Product Specification
Product Specification
i
i
Crypto M.2 SATA 6Gbps 22x60
Full Disk Encryption
AES 256-bit
Epoxy Resin
128
GB
INTRODUCTION
The most secure next generation form factor encrypted
SSD available.
If an ultrabook or laptop with an Integral Crypto M.2
SSD installed is lost or stolen, sensitive data is secure
and cannot be accessed without the high-strength
password. When the system is shut down, 256-bit full
disk encryption is instigated.
256
GB
512
GB
Security Features
–– Total Drive Encryption - All data stored on the Crypto M.2
SSD is encrypted (including the Operating System).
–– Dual Password - As an option an Administrator can setup
a user password and a master override password. If the user
forgets their password, the Crypto M.2 SSD can be unlocked
by the Administrator and the user password reset.
Crypto M.2 SSD is the no-fuss and highly-secure solid
state encryption solution for many industries including;
finance, legal, health, education and government.
–– Secure Entry - Encrypted data cannot be accessed without
the correct high-strength 8-16 character alphanumeric
password. An optional password hint can be set-up which
cannot be the same as the password. Before use a highstrength password must be set.
M.2 SATA SSD storage solutions are designed for
Notebooks, Desktops, Ultrabooks and tablets. They
address the need for more low powered compact
storage without compromising performance and
reliability of solid state drives.
–– Brute-Force Password Attack Protection - Encrypted data
is automatically erased after the default 6 failed password
attempts (password attempts configurable to a maximum of
20). The data and encryption key are securely destroyed and
the Crypto M.2 SSD is reset and can then be reused.
FEATURES
• Military level security with AES 256-bit hardware
encryption - More secure than a software-only solution.
• FIPS 140-2 Validated - Certificate No. 2126
• M.2 2260 form factor with SATA III 6Gbps interface (backwards
compatible with SATA 3Gbps and SATA 1.5Gbps)
• Supports ‘M’ & ‘B’ Key sockets
• Performance: Faster boot than HDD, Faster access to
applications, enhanced productivity and increased efficiency
• Fully compatible with devices and OS that support the SATA
standard with M.2 M and B connectors
• Multi-lingual interface – in 14 languages*
–– Anti-Clone - Crypto M.2 SSD cannot be cloned once
encryption is set.
–– Tamper-Proof Design - The electronics are sealed in tamperproof epoxy resin.
• High-speed Read/Write – The Crypto M.2 SSD has both high
encryption and the main benefit of a performance SSD; a highspeed sustained data transfer rate.
• Quick Boot - Using a Crypto M.2 SSD in place of a traditional
HDD can cut your ultrabook or laptop’s boot time in half.
• No moving parts - greater resistance to shock and vibration
• Noise free - no spin or seek time
• Endpoint security software compatible – The Integral
Crypto M.2 SSD operates comfortably with endpoint security
solutions by using the configurable unique ID feature, which is
part of the setup program
• Warranty – 3 Years
Rev:1
Product Specification
i
Technical Features
APPROVED SECURITY FUNCTION
• MLC-NAND Flash Technology
• Compatible with Windows XP, Vista, 7 and 8
PERFORMANCE
128GB
256GB
512GB
i
CERTIFICATE
AES (H/W implementation)
• CBC (enc/dec; 256)
2175
XTS 128, XTS 256
2175
HMAC 512 HMAC 256
1335
DRBG
254
SHA 512 SHA 256
1887
Read
450MB/s (up to)*
Write
200MB/s (up to)*
Read
450MB/s (up to)*
Write
350MB/s (up to)*
Read
450MB/s (up to)*
–– Arabic
–– Italian
Write
350MB/s (up to)*
–– Chinese
–– Norwegian
–– Dutch
–– Polish
–– English
–– Portuguese
INTERFACE
*14 languages supported by the software GUI -
Interface
SATA III 6Gbps
Also Compatible with SATA II
3Gbps and SATA 1.5Gbps
–– French
–– Russian
NAND
MLC
–– German
–– Spanish
Form Factor
M.2 22x60 ‘M’ & ‘B’ Key connector
M.2 (previously known as Next
Generation Form Factor (NGFF))
–– Hindi
–– Swedish
Standard
*Based on internal testing
RELIABILITY
MTTF
2,000,000 hours
ECC algorithm
24 9-bit Symbols Correction per
512 9-bit Symbol
POWER CONSUMPTION
Supply Voltage
Power Consumption (mW)
128GB
INSSD128GM2M2260C140
5055288428270
256GB
INSSD256GM2M2260C140
5055288428287
512GB
INSSD512GM2M2260C140
5055288428294
Please Note: No security software can be guaranteed 100% secure.
Read : 128G = 1565 / 256G =
1630 / 512G = 1730
Write : 128G = 1620 / 256G =
1850 / 512G = 2250
This device should not be used as your sole backup.
Idle = 250
For warranty information please visit www.integralmemory.com/warranty
Yes
Yes (OS support required)
ECC algorithm
Supports 72bit ECC correct per
1K Byte
MTBF
>1 Million Hours
Compliancy
CE, FCC, RoHS
ENVIRONMENTAL
Operating Temp
0° - +70°C
Non - Operating Temp
-40° - +85°C
Humidity
RH 90% under 40C in operation
Vibration
80Hz~2000Hz / 20G
PHYSICAL
Length
60mm
Width
22mm
Height
3.8mm
Weight
8g
Length (Packed)
115mm
Width (Packed)
132mm
Height (Packed)
57mm
Weight (Packed)
77g
Rev:1
BARCODE (EAN)
1GB = 1,000,000,000 bytes. Formatted capacity is less.
Supports TRIM
3 years
PART CODE
3.3V
Supports SMART Software
WARRANTY
CAPACITY
Product design and specification subject to change or modification without notice. E&OE.
All trademarks acknowledged.
For products with security software or hardware; the product cannot be guaranteed to be fully
secure. No security system can be considered absolute.
Product Specification
i
Rev:1
i
