Samsung 211MP, 241MP User's manual

Samsung 211MP, 241MP User's manual
SyncMaster 211MP
SyncMaster 241MP
(For NTSC systems)
TFT-LCD TV/Monitor
ELECTRONICS
Owner’s
Instructions
BN68-00169C-03
For Better Display
1. Adjust computer resolution and screen injection rate (refresh rate) in the control panel of computer as described
below to enjoy the best picture quality.
• Resolution :
21” - 1600 x 1200
24” - 1920 x 1200
• Vertical frequency (refresh rate) : 60 Hz
2 This TFT LCD panel was manufactured by using advanced precision semiconductor technology. Still, different color
pixels may be seen. This is normal and not a defect.
• For example, the number of TFT LCD pixels that is contained in this product are 5,760,000 (21”), 6,912,000 (24”).
3. When you clean the outside of the monitor and panel, use a soft cloth with a small amount of cleaner.
Do not use excessive force as it can cause stains.
4. If you are not satisfied with the quality of picture, you can get better quality of picture by executing “auto
adjustment function” in display screen that is appeared as window termination button is pressed. If there's still
noise after automatic adjustment, use FINE/COARSE adjustment function.
Information in this document is subject to change without notice.
© 2002 Samsung Electronics Co., Ltd. All rights reserved.
Reproduction in any manner whatsoever without the written permission of Samsung Electronics Co., Ltd. is strictly
forbidden.
Samsung Electronics Co., Ltd. shall not be liable for errors contained herein or for incidental or consequential
damages in connection with the furnishing, performance, or use of this material.
The Samsung logo is the registered trademark of Samsung Electronics Co., Ltd.; Microsoft, Windows® and
Windows® NT are registered trademark of Microsoft Corporation; VESA, DPMS and DDC are registered trademarks
of Video Electronics Standard Association. All other product names mentioned herein may be the trademarks or
registered trademarks of their respective owners.
2
Thank You for Choosing Samsung
Thank you for choosing Samsung! Your new Samsung LCD TV/Monitor represents the latest in LCD TV/Monitor
technology. We designed it with easy-to-use on-screen menus and closed captioning capabilities, making it one of the
best products in its class. We are proud to offer you a product that will provide convenient, dependable service and
enjoyment for years to come.
Warning! Important Safety Instructions
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO PREVENT ELECTRICAL SHOCK, DO NOT
REMOVE REAR COVER, NO USER SERVICEABLE PARTS
INSIDE. REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.
WARNING:
The lightning flash and arrow head
within the triangle is a warning sign
alerting you of “dangerous voltage”
inside the product.
The exclamation point within the
triangle is a warning sign alerting
you of important instructions
accompanying the product.
TO PREVENT DAMAGE WHICH MAY RESULT IN FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE.
Note to CATV system installer: This reminder is provided to call CATV system installer’s attention to Article
820-40 of the National Electrical Code (Section 54 of Canadian Electrical
Code, Part I), that provides guidelines for proper grounding and, in
particular, specifies that the cable ground shall be connected to the
grounding system of the building as close to the point of cable entry as
practical.
Caution: FCC/CSA regulations state that any unauthorized changes or modifications to this equipment may
void the user’s authority to operate it.
Caution: To prevent electric shock, match the wide blade of plug to the wide slot, and fully insert the plug.
Attention: Pour eviter les chocs electriques, introduire la lame le plus large de la fiche dans la borne
correspondante de la prise et pousser jusqu’au fond.
Important: One Federal Court has held that unauthorized recording of copyrighted TV programs is an
infringement of U.S. copyright laws. Certain Canadian programs may also be copyrighted and any
unauthorized recording in whole or in part may be in violation of these rights.
3
Warning! Important Safety Information
Always be careful when using your LCD TV/Monitor. To reduce the risk of fire, electrical shock, and other injuries,
keep these safety precautions in mind when installing, using, and maintaining your machine.
◆ Read all safety and operating instructions before operating your LCD TV/Monitor.
◆ Keep the safety and operating instructions for future reference.
◆ Heed all warnings on the LCD TV/Monitor and in the operating instructions.
◆ Follow all operating and use instructions.
◆ Unplug the LCD TV/Monitor from the wall outlet before cleaning. Use a damp cloth; do not use liquid or
aerosol cleaners.
◆ Never add any attachments and/or equipment without approval of the manufacturer. Such additions can
increase the risk of fire, electric shock, or other personal injury.
◆ Do not use the LCD TV/Monitor where contact with or immersion in water is a possibility, such as near bath
tubs, sinks, washing machines, swimming pools, etc.
◆ Do not place the LCD TV/Monitor on an unstable cart, stand, tripod, bracket,
or table where it can fall. A falling LCD TV/Monitor can cause serious injury
to a child or adult, and serious damage to the appliance. Use only with a
cart, stand, tripod, bracket, or table recommended by the manufacturer or
sold with the LCD TV/Monitor. Follow the manufacturer’s instructions when
mounting the unit, and use a mounting accessory recommended by the
manufacturer. Move the LCD TV/Monitor and cart with care. Quick stops,
excessive force, and uneven surfaces can make the unit and cart unsteady
and likely to overturn.
◆ Provide ventilation for the LCD TV/Monitor. The unit is designed with slots in the cabinet for ventilation to
protect it from overheating. Do not block these openings with any object, and do not place the LCD TV/Monitor
on a bed, sofa, rug, or other similar surface. Do not place it near a radiator or heat register. If you place the
LCD TV/Monitor on a rack or bookcase, ensure that there is adequate ventilation and that you’ve followed the
manufacturer’s instructions for mounting.
◆ Operate your LCD TV/Monitor only from the type of power source indicated on the marking label. If you are
not sure of the type of power supplied to your home, consult your appliance dealer or local power company.
◆ Use only a grounded or polarized outlet. For your safety, this LCD TV/Monitor is equipped with a polarized
alternating current line plug having one blade wider than the other. This plug will fit into the power outlet only
one way. If you are unable to insert the plug fully into the outlet, try reversing the plug. If the plug still does not
fit, contact your electrician to replace your outlet.
◆ Protect the power cord. Power supply cords should be routed so that they won’t be walked on or pinched by
objects placed on or against them. Pay particular attention to cords at plugs, convenience receptacles, and the
point where they exit from the unit.
◆ Unplug the LCD TV/Monitor from the wall outlet and disconnect the antenna or cable system during a lightning
storm or when left unattended and unused for long periods of time. This will prevent damage to the unit due to
lightning and power-line surges.
◆ Avoid overhead power lines. An outside antenna system should not be placed in the vicinity of overhead power
lines or other electric light or power circuits or where it can fall into such power lines or circuits. When
installing an outside antenna system, be extremely careful to keep from touching the power lines or circuits.
Contact with such lines can be fatal.
4
Warning! Important Safety Information
◆ Do not overload the wall outlet or extension cords. Overloading can result in fire or electric shock.
◆ Do not insert anything through the openings in the unit, where they can touch dangerous voltage points or
damage parts. Never spill liquid of any kind on the LCD TV/Monitor.
◆ Ground outdoor antennas. If an outside antenna
or cable system is connected to the LCD
TV/Monitor, be sure the antenna or cable system
is grounded so as to provide some protection
against voltage surges and built-up static charges.
Section 810 of the National Electrical Code,
ANSI/NFPA No.70-1984, provides information
about proper grounding of the mast and
supporting structure, grounding of the lead-in wire
to an antenna discharge unit, size of grounding
conductors, location of antenna discharge unit,
connection to grounding electrodes, and
requirements for the grounding electrode.
EXAMPLE OF ANTENNA GROUNDING
ANTENNA
LEAD IN WIRE
GROUND CLAMP
ELECTRIC
SERVICE
EQUIPMENT
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
GROUNDING
CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)
NEC NATIONAL ELECTRICAL CODE
◆ Do not attempt to service the LCD TV/Monitor
yourself. Refer all servicing to qualified service
personnel. Unplug the unit from the wall outlet and refer servicing to qualified service personnel under the
following conditions:
- when the power-supply cord or plug is damaged
- if liquid has been spilled on the unit or if objects have fallen into the unit
- if the LCD TV/Monitor has been exposed to rain or water
- if the LCD TV/Monitor does not operate normally by following the operating instructions
- if the LCD TV/Monitor has been dropped or the cabinet has been damaged
- when the LCD TV/Monitor exhibits a distinct change in performance
◆ If you make adjustments yourself, adjust only those controls that are covered by the operating instructions.
Adjusting other controls may result in damage and will often require extensive work by a qualified technician to
restore the LCD TV/Monitor to normal.
◆ When replacement parts are required, be sure the service technician uses replacement parts specified by the
manufacturer or those that have the same characteristics as the original part. Unauthorized substitutions may
result in additional damage to the unit.
◆ Upon completion of any service or repairs to this LCD TV/Monitor, ask the service technician to perform safety
checks to determine that the LCD TV/Monitor is in a safe operating condition.
◆ Keep all power adaptors apart.
Possible fire hazard.
◆ Keep the power adaptor away from any other heater.
Possible fire hazard.
◆ Remove and discard the plastic cover from the power adaptor before use.
Possible fire hazard.
◆ Always keep the power adaptor in a well-ventilated area.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference that may cause undesired operation.
This LCD TV/Monitor provides display of television closed captioning in accordance with §15.119 of the
FCC rules.
5
Contents
6
For Better Display............................................................................................................................................
2
Warning! Important Safety Information ......................................................................................................
3
Unpacking Your LCD TV/Monitor..................................................................................................................
7
Inserting the Batteries in the Remote Control ............................................................................................
7
Setting up Your LCD TV/Monitor
Setting up an Ergonomic Workstation ..................................................................................................
LCD TV/Monitor location ........................................................................................................................
Workstation height ..................................................................................................................................
Viewing angle ............................................................................................................................................
Plug and Play ............................................................................................................................................
Installing the Monitor Driver ..................................................................................................................
Self-Test Feature Check (STFC)..............................................................................................................
Getting Help ..............................................................................................................................................
Warm-up Time ..........................................................................................................................................
Connecting Your LCD TV/Monitor ..........................................................................................................
15 Pin D-sub connector ..........................................................................................................................
8
8
8
8
8
8
9
9
9
10
12
Viewing Your LCD TV/Monitor
Front Controls ............................................................................................................................................
Remote Control..........................................................................................................................................
13
14
Adjusting Your LCD TV/Monitor
Automatic Save ........................................................................................................................................
Accessing the Menu System..................................................................................................................
Changing your Language ........................................................................................................................
Setting the Channel ..................................................................................................................................
Setting the Picture....................................................................................................................................
Setting the Sound ....................................................................................................................................
Viewing the Picture In Picture (PIP)......................................................................................................
Viewing the Picture By Picture (PBP) ..................................................................................................
Viewing Closed Captions ........................................................................................................................
Viewing the V-Chip ..................................................................................................................................
PC Functions and Adjustments ..............................................................................................................
Setting the Sleep Timer ..........................................................................................................................
Switching the Sound Off Temporarily ..................................................................................................
Viewing pictures from External Sources..............................................................................................
Displaying information ............................................................................................................................
PC Display Modes ....................................................................................................................................
PowerSaver ..............................................................................................................................................
15
15
15
16
18
19
20
21
22
23
25
28
28
28
28
29
29
Troubleshooting
Image ..........................................................................................................................................................
Audio & TV ................................................................................................................................................
30
31
Technical and Environmental Specifications............................................................................................
32
Regulatory Information ..................................................................................................................................
33
Unpacking Your LCD TV/Monitor
Please make sure the following items are included with your LCD TV/Monitor. If any items are missing, contact your dealer.
Power Cord
(BH39-10339X)
Warranty Card
(Not available in all locations)
LCD TV/Monitor & Speakers
Owner’s Instructions
Power
SOURCE
AUTO
DISPLAY
P.STD
STILL
S.STD
DC Adapter
(BN44-00051D)
CH
VOL
MENU
VOL
CH
MUTE
Hexagonal wrench
(BN80-00001A)
EXIT
1
2
4
5
7
8
+100
0
3
6
9
PRE-CH
SLEEP
ASPECT
V.DOLBY
MTS
PBP
LOCATE
V.CHIP
CAPTION
ADD/ERASE CH.SCAN
SIZE
PC Stereo Cable
(BH39-00120A)
PIP
ON
Installation CD
(BH59-00179A)
Remote Control (BN59-00226A) &
Batteries (AAA x 2) (4301-000121)
15-pin D-Sub Signal Cable
(BN39-00115A)
Inserting the Batteries in the Remote Control
1
Remove the cover on the rear of the remote control by pressing the
downwards and then pulling firmly to remove it as shown in
the figure.
2
Insert two R03, UM4, “AAA” 1.5V or equivalent batteries, taking care
to respect the polarities:
◆ + on the battery against + on the remote control
◆ - on the battery against - on the remote control
3
Replace the cover by aligning it with the base of the remote control
and pressing it back into place.
➣
Do not mix battery types, i.e. alkaline and manganese.
7
Setting up Your LCD TV/Monitor
Setting up an Ergonomic
Workstation
Consider the advice given below before you install
your LCD TV/Monitor.
LCD TV/Monitor location
Choose a position that exposes your LCD TV/Monitor
to the least reflection from lights or windows, usually
at a right angle to any window.
Plug and Play
The adoption of the new VESA® Plug and Play
solution eliminates complicated and time consuming
setup. It allows you to install your LCD TV/Monitor in
a Plug and Play compatible system without the usual
hassles and confusion. Your PC system can easily
identify and configure itself for use with your display.
This LCD TV/Monitor automatically tells the PC
system its Extended Display Identification Data
(EDID), using Display Data Channel (DDC) protocols,
so the PC system can automatically configure itself
to use the flat panel display. If your PC system needs
a monitor driver, follow the instructions given below
according to the operating system your computer
uses.
Workstation height
Place your LCD TV/Monitor so that the top of the
screen is slightly below your eye level when
you are comfortably seated.
Viewing angle
Tilt the screen until you feel comfortable working
with your LCD TV/Monitor.
➣
8
The maximum tilt angle is 15 degrees in the
backward direction. Please do not tilt the LCD
TV/Monitor beyond the specified range.
Tilting the LCD TV/Monitor beyond the
specified range may cause permanent
damage to the mechanical part of the stand.
Installing the Monitor Driver
The CD that accompanies this product contains the
necessary drivers for installing your LCD TV/Monitor.
Please refer to the driver installation instructions
included with your CD package for more information.
Setting up Your LCD TV/Monitor
Self-Test Feature Check (STFC)
Your LCD TV/Monitor provides a self-test feature that
allows you to check whether your LCD TV/Monitor is
functioning properly. Make sure that PC is selected
as a primary source by checking if the source
indicator LED labeled “PC” is on. If your LCD
TV/Monitor and computer are properly connected
but the LCD TV/Monitor screen remains dark and the
power indicator is blinking, run the LCD TV/Monitor
self-test by following the steps:
4
Turn off your LCD TV/Monitor and reconnect the
video cable; then turn on both your computer and
the LCD TV/Monitor.
If your LCD TV/Monitor screen remains blank after
following the previous procedure, check your
video controller and computer system; your LCD
TV/Monitor is functioning properly.
Getting Help
Power Indicator
If your LCD TV/Monitor does not display an image,
check your cable connections and refer to
“Troubleshooting” on page 29. If you experience
difficulties with the quality of the displayed image,
press the Auto button (see page 13).
Warm-up Time
1
Turn off both your computer and the LCD
TV/Monitor.
2
Unplug the video cable from the back of the
computer.
3
Turn on the LCD TV/Monitor.
All LCD TV/Monitor need time to become thermally
stable when turned after being off for a couple of
hours.
Therefore, to achieve more accurate adjustments for
parameters, allow the LCD TV/Monitor to warm up
for at least 20 minutes before making any screen
adjustments.
If the LCD TV/Monitor is functioning properly,
you will see a white box with a large blue oval
Samsung logo and an error message : Check
Signal Cable.
Check Signal Cable
This box also appears during normal operation if
the video cable becomes disconnected or
damaged.
9
Setting up Your LCD TV/Monitor
Connecting Your LCD TV/Monitor
SPK(R)
L
R
S-VIDEO VIDEO AUDIO(L) AUDIO(R)
AUDIO OUT
SPK(L)
AV JACK
7
7
DVD or VCR
8
5
External speakers
6
DC POWER PC AUDIO(ST)
VIDEO DTV Y
Pb
Pr
AUDIO(L) AUDIO(R)
Y
Pb
Pr
AUDIO(L) AUDIO(R) DVD
RF
DVD
4
DTV Set-Top
1
3
PC
2
1. Connecting TV/CATV
Connect an antenna or CATV cable to the antenna terminal.
2. Connecting Computer
- Connect the 15-Pin D-SUB of the video signal cable to the PC video connector.
- Connect the PC stereo audio cable to “Audio (ST)” on the rear of the LCD TV/Monitor and the other end to
“Audio Out” terminal of the sound card on your computer.
- If necessary, please install monitor driver contained on the supplied CD. For driver installation, please refer
“Installing Monitor Driver” section on page 8.
3. Connecting DTV Set-Top Box
- Connect an RCA Cable to “AUDIO(L)” and “AUDIO(R)” on the rear of the LCD TV/Monitor and the other end to
“Audio Out” terminal of the Set-Top Box.
- Connect an RCA Cable to “Y”, “Pb”, and “Pr” on the rear of the LCD TV/Monitor and the other end to “Video Out”
terminal of the Set-Top Box.
continued...
10
Setting up Your LCD TV/Monitor
4. Connecting DVD
- Connect an RCA Cable to “AUDIO(L)” and “AUDIO(R)” on the rear of the LCD TV/Monitor and the other end to
“Audio Out” terminal of the DVD.
- Connect an RCA Cable to “Y”, “Pb”, and “Pr” on the rear of the LCD TV/Monitor and the other end to “Video Out”
terminal of the DVD.
5. Connecting External A/V Devices
- Connect RCA or S-VHS cable to an appropriate external A/V device such as VCR, DVD or Camcorder.
- Connect RCA Audio cables to “AUDIO(L)” and “AUDIO(R)” on the rear of the LCD TV/Monitor and the other ends
to corresponding audio out terminals on the A/V device.
- Headphone may be connected to the headphone output on the rear of the LCD TV/Monitor (”).
While the headphone is connected, the sound from the built-in speakers will be disabled.
6. Connecting External Speakers
Connect RCA Audio cables to the supplied speakers.
7. Connecting Speakers
or
11
Setting up Your LCD TV/Monitor
Wall Installation Instructions
Œ
´
ΠRemoving the TV stand
Using a hexagonal wrench, remove the TV stand.
´ Removing rubbers
Remove the four rubbers from the edges.
ˇ Mounting on the wall
Mount the TV stand on the wall using screws or
nails.
ˇ
¨
¨ Fixing the TV
Using a hexagonal wrench, fix the TV into the TV
stand.
15 Pin D-sub connector
12
Pin
Separate H/V
Composite H/V
Sync-on-green
1
Red
Red
Red
2
Green
Green
Green + H/V Sync
3
Blue
Blue
Blue
4
GND
GND
GND
5
GND (DDC Return)
GND (DDC Return)
GND (DDC Return)
6
GND-Red
GND-Red
GND-Red
7
GND-Green
GND-Green
GND-Green
8
GND-Blue
GND-Blue
GND-Blue
9
No Connection
No Connection
Not used
10
GND-Sync/Self
Test GND-Sync/Self
Test GND-Sync/Self Test
11
GND
GND
GND
12
DDC _SDA
DDC _SDA
DDC _SDA
13
H_Sync
H/V Sync
Not used
14
V_ Sync
Not used
Not used
15
DDC _SCL
DDC _SCL
DDC _SCL
Viewing Your LCD TV/Monitor
Front Controls
Your LCD TV/Monitor allows you to easily adjust the characteristics of the image being displayed. All of these
adjustments are made using the control buttons on the top of the LCD TV/Monitor. While you use these buttons to
adjust the controls, an OSD shows you their numeric values as they change.
1
2
3
4
5
ΠRemote Control Sensor
Aim the remote control towards this spot on the
LCD TV/Monitor.
´ Source
Displays a menu of all of the available input
sources (TV/Video/S-Video/DVD/DTV/PC).
ˇ PIP
Activates PIP (Picture-In-Picture)
6
7
8
9
10
∏ - ▼ CH ▲ +
Moves the selector up or down on the OSD.
Increases or decreases the channel number.
” - œ VOL √ +
Moves the selector left or right on the OSD.
Increases or decreases the level of audio volume
and the values of the selected function.
¨ PBP
Activates PBP (Picture-By-Picture).
’ Auto
Allows the TV to self-adjust to the incoming video
signal. The values of fine, coarse and position are
adjusted automatically. (It works PC mode only.)
ˆ Menu
Opens the OSD and selects the highlighted
function.
˝
(Power)
Turns the LCD TV/Monitor ON/OFF.
Ø Exit
Exit from the on-screen menu.
13
Viewing Your LCD TV/Monitor
Remote Control
Auto aligns monitor PC signal
Power
Power
SOURCE
Available sources selection
(TV/Video/S-Video/DVD/DTV/PC)
AUTO
DISPLAY
STILL
Display the setting information
Picture freeze
P.STD
S.STD
Picture effect selection
Sound effect selection
Next channel
Menu display and
change confirmation
CH
VOL
MENU
VOL
Volume decrease
Volume increase
CH
Previous channel
MUTE
EXIT
Temporary sound switch-off
Numeric buttons for
direct channel access
Exit from the OSD
1
2
3
4
5
6
7
8
9
PRE-CH
Three-digit channel selection
+100
0
Previous channel
SLEEP
V.DOLBY
Virtual Dolby menu display
Automatic switch-off
Picture size selection
Multichannel Television Stereo
Picture-By-Picture
(Double screen)
Parental lock
P.SIZE
MTS
PBP
LOCATE
ADD/ERASE CH.SCAN
SIZE
PIP
ON
V.CHIP
CAPTION
Channel scan
Channel add or erase
Picture-In-Picture On/Off
PIP size selection
PIP location
Caption decoder control
➣
14
◆ The channel up/down and volume up/down buttons are used to select the menu option and change
these values.
Adjusting Your LCD TV/Monitor
Automatic Save
Whenever you open the OSD and allow an adjustment window to remain active for about 3 seconds without pressing
other buttons, the LCD TV/Monitor automatically saves any adjustment you have made. These changes are saved into
a user area in the LCD TV/Monitor. The LCD TV/Monitor can save adjustments for up to 4 user modes. It has 13 for
211MP (15 for 241MP) factory preset or preload modes, one for each signal frequency as listed in table on page 29.
If you have made no adjustments, the OSD disappears and the LCD TV/Monitor does not save anything.
Accessing the Menu System
1
Press the MENU button to display the main OSD menu.
2
Use the †/…/œ/œ buttons to move from one function to another. As you move from one icon to another, the
function name changes to reflect the function or group of functions represented by that icon.
3
Press the MENU button once to activate the highlighted function, then follow the Tool Tips to select the function
and adjust the value.
4
Use the †/… buttons to select the sub-menu, and press the MENU button once to activate the selected submenu.
5
After selecting a function, use the œ / √ buttons to make necessary adjustments. The setting bar moves and the
numeric value indicator changes to reflect your adjustments.
6
Press the EXIT button a couple of times to return to the main menu to select another function or to exit from the
OSD.
Changing your Language
Main Menu
Sub-Menus
Function Descriptions
Function
Sleep Timer
PIP
PBP
Caption
V-Chip
Language
Move
¨
¨
¨
¨
Ã
Select
Ã
Off
English
¨
When you start using your LCD TV/Monitor for the first
time, you must select the language which will be used
for displaying menus and indications.
¨
Select a particular language by pressing the - or +
button. The following languages are available: English,
Spanish, Français, Português.
Exit
15
Adjusting Your LCD TV/Monitor
Setting the Channel
Main Menu
Sub-Menus
Function Descriptions
Channel
Ant/CATV
Auto Program
Fine Tune
Add/Erase
:
LNA
:
Move
➣
Select
Ã
¨
Ã
Ant
00
Erased
Off
¨
¨
Channel auto program does not work when the V-Chip function is active.
Channel
Select
Ã
¨
Ã
Ant
00
Erased
Off
Adjust
Ã
¨
Ã
Ant
00
Erased
Off
Your LCD TV/Monitor can memorize and store all of the
available channels found automatically for both “offair” (antenna) and cable channels.
Press the - or + button, and then begin memorizing all
of the available channels with the horizontal bar is
displayed.
¨
¨
Fine tuning Channel Reception
¨
¨
Skipping Unwanted Channels
Channel
➣
Memorizing the Channels Automatically
If the reception is clear, you do not have to fine-tune
the channel, as this is done automatically during the
memorize and store operation.
If however the signal is weak or distorted, you may
have to fine-tune the channel.
Exit
Ant/CATV
Auto Program
Fine Tune
Add/Erase
:
LNA
:
Move
¨
¨
Exit
Channel
Ant/CATV
Auto Program
Fine Tune
Add/Erase
:
LNA
:
Move
Before begin memorizing the available channels,
you must specify the type of signal source that is
connected to the your LCD TV/Monitor.
Press the - or + button to select Ant (antenna) or CATV
(cable system).
Exit
Ant/CATV
Auto Program
Fine Tune
Add/Erase
:
LNA
:
Move
Selecting the Video Signal Source
Select
Ã
¨
Ã
Ant
00
Erased
Off
You can exclude the channels of your choice from the
channel scan operation. when you scan through the
stored channels, those you have chosen to skip are not
displayed. All channels that you do not specifically
choose to skip are displayed during scanning.
Exit
You can do easily by pressing the ADD/ERASE button on the remote control.
continued...
16
Adjusting Your LCD TV/Monitor
Setting the Channel
Main Menu
Sub-Menus
Function Descriptions
Channel
Ant/CATV
Auto Program
Fine Tune
Add/Erase
:
LNA
:
Move
Adjust
Ã
¨
Ã
Ant
00
Erased
On
¨
¨
Exit
Using the LNA (Low Noise Amplifier) function
This function is very useful in the situation that your
LCD TV/Monitor is used in weak signal. LNA amplifies
the TV signal in the weak signal area, but not noise.
This function is working automatically only weak signal
condition, and that is memorized on current channel,
additional.
Scanning the Available Channels
You can view all of the available channels and then store them in memory by simply
pressing the CH.SCAN button on the remote control.
Press the CH.SCAN button, and then the memorized channels will appear in sequence.
To stop the scanning, press the CH.SCAN button again.
17
Adjusting Your LCD TV/Monitor
Setting the Picture
Main Menu
Sub-Menus
Ã
Mode
Brightness
Contrast
Sharpness
Color
Tint
Size
Ã
Move
➣
Select
Ã
Select
Ã
Custom
Wide
Ã
Select
¨
¨
Exit
Mode
Brightness
Contrast
Sharpness
Color
Tint
Size
➣
¨
Using Automatic Picture Settings
You can select the picture effect which best
corresponds to your viewing requirements by pressing
the - or + button repeatedly. The following picture
effects are available: Custom, Standard, Natural, Mild.
Exit
Ã
Move
Wide
¨
You can select the picture effect directly by pressing the P.STD (Picture
Standard) button on the remote control.
Mode
Brightness
Contrast
Sharpness
Color
Tint
Size
Move
Custom
Function Descriptions
Custom
Wide
¨
¨
Customizing the Picture
Your LCD TV/Monitor has several setting which allow
you to control picture quality: Brightness, Contrast,
Sharpness, Color, Tint.
Select the required option by pressing the œ or √
button. Then press the - or + button to adjust the value
of selected option.
Changing the Picture Format
You can select the picture format which best
corresponds to your viewing requirements by pressing
the - or + button repeatedly. The following picture
formats are available: Wide, Normal 1, Normal 2,
Zoom 1, Zoom 2.
Exit
You can select the picture format directly by pressing the P.SIZE (Picture Size)
button on the remote control.
Freezing the Current Picture
Press the STILL button on the remote control to freeze the picture on a given frame.
To return to normal viewing, press the STILL button again.
18
Adjusting Your LCD TV/Monitor
Setting the Sound
Main Menu
Sub-Menus
Mode
Bass
Treble
Dolby
Speaker
MTS
Move
➣
:
:
Off
Off
Mono
¨
¨
Using Automatic Picture Settings
You can select the type of special sound effect to be
used when watching a given broadcast by pressing the
- or + button repeatedly. The following sound effects
are available: Custom, Standard, Music, Movie,
Speech.
Exit
Ã
Ã
Sound
Custom
:
:
Off
Off
Mono
Select
Ã
Ã
Ã
Ã
Sound
Custom
:
:
Ã
Ã
¨
Customizing the Sound
The sound settings can be adjusted to suit your
personal preferences: Bass, Treble.
Select the required option by pressing the † or …
button. Then press the - or + button to adjust the value
of selected option.
On
Off
Mono
¨
Enjoying Dolby Sound
¨
Exit
Sound
Custom
:
:
Select
Mode
Bass
Treble
Dolby
Speaker
MTS
¨
Exit
Select
Mode
Bass
Treble
Dolby
Speaker
MTS
Move
Custom
You can select the sound effect directly by pressing the S.STD (Sound
Standard) button on the remote control.
Mode
Bass
Treble
Dolby
Speaker
MTS
Move
Ã
Sound
Select
Mode
Bass
Treble
Dolby
Speaker
MTS
Move
Ã
Function Descriptions
On
On
Mono
¨
Switching the Internal Speakers On/Off
When the internal speakers are switched off, all the
sound is routed to the external speakers.
¨
Exit
Sound
Custom
:
:
On
On
Mono
¨
¨
Choosing the MTS (Multichannel Television Stereo)
Depending on the particular program being broadcast,
you can listen to Stereo, Mono, or Dual I/I I(Dual I/II is
usually a foreign-language translation).
➣
Move
Select
Exit
You can change the sound system directly by
pressing the MTS button on the remote control.
Switching the Sound Off Temporarily
You can switch the sound off temporarily. For example, you may wish to answer the telephone.
Press the MUTE button and then, the sound is switched off and “ ” is displayed. When you
wish to turn the sound back on, press the MUTE button again or either of the volume buttons.
19
Adjusting Your LCD TV/Monitor
Viewing the Picture In Picture (PIP)
Main Menu
Sub-Menus
Function Descriptions
Function
Sleep Timer
PIP
PBP
Caption
V-Chip
Language
Move
¨
¨
¨
¨
Ã
Ã
Off
English
Select
¨
¨
Exit
Function
PIP
TV/Video
Size
Position
Move
➣
:
Ã
Ã
¨
Select
On
TV
Large
¨
¨
:
Ã
Ã
¨
Select
On
TV
Large
¨
¨
¨
¨
You can select a size of the sub picture by pressing the
- or + button. The sizes are displayed in the following
order: Large, Small, Medium.
Exit
:
Ã
Ã
¨
Select
On
TV
Large
➣
Select
You can select a size of the sub picture by
pressing the SIZE button repeatedly on the remote
control.
Exit
Function
PIP
TV/Video
Size
Position
20
You can do directly by pressing the PIP button on
the remote control.
You can select a source of the sub picture by pressing
the - or + button. The sources are displayed in the
following order: TV, Video, S-Video, DVD, DTV.
Function
PIP
TV/Video
Size
Position
Move
➣
Exit
Function
Move
To activate the PIP function, set the PIP to On by
pressing the - or + button.
The PIP function does not work when the V-Chip is active.
PIP
TV/Video
Size
Position
Move
When external A/V devices such as VCR, DVD or
RF(TV) cable are connected to the LCD TV/Monitor, PIP
(Picture-In-Picture) allows you to watch video from
such devices in a small window superimposed on pc
video signal. (It works PC mode only.)
:
Ã
Ã
¨
On
TV
Large
¨
¨
You can select a position of the sub picture. Move the
sub picture counterclockwise by pressing the - or +
button.
➣
Exit
You can select a position of the sub picture by
repeatedly pressing the LOCATE button on the
remote control.
Adjusting Your LCD TV/Monitor
Viewing the Picture By Picture (PBP)
Main Menu
Sub-Menus
Function Descriptions
Function
Sleep Timer
PIP
PBP
Caption
V-Chip
Language
Move
¨
¨
¨
¨
Ã
Ã
Off
English
Select
¨
¨
Exit
Function
PBP
TV/Video
Swap
Move
:
Ã
¨
Select
On
TV
¨
➣
Function
:
Ã
¨
Select
On
TV
¨
Move
Select
You can do directly by pressing the PBP button on
the remote control.
You can select a source to your viewing requirement by
pressing the - or + button. The sources are displayed
in the following order: TV, Video, S-Video, DVD, DTV.
Exit
Function
PBP
TV/Video
Swap
To activate the PBP function, set the PBP to On by
pressing the - or + button.
Exit
PBP
TV/Video
Swap
Move
PBP (Picture-By-Picture) allows you to watch double
screen.
:
Ã
¨
On
TV
¨
You can interchange the main picture and the sub
picture by pressing the - or + button.
➣
You can do by repeatedly pressing the PBP button
on the remote control.
Exit
21
Adjusting Your LCD TV/Monitor
Viewing Closed Captions
Main Menu
Sub-Menus
Function Descriptions
Function
Sleep Timer
PIP
PBP
Caption
V-Chip
Language
Move
¨
¨
¨
¨
Ã
Ã
English
Select
➣
¨
Off
¨
Exit
The Caption feature does not work with DVD or DTV signals.
Function
Caption
Mode
Channel
Field
Move
➣
Ã
:
On
Caption
1
1
¨
à ¨
à ¨
Select
To activate the Caption function, set the Caption to On
by pressing the - or + button.
➣
You can do directly by pressing the CAPTION
button on the remote control.
Exit
Misspellings and unusual characters sometimes occur during closed caption
transmissions, especially those of live events. There may be a small delay
before captions appear when you change channels. These are not malfunctions
of your LCD TV/Monitor.
Function
Caption
Mode
Channel
Field
Move
Your LCD TV/Monitor decodes and displays the closed
captions that are broadcast with certain TV shows.
These captions are usually subtitles for the hearing
impaired or foreign-language translations. All VCRs
record the closed caption signal from television
programs, so home-recorded video tapes also provide
closed captions. Most pre-recorded commercial video
tapes provide closed captions as well. Check for the
closed caption symbol in your television schedule and
on the tape’s packaging:
.
Ã
:
Select
On
Caption
1
1
¨
à ¨
à ¨
In Caption mode, captions appear at the bottom of the
screen, and they usually cover only a small portion of
the picture.
In Text mode, information unrelated to the program,
such as news or weather, is displayed. Text often
covers a large portion of the screen.
Exit
Function
Caption
Mode
Channel
Field
Move
Ã
Select
:
On
Caption
1
1
¨
à ¨
à ¨
Exit
Function
Caption
Mode
Channel
Field
Move
Ã
Select
:
On
Caption
1
1
¨
à ¨
à ¨
Exit
Depending on the particular broadcast, it might be necessary to make changes to
Channel and Field. Different channels and fields display different information.
22
Adjusting Your LCD TV/Monitor
Using the V-Chip
Main Menu
Sub-Menus
Function Descriptions
Function
Sleep Timer
PIP
PBP
Caption
V-Chip
Language
Move
➣
¨
¨
¨
¨
Ã
Select
Ã
Off
English
¨
¨
The V-Chip function automatically locks out
programming that is deemed inappropriate for children.
The user must first enter a PIN (Personal ID Number)
before any of the V-Chip restrictions can be set up or
changed.
Exit
When the V-Chip function is active, the PIP and channel auto program functions
does not work.
Function
V-Chip
Enter Pin
_
Enter your 4-digit PIN number.
The default PIN number is 0000.
If you enter an incorrect pin number, Incorrect
message will be displayed for 3 seconds.
➣
O~9Select
Exit
Function
V-Chip Lock
:
TV GuideLines
MPAA Rating
Change Pin
Move
Select
¨
¨
¨
No
Function
Select
Use the numeric buttons enter a new pin number.
Confirm New Pin appears. Again, use the numeric
buttons to enter the pin number you entered at the
previous step. If the two pin numbers do not match,
Incorrect message will be displayed for 3 seconds.
Exit
V-Chip Lock
:
TV GuideLines
MPAA Rating
Change Pin
Move
You can do directly by pressing the V.CHIP button
on the remote control.
¨
¨
¨
Yes
To activate the V-Chip function, set the V-Chip Lock to
Yes by pressing the - or + button.
➣ If you forget the PIN, press the remote-control keys
in the following sequence, which resets the pin to
0-0-0-0: Power Off ➡ Mute ➡ 8 ➡ 2 ➡ 4 ➡ Power
On.
Exit
continued...
V-Chip (US only)
The Telecommunications Act of 1996 in USA requires that every television made, starting in 1998, must be equipped with
the technological device named V-Chip. The V-Chip can block certain rated television shows off television (if chosen) so
children cannot watch programs that their parents do not approve. With this device, program-rating information will be
transmitted along with the television signal, and be decoded by the chip in each television.
The chip will then compare the rating codes to values preset by the viewer, which is meant to be the parents. If the
rating codes are higher than the preset values, the television signal will be blocked, and a blank screen will be displayed.
23
Adjusting Your LCD TV/Monitor
Using the V-Chip
Main Menu
Sub-Menus
Function Descriptions
Function
V-Chip Lock
:
TV GuideLines
MPAA Rating
Change Pin
Move
Select
¨
¨
¨
The restrictions for these two groups work
independently: If a household includes very young
children as well as young adults, the TV guidelines
must be set up separately for each age group.
Exit
Function
ALL FV V S L D
U
TV-Y
TV-Y7
U
U
TV-G
U
TV-PG
U
U U U U
TV-14
U
U U U U
TV-MA
U
U U U
B:Blocked U:Unblocked
¨
¨
¨
¨
¨
¨
Move
Select
Setup Restrictions Using the “TV GuideLines”
Yes
Exit
These categories consist of two separate groups:
TV-Y and TV-Y7 (young children through age 7),
and TV-G through TV-MA (everybody else).
The V-Chip will automatically block certain categories
that are “more restrictive.” For example, if you block
“TV-Y” category, then TV-Y7 will automatically be
blocked. Similarly, if you block the TV-G category, then
all the categories in the “young adult” group will be
blocked (TV-G, TV-PG, TV-14 and TV-MA).
The sub-ratings (V, S, L, D) work together similarly.
TV-Y : Young Children
TV-Y7 : Children 7 and over
TV-G : General Audience
TV-PG : Parent Guidance
TV-14 : Viewers 14 and over
TV-MA : Mature Audience
Function
V-Chip Lock
:
TV GuideLines
MPAA Rating
Change Pin
Move
G
PG
PG-13
R
NC-17
X
NR
Move
24
Select
¨
¨
¨
¨
¨
¨
¨
¨
¨
¨
Setup Restrictions Using the “MPAA Rating”
Yes
Exit
Function
B/U
U
U
U
U
U
U B:Blocked
U:Unblocked
U
Select
FV : Fantasy Violence
V : Violence
S : Sexual Situation
L : Coarse Language
D : Suggestive Dialog
Exit
The MPAA rating system uses the MPAA (Motion
Picture Association of America) system, and its main
application is for movies. (Eventually, movie
videocassettes will be encoded with MPAA ratings.)
When the V-Chip lock is on, the TV will automatically
block any programs that are coded with objectionable
ratings (either MPAA or TV-Ratings).
The V-Chip will automatically block any category that
is “more restrictive.” For example, if you block the
“PG-13” category, then “R,” “NC-17,” and “X” will
automatically be blocked also.
G : General Guidance
PG : Parental Guidance Suggested
PG-13 : Parents Strongly Cautioned
R : Restricted Under 17 Requires
NC-17 : No Children Under 17 Admitted
X : Adult Only
NR : Not Rated
Adjusting Your LCD TV/Monitor
PC functions and adjustments - Image
Main Menu
Sub-Menus
Function Descriptions
PC
¨
¨
¨
¨
¨
Image Lock
Position
Color Adjust
Recall
1024x768
48kHz
Move
Select
59Hz
Exit
Use the œ / √ buttons to adjust the brightness or
contrast without affecting PC RGB’s brightness or
contrast.
PC
Brightness
Contrast
Size
Expanded 1
Ã
Move
¨
Select
œ
Exit
Brightness
PC
Brightness
Contrast
Expanded 1
Size
Ã
Move
Select
¨
√
œ
Contrast
√
You can select a image size by pressing the - or +
button. The sizes are displayed in the following order:
Expanded 1, Expanded 2, Normal.
➣
You can select a image size by pressing the P.SIZE
(Picture Size) button repeatedly on the remote
control.
Exit
25
Adjusting Your LCD TV/Monitor
PC functions and adjustments - Image Lock & Position
Main Menu
Sub-Menus
Function Descriptions
PC
Image Lock is used to fine tune and get the best image
by removing noises that create unstable images with
jitters and shimmers.
¨
¨
¨
¨
¨
Image Lock
Position
Color Adjust
Recall
1024x768
48kHz
Move
Select
This function may change the width of the image.
Use the H-Position menu to center the image on the
screen.
59Hz
Exit
The Coarse and Fine adjustments allow you to fine tune
the image quality of your LCD TV/Monitor to your
preference. Use the œ / √ buttons to remove any
noise.
If satisfactory results are not obtained using the Fine
adjustment, use the Coarse adjustment and then use
Fine again.
PC
Image Lock
Coarse
Fine
Move
Select
Exit
When Coarse value is wrong.
When Fine value is wrong.
PC
¨
¨
¨
¨
¨
Image Lock
Position
Color Adjust
Recall
1024x768
48kHz
Move
Select
59Hz
Exit
Use the œ / √ buttons to adjust the positions
(Horizontal/Vertical).
PC
Position
H-Position
V-Position
Move
Select
œ
26
➣
Exit
H-Position
√
œ
V-Position
The AUTO button allows to self-adjust to the incoming video signal.
The values of fine, coarse and position are adjusted automatically.
√
Adjusting Your LCD TV/Monitor
PC functions and adjustments - Color Adjust & Recall
Main Menu
Sub-Menus
Function Descriptions
PC
Image Lock is used to fine tune and get the best image
by removing noises that create unstable images with
jitters and shimmers.
¨
¨
¨
¨
¨
Image Lock
Position
Color Adjust
Recall
1024x768
48kHz
Move
Select
Move
PC
¨
Custom
Ã
Select
Exit
PC
Custom
¨
Exit
PC
All Image settings are replaced with the factory default
values.
¨
¨
¨
¨
¨
Select
Customizing the Color
Select the required option (Red, Green, Blue) by
pressing the † or π button. Then press the - or +
button to adjust the value of selected option.
Image Lock
Position
Color Adjust
Recall
1024x768
48kHz
Move
Using Automatic Color Settings
You can select a color mode which best corresponds to
your viewing requirements by pressing the - or +
button repeatedly. The following color modes are
available: Custom, Color 1, Color 2, Color 3.
Select
Color Mode
Red
Green
Blue
Move
Exit
Ã
Color Mode
Red
Green
Blue
This function may change the width of the image.
Use the H-Position menu to center the image on the
screen.
59Hz
59Hz
Exit
27
Adjusting Your LCD TV/Monitor
Setting the Sleep Timer
Main Menu
Sub-Menus
Function Descriptions
Function
Sleep Timer
PIP
PBP
Caption
V-Chip
Language
Move
➣
¨
¨
¨
¨
Ã
Select
Ã
Off
English
¨
You can select a time period of between 10 and 240
minutes after which your LCD TV/Monitor automatically
switches off.
¨
The preset time intervals: 10, 20, 30, 60, 90, 120, 150, 180,
210, and 240 minutes.
Exit
Using the “SLEEP” button
Press the SLEEP button on the remote control.
If the sleep timer is already set, the screen displays time remaining before your LCD
TV/Monitor will be switched off. If the sleep timer is not yet set, displays Off.
You can select the preset time intervals by pressing SLEEP button repeatedly.
Switching the Sound Off Temporarily
You can switch the sound off temporarily. For example, you may wish to answer the telephone.
Press the MUTE button and then, the sound is switched off and “
” is displayed.
When you wish to turn the sound back on, press the MUTE button again or either of the volume buttons.
Viewing Pictures from External Sources
Once you have connected up your various audio and video systems, you can view the different sources by selecting the
appropriate input.
Check that all the necessary connections have been made. Press the SOURCE button one or more times until the
required input is displayed. Depending on the source selected, the pictures may appear automatically.
Displaying information
Ant
You can view the setting status of selected source by pressing the
DISPLAY button on the remote control. The displayed information are
different depending on the selected source.
Picture Mode
Sound Mode
MTS
Signal
Caption
4
:
:
:
:
:
Standard
Speech
Stereo
Stereo
On
• Example: TV mode
28
Adjusting Your LCD TV/Monitor
PC Display Modes
If the signal from the system equals the standard signal mode(1024 x 768), the screen is adjusted automatically. If the
signal from the system doesn’t equal the standard signal mode, adjust the mode by referring to your Video card user
guide as video may not be displayed, with just the Power LED blinking. For the display modes listed below, the screen
image has been optimized during manufacture.
Mode
Resolution
Horizontal
Frequency (kHz)
Vertical
Frequency (Hz)
Pixel Clock
Frequency (MHz)
Sync Polarity
(H/V)
HDTV Format
1280 x 720p
1920 x 1080i
44.955
33.716
59.94
59.94i
74.176
74.176
+/-,+/+/-,+/-
VGA
720 x 400
640 x 480
640 x 480
640 x 480
31.469
31.469
37.500
43.269
70.087
59.940
75.000
85.008
28.322
25.175
31.500
36.000
-/+
-/-/-/-
SVGA
800 x 600
800 x 600
46.875
53.674
75.000
85.061
49.500
56.250
+/+
+/+
XGA
1024 x 768
1024 x 768
1024 x 768
48.363
60.023
68.677
60.004
75.029
84.997
65.000
78.750
94.500
-/+/+
+/+
SXGA
1280 x 1024
1280 x 1024
63.981
79.976
60.020
75.025
108.000
135.000
+,-/+,+/+
UXGA
1600 x 1200
75.000
60.000
162.000
+/-,+/-
WUXGA
(241MP)
1920 x 1200
75.000
60.000
193.156
+/-,+/-
PowerSaver
This LCD TV/Monitor has a built-in power management system called PowerSaver. This system saves energy by switching
your LCD TV/Monitor into a low-power mode when it has not been used for a certain period of time. The available modes
are “On”, “Standby”, “Sleep”, and “Deep Sleep”. PowerSaver operates with a VESA DPMS compliant video card installed
in your computer. You use a software utility installed on your computer to set up this feature.
State
Normal Operation
Power-Saving Function mode (EPA/NUTEK)
Horizontal Sync
Active
Inactive
Vertical Sync
Active
Inactive
Power Indicator
Green
Green, Blinking (1 sec interval)
211MP : 110W (Max.)
241MP : 120W (Max.)
Less than 8W
Power Consumption
➣
This LCD TV/Monitor automatically returns to normal operation when horizontal and vertical sync return.
This occurs when you move the computer’s mouse or press a key on the keyboard.
This LCD TV/Monitor is EPA ENERGY STAR® compliant and NUTEK compliant when used with a computer
equipped with VESA DPMS functionality. For energy conservation, turn your LCD TV/Monitor Off when
you are not using it or when leaving it unattended for long periods.
29
Troubleshooting - Image
If you have a problem setting up or using your LCD TV/Monitor, you may be able to solve it yourself. Before contacting
customer service, try the suggested actions that are appropriate to your problem.
What you see...
Suggested Actions
Screen is black and
power indicator is off
◆ Ensure that the power cord is firmly connected and the LCD
TV is on.
“Check Signal Cable” message
◆ Ensure that the signal cable is firmly connected to the PC or
video sources.
◆ Ensure that the PC or video sources are turned on.
“Sync. Out of Range” message
◆ Check the maximum resolution and the frequency of the video
adapter.
◆ Compare these values with the data in the Display Modes
Timing Chart.
The image is too light or too dark
◆ Adjust the Brightness and Contrast.
Horizontal bars appear to flicker,
jitter or shimmer on the image
◆ Adjust the Fine function.
Vertical bars appear to flicker,
jitter or shimmer on the image.
◆ Adjust the Coarse function and then adjust the Fine function.
Screen is black and power indicator
light is steady amber or blinks
every 0.5 or 1 seconds
◆ The LCD TV/Monitor is using its power management system.
◆ Move the computer’s mouse or press a key on the keyboard.
Image is not stable and may appear
to vibrate
◆ Check that the display resolution and frequency from your PC
or video board is an available mode for your LCD TV/Monitor.
On your computer check: Control Panel, Display, Settings.
◆ If the setting is not correct, use your computer utility program
to change the display settings.
➣
30
Your LCD TV/Monitor supports multiscan display
functions within the following frequency domain:
Horizontal frequency: 30~85kHz
Vertical frequency: 55~85Hz
Image is not centered on the screen.
◆ Adjust the horizontal and vertical position.
You need the monitor driver software
◆ Download the driver from WWW pages:
http://www.samsung-monitor.com
http://www.samsungmonitor.com (USA Only)
Troubleshooting - Audio & TV
Problem
Suggested Actions
No sound
◆ Ensure that the audio cable is firmly connected to both the
audio-in port on your LCD TV/Monitor and the audio-out port
on your sound card.
◆ Check the volume level.
Sound level is too low
◆ Check the volume level.
◆ If the volume is still too low after turning the control to its
maximum, check the volume control on the computer sound
card or software program.
Sound is too high pitched or
too low pitched
◆ Adjust the Treble and Bass to appropriate level.
TV signal is not received
◆ Select “Channel auto program” to configure the channel
system automatically.
◆ Check “TV Tuner Box”.
31
Technical and Environmental Specifications
Model
211MP
241MP
Panel
Size
Display Size
Type
Pixel pitch
Viewing Angle
21.3” Diagonal
24.06” Diagonal
432(H) x 324(V) mm
518.4(H) x 324(V) mm
a-si TFT active matrix
0.27 (H) x 0.27 (V) mm
80/80/80/80 (L/R/T/B)
Frequency
Horizontal
Vertical
Display color
30 ~ 85 kHz
55 ~ 85 Hz
16,777,216 colors
Display Resolution
Maximum Mode
1600 x 1200 @ 60 Hz
Input Signal
Sync.
H/V Separate, TTL, P. or N.
H/V Composite, TTL, P. or N.
Sync-on-green 0.3 Vp-p, N.
0.7 Vp-p @ 75 ohm
Video signal
TV, Video
Color system
Sound system
Video format
NTSC
M/N
CVBS, S-VHS
Component
DTV
DVD
Video signal
YPbPr Composite sync. 1080i, 720p, 480p
YPbPr Composite sync. 480p, 480i
0.7 Vp-p @ 75 ohm
Color system
NTSC
Power Supply
Input
Output
AC 90 ~ 264 Vrms (50Hz / 60Hz)
DC 14V/8A
Power Consumption
Maximum
Power Saving
Dimensions (W X D X H)
Monitor body
With stand
Environmental Considerations
Operating Temperature
Operating Humidity
Storage Temperature
Storage Humidity
Audio Characteristics
Audio Input 1
Audio Input 2
Audio Input 3
Headphone out
Frequency
Response
32
1920 x 1200 @ 60 Hz
110 W
120 W
<8W
531.5 x 67.5 x 422 mm
578.7 x 218.2 x 472 mm
618 x 67.5 x 422 mm
665.2 x 218.2 x 472 mm
50 °F to 104 °F (10 °C to 40 °C)
10% to 80%
- 13 °F to 113 °F (-25 °C to 45 °C)
5% to 95%
RCA Jack Red(R) White(L), 0.5Vrms (-9dB)
3.5Ø Stereo Jack, 0.5Vrms (-9dB)
RCA Jack Red(R) White(L), 0.5Vrms (-9dB)
Max. 10mW Output (3.5Ø Stereo Jack 32Ω)
RF: 80Hz ~ 15kHz (at- 3dB)
A/V: 80Hz ~ 20kHz (at - 3dB)
Regulatory Information
User Instructions
The Federal Communications Commission Radio
Frequency Interference Statement includes the following
warning:
Note: This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is
no guarantee that interference will not occur in a
particular installation.
If this equipment does cause harmful interference to
radio or television receptions, which can be determined
by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or
more of the following measures:
◆ Reorient or relocate the receiving antenna.
◆ Increase the separation between the equipment and
receiver.
◆ Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
◆ Consult the dealer or an experienced radio/TV
technician for help.
User Information
Changes or modifications not expressly approved by the
party responsible for compliance could void the user’s
authority to operate the equipment.
If necessary, consult your dealer or an experienced
radio/television technician for additional suggestions.
You may find the booklet called How to Identify and
Resolve Radio/TV Interference Problems helpful. This
booklet was prepared by the Federal Communications
Commission. It is available from the U.S. Government
Printing Office, Washington, DC 20402, Stock Number
004-000-00345-4.
The party responsible for product compliance:
SAMSUNG ELECTRONICS CO., LTD
America QA Lab of Samsung
85 West Tasman Drive
San Jose, CA 95134 USA
Tel) 408-544-5124
Fax) 408-544-5191
Provided with this monitor is a detachable power supply
cord with IEC320 style terminations. It may be suitable
for connection to any UL Listed personal computer with
similar configuration. Before making the connection,
make sure the voltage rating of the computer
convenience outlet is the same as the monitor and that
the ampere rating of the computer convenience outlet is
equal to or exceeds the monitor voltage rating.
For 120 Volt applications, use only UL Listed detachable
power cord with NEMA configuration 5-15P type (parallel
blades) plug cap. For 240 Volt applications use only UL
Listed Detachable power supply cord with NEMA
configuration 6-15P type (tandem blades) plug cap.
IC Compliance Notice
This Class B digital apparatus meets all requirements of
the Canadian Interference-Causing Equipment
Regulations of ICES-003.
Notice de Conformité IC
Cet appareil Numérique de classe B respecte toutes les
exigences du Règlemont ICES-003 sur les équipements
produisant des interférences au Canada.
MPR II Compliance
This monitor complies with SWEDAC(MPR II)
recommendations for reduced electric and magnetic fields.
Warning
User must use shielded signal interface cables to
maintain FCC compliance for the product.
Declaration of conformity for products
Marked with FCC Logo
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired
operation.
33
Regulatory Information
U.S.A.
MEXICO
Samsung Computer Products Customer Service
400 Valley Road, Suite 201, Mt. Arlington, NJ 07856
Tel. : (973)601-6000, 1-800-SAMSUNG (1-800-726-7864)
Fax. : (973)601-6001
http://samsungmonitor.com/
Samsung Electronics Mexico S.A. de C.V.
Saturno 44 Col. Nueva Industrial Vallejo
Del. Gustavo A. Madero C.P. 07700
Mexico D.F.
Tel. 01 57 47 51 00
Fax. 01 57 47 52 02
RFC: SEM950215S98
http://www.samsung.com.mx/
BRAZIL
Samsung Eletronica da Amazonia Ltda.
R. Prof. Manoelito de Ornellas, 303, Terro B
Chacara Sto. Antonio, CEP : 04719-040
Sao Paulo, SP
SAC : 0800 124 421
http://www.samsung.com.br/
CANADA
Samsung Electronics Canada Inc.
7037 Financial Drive
Mississauga, Ontario L5N 6R3
Tel. : 1-800-SAMSUNG (1-800-726-7864)
Fax. : (905) 542-1199
http://www.samsung.ca
COLOMBIA
Samsung Electrinics Colombia
Cra 9 No 99A-02 Of. 106
Bogota, Colombia
Tel.: 9-800-112-112
Fax: (571) 618 - 2068
http://www.samsung-latin.com/
e-mail : [email protected]
34
PANAMA
Samsung Electronics Latinoamerica (Z.L.) S.A.
Calle 50 Edificio Plaza Credicorp, Planta Baja
Panama
Tel. : (507) 210-1122, 210-1133
Tel : 800-3278(FAST)
http://www.samsung-latin.com/
PERU
Servicio Integral Samsung
Av.Argentina 1790 Lima1. Peru
Tel: 51-1-336-8686
Fax: 51-1-336-8551
http://www.samsungperu.com
IMPORTADO POR: SAMSUNG ELECTRONICS MEXICO S.A. DE C.V.
SATURNO 44 COL. NVA. INDUSTRIAL VALLEJO
DEL. GUSTAVO A. MADERO C.P. 07700
MEXICO D.F.
TEL. 5747-5100
RFC: SEM950215S98
EXPORTADO POR: SAMSUNG ELECTRONICS CO.,LTD.
JOONG-ANG DAILY NEWS BLDG.
7 SOON-WHA-DONG CHUNG-KU,
C.P.O BOX 2775, 1144 SEOUL, KOREA
Memo
35
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
