DRAFT
USER’S GUIDE
BOXLIGHT XP-8t
TO THE OWNER
Before operating this projector, read this manual thoroughly and operate the projector properly.
This projector provides many convenient features and functions. Operating the projector properly enables you to
manage those features and maintains it in better condition for a considerable time.
Improper operation may result in not only shortening the product-life, but also malfunctions, fire hazard, or other
accidents.
If your projector seems to operate improperly, read this manual again, check operations and cable connections and try
the solutions in the “Trouble-shooting” section of the end of this booklet. If the problem still persists, contact the sales
dealer where you purchased the projector or the service center.
SAFETY PRECAUTIONS
WARNING : TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO
RAIN OR MOISTURE.
● This projector produces intense light from the projection lens. Do not stare directly into the lens as possible.
Eye damage could result. Be especially careful that children do not stare directly into the beam.
● This projector should be set in the way indicated. If not, it may result in a fire hazard.
● Take appropriate space on the top, sides and rear of the projector
cabinet for allowing air circulation and cooling the projector.
Minimum distance should be taken. If the projector is to be built
into a compartment or similarly enclosed, the minimum distances
must be maintained. Do not cover the ventilation slot on the
projector. Heat build-up can reduce the service life of your
projector, and can also be dangerous.
SIDE and TOP
REAR
20cm
50cm
50cm
50cm
● Do not put any flammable object or spray can near the projector, hot air is exhausted from the ventilation
holes.
● If the projector is not to be used for an extended time, unplug the projector from the power outlet.
READ AND KEEP THIS OWNER'S MANUAL FOR LATER USE.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION :
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USERSERVICEABLE PARTS INSIDE EXCEPT LAMP REPLACEMENT. REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
THIS SYMBOL INDICATES THAT DANGEROUS
VOLTAGE CONSTITUTING A RISK OF ELECTRIC
SHOCK IS PRESENT WITHIN THIS UNIT.
2
THIS SYMBOL INDICATES THAT THERE ARE IMPORTANT
OPERATING AND MAINTENANCE INSTRUCTIONS IN THE
OWNER'S MANUAL WITH THIS UNIT.
SAFETY INSTRUCTIONS
All the safety and operating instructions should be read before
the product is operated.
Read all of the instructions given here and retain them for later
use. Unplug this projector from AC power supply before
cleaning. Do not use liquid or aerosol cleaners. Use a damp
cloth for cleaning.
This projector should be operated only from the type of power
source indicated on the marking label. If you are not sure of
the type of power supplied, consult your authorized dealer or
local power company.
Follow all warnings and instructions marked on the projector.
Do not overload wall outlets and extension cords as this can
result in fire or electric shock. Do not allow anything to rest on
the power cord. Do not locate this projector where the cord
may be damaged by persons walking on it.
For added protection to the projector during a lightning storm,
or when it is left unattended and unused for long periods of
time, unplug it from the wall outlet. This will prevent damage
due to lightning and power line surges.
Do not attempt to service this projector yourself as opening or
removing covers may expose you to dangerous voltage or
other hazards. Refer all servicing to qualified service
personnel.
Do not expose this unit to rain or use near water... for
example, in a wet basement, near a swimming pool, etc...
Do not use attachments not recommended by the
manufacturer as they may cause hazards.
Do not place this projector on an unstable cart, stand, or table.
The projector may fall, causing serious injury to a child or
adult, and serious damage to the projector. Use only with a
cart or stand recommended by the manufacturer, or sold with
the projector. Wall or shelf mounting should follow the
manufacturer's instructions, and should use a mounting kit
approved by the manufacturers.
An appliance and cart combination should
be moved with care. Quick stops,
excessive force, and uneven surfaces
may cause the appliance and cart
combination to overturn.
Slots and openings in the back and bottom of the cabinet are
provided for ventilation, to insure reliable operation of the
equipment and to protect it from overheating.
Unplug this projector from wall outlet and refer servicing to
qualified service personnel under the following conditions:
a. When the power cord or plug is damaged or frayed.
b. If liquid has been spilled into the projector.
c. If the projector has been exposed to rain or water.
d. If the projector does not operate normally by following the
operating instructions. Adjust only those controls that are
covered by the operating instructions as improper
adjustment of other controls may result in damage and will
often require extensive work by a qualified technician to
restore the projector to normal operation.
e. If the projector has been dropped or the cabinet has been
damaged.
f. When the projector exhibits a distinct change in
performance-this indicates a need for service.
When replacement parts are required, be sure the service
technician has used replacement parts specified by the
manufacturer that have the same characteristics as the
original part. Unauthorized substitutions may result in fire,
electric shock, or injury to persons.
Upon completion of any service or repairs to this projector, ask
the service technician to perform routine safety checks to
determine that the projector is in safe operating condition.
The openings should never be covered with cloth or other
materials, and the bottom opening should not be blocked by
placing the projector on a bed, sofa, rug, or other similar
surface. This projector should never be placed near or over a
radiator or heat register.
This projector should not be placed in a built-in installation
such as a book case unless proper ventilation is provided.
Never push objects of any kind into this projector through
cabinet slots as they may touch dangerous voltage points or
short out parts that could result in a fire or electric shock.
Never spill liquid of any kind on the projector.
Voor de klanten in Nederland
Bij dit product zijn batterijen
geleverd.
Wanneer deze leeg zijn,
moet u ze niet weggooien
maar inleveren als KCA.
3
COMPLIANCES
Federal Communication Commission Notice
Note : This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following measures :
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
– Consult the dealer or an experienced radio/TV technician for help.
Use of shielded cable is required to comply with class B limits in Subpart B of Part 15 of FCC Rules.
Do not make any changes or modifications to the equipment unless otherwise specified in the instructions. If such
changes or modifications should be made, you could be required to stop operation of the equipment.
Model Number
Trade Name
Responsible party
Address
Telephone No.
: BOXLIGHT XP-8t
: Boxlight
: BOXLIGHT
: 19332 Powder Hill Place Poulsbo, WA 98370-7407 USA
: (800)762-5757
AC POWER CORD REQUIREMENT
The AC Power Cord supplied with this projector meets the requirement for use in the country you purchased it.
AC Power Cord for the United States and Canada :
AC Power Cord used in the United States and Canada is listed by the Underwriters
Laboratories (UL) and certified by the Canadian Standard Association (CSA).
AC Power Cord has a grounding-type AC line plug. This is a safety feature to be sure that the
plug will fit into the power outlet. Do not try to defeat this safety feature. Should you be
unable to insert the plug into the outlet, contact your electrician.
GROUND
THE SOCKET-OUTLET SHOULD BE INSTALLED NEAR THE EQUIPMENT AND EASILY ACCESSIBLE.
4
TABLE OF CONTENTS
FEATURES AND DESIGN
PREPARATION
6
7
COMPUTER INPUT
SELECTING INPUT SOURCE
SELECTING COMPUTER SYSTEM
COMPATIBLE COMPUTER SPECIFICATIONS
PC ADJUSTMENT
NAME OF EACH PART OF PROJECTOR
SETTING-UP PROJECTOR
CONNECTING AC POWER CORD
POSITIONING PROJECTOR
ADJUSTABLE FEET
MOVING PROJECTOR
7
8
8
9
9
10
CONNECTING PROJECTOR
11
TERMINALS OF PROJECTOR
CONNECTING TO COMPUTER
CONNECTING TO VIDEO EQUIPMENT
11
12
13
BEFORE OPERATION
OPERATION OF REMOTE CONTROL
OPERATING RANGE
REMOTE CONTROL BATTERY INSTALLATION
TOP CONTROLS AND INDICATORS
OPERATING ON-SCREEN MENU
HOW TO OPERATE ON-SCREEN MENU
FLOW OF ON-SCREEN MENU OPERATION
MENU BAR
14
14
15
15
16
17
17
17
18
AUTO PC ADJUSTMENT
MANUAL PC ADJUSTMENT
PICTURE IMAGE ADJUSTMENT
IMAGE LEVEL SELECT
IMAGE LEVEL ADJUSTMENT
PICTURE SCREEN ADJUSTMENT
VIDEO INPUT
SELECTING INPUT SOURCE
SELECTING VIDEO SYSTEM
PICTURE IMAGE ADJUSTMENT
IMAGE LEVEL SELECT
IMAGE LEVEL ADJUSTMENT
PICTURE SCREEN ADJUSTMENT
SETTING
SETTING MENU
APPENDIX
MAINTENANCE
BASIC OPERATION
TURNING ON / OFF PROJECTOR
ADJUSTING SCREEN
ZOOM ADJUSTMENT
FOCUS ADJUSTMENT
KEYSTONE ADJUSTMENT
PICTURE FREEZE FUNCTION
NO SHOW FUNCTION
P-TIMER FUNCTION
SOUND ADJUSTMENT
19
19
20
20
20
20
20
21
21
22
22
22
23
24
24
25
27
27
28
29
30
30
31
32
32
33
34
35
35
37
37
WARNING TEMP. INDICATOR
AIR FILTER CARE AND CLEANING
CLEANING PROJECTION LENS
LAMP REPLACEMENT
LAMP REPLACE COUNTER
37
37
37
38
38
TROUBLESHOOTING
TECHNICAL SPECIFICATIONS
39
41
21
TRADEMARKS
● Apple, Macintosh, and PowerBook are trademarks or registered trademarks of Apple Computer,Inc.
● IBM and PS/2 are trademarks or registered trademarks of International Business Machines, Inc.
● Windows and PowerPoint are registered trademarks of Microsoft Corporation.
● Each name of corporations or products in the owner's manual is a trademark or a registered trademark of its
respective corporation.
5
FEATURES AND DESIGN
This Multimedia Projector is designed with the most advanced technology for portability, durability, and ease of use. This
projector utilizes built-in multimedia features, a palette of 16.77 million colors, and matrix liquid crystal display (LCD)
technology.
◆
Compact Design
This projector is extremely compact in size and weight.
It is designed to carry and work anywhere you wish to
use.
◆
● Computers
IBM-compatible or Macintosh computer up to 1280
x 1024 resolution.
● 6 Color Systems
NTSC, PAL, SECAM, NTSC 4.43, PAL-M or PALN color system can be connected.
● Component Video
Component video signal, such as a DVD player
output, high definition TV signals including 480i,
480p, 575i, 575p, 720p, 1035i or 1080i, can be
connected.
● S-Video
S-Video signal, such as a S-VHS VCR output
signal, can be connected.
High Resolution Image
This projector provides 1024 x 768 dots resolution for
computer input and 550 horizontal TV lines. Resolution
from a computer between XGA (1024 x 768) and SXGA
(1280 x 1024) is compressed into 1024 x 768 dots. This
projector cannot display image of over 1280 x 1024 dots.
When resolution of your computer is higher than 1280 x
1024, reset a computer output for lower resolution.
◆
Multi-Scan System
This projector has Multi-Scan System to conform to
almost all computer output signals quickly. There is no
need for troublesome manual adjustment of frequency
and other settings.
6
One-Touch Auto PC Adjustment
Incoming computer video signals are recognized and the
best adjustment is automatically set by Auto PC
Adjustment. No complicated setup is necessary and
projection is always precise.
Compatibility
This projector widely accepts various video and
computer input signals including;
◆
◆
◆
Digital Zoom (for Computer)
Digital Zoom function expands (to approx. 16 times of
screen size) or compress the image size, allowing you to
focus on crucial information at a presentation.
◆
Keystone Correction
Positioning height of a projector may result in distorted
image being displayed in a trapezoid shape. Keystone
Correction solves this problem by digitally altering
projection to produce undistorted images.
◆
Power Management
Power Management function is provided to reduce power
consumption while a projector is not in use.
This Power Management function operates to turn
Projection Lamp off when a projector detects signal
interruption and any button is not pressed over 5
minutes. Projection Lamp is automatically turned on
again when a projector detects signal or any operation
button is pressed.
This projector is shipped with this function ON.
◆
Multilanguage Menu Display
Operation menu is displayed in; English, German,
French, Italian, Spanish, Portuguese, Dutch, Swedish,
Chinese, Korean or Japanese.
PREPARATION
NAME OF EACH PART OF PROJECTOR
FRONT
INFRARED
REMOTE RECEIVER
POWER CORD CONNECTOR
PROJECTION LENS
FOCUS RING
EXHAUST VENTS
ZOOM LEVER
LENS COVER
HOT AIR EXHAUSTED !
Air blown from Exhaust Vents is hot. When using or
installing projector, following precautions should be taken.
● Do not put any flammable object near these vents.
● Keep front grills at least 3’(1m) away from any object,
especially heat-sensitive object.
● Do not touch this area, especially screw and metallic part.
This area will become hot while a projector is used.
This projector detects internal temperature and
automatically controls operating power of Cooling Fans.
BACK
TOP CONTROLS
AND INDICATORS
TERMINALS
AND CONNECTORS
AIR INTAKE VENTS
(Back and Bottom)
SPEAKER
BOTTOM
This projector is equipped with Cooling
Fans for protection from overheating.
Pay attention to the following to ensure
proper ventilation and avoid a possible
risk of fire and malfunction.
● Do not cover vent slots.
● Keep back and bottom clear of any
object. Obstructions may block
cooling air.
AIR INTAKE VENTS
AND AIR FILTERS
ADJUSTABLE FEET
AND
FEET LOCK LATCHES
LAMP COVER
7
PREPARATION
SETTING-UP PROJECTOR
CONNECTING AC POWER CORD
This projector uses nominal input voltages of 100-120 V or 200-240
V AC. This projector automatically selects the correct input
voltage. It is designed to work with single-phase power systems
having a grounded neutral conductor. To reduce risk of electrical
shock, do not plug into any other type of power system.
Consult your authorized dealer or service station if you are not sure
of the type of power supply being in use.
Connect a projector with a peripheral equipment before turning a
projector on. (Refer to pages 11 ~ 13 for connection.)
CAUTION
For safety, unplug AC Power Cord when an appliance is not
used.
When this projector is connected to the outlet with AC Power
Cord, an appliance is in Stand-by Mode and consumes a little
electric power.
Connect AC Power Cord (supplied) to a projector.
The AC outlet must be near this equipment and
must be easily accessible.
NOTE ON THE POWER CORD
AC Power Cord must meet requirement of the country where you use a projector.
Confirm an AC plug type with the chart below and proper AC Power Cord must be used.
If supplied AC Power Cord does not match your AC outlet, contact your sales dealer.
Projector side
AC Outlet side
For the U.S.A. and Canada
For Continental Europe
Ground
To POWER CORD
CONNECTOR on your
projector.
8
To the AC Outlet.
(120 V AC)
To the AC Outlet.
(200 - 240 V AC)
PREPARATION
POSITIONING PROJECTOR
● This projector is designed to project on a flat projection surface.
● The projector can be focused from 5.3’(1.6m) ~ 26.6’(8.1m).
● Refer to the figure below to adjust a screen size.
ROOM LIGHT
The brightness in a room has a great influence on
picture quality. It is recommended to limit
ambient lighting in order to provide the best
image.
26.6’ (8.1m)
20.0’ (6.1m)
200”
13.1’ (4.0m)
150”
Max. Zoom
5.3’ (1.6m)
166”
100”
123”
Min. Zoom
H1
83”
40”
H2
34”
Screen Size
(W x H) mm
34”
40”
100”
150”
200”
690.9 x 518.2
812.8 x 609.6
2032 x 1524
3048 x 2286
4064 x 3048
Height (H1)
19.4”(492.3mm)
22.8”(579.12mm)
57”(1447.8mm)
85.5”(2171.7mm)
114”(2895.6mm)
Height (H2)
1.0”(25.9mm)
1.2”(30.48mm)
3”(76.2mm)
4.5”(114.3mm)
6”(152.4mm)
ADJUSTABLE FEET
Picture tilt and projection angle can be adjusted by rotating
ADJUSTABLE FEET. Projection angle can be adjusted to 10.6
degrees.
1
Lift the front of a projector and pull FEET LOCK LATCHES
on the both sides of a projector.
2
Release FEET LOCK LATCHES to lock ADJUSTABLE FEET
and rotate ADJUSTABLE FEET to adjust position and tilt.
3
To retract ADJUSTABLE FEET, lift the front of a projector
and pull and undo FEET LOCK LATCHES.
Keystone distortion of a projected image can be adjusted by
Menu Operation. (Refer to P20 and 35.)
CAUTION
Avoid positioning a projector with the angle of more than 20
degrees. Projection Lamp may malfunction.
ADJUSTABLE FEET
FEET LOCK
LATCHES
9
PREPARATION
MOVING PROJECTOR
When moving a projector, replace Lens Cover and retract Adjustable Feet to prevent damage to the lens and cabinet.
When the projector is not in use for an extended period, put it into the case (carrying bag) supplied with the projector.
CAUTION
Carrying Bag (supplied) is intended for protection from dust and scratches on the surface of a cabinet, and it is not designed
to protect an appliance from external forces. Do not transport a projector through a courier or transport services with this
bag, otherwise the projector can be damaged. When handling a projector, do not drop, bump, subject it to strong forces or
put other things on the cabinet.
CAUTION IN CARRYING OR TRANSPORTING THE PROJECTOR
● Do not drop or bump a projector, otherwise damages or malfunctions may result.
● When carrying a projector, use a suitable carrying case.
● Do not transport a projector by using a courier or transport service in an unsuitable transport case. This may cause
damage to a projector. To transport a projector through a courier or transport service, consult Boxlight dealer for best
way.
10
CONNECTING PROJECTOR
TERMINALS OF PROJECTOR
This projector has input and output terminals on its side for connecting computers and video equipment. Refer to figures on
pages 11 to 13 and connect properly.
USB CONNECTOR (Series B)
RESET BUTTON
VIDEO INPUT JACKS
When controlling the computer
with Remote Control Unit of this
projector, connect USB port of
your personal computer to this
connector. (Refer to P12.)
This projector uses a micro
processor to control this unit,
and occasionally, this micro
processor may malfunction
and need to be reset. This
can be done by pressing
RESET button with a pen,
which will shut down and
restart the unit. Do not use
RESET function excessively.
Connect the composite video
output from video equipment
to VIDEO/Y jack or connect
the component video outputs
to VIDEO/Y, Pb/Cb and
Pr/Cr jacks. (Refer to P13.)
S-VIDEO INPUT JACK
Connect the S-VIDEO
output from video
equipment to this
jack. (Refer to P13.)
CONTROL PORT CONNECTOR
VIDEO
RESET
Y – Pb / Cb – Pr / Cr
When controlling the computer
with Remote Control Unit of
this projector, connect the
mouse port of your personal
computer to this connector.
(Refer to P12.)
USB
COMPUTER
CONTROL PORT
S–VIDEO
AUDIO IN
COMPUTER INPUT
TERMINAL (ANALOG)
AV
COMPUTER IN
Connect the computer
output to this jack.
(Refer to P12.)
AUDIO OUT
COMPUTER AUDIO
INPUT JACK
Connect the audio output
(stereo) from computer to
this jack. (Refer to P12.)
AUDIO OUTPUT JACK
AUDIO INPUT JACK
Connect an external
audio amplifier to this
jack.
(Refer to P12, 13.)
Connect the audio output
from video equipment to
this jack.
(Refer to P13.)
11
CONNECTING PROJECTOR
CONNECTING TO COMPUTER
Cables used for connection
(✽ = Cable or adapter is not supplied with this projector.)
• VGA Cable (HDB 15 pin)
• MAC Adapter (When connecting to Macintosh computer)
• Audio Cable (Mini Plug (stereo) x 1) ✽
• Control Cable for PS/2 Port ✽, Serial Port ✽, or ADB Port ✽
• USB Cable ✽
IBM-compatible computer or Macintosh computer (VGA / SVGA / XGA / SXGA)
Desktop type
Laptop type
Monitor Output
Audio Output
MAC Adapter ✽
Set slide switches
according to the
chart below.
USB port
PS/2 port
ADB port
Control Cable
Control Cable
for Serial Port ✽ for PS/2 Port ✽
USB
Cable ✽
Audio
Cable ✽
(stereo)
Serial port
Terminal
Terminal
Control Cable
for ADB Port ✽
Terminal
VGA Cable
COMPUTER AUDIO IN
USB
CONTROL PORT
Use one of these Control
Cables or USB Cable
corresponding with the
terminal of your computer.
COMPUTER IN ANALOG
VIDEO
RESET
Y – Pb / Cb – Pr / Cr
USB
COMPUTER
CONTROL PORT
S–VIDEO
AUDIO IN
AV
COMPUTER IN
AUDIO OUT
Terminals
of the Projector
AUDIO OUT
NOTE :
When connecting the cable, the power
cords of both the projector and the external
equipment should be disconnected from
AC outlet. Turn the projector and
peripheral equipment on before the
computer is switched on.
Audio Cable
(stereo) ✽
◆ MAC ADAPTER (Not supplied)
Set switches as shown in the table ON
below depending on RESOLUTION
MODE that you want to use before
you turn on projector and computer. OFF
1
13" MODE (640 x 480)
ON
16" MODE (832 x 624) OFF
19" MODE (1024 x 768) OFF
21" MODE (1152 x 870) ON
12
2
ON
ON
ON
ON
3
ON
DIP
1 2 3 4 5 6
4
5
Audio Input
6
OFF OFF OFF OFF
OFF ON OFF OFF
ON OFF OFF OFF
ON ON OFF OFF
External Audio Equipment
Audio Speaker
Audio Amplifier
(stereo)
✽
CONNECTING PROJECTOR
CONNECTING TO VIDEO EQUIPMENT
Cables used for connection
(✽ = Cable is not supplied with this projector.)
• Video Cable (RCA x 1 or RCA x 3) ✽
• S-VIDEO Cable ✽
• Audio Cable (Mini Plug (stereo) x 1) ✽
Component video output equipment.
Video Source (example)
Video Cassette Recorder
Audio Output
Audio Cable
(stereo) ✽
Composite
Video Output
Component Video Output
(Y, Pb/Cb, Pr/Cr)
Video Cable
(RCA x 1) ✽
AUDIO IN
(such as DVD player or high-definition
TV source.)
Video Disc Player
VIDEO
Video Cable
(RCA x 3) ✽
Y - Pb/Cb - Cr/Pr
S-VIDEO Output
S-VIDEO
Cable ✽
S-VIDEO
Use any of VIDEO jack Y-Pb/CbPr/Cr jacks or S-VIDEO jack.
• When both VIDEO jack and SVIDEO jack are connected, SVIDEO jack has priority over
VIDEO jack.
• When both Y-Pb/Cb-Pr/Cr jacks
and S-VIDEO jack are connected,
Y-Pb/Cb-Pr/Cr jacks has priority
over S-VIDEO jack.
VIDEO
RESET
Y – Pb / Cb – Pr / Cr
USB
COMPUTER
CONTROL PORT
S–VIDEO
AUDIO IN
AV
COMPUTER IN
AUDIO
UDIO OUT
AUDIO OUT
Terminals
of the Projector
Audio Cable
(Stereo) ✽
Audio Input
External Audio Equipment
Audio Amplifier Audio Speaker (stereo)
NOTE :
When connecting the cable, the power
cords of both the projector and the external
equipment should be disconnected from
AC outlet.
13
BEFORE OPERATION
OPERATION OF REMOTE CONTROL
Infrared signals are transmitted from this point.
INPUT BUTTON
POWER ON-OFF BUTTON
Used to select input source.
(P22, 30)
ON–OFF
INPUT
D.ZOOM BUTTONS
Used to turn the projector
on or off. (P19)
VOLUME BUTTONS
Used to select DIGITAL
ZOOM mode and resize the
image. (P29)
KEYSTONE D.ZOOM
VOLUME
+
Used to adjust volume.
(P21)
POINT BUTTONS
KEYSTONE BUTTONS
Used to correct
keystone distortion.
(P20, 35)
–
the
MENU BUTTON
MENU
Used to move the pointer on
the MENU, to adjust the
item, or to pan the image in
DIGITAL ZOOM mode.
(P29)
SELECT
Used to select MENU
operation. (P17, 18)
SELECT BUTTON
FREEZE BUTTON
NOSHOW FREEZE
MUTE
AUTO PC ADJ. P–TIMER
Used to freeze the picture.
(P20)
NO SHOW BUTTON
Used to turn the picture into
black image. (P21)
Used to execute the item
selected or to expand /
compress the image in
DIGITAL ZOOM mode.
(P29)
MUTE BUTTON
Used to mute sound.(P21)
AUTO PC ADJ. BUTTON
Use to operate Auto PC
Adjustment function. (P24)
IMAGE BUTTON
Used to select image level.
(P27, 32)
P-TIMER BUTTON
Used to operate P-TIMER
function. (P21)
To insure safe operation, please observe the following
precautions :
● Do not bend, drop Remote Control Unit, or expose
Remote Control Unit to moisture or heat.
● For cleaning, use soft dry cloth. Do not apply
benzene, thinner, splay or any chemical material.
Battery is installed in Remote
Control Unit.
Before operation, pull out and
remove a protect sheet from
Remote Control Unit. This sheet
protecting discharge of a battery.
AUTO PC ADJ. P–TIMER
Pull and remove.
BATTERY PROTECT SHEET
(transparent sheet)
14
BEFORE OPERATION
OPERATING RANGE
Point Remote Control Unit toward projector (Receiver
Window) whenever pressing any button. Maximum
operating range for Remote Control Unit is about 16.4’ (5m)
and 60° in front of the projector.
16.4’
(5 m)
30°
30°
REMOTE CONTROL BATTERY INSTALLATION
1
Pull out Battery Holder.
2
Replace with new battery. Install
with battery (+),(–) marks properly.
Put Battery + mark
as shown direction.
3
Install battery and
Battery Holder into
Remote Control Unit.
BATTERY
LITHIUM BATTERY
CR2025 (3.0V)
(+) mark indicates
its (+) polarity.
BATTERY HOLDER
To insure safe operation, please observe the following precautions :
● Use only specified battery. Improper battery may cause malfunction of Remote Control or improper battery's
installation may cause explosion.
● Be sure to install battery with correct polarity.
● Do not expose a battery to moisture or heat. Do not charge a battery.
● If a battery have leaked on Remote Cotrol Unit, carefully wipe the case clean and load a new battery.
● Dispose used battery according to the battery-manufacturer's instrunctions.
15
BEFORE OPERATION
TOP CONTROLS AND INDICATORS
This projector has CONTROL BUTTONS (TOP CONTROLS) and INDICATORS on its top.
LAMP INDICATOR
Becomes dim when the
projector is turned on.
And bright when the
projector is in stand-by
mode.
POWER ON–OFF BUTTON
Used to turn the projector
on or off. (P19)
READY INDICATOR
LAMP
INPUT BUTTON
Used to select input
source. (P22, 30)
READY
ON – OFF
WARNING
TEMP .
INPUT
MENU BUTTON
Used to open or close
MENU operation. (P17,
18)
LAMP
REPLACE
MENU
WARNING TEMP. INDICATOR
-VOLUME-
Flashes red when
internal
projector
temperature is too
high. (P37)
SELECT
LAMP REPLACE INDICATOR
IMAGE BUTTON
Turns to yellow when
the life of the projection
lamp draws to an end.
(P38)
Used to select image
level. (P27, 32)
16
Lights green when the
projector is ready to be
turned on.
And it
flashes green in Power
Management mode.
(P36)
SELECT BUTTON
POINT (VOLUME + / – ) BUTTONS
Used to execute the item
selected. It is also used
to expand / compress
the image in DIGITAL
ZOOM mode. (P29)
Used to select an item or adjust
value in ON-SCREEN MENU. They
are also used to pan the image in
DIGITAL ZOOM +/– mode. (P29)
POINT LEFT/RIGHT buttons are
also used as VOLUME +/– buttons.
BEFORE OPERATION
OPERATING ON-SCREEN MENU
HOW TO OPERATE ON-SCREEN MENU
You can control and adjust this projector through ON-SCREEN
MENU. Refer to the following pages to operate each adjustment
on ON-SCREEN MENU.
WIRELESS REMOTE CONTROL
POINT BUTTON
Used to move the
Pointer UP/ DOWN/
RIGHT/ LEFT.
MENU BUTTON
1 DISPLAY MENU
Press MENU button to display ON-SCREEN MENU.
2 MOVING POINTER
Move the pointer (✽ see below) or adjust the value of item by
pressing POINT button(s) on Top Control or on Remote Control
Unit.
✽ Pointer is the icon on ON-SCREEN MENU to select the item.
See the figures on the section "FLOW OF ON-SCREEN MENU
OPERATION" below.
SELECT BUTTON
Used to select the item.
TOP CONTROL
MENU BUTTON
MENU
-VOLUME-
3 SELECT ITEM
Select the item or set selected function by pressing SELECT
button.
POINT BUTTONS
Used to move the
Pointer UP/ DOWN/
RIGHT/ LEFT.
SELECT
SELECT BUTTON
Used to select the item.
FLOW OF ON-SCREEN MENU OPERATION
Display ON-SCREEN MENU
1
MENU ICON
Press MENU button to display ON-SCREEN MENU (MENU
BAR). A red frame is POINTER.
Select Menu to be adjusted
2
MENU BAR
Move POINTER (red frame) to MENU ICON that you want to
select by pressing POINT RIGHT / LEFT buttons.
POINTER (red frame)
Press POINT DOWN button to
move POINTER.
POINTER
(red frame)
ITEM
Control or adjust item through ON-SCREEN MENU
3
4
Press POINT DOWN button and move POINTER (red frame
or red arrow) to ITEM that you want to adjust, and then press
SELECT button to show ITEM DATA.
SELECT
BUTTON
Adjust ITEM DATA by pressing POINT RIGHT / LEFT
buttons.
Refer to the following pages for details of respective
adjustments.
ITEM DATA
Press POINT LEFT/RIGHT
buttons to adjust value or
set function.
17
BEFORE OPERATION
MENU BAR
FOR PC SOURCE
Press MENU BUTTON while connecting to PC input source.
GUIDE WINDOW
PC SYSTEM MENU
Shows selected
item of ONSCREEN MENU.
Used to select
computer system.
(Refer to P22, 23)
IMAGE SELECT MENU
SCREEN MENU
SETTING MENU
Used to select
image level among
Standard, Real
and Image 1 ~ 4.
(Refer to P27)
Used to adjust size
of image. [Normal
/ True / Wide /
Digital zoom +/–]
(Refer to P29)
Used to change
settings of projector
or reset Lamp
Replace Counter.
(Refer to P35, 36)
INPUT MENU
PC ADJUST MENU
IMAGE ADJUST MENU
SOUND MENU
Used to select
input source either
Computer or
Video.
(Refer to P22)
Used to adjust
parameters to
match with input
signal format.
(Refer to P24-26)
Used to adjust computer
image.
[Contrast / Brightness /
Color / Tint / White balance
(R/G/B) / Sharpness /
Gamma]
(Refer to P28)
Used to adjust
volume or mute
sound.
(Refer to P21)
FOR VIDEO SOURCE
Press MENU BUTTON while connecting to VIDEO input source.
INPUT MENU
IMAGE SELECT MENU
Used to select
input source
either Video or
Computer.
(Refer to P30)
Used to select image
level among
Standard, Cinema
and Image 1 ~ 4.
(Refer to P32)
Same function as
Menu for PC source.
AV SYSTEM MENU
Used to select
system of selected
video source.
(Refer to P31)
IMAGE ADJUST MENU
Used to adjust picture image.
[Contrast / Brightness / Color /
Tint / White balance (R/G/B) /
Sharpness / Gamma]
(Refer to P33, 34)
18
SCREEN MENU
Used to set size of
image to Normal
or Wide.
(Refer to P34)
Same function as
Menu for PC source.
BASIC OPERATION
TURNING ON / OFF PROJECTOR
TURNING ON PROJECTOR
1
Complete peripheral connections (with Computer, VCR, etc.)
before turning on projector. (Refer to "CONNECTING TO
PROJECTOR" on pages 11~13 for connecting that equipment.)
2
Connect the projector's AC Power Cord into an AC outlet. LAMP
Indicator lights RED, and READY Indicator lights GREEN.
3
Press POWER ON-OFF button on Top Control or on Remote
Control Unit to ON. LAMP Indicator dims, and Cooling Fans
start to operate. Preparation Display appears on a screen and
the count-down starts. The signal from PC or Video source
appears after 30 seconds.
30
Preparation Display disappears after 30 seconds.
TURNING OFF PROJECTOR
1
Press POWER ON-OFF button on Top Control or on Remote
Control Unit, and a message "Power off?" appears on a screen.
2
Press POWER ON-OFF button again to turn off projector. LAMP
Indicator lights bright and READY Indicator turns off. After
projector is turned off, Cooling Fans operate (for 90 seconds).
During this "Cooling Down" period, the projector cannot be
turned on.
3
When projector has cooled down, READY Indicator lights
GREEN again and you can turn projector on. After cooling down
completely, disconnect AC Power Cord.
Power off?
Message disappears after 4 seconds.
TO MAINTAIN THE LIFE OF LAMP, ONCE YOU TURN
PROJECTOR ON, WAIT AT LEAST 5 MINUTES BEFORE
TURNING IT OFF.
When “Power Management” function is ON, projector detects signal interruption and turns off Projection Lamp automatically.
Refer to “Power Management” on page 36.
When WARNING TEMP. Indicator flashes red, projector is automatically turned off. Wait at least 5 minutes before turning on
projector again.
When WARNING TEMP. Indicator continues to flash, follow procedures below:
1. Press POWER ON-OFF button to turn a projector off and disconnect AC Power Cord from an AC outlet.
2. Check Air Filters for dust accumulation.
3. Clean Air Filters. (See "AIR FILTER CARE AND CLEANING" section on page 37.)
4. Turn a projector on again.
If WARNING TEMP. Indicator should still continue to flash, call Boxlight at 1-800-762-5757 or 360-779-7901.
19
BASIC OPERATION
ADJUSTING SCREEN
ZOOM ADJUSTMENT
Move ZOOM LEVER upward to make the image larger. Move ZOOM
LEVER downward to make the image smaller.
ZOOM LEVER
WIDE
TELE
FOCUS ADJUSTMENT
Rotate the FOCUS RING to adjust the projected picture focus.
FOCUS RING
KEYSTONE ADJUSTMENT
If a projected picture has keystone distortion, correct image with KEYSTONE adjustment.
1
Press KEYSTONE ▲/▼ button on Remote Control Unit or select
Keystone on SETTING menu. (Refer to page 35.) Keystone
dialog box appears.
2
Correct keystone distortion by pressing KEYSTONE ▲/▼ button
or POINT UP/DOWN button(s). Press KEYSTONE ▲ button or
POINT UP button to reduce the upper part of image, and press
KEYSTONE ▼ button or POINT DOWN button to reduce the
lower part.
Reduce the upper width with KEY STONE ▲ button
or POINT UP button.
Reduce the lower width with KEY STONE ▼ button
or POINT DOWN button.
PICTURE FREEZE FUNCTION
Press FREEZE button on Remote Control Unit to freeze the picture
on-screen. To cancel FREEZE function, press FREEZE button again
or press any other button.
20
BASIC OPERATION
NO SHOW FUNCTION
Press NO SHOW button on Remote Control Unit to black out the
image. To restore to normal, press NO SHOW button again or press
any other button.
No show
Message disappears after 4 seconds.
P-TIMER FUNCTION
Press P-TIMER button on Remote Control unit. The timer display “00
: 00” appears on the screen and the timer starts to count time (00 : 00
~ 59 : 59).
To stop P-TIMER display, press P-TIMER button. And then, press PTIMER button again to cancel P-TIMER function.
SOUND ADJUSTMENT
Indicates roughly level of
volume.
DIRECT OPERATION
Volume
Press VOLUME (+/–) button(s) on Remote Control Unit or POINT
LEFT / RIGHT button on Top Control to adjust volume. Volume dialog
box appears on the screen for a few seconds.
VOLUME (+) or POINT RIGHT button to increase volume, and
VOLUME (–) or POINT LEFT button for decreasing.
Mute
Press MUTE button on Remote Control Unit to cut off sound. To
restore sound to its previous level, press MUTE button again or press
Volume (+/–) or POINT LEFT / RIGHT button(s).
Press MUTE button to set
Mute function On or Off.
The display disappears after 4 seconds.
MENU OPERATION
SOUND MENU
1
Press MENU button and ON-SCREEN MENU will appear. Press
POINT LEFT/RIGHT buttons to move a red frame pointer to
SOUND Menu icon.
2
Press POINT DOWN button to move a red frame pointer to the
item that you want to select, and then press SELECT button.
SOUND Menu icon
Volume
Indicates roughly
level of volume.
Close SOUND Menu.
To increase volume, press POINT RIGHT button, and press POINT
LEFT button for decreasing.
Mute
Press POINT LEFT/RIGHT button(s) to cut off sound. Dialog box
display is changed to “On” and sound is cut off. To restore sound to
its previous level, press POINT LEFT/RIGHT button(s) again.
21
COMPUTER INPUT
SELECTING INPUT SOURCE
DIRECT OPERATION
INPUT button
Computer
Choose Computer by pressing INPUT button on Top Control or on
Remote Control Unit.
If projector cannot reproduce proper image, select correct input source
through MENU OPERATION (see below).
Video
MENU OPERATION
1
Press MENU button and ON-SCREEN MENU will appear. Press
POINT LEFT/RIGHT button to move a red frame pointer to
INPUT Menu icon.
2
Press POINT DOWN button to move a red arrow pointer to
Computer and then press SELECT button.
INPUT MENU
INPUT Menu icon
Move a pointer (red arrow)
to Computer and press
SELECT button.
SELECTING COMPUTER SYSTEM
This projector automatically tunes to most different types of computers based on VGA, SVGA, XGA or SXGA (refer to
“COMPATIBLE COMPUTER SPECIFICATION” on page 23). When selecting Computer, this projector automatically tunes
to incoming signal and projects proper image without any special setting. (Some computers need setting manually.)
Note : Projector may display one of the following messages.
Auto
––––
When projector cannot recognize connected signal as PC
system provided in this projector, Auto PC Adjustment
function operates to adjust projector and the message
“Auto” is displayed on SYSTEM Menu icon. (Refer to
P24.) When image is not provided properly, manual
adjustment is required. (Refer to P25 and 26.)
PC SYSTEM MENU
SYSTEM Menu icon
Displays system being
selected.
There is no signal input from computer. Make sure the
connection of computer and a projector is set correctly.
(Refer to TROUBLESHOOTING on page 39.)
SELECT COMPUTER SYSTEM MANUALLY
This projector automatically selects PC system among those provided
in this projector and PC system can be also selected manually.
1
2
Press MENU button and ON-SCREEN MENU will appear. Press
POINT LEFT/RIGHT buttons to move a red frame pointer to PC
SYSTEM Menu icon.
Press POINT DOWN button to move a red arrow pointer to the
system that you want to set, and then press SELECT button.
PC SYSTEM MENU
SYSTEM Menu icon
Displays system being selected.
The systems on this dialog box
can be selected.
Custom Mode (1~5) set in PC
ADJUST Menu. (P25, 26)
22
COMPUTER INPUT
COMPATIBLE COMPUTER SPECIFICATIONS
Basically this projector can accept the signal from all computers with the V, H-Frequency below mentioned and less than 140
MHz of Dot Clock.
ON-SCREEN
DISPLAY
VGA 1
VGA 2
VGA 3
VGA 4
VGA 5
VGA 6
VGA 7
MAC LC13
MAC 13
RGB
RGB
SVGA 1
SVGA 2
SVGA 3
SVGA 4
SVGA 5
SVGA 6
SVGA 7
SVGA 8
SVGA 9
SVGA 10
SVGA 11
MAC 16
XGA 1
XGA 2
XGA 3
XGA 4
XGA 5
XGA 6
XGA 7
XGA 8
XGA 9
RESOLUTION
640 x 480
720 x 400
640 x 400
640 x 480
640 x 480
640 x 480
640 x 480
640 x 480
640 x 480
––––––––
––––––––
800 x 600
800 x 600
800 x 600
800 x 600
800 x 600
800 x 600
800 x 600
800 x 600
800 x 600
800 x 600
800 x 600
832 x 624
1024 x 768
1024 x 768
1024 x 768
1024 x 768
1024 x 768
1024 x 768
1024 x 768
1024 x 768
1024 x 768
H-Freq.
(kHz)
31.47
31.47
31.47
37.86
37.86
37.50
43.269
34.97
35.00
15.625
15.734
35.156
37.88
46.875
53.674
48.08
37.90
34.50
38.00
38.60
32.70
38.00
49.72
48.36
68.677
60.023
56.476
60.31
48.50
44.00
63.48
36.00
V-Freq.
(Hz)
59.88
70.09
70.09
74.38
72.81
75.00
85.00
66.60
66.67
50
(Interlace)
60
(Interlace)
56.25
60.32
75.00
85.06
72.19
61.03
55.38
60.51
60.31
51.09
60.51
74.55
60.00
84.997
75.03
70.07
74.92
60.02
54.58
79.35
87.17
(Interlace)
ON-SCREEN
DISPLAY
XGA 10
XGA 11
XGA 12
XGA 13
XGA 14
XGA 15
MAC 19
MAC 21
SXGA 1
SXGA 2
SXGA 3
SXGA 4
SXGA 5
SXGA 6
SXGA 7
SXGA 8
SXGA 9
SXGA 10
SXGA 11
SXGA 12
SXGA 13
SXGA 14
SXGA 15
SXGA 16
SXGA 17
SXGA 18
SXGA 19
MAC
MAC
720p (HDTV)
1035i (HDTV)
1080i (HDTV)
RESOLUTION
1024 x 768
1024 x 768
1024 x 768
1024 x 768
1024 x 768
1024 x 768
1024 x 768
1152 x 870
1152 x 864
1280 x 1024
1280 x 1024
1280 x 1024
1280 x 1024
1280 x 1024
1280 x 1024
1280 x 1024
1280 x 1024
1280 x 960
1152 x 900
1152 x 900
1280 x 1024
1280 x 1024
1280 x 1024
1280 x 1024
1152 x 900
1280 x 1024
1280 x 1024
1280 x 960
1280 x 1024
––––––––
––––––––
––––––––
H-Freq.
(kHz)
62.04
61.00
35.522
46.90
47.00
58.03
60.24
68.68
64.20
62.50
63.90
63.34
63.74
71.69
81.13
63.98
79.976
60.00
61.20
71.40
50.00
50.00
63.37
76.97
61.85
46.43
63.79
75.00
80.00
45.00
33.75
33.75
V-Freq.
(Hz)
77.07
75.70
86.96
(Interlace)
58.20
58.30
72.00
75.08
75.06
70.40
58.60
60.00
59.98
60.01
67.19
76.107
60.02
75.025
60.00
65.20
75.60
86.00
(Interlace)
94.00
(Interlace)
60.01
72.00
66.00
86.70
(Interlace)
60.18
75.08
75.08
60.00
60.00
(Interlace)
60.00
(Interlace)
NOTE : Specifications are subject to change without notice.
23
COMPUTER INPUT
PC ADJUSTMENT
AUTO PC ADJUSTMENT
Auto PC Adjustment function is provided to automatically adjust Fine sync, Total dots and Picture Position to conform to your
computer. Auto PC Adjustment function can be operated as follows.
Auto PC Adj.
1
Press MENU button and ON-SCREEN MENU will appear. Press
POINT LEFT/RIGHT button to move a red frame pointer to PC
ADJUST Menu icon.
2
Press POINT DOWN button to move a red frame pointer to
AUTO PC Adj. icon and then press SELECT button twice.
This Auto PC Adjustment can be also executed by pressing
AUTO PC ADJ. button on Remote Control Unit.
Store adjustment parameters.
Adjustment parameters from Auto PC Adjustment can be memorized
in this projector. Once parameters are memorized, setting can be
done just by selecting Mode in PC SYSTEM Menu (P22). Refer to
step 3 of MANUAL PC ADJUSTMENT section (P26).
NOTE
● Fine sync, Total dots and Picture Position of some computers can
not be fully adjusted with this Auto PC Adjustment function. When
the image is not provided properly through this function, manual
adjustments are required. (Refer to page 25, 26.)
● Auto PC Adjustment function cannot be operated when “RGB,”
“720p (HDTV),” “1035i (HDTV)” or “1080i (HDTV)” is selected on PC
SYSTEM Menu (P22).
24
PC ADJUST MENU
PC ADJUST Menu icon
Move a red frame pointer to AUTO PC
Adj. icon and press SELECT button.
COMPUTER INPUT
MANUAL PC ADJUSTMENT
This projector can automatically tune to the display signals from most personal computers currently distributed. However,
some computers employ special signal formats which are different from the standard ones and may not be tuned by MultiScan system of this projector. If this happens, projector cannot reproduce a proper image and the image may be recognized
as a flickering picture, a non-synchronized picture, a non-centered picture or a skewed picture.
This projector has a Manual PC Adjustment to enable you to precisely adjust several parameters to match with those special
signal formats. This projector has 5 independent memory areas to memorize those parameters manually adjusted. This
enables you to recall the setting for a specific computer whenever you use it.
Note : This PC ADJSUT Menu cannot be operated when "RGB" is selected on PC SYSTEM Menu (P22).
1
Press MENU button and ON-SCREEN MENU will appear. Press
POINT LEFT/RIGHT button to move a red frame pointer to PC
ADJUST Menu icon.
2
Press POINT DOWN button to move a red frame pointer to the
item that you want to adjust and then press SELECT button.
Adjustment dialog box will appear. Press POINT LEFT/RIGHT
button to adjust value.
Fine sync
PC ADJUST MENU
PC ADJUST Menu icon
Move a red frame icon to the item and
press SELECT button.
Adjusts an image as necessary to eliminate flicker from the display.
Press POINT LEFT/RIGHT button to adjust value.(From 0 to 31.)
Total dots
The number of total dots in one horizontal period. Press POINT
LEFT/RIGHT button(s) and adjust number to match your PC image.
Selected Mode
Shows status
(Stored / Free) of the
selected Mode.
Horizontal
Adjusts horizontal picture position. Press POINT LEFT/RIGHT
button(s) to adjust the position.
Vertical
Adjusts vertical picture position. Press POINT LEFT/RIGHT
button(s) to adjust the position.
Current mode
Press POINT LEFT/RIGHT
button to adjust the value.
Press SELECT button at this
icon to adjust “Clamp,” “Display
area (H/V)” or set “Full screen.”
Press SELECT button to show the information of computer selected.
Clamp
Adjusts clamp level. When the image has a dark bar(s), try this
adjustment.
Current mode
Press SELECT button at
Current mode icon to show
the information of computer
connected.
25
COMPUTER INPUT
Display area
Selects area displayed with this projector. Select the resolution at
Display area dialog box.
Press SELECT button at
Display area icon and Display
area dialog box appears.
Display area H
Adjustment of horizontal area displayed with this projector. Press
POINT LEFT/RIGHT button(s) to decrease/increase value to match
the resolurtion of image.
Display area
Display area V
Adjustment of vertical area displayed with this projector. Press
POINT LEFT/RIGHT button(s) to decrease/increase value to match
the resolurtion of image.
Full screen
Press POINT LEFT/RIGHT button(s) to switch Full screen function to
“On” or “Off.” Set “On” to resize the image with 4 x 3 aspect ratio to
fit the screen.
NOTE : Fine sync, Total dots, Display area (H/V) and Full screen
cannot be adjusted when “1035i (HDTV)” or “1080i (HDTV)”
is selected on PC SYSTEM Menu (P22).
3
To store adjustment data.
This Mode has parameters being stored.
Store
To store adjustment parameters, move a red frame pointer to
Store icon and then press SELECT button. Move a red arrow
pointer to any of Mode 1 to 5 that you want to store to and then
press SELECT button.
Mode free
To clear adjustment parameters previously set, move a red
frame pointer to Mode free icon and then SELECT button. Move
a red arrow pointer to the Mode that you want to clear and then
press SELECT button.
Other icons operates as follows.
Vacant Mode
Shows values of “Total dots,”
“Horizontal,” “Vertical,” “Display
area H,” and “Display area V.”
Reset
Reset all adjust parameters on adjustment dialog box to previous
figure.
To clear adjustment data.
Quit
Closes PC ADJUST MENU.
Close this dialog box.
26
COMPUTER INPUT
PICTURE IMAGE ADJUSTMENT
IMAGE LEVEL SELECT (DIRECT)
Select image level among Standard, Real, Image 1, Image 2, Image 3
and Image 4 by pressing IMAGE button on Top Control or on Remote
Control Unit.
IMAGE button
Standard
Real
Standard
Normal picture adjustment preset on this projector.
Image 1
Real
Picture adjustment improved in reproduction of halftones. This
adjustment is suitable for providing better image in brighter place.
Image 2
Image 3
IMAGE 1~4
User preset picture adjustment in IMAGE ADJUST Menu (P28, 29).
Image 4
IMAGE LEVEL SELECT (MENU)
1
Press MENU button and ON-SCREEN MENU will appear. Press
POINT LEFT/RIGHT button to move a red frame pointer to
IMAGE SELECT Menu icon.
2
Press POINT DOWN button to move a red frame pointer to the
level that you want to set and then press SELECT button.
IMAGE SELECT MENU
IMAGE SELECT
Menu icon
Standard
Normal picture adjustment preset on this projector.
Real
Move a red frame pointer to the level
and press SELECT button.
Picture adjustment improved in reproduction of halftones. This
adjustment is suitable for providing better image in brighter place.
IMAGE 1~4
The level being selected.
User preset picture adjustment in IMAGE ADJUST Menu (P28, 29).
27
COMPUTER INPUT
IMAGE LEVEL ADJUSTMENT
1
Press MENU button and ON-SCREEN MENU will appear. Press
POINT LEFT/RIGHT buttons to move a red frame pointer to
IMAGE ADJUST Menu icon.
2
Press POINT DOWN button to move a red frame pointer to the
item that you want to adjust. and then press SELECT button.
The level of each item is displayed. Adjust each level by
pressing POINT LEFT/RIGHT button(s).
IMAGE ADJUST MENU
Move a red frame pointer to
the item to be selected and
then press SELECT button.
IMAGE ADJUST
Menu icon
Contrast
Press POINT LEFT button to decrease contrast, and POINT RIGHT
button to increase contrast. (From 0 to 63.)
Brightness
Press POINT LEFT button to adjust image darker, and POINT
RIGHT button to adjust brighter. (From 0 to 63.)
Selected Image level
Color
Press POINT LEFT button to lighten color, and POINT RIGHT button
to deeper color. (From 0 to 63.)
Tint
Press POINT LEFT button or POINT RIGHT button to obtain proper
color. (From 0 to 63.)
White balance (Red)
Press POINT LEFT button to lighten red tone and POINT RIGHT
button to deeper tone. (From 0 to 63.)
Press POINT LEFT/RIGHT buttons
to adjust value.
Store icon
Press SELECT button at this icon to
store the adjustment.
White balance (Green)
Press POINT LEFT button to lighten green tone and POINT RIGHT
button to deeper tone. (From 0 to 63.)
White balance (Blue)
Press POINT LEFT button to lighten blue tone and POINT RIGHT
button to deeper tone. (From 0 to 63.)
Sharpness
Press POINT LEFT button to soften the image, and POINT RIGHT
button to sharpen the image. (From 0 to 15.)
Gamma
Press either POINT LEFT button or POINT RIGHT button to obtain
better balance of contrast. (From 0 to 15.)
28
Press POINT LEFT/RIGHT buttons
to adjust value.
COMPUTER INPUT
3
Store
To store manually preset image, move a red frame pointer to
Store icon and press SELECT button. Image Level Menu will
appear. Move a red frame pointer to the Image 1 to 4 where you
want to set and then press SELECT button.
Image Level Menu
Move a red frame pointer to any
of Image 1 to 4 where you want
to set and then press SELECT
button.
Other icons operates as follows.
Reset
Reset all adjustment to previous figure.
Quit
Closes IMAGE MENU.
PICTURE SCREEN ADJUSTMENT
This projector has a picture screen resize function, which enables you to display the desirable image size.
1
Press MENU button and ON-SCREEN MENU will appear. Press
POINT LEFT/RIGHT button(s) to move a red frame pointer to
SCREEN Menu icon.
2
Press POINT DOWN button and move a red frame pointer to the
function that you want to select and then press SELECT button.
SCREEN MENU
SCREEN Menu icon
Move the red frame to the function and
press SELECT button.
Normal
Provides image to fit screen size.
True
Provides image in its original size. When the original image size is
larger than screen size (1024 x 768), this projector enters “Digital
zoom +” mode automatically.
Wide
Provides image to fit wide video aspect ratio (16 : 9) by expanding
image width uniformly. This function can be used for providing a
squeezed video signal at 16 : 9.
Digital zoom +
When Digital zoom + is selected, ON-SCREEN MENU disappears
and the message “D. Zoom +” is displayed. Press SELECT button to
expand image size. And press POINT UP/DOWN/LEFT/RIGHT
button(s) to pan the image. Panning function can work only when
the image is larger than screen size.
A projected image can be also expanded by pressing D.ZOOM ▲
button on Remote Control Unit.
Digital zoom –
When Digital zoom – is selected, ON-SCREEN MENU disappears
and the message “D. Zoom –” is displayed. Press SELECT button to
compress image size.
A projected image can be also compressed by pressing D.ZOOM ▼
button on Remote Control Unit.
NOTE
● This SCREEN Menu cannot be operated when
“1035i (HDTV)” or “1080i (HDTV)” is selected on
PC SYSTEM Menu (P22).
● Wide cannot be selected when “720p (HDTV)” is
selected on PC SYSTEM Menu (P22).
● True and Digital zoom +/– cannot be selected
when “RGB” is selected on PC SYSTEM Menu
(P22).
● This projector cannot display any resolution higher
than 1280 X 1024. If your computer’s screen
resolution is higher than 1280 X 1024, reset the
resolution to the lower before connecting projector.
● Digital zoom – cannot be fully operated when the
image resolution is higher than XGA (1024 x 768).
● The image data in other than XGA (1024 x 768) is
modified to fit the screen size in initial mode.
● Panning function may not operate properly if the
computer system prepared on PC ADJUST Menu
is used.
To cancel Digital Zoom +/– mode, press any button except D.ZOOM
▲/▼, SELECT, and POINT buttons.
29
VIDEO INPUT
SELECTING INPUT SOURCE
DIRECT OPERATION
INPUT button
Video
Choose Video by pressing INPUT button on Top Control or on Remote
Control Unit.
If projector cannot reproduce proper video source, select correct input
source through MENU OPERATION (see below).
Computer
MENU OPERATION
1
Press MENU button and ON-SCREEN MENU will appear. Press
POINT LEFT/RIGHT button to move a red frame pointer to
INPUT Menu icon.
2
Press POINT DOWN button to move a red arrow pointer to
Video and then press SELECT button. Source Select Menu will
appear.
3
Move a pointer to the source that you want to select and then
press SELECT button.
Auto
Projector automatically detects incoming Video signal,
and adjusts itself to optimize its performance.
• When both VIDEO jack and S-VIDEO jack are
connected, S-VIDEO jack has priority over VIDEO jack.
• When both Y-Pb/Cb-Pr/Cr jacks and S-VIDEO jack are
connected, Y-Pb/Cb-Pr/Cr jacks have priority over SVIDEO jack.
Video
When video input signal is connected to VIDEO jack,
select Video.
S-Video
When video input signal is connected to S-VIDEO jack,
select S-Video.
Y,Pb/Cb,Pr/Cr
30
When video input signal is connected to Y-Pb/CbPr/Cr jacks, select Y, Pb/Cb, Pr/Cr.
INPUT MENU
Move a pointer to Video and
press SELECT button.
VIDEO
Source Select Menu (VIDEO)
Move a pointer to the source and press SELECT button.
VIDEO INPUT
SELECTING VIDEO SYSTEM
1
Press MENU button and ON-SCREEN MENU will appear. Press
POINT LEFT/RIGHT buttons to move a red frame pointer to AV
SYSTEM Menu icon.
2
Press POINT DOWN button to move a red arrow pointer to the
system that you want to select and then press SELECT button.
VIDEO JACK OR S-VIDEO JACK
Auto
Projector automatically detects incoming Video system, and adjusts
itself to optimize its performance.
When Video System is PAL-M or PAL-N, select system manually.
PAL / SECAM / NTSC / NTSC4.43 / PAL-M / PAL-N
If projector cannot reproduce proper video image, it is necessary to
select a specific broadcast signal format among PAL, SECAM, NTSC,
NTSC 4.43, PAL-M, and PAL-N.
AV SYSTEM MENU (VIDEO OR S-VIDEO)
AV SYSTEM Menu icon
This box indicates the system
being selected.
Move the pointer to the
system and press
SELECT button.
Y, Pb/Cb, Pr/Cr JACKS
Auto
Projector automatically detects incoming Video signal, and adjusts
itself to optimize its performance.
COMPONENT VIDEO SIGNAL FORMAT
If projector cannot reproduce proper video image, it is necessary to
select a specific component video signal format among 480i, 575i,
480p, 575p, 720p, 1035i and 1080i.
AV SYSTEM MENU (COMPONENT VIDEO)
AV SYSTEM Menu icon
This box indicates the system
being selected.
Move the pointer to the
system and press
SELECT button.
31
VIDEO INPUT
PICTURE IMAGE ADJUSTMENT
IMAGE LEVEL SELECT (DIRECT)
Select image level among Standard, Cinema, Image 1, Image 2,
Image 3 and Image 4 by pressing IMAGE button on Top Control or on
Remote Control Unit.
IMAGE button
Standard
Cinema
Standard
Normal picture adjustment preset on this projector.
Image 1
Cinema
Picture level adjusted for the picture with fine tone.
Image 2
IMAGE 1~4
User preset picture adjustment in IMAGE ADJUST Menu (P33,34).
Image 3
Image 4
IMAGE LEVEL SELECT (MENU)
1
Press MENU button and ON-SCREEN MENU will appear. Press
POINT LEFT/RIGHT button to move a red frame pointer to
IMAGE SELECT Menu icon.
2
Press POINT DOWN button to move a red frame pointer to the
level that you want to set and then press SELECT button.
IMAGE SELECT MENU
IMAGE SELECT
Menu icon
Standard
Normal picture adjustment preset on this projector.
Cinema
Move the red frame pointer to the
level and press SELECT button.
Picture level adjusted for the picture with fine tone.
IMAGE 1~4
User preset picture adjustment in IMAGE ADJUST Menu (P33,34).
32
The level being selected.
VIDEO INPUT
IMAGE LEVEL ADJUSTMENT
1
Press MENU button and ON-SCREEN MENU will appear. Press
POINT LEFT/RIGHT button(s) to move a red frame pointer to
IMAGE ADJUST Menu icon.
2
Press POINT DOWN button to move a red frame pointer to the
item that you want to adjust and then press SELECT button.
The level of each item is displayed. Adjust each level by
pressing POINT LEFT/RIGHT button(s).
IMAGE ADJUST MENU
Move a red frame pointer to
the item to be selected and
then press SELECT button.
IMAGE ADJUST
Menu icon
Contrast
Press POINT LEFT button to decrease contrast, and POINT RIGHT
button to increase contrast. (From 0 to 63.)
Brightness
Press POINT LEFT button to adjust image darker, and POINT
RIGHT button to adjust brighter. (From 0 to 63.)
Color
Press POINT LEFT button to lighten color, and POINT RIGHT button
to deeper color. (From 0 to 63.)
Press POINT LEFT/RIGHT buttons
to adjust value.
Tint
Press POINT LEFT button or POINT RIGHT button to obtain proper
color. (From 0 to 63.)
Press SELECT button at this icon to
display other items.
White balance (Red)
Press POINT LEFT button to lighten red tone and POINT RIGHT
button to deeper tone. (From 0 to 63.)
Press SELECT button at this icon to
display previous items.
White balance (Green)
Press POINT LEFT button to lighten green tone and POINT RIGHT
button to deeper tone. (From 0 to 63.)
White balance (Blue)
Press POINT LEFT button to lighten blue tone and POINT RIGHT
button to deeper tone. (From 0 to 63.)
Press POINT LEFT/RIGHT buttons
to adjust value.
Sharpness
Press POINT LEFT button to soften the image, and POINT RIGHT
button to sharpen the image. (From 0 to 15.)
Gamma
Press SELECT button at this icon to
store the value.
Press either POINT LEFT button or POINT RIGHT button to obtain
better balance of contrast. (From 0 to 15.)
NOTE : Tint cannot be adjusted when the video system is PAL,
SECAM, PAL-M or PAL-N.
33
VIDEO INPUT
3
Store
To store the adjustment data, move a red frame pointer to Store
icon and press SELECT button. Image Level Menu will appear.
Move a red frame pointer to the Image Level 1 to 4 and then
press SELECT button.
Other icons operates as follows.
Image Level Menu
Move a red frame pointer to
the image icon to be set
and then press SELECT
button.
Reset
Reset all adjustment to previous figure.
Quit
Closes IMAGE MENU.
Store icon
PICTURE SCREEN ADJUSTMENT
This projector has a picture screen resize function, which enables you to display the desirable image size.
1
Press MENU button and ON-SCREEN MENU will appear. Press
POINT LEFT/RIGHT button(s) to move a red frame pointer to
SCREEN Menu icon.
2
Press POINT DOWN button and move a red frame pointer to the
function that you want to select and then press SELECT button.
Normal
SCREEN MENU
SCREEN Menu icon
Move the red frame to the function and
press SELECT button.
Provides image at a normal video aspect ratio of 4 : 3.
Wide
Provides image at a wide screen ratio of 16 : 9.
34
NOTE : SCREEN Menu cannot be operated when
“720p,” “1035i,” or “1080i” is selected on AV
SYSTEM Menu (P31).
SETTING
SETTING MENU
1
Press MENU button and ON-SCREEN MENU will appear. Press
POINT LEFT/RIGHT button(s) to move a red-frame pointer to
SETTING icon.
2
Press POINT DOWN button to move a red-frame pointer to the
item that you want to set and then press SELECT button.
Setting dialog box appears.
SETTING MENU
Set a red frame
pointer to the item
and press SELECT
button.
SETTING Menu icon
Language
Language used in ON-SCREEN MENU is selectable from among
English, German, French, Italian, Spanish, Portuguese, Dutch,
Swedish, Chinese, Korean and Japanese.
Keystone
When the image is distorted vertically, select Keystone. ONSCREEN MENU disappears and Keystone dialog box is displayed.
Correct keystone distortion by pressing POINT UP/DOWN button(s).
Refer to KEYSTONE ADJUSTMENT on page 20.
When pressing SELECT
button at Language,
Language Menu appears.
Blue back
When this function is “On,” this projector will produce a blue image
instead of the video noise on the screen when any input source is
unplugged or turned off.
Display
This function decides whether to display On-Screen Displays.
On ··· shows all the On-Screen Displays.
Off ···· sets On-Screen Displays disappeared except;
● ON-SCREEN MENU
● “Power off?” message (P19)
● P-TIMER
● “No signal” message (P36)
Logo
When this function is “On,” projector displays our logo when starting
up.
Move a pointer to the item
and then press POINT
LEFT/RIGHT button(s).
Ceiling function
Ceiling
When this function is “On,” picture is top / bottom and left / right
reversed. This function is used to project the image from a ceiling
mounted projector.
Rear
Rear function
When this function is “On,” picture is left / right reversed. This
function is used to project the image to a rear projection screen.
35
SETTING
Power management
This function turns Projection Lamp off when this projector detects
signal interruption and is not used for a certain period in order to
reduce power consumption and maintain the Lamp-life. (This
projector is shipped with this function ON.)
Power Management function operates to turn Projection Lamp off
when the input signal is interrupted and any button is not pressed
over 5 minutes. This function operates as follows;
1. When any input signal is interrupted, “No signal” and the
counting down display appears (for 5 minutes).
2. When Projection Lamp turned off, READY Indicator turns off.
Cooling Fans operate and Projection Lamp is turned off for 90
seconds. (During this "Cooling Down" period, projector cannot
be turned on.)
3. When Projection Lamp has cooled down, READY Indicator
flashes and Projection Lamp can be turned on again (Power
Management mode).
In this Power Management mode, Projection Lamp is
automatically turned on when the input signal connected or
projector is operated with any button on Top Control or on
Remote Control Unit again.
Time left until Lamp off.
Remote control
This projector has two different remote control codes; the factory-set
normal code (Code 1) and the secondary code (Code 2). This
switching function prevents remote control operation mixture (jam)
when operating several projectors or video equipment together.
When operating projector in “Code 2,” both projector and Remote
Control Unit must be switched to “Code 2.”
To change the code of Projector;
Set Remote control in the SETTING MENU to “Code 2.”
To change the code of the Remote Control Unit;
Press both MENU and IMAGE buttons on Remote Control Unit
together for over 10 seconds.
After changing the code, make sure Remote Control operates
properly.
To return to the normal code (Code 1), operate both projector and
Remote Control in the ways above again.
NOTE : When battery of Remote Control Unit is replaced, the remote
control code automatically returns to the normal code (Code
1).
Lamp counter reset
This function is used to reset Lamp Replace Counter. When
replacing Projection Lamp, reset Lamp Replace Counter by using
this function. Refer to page 38 for operation.
36
Move the pointer to Lamp counter reset and then press
SELECT button. The message “Lamp replace counter
reset?” is displayed.
APPENDIX
MAINTENANCE
WARNING TEMP. INDICATOR
WARNING TEMP. Indicator flashes red when an internal temperature of a projector exceeds the normal temperature. This
Indicator stops flashing when the temperature of a projector returns to normal.
When WARNING TEMP. Indicator continues to flash, check the items listed below.
1
2
3
Ventilation Slots of the projector may be blocked. In such an event, reposition the projector so that Ventilation Slots
are not obstructed.
Air Filters may be clogged with dust particles. Clean Air Filters by following the section AIR FILTER CARE AND
CLEANING below.
If WARNING TEMP. Indicator remains on after performing the above checks, Cooling Fans or the Internal Circuits may
be malfunctioning. In that case, call Boxlight.
AIR FILTER CARE AND CLEANING
Removable Air Filters prevent dust from accumulating on the surface of Projection Lens and Projection Mirror. Should Air
Filters become clogged with dust particles, it will reduce Cooling Fans’ effectiveness and may result in internal heat build up
and adversely affect the life of the projector. Clean Air Filters following the steps below:
1
Turn off the projector, and disconnect AC power cord from the
AC outlet.
2
Turn the projector upside down and remove two Air Filters
(Large and Small) by pulling the latches upward.
3
4
Clean Air Filters with a brush or wash out dust and particles.
AIR FILTER (Small)
Replace each Air Filter properly. Make sure that Air Filters are
fully inserted.
CAUTION
Do not operate the projector with Air Filter removed. Dust
may accumulate on LCD Panel and Projection Mirror
degrading picture quality.
Do not put small parts into Air Intake Vents. It may result in
malfunction of the projector.
AIR FILTER (Large)
RECOMMENDATION
We recommend avoiding dusty/smoky environments when operating a projector. Usage in these environments
may cause poor image quality.
When using under dusty or smoky conditions, dust may accumulate on a lens, liquid crystal panels, or optical elements
inside the projector. This condition may degrade the quality of a projected image.
When the above symptoms are noticed, contact Boxlight at 1-800-762-5757 or 360-779-7901 for cleaning.
CLEANING PROJECTION LENS
Follow these steps to clean Projection Lens:
1
Apply a non-abrasive camera lens cleaner to a soft, dry cleaning cloth. Avoid using an excessive amount of cleaner.
Abrasive cleaners, solvents or other harsh chemicals might scratch a surface.
2
3
Lightly wipe a cleaning cloth over Projection Lens.
When the projector is not in use, replace Lens Cover.
37
APPENDIX
LAMP REPLACEMENT
When the life of Projection Lamp of this projector draws to an end, LAMP REPLACEMENT indicator lights yellow. When a
projected image becomes dark or the color of an image becomes unnatural, replacement of Projection Lamp is required.
CAUTION
CAUTION
For continued safety, replace with a lamp
assembly of the same type.
Allow a projector to cool for at least 45
minutes before you open Lamp Cover. The
inside of a projector can become very hot.
Do not drop a lamp assembly or touch a glass
bulb! The glass can shatter and may cause
injury.
Follow these steps to replace the lamp assembly.
1
Turn off the projector and disconnect AC plug. Allow the
projector to cool for at least 45 minutes.
2
3
Remove a screw with a screwdriver to remove Lamp Cover.
4
Replace Lamp Assembly with a new one and tighten 2 screws
back. Make sure that Lamp Assembly is set properly. Replace
Lamp Cover and tighten a screw.
5
6
LAMP COVER
Remove 2 screws with a screwdriver and pull out Lamp
Assembly by grasping Handle.
HANDLE
Connect AC Power Cord to the projector and turn it on.
Reset Lamp Replace Counter (refer to the section “Lamp
Replace Counter” below).
LAMP
ASSEMBLY
NOTE : Do not reset Lamp Replace Counter when Projection
Lamp is not replaced.
ORDER REPLACEMENT LAMP
Replacement Lamp can be ordered through Boxlight at 1-800-762-5757 or 360-779-7901.
● Model No. of your projector : BOXLIGHT XP-8t
● Replacement Lamp Type No. : POA-LMP36
(Service Parts No. 610 293 8210)
LAMP REPLACE COUNTER
Be sure to reset Lamp Replace Counter when Lamp Assembly is replaced. When Lamp Replace Counter is reset, LAMP
REPLACE Indicator stops lighting.
1
Turn projector on, press MENU button and ON-SCREEN MENU will appear. Press POINT LEFT/RIGHT button(s) to
move a red frame pointer to SETTING Menu icon (refer to page 35, 36).
2
Press POINT DOWN button to move a red frame pointer to “Lamp counter reset” and then press SELECT button. The
message "Lamp replace counter reset?" is displayed. Move the pointer to [Yes] and then press SELECT button.
3
Another confirmation dialog box appears and select [Yes] to reset Lamp Replace Counter.
Do not reset Lamp Replace Counter except after Projection Lamp is replaced.
38
APPENDIX
TROUBLESHOOTING
Before calling your dealer or service center for assistance, check the matters below once again.
1. Make sure you have connected a projector to your computer or video equipment as described in the section
"CONNECTING THE PROJECTOR" on pages 11 ~ 13.
2. Check cable connection. Verify that all computer, video and power cord are properly connected.
3. Verify that all power is switched on.
4. If a projector still does not produce an image, re-start your computer.
5. If an image still does not appear, unplug a projector from your computer and check your computer monitor's display. The
problem may be with your graphics controller rather than with a projector. (When you reconnect a projector, be sure to
turn the computer and monitor off before you power up the projector. Power the equipment back on in order of : Projector
and computer.)
6. If the problem still exists, check following chart.
Problem:
No power.
Try these Solutions
● Plug a projector into your AC outlet.
● Make sure READY Indicator lights.
● Wait 90 seconds after a projector is turned OFF when turning the projector back on.
NOTE : After pressing Power ON-OFF button to OFF, make sure a projector works as
follows:
1. LAMP indicator lights bright and READY indicator turns off.
2. After 90 seconds, READY indicator lights green again and a projector may be
turned on by pressing Power ON-OFF button.
● Check WARNING TEMP. indicator. If the indicator flashes red, the projector cannot be
turned on.
(See "TURNING ON/OFF PROJECTOR" section on page 19.)
● Check Projection Lamp. (Refer to page 38.)
Image is out of
focus.
● Adjust focus of a projector.
● Make sure a projection screen is at least 5.3’ (1.6m) from the projector.
● Check Projection Lens to see if it needs cleaning.
NOTE : Moving a projector from a cool temperature location to a warm temperature location
may result in moisture condensation on Projection Lens. In such an event, leave a
projector OFF and wait until condensation disappears.
Picture is Left/Right
reversed.
● Check Ceiling / Rear feature. (See “SETTING” section on page 35.)
Picture is
Top/Bottom
reversed.
● Check Ceiling feature. (See “SETTING” section on page 35.)
Some displays are
not seen during the
Operation.
● Check Display feature.(See “SETTING” section on page 35.)
No image.
● Check the connection between your computer or video equipment and a projector.
● Check NO SHOW function. (Refer to page 21.)
● When turning a projector on, it takes about 30 seconds to display an image.
● Check the system that you select is corresponding with your computer or video
equipment.
● Make sure the temperature is not out of the Operating Temperature (5°C ~ 35°C).
No sound.
● Check audio cable connection from audio input source.
● Adjust the audio source.
● Press VOLUME (+) button.
● Press MUTE button.
39
APPENDIX
Problem:
Remote Control Unit
does not work.
Try these Solution
● Check the battery.
● Make sure nothing is between Infrared Remote Receiver and Remote Control Unit.
● Make sure you are not too far from a projector when using Remote Control Unit.
Maximum operating range is 16.4’ (5m).
● Make sure the code of Remote Control is set to conform to projector.
(See “SETTING” section on page 35, 36.)
WARNING :
High voltages are used to operate this projector. Do not attempt to open the cabinet.
If the problem still persists after following all operating instructions, contact Boxlight for assistance at 1-800-762-5757 or 360779-7901. Give the model number and explain the difficulty. We will advise you how to obtain service.
Please have the following information available.
● Serial No. of projector.
● Resolution of the computer.
● Refresh rate of computer.
This symbol on the nameplate means the product is Listed by Underwriters
Laboratories Inc. It is designed and manufactured to meet rigid U.L. safety standards
against risk of fire, casualty and electrical hazards.
40
APPENDIX
TECHNICAL SPECIFICATIONS
Projector Type
Dimensions (W x H x D)
Net Weight
LCD Panel System
Panel Resolution
Number of Pixels
Color System
High Definition TV Signal
Scanning Frequency
Projection Image size (Diagonal)
Horizontal Resolution
Projection Lens
Throw Distance
Projection Lamp
Video Input Jacks
Audio Input Jacks
Computer Input Terminals
Computer Audio Input Jack
Control Port Connector
USB Connector
Audio Output Jacks
Internal Audio Amp
Built-in Speakers
Feet Adjustment
Voltage and
Power Consumption
Operating Temperature
Storage Temperature
Remote Control Transmitter
Accessories
Multi-media Projector
10.12" x 2.98" x 9.02" (257mm x 75.8mm x 229mm) (not including Adjustble Feet and Lens)
6.17lbs (2.8 kg)
0.7" TFT Active Matrix type, 3 panels
1024 x 768 dots
2,359,296 (1024 x 768 x 3 panels)
PAL, SECAM, NTSC, NTSC4.43, PAL-M and PAL-N
480i, 480p, 575i, 575p, 720p, 1035i, and 1080i
H-sync. 15 ~ 100 KHz, V-sync. 50 ~ 100 Hz
Adjustable from 34” to 200”
550 TV lines
F 1.6 ~ 1.78 lens with f 28.7 mm ~ 34.5 mm with manual zoom and focus
5.3’ ~ 26.6’ (1.6 m ~ 8.1 m)
150 W
RCA Type x 3 (Video/Y, Pb/Cb, Pr/Cr) and Mini DIN 4 pin x 1 (S-Video)
Mini Jack (stereo) x 1
(VGA) HDB 15 Terminal x 1
Mini Jack (stereo) x 1
Mini DIN 8 pin x 1
USB Series B receptacle x 1
Mini Jack (stereo) x 1
1.0 W RMS
1 speaker, ø1.1" (28mm)
0˚ to 10.6˚
AC 100 ~ 120 V (2.8 A Max. Ampere), 50 / 60 Hz (The U.S.A and Canada)
AC 200 ~ 240 V (1.4 A Max. Ampere), 50 / 60 Hz (Continental Europe)
41 ˚F ~ 95 ˚F (5 ˚C ~ 35 ˚C)
14 ˚F ~ 140 ˚F (-10 ˚C ~ 60 ˚C)
Power Source
Operating Range
Dimensions
Net Weight
:
:
:
:
Lithium Type (CR2025 / 3.0V)
16.4’ (5m) / ±30˚
2.1” x 0.28” x 5.3” (54mm x 7mm x 135mm)
1.27oz (36 g) (including battery)
Owner’s Manual
AC Power Cord
Wireless Remote Control Transmitter and Battery
VGA Cable
Carrying Bag
Lens Cover
● The specifications are subject to change without notice.
OPTIONAL PARTS
The parts listed below are optionally supplied. When ordering those parts, give name and Type No. of it to the sales dealer.
● Wireless Remote Control Unit
● Control Cable for PS/2Port
● Control Cable for Serial Port
Type No. : XP8T-711
Type No. : POA-MCPS2
Type No.: POA-MCSRL
● Control Cable for ADB Port
● MAC Adapter
Type No.: POA-MCMAC
Type No.: POA-MACAP
41
APPENDIX
CONFIGURATIONS OF THE TERMINALS
COMPUTER INPUT TERMINAL (ANALOG)
Terminal : HDB15-PIN
Connect the display output terminal of the computer to this terminal with the VGA Cable (supplied). When connecting the
Macintosh computer, MAC Adapter (not supplied) is required.
Pin Configuration
4
5
10
15
14
2
3
9
8
13
1
7
12
6
11
1
2
3
4
5
6
7
8
Red Input
Green Input
Blue Input
Sense 2
Ground (Horiz.sync.)
Ground (Red)
Ground (Green)
Ground (Blue)
9
10
11
12
13
14
15
No Connect
Ground (Vert.sync.)
Sense 0
Sense 1
Horiz. sync.
Vert. sync.
Reserved
CONTROL PORT CONNECTOR
Terminal : Mini DIN 8-PIN
Connect control port (PS/2, Serial or ADB port) on your computer to this connector with Control Cable (not supplied).
Pin Configuration
8
5
7 6
4 3
2 1
1
2
3
4
5
6
7
8
PS/2
----CLK
DATA
GND
--------GND
-----
Serial
RXD
--------GND
RTS / CTS
TXD
GND
GND
ADB
----ADB
----GND
------------GND
USB CONNECTOR (Series B)
Connect USB port terminal on your computer or peripheral equipment to this connector with USB Cable (not supplied).
Pin Configuration
42
2
1
3
4
1
2
3
4
Vcc
- Data
+ Data
Ground
43
LIMITED WARRANTY
BOXLIGHT CORPORATION (“BOXLIGHT”) warrants that each BOXLIGHT XP-8t (“the Product”) sold hereunder will
conform to and function in accordance with the written specifications of BOXLIGHT. Said limited warranty shall apply
only to the first person or entity that purchases the Product for personal or business use and not for the purpose of
distribution resale. Said warranty shall continue for a period of two (2) years from the date of such purchase.
BOXLIGHT does not warrant that the Product will meet the specific requirements of the first person or entity that
purchases the Product for personal or business use. Lamp is warrantied for 120 days.
BOXLIGHT CORPORATION’s liability for the breach of the foregoing limited warranty is limited to the repair or
replacement of the Product or refund of the purchase price of the Product, at BOXLIGHT’s sole option. To exercise
the Purchaser’s rights under the foregoing warranty, the Product must be returned at the Purchaser’s sole cost and
expense, to BOXLIGHT or any authorized service center provided, however, that the Product must be accompanied by
a written letter explaining the problem and which includes (i) proof of purchase; (ii) the dealer’s name; (iii) the model
and serial number of the Product. A return authorization number, issued by the BOXLIGHT customer service
department, must also be clearly displayed on the outside of the shipping carton containing the Product.
WARRANTY LIMITATION AND EXCLUSION
BOXLIGHT CORPORATION shall have no further obligation under the foregoing limited warranty if the Product has
been damaged due to abuse, misuse, neglect, accident, unusual physical or electrical stress, unauthorized
modification, tampering, alterations, or service other than by BOXLIGHT or its authorized agents, causes other than
from ordinary use or failure to properly use the Product in the application for which said Product is intended.
DISCLAIMER OR UNSTATED WARRANTIES
The warranty printed above is the only warranty applicable to this purchase.
All other warranties express or implied, including, but not limited to, the implied warranties or merchantability and
fitness for a particular purpose are disclaimed. There are no warranties that extend beyond the face of hereof and the
foregoing warranty shall not be extended, altered or varied except by written instrument signed by BOXLIGHT
CORPORATION.
LIMITATION OR LIABILITY
It is understood and agreed that BOXLIGHT’s liability whether in contract, in tort, under any warranty, in negligence or
otherwise shall not exceed the return of the amount of the purchase price paid by purchaser and under no
circumstances shall BOXLIGHT be liable for special, indirect or consequential damages. The price stated for the
Product is a consideration in limiting BOXLIGHT’s liability. No action regardless of form, arising out of the agreement
to purchase the product, may be brought by purchaser more than one year after the cause of action has accrued.
Printed in Japan
Part No. 610 294 2934 (1AA6P1P2915-- MW6E)
Boxlight
19332 Powder Hill Place
Poulsbo, WA 98370-7407 USA
www.boxlight.com
USA and Canada 800-762-5757
International 360-779-7901
Was this manual useful for you? yes no
