Digital Rebel XT
Type
Type
Digital AF/AE SLR
Recording
Medium
CF card Type I and II
Image Format
0.87 x 0.58 in./22.2 x 14.8mm
Compatible
Lenses
Canon EF Lenses including EF-S Lenses (Focal length conversion factor: Equivalent
to approx. 1.6x indicated focal length compared to 35mm format)
Lens Mount
Canon EF mount
View Similar Models
Image Sensor
Type
High-sensitivity, high-resolution, single-plate color CMOS sensor
Pixels
Approx. 8.0 Megapixels
Total Pixels
Approx. 8.2 Megapixels
Aspect Ratio
2:3 (Vertical:Horizontal)
Color Filter
System
RGB primary color filter
Low-pass
Filter
Fixed position in front of the image sensor
Recording System
Recording
Format
Design rule for Camera File System 2.0
Image Format
JPEG, RAW (12bit)
Simultaneous Recording: Possible
File Size
JPEG: (1) Large/Fine: Approx. 3.3 MB (3456 x 2304), (2) Large/Normal: Approx. 1.7
MB (3456 x 2304), (3) Medium/Fine: Approx. 2.0 MB (2496 x 1664), (4)
Medium/Normal Approx. 1.0 MB (2496 x 1664), (5) Small/Fine: Approx. 1.2 MB (1728 x
1152), (6) Small/Normal: Approx. 0.6 MB (1728 x 1152); RAW: Approx. 8.3 MB (3456 x
2304)
Folders
Automatic setting
File
Numbering
(1) Continuous numbering, (2) Auto reset
Imageprocessing
Parameters
Standard parameters plus up to three custom processing parameter sets and
monochrome can be set
Interface
USB 2.0 Hi-Speed
White Balance
Settings
Auto, Preset (Daylight, Shade, Cloudy/Twilight/Sunset, Tungsten light, White
fluorescent light, Flash), Manual (Custom: read off photo quality gray card or white
subject)
New Eight Megapixel EOS
Digital Rebel XT SLR
Viewfinder
Type
Eye-level SLR (with fixed pentamirror)
Coverage
Approx. 95% vertically and horizontally (against JPEG Large)
Magnification
0.8x (-1 diopter with 50mm lens at infinity)
Eyepoint
21mm
Dioptric
Adjustment
Correction
-3.0 - +1.0 diopters
Focusing
Screen
Fixed
Mirror
Quick-return half mirror (Transmittance: reflection ratio of 40:60, no mirror cut-off with
lenses up to EF 600mm f/4)
Viewfinder
Information
AF points, AE lock, FE lock, AEB in progress, Flash ready, Improper FE lock warning,
High-speed Sync, Flash exposure compensation, Red-Eye reduction, Shutter speed,
Bulb, FE lock, Processing data, Built -in flash recycling, Aperture, Exposure level
display (Exposure compensation, Manual exposure level, AEB level, Flash exposure
compensation, Red-Eye Reduction lamp on time display), Max burst during continuous
shooting, AF/MF focus confirmation, CF card full, CF card error, no CF card
Depth-of-Field Enabled with depth-of-field preview button
Preview
Eyepiece
Shutter
None (provided on strap)
Autofocus
Type
TTL-CT-SIR with AF-dedicated CMOS sensor
AF Points
7
AF Working
Range
EV 0.5 - 18 (at ISO 100)
Focusing
Modes
One-Shot AF, Predictive AI Servo AF, AI Focus AF (Automatically selects One-Shot
AF or AI Servo AF selected according to shooting mode), Manual Focusing (MF)
AF Point
Selection
Automatic selection, manual selection
Selected AF
Point Display
Superimposed in viewfinder and indicated on LCD panel
AF-assist
Beam
Intermittent firing of built-in flash, effective range: approx. 13.1 ft./4m at center,
approx. 11.5 ft./3.5m at periphery
Exposure Control
Metering
Modes
Max. aperture TTL metering with 35-zone SPC. (1) Evaluative metering, (2) Partial
metering at center (approx. 9% of viewfinder), (3) Center-weighted average metering
Metering
Range
EV 1-20 (at 68° F/20° C with 50mm f/1.4 lens at ISO 100)
Exposure
Control
Systems
Program AE (shiftable), Shutter-priority AE, Aperture-priority AE, Automatic Depth-of
Field AE, Full Auto, Programmed Image Control modes (Portrait, Landscape, Closeup, Sports, Night Portrait, Flash Off), E-TTL II Autoflash Program AE, and Manual
ISO Speed
Range
Equivalent to ISO 100-1600
Exposure
Up to +/ -2 stops in 1/2- or 1/3-stop increments (1) Manual exposure compensation (2)
Compensation AEB (Auto Exposure Bracketing)
AE Lock
Auto: Operates in One-Shot AF mode evaluative metering when focus is achieved;
Manual: Enabled with AE lock button (No AE lock in Basic Zone modes)
Shutter
Type
Vertical-travel, mechanical, focal-plane shutter with all speeds electronically-controlled
Shutter
Speeds
1/4000 to 30 sec. in 1/2- or 1/3-stop increments, bulb, X-Sync at 1/200 sec.
Shutter
Release
Soft-touch electromagnetic release
Noise
Reduction for
Long
Exposure
Set with C. Fn-02
Self-timer
10-sec. delay
Remote
Control
Remote control with RS-60E3 Terminal or Wireless remote controllers RC-1/RC-5
Built-in Flash
Type
Auto pop-up, retractable, built-in flash in the pentaprism
Guide Number 13 (at ISO 100 in meters)
Recycling
Time
Approx. 3 sec.
Flash-ready
Indicator
Flash-ready indicator lights on in viewfinder
Flash
Coverage
Up to 17mm focal length (equivalent to 27mm in 35mm format)
External Speedlite
EOS External
Flash or
Dedicated
Speedlites
E-TTL II autoflash
Drive System
Drive Modes
(1) Single, (2) Continuous, (3) Self -timer/Remote Control
Continuous
Shooting
Speed
Approx. 3.0 fps (with Battery Pack NB-2LH, at Tv=1/250 sec. for all recording
qualities)
Max. Burst
During
Continuous
Shooting
14 shots (Large/Fine)
LCD Monitor
Type
TFT color LCD monitor
Screen
Monitor size
1.8 inches
Pixels
Approx. 115,000 pixels (Displayed pixels)
Coverage
Approx. 100% (for JPEG images)
Brightness
Control
5 levels (settable with menu's "LCD brightness")
Playback
Image Display (1) Single image, (2) 9-image Index, (3) Magnified Zoom, (4) Auto Play, (5) Auto Play
Format
right after shooting
Highlight
In the single image with information display mode, the highlighted portions containing
Alert
no image information with blink
Image Protection and Erase
Protection
A single image can be protected or unprotected
Erase
A single image or all images stored in a CompactFlash card can be erased if they are
unprotected
Menus
Menu
Categories
(1) Shooting 1 [6 items], (2) Shooting 2 [7 items], (3) Playback [5 items], (4) Setup 1 [7
items], (5) Setup 2 [7 items]
LCD Monitor
Language
Any of the following 15 languages can be selected: English, German, French, Dutch,
Danish, Italian, Finnish, Norwegian, Swedish, Spanish, Simplified/Traditional Chinese,
Korean, Russian, and Japanese
Firmware
Update
Enabled by the user
Power Source
Battery
Battery Pack NB-2LH (x1)
Dimensions and Weight
Dimensions
(W x H x D)
4.98 x 3.71 x 2.63 in./126.5 x 94.2 x 64mm
Weight
17.1 oz./485g
Operating Environment
Operating
Temperature
Range
32-104° F/0-40° C
Operating
Humidity
Range
85% or less
