UCM6100 series Video Features

UCM6100 series Video Features

UCM6100 series Video Features

Agenda

1. UCM6100 series Overview and Video Overview

2. Video Calling with the UCM6100 series

3. Integrating Video Surveillance

4. Integrating Video Conferencing Solutions

5. Integrating IP Door Cameras

Delivering Voice, Video, Data & Mobility to SMBs

UCM6100 series IP PBX Appliance

UCM6100 series IP PBX Appliance

UCM6102

UCM6104

UCM6108

UCM6116

Asterisk is a Registered Trademark of Digium

UCM6100 series

Delivering high quality, secure and reliable voice, video, data & mobility for SMBs

Enterprise-grade features in an affordable, compact & easy-to-manage PBX designed specifically for the SMB market

No licensing fees

Fast and easy setup & management

ALL hardware/software included as well as lifetime firmware updates

Voice

Secure, clear, and reliable

Conferencing

Comprehensive Codec Support

Endless Customizable Voice features

Data

Phonebook files

CDR

Codec Transcoding

System Backup

Call Recording

Voicemail/fax to email

Mobility

Softphone apps

Monitor your business

Connect Multiple Offices

Video

Face to face video calls

Video Surveillance Integration

SIP Video

Video Codec Support

UCM6100 series - General Specifications

Up to 500 extensions

# of FXO ports & concurrent calls:

2 - 30 (UCM6102)

4 - 45 (UCM6104)

8 - 60 (UCM6108)

16 - 60 (UCM6116)

Gigabit ports with PoE Plus

Each bridge supports up to

25 (UCM6102 & UCM6104) or

32 (UCM6108 & UCM6116) conference attendees

Zero-configuration provisioning

Simple setup/management with

Web UI

Asterisk is a Registered Trademark of Digium

Easiest Possible Setup…

Asterisk is a Registered Trademark of Digium

Zero Configuration

Auto-Discovery of SIP endpoints

Auto-Provision of SIP endpoints

Zero Config can be managed remotely

UCM6100 series – Full SIP Video Support

UCM6100 Series -

Video

Delivering high quality, secure and reliable video communications

Full SIP Video Support

Any SIP video endpoint, such as

Video Phones

Video Conferencing Solutions

Door/Facility Access Cameras/Modules

IP Video Surveillance cameras

Video Features

UCM6100 series -

Video

Delivering high quality, secure and reliable video communications

Supports all major video codecs

H.263

H.263+

H.264

UCM6100 series-

Video Calling

Delivering high quality, secure and reliable video communications

Video Features

UCM6100 series -

Video

Delivering high quality, secure and reliable video communications

Video Calling

Video calling from video-enabled endpoint to video enabled endpoint automatically supported with no action needed

UCM6100 series can transcode video codecs if needed

UCM6100 series-

Video Surveillance

Delivering high quality, secure and reliable video communications

Video Features

UCM6100 series-

Video

Delivering high quality, secure and reliable video communications

Video Surveillance Integration

Create a comprehensive solution to view, monitor and receive alerts from IP cameras

Register IP cameras to the PBX

Make video calls to IP cameras to view live feeds

Speak through cameras with 2-way audio & video (door entry)

IP cameras can be set to automatically call video phone when alert is triggered

Receive alerts from anywhere in the world

Cameras are Registered to the IP PBX the same way as any Endpoint

Integrate Surveillance with Your IP PBX

Make it a Solution…

Register Grandstream’s SIP cameras to an IP PBX

Ext. 301

Ext. 501

Ext. 601

Ext. 101

Ext. 102

Ext. 303

Ext. 201

• Make video calls to IP cameras to see live feeds

• Set cameras to call video device (IP Video phones) when alert/alarm is triggered

• Cameras can send you an email or screen capture

• To communicate with IP Door Cameras, etc.

• 2-way video/audio calls to/from cameras thanks to

SIP/VoIP support

GXV3601 series, GXV3610 series, GXV3611_HD and GXV3615 series feature built-in microphone and speaker

Advantage 1: Integrated Solution under One Network

Unified Communications: One Integrated Network Solution

All Grandstream phone, cameras, and UCM6100 series are SIP-based devices

A true Unified Communications solution offering voice, video, data and mobility features

All devices can be easily setup, customized and managed from one central location

Add functionality to devices by combining them onto the same network

Even add/include analog phones and analog cameras

Advantage 2: Communicate with Any SIP Camera on Any Network

Communicate With Cameras on Any Network

Internet

UCM6100 Series

Camera’s can send alerts or be contacted from outside networks thanks to their SIP registration when registered to an IP PBX

You set the phone number the cameras contact when an alert is triggered

With a SIP registration, any IP camera is given a phone number/IP address that can be called to view the camera’s live feed

View camera’s live feed from any device that has an internet connection

Integrating Surveillance with Your IP PBX

1. Receive video calls from cameras whenever alerts/alarms are triggered

2. Make video calls to cameras to see the live feed

Receiving Alerts from Cameras

Video Surveillance Alerts

1. Browser/GSurf Live

View

When an alarm is triggered, the Live View will notify user using pop-up on-screen

2. Video Call to video devices

3. Voice Call Alerts 4. Email Screenshot

When a new object is detected by the camera

Set Up Alarm Actions…

Voice/Video Alerts to SIP Phone

Integrating Surveillance with Your IP PBX

1. Receive video calls from cameras whenever alerts/alarms are triggered

2. Make video calls to cameras to see the live feed

UCM6100 series-

Video Conferencing

Delivering high quality, secure and reliable video communications

Video Features

UCM6100 series –

Video Conferencing

Delivering high quality, secure and reliable video communications

Video Conferencing

Integrate 3 rd

Party SIP-based Video

Conferencing solutions

This also allows conferencing solutions to interact with video phones, video cameras, etc.

UCM6100 series-

IP Door Cameras

Delivering high quality, secure and reliable video communications

Door Access Solution

Turn a Grandstream IP Surveillance Camera into a Door Opener when Paired with a

Grandstream Video Phone

Step 1: Configure the Grandstream Video Phone and the IP Camera

Step 2: Enable Alert Event

Step 3: Connect Doorbell and IP Camera

Step 4: Open Door via Incoming Video Call

Integrating Surveillance and Door Access Solutions with Your IP PBX

1. Visitor can call from door phone to video phone in apartment or office

2. From video phone, user can unlock door using a pre-configured DTMF key

[email protected]

www.grandstream.com
