iP Dock
iPhooneo\iPod Dock
o Projector
Important Safety Instruction
CLASS 1 LED PRODUCT
Eye Safety Warnings
Avoid staring/facing directly into
the projector beam at all times.
Keep your back to the beam as
much as possible.
A stick or laser pointer is
recommended to avoid the need
for the user to enter the beam.
When projector is used in a
classroom, adequately supervise
students when they are asked to
point out something on the screen.
In order to minimize power, use
room blinds to reduce ambient
light levels.
1.Do not block any ventilation openings.
To ensure reliable operation of the
projector and to protect from over
heating, it is recommended to install
the projector in a location that does not
block ventilation. As an example, do not
place the projector on a crowded coffee
table, sofa, bed, etc. Do not put the
projector in an enclosure such as a book
case or a cabinet that restricts air flow.
2.Do not use the projector near water or
moisture. To reduce the risk of fire and/
or electric shock, do not expose the
projector to rain or moisture.
3.Do not install near heat sources such as
radiators, heaters, stoves or any other
apparatus such as amplifiers that emits
heat.
4.Do not use the projector in direct
sunlight.
5.Do not use near any appliance
generating a strong magnetic field.
6.Do not use the projector in areas
susceptible to excessive dust and dirt.
7.Turn off the product before cleaning.
8.Ensure that the ambient room
temperature is within 5- 35°C.
9.Relative Humidity is 5 - 35°C, 80%
(Max.), non-condensing.
10.Do not drop, throw or try to bend your
product.
11.May explode if disposed of in fire.
12.Clean only with dry cloth.
13.Only use attachments/accessories
specified by the manufacturer.
14.Do not use the unit if it has been
physically damaged or abused. Physical
damage/abuse would be (but not
limited to):
▀■Unit has been dropped.
▀■Charger or plug has been damaged.
▀■Liquid has been spilled on to the
projector.
▀■Projector has been exposed to rain or
moisture.
Regulation & safety notices
This appendix lists the general notices of
your Projector.
FCC notice
This device has been tested and found
to comply with the limits for a Class B
digital device pursuant to Part 15 of the
FCC rules. These limits are designed to
provide reasonable protection against
harmful interference in a residential
installation. This device generates, uses,
and can radiate radio frequency energy
and, if not installed and used in accordance
with the instructions, may cause harmful
interference to radio communications.
However, there is no guarantee that
interference will not occur in a particular
installation. If this device does cause
harmful interference to radio or television
reception, which can be determined by
turning the device off and on, the user is
encouraged to try to correct the interference
by one or more of the following measures:
• Reorient or relocate the receiving
antenna.
• Increase the separation between the
device and receiver.
• Connect the device into an outlet on
a circuit different from that to which
the receiver is connected.
• Consult the dealer or an experienced
radio/television technician for help.
2
Notice: Shielded cables
All connections to other computing
devices must be made using shielded
cables to maintain compliance with
FCC regulations.
Caution
Changes or modifications not
expressly approved by the
manufacturer could void the
user’s authority, which is granted
by the Federal Communications
Commission, to operate this device.
Operation conditions
This device complies with Part 15 of the
FCC Rules. Operation is subject to the
following two conditions:
1. this device may not cause harmful
interference, and
2. this device must accept any
interference received, including
interference that may cause
undesired operation.
Notice: Canadian users
This Class B digital apparatus complies with Canadian
ICES-003.
Remarque à l’intention des utilisateurs canadiens
Cet appareil numerique de la classe B est conforme a la
norme NMB-003 du Canada.
Declaration of Conformity for EU countries
• EMC Directive 2004/108/EC (including
amendments)
• Low Voltage Directive 2006/95/EC
• R & TTE Directive 1999/5/EC (if product has
RF function)
▀■Something has fallen in the projector
or something is loose inside.
Do not attempt to service the unit
yourself. Opening or removing covers
may expose you to dangerous voltages
or other hazards. Please contact your
local reseller or service center before you
send the unit for repair.
15.Do not let objects or liquids enter the
projector. They may touch dangerous
voltage points and short out parts that
could result in fire or electric shock.
16.See projector enclosure for safety related
markings.
17.The unit should only be repaired by
appropriate service personnel.
18.Do not touch the projector for a long
time while the projector is used.
Disposal of old
Electrical &
Electronic Equipment
(Applicable throughout the European
Union and other European countries
with separate collection programs)
This symbol found on your product or on
its packaging, indicates that this product
should not be treated as household
waste when you wish to dispose of it.
Instead, it should be handed over to an
applicable collection point for the recycling
of electrical and electronic equipment.
By ensuring this product is disposed of
correctly, you will help prevent potential
negative consequences to the environment
and human health, which could otherwise
be caused by inappropriate disposal of this
product. The recycling of materials will
help to conserve natural resources.
This symbol is only
valid in the European
Union.
If you wish to discard
this product, please
contact your local
authorities or dealer
and ask for the correct
method of disposal.
Product Overview
1
1. Lens
2. iPod/iPhone Docking Station
3. Source Button
4. Rewind Button
5. Play/Pause Button
6.Fast Forward Button
7. Enter Button
8. Down Button
9. Up Button
10.Menu Button
11.Power Button
12.VGA Input Connector
13.HDMI Connector
14.AV Input Connector
15.Audio Out Connector
16.DC Input
17.IR Receiver
2
3
VGA
11
12
AV in
13 14 15 16
6
5
6
7
7
3
10
Power On
8c
1
9
10
Source
Menu
9
17
2
2
8
Audio out DC in
Package Overview
1
4
out
AV in Audio
3
DC in
VGA
Info.
i.Menu
8a
Enter
Repeat
1. Connect the power cord to the
power adapter. ()
2. Plug the power cord into an
electrical outlet. ()
3. Connect the power adapter to the
DC Input of the projector. ()
4. During the standby mode, projector
can be powered on by pressing
the power button on the remote or
the projector. By plugging the iPod/
iPhone can also automatically turn
on the projector ()
Shuffle
11
4
4
8b
out
AV in Audio
DC in
VGA
5
Standard Accessory
1. Power adaptor
2. Power cord
3. Remote control
4. AV composite cable
5. iPod Universal dock
<Note>
The standard accessories may vary in each
region due to different applications.
Optional Accessory
6. VGA to VGA cable
7. AV composite cable
8. iPad Connection Kit
a. USB Cable for iPad
Connector
b. iPad Cable
c. iPad Connector
9. VGA to component
adapter
10.HDMI to HDMI cable
11. Nokia cable
3
Connect Input source - iPod/iPhone
out
AV in Audio
Connect Input source - Video in
1. Turn on your projector.
2. Plug your iPod/iPhone into the
docking station.
• iPod/iPhone will take priority and
take over other signal input when
other sources are being displayed.
3. U
se the keypad or remote control to
control the music playback.
DC in
VGA
or
out
AV in Audio
1. Connect the AV input source.
(~)
2. After powering on the projector,
press "Source Button" to switch
source.
3. Connect earphones or amplified
external speakers to the audio out
connector of the projector ()
DC in
VGA
1
2
<Note>
It is designed to be compatible with all
series of iPod, iPhone 2G/3G, iPhone 3GS,
iPhone 4 and iPad (WWi and MFi certified)
or
out
AV in Audio
DC in
1
VGA
<Note>
1. All other brand and product names are
trademarks or registered trademarks of
their respective companies.
2. The connecting cable of video output
device is not supplied, please contact
their service center.
3. It is designed to be compatible with all
series of iPod, iPhone 2G/3G, iPhone
3GS, iPhone 4 and iPad (WWi and MFi
certified).
2
out
AV in Audio
DC in
VGA
or
out
AV in Audio
DC in
or
out
AV in Audio
1
VGA
VGA
DC in
3
2
Connect Input source - VGA/Component in
out
AV in Audio
CONNECT INPUT SOURCE
1. Connect the VGA/Component
source device with its respective
connector.
2. After powering on the projector,
press "Source Button" to switch
source.
DC in
VGA
1
2
or
out
AV in Audio
DC in
VGA
1
2
4
<Note>
VGA cable, Component cable and HDMI
cable are optional accessories.
Connect Input source - HDMI
out
AV in Audio
CONNECT HDMI SOURCE
1. Connect the HDMI source device to
the HDMI connector. (~)
2. After powering on the projector,
press "Source Button" to switch
source.
DC in
VGA
1
2
Adjusting the Projected Image
Projection Distance (A)
Screen Size Width (B)
Media Playback Control Operation
Use the keypad or remote control to control the music or video playback.
Screen Size Height (C)
Screen Diagonal (D)
Meter
Feet
(mm)
(inch)
(mm)
(inch)
(mm)
(inch)
0.20
0.66
110
4.3
62.7
2.5
127
5
0.40
1.64
221
8.7
125.4
4.9
254
10
0.60
3.28
331
13.0
188.1
7.4
381
15
0.80
4.92
448
17.4
250.8
9.9
508
20
2.40
6.56
1325
52.2
752.3
29.6
1524
60
4.80
8.20
2651
104.4
1504.5
59.2
3048
120
Button
Rewind
Short press: Previous
Long press: Backward (Rewind)
Short press: Next
Long press: Forward
Fast Forward
Enter
1
Play/Pause (MP3 or Video)
DC in
VGA
1. Adjust Focus () until image is
clear.
MP3/Video Playback: Play/
Pause
Enter
Enter
Down
OSD menu On: Down
Up
OSD menu On: Up
Menu
Display/hide the OSD menu
Power
out
AV in Audio
Remote Control
Switch source
Play/Pause
B
Keypad
Source
Power on/off
Mute
-
Info.
-
Mute
Display metadata
Repeat
-
Toggle Repeat option to on/off
Shuffle
-
Toggle Shuffle option to on/off
Volume +
-
Increase volume level
Volume -
-
Decrease volume level
i.Menu
-
Switch function on iPod or iPod
mode on iPhone
How to use the menu
Main menu
Item
1. Press ( ) to display the OSD main
menu.
•• Press it again to hide the OSD
menu.
•• If there projector is left idle for 15
seconds, the LED and OSD menu
will be turned off.
2. Highlight the desired option (
)
)
3. Enter the desired option. (
4. Highlight the desired item. (
)
5. Select and confirm the selected item.
(
)
6. Press ( ) to exit the current menu.
5
How to use the menu - Source: HDMI, Composite AV (AV IN), VGA
Input signal source
Display OSD menu
Picture Menu
Picture Menu
Image Mode: Select image mode
(Bright, Cinema, Photo).
Color Mode: Select color mode
(Standard, Extended).
Contrast: Set the contrast level.
Aspect Ratio: Select aspect ratio (4:3,
16:9, Auto).
Signal: Select signal mode (H-Position,
V-Position, Clock, Phase).
Picture Menu (VGA source)
Music Menu
Music Menu
EQ: Select equalizer mode (Standard,
Deep Bass, Treble, Surround, Rock,
Jazz, Classic).
Mute: Toggle mute option to on/off.
Volume: Adjust the volume level.
System Menu
System Menu
Languages: Set the OSD language.
Projection: Select projection mode
(Front Desktop, Rear Desktop).
6
How to use the menu - Source: iPod/iPhone
Display OSD menu
Picture Menu
Picture Menu
Image Mode: Select image mode
(Bright, Cinema, Photo).
Color Mode: Select color mode
(Standard, Extended).
Music Menu
Contrast: Set the contrast level.
Aspect Ratio: Select aspect ratio (4:3,
16:9, Auto).
Music Menu
EQ: Select equalizer mode (Standard,
Deep Bass, Treble, Surround, Rock,
Jazz, Classic).
Mute: Toggle mute option to on/off.
System Menu
Volume: Adjust the volume level.
Shuffle: Toggle shuffle option to on/off.
Repeat: Toggle repeat option to on/off.
Info.: Toggle information option to on/
off.
System Menu
Languages: Set the OSD language.
Projection: Select projection mode
(Front Desktop, Rear Desktop).
Troubleshooting
If you experience a problem with your projector, please refer to the following
information. If a problem persists, please contact your local reseller or service center.
Image Problems
No image appears on-screen
• Ensure the cables/charger/battery are correctly and securely connected.
• Ensure the pins of connectors are not crooked or broken.
• Make sure the projector is switched on.
Image is out of focus
• Adjust the Focus Dial.
• Make sure the projection screen is between the required distance 9.6 to 126.6
inches (0.245 to 3.215 meters) from the projector. See page 5.
Image is too small or too large
• Move the projector closer to or further from the screen.
Image is reversed
• Select “Source --> System --> Projection” from the OSD and adjust the
projection direction.
Compatibility Mode
Timing Table
Mode
VGA
Composite*
Component
HDMI
Resolution
V-Sync (Hz)
640x480
60
800x600
60
1024x768
60
1280x720
60
1280x800
60
480i* / 480P
60
576i* / 576P
50
720P
50 / 60
1080i
50 / 60
Audio Problems
No sound
• Press the Volume + button. (See page 5)
7
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
