Ophthalmic diagnostic products

Ophthalmic diagnostic products

11

Ophthalmic diagnostic products

Catalogue 2012

Technology for Life Science

3 Retinal camera

Non-mydriatic

4

nonmyd WX

3D

8

nonmyd 7

9

nonmyd

α-DIII

Retinal camera

Special function

10 VX-10i

11

VX-20

12

Genesis-D

12

Genesis-Df

Software

6

system for

nonmyd WX

7

3D analysis

VK-2

3D

Refraction

13

KA-1000

13

KW-2000

Diagnostic

14

AP-7000

16

KT-800

17

HA-2

Anterior

18

FM-600

19

SL-15

Kowa Optimed –

Ophthalmic diagnostic products

History and experience

Kowa Optimed is part of Kowa Company limited founded in 1894 which achieved to become one of the largest privately owned companies in Japan. The group has four primary divisions among which ethical and OTC pharmaceutical products, optics and medical devices play a large role with research and development facilities, factories and sales offices across Japan, and subsidiaries across the globe.

Kowa Optimed is part of the Electronics and Optics Division of the company. Since its inception in 1946, the Kowa Electronics and Optics Division has combined electronics, mechanical design and optics to create a wide range of significant new technologies.

Since the launch of its first retinal camera in 1962, Kowa has been devoted to producing the most innovative optical products and integrated technology solutions in the world.

The company’s focus on leading edge technology, flexible machine technology, application software and traditional optical technology has produced a wide range of products designed to enhance the visual experience and provide vision solutions and diagnostics for all users.

R&D and manufacturing

The Ophthalmic Diagnostic products are the result of the companies R&D facilities at the company’s state-of-the-art laboratories and factory in Hamamatsu.

Quality and customer care

The Medical Diagnostic Products set clinical standards for diagnosis of a wide range of ophthalmic conditions and have been designed and engineered to provide simple to use solutions for health care professionals allowing for the patient to be put first in the diagnostic process. This means that the Kowa products deliver meaningful clinical results to the highest standards, cost effectively and assist in optimising clinic workflows.

If you would like more information on your local supplier (or servicer) of Kowa’s

Ophthalmic Diagnostic Products or any of Kowa’s wide range of other Life-Science and

Optical Products please contact one of our European offices or visit the Kowa Optimed web site.

All our products are CE-certified

4 Retinal camera

Non-mydriatic

Retinal camera

Special function

Software Refraction Diagnostic Anterior

nonmyd WX

3D

Retinal camera

A non-mydriatic camera combining both standard and stereo retinal imaging

An advanced retinal camera that provides both standard 2D and stereo 3D images whilst maintaining the Kowa traditions of high quality and ease of use. The exclusive optical design combined with the high resolution Nikon® digital camera back delivers extremely detailed images. In 2D mode the camera operates like a standard 45° non-mydriatic camera. The small pupil option enables photography with a pupil size above ø3.5mm. Mosaic photography is a further option using the 9-point fi xation mode. In 3D mode the camera captures a

20°x 27° fi eld of view as a stereo image in one shot. This may be viewed using prism glasses or by using a 3D monitor.

Special features

- 1-shot capture of stereo images

- View the optic nerve in 3D

- Standard 45° images in 2D

- Supports standard

3D monitors

- Small pupil mode

- Mosaic function

- Optional 3D analysis system

Approved by ENSPDR (English National Screening Programme for Diabetic Retinopathy) for diabetic retinopathy screening in the UK

5 Retinal camera

Non-mydriatic

Retinal camera

Special function

Software Refraction Diagnostic Anterior

2D – normal & SP (small pupil)

2D - normal

Normal field angle: 45°

Kowa‘s exclusive optical design in combination with the 12 megapixel digital SLR camera delivers extremely detailed retinal images.

2D - SP (small pupil)

Field angle: 45°

Retinal images can be taken even with smaller pupils. On screen guides indicate if the pupil size is within the sufficient range (above 3.5mm) for photography.

Automatic mosaic merge function

Mosaic images are created easily with automatic image rotation & alignment.

3D – stereo

Options

3D analysis system

The optional digital 3D analysis system provides quantitative analysis of stereo images of the optic nerve including a disc damage likelihood scale (DDLS). see page 6

Photography

Field angle: 34° (20°x 27°)

Instant and simultaneous 3D photography is possible in 1-shot.

Stereoscopic images are captured without the camera shifting.

Stereo viewing

Examine the shape of the optic cup using a standard monitor and prism glasses or with a 3D monitor.

6 Retinal camera

Non-mydriatic

Retinal camera

Special function

Software Refraction Diagnostic Anterior

3D analysis system for nonmyd WX

3D

A sophisticated software analysis tool for use with stereo images from the nonmyd WX

3D

camera. Examine the optic nerve quickly, easily and in far more detail than is possible from a standard 2-dimensional image. This simple to use system provides a detailed quantitative display of optic disc parameters, including the vertical cup to disc ratio, neuro-retinal rim area and rim to disc area along with many others. The rim width in various locations can be compared using the polar coordinates display whilst a disc damage likelihood scale gives a simple numerical estimate of the possibility of glaucomatous damage to the optic nerve.

1

2

1

Depth distribution

Color-coded display of the depth distribution in the analysis area, or graphical display of the cross section of a chosen position.

2

3D display

Display of 3D image based on stereographic data

3

Quantitative optic disc parameters

Display of various optic disc parameters including the “DDLS“ - disk damage likelihood scale; which was suggested by Dr. George L.

Spaeth as a method to diagnose the optic disc using the disc size and rim/disc ratio*

3

4

5

6

4

Polar coordinates display

The polar coordinates display of the depth distribution permits a visual display of the thinnest part of the rim.

5

Contour line depth distribution graph

This provides a graphical display of the depth distribution of the cup and disc profiles.

6

Follow-up

Graphical display of current and historical disc parameters of cup/ disk ratio, rim/disc ratio, cup area and many other parameters to assist to the detection of change.

* References

Validity of a new disk grading scale for estimating glaucomatous damage: correlation with visual field damage.

Bayer A, Harasymowycz P, Henderer JD,

Steinmann WG, Spaeth GL.

Am J Ophthalmol. 2002 Jun;133(6):758-63.

The disc damage likelihood scale: reproducibility of a new method of estimating the amount of optic nerve damage caused by glaucoma. Spaeth GL,

Henderer J, Liu C, Kesen M, Altangerel

U, Bayer A, Katz LJ, Myers J, Rhee D,

Steinmann W.

Trans Am Ophthalmol Soc. 2002;100:181-5

Refraction Diagnostic 7 Retinal camera

Non-mydriatic

Retinal camera

Special function

Software

VK-2

High performance digital imaging software

Anterior

Simple image management at your fingertips

The VK-2 digital imaging software easily captures and stores retinal photographs taken from Kowa retinal cameras well as images from other sources including a scanner. Video inputs via USB or IEEE1394 (Firewire®) are supported with 1-click switching between instruments. Images can be magnified for viewing and filters such as red free are readily available. In ICG and FA mode the patient timer is displayed on screen and multiple timers are available in FA mode for managing several patients. When used in combination with the Kowa perimeter the software allows integrated management of fundus images and perimetry results. A montage function creates panoramic views from multiple fundus images.

Special features

- Store, view and compare images

- Multiple inputs

- Supports the latest high resolution cameras

- Manipulate images with magnification and filters

- Quick and easy networking

- E-mail images direct from the software

- Archive facility

- Integrates with Kowa perimeter

7

Multiple timers

Manage the timer counts for several patients

Detailed database viewer

provides advanced searching, viewing, image processing, printing, and reporting for your VK-2 database.

Link to perimeter

This unique function from Kowa allows total management of fundus

Refraction 8 Retinal camera

Non-mydriatic

Retinal camera

Special function

Software

nonmyd 7

Non-mydriatic retinal

camera

Diagnostic Anterior

A superb and capable tool for colour image acquisition

The nonmyd 7 is a high quality, simple to use digital retinal camera with traditional Kowa reliability. High levels of clinical detail can be captured with the sharp and clear images of the latest Nikon® digital camera. A choice of optical magnifi cations offer the standard

45° view or a 20° view for enhanced detail. All controls are at your fi ngertips for ease of operation – simply align, focus and shoot.

A choice of fi xation modes offers 3 standard positions while the optional external fi xation target allows to freely choose the position on the retina. The industry standard USB interface connects to a desktop or laptop PC and the included Portable VK-2 digital imaging software lets you store, view and compare your images with ease.

Special features

- High resolution using the latest Nikon® cameras

- External digital camera back

- 20° fi eld by optical magnifi cation for enhanced detail of clinical features

- Fingertip control

- Connects to laptop or desktop PC

- Easy to use software

- Small pupil mode

- Software montage function for mosaic images

- Portable VK-2 imaging software included

Options

-

VK-2 high performance digital imaging software

Connect to Kowa VK-2 software for enhanced viewing and image manipulation see page 7

20° ONH image 45° overview

Approved by ENSPDR (English National Screening Programme for Diabetic Retinopathy) for diabetic retinopathy screening in the UK

Refraction 9 Retinal camera

Non-mydriatic

Retinal camera

Special function

Software

nonmyd

α-DIII

Non-mydriatic retinal

camera

Diagnostic Anterior

Quality imaging in an easy to use camera

The nonmyd

α-DIII is a compact digital fundus camera that continues the Kowa tradition of electronic imaging excellence. The lightweight construction and internal scientifi c 8 megapixel sensor produce a robust camera that combines advanced technology with modern design. Rapid capture of fundus images is easy with the simple controls that are conveniently located at your fi ngertips. Connect to a computer via a USB interface to store, view and compare images in the Portable VK-2 digital imaging software. Two fi xation modes enable the capture of 3 standard positions or an extended “mosaic” mode of 9 positions which can be merged into one panoramic image.

Special features

- Lightweight, compact design

- Integrated scientifi c 8 mp imaging sensor

- Easy to use controls at your fi ngertips

- 3 standard fi xation targets

- 9 targets for extended peripheral view

- Small pupil mode

- Software montage function for mosaic images

- Portable VK-2 imaging software included

Options

-

VK-2 high performance digital imaging software

Connect to Kowa VK-2 software for enhanced viewing and image manipulation see page 7

A panoramic image using the 9 fi xation positions and the montage function

10 Retinal camera

Non-mydriatic

Retinal camera

Special function

Software Refraction Diagnostic Anterior

VX-10i

Combined non-mydriatic and mydriatic retinal camera

A true partner in a clinical environment

The VX-10i offers non-mydriatic, mydriatic and FA modes with a 50° fi eld of view in full mydriatic mode. The optics are mounted on a swing arm to allow photography of the peripheral retina. SP mode allows both colour and FA photography in cases of insuffi cient mydriasis. Colour and FA images are captured using the latest Nikon® digital camera back. ICG capability can be easily added as an option to VX-10i which offers colour and FA as standard. Operation is simple, with controls designed for use in darkened rooms and with multiple step fl ash settings for correct exposure in all modes of operation.

Special features

- Mydriatic and non-mydriatic operation

- Colour and FA modes

- Clear viewfi nder

- Small pupil mode

- 50° and 30° views

- Optional ICG mode

- ICG observation using

LCD monitor

Options

-

VK-2 high performance digital imaging software

Connect to Kowa VK-2 software for enhanced viewing and image manipulation see page 7

ONH 30°

?

Colour 50° FAG 50°

11 Retinal camera

Non-mydriatic

Retinal camera

Special function

Software Refraction Diagnostic Anterior

VX-20

Combined non-mydriatic and mydriatic retinal camera

Clinical fundus imaging of your choice

Like the VX-10i, the VX-20 offers non-mydriatic, mydriatic and FA modes with 50° and 30° views. Additionally the VX-20 has an autofl uorescence mode to provide further diagnostic investigation of the health of the retina such as AMD. Linked to VK-2 software the

VX-20 provides outstanding options for fundus image analysis. With a built in PC and high resolution camera back, this fundus camera is a versatile diagnostic tool with stand-alone capability.

Special features

- Mydriatic and non-mydriatic operation

- Colour and FA modes

- Clear viewfi nder

- Small pupil mode

- 50° and 30° views

- Autofl uorescence mode

- Built in PC

Options

-

VK-2 high performance digital imaging software

Connect to Kowa VK-2 software for enhanced viewing and image manipulation see page 7

Colour 50°

?

FAG 50° FAF 50°

12 Retinal camera

Non-mydriatic

Retinal camera

Special function

Software

Genesis-D/Df

Hand-held retinal camera

Refraction Diagnostic Anterior

Quality and versatility; the choice in portable retinal photography

The Genesis-D series of colour mydriatic fundus cameras are portable, hand held retinal cameras that are ideal for domiciliary situations or where imaging using a conventional table-mounted camera is not possible. Designed for easy one-handed shooting, all the controls fall easily to hand and can be operated from both sides of the camera. An LCD monitor in the side of the camera allows review of the images whilst connectivity includes the Kowa VK-2 software as well as export of images in DICOM, JPG and BMP formats. The Genesis-

Df model also allows fl uorescein angiography and includes a timer display as well as easy switching of colour and FA modes.

Special features

- Takes photographs in any location and in any position

- Integrated 2 megapixel digital camera

- Easy 1-handed operation

- FA mode in Genesis-Df

Options

-

VK-2 high performance digital imaging software

Connect to Kowa VK-2 software for enhanced viewing and image manipulation see page 7

-

Indirect lens holder enables viewing of more peripheral areas of the retina

Anterior image Retinal image FAG Image

13 Retinal camera

Non-mydriatic

Retinal camera

Special function

Software Refraction Diagnostic Anterior

KA-1000 KW-2000

Autorefractor Combined autorefractor and keratometer

Quick and simple for accurate refraction

Kowa’s single footprint autorefractors offer quick and easy objective measurements of the refractive error of the eye and provide the data you need to assist with both spectacle and contact lens fi tting. The auto start function makes operation straightforward – just focus and measurement begins automatically. Interpretation of the results is simple with an on-screen readout display using coloured icons as well as a paper printout. Small pupils down to ø2.3mm can be measured and IOL implants considered. In addition, the

KW-2000 has the added function of keratometry with central measurement as well as the periphery in four directions.

Special features

KA-1000 and KW-2000

- Easy auto start operation

- Accurate results

- Colour display

- Paper printout

- Connectivity with third party electronic health records (EHR)

KW-2000

- Central keratometry readings

- Peripheral K-readings in 4 directions

- Refraction and central

K-readings in one measurement

On-screen display with coloured icons

Paper printout

14 Retinal camera

Non-mydriatic

Retinal camera

Special function

Software Refraction Diagnostic Anterior

AP-7000

NEW

Automated perimeter for both static and kinetic perimetry

Next generation perimeter with the gold standard threshold test

The AP-7000 is Kowa’s next generation automated perimeter that offers an extensive variety of test strategies and screening programmes. It provides reliable and consistent assessment results due to its normalised database. Full threshold modes offer macular, central and peripheral coverage up to 80° whilst screening modes provide swift evaluation of the visual fi eld for relative or absolute scotomas. To shorten test times quick modes are available for both threshold and screening modes. Furthermore, by automatically correlating the fundus image (from a fundus camera, OCT or SLO) with the static visual fi eld, early detection of glaucoma is possible.

With its ergonomic, compact design, the AP-7000 offers additional comfort to patients, easy operation for the clinician and fi ts perfectly within the practice.

Special features

- Easy touch screen operation

- Quick modes for threshold & screening programmes

- Extensive range of test & screening strategies, including blue/yellow test

- Kinetic perimetry

- Fixation control

- Automated correlation of fundus images with the static visual fi eld

- Chronological Analysis

- Advanced network connectivity

- Connectivity to third party electronic health records (EHR)

2

1

8

3

9

4

5

6

7

Clear, concise display of analytical results

4

5

6

2

3

7

8

9

1

Threshold

(measure values)

Grayscale

Total deviation

Pattern deviation

MD

PSD

Analytical indices

Bebie Curve

Gaze monitor

15 Retinal camera

Non-mydriatic

Retinal camera

Special function

Software Refraction Diagnostic Anterior

Seamless management of Glaucoma

Screening programmes for a swift check of the visual fi eld for abnormalities.

Kinetic perimetry is included as standard with multiple isopters.

Chronological change (graph).

Reports can provide an analysis of chronological change for a patient.

Fundus Image

Test results

VK-2 or Portable VK-2

Easy networking to other systems for data transfer and storage.

Correlate the fundus image (from a camera, OCT or SLO) with the static visual fi eld.

Key analytical indices

GHT (Glaucoma Hemifi eld Test)

GHT analyses the upper and lower hemisphere of the visual fi eld and provides a quick indication of possible glaucoma damage.

VFI (Visual Field Index)

VFI is the measurement of the visual fi eld status as a percentage of a normal age- adjusted visual fi eld in which a normal visual fi eld is 100% and total loss of fi eld is 0%.

Refraction Diagnostic 16 Retinal camera

Non-mydriatic

Retinal camera

Special function

Software

KT-800

Non-contact tonometer with 3D auto alignment

Anterior

Accurate eye tracking tonometer

The KT-800 is an accurate and easy to use non-contact tonometer. Auto alignment simply requires placing the positioning spot inside a circle on the monitor after which alignment up and down, right and left and forwards and backwards is automatic. The air puff is very gentle and feels “soft” to the patient. The pressure measurement range goes from 1 to 60mmHg without any range switching and the results are swiftly printed on paper. The chin rest height is electrically controlled using buttons close at hand. The instrument detects occasions when the eye is not open suffi ciently and prevents processing of the potentially inaccurate measurement.

Special features

- Simple to operate

- 3D auto alignment and eye tracking

- Accurate measurement

- Soft air puff

- Senses when eye is not open suffi ciently

- Easy paper replacement

- Electrically operated chin rest

3D auto alignment

is performed to guarantee precise measurement

Easy paper replacement

Pursued usability and fast printing

Refraction 17 Retinal camera

Non-mydriatic

Retinal camera

Special function

Software

HA-2

Hand-held applanation tonometer

Diagnostic Anterior

Gold standard tonometry in a portable package

The HA-2 applanation tonometer works on the Goldmann prism principle and uses industry standard tonometer probes or disposable heads. The internal spring mechanism allows accurate readings of intra-ocular pressure in any orientation, regardless of patient position or posture. The compact and lightweight design allows easy one-handed operation and the built in illumination enables use of the instrument regardless of the lighting conditions. The precision dial provides direct readings of the pressure. This instrument is ideal for domiciliary situations and as a back up tonometer and provides pressure readings using the gold standard applanation principle.

Special features

- Highly portable

- Can be used in any orientation

- Standard prism heads or disposable probes

- Lightweight and compact

- Easy, one-handed use

- Built in illumination

Options

- Adjustable headrest

· For ease of operation and

accurate positioning

- Interchangeable eyepiece

· For viewing from a distance

Long eye relief

for a more relaxed examination

18 Retinal camera

Non-mydriatic

Retinal camera

Special function

Software

FM-600

Laser fl are meter

Refraction Diagnostic Anterior

Reproducible and reliable guide to ocular infl ammation

The FM-600 laser fl are meter enhances the follow up of patients by enabling the in-vivo measurement of aqueous fl are in a non-contact, non-invasive and painless manner. The quantitative and reproducible measurement of aqueous fl are it provides is known to be useful in cases of uveitis and following IOL implantation, and increased levels of fl are have been reported with many other ocular conditions.

This latest generation of the Kowa laser fl are meter has been designed to combine the ultimate in effi ciency and accuracy with fast and easy operation in a compact and modern body.

Special features

- Easy operation and alignment using the LCD monitor

- Stand alone operation

- Utilises the principle of laser light scattering detection

- Quantitative protein measurement

- Reproducible results

- Results displayed numerically and graphically

- Enhances patient follow up

Graph results Numerical results

Refraction 19 Retinal camera

Non-mydriatic

Retinal camera

Special function

Software

SL-15

Hand-held portable slit lamp

Diagnostic Anterior

Compact and portable; slit lamp examinations wherever you go

The SL-15 is a compact and portable hand-held slit lamp that is ideal for the domiciliary environment. Offering cordless rechargeable operation, the large battery capacity provides long lasting continuous operation of the extra-bright halogen lamp. The lightweight design weighs less than 800g and provides easy and versatile operation with a choice of 10x and 16x magnifi cation, 3 slit widths plus spot illumination and a cobalt blue fi lter. The stand doubles as a charger and can accommodate both the main unit and a spare lithium ion battery simultaneously. The slit lamp supports digital or video cameras via the optional c-mount camera adaptor.

Special features

- Lightweight and easy to handle

- Cordless operation

- Rechargeable high capacity lithium ion battery

- 10x and 16x magnifi cation

- 3 slit widths

- Cobalt blue fi lter

- Extra bright halogen light source

Options

- C-mount adaptor

- Headrest

- Spare battery

- Carrying case

Video adaptor

Connect a digital or video camera using the optional c-mount adaptor

Headrest

The optional headrest can assist with stability during an examination

Worldwide network

Offi ces & factory

United Kingdom

Germany

France

Italy

Dubai

Beijing

Dalian

Shanghai

Hong Kong

Taipei

Mumbai

Bangkok

Tokyo

Hamamatsu

Nagoya

Osaka

Singapore

Jakarta

Los Angeles

New York

North Carolina

Alabama

Santiago

297 Yorktown Road

Sandhurst, Berkshire, GU47 0QA, UK

Phone: +44 (0) 1276 937021

Facsimile: +44 (0) 1276 937023

E-Mail: [email protected]

Web: www.kowaoptimed.com

Kowa Optimed Deutschland GmbH

Immermannstraße 43 B

40210 Düsseldorf, Germany

Phone: +49 (0) 211 179354 - 0

Facsimile: +49 (0) 211 161952

E-Mail: [email protected]

Web: www.kowa.eu

World Sales Headquarter

Kowa Co. Ltd.

4-14, Nihonbashi-honcho 3-chome,

Chuo-ku, Tokyo 103-8433 Japan

Phone: +81-3-3279-7331

Facsimile: +81-3-3279-7541

Web: www.kowa.co.jp

Hamamatsu Factory

3-1, Shinmiyakoda 1-chome, Kita-ku,

Hamamatsu City, Shizuoka Pref.,

431-2103 Japan

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
