Quality &
innovation thaT
inspires
Enjoy ice cold beverages, the perfectly chilled vintage, and crisp fruits and vegetables
bursting with flavor – all made possible with Perlick’s quality line of residential
undercounter refrigeration.
Featuring the most innovative products in the industry, Perlick makes it easier than ever
to add refrigeration to any room of the home – including the home bar, entertainment
room, kitchen, and outdoor living areas – no matter how much space you have.
For nearly 100 years, Perlick’s award-winning products have inspired our customers.
Get inspired. Choose Perlick.
HANDCRAFTED REFRIGERATION SINCE 1917 4 | WHAT MAKES IT A PERLICK
6 | REFRIGERATORS 8 | BEVERAGE CENTERS 10 | WINE RESERVES 12
| ACCESSORIES & MODEL NUMBERS 14
3
4
100 years
of excellence in refrigeration
The Perlick name is synonymous with innovation and unparalleled quality. We’ve made a name
for ourselves in refrigeration and beverage dispensing technology in bars, restaurants and
large sports venues around the world since opening our doors on Florida Street in Milwaukee,
Wisconsin, USA back in 1917. We’ve parlayed our expertise into a collection of premium, awardwinning undercounter refrigeration refined for the home.
5
Digital Temperature Control provides
Adjustable Cool Blue and Crisp White LED
Lighting illuminates product beautifully
what makes it a
Perlick
clear, accurate temperature readout
Perlick’s Front-vented, RAPIDcool™ forced-air refrigeration system continuously circulates cold air throughout the cabinet, providing
consistent temperature and eliminating cold spots
outdoors
indoors
There is a reason high-end showrooms proudly feature Perlick on their showfloors. It’s because
Perlick craftsmanship is second to none, because we build each and every cabinet by hand with
only the finest materials available. Read on to learn more about what makes it a Perlick.
All Perlick models can be used inside or outside
All Perlick Signature Series and Signature Sottile are rated for
both indoor and outdoor use
Full-extension pullout shelves are black vinyl-coated and are
adjustable anywhere in the cabinet. Shelves glide smoothly in and out
of the cabinet with ease thanks to stainless steel ball bearing glides. They
are engineered to allow for proper air flow throughout the entire cabinet which is something glass shelves cannot achieve
Stainless steel interiors provide the most santiary surface
available to keep food and beverages fresher – longer.
Two-inch thick foamed-in-place insulation provides industry
leading protection against warm temperatures and vibration
6
7
Signature Series Outdoor Refrigerator (shown)
refrigerators
8
Perlick offers the industry’s widest selection of undercounter
refrigerators, making it easier than ever to add fully
customizable refrigeration to any room of the home.
Solid Door
Glass Door
Drawers
Robust refrigeration system properly
chills room-temperature product
in just 30 minutes – far exceeding
the temperature pulldown of any
competitive models.
Signature sottile
Signature Series
AVAILABLE MODELS | Refrigerators
Solid Door
Glass Door
Glass doors feature Low E coated, Argon
filled dual-pane thermal glass to limit
energy transfer through glass and add
increased strength - indoors or outdoors.
9
(left to right) Signature Sottile Wine Reserve,
Sottile Beverage Center, and Sottile Refrigerator
beverage
centers
10
The practicality of a refrigerator meets the elegance of a
wine reserve in Perlick’s full line of beverage centers. Two full
extension wine racks keep wine bottles chilled on top, while
a refrigerator shelf accommodates goods below.
Solid Door
Glass Door
Signature sottile
Signature Series
AVAILABLE MODELS | Beverage Center
Robust refrigeration system properly
chills room-temperature product
in just 30 minutes – far exceeding
the temperature pulldown of any
competitive models.
Solid Door
Glass Door
Glass doors feature Low E coated, Argon
filled dual-pane thermal glass to limit
energy transfer through glass and add
increased strength - indoors or outdoors.
11
(left to right) Signature Series Wine Reserve
and Signature Series Beverage Center
Wine
Reserves
12
For the serious wine connoisseur, Perlick manufactures the
most well-built, skillfully designed wine storage in the world.
Perlick’s wine reserves are simply designed and built to store
vintages properly and beautifully.
Solid Door
Glass Door
Signature sottile
Signature Series
AVAILABLE MODELS | Wine Reserves
Solid Door
Glass Door
Capacity 40 wine bottles
Capacity 20 wine bottles
(on five shelves) + room on floor
(on four shelves) + room on floor
Industry exclusive black vinylcoated, full-extension adjustable
pullout shelves on stainless steel
ball bearing glides provide smooth
movement of shelves in and out of the
cabinet to reduce vibration
Perlick has storage options for up to 40
wine bottles in 18- and 24-inch depths.
13
customize your
perlick
Perlick offers the industry’s widest selection of premium
undercounter refrigeration for inside and outside the
home, and for that, we have a wide variety of accessory
items to create refrigeration that meets your every need
and desire.
Customized Storage to Fit Your Needs Perlick offers optional
RS-24-24M Shelf,
Martini Rack
RS-24-24DS Shelf,
Divider
RS-24-24WS Shelf, Wine
(stainless steel front)
accessory shelving to customize your refrigerated storage. Martini racks perfectly
chill glasses while leaving storage below for storing spirits. Divider shelves keep
cans in line, maximizing refrigerated storage in Signature Series cabinets. All Perlick
shelving is full-extension - pulling completely out of the cabinet to to make stocking
and retrievign product easy.
Personalize Storage with Accessory Hardware Rich
maple wine shelf fronts replace the standard stainless steel wine fronts to match
surrounding cabinetry.
67115-24 Wine Shelf,
Wood Faces (6)
66736 Signature
Series Casters
67439L/67439R Left (L) or
Right (R) Door Hinge Kit
Perlick also offers a variety of hardware accessories to further customize your cabinet.
Switch the door swing in the field with a hinge kit (a Industry Exclusive feature), add
casters for portability, or create custom column-style refrigeration with our exclusive
stacking kit – allowing you to mix and match pieces from the Perlick portfolio to
create modular refrigeration.
See page 18 for full list of available Perlick accessories
14
2
3
4
fully integrated drawers
stainless steel drawers
fully integrated glass door
stainless steel glass door
fully integrated solid door
solid stainless steel door
1
5
6
Door Styles for Every Design We love the look of stainless steel, but that doesn’t mean you have to. Perlick
offers a variety of door styles to accommodate any design. Choose from solid door, glass door or drawers in stainless steel
or ready to accept a custom panel to match surrounding cabinetry.
Each style door is signified by a specific number in the overall model number as shown above. For door styles 1-4, a ‘R’ or ‘L’
follows to signify right or left hinge. For example, an HHA24RO-3-4L is a fully integrated glass door, hinged left.
• Industry Exclusive convertible
door design allows all doors to be
converted to overlay from stainless
steel
• All doors are field reversible with
accessory hinge kit
• Template available to create a
matching overlay toe kick
15
Signature Series
Signature Series
REFRIGERATORS
Signature Series
WINE RESERVE
HPA24RO-3-1L
solid stainless steel door, hinge left
HPA24WO-3-1L
solid stainless steel door, hinge left
HPA24RO-3-1R
solid stainless steel door, hinge right
HPA24WO-3-1R
solid stainless steel door, hinge right
HPA24RO-3-2L
wood overlay steel door, hinge left
HPA24WO-3-2L
solid wood overlay door, hinge left
HPA24RO-3-2R
wood overlay steel door, hinge right
HPA24WO-3-2R
solid wood overlay door, hinge right
HPA24RO-3-3L
stainless steel glass door, hinge left
HPA24WO-3-3L
stainless steel glass door, hinge left
HPA24RO-3-3R
stainless steel glass door, hinge right
HPA24WO-3-3R
stainless steel glass door, hinge right
HPA24RO-3-4L
wood overlay glass door, hinge left
HPA24WO-3-4L
wood overlay glass door, hinge left
HPA24RO-3-4R
wood overlay glass door, hinge right
HPA24WO-3-4R
wood overlay glass door, hinge right
HPA24RO-3-5
stainless steel drawers
HPA24RO-3-6
wood overlay drawers
Signature Series
BEVERAGE CENTER
16
HPA24BO-3-1L
solid stainless steel door, hinge left
HPA24BO-3-1R
solid stainless steel door, hinge right
HPA24BO-3-2L
solid wood overlay door, hinge left
HPA24BO-3-2R
solid wood overlay door, hinge right
HPA24BO-3-3L
stainless steel glass door, hinge left
HPA24BO-3-3R
stainless steel glass door, hinge right
HPA24BO-3-4L
wood overlay glass door, hinge left
HPA24BO-3-4R
wood overlay glass door, hinge right
Signature Sottile
Signature SOTTILE
REFRIGERATORS
Signature SOTTILE
WINE RESERVES
HHA24RO-3-1L
solid stainless steel door, hinge left
HHA24WO-3-1L solid stainless steel door, hinge left
HHA24RO-3-1R
solid stainless steel door, hinge right
HHA24WO-3-1R solid stainless steel door, hinge right
HHA24RO-3-2L
solid wood overlay door, hinge left
HHA24WO-3-2L solid wood overlay door, hinge left
HHA24RO-3-2R
solid wood overlay door, hinge right
HHA24WO-3-2R solid wood overlay door, hinge right
HHA24RO-3-3L
stainless steel glass door, hinge left
HHA24WO-3-3L stainless steel glass door, hinge left
HHA24RO-3-3R
stainless steel glass door, hinge right
HHA24WO-3-3R stainless steel glass door, hinge right
HHA24RO-3-4L
wood overlay glass door, hinge left
HHA24WO-3-4L wood overlay glass door, hinge left
HHA24RO-3-4R
wood overlay glass door, hinge right
HHA24WO-3-4R wood overlay glass door, hinge right
Signature SOTTILE
beverage centers
HHA24BO-3-1L
solid stainless steel door, hinge left
HHA24BO-3-1R
solid stainless steel door, hinge right
HHA24BO-3-2L
solid wood overlay door, hinge left
HHA24BO-3-2R
solid wood overlay door, hinge right
HHA24BO-3-3L
stainless steel glass door, hinge left
HHA24BO-3-3R
stainless steel glass door, hinge right
HHA24BO-3-4L
wood overlay glass door, hinge left
HHA24BO-3-4R
wood overlay glass door, hinge right
17
Accessories
displays/wOOD fronts
for wine reserves
67115-24
Wine Shelf Wood Faces (pack/6)
misc. hardware
& accessory kits
67439L
Door Hinge Kit, Left
67439R
Door Hinge Kit, Right
67360
6”Toe Kick and Riser, Sottile Series
full extension shelves
66736
Casters, Signature Series
RS-24-24R
Shelf, Refrigerator, Signature Series
67991-L
Stacking Kit for HPA24 models, left hinge
RS-24-24WS
Shelf, Wine, Signature Series
67991-R
Stacking Kit for HPA24 models, right hinge
RS-24-24M
Shelf, Martini Rack, Signature Series
67992-L
Stacking Kit for HHA24 models, left hinge
RS-24-24DS
Shelf, Divider Shelf, Signature Series
67992-R
Stacking Kit for HHA24 models, right hinge
RS-18-18R
Shelf, Refrigerator, Signature Sottile
67964
RS-18-18W
Shelf, Wine, Signature Sottile
Signature Stainless Steel Drawer Dividers
(pack/3)
handles door/drawer
18
65305-1
Door Handle, Signature Series only
65305-5
Drawer Handles, Signature Series
only (set/2)
67941-1
Designer Door Handle, Signature
Series only
67941-2
Designer Drawer Handles,
Signature Series only (set/2)
Martini Rack
Wood Wine Fronts
Divider Shelf
Stacking Kit
(creates a flush finish from top to bottom)
(shown installed)
Designer Door Handle
19
Signature Series
Dwg\95000\95005.slddrw
20
50" 1270 Area in which
electrical outlet must be located
7916" 192
Signature Series HP24 Models
Power cord 6-5/8" [168] off floor. *
1
6 4" 159
3
1 3/8" 32 Min.
clearance from
a corner to
acheive 90
door swing.
*
- Leg levelers can add
3/4" [19] to these dimensions
when fully extended.
90° Swing
required for
pull-out shelf
clearance.
2378" 606
158" 42
18 16" 461
7
11 8" 302
20" 508
2138" 543
241516" 634
Min clearance
for door swing.
11516" 49
26916" 674
3
1 8" 35
Value may
change with a
custom pull.
24" 611
(with 1/16" tolerance)
Values may change
with a wood overlay door.
18316" 461
5
1 8" 42
2138" 543
2" 50
Shelf
adjustability.
26916" 674
*34516" 872
312" 89
312" 89
*31516" 100
PERLICK CORPORATION
MILWAUKEE, WI 53223
PROPERTY OF THE PERLICK CORP.
NOT TO BE COPIED OR USED DETRIMENTAL TO OUR INTERESTS
1178" 302
614" 159
414" 108
Lowest
shelf location.
SCALE:
DR.:
PRINTED
6/9/2015
1:10
DAS DATE:
9/30/09
95005
SHEET 1 OF 3
6/9/2015 1:39 PM
Signature SottileHH24RS/RO GEN3 CUTSHEET DIMENSIONS
50" 1270 Area in which
electrical oulet must be located
2 5/8" 67
*Power cord 2 3/16" [56] off floor.
4 3/4" 121
7 7/16" 189
1 1/4" 32 Min.
clearance from
a corner to
acheive 90
door swing
90° Swing
required for
pull-out shelf
clearance
12 3/16" 309
* - Leg levelers can add
3/4" [19] to these dimensions
when fully extended.
24 15/16" 634
Min. clearance
for door swing
18" 457
( 1/16" tolerance)
Value may
change with a
wood overlay door
1 3/8" 35
Value may
change due to
a custom pull
23 7/8" 606
20" 508
12 3/16" 309
1 1/8" 29
shelf
adjustability
6 5/16" 161
22 5/8" 575
19 1/8" 486
*32 1/16" 814
10 3/4" 274
3 1/2" 89
*4" 101
7 7/16" 189
4 3/4" 121
21
ADDED METRIC DIMS.
B 5/28/2015
RELEASE FOR PRODUCTION
JMP
SCALE
1:14
8300 West Good Hope Road
Milwaukee, WI 53223
United States of America
phone 800.558.5592
web perlick.com/residential-products
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
