Netop Asset Agent
Version 9.2
Installation Guide
Version 1.1
Copyright© 1981-2009 Netop Business Solutions A/S. All Rights Reserved.
Portions used under license from third parties.
Please send any comments to:
Netop Business Solutions A/S
Bregnerodvej 127
DK-3460 Birkerod
Denmark
Fax: Int +45 45 90 25 26
E-mail: [email protected]
Internet: www.netop.com
Netop™ is a trademark of Netop Business Solutions A/S. All other products mentioned in
this document are trademarks of their respective manufacturers. Netop Business Solutions
A/S denies any and all responsibility for damages caused directly or indirectly as a result
of using this document. The content of this document is subject to change without
notice. Netop Business Solutions A/S retains the copyright to this document.
The document is optimized for double-sided printing.
Contents
Contents
1 .................................................................................................2
Overview of Netop Asset Control components
2 .................................................................................................4
Installation prerequisites
3 .................................................................................................5
Install Netop Asset Control
4 .................................................................................................9
Distribute and start Agent
...................................................................................................................9
4.1
Use Group Policy to remotely install and start Agent
...................................................................................................................11
4.2 Manually install and start Agent
...................................................................................................................12
4.3 Install Agent locally
5.................................................................................................14
Start Netop Asset Control
6.................................................................................................15
Appendix
...................................................................................................................15
6.1 Netop Asset Control database
...................................................................................................................15
6.2 Netop Asset Control data share
...................................................................................................................16
6.3 Netop Asset Agent
...................................................................................................................17
6.4 Redeploy Netop Asset Agent
...................................................................................................................17
6.5 Notes
Index
.................................................................................................19
1
Overview of Netop Asset Control components
1 Overview of Netop Asset Control components
These are the components of a complete Netop Asset Control installation:
Netop Asset
Agent
Netop Asset Agent is installed on all PCs and servers to be scanned
regularly.
Note
Netop Asset Agent does not necessarily have to be installed on a
computer for it to be included in an instant scan: a remote scan of a
single computer based on computer name or of computers within an
IP range can be initiated and run from the Manager without installing
any software; refer to the Netop Asset Manager Help for details.
Netop Asset Agent can also be activated from a logon script and thus
activated when a computer starts up; refer to Distribute and start
Agent for details.
The Agent runs as a service and users will not see the Agent nor
experience any performance load on their computers.
Each Agent delivers scan data to the scan data folder on the data
2
Overview of Netop Asset Control components
share. The scan data is subsequently imported from the data share to
the central data storage, the SQL Server.
Agents read their configuration settings like for example scan
frequency, from the data share.
SQL Server
and
data share
The SQL Server is the central storage area and is where the Netop
Asset Control database is installed.
The data share is a simple folder structure that contains the collected
data from all Agents. In addition to the scan data, the data share
also stores Agent configuration settings and log files.
The data share folder also contains the following Netop Asset Control
components:
· Netop Asset Import - manages data import to the database on the
SQL Server.
· Netop Asset Sync - handles the synchronization between the SQL
Server and the Active Directory Server.
The data share must be located on the same server as the SQL
Server.
Netop Asset
Manager
Netop Asset Manager is the interface to data collected by the
Agents.
The Manager imports the scan data from the Netop Asset Control
database on the SQL Server and presents data about hardware and
software.
The Manager is also the interface to configuring how the Agents
work: scan frequency and other Agent settings are defined from the
Manager, saved in the configuration folder and refreshed at a
configurable interval.
Active
Directory
Server
An Active Directory (AD) Server is not required for running Netop
Asset Control but if Active Directory has already been implemented
and is operational on one or more servers in the company, Netop
Asset Control can use the Active Directory information and offer, for
example, data filtering on organizational unit.
Note
The arrows between the components in the illustration symbolize both transfer of
configuration settings, for example from Netop Asset Manager to the data share and to
Agents, and normal data flow from Agents to the data share and then to SQL Server.
3
Installation prerequisites
2 Installation prerequisites
Below table lists the prerequisites for installing Netop Asset Control.
Microsoft SQL Server 2005 with
Reporting Services
A fully functional Microsoft SQL Server 2005 with
Reporting Services and the most recent Service Pack
must be available for installing the Netop Asset
Control database.
The computer must run Microsoft Windows NT
operating system (or later).
Microsoft .NET Framework version The computers running Netop Asset Manager and
2.0
Netop Asset Agent must have Microsoft .NET
Framework version 2.0 or higher installed. Only the
runtime and associated files required to run
applications developed to target the .NET Framework
are required.
If these components are not already on the
computers, the redistributable package can be
downloaded from the Microsoft .NET home page (
http://www.microsoft.com/net/)
Note
The user who is handling the installation must have the appropriate access rights,
including permission to
· Create a user in Active Directory.
· Create a database on the SQL Server.
· Create a share with folder and files on the File Server.
· Create folders and install files on the Netop Asset Manager computer.
4
Install Netop Asset Control
3 Install Netop Asset Control
To have a fully functional Netop Asset Control system, you need to install the following
components:
· Netop Asset Manager
· Netop Asset Control server components and database
· Netop Asset Agent
When you are installing Netop Asset Control for the first time, you begin by installing and
starting up Netop Asset Manager. Once you start up Netop Asset Manager, a wizard will
automatically open and lead you through the necessary steps to handle installing the
database and the server components.
When these components have been installed, Netop Asset Manager is started again and
the remaining setup can be completed.
Note
Netop Asset Agent is not handled by the installation wizard. For information about
distributing the Agent, see Distribute and start Agent.
Installation sequence
1. On the computer you want to use as Netop Asset Manager, start the installation
program called NetopAssetManager.msi.
2. In the installation wizard pages, select installation folder and choose whether this
program is to be used by you only or by others as well.
3. Start Netop Asset Manager from Windows' Start menu when the installation is
complete.
When Netop Asset Manager opens, a wizard to complete the installation and make the
5
Install Netop Asset Control
required setup automatically starts. Click Next on the welcome page to continue
installing and setting up Netop Asset Control.
4. On the Select installation type page, click Create a new installation to install and
set up the Netop Asset Control components.
5. On the Connect to an SQL Server page, type the name of an existing SQL Server,
type the name that you want to use for the new Netop Asset Control database, and
type the name of the domain that the SQL Server belongs to.
Tip
If you cannot recall the precise name of the SQL Server, click the Look up button to
have the wizard scan the network for available SQL Servers.
6. On the Netop Asset Control share page, create a new share or select an existing
6
Install Netop Asset Control
one.
The share is used for the data share components like configuration, data, and log
folders and also for the folder where the Agents deliver their data.
If you create a new share, a new dialog box opens where you can type a suitable name
and a description.
On the following page, you can see and confirm the settings you made.
On the Netop Asset Control licensing page, you must type or paste your license
codes and have them validated.
When you click OK, the following happens:
· The new share is created - if you chose to create new rather than use an existing.
· A group is created in the Active Directory with the same name as the Netop Asset
Control database. This means that users merely need to be members of this group to
have the appropriate access rights.
· The folder structure is created on the share; please refer to the Appendix for details.
· The Netop Asset Control database is created.
· The reports are installed.
When the Congratulations! page opens and you click Finish, the Netop Asset Control
installation is complete.
All that remains now is to distribute the Agent to client computers, see Distribute and
start Agent.
7
Install Netop Asset Control
Install a new manager and connect to an existing database
If you have previously installed and used Netop Asset Control and subsequently install a
new version of Netop Asset Manager, the wizard to complete the required setup
automatically starts when you first start Netop Asset Manager. Click Next on the
welcome page to continue the setup.
1. On the Select installation type page, click Connect to an existing to connect to
an existing SQL Server and Netop Asset Control database.
2. On the Connect to an SQL Server page, select the name of an existing SQL Server
and select the name of an existing database.
Netop Asset Manager now displays data from an existing database.
8
Distribute and start Agent
4 Distribute and start Agent
For the Agent to run regular scans the Netop Asset Agent needs to be physically located
on the client computers. On the client computers the Agent can be installed as a service
and run at intervals defined in Netop Asset Manager, for example once every day or once
every 6 hours. Or the Agent can be started from a script, for example the logon script, so
that the client computer is scanned each time a user logs on.
Netop Asset Agent consists of a single, small file, called NetopAssetAgent.exe. The file
can be distributed and installed to client computers in a number of different ways,
depending on company processes and preferences. We recommend that you deploy using
Group Policy in Active Directory and the section Use Group Policy to remotely install and
start Agent describes the required steps in the process.
If remote installation using Group Policy is not a viable option, you can use any method to
distribute the Agent to the client computers. When NetopAssetAgent.exe is located on
the client computers, you can install the Agent or start a scan from a command line. Like
other commands executed from a command line, the commands to install or start could
also be included in a login script. The section Manually install and start Agent describes
these options.
If using Group Policy is not possible and you also do not want to install the Agent from a
command line, a third alternative is to run the Agent installation program locally on each
client computer. The section Install Agent locally describes the Agent installation
program.
See Also
For a list of available parameters for NetopAssetAgent.exe, refer to Netop Asset Agent
details.
For more information about services and service user accounts, refer to http://msdn.
microsoft.com, specifically http://msdn.microsoft.com/en-us/library/ms685141(VS.85).
aspx.
To learn about the scan cycle, refer to Netop Asset Control data share.
4.1 Use Group Policy to remotely install and start Agent
To deploy using Group Policies, you use the standard MSI and create a customized MST
which contains your preferred Netop Asset Control options. The customized files are then
deployed through Group Policies in Active Directory and consequently available on client
computers when users log on. You can use the Netop Pack'n Deploy utility to create a
customized MST.
Create a customized MSI and MST file and place it on a public share
1. Start Netop Pack'n Deploy.
2. On the MSI tab, add NetopAssetAgent.msi in the Original MSI File field, and specify
an output folder for the customized MSI.
We recommend that you place the output folder in a central location which all the
target client computers can access.
3. On the Properties tab, add three new properties and leave the other values with
their default settings.
The new properties are: SCANDATAFOLDER, LOGFILEFOLDER and LOGLEVEL.
9
Distribute and start Agent
SCANDATAFOLDER
is the path to the share you created as part of the installation
process, for example \\WIN03SRVSANDBX\MyOwnShare\inbox
LOGFILEFOLDER
is the path to the share where the log files will be stored, for
example \\WIN03SRVSANDBX\MyOwnShare\log
LOGLEVEL
is an option that lets you decide how much information should be
logged in the above log file, for example, standard, detailed or no
information at all.
Standard=0
Detailed=1
No log=2
4. Click Build to create an MSI and MST file in the output folder and then close down
Netop Pack'n Deploy.
Now you have a customized MSI and MST file ready for remote installation using Group
Policy.
Create a group policy object to use to distribute the MSI
1. Start the Active Directory Users and Computers snap-in. To do this, click Start, point
to Administrative Tools, and then click Active Directory Users and Computers.
Note that the exact path may vary depending on your operating system.
2. In the console tree, right-click your domain, and then click Properties.
3. Click the Group Policy tab, and then click New.
4. Type a name for this new policy, and then press ENTER.
5. Click Properties, and then click the Security tab.
6. Click to clear the Apply Group Policy check box for the security groups that you
want to prevent from having this policy applied.
7. Click to select the Apply Group Policy check box for the groups that you want this
policy to apply to.
8. When you are finished, click OK.
Now you have created a new group policy to use to distribute the MSI, and made sure
that the policy is applied to the appropriate groups.
Assign the MSI and MST to the policy
1. In the Active Directory Users and Computers console tree, right-click your domain,
and then click Properties.
2. Click the Group Policy tab, select the group policy object that you created in the
previous step, and then click Edit.
3. Under Computer Configuration, expand Software Settings.
4. Right-click Software installation, point to New, and then click Package.
5. In the Open dialog box, type the full Universal Naming Convention (UNC) path of the
shared MSI installer package that you want. For example, \
\server\share\NetopAssetAgent.msi.
10
Distribute and start Agent
Important If you choose to use the Browse button to access the location, make
sure that you use the UNC path (by using My Network Places) rather than a mapped
drive location to the output folder that contains the shared installer package.
6. Click Open.
7. Click Advanced, and then click the Modifications tab. Click Add and select the MST
file associated with your MSI installer package, for example, \
\server\share\NetopAssetAgent.mst. Click OK and the package is listed in the right
pane of the Group Policy window.
8. Close the Group Policy snap-in, click OK, and then quit the Active Directory Users and
Computers snap-in.
When the client computers start, the managed software package is automatically installed
as a service and started.
Tip
If you need to redeploy the Agent later, for example if you upgrade or modify the MSI,
this can conveniently be done using Group Policy. For details, refer to Redeploy Netop
Asset Agent.
4.2 Manually install and start Agent
If using Group Policy to remotely install Netop Asset Agent is not possible, the Agent must
be distributed to the client computers in some other way. This can be in a logon script or
any other way that you normally distribute files or updates on the company network, for
example using Microsoft Systems Management Server.
When the Agent is physically located on client computers, it can be installed as a service
and run at intervals defined in Netop Asset Manager. The way to do this is described in
the section "Install Netop Asset Agent as a service" below.
If you do not want to install the Agent as a service but just want to run it, for example,
when a client computer starts, this is also possible. The way to do this is described in the
section "Start Netop Asset Agent from a script" below.
When the Netop Asset Manager has been installed, the NetopAssetAgent.exe file is
located in the Netop Asset Manager folder. Depending on the operating system, this could
for example be C:\Program Files\Danware Data\Netop Asset Control\Netop Asset
Manager.
Install Netop Asset Agent as a service
On the client computer the agent software can be installed as a service and then started
using this command:
NetopAssetAgent /o=\\MyServerName\MyShareName\inbox /install
where \MyServerName\MyShareName\inbox must be the path to the share you
created as part of the installation process, for example
\\WIN03SRVSANDBX\MyOwnShare\inbox.
Tip
Use the service user account LocalSystem to install Netop Asset Agent.
11
Distribute and start Agent
Start Netop Asset Agent from a script
If you prefer not to have Netop Asset Agent installed as a service but want to activate a
scan as part of the computer's logon script, the same command as above is used but
without the /install parameter, for example:
NetopAssetAgent /o=\\MyServerName\MyShare\inbox
See Also
For a list of available parameters for NetopAssetAgent.exe, refer to Netop Asset Agent
details.
For more information about services and service user accounts, refer to http://msdn.
microsoft.com, specifically http://msdn.microsoft.com/en-us/library/ms685141(VS.85).
aspx.
To learn about the scan cycle, refer to Netop Asset Control data share.
4.3 Install Agent locally
Installing the Agent locally means that you run the Agent installation program on all client
computers.
First, make sure that the Agent installation program is available to all client computers in
a central location which all the target client computers can access.
1. Start the installation program called NetopAssetAgent.msi.
2. On the second installation wizard page, select installation folder and click Next. On
next page confirm that you want to start the installation.
3. As part of the installation, specify path to data share, path to log file and determine
how much information you want to log when the system is operational.
Data share path
is the path to the share you created as part of the installation
process, for example \\WIN03SRVSANDBX\MyOwnShare\inbox
Log file path
is the path to the share where the log files will be stored, for
example \\WIN03SRVSANDBX\MyOwnShare\log
Log level
is an option that lets you decide how much information should be
logged in the above log file.
4. On the Installation Complete wizard page, click Close to complete the installation.
The Agent is now installed and runs as a service. You can verify this from Windows'
12
Distribute and start Agent
Services:
13
Start Netop Asset Control
5 Start Netop Asset Control
When Netop Asset Manager has been started and when Netop Asset Agent has been
distributed and is running on all client computers, Netop Asset Import must be running on
the SQL Server to have the data that the Agents collect imported from the scan data
folder to the database.
Netop Asset Import is automatically enabled as part of the installation. Use the SQL
Server Management Studio to verify that the SQL job is active. By default, the Netop
Asset Import job runs every minute although the schedule can be changed using the SQL
Server Management Studio.
To have Active Directory information synchronized with the SQL database, Netop Asset
Sync must also be enabled. The Active Directory synchronization is not required but is
enabled upon installation. By default, the Netop Active Sync job runs once every 24 hours
although the schedule can be changed using the SQL Server Management Studio.
14
Appendix
6 Appendix
The following sections describe details about the Netop Asset Control components that
might be useful to know but are not necessary to install and set up the system.
6.1 Netop Asset Control database
The Netop Asset Control database holds these types of data:
· Master data: information about computers and printers.
· Products data: information about installed software.
· Licenses: information about acquired licenses.
The first two types of data are based on scanned information whereas the license
information has to be entered manually.
6.2 Netop Asset Control data share
The data share is the collection point for data from all Agents. In addition to the scan
data, the data share also stores agent configuration settings and log files.
The data share also manages the import to the SQL database using the Netop Asset
Import.
Scan cycle - overview
1. When Netop Asset Agent has completed a scan on a client computer, the scan
results are committed to a local .xml file
A second .xml is also generated and this file name includes the term “delta”. This file
will contain only the changes when compared with the original .xml file and will
therefore improve performance when generating and uploading subsequent scans.
When the Agent runs as a service, a third .xml file with the term “ps” is created. This
file contains running processes and is used to help measure software usage.
The file name is constructed from the computer name and the name of the domain that
the computer belongs to.
2. Netop Asset Agent copies the relevant .xml files to the inbox on the data share. Only
the “delta” and/or “ps” file will appear in the central inbox.
3. The SQL Server job called Netop Asset Import is used to process the .xml files and
imports the data into the SQL database. By default, this job runs every minute.
Overview of files and folders
config
Folder that holds global .ini file, NetopAssetAgentConfig.ini.
inbox
Folder where the Agents deliver their .xml files and Netop
Asset Import takes them for import into the SQL database.
This folder is called "Scan data folder" in Netop Asset
Manager.
The scan data files are deleted when they have been
imported to the SQL database.
15
Appendix
Log
Folder that holds the log file import log file.
rejected
Folder that holds rejected scan data files. Rejected files are
moved from the Inbox folder to the rejected folder and remain
until they are manually removed’
6.3 Netop Asset Agent
Below is a list of available parameters for NetopAssetAgent.exe.
The only required parameter is /o= to specify where the scan data folder is located. The
other parameters are optional.
/o=<path to scan
data folder>
For example:
NetopAssetAgent /o=\\MyServerName\MyShare\inbox
Initially the scan data files are created in folder where the
NetopAssetAgent.exe file is located. These files are subsequently
copied to the scan data folder.
The files are in .xml format.
/l=<path to the log
file>
For example:
NetopAssetAgent /o=\\MyServerName\MyShare\inbox /
l=c:\temp\logs
By default log files are saved in the folder where the
NetopAssetAgent.exe is located. Use the /l= parameter to change
the default.
/q
For "quiet" mode which means that no logs are generated at all.
For example:
NetopAssetAgent /o=\\MyServerName\MyShare\inbox /
q
/d
For "debug" mode which means that an extensive log file is
generated. For example:
NetopAssetAgent /o=\\MyServerName\MyShare\scan
data folder /d
/install
Install the application as a service. For example:
NetopAssetAgent /o=\\MyServerName\MyShare\inbox /
install
Tips
You can verify that the Agent has in fact been installed as a
service and is running in a number of ways:
· A log file named NetopAssetAgent.InstallLog has been created in
folder where NetopAssetAgent.exe is located and the log file
16
Appendix
reports that the agent has been successfully installed as a
service.
· NetopAssetAgent is listed as a service in Windows Computer
Management.
· NetopAssetAgent is listed in Windows registry under
HKEY_LOCAL_MACHINE.
/uninstall
Uninstall the service. For example:
NetopAssetAgent /o=\\MyServerName\MyShare\inbox /
uninstall
6.4 Redeploy Netop Asset Agent
If you want to redeploy Netop Asset Agent, for example if you upgrade or modify the MSI,
you can use Group Policy in almost the same way you remotely installed the Agent.
To redeploy an MSI once you have an updated MSI file
1. To update the original Netop Asset Agent distribution package, simply copy the new
NetopAssetAgent.msi file to your output directory.
2. Start the Active Directory Users and Computers snap-in. To do this, click Start, point
to Administrative Tools, and then click Active Directory Users and Computers.
Note that the exact path may vary depending on your operating system.
3. In the console tree, right-click your domain, and then click Properties.
4. Click the Group Policy tab, click the Group Policy object that you used to deploy the
package, and then click Edit.
5. Expand the Software Settings container that contains the software installation item
that you used to deploy the package.
6. Click the software installation container that contains the package.
7. In the right pane of the Group Policy window, right-click the program, point to All
Tasks, and then click Redeploy application. You will receive the following
message:
Redeploying this application will reinstall the application everywhere it is already
installed. Do you want to continue?
8. Click Yes.
9. Quit the Group Policy snap-in, click OK, and then quit the Active Directory Users and
Computers snap-in.
When the client computers start, the managed software package is automatically installed
as a service and started.
6.5 Notes
service
A service is an executable program that runs in the background. A service is
different from other programs in several ways, for example: services are not
run interactively and services run even when no one is logged in to the
17
Appendix
machine.
18
Index
Index
T
technical requirements
.
types of data
.NET
4
15
4
A
agent
9, 16
C
client computer component
collect data
9
components
2
16
D
data
15
data share
15
database
15
distribute agent
9
download .NET
4
F
folders on server
5
I
install
5
install overview
2
O
overview
2
P
prerequsites
4
R
requirements
4
S
scan agent
9, 16
scan data folder
server components
service
share
15
17
5, 15
SQL Server
start
5
4
14
19
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
