5.10 PRINTING TASKS
Scaling Your Document
This printer feature allows you to scale your print job on a
page.
1 When you change the print settings from your software
application, access the printer properties. See page 5.2 to
access the printer properties.
2 Click the Output tab, and select Scale Printing in the
Type drop-down list.
3 Enter the desired scaling rate in the Scales input field.
You can also click the œ or ❷ buttons.
4 Click OK, then start printing.
PRINTING TASKS 5.11
Fitting Your Document To a Selected Paper Size
A
This printer feature allows you to scale your print job to any
selected paper size regardless of the digital document size.
This can be useful when you want to check fine details on a
small document.
1 When you change the print settings from your software
application, access the printer properties. See page 5.2 to
access the printer properties.
2 Click the Output tab, and select Fit to Page in the Type
drop-down list.
3 You’ll see the Application paper size and then you will be
prompted to select the Fit to paper Size. Select the
correct size from the drop-down list.
4 Click OK, then start printing.
5.12 PRINTING TASKS
Printing Booklets
9
8
œ
Portrait orientation
The Booklet printing feature allows you to print your document
as a 2-sided (duplex) job and to arrange the pages so that the
paper can be folded in half after printing to produce a booklet.
Note: To print booklet, you must use the Multi-Purpose Tray for
the paper input source. Load paper in the Multi-Purpose Tray.
1 When you change the print settings from your software
1
97
œ
Landscape orientation
application, access the printer properties. See page 5.2 to
access the printer properties.
From the Paper tab, select the paper orientation, source,
size and type.
Note: For booklet printing, only four paper sizes are supported:
Letter, A4, Legal, and Executive.
2 Click the Output tab, then choose Booklet Printing from
the Type drop-down list.
Then select the paper size you are using from the Booklet
drop-down list.
PRINTING TASKS 5.13
Printing Booklets
3 Select Face Down Tray (top output tray) or Face Up Tray
(rear output tray) in which the printed media is stacked.
According to this option, the printer will determine the print
page order when the second sides are printed.
If you select Face Up Tray, open the face up tray.
4 If you want the instruction page which tells you how to load
the paper, click Print Instruction sheet. If the box is
checked, the printer prints the instruction page before the
duplexing job is printed. If the box is empty, this feature is
disabled.
5 Print the document.
6 After side one has been printed, remove the remaining
paper from the Multi-Purpose Tray and set it aside until
your booklet job is complete.
The printer prints side one as shown below for an 8-page
document.
8
1
6
œ 8 page document
5.14 PRINTING TASKS
3
Printing Booklets
7 Gather up the printed pages, flip the stack, and then
straighten the stack before placing it back in the multipurpose tray. The following illustrations show how to put
the paper back into the printer.
Remove the printed pages,
and reload them into the
Multi-Purpose Tray with
printed side face down.
In Portrait orientation,
insert the pages with
left edge
toward the printer.
œ Face Down Tray output
œ Face Up Tray output
Note: If you have selected
the Face Up tray option at
Step 3, the last page is
placed on the top of the
stack. Do not rearrange the
pages before reloading the
pages. Your printer knows
the stacked page order and
will print the corresponding
second side for each page.
In Landscape orientation,
insert the pages with
bottom edge
toward the printer.
œ Face Down Tray output
œ Face Up Tray output
8 You are prompted to reinsert the paper into the MultiPurpose Tray. Click OK on the screen. The printer will finish
printing.
9 Fold and staple the pages.
8
9
PRINTING TASKS 5.15
Printing Posters
This feature allows you to print a single-page document onto
4, 9, 16, 25, or 36 sheets of paper, for the purpose of pasting
the sheets together to form one poster-size document.
1 When you change the print settings from your software
application, access the printer properties. See page 5.2 for
more information on accessing printer properties.
From the Paper tab, select the paper orientation, source,
size and type.
œ
Poster printing
with 2x2 style
5.16 PRINTING TASKS
2 Click the Output tab, and select Poster Printing in the
Type drop-down list.
Printing Poster
3 To determine the scaling factor, select the Style; 2x2, 3x3,
4x4, 5x5 or 6x6.
For example, if you select 2x2, the output will be
automatically stretched to cover 4 physical pages.
➛ 2 x 2
➛ 3 x 3
4 You may specify an overlap in millimeter or inch to make it
easier to reconstruct the resulting poster.
0.3 inches
0.3 inches
œ Overlap=0
œ Overlap=0.3
5 Click OK, then start printing.
PRINTING TASKS 5.17
Setting Graphic Properties
Use the following options to adjust the print quality for your
specific printing needs when you access the printer properties.
See page 5.2 for more information on accessing printer
properties.
If necessary, click the Graphic tab to display the settings shown
below.
Resolution
5.18 PRINTING TASKS
You can select the printing resolution by choosing either
1200 DPI (Class), 600 DPI, 300 DPI. The higher the
setting, the sharper the clarity of printed characters and
graphics. Higher settings may increase the time it takes to
print a document.
Setting Graphic Properties
SRT Mode
Some printed characters or images appear to have jagged or
uneven edges. Set this Samsung Resolution enhancement
Technology (SRT) option to improve the print quality of your
text and image and make the characters and images appear
smoother.
• Text Enhance - This setting refines the print quality of
characters by smoothing out jagged edges
that can occur on the angles and curves of
each character.
• Image Enhance - This setting refines the print quality of
photo images using SRT.
Note: Text Enhance and Image Enhance are disabled when the 600
dpi, 300 dpi setting is selected.
Darkness
Use this option to lighten or darken the image appearance in
your print jobs.
• Normal – This setting is for normal documents.
• Light – This setting is for bolder line widths or darker grayscale images.
• Dark – This setting is for finer line width, higher definition in
graphics, and lighter gray-scale images.
Dark Text
All Text to Black
When the Dark Text is checked, all text in your document is
allowed to print darker than normal document.
When the All Text To Black is checked, all text in your
document is allowed to print solid black, regardless of the color
it appears on the screen.
When it is not checked, colored text is allowed to print in
shades of gray.
PRINTING TASKS 5.19
Setting Graphic Properties
Reprint
You can set the printer not to print the last page of the last job
when the Cancel/Reprint button is pressed. For details, see
‘Reprinting the Last Page’ on page 5.29.
Reprint When Jam
With this option ON, the printer keeps the image for a printed
page until the printer signals that the page has successfully
exited the printer. If a paper jam occurs, the printer will
automatically reprint all jammed pages after the jam is
cleared.
Power Save Mode
To conserve power when a printer is idle, you can set the
printer to enter a reduced power state after completing a print
job, according to a time specified by you in the Power save
Mode box.
Select the desired length of time from the drop-down list.
If your printer is constantly used, select OFF to keep the
printer ready to print with the minimum warm-up time. This
uses more energy to keep the printer warm and ready to print.
5.20 PRINTING TASKS
Printing Watermarks
The Watermark option allows you to print text over an existing
document. For example, you may want to have large gray
letters reading “DRAFT” or “CONFIDENTIAL” printed diagonally
across the first page or all pages of a document.
There are several predefined watermarks that come with the
ML-1450 series printer, and they can be modified or you can
add new ones to the list.
To use an existing
watermark
1 When you change the print settings from your software
application, access the printer properties. See page 5.2 for
more information on accessing printer properties.
2 Click the Watermark tab, and select the desired
watermark in the Message drop-down list. You will see the
selected watermark in the preview window.
preview
window
3 Click OK, then start printing.
PRINTING TASKS 5.21
Printing Watermarks
To create or edit a
watermark
1 When you change the print settings from your software
application, access the printer properties. See page 5.2 for
more information on accessing the printer properties.
2 Click the Watermark tab, and enter the desired text
message in the Text field. This will be displayed in the
preview window. The preview window is provided so that you
can see how the watermark will appear on the printed page.
3 Select the desired watermark options. You can select the
font type and size, color and angle. There are three
checkboxes at the bottom of the dialog box:
• Transparent Text – Allows the document to show
through the watermark.
• As Outline Only – Prints the text outline of the
watermark. This setting globally effects
all watermarks in the list.
• On First Page Only – Prints the watermark only on the
first page.
Use these scroll
bars to adjust
the position.
5.22 PRINTING TASKS
Printing Watermarks
4 If you have created a new or edited an existing watermark,
the Add and Update button is enabled.
To add a new watermark to the list, click Add.
5 If you want to edit, select the desired watermark from the
list, edit, then click Update.
6 When you complete the edit, click OK, then start printing.
To stop printing the watermark, select None in the Message
drop-down list.
To delete a
watermark
1 When you change the print settings from your software
application, access the printer properties. See page 5.2 for
more information on accessing the printer properties.
2 From the Watermark tab, select the watermark you want
to delete in the Messages drop-down list.
3 Click Delete.
4 Click OK.
PRINTING TASKS 5.23
Using Page Overlay
What is an Overlay?
Dear ABC
Regards
An overlay is text and/or images stored in the computer HDD
as a special file format that can be printed on any document
you choose. Overlays are often used to take the place of
preprinted forms and letterhead paper. Rather than using
preprinted letterhead, for example, you can create an overlay
containing the exact same information that is currently on
your letterhead. Then when you want to print a letter with
your company’s letterhead, you do not need to load preprinted
letterhead paper in the printer. You need only to tell the
printer to print the letterhead overlay on your document.
WORLD BEST
Creating a New Page
Overlay
To use a page overlay, you must create a new page overlay
containing your logo or image.
1 Create or open a document containing a text or image you
want to use for page overlay. Position the items exactly as
you wish them to appear when printed as an overlay. If
needed, save the file for later use.
2 Select Print from the File menu. Then click Properties in
WORLD BEST
the application’s Print dialog box to access the printer
properties. For details, see page 5.2.
3 Click the Overlays tab, and click Create Overlay.
5.24 PRINTING TASKS
Using Page Overlay
4 In the Create Overlay dialog box, type a name of up to
eight characters in the File name box. Select the
destination path if necessary. (The default is
C:\FORMOVER).
5 Click Save. You will see the name in the Overlay List box.
6 Click OK or Yes until you complete the creation.
The file is not printed out. Instead it will be stored on your
computer HDD disk.
Note: The overlay document size must be the same as documents
you will print with the overlay. Do not create overlay with the
watermark.
Using Page Overlay
After an overlay has been created, it is ready to be printed
with your document. To print an overlay with a document:
1 Create or open the document you want to print.
2 When you change the print settings from your software
application, access the printer properties. See page 5.2 to
access the printer properties.
3 Click the Overlays tab, and select the desired overlay from
the Overlay List box.
PRINTING TASKS 5.25
Using Page Overlay
4 If the desired overlay file does not appear in the Overlay
List box, click Load Overlay, and select the overlay file.
If you have stored the overlay file you want to use into an
external source, you can also load the file when you access
this Load Overlay window.
After you select the file, click Open. The file is now shown in
the Overlay List box and is available for printing. Select
the overlay from the Overlay List box.
5.26 PRINTING TASKS
Using Page Overlay
5 If necessary, click Query Page Overlay. If this box is
checked, a message box will appear each time you submit a
document for printing, asking you to confirm your wish to
print an overlay on your document.
Answering Yes to the message box means that the selected
overlay will be printed with your document.
Answering No to the message box cancels overlay printing.
If this box is empty, and an overlay has been selected, the
overlay will be automatically printed with your document.
6 Click OK or Yes until the printing starts.
The selected overlay will be downloaded with your print job
and printed on your document.
Note: The overlay document resolution must be save as document
you will print with the overlay.
Deleting a Page
Overlay
You can delete page overlays that are no longer used.
1 In the printer properties dialog box, click the Overlay tab.
2 Select the overlay you want to delete from the Overlay
List box.
3 Click Delete Overlay.
4 Click OK until you exit the Print dialog box.
PRINTING TASKS 5.27
Printing on Different Paper for the First Page
1 When you change the print settings from your software
application, access the printer properties. See page 5.2 to
access the printer properties.
2 Click the Paper tab, and click Different Source for First
Page.
If the box is checked, this feature is enabled and the dialog
box allows you to select the desired paper source for the
First Page and Other Page independently. If the box is
empty, this feature is disabled.
3 Click OK, then start printing.
Note: The paper size for all pages of the print job must be the
same.
5.28 PRINTING TASKS
Reprinting the Last Page
The Samsung ML-1450 printer’s memory always keep the last
page of the last job. If you canceled a print job due to a paper
jam or other problems and you want to know which page was
printed last, reprint the last page.
Press Cancel/Reprint briefly in the ready mode.
Cancel/Reprint
Note: If you want to prevent somebody from reprinting your document, you can turn the
Reprinting feature off in the printer’s properties dialog box. When you turn the feature off in
the printer’s properties, the Cancel/Reprint button on the control panel does not perform the
reprinting operation.
To disable this feature:
1. From the Start menu, select Settings and then
Printers.
2. Click the right mouse button on the Samsung ML-1450
Series printer icon and select Properties to open the
properties window.
3. From the Graphic tab, Select OFF from the Reprint
drop-down list.
With this option Off, you cannot reprint the last page
from the control panel.
When you want to reprint the last page on the control
panel, you must select ON from the list.
4. Click OK.
PRINTING TASKS 5.29
6 Maintaining
CHAPTER
Your Printer
This chapter provides suggestions for high-quality and
economical printing and information for maintaining the toner
cartridge and the printer.
Topics included in this chapter are:
◆ Maintaining Toner Cartridge
◆ Cleaning the Printer
Maintaining Toner Cartridge
Toner cartridge
storage
To get the most from the toner cartridge, keep the following
guidelines in your mind.
• Do not remove the toner cartridge from its package until you
are ready to use it. The shelf life of a cartridge in an unopened
package is approximately 2 years. The shelf life of a cartridge
in an opened package is approximately 6 months.
• Do not refill toner cartridges. The printer warranty does not
cover damage caused by using a refilled cartridge.
• Store toner cartridges in the same environment as the printer.
• Do not remove a toner cartridge from the printer except to
replace it, clean it or clear a paper jam. Replace the cartridge
immediately.
• To prevent damage to the toner cartridge, do not expose it to
light for more than a few minutes.
Toner cartridge life
expectancy
The life of the toner cartridge depends on the amount of toner
that print jobs require. When printing text at 5 % coverage, a
new toner cartridge lasts an average of 6,000 pages. (But, the
toner cartridge supplied with the printer lasts an average of
3,000 pages.)
Recycling toner
cartridge
After you install a new toner cartridge (see page 2.3), follow the
instructions included in the toner cartridge box to recycle the old
cartridge.
Saving toner
To save toner, press the Toner Save button on the printer
control panel. The button will be lit. You can also enable the
Toner Save Mode in your printer properties. Refer to “Using
Toner Save Mode” on page 5.6. Selecting this option will expand
the life of the toner cartridge and reduce your cost per page, but
will reduce print quality.
MAINTAINING YOUR PRINTER 6.1
Toner Cartridge
Redistributing Toner
When toner is low, faded or light areas may appear on a printed page. You may be able to
temporarily improve print quality by redistributing the toner. The following procedures may
allow you to finish the current print job before replacing the toner cartridge.
1
Open the top cover.
2
Remove the toner cartridge from the
printer.
CAUTIONS:
• Avoid reaching too far into the printer.
The fusing area may be hot.
• To prevent damage to the toner
cartridge, do not expose it to light for
more than a few minutes.
3
Gently shake the toner cartridge from
side to side 5 or 6 times to redistribute
the toner.
Note: If the toner gets on your clothing,
wipe it off with a dry cloth and wash
clothing in cold water. Hot water sets
toner into fabric.
6.2 MAINTAINING YOUR PRINTER
Toner Cartridge
4
Reinsert the toner cartridge into the
printer. Be sure that the toner cartridge
is firmly in its place.
5
Firmly close the cover.
If the print remains light
Remove the old cartridge and install a
new toner cartridge. See “Install the
Toner Cartridge” on page 2.3.
MAINTAINING YOUR PRINTER 6.3
Cleaning the Printer
To maintain print quality, follow the cleaning procedures below every time the toner cartridge
is replaced or whenever print quality problems occur. As much as possible, keep the printer
free from dust and debris.
Notes:
• Do not use ammonia-based cleaners or volatile solvents such as thinner, on or around the printer.
These can damage the printer.
• While cleaning the inside of the printer, be careful not to touch the transfer roller (located
underneath the toner cartridge ). The oil from your hands on the roller can cause print quality
problems.
Cleaning the Outside
Wipe the outside surface of the printer with a soft, clean, lintfree cloth. You can dampen the cloth slightly with water, but be
careful not to be let any water drip onto the printer or inside of
it.
Cleaning the Inside
During the printing process, paper, toner, and dust particles
can accumulate inside the printer. Over time, this buildup can
cause print quality problems such as toner specks or smearing.
Cleaning inside the printer will eliminate or reduce these
problems.
Cleaning inside the 1
printer
Turn the printer off and unplug the power cord, then wait for
the printer to cool.
2 Open the top cover and remove the toner cartridge.
Note: To prevent damage to
the toner cartridge, do not
expose it to light for more
than a few minutes. Cover it
with a piece of paper, if
necessary. Also, do not
touch the black transfer
roller inside the printer. By
doing so, you can damage
the printer.
6.4 MAINTAINING YOUR PRINTER
3 With a dry, lint-free cloth, wipe away any dust and spilled toner
from the toner cartridge area and the toner cartridge cavity.
Cleaning the Printer
4 Locate the long strip of glass (LSU) inside the top of the
cartridge compartment, and gently swab the glass to see if dirt
turns the white cotton black.
5 Reinsert the toner cartridge and close the top cover. Then, turn
the printer on.
Printing a cleaning
sheet
Printing a cleaning sheet cleans the drum inside the toner
cartridge. Use this process if you are experiencing blurred,
faded or smeared printouts. This process will produce a page
with toner debris, which should be discarded.
1 Make sure the printer is turned on and in the ready state and
that there is paper loaded in the paper tray.
2 Press and hold Demo on the control panel for about 10 seconds
until all control panel lights remain steadily lit, then release.
3 Your printer automatically picks up a sheet of paper from the
paper tray and prints out a cleaning sheet with the dust or
toner particles on it.
MAINTAINING YOUR PRINTER 6.5
7 Problem Solving
CHAPTER
This chapter gives helpful information for what to do if you
encounter a printer error. It provides information on the
following topics:
◆ Troubleshooting Checklist
◆ Solving General Printing Problems
◆ Printing Special Pages
◆ Clearing Paper Jams
◆ Solving Print Quality Problems
◆ Troubleshooting Error Messages
◆ Common Windows Problems
◆ Common Macintosh Problems
◆ Troubleshooting PS Errors
Troubleshooting Checklist
If the printer is not working properly, complete the following checklist in order. If the printer
does not pass a step, follow the corresponding troubleshooting suggestions.
Check
Solution
Make sure that the Data light on
the control panel is on.
• If no lights are on, check the power cord
connection. Check the power switch. Check the
power source by plugging into another outlet.
• If other lights are on, go to “Troubleshooting Error
Messages” on page 7.22.
Press the Demo button to print
a demo page to verify that the
printer is feeding paper correctly.
See page 7.6.
• If a demo page does not print, check the paper
supply in the paper tray.
• If the paper jams in the printer, go to “ Clearing
Paper Jams” on page 7.7.
• If the Error indicator light is illuminated on the
control panel, go to “Troubleshooting Error
Messages” on page 7.22.
Check the demo page to see if it
is printed correctly.
If there is a print quality problem, go to “Solving
Print Quality Problems” on page 7.16.
Print a short document from a
software application to verify
that the computer and printer
are connected and are
communicating correctly.
• If the page does not print, check the cable
connection between the printer and computer.
• Check the print queue or print spooler (print
monitor in Mac) to see if the printer has been
paused.
• Check the software application to make sure you
are using the proper printer driver and
communication port. If the page is interrupted
during printing, go to “Solving General Printing
Problems” on page 7.2.
If completing the checklist did
not diagnose the problem with
the printer, check the following
troubleshooting sections.
•
•
•
•
•
“Solving General Printing Problems” on page 7.2.
“Troubleshooting Error Messages” on page 7.22.
“Common Windows Problems” on page 7.25.
“Common Macintosh Problems” on page 7.26.
“Troubleshooting PS Errors” on page 7.28.
PROBLEM SOLVING 7.1
Solving General Printing Problems
If you have any problems with the operation of your ML-1450 series printer, refer to the table
for suggested solutions.
Problem
The printer does not
print.
7.2 PROBLEM SOLVING
Possible Cause
Solution
The printer is not
receiving power.
If no lights are on, check the power
cord connections. Check the power
switch and the power source.
Your printer is not
selected as the default
printer.
Select Samsung ML-1450 Series
or Samsung ML-1450 Series PS as
your default printer.
Check the printer for
the following:
•
•
•
•
•
The printer may be in
manual feed mode and
out of paper. (The
Manual and the Data
lights are blinking.)
Add paper to the Multi-Purpose tray,
and press the Demo button on the
printer’s control panel.
The connection cable
between the computer
and the printer is not
connected properly.
Disconnect the printer cable and
reconnect it.
The connection cable
between the computer
and the printer is
defective.
If possible, attach the cable to
another computer that is working
properly and print a job. You may
also try using a different printer
cable.
The port setting is
incorrect.
Check the Windows printer setting to
make sure that the print job is sent
to the correct port (for example,
LPT1). If the computer has more
than one port, make sure the printer
is attached to the correct one.
The printer cover is not closed.
Paper is jammed.
No paper is loaded.
Toner cartridge is not installed.
Printer system error occurs.
Contact a service representative.
Solving General Printing Problems
Problem
Possible Cause
Solution
The printer may be
configured incorrectly.
Check the printer properties to make
sure that all print settings are correct.
The printer driver may
be incorrectly installed.
Uninstall the printer driver, then
reinstall the printer driver. Try printing
a demo page.
The printer is
malfunctioning.
Check the lights on the control panel to
determine if the printer is indicating a
system error.
Printer selects media
from the wrong
paper source.
The paper source
selection in the printer
properties may be
incorrect.
For many software applications the
paper source selection is found under
the Paper tab within the printer
properties. Select the correct paper
source.
Paper does not feed
into the printer.
Paper has not been
loaded correctly.
Remove paper from the paper tray and
reload it correctly.
There is too much paper
in the paper tray.
Remove excess paper from the tray .
The paper is too thick.
Use only paper that meets the
specifications required by the printer.
The job may be very
complex.
Reduce the complexity of the page or
try adjusting the print quality settings.
If this problem occurs frequently, add
memory to the printer.
The printer does not
print. (continued)
Print job is extremely
slow.
The maximum speed of
14 pages per minute
cannot be exceeded even
when more memory is
added.
If using Windows 9x/Me, From the Start menu, choose Settings
the Spooling Setting may and Printers. Right-click the Samsung
be set incorrectly.
ML-1450 series printer icon, choose
Properties, click the Details tab, and
then choose the Spool Settings
button. Select the desired spool setting
from the available choices.
PROBLEM SOLVING 7.3
Solving General Printing Problems
Problem
Possible Cause
Solution
Print job is extremely
slow. (continued)
The computer may have
insufficient randomaccess memory (RAM).
Install more random-access memory
(RAM) in your computer. See “Memory
and PostScript SIMMs” on page F.2.
Half of the page is
blank.
The page layout is too
complex.
Simplify the page layout and remove
any unnecessary graphics from the
document, if possible. Install more
memory. See “Memory and PostScript
SIMMs” on page F.2.
The page orientation
setting may be
incorrect.
Change the page orientation in your
application.
The paper size and the
paper size settings do
not match.
Make sure that the paper size in the
print settings matches the paper in
the paper tray.
There is too much
paper in the paper tray.
Remove excess paper from the tray.
If printing special media, use the
Multi-Purpose Tray.
An incorrect type of
paper is being used.
Use only paper that meets the
specifications required by the printer.
An incorrect output
method is being used.
Media such as thick paper should not
be printed using the standard facedown stacker. Use the rear face-up
output tray instead.
There may be debris
inside the machine.
Open the top cover and remove the
debris.
The paper keeps
jamming.
7.4 PROBLEM SOLVING
Solving General Printing Problems
Problem
The printer prints, but
the text is wrong,
garbled, or incomplete.
Pages print, but are
totally blank.
Possible Cause
Solution
The printer cable is
loose or defective.
Disconnect the printer cable and
reconnect it. Try a print job that you
know works. If possible, attach the
cable and printer to another computer
and try a print job that you know
works. Finally, try a new printer cable.
The wrong printer driver
was selected.
Check the application’s printer
selection menu to make sure that your
printer is selected.
The software application
is malfunctioning.
Try printing a job from another
application.
The operating system is
malfunctioning.
If printing from Windows (any
version), exit to a Dos prompt and
verify functionality with the following
command: At a C:\ prompt, type Dir
LPT1, then press Enter. (This
assumes you are connected to LPT1.)
Exit Windows and reboot the
computer. Turn the printer off and then
back on again.
The toner cartridge is
defective or out of toner.
Replace the toner cartridge.
The sealing tape may
still be in the toner
cartridge.
Remove the toner cartridge and pull
out the sealing tape. Reinstall the
toner cartridge, and check by printing
a demo page.
The file may have blank
pages.
Check the file to make sure that it
does not contain blank pages.
Some parts, such as the
controller or the board
may be defective.
Contact a service representative.
PROBLEM SOLVING 7.5
Printing Special Pages
There are special pages within the memory of the printer that
will help you to diagnose and learn about problems with your
printer.
Use the Demo button on the printer control panel to print
these special pages. The printer must be in the ready mode.
Demo Page
ML-1450 Series
Laser Beam Printer
Printing the demo page will help you check if the printer is
properly working.
Excellent Performance, High quality
Robust Network connectivity
Compatibility
Press and hold Demo for about 2 seconds until the control
panel lights blink slowly.
Configuration Sheet
Samsung ML-1450 Series
The configuration sheet lists many of the current settings and
properties of the printer.
To print the configuration sheet, press and hold Demo for
about 6 seconds until the control panel lights blink rapidly.
Cleaning Sheet
This printing cleans the drum of the toner cartridge. Use this
process if you are experiencing blurred, faded or smeared
printouts.
Press and hold Demo for about 10 seconds until the control
panel lights remain illuminated. Discard the blank page
produced from the cleaning process.
Note: The cartridge cleaning process takes some time. To stop the
printing, turn the power off.
7.6 PROBLEM SOLVING
Clearing Paper Jams
Occasionally, paper can become jammed during a print job. Some of the causes include:
• The paper tray is loaded improperly or overfilled.
• The paper tray has been pulled out during a print job.
• The top cover has been opened during a print job.
• Paper that does not meet paper specifications has been used. See “Paper Specifications” on
page A.2.
• Paper that is outside of the supported size range has been used. See “Paper Specifications”
on page A.2.
If a paper jam occurs, the Paper and the Error lights remain lit on the control panel. Find
and remove the jammed paper. If the location of the paper jam is not obvious, look inside the
printer.
Output Area
Note: Paper jams in this area may result in loose toner on the page. If you get any toner on your
clothes, wash them in cold water because hot water will set the toner into the fabric.
1
If the paper is almost completely visible
from the top output tray, pull the
remaining paper carefully out of the
printer.
PROBLEM SOLVING 7.7
Clearing Paper Jams
2
If the jammed paper is not visible or
there is resistance when you pull the
paper, open the rear output tray.
3
Remove the stopper fastening the rear
output tray, and push the tray down so
that it is open at 90 degrees angle.
2
1
4
If there is resistance when you pull the
paper, squeeze the handle on the right
end of the exit roller 1 , then pull the
roller in the direction of arrow 2 .
Exit roller
2
5
Remove the jammed paper.
7.8 PROBLEM SOLVING
1
Clearing Paper Jams
6
Replace the exit roller.
Make sure that you click the right
end of the roller back in place. If you
fail to do so, the printer system will
recognizes that the printer cover is open
or that a system fuser error has
occurred, and the Error light on the
control panel will turn on.
7
Replace the stopper and close the rear
output tray.
1
2
8
To resume printing, open the top cover,
and then close it close it again.
Note: If the Paper and the Error lights do
not turn off, there is still jammed paper
inside the printer. Check the input area
and the inside of the printer.
PROBLEM SOLVING 7.9
Clearing Paper Jams
Input Area
Note: If paper has entered the toner cartridge area, follow the instructions on page 7.12. It is easier to
remove such jams from the inside of the printer than the paper input area.
1
Slide out Tray 1 to expose the jammed
paper.
2
Remove any misfed paper by pulling it
out by the visible edge from the tray.
Make sure that all of the paper is
properly aligned in the tray.
Note: If the paper is jammed in the
paper feed area and cannot be
accessed from inside the printer, remove
Tray 1 from the printer and carefully pull
the jammed paper free from the printer.
7.10 PROBLEM SOLVING
Clearing Paper Jams
3
Slide the tray back into the printer.
4
To resume printing, open the top cover,
and then close in again.
Note: If the Paper and the Error lights
do not turn off, there is still jammed paper
inside the printer. Check the inside of the
printer.
PROBLEM SOLVING 7.11
Clearing Paper Jams
Inside the Printer
Note: Paper jams in this area may result in loose toner on the page. If you get any toner on your
clothes, wash them in cold water because hot water will set the toner into the fabric.
1
Open the top cover and remove the
toner cartridge.
CAUTION: To prevent damage to the
toner cartridge, do not expose it to light
for more than a few minutes. Place a
piece of paper over the top of the toner
cartridge to shield it while it is out of the
printer.
2
Carefully lift up the guide feed.
Guide feed
3
Gently pull the paper toward you to
remove it from the printer.
7.12 PROBLEM SOLVING
Clearing Paper Jams
4
Flip down the guide feed, and reinstall
the toner cartridge.
Note: If the toner cartridge is difficult to
reinstall, make sure the guide feed has
been flipped back down into position.
5
Close the top cover. Printing can be
resumed.
Note: If you have the optional Tray 2 installed, and cannot find the jammed paper in the output
or input area, or inside the printer, the paper jam may have occurred in the optional Tray 2. See
the next page to clear the jammed paper in the optional tray.
PROBLEM SOLVING 7.13
Clearing Paper Jams
In the Optional Tray 2
1
Pull the option Tray 2 out of the printer.
2
If you see the jammed paper, remove
the paper from the tray.
3
If you cannot find the jammed paper in
the Tray 2, pull the upper Tray 1 half
way out of the printer, and remove the
paper as shown in the figure at right.
4
Slide the trays back into the printer.
Open the top cover, then close it again.
Printing can be resumed.
7.14 PROBLEM SOLVING
Clearing Paper Jams
Tips for Avoiding Paper Jams
By selecting correct paper types and loading them properly,
you should be able to avoid most paper jams. If paper jams
occur, follow the steps outlined in “Clearing Paper Jams” on
page 7.7. If jams occur frequently, make sure you are
following these tips to avoid jams.
• Follow the procedures in “Load Paper” on page 2.5 to load
the paper properly. Make sure the adjustable guides are
positioned correctly.
• Do not overload the paper tray. Make sure the paper is under
the paper capacity mark on the inside of the paper tray.
• Do not pull out the paper tray while print jobs are in process.
• Flex, fan and straighten the paper before loading it.
• Do not load stacks of labels or transparencies in Tray 1.
Labels or transparencies must be fed using the Multi-Purpose
Tray.
• Do not load wrinkled, creased, damp or highly curled paper.
• Do not mix paper types in the paper tray.
• Use only recommended print media. See “Paper
Specifications” on page A.2.
• Make sure that the recommended print side is facing down
when loading the paper into Tray 1 or optional Tray 2 and
facing up when loading into the Multi-Purpose Tray.
• Keep print media stored in an acceptable environment.
PROBLEM SOLVING 7.15
Solving Print Quality Problems
Print Quality Checklist
General print quality problems can be solved by following the checklist below.
• Check the printer properties to make sure that you are using the best available print quality
option (see page 5.18).
• Redistribute the toner in the toner cartridge (see page 6.2).
• Clean the inside of the printer (see page 6.4).
• Adjust the print resolution from the printer properties (see page 5.18).
• Check to make sure that Toner Save Mode is off (see page 5.6).
• Troubleshoot general printing problems (see page 7.2).
• Install a new toner cartridge, then check print quality again (see page 2.3).
Solving Print Quality Problems
Problem
Solution
Light or faded print
If a vertical white streak or faded area appears on the page:
AaBbCc
AaBb
Cc
AaBb
Aa
BbCc
Cc
AaBb
Aa
BbCc
Cc
AaBb
Aa
BbCc
Cc
AaBb
Aa
BbCc
Cc
• The toner supply is low. You may be able to temporarily
extend the toner cartridge life. See “Redistributing
Toner” on
AaBbCc
page 6.2. If this does not improve the print
quality, install a
AaBbCc
new toner cartridge.
AaBbCc
• The paper may not meet paper specifications
(for example,
AaBbCc
the paper is too moist or too rough). SeeAaBbCc
“Paper
Specifications” on page A.2.
• If the whole page is light, the print resolution setting is too
light or Toner Save Mode may be on. Adjust the print
resolution and Toner Save Mode within the printer
properties. See page 5.18.
• A combination of faded and smeared defects may indicate
that the toner cartridge needs cleaning. See “Cleaning the
Printer” on page 6.4.
• The surface of the LSU part inside the printer may be dirty.
Clean the LSU (see page 6.5).
7.16 PROBLEM SOLVING
aBbCc
aBbCc
aBbCc
aBbCc
aBbCc
Solving Print Quality Problems
Problem
Solution
Toner specks
• The paper may not meet paper specifications (for example,
the paper is too moist or too rough). See “Paper
Specifications” on page
A.2.
AaBbCc
AaBbCc
AaBbCc
AaBbCc
AaBbCc
AaBbCc
Dropouts
AaBbCc
AaBbCc
AaBbCc
AaBbCc
AaBbCc
• The transfer roller may
be dirty. See “Cleaning the Inside”
AaBbCc
on page 6.4.
AaBbCc
• The paper path mayAaBbCc
need cleaning. See “Cleaning the
Inside”on page 6.4. AaBbCc
If faded areas, generally rounded, occur randomly on the
page:
AaBbCc
• A single sheet of paper may be defective. Try reprinting the
AaBbCc
job.
AaBbCc
• The moisture content of the paper is uneven or the paper
AaBbCc
has moist spots on its surface. Try a different kind or brand
AaBbCc
of paper. See “Paper Specifications” on page A.2.
• The paper lot is bad. The manufacturing processes can
cause some areas to reject toner. Try a different kind or
brand of paper.
• The toner cartridge may be defective. See Repetitive vertical
defects” on page 7.18.
• If these steps do not correct the problems, contact a
service representative.
Vertical lines
AaBbCc
AaBbCc
AaBbCc
AaBbCc
AaBbCc
If black vertical streaks appear on the page:
• The photosensitive drum inside the toner cartridge has
probably been scratched. Install a new toner cartridge.
If white vertical streaks appear on the page:
• The surface of the LSU part inside the printer may be dirty.
Clean the LSU (see page 6.5).
PROBLEM SOLVING 7.17
Solving Print Quality Problems
AaBbCc
AaBbCc
AaBbCc
AaBbCc
AaBbCc
Problem
Gray background
BbCc
BbCc
BbCc
aBbCc
aBbCc
AaBbCc
AaBbCc
AaBbCc
AaBbCc
AaBbCc
Solution
AaBbCc
AaBbCc
AaBbCc
AaBbCc
AaBbCc
If the amount of background toner shading becomes
unacceptable, the procedures below may help to clear the
condition:
• Change the paper to a lighter basis weight. See “Paper
Specifications” on page A.2.
• Check the printer’s AaBbCc
environment; very dry (low humidity)
or high humidity (higher
than 80 % RH) conditions can
AaBbCc
increase the amountAaBbCc
of background shading.
• Install a new toner AaBbCc
cartridge.
AaBbCc
Toner smear
• Clean the inside of the printer. See “Cleaning the Inside” on
page 6.4.
• Check the paper type and quality. See “Paper
Specifications” on page A.2.
• Try installing a new toner cartridge.
AaBbCc
AaBbCc
AaBbCc
AaBbCc
AaBbCc
Repetitive vertical
defects
AaBbCc
AaBbCc
AaBbCc
AaBbCc
AaBbCc
If marks repeatedly appear on the printed side of the page
at even intervals:
• The toner cartridge may be damaged. If a repetitive mark
occurs every 95 mm or 38 mm on the page, print the
cleaning sheet several times to clean the cartridge (see
page 6.5). If you still have the same problems, install a
new toner cartridge.
• Parts in the printer may have toner on them. If the defects
occur on the back of the page, the problem will likely
correct itself after a few more pages.
• The fusing assembly may be damaged. Contact a service
representative.
7.18 PROBLEM SOLVING
aBbCc
aBbCc
aBbCc
aBbCc
aBbCc
Solving Print Quality Problems
AaBbCc
AaBbCc
AaBbCc
AaBbCc
AaBbCc
Problem
Background scatter
AaBbCc
AaBbCc
AaBbCc
AaBbCc
AaBbCc
A
Solution
Background scatter results from bits of toner distributed on
the printed page.
• The paper may be too damp. Try printing AaBbCc
with a different
AaBbCc
batch of paper. Do not open packages of paper
until
AaBbCc
necessary so that the paper does not absorb
too much
moisture from the air.
AaBbCc
AaBbCc
• If background scatter occurs on an envelope,
change your
printing layout to avoid printing over areas that have
overlapping seams on the reverse side. Printing on seams
can cause this problem.
• If background scatter covers the entire surface of a printed
page, adjust the print resolution through your software
AaBbCc
application or the printer
properties.
Misformed characters
AaBbCc
AaBbCc
• If characters are improperly
formed, producing hollow
AaBbCc
images, the paper stock
may be too slick. Try a different
AaBbCc
paper. See “Paper Specifications” on page A.2.
• If characters are improperly formed, producing a wavy
effect, the scanner unit may need service. Check to see if it
also occurs on a demo page by pressing the Demo button
on the control panel when the printer is ready. If you need
service, contact a service representative.
Page skew
• Check the paper type and quality. See “Paper
Specifications” on page A.2.
AaBbC
AaBbCcc
AaBbC
AaBbCcc
AaBbCc
• Make sure that the paper or other media is loaded correctly
and the guides are not too tight or too loose against the
paper stack.
PROBLEM SOLVING 7.19
AaBbCc
AaBbCc
Solving Print Quality Problems
AaBbCc
AaBbCc
AaBbCc
Problem
AaBbCc
AaBbCc
AaBbCc
AaBbCc
Curl
or wave
AaBbCc
AaBbCc
AaBbCc
AaBbCc
AaBbCc
AaBbCc
• Check the paper type and quality. Both high
temperature
AaBbCc
and humidity will cause paper curl. See “Paper
Specifications” on page A.2.
AaBbCc
Solution
• Turn over the stack of paper in the paper tray. Also try
rotating the paper 180° in the paper tray.
• Open the rear output tray and try printing to the face up
output tray.
Wrinkles or creases
• Make sure that paper is loaded properly.
• Check the paper type and quality. See “Paper
Specifications” on page A.2.
• Open the rear output tray and try printing to the face up
output tray.
• Turn over the stack of paper in the paper tray. Also try
rotating the paper 180° in the tray.
Back of printouts dirty
• The transfer roller may be dirty. See “Cleaning the Inside”
on page 6.4.
• Check if the toner is leaking. Clean inside the printer.
aBbCc
aBbCc
aBbCc
aBbCc
aBbCc
AaBbCc
AaBbCc
AaBbCc
AaBbCc
AaBbCc
Black pages
• The toner cartridge may not be installed properly. Remove
the cartridge and reinsert it.
• The toner cartridge may be defective and need replacing.
Install a new toner cartridge.
• The printer may require repairs. Contact a service
representative.
7.20 PROBLEM SOLVING
AaBbCc
AaBbCc
AaBbCc
Problem
Solving Print Quality Problems
Solution
Loose toner
• Clean the inside of the printer.
AaBbCc
AaBbCc
AaBbCc
AaBbCc
AaBbCc
• Check the paper type and quality. See “Paper
Specifications” on page A.2.
Character Voids
A
• Try installing a new toner cartridge.
• If the problem persists, the printer may require repairs.
Contact a service representative.
Character voids are white areas within the parts of
characters that should be solid black:
• If you are using transparencies when you experience this
problem, try another type of transparency. (Because of the
composition of transparency media, some character voids
are normal.)
• You may be printing on the wrong surface of the paper.
Remove the paper and turn it around.
• The paper may not meet paper specifications. See “Paper
Specifications” on page A.2.
Horizontal stripes
AaBbCc
AaBbCc
AaBbCc
AaBbCc
AaBbCc
If horizontally aligned black streaks or smears appear:
• The toner cartridge may be installed improperly. Remove
the cartridge and reinsert it.
• The toner cartridge may be defective. Install a new toner
cartridge.
• If the problem persists, the printer may require repairs.
Contact a service representative.
PROBLEM SOLVING 7.21
Troubleshooting Error Messages
When the printer detects an error, the control panel indicator lights will indicate error
messages. Find the light pattern below that matches the printer light pattern and follow the
solutions to clear the error.
Printer Light Patterns
Light status legend
symbol for “light off”
symbol for “light on”
symbol for “light blinking”
Power off
• Check the power cord and the power switch if your printer does not
generate a response.
• Make sure that the printer is powered with the specified AC voltage.
Paper out
The printer is out of paper in the paper tray. The Paper light blinks until
paper is added.
• Loading paper into the tray will cancel this message and allow you to
continue with the print job.
7.22 PROBLEM SOLVING
Troubleshooting Error Messages
Paper out in the manual feed mode
While printing in the manual feed mode, the printer is out of paper in
the Multi-Purpose Tray.
• Load the correct paper into the Multi-Purpose Tray and press the Demo
button on the control panel to print each page.
Paper jam
Paper is jammed inside the printer.
• Clear the paper jam. See “Clearing Paper Jams” on page 7.7.
Door open, no toner cartridge
The printer top cover may be opened or the toner cartridge is not
installed.
• Check that the printer top cover door and rear door (face-up output tray)
are closed properly.
• Make sure that the toner cartridge is correctly installed in the printer.
PROBLEM SOLVING 7.23
Troubleshooting Error Messages
Memory out (Insufficient Memory)
The printer ran out of memory in the middle of a print job. The page
being printed may have been too complex for the memory capacity of
the printer. Press the Cancel/Reprint button to cancel the current job.
• Turn the printer power off and back on to remove any unnecessary fonts,
macros, or any data currently in printer memory.
• Add more printer memory. See “Memory and PostScript SIMMs” on page F.2.
• For a temporary solution, simplify the image or print at a lower resolution.
System error
• Reset the printer by briefly turning the printer off and back on again.
• If the error persists, contact the service representative.
7.24 PROBLEM SOLVING
Common Windows Problems
Problem
Possible Cause and Solution
“File in Use” message
appears during installation.
Quit all software applications. Remove all software from the
StartUp Group, then restart Windows. Reinstall the printer
driver.
“Error Writing to LPTx”
message appears.
• Make sure that the cables are connected correctly, the
printer is on, and the Data light on the control panel is
on.
• If bi-directional communication is not turned on in the
driver, it will also cause this message.
“General Protection Fault”,
“Exception OE”, “Spool32”,
or “Illegal Operation”
messages appears.
Close all other applications, reboot Windows, and try
printing again.
Note: Refer to Microsoft Windows 9x, Me, NT 4.0, 2000 or XP documentation that came with your
PC for further information on Windows error messages.
PROBLEM SOLVING 7.25
Common Macintosh Problems
Problems in the Chooser
Problem
The printer driver icon
does not appear in the
Chooser.
Possible Cause and Solution
Software is not installed correctly.
• The LaserWriter driver should be present as a part of the
Macintosh OS. Make sure that the LaserWriter driver is in the
Extensions folder within the Systems folder. If not, install
the LaserWriter driver component from the Macintosh OS CD.
• Make sure that you are using a high-quality cable.
• Make sure that the printer is on the correct network. Select
Network or AppleTalk Control Panel from Control
Panels in the Apple menu and then choose the correct
network.
The printer name does
not appear in the Select
a PostScript Printer box
in the Chooser.
• Make sure that the cables are connected correctly, the
printer is on, and the Data light is on.
• Make sure that the correct printer driver has been selected
in the Chooser.
• If the printer resides on a network with multiple zones,
make sure that the correct zone is selected in the
AppleTalk Zones box in the Chooser.
• Make sure AppleTalk is on. (The button next to Active is
selected in the Chooser.) You may need to restart the
computer to activate the change.
7.26 PROBLEM SOLVING
Common Macintosh Problems
Printing Errors
Problem
You cannot use the
computer while the printer
is printing.
Possible Cause and Solution
Background Printing has not been selected.
• For LaserWriter 8.3, turn Background Printing on in the
Chooser. Status messages will now be redirected to the
Print Monitor allowing you to continue working while the
computer is processing data to be sent to the printer.
• For LaserWriter 8.4 or higher, turn Background Printing
on at the Print dialog box.
PROBLEM SOLVING 7.27
Troubleshooting PS Errors
The following situations are PS language specific and may occur when several printer
languages are being used.
Note: To receive a printed or screen displayed message when PS errors occur, open the Print Options
dialog box and click the desired selection next to the PostScript errors section.
Problem
Possible Cause
Solution
PostScript file can not
be printed.
The PostScript option may
not be installed.
• Print a configuration page and
verify that the PS version is
available for printing.
• If PostScript is not available,
install the PostScript option. See
“Memory and PostScript SIMMs”
on page F.2.
“This job contains
binary data...”
message appears.
The pure binary data
option is not supported by
the PostScript driver.
Open the Properties of the
PostScript driver, click on
PostScript, and click on
Advanced button. The pure
binary data option is not
supported. Choose another.
A PS error page
prints.
Print job may not be PS.
Make sure that the print job is a
PS job. Check to see whether the
software application expected a
setup or PS header file to be sent
to the printer.
The optional Tray 2 is
not selected in the
driver.
The printer driver has not
been configured to
recognize the optional
Tray 2.
Open the PostScript driver
properties and set the Option Tray
item of Device option to
Installed.
7.28 PROBLEM SOLVING
Troubleshooting PS Errors
Memo
PROBLEM SOLVING 7.29
APPENDIX
A Specifications
This appendix provides information on the following topics:
◆ Printer Specifications
◆ Paper Specifications
Printer Specifications
Specification and Description
Item
Print Speed
14 PPM (A4), 15 PPM (Letter)
Resolution
Up to 1,200 x 1,200 dpi effective output
First Printing Time
Less than 15 seconds
WarmUp Time
Less than 40 seconds
Power Rating
AC 100 ~ 127 V (USA, Canada) / 220 ~ 240 V (Others), 50 / 60 Hz
Power Consumption
350 W average during operation / Less than 12 W in power-save mode
Acoustic Noise
Stand by: Less than 35 dB; Operating: Less than 48 dB
Toner Supply
Single cartridge
Toner Cartridge Life
6,000 pages (for starter, 3,000 pages), 5% area coverage
Duty Cycle
Monthly: 12,000 pages maximum
Weight
12.4 Kg / 27.3 lb.
Package Weight
Paper: 1.83 Kg
Plastic: 0.33 Kg
External Dimensions
361 (W) x 409 (D) x 294.5 (H) mm (without options)
Operating Environment
Temperature:10 ~ 32 °C / 50 ~ 90 °F; Humidity: 20 ~ 80 % RH
Emulation
PCL 6, PostScript 3 optional
Random Access
Memory (RAM)
Standard 4 MB (16 MB standard on ML-1451N)
Expandable to 68 MB (80 MB on ML-1451N)
: 72 pin, EDO, non-parity, 60ns;
4 MB, 8 MB, 16 MB, 32 MB, or 64 MB available
Fonts
1 bitmap, 45 scalable (136 PS fonts)
Interface Switching
Automatic (Parallel, USB, Network)
Interface
• 14PPM (A4) Bidirectional Parallel Standard
- Modes supported: Compatible, Nibble, Byte, ECP
• USB Interface Standard
- USB 1.1 compliant
- 12Mbps 1 port
• Network Optional (standard for ML-1451N)
- Ethernet 10/100M Base T
- Novell
- TCP/IP and AppleTalk
- LPD
SPECIFICATIONS A.1
Paper Specifications
Overview
This printer accepts a variety of media, such as cut-sheet
paper (including up to 100 % recycled fiber content paper),
envelopes, labels, transparencies and custom-size paper.
Properties such as weight, composition, grain and moisture
content are important factors affecting printer performance and
output quality. Paper that does not meet the guidelines
outlined in this manual can cause the following problems:
• Poor print quality
• Increased paper jams
• Premature wear on the printer, requiring repairs.
Notes:
• Some paper may meet all of the guidelines in this manual and
still not produce satisfactory results. This might be the result of
improper handling, unacceptable temperature and humidity
levels, or other variables over which Samsung has no control.
• Before purchasing large quantities of paper, make sure that the
paper meets the requirements specified in this user guide.
Always test paper before buying large quantities.
CAUTION: Using paper that does not meet that stated
specifications may cause problems for the printer, requiring
repairs. Repairs made necessary by the use of paper not
specified in this manual are not covered by the Samsung
warranty or service agreements.
A.2 SPECIFICATIONS
Paper Specifications
Supported Sizes of Paper
Tray 1 or Optional Tray 2
Dimensionsa
Letter
8.5 X 11 in. (216 X 279 mm)
A4
210 X 297 mm (8.3 X 11.7 in.)
Executive
7.3 X 10.5 in. (191 X 267 mm)
Legal
8.5 X 14 in. (216 X 356 mm)
B5 (JIS)
182 X 257 mm (7.2 X 10 in.)
Folio
216 X 330 mm (8.5 X 13 in.)
Weight
Capacityb
16 to 28 lb Bond
(60 to 105 g/m2)
550 sheets of
20 lb Bond
(75 g/m2) paper
a. The printer supports a wide range of media sizes. See “Printing on Card Stock or Custom-sized Media” on
page 4.17.
b. Capacity may vary depending on media weight and thickness, and environmental conditions.
Multi-Purpose Tray
Dimensionsa
Minimum Size (custom)
90 X 148 mm (3.5 X 5.83 in.)
Maximum Size (custom)
216 X 356 mm (8.5 X 14 in.)
Envelopes
60 to 163 g/m2 Bond
(16 to 43 lb )
Capacityb
100 sheets of
75 g/m2 Bond
(20 lb) paper
Thickness:
20 typical
.10 X .14 mm
(0.0039 X 0.0055 in.)
Transparency
Labelsc
Weight
Same minimum and
maximum paper sizes as
listed above.
Thickness:
.10 X .14 mm
25 typical
(0.0039 X 0.0055 in.)
up to 90 g/m2
(16-24 lb)
up to 10
a. The printer supports a wide range of media sizes. See “Printing on Card Stock or Custom-sized Media” on
page 4.17.
b. Capacity may vary depending on media weight and thickness, and environmental conditions.
c. Smoothness - 100 to 250 (Sheffield)
Note: You may experience some paper jams when using any media with a length of less than 148
mm (5.83 in.). For optimum performance, make sure you are storing and handling the paper
correctly. Please refer to “Printer and Paper Storage Environment” on page A.6.
SPECIFICATIONS A.3
Paper Specifications
Guidelines for Using Paper
For best results, use conventional 90 g/m2 (24 lb) paper. Make sure the paper is of good
quality, and free of cuts, nicks, tears, spots, loose particles, dust, wrinkles, voids, and curled
or bent edges.
If you are unsure of what type of paper you are loading (such as bond or recycled), check the
label on the package of the paper.
The following problems with paper can cause print quality deviations, jamming, or even
damage to the printer.
Symptom
Problem with Paper
Solution
Poor print quality or
toner adhesion
Problems with feeding
Too moist, too rough, too
smooth, or embossed;
faulty paper lot
Try another kind of paper,
between 100 ~ 250 Sheffield,
4 ~ 5 % moisture content.
Dropout, jamming,
curl
Stored improperly
Store paper flat in its moistureproof wrapping.
Increased gray
background shading
/printer wear
Too heavy
Use lighter paper, open the rear
output tray.
Excessive curl
problems with feeding
Too moist, wrong grain
direction or short-grain
construction
• Open the rear output tray.
• Use long-grain paper.
Jamming, damage to
printer
Cutouts or perforations
Do not use paper with cutouts or
perforations.
Problems with feeding
Ragged edges
Use good quality paper
Notes:
• Do not use letterhead paper that is printed with low-temperature inks, such as those used in some
types of thermography.
• Do not use raised or embossed letterhead.
• The printer uses heat and pressure to fuse toner to the paper. Make sure that any colored paper or
preprinted forms use inks that are compatible with this fusing temperature (200 °C or 392 °F for 0.1
second).
A.4 SPECIFICATIONS
Paper Specifications
Paper Specifications
Category
Specifications
Acid Content
5.5 ~ 8.0 pH
Caliper
.094 ~ .18 mm (3.0 ~ 7.0 mils)
Curl in Ream
Flat within 5 mm (.02 in.)
Cut Edge Conditions
Cut with sharp blades with no visible fray.
Fusing Compatibility
Must not scorch, melt, offset, or release hazardous
emissions when heated to 200 °C (392 °F) for .1
second.
Grain
Long Grain
Moisture Content
4 % ~ 6 % by weight
Smoothness
100 ~ 250 Sheffield
Paper Output Capacity
Output Tray
Capacity
Top output (Face-down) tray
250 sheets of 20 lb bond (75 g/m2) paper
Rear output (Face-up) tray
100 sheets of 20 lb bond (75 g/m2) paper
SPECIFICATIONS A.5
Paper Specifications
Printer and Paper Storage Environment
Ideally, the printer and paper storage environment should be
at or near room temperature, and not too dry or humid.
Remember that paper absorbs and loses moisture rapidly.
Heat works with humidity to damage paper. Heat causes the
moisture in paper to evaporate, while cold causes it to
condense on the sheets. Heating systems and air conditioners
remove most of the humidity from a room. As paper is opened
and used, it loses moisture, causing streaks and smudging.
Humid weather or water coolers can cause the humidity to
increase in a room. As paper is opened and used it absorbs
any excess moisture, causing light print and dropouts. Also, as
paper loses and gains moisture it can distort. This can cause
paper jams.
As a result, paper storage and handling are as important as
the paper-making process itself. Paper storage environmental
conditions directly affect the feed operation.
Care should be taken not to purchase more paper than can be
easily used in a short time (about 3 months). Paper stored for
long periods may experience heat and moisture extremes,
which can cause damage. Planning is important to prevent
damage to a large supply of paper.
Unopened paper in sealed reams can remain stable for several
months before use. Opened packages of paper have more
potential for environment damage, especially if they are not
wrapped with a moisture-proof barrier.
The paper storage environment should be properly maintained
to ensure optimum printer performance. The required condition
is 20 ° to 24 °C (68° to 75 °F), with a relative humidity of
45 % to 55 %. The following guidelines should be helpful when
evaluating the paper’s storage environment:
• Paper should be stored at or near room temperature.
• The air should not be too dry or too humid (due to the
hygroscopic properties of paper).
• The best way to store an opened ream of paper is to rewrap it
tightly in its moisture-proof wrapping. If the printer
environment is subject to extremes, unwrap only the amount
of paper to be used during the day’s operation to prevent
unwanted moisture changes.
A.6 SPECIFICATIONS
Paper Specifications
Envelopes
Envelope construction is critical. Envelope fold lines can vary
considerably, not only between manufacturers, but also within
a box from the same manufacturer. Successful printing on
envelopes depends upon the quality of the envelopes. When
selecting envelopes, consider the following components:
• Weight: The weight of the envelope paper should not exceed
90 g/m2 (24 lb) or jamming may occur.
• Construction: Prior to printing, envelopes should lie flat with
less than 6 mm (0.25 in.) curl, and should not contain air.
• Condition: Envelopes should not be wrinkled, nicked, or
otherwise damaged.
• Temperature: You should use envelopes that are compatible
with the heat and pressure of the printer.
• Size: You should only use envelopes within the following size
ranges.
Minimum
Maximum
Multi-Purpose
Tray
90 X 148 mm
(3.5 X 5.83 in.)
216 X 356 mm
(8.5 X 14 in.)
Optional Tray 2
148 X 210 mm
(5.83 X 8.3 in.)
216 X 356 mm
(8.5 X 14 in.)
Notes:
• Use only the Multi-Purpose Tray to print envelopes.
• You may experience some paper jams when using any media
with a length less than 148 mm (5.83 in.). This may be caused
by paper that has been affected by environmental conditions.
For optimum performance, make sure you are storing and
handling the paper correctly. Please refer to “Printer and Paper
Storage Environment” on page A.6.
SPECIFICATIONS A.7
Paper Specifications
Envelopes with
Double Side Seams
Double side-seams construction has vertical seams at both ends
of the envelope rather than diagonal seams. This style may be
more likely to wrinkle. Be sure the seam extends all the way to
the corner of the envelope as illustrated below.
Correct
Incorrect
Envelopes with
Adhesive Strips or
Flaps
Envelope Margins
Envelopes with a peel-off adhesive strip or with more than one
flap that folds over to seal must use adhesives compatible with
the heat and pressure in the printer. The extra flaps and strips
might cause wrinkling, creasing, or even jams and may even
damage the fuser.
The following gives typical address margins for a commercial
#10 or DL envelope.
Type of Address
Minimum
Maximum
Return address
15 mm (0.6 in.)
51 mm (2 in.)
Delivery address
51 mm (2 in.)
89 mm (3.5 in.)
Notes:
• For best print quality, position margins no closer than 15 mm
(0.6 in.) from the edges of the envelope.
• Avoid printing over the area where the envelope’s seams meet.
Envelope Storage
A.8 SPECIFICATIONS
Proper storage of envelopes helps contribute to print quality.
Envelopes should be stored flat. If air is trapped in an envelope,
creating an air bubble, then the envelope may wrinkle during
printing. See “Printing on Envelopes” on page 4.12.
Paper Specifications
Labels
CAUTIONS:
• To avoid damaging the printer, use only labels recommended
for laser printers.
• To prevent serious jams, always use the Multi-Purpose Tray to
print labels and always use the rear output tray.
• Never print on the same sheet of labels more than once and
never print on a partial sheet of labels.
When selecting labels, consider the quality of each component:
• Adhesives: The adhesive material should be stable at
200 °C (392 °F), the printer’s fusing temperature.
• Arrangement: Only use labels with no exposed backing
between them. Labels can peel off sheets with spaces
between the labels, causing serious jams.
• Curl: Prior to printing, labels must lie flat with no more than
13 mm (.5 in.) of curl in any direction.
• Condition: Do not use labels with wrinkles, bubbles, or other
indications of separation.
See “Printing on Labels” on page 4.14.
Transparencies
Transparencies used in the printer must be able to withstand
200 °C (392 °F), the printer’s fusing temperature.
CAUTION: To avoid damaging the printer, use only
transparencies recommended for use in laser printers.
See “Printing on Transparencies” on page 4.15.
SPECIFICATIONS A.9
APPENDIX
B Using Your
Printer with
a Macintosh
Your printer supports Macintosh systems with a built-in USB
interface or 10/100 Base-TX network interface card (option
for ML-1450, standard for ML-1451N). When you print a file
from Macintosh, you can use the QPDL driver to support your
printer’s major printing features. You can also use PostScript
driver by installing the PPD file.
Topics included in this appendix are:
◆ Macintosh Installation
◆ Using QPDL Driver
◆ Using PS Driver
Macintosh Installation
System Requirements
To use your ML-1450 series printer and its software with a
Macintosh, your system should have:
Macintosh Hardware
Requirement
• One of the following Macintosh models:
-Power Macintosh series (for network connection only)
-Power Macintosh G3, G4
-iMac series
-iBook series
-Power Book series
• USB interface or network interface (for network connection
only)
Macintosh System
Requirement
Printer Hardware
Requirement
• For network connection: System 7.6 or later
• For USB connection: System 8.6 or later
• PS SIMM (for PS driver user only. PS SIMM is option)
• Network interface (for network connection only. Network
interface is option for ML-1450. ML-1451N came with a builtin network interface.)
USING YOUR PRINTER WITH A MACINTOSH B.1
Macintosh Installation
Connecting To Macintosh
You can connect the printer to your Macintosh using the USB
interface or network interface.
USB Connection
USB cable is not provided in your printer. Purchase a certified
USB 1.0 or 1.1 compliant cable.
1 Turn off the printer and computer.
2 Hold the USB cable so the
icon faces up and connect it
to your printer’s USB connector.
3 Connect the other end of the cable to an available USB port
on your Macintosh computer. If you have any connecting
problems, please refer to your computer documentation.
Note: If you are using a USB hub, connect the printer’s cable to
the first tier of the hub or the printer may malfunction. If the
printer doesn’t work with the hub, connect it directly to the
USB port.
B.2 USING YOUR PRINTER WITH A MACINTOSH
Macintosh Installation
Network Connection
If you have a printer with 10/100Base-TX network interface
card installed (standard for ML-1451N, option for ML-1450),
you can connect to an Ethernet network. Use a Category 5
twisted pair cable with RJ-45 connectors for 10/100Base-T
Ethernet.
1 Plug one end of the network cable into the twisted-pair
connector on the back of the printer.
2 Connect the other end to the network hub.
Note: You must configure your printer for the network.
For information about configuring your printer, refer to
the Network User’s Guide.
USING YOUR PRINTER WITH A MACINTOSH B.3
Macintosh Installation
Installing Software
for Macintosh
1 Turn on your computer and printer.
2 Insert the CD-ROM which came with your printer into the
CD-ROM drive.
3 Double-click ML-1450 on your Macintosh desktop.
4 Click the Samsung Laser Printer Installer icon next to
the each language to select the correct one.
If you want to see the User Guide, click User’s Guide.
5 Click Continue, then click Continue.
6 The Samsung Laser Printer Installer opens. Select
installation type. The installer provides two options for
software installation:
• Easy Install (recommended method): This option loads
PPD and installs QPDL driver.
• Custom Install : This option allows you to choose which
components will be installed.
If you want to use the QPDL driver, you must install it.
If you want to use PostScript driver, you must install
the PPD file.
If you want to use Adobe Acrobat Reader program, you
must install it.
7 Click Install.
8 After installation is complete, click Quit.
B.4 USING YOUR PRINTER WITH A MACINTOSH
Using QPDL Driver
If you want to use your printer’s QPDL driver on your Macintosh
computer, take the following steps:
QPDL Driver installation method is different for USB connection
and the network connection.
Installing QPDL Driver on the USB-connected Macintosh
1 From the Apple menu, select Chooser.
2 From the left pane of the Chooser window, click SAMSUNG
QPDL. Then the ML-1450 will appear in the right pane of
the Chooser window.
3 Click the ML-1450, and close the Chooser window.
4 You see the message box indicating that you have changed
your current printer. Click OK.
5 A ML-1450 printer icon will be created on your desktop.
Installing QPDL Driver on the network-connected Macintosh
1 From the Apple menu, select Chooser.
2 Click SAMSUNG QPDL. The name of your printer appears in
the list. Select SEC000xxxxxxxxx from the printer box
(where the xxxxxxxxx varies depending on each of the
products.), and close the Chooser window.
3 When the setup is completed, you can see your printer icon
is created on the desktop window.
USING YOUR PRINTER WITH A MACINTOSH B.5
Using QPDL Driver
Printing from a Macintosh
When you print with a Macintosh, you need to check the
printer software setting in each application you use. Follow
these steps to print from a Macintosh:
1 Open a Macintosh application and select a file you want to
print.
2 Open the File menu, and click Page Setup (Document
Setup in some applications). You will see the Page Setup
dialog box.
3 Choose your paper size, orientation, paper type and other
options and click OK.
B.6 USING YOUR PRINTER WITH A MACINTOSH
Using QPDL Driver
Choose Watermark if you want to add a watermark to
each page in your document to emphasize its purpose or
indicate how it should be handled. For details on the
watermark option, see page 5.21.
4 Now open the File menu and click Print. You see the main
printer settings dialog box.
USING YOUR PRINTER WITH A MACINTOSH B.7
Using QPDL Driver
5 Choose the number of copies and indicate which pages you
want to print. For advanced printing features, select the
desired option. For details, see page B.9.
Select the desired option for
advanced printing features.
6 Click Print when you are finished checking your settings.
B.8 USING YOUR PRINTER WITH A MACINTOSH
Using QPDL Driver
Advanced Printing
The Page Setup dialog box contains five categories of page
setup properties. Listed below is the name of each property.
-Darkness/Quality
-Layout
-Color
-Background Printing
-Paper Source
Figures below display each property in the Page Setup dialog
box.
Darkness/Quality
Select print
darkness.
Select print
resolution.
Layout
Select the number
of pages you want to print
on one sheet of paper. The
pages will appear decreased
in size and arranged on
the sheet.
USING YOUR PRINTER WITH A MACINTOSH B.9
Using QPDL Driver
Color
Select grayscale
mode.
œ Grayscale
œ Black&White
Background Printing
Turns
background
printing on or
off.
Select a priority for your print job in
the queue of jobs waiting to print,
by clicking one of the following:
• Normal to print in the order the
job is received.
• Urgent to print before any
Normal priority job.
• Print at: to print at the specific
time you enter in the day and
time in the fields to the right.
• Put document on hold to hold
the print job in the print queue
until you are ready to release it.
Paper Source
Select the corresponding paper
source. If Auto Select is set, the
printer automatically selects the
print media according to the
following order: Multi-Purpose
Tray, Tray 1, Tray 2 (option).
Click it if
optional Tray 2
is installed.
B.10 USING YOUR PRINTER WITH A MACINTOSH
Using PS Driver
If you want to use the PS driver which were installed on your Macintosh computer, you must
install the PPD file to access your printer features and allow the computer to communicate with
your printer.
PPD file installation method is different for USB connection and the network connection.
Installing PPD file on the USB-connected Macintosh
1 Follow the instruction as described on page B.4 to install
the PPD file on your computer.
2 Open the Macintosh HD and double-click Application.
3 Double-click Utilities.
Note: The position of Desktop
Printer Utility may vary
depending to the MAC OS.
4 Double-click Desktop Printer Utility.
5 Select LaserWriter 8, and select Printer (USB) in the list
box. Then click OK.
6 Click the Change button in the USB Printer Selection
section. The name of your printer appears in the list.
7 Click ML-1450, then click OK.
8 Click the Auto Setup button in the PostScript Printer
Description (PPD) File section.
If Auto Setup does not work properly, click Select PPD and
choose Samsung ML-1450 Series.
9 When the setup is completed, click the Create button.
10 Click the Save button to save ML-1450 as a desktop
printer.
USING YOUR PRINTER WITH A MACINTOSH B.11
Using PS Driver
Installing PPD file on the network-connected Macintosh
1 Follow the instruction as described on page B.4 to install
the PPD file on your computer.
2 From the Apple menu, select Chooser.
3 Click LaserWriter 8 (the PostScript driver provided with
your Macintosh). The name of your printer appears in the
list. Select SEC000xxxxxxxxx from the printer box
(where the xxxxxxxxx varies depending on each of the
products.).
4 When the setup is completed, you see your printer icon is
created as a desktop printer.
If Auto Setup does not work properly, click Select PPD
and choose Samsung ML-1450 Series, then click OK.
B.12 USING YOUR PRINTER WITH A MACINTOSH
Using PS Driver
Printing from a Macintosh
Follow these steps to print from a Macintosh:
1 Open a Macintosh application and select a file you want to
print.
2 Open the File menu, and click Print. You see the main
printer settings dialog box.
3 Choose the number of copies and indicate which pages you
want to print. For advanced printing features, select the
desired option.
4 Click Print when you are finished checking your settings.
USING YOUR PRINTER WITH A MACINTOSH B.13
APPENDIX
C Printing from
DOS Applications
While your printer is primarily a Windows printer, you can
also print from a DOS software program using the Remote
Control Panel utility provided in the ML-1450 series CD-ROM.
Topics included in this Appendix are:
◆ About Remote Control Panel for DOS
◆ Installing the Remote Control Panel for DOS Users
◆ Selecting Print Settings
About Remote Control Panel for DOS
DOS users have access to many printer features through
specific DOS printer drivers; however, many software
manufactures do not develop printer drivers for their software
programs. The Samsung ML-1450 series printer provides the
DOS software control panel for improved printer control when
DOS printer drivers are not available or when certain print
settings are not available through DOS software programs.
Note: The ML-1450 series printer’s Remote Control Panel is not a
printer driver. It should be used to set print settings that are not
available through DOS software programs. Printer drivers are
supplied by the manufacturers of your DOS software programs. If
your DOS software program does not include a printer driver for
your Samsung printer, contact the manufacturer of the software
program or use one of the alternate printer drivers.
PRINTING FROM DOS APPLICATIONS C.1
Installing the Remote Control Panel
for DOS Users
ng ML-1450 Ser
msu
ies
Sa
The Remote Control Panel utility is provided on the printer
software CD-ROM.
1 Place the CD-ROM in the CD-ROM drive. Installation will
start automatically.
If the CD-ROM drive does not automatically run:
Select Run from the Start menu, and type
x:\cdsetup.exe in the Open box (where x is the drive
letter for the CD-ROM drive), then click OK.
2 When the opening screen appears, select the appropriate
language.
C.2 PRINTING FROM DOS APPLICATIONS
Installing the Remote Control Panel for DOS Users
3 Click Install the Samsung Software-III on your PC
(WinRCP).
4 Click Next.
PRINTING FROM DOS APPLICATIONS C.3
Installing the Remote Control Panel for DOS Users
5 The files are copied into the appropriate directory.
6 Click Finish.
Uninstall Remote Control Panel
The Uninstall icon in the ML-1450 series program group allows
you to select and remove any or all of the Windows ML-1450
printing system components.
1 From the Start menu, select Programs.
2 Select Samsung ML-1450 Series, and then
Uninstall Remote Control Panel.
3 Click OK.
4 The Samsung ML-1450 Series Remote Control Panel and all
of its components are removed from your computer.
5 Click Finish.
C.4 PRINTING FROM DOS APPLICATIONS
Selecting Print Settings
When you are running DOS, you can use this Remote Control
Panel to select print settings that may not be available on
some DOS programs. Typically, duplicate print settings that are
selected from a DOS software program override the ones that
are selected in the ML-1450 series Remote Control Panel.
Starting Remote Control Panel
1 From the Start menu, select Programs.
2 Select Samsung ML-1450 Series, and then
Remote Control Panel.
3 The Dialog box allows you to access all the information you
need when using your printer. If necessary, click other tabs
on the top of the dialog box to access other features.
4 When you complete the print settings, click Send until the
Print dialog box is displayed.
PRINTING FROM DOS APPLICATIONS C.5
Selecting Print Settings
The Remote Control Panel allows you to access the following
features:
PRINTING
• Paper Size sets the paper size.
• Paper Tray sets the default paper source.
• Copies sets the number of copies printed for each page.
• Orientation determines how the output is printed on the
page.
• Top Margin sets the top margin of the print material.
• Left Margin sets the left margin of the print material.
• AUTO CR sets how the printer performs a carriage return.
C.6 PRINTING FROM DOS APPLICATIONS
Selecting Print Settings
CONFIG
• Emulation You can select the emulation for printing a document
between AUTO and PCL. The factory default is AUTO.
• Power Save determines the length of time the printer waits
after a job is printed before it goes to a reduced power state. If
the printer is used frequently, select Off which keeps the printer
ready to print with the minimum warm-up time. This uses more
electricity to keep the printer warm and ready to print.
• Auto Continue determines what action the printer should take
when a manual feed print job is sent to the printer and there is
no paper in the Multi-Purpose Tray. If it is checked, the printer
will pick up the paper from the standard Tray 1 or optional Tray
2 after fifteen seconds. Otherwise, the printer will wait for you
to load paper in the Multi-Purpose Tray.
• Jam Recovery determines what action the printer should take
when a paper jam occurs. If it is unchecked, the printer does
not reprint a page that has jammed. If it is checked, the printer
keeps the image in memory for a printed page until the printer
signals that the page has successfully printed. The printer
reprints all jammed pages.
• Econo Mode determines the toner quantity the printer should
use when printing. If it is checked, the printer conserves toner
when printing. The default value is unchecked, which provides
100% usage.
PRINTING FROM DOS APPLICATIONS C.7
Selecting Print Settings
JOB
• Toner Density determines the toner density of page. The
default value is Medium.
• Paper Type provides the printer with information about the
type of paper to be used for a print job. For the best result, set
this to the paper type you loaded in the paper tray of the
printer. When using the plain paper, set this to Printer default.
• Image Quality improves the print quality of your text and
image and make the characters and images appear smoother. It
is preset to Text Enhancement at the factory.
• Time out determines the amount of time (in seconds) the
printer will wait before printing the last page of a print job that
does not end with a command to print the page or a formfeed
character. You can set from 0 to 300 seconds.
C.8 PRINTING FROM DOS APPLICATIONS
Selecting Print Settings
TEST
• Self Test prints the configuration sheet. A list of the user
default settings, the installed options, and the amount of printer
memory available prints.
• Demo Page prints the demonstration page. It shows the printer
features and specifications.
PRINTING FROM DOS APPLICATIONS C.9
Selecting Print Settings
PCL
• Typeface allows you to select the desired typeface. This
setting is ignored when the software application specifies a
font.
• Symbol set determines the symbol set. A symbol set is a set
of alphabetic and numeric characters, punctuation, and special
symbols used when printing with a selected font.
• Pitch sets the font pitch (only if you have selected a scalable
monospaced font). Pitch refers to the number of fixed-space
characters in a horizontal inch of type.
• Point Size sets the font point size (only if you have selected a
scalable typographic font). Point size refers to the height of the
characters in the font. One point equals approximately 1/72 of
an inch. You can select point sizes from 4.0 to 999.75 in
increments of 0.25 points.
• Lines Per Page sets the number of lines that print on each
page. The setting can range from 5 to 128 lines per page.
• Courier determines the courier font type: Regular or Dark.
• Font List prints the font list showing all the fonts available for
PCL emulation.
C.10 PRINTING FROM DOS APPLICATIONS
Selecting Print Settings
When installing PS option, you can use fallowing features.
PS 3
• Font List prints the font list showing all the fonts available for
PostScript (only available when the PostScript option is
installed).
• Print error information determines what action the printer
should take when an error occurs in PS interpreter. When set
to Off, the printer does not print error information when error
occurs in PS interpreter. When set to On, the printer prints
error information when error occurs in PS interpreter.
PRINTING FROM DOS APPLICATIONS C.11
APPENDIX
D Using Windows
PostScript Driver
If you want to use the PostScript driver provided with your
system CD-ROM or diskettes to print a document, use the
information on this Appendix.
Topics included in this Appendix are:
◆ Setting Your Printer with the PS Option
◆ Installing PPD Files
◆ Accessing the PS Printer Driver Features
Setting Your Printer with the PS Option
If you want to use the PostScript driver to print a document,
your printer should have:
• PS SIMM (Option)
• 12 MB or more RAM. ML-1450 comes with 4 MB RAM, so
additional 8 MB or more RAM should be added. (ML-1451N
come with 16 MB RAM, so additional RAM is not required.)
For instructions on installing the printer options,
see Appendix F, “Printer Options.”
Installing PPD Files
PPDs, in combination with the PostScript driver, access the
printer features and allow the computer to communicate with
the printer. An installation program for the PPDs is provided on
the ML-1450 CD-ROM.
Notes:
• Installing the PostScript printer driver may require the use of the
operating system files on the original CD-ROM or diskette that
came with your system.
• If you have a PostScript 3 driver and want to use it, you must install
the PostScript 3 PPD which is also provided on the ML-1450 series
CD-ROM.
Before installing PPD files, make sure that the printer and
the PC are properly connected with parallel, USB, or optional
network interface. For information on:
• Connecting with parallel interface, see page 2.8.
• Connecting with an USB interface, see page 2.17,
“Installing USB Driver.” To use the USB interface, you must
also install the USB port driver.
• Connecting with an optional network interface,
see page F.5, “Network Interface Card.”
USING WINDOWS POSTSCRIPT DRIVER D.1
Installing PPD Files
Installing PS driver in Windows 95/98/Me/NT
1 Insert the CD-ROM shipped with your printer into your
CD-ROM drive.
If the CD-ROM drive does not automatically run:
Select Run from the Start menu, and type
x:\cdsetup.exe in the Open box (where x is the drive
letter for the CD-ROM drive), then click OK.
2 When the opening screen appears, select the appropriate
language.
3 Click Install the Samsung Software-II on your PC
(PostScript).
D.2 USING WINDOWS POSTSCRIPT DRIVER
Installing PPD Files
4 The Welcome window opens. Click Next.
5 Select Local printer. Click Next.
Language Codes
Code
Language
DEU
ENG
ESN
FRN
ITA
CHS
German
English
Spanish
French
Italian
Chinese
6 Click on Have Disk, click Browse, then choose:
• for Windows 95/98, x:\1450\Eng(or the desired
language code.)\addprint\ps\Win9598\level2
• for Windows Me, x:\1450\Eng(or the desired language
code.)\addprint\ps\WinMe\level2
• for Windows NT 4.0, x:\1450\Eng(or the desired
language code.)\addprint\ps\WinNT\level2
where x is the drive letter for the CD-ROM drive,
then click OK.
USING WINDOWS POSTSCRIPT DRIVER D.3
Installing PPD Files
7 Click Next.
Note: When you install the
driver, if the dialog box
prompting you to insert the
Windows CD appears, insert
the Windows CD-ROM
shipped with your printer into
your CD-ROM drive. Click
Browse, and then select
CD-ROM drive or click OK.
8 The files are copied into the appropriate directory.
9 Click Next.
D.4 USING WINDOWS POSTSCRIPT DRIVER
Installing PPD Files
10 Click Next.
11 Click Finish.
USING WINDOWS POSTSCRIPT DRIVER D.5
Installing PPD Files
12 Click Finish.
Installing PS driver in Windows 2000/XP
1 Insert the CD-ROM shipped with your printer into your
CD-ROM drive.
If the CD-ROM drive does not automatically run:
Select Run from the Start menu, and type
x:\cdsetup.exe in the Open box (where x is the drive
letter for the CD-ROM drive), then click OK.
2 When the opening screen appears, select the appropriate
language.
D.6 USING WINDOWS POSTSCRIPT DRIVER
Installing PPD Files
3 Click Install the Samsung Software-II on your PC
(PostScript).
4 The Welcome window opens. Click Next.
USING WINDOWS POSTSCRIPT DRIVER D.7
Installing PPD Files
5 The files are copied into the appropriate directory.
6 Click Finish.
Uninstall PS Driver
1 From the Start menu, select Programs.
2 Select Samsung ML-1450 Series, and then
Samsung ML-1450 Series PS Driver Maintenance.
3 The Samsung ML-1450 Series PS Maintenance dialog box
appears. Check Remove and then click Next.
4 When you are asked to confirm your selection, click OK.
5 The Samsung ML-1450 Series PS driver and all of its
components are removed from your computer.
6 Click Finish.
D.8 USING WINDOWS POSTSCRIPT DRIVER
Accessing the PS Printer Driver Features
Certain printer features are not available in this PS driver. Refer
to “Printer Driver Features” on page 2.15.
The printer automatically switches between PS and SPL printer
languages depending on the driver you have selected.
Opening the Printer Properties Window
The properties window for the Windows PostScript printer driver
can be opened from the Printers folder or an application.
To open the properties window from the Printer folder:
1. Click the Windows Start button.
2. Select Settings then Printers to open the Printers window.
3. Select Samsung ML-1450 Series PS.
4. Click the right mouse button and select Properties to open
the properties window.
To open the properties window from inside an
application:
1. From the File menu, select Print to open the Print dialog
box.
2. Make sure that Samsung ML-1450 Series PS is selected in
the Name drop-down list.
3. Click Properties to open the properties window.
USING WINDOWS POSTSCRIPT DRIVER D.9
APPENDIX
E Using Your
Printer on
a Network
If you work in a networked environment, the printer can be
shared by other users on the network. ML-1451N printer are
network printers and can be connected to the network via
direct attachment to an external print server.
This appendix provides information on the following topics:
◆ About sharing the Printer on a Network
◆ Setting Up a Locally Shared Printer
◆ Setting Up a Network-Connected Printer
About Sharing the Printer on a Network
If you work in a networked environment, you can connect
the ML-1450 series printer to your network.
Locally Shared
You can connect the printer directly to a selected computer
(called the “host computer”) on the network. The printer
can then be shared by other users on the network through
a Windows 9x, Me, 2000, XP or NT 4.0 network printer
connection.
Network-Connect
If an option network card was installed on your printer (see
page F.5 for information on installing the option network
card in your printer) or if you have a ML-1451N printer, the
printer can be connected to the network via direct
attachment to an external print server.
Printing Across a Network
Whether the printer is locally connected or network
connected, you need to install the ML-1450 series printer
software on each computer that will print documents to the
ML-1450 series printer.
USING THE PRINTER ON A NETWORK E.1
Setting Up a Locally Shared Printer
Windows 98/Me
Setting Up Host Computer
1 Start Windows.
2 From the Start menu, select Control Panel, and doubleclick on the Network icon.
3 Check the File and Print Sharing box, then click OK.
Close the window.
4 Click Start and select Printers from Settings, then doubleclick your printer name.
5 Select Properties in the Printer menu.
6 Click the Sharing tab, then check the Shared As box. Fill
in the Shared Name field, then click OK.
Setting Up Client PC
1 Right-click Start, and select Explorer.
2 Open your network folder in the left column.
3 Right-click the shared name, and select Capture Printer
Port.
4 Select the port you want, check the Reconnect at log on
box, then click OK.
5 From the Start menu, select Settings, then Printers.
6 Double-click your printer icon.
7 From the Printer menu, select Properties.
8 Press the Details tab, select the printer port, then click OK.
E.2 USING THE PRINTER ON A NETWORK
Setting Up a Locally Shared Printer
Windows NT/2000/XP
Setting Up Host Computer
1 Start Windows.
2 From the Start menu, select Settings, then Printers.
(Windows NT/2000)
From the Start menu, select Printers and Faxes.
(Windows XP)
3 Double-click your printer icon.
4 From the Printer menu, select Sharing.
5 Check the Shared box. (Windows NT)
Check the Shared As box. (Windows 2000)
Check the Share this printer box. (Windows XP)
Fill in the Share Name field, then click OK.
(Windows NT)
Fill in the Shared Name field, then click OK.
(Windows 2000/XP)
USING THE PRINTER ON A NETWORK E.3
Setting Up a Locally Shared Printer
Setting Up Client PC
1 Right-click Start, and select Explorer.
2 Open your network folder in the left column.
3 Click the shared name.
4 From the Start menu, select Settings, then Printers.
(Windows NT/2000)
From the Start menu, select Printers and Faxes.
(Windows XP)
5 Double-click your printer icon.
6 From the Printer menu, select Properties.
7 Press the Ports tab, click Add Port.
8 Select Local port, and click New Port.
9 Fill in the Enter a port name field, enter the shared
name.
10 Click OK, and click Close .
11 Click OK. (Windows NT)
Click Apply, and click OK. (Windows 2000/XP)
E.4 USING THE PRINTER ON A NETWORK
Setting Up a Network-Connected Printer
To use ML-1450 series printer as a network printer, you
must install an optional network card in your printer. See
page F.5 for information on installing network card. If you
have ML-1451N printer, you do not need to install the
network card. The Samsung ML-1451N printer are shipped
with the network card.
After the network card is installed, you must set up your
printer as a network printer using the documentation and
Samsung SyncThru software provided with the network
card.
USING THE PRINTER ON A NETWORK E.5
APPENDIX
F Printer Options
Your printer is a full-featured laser printer that has been
optimized to meet most of your printing needs. Recognizing
that each user may have different requirements, however,
Samsung makes several options available to enhance the
printer’s capabilities.
This appendix provides information on the following topics:
◆ Precautions
◆ Memory and PostScript SIMMs
◆ Network Interface Card
◆ Paper Tray 2
Precautions
DISCONNECT THE POWER CORD:
Never remove the printer control board while the printer is
plugged in.
To avoid the possibility of electrical shock, always disconnect the
power cord when installing or removing ANY internal or external
printer option.
DISCHARGE STATIC ELECTRICITY:
The control board and internal printer options (Memory SIMM,
PS SIMM, Network interface) are sensitive to static electricity.
Before installing or removing an internal option, discharge static
electricity from your body by touching something metal, such as
the metal back plate on any device plugged into a grounded
power source. If you walk round before finishing the installation,
discharge any static electricity once again.
PRINTER OPTIONS F.1
Memory and PostScript SIMMs
Additional printer memory and the PostScript option are provided on SIMMs (single in-line
memory modules). This procedure is applicable to either option.
Notes:
• Since PostScript setting requires 12 MB of printer memory and the ML-1450 comes with
4 MB standard, installation of the PS SIMM requires installation of a 8 MB SIMM memory as well.
• ML-1451N has 16 MB RAM standard, so additional memory is not required to install option PS
SIMM.
1
Turn the printer power off and unplug
all cables from the printer.
2
Remove the two screws on the rear of
the printer, then remove the control
board cover.
3
Locate the PS SIMM slot (the lower slot
on the left as shown) and the memory
SIMM slot (the upper slot) on the
control board. They are not
interchangeable.
• To install the memory SIMM, continue
with Step 4.
• To install the PS SIMM, go to Step 6.
Memory
DRAM MODULE
FLASH-ROM MODULE
PS SIMM
F.2 PRINTER OPTIONS
Memory and PostScript SIMMs
4
Hold the memory SIMM so that the
notch 1 and the connection point 2
are aligned with the slot as shown, and
insert the SIMM all the way into the
upper slot labeled DRAM MODULE at
a 45 degrees angle.
1
DRAM MODULE
2
5
FLASH-ROM MODULE
Rotate it up until it snaps into place.
DRAM MODULE
FLASH-ROM MODULE
6
Hold the PS SIMM so that the notch 1
and the connection point 2 are aligned
with the slot as shown, and insert the
SIMM all the way into the lower slot
labeled FLASH-ROM MODULE at a 45
degrees angle.
1
DRAM MODULE
FLASH-ROM MODULE
2
7
Rotate it up until it snaps into place.
DRAM MODULE
FLASH-ROM MODULE
PRINTER OPTIONS F.3
Memory and PostScript SIMMs
8
Make sure that the SIMMs are secured
in place by the metal clips and pins on
both sides of the connectors.
pin
clip
9
Reconnect the power cord and printer
cable, then turn the printer on.
Note: For PostScript driver installation and usage information on a Macintosh system, refer to
Appendix B, “Using Your Printer with Macintosh.” For PS printing on a Windows system,
refer to Appendix D, “Using Windows PostScript Driver.”
F.4 PRINTER OPTIONS
Network Interface Card
Review the precautions on page F.1 and then follow this procedure to install the Network card
option in your printer.
1
Unpack the network printer card. You
should find the following items.
2
Two brackets come with the network
card. Select the long bracket and attach
it to the network card with two screws
provided.
3
Turn the printer power off and unplug all
cables from the printer.
4
Remove the two screws on the back of
the printer, then remove the control
board cover. See the figure on page F.2.
5
Remove the two screws, then remove
the plate.
Network card
(PortThru)
User’s guide
Brackets
Screws
CD-ROM
(SyncThru)
PRINTER OPTIONS F.5
Network Interface Card
6
Align the connector on the network card
with the connector on the control board.
Push the card firmly into the connector
until it is completely inserted in place.
7
Tighten the two screws as shown.
8
Tighten the two screws, then replace
the plate.
9
Reconnect the power cord and network
cable, then turn the printer on.
Note: For information on configuring and using the printer on a network environment, refer to
the documentation provided with the network card option.
F.6 PRINTER OPTIONS
Paper Tray 2
You can increase the paper handling
capacity of your printer by installing the
optional Tray 2. The optional paper tray
consists of two components; the support
unit and paper tray.
support unit
paper tray
Label
Note: Be sure you check the label before
using the optional Tray 2. (For use
with ML-1450 Series only)
1
Turn off the printer and unplug all cables
from the printer.
2
Observe the location of the support
unit’s connector and tabs.
tap
connector
tap
3
Align the printer with the support unit
and lower it into place on the tabs and
connector.
4
Load paper in Tray 2. For information on
loading paper in the tray, see page 2.5.
PRINTER OPTIONS F.7
Paper Tray 2
5
Reconnect the cables, then turn the
printer on.
Note: To print from Tray 2, you must configure the printer driver from your application prior to
printing. To access the printer driver, see page 5.2.
Click. If this box is checked,
you can select Tray 2 in the
Paper Source drop-down list.
F.8 PRINTER OPTIONS
Paper Tray 2
Memo
PRINTER OPTIONS F.9
APPENDIX
G Using Your
Printer in Linux
You can use Samsung ML-1450 Series printer in Linux
environment.
This appendix provides information on the following topic:
◆ Linux Driver Installation
Linux Driver Installation
This Linux driver is designed for the Samsung ML-1450 Series
printer and supports Linux Red Hat 6.0 or higher and Intel
Linux. If your Linux version is not included, this driver might
not work properly.
• Install Setup Script file configuration
a. /cdrom/linux/install.sh
b. /cdrom/linux/ssprt.db
c. /cdrom/linux/readme.txt
Installation
To install the driver, open the x terminal screen and take the
following steps:
1. Mount the
CD-ROM drive.
Note: To mount the CD-ROM drive, you must be a super user or
must be authorized to mount the CD-ROM by the super user. If
you fail to mount the CD-ROM drive, ask the system
administrator.
To mount the CD-ROM drive:
1 Insert the Samsung ML-1450 Series CD-ROM into the
CD-ROM drive.
2 Mount the CD-ROM drive under a directory like /mnt in
order to access the files on the CD-ROM:
>mount -t iso9660 /dev/cdrom /mnt/cdrom
2. Install setup script.
For details on installing the setup script, refer to the
/cdrom/linux/readme.txt file.
Add the driver to the printer list by typing in:
/cdrom/linux>install.sh (or)
/cdrom/linux>./install.sh (if the path of the current
working directory is not determined.)
USING YOUR PRINTER IN LINUX G.1
Linux Driver Installation
3. Set up the printer
filter.
To set up:
1 Run printtool at x terminal.
2 To add the printer driver, click the Add button.
3 In the Add a Printer Entry window, decide the printer type
you will use. Select Local Printer if you have a PCconnected printer.
4 Click the OK button.
5 If the Info button appears, ignore it, then click the OK
button.
6 The Edit xxxx Entry window opens (where xxxx is the
printer type you have selected at step 3).
If you are not an advanced user, do not change the
Names/Spool Directory/File Limit in Kb/Printer
Device option.
7 Click the Select button in the Input Filter to access filter
setup.
8 Select Samsung Printer PCL5e Compatible for the
Printer Type item. Then select the default resolution and
paper size.
9 To save the setting, press the OK button.
10 In the Edit xxxx Entry window, press the OK button to
complete the printer driver installation.
11 You can find that the printer driver is added to the driver
window. Select Quit from the PrintTool menu.
G.2 USING YOUR PRINTER IN LINUX
INDEX
D
Numeric
2-sided printing
5.7
A
All text to Black
5.19
B
booklet printing
Darkness
5.19
Dark text
5.19
Data light
3.4
Demo button
3.2
demo page, print
2.9, 7.6
driver
access
5.1
features
2.15
install
2.12
remove
2.16
repair
2.16
5.13
E
C
cancel, print job
5.5
Cancel/Reprint button
3.1, 5.29
card stock, print
4.17
clean, printer
6.4
clean sheet, print
7.6
components
1.4
configuration page, print
7.6
control panel
buttons
3.1
lights
3.3
custom-sized media, print
4.17
envelopes, print
error messages
4.12
7.22
F
face-down tray
4.4
face-up tray
4.4
features
1.1
G
graphic properties
5.18
all text to black
5.19
darkness
5.19
dark text
5.19
power save mode
5.20
reprint
5.20
reprint when jam
5.20
resolution
5.18
SRT mode
5.19
INDEX
I
INDEX
I
install
Linux driver
G.1
PPD file for windows
D.1
printer software, parallel cable
2.12
printer software, USB cable
2.17
QPDL driver for macintosh
B.4
remote control panel for windows
C.2
toner cartridge
2.3
J
5.10
N
jam
see paper jam
network interface
install network card
F.5
set up a locally shared printer
E.2
sharing the printer on a network
E.1
n-up printing
5.10
L
labels, print
4.14
letterhead, print
4.16
load, paper
in the multi-purpose tray
4.8
in tray 1 or the optional tray 2
using the manual feed
4.10
Linux driver
G.1
O
2.5
M
Macintosh
connecting network interface
B.3
connecting USB interface
B.2
install macintosh driver
B.4
install PPD file
B.4
solving common problems
7.26
system requirements
B.1
using PS driverr
B.11
using QPDL driverr
B.5
manual 2-sided printing
5.7
manual duplexing
5.7
II
manual feed
loading paper
4.10
paper source setting
5.3
Manual light
3.5
memory, option
F.2
multi-purpose tray
loading paper
4.8
paper source setting
5.3
multiple pages on one sheet, print
INDEX
option
memory SIMM
F.2
network interface card
paper tray 2
F.7
PS SIMM
F.2
orientation
5.3
output tray, select
4.4
rear
4.4
top
4.4
overlay, print
5.24
F.5
INDEX
P
paper
acceptable size and capacities 4.2, A.3
choose
4.1
guidelines
4.3, A.4
load
2.5, 4.6
specifications
A.2
storage environment
A.6
paper jam, clear
7.7
in the optional Tray 2
7.14
input area
7.10
inside the printer
7.12
output area 7.7
tips for avoiding paper jams
7.15
paper level indicator
4.6
Paper light
3.4
paper orientation, setting
5.3
paper out, indicator
7.22
paper source, setting
5.3
paper tray
change paper size in tray
2.6
load paper
2.5
optional Tray 2
F.7
paper type, setting
5.3
parallel, connection
2.8
poster, print
5.16
postscript 3 emulation
1.2
access windows PS driver
D.9
install PPD file for Macintosh
B.4
install PPD file for windows
D.1
problem solving
7.28
print media
see paper
print quality problem, solving
back of printouts dirty
7.20
background scatter
7.19
black pages
7.20
character voids
7.21
checklist
7.16
curl or wave
7.20
dropouts
7.17
grey background
7.18
horizontal stripes
7.21
light or feded print
7.16
loose toner
7.21
misformed characters
7.19
page skew
7.19
toner smear
7.18
toner specks
7.17
vertical lines
7.17
vertical repetitive defects
7.18
wrinkles or creases
7.20
printer light patterns
7.22
printer driver
see driver
printer software, install
2.12
printing
booklets
5.13
cancel
5.5
cleaning sheet
7.6
configuration page
7.6
demo page
7.6
fitting to a selected paper size
5.12
from windows application 5.1
from DOS applications
C.1
general problems, solving
7.2
help
5.5
multiple pages on one sheet
5.10
on both sides of the paper
5.7
on different paper for first page 5.28
poster
5.16
quality problems, solving
7.16
reprinting
5.29
scaling
5.11
using page overlay
5.24
watermarks
5.21
with macintosh
B.6, B.13
INDEX
III
INDEX
P
S
(continued)
problem, solving
common macintosh problems
7.26
common windows problems
7.25
error messages
7.22
general
7.2
paper jam
7.7
print quality
7.16
PS errors
7.28
Troubleshooting checklist
7.1
PS
see postscript 3 emulation
scaling your document
5.11
setup printer
chapter 2
specifications
paper
A.2
printer
A.1
SRT mode
5.19
system error
7.24
T
Q
quality, problems
7.16
R
Ready Mode
3.3
rear output tray
4.4
remote control panel
install
C.2
use
C.5
remove
C.4
remove
printer driver
2.16
PS driver
D.8
Remote control panel
C.4
reprint
5.20
reprinting the last page
5.29
reprint when jam
5.20
resolution
5.18
toner cartridge
cleaning sheet
6.5, 7.6
install
2.3
life expectancy
6.1
recycle
6.1
redistribute toner
6.2
save toner
5.6, 6.1
storage
6.1
Toner Save button
3.2. 5.6
top output tray
4.4
transparency, print
4.15
troubleshooting
see problem, solving
tray 1
see paper tray
U
uninstall, driver
2.16
unpacking
2.1
USB cable
setup in windows
2.17
setup in macintosh
B.2
W
watermark, print
5.21
WIN RCP
see remote control panel
IV
INDEX
Home
