T I L E W O R K S

Tileworks

Welcome to the latest edition of Tileworks, our contemporary collection of porcelain and ceramic tiles and mosaics. Large formats, innovative textures, a wide range of finishes, colours using the latest ink jet technology – this range includes designs suitable for every taste, location and setting.

During our travels around the world we have seen and sourced some amazing products and the Tileworks collection is a culmination of this quest.

Now you can use the finest quality porcelains and ceramic tiles to enhance your home, on floors and walls in bathrooms, wet rooms, kitchens, living spaces, wherever you choose. They will be equally at home in commercial settings such as hotels, offices, restaurants, bars, retail environments …

(the possibilities are limited only by the imagination).

Front cover: Wall and floor: Broadway Concrete CS755-6060

Image this page: Rovere CS764-12020

03

C O N T E N T S

04 Mineral Collection

12 Broadway

14 Cementi

18 New York and Paulista

20 Wood Effect

24 Bamboo Effect

28 Fabulous Creatures

32 Santiago

36 Arles and Thenac

38 Slate Chiara

42 City Range

46 Sands

50 Zelo Slimline

54 New York Mosaics and

Mattone Brick Effect

58 Coliseum, Rock and Mediterranean

62 Parisian White, Fantasy Black and Illusion White

64 Borgogna, Belize and Acropolis Sand

66 Valencia and Dream Beige

70 Essence

74 Reykjavik and Komotiite

76 Vision and Pyrenees

78 Bodecia

80 Lyon Beige

82 Strasbourg Cream, Sunlight and Stone Effect

85 Milan

86 Materia

88 Africa

90 Modern Collection and New Age White

92 Classic Whites

93 Important Information

Mineral Off White Structured CS751-6060

Mineral Collection

05

M I N E R A L

C O L L E C T I O N

Floor: Mineral Grafite Polished CS743-6060, shown with Mekong glass wall tiles from the Glassworks range

Seven subtle colours, each in three practical finishes

Mineral is a collection of large, through body, rectified porcelains in natural (matt) and polished finishes, and also with a structured

(slip resistant) finish. The seven subtle colours of these beautiful and tough tiles will look fabulous on their own or combined together.

06

M I N E R A L

C O L L E C T I O N

Floor: Mineral Portland Natural

CS747-6060

Wall: Gold Leaf glass tiles from the Glassworks range

The range of colours and finishes means that the Mineral collection is incredibly versatile

The beauty of the Mineral collection is that the tiles look great in large areas – the perfect choice for achieving a seamless look in wide open spaces.

They also co-ordinate superbly with our Glassworks range of 600 x 300mm decorative glass designs, as shown here.

Walls: Mineral Fendi Natural CS738-6060, Concreto Aparante Natural CS735-6060

Floor: Mineral Fendi Structured CS-739-6060

09

M I N E R A L

C O L L E C T I O N

Walls, floors, residential, commercial?

The Mineral range has got it all covered

The structured tiles are suitable and safe for wet room floors, and with the range of co-ordinating colours in the three finishes there are many different pleasing and stylish combinations that can be achieved for every type of room. Turn the page for full details.

10

P R O D U C T

I N F O R M A T I O N

Mineral rectified full bodied porcelain

Off White Natural

CS750-6060 • 600 x 600 x 10mm

Wear Rating: ISO 10545-6 (<175mm 3

Weight: 21.9kg per m

2

)

Off White Structured

CS751-6060 • 600 x 600 x 10mm

Wear Rating: ISO 10545-6 (<175mm 3

PTV: 55W

)

Weight: 21.9kg per m 2

Off White Polished

CS752-6060 • 600 x 600 x 9mm

Wear Rating: ISO 10545-6 (<175mm 3

Weight: 19.0kg per m

2

)

Portland Natural

CS747-6060 • 600 x 600 x 10mm

Wear Rating: ISO 10545-6 (<175mm

3

)

Weight: 21.9kg per m 2

Portland Structured

CS748-6060 • 600 x 600 x 10mm

Wear Rating: ISO 10545-6 (<175mm

3

)

PTV: 55W

Weight: 21.9kg per m

2

Portland Polished

CS749-6060 • 600 x 600 x 9mm

Wear Rating: ISO 10545-6 (<175mm

3

)

Weight: 19.0kg per m 2

Nude Natural

CS744-6060 • 600 x 600 x 10mm

Wear Rating: ISO 10545-6 (<175mm

Weight: 21.9kg per m

2

3

)

Walls Floors Internal

Nude Structured

CS745-6060 • 600 x 600 x 10mm

Wear Rating: ISO 10545-6 (<175mm

3

)

PTV: 55W

Weight: 21.9kg per m

2

Structured tiles are also suitable for external use. See pages 93-95

Nude Polished

CS746-6060 • 600 x 600 x 9mm

Wear Rating: ISO 10545-6 (<175mm

3

)

Weight: 19.0kg per m

2

Concreto Aparante Natural

CS735-6060 • 600 x 600 x 10mm

Wear Rating: ISO 10545-6 (<175mm

3

)

Weight: 21.9kg per m

2

Concreto Structured

CS736-6060 • 600 x 600 x 10mm

Wear Rating: ISO 10545-6 (<175mm

3

)

PTV: 55W

Weight: 21.9kg per m

2

Concreto Polished

CS737-6060 • 600 x 600 x 9mm

Wear Rating: ISO 10545-6 (<175mm

3

)

Weight: 19.0kg per m

2

Argento Natural

CS732-6060 • 600 x 600 x 10mm

Wear Rating: ISO 10545-6 (<175mm 3

Weight: 21.9kg per m

2

)

Argento Structured

CS733-6060 • 600 x 600 x 10mm

Wear Rating: ISO 10545-6 (<175mm 3

PTV: 55W

)

Weight: 21.9kg per m 2

Argento Polished

CS734-6060 • 600 x 600 x 9mm

Wear Rating: ISO 10545-6 (<175mm 3

Weight: 19.0kg per m

2

)

Fendi Natural

CS738-6060 • 600 x 600 x 10mm

Wear Rating: ISO 10545-6 (<175mm

3

)

Weight: 21.9kg per m 2

Fendi Structured

CS739-6060 • 600 x 600 x 10mm

Wear Rating: ISO 10545-6 (<175mm

3

)

PTV: 55W

Weight: 21.9kg per m

2

Fendi Polished

CS740-6060 • 600 x 600 x 9mm

Wear Rating: ISO 10545-6 (<175mm

3

)

Weight: 19.0kg per m 2

Grafite Natural

CS741-6060 • 600 x 600 x 10mm

Wear Rating: ISO 10545-6 (<175mm

3

)

Weight: 21.9kg per m

2

Grafite Structured

CS742-6060 • 600 x 600 x 10mm

Wear Rating: ISO 10545-6 (<175mm

3

)

PTV: 55W

Weight: 21.9kg per m

2

Structured tiles are also suitable for external use. See pages 93-95

Grafite Polished

CS743-6060 • 600 x 600 x 9mm

Wear Rating: ISO 10545-6 (<175mm

3

)

Weight: 19.0kg per m

2

Walls Floors Internal

12

B R O A D W A Y

Broadway Road CS756-6060 Floor and Wall: Broadway Concrete CS755-6060

Broadway

A washed cement effect, for the modern warehouse look

Broadway’s rectified tiles are perfect for the pared down modern style of interior design. The glazed porcelain has a washed cement effect in four streetwise colours (see page 16 for the full colour range).

Floor: Broadway Lime CS753-6060

Wall behind the bed: New Age Off White CS725-6030 (see page 91), shown with Chenab Clear glass tiles from the

Glassworks range and in the en suite, Cascade Silk mosaics from the Mosaics range

14

C E M E N T I

Cimenti Grey CS801-6060

Cementi

Cool colours for contemporary interiors

Glazed porcelain tiles in a palette of soft greys to resemble cemented surfaces, using ink jet technology. The non-rectified format means the edges have a softer feel to them. Like

Broadway, Cementi will fit in well with the current urban warehouse style trend. Please turn the page for full details.

16

P R O D U C T

I N F O R M A T I O N

Broadway rectified glazed porcelain

Broadway Lime

CS753-6060 • 600 x 600 x 10mm

PEI Rating: 4

Weight: 20.9kg per m

2

Broadway Cement

CS754-6060 • 600 x 600 x 10mm

PEI Rating: 4

Weight: 20.9kg per m

2

Broadway Concrete

CS755-6060 • 600 x 600 x 10mm

PEI Rating: 4

Weight: 20.9kg per m 2

Broadway Road

CS756-6060 • 600 x 600 x 10mm

PEI Rating: 4

Weight: 20.9kg per m 2

Please note, because of their size, these tiles are not in proportion to reference images of tiles in other sections.

Merci de noter qu’en raison de leur taille ces carreaux ne sont pas en proportion avec les autres images dans les autres sections.

Es ist zu merken, daß diese Fliesen in keinem Verhältniss zu der Abbildungen von Fliesen in anderer Ausschnitten stehen.

De tegels in deze afbeeldingen zijn niet afgebeeld in dezelfde schaal als de tegels afgebeeld in andere secties.

Walls Floors Internal

17

P R O D U C T

I N F O R M A T I O N

Cementi glazed porcelain

White Glazed Porcelain

CS798-6060 • 600 x 600 x 9.5mm

PEI Rating: 5

Weight: 20.7kg per m

2

Soft Grey Glazed Porcelain

CS799-6060 • 600 x 600 x 9.5mm

PEI Rating: 5

Weight: 20.7kg per m

2

Grafite Glazed Porcelain

CS800-6060 • 600 x 600 x 9.5mm

PEI Rating: 4

Weight: 20.7kg per m 2

Grey Glazed Porcelain

CS801-6060 • 600 x 600 x 9.5mm

PEI Rating: 4

Weight: 20.7kg per m 2

Please note, because of their size, these tiles are not in proportion to reference images of tiles in other sections.

Merci de noter qu’en raison de leur taille ces carreaux ne sont pas en proportion avec les autres images dans les autres sections.

Es ist zu merken, daß diese Fliesen in keinem Verhältniss zu der Abbildungen von Fliesen in anderer Ausschnitten stehen.

De tegels in deze afbeeldingen zijn niet afgebeeld in dezelfde schaal als de tegels afgebeeld in andere secties.

Walls Floors Internal

New York and

Paulista

Wall: New York CS783-9045

Floor: Cimenti Grey CS801-6060

New York Glazed Porcelain

CS783-9045 • 900 x 450 x 10mm

Weight: 22.0kg per m 2

Paulista Glazed Porcelain

CS784-9045 • 900 x 450 x 10mm

Weight: 22.0kg per m 2

Two striking wall tiles with amazing textured effects

The relief patterns on these striking glazed porcelain tiles can be used for creating amazing and distinctive effects for modern interior walls. Try different lighting methods to enhance the decorative designs.

Walls Internal

19

N E W Y O R K

A N D P A U L I S T A

Rovere S764-12020

Wood Effect

21

W O O D E F F E C T

All the character of wood in a glazed porcelain tile

These amazingly realistic wood effect planks are designed and manufactured with the use of digital inkjet technology, ensuring a depth of colour and the ultimate in realism.

These planks are perfect when you want the look of wood and the practicality of porcelain. Beautiful on the floor, they also look great on the wall. You could say, they are just like the real thing, only better!

22

W O O D E F F E C T

Wood Effect

Eucalipto Glazed Porcelain

CS761-12020 • 1200 x 200 x 12mm

PEI Rating: 4

Weight: 25.8kg per m

2

Rovere Glazed Porcelain

CS764-12020 • 1200 x 200 x 12mm

PEI Rating: 4

Weight: 25.8kg per m

2

Peroba Castanho Glazed Porcelain

CS763-12020 • 1200 x 200 x 12mm

PEI Rating: 4

Weight: 25.8kg per m

2

Peroba Amendola Glazed Porcelain

CS762-12020 • 1200 x 200 x 12mm

PEI Rating: 4

Weight: 25.8kg per m

2

Please note, because of their size, these tiles are not in proportion to reference images of tiles in other sections.

Merci de noter qu’en raison de leur taille ces carreaux ne sont pas en proportion avec les autres images dans les autres sections.

Es ist zu merken, daß diese Fliesen in keinem Verhältniss zu der Abbildungen von Fliesen in anderer Ausschnitten stehen.

De tegels in deze afbeeldingen zijn niet afgebeeld in dezelfde schaal als de tegels afgebeeld in andere secties.

Walls Floors Internal

Wall: Peroba Castanho CS763-12020

Floor: Bottocino Tumbled Marble from the Earthworks range, and St Kitts Mosaics from the Pool and Spa range

24

B A M B O O

Bamboo

Make a statement with these funky bamboo lookalikes

Ink jet technology has been used for these three glazed porcelain tiles which closely resemble bamboo. They will bring a touch of the tropics to any bathroom or spa area.

Sisal CS787-9015

Buriti CS785-9015

Bamboo

Sisal Glazed Porcelain

CS787-9015 • 900 x 150 x 10mm

Weight: 21.0kg per m

2

Juta Glazed Porcelain

CS786-9015 • 900 x 150 x 10mm

Weight: 21.0kg per m 2

Buriti Glazed Porcelain

CS785-9015 • 900 x 150 x 10mm

Weight: 21.0kg per m 2

Please note, because of their size, these tiles are not in proportion to reference images of tiles in other sections.

Merci de noter qu’en raison de leur taille ces carreaux ne sont pas en proportion avec les autres images dans les autres sections.

Es ist zu merken, daß diese Fliesen in keinem Verhältniss zu der Abbildungen von Fliesen in anderer Ausschnitten stehen.

De tegels in deze afbeeldingen zijn niet afgebeeld in dezelfde schaal als de tegels afgebeeld in andere secties.

Walls Internal

27

P R O D U C T

I N F O R M A T I O N

Floor and wall on right: Cavallino Anthracite CS583-4545

Wall on left: Cavallino White CS580-4545

Fabulous Creatures

Outrageously glamorous animal prints, with co-ordinating textured tiles

These definitely have the wow factor. The animal prints can be used on their own or with the matching plain coloured tiles, which also have the texture of animal hide.

These striking tiles change their appearance in different lighting conditions.

Top right: Cavallino Zebra CS587-4545

Right: Cavallino Leopard CS584-4545

29

F A B U L O U S

C R E A T U R E S

Wall: Cavallino Friesian CS586-4545

Floor: Cavallino Anthracite CS583-4545

30

P R O D U C T

I N F O R M A T I O N

Fabulous Creatures

Cavallino White Glazed Porcelain

CS580-4545 • 450 x 450 x 9mm

PEI Rating: 3

Weight: 22.0kg per m

2

Cavallino Crema Glazed Porcelain

CS615-4545 • 450 x 450 x 9mm

PEI Rating: 3

Weight: 22.0kg per m

2

Cavallino Gold Glazed Porcelain

CS581-4545 • 450 x 450 x 9mm

PEI Rating: 3

PTV: 54W

Weight: 22.0kg per m

2

Cavallino Bronze Glazed Porcelain

CS582-4545 • 450 x 450 x 9mm

PEI Rating: 3

Weight: 22.0kg per m 2

Cavallino Anthracite Glazed Porcelain

CS583-4545 • 450 x 450 x 9mm

PEI Rating: 3

Weight: 22.0kg per m

2

Walls Floors Internal

31

P R O D U C T

I N F O R M A T I O N

Cavallino Leopard Glazed Porcelain

CS584-4545 • 450 x 450 x 9mm

PEI Rating: 2

Weight: 22.0kg per m

2

Cavallino Tiger Glazed Porcelain

CS585-4545 • 450 x 450 x 9mm

PEI Rating: 2

Weight: 22.0kg per m

2

Cavallino Friesian Glazed Porcelain

CS586-4545 • 450 x 450 x 9mm

PEI Rating: 2

Weight: 22.0kg per m 2

Cavallino Zebra Glazed Porcelain

CS587-4545 • 450 x 450 x 9mm

PEI Rating: 2

Weight: 22.0kg per m 2

Please note, because of their size, these tiles are not in proportion to reference images of tiles in other sections.

Merci de noter qu’en raison de leur taille ces carreaux ne sont pas en proportion avec les autres images dans les autres sections.

Es ist zu merken, daß diese Fliesen in keinem Verhältniss zu der Abbildungen von Fliesen in anderer Ausschnitten stehen.

De tegels in deze afbeeldingen zijn niet afgebeeld in dezelfde schaal als de tegels afgebeeld in andere secties.

Walls Floors Internal

32

S A N T I A G O

Wall: Santiago White Decorated CS529-6030 and Santiago White CS528-6030 shown with

Metallica Border from the Glassworks range

Floor: Santiago White CS528-6060

Wall: Santiago Beige Decorated CS527-6030

Floor: Santiago Beige CS526-6060

Cutting edge design for modern living spaces

The semi-polished finish enhances the contemporary credentials of this range. In shades of white, beige, brown, olive, grey and black, the plain tiles have a subtle movement of tone, and the co-ordinating decorative pieces have a delicate repeating pattern. Turn the page for full details.

Santiago

Wall: Santiago Black Decorated CS531-6030 and Santiago Black CS530-6030

Floor: Santiago Black CS530-6060

34

P R O D U C T

I N F O R M A T I O N

Santiago semi-polished porcelain

Santiago White Decorated

CS529-6030 • 600 x 300 x 9.5mm

Weight: 22.9kg per m2

Santiago White Rectified

CS528-6030 • 600 x 300 x 9.5mm

CS528-6060 • 600 x 600 x 9.5mm

PEI Rating: 4

Weight: 22.9kg per m

2

Santiago Beige Decorated

CS527-6030 • 600 x 300 x 9.5mm

Weight: 22.9kg per m

2

Santiago Olive Decorated

CS525-6030 • 600 x 300 x 9.5mm

Weight: 22.9kg per m

2

Santiago Beige Rectified

CS526-6030 • 600 x 300 x 9.5mm

CS526-6060 • 600 x 600 x 9.5mm

PEI Rating: 4

Weight: 22.9kg per m

2

Santiago Olive Rectified

CS524-6030 • 600 x 300 x 9.5mm

CS524-6060 • 600 x 600 x 9.5mm

PEI Rating: 4

Weight: 22.9kg per m

2

Santiago Black Decorated

CS531-6030 • 600 x 300 x 9.5mm

Weight: 22.9kg per m

2

Santiago Black Rectified

CS530-6030 • 600 x 300 x 9.5mm

CS530-6060 • 600 x 600 x 9.5mm

PEI Rating: 4

Weight: 22.9kg per m

2

Lisboa Terra Rectified

CS717-6060 • 600 x 600 x 10mm

PEI Rating: 4

Weight: 22.2kg per m

2

Sintra Terra Rectified

CS718-6060 • 600 x 600 x 10mm

PEI Rating: 4

Weight: 22.2kg per m

2

Santiago Grey Rectified

CS532-6030 • 600 x 300 x 9.5mm

CS532-6060 • 600 x 600 x 9.5mm

PEI Rating: 4

Weight: 22.9kg per m

2

Please note, because of their size, these tiles are not in proportion to reference images of tiles in other sections.

Merci de noter qu’en raison de leur taille ces carreaux ne sont pas en proportion avec les autres images dans les autres sections.

Es ist zu merken, daß diese Fliesen in keinem Verhältniss zu der Abbildungen von Fliesen in anderer Ausschnitten stehen.

De tegels in deze afbeeldingen zijn niet afgebeeld in dezelfde schaal als de tegels afgebeeld in andere secties.

35

P R O D U C T

I N F O R M A T I O N

37

A R L E S A N D

T H E N A C

Wall: Thenac CS556-9030

Floor: Thenac CS563-9090

Arles CS489-6030

Arles and Thenac

Soft colours and a limestone effect

The versatile 900 x 900mm rectified porcelain floor tiles are perfect for any entrance hall or large area. The satin finish is complemented by the rectified 900 x 300mm gloss ceramic wall tiles. The range also includes

600 x 300mm gloss ceramic in both colours. See page 40 for full details.

38

S L A T E C H I A R A

Slate Di Savoia Argento CS767-6060

Slate Chiara

Slate effect tiles in both light and dark, with two matching mosaic finishes

All the fine details and good looks of natural slate and quartz, in glazed porcelain. Digital ink jet technology lends a genuine quality to these attractive stone effect tiles, which are further enhanced in the mosaic effect versions. Turn the page for full details.

Floor: Slate Chiara Bianco CS765-6060

Wall on right: Slate Chiara Mosaic Finish CS766-6060

Other walls: Essence Crema Act CS788-6030 (see page 70)

40

P R O D U C T

I N F O R M A T I O N

Arles and Thenac

Arles Gloss Ceramic

CS489-6030 • 600 x 300 x 9mm

Weight: 18.8kg per m 2

Arles Rectified Glazed Ceramic

CS489-9030 • 900 x 300 x 13mm

Weight: 24.9kg per m 2

Arles Rectified Double Pressed Porcelain Satin Finish

CS562-9090 • 900 x 900 x 13mm

Wear Rating: ISO 10545-6 (<175mm 3

Weight: 24.9kg per m

2

)

Thenac Stone Ceramic

CS556-6030 • 600 x 300 x 9mm

Weight: 18.8kg per m

2

Thenac Rectified Glazed Ceramic

CS556-9030 • 900 x 300 x 13mm

Weight: 24.9kg per m

2

Thenac Rectified Double Pressed Porcelain Satin Finish

CS563-9090 • 900 x 900 x 13mm

Wear Rating: ISO 10545-6 (<175mm

3

)

Weight: 24.9kg per m

2

Slate Chiara

Slate Chiara Bianco Glazed Porcelain

CS765-6060 • 600 x 600 x 10mm

PEI Rating: 4

Weight: 21.9kg per m

2

Slate Chiara Mosaic Finish Glazed Porcelain

CS766-6060 • 600 x 600 x 10mm

PEI Rating: 4

Weight: 20.9kg per m

2

Slate Di Savoia Argento Glazed Porcelain

CS767-6060 • 600 x 600 x 10mm

PEI Rating: 4

Weight: 21.9kg per m

2

Slate Di Savoia Mosaic Finish Glazed Porcelain

CS768-6060 • 600 x 600 x 10mm

PEI Rating: 4

Weight: 20.9kg per m

2

Please note, because of their size, these tiles are not in proportion to reference images of tiles in other sections.

Merci de noter qu’en raison de leur taille ces carreaux ne sont pas en proportion avec les autres images dans les autres sections.

Es ist zu merken, daß diese Fliesen in keinem Verhältniss zu der Abbildungen von Fliesen in anderer Ausschnitten stehen.

De tegels in deze afbeeldingen zijn niet afgebeeld in dezelfde schaal als de tegels afgebeeld in andere secties.

41

P R O D U C T

I N F O R M A T I O N

42

C I T Y R A N G E

City Range

Chic and fashionable, like their Italian city name sakes

A range of stylish colours, polished and matt finishes in a tough, stone-effect porcelain make these tiles extremely adaptable for all spaces. This double loaded porcelain is suitable for even heavy footfall in commercial settings.

Wall: Napoli Sabbia Matt CS494-6030 shown with New York Mix Mosaics (see page 57),

Floor: Napoli Sabbia Polished CS500-6030

Rimini Taupe Polished CS811-6030

Verona Bianco Matt CS497-6030

Wall: Bari Mocha Polished CS505-6030

Floor: Bari Mocha Matt CS499-6030

44

P R O D U C T

I N F O R M A T I O N

City Range full bodied double loaded porcelain

Verona Bianco Matt Rectified

CS497-3030 • 300 x 300 x 10mm

CS497-6030 • 600 x 300 x 10mm

CS497-6060 • 600 x 600 x 10mm

Wear Rating: ISO 10545-6 (<175mm

3

)

Weight: 22.9kg per m

2

Florence Beige Matt Rectified

CS495-3030 • 300 x 300 x 10mm

CS495-6030 • 600 x 300 x 10mm

CS495-6060 • 600 x 600 x 10mm

Wear Rating: ISO 10545-6 (<175mm

3

)

Weight: 22.9kg per m

2

Genoa Natrale Matt Rectified

CS496-3030 • 300 x 300 x 10mm

CS496-6030 • 600 x 300 x 10mm

CS496-6060 • 600 x 600 x 10mm

Wear Rating: ISO 10545-6 (<175mm

3

)

Weight: 22.9kg per m

2

Verona Bianco Polished Rectified

CS503-6030 • 600 x 300 x 9mm

CS503-6060 • 600 x 600 x 9mm

Wear Rating: ISO 10545-6 (<175mm 3

Weight: 22.9kg per m

2

)

Florence Beige Polished Rectified

CS501-6030 • 600 x 300 x 9mm

CS501-6060 • 600 x 600 x 9mm

Wear Rating: ISO 10545-6 (<175mm 3

Weight: 22.9kg per m

2

)

Genoa Natrale Polished Rectified

CS502-6030 • 600 x 300 x 9mm

CS502-6060 • 600 x 600 x 9mm

Wear Rating: ISO 10545-6 (<175mm 3

Weight: 22.9kg per m

2

)

Please note, because of their size, these tiles are not in proportion to reference images of tiles in other sections.

Merci de noter qu’en raison de leur taille ces carreaux ne sont pas en proportion avec les autres images dans les autres sections.

Es ist zu merken, daß diese Fliesen in keinem Verhältniss zu der Abbildungen von Fliesen in anderer Ausschnitten stehen.

De tegels in deze afbeeldingen zijn niet afgebeeld in dezelfde schaal als de tegels afgebeeld in andere secties.

45

P R O D U C T

I N F O R M A T I O N

Napoli Sabbia Matt Rectified

CS494-3030 • 300 x 300 x 10mm

CS494-6030 • 600 x 300 x 10mm

CS494-6060 • 600 x 600 x 10mm

Wear Rating: ISO 10545-6 (<175mm

3

)

Weight: 22.9kg per m

2

Rimini Taupe Matt Rectified

CS810-3030 • 300 x 300 x 10mm

CS810-6030 • 600 x 300 x 10mm

CS810-6060 • 600 x 600 x 10mm

Wear Rating: ISO 10545-6 (<175mm

3

)

Weight: 22.9kg per m

2

Bari Mocha Matt Rectified

CS499-3030 • 300 x 300 x 10mm

CS499-6030 • 600 x 300 x 10mm

CS499-6060 • 600 x 600 x 10mm

Wear Rating: ISO 10545-6 (<175mm

3

)

Weight: 22.9kg per m

2

Napoli Sabbia Polished Rectified

CS500-6030 • 600 x 300 x 9mm

CS500-6060 • 600 x 600 x 9mm

Wear Rating: ISO 10545-6 (<175mm 3

Weight: 22.9kg per m

2

)

Rimini Taupe Polished Rectified

CS811-6030 • 600 x 300 x 9mm

CS811-6060 • 600 x 600 x 9mm

Wear Rating: ISO 10545-6 (<175mm 3

Weight: 22.9kg per m

2

)

Bari Mocha Polished Rectified

CS505-6030 • 600 x 300 x 9mm

CS505-6060 • 600 x 600 x 9mm

Wear Rating: ISO 10545-6 (<175mm 3

Weight: 22.9kg per m

2

)

Turin Grigio Matt Rectified

CS498-3030 • 300 x 300 x 10mm

CS498-6030 • 600 x 300 x 10mm

CS498-6060 • 600 x 600 x 10mm

Wear Rating: ISO 10545-6 (<175mm

3

)

Weight: 22.9kg per m

2

Turin Grigio Polished Rectified

CS504-6030 • 600 x 300 x 9mm

CS504-6060 • 600 x 600 x 9mm

Wear Rating: ISO 10545-6 (<175mm 3

Weight: 22.9kg per m

2

)

Walls Floors Internal

46

S A N D S

Floor: Santa Monica CS698-6060

Wall: Solstice wall tiles from the Glassworks range

Sands

Colours that resemble the sands of famous beaches from around the globe

These full bodied, rectified porcelains have soft colours from white through to black.

However, unlike shifting beach sand, the tiles in this collection are as solid as a rock underfoot and can be used with confidence for flooring in heavy footfall areas.

See overleaf for full details.

Wall: Vigan CS696-6030 shown with Ulysses bevel tiles from the Glassworks range

Floor: Vigan CS696-6060

49

S A N D S

Sands rectified full bodied porcelain

Waikiki

CS697-6030 • 600 x 300 x 10mm

CS697-6060 • 600 x 600 x 10mm

Wear Rating: ISO 10545-6 (<175mm

3

)

Weight: 22.2kg per m 2

Santa Monica

CS698-6030 • 600 x 300 x 10mm

CS698-6060 • 600 x 600 x 10mm

Wear Rating: ISO 10545-6 (<175mm

3

)

Weight: 22.2kg per m 2

Vigan

CS696-6030 • 600 x 300 x 10mm

CS696-6060 • 600 x 600 x 10mm

Wear Rating: ISO 10545-6 (<175mm

3

)

Weight: 22.2kg per m 2

Myrtos

CS695-6030 • 600 x 300 x 10mm

CS695-6060 • 600 x 600 x 10mm

Wear Rating: ISO 10545-6 (<175mm

3

)

Weight: 22.2kg per m 2

Papakolea

CS693-6030 • 600 x 300 x 10mm

CS693-6060 • 600 x 600 x 10mm

Wear Rating: ISO 10545-6 (<175mm

3

)

Weight: 22.2kg per m 2

Kehena

CS694-6030 • 600 x 300 x 10mm

CS694-6060 • 600 x 600 x 10mm

Wear Rating: ISO 10545-6 (<175mm

3

)

Weight: 22.2kg per m 2

Please note, because of their size, these tiles are not in proportion to reference images of tiles in other sections.

Merci de noter qu’en raison de leur taille ces carreaux ne sont pas en proportion avec les autres images dans les autres sections.

Es ist zu merken, daß diese Fliesen in keinem Verhältniss zu der Abbildungen von Fliesen in anderer Ausschnitten stehen.

De tegels in deze afbeeldingen zijn niet afgebeeld in dezelfde schaal als de tegels afgebeeld in andere secties.

Walls Floors Internal

50

Z E L O S L I M L I N E

Zelo Slimline

Ultra thin and light weight

Zelo are exceptionally thin panels of glazed porcelain (only 5mm) and so they are lighter in weight than thicker tiles. This means they can be used to tile over previously tiled surfaces (providing these are sound). They are easy to cut, and as they are large format (800 x 400mm), a room can be quickly and completely transformed. Ink jet printing used in their production also results in smooth and even colour coverage, and they have a very subtle glimmer effect which can be seen in certain lights.

Wall: White CS805-8040

Floor: Grey CS803-8040

Wall: Anthracite CS804-8040, shown with Spectre Mosaics from the Mosaics range

Floor: Anthracite CS804-8040

Zelo Slimline glazed porcelain

White Rectified

CS805-8040 • 800 x 400 x 5mm

PEI Rating: 5

Weight: 11.5kg per m

2

Beige Rectified

CS802-8040 • 800 x 400 x 5mm

PEI Rating: 5

Grey Rectified

CS803-8040 • 800 x 400 x 5mm

PEI Rating: 4

Antracite Rectified

CS804-8040 • 800 x 400 x 5mm

PEI Rating: 4

Weight: 11.5kg per m

2

53

P R O D U C T

I N F O R M A T I O N

Although they have a thickness of only 5mm, Zelo Slimline tiles conform to the standards for impact resistance tests:

BS EN ISO 10545-5: Average Coefficient of Restitution 0.85 (impact resistance with no damage caused though test). Please see pages 93-95.

Please note, because of their size, these tiles are not in proportion to reference images of tiles in other sections.

Merci de noter qu’en raison de leur taille ces carreaux ne sont pas en proportion avec les autres images dans les autres sections.

Es ist zu merken, daß diese Fliesen in keinem Verhältniss zu der Abbildungen von Fliesen in anderer Ausschnitten stehen.

De tegels in deze afbeeldingen zijn niet afgebeeld in dezelfde schaal als de tegels afgebeeld in andere secties.

Walls Floors Internal

54

N E W Y O R K M O S A I C S

A N D M AT T O N E

B R I C K E F F E C T

New York Times Square Black Mosaic

CS357-3030

Mattone Bianco Ceramic CS769-2307

New York Mosaics and

Matonne Brick Effect

Sleek and linear mosaics, and brick effect tiles

The New York mosaics are available in a variety of colours and mixes, and look stylish placed either vertically or horizontally. Mattone are brick effect ceramic tiles in both black and white, bringing a rustic feel to contemporary settings.

Mattone Nero Ceramic CS770-2307

56

P R O D U C T

I N F O R M A T I O N

Matonne Brick Effect

Mattone Bianco Ceramic

CS769-2307 • 65 x 230 x 7mm

Weight: 13.8kg per m 2

Mattone Nero Ceramic

CS770-2307 • 65 x 230 x 7mm

Weight: 13.8kg per m 2

New York Mosaics full bodied porcelain

Central Park Cream

CS354-3030 • 287 x 295 x 7mm

Wear Rating: ISO 10545-6 (<175mm

3

)

Weight: 13.3kg per m 2

Brooklyn Beige

CS353-3030 • 287 x 295 x 7mm

Wear Rating: ISO 10545-6 (<175mm

3

)

Weight: 13.3kg per m 2

First Avenue Taupe

CS356-3030 • 287 x 295 x 7mm

Wear Rating: ISO 10545-6 (<175mm

3

)

Weight: 13.3kg per m 2

Manhattan Mocha

CS355-3030 • 287 x 295 x 7mm

Wear Rating: ISO 10545-6 (<175mm

3

)

Weight: 13.3kg per m 2

57

P R O D U C T

I N F O R M A T I O N

Empire State Coffee

CS358-3030 • 287 x 295 x 7mm

Wear Rating: ISO 10545-6 (<175mm

3

)

Weight: 13.3kg per m 2

Union City Brown

CS359-3030 • 287 x 295 x 7mm

Wear Rating: ISO 10545-6 (<175mm

3

)

Weight: 13.3kg per m 2

New York Mix

CS352-3030 • 287 x 295 x 7mm

Wear Rating: ISO 10545-6 (<175mm

3

)

Weight: 13.3kg per m 2

Times Square Black

CS357-3030 • 287 x 295 x 7mm

Wear Rating: ISO 10545-6 (<175mm

3

)

Weight: 13.3kg per m 2

Please note, because of their size, these tiles are not in proportion to reference images of tiles in other sections.

Merci de noter qu’en raison de leur taille ces carreaux ne sont pas en proportion avec les autres images dans les autres sections.

Es ist zu merken, daß diese Fliesen in keinem Verhältniss zu der Abbildungen von Fliesen in anderer Ausschnitten stehen.

De tegels in deze afbeeldingen zijn niet afgebeeld in dezelfde schaal als de tegels afgebeeld in andere secties.

Walls Floors Internal

Coliseum Beige CS715-5050, CS715-5025 and CS715-2525

59

C O L I S E U M ,

R O C K A N D

M E D I T E R R A N E A N

Rock Arena CS124-1010, Rock Dorato CS125-1010 and

Rock Noce CS123-1010

Upper wall Sardinian Beige CS392-3040, lower wall, shelf, Maltese Brown CS393-3040, Mixed Travertine 2.3

Mosaics and Mosaic Basin from the Earthworks range

Coliseum, Rock and Mediterranean

Stone-effect tiles in different formats for floors and walls

Coliseum is a rustic, travertine effect floor tile, perfect for that country kitchen look.

Available in three colours and sizes, which look fantastic used on their own or together in a multi-format pattern as shown. Rock is a collection of 100 x 100mm tiles in six colours which can be mixed or used as a single colour for walls (and floors). The shades of

Mediterranean wall tiles co-ordinate beautifully with each other and with natural stone mosaics (as shown above).

60

P R O D U C T

I N F O R M A T I O N

Coliseum

Coliseum White Glazed Porcelain

CS716-2525 • 250 x 250 x 10mm

CS716-5025 • 500 x 250 x 10mm

CS716-5050 • 500 x 500 x 10mm

PEI Rating: 4

Weight: 21.3kg per m

2

Rock

Coliseum Beige Glazed Porcelain

CS715-2525 • 250 x 250 x 10mm

CS715-5025 • 500 x 250 x 10mm

CS715-5050 • 500 x 500 x 10mm

PEI Rating: 4

Weight: 21.3kg per m

2

Coliseum Noce Glazed Porcelain

CS714-2525 • 250 x 250 x 10mm

CS714-5025 • 500 x 250 x 10mm

CS714-5050 • 500 x 500 x 10mm

PEI Rating: 4

Weight: 21.3kg per m

2

Rock Bianco Glazed Porcelain

CS126-1010 • 100 x 100 x 8.5mm

PEI Rating: 4

Weight: 19.0kg per m

2

Rock Grigio Glazed Porcelain

CS127-1010 • 100 x 100 x 8.5mm

PEI Rating: 4

Weight: 19.0kg per m

2

Rock Arena Glazed Porcelain

CS124-1010 • 100 x 100 x 8.5mm

PEI Rating: 4

Weight: 19.0kg per m

2

Rock Noce Glazed Porcelain

CS123-1010 • 100 x 100 x 8.5mm

PEI Rating: 4

Weight: 19.0kg per m

2

Rock Dorato Glazed Porcelain

CS125-1010 • 100 x 100 x 8.5mm

PEI Rating: 4

Weight: 19.0kg per m

2

Rock Nero Glazed Porcelain

CS128-1010 • 100 x 100 x 8.5mm

PEI Rating: 4

Weight: 19.0kg per m

2

Walls Floors Internal

Mediterranean

Sicilian White Ceramic

CS391-3040 • 400 x 300 x 8mm

Weight: 16.1kg per m 2

Sardinian Beige Ceramic

CS392-3040 • 400 x 300 x 8mm

Weight: 16.1kg per m 2

Maltese Brown Ceramic

CS393-3040 • 400 x 300 x 8mm

Weight: 16.1kg per m 2

61

P R O D U C T

I N F O R M A T I O N

Sicilian White Glazed Porcelain

CS391-4545 • 450 x 450 x 8mm

PEI Rating: 5

Weight: 21.7kg per m

2

Sardinian Beige Glazed Porcelain

CS392-4545 • 450 x 450 x 8mm

PEI Rating: 5

Weight: 21.7kg per m

2

Maltese Brown Glazed Porcelain

CS393-4545 • 450 x 450 x 8mm

PEI Rating: 4

Weight: 21.7kg per m

2

Please note, because of their size, these tiles are not in proportion to reference images of tiles in other sections.

Merci de noter qu’en raison de leur taille ces carreaux ne sont pas en proportion avec les autres images dans les autres sections.

Es ist zu merken, daß diese Fliesen in keinem Verhältniss zu der Abbildungen von Fliesen in anderer Ausschnitten stehen.

De tegels in deze afbeeldingen zijn niet afgebeeld in dezelfde schaal als de tegels afgebeeld in andere secties.

Wall and Florr: Illusion White CS521-6060, CS521-6030 and Fantasy Black CS522-6030

Wall behind stove Parisian White CS301-6030, shown with Stovax Riva Vision on a Riva bench installed on a Stovax hearth

Parisian White,

Fantasy and Illusion

Classic Black and Whites

Fantasy is a superb black, full bodied polished porcelain, perfect on its own and also beautiful when teamed with its soul mate, Illusion White. Parisian White is also a stylish polished white porcelain to suit all needs for walls and floors.

63

P A R I S I A N W H I T E ,

F A N T A S Y

A N D I L L U S I O N

64

B O R G O G N A ,

B E L I Z E A N D

A C R O P O L I S S A N D

Belize Sand CS548-9045 Borgogna Crema CS558-9045

Borgogna, Belize and Acropolis Sand

Tiles with a superior stone effect finish

Available in white and cream, Borgogna sandstone effect large format tiles will enhance kitchens, hallways and conservatories. The warm tones of Acropolis Sand are enhanced by its subtle matt travertine effect. Belize, a large format, rectified glazed porcelain in a subtle sand colour, will look at home in many different settings.

Wall: Acropolis Sand CS781-9030, shown with Jurassic Mosaic from the Mosaics range

Floor: Mineral Nude Structured CS745-6060

Valencia and

Dream Beige

67

V A L E N C I A A N D

D R E A M B E I G E

Valencia Crema

CS459-9045, shown with Borgogna Crema

(see page 64)

Wall: Dream Beige CS523-6030, shown with Divine mosaics from the Mosaics range

Floor: Dream Beige CS523-6060

The ultimate in elegance and style

Valencia Crema has all the stunning good looks of polished marble, with the durability of porcelain. Dream Beige is a decorator’s dream: a full bodied polished porcelain wall and floor tile in three sizes.

68

P R O D U C T

I N F O R M A T I O N

Parisian White, Fantasy and Illusion full bodied polished porcelain

Parisian White

CS301-3030 • 300 x 300 x 10mm

CS301-6030 • 600 x 300 x 10mm

CS301-6060 • 600 x 600 x 10mm

Wear Rating: ISO 10545-6 (<175mm

3

)

Weight: 22.9kg per m

2

Illusion White Rectified

CS521-4040 • 400 x 400 x 8mm

CS521-6030 • 600 x 300 x 9mm

CS521-6060 • 600 x 600 x 9mm

Wear Rating: ISO 10545-6 (<175mm

3

)

Weight: 20.8kg per m

2

Fantasy Black Rectified

CS522-4040 • 400 x 400 x 8mm

CS522-6030 • 600 x 300 x 9mm

CS522-6060 • 600 x 600 x 9mm

Wear Rating: ISO 10545-6 (<175mm

3

)

Weight: 22.2kg per m

2

Valencia and Dream Beige

Valencia Crema Rectified

Double Loaded Polished Porcelain

CS459-9045 • 900 x 450 x 10mm

Wear Rating: ISO 10545-6 (<175mm

3

)

Weight: 20.0kg per m

2

Dream Beige Rectified Full Bodied

Polished Porcelain

CS523-4040 • 400 x 400 x 8mm

CS523-6030 • 600 x 300 x 9mm

CS523-6060 • 600 x 600 x 9mm

Wear Rating: ISO 10545-6 (<175mm

3

)

Weight: 20.8kg per m

2

Please note, because of their size, these tiles are not in proportion to reference images of tiles in other sections.

Merci de noter qu’en raison de leur taille ces carreaux ne sont pas en proportion avec les autres images dans les autres sections.

Es ist zu merken, daß diese Fliesen in keinem Verhältniss zu der Abbildungen von Fliesen in anderer Ausschnitten stehen.

De tegels in deze afbeeldingen zijn niet afgebeeld in dezelfde schaal als de tegels afgebeeld in andere secties.

Walls Floors Internal

Borgogna, Belize and

Acropolis Sand

Borgogna Bianco Rectified Glazed Porcelain

CS557-9045 • 900 x 450 x13mm

PEI Rating: 4

Weight: 27.0kg per m 2

Acropolis Sand Rectified Matt Ceramic

CS781-9030 • 900 x 300 x 11.2mm

Weight: 23.0kg per m

2

69

P R O D U C T

I N F O R M A T I O N

Borgogna Crema Rectified Glazed Porcelain

CS558-9045 • 900 x 450 x13mm

PEI Rating: 4

Weight: 27.0kg per m

2

Belize Sand Rectified Glazed Porcelain

CS548-9045 • 900 x 450 x 14mm

PEI Rating: 4

PTV: 55W

Weight: 27.0kg per m 2

Please note, because of their size, these tiles are not in proportion to reference images of tiles in other sections.

Merci de noter qu’en raison de leur taille ces carreaux ne sont pas en proportion avec les autres images dans les autres sections.

Es ist zu merken, daß diese Fliesen in keinem Verhältniss zu der Abbildungen von Fliesen in anderer Ausschnitten stehen.

De tegels in deze afbeeldingen zijn niet afgebeeld in dezelfde schaal als de tegels afgebeeld in andere secties.

70

E S S E N C E

A smooth satin finish in calming tones

The Essence collection of co-ordinating wall and floor tiles, with their subtle shades and smooth satin finish, will provide a perfect backdrop for all styles of furnishings and fashions.

Essence

Wall: Essence White Plain Matt CS792-6030, shown with Perfume tiles from the Glassworks range (in alcove)

Floor: White Plain Matt CS797-4545

72

P R O D U C T

I N F O R M A T I O N

Essence

White Plain Matt Ceramic

CS792-6030 • 600 x 300 x 9mm

Weight: 15.1kg per m

2

Crema Ceramic

CS788-6030 • 600 x 300 x 9mm

Weight: 15.1kg per m

2

Nebia Ceramic

CS789-6030 • 600 x 300 x 9mm

Weight: 15.1kg per m

2

Grigio Ceramic

CS790-6030 • 600 x 300 x 9mm

Weight: 15.1kg per m

2

Sabbia Ceramic

CS791-6030 • 600 x 300 x 9mm

Weight: 15.1kg per m 2

Walls Internal

73

P R O D U C T

I N F O R M A T I O N

White Plain Matt Glazed Porcelain

CS797-4545 • 450 x 450 x 8.5mm

PEI Rating: 5

Weight: 17.6kg per m

2

Crema Glazed Porcelain

CS793-4545 • 450 x 450 x 8.5mm

PEI Rating: 4

Weight: 17.6kg per m

2

Nebia Glazed Porcelain

CS794-4545 • 450 x 450 x 8.5mm

PEI Rating: 4

Weight: 17.6kg per m

2

Grigio Glazed Porcelain

CS795-4545 • 450 x 450 x 8.5mm

PEI Rating: 4

Weight: 17.6kg per m 2

Sabbia Glazed Porcelain

CS796-4545 • 450 x 450 x 8.5mm

PEI Rating: 4

Weight: 17.6kg per m 2

Please note, because of their size, these tiles are not in proportion to reference images of tiles in other sections.

Merci de noter qu’en raison de leur taille ces carreaux ne sont pas en proportion avec les autres images dans les autres sections.

Es ist zu merken, daß diese Fliesen in keinem Verhältniss zu der Abbildungen von Fliesen in anderer Ausschnitten stehen.

De tegels in deze afbeeldingen zijn niet afgebeeld in dezelfde schaal als de tegels afgebeeld in andere secties.

Walls Floors Internal

Reykjavik and Komotiite

Wall and Floor: Reykjavík Rectified CB Glazed Porcelain CS372-6060

Komatiite Black CS308-4545, Komatiite Grey CS307-4545

Texture, colour and drama

Reykjavik will add style to any contemporary interior;

Komotiite is an ultra modern tile with a ribbed texture, in a soft grey and a smoky black.

75

R E Y K J A V I K

A N D K O M O T I I T E

Vision Black CS416-4545 and Vision Grey CS415-4545

Vision and Pyrenees

Vision, available in grey and black, brings an understated simplicity to a room (Vision Black is available in a rectified version too). Pyrenees, a matt glazed porcelain, is a subtle soft light grey.

Reykjavik, Komotiite,

Vision and Pyrenees

77

P R O D U C T

I N F O R M A T I O N

Reykjavík Rectified Colour Bodied

Glazed Porcelain

CS372-6060 • 600 x 600 x 11mm

PEI Rating: 3

Weight: 22.9kg per m

2

Komatiite Grey Full Bodied Porcelain

CS307-4545 • 450 x 450 x 9mm

Wear Rating: ISO 10545-6 (<175mm

3

)

Weight: 19.3kg per m 2

Komatiite Black Full Bodied Porcelain

CS308-4545 • 450 x 450 x 9mm

Wear Rating: ISO 10545-6 (<175mm

3

)

Weight: 19.3kg per m 2

Vision Grey Glazed Porcelain

CS415-4545 • 450 x 450 x 9mm

PEI Rating: 4

Weight: 19.7kg per m

2

Vision Black Glazed Porcelain

CS416-4545 • 450 x 450 x 9mm

PEI Rating: 4

Weight: 19.7kg per m

2

Vision Black Rectified Semi Polished

Glazed Porcelain

CS414-4444 • 440 x 440 x 9mm

PEI Rating: 4

Weight: 19.0kg per m

2

Pyrenees Rectified Colour

Bodied Glazed Porcelain

CS370-6060 • 600 x 600 x 10mm

PEI Rating: 3

Weight: 22.9kg per m

2

Please note, because of their size, these tiles are not in proportion to reference images of tiles in other sections.

Merci de noter qu’en raison de leur taille ces carreaux ne sont pas en proportion avec les autres images dans les autres sections.

Es ist zu merken, daß diese Fliesen in keinem Verhältniss zu der Abbildungen von Fliesen in anderer Ausschnitten stehen.

De tegels in deze afbeeldingen zijn niet afgebeeld in dezelfde schaal als de tegels afgebeeld in andere secties.

Walls Floors Internal

78

B O D E C I A

Bodecia

A chic wall tile that has all the looks of a cross-cut travertine

Create a feeling of calm and tranquillity with this attractive stone effect wall tile.

Bodecia Beige Rectified Gloss Ceramic

CS779-6030 • 600 x 300 x 10.2mm

Weight: 19.6kg per m 2

Walls Internal

Bodecia CS779-6030

80

LY O N B E I G E

Hard wearing and beautiful – a winning combination

Lyon Beige, a limestoneeffect polished porcelain has excellent wear rating properties. It is suitable both for homes and even the most demanding of commercial locations.

Wall: Lyon Beige CS373-3060

Floor: Lyon Beige CS373-6060

Lyon Beige

82

S T R A S B O U R G C R E A M ,

S U N L I G H T A N D

S T O N E E F F E C T

Floor: Polished Sunlight CS386-4545

Wall: Ebro Beveled tiles from the Glassworks range

Soft Limestone CS591-6030

Sleek finishes and effects of stone for an understated look

Limestone-effect Strasbourg Cream is stunning in bathrooms and kitchens;

Sunlight is dazzling in both natural and polished finishes, as a hard wearing full bodied porcelain for both walls and floors. Soft Limestone is an outstanding stone effect wall tile with a soft sheen, and Maison Beige (shown overleaf) has a soft satin marble effect.

Strasbourg Cream,

Sunlight and

Stone Effect

Wall: Strasbourg Cream CS298-6030 shown with Mellow Mosaics from the Mosaics range

Floor: Strasbourg Cream CS298-6060

84

P R O D U C T

I N F O R M A T I O N

Lyon Beige,

Strasbourg Cream and Sunlight

Lyon Beige Rectified Double Loaded

Polished Porcelain

CS373-3060 • 600 x 300 x 10mm

CS373-6060 • 600 x 600 x 10mm

Wear Rating: ISO 10545-6 (<175mm 3

Weight: 22.9kg per m

2

)

Strasbourg Cream Rectified Double

Loaded Polished Porcelain

CS298-3030 • 300 x 300 x 10mm

CS298-6030 • 600 x 300 x 10mm

CS298-6060 • 600 x 600 x 10mm

Wear Rating: ISO 10545-6 (<175mm

3

)

Weight: 22.9kg per m

2

Polished Sunlight Rectified Full

Bodied Porcelain

CS386-4545 • 450 x 450 x 8mm

Wear Rating: ISO 10545-6 (<175mm

3

)

Weight: 19.9kg per m

2

Natural Sunlight Rectified Full

Bodied Porcelain

CS385-4545 • 450 x 450 x 8mm

Wear Rating: ISO 10545-6 (<175mm

3

)

Weight: 19.9kg per m

2

Stone Effect

Walls Floors Internal

Soft Limestone Rectified Ceramic

CS591-6030 • 600 x 300 x 10mm

Weight: 18.0kg per m 2

Walls Internal

Maison Beige Rectified Ceramic

CS723-6030 • 600 x 300 x 10mm

Weight: xx.xkg per m 2

Milan

Milan White Rectified Ceramic

CS375-3060 • 600 x 300 x 11mm

Weight: 19.4kg per m 2

CS375-9030 • 900 x 300 x 13mm

Weight: 24.9kg per m

2

Milan Sky Rectified Ceramic

CS376-3060 • 600 x 300 x 11mm

Weight: 19.4kg per m 2

Milan Beige Rectified Ceramic

CS374-3060 • 600 x 300 x 11mm

Weight: 19.4kg per m 2

Milan Sky CS376-3060

Chic Milan offers a wall tile with a deep glassy pinstripe glaze in White, Sky, Beige and Mocha.

Milan Mocha Rectified Ceramic

CS377-3060 • 600 x 300 x 11mm

Weight: 19.4kg per m 2

Please note, because of their size, these tiles are not in proportion to reference images of tiles in other sections.

Merci de noter qu’en raison de leur taille ces carreaux ne sont pas en proportion avec les autres images dans les autres sections.

Es ist zu merken, daß diese Fliesen in keinem Verhältniss zu der Abbildungen von Fliesen in anderer Ausschnitten stehen.

De tegels in deze afbeeldingen zijn niet afgebeeld in dezelfde schaal als de tegels afgebeeld in andere secties.

Walls Internal

85

P R O D U C T

I N F O R M A T I O N

86

M A T E R I A

Materia

A high specification tile for high volume footfall

Materia, a full bodied and rectified porcelain, has a cement-like finish and is superbly suited to large area commercial applications.

Materia Cement Rectified

Full Bodied Porcelain

CS726-6060 • 600 x 600 x 10mm

Wear Rating: ISO 10545-6 (<175mm

3

)

Weight: 22.9kg per m 2

Walls Floors Internal

Materia Cement CS726-6060

Africa

Smart and hard wearing for residential and commercial applications

Matt and polished finishes in

600 x 600mm and 600 x 300mm sizes, these rectified full bodied porcelains are also durable enough to be placed in high footfall commercial areas. Modern colours are soft and subtle enough for residential settings, too.

Wall: Durban White Polished CS771-6030, Cape Town Grey Polished CS773-6030

Floor: Durban White Matt CS772-6060

89

P R O D U C T

I N F O R M A T I O N

Africa rectified full bodied porcelain

Durban White Matt

CS772-6030 • 600 x 300 x 10mm

CS772-6060 • 600 x 600 x 10mm

Wear Rating: ISO 10545-6 (<175mm

3

)

Weight: 22.0kg per m

2

Durban White Polished

CS771-6030 • 600 x 300 x 9mm

CS771-6060 • 600 x 600 x 9mm

Wear Rating: ISO 10545-6 (<175mm

3

)

Weight: 22.0kg per m

2

Cape Town Grey Matt

CS774-6030 • 600 x 300 x 10mm

CS774-6060 • 600 x 600 x 10mm

Wear Rating: ISO 10545-6 (<175mm

3

)

Weight: 22.0kg per m 2

Cape Town Grey Polished

CS773-6030 • 600 x 300 x 9mm

CS773-6060 • 600 x 600 x 9mm

Wear Rating: ISO 10545-6 (<175mm

3

)

Weight: 22.0kg per m 2

Pretoria Anthracite Matt

CS776-6030 • 600 x 300 x 10mm

CS776-6060 • 600 x 600 x 10mm

Wear Rating: ISO 10545-6 (<175mm

3

)

Weight: 22.0kg per m 2

Pretoria Anthracite Polished

CS775-6030 • 600 x 300 x 9mm

CS775-6060 • 600 x 600 x 9mm

Wear Rating: ISO 10545-6 (<175mm

3

)

Weight: 22.0kg per m 2

Please note, because of their size, these tiles are not in proportion to reference images of tiles in other sections.

Merci de noter qu’en raison de leur taille ces carreaux ne sont pas en proportion avec les autres images dans les autres sections.

Es ist zu merken, daß diese Fliesen in keinem Verhältniss zu der Abbildungen von Fliesen in anderer Ausschnitten stehen.

De tegels in deze afbeeldingen zijn niet afgebeeld in dezelfde schaal als de tegels afgebeeld in andere secties.

Walls Floors Internal

90

M O D E R N

C O L L E C T I O N A N D

N E W A G E W H I T E

New Age Off White CS725-6030 shown with

Chenab clear glass tiles from the Glassworks range

Wall above shelf: Modern Off White Flow CS757-6030

Modern Collection and New Age White

These whites and pastels are infinitely versatile and will go anywhere

There’s always a need for a classic white tile, and here you have a choice of sizes. The Modern Collection has a subtle undulating texture for interest.

See overleaf for more white tile options.

Modern Off White Flow Ceramic

CS757-6030 • 600 x 300 x 10mm

Weight: 17.2kg per m

2

Modern Pastel Flow Ceramic

CS758-6030 • 600 x 300 x 10mm

Weight: 17.2kg per m

2

Modern Argento Flow Ceramic

CS760-6030 • 600 x 300 x 10mm

Weight: 17.2kg per m

2

Modern Portland Flow Ceramic

CS759-6030 • 600 x 300 x 10mm

Weight: 17.2kg per m

2

New Age Off White Rectified Glazed Porcelain

CS725-4545 • 450 x 450 x 8mm

CS725-6030 • 600 x 300 x 10mm

CS725-6060 • 600 x 600 x 10mm

Wear Rating: ISO 10545-6 (<175mm

3

)

Weight: 20.3kg per m

2

Please note, because of their size, these tiles are not in proportion to reference images of tiles in other sections.

Merci de noter qu’en raison de leur taille ces carreaux ne sont pas en proportion avec les autres images dans les autres sections.

Es ist zu merken, daß diese Fliesen in keinem Verhältniss zu der Abbildungen von Fliesen in anderer Ausschnitten stehen.

De tegels in deze afbeeldingen zijn niet afgebeeld in dezelfde schaal als de tegels afgebeeld in andere secties.

91

P R O D U C T

I N F O R M A T I O N

Classic Whites

A collection of white ceramic wall tiles in different sizes and thicknesses, and two finishes.

Baltic White CS536-9030

Ice White Rectified Gloss Glazed Ceramic

CS534-6030 • 600 x 300 x 11mm

CS777-6030 • 600 x 300 x 10.2mm

Weight: 18.8kg per m 2

CS431-3060 • 600 x 300 x 10.5mm

Weight: 19.7kg per m

2

Ice White Rectified Matt Glazed Ceramic

CS535-6030 • 600 x 300 x 11mm

CS778-6030 • 600 x 300 x 10.2mm

Weight: 18.8kg per m 2

Baltic White Rectified Gloss Glazed Ceramic

CS536-9030 • 900 x 300 x 12mm

CS780-9030 • 900 x 300 x 11.2mm

Weight: 22.4kg per m

2

Classic White Rectified Gloss Glazed Ceramic

CS397-3040 • 400 x 300 x 9mm

Weight: 16.1kg per m

2

Please note, because of their size, these tiles are not in proportion to reference images of tiles in other sections.

Merci de noter qu’en raison de leur taille ces carreaux ne sont pas en proportion avec les autres images dans les autres sections.

Es ist zu merken, daß diese Fliesen in keinem Verhältniss zu der Abbildungen von Fliesen in anderer Ausschnitten stehen.

De tegels in deze afbeeldingen zijn niet afgebeeld in dezelfde schaal als de tegels afgebeeld in andere secties.

Walls Internal

93

I M P O R T A N T

I N F O R M A T I O N

Tile area calculator

Calculateur de surface de carrelage / Rechner für Fliesenfläche / Rekenhulpmiddel voor te betegelen ondergronden

Nominal size*

Tiles / Carreaux / Fliesen / Tegels

65 x 230

100 x 100

150 x 900

200 x 1200

250 x 250

250 x 500

287 x 295

300 x 300

300 x 400

300 x 600

Per m

66.89

100.0

7.41

4.17

16

8

11.81

8.3333

5.556

2

11.1111

Nominal size*

Tiles / Carreaux / Fliesen / Tegels

300 x 900

400 x 400

400 x 800

440 x 440

450 x 450

450 x 900

500 x 500

600 x 600

900 x 900

Per m

3.7037

6.25

3.125

5.16

4.94

2.47

4

2.78

1.23

2

*All of the above dimensions are subject to a tolerance of ± 2.5mm or 3/32”. Quantities shown exclude grout gaps between each tile. Please allow an additional 5% for cutting/wastage.

*Remarque : Toutes les dimensions précédentes sont sujettes à une tolérance de ± 2,5 mm. Les quantités démontrées n’incluent pas les joints entre les carreaux. Nous vous recommandons de prévoir au moins 5% supplémentaires pour les chutes.

*Beachten Sie bitte: Alle oben genannten Abmessungen können Abweichungen von ± 2.5mm aufweisen. Angegebene Mengen schliessen die Fugen zwischen jeder Fliese aus. Es empfiehlt sich, mindestens 5% material für etwaiger Bruch einzuplanen.

*Voor alle afmetingen geldt een tolerantiewaarde van ± 2.5mm. Voeg openingen tussen tegels zijn niet meegerekend in de aangegeven hoeveelheden. Houd rekening met vijf procent snijverlies.

WEAR RATINGS FOR GLAZED PORCELAINS AND CERAMICS, IN LINE WITH ISO 10545-7

Taux d’usure pour les Porcelaines Emaillées et les Céramiques, selon la norme ISO 10545-7 / Verschleißwerte für glasiertes Feinsteinzeug und Keramik, nach ISO 10545-7 / Slijtageclassificatie voor geglazuurd porselein en keramiek, in overeenstemming met ISO 10545-7

2 Floor coverings in areas that are walked on by soft soled or normal footwear with low traffic and occasional scratching / Revêtements pour les sols sur lesquels on marche avec des chaussures aux semelles souples ou normales, où le passage est faible et où le risque de rayures est peu élevé / Bodenbeläge für Bereiche, die mit weich besohlten oder normalen Schuhen betreten werden. Geringer Durchgangsverkehr, gelegentliche Kratzer / Vloeroppervlak op plaatsen met licht verkeer en incidentele krassen waar men op loopt met schoenen met zachte zolen of normale schoenen

3 Floor coverings in areas that, with normal footwear, are walked on more often with small amounts of scratching and dirt. Suitable for residential kitchens, halls and corridors / Revêtements pour les sols sur lesquels le passage avec des chaussures normales est plus fréquent, et où rayures et salissures sont légères.

Convient aux cuisines, aux halls et aux couloirs domestiques / Bodenbeläge für Bereiche, die mit normalem Schuhwerk betreten werden. Geringe Kratzer und

Verschmutzungen. Geeignet für Wohnküchen, Flure und Dielen / Vloeroppervlak op plaatsen waar men, met normale schoenen, vaker loopt met kleine hoeveelheden vuil en krassen. Geschikt voor huishoudelijke keukens, hallen en gangen

4 Floor coverings that are walked on by regular traffic with some scratching dirt. Suitable for entrances, commercial kitchens etc / Revêtements pour les sols sur lesquels le passage est régulier avec salissures et rayures. Convient aux entrées, aux cuisines commerciales, etc / Bodenbeläge für Bereiche mit regelmäßigem

Durchgang und gewissen Kratzverschmutzungen. Geeignet für Eingänge, Großküchen etc / Vloeroppervlak op plaatsen waar regelmatig op wordt gelopen met wat krassend vuil. Geschikt voor ingangen, commerciële keukens, enz

5 Floor coverings that are subject to severe pedestrian traffic over sustained periods with some scratching dirt. Suitable for shopping centres, airport concourses, hotel foyers etc / Revêtements pour les sols sur lesquels le passage est intense sur de longues périodes, avec salissures et rayures. Convient aux centres commerciaux, aux halls d’aéroport, aux réceptions d’hôtels, etc. / Bodenbeläge für Bereiche mit starkem Fußgängerverkehr über längere Zeiträume mit gewissen

Kratzverschmutzungen. Geeignet für Einkaufszentren, Flughafengebäude, Empfangshallen etc / Vloeroppervlak op plaatsen die worden blootgesteld aan een grote hoeveelheid voetgangers gedurende langere perioden met krassend vuil. Geschikt voor winkelcentra, luchthavenhallen, hotelfoyers, enz

WEAR RATING: FOR UNGLAZED PORCELAINS AND CERAMICS, IN LINE WITH ISO 10545-6

ISO 10545-6 (<175mm 3 )

Passes current tests for deep abrasion in line with ISO 10545-6 / French here / German / Dutch here

Pendulum Test BS7976-2 (4S96)

Certain tiles have been rated for their Pendulum Test Value (PTV) a test for slip potential in the wet. Low potential for slip rating is between 35-64W.

External use

All our porcelain tiles have passed the ISO 10545-12 frost resistance test, making them suitable for external use. We recommend that only tiles with PTVW slip resistance results of 36+ are used in external situations. Original Style Ltd cannot be held liable for cracking that can occur due to adverse weather conditions or poor installation.

Key to symbols

Légende des symbols / Legende der Symbole / Uitleg van symbolen

Suitable for walls

convient aux poses murales / Geeignet für Wände / Geschikt voor muren

Suitable for floors

convient aux poses sur plancher / Geeignet für Böden / Geschikt voor vloeren

Internal

utisation intérieure uniqument / Nur zur Verwendung im Innenbereich / Alleen voor gebruik binnen

94

I M P O R T A N T

I N F O R M A T I O N

Important information Informations essentielles

NOMINAL DIMENSIONS

We quote nominal dimensions throughout this brochure which are subject to slight variation within internationally accepted standards.

SHADE VARIATION

Shade variation is an inherent feature of Tileworks porcelain and ceramic tiles.

We recommend that tiles are loosely laid out and ‘blended’ prior to fixing to achieve the most pleasing distribution of shades. Differences between batches can be more marked, for this reason we recommend that you buy all the tiles at one time. No liability for shading issues can be accepted after installation.

ADHESIVES AND GROUTS

Always use high quality adhesives and grouts following manufacturers’ recommendations for their use and suitability for the type of tile, the application and the substrate being tiled.

SEALING

As with any polished surface, polished porcelain is susceptible to staining if it is not protected with an appropriate sealer such as LTP MPG Sealer. We recommend that all of our polished porcelains are treated with an appropriate product. Always follow the manufacturer’s instructions.

Dream Beige CS523-4040, CS523-6030, CS523-6060, page 66: Some batches of this polished porcelain may have been treated with a nano coating after manufacture, which means they do not need to be sealed. Please refer to our Fixing Guide at www.originalstyle.com/fixing-html for full details of how to test for the nano coating and subsequent sealing procedure.

Zelo Slimline CS802-8040, CS803-8040, CS804-8040, CS805-8040, page

50: Although they have a thickness of only 5mm, Zelo Slimline tiles conform to the standards for impact resistance tests: BS EN ISO 10545-5: Average Coefficient of Restitution 0.85 (impact resistance with no damage caused through test). The application of the tiles must be a solid bed method with no voids behind the tiles and all expansion joints must be followed and uncoupling systems set in place if required.

INSTALLATION, ADHESIVES, GROUTS, SEALANTS, CLEANING

AND MAINTENANCE

Please refer to our Fixing Guide at www.originalstyle.com/fixing-html before commencing any installations as Original Style cannot accept responsibility for any faults after tiles have been fixed. Original Style will not be held liable for any claims regarding the inappropriate use of sealing, adhesives or grouting materials.

For technical queries, please contact our technical department at [email protected]

PHOTOGRAPHY

Owing to variations in studio lighting and printing inks, the tile colours shown in this catalogue may differ slightly from those of the actual tiles.

LIMITS OF LIABILITY

Original Style accepts no liability for the faulty installation of its products. In the case of any claim relating to the tiles themselves, Original Style’s liability, to the extent permitted by law, is limited to either the replacement of the product or a refund of the cost of the product, and does not extend to cover any consequential loss.

Claims must be reported within seven working days from receipt of the tiles. Tiles must be inspected prior to installation and claims cannot be considered after the tiles have been installed. Please be advised that installation constitutes acceptance of the quality, size, colour, texture and shade of the tiles. Original Style warrants that its tiles conform to their description and are fit for their purpose.

Original Style makes no other express or implied warranty as to fitness or suitability of the products for particular installations. We extend no guarantees, express or implied, as to wear resistance or maintenance procedures.

It is imperative to follow sealer, grout and adhesive manufacturers’ instructions regarding their suitability with our products. If in doubt please consult the sealant/grout/adhesive stockist from whom you purchased the products.

Original Style makes no representations as to the fitness for purpose of third party sealants, adhesives and grouts.

Please note the use of certain acid based cleaning products may cause some of the tiles to react and change in character.

Original Style gratefully acknowledges the assistance of the following companies with the photographic settings:

Amos Lighting

Debenhams

Furniture Village

Gazco

House of Fraser

John Lewis

Orange Tree

Samuel Heath

Stovax

Totnes Tile Studio

UKBW www.amoslighting.co.uk

www.debenhams.com

www.furniturevillage.co.uk

www.gazco.com

www.houseoffraser.co.uk

www.johnlewis.com

www.theorangetree.co.uk

www.samuelheath.co.uk

www.stovax.com

tel +44 (0)1803 865865 www.ukbw.com

DIMENSIONS NOMINALES

Les dimensions indiquées dans cette brochure correspondent aux dimensions nominales, qui sont sujettes à de légères variations dans les limites des normes internationalement admises.

NUANCES DE TEINTE

Les nuances de teinte sont une caractéristique inhérente. Tileworks porcelain and ceramic tiles. Nous vous conseillons de positionner et d’assortir les carreaux avant de les cimenter afin d’obtenir la meilleure distribution possible des nuances. Les différences peuvent être plus flagrantes entre les lots; pour cette raison, nous vous recommandons d’acheter l’ensemble de vos carreaux en même temps. Une fois la pose réalisée, tout problème lié aux nuances de teinte ne saurait donner lieu à réclamation.

COLLES ET MORTIERS

Utilisez systématiquement des colles et mortiers de haute qualité, en respectant les recommandations des fabricants en termes d’utilisation et de convenance vis-

à-vis du type de carrelage, du mode d’application et de la surface à carreler.

SEALING

As with any polished surface, polished porcelain is susceptible to staining if it is not protected with an appropriate sealer such as LTP MPG Sealer. We recommend that all of our polished porcelains are treated with an appropriate product. Always follow the manufacturer’s instructions.

Dream Beige CS523-4040, CS523-6030, CS523-6060, page 66: Some batches of this polished porcelain may have been treated with a nano coating after manufacture, which means they do not need to be sealed. Please refer to our Fixing Guide at www.originalstyle.com/fixing-html for full details of how to test for the nano coating and subsequent sealing procedure.

Zelo Slimline CS802-8040, CS803-8040, CS804-8040, CS805-8040, page

50: Although they have a thickness of only 5mm, Zelo Slimline tiles conform to the standards for impact resistance tests: BS EN ISO 10545-5: Average

Coefficient of Restitution 0.85 (impact resistance with no damage caused through test). The application of the tiles must be a solid bed method with no voids behind the tiles and all expansion joints must be followed and uncoupling systems set in place if required.

INSTALLATION, ADHESIFS, JOINTS, NETTOYAGE ET ENTRETIEN

Merci de vous reporter au guide d’installation sur www.originalstyle.com/fixing-html avant de commencer l’installation de votre carrelage Original Style car nous ne pouvons accepter la responsabilité pour les défauts une fois l’installation faite. Original Style will not be held liable for any claims regarding the inappropriate use of sealing, adhesives or grouting materials.

For technical queries, please contact our technical department at [email protected]

PHOTOGRAPHIES

En raison des variations au niveau de l’éclairage du studio et des encres d’impression, les couleurs affichées dans ce catalogue sont susceptibles d’être légèrement différentes de celles des carreaux réels.

LIMITATION DE RESPONSABILITE

Original Style dégage toute responsabilité en cas d’installation incorrecte de ses produits. En cas de réclamation relative aux carreaux eux-mêmes, la responsabilité d’Original Style sera confinée, dans la limite autorisée par la loi, au remplacement du produit ou au remboursement du prix du produit, et ne couvre pas les dommages indirects. Toute réclamation doit être effectuée dans les sept jours suivant la reception des carreaux. Les carreaux doivent

être inspectés avant installation. Aucune réclamation ne sera prise en compte une fois les carreaux installés. Notez que l’installation du carrelage constitue l’acceptation de la qualité, de la couleur, de la texture, de la taille et de la teinte des carreaux. Original Style garantit que ses carreaux sont conformes au descriptif fourni et qu’ils sont adaptés à l’usage pour lequel ils sont prévus.

Original Style ne formule aucune garantie expresse ou implicite supplémentaire vis-à-vis de l’adéquation ou de la compatibilité de ses produits dans des installations spécifiques. Nous ne formulons aucune garantie, expresse ou implicite, vis-à-vis de la résistance à l’usure ou des procédures d’entretien.

Il est impératif de suivre les instructions des fabricants de colles et de cimentsjoints afin d’en vérifier la compatibilité avec nos produits. En cas de doute, consultez le revendeur qui vous aura fourni la colle ou le ciment-joint. Original

Style n’assumera aucune responsabilité en ce qui concerne la compatibilité ou l’usage de colles et de ciments-joints tiers. Veuillez noter que l’utilisation de certains produits nettoyants à base d’acide peut provoquer des réactions sur certains carreaux et en modifier les caractéristiques.

Wichtige informationen Belangrijke infomatie

NENNMASSE

In dieser Broschüre werden Nennmaße angegeben die innerhalb internationaler gültigen Standards leicht veränderlich sind.

VARIATIONEN DES FARBTONS

Bedingt durch den Herstellungsprozess entstehen geringfügige

Farbvariationen. Wir empfehlen, die Fliesen vor dem Verkleben lose zu verlegen und dann zu “mischen”, um die angenehmste Verteilung der

Farbtöne zu erreichen. Unterschiede zwischen mehreren Chargen können ausgeprägter sein, daher empfehlen wir Ihnen, alle Fliesen auf einmal zu kaufen. Nach der Verlegung der Fliesen kann keinerlei Haftung für Probleme mit dem Farbton mehr übernommen werden.

KLEBER & FUGENMÖRTEL

Verwenden Sie immer qualitativ hochwertige Kleber und Fugenmörtel und befolgen Sie die Herstelleranweisungen in Bezug auf deren Verwendung und

Eignung für die Fliesenart, die Anwendung und den zu fliesenden Untergrund.

SEALING

As with any polished surface, polished porcelain is susceptible to staining if it is not protected with an appropriate sealer such as LTP MPG Sealer. We recommend that all of our polished porcelains are treated with an appropriate product. Always follow the manufacturer’s instructions.

Dream Beige CS523-4040, CS523-6030, CS523-6060, page 66: Some batches of this polished porcelain may have been treated with a nano coating after manufacture, which means they do not need to be sealed. Please refer to our Fixing Guide at www.originalstyle.com/fixing-html for full details of how to test for the nano coating and subsequent sealing procedure.

Zelo Slimline CS802-8040, CS803-8040, CS804-8040, CS805-8040, page

50: Although they have a thickness of only 5mm, Zelo Slimline tiles conform to the standards for impact resistance tests: BS EN ISO 10545-5: Average

Coefficient of Restitution 0.85 (impact resistance with no damage caused through test). The application of the tiles must be a solid bed method with no voids behind the tiles and all expansion joints must be followed and uncoupling systems set in place if required.

INSTALLATION, KLEBER, FUGENMÖRTEL, REINIGUNG UND PFLEGE

Bitte lesen Sie vor Beginn der Installation die Installationsanleitung unter www.

originalstyle.com/fixing-html, da Original Style keine Haftung für Fehler

übernehmen kann, nachdem die Fliesen befestigt wurden. Original Style will not be held liable for any claims regarding the inappropriate use of sealing, adhesives or grouting materials.

PHOTOGRAPHIE

Aufgrund variierender Beleuchtungsverhältnisse im Studio oder bei Druckfarben können die im Katalog zu sehenden Farben geringfügig von der tatsächlichen

Farbgebung abweichen. Bevor Sie Ihre Auswahl treffen, sollten Sie immer zuvor einen Einzelhändler für Original Style nach Mustern fragen.

HAFTUNGSBESCHRÄNKUNG

Original Style übernimmt für die fehlerhafte Installation seiner Fliesen keine

Haftung. Sollte es Reklamationen bezüglich der Fliesen selbst geben, dann beschränkt sich die gesetzlich eingeräumte Haftung von Original Style lediglich auf den Artikelaustausch oder Kostenrückerstattung. Weitere Schäden warden nicht abgedeckt. Vor der Installation sind die Fliesen zu prüfen. Nachträgliche

Reklamationen können nicht berücksichtigt werden.

Bitte beachten Sie, dass Sie durch die Installation anzeigen, dass hinsichtlich

Qualität, Farbgebung, Textur, Größe oder Schattierung keine Beanstandungen vorliegen. Original Style gewährleistet die beschreibungs- und zweckgemäße

Fabrikationsausführung der Fliesen.

Original Style gibt keine weiteren ausdrücklichen oder impliziten Garantien hinsichtlich Eignung der Artikel für besondere Installationsarten. Wir geben weder ausdrücklich noch implizit eine Garantieverlängerung auf

Abnutzungsverhalten oder Wartungsarbeiten. Beachten Sie bitte, dass die

Fliesen auf Säure basierte Reinigungsmittel reagieren und ihr Aussehen verändern können.

NOMINALE AFMETINGEN

Tegelafmetingen kunnen enigszins afwijken van de nominale afmetingen binnen internationaal geaccepteerde standaarden.

LIJMEN EN VOEGMIDDELEN

Gebruik altijd lijm en voegmiddel van hoge kwaliteit en volg de richtlijnen van de producenten op inzake gebruik en geschiktheid voor het type tegel, het aanbrengen en de ondergrond die wordt betegeld.

SEALING

As with any polished surface, polished porcelain is susceptible to staining if it is not protected with an appropriate sealer such as LTP MPG Sealer. We recommend that all of our polished porcelains are treated with an appropriate product. Always follow the manufacturer’s instructions.

Dream Beige CS523-4040, CS523-6030, CS523-6060, page 66: Some batches of this polished porcelain may have been treated with a nano coating after manufacture, which means they do not need to be sealed. Please refer to our Fixing Guide at www.originalstyle.com/fixing-html for full details of how to test for the nano coating and subsequent sealing procedure.

Zelo Slimline CS802-8040, CS803-8040, CS804-8040, CS805-8040, page

50: Although they have a thickness of only 5mm, Zelo Slimline tiles conform to the standards for impact resistance tests: BS EN ISO 10545-5: Average

Coefficient of Restitution 0.85 (impact resistance with no damage caused through test). The application of the tiles must be a solid bed method with no voids behind the tiles and all expansion joints must be followed and uncoupling systems set in place if required.

INSTALLATIE, LIJMEN, VOEGMIDDELEN, REINIGING

EN ONDERHOUD

Raadpleeg de installatiegids op www.originalstyle.com/fixing-html voordat u begint met het leggen, aangezien Original Style niet verantwoordelijk is voor defecten nadat de tegels zijn gezet. Original Style will not be held liable for any claims regarding the inappropriate use of sealing, adhesives or grouting materials.

FOTOGRAFIE

Als gevolg van variaties in studiobelichting en printinkten kunnen de in deze brochure afgebeelde kleuren enigszins afwijken van die van de daadwerkelijke tegels. We raden altijd aan dat u uw Original Style-leverancier vraagt om enkele voorbeelden.

AANSPRAKELIJKHEIDSBEPERKING

Original Style is niet aansprakelijk voor de verkeerde installatie van zijn producten. In geval van claims met betrekking tot de tegels zelf is de aansprakelijkheid van Original Style, voor zover dit wettelijk is toegestaan, beperkt tot het vervangen van het product of het vergoeden van de kosten van het product, en is gevolgschade niet inbegrepen. Claims moeten binnen zeven werkdagen na ontvangst van de tegels worden ingediend. De tegels moeten worden geïnspecteerd voordat deze worden gezet. Claims worden niet behandeld nadat de tegels zijn gezet. We wijzen u erop dat tot de zetting het aanvaarden van de hoeveelheid, kleur, structuur, afmetingen en schakering van de tegels behoort.

Original Style garandeert dat zijn tegels overeenkomen met hun omschrijving en geschikt zijn voor het beoogde gebruik. Original Style maakt geen andere uitdrukkelijke of impliciete garanties met betrekking tot de geschiktheid van de producten voor bepaalde installaties. We maken geen garanties, uitdrukkelijk of impliciet, ten aanzien van slijtagebestendigheid of onderhoudsmaatregelen.

Het is van groot belang dat de instructies van de producent voor voeg- en lijmmiddelen worden opgevolgd ten aanzien van hun geschiktheid in combinatie met onze producten. Raadpleeg de leverancier van de voeg- en lijmmiddelen van wie u de producten hebt gekocht in geval van twijfel. Original

Style maakt geen beweringen over de geschiktheid voor gebruik van de lijmen en voegmiddelen van derde partijen. We wijzen u erop dat het gebruik van bepaalde bijtende reinigingsmiddelen kan leiden toteen reactie van de tegels, waarvan het uiterlijk kan veranderen.

95

I M P O R T A N T

I N F O R M A T I O N

G L A S S W O R K S

A r t w o r k s

POP ART

Original Style also produce other ranges of ceramic tiles, natural stone, Mosaics and Victorian floor tiles. Please ask your retailer for copies of these brochures. Please return this brochure to your Original Style stockist after use.

The ‘Original Style’ logo is a registered trade mark of Original Style Ltd.

Original Style Limited is registered in England number 3018117. Registered Office:

Falcon Road, Sowton Industrial Estate, Exeter, Devon EX2 7LF, England

Your Original Style stockist £2.00 €3.00 $3.50

TWORKS3/4/12

GENERAL ENQUIRIES

Tel: +44 (0)1392 473004

Fax: +44 (0)1392 473014

UK SALES

Tel: +44 (0)1392 473000

Fax: +44 (0)1392 473010

EXPORT SALES

Tel: +44 1392 473001

Fax: +44 1392 473011

Email:

[email protected]

Website:

www.originalstyle.com

© Copyright Original Style Ltd 2012

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Related manuals

Download PDF

advertisement
