C

ONTENTS

1. Introduction

Special features ...................................................................................................................................................... 1.1

Printer overview ...................................................................................................................................................... 1.3

Finding more information ........................................................................................................................................ 1.4

Selecting a location ................................................................................................................................................. 1.5

2. System setup

Using control panel menus ...................................................................................................................................... 2.1

Menu overview ........................................................................................................................................................ 2.2

Printing a demo page .............................................................................................................................................. 2.8

Changing the display language ............................................................................................................................... 2.8

Using toner save mode ........................................................................................................................................... 2.8

Changing the font setting ........................................................................................................................................ 2.8

3. Software overview

Supplied software .................................................................................................................................................... 3.1

Printer driver features .............................................................................................................................................. 3.2

System requirements .............................................................................................................................................. 3.2

4. Network setup

Introduction ............................................................................................................................................................. 4.1

Supported operating systems ................................................................................................................................. 4.2

Configuring TCP/IP ................................................................................................................................................. 4.2

Configuring EtherTalk ............................................................................................................................................. 4.2

Configuring IPX frame types ................................................................................................................................... 4.3

Setting Ethernet speed ............................................................................................................................................ 4.3

Restoring the network configuration ........................................................................................................................ 4.3

Printing a network configuration page ..................................................................................................................... 4.3

5. Loading print media

Selecting print media ............................................................................................................................................... 5.1

Loading paper ......................................................................................................................................................... 5.4

Selecting an output location .................................................................................................................................... 5.8

6. Basic printing

Printing a document ................................................................................................................................................ 6.1

Canceling a print job ............................................................................................................................................... 6.1

7. Ordering supplies and accessories

Toner cartridges ...................................................................................................................................................... 7.1

Accessories ............................................................................................................................................................. 7.1

How to purchase ..................................................................................................................................................... 7.1

8. Maintenance

Printing information pages ...................................................................................................................................... 8.1

Cleaning the printer ................................................................................................................................................. 8.1

Maintaining the toner cartridge ................................................................................................................................ 8.3

Maintenance parts ................................................................................................................................................... 8.7

9. Troubleshooting

Clearing paper jams ................................................................................................................................................ 9.1

Troubleshooting checklist ........................................................................................................................................ 9.5

Understanding the status LED ................................................................................................................................ 9.6

Understanding display messages ........................................................................................................................... 9.6

Toner cartridge-related messages .......................................................................................................................... 9.8

Solving general printing problems ........................................................................................................................... 9.9

Solving print quality problems ............................................................................................................................... 9.11

Common Windows problems ................................................................................................................................ 9.13

Common PostScript problems .............................................................................................................................. 9.13

Common Linux problems ...................................................................................................................................... 9.14

Common Macintosh problems .............................................................................................................................. 9.14

10. Installing accessories

Precautions when installing accessories ............................................................................................................... 10.1

Installing a dual in-line memory module (DIMM) ................................................................................................... 10.1

Installing a network interface card ......................................................................................................................... 10.3

Using the hard disk ............................................................................................................................................... 10.4

11. Specifications

Printer specifications ............................................................................................................................................. 11.1

Important Precautions and Safety Information

When using this machine, these basic safety precautions should always be followed to reduce risk of fire, electric shock, and injury to people:

1 Read and understand all instructions.

2 Use common sense whenever operating electrical appliances.

3 Follow all warnings and instructions marked on the machine and in the literature accompanying the machine.

4 If an operating instruction appears to conflict with safety information, heed the safety information. You may have misunderstood the operating instruction. If you cannot resolve the conflict, contact your sales or service representative for assistance.

5 Unplug the machine from the AC wall socket before cleaning. Do not use liquid or aerosol cleaners. Use only a damp cloth for cleaning.

6 Do not place the machine on an unstable cart, stand or table. It may fall, causing serious damage.

7 Your machine should never be placed on, near or over a radiator, heater, air conditioner or ventilation duct.

8 Do not allow anything to rest on the power cable. Do not locate your machine where the cords will be abused by persons walking on them.

9 Do not overload wall outlets and extension cords. This can diminish performance, and may result in the risk of fire or electric shock.

10 Do not allow pets to chew on the AC power or PC interface cords.

11 Never push objects of any kind into the machine through case or cabinet openings. They may touch dangerous voltage points, creating a risk of fire or shock. Never spill liquid of any kind onto or into the machine.

12 To reduce the risk of electric shock, do not disassemble the machine. Take it to a qualified service technician when repair work is required. Opening or removing covers may expose you to dangerous voltages or other risks. Incorrect reassembly could cause electric shock when the unit is subsequently used.

13 Unplug the machine from the PC and AC wall outlet, and refer servicing to qualified service personnel under the following conditions:

• When any part of the power cord, plug, or connecting cable is damaged or frayed.

• If liquid has been spilled into the machine.

• If the machine has been exposed to rain or water.

• If the machine does not operate properly after instructions have been followed.

• If the machine has been dropped, or the cabinet appears damaged.

• If the machine exhibits a sudden and distinct change in performance.

14 Adjust only those controls covered by the operating instructions. Improper adjustment of other controls may result in damage, and may require extensive work by a qualified service technician to restore the machine to normal operation.

15 Avoid using this machine during a lightning storm. There may be a remote risk of electric shock from lightning. If possible, unplug the AC power for the duration of the lightning storm.

16 If you continuously print multiple pages, the surface of the output tray may become hot. Be careful not to touch the surface, and keep children away from the surface.

17 The Power cord supplied with your machine should be used for safe operation. If you are using a cord which is longer than 2 m with 110 V machine, then it should be 16 AWG

1

or bigger.

18 SAVE THESE INSTRUCTIONS.

Environmental and Safety Consideration

Laser Safety Statement

The printer is certified in the U.S. to conform to the requirements of DHHS 21 CFR, chapter 1 Subchapter J for Class I(1) laser products, and elsewhere, is certified as a

Class I laser product conforming to the requirements of IEC 825.

Class I laser products are not considered to be hazardous. The laser system and printer are designed so there is never any human access to laser radiation above a Class I level during normal operation, user maintenance, or prescribed service condition.

W

ARNING

Never operate or service the printer with the protective cover removed from Laser/

Scanner assembly. The reflected beam, although invisible, can damage your eyes.

When using this product, these basic safety precautions should always be followed to reduce risk of fire, electric shock, and injury to persons:

Ozone Safety

During normal operation, this machine produces ozone. The ozone produced does not present a hazard to the operator. However, it is advisable that the machine be operated in a well ventilated area.

If you need additional information about ozone, please contact your nearest Samsung dealer.

1 AWG: American Wire Gauge

i

Power Saver

This printer contains advanced energy conservation technology that reduces power consumption when it is not in active use.

When the printer does not receive data for an extended period of time, power consumption is automatically lowered.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

C

AUTION

:

Changes or modifications not expressly approved by the manufacturer responsible for compliance could void the user’s authority to operate the equipment.

Recycling

Please recycle or dispose of packaging materials for this product in an environmentally responsible manner.

Canadian Radio Interference Regulations

This digital apparatus does not exceed the Class A limits for radio noise emissions from digital apparatus as set out in the interference-causing equipment standard entitled

“Digital Apparatus”, ICES-003 of the Industry and Science Canada.

Cet appareil numérique respecte les limites de bruits radioélectriques applicables aux appareils numériques de Classe A prescrites dans la norme sur le matériel brouilleur:

“Appareils Numériques”, ICES-003 édictée par l’Industrie et Sciences Canada.

Correct Disposal of This Product (Waste Electrical &

Electronic Equipment)

(Applicable in the European Union and other European countries with separate collection systems)

This marking shown on the product or its literature, indicates that it should not be disposed with other household wastes at the end of its working life. To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate this from other types of wastes and recycle it responsibly to promote the sustainable reuse of material resources.

Household users should contact either the retailer where they purchased this product, or their local government office, for details of where and how they can take this item for environmentally safe recycling.

Business users should contact their supplier and check the terms and conditions of the purchase contract. This product should not be mixed with other commercial wastes for disposal.

Declaration of Conformity (European Countries)

Approvals and Certifications

The CE marking applied to this product symbolises Samsung

Electronics Co., Ltd. Declaration of Conformity with the following applicable 93/68/EEC Directives of the European Union as of the dates indicated:

January 1, 1995: Council Directive 73/23/EEC Approximation of the laws of the member states related to low voltage equipment.

January 1, 1996: Council Directive 89/336/EEC (92/31/EEC), approximation of the laws of the Member States related to electromagnetic compatibility.

March 9, 1999: Council Directive 1999/5/EC on radio equipment and telecommunications terminal equipment and the mutual recognition of their conformity.

A full declaration, defining the relevant Directives and referenced standards can be obtained from your Samsung Electronics Co., Ltd. representative.

Radio Frequency Emissions

FCC Regulations

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

• This device may not cause harmful interference, and

• This device must accept any interference received, including interference that may cause undesired operation.

This device has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

ii

Replacing the Fitted Plug (for UK Only)

Important

The mains lead for this machine is fitted with a standard (BS 1363) 13 amp plug and has a 13 amp fuse. When you change or examine the fuse, you must re-fit the correct 13 amp fuse. You then need to replace the fuse cover. If you have lost the fuse cover, do not use the plug until you have another fuse cover.

Please contact the people from you purchased the machine.

The 13 amp plug is the most widely used type in the UK and should be suitable.

However, some buildings (mainly old ones) do not have normal 13 amp plug sockets.

You need to buy a suitable plug adaptor. Do not remove the moulded plug.

Warning

If you cut off the moulded plug, get rid of it straight away.

You cannot rewire the plug and you may receive an electric shock if you plug it into a socket.

I

MPORTANT WARNING

:

You must earth this machine.

The wires in the mains lead have the following color code:

• Green and Yellow: Earth

• Blue: Neutral

• Brown: Live

If the wires in the mains lead do not match the colors marked in your plug, do the following:

You must connect the green and yellow wire to the pin marked by the letter “E” or by the safety ‘Earth symbol’ or colored green and yellow or green.

You must connect the blue wire to the pin which is marked with the letter “N” or colored black.

You must connect the brown wire to the pin which is marked with the letter “L” or colored red.

You must have a 13 amp fuse in the plug, adaptor, or at the distribution board.

iii

OPENSSL LICENSE ORIGINAL SSLEAY LICENSE

Copyright (c) 1998-2001 The OpenSSL Project. All rights reserved.

Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met:

1. Redistributions of source code must retain the above copyright notice, this list of conditions and the following disclaimer.

2. Redistributions in binary form must reproduce the above copyright notice, this list of conditions and the following disclaimer in the documentation and/or other materials provided with the distribution.

3. All advertising materials mentioning features or use of this software must display the following acknowledgment: "This product includes software developed by the OpenSSL Project for use in the OpenSSL Toolkit. (http:// www.openssl.org/)"

4. The names "OpenSSL Toolkit" and "OpenSSL Project" must not be used to endorse or promote products derived from this software without

5. prior written permission. For written permission, please contact [email protected]

6. Products derived from this software may not be called "OpenSSL" nor may

"OpenSSL" appear in their names without prior written permission of the

OpenSSL Project.

7. Redistributions of any form whatsoever must retain the following acknowledgment: "This product includes software developed by the OpenSSL

Project for use in the OpenSSL Toolkit (http://www.openssl.org/)"

THIS SOFTWARE IS PROVIDED BY THE OpenSSL PROJECT ``AS IS'' AND ANY

EXPRESSED OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO,

THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A

PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE OpenSSL

PROJECT OR ITS CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT,

INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES

(INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS

OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS

INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY,

WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING

NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS

SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.

This product includes cryptographic software written by Eric

Young([email protected]). This product includes software written by Tim Hudson

([email protected]).

Copyright (C) 1995-1998 Eric Young ([email protected]) All rights reserved.

This package is an SSL implementation written by Eric Young

([email protected]). The implementation was written so as to conform with

Netscapes SSL.

This library is free for commercial and non-commercial use as long as the following conditions are aheared to. The following conditions apply to all code found in this distribution, be it the RC4, RSA, lhash, DES, etc., code; not just the SSL code. The

SSL documentation included with this distribution is covered by the same copyright terms except that the holder is Tim Hudson ([email protected]).

Copyright remains Eric Young's, and as such any Copyright notices in the code are not to be removed. If this package is used in a product, Eric Young should be given attribution as the author of the parts of the library used. This can be in the form of a textual message at program startup or in documentation (online or textual) provided with the package.

Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met:

1. Redistributions of source code must retain the copyright notice, this list of conditions and the following disclaimer.

2. Redistributions in binary form must reproduce the above copyright notice, this list of conditions and the following disclaimer in the documentation and/or other materials provided with the distribution.

3. All advertising materials mentioning features or use of this software must display the following acknowledgement: "This product includes cryptographic software written by Eric Young ([email protected])" The word 'cryptographic' can be left out if the rouines from the library being used are not cryptographic related:-).

4. If you include any Windows specific code (or a derivative thereof) from the apps directory (application code) you must include an acknowledgement: "This product includes software written by Tim Hudson ([email protected])"

THIS SOFTWARE IS PROVIDED BY ERIC YOUNG ``AS IS'' AND ANY EXPRESS

OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED

WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR

PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE AUTHOR OR

CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL,

SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT

LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF

USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED

AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT

LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN

ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE

POSSIBILITY OF SUCH DAMAGE.

The licence and distribution terms for any publically available version or derivative of this code cannot be changed. i.e. this code cannot simply be copied and put under another distribution licence [including the GNU Public Licence.] iv

1

Introduction

Congratulations on the purchase of your printer!

This chapter includes:

Special features

Printer overview

Finding more information

Selecting a location

Special features

Your new printer is equipped with several special features that improve the print quality. You can:

Print with excellent quality and high speed

• You can print up to 1200 x 1200 dpi effective output. See the Software Section.

• Your printer prints A4-sized paper at up to 43 ppm a and letter-sized paper at up to 45 ppm. For duplex printing, your printer prints A4-sized paper at up to

29 ipm b

and letter-sized paper at up to 30 ipm.

Handle paper flexibly

• The multi-purpose tray supports letterheads, envelopes, labels, transparencies, custom-sized materials, postcards, and heavy paper. The multipurpose tray holds up to 100 sheets of plain paper.

• The 500-sheet standard tray 1 supports plain paper in various sizes.

• The 500-sheet optional tray support plain paper in various sizes. You can install up to 3 additional trays.

• Two output tray; select either the output tray (facedown) or the rear cover (face-up) for the most convenient access.

Straight-through paper path capability from the multi-purpose tray to the rear cover.

Create professional documents

• Print Watermarks. You can customize your documents with words, such as “Confidential.” See the Software Section.

• Print Posters. The text and pictures of each page of your document are magnified and printed across the sheet of paper and can then be taped together to form a poster. See the Software Section.

a. pages per minute b. images per minute

1.1

<Introduction>

Save time and money

1

3

2

4

• This printer allows you to use toner save mode to

save toner. See page 2.8.

• You can print on both sides of the paper to save paper (double-sided printing) if you use the ML-

4551ND or install the optional duplex unit in the

ML-4550 and ML-4551N.

• You can print multiple pages on a single sheet of paper to save paper (N-Up printing). See the

Software Section.

• You can use preprinted forms and letterhead with plain paper. See the Software Section.

• This printer automatically conserves electricity by substantially reducing power consumption when not in use.

Expand the printer capacity

• Your printer has 128 MB of memory which can be

expanded to 512 MB. See page 10.1.

• A Network interface enables network printing.

You can add an optional network interface card to the ML-4550. The ML-4551N and ML-4551ND come with a built-in network interface, 10/100

Base TX.

• You can add 500-sheet optional trays to your printer. These trays let you add paper to the printer less often.

• A PostScript 3 Emulation* (PS) enables PS printing.

* Zoran IPS Emulation compatible with PostScript 3

• © Copyright 1995-2005, Zoran Corporation.

All rights reserved. Zoran, the Zoran logo,

IPS/PS3 and OneImage are trademarks of

Zoran Corporation.

* 136 PS3 fonts

• Contains UFST and MicroType from Monotype Imaging Inc..

Use the optional hard disk

You can install an optional hard disk in your printer.

• The 40 GB hard disk can store the data from your computer in the print queue. This decreases the workload of the computer.

• You can use various print features, such as storing a job in the hard disk, proofing a job, and printing private documents.

• You can manage the print jobs in the print queue of the printer hard disk.

For details, see page 10.4.

Print in various environments

• You can print in Windows 98/Me/NT 4.0/2000/XP/2003.

• Your printer is compatible with Linux and Macintosh.

• Your printer comes with both Parallel and USB interfaces.

• You can also use a network interface. The ML-4551N and ML-

4551ND come with a built-in network interface, 10/100 Base TX.

However, you need to install the optional wired network interface card to the ML-4550.

Printer features

The table below lists a general overview of features supported by your printer.

(I: Installed, O: Option)

Features

IEEE 1284 Parallel

USB 2.0

Network Interface

(Ethernet 10/100 Base TX)

Hard Disk

PostScript* Emulation

Duplex Unit

Optional Tray 2

Optional Tray 3

Optional Tray 4

ML-4550 ML-4551N ML-4551ND

I

I

O I

I

I

I

I

I

O

I

O

O

O

O

O

I

O

O

O

O

I

O

O

I

O

O

1.2

<Introduction>

Front view

Printer overview

Rear view

3

4

1

2

5

6

7 output tray control panel control board cover tray 1 optional tray 2 optional tray 3 optional tray 4

* The figure above shows an ML-4551ND with all available options.

8 handle

9 paper level indicator

10 multi-purpose tray

11 top cover

12 output support

13 multi-purpose tray paper width guides

14 multi-purpose tray extension

1.3

<Introduction>

3

4

1

2 power switch rear cover duplex unit power receptacle

* The figure above shows an ML-4551ND with all available options.

5

6

7 parallel port

USB port network port

Control panel overview

1

2

3

4

5

6

7

8

Menu: Enters Menu mode and scrolls through the available menus.

Scroll buttons: Scroll through the options available in the selected menu, and increase or decrease values.

OK: Confirms the selection on the display.

Back: Sends you back to the upper menu level.

Toner Save: Allows you to save on toner by using less toner in printing.

Demo: Prints a demo page.

Stop: Stops an operation at any time.

Status: Indicates the status of your printer. See page 9.6.

Finding more information

You can find information for setting up and using your printer from the following resources, either printed or onscreen.

Quick Install

Guide

Provides information on setting up your printer and, therefore, be sure to follow the instructions in the guide to get the printer ready.

Online User’s

Guide

Network Printer

User’s Guide

Provides you with step-by-step instructions for using your printer’s full features, and contains information for maintaining your printer, troubleshooting, and installing accessories.

This user’s guide also contains the Software

Section providing you with information on how to print documents with your printer on various operating systems, and how to use the supplied software utilities.

Note

• You can access the user’s guides in other languages from the Manual folder on the printer driver CD.

Contained on the network utilities CD, provides you with information on setting up and connecting your printer to a network.

Printer Driver

Help

Provides you with help information on printer driver properties and instructions for setting up the properties for printing. To access a printer driver help screen, click Help from the printer properties dialog box.

Samsung

Website

If you have Internet access, you can get help, support, printer drivers, manuals, and order information from the Samsung website, www.samsungprinter.com.

1.4

<Introduction>

Selecting a location

Select a level, stable place with adequate space for air circulation. Allow extra space for opening covers and trays.

The area should be well-ventilated and away from direct sunlight or sources of heat, cold, and humidity. Do not set the printer close to the edge of your desk or table.

Clearance space

Front: 482.6 mm (enough space so that trays can be opened or removed)

Back: 320 mm (enough space to allow opening of the rear cover or the duplex unit)

Right: 100 mm (enough space to allow opening of the control board cover)

Left: 100 mm (enough space for ventilation)

1.5

<Introduction>

2

System setup

This chapter shows menus you can set and provides basic settings for your printer.

This chapter includes:

Using control panel menus

Menu overview

Printing a demo page

Changing the display language

Using toner save mode

Changing the font setting

Using control panel menus

A number of menus are available to make it easy for you to change the printer settings. The diagram on the next column shows the menus and all of the menu items available in each menu. The items in each menu and the options you can select are described in more detail in the tables

beginning on page 2.2.

Accessing control panel menus

You can control your printer from the printer’s control panel. You can also set the control panel menus while printing.

1

Press Menu until the menu you want appears on the bottom line of the display and press OK.

2

Press the Scroll buttons until the desired menu item appears and press OK.

3

If the menu item has sub menus, repeat step 2.

4

Press the Scroll buttons to access the desired setting option or the required value.

5

Press OK to save your selection.

An asterisk (*) appears next to the selection on the display, indicating that it is now the default.

6

Press Stop to return to Standby mode.

Note

• Print settings made from the printer driver on a connected computer override the settings on the control panel.

2.1

<System setup>

Menu overview

The control panel menus are used to configure the printer. The control panel provides access to the foling menus.

The menus are listed based on the ML-4550 printer. The menus in the colored characters appear only when the optional items are installed.

0.Job Manage.

a

(See page 10.6.)

Active Job

Store Job

1. Information

(See page 2.2.)

Menu Map

Configuraton

Demo Page

Stored Job

a

Usage Page

a

Completed Job

a

PCL Font List

PS3 Font List

EPSON Font

3. Paper

(See page 2.4.)

Copies

Paper Size

Paper Type

Paper Source

Tray Chaining

2. Layout

(See page 2.3.)

Orientation

Simplex Margin

Duplex

b

Duplex Margin

b

4. Graphic

(See page 2.4.)

Resolution

Darkness

5. System Setup

(See page 2.5.)

Date & Time

a

Form Menu

a

Select Form

a

Language

Power Save

Auto Continue

Altitude Adj.

Auto CR

Job Timeout

Maintenance

Clear Setting

7. Network

c

(See page 2.7.)

TCP/IP

EtherTalk

NetWare

Ethernet Speed

Clear Setting

Network Info

6. Emulation

(See page 2.6.)

Emulation Type

Setup

a. Available with an optional hard disk.

b. Available with an optional duplex unit in the ML-4550 or ML-4551N.

c. Available with an optional network interface card for the ML-4550.

2.2

<System setup>

Note

• The default settings and available values of your printer could be differ from this guide.

Job manager menu

This menu is available when the optional hard disk is installed.

Item

Active Job

Store Job

Explanation

This menu shows the print jobs waiting to be

printed. See page 10.7.

This menu shows the print jobs stored in the

installed hard disk. See page 10.6.

1. Information menu

This menu allows you to print printer information pages that give details about the printer and its configuration.

Item

Menu Map

Configuraton

Demo Page

Stored Job

Usage Page

Completed Job

PCL Font List

PS3 Font List

EPSON Font

Explanation

The menu map shows the layout and current settings of the control panel menu items.

The configuration page shows the printer’s current configuration.

The demo page allows you to check if your printer properly performs printing. See page

2.8.

The stored job page shows the print file list stored in the optional hard disk.

Note

• This menu item is available when the optional hard disk is installed.

The usage page contains the total number of pages printed by person or group. This page can be used for cost accounting.

Note

• This menu item is available when the optional hard disk is installed.

The Completed Job page shows the list of completed print jobs. The list contains up to 50 files from the latest print jobs.

The font sample list shows all of the fonts currently available for the selected language.

2. Layout menu

Use the 2. Layout menu to define all settings relating to output.

Item

Orientation

Explanation

Values: Portrait, Landscape

Choose the default orientation of the print image on the page.

Simplex

Margin

Portrait

Landscape

Values: Top Margin: 0, Left Margin: 0

Set the margin of print meterials for one-sided printing. You can increase or decrease the value in

0.1 mm increments.

Top Margin: Set the top margin, from 0 to 250 mm.

Left Margin: Set the left margin, from 0 to 164 mm.

Item

Duplex

Duplex

Margin

Explanation

Values: Off, Long Edge, Short Edge

To print on both sides of paper, choose the binding edge as follows.

Long Edge

: Flip on the long edge.

Short Edge

: Flip on the short edge.

2

2

3

5

Long Edge in the

Portrait orientation

2

3

5

Long Edge in the

Landscape orientation

2

3

5

3

5

Short Edge in the

Portrait orientation

Short Edge in the

Landscape orientation

Select Off to print on one side of the paper.

Note

• In the ML-4550 and ML-4551N, this menu item is available when the optional duplex unit is installed.

Values: Top Margin/ Left Margin: 5.0,

Short Binding/ Long Binding: 0

In this menu, you can set the margins for doublesided printing. You can increase or decrease the value in 0.1 mm increments.

Top Margin: Set the top margin, from 0.0 to 9.9 mm.

Left Margin: Set the left margin, from 0.0 to 9.9 mm.

Short Binding: Set the bottom margin of the back of the page for short binding, from 0 to 22 mm.

Long Binding: Set the right margin of the back of the page for long binding, from 0 to 22 mm.

Note

• In the ML-4550 and ML-4551N, this menu item is available when the optional duplex unit is installed.

2.3

<System setup>

3. Paper menu

Use the 3. Paper menu to define all settings relating to print meterials such as paper feed and exit, as well as size and type the specific print meterials you are using with your printer.

Item

Copies

Explanation

Values: 1 ~ 999

Set the default number of copies by selecting any number from 1 to 999.

Paper Size

Values: A4, A5, A6, JIS B5, ISO B5, Letter, Legal,

Executive, No.10 Env., Monarch Env., DL Env.,

C5 Env., C6 Env., US Folio, Oficio, Custom Paper

Paper Type

Depending on the paper source or duplex setting, available options vary.

Select the paper size currently loaded in the tray.

Values: Plain Paper, Bond, Transparency,

Envelope, Labels, CardStock, Preprinted,

Color Paper, Thick, Thin

Select the paper type currently loaded in the tray.

Paper

Source

Tray

Chaining

Values: Tray 1, Tray 2, Tray 3, Tray 4, MP Tray,

Manual Tray, Auto

Select which tray you want to use.

• If you select

Auto

, the printer can automatically determine the source.

• Select MP Tray or Manual Tray to use the multipurpose tray. If you select Manual Tray, you need to press OK each time you print a page.

Tray 2, Tray 3, or Tray 4 is available only when the corresponding tray is installed.

Values: Off, On

When you select any other value except Auto from

Paper Source and the selected tray is empty, you can set the printer automatically to print from other trays.

If this menu item is set to Off, the default LED lights red and the printer doesn’t work until you insert paper into the specified tray.

Graphic menu

Use the 4. Graphic menu to change settings affecting the quality of the printed characters and images.

Item

Resolution

Explanation

Values: 600dpi-Normal, 1200dpi-Best

Darkness

Specify the number of dots printed per inch (dpi).

The higher the setting, the sharper printed characters and graphics.

• If your print jobs are mostly text, select

600dpi-

Normal

for the highest quality printing.

• Select

1200dpi-Best

when your job contains bitmapped images, such as scanned photos or some graphics, that will benefit from enhanced line screening.

Values: Normal, Light, Dark

You can lighten or darken the print on the page by changing the toner density setting. The

Normal

setting usually produces the best result. Use the

Light

toner density setting to save toner.

2.4

<System setup>

System Setup menu

Use the 5. System Setup menu to configure a variety of printer features.

Item

Date & Time

Form Menu

Select Form

Explanation

See page 10.6 and 10.7.

Note

• This menu item is available when the optional hard disk is installed.

Language

Values: English, FRANCAIS, Espanol,

Portugues E., Portugues B., Deutsch, Italiano...

This setting determines the language of the text that appears on the control panel display and information printing.

Power Save

Values: [ 5 ] Min, [ 10] Min, [ 15 ] Min, [ 30 ] Min,

[ 60 ] Min, [ 120 ] Min

When the printer does not receive data for an extended period of time, power consumption is automatically lowered. You can set how long the printer waits before going to power save mode.

Auto

Continue

Values: Off, On

This item determines whether or not the printer continues printing when it detects the paper unmatched to your paper setting.

Off: If a paper mismatch occurs, an error message will remain on the display and the printer will remain off-line until you insert the correct paper.

On: If the paper mismatch occurs, an error message will display. The printer will go offline for 30 seconds, then automatically clear the message and continue printing.

Altitude Adj.

Values: Plain, High, Higher, Highest

You can optimize print quality according to your altitude.

Auto CR

Values: LF, LF+CR

This item allows you to append the required carriage return to each line feed.

Refer to the following samples:

AA

BB

CC

AA

BB

CC

LF LF+CR

2.5

<System setup>

Item

Job Timeout

Maintenance

Clear Setting

Explanation

Values:[0-1800] sec:15

You can set the length of time the printer waits before printing the last page of a print job that does not end with a command to print the page.

When a print time-out occurs, the printer prints the page in the print buffer.

This item allows you to maintain your printer.

Clean Drum

: Cleans the OPC drum of the toner cartridge and produces a cleaning sheet with toner debris on it.

Clean Fuser

: Cleans the fuser unit inside of the printer and produces a cleaning sheet with toner debris on it.

CLR Empty MSG.

: Prevents the

Toner Low

Replace Toner

message from appearing on the display. Once you have selected On, this setting will be permanently written to the memory of the toner cartridge, and this menu will be disappeared from the

Maintenance

menu.

Supplies Life

: Allows you to check how many pages have been printed and how much toner are left in the cartridge.

This menu item allows you to restore the printer’s factory default settings.

Emulation menu

Use the 6. Emulation menu to configure printer language emulation.

Explanation Item

Emulation

Type

Values: Auto, PCL, PostScript, EPSON,

HEXDUMP, PS3, IBM ProPrint

The printer language defines how the computer communicates with the printer.

If you select Auto, your printer can change the printer language automatically.

Setup

Values: PCL, PostScript, EPSON

See the following tables to configure properties of the printer language.

PCL

This menu sets the PCL emulation configuration. You can set the font type, symbol type, lines per page, and font size.

Item

Typeface

Explanation

Values: PCL1 ~ PCL54

You can select the standard font to be used in PCL emulation.

• PCL1~PCL7’s interval between letters is fixed, and

PCL8~PCL45’s interval is proportional to the font type and font size. You can adjust the font size of

PCL1~PCL7 using the Pitch item, and

PCL8~PCL45 can do using

Point Size

item.

• PCL46~PCL54’s interval and font size are fixed.

Symbol

Point Size

Values: 4.00 ~ 999.75 (0.25 unit)

When you select one between PCL8 and PCL45 from the Typeface menu, you can determine the font size by setting the height of the characters in the font.

Courier

Values: ROMAN8 ~ PCCYRIL

This item selects the symbol set to be used in PCL emulation. The symbol is the group of numbers, marks, and special signs being used when printing letters.

Depending on the Typeface setting, available symbol sets vary.

Values: Regular, Dark

This item lets you select the version of Courier font to use.

2.6

<System setup>

Item

Pitch

Explanation

Values: 0.44 ~ 99.99 (0.01 unit)

When you select one between PCL1 and PCL7 from the Typeface menu, you can determine the font size by setting the number of characters that will print in one horizontal inch of type. The default value, 10 is the best size.

Lines

Values: [5 ~ 128]:64

This item allows you to set vertical spacing from 5 to

128 lines for the default paper size. The default number of lines may differ according to the paper size and printing orientation.

PostScript

This menu provides you with the Print PS Error menu item.

Explanation Item

Print PS

Error

Values: On, Off

You can select whether or not your printer prints an error list when a PS error occurs.

• Select On to print PS 3 emulation errors. If an error occurs, the job stops processing, the error message prints, and the printer flushes the job.

• If this menu is set to Off, the job is flushed without an indication of the error.

EPSON

This menu sets the EPSON emulation configuration.

Item

Font

Explanation

Values: SANSERIF, ROMAN

You can select the default font will be used in EPSON emulation.

Character

Set

Values: USA, FRANCE, GERMANY, UK,

DENMARK1, SWEDEN, ITALY, SPAIN1, JAPAN,

NORWAY, DENMARK2, SPAIN2, LATIN

This item allows you to select a character set of the desired language.

Character

Tab.

Values: ITALIC, PC437US, PC850

This item selects the character set.

Item

Pitch

LPI

Auto

Wrap

Explanation

Values: 10, 12, 17.14, 20

You can determine the font size by setting the number of characters that will print in one horizontal inch of type.

Values: 6, 8

You can set the number of lines printed in one vertical inch.

Values: Off, On

This item determines whether or not the printer automatically performs line feed when the data overflows the printable area of the print meterials.

Network menu

This menu lets you configure the network interface installed in your printer. You can reset the network interface and print a configuration

page. For details, see page 4.1.

Item

TCP/IP

Explanation

Values: DHCP, BOOTP, Static

This item allows you to manually set the TCP/IP addresses or receive the addresses from the network.

DHCP: The DHCP server allots the IP address to you automatically.

BOOTP: The BOOTP server allots the IP address to you automatically.

Static: You can enter IP Address, Subnet Mask, and Gateway manually.

EtherTalk

Values: Off, On

This item lets you select whether or not you use the

EtherTalk protocol. Select On to use the protocol.

NetWare

Values: Auto, 802.2, 802.3, Ethernet II, SNAP, Off

This item lets you select the IPX frame type.

Auto: You can set the printer to select the frame type automatically.

802.2: Select this value to use the IEEE 802.2 frame type.

802.3: Select this value to use the IEEE 802.3 frame type.

Ethernet II: Select this value to use the Ethernet 2 frame type.

SNAP: Select this value to use the SNAP frame type.

Off: You can disable the NetWare protocol.

Ethernet

Speed

Clear

Setting

Network

Info

Values: Auto, 10M Half, 10M Full, 100M Half,

100M Full

This item allows you to select the ethernet speed.

This item performs a simple reset and restores the factory default settings for the network configuration. This setting will only take effect after you restart the printer.

This item prints a page showing the network parameters you set.

2.7

<System setup>

Printing a demo page

After setting up your printer, print a demo page to make sure that the printer is operating correctly.

Press and hold Demo for about 2 seconds.

Or,

1

Press Menu and then OK when 1. Information appears.

2

Press the Scroll buttons until Demo Page appears and press OK.

3

Press OK when Yes appears.

A demo page prints out.

Changing the display language

To change the language that is displayed on the control panel, follow these steps:

1

Press Menu until 5. System Setup appears on the bottom line of the display and press OK.

2

Press the Scroll buttons until Language appears and press OK.

3

Press the Scroll buttons to select the language you want and press

OK.

4

Press Stop to return to Standby mode.

Using toner save mode

Toner save mode allows the printer to use less toner on each page.

Activating this mode extends the life of your toner cartridge and reduces your cost per page beyond what one would experience in the normal mode, but it reduces print quality. This setting is not available with the

1200dpi-Best setting.

There are two ways to enable this mode:

Using the control panel button

Press Toner Save on the control panel. The printer must be in Standby mode; the Status LED lights green and Ready is shown on the display.

• If the button backlight is on, the mode is enabled and the printer uses less toner to print a page.

• If the button backlight is off, the mode is disabled and the printer prints in normal mode.

From the software application

You can set toner save mode from the printer properties window on your printer driver. See the Software Section.

2.8

<System setup>

Changing the font setting

Your machine has preset the font for your region or country. If you want to change the font which you prefer or set the font under special condition such as the DOS environment, you can change the font setting as follows:

1

Press Menu on the control panel until you see 6. Emulation feature.

2

Press OK to access the font setting.

3

Press the left/right arrow until Setup displays.

4

Press the left/right arrow until PCL displays.

5

Press the left/right arrow until Symbol displays.

6

Press the left/right arrow until your preferred font displays.

7

Press OK.

8

Press Stop to return to machine ready mode.

Note

Following information shows the proper font list for corresponding languages.

•Russian: CP866, Cyrillic

•Hebrew: 15Q, 8H, 0H (Israel only)

•Greek: GREEK, PC737

•Arabic & Farsi: ARABIC8, WINARABIC, PC864, FARSI,

ISOARABIC.

3

Software overview

This chapter gives you an overview of the software that comes with your printer. Further details about installing and using the software are exed in the Software Section.

This chapter includes:

Supplied software

Printer driver features

System requirements

Supplied software

You must install the printer software using the supplied CDs after you have set up your printer and connected it to your computer.

Each CD provides you with the following software:

CD printer software CD network utilities CD

(ML-4551N,

ML-4551ND only)

Windows

Linux

Contents

Printer driver: Use this driver to take full advantage of your printer’s features.

Smart Panel: This program allows you to monitor the printer’s status and alerts you when an error occurs during printing.

Direct Printing Utility: This program allows you to print PDF files easily.

Postscript Printer Description

(PPD) file: Use the PostScript driver to print documents with complex fonts and graphics in the

PostScript language.

User’s Guide in PDF

Printer driver: Use this driver to run your printer from a Linux computer and print documents.

Smart Panel: This program allows you to monitor the printer’s status and alerts you when an error occurs during printing.

Macintosh • Postscript Printer Description

(PPD) file: Use this file to run your printer from a Macintosh computer and print documents.

Smart Panel: This program allows you to monitor the printer’s status and alerts you when an error occurs during printing.

Windows • SyncThru™ Web Admin Service:

Use this web-based program to remotely manage, monitor, and troubleshoot network printers.

Set IP: Use this program to set your printer’s TCP/IP addresses.

Network Printer User’s Guide in

PDF

3.1

<Software overview>

Printer driver features

Your printer drivers support the following standard features:

• Paper source selection

• Paper size, orientation and media type

• Number of copies

In addition, you can use various special printing features. The following table shows a general overview of features supported by your printer drivers:

Feature

PCL 6

Windows

O

O

PostScript

Windows

O

O

Macintosh

X

O

Linux

O

O

Toner save

Print quality option

Poster printing

Multiple pages per sheet (N-up)

Fit to page printing

Scale printing

Different source for first page

Watermark

Overlay

O

O

O

O

O

O

O

X

O

O

X

X

O

X

X

O

O

X

X

O

O

X

O

(2, 4)

O

X

X

O

X

Note

• Overlay is not supported in Windows NT 4.0.

System requirements

Before you begin, ensure that your system meets the following requirements:

Windows

Item

Operating system

CPU

Requirements

Windows 98/Me/NT 4.0/2000/XP/2003

Recommended

RAM

Free disk space

Internet

Explorer

Windows 98/

Me/NT 4.0/2000

Windows XP/

2003

Pentium II

400 MHz or higher

Pentium III

933 MHz or higher

64 MB or more Windows 98/

Me/NT 4.0/2000

Windows XP/

2003

Windows 98/

Me/NT 4.0/2000

Windows XP/

2003

5.0 or higher

128 MB or more

300 MB or more

1 GB or more

Pentium III

933 MHz

Pentium IV

1 GHz

128 MB

256 MB

1 GB

5 GB

Note

• For Windows NT 4.0/2000/XP/2003, users who have an administrator right can install the software.

3.2

<Software overview>

Linux

Item

Operating system

Processor

RAM

Free disk page

Software

Requirements

• Red Hat 8.0 ~ 9.0

• Fedora Core 1 ~ 3

• Mandrake 9.2 ~ 10.1

• SuSE 8.2 ~ 9.2

Pentium IV 1 GHz or higher

256 MB or higher

1 GB or higher

• Linux Kernel 2.4 or higher

• Glibc 2.2 or higher

• CUPS

• SANE

Macintosh

Item

Operating system

RAM

Free disk space

Connection

Requirements

8.6 ~ 9.2 and 10.1 ~ 10.4

128 MB

200 MB

USB interface, Network interface

3.3

<Software overview>

4

Network setup

This chapter gives you step-by-step instructions for setting up your printer for network connections.

This chapter includes:

Introduction

Supported operating systems

Configuring TCP/IP

Configuring IPX frame types

Setting Ethernet speed

Restoring the network configuration

Printing a network configuration page

Introduction

Once you have connected your printer to a network with an RJ-45

Ethernet cable, you can share the printer with other network users.

You need to set up the network protocols on the printer to use it as your network printer. Protocols can be set up by the following two methods:

Via network administration programs

You can configure your printer’s print server settings and manage the printer via the following programs that came with your printer:

SyncThru™ Web Admin Service: A web-based printer management solution for network administrators. SyncThru™ Web

Admin Service provides you with an efficient way of managing network devices and lets you remotely monitor and troubleshoot network printers from any site with corporate intranet access.

SyncThru™ Web Service: A web server embedded to your network print server, which allows you to configure the network parameters necessary for the printer to connect to various network environments.

SetIP: A utility program allowing you to select a network interface and manually configure the addresses for use with the TCP/IP protocol.

For further details, refer to the user’s guide on the network utilities CD that came with your printer.

Via the control panel

You can set up the following basic network parameters through the printer’s control panel:

• Configure TCP/IP

• Configure IPX frame types for NetWare

• Configure EtherTalk

4.1

<Network setup>

Supported operating systems

The following table shows the network environments supported by the printer:

Network interface

Network operating system

Item Requirements

• 10/100 Base-TX

• Novell NetWare 4.x, 5.x, 6.x

• Windows 98/Me/NT 4.0/2000/XP/2003

• Various Linux OS

• Mac OS 10.3 and above (TCP/IP only)

Network protocols • NetWare IPX/SPX

• TCP/IP

• EtherTalk

• HTTP 1.1

• SNMP

Dynamic addressing server

• DHCP, BOOTP

• IPX/SPX: Internet Packet eXchange/Sequenced Packet eXchange

• TCP/IP: Transmission Control Protocol/Internet Protocol

• DHCP: Dynamic Host Configuration Protocol

• BOOTP: Bootstrap Protocol

Configuring TCP/IP

Your printer can be set up with a variety of TCP/IP network information, such as an IP address, a subnet mask, a gateway, and DNS addresses.

There are several ways in which your printer can be assigned a TCP/IP address, depending on your network.

• Static addressing: A TCP/IP address is assigned manually by the system administrator.

• Dynamic addressing via BOOTP/DHCP (default): A TCP/IP address is assigned automatically by the server.

Note

• Before configuring TCP/IP, you need to set the network protocol to TCP/IP.

Static addressing

To enter a TCP/IP address from your printer’s control panel, take the following steps:

1

Press Menu until Network appears on the bottom line of the display and press OK.

2

Press OK when TCP/IP appears.

3

Press the Scroll buttons until Static appears and press OK.

4

Press OK when IP Address appears.

4.2

<Network setup>

5

Set the first byte between 0 and 255 using the Scroll buttons and press OK to move to the next byte.

Repeat this to complete the address from the 1st byte to the 4th byte.

6

When you have finished, press OK.

7

Repeat step 5 and 6 to configure the other TCP/IP parameters:

Subnet Mask and Gateway address.

8

Press Stop to return to Standby mode.

Dynamic addressing (BOOTP/DHCP)

To have a TCP/IP address assigned automatically by the server, take the following steps:

1

Press Menu until Network appears on the bottom line of the display and press OK.

2

Press OK when TCP/IP appears.

3

Press the Scroll buttons until DHCP or BOOTP appears and press

OK.

4

Press Stop to return to Standby mode.

Configuring EtherTalk

EtherTalk is AppleTalk used in an Ethernet network. This protocol is widely used in Macintosh network environments. To use EtherTalk, take the following steps:

1

Press Menu until Network appears on the bottom line of the display and press OK.

2

Press the Scroll buttons until EtherTalk appears and press OK.

3

Press the Scroll buttons until On appears and press OK.

4

Press Stop to return to Standby mode.

Configuring IPX frame types

To use IPX/SPX protocol networks (for example, Novell NetWare), the format of the network communication frames must be specified for the printer. In most cases, you can keep the Auto setting. However, you can manually set the frame type format, if required. Take the following step to change the frame type format:

1

Press Menu until Network appears on the bottom line of the display and press OK.

2

Press the Scroll buttons until NetWare appears and press OK.

3

Press the Scroll buttons until the desired frame type appears.

Auto: Automatically senses and limits the frame type to the first one detected.

802.2: Limits the frame type to IPX over IEEE 802.2 with IEEE

802.3 frames. All others will be discarded.

802.3: Limits the frame type to IPX over IEEE 802.3 frames. All others will be discarded.

Ethernet II: Limits the frame type to IPX over Ethernet Frames. All others will be discarded.

SNAP: Limits the frame type to IPX over SNAP with IEEE 802.3 frames. All others will be discarded.

Off: Disables the IPX/SPX protocol.

4

Press OK to save the selection.

5

Press Stop to return to Standby mode.

Setting Ethernet speed

You can select the communication speed for Ethernet connections.

1

Press Menu until Network appears on the bottom line of the display and press OK.

2

Press the Scroll buttons until Ethernet Speed appears and press

OK.

3

Press the Scroll buttons until the speed you want appears and press OK.

4

Press Stop to return to Standby mode.

Restoring the network configuration

You can return the network configuration to its default settings.

1

Press Menu until Network appears on the bottom line of the display and press OK.

2

Press the Scroll buttons until Clear Setting appears and press

OK.

3

Press OK when Yes appears to restore the network configuration.

4

Power the printer off and back on.

Printing a network configuration page

The network configuration page shows how the network interface card on your printer is configured.

1

Press Menu until Network appears on the bottom line of the display and press OK.

2

Press the Scroll buttons until Network Info appears and press OK.

3

Press OK when Yes appears.

The network configuration page prints out.

4.3

<Network setup>

5

Loading print media

This chapter will help you understand types of paper you can use with your printer and how to properly load paper in the different paper trays for the best print quality.

This chapter includes:

Selecting print media

Loading paper

Selecting an output location

Selecting print media

You can print on a variety of print media, such as plain paper, envelopes, labels, and transparencies. Always use print media that meet the guidelines for use with your printer. Print media that does not meet the guidelines outlined in this user’s guide may cause the following problems:

• Poor print quality

• Increased paper jams

• Premature wear on the printer

Properties, such as weight, composition, grain, and moisture content, are important factors that affect the printer’s performance and the output quality. When you choose print media, consider the following:

• Desired outcome: The print media you choose should be appropriate for your project.

• Size: You can use any size media that fits easily within the paper adjusters of the paper tray.

• Weight: Your printer supports print media weights as follows:

- 16 to 28 lb bond (60 to 105 g/m

2 tray 3, tray 4

) for the tray 1 and optional tray 2,

- 16 to 50 lb bond (60 to 190 g/m

2

) for the multi-purpose tray

- 20 to 24 lb (75 to 90 g/m

2

) for the duplex printing

• Brightness: Some print media are whiter than others and produce sharper, more vibrant images.

• Surface smoothness: The smoothness of the print media affects how crisp the printing looks on the paper.

Notes

• Some print media may meet all of the guidelines in this section and still not produce satisfactory results. This may be the result of improper handling, unacceptable temperature and humidity levels, or other variables over which Samsung has no control.

• Before purchasing large quantities of print media, ensure that it meets the requirements specified in this user’s guide.

Caution

• Using print media that does not meet these specifications may cause problems, requiring repairs. Such repairs are not covered by Samsung’s warranty or service agreements.

5.1

<Loading print media>

Supported sizes of paper

Type

Plain paper Letter

Legal

Folio

Oficio

Size Dimensions

216 x 279 mm (8.5 x 11 inches)

216 x 356 mm (8.5 x 14 inches)

216 x 330.2 mm (8.5 x 13 inches)

216 x 343 mm (8.5 x 13.5 inches)

Weight a

• 60 to 105 g/m

2 bond) for the tray

• 60 to 1 bond) for the multi-purpose tray

90 g/m

2

(16 to 28 lb

(16 to 50 lb

Capacity

• 500 sheets of 75 g/m

2

(20 lb bond) paper for the tray

• 100 sheets for the multipurpose tray

b

A4

JIS B5

ISO B5

Executive

A5

A6

210 x 297 mm (8.27 x 11.69 inches)

182 x 257 mm (7.18 x 10.12 inches)

176 x 250 mm (6.93 x 9.84 inches)

184.2 x 266.7 mm (7.25 x 10.5 inches)

148.5 x 210 mm (5.85 x 8.27 inches)

105 x 148.5 mm (4.13 x 5.85 inches)

Envelope Envelope B5

Envelope Monarch

Envelope COM-10

176 x 250 mm (6.93 x 9.84 inches)

98.4 x 190.5 mm (3.88 x 7.5 inches)

105 x 241 mm (4.12 x 9.5 inches)

60 to 90 g/m

2

(16 to 24 lb) 10 sheets of 75 g/m

2

(20 lb) in the multi-purpose tray

Envelope DL

Envelope C5

110 x 220 mm (4.33 x 8.66 inches)

162 x 229 mm (6.38 x 9.02 inches)

Envelope C6 114 x 162 mm (4.49 x 6.38 inches)

Transparency

Labels

Letter, A4

Letter, Legal, Folio,

Oficio, A4, JIS B5,

ISO B5, Executive,

A5, A6

Refer to the Plain paper section

Refer to the Plain paper section

138 to 146 g/m

2

(37 to 39 lb) 50 sheets of 75 g/m

2

(20 lb) in the multi-purpose tray

120 to 150 g/m

2

(32 to 40 lb) 25 sheets of 75 g/m

2

(20 lb) in the multi-purpose tray

Card stock Letter, Legal, Folio,

Oficio, A4, JIS B5,

ISO B5, Executive,

A5, A6

Refer to the Plain paper section 60 to 1 90 g/m

2

(16 to 50 lb) 10 sheets of 75 g/m

2

(20 lb) in the multi-purpose tray

Minimum size (custom) 76 x 127 mm (3 x 5 inches) 60 to 1 90 g/m

2

(16 to 50 lb) Refer to the above Capacity sections

Maximum size (custom) 216 x 356 mm (8.5 x 14 inches) a. If media weight is over 28 lb (105 g/m

2

), use the multi-purpose tray.

b. Maximum capacity may differ depending on media weight, thickness, and environmental conditions.

Print media for duplex printing

Type

Plain paper

Size

A4, Letter, Oficio, Legal, and Folio

Weight

75 ~ 90 g/m

2

(20 to 24 lb)

5.2

<Loading print media>

Guidelines for selecting and storing print media

When selecting or loading paper, envelopes, or other print media, keep these guidelines in mind:

• Always use print media that conform with the specifications listed on the next column.

• Attempting to print on damp, curled, wrinkled, or torn paper can cause paper jams and poor print quality.

• For the best print quality, use only high quality copier grade paper specifically recommended for use in laser printers.

• Avoid using the following media types:

- Paper with embossed lettering, perforations, or a texture that is too smooth or too rough

- Erasable bond paper

- Multi-paged paper

- Synthetic paper and thermally reactive paper

- Carbonless paper and Tracing paper.

• Use of these types of paper could result in paper jams, chemical smells, and damage to your printer.

• Store print media in its ream wrapper until you are ready to use it.

Place cartons on pallets or shelves, not on the floor. Do not place heavy objects on top of the paper, whether it is packaged or unpackaged. Keep it away from moisture or other conditions that can cause it to wrinkle or curl.

• Store unused print media at temperatures between 15 o

C and 30 o

C

(59 o

F to 86 o

F). The relative humidity should be between 10% and

70%.

• Store unused print media in a moisture-proof wrap, such as a plastic container or bag, to prevent dust and moisture from contaminating your paper.

• Load special media types one sheet at a time through the multipurpose tray to avoid paper jams.

• To prevent print media, such as transparencies and label sheets, from sticking together, remove them as they print out.

Guidelines for special print media

Media type

Envelopes

Guidelines

• Successful printing on envelopes depends upon the quality of the envelopes. When selecting envelopes, consider the following factors:

- Weight: The weight of the envelope paper should not exceed 90 g/m

2

(24 lb) or jamming may occur.

- Construction: Prior to printing, envelopes should lie flat with less than 6 mm

(0.25 inches) curl, and should not contain air.

- Condition: Envelopes should not be wrinkled, nicked, or otherwise damaged.

- Temperature: You should use envelopes that are compatible with the heat and pressure of the printer during operation.

• Use only well-constructed envelopes with sharp and well creased folds.

• Do not use stamped envelopes.

• Do not use envelopes with clasps, snaps, windows, coated lining, self-adhesive seals, or other synthetic materials.

• Do not use damaged or poorly made envelopes.

• Be sure the seam at both ends of the envelope extends all the way to the corner of the envelope.

Acceptable

Unacceptable

• Envelopes with a peel-off adhesive strip or with more than one flap that folds over to seal must use adhesives compatible with the printer’s fusing temperature of 195° C (383° F) for

0.1 second. The extra flaps and strips might cause wrinkling, creasing, or jams, and may even damage the fuser.

• For the best print quality, position margins no closer than 15 mm (0.6 inches) from the edges of the envelope.

• Avoid printing over the area where the envelope’s seams meet.

5.3

<Loading print media>

Media type Guidelines

Transparencies • To avoid damaging the printer, use only transparencies designed for use in laser printers.

• Transparencies used in the printer must be able to withstand 195° C (383° F), the printer’s fusing temperature.

• Place them on a flat surface after removing them from the printer.

• Do not leave them in the paper tray for long periods of time. Dust and dirt may accumulate on them, resulting in spotty printing.

• To avoid smudging caused by fingerprints, handle them carefully.

• To avoid fading, do not expose printed transparencies to prolonged sunlight.

• Ensure that transparencies are not wrinkled, curled, or have any torn edges.

Labels • To avoid damaging the printer, use only labels designed for use in laser printers.

• When selecting labels, consider the following factors:

- Adhesives: The adhesive material should be stable at 195° C (383° F), the printer’s fusing temperature.

- Arrangement: Only use labels with no exposed backing between them. Labels can peel off sheets that have spaces between the labels, causing serious jams.

- Curl: Prior to printing, labels must lie flat with no more than 13 mm (5 inches) of curl in any direction.

- Condition: Do not use labels with wrinkles, bubbles, or other indications of separation.

• Make sure that there is no exposed adhesive material between labels. Exposed areas can cause labels to peel off during printing, which can cause paper jams. Exposed adhesive can also cause damage to printer components.

• Do not run a sheet of labels through the printer more than once. The adhesive backing is designed for only a single pass through the printer.

• Do not use labels that are separating from the backing sheet or are wrinkled, bubbled, or otherwise damaged.

Card stock or custom-sized materials

• Do not print on media smaller than 76 mm

(3 inches) wide or 127 mm (5 inches) long.

• In the software application, set margins at least

6.4 mm (0.25 inches) away from the edges of the material.

5.4

<Loading print media>

Media type

Preprinted paper

Guidelines

• Letterhead must be printed with heat-resistant ink that will not melt, vaporize, or release hazardous emissions when subjected to the printer’s fusing temperature of 195° C (383° F) for 0.1 second.

• Letterhead ink must be non-flammable and should not adversely affect printer rollers.

• Forms and letterhead should be sealed in a moisture-proof wrapping to prevent changes during storage.

• Before you load preprinted paper, such as forms and letterhead, verify that the ink on the paper is dry. During the fusing process, wet ink can come off preprinted paper, reducing print quality.

Loading paper

Load the print media you use for the majority of your print jobs in the tray

1. The tray 1 can hold a maximum of 500 sheets of 75 g/m

2

(20 lb) plain paper.

You can purchase optional trays and attach them below the standard tray to load an additional 500 sheets of paper for each tray. You can attach up to three additional trays. For order information for optional trays, see

page 7.1.

The paper level indicator on the front of the tray 1 and the optional trays shows the amount of paper currently left in the tray. When the tray is empty, the indicator of the bar is completely lowered.

Full

Empty

Using the standard tray or the optional trays

Load the print media you use for the majority of your print jobs in the standard tray. The standard tray can hold a maximum of 500 sheets of

75 g/m

2

(20 lb) paper.

To load paper, pull open the tray and load paper with the side to be printed on face down.

2

Squeeze the paper length guide and slide it to the correct position for the paper size you are loading, which is marked at the bottom of the tray.

1

You can load letterhead paper with the design side face down. The top edge of the sheet with the logo should be placed at the front of the tray.

Notes

• If you experience problems with paper feed, place one sheet at a time in the multi-purpose tray.

• You can load previously printed paper. The printed side should be facing up with an uncurled edge at the front of the tray. If you experience problems with paper feed, turn the paper around. Note that the print quality is not guaranteed.

Changing the size of the paper in the tray

The tray is preset to Letter or A4 size, depending on your country. To change the size, you need to adjust the paper guides.

1

Push the back plate of the tray outwards completely so that it can extend the length of the tray.

1

paper length guide

3

Squeeze the paper width guides and slide them to the desired paper size marked at the bottom of the tray.

1

1

paper width guide

Notes

• Do not push the paper width guide far enough to cause the media to warp.

• If you do not adjust the paper width guide, it may cause paper jams.

4

Load paper with the print side down.

5.5

<Loading print media>

Using the multi-purpose tray

The multi-purpose tray can hold special sizes and types of print media, such as transparencies, postcards, note cards, and envelopes. It is useful for single page printing on letterhead or colored paper.

To load paper in the multi-purpose tray:

1

Pull the multi-purpose tray down towards you and pull the multipurpose tray extension to hold longer paper.

• Envelopes: Flap side down and with the stamp area on the top left side.

Note

• To print on envelopes, you must open the rear cover and push the fuser levers upwards. The print quality will be enhanced.

2

If you are using paper, flex or fan the edge of the paper stack to separate the pages before loading.

For transparencies, hold them by the edges and avoid touching the print side. Oils from your fingers can cause print quality problems.

3

Load the paper with the side to be printed on facing up.

• Transparencies: Print side up and the top with the adhesive strip entering the printer first.

• Labels: Print side up and the top short edge entering the printer first.

• Preprinted paper: Design side up and the top edge entering the printer first.

• Card stock: Print side up and the short edge entering the printer first.

• Previously printed paper: Previously printed side down and an uncurled edge entering the printer first.

Note

• Make sure that you have not loaded too much print media. The print media buckles if you load a stack that is too deep or if you push it in too far.

Caution

• When you print on special media like envelopes, labels, transparencies, or cards, the output location should be the rear

cover. Open the rear cover to use it. See page 5.8.

Depending on the media type you are using, keep the following loading guidelines:

5.6

<Loading print media>

4

Squeeze the multi-purpose tray paper width guides and adjust them to the width of the paper. Do not force too much, or the paper will be bent, which will result in a paper jam or skew.

1

Load the paper with the side to be printed on facing up.

5

When you print a document, set the paper source and type in the software application. See the Software Section.

For information about setting the paper source and type on the

control panel, see page 2.4.

6

After printing, put the multi-purpose tray extension back to its place and close the multi-purpose tray.

Tips on using the multi-purpose tray

• Load only one size of print media at a time in the multi-purpose tray.

• To prevent paper jams, do not add paper when there is still paper in the multi-purpose tray. This also applies to other tray.

• Print media should be loaded face up with the top edge going into the multi-purpose tray first and be placed in the center of the tray.

• Always load only the print media specified in page 5.2 to avoid paper

jams and print quality problems.

• Flatten any curl on postcards, envelopes, and labels before loading them into the multi-purpose tray.

• When you print on 76 mm x 127 mm (3 x 5 inches) sized media on the multi-purpose tray, open the rear cover for straight paper path to avoid paper jams.

• When you print on transparencies, open the rear cover. If not they may tear while exiting the printer.

Using manual feed mode

You can manually load a sheet of print media in the multi-purpose tray if you select Manual Feed in the Source option from the Paper tab when you change print settings to print a document. See the Software

Section. Manually loading paper can be helpful when you want to check the print quality after each page is printed.

This loading procedure is almost the same as the procedure for loading in the multi-purpose tray, except you load paper sheet-by-sheet in the tray, send print data to print the first page, and press OK on the control panel to print each following page.

2

Squeeze the multi-purpose tray paper width guides and adjust them to the width of the paper. Do not force too much, or the paper will be bent, which will result in a paper jam or skew.

3

When you print a document, set the paper source to Manual Feed and select the appropriate paper size and type in the software application. See the Software Section.

4

Print a document.

The display shows a message prompting you to load paper and press OK.

5

Press OK.

The printer picks up the print media and prints. After one page is printed, the message appears again.

Note

• If you do not press the button, after a pause the printer will automatically pick the print media.

6

Insert the next sheet into the multi-purpose tray and press OK.

Repeat this step for every page to be printed.

5.7

<Loading print media>

Selecting an output location

The printer has two output locations; the rear cover (face up) and the output tray (face down).

1

2

Printing to the output tray

(Face down)

The output tray collects paper face down, in the order in which the sheets were printed. The tray should be used for most print jobs.

Printing to the rear cover

(Face up)

Using the rear cover, paper comes out of the printer face up.

Printing from the multi-purpose tray to the rear cover provides a straight paper path. Using the rear cover might improve the output quality with special print media.

To use the rear cover, open it by pulling down and pull the rear cover extension.

1

rear cover

2

output tray

The printer sends output to the output tray by default. To use the output tray, make sure that the rear cover is closed.

Notes

• If paper coming out of the output tray has problems, such as excessive curl, try printing to the rear cover.

• To avoid paper jams, do not open or close the rear cover while the printer is printing.

Caution

• The fuser area inside the rear cover of your printer becomes very hot when in use. Take care when you access this area.

5.8

<Loading print media>

6

Basic printing

This chapter explains common printing tasks.

This chapter includes:

Printing a document

Canceling a print job

Printing a document

This printer allows you to print from various Windows, Macintosh, or

Linux applications. The exact steps for printing a document may vary depending on the application you use.

For details about printing, see the Software Section.

Canceling a print job

If the print job is waiting in a print queue or print spooler, such as the printer group in Windows, delete the job as follows:

1

Click the Windows Start button.

2

For Windows 98/Me/NT 4.0/2000, select Settings and then

Printers.

For Windows XP/2003, select Printers and Faxes.

3

Double-click the Samsung ML-4550 Series PCL 6 or Samsung

ML-4550 Series PS icon.

4

From the Document menu, select

Cancel Printing

(Windows 98/

Me) or

Cancel

(Windows NT 4.0/2000/XP/2003).

Note

• You can access this window simply by double-clicking the printer icon at the bottom right corner of the Windows desktop.

You can also cancel the current job by pressing Stop on the control panel of your printer.

6.1

<Basic printing>

7

Ordering supplies and accessories

This chapter provides information on purchasing toner cartridges and accessories available for your printer.

Toner cartridges

Accessories

How to purchase

Toner cartridges

When the toner runs out, you can order the following types of toner cartridges for your printer:

Type Yield a

Part number

Standard yield 10,000 pages ML-D4550A

High yield 20,000 pages ML-D4550B a. Declared yield value in accordance with ISO/IEC 19752.

Accessories

You can purchase and install accessories to enhance your printer’s performance and capacity.

The following accessories are available for your printer:

Accessory

Optional Tray

Description

If you are experiencing frequent paper supply problems, you can attach additional 500 sheet trays up to three.

You can print documents on various sizes and types of print media.

Extends your printer’s memory capacity.

Part number

ML-S4550A

DIMM • ML-MEM150:

128 MB

• ML-MEM160:

256 MB

ML-NWA20N Ethernet 10/100

Base TX Wired

Network Printer

Interface Card

Duplex Unit

Hard Disk

Allows you to connect your printer to a network environment using the wired network card.

Allows you to print on both sides of the paper.

Allows you to enhance the printer’s capability and print in various ways.

ML-3560U1

ML-HDK210

How to purchase

To order Samsung-authorized supplies or accessories, contact your local Samsung dealer or the retailer where you purchased your printer, or visit www.samsungprinter.com

and select your country/region for information on calling for technical support.

7.1

<Ordering supplies and accessories>

8

Maintenance

This chapter provides information for maintaining your printer and the toner cartridge, as well as suggestions for high-quality and economical printing.

This chapter includes:

Printing information pages

Cleaning the printer

Maintaining the toner cartridge

Maintenance parts

Printing information pages

From the printer’s control panel, you can print pages that give detailed information about the printer. They can help you check your printer’s status and maintain the printer.

1

Press Menu until Information appears on the bottom line of the display and press OK.

2

Press the Scroll buttons until the information page you want appears and press OK.

3

Press OK when Yes appears.

A page prints out.

Cleaning the printer

During the printing process, paper, toner, and dust particles can accumulate inside the printer. This buildup can cause print quality problems, such as toner specks or smearing. Your printer has a cleaning mode that can correct and prevent these types of problems.

Caution

• Cleaning the cabinet of the printer with cleaning materials containing large amounts of alcohol, solvents, or other strong substances can discolor or crack the cabinet.

Cleaning the outside of the printer

Clean the cabinet of the printer with a soft, lint-free cloth. You can dampen the cloth slightly with water, but be careful not to let any water drip onto or into the printer.

Cleaning the inside of the printer

There are two methods to clean the inside of the printer:

• Clean the inside manually.

• Print a cleaning sheet, which can be done from the control panel.

Cleaning the inside of the printer manually

1

Turn the printer off and unplug the power cord. Wait for the printer to cool down.

8.1

<Maintenance>

2

Open the top cover and pull the toner cartridge out. Set it on a clean flat surface.

4

Gently swab the long strip of glass (LSU) inside the top of the cartridge cavity and check for dirt or dust.

Caution

• To prevent damage to the toner cartridge, do not expose it to light for more than a few minutes. Cover it with a piece of paper, if necessary.

• Do not touch the green surface underside of the toner cartridge. Use the handle on the cartridge to avoid touching this area.

3

With a dry lint-free cloth, wipe away any dust and spilled toner from the toner cartridge area and the toner cartridge cavity.

Note

• The long strip of glass is hard to locate.

5

Locate the PTL lens by flipping up the guide feed and gently swab the lens with the pointed white cotton.

1

1

PTL lens

Caution

• While cleaning the inside of the printer, be careful not to touch the transfer roller, located underneath the toner cartridge. Oil from your fingers can cause print quality problems.

8.2

<Maintenance>

6

Clean a feed sensor with a cotton bud.

1

1

Feed Sensor

7

Reinsert the toner cartridge and close the top cover.

8

Plug in the power cord and turn the printer on.

Printing a cleaning sheet

If you are experiencing blurred, faded, or smeared printouts, you can clear the problem by printing a cleaning sheet, provided by your printer.

You can print:

• OPC cleaning sheet: cleans the OPC drum of the toner cartridge.

• Fuser cleaning sheet: cleans the fuser unit inside the printer.

This process will produce a page with toner debris, which should be discarded.

1

Make sure that the printer is turned on with paper loaded in the tray.

2

Press Menu until System Setup appears on the bottom line of the display and press OK.

3

Press the Scroll buttons until Maintenance appears and press

OK.

4

Press the Scroll buttons until

Clean Fuser

or

Clean Drum appears and press OK.

Your printer automatically picks up a sheet of paper from the tray and prints out a cleaning sheet with dust or toner particles on it.

Maintaining the toner cartridge

Toner cartridge storage

To get the most from the toner cartridge, keep the following guidelines in mind:

• Do not remove the toner cartridge from its package until ready for use.

• Do not refill the toner cartridge. The printer warranty does not cover damage caused by using a refilled cartridge.

• Store toner cartridge in the same environment as the printer.

• To prevent damage to the toner cartridge, do not expose it to light for more than a few minute.

Expected cartridge yield

The toner cartridge yield depends on the amount of toner that print jobs require. The actual number may also be different depending on the print density of the pages you print on, and the number of pages may be affected by operating environment, printing interval, media type, and media size. If you print a lot of graphics, you may need to change the cartridge more often.

Saving toner

To save toner, press Toner Save on the control panel. The button backlight turns on.

Using this feature extends the life of the toner cartridge and reduce your cost per page, but it also reduces print quality.

8.3

<Maintenance>

Checking the remaining toner

You can check the level of toner left in the cartridge.

If you are having print quality problems, this can help you determine if the problem is caused by low toner.

1

Press Menu until System Setup appears on the bottom line of the display and press OK.

2

Press the Scroll buttons until Maintenance appears and press

OK.

3

Press the Scroll buttons until Supplies Life appears and press

OK.

4

Press the Scroll buttons until Toner Remains appears and press

OK.

The display shows the percentage of the remaining toner.

Note

While the following messages are appearing on the display, the sub-menu(s) under Supplies Life can be changed:

-

Invalid Toner, NonGenuine Toner, Replace Toner,

Toner Exhausted

Redistributing toner cartridge

When the toner cartridge is near the end of its life:

• White streaks and light printing occur.

Toner Low appears on the display.

• The Status LED blinks red.

If this happens, you can temporarily reestablish print quality by redistributing the remaining toner in the cartridge. In some cases, white streaks or light printing will still occur even after you have redistributed the toner.

1

Open the top cover.

2

Pull the toner cartridge out.

Caution

• Avoid reaching too far into the printer. The fusing area may be hot.

• To prevent damage to the toner cartridge, do not expose it to light for more than a few minutes. Cover it with a piece of paper, if necessary.

• Do not touch the green surface underside of the toner cartridge. Use the handle on the cartridge to avoid touching this area.

3

Thoroughly shake the cartridge 5 or 6 times to distribute the toner evenly inside the cartridge.

Note

• If toner gets on your clothing, wipe it off with a dry cloth and wash clothing in cold water. Hot water sets toner into fabric.

8.4

<Maintenance>

4

Hold the toner cartridge by the handle and slowly insert the cartridge into the opening in the printer.

Tabs on the sides of the cartridge and corresponding grooves within the printer will guide the cartridge into the correct position until it locks into place completely.

2

Pull the toner cartridge out.

3

Remove the new toner cartridge from its bag.

5

Close the top cover. Make sure that the cover is securely closed.

Replacing the toner cartridge

When the toner cartridge is completely empty:

Toner Empty appears on the display.

• The Status LED lights red.

At this stage, the toner cartridge needs to be replaced. For order

information for toner cartridges, see page 7.1.

1

Open the top cover.

Caution

• Do not use sharp objects, such as a knife or scissors, to open the toner cartridge package. They might scratch the drum of the cartridge.

8.5

<Maintenance>

4

Locate the sealing tape at the end of the toner cartridge. Carefully pull the tape completely out of the cartridge and discard it.

Caution

• If toner gets on your clothing, wipe it off with a dry cloth and wash clothing in cold water. Hot water sets toner into fabric.

• To prevent damage to the toner cartridge, do not expose it to light for more than a few minutes. Cover it with a piece of paper, if necessary.

• Do not touch the green surface underside of the toner cartridge. Use the handle on the cartridge to avoid touching this area.

7

Hold the toner cartridge by the handle and slowly insert the cartridge into the opening in the printer.

Tabs on the sides of the cartridge and corresponding grooves within the printer will guide the cartridge into the correct position until it locks into place completely.

Note

• The sealing tape should be longer than 60 cm when correctly removed.

• Holding the toner cartridge, pull the sealing tape straight to remove it form the cartridge. Be careful not to cut the tape. If this happens, you cannot use the toner cartridge.

• Refer to the helpful pictures on the cartridge wrapping paper.

5

Remove the flexible plastic holder out of the toner cartridge.

6

Thoroughly shake the cartridge 5 or 6 times to distribute the toner evenly inside the cartridge.

8

Close the top cover. Make sure that the cover is securely closed.

Thoroughly roll the cartridge to assure maximum copies per cartridge. Save the box and the plastic bag for shipping.

8.6

<Maintenance>

Clearing the Toner Low Replace Toner message

When the Toner Low Replace Toner message appears you can configure not to see this message again not to disturb you.

1

Press Menu until System Setup appears on the bottom line of the display and press OK.

2

Press the Scroll buttons until Maintenance appears and press OK.

3

Press the Scroll buttons until CLR Empty Msg. appears and press

OK.

4

Select On and press OK.

5

Now the Toner Low Replace Toner message does not appear but the Replace Toner message will remain for reminding you that the new cartridge needs to be installed for quality.

Caution

•Once you have selected On, this setting will be permanently written to the memory of the toner cartridge, and this menu will be disappeared from the Maintenance menu.

Maintenance parts

To avoid print quality and paper feed problems resulting from worn parts and to maintain your printer in top working condition, the following items will need to be replaced when the specified number of pages have been printed or when the life span of each item has expired.

Items

Transfer roller

Fuser unit

Paper feeding roller

Rubber pad

150,000

150,000

150,000

150,000

Yield (Average)

Samsung highly recommends that an authorized service provider, dealer or the retailer where you bought printer performs this maintenance activity.

8.7

<Maintenance>

9

Troubleshooting

This chapter provides helpful information for what to do if you encounter an error while using your printer.

This chapter includes:

Clearing paper jams

Troubleshooting checklist

Understanding the status LED

Understanding display messages

Toner cartridge-related messages

Solving general printing problems

Solving print quality problems

Common Windows problems

Common Macintosh problems

Common PostScript problems

Common Linux problems

Clearing paper jams

Note

• When removing paper that is jammed in the printer, if possible always pull the paper in the direction that it normally moves so as not to damage internal components. Always pull firmly and evenly; do not jerk the paper. If the paper tears, ensure that all fragments of paper are removed; otherwise a jam will occur again.

When a paper jam occurs, the Status LED lights red. Open and close the top cover. The jammed paper automatically exits the printer.

If the paper does not exit, check the display on the control panel. The message indicating the corresponding location of the paper jam appears. Refer to the table below to locate the paper jam and to clear it:

Message Location of Jam Go To

Paper Jam 0

Open/Close Door

In the paper feed area

(tray 1, optional tray 2, optional tray 3, optional tray 4, multi-purpose tray)

Around the toner cartridge the next column

Paper Jam 1

Open/Close Door

Paper Jam 2

Check Inside

Paper Exit Jam 1

Open/Close Door

In the paper exit area

Between the toner cartridge and the paper exit area

page 9.3

page 9.4

page 9.3

Paper Tray 2 Jam

Open Tray 2

Paper Tray 3 Jam

Open Tray 3

Paper Tray 4 Jam

Open Tray 4

Duplex Jam 0

a

Check Inside

Duplex Jam 1

a

Open/Close Door

In the optional tray 2

In the optional tray 3

In the optional tray 4

In the duplex area

In the duplex area

page 9.2

page 9.2

page 9.2

page 9.4

page 9.5

a. Available with the optional duplex unit in the ML-4550 and ML-4551N.

9.1

<Troubleshooting>

In the paper feed area

In the tray 1

1

Pull the tray 1 open.

In the optional tray

1

Pull the optional tray open.

2

Remove the jammed paper from the printer.

2

Remove the jammed paper by gently pulling it straight out. Make sure that all of the paper is properly aligned in the tray 1.

If the paper does not move when you pull, or if you do not see the paper in this area, stop and go to step 3.

3

Pull the upper tray half way out.

4

Pull the jammed paper straight up and out.

If the paper does not move when you pull, or if you do not see the paper in this area, check the fuser area around the toner cartridge.

See page 9.3.

3

Insert the tray 1 into the printer until it snaps into place. Printing automatically resumes.

5

Fully insert the trays back into the printer. Printing automatically resumes.

9.2

<Troubleshooting>

In the multi-purpose tray

1

If the paper is not feeding properly, pull the paper out of the printer.

2

Carefully lift up the guide feed.

1

2

Open and close the top cover to resume printing.

Around the toner cartridge

Note

• The fuser area is hot. Take care when removing paper from the printer.

1

Open the top cover and pull the toner cartridge out.

1

guide feed

3

Remove the jammed paper by gently pulling it straight out.

If you do not see the jammed paper or if there is any resistance removing the paper, stop pulling and go to the paper exit area. See

page 9.4.

4

Flip down the guide feed.

Caution

• To prevent damage to the toner cartridge, do not expose it to light for more than a few minutes. Cover it with a piece of paper, if necessary.

• Do not touch the green surface underside of the toner cartridge. Use the handle on the cartridge to avoid touching this area.

9.3

<Troubleshooting>

5

Replace the toner cartridge and close the top cover. Printing automatically resumes.

Note

• If it is difficult to reinstall the toner cartridge, make sure that the guide feed has been flipped back down into position.

In the paper exit area

1

Open and close the top cover. The jammed paper is automatically ejected from the printer.

2

Gently pull the paper out of the output tray.

In the duplex unit area

If the duplex unit is not inserted correctly, paper jam may occur. Make sure that the duplex unit is inserted correctly.

In the ML-4550 and ML-4551N, the optional duplex unit should be installed.

Duplex jam 0

1

Pull the duplex unit out of the printer.

If you do not see the jammed paper or if there is any resistance when you pull, stop and go to the next step.

3

Open the rear cover.

4

By pusing the fuser levers upwards, loosen the jammed paper.

Then gently pull the paper straight out.

2

Locate the jammed paper and remove it.

3

Insert the duplex unit into the slot.

4

Open and close the top cover. The printer will resume printing.

5

Put the fuser levers to their original position and close the rear cover. Printing automatically resumes.

9.4

<Troubleshooting>

Duplex jam 1

1

Open the rear cover.

2

Gently pull the jammed paper straight up.

3

Close the rear cover.

4

Open and close the top cover. The printer will resume printing.

Tips for avoiding paper jams

By selecting the correct media types, most paper jams can be avoided.

When a paper jam occurs, follow the steps outlined on page 9.1.

• Follow the procedures on page 5.5. Ensure that the adjustable guides

are positioned correctly.

• Do not overload the tray. Ensure that the paper level is below the paper capacity mark on the inside wall of the tray.

• Do not remove paper from the tray while your printer is printing.

• Flex, fan, and straighten paper before loading.

• Do not use creased, damp, or highly curled paper.

• Do not mix paper types in a tray.

• Use only recommended print media. See page 5.1.

• Ensure that the recommended print side of print media is facing down in the tray, or facing up in the multi-purpose tray.

9.5

<Troubleshooting>

Troubleshooting checklist

If the printer is not working properly, consult the following checklist. If the printer does not pass a step, follow the corresponding suggested solutions.

Condition

Make sure that the

Status LED on the control panel lights green and Ready is shown on the display.

Print a demo page to verify that the printer is feeding paper correctly. See

page 2.8.

Check the demo page to see if it printed correctly.

Print a short document from a software application to verify that the computer and printer are connected and are communicating correctly.

If completing the checklist does not resolve the printer problem, check the following troubleshooting sections.

Suggested solutions

• If the Status LED is off, check the power cord connection. Check the power switch.

Check the power source by plugging the power cord into another outlet.

• If the Status LED lights red, check the

display message. See page 9.6.

• If a demo page does not print, check the paper supply in the tray.

• If the paper jams in the printer, see page

9.1.

• If an error message appears on the

display, see page 9.6.

If there is a print quality problem, see page

9.11.

• If the page does not print, check the cable connection between the printer and the computer.

• Check the print queue or print spooler to see if the printer has been paused.

• Check the software application to ensure that you are using the proper printer driver and communication port. If the page is

interrupted during printing, see page 9.9.

• “Understanding the status LED” on page

9.6.

• “Understanding display messages” on page 9.6.

• “Solving general printing problems” on page 9.9.

• “Common Windows problems” on page

9.13.

• “Common PostScript problems” on page

9.13.

• “Common Linux problems” on page 9.14.

• “Common Macintosh problems” on page

9.14.

Understanding the status LED

Off

Status Description

• The printer is off-line and cannot print.

• The printer is in power save mode. When data is received, it switches to on-line automatically.

Green On The printer is on-line and can receive data from the computer.

Blinking • When the backlight blinks slowly, the printer is receiving data from the computer.

• When the backlight blinks quickly, the printer is printing data.

Red On • The toner is totally exhausted. Remove the old toner cartridge and install a new one.

See page 8.5.

• A paper jam has occurred. To solve the

problem, see page 9.1.

• The top cover is open. Close the top cover.

• There is no paper in the tray. Load paper in the tray.

• The toner cartridge installed is not a genuine cartridge, and you selected Stop at the

NonGenuine Toner prompt. See page 9.6.

• The lifespan of the toner cartridge is reached, and you selected Stop at the

Toner Exhausted prompt. See page 9.6.

• The printer has stopped printing due to a major error. Check the display message.

See page 9.6 for details on the meaning of

the error message.

Blinking • A minor error is occurring and the printer is waiting for the error to be cleared. Check the display message. When the problem is cleared, the printer resumes printing.

• The toner cartridge is low. Order a new toner cartridge. You can temporarily improve print quality by redistributing the toner. See page

8.4.

Understanding display messages

Messages appear on the Smart Panel program window or the control panel display to indicate the printer’s status or errors. Refer to the tables below to understand the messages’ meaning and correct the problem if necessary. Messages and their meanings are listed in alphabetical order.

Note

• When you call for service, it is very convenient to tell the service representative the display message.

Message

ADC Not

Confirm Error

Door Open

Duplex Jam 0

Check Inside

Duplex Jam 1

Open/Close Door

Fuser Door Open

Fuser is Cleaning

Inner Temp. Open

Cycle Power

Inner Temp. Error

Cycle Power

Meaning

There is a problem in your printer system.

The top cover or rear cover is not securely latched.

Paper has jammed during duplex printing.

Paper has jammed during duplex printing.

The fuser door is not securely latched.

Suggested solutions

Unplug the power cord and plug it back in. If the problem persists, please call for service.

Close the cover until it locks into place.

Clear the jam. See

page 9.4.

Clear the jam. See

page 9.5.

Open the rear cover and close the fuser door until it locks into place.

Please wait a few minutes.

Your printer is printing a Cleaning sheet now.

There is a problem in your printer system.

There is a problem in your printer system.

Unplug the power cord and plug it back in. If the problem persists, please call for service.

Unplug the power cord and plug it back in. If the problem persists, please call for service.

9.6

<Troubleshooting>

Load

Message

[Size] In [Tray]

Load Manual

Press Cont Key

Low Heat Error

Cycle Power

LSU Motor Error

Cycle Power

MP Tray

Paper Empty

OPC is Cleaning

Open Heat Error

Cycle Power

Out-Bin Full

Over Heat Error

Cycle Power

Paper Exit Jam 1

Open/Close Door

Meaning

The paper size specified in the printer properties does not match the paper you are loading.

The multi-purpose tray is empty in manual feed mode.

Suggested solutions

Load the correct paper in the tray.

There is a problem in the fuser unit.

A problem has occurred in the LSU

(Laser Scanning

Unit).

Load a sheet of print media and press OK.

You need to press

OK each page to be printed.

Unplug the power cord and plug it back in. If the problem persists, please call for service.

Unplug the power cord and plug it back in. If the problem persists, please call for service.

Load paper in the multi-purpose tray.

See page 5.6.

Please wait a few minutes.

There is no paper in the multi-purpose tray.

Your printer is printing a cleaning sheet now.

There is a problem in the fuser unit.

The output tray is full.

There is a problem in the fuser unit.

Paper has jammed before reaching to the exit sensor.

Unplug the power cord and plug it back in. If the problem persists, please call for service.

It can hold up to 250 sheets of plain paper.

Once the paper is removed from the output tray, the printer resumes printing.

Unplug the power cord and plug it back in. If the problem persists, please call for service.

Clear the jam. See

page 9.3.

9.7

<Troubleshooting>

Message

Paper Jam 0

Open/Close Door

Paper Jam 1

Open/Close Door

Paper Jam 2

Check Inside

Paper [Tray] Jam

Open [Tray]

Printing...

Ready

Self Diagnostic

LSU

Self Diagnostic

Temperature

Sleeping...

[Tray]

Cassette Out

[Tray]

Paper Empty

Warming Up

Please Wait...

Meaning

Paper has jammed in the feeding area of the tray.

Paper has jammed in the fuser area.

Suggested solutions

Clear the jam. See

page 9.2.

Clear the jam. See

page 9.3.

There are toner powders on a feed sensor.

Paper has jammed in the paper exit area.

Paper has jammed in the displayed optional tray.

The printer is printing jobs.

The printer is on-line and ready to print.

The LSU (Laser

Scanning Unit) in your printer is checking some problems detected.

The engine in your printer is checking some problems detected.

The printer is in power save mode.

Clean a feed sensor.

see page 8.1.

Clear the jam. See

page 9.4.

Clear the jam. See

page 9.2.

Complete your printing.

Use your printer.

Please wait a few minutes.

Please wait a few minutes.

The displayed tray is open.

When data is received, it switches to on-line automatically.

Close the tray until it locks into place.

There is no paper in the tray.

Load paper in the

tray. See page 5.5.

Your printer is warming up now.

Please wait a few minutes.

Toner cartridge-related messages

Message

Install Toner

Invalid Toner

Toner Low

NonGenuine Toner

Stop

NonGenuine Toner

Replace Toner1

NonGenuine Toner

Replace Toner

Toner Low

Replace Toner

Replace Toner

Toner Exhausted

Stop

Toner Exhausted

Replace Toner1

Toner Exhausted

Replace Toner

The toner cartridge installed is not a genuine cartridge.

The toner cartridge installed is not a genuine cartridge.

out.

out.

The lifespan of the toner cartridge is reached.

The lifespan of the toner cartridge is reached.

Meaning

A toner cartridge is not installed.

The toner cartridge you have installed is not for your printer.

The toner cartridge is almost empty.

The toner cartridge installed is not a genuine cartridge.

The toner in the cartridge has run

The toner in the cartridge has run

The lifespan of the toner cartridge is reached.

Install a toner cartridge.

Suggested solutions

Install a Samsung-genuine toner cartridge, designed for your printer.

Take out the toner cartridge and thoroughly shake it. By doing this, you can temporarily reestablish printing operations.

You can select either Stop or Continue. If you do not select any, the printer will work as

Stop is selected.

If you select Stop, you cannot print until the genuine cartridge is installed. However, you can still print any kind of reports.

If you select Continue, you can keep printing but the quality cannot be guaranteed, and the product support is no longer provided.

If you want to change the selection, turn the printer off and on to have this message appear again, and then re-select Stop or Continue.

This message appears when you selected Stop at the NonGenuine Toner prompt.

Install the genuine toner cartridge.

This message appears when you selected Continue at the NonGenuine Toner prompt.

Install the genuine toner cartridge.

Install a new genuine toner cartridge.

You can keep printing but the quality cannot be guaranteed, and the product support is no longer provided.

You can configure not to see the Toner Low Replace Toner message. See page 8.4.

This message appears when you turned off the Toner Low Replace Toner message. See page 8.4.

Install a new genuine toner cartridge.

You can keep printing but the quality cannot be guaranteed, and the product support is no longer provided.

You can select either Stop or Continue. If you do not select any, the printer will work as

Stop is selected.

If you select Stop, you cannot print until the genuine cartridge is installed.

If you select Continue, you can keep printing but the quality cannot be guaranteed, and the product support is no longer provided.

If you want to change the selection, turn the printer off and on to have this message appear again, and then re-select Stop or Continue.

This message appears when you selected Stop at the Toner Exhausted prompt.

Install the genuine toner cartridge.

This message appears when you selected Continue at the Toner Exhausted prompt.

Install the genuine toner cartridge.

9.8

<Troubleshooting>

Solving general printing problems

For problems with the operation of your printer, refer to the table for suggested solutions.

Condition

The printer does not print.

Possible cause Suggested solutions

The printer is not receiving power.

The printer is not selected as the default printer.

Check the power cord connections. Check the power switch and the power source.

Select Samsung ML-4550

Series PCL 6 or Samsung ML-

4550 Series PS as your default printer.

The printer cover is not closed.

Close the printer cover.

Paper is jammed.

Clear the paper jam. See page

9.1.

No paper is loaded.

The toner cartridge is not installed.

The printer may be in manual feed mode and out of paper.

The connection cable between the computer and the printer is not connected properly.

The connection cable between the computer and the printer is defective.

The port setting is incorrect.

Load paper. See page 5.4.

Install the toner cartridge.

Check the display message, add paper to the multi-purpose tray, and press OK on the printer’s control panel.

Disconnect the printer cable and reconnect it.

If possible, attach the cable to another computer that is working properly and try to print a document. You can also try using a different printer cable.

Check the Windows printer setting to make sure that the print job is sent to the correct port. If the computer has more than one port, make sure that the printer is attached to the correct one.

Condition

The printer does not print.

(Continued)

Printer selects print media from the wrong paper source.

Paper does not feed into the printer.

Print job is extremely slow.

Possible cause

The printer may be configured incorrectly.

The printer driver may be incorrectly installed.

The printer is malfunctioning.

Suggested solutions

Check the printer properties to ensure that all of the print settings are correct.

Reinstall the printer driver; See the Software Section. Try printing a test page.

The paper source selection in the printer properties may be incorrect.

Paper has not been loaded correctly.

There is too much paper in the tray.

The paper is too thick.

The job may be very complex.

Check the display message on the control panel to determine if the printer is indicating a system error.

For many software applications, the paper source selection is found under the

Paper tab within the printer properties. Select the correct paper source. See the

Software Section.

Remove paper from the tray and reload it correctly.

Check that the paper size guides are set correctly.

Remove excess paper from the tray.

Use only paper that meets printer specifications.

Reduce the complexity of the page(s) or try adjusting the print quality settings.

To adjust the print quality settings, reduce the resolution.

If you have set the resolution to

1200 dpi (Best), change it to

600 dpi (Normal). See the

Software Section.

Change the port setting to the

USB or network port to improve print speed.

Your printer prints A4-sized paper at 43 ppm and lettersized paper at 45 ppm. If you use the ML-4551ND and install an option duplex unit in the ML-

4550 or ML-4551N, your printer prints A4-sized paper at 29 ipm and letter-sized paper at 30 ipm in the duplex printing mode.

9.9

<Troubleshooting>

Condition

Print job is extremely slow.

(Continued)

Possible cause

If using Windows

98/Me, the

Spooling Setting may be set incorrectly.

Suggested solutions

From the Start menu, choose

Settings and Printers. Rightclick the Samsung ML-4550

Series PCL 6 printer icon, choose Properties, click the

Details tab, and then choose the Spool Settings button.

Select the desired spool setting.

Install more memory in your

printer. See page 10.1.

Half the page is blank.

The computer may have insufficient random-access memory (RAM).

The page layout is too complex.

The paper keeps jamming.

The page orientation setting may be incorrect.

The paper size and the paper size settings do not match.

There is too much paper in the tray.

An incorrect type of paper is being used.

An incorrect output method is being used.

There may be debris inside the printer.

Simplify the page layout and remove any unnecessary graphics from the document.

Install more memory in your

printer. See page 10.1.

Change the page orientation in your application. See the

Software Section.

Ensure that the paper size in the printer driver settings matches the paper in the tray.

Or, ensure that the paper size in the printer driver settings matches the paper selection in the software application settings you use.

Remove excess paper from the tray.

If printing on special media, use the multi-purpose tray and open the rear cover.

Use only paper that meets printer specifications.

If printing on special media, use the multi-purpose tray and open the rear cover.

Special print media, such as thick paper, should not be printed using the output tray

(face-down). Use the rear cover (face-up) instead.

Open the top cover and remove the debris.

9.10

<Troubleshooting>

Condition

The printer prints, but the text is wrong, garbled, or incomplete.

Pages print, but are blank.

The illustrations print incorrectly in

Adobe

Illustrator.

Possible cause

The printer cable is loose or defective.

The wrong printer driver was selected.

The software application is malfunctioning.

The operating system is malfunctioning.

Suggested solutions

Disconnect and reconnect the printer cable. Try a print job that you have already printed successfully. If possible, attach the cable and printer to another computer and try a print job that you know works. Finally, try a new printer cable.

Check the application’s printer selection menu to ensure that your printer is selected.

Try printing a job from another application.

The toner cartridge is defective or out of toner.

The file may have blank pages.

Some parts, such as the controller or the board, may be defective.

The setting in the software application is wrong.

If printing from Windows (any version), exit to a DOS prompt and verify functionality with the following command: At a C:\ prompt, type Dir LPT1, and press Enter. (This assumes you are connected to LPT1.)

Exit Windows and reboot the computer. Turn the printer off and then back on again.

Redistribute the toner

cartridge. See page 8.4.

If necessary, replace the toner

cartridge. See page 8.5.

Check the file to ensure that it does not contain blank pages.

Contact a service representative.

Select Download as Bitmap in the Advanced Options window of the graphic properties. Print the document again.

Solving print quality problems

Dirt inside of the printer or improper paper loading may reduce print quality. See the table below to troubleshoot problems.

Condition

Light or faded print

Aa

Aa

Aa

Aa

Aa

B b

B b

B b

B b

B b

C c

C c

C c

C c

C c

Toner spots

Aa

Aa

Bb

Bb

Cc

Cc

Aa Bb Cc

Aa Bb Cc

Aa Bb Cc

Suggested solutions

If a vertical white streak or faded area appears on the page:

• The toner supply is low. You may be able to temporarily extend the toner cartridge life. See

page 8.4. If this does not improve print quality,

install a new toner cartridge.

• The paper may not meet paper specifications

(for example, the paper is too moist or too

rough). See page 5.3.

• If the entire page is light, the print resolution setting is too light or toner save mode is on.

Adjust the print resolution and toner save mode in the printer properties. See the

Software Section.

• If the entire page is faded with "Toner Low

Replace Toner" message on LCD, set "CLR Empty Msg." to "On" referring to

page 8.7. In this case, you can keep printing

but the quality cannot be guaranteed, and the product support is no longer provided.

• A combination of faded or smeared defects may indicate that the printer needs cleaning.

See page 8.1.

• The surface of LSU may be dirty. Clean the

LSU. See page 8.2.

• The paper may not meet specifications (for example, the paper is too moist or too rough).

See page 5.3.

• The transfer roller or paper path may be dirty.

See page 8.1.

Condition

Dropouts

AaBbCc

AaBbCc

AaBbCc

AaBbCc

AaBbCc

Vertical lines

Gray background

AaBbCc

AaBbCc

AaBbCc

AaBbCc

AaBbCc

Toner smear

Suggested solutions

If generally rounded, faded areas occur randomly on the page:

• A single sheet of paper may be defective. Try reprinting the job.

• The moisture content of the paper is uneven or the paper has moist spots on its surface.

Try a different brand of paper. See page 5.3.

• The paper lot is bad. The manufacturing processes can cause some areas to reject toner. Try a different kind or brand of paper.

• The toner cartridge may be defective. See

“Vertical repetitive defects” on the next page.

• If these steps do not correct the problems, contact a service representative.

If black vertical streaks appear on the page:

• The drum inside the toner cartridge has probably been scratched. Install a new toner

cartridge. See page 8.5.

If white vertical streaks appear on the page:

• The surface of the LSU part inside the printer

may be dirty. Clean the LSU. See page 8.2.

If the amount of background shading becomes unacceptable, the procedures below may fix the problem.

• Change to lighter weight pages. See page 5.3.

• Check the printer’s environment; very dry (low humidity) or high humidity (higher than 80%

RH) conditions can increase the amount of background shading.

• Remove the old toner cartridge and install a

new one. See page 8.5.

• Clean the inside of the printer. See page 8.1.

• Check the type and quality. See page 5.2.

• Remove the toner cartridge and install a new

one. See page 8.5.

9.11

<Troubleshooting>

Condition

Vertical repetitive defects

AaB bC c

AaB bC c

AaB bC c

AaB bC c

AaB bC c

Background scatter

A

Misformed characters

Page skew

AaBbCc c

AaBbCc

AaBbCc

Suggested solutions

If marks repeatedly appear on the printed side of the page at even intervals:

• The toner cartridge may be damaged. If a repetitive mark occurs on the page, print a cleaning sheet several times to clean the

cartridge; see page 8.3. After the printout, if

you still have the same problems, install a new

toner cartridge. See page 8.5.

• Parts of the printer may have toner on them. If the defects occur on the back of the page, the problem will likely correct itself after a few more pages.

• The fusing assembly may be damaged.

Contact a service representative.

Background scatter results from bits of toner distributed on the printed page.

• The paper may be too damp. Try printing with a different batch of paper. Do not open packages of paper until necessary so that the paper does not absorb too much moisture.

• If background scatter occurs on an envelope, change the printing layout to avoid printing over areas that have overlapping seams on the reverse side. Printing on seams can cause problems.

• If background scatter covers the entire surface area of a printed page, adjust the print resolution through your software application or via the printer properties window.

• If characters are improperly formed and producing hollowed images, the paper stock may be too slick. Try a different paper. See

page 5.3.

• If characters are improperly formed and producing a wavy effect, the scanner unit may need service. Verify that it also occurs on a

demo page (see page 2.8). For service,

contact a service representative.

• Ensure that the paper is loaded properly.

• Check the paper type and quality. See page

5.2.

• Ensure that the paper or other media is loaded correctly and the guides are not too tight or too loose against the paper stack.

Condition

Curl or wave

Suggested solutions

• Ensure that the paper is loaded properly.

• Check the type and quality. Both high temperature and humidity can cause paper

curl. See page 5.2.

• Turn over the stack of paper in the tray. Also try rotating the paper 180° in the tray.

• Try printing to the rear cover (face-up).

Wrinkles or creases

• Ensure that the paper is loaded properly.

• Check the paper type and quality. See page

5.2.

• Open the rear cover and try printing to the rear cover (face-up).

• Turn over the stack of paper in the tray. Also try rotating the paper 180° in the tray.

Back of printouts are dirty

• The transfer roller may be dirty. See page 8.1.

• Check for leaking toner. Clean the inside of the printer.

Solid color or

Black pages

A

Loose toner

• The toner cartridge may not be installed properly. Remove the cartridge and reinsert.

• The toner cartridge may be defective and need replacing. Install a new toner cartridge.

• The printer may require repair. Contact a service representative.

• Clean the inside of the printer.

• Check the paper type and quality. See page

5.2.

• Install a new toner cartridge. See page 8.5.

• If the problem persists, the printer may require repair. Contact a service representative.

9.12

<Troubleshooting>

Curl

Condition Suggested solutions

Character Voids

Character voids are white areas within characters that should be solid black:

A

• If you are using transparencies, try another type of transparency. Because of the composition of the transparency, some character voids may be normal.

• You may be printing on the wrong surface on the paper. Remove the paper and turn it around.

• The paper may not meet paper specifications.

See page 5.3.

Horizontal stripes

AaBbCc

AaBbCc

AaBbCc

AaBbCc

AaBbCc

If horizontally aligned black streaks or smears appear:

• The toner cartridge may be installed improperly. Remove the cartridge and reinsert.

• The toner cartridge may be defective. Install a

new toner cartridge. See page 8.5.

• If the problem persists, the printer may require repair. Contact a service representative.

If the printed paper is curled or paper does not feed into the printer:

• Turn over the stack of paper in the tray. Also try rotating the paper 180° in the tray.

• Try printing to rear cover (face up).

An unknown image repetitively appears on a next few sheets or loose toner, light print or contamination occurs.

Your printer is probably being used at an altitude of 2,500 m (8,200 ft) or above.

The high altitude may affect the print quality such as loose toner or light imaging. You can set this option through Printer Settings Utility or

Printer Tab in printer driver’s properties. Refer to the Software Section for details.

Common Windows problems

Condition

“File in Use” message appears during installation.

Suggested solutions

Exit all software applications. Remove all software from the StartUp Group, then restart

Windows. Reinstall the printer driver.

Condition

“Error Writing to

LPTx” message appears.

Suggested solutions

• Ensure that the cables are connected correctly, the printer is on.

• If bi-directional communication is not turned on in the driver, it will also cause this message.

Close all other applications, reboot Windows, and try printing again.

“General Protection

Fault”, “Exception

OE”, “Spool32”, or

“Illegal Operation” messages appear.

“Fail To Print,” “A printer timeout error occurred,” messages appear.

These messages may appear during printing.

Just keep waiting until the printer finishes printing. If the message appears in standby mode or after printing has been completed, check the connection and/or whether an error has occurred.

Note

• Refer to Microsoft Windows 98/Me/NT 4.0/2000/XP/2003

User’s Guide that came with your PC for further information on

Windows error messages.

Common PostScript problems

The following situations are PostScript language specific and may occur when several printer languages are being used.

Note

• To receive a printed or screen displayed message when

PostScript errors occur, open the Print Options window and click the desired selection next to the PostScript errors section.

Condition

PostScript file can not be printed.

“Limit Check

Error” message appears.

Possible cause

The PostScript driver may not be installed correctly.

Suggested solutions

• Print a configuration page and verify that the PostScript version is available for printing.

• Install the PostScript driver; to installing the PS printer driver, see the Software

Section.

• If problem consists, contact a service representative.

The print job was too complex.

You might need to reduce the complexity of the page or install more memory.

9.13

<Troubleshooting>

Condition

A PostScript error page prints.

The optional tray 2 (tray 3 or tray 4) is not selected in the driver.

When print a document in

Macintosh with

Acrobat Reader

6.0 or higher, colors print incorrectly.

Possible cause

Print job may not be

PostScript.

The printer driver has not been configured to recognize the optional tray 2

(tray 3 or tray

4).

The resolution setting in the printer driver may not be matched with that in Acrobat

Reader.

Suggested solutions

Make sure that the print job is a

PostScript job. Check to see whether the software application expected a setup or

PostScript header file to be sent to the printer.

Open the PostScript driver properties, select the Device

Settings tab, and set the Tray2

(Tray3 or Tray4) option of the

Installable Options section to

Installed.

Make sure that the resolution setting in your printer driver matches that in Acrobat

Reader.

Common Linux problems

Condition

The printer doesn’t print.

Suggested solutions

• Check if the printer driver is installed in your system. Open Unified Driver Configurator and switch to the Printers tab in Printers configuration window to look at the list of available printers. Make sure that your machine is displayed on the list. If not, please, invoke Add new printer wizard to set up your device.

• Check if the printer is started. Open Printers configuration and select your machine on the printers list. Look at the description in the Selected printer pane. If its status contains “(stopped)” string, please, press the OK button. After that normal operation of the printer should be restored. The

"stopped" status might be activated when some problems in printing occurred.

Condition

I encounter error

“Unable to open mfp port device file!” when printing a document.

Suggested solutions

Please avoid changing print job parameters

(via LPR GUI, for example) while a print job is in progress. Known versions of CUPS server break the print job whenever print options are changed and then try to restart the job from the beginning. Since Unified Linux Driver locks mfp port while printing, the abrupt termination of the driver keeps the port locked and therefore unavailable for subsequent print jobs. If this situation occurred, please, try to release the mfp port.

Common Macintosh problems

Condition

The printer does not print a document from

Acrobat Reader.

The document has printed, but the print job has not disappeared from the spooler in Mac

OS 10.3.2.

The printer does not print a document from

Illustrator on IPP printing.

Suggested solutions

Change the Print Method option to Print

as Image when you print from Acrobat

Reader.

Update your Mac OS to OS 10.3.3 or higher.

Change the Data type option in the

Adobe Illustrator print menu to Binary.

Or, you can use Appletalk printing.

9.14

<Troubleshooting>

10

Installing accessories

Your printer is a full-featured laser printer that has been optimized to meet the majority of your printing needs. Recognizing that each user may have different requirements, however, Samsung makes several accessories available to enhance the printer’s capabilities.

This chapter includes:

Precautions when installing accessories

Installing a dual in-line memory module (DIMM)

Installing a network interface card

Using the hard disk

Precautions when installing accessories

Disconnect the power cord:

Never remove the control board cover while the printer is plugged in.

To avoid the possibility of an electrical shock, always disconnect the power cord when installing or removing ANY internal or external accessories.

Discharge static electricity:

The control board and internal accessories (network interface card,

DIMM, and hard disk) are sensitive to static electricity. Before installing or removing internal accessories, discharge static electricity from your body by touching something metal, such as the metal back plate on any device plugged into a grounded power source. If you walk round before finishing installation, discharge any static electricity once again.

Installing a dual in-line memory module (DIMM)

Your printer has a dual in-line memory module (DIMM) slot. Use this

DIMM slot to install additional memory.

Your printer has 128 MB of memory which can be expanded to 512 MB.

For information about ordering optional DIMMs, see page 7.1.

1

Turn the printer power off and unplug the power cord and printer cable from the printer.

2

Remove the duplex-slot cover or the duplex unit from the back of the printer.

1

1

duplex-slot cover

10.1

<Installing accessories>

3

Grasp the control board cover and remove it.

7

Close the control board cover by aligning the groove on it with the notch on the printer and sliding it.

4

Take out a new DIMM from its plastic bag.

5

Locate the extra DMM slot and align the notch on the DIMM with the groove at the DIMM slot, holding the DIMM by its edges.

1

2

1

2

notch groove

6

Push the DIMM into the printer until it snaps into place. Make sure that the latches fit over the notches located on either side of the

DIMM.

8

Reinstall the duplex-slot cover or the duplex unit.

9

Reconnect the power cord and printer cable, and turn the printer on.

Setting the memory in the PostScript printer properties

After installing the DIMM, you need to select it in the printer properties of the PostScript printer driver to enable its use.

1

Make sure that the PostScript printer driver is installed on your computer. To install the PostScript printer driver, see the Software

Section.

2

Click the Windows Start menu.

3

For Windows 98/Me/NT 4.0/2000, select Settings and then

Printers.

For Windows XP/2003, select Printers and Faxes.

4

Select the Samsung ML-4550 Series PS printer.

5

Click the right mouse button on the printer icon and select

Properties.

6

For Windows 98/Me, select the Device Option tab.

For Windows NT 4.0/2000/XP/2003, select the Device Settings tab.

7

Select the amount of memory you installed from Printer Memory in the Installable Options section.

For Windows 98, select Installable Options

VMOption

change setting for:NMOption

change memory.

8

Click OK.

10.2

<Installing accessories>

Removing a DIMM

To expand the printer memory to 512 MB, you need to remove the preinstalled 128 MB DIMM and install two 256 MB DIMMs into the DIMM slots.

Push the latches at both ends of the DIMM slot away to remove the

DIMM and pull out the DIMM.

2

Remove the duplex-slot cover or the duplex unit from the back of the printer.

1

2

1

2

latch

DIMM

Installing a network interface card

The ML-4551N and ML-4551ND are equipped with wired network interface cards, allowing you to use your printer on a network.

To use the ML-4550 in network environments, you need to buy an

optional network interface card. For order information, see page 7.1.

Review the precautions on page 10.1 and then follow this procedure to

install a network interface card in your printer.

1

Turn the printer power off and unplug the power cord and printer cable from the printer.

1

1

duplex-slot cover

3

Grasp the control board cover and remove it.

Note

• Knowing the connectors’ name and location will make it easy to install the accessories.

1 2

1

2

hard disk connector wired network connector

10.3

<Installing accessories>

4

Align the connector on the wired network interface card with the connector on the control board. Push the card firmly into the connector on the control board until it is completely and securely in place.

1

2

Using the hard disk

Installing the hard disk allows the data from your computer to be sent to the print queue of the printer hard disk. This decreases the workload of the computer. You can also use various print features, such as storing a job in the hard disk, proofing a job, and printing private documents.

Installing the hard disk

For order information, see page 7.1.

Review the precautions on page 10.1.

1

Turn the printer power off and unplug the power cord and printer cable from the printer.

2

Remove the duplex-slot cover or the duplex unit from the back of the printer.

1

wired network connector

2

wired network interface card

5

Insert and tighten the two screws supplied with your network card.

1

1

duplex-slot cover

3

Grasp the control board cover and remove it.

6

Close the control board cover by aligning the groove on it with the notch on the printer and sliding it.

7

Reinstall the duplex-slot cover or the duplex unit.

8

Reconnect the power cord and printer cable (if necessary), and turn the printer on.

10.4

<Installing accessories>

4

Align the connector on the hard disk with the connector on the control board. Push the hard disk in until it is latched into place.

5

Fasten the four screws supplied with your new hard disk.

Setting the hard disk in the printer properties

After installing the hard disk, you need to select it in the printer properties to enable its use. Take the following steps:

1

Click the Windows Start menu.

2

For Windows 98/Me/NT 4.0/2000, select Settings and then

Printers.

For Windows XP/2003, select Printers and Faxes.

3

Select the Samsung ML-4550 Series PCL 6 printer icon or

Samsung ML-4550 Series PS printer icon.

4

Click the right mouse button on the printer icon and select

Properties.

5

In PCL 6 Properties, click the Printer tab and then check Optional

Hard Disk Drive (HDD).

In PS Properties, click the Device Option or Device Settings tab and set the Optional Hard Disk Drive (HDD) option to Installed.

6

Click OK.

6

Close the control board cover by aligning the groove on it with the notch on the printer and sliding it.

7

Reinstall the duplex-slot cover or the duplex unit.

8

Reconnect the power cord and printer cable, and turn the printer on.

9

Print a configuration page from the control panel to check if the

hard disk is correctly installed. See page 8.1.

10.5

<Installing accessories>

Printing with the optional hard disk

After installing the optional hard disk, you can use advanced printing features, such as storing or spooling a print job to the hard disk, proofing a job, and specifying of printing a private job in the printer properties window.

Once you have stored files in the hard disk, you can easily print or delete the stored files using the control panel of your printer.

Setting the time and date

1

Press Menu until System Setup appears on the bottom line of the display and press OK.

2

Press OK when Date & Time appears.

3

Press the Scroll buttons until the digit you want appears and press

OK.

You can enter from 2000 to 2065 in the year input section. The cursor moves to the next position.

4

Repeat step 3 until all digits appear correctly.

5

Press OK.

Storing a job

You can store jobs in the installed hard disk.

1

Open the file you want to store.

2

Select Print from the File menu. The Print window displays.

3

Click Properties. If you see Setup, Print or Options, click the button instead.

4

Click the Extra tab and click Print and Hold.

5

Select the print mode you want from the drop-down list.

Normal: prints in normal mode.

Proof: prints the first file and after a pause prints the next file.

Confidentical: stores the files, securing them with a password.

Store: stores the file to the hard disk.

Spool: spools the file into the hard disk and prints it from the hard disk queue.

Delay: prints the file at a specified time.

6

Enter the user’s name and file name.

7

Click OK until the Print window is displayed.

8

Click OK or Print to start printing.

Printing a stored job

You can print jobs currently stored in the hard disk.

1

Press Menu until Job Manage. appears on the bottom line of the display and press OK.

10.6

<Installing accessories>

2

Press the Scroll buttons until Store Job appears and press OK.

3

Press the Scroll buttons until the user’s name and file name you want appear and press OK.

4

If the select file is a confidential print job, enter the specified 4-digit password.

Press the Scroll buttons to enter the first digit and press OK. The cursor automatically moves to the next digit position. Enter the 2nd,

3rd, and 4th digit in the same way.

5

When Print appears, press OK.

If you enter the incorrect password, Invalid Password appears.

Reenter the correct password.

6

Press the Scroll buttons until the number of copies you want appears and press OK.

7

Press OK. Printing starts.

Deleting a stored job

You can delete jobs currently stored in the hard disk.

1

Press Menu until Job Manage. appears on the bottom line of the display and press OK.

2

Press the Scroll buttons until Store Job appears and press OK.

3

Press the Scroll buttons until the user’s name and file name you want appear and press OK.

4

If the select file is a confidential print job, enter the specified 4-digit password.

Press the Scroll buttons to enter the first digit and press OK. The cursor automatically moves to the next digit position. Enter the 2nd,

3rd, and 4th digit in the same way.

5

Press the Scroll buttons until Delete appears and press OK.

If you enter the incorrect password, Invalid Password appears.

Reenter the correct password.

6

When Yes appears, press OK.

Controlling the active job queue

All of the print jobs waiting to be printed are listed in the Active Job

Queue in the order you sent them to the printer. You can delete a job from the queue before printing, or promote a job to print sooner.

To delete a file from the queue:

1

Press Menu until Job Manage. appears on the bottom line of the display and press OK.

2

Press the Scroll buttons until Active Job appears and press OK.

3

Press the Scroll buttons until the user’s name and file name you want appear and press OK.

4

If the select file is a confidential print job, enter the specified 4-digit password.

Press the Scroll buttons to enter the first digit and press OK. The cursor automatically moves to the next digit position. Enter the 2nd,

3rd, and 4th digit in the same way.

5

Press the Scroll buttons until Cancel appears and press OK.

If you enter the incorrect password, Invalid Password appears.

Reenter the correct password.

6

Press the Scroll buttons until Yes appears and press OK.

To promote a file from the queue:

You can select a job waiting in the Active Job Queue and change its print order so that it can be printed sooner.

1

Press Menu until Job Manage. appears on the bottom line of the display and press OK.

2

Press the Scroll buttons until Active Job appears and press OK.

3

Press the Scroll buttons until the user’s name and file name you want appear and press OK.

4

If the select file is a confidential print job, enter the specified 4-digit password.

Press the Scroll buttons to enter the first digit and press OK. The cursor automatically moves to the next digit position. Enter the 2nd,

3rd, and 4th digit in the same way.

5

Press the Scroll buttons until Promote appears and press OK.

If you enter the incorrect password, Invalid Password appears.

Reenter the correct password.

To print a file immediately:

You can print a job scheduled to be printed at a specified time immediately. In this case, the job currently printing is stopped and the selected job will be printed. This function is available when the job is scheduled for later printing.

1

Press Menu until Job Manage. appears on the bottom line of the display and press OK.

2

Press the Scroll buttons until Active Job appears and press OK.

10.7

<Installing accessories>

3

Press the Scroll buttons until the user’s name and file name you want appear and press OK.

4

If the select file is a confidential print job, enter the specified 4-digit password.

Press the Scroll buttons to enter the first digit and press OK. The cursor automatically moves to the next digit position. Enter the 2nd,

3rd, and 4th digit in the same way.

5

Press the Scroll buttons until Release appears and press OK.

This option appears only when you select a Delay print job. See

page 10.6.

If you enter the incorrect password, Invalid Password appears.

Reenter the correct password.

Printing using the form files

You can store up to 10 form files in the hard disk and make them printed with your document.

First, you need to create a form file using the printer driver. See the

Software Section.

1

Press Menu until System Setup appears on the bottom line of the display and press OK.

2

Press the Scroll buttons until Form Menu appears and press OK.

3

Press the Scroll buttons until the form you want appears and press

OK.

Off: prints in normal mode.

Single Form: prints all page using the first form.

Double Form: prints the front page using the first form and the back page using the second form.

4

Press Back to return to the upper menu level.

5

Press the Scroll buttons until Select Form appears and press OK.

6

Press OK when 1st Form appears.

7

Press the Scroll buttons until the form file you want appears and press OK.

If you select Double Form, continue the next step.

8

Press the Scroll buttons until 2nd Form appears and press OK.

9

Press the Scroll buttons until the form file for the second form appears and press OK.

11

Specifications

Printer specifications

Item

Printing speed

Resolution

Warm-up time

First print out time

Power rating

Power consumption

Noise level b a

Specifications and Description

Up to 43 ppm in A4 (45 ppm in Letter)

Duplex: 29 ipm (A4); 30 ipm (Letter)

Up to 1200 x 1200 dpi

Less than 45 seconds

8.5 seconds (From Ready)

Sleep mode: 35 seconds

110 - 127 VAC or 220 - 240 VAC

See the Rating label on the machine for the correct voltage, hertz and current of your machine.

Average: 650 W

Power save mode: Less than 13 W

Standby mode: Less than 35 dBA

Printing mode: Less than 57 dBA

10,000 or 20,000 pages.

Toner cartridge yield c

Duty cycle

Weight

Package weight

Display

Monthly: Up to 200,000 pages

ML-4550,

ML-4551N

ML-4551ND

ML-4550,

ML-4551N

21.6 Kg (including consumables)

23.5 Kg (including consumables)

Paper: 2.8 Kg, Plastic: 0.7 Kg

External dimensions

(W x D x H)

ML-4551ND

ML-4550,

ML-4551N

ML-4551ND

Paper: 3.0 Kg, Plastic: 0.8 Kg

15.6 X 17.8 X 13.9 inches

(396 X 453 X 353 mm)

15.6 X 19.7 X 13.9 inches

(396 X 501 X 353 mm)

Operating environment

Temperature: 50° F to 90° F (10° C to 32.5° C)

Humidity: 20% to 80% RH

Printer language PCL 6 d

, PostScript 3, IBM ProPrinter, EPSON

Memory 128 MB (Max. 512 MB)

128, or 256 MB optional memory available.

Use only the Samsung-approved DIMM.

128 MB: ML-MEM150

256 MB: ML-MEM160

16 characters x 2 lines

11.1

<Specifications>

Fonts

Item

Interface

Specifications and Description

1 bitmap, 45 scalable, 136 PostScript 3 fonts,

Bar Code fonts, OCR fonts

• IEEE 1284 Bidirectional Parallel Standard

- Modes supported: Compatible, Nibble, Byte,

ECP

• USB Interface Standard

- USB 2.0 compliant

- 480 Mbps 1 port

• Network Interface

- ML-4551N, ML-4551ND: enthernet 10/100

Base TX wired LAN

OS compatibility • Windows 98/Me/NT 4.0/2000/XP/2003

• Various Linux OS

• Mac 8.6 ~ 9.2/10.1 ~ 10.4

Printer drivers e

• PCL driver: Windows 98/Me/NT 4.0/2000/XP/

2003

• Various Linux OS

• PostScript driver: Windows 98/Me/NT 4.0/

2000/XP/2003, Macintosh OS 8.6 ~ 9.2/

10.1 ~ 10.4

Options ML-4550

ML-4551N,

ML-4551ND

500-sheet trays, ethernet 10/

100 Base TX wired LAN, hard disk, duplex unit, DIMM

500-sheet trays, hard disk, duplex unit, DIMM

500-sheet trays, hard disk,

DIMM a. Print speed will be affected by operating system used, computing performance, application software, connection method, media type, media size, and job complexity.

b. Sound pressure Level, ISO7779 c. Average cartridge yield declared in accordance with ISO/IEC 19752.

The number of pages may be affected by operating environment, printing interval, media type, and media size.

d. Compatible with PCL6 Version 2.1 e. Please visit www.samsungprinter.com

to download the latest software version.

11.2

<Specifications>

I

NDEX

A

accessories installing

DIMM 10.1

hard disk 10.4

network interface card/device 10.3

order information 7.1

C

cleaning

drum 8.3

inside 8.1

outside 8.1

cleaning sheet, print 8.3

component location 1.3

control panel

buttons 1.4

menus 2.1

status LED 9.6

D

demo page, print 2.8

DIMM, install 10.1

display language, change

control panel 2.8

display messages 9.6

drum, clean 8.3

E

error messages 9.6

H

hard disk

installing 10.4

use 10.6

I

installing accessories

hard disk 10.4

memory 10.1

network interface card/device 10.3

J

jam, clear 9.1

L

Linux problems 9.14

loading paper

multi-purpose tray 5.6

tray 5.5

M

Macintosh problems 9.14

maintenance parts 8.7

manual feed mode 5.7

memory 10.1

multi-purpose tray 5.6

N

network interface card/device, install 10.3

network setup

EtherTalk 4.2

IPX frame types 4.3

operating systems 4.2

TCP/IP 4.2

O

output location, select 5.8

output tray 5.8

P

paper guidelines 5.3

paper jam, clear

around the toner cartridge 9.3

duplex area 9.4

multi-purpose tray 9.3

optional tray 2 9.2

optional tray 3 9.2

optional tray 4 9.2

paper exit area 9.4

tray 1 9.2

paper level indicator 5.4

paper load

multi-purpose tray 5.6

tray 5.5

paper size

setting 2.4

specifications 5.2

paper type

setting 2.4

specifications 5.2

PostScript problems 9.13

print quality problems, solve 9.11

printing

demo page 2.8

information page 8.1

problems 9.9

problem, solve

checklist 9.5

error messages 9.6

Linux 9.14

Macintosh 9.14

paper jams 9.1

printing 9.9

printing quality 9.11

PS errors 9.13

Windows 9.13

Q

quality problems 9.11

1

R

rear cover, use 5.8

redistributing, toner cartridge 8.4

replacing, toner cartridge 8.5, 8.7

S

special print media, guidelines 5.3

specification, printer 11.1

status LED, meaning 9.6

supplies

checking life 8.4

order information 7.1

system requirements

Linux 3.3

Macintosh 3.3

Windows 3.2

T

toner cartridge

checkig remaining toner 8.4

cleaning 8.3

maintaining 8.3

redistributing 8.4

replacing 8.5, 8.7

toner save mode, use 2.8

troubleshooting 9.1

W

Windows problems 9.13

2

Samsung Printer

Software section

S

OFTWARE SECTION

C

ONTENTS

Chapter 1:

I

NSTALLING

P

RINTER

S

OFTWARE IN

W

INDOWS

Installing Printer Software ........................................................................................................ 4

Installing Software for Local Printing ................................................................................. 4

Installing Software for Network Printing ............................................................................. 7

Changing the Software Language ............................................................................................ 10

Reinstalling Printer Software ................................................................................................... 10

Removing Printer Software ..................................................................................................... 11

Chapter 2:

B

ASIC

P

RINTING

Printing a Document .............................................................................................................. 12

Printer Settings ..................................................................................................................... 13

Layout Tab .................................................................................................................. 13

Paper Tab .................................................................................................................... 14

Graphics Tab ............................................................................................................... 15

Extras Tab ................................................................................................................... 16

About Tab ................................................................................................................... 17

Printer Tab .................................................................................................................. 17

Using a Favorite Setting ................................................................................................ 17

Using Help ................................................................................................................... 17

Chapter 3:

A

DVANCED

P

RINTING

Printing Multiple Pages on One Sheet of Paper (N-Up Printing) ..................................................... 18

Printing Posters ..................................................................................................................... 19

Printing Booklets .................................................................................................................. 19

Printing on Both Sides of Paper ............................................................................................... 20

Printing a Reduced or Enlarged Document ................................................................................ 20

Fitting Your Document to a Selected Paper Size ......................................................................... 20

Using Watermarks ................................................................................................................. 21

1

Using an Existing Watermark ......................................................................................... 21

Creating a Watermark ................................................................................................... 21

Editing a Watermark ..................................................................................................... 21

Deleting a Watermark ................................................................................................... 21

Using Overlays ...................................................................................................................... 22

What is an Overlay? ...................................................................................................... 22

Creating a New Page Overlay ......................................................................................... 22

Using a Page Overlay .................................................................................................... 22

Deleting a Page Overlay ................................................................................................ 22

Chapter 4:

U

SING

W

INDOWS

P

OST

S

CRIPT

D

RIVER

Printer Settings ..................................................................................................................... 23

Advanced .................................................................................................................... 23

Using Help ................................................................................................................... 23

Chapter 5:

U

SING

D

IRECT

P

RINT

U

TILITY

Overview Direct Print Utility .................................................................................................... 24

Printing ................................................................................................................................ 24

From the Direct Print Utility window ................................................................................ 24

Using the shortcut icon ................................................................................................. 24

Using the right-click menu ............................................................................................. 24

Chapter 6:

S

HARING THE

P

RINTER

L

OCALLY

Setting Up a Host Computer ................................................................................................... 25

Setting Up a Client Computer .................................................................................................. 25

Chapter 7:

U

SING

S

MART

P

ANEL

Understanding Smart Panel .................................................................................................... 26

Opening the Troubleshooting Guide ......................................................................................... 27

Using Printer Settings Utility ................................................................................................... 27

Using Onscreen Help File ............................................................................................... 27

Changing the Smart Panel Program Settings ............................................................................. 27

2

Chapter 8:

U

SING

Y

OUR

P

RINTER IN

L

INUX

Getting Started ..................................................................................................................... 28

Installing the Unified Linux Driver ............................................................................................ 28

Installing the Unified Linux Driver ................................................................................... 28

Uninstalling the Unified Linux Driver ............................................................................... 29

Using the Unified Driver Configurator ....................................................................................... 30

Opening the Unified Driver Configurator .......................................................................... 30

Printers Configuration ................................................................................................... 30

Ports Configuration ....................................................................................................... 31

Configuring Printer Properties ................................................................................................. 31

Printing a Document .............................................................................................................. 32

Printing from Applications .............................................................................................. 32

Printing Files ................................................................................................................ 32

Chapter 9:

U

SING

Y

OUR

P

RINTER WITH A

M

ACINTOSH

Installing Software for Macintosh ............................................................................................. 33

Setting Up the Printer ............................................................................................................ 34

For a Network-connected Macintosh ................................................................................ 34

For a USB-connected Macintosh ..................................................................................... 34

Printing ................................................................................................................................ 35

Printing a Document ..................................................................................................... 35

Changing Printer Settings .............................................................................................. 35

Printing Multiple Pages on One Sheet of Paper .................................................................. 36

Duplex Printing ............................................................................................................ 37

3

1

Installing Printer

Software in Windows

This chapter includes:

• Installing Printer Software

• Changing the Software Language

• Reinstalling Printer Software

• Removing Printer Software

Installing Printer Software

You can install the printer software for local printing or network printing. To install the printer software on the computer, perform the appropriate installation procedure depending on the printer in use.

A printer driver is software that lets your computer communicate with your printer. The procedure to install drivers may differ depending on the operating system you are using.

All applications should be closed on your PC before beginning installation.

Installing Software for Local Printing

A local printer is a printer directly attached to your computer using the printer cable supplied with your printer, such as a USB or parallel cable. If your printer is attached to a network, skip

this step and go to “Installing Software for Network Printing” on page 7.

You can install the printer software using the typical or custom method.

N

OTE

: If the “New Hardware Wizard” window appears during the installation procedure, click in the upper right corner of the box to close the window, or click Cancel.

Typical Installation

This is recommended for most users. All components necessary for printer operations will be installed.

1

Make sure that the printer is connected to your computer and powered on.

2

Insert the supplied CD-ROM into your CD-ROM drive.

The CD-ROM should automatically run, and an installation window appears.

If the installation window does not appear, click Start and then Run. Type X:\Setup.exe, replacing “X” with the letter which represents your drive and click OK.

3

Click Next.

• If necessary, select a language from the drop-down list.

View User’s Guide: Allows you to view the User’s

Guide. If your computer doesn’t have Adobe Acrobat, click on this option and it will automatically install Adobe

Acrobat Reader for you.

4

Select Typical installation for a local printer. Click

Next.

4

Installing Printer Software in Windows

N

OTE

: If your printer is not already connected to the computer, the following window will appear.

7

To register yourself as a user of Samsung Printers in order to receive information from Samsung, select the checkbox and click Finish. You are now sent to the Samsung web site.

Otherwise, just click Finish.

• After connecting the printer, click Next.

• If you don’t want to connect the printer at this time, click

Next, and No on the following screen. Then the installation will start and a test page will not be printed at the end of the installation.

• The installation window that appears in this User’s

Guide may differ depending on the printer and interface in use.

5

After the installation is finished, a window asking you to print a test page appears. If you choose to print a test page, select the checkbox and click Next.

Otherwise, just click Next and skip to step 7.

6

If the test page prints out correctly, click Yes.

If not, click No to reprint it.

N

OTE

: After setup is complete, if your printer driver doesn’t

work properly, reinstall the printer driver. See “Reinstalling

Printer Software” on page 10.

Custom Installation

You can choose individual components to install.

1

Make sure that the printer is connected to your computer and powered on.

2

Insert the supplied CD-ROM into your CD-ROM drive.

The CD-ROM should automatically run, and an installation window appears.

If the installation window does not appear, click Start and then Run. Type X:\Setup.exe, replacing “X” with the letter which represents your drive and click OK.

5

Installing Printer Software in Windows

3

Click Next.

• If necessary, select a language from the drop-down list.

View User’s Guide: Allows you to view the User’s

Guide. If your computer doesn’t have Adobe Acrobat, click on this option and it will automatically install Adobe

Acrobat Reader for you.

4

Select Custom installation. Click Next.

N

OTE

: If your printer is not already connected to the computer, the following window will appear.

5

Select your printer and click Next.

• After connecting the printer, click Next.

• If you don’t want to connect the printer at this time, click

Next, and No on the following screen. Then the installation will start and a test page will not be printed at the end of the installation.

• The installation window that appears in this User’s

Guide may differ depending on the printer and interface in use.

6

Select the components to be installed and click Next.

N

OTE

: You can change the desired installation folder by clicking [Browse].

7

After the installation is finished, a window asking you to print a test page appears. If you choose to print a test page, select the checkbox and click Next.

Otherwise, just click Next and skip to step 9.

8

If the test page prints out correctly, click Yes.

If not, click No to reprint it.

6

Installing Printer Software in Windows

9

To register yourself as a user of Samsung Printers in order to receive information from Samsung, select the checkbox and click Finish. You are now sent to the Samsung web site.

Otherwise, just click Finish.

If the installation window does not appear, click Start and then Run. Type X:\Setup.exe, replacing “X” with the letter which represents your drive and click OK.

Installing Software for Network

Printing

When you connect your printer to a network, you must first configure the TCP/IP settings for the printer. After you have assigned and verified the TCP/IP settings, you are ready to install the software on each computer on the network.

You can install the printer software using the typical or custom method.

Typical Installation

This is recommended for most users. All components necessary for printer operations will be installed.

1

Make sure that the printer is connected to your network and powered on. For details about connecting to the network, see the supplied printer’s User’s Guide.

2

Insert the supplied CD-ROM into your CD-ROM drive.

The CD-ROM should automatically run, and an installation window appears.

3

Click Next.

• If necessary, select a language from the drop-down list.

View User’s Guide: Allows you to view the User’s

Guide. If your computer doesn’t have Adobe Acrobat, click on this option and it will automatically install Adobe

Acrobat Reader for you.

4

Select Typical installation for a network printer. Click

Next.

7

Installing Printer Software in Windows

5

The list of printers available on the network appears.

Select the printer you want to install from the list and then click Next.

Custom Installation

You can choose individual components to install and set a specific IP address.

1

Make sure that the printer is connected to your network and powered on. For details about connecting to the network, see the supplied printer’s User’s Guide.

2

Insert the supplied CD-ROM into your CD-ROM drive.

The CD-ROM should automatically run, and an installation window appears.

If the installation window does not appear, click Start and then Run. Type X:\Setup.exe, replacing “X” with the letter which represents your drive and click OK.

• If you do not see your printer on the list, click Update to refresh the list, or select Add TCP/IP Port to add your printer to the network. To add the printer to the network, enter the port name and the IP address for the printer.

• To find a shared network printer (UNC Path), select

Shared Printer [UNC] and enter the shared name manually or find a shared printer by clicking the Browse button.

6

After the installation is finished, a window appears asking you to print a test page and to register yourself as a user of Samsung Printers in order to receive information from

Samsung. If you so desire, select the corresponding checkbox(es) and click Finish.

Otherwise, just click Finish.

3

Click Next.

• If necessary, select a language from the drop-down list.

View User’s Guide: Allows you to view the User’s

Guide. If your computer doesn’t have Adobe Acrobat, click on this option and it will automatically install Adobe

Acrobat Reader for you.

4

Select Custom installation. Click Next.

N

OTE

: After setup is complete, if your printer driver doesn’t

work properly, reinstall the printer driver. See “Reinstalling

Printer Software” on page 10.

8

Installing Printer Software in Windows

5

The list of printers available on the network appears.

Select the printer you want to install from the list and then click Next.

6

Select the components to be installed. After selecting the components, the following window appears. You can also change the printer name, set the printer to be shared on the network, set the printer as the default printer, and change the port name of each printer. Click Next.

• If you do not see your printer on the list, click Update to refresh the list, or select Add TCP/IP Port to add your printer to the network. To add the printer to the network, enter the port name and the IP address for the printer.

• To find a shared network printer (UNC Path), select

Shared Printer [UNC] and enter the shared name manually or find a shared printer by clicking the Browse button.

T

IP

: If you want to set a specific IP address on a specific network printer, click the Set IP Address button. The Set IP

Address window appears. Do as follows:

To install this software on a server, select the Setting up

this printer on a server checkbox.

7

After the installation is finished, a window appears asking you to print a test page and to register yourself as a user of Samsung Printers in order to receive information from

Samsung. If you so desire, select the corresponding checkbox(es) and click Finish.

Otherwise, just click Finish.

a. Select a printer to be set with a specific IP address from the list. To verify your printer’s IP address or MAC address, print a Network Configuration page.

b. Configure an IP address, subnet mask, and gateway for the printer manually and click Configure to set the specific IP address for the network printer.

c. Click Next.

N

OTE

: After setup is complete, if your printer driver doesn’t

work properly, reinstall the printer driver. See “Reinstalling

Printer Software” on page 10.

9

Installing Printer Software in Windows

Changing the Software

Language

After installation of the software, you can change the display language.

1

Click the Windows Start menu.

2

Select Programs or All Programs and then your printer

driver name.

3

Select Language Selection.

4

Select the desired language from the language selection window, and click OK.

Reinstalling Printer Software

You can reinstall the software if installation fails.

1

Start Windows.

2

From the Start menu select Programs or All Programs

your printer driver name Maintenance.

3

Select Repair and click Next

.

4

The list of printers available on the network appears.

Select the printer you want to install from the list and then click Next.

N

OTE

: If your printer is not already connected to the computer, the following window will appear.

• If you do not see your printer on the list, click Update to refresh the list, or select Add TCP/IP Port to add your printer to the network. To add the printer to the network, enter the port name and the IP address for the printer.

• To find a shared network printer (UNC Path), select

Shared Printer [UNC] and enter the shared name manually or find a shared printer by clicking the Browse button.

You will see a component list so that you can reinstall any item individually.

10

Installing Printer Software in Windows

• After connecting the printer, click Next.

• If you don’t want to connect the printer at this time, click

Next, and No on the following screen. Then the installation will start and a test page will not be printed at the end of the installation.

• The reinstallation window that appears in this User’s

Guide may differ depending on the printer and interface in use.

5

Select the components you want to reinstall and click

Next

.

If you installed the printer software for local printing and you select your printer driver name, the window asking you to print a test page appears. Do as follows: a. To print a test page, select the check box and click

Next

.

b. If the test page prints out correctly, click Yes.

If it doesn’t, click No to reprint it.

6

When the reinstallation is done, click Finish.

Removing Printer Software

1

Start Windows.

2

From the Start menu select Programs or All Programs

your printer driver name Maintenance.

3

Select Remove and click Next.

You will see a component list so that you can remove any item individually.

4

Select the components you want to remove and then click

Next.

5

When your computer asks you to confirm your selection, click Yes.

The selected driver and all of its components are removed from your computer.

6

After the software is removed, click Finish.

11

Installing Printer Software in Windows

2

Basic Printing

This chapter explains the printing options and common printing tasks in Windows.

This chapter includes:

• Printing a Document

• Printer Settings

- Layout Tab

- Paper Tab

- Graphics Tab

- Extras Tab

- About Tab

- Printer Tab

- Using a Favorite Setting

- Using Help

Printing a Document

N

OTES

:

• Your printer driver Properties window that appears in this

User’s Guide may differ depending on the printer in use.

However the composition of the printer properties window is similar.

• Check the Operating System(s) that are compatible with your printer. Please refer to the OS Compatibility section of Printer Specifications in your Printer User’s

Guide.

• If you need to know the exact name of your printer, you can check the supplied CD-ROM.

The following procedure describes the general steps required for printing from various Windows applications. The exact steps for printing a document may vary depending on the application program you are using. Refer to the User’s Guide of your software application for the exact printing procedure.

1

Open the document you want to print.

2

Select Print from the File menu. The Print window is displayed. It may look slightly different depending on your application.

The basic print settings are selected within the Print window. These settings include the number of copies and print range.

Make sure that your printer is selected.

3

Select your printer driver from the Name drop-down list.

4

To take advantage of the printer features provided by your printer driver, click Properties or Preferences in the

application’s Print window. For details, see “Printer

Settings” on page 13.

If you see Setup, Printer, or Options in your Print window, click it instead. Then click Properties on the next screen.

5

Click OK to close the printer properties window.

6

To start the print job, click OK or Print in the Print window.

12

Basic Printing

Printer Settings

You can use the printer properties window, which allows you to access all of the printer options you need when using your printer. When the printer properties are displayed, you can review and change the settings needed for your print job.

Your printer properties window may differ, depending on your operating system. This Software User’s Guide shows the

Properties window for Windows XP.

Your printer driver Properties window that appears in this

User’s Guide may differ depending on the printer in use.

If you access printer properties through the Printers folder, you can view additional Windows-based tabs (refer to your

Windows User’s Guide) and the Printer tab (see “Printer Tab” on page 17).

N

OTES

:

• Most Windows applications will override settings you specify in the printer driver. Change all print settings available in the software application first, and change any remaining settings using the printer driver.

• The settings you change remain in effect only while you are using the current program. To make your changes

permanent, make them in the Printers folder.

• The following procedure is for Windows XP. For other

Windows OS, refer to the corresponding Windows User's

Guide or online help.

1. Click the Windows Start button.

2. Select Printers and Faxes.

3. Select your printer driver icon.

4. Right-click on the printer driver icon and select

Printing Preferences.

5. Change the settings on each tab, click OK.

Layout Tab

The Layout tab provides options to adjust how the document appears on the printed page. The Layout Options includes

Multiple Pages per Side and Poster Printing. See “Printing a Document” on page 12 for more information on accessing

printer properties.

1

2

Paper Orientation

Paper Orientation allows you to select the direction in which information is printed on a page.

Portrait prints across the width of the page, letter style.

Landscape prints across the length of the page, spreadsheet style.

Rotate allows you to rotate the page the selected degrees.

Portrait

Landscape

Layout Options

Layout Options allows you to select advanced printing options.

You can choose Multiple Pages per Side and Poster Printing.

• For details, see “Printing Multiple Pages on One Sheet of Paper

(N-Up Printing)” on page 18.

• For details, see “Printing Posters” on page 19

Double-sided Printing

Double-sided Printing allows you to print on both sides of paper.

If this option does not appear, your printer does not have this feature.

• For details, see “Printing on Both Sides of Paper” on page 20.

13

Basic Printing

Paper Tab

Use the following options to set the basic paper handling specifications when you access the printer properties. See

“Printing a Document” on page 12 for more information on

accessing printer properties.

Click the Paper tab to access various paper properties.

1

2

3

4

5

1

Copies

Copies allows you to choose the number of copies to be printed.

You can select 1 to 999 copies.

2

Size

Size allows you to set the size of paper you loaded in the tray.

If the required size is not listed in the Size box, click Custom.

When the Custom Paper Setting window appears, set the paper size and click OK. The setting appears in the list so that you can select it.

3

Source

Make sure that Source is set to the corresponding paper tray.

Use Manual Feeder when printing on special materials like envelopes and transparencies. You have to load one sheet at a time into the Manual Tray or Multi-Purpose Tray.

If the paper source is set to Auto Selection, the printer automatically picks up print material in the following tray order:

Manual Tray or Multi-Purpose Tray, Tray n.

4

Type

Set Type to correspond to the paper loaded in the tray from which you want to print. This will let you get the best quality printout. If not, print quality may not be acheived as you want.

Cotton: 20 lb to 24 lb (75~90 g/m2) cotton paper such as Gilbert

25 % and Gilbert 100 %.

Plain Paper: Normal plain paper. Select this type if your printer is monochrome and printing on the 16 lb (60 g/m2) cotton paper.

Recycled Paper: 20 lb to 24 lb (75~90 g/m2) recycled paper.

Color Paper: 20 lb to 24 lb (75~90 g/m2) color-backgrounded paper.

First Page

This property allows you to print the first page using a different paper type from the rest of the document. You can select the paper source for the first page.

For example, load thick stock for the first page into the Multipurpose Tray, and plain paper into Tray n. Then, select Tray n in the

Source

option and Multi-Purpose Tray in the First Page option.

Some printers do not support this feature.

5

Scaling Printing

Scaling Printing allows you to automatically or manually scale your print job on a page. You can choose from None, Reduce/

Enlarge, and Fit to Page.

• For details, see “Printing a Reduced or Enlarged Document” on page 20.

• For details, see “Fitting Your Document to a Selected Paper

Size” on page 20.

14

Basic Printing

Graphics Tab

Use the following Graphic options to adjust the print quality for

your specific printing needs. See “Printing a Document” on page 12 for more information on accessing printer properties.

Click the Graphic tab to display the properties shown below..

Resolution

The Resolution options you can select may vary depending on your printer model.

The higher the setting, the sharper the clarity of printed characters and graphics. The higher setting also may increase the time it takes to print a document.

Toner Save Mode

Selecting this option extends the life of your toner cartridge and reduces your cost per page without a significant reduction in print quality.

Some printers do not support this feature.

Printer Setting: If you select this option, this feature is determined by the setting you’ve made on the control panel of the printer.

On: Select this option to allow the printer to use less toner on each page.

Off: If you don’t need to save toner when printing a document, select this option.

Advanced Options

You can set advanced settings by clicking the Advanced

Options button.

TrueType Options: This option determines what the driver tells the printer about how to image the text in your document.

Select the appropriate setting according to the status of your document.

This option may be available only in

Windows 9x/Me, depending on your particular printer model.

- Download as Outline: When this option is selected, the driver will download any TrueType fonts that are used in your document not already stored (resident) on your printer. If, after printing a document, you find that the fonts did not print correctly, choose Download as bit image and resubmit your print job. The Download as bit image setting is often useful when printing Adobe.

This feature is available only when you use the PCL printer driver.

- Download as Bitmap: When this option is selected, the driver will download the font data as bitmap images.

Documents with complicated fonts, such as Korean or

Chinese, or various other fonts, will print faster in this setting.

- Print as Graphics: When this option is selected, the driver will download any fonts as graphics. When printing documents with high graphic content and relatively few TrueType fonts, printing performance (speed) may be enhanced in this setting.

Print All Text To Black: When the Print All Text To Black option is checked, all text in your document prints solid black, regardless of the color it appears on the screen.

15

Basic Printing

Extras Tab

You can select output options for your document. See “Printing a Document” on page 12 for more information about accessing

the printer properties.

Click the Extras tab to access the following feature:

1

2

3

1

Watermark

You can create a background text image to be printed on each

page of your document. For details, see “Using Watermarks” on page 21.

2

Overlay

Overlays are often used to take the place of preprinted forms and

letterhead paper. For details, see “Using Overlays” on page 22.

3

Output Options

Print Subset: You can set the sequence in which the pages print. Select the print order from the drop-down list.

- Normal(1,2,3): Your printer prints all pages from the first page to the last page.

- Reverse All Pages(3,2,1): Your printer prints all pages from the last page to the first page.

- Print Odd Pages: Your printer prints only the odd numbered pages of the document.

Print Even Pages: Your printer prints only the even numbered pages of the document.

Information Page: Select Banner Page to print a banner sheet containing the printer name, the network user ID, job name before printing the document. When several users send a print job to the printer, this option allows you to easily find your printing from the output tray.

Some printers do not support this feature.

Use Printer Fonts: When Use Printer Fonts is checked, the printer uses the fonts that are stored in its memory (resident fonts) to print your document, rather than downloading the fonts used in your document. Because downloading fonts takes time, selecting this option can speed up your printing time.

When using Printer fonts, the printer will try to match the fonts used in your document to those stored in its memory. If, however, you use fonts in your document that are very different from those resident in the printer, your printed output will appear very different from what it looks like on the screen.

This feature is available only when you use the PCL printer driver.

Save as Form for Overlay: Select Save as Form for Overlay to save the document as a form file (C:\FORMOVER\*.FOM). Once this option is selected, the printer driver requires the file name and the destination path each time you print. If you want to preset the file name and specify the path, click on the button in the Output to area, and type the file name and specify the path.

This feature is available only when you use the PCL printer driver.

4

Job Setting

Print and Hold dialog allows you to select how to print or save the printing file by using the optional HDD.

Some printers do not support this feature.

Using Onscreen Help File

• For more information about

Job Setting

top right corner of the window. The

, click

Job Setting

at the

Help window opens and allows you to view onscreen help supplied on the

Job Setting

.

16

Basic Printing

About Tab

Use the About tab to display the copyright notice and the version number of the driver. If you have an Internet browser, you can connect to the Internet by clicking on the web site icon.

See “Printing a Document” on page 12 for more information

about accessing printer properties.

Printer Tab

If you access printer properties through the Printers folder, you can view the Printer tab. You can set the printer configuration.

The following procedure is for Windows XP. For other Windows

OS, refer to the corresponding Windows User's Guide or online help.

1

Click the Windows Start menu.

2

Select Printers and Faxes.

3

Select your printer driver icon.

4

Right-click on the printer driver icon and select

Properties.

5

Click the Printer tab and set the options.

Using a Favorite Setting

The Favorites option, which is visible on each properties tab, allows you to save the current properties settings for future use.

To save a Favorites item:

1

Change the settings as needed on each tab.

2

Enter a name for the item in the Favorites input box.

3

Click Save.

When you save Favorites, all current driver settings are saved.

To use a saved setting, select the item from the Favorites drop down list. The printer is now set to print according to the

Favorites setting you selected.

To delete a Favorites item, select it from the list and click

Delete.

You can also restore the printer driver’s default settings by selecting Printer Default from the list.

Using Help

Your printer has a help screen that can be activated by clicking the Help button in the printer properties window. These help screens give detailed information about the printer features provided by the printer driver.

You can also click from the upper right corner of the window, and then click on any setting.

17

Basic Printing

3

Advanced Printing

This chapter explains printing options and advanced printing tasks.

N

OTE

:

• Your printer driver Properties window that appears in this

User’s Guide may differ depending on the printer in use.

However the composition of the printer properties window is similar.

• If you need to know the exact name of your printer, you can check the supplied CD-ROM.

This chapter includes:

• Printing Multiple Pages on One Sheet of Paper (N-Up

Printing)

• Printing Posters

• Printing Booklets

• Printing on Both Sides of Paper

• Printing a Reduced or Enlarged Document

• Fitting Your Document to a Selected Paper Size

• Using Watermarks

• Using Overlays

1 2

3 4

Printing Multiple Pages on One

Sheet of Paper (N-Up Printing)

You can select the number of pages to print on a single sheet of paper. To print more than one page per sheet, the pages will be reduced in size and arranged in the order you specify. You can print up to 16 pages on one sheet.

1

To change the print settings from your software

application, access printer properties. See “Printing a

Document” on page 12.

2

From the Layout tab, choose Multiple Pages per Side in the Layout Type drop-down list.

3

Select the number of pages you want to print per sheet

(1, 2, 4, 6, 9, or 16) in the Pages per Side drop-down list.

4

Select the page order from the Page Order drop-down list, if necessary.

Check Print Page Border to print a border around each page on the sheet.

5

Click the Paper tab, select the paper source, size, and type.

6

Click OK and print the document.

18

Advanced Printing

Printing Posters

This feature allows you to print a single-page document onto 4,

9, or 16 sheets of paper, for the purpose of pasting the sheets together to form one poster-size document.

1

To change the print settings from your software

application, access printer properties. See “Printing a

Document” on page 12.

2

Click the Layout tab, select Poster Printing in the

Layout Type drop-down list.

3

Configure the poster option:

You can select the page layout from Poster<2x2>,

Poster<3x3>, or Poster<4x4>. If you select

Poster<2x2>, the output will be automatically stretched to cover 4 physical pages.

Printing Booklets

9

8

9

8

This printer feature allows you to print your document on both sides of the paper and arranges the pages so that the paper can be folded in half after printing to produce a booklet.

1

To change the print settings from your software

application, access the printer properties. See “Printing a

Document” on page 12.

2

From the Layout tab, choose Booklet Printing from the

Type drop-down list.

N

OTE

: The booklet printing option is available when A4,

Letter, Legal, or Folio size is selected in the Size option on the

Paper tab.

3

Click the Paper tab, and select the paper source, size, and type.

4

Click OK and print the document.

5

After printing, fold and staple the pages.

Specify an overlap in millimeters or inches to make it easier to pasting the sheets together.

0.15 inches

0.15 inches

4

Click the Paper tab, select the paper source, size, and type.

5

Click OK and print the document. You can complete the poster by pasting the sheets together.

19

Advanced Printing

Printing on Both Sides of Paper

You can print on both sides of a sheet of paper. Before printing, decide how you want your document oriented.

The options are:

Printer Setting, if you select this option, this feature is determined by the setting you’ve made on the control panel of the printer.

If this option does not appear, your printer does not have this feature.

None

Long Edge

, which is the conventional layout used in book binding.

Short Edge

, which is the type often used with calendars.

2

2

2

3

5

Long Edge

5

3

2

5

3

Short Edge

3

5

Reverse Duplex, allows you to select general print order compare to duplex print order.

If this option does not appear, your printer does not have this feature.

N

OTE

:

• Do not print on both sides of labels, transparencies, envelopes, or thick paper. Paper jamming and damage to the printer may result.

• To use double-sided printing, you can use only the following paper sizes: A4, Letter, Legal, and Folio, with a weight of

20~24 lbs (75~90 g/m²).

1

To change the print settings from your software

application, access printer properties. “Printing a

Document” on page 12.

2

From the Layout tab, select the paper orientation.

3

From the Double-sided Printing section, select the binding option you want.

4

Click the Paper tab and select the paper source, size, and type.

5

Click OK and print the document.

N

OTE

: If your printer does not have a duplex unit, you should complete the printing job manually. The printer prints every other page of the document first. After printing the first side of your job, the Printing Tip window appears. Follow the onscreen instructions to complete the printing job.

A

Printing a Reduced or Enlarged

Document

You can change the size of a page’s content to appear larger or smaller on the printed page.

1

To change the print settings from your software

application, access printer properties. See “Printing a

Document” on page 12.

2

From the Paper tab, select Reduce/Enlarge in the

Printing Type drop-down list.

3

Enter the scaling rate in the Percentage input box.

You can also click the or button.

4

Select the paper source, size, and type in Paper Options.

5

Click OK and print the document.

Fitting Your Document to a

Selected Paper Size

This printer feature allows you to scale your print job to any selected paper size regardless of the digital document size. This can be useful when you want to check fine details on a small document.

1

To change the print settings from your software

application, access printer properties. See “Printing a

Document” on page 12.

2

From the Paper tab, select Fit to Page in the Printing

Type drop-down list.

3

Select the correct size from the Target Page drop-down list.

4

Select the paper source, size, and type in Paper Options.

5

Click OK and print the document.

20

Advanced Printing

Using Watermarks

The Watermark option allows you to print text over an existing document. For example, you may want to have large gray letters reading “DRAFT” or “CONFIDENTIAL” printed diagonally across the first page or all pages of a document.

There are several predefined watermarks that come with the printer, and they can be modified, or you can add new ones to the list.

Using an Existing Watermark

1

To change the print settings from your software

application, access printer properties. See “Printing a

Document” on page 12.

2

Click the Extras tab, and select the desired watermark from the Watermark drop-down list. You will see the selected watermark in the preview image.

3

Click OK and start printing.

N

OTE

: The preview image shows how the page will look when it is printed.

Creating a Watermark

1

To change the print settings from your software

application, access printer properties. See “Printing a

Document” on page 12.

2

Click the Extras tab, and click the Edit button in the

Watermark section. The Edit Watermark window appears.

3

Enter a text message in the Watermark Message box.

You can enter up to 40 characters. The message displays in the preview window.

When the First Page Only box is checked, the watermark prints on the first page only.

4

Select watermark options.

You can select the font name, style, size, or grayscale level from the Font Attributes section and set the angle of the watermark from the Message Angle section.

5

Click Add to add a new watermark to the list.

6

When you have finished editing, click OK and start printing.

To stop printing the watermark, select <No Watermark> from the Watermark drop-down list.

Editing a Watermark

1

To change the print settings from your software

application, access printer properties. See “Printing a

Document” on page 12.

2

Click the Extras tab and click the Edit button in the

Watermark section. The Edit Watermark window appears.

3

Select the watermark you want to edit from the Current

Watermarks list and change the watermark message and options.

4

Click Update to save the changes.

5

Click OK until you exit the Print window.

Deleting a Watermark

1

To change the print settings from your software

application, access printer properties. See “Printing a

Document” on page 12.

2

From the Extras tab, click the Edit button in the

Watermark section. The Edit Watermark window appears.

3

Select the watermark you want to delete from the Current

Watermarks list and click Delete.

4

Click OK until you exit the Print window.

21

Advanced Printing

Dear ABC

Regards

WORLD BEST

WORLD BEST

Using Overlays

What is an Overlay?

An overlay is text and/or images stored in the computer hard disk drive (HDD) as a special file format that can be printed on any document. Overlays are often used to take the place of preprinted forms and letterhead paper. Rather than using preprinted letterhead, you can create an overlay containing the exact same information that is currently on your letterhead. To print a letter with your company’s letterhead, you do not need to load preprinted letterhead paper in the printer. You need only tell the printer to print the letterhead overlay on your document.

Creating a New Page Overlay

To use a page overlay, you must create a new page overlay containing your logo or image.

1

Create or open a document containing text or an image for use in a new page overlay. Position the items exactly as you wish them to appear when printed as an overlay.

2

To save the document as an overlay, access printer

properties. See “Printing a Document” on page 12.

3

Click the Extras tab, and click Edit button in the Overlay section.

4

In the Edit Overlay window, click Create Overlay.

5

In the Create Overlay window, type a name of up to eight characters in the File name box. Select the destination path, if necessary. (The default is C:\Formover).

6

Click Save. The name appears on the Overlay List box.

7

Click OK or Yes to finish creating.

The file is not printed. Instead it is stored on your computer hard disk drive.

N

OTE

: The overlay document size must be the same as the documents you print with the overlay. Do not create an overlay with a watermark.

Using a Page Overlay

After an overlay has been created, it is ready to be printed with your document. To print an overlay with a document:

1

Create or open the document you want to print.

2

To change the print settings from your software

application, access printer properties. See “Printing a

Document” on page 12.

3

Click the Extras tab.

4

Select the desired overlay from the Overlay drop-down list box.

5

If the overlay file you want does not appear in the

Overlay list, click Edit button and Load Overlay, and select the overlay file.

If you have stored the overlay file you want to use in an external source, you can also load the file when you access the Load Overlay window.

After you select the file, click Open. The file appears in the

Overlay List box and is available for printing. Select the overlay from the Overlay List box.

6

If necessary, click Confirm Page Overlay When

Printing. If this box is checked, a message window appears each time you submit a document for printing, asking you to confirm your wish to print an overlay on your document.

If this box is not checked and an overlay has been selected, the overlay automatically prints with your document.

7

Click OK or Yes until printing begins.

The selected overlay downloads with your print job and prints on your document.

N

OTE

: The resolution of the overlay document must be the same as that of the document you will print with the overlay.

Deleting a Page Overlay

You can delete page overlays that you no longer use.

1

In the printer properties window, click the Extras tab.

2

Click the Edit button in the Overlay section.

3

Select the overlay you want to delete from the Overlay

List box.

4

Click Delete Overlay.

5

When a confirming message window appears, click Yes.

6

Click OK until you exit the Print window.

22

Advanced Printing

4

Using Windows

PostScript Driver

If you want to use the PostScript driver provided with your system CD-ROM to print a document.

PPDs, in combination with the PostScript driver, access printer features and allow the computer to communicate with the printer. An installation program for the PPDs is provided on the supplied software CD-ROM.

This chapter includes:

Printer Settings

You can use the printer properties window, which allows you to access all of the printer options you need when using your printer. When the printer properties are displayed, you can review and change the settings needed for your print job.

Your printer properties window may differ, depending on your operating system. This Software User’s Guide shows the

Properties window for Windows XP.

Your printer driver Properties window that appears in this

User’s Guide may differ depending on the printer in use.

N

OTES

:

• Most Windows applications will override settings you specify in the printer driver. Change all print settings available in the software application first, and change any remaining settings using the printer driver.

• The settings you change remain in effect only while you are using the current program. To make your changes

permanent, make them in the Printers folder.

• The following procedure is for Windows XP. For other

Windows OS, refer to the corresponding Windows User's

Guide or online help.

1. Click the Windows

Start

button.

2. Select Printers and Faxes.

3. Select your printer driver icon.

4. Right-click on the printer driver icon and select

Printing Preferences.

5. Change the settings on each tab, click OK.

Advanced

You can use advanced settings by clicking the

Advanced

button.

Paper/Output this option allows you to select the size of the paper loaded in the tray.

Graphic this option allows you to adjust the print quality for your specific printing needs.

Document Options this options allow you to set the PostScript options or printer features.

Using Help

You can click from the upper right corner of the window, and then click on any setting.

23

Using Windows PostScript Driver

5

Using Direct Print Utility

This chapter explains how to use Direct Print Utility to print PDF files without having to open the files.

Overview Direct Print Utility

Direct Print Utility is a program that sends a PDF file directly to your printer without having to open the file. It sends data through the Windows spooler using the port of the printer driver. It only supports PDF format.

To installing this program, you should select Custom and put a check mark in this program when you install the printer driver.

Printing

There are several ways you can print using Direct Print Utility.

From the Direct Print Utility window

1

From the Start menu select Programs or All Programs

Direct Print Utility

Direct Print Utility.

Or, double-click the Direct Print Utility shortcut icon on your desk top.

The Direct Print Utility window opens.

2

Select the printer you will use in the Select Printer section and click Browse.

3

Select the PDF file you will print and click Open.

The PDF file is added in the Select Files section.

4

Customize the printer settings for your needs. See the next column.

5

Click Print.

The selected PDF file is sent to the printer.

Using the shortcut icon

1

Select the PDF file you will print and by dragging drop it to the Direct Print Utility shortcut icon on your desk top.

The selected PDF file is sent to the default printer.

N

OTE

:

If the default printer does not support Direct Print Utility, the message window alerting you to select the appropriate printer opens. Select the appropriate printer in the Select Printer section.

2

Customize the printer settings for your needs.

3

Click Print.

The selected PDF file is sent to the printer.

Using the right-click menu

1

Right-click on the PDF file you will print and select Direct

Printing.

The Direct Print Utility window opens with the PDF file is added.

2

Select the printer you will use.

3

Customize the printer settings for your needs. See the below part.

4

Click Print.

The selected PDF file is sent to the printer.

24

Using Direct Print Utility

6

Sharing the Printer

Locally

You can connect the printer directly to a selected computer, which is called “host computer,” on the network.

The following procedure is for Windows XP. For other Windows

OS, refer to the corresponding Windows User's Guide or online help.

N

OTES

:

• Check the Operating System(s) that are compatible with your printer. Please refer to the OS Compatibility section of

Printer Specifications in your Printer User’s Guide.

• If you need to know the exact name of your printer, you can check the supplied CD-ROM.

Setting Up a Host Computer

1

Start Windows.

2

From the Start menu select Printers and Faxes.

3

Double-click your printer driver icon.

4

From the Printer menu, select Sharing.

5

Check the Share this printer box.

6

Fill in the Shared Name field, and then click OK.

Setting Up a Client Computer

1

Right-click the Windows Start button and select Explorer.

2

Open your network folder in the left column.

3

Click the shared name.

4

From the Start menu select Printers and Faxes.

5

Double-click your printer driver icon.

6

From the Printer menu, select Properties.

7

From the Ports tab, click Add Port.

8

Select Local Port and click New Port.

9

Fill in the Enter a port name field with the shared name.

10

Click OK and click Close.

11

Click Apply and click OK.

25

Sharing the Printer Locally

7

Using Smart Panel

Smart Panel is a program that monitors and informs you of the status of the printer, and allows you to customize the printer’s settings. Smart Panel is installed automatically when you install the printer software.

N

OTES

:

• To use this program, you need:

- Windows 98 or higher (Windows NT 4.0 can be used only for network-supported printers.) To check for Operating

System(s) that are compatible with your printer, refer to

Printer Specifications in your Printer User’s Guide.

- Mac OS X 10.3 or higher

- Linux. To check for Linux systems that are compatible with your printer, refer to Printer Specifications in your Printer

User’s Guide.

- Internet Explorer version 5.0 or higher for flash animation in HTML Help.

• If you need to know the exact name of your printer, you can check the supplied CD-ROM.

Understanding Smart Panel

If an error occurs while printing, Smart Panel appears automatically, showing the error.

You can also launch Smart Panel manually. Double-click the

Smart Panel icon on the Windows task bar (in Windows), or

Notification Area (in Linux). You can also click it on the status bar (in Mac OS X).

Double-click this icon in Windows.

Click this icon in Mac OS X.

Click this icon in Linux.

26

Using Smart Panel

If you are a Windows user, from the Start menu, select

Programs or All Programs

your printer driver name

Smart Panel.

N

OTES

:

• If you have already installed more than one Samsung printer, first select the printer model you want in order to use the corresponding Smart Panel. Right-click (in Windows or Linux) or click (in Mac OS X) the Smart Panel icon and select your printer name.

• The Smart Panel window and its contents shown in this

Software User’s Guide may differ depending on the printer or

Operating System in use.

The Smart Panel program displays the current status of the printer, the level of toner remaining in the toner cartridge(s) and various other information. You can also change settings.

1

2

4

5

3

1

Toner Level

You can view the level of toner remaining in the toner cartridge(s). The printer and the number of toner cartridge(s) shown in the above window may differ depending on the printer in use. Any printers do not have this feature.

2

Buy Now

You can order replacement toner cartridge(s) online.

3

Troubleshooting Guide

You can view Help to solve problems.

4

Printer Setting

You can configure various printer settings in the Printer Settings

Utility window. Any printers do not have this feature.

N

OTE

:

If your printer is connected to a network and you are a

Windows user, the SyncThru Web Service window appears instead of the Printer Settings Utility window. Mac OS X and

Linux do not support network environments.

5

Driver Setting (Only for Windows)

You can use the printer properties window, which allows you to access all of the printer options you need for using your

printer. For details, See “Printer Settings” on page 13.

Opening the Troubleshooting

Guide

Using the troubleshooting guide, you can view solutions for error status problems.

Right-click (in Windows or Linux) or click (in Mac OS X) the

Smart Panel icon and select Troubleshooting Guide.

Using Printer Settings Utility

Using the Printer Settings Utility, you can configure and check print settings.

1

Right-click (in Windows or Linux) or click (in Mac OS X) the

Smart Panel icon and select Printer Setting.

2

Change the settings.

3

To send the changes to the printer, click the Apply button.

N

OTES

: If your printer is connected to a network, the

SyncThru Web Service window appears instead of the

Printer Settings Utility window.

Using Onscreen Help File

For more information about Printer Settings Utility, click .

Changing the Smart Panel

Program Settings

Right-click (in Windows or Linux) or click (in Mac OS X) the

Smart Panel icon and select Options.

The following window opens.

Display when job is finished for network printer: The computer shows the Smart Panel popup window or balloon when your job is complete in Windows.

(Only for

Windows network-supported printers.)

Display when error occurs during printing: The computer shows the Smart Panel popup window or balloon when an error occurs during printing.

Display with: You can select how the computer shows you a message. If you select Popup window (smart

panel), the message appears in the Smart Panel popup window in Windows and Mac OS X.

Launch Job Monitor when the job is saved in the

printer: If you store print jobs on the printer’s hard disk, the computer opens the Job Monitor window in Windows.

(Only for Windows network-supported printers with built-in hard disks.)

Schedule an automatic status checking every: The computer updates the printer status regularly. Setting the value close to 1 second causes the computer to check the printer status more frequently, thereby allowing a faster response to any printer error.

27

Using Smart Panel

8

Using Your Printer in

Linux

You can use your machine in a Linux environment.

This chapter includes:

• Getting Started

• Installing the Unified Linux Driver

• Using the Unified Driver Configurator

• Configuring Printer Properties

• Printing a Document

Getting Started

The supplied CD-ROM provides you with Samsung’s Unified

Linux Driver package for using your machine with a Linux computer.

After the driver is installed on your Linux system, the driver package allows you to monitor a number of machine devices via fast ECP parallel ports and USB simultaneously.

The Unified Linux Driver package is supplied with a smart and flexible installation program. You don't need to search for additional components that might be necessary for the Unified

Linux Driver software: all required packages will be carried onto your system and installed automatically; this is possible on a wide set of the most popular Linux clones.

Installing the Unified Linux

Driver

Installing the Unified Linux Driver

1

Make sure that you connect your machine to your computer. Turn both the computer and the machine on.

2

When the Administrator Login window appears, type in

root

in the Login field and enter the system password.

N

OTE

: You must log in as a super user (root) to install the printer software. If you are not a super user, ask your system administrator.

3

Insert the printer software CD-ROM. The CD-ROM will automatically run.

If the CD-ROM does not automatically run, click the icon at the bottom of the desktop. When the Terminal screen appears, type in:

If the CD-ROM is secondary master and the location to mount is /mnt/cdrom,

[[email protected] root]#mount -t iso9660 /dev/hdc /mnt/ cdrom

[[email protected] root]#cd /mnt/cdrom/Linux

[[email protected] root]#./install.sh

N

OTE

: The installation program runs automatically if you have an autorun software package installed and configured.

4

When the welcome screen appears, click Next.

28

Using Your Printer in Linux

5

When the installation is complete, click Finish.

The installation program has added the Unified Driver

Configurator desktop icon and Samsung Unified Driver group to the system menu for your convenience. If you have any difficulties, consult the onscreen help that is available through your system menu or can otherwise be called from the driver package windows applications, such as Unified Driver Configurator.

Uninstalling the Unified Linux Driver

1

When the Administrator Login window appears, type in

root

in the Login field and enter the system password.

N

OTE

: You must log in as a super user (root) to install the printer software. If you are not a super user, ask your system administrator.

2

Insert the printer software CD-ROM. The CD-ROM will automatically run.

If the CD-ROM does not automatically run, click the icon at the bottom of the desktop. When the Terminal screen appears, type in:

If the CD-ROM is secondary master and the location to mount is /mnt/cdrom,

[[email protected] root]#mount -t iso9660 /dev/hdc /mnt/ cdrom

[[email protected] root]#cd /mnt/cdrom/Linux

[[email protected] root]#./uninstall.sh

N

OTE

: The installation program runs automatically if you have an autorun software package installed and configured.

3

Click Uninstall.

4

Click Next.

29

Using Your Printer in Linux

5

Click Finish.

Using the Unified Driver

Configurator

Unified Linux Driver Configurator is a tool primarily intended for configuring Printer.

After installing the Unified Linux driver, the Unified Linux Driver

Configurator icon will automatically be created on your desktop.

Opening the Unified Driver

Configurator

1

Double-click Unified Driver Configurator on the desktop.

You can also click the Startup Menu icon and select

Samsung Unified Driver and then Unified Driver

Configurator.

2

Press each button on the Modules pane to switch to the corresponding configuration window.

Printers Configuration button

Scanners Configuration button

(for MFP device only)

Ports Configuration button

Printers Configuration

Printers configuration has the two tabs: Printers and Classes.

Printers Tab

You can see the current system’s printer configuration by clicking on the printer icon button on the left side of the Unified

Driver Configurator window.

Switches to Printer configuration.

Shows all of the installed printer.

Shows the status, model name and

URI of your printer.

You can use the following printer control buttons:

Refresh: renews the available printers list.

Add Printer: allows you to add a new printer.

Remove Printer: removes the selected printer.

Set as Default: sets the current printer as a default printer.

Stop/Start: stops/starts the printer.

Test: allows you to print a test page to check if the machine is working properly.

Properties: allows you to view and change the printer

properties. For details, see page 31.

You can use the onscreen help by clicking Help.

3

After changing the configurations, click Exit to close the

Unified Driver Configurator.

30

Using Your Printer in Linux

Classes Tab

The Classes tab shows a list of available printer classes.

Shows all of the printer classes.

Shows the status of the class and the number of printers in the class.

Refresh : Renews the classes list.

Add Class... : Allows you to add a new printer class.

Remove Class : Removes the selected printer class.

Ports Configuration

In this window, you can view the list of available ports, check the status of each port and release a port that is stalled in busy state when its owner is terminated for any reason.

Switches to ports configuration.

Shows the port type, device connected to the port and status

Shows all of the available ports.

Refresh : Renews the available ports list.

Release port : Releases the selected port.

Configuring Printer Properties

Using the properties window provided by the Printers configuration, you can change the various properties for your machine as a printer.

1

Open the Unified Driver Configurator.

If necessary, switch to Printers configuration.

2

Select your machine on the available printers list and click

Properties.

3

The Printer Properties window opens.

The following five tabs display at the top of the window:

General: allows you to change the printer location and name. The name entered in this tab displays on the printer list in Printers configuration.

Connection: allows you to view or select another port. If you change the printer port from USB to parallel or vice versa while in use, you must re-configure the printer port in this tab.

Driver: allows you to view or select another printer driver. By clicking Options, you can set the default device options.

Jobs: shows the list of print jobs. Click Cancel job to cancel the selected job and select the Show completed

jobs check box to see previous jobs on the job list.

Classes: shows the class that your printer is in. Click

Add to Class to add your printer to a specific class or click Remove from Class to remove the printer from the selected class.

4

Click OK to apply the changes and close the Printer

Properties Window.

31

Using Your Printer in Linux

Printing a Document

Printing from Applications

There are a lot of Linux applications that you are allowed to print from using Common UNIX Printing System (CUPS). You can print on your machine from any such application.

1

From the application you are using, select Print from the

File menu.

2

Select Print directly using lpr.

3

In the LPR GUI window, select the model name of your machine from the Printer list and click Properties.

Click.

4

Change the printer and print job properties.

The following four tabs display at the top of the window.

General - allows you to change the paper size, the paper type, and the orientation of the documents, enables the duplex feature, adds start and end banners, and changes the number of pages per sheet.

Text - allows you to specify the page margins and set the text options, such as spacing or columns.

Graphics - allows you to set image options that are used when printing images/files, such as color options, image size, or image position.

Device: allows you to set the print resolution, paper source, and destination.

5

Click Apply to apply the changes and close the Properties window.

6

Click OK in the LPR GUI window to start printing.

7

The Printing window appears, allowing you to monitor the status of your print job.

To abort the current job, click Cancel.

Printing Files

You can print many different types of files on the Samsung machine device using the standard CUPS way - directly from the command line interface. The CUPS lpr utility allows you do that. But the drivers package replaces the standard lpr tool by a much more user-friendly LPR GUI program.

To print any document file:

1

Type

lpr <file_name>

from the Linux shell command line and press Enter. The LPR GUI window appears.

When you type only

lpr

and press Enter, the Select file(s) to print window appears first. Just select any files you want to print and click Open.

2

In the LPR GUI window, select your printer from the list, and change the printer and print job properties.

For details about the properties window, see page 32.

3

Click OK to start printing.

32

Using Your Printer in Linux

9

Using Your Printer with a Macintosh

Your machine supports Macintosh systems with a built-in USB interface or a 10/100 Base-TX network interface card. When you print a file from a Macintosh computer, you can use the

PostScript driver by installing the PPD file.

N

OTE

:

Some printers do not support a network interface. Make sure that your printer supports a network interface by referring to Printer Specifications in your Printer User’s Guide.

This chapter includes:

• Installing Software for Macintosh

• Setting Up the Printer

• Printing

Installing Software for

Macintosh

The PostScript driver CD-ROM that came with your machine provides you with the PPD file to use the PS driver, Apple

LaserWriter driver, for printing on a Macintosh computer.

1

Connect your machine to the computer using the USB cable or the Ethernet cable.

2

Turn on your computer and the machine.

3

Insert the PostScript driver CD-ROM which came with your machine into the CD-ROM drive.

4

Double-click the CD-ROM icon on your Macintosh desktop.

5

Double-click the MAC_Installer folder.

6

Double-click the MAC_Printer folder.

7

For Mac OS 8.6~9.2, double-click the Samsung LBP

Installer Classic icon.

For Mac OS 10.1 or higher, double-click the Samsung LBP

Installer OSX icon.

8

Click Continue.

9

Click Install.

10

After the installation is finished, click Quit.

33

Using Your Printer with a Macintosh

Setting Up the Printer

Set up for your printer will be different depending on which cable you use to connect the printer to your computer—the network cable or the USB cable.

For a Network-connected Macintosh

N

OTE

:

Some printers do not support a network interface. Before connecting your printer, make sure that your printer supports a network interface by referring to Printer Specifications in your Printer User’s

Guide.

Mac OS 8.6 ~ 9.2

1

Follow the instructions on “Installing Software for

Macintosh” on page 33 to install the PPD file on your

computer.

2

From the Apple menu, select Chooser.

3

Click LaserWriter 8 (the PostScript driver provided with your Macintosh).

The name of your machine appears on the list.

4

Select SEC000xxxxxxxxx from the printer box (where the xxxxxxxxx varies depending on each of the machines) and Click Select.

If Auto Setup does not work properly, click Select PPD, choose your printer name, and click OK.

5

When the setup is complete, you see your machine icon created as a desktop printer.

6

Close the Chooser.

7

When a message window appears telling you that you have changed your current machine, click OK.

Mac OS 10.1 or higher

1

Follow the instructions on “Installing Software for

Macintosh” on page 33 to install the PPD file on your

computer.

2

Open Print Center or Printer Setup Utility from the

Utilities folder.

3

Click Add on the Printer List.

4

Select the AppleTalk tab.

The name of your machine appears on the list. Select

SEC000xxxxxxxxx from the printer box, where the

xxxxxxxxx varies depending on your machine.

5

Click Add.

6

If Auto Select does not work properly, select Samsung in

Printer Model and your printer name in Model Name.

Your machine appears on the Printer List and is set as the default printer.

For a USB-connected Macintosh

Mac OS 10.1 or higher

1

Follow the instructions on “Installing Software for

Macintosh” on page 33 to install the PPD file on your

computer.

2

Open Print Center or Printer Setup Utility from the

Utilities folder.

3

Click Add on the Printer List.

4

Select the USB tab.

5

Select your printer name and click Add.

6

If Auto Select does not work properly, select Samsung in

Printer Model and your printer name in Model Name.

Your machine appears on the Printer List and is set as the default printer.

34

Using Your Printer with a Macintosh

Printing

N

OTES

:

• The Macintosh printer’s properties window that appears in this User’s Guide may differ depending on the printer in use.

However the composition of the printer properties window is similar.

• You can check your printer name in the supplied CD-

ROM.

Printing a Document

When you print with a Macintosh, you need to check the printer software setting in each application you use. Follow these steps to print from a Macintosh.

1

Open a Macintosh application and select the file you want to print.

2

Open the File menu and click Page Setup (Document

Setup in some applications).

3

Choose your paper size, orientation, scaling, and other options and click OK.

Make sure that your printer is selected.

Changing Printer Settings

You can use advanced printing features when using your printer.

From your Macintosh application, select Print from the File menu. The printer name which appears in the printer properties window may differ depending on the printer in use. Except for the name, the composition of the printer properties window is similar.

Layout Setting

The Layout tab provides options to adjust how the document appears on the printed page. You can print multiple pages on one sheet of paper.

Select Layout from the Presets drop-down list to access the

following features. For details, see “Printing Multiple Pages on

One Sheet of Paper” on the next column.

▲ Mac OS 10.3

▲ Mac OS 10.3

4

Open the File menu and click Print.

5

Choose the number of copies you want and indicate which pages you want to print.

6

Click Print when you finish setting the options.

35

Printer Features Setting

The Printer Features tab provides options for selecting the paper type and adjusting print quality.

Select Printer Features from the Presets drop-down list to access the following features:

Printing Multiple Pages on One Sheet of Paper

You can print more than one page on a single sheet of paper.

This feature provides a cost-effective way to print draft pages.

1

From your Macintosh application, select Print from the

File menu.

2

Select Layout.

▲ Mac OS 10.3

Reverse Duplex

Allows you to select general print order compare to duplex print order.

Fit to Page

This printer feature allows you to scale your print job to any selected paper size regardless of the digital document size. This can be useful when you want to check fine details on a small document.

Paper Type

Set Type to correspond to the paper loaded in the tray from which you want to print. This will let you get the best quality printout. If you load a different type of print material, select the corresponding paper type.

Resolution(Quality)

The Resolution options you can select may vary depending on your printer model.

You can select the printing resolution. The higher the setting, the sharper the clarity of printed characters and graphics. The higher setting also may increase the time it takes to print a document.

▲ Mac OS 10.3

3

Select the number of pages you want to print on one sheet of paper on the Pages per Sheet drop-down list.

4

Select the page order from the Layout Direction option.

To print a border around each page on the sheet, select the option you want from the Border drop-down list.

5

Click Print, and the printer prints the selected number of pages on one side of each page.

36

Duplex Printing

You can print on both sides of the paper. Before printing in the duplex mode, decide on which edge you will be binding your finished document. The binding options are:

Long-Edge Binding: Which is the conventional layout

used in book binding.

Short-Edge Binding: Which is the type often used with

calendars.

1

From your Macintosh application, select Print from the

File menu.

2

Select the Layout.

▲ Mac OS 10.3

3

Select a binding orientation from Two Sided Printing option.

4

Click Print and the printer prints on both sides of the paper.

C

AUTION

:

If you have selected duplex printing and then try to print multiple copies of a document, the printer may not print the document in the way you want. In case of "Collated copy" , if your document has odd pages, the last page of the first copy and the first page of the next copy will be printed on the front and back of one sheet. In case of "Uncollated copy", the same page will be printed on the front and back of one sheet. Therefore, if you need multiple copies of a document and you want those copies on both sides of the paper, you must print them one at a time, as separate print jobs

.

37

S

OFTWARE SECTION

I

NDEX

A

advanced printing, use

18

B

booklet printing

19

D

document, print

Macintosh

35

Windows

12

double-sided printing

20

E

Extras properties, set

16

F

favorites settings, use

17

G

Graphics properties, set
